milling
INNOVATIVE COMBINATIONS - UNPRECEDENTED VERSATILITY
• Insert sizes of 5, 11 and 13mm offer new combinations of diameters, densities and lengths-of-cut.
• Starting in diameters as small as .500”!
• Dovetailed insert mounting for increased edge-life and improved cutter reliability
• High performance, ground-profile inserts are shaped to minimize lap-lines when shouldering, available in both heavy and light geometries
• Economical utility inserts for situations not requiring the performance benefits of ground-profile inserts
• MaxSFeed is capable of ramping and spiral interpolation!
OAL
LPR
LUX
DC DCON
.16APMX
90°KAPR
WEP WEP - See insert drawing for wiper options.
90º END MILL (5MM INSERT)
1EJ5A-05009S4R01 0.500 0.800 1.000 2.780 2 0.500 1.60
1EJ5A-05009S4R02 0.500 0.800 1.000 2.780 3 0.500 1.60
1EJ5A-07015S7R01 0.750 1.300 1.500 3.500 3 0.750 0.97
1EJ5A-07015S7R02 0.750 1.300 1.500 3.500 4 0.750 0.97
1EJ5A-10015S1R01 1.000 1.300 1.500 3.750 5 1.000 0.69
1EJ5A-10015S1R02 1.000 1.300 1.500 3.750 6 1.000 0.69
Part Number DC
Cutting
Dia.
LUX
Usable Length
Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Shank
Dia.
RMPX
Ramp Angle
Max.
SERIES 1EJ5A (CYLINDRICAL SHANK)
05
LF CCMS
DC
DHUB
.16APMX
90°KAPR
WEP
WEP - See insert drawing for wiper options.
90º END MILL (5MM INSERT)
1EJ5A-05006T8R01 0.500 0.65 2 ChipSurfer T08 0.485 1.60
1EJ5A-05006T8R02 0.500 0.65 3 ChipSurfer T08 0.485 1.60
1EJ5A-07010TSR01 0.750 1.00 3 ChipSurfer T12 0.725 0.97
1EJ5A-07010TSR02 0.750 1.00 4 ChipSurfer T12 0.725 0.97
Part Number DC
Cutting
Dia.
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection Code
Machine Side
DHUB
Hub
Dia.
RMPX
Ramp Angle
Max.
SERIES 1EJ5A (CHIP•SURFER STYLE)
05
Pocket Corkscrew CoolantFacing RampChannelingShoulder
Pocket Corkscrew Coolant
Facing RampChannelingShoulder
4
LF CCMS
DC
DHUB
WEP
WEP - See insert drawing for wiper options.
.16APMX
90°KAPR
90º END MILL (5MM INSERT)
1EJ5A-05010X4R01 0.500 1.00 2 TopOn 6mm 0.465 1.60
1EJ5A-05010X4R02 0.500 1.00 3 TopOn 6mm 0.465 1.60
1EJ5A-07015X6R01 0.750 1.50 3 TopOn 10mm 0.700 0.97
1EJ5A-07015X6R02 0.750 1.50 4 TopOn 10mm 0.700 0.97
1EJ5A-10015X7R01 1.000 1.50 5 TopOn 12mm 0.820 0.70
1EJ5A-10015X7R02 1.000 1.50 6 TopOn 12mm 0.820 0.70
Part Number DC
Cutting
Dia.
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection Code
Machine Side
DHUB
Hub
Dia.
RMPX
Ramp Angle
Max.
SERIES 1EJ5A (TOP•ON STYLE)
05
INSERTS
05
W1 S1
BS RE
INSL
CGM101R001-ML
Part Number Application RE
Corner
Radius
BS
Wiper
Length
INSL
Insert
Length
W1
Insert
Width
S1
Thickness
Grade
IN2510
IN2530
CGM101R001-ML General Purpose 0.015 0.030 0.240 0.200 0.200 • •
CGX101R001-ML Utility 0.015 0.030 0.240 0.200 0.200 • •
05 Cutters DS-TP06S-NEU SM18-041-00
Driver Screw
HARDWARE
05
ML
Pocket Corkscrew CoolantFacing RampChannelingShoulder
5
milling
OAL
LPR
LUX
DC DCON
.38APMX
90°KAPR
WEP
WEP - See insert drawing for wiper options.
1EJ5C-1001780R01 1.000 1.550 1.750 4.000 2 1.000 1.99
1EJ5C-1001784R01 1.000 1.750 1.750 3.750 2 0.750 1.99
1EJ5C-1003780R01 1.000 3.550 3.750 6.000 2 1.000 1.99
1EJ5C-1201780R01 1.250 1.750 1.750 4.000 3 1.000 1.41
1EJ5C-1201781R01 1.250 1.550 1.750 4.000 3 1.250 1.41
1EJ5C-1204281R01 1.250 4.050 4.250 6.500 3 1.250 1.41
1EJ5C-1501781R01 1.500 1.550 1.750 4.000 4 1.250 1.08
1EJ5C-1501781R02 1.500 1.550 1.750 4.000 3 1.250 1.08
1EJ5C-1504281R02 1.500 4.050 4.250 6.500 3 1.250 1.08
Part Number DC
Cutting
Dia.
LUX
Usable Length
Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Shank
Dia.
RMPX
Ramp Angle
Max.
SERIES 1EJ5C (WELDON SHANK)
11
LF CCMS
DC
DHUB
.38APMX
90°KAPR
WEP
WEP - See insert drawing for wiper options.
1EJ5C-10015X7R01 1.000 1.500 2 TopOn 12mm 0.820 1.99
1EJ5C-12017X8R01 1.250 1.750 3 TopOn 16mm 1.135 1.41
Part Number DC
Cutting
Dia.
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection Code
Machine Side
DHUB
Hub
Dia.
RMPX
Ramp Angle
Max.
SERIES 1EJ5C (TOP•ON STYLE)
11
90º END MILL (11MM INSERT)
90º END MILL (11MM INSERT)
Pocket Corkscrew Coolant
Facing RampChannelingShoulder
Pocket Corkscrew CoolantFacing RampChannelingShoulder
6
WEP - See insert drawing for wiper options.
DCON
KWW
OAL
DC
.38APMX
90°KAPR WEP
EJ5C-01R01 1.500 1.570 5 0.500 0.250 1.08
EJ6C-01R01 1.500 1.570 4 0.500 0.250 1.08
EJ5C-02R01 2.000 1.570 6 0.750 0.312 0.76
EJ6C-02R01 2.000 1.570 5 0.750 0.312 0.76
EJ5C-02R02 2.500 1.570 7 0.750 0.312 0.58
EJ6C-02R02 2.500 1.570 6 0.750 0.312 0.58
EJ5C-03R01 3.000 2.375 9 1.000 0.375 0.47
EJ6C-03R01 3.000 2.375 7 1.000 0.375 0.47
EJ5C-04R01 4.000 2.375 13 1.500 0.625 0.34
EJ6C-04R01 4.000 2.375 9 1.500 0.625 0.34
Part Number DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Bore
Dia.
KWW
Keyway
RMPX
Ramp Angle
Max.
SERIES EJ5C, EJ6C
11
INSERTS
11
W1 S1
BS RE
INSL
CGM313R00_-ML
W1 S1
BS RE
INSL
CGM313R00_-M
Part Number Application RE
Corner
Radius
BS
Wiper
Length
INSL
Insert
Length
W1
Insert
Width
S1
Thickness
Grade
IN4015
IN2515
IN4005
IN2505
IN4030
IN2530
IN15K
CGM313R001-M General Purpose 0.031 0.093 0.433 0.436 0.236 • • • • • •
CGM313R001-ML General Purpose 0.031 0.093 0.433 0.436 0.236 • • • • • •
CGM313R001-MLP Grd/Pol for Alumimum 0.031 0.093 0.433 0.436 0.236 •
CGM313R002-M General Purpose 0.062 0.062 0.433 0.436 0.236 • • • • • •
CGM313R002-ML General Purpose 0.062 0.062 0.433 0.436 0.236 • • • • • •
CGX313R001-M Utility 0.031 0.093 0.433 0.436 0.236 • • • • • •
CGX312R002-M Utility 0.062 0.062 0.433 0.436 0.236 • • • • • •
ML
M
90º FACE MILL (11MM INSERT)
Pocket Corkscrew Coolant
Facing RampChannelingShoulder
7
milling
HARDWARE
11
1EJ5C-1001780R01 DS-A00T DS-T156B SM35-095-H0 - DS-A00-.25-T DT-35-.25 DS-T15B
1EJ5C-1001784R01 DS-A00T DS-T156B SM35-095-H0 -DS-A00-.25-T DT-35-.25 DS-T15B
1EJ5C-1003780R01 DS-A00T DS-T156B SM35-095-H0 -DS-A00-.25-T DT-35-.25 DS-T15B
1EJ5C-1201780R01 DS-A00T DS-T156B SM35-107-H0 -DS-A00-.25-T DT-35-.25 DS-T15B
1EJ5C-1201781R01 DS-A00T DS-T156B SM35-107-H0 -DS-A00-.25-T DT-35-.25 DS-T15B
1EJ5C-1204281R01 DS-A00T DS-T156B SM35-107-H0 -DS-A00-.25-T DT-35-.25 DS-T15B
1EJ5C-1501781R01 DS-A00T DS-T156B SM35-107-H0 -DS-A00-.25-T DT-35-.25 DS-T15B
1EJ5C-1501781R02 DS-A00T DS-T156B SM35-107-H0 -DS-A00-.25-T DT-35-.25 DS-T15B
1EJ5C-1504281R02 DS-A00T DS-T156B SM35-107-H0 -DS-A00-.25-T DT-35-.25 DS-T15B
1EJ5C-10015X7R01 DS-A00T DS-T156B SM35-095-H0 -DS-A00-.25-T DT-35-.25 DS-T15B
1EJ5C-12017X8R01 DS-A00T DS-T156B SM35-107-H0 -DS-A00-.25-T DT-35-.25 DS-T15B
EJ5C-01R01 DS-A00T DS-T156B SM35-107-H0 SD04-47 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6C-01R01 DS-A00T DS-T156B SM35-107-H0 SD04-47 DS-A00-.25-T DT-35-.25 DS-T15B
EJ5C-02R01 DS-A00T DS-T156B SM35-107-H0 SD06-47 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6C-02R01 DS-A00T DS-T156B SM35-107-H0 SD06-47 DS-A00-.25-T DT-35-.25 DS-T15B
EJ5C-02R02 DS-A00T DS-T156B SM35-107-H0 SD06-47 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6C-02R02 DS-A00T DS-T156B SM35-107-H0 SD06-47 DS-A00-.25-T DT-35-.25 DS-T15B
EJ5C-03R01 DS-A00T DS-T156B SM35-107-H0 SD08-43 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6C-03R01 DS-A00T DS-T156B SM35-107-H0 SD08-43 DS-A00-.25-T DT-35-.25 DS-T15B
EJ5C-04R01 DS-A00T DS-T156B SM35-107-H0 SD12-89 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6C-04R01 DS-A00T DS-T156B SM35-107-H0 SD12-89 DS-A00-.25-T DT-35-.25 DS-T15B
Driver BitDriver Handle Insert Screw Retention Bolt Torque Driver Handle Preset Torque Bit Torque Driver Bit
**OPTIONAL** **OPTIONAL****OPTIONAL**
Insert screw tightening torque: 35 in*lb.
8
WEP
WEP - See insert drawing for wiper options.
DCON
KWW
OAL
DC
.48APMX
90°KAPR
EJ5D-02R01 2.000 1.570 5 0.750 0.312 0.98
EJ6D-02R01 2.000 1.570 4 0.750 0.312 0.98
EJ5D-02R02 2.500 1.570 6 0.750 0.312 0.75
EJ5D-02R03 2.500 1.570 6 1.000 0.375 0.75
EJ6D-02R02 2.500 1.570 5 0.750 0.312 0.75
EJ5D-03R01 3.000 2.000 7 1.000 0.375 0.60
EJ6D-03R01 3.000 2.000 5 1.000 0.375 0.60
EJ5D-04R01 4.000 2.375 9 1.500 0.625 0.44
EJ6D-04R01 4.000 2.375 7 1.250 0.500 0.44
EJ6D-04R02 4.000 2.375 7 1.500 0.625 0.44
EJ6D-05R01 5.000 2.500 11 1.500 0.625 0.34
EJ6D-06R01 6.000 2.500 13 1.500 0.625 0.28
Part Number DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Bore
Dia.
KWW
Keyway
RMPX
Ramp Angle
Max.
SERIES EJ5D, EJ6D
13
INSERTS
13
W1 S1
BS RE
INSL
CGM324R00_-ML
W1 S1
BS RE
INSL
CGM324R00_-M
Part Number Application RE
Corner
Radius
BS
Wiper
Length
INSL
Insert
Length
W1
Insert
Width
S1
Thickness
Grade
IN4015
IN2515
IN4005
IN2505
IN4030
IN2530
IN4035
IN2535
CGM324R001-M General Purpose 0.031 0.093 0.531 0.518 0.281 • • • • • •
CGM324R001-ML General Purpose 0.031 0.093 0.531 0.518 0.281 • • • • • • • •
CGM324R002-M General Purpose 0.062 0.069 0.531 0.518 0.281 • • • • • •
CGM324R002-ML General Purpose 0.062 0.069 0.531 0.518 0.281 • • • • • • • •
CGM324R004-M General Purpose 0.125 0.016 0.531 0.518 0.281 • • • • • •
CGM324R004-ML General Purpose 0.125 0.016 0.531 0.518 0.281 • • • • • • • •
CGX324R001-M Utility 0.031 0.093 0.531 0.518 0.281 • • • • • •
CGX324R002-M Utility 0.062 0.069 0.531 0.518 0.281 • • • • • •
CGX324R004-M Utility 0.125 0.016 0.531 0.518 0.281 • • • • • •
ML
M
90º FACE MILL (13MM INSERT)
Pocket Corkscrew CoolantFacing RampChannelingShoulder
9
milling
HARDWARE
13
EJ5D-02R01 DS-A00T DS-T156B SM40-123-H0 SD06-47 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6D-02R01 DS-A00T DS-T156B SM40-123-H0 SD06-47 DS-A00-.25-T DT-35-.25 DS-T15B
EJ5D-02R02 DS-A00T DS-T156B SM40-123-H0 SD06-47 DS-A00-.25-T DT-35-.25 DS-T15B
EJ5D-02R03 DS-A00T DS-T156B SM40-123-H0 SD08-46 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6D-02R02 DS-A00T DS-T156B SM40-123-H0 SD06-47 DS-A00-.25-T DT-35-.25 DS-T15B
EJ5D-03R01 DS-A00T DS-T156B SM40-123-H0 SD08-46 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6D-03R01 DS-A00T DS-T156B SM40-123-H0 SD08-46 DS-A00-.25-T DT-35-.25 DS-T15B
EJ5D-04R01 DS-A00T DS-T156B SM40-123-H0 SD12-89 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6D-04R01 DS-A00T DS-T156B SM40-123-H0 SD10-49 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6D-04R02 DS-A00T DS-T156B SM40-123-H0 SD12-89 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6D-05R01 DS-A00T DS-T156B SM40-123-H0 SD12-89 DS-A00-.25-T DT-35-.25 DS-T15B
EJ6D-06R01 DS-A00T DS-T156B SM40-123-H0 SD12-89 DS-A00-.25-T DT-35-.25 DS-T15B
Driver BitDriver Handle Insert Screw Retention Bolt Torque Driver Handle Preset Torque Bit Torque Driver Bit
**OPTIONAL** **OPTIONAL****OPTIONAL**
Insert screw tightening torque: 35 in*lb.
10
END MILLS & SHELL MILLS WITH INTERLOCKING INSERTS FOR
SMOOTH AND RELIABLE OPERATION
• Overlapping “V-Notch” inserts that allow for smooth chip formation at high feed-rates
• The patented end-station fully supports the insert for reliable operation and unobstructed chip evacuation
• Tangentially mounted inserts with dovetailed seating for greater cutter reliability and insert stability
• End-station inserts with corner radii from .031” to .250” and that fit the same cutter body, no cutter modifications needed
• High axial shear for smooth chip formation in both keen and landed insert geometries
OAL
APMX
DC
90°KAPR
DCON
KWW
WEP
WEP - See insert drawing for wiper options.
SERIES 2XJ3J
90° SHELL MILL
Shoulder
2XJ3J-20023D1R01 2.000 1.512 2.35 4 4 4 8 4 0.750 0.312
2XJ3J-20027D1R01 2.000 1.971 2.75 4 4 4 12 4 0.750 0.312
2XJ3J-20027D1R02 2.000 1.512 2.75 3 3 3 6 3 0.750 0.312
2XJ3J-20030D1R01 2.000 2.430 3.00 4 4 4 16 4 0.750 0.312
2XJ3J-20035D1R01 2.000 2.889 3.50 4 4 4 20 4 0.750 0.312
2XJ3J-25035D3R02 2.500 2.886 3.50 4 4 4 20 4 1.000 0.375
2XJ3J-25030D3R01 2.500 2.431 3.00 5 5 5 20 5 1.000 0.375
2XJ3J-25035D3R01 2.500 2.886 3.50 5 5 5 25 5 1.000 0.375
2XJ3J-25035D3R02 2.500 2.886 3.50 4 4 4 20 4 1.000 0.375
2XJ3J-25040D3R01 2.500 3.348 4.00 5 5 5 30 5 1.000 0.375
2XJ3J-25045D3R01 2.500 3.806 4.50 5 5 5 35 5 1.000 0.375
2XJ3J-30037D4R01 3.000 2.890 3.75 5 5 5 25 5 1.250 0.500
2XJ3J-30037D4R02 3.000 2.890 3.75 6 6 6 30 6 1.250 0.500
2XJ3J-30042D4R01 3.000 3.348 4.25 5 5 5 30 5 1.250 0.500
2XJ3J-30050D4R01 3.000 3.807 5.00 5 5 5 35 5 1.250 0.500
2XJ3J-30050D4R02 3.000 3.807 5.00 6 6 6 42 6 1.250 0.500
* End station insert screw tightening torque: 40-45 in*lb. Side station insert screw tightening torque: 30-35 in*lb.
** Total number of inserts = ZNF + ZNP.
Facing Channel Coolant
Part Number DC
Cutting
Dia.
APMX
Depth of Cut
Max.
OAL
Overall
Length
ZEFF
Effective
Teeth
ZEFP
Eff. Teeth
Periphery
ZNF
Face Insert
Count
ZNP
Peripheral
Insert Count
NOF
Flute
Count
DCON
Bore Dia. KWW
Keyway
11
milling
OAL
LPR
DC
APMX
90°KAPR
DCON
WEP
WEP - See insert drawing for wiper options.
SERIES 2XJ3J
90° WELDON DIMPLE STYLE END MILL
Shoulder
2XJ3J-2002281R01 2.000 1.510 2.250 2.250 2.250 4.500 4 4 4 8 4 1.250
2XJ3J-2002781R01 2.000 1.971 2.750 2.750 2.750 5.000 4 4 4 12 4 1.250
2XJ3J-2003081R01 2.000 2.430 3.000 3.000 3.000 5.250 4 4 4 16 4 1.250
*End station insert screw tightening torque: 40-45 in*lb. Side station insert screw tightening torque: 30-35 in*lb.
** Total number of inserts = ZNF + ZNP.
Facing Channel Coolant
Part Number DC
Cutting
Dia.
APMX
Depth of Cut
Max.
LUX
Usable Length
Max.
LPR
Protruding
Length
LF
Functional
Length
OAL
Overall
Length
ZEFF
Effective
Teeth
ZEFP
Eff. Teeth
Periphery
ZNF
Face Insert
Count
ZNP
Peripheral
Insert Count
NOF
Flute
Count
DCON
Shank Dia.
DC
WEP
APMX
90°KAPR
WEP - See insert drawing for wiper options.
OAL
LPR
DCON
SERIES 2XJ3J
90° WELDON STYLE END MILL
Shoulder
*End station insert screw tightening torque: 40-45 in*lb. Side station insert screw tightening torque: 30-35 in*lb.
** Total number of inserts = ZNF + ZNP.
Facing Channel Coolant
2XJ3J-2004082R01 2.000 4.262 4.650 4.650 4.650 7.750 4 4 4 32 4 2.000
Part Number DC
Cutting
Dia.
APMX
Depth of Cut
Max.
LUX
Usable Length
Max.
LPR
Protruding
Length
LF
Functional
Length
OAL
Overall
Length
ZEFF
Effective
Teeth
ZEFP
Eff. Teeth
Periphery
ZNF
Face Insert
Count
ZNP
Peripheral
Insert Count
NOF
Flute
Count
DCON
Shank Dia.
12
LF
LUX
APMX
DC
CCMS
90°KAPR
OAL
WEP - See insert drawing for wiper options.
WEP
SERIES 2XJ3J
90° V-FLANGE STYLE END MILL
Shoulder
*End station insert screw tightening torque: 40-45 in*lb. Side station insert screw tightening torque: 30-35 in*lb.
** Total number of inserts = ZNF + ZNP.
Facing Channel Coolant
2XJ3J-2006048R01 2.000 4.262 4.625 6 10 4 4 4 32 4 ICTC #50 .125 Draw
2XJ3J-2006048R02 2.000 4.262 4.625 6 10 3 3 3 24 3 ICTC #50 .125 Draw
2XJ3J-2506048R01 2.500 4.262 4.625 6 10 5 5 5 40 5 ICTC #50 .125 Draw
2XJ3J-2508048R01 2.500 6.099 6.625 8 12 5 5 5 60 5 ICTC #50 .125 Draw
Part Number DC
Cutting
Dia.
APMX
Depth of Cut
Max.
LUX
Usable Length
Max.
LF
Functional
Length
OAL
Overall
Length
ZEFF
Effective
Teeth
ZEFP
Eff. Teeth
Periphery
ZNF
Face Insert
Count
ZNP
Peripheral
Insert Count
NOF
Flute
Count
CCMS
Connection Code
Machine Side
W1 S1
RE
INSL
IPM324
W1 S1
RE
BS
INSL
IPM426
INSERTS
Part Number Application Station RE
Corner
Radius
BS
Wiper
Length
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN4005
IN2505
IN4030
IN2530
IN7035
IN4035
IN2535
IPM324R001-ML Multi-Purpose, Keen Edge Periphery 0.015 . 0.482 0.512 0.514 0.281 4 Right • • • • •
IPM324R001-MM Multi-Purpose/Heavy-Duty Periphery 0.015 . 0.512 0.512 0.512 0.281 4 Right • • • •
IPM426R001-ML Multi-Purpose, Keen Edge Face 0.030 0.103 0.617 0.617 0.595 0.375 2 Right • • • • •
IPM426R001-MM Multi-Purpose/Heavy-Duty Face 0.030 0.103 0.617 0.617 0.595 0.375 2 Right • • • •
IPM426R002-ML Multi-Purpose, Keen Edge Face 0.060 0.103 0.620 0.620 0.594 0.375 2 Right • • • • •
IPM426R002-MM Multi-Purpose/Heavy-Duty Face 0.060 0.103 0.620 0.620 0.594 0.375 2 Right • • • •
IPM426R003-ML Multi-Purpose, Keen Edge Face 0.090 0.103 0.623 0.623 0.586 0.375 2 Right • • • • •
IPM426R003-MM Multi-Purpose/Heavy-Duty Face 0.090 0.103 0.623 0.623 0.586 0.375 2 Right • • • •
IPM426R004-ML Multi-Purpose, Keen Edge Face 0.125 0.104 0.626 0.626 0.585 0.375 2 Right • • • • •
IPM426R004-MM Multi-Purpose/Heavy-Duty Face 0.125 0.104 0.626 0.626 0.585 0.375 2 Right • • • •
IPM426R009-ML Multi-Purpose, Keen Edge Face 0.250 0.020 0.630 0.630 0.567 0.375 2 Right • • • • •
IPM426R009-MM Multi-Purpose/Heavy-Duty Face 0.250 0.020 0.630 0.630 0.567 0.375 2 Right • • • •
ML MM
13
milling
2XJ3J-20023D1R01 DS-T206B DS-T156B DS-A00T SM50-140-10 SM40-143-H0 SD-06-50 SA030-01 SA030-02
2XJ3J-20027D1R01 DS-T206B DS-T156B DS-A00T SM50-140-10 SM40-143-H0 SD-06-A2 SA030-01 SA030-02
2XJ3J-20027D1R02 DS-T206B DS-T156B DS-A00T SM50-140-10 SM40-143-H0 SD-06-79 SA030-01 SA030-02
2XJ3J-20030D1R01 DS-T206B DS-T156B DS-A00T SM50-140-10 SM40-143-H0 SD-06-79 SA030-01 SA030-02
2XJ3J-20035D1R01 DS-T206B DS-T156B DS-A00T SM50-140-10 SM40-143-H0 SD-06-B2 SA030-01 SA030-02
2XJ3J-25030D3R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 SD-08-52 SA030-01 SA030-02
2XJ3J-25035D3R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 SD-08-81 SA030-01 SA030-02
2XJ3J-25035D3R02 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 SD-08-81 SA030-01 SA030-02
2XJ3J-25040D3R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 SD-08-D3 SA030-01 SA030-02
2XJ3J-25045D3R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 SD-08-97 SA030-01 SA030-02
2XJ3J-30037D4R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 SD-10-54 SA030-01 SA030-02
2XJ3J-30037D4R02 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 SD-10-54 SA030-01 SA030-02
2XJ3J-30042D4R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 SD-10-73 SA030-01 SA030-02
2XJ3J-30042D4R02 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 SD-10-73 SA030-01 SA030-02
2XJ3J-30050D4R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 SD-10-04 SA030-01 SA030-02
2XJ3J-30050D4R02 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 SD-10-04 SA030-01 SA030-02
2XJ3J-2002281R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 - SA030-01 SA030-02
2XJ3J-2002781R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 - SA030-01 SA030-02
2XJ3J-2003081R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 - SA030-01 SA030-02
2XJ3J-2004082R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 - SA030-01 SA030-02
2XJ3J-2006048R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 - SA030-01 SA030-02
2XJ3J-2006048R02 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 - SA030-01 SA030-02
2XJ3J-2506048R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 - SA030-01 SA030-02
2XJ3J-2508048R01 DS-T206B DS-T156B DS-A00T SM50-160-10 SM40-143-H0 - SA030-01 SA030-02
Face Driver Bit Periphery Driver Bit Driver Handle Face Insert Screw Periphery Insert Screw Retention Bolt
Coolant Hole Socket Set Screw
Alt. Coolant Blocking Socket Set Screw
HARDWARE
optional preset torque components recommended for proper tightening screws. All components are sold separately.
14
12.5°KAPR
.06APMX
.097REEQ
WEP - See insert drawing for wiper options.
DCON KWW
OAL
DCX
WEP
DC
HIGH FEED FACE MILL
8G5A-02R01 2.000 1.408 1.750 5 0.097 12.7 0.750 0.31 3.00
8G6A-02R01 2.000 1.408 1.750 4 0.097 12.7 0.750 0.31 3.00
8G6A-02R03 2.500 1.901 1.750 5 0.097 12.6 0.750 0.31 2.10
8G6A-02R02 2.500 1.902 1.750 5 0.097 12.6 1.000 0.38 2.10
8G5A-03R01 3.000 2.399 1.750 7 0.097 12.7 1.000 0.38 1.60
8G5A-03R02 3.000 2.399 1.750 7 0.097 12.5 1.250 0.50 1.60
8G5A-04R01 4.000 3.398 2.500 9 0.097 12.5 1.500 0.63 1.10
8G6A-04R01 4.000 3.398 2.500 7 0.097 12.5 1.500 0.63 1.10
Insert screw tightening torque: 30-35 in*lb.
Corkscrew Coolant
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
KAPR
Cutting Edge
Angle
DCON
Bore Dia.
KWW
Keyway
RMPX
Ramp Angle
Max.
Facing Shoulder Plunge
SERIES 8G5A, 8G6A
ContourChannel
W1 S1
RE
BS
INSL
LGM324R001-ML
W1 S1
RE
BS
INSL
LGX324R001-M
INSERTS
Part Number Application RE
Corner
Radius
BS
Wiper
Length
INSL
Insert
Length
W1
Insert
Width
S1
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN4005
IN2505
IN4030
IN2530
IN4035
IN2535
LGX324R001-M Hi-Feed, Heavy-Duty 0.040 0.060 0.610 0.373 0.256 4 Right • • • •
LGM324R001-ML Hi-Feed, Heavy-Duty Keen Edge 0.040 0.060 0.610 0.373 0.256 4 Right • • • • • •
M
ML
HI-FEED FACEMILL FAMILY WITH STRONG TANGENTIAL INSERTS AND
RELIABLE DOVETAILED INSERT SEATING
• Unique diamond shaped inserts provide the highest ramping feed-rates at the steepest ramping angles
• Thick tangential inserts give maximum reinforcement to the cutting edge and cutter longevity
• Large insert seating areas are dovetailed to stabilize and support the insert under the most aggressive conditions
• Inserts offered in both pressed and ground profiles for economical performance across all material types
15
milling
8G5A-02R01 SM40-123-H0 DS-A00T DS-T156B SB-04-15 DS-A00-.25T DT-35-.25 DS-T15B
8G6A-02R01 SM40-123-H0 DS-A00T DS-T156B SB-04-15 DS-A00-.25T DT-35-.25 DS-T15B
8G6A-02R03 SM40-123-H0 DS-A00T DS-T156B SD-06-47 DS-A00-.25T DT-35-.25 DS-T15B
8G6A-02R02 SM40-123-H0 DS-A00T DS-T156B SD-08-47 DS-A00-.25T DT-35-.25 DS-T15B
8G5A-03R01 SM40-123-H0 DS-A00T DS-T156B SD-08-47 DS-A00-.25T DT-35-.25 DS-T15B
8G5A-03R02 SM40-123-H0 DS-A00T DS-T156B SD-10-47 DS-A00-.25T DT-35-.25 DS-T15B
8G5A-04R01 SM40-123-H0 DS-A00T DS-T156B SD-12-82 DS-A00-.25T DT-35-.25 DS-T15B
8G6A-04R01 SM40-123-H0 DS-A00T DS-T156B SD-12-82 DS-A00-.25T DT-35-.25 DS-T15B
Screw Driver Handle Retention Bolt
HARDWARE
Driver Bit Torque Driver Handle Preset Torque Bit Torque Driver Bit
**OPTIONAL** **OPTIONAL****OPTIONAL**
16
ROBUST 45º FACE MILL WITH 12-EDGE ECONOMY
• Reinforced cutting edge boasts high feed rate potential
• High radial pocket incline promotes utmost chip evacuation and fine pitch cutter design for maximized productivity
• Helical cutting edges promote smooth machining
• Unequally spaced insert placement aids to diffuse vibration
• Integrated wiper flats produce 32-63 Ra surface finishes
• Ideal for steels and iron!
.11APMX
45°KAPR
WEP
KWW
OAL
DC
DCX
DCON
WEP - See insert drawing for wiper options.
SERIES HN5D, HN6D
HN6D-15R01 1.500 1.88 1.750 4 0.500 0.250 Yes
HN5D-20R01 2.000 2.38 1.750 6 0.750 0.312 Yes
HN6D-20R01 2.000 2.38 1.750 4 0.750 0.312 Yes
HN5D-25R01 2.500 2.89 1.750 7 1.000 0.375 Yes
HN6D-25R01 2.500 2.89 1.750 5 1.000 0.375 Yes
HN5D-30R01 3.000 3.39 1.750 10 1.000 0.375 Yes
HN6D-30R01 3.000 3.39 1.750 6 1.000 0.375 Yes
HN5D-40R01 4.000 4.39 2.375 12 1.500 0.625 Yes
HN6D-40R01 4.000 4.39 2.375 7 1.500 0.625 Yes
HN5D-50R01 5.000 5.39 2.375 16 1.500 0.625 Yes
HN6D-50R01 5.000 5.39 2.375 10 1.500 0.625 Yes
HN5D-60R01 6.000 6.39 2.375 20 1.500 0.625 No
HN6D-60R01 6.000 6.39 2.375 12 1.500 0.625 No
CoolantChamferLead AngleFacing
45° FACE MILL (6MM INSERT)
06
INSERTS
Part Number Application BS
Wiper
Length
IC
Inscribed
Circle Dia.
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2510
IN6537
HNGU0605ANTR-M Medium Roughing 0.023 0.551 0.264 12 Right • •
HNGU0605ANTR-MM Medium, Pos. Rake Angle 0.047 0.551 0.264 12 Right • •
S
IC
BS
HNGU06_M
S
IC
BS
Part Number DC
Cutting
Dia.
DCX
Cutting
Diameter Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
KWW
Keyway CSP
Coolant
06
M
MM
HNGU06_MM
17
milling
KWW
OAL
DC
DCX
DCON
WEP - See insert drawing for wiper options.
.20APMX
45°KAPR
WEP
SERIES HN5G, HN6G
HN5G-25R01 2.500 3.03 1.750 7 1.000 0.375 - Yes
HN6G-25R01 2.500 3.03 1.750 5 1.000 0.375 - Yes
HN5G-30R01 3.000 3.53 1.750 9 1.000 0.375 - Yes
HN6G-30R01 3.000 3.53 1.750 6 1.000 0.375 - Yes
HN5G-40R01 4.000 4.53 2.375 11 1.500 0.625 - Yes
HN6G-40R01 4.000 4.53 2.375 7 1.500 0.625 - Yes
HN5G-50R01 5.000 5.52 2.375 14 1.500 0.625 - Yes
HN6G-50R01 5.000 5.52 2.375 8 1.500 0.625 - Yes
HN5G-60R01 6.000 6.52 2.375 16 1.500 0.625 - No
HN6G-60R01 6.000 6.52 2.375 10 1.500 0.625 - No
HN5G-80R01 8.000 8.52 2.375 21 2.500 1.000 4.00" No
HN6G-80R01 8.000 8.52 2.375 14 2.500 1.000 4.00" No
HN5G-10R01 10.000 10.53 2.375 26 2.500 1.000 4.00" No
HN6G-10R01 10.000 10.53 2.375 16 2.500 1.000 4.00" No
CoolantChamferLead AngleFacing
45° FACE MILL (10MM INSERT)
10
INSERTS
10
Part Number Application BS
Wiper
Length
IC
Inscribed
Circle Dia.
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2510
IN6515
IN6537
HNGU1007ANTR-M Medium Roughing 0.039 0.752 0.327 12 Right • •
HNGU1007ANTR-MM Medium, Pos. Rake Angle 0.063 0.752 0.327 12 Right •
HNGU1007ANTR-HR Heavy-Duty 0.039 0.752 0.327 12 Right • •
S
IC
BS
HNGU10_M
S
IC
BS
HNGU10_HR
S
IC
BS
Part Number DC
Cutting
Dia.
DCX
Cutting
Diameter Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
KWW
Keyway
DBC
Bolt
Circle
CSP
Coolant
M
HR
MM
HNGU10_MM
18
HN6D-15R01 SM40-100-R0 DS-A00T DS-T156B1 SD-04-48 - DS-A00-.25-T DS-T15B1 DT-35-.25
HN5D-20R01 SM40-100-R0 DS-A00T DS-T156B1 SD-06-47 SD-06-A6 DS-A00-.25-T DS-T15B1 DT-35-.25
HN6D-20R01 SM40-100-R0 DS-A00T DS-T156B SD-06-47 SD-06-A6 DS-A00-.25-T DS-T15B1 DT-35-.25
HN5D-25R01 SM40-100-R0 DS-A00T DS-T156B SD-08-47 SD08-C9 DS-A00-.25-T DS-T15B1 DT-35-.25
HN6D-25R01 SM40-100-R0 DS-A00T DS-T156B SD-08-47 SD08-C9 DS-A00-.25-T DS-T15B1 DT-35-.25
HN5D-30R01 SM40-100-R0 DS-A00T DS-T156B SD-08-47 SD08-C9 DS-A00-.25-T DS-T15B1 DT-35-.25
HN6D-30R01 SM40-100-R0 DS-A00T DS-T156B SD-08-47 SD08-C9 DS-A00-.25-T DS-T15B1 DT-35-.25
HN5D-40R01 SM40-100-R0 DS-A00T DS-T156B SD-12-82 SD-12-99 DS-A00-.25-T DS-T15B1 DT-35-.25
HN6D-40R01 SM40-100-R0 DS-A00T DS-T156B SD-12-82 SD-12-99 DS-A00-.25-T DS-T15B1 DT-35-.25
HN5D-50R01 SM40-100-R0 DS-A00T DS-T156B SD-12-82 SD-12-99 DS-A00-.25-T DS-T15B1 DT-35-.25
HN6D-50R01 SM40-100-R0 DS-A00T DS-T156B SD-12-82 SD-12-99 DS-A00-.25-T DS-T15B1 DT-35-.25
HN5D-60R01 SM40-100-R0 DS-A00T DS-T156B SD-12-82 - DS-A00-.25-T DS-T15B1 DT-35-.25
HN6D-60R01 SM40-100-R0 DS-A00T DS-T156B SD-12-82 - DS-A00-.25-T DS-T15B1 DT-35-.25
HN5G-25R01 SM50-130-R0 DS-A00T DS-T206B SD-08-47 SD08-C9 DS-A00-.25-T DS-T20B1 DT-44-.25
HN6G-25R01 SM50-130-R0 DS-A00T DS-T206B SD-08-47 SD08-C9 DS-A00-.25-T DS-T20B1 DT-44-.25
HN5G-30R01 SM50-130-R0 DS-A00T DS-T206B SD-08-47 SD08-C9 DS-A00-.25-T DS-T20B1 DT-44-.25
HN6G-30R01 SM50-130-R0 DS-A00T DS-T206B SD-08-47 SD08-C9 DS-A00-.25-T DS-T20B1 DT-44-.25
HN5G-40R01 SM50-130-R0 DS-A00T DS-T206B SD-12-89 SD-12-99 DS-A00-.25-T DS-T20B1 DT-44-.25
HN6G-40R01 SM50-130-R0 DS-A00T DS-T206B SD-12-89 SD-12-99 DS-A00-.25-T DS-T20B1 DT-44-.25
HN5G-50R01 SM50-130-R0 DS-A00T DS-T206B SD-12-89 SD-12-99 DS-A00-.25-T DS-T20B1 DT-44-.25
HN6G-50R01 SM50-130-R0 DS-A00T DS-T206B SD-12-89 SD-12-99 DS-A00-.25-T DS-T20B1 DT-44-.25
HN5G-60R01 SM50-130-R0 DS-A00T DS-T206B SD-12-89 SD-12-99 DS-A00-.25-T DS-T20B1 DT-44-.25
HN6G-60R01 SM50-130-R0 DS-A00T DS-T206B SD-12-89 SD-12-99 DS-A00-.25-T DS-T20B1 DT-44-.25
HN5G-80R01 SM50-130-R0 DS-A00T DS-T206B - - DS-A00-.25-T DS-T20B1 DT-44-.25
HN6G-80R01 SM50-130-R0 DS-A00T DS-T206B - - DS-A00-.25-T DS-T20B1 DT-44-.25
HN5G-10R01 SM50-130-R0 DS-A00T DS-T206B - - DS-A00-.25-T DS-T20B1 DT-44-.25
HN6G-10R01 SM50-130-R0 DS-A00T DS-T206B - - DS-A00-.25-T DS-T20B1 DT-44-.25
Screw Driver Handle Torx Driver Blade Retention Bolt
HARDWARE
06/10
Coolant Retention Bolt
**OPTIONAL**
Torque Driver Handle Torque Driver Bit Preset Torque Bit
**OPTIONAL** **OPTIONAL****OPTIONAL**
19
milling
HI-FEED & 65° MILLS WITH 10-EDGE ECONOMY!
• Same insert fits Hi-Feed & 65° mills
• Reinforced cutting edge boasts high feed rate potential
• Positive geometry promotes smooth machining
• Wide market range including Die/Mold and General Purpose!
.06APMX
26°KAPR
Backdraft
.06APMX
.10REEQ
DCX
DC
LUX
LPR
OAL
DCON
SERIES 1DP1C (CYLINDRICAL SHANK)
HI-FEED END MILL (5MM INSERT)
05
CoolantCorkscrew FacingRampChannelContour
.06APMX
26°KAPR
Backdraft
.06APMX
.10REEQ
DCX DC
LF
DHUB
CCMS
Program like an end mill with .10” Corner Radius.
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
CCMS
Connection
Code
RMPX
Ramp Angle
Max.
1DP1C-07015X6R01 0.750 0.431 1.50 3 0.100 TopOn M10 1.3
1DP1C-10015X7R01 1.000 0.677 1.50 4 0.100 TopOn M12 1.1
1DP1C-12015X8R01 1.250 0.927 1.50 5 0.100 TopOn M16 1
1DP1C-15015X8R01 1.500 1.177 1.50 6 0.100 TopOn M16 0.8
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
RMPX
Ramp
Angle Max.
1DP1C-07015S7R01 0.750 0.431 1.50 4.00 6.00 3 0.100 0.750 1.3
1DP1C-10015S1R01 1.000 0.677 1.50 3.75 6.00 4 0.100 1.000 1.1
1DP1C-12020S9R01 1.250 0.927 2.00 5.75 8.00 5 0.100 1.250 1
1DP1C-15020S5R01 1.500 1.177 2.00 5.34 8.00 6 0.100 1.500 0.8
Program like an end mill with .10” Corner Radius.
Designed with modification in mind. Extend usable length by turning back the neck diameter or shorten the overall length by cutting off back end.
SERIES 1DP1C (TOP•ON STYLE)
HI-FEED MODULAR END MILL (5MM INSERT)
05
CoolantCorkscrew FacingRampChannelContour
20
.06APMX
26°KAPR
Backdraft
.06APMX
.10REEQ
OAL
DC
DCX
DCON KWW
SERIES DP6C
HI-FEED FACE MILL (5MM INSERT)
05
CoolantCorkscrew FacingRampChannelContour
Programing Corner Radius: .10”R.
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
OAL
Overall
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DCON
Bore
Dia.
KWW
Keyway
RMPX
Ramp Angle
Max.
DP6C-15R01 1.500 1.177 1.57 6 0.100 0.500 0.25 0.8
DP6C-20R01 2.000 1.677 1.57 7 0.100 0.750 0.31 0.7
DP6C-25R01 2.500 2.177 1.57 8 0.100 0.750 0.31 0.6
65°KAPR1
OAL
DC
DCX
DCON KWW
.13APMX
SERIES DM6C
65° FACE MILL (5MM INSERT)
05
CoolantFacingChannel
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Bore
Dia.
KWW
Keyway
DM6C-15R01 1.500 1.65 1.570 6 0.500 0.250
DM6C-20R01 2.000 2.15 1.570 7 0.750 0.312
DM6C-25R01 2.500 2.65 1.570 8 0.750 0.312
DM6C-30R01 3.000 3.15 1.750 9 1.000 0.375
21
milling
1DP1C-07015S7R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1 -
1DP1C-10015S1R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1 -
1DP1C-12020S9R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1 -
1DP1C-15020S5R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1 -
1DP1C-07015X6R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1 615MM
1DP1C-10015X7R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1 617MM
1DP1C-12015X8R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1 622MM
1DP1C-15015X8R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1 622MM
DP6C-15R01 SM25-060-90 DS-TP07S SD-04-46 - DS-A00-.25-S DT-08-.25 DS-TP07B1 -
DP6C-20R01 SM25-060-90 DS-TP07S SD-06-46 SD-06-89 DS-A00-.25-S DT-08-.25 DS-TP07B1 -
DP6C-25R01 SM25-060-90 DS-TP07S SD-06-46 SD-06-89 DS-A00-.25-S DT-08-.25 DS-TP07B1 -
DM6C-15R01 SM25-060-90 DS-TP07S SD-04-46 - DS-A00-.25-S DT-08-.25 DS-TP07B1 -
DM6C-20R01 SM25-060-90 DS-TP07S SD-06-46 SD-06-89 DS-A00-.25-S DT-08-.25 DS-TP07B1 -
DM6C-25R01 SM25-060-90 DS-TP07S SD-06-46 SD-06-89 DS-A00-.25-S DT-08-.25 DS-TP07B1 -
DM6C-30R01 SM25-060-90 DS-TP07S SD-08-46 SD08-C9 DS-A00-.25-S DT-08-.25 DS-TP07B1 -
Screw Torque Driver Handle
Torx Driver Preset Torque BitCoolant Retention Bolt Wrench
Retention Bolt Torque Driver Bit
Part Number Application RE
Corner
Radius
IC
Inscribed
Circle Dia.
S
Thickness NOI
Number of Indexes
IH
Insert
Hand
Grade
IN2505
IN2530
PNCU050315R-M Multi-Purpose 0.059 0.279 0.149 10 Right • •
S
IC
RE
PNCU05_M
INSERT
05
HARDWARE
05
**OPTIONAL** **OPTIONAL** **OPTIONAL** **OPTIONAL** **OPTIONAL**
M
22
.06APMX
25°KAPR
Backdraft
.11APMX
.21REEQ
DCX
DC
LUX
LPR
OAL
DCON
SERIES 1DP1P (CYLINDRICAL SHANK)
HI-FEED END MILL (10MM INSERT)
10
CoolantCorkscrew FacingRampChannelContour
.06APMX
25°KAPR
Backdraft
.11APMX
.21REEQ
DCX DC
LF
DHUB
CCMS
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
APMX
Depth of
Cut Max.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
RMPX
Ramp
Angle Max.
1DP1P-15020S5R01 1.500 0.850 0.118 2.00 5.34 8.00 3 0.210 1.500 2.2
Program like an end mill with .21” Corner Radius.
Designed with modification in mind. Extend usable length by turning back the neck diameter or shorten the overall length by cutting off back end.
SERIES 1DP1P (TOP•ON STYLE)
HI-FEED MODULAR END MILL (10MM INSERT)
10
CoolantCorkscrew FacingRampChannelContour
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
APMX
Depth of
Cut Max.
LF
Functional
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DHUB
Hub
Dia.
CCMS
Connection
Code
RMPX
Ramp
Angle Max.
1DP1P-15020X9R01 1.500 0.850 0.118 2.00 3 0.210 1.41 TopOn M20 2.2
Program like an end mill with .21” Corner Radius.
23
milling
OAL
DC
DCX
DCON KWW
.06APMX
25°KAPR
Backdraft
.11APMX
.21REEQ
SERIES DP6P
HI-FEED FACE MILL (10MM INSERT)
10
CoolantCorkscrew FacingRampChannelContour
Programing Corner Radius: .21”R.
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
OAL
Overall
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DCON
Bore
Dia.
KWW
Keyway
RMPX
Ramp Angle
Max.
DP6P-20R01 2.000 1.350 1.57 4 0.210 0.750 0.31 2.5
DP6P-25R01 2.500 1.850 1.75 5 0.210 1.000 0.38 1.6
DP6P-30R01 3.000 2.350 1.75 6 0.210 1.000 0.38 1.2
65°KAPR
.25APMX
OAL
DC
DCX
DCON KWW
SERIES DM6P
65° FACE MILL (10MM INSERT)
10
CoolantFacingChannel
Part Number DC
Cutting
Diameter
DCX
Cutting
Dia. Max.
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Bore
Dia.
KWW
Keyway
DM6P-20R01 2.000 2.280 1.750 4 1.000 0.375
DM6P-25R01 2.500 2.780 1.750 5 1.000 0.375
DM6P-30R01 3.000 3.280 1.750 6 1.000 0.375
DM6P-40R01 4.000 4.280 2.375 8 1.500 0.625
24
Part Number Application RE
Corner
Radius
IC
Inscribed
Circle Dia.
S
Thickness NOI
Number of Indexes
IH
Insert
Hand
Grade
IN2505
IN2530
PNCU100630R-M Multi-Purpose 0.118 0.559 0.303 10 Right • •
S
IC
RE
PNCU10_M
INSERT
10
HARDWARE
10
1DP1P-15020S5R01 SM50-127-10 DS-A00T DS-T206B - - DS-A00-.25-T DT-44-.25 DS-T20B1 -
1DP1P-15020X9R01 SM50-127-10 DS-A00T DS-T206B - - DS-A00-.25-T DT-44-.25 DS-T20B1 630MM
DP6P-20R01 SM50-127-10 DS-A00T DS-T206B SD-06-46 SD-06-89 DS-A00-.25-T DT-44-.25 DS-T20B1 -
DP6P-25R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD08-C9 DS-A00-.25-T DT-44-.25 DS-T20B1 -
DP6P-30R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD08-C9 DS-A00-.25-T DT-44-.25 DS-T20B1 -
DM6P-20R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD08-C9 DS-A00-.25-T DT-44-.25 DS-T20B1 -
DM6P-25R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD08-C9 DS-A00-.25-T DT-44-.25 DS-T20B1 -
DM6P-30R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD08-C9 DS-A00-.25-T DT-44-.25 DS-T20B1 -
DM6P-40R01 SM50-127-10 DS-A00T DS-T206B SD-12-82 SD-12-99 DS-A00-.25-T DT-44-.25 DS-T20B1 -
Screw Driver Handle Torx Driver Blade Torque Driver Handle
**OPTIONAL**
Torque Driver Bit
**OPTIONAL**
Preset Torque Bit
**OPTIONAL**
Wrench
**OPTIONAL**
Retention Bolt Retention Bolt
**OPTIONAL**
M
25
milling
TRUE 90° SHOULDER MILLS WITH 8-EDGE ECONOMY
• High axial rake reduces cutting loads and promotes smooth machining
• 07 Insert generates true 90° and is optimized to step down axially with minimal mismatch
• 12 Insert generates true 90° up to .33 depth of cut
• Unequally spaced insert placement aids to diffuse vibration
• Integrated wiper flats produce 32-63 Ra surface finishes
SERIES 1DJ1E (WELDON SHANK)
07
WEP - See insert drawing for wiper options.
.19APMX
90°KAPR
OAL
LPR
LUX
DCON
DC
WEP
CoolantChannelShoulderFacing
90° ROUGH & FINISH END MILL (7MM INSERT)
Part Number DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
1DJ1E-0600779R01 0.625 0.70 0.75 2.66 2 0.625
1DJ1E-0701084R01 0.750 0.95 1.00 3.00 3 0.750
1DJ1E-1001280R01 1.000 1.20 1.25 3.50 4 1.000
1DJ1E-1201581R01 1.250 1.45 1.50 3.75 4 1.250
1DJ1E-1201581R02 1.250 1.45 1.50 3.75 5 1.250
1DJ1E-1501786R01 1.500 1.70 1.75 4.41 5 1.500
1DJ1E-1501786R02 1.500 1.70 1.75 4.41 8 1.500
26
DJ5E-15R01 1.500 1.57 6 0.500 0.250
DJ5E-20R01 2.000 1.57 8 0.750 0.312
DJ6E-20R01 2.000 1.57 6 0.750 0.312
DJ5E-25R01 2.500 1.57 10 1.000 0.375
DJ6E-25R01 2.500 1.57 7 1.000 0.375
DJ5E-30R01 3.000 1.75 12 1.000 0.375
DJ6E-30R01 3.000 1.75 8 1.000 0.375
Part Number DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Bore
Dia.
KWW
Keyway
DCON
KWW
90°KAPR
OAL
DC
.19APMX
WEP
WEP - See insert drawing for wiper options.
SERIES DJ5E, DJ6E
CoolantChannelShoulderFacing
90° ROUGH & FINISH FACE MILL (7MM INSERT)
07
Part Number Application RE
Corner
Radius
BS
Wiper
Length
IC
Inscribed
Circle Dia.
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2510
IN2530
SQGU070308TR-M Multi-Purpose - Integrated Wiper 0.031 0.035 0.275 0.165 8 Right • • •
S
IC
RE
BS
SQGU07_M
INSERT
07
M
27
milling
HARDWARE
07
1DJ1E-0600779R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1
1DJ1E-0701084R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1
1DJ1E-1001280R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1
1DJ1E-1201581R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1
1DJ1E-1201581R02 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1
1DJ1E-1501786R01 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1
1DJ1E-1501786R02 SM25-060-90 DS-TP07S - - DS-A00-.25-S DT-08-.25 DS-TP07B1
DJ5E-15R01 SM25-060-90 DS-TP07S SD-04-47 - DS-A00-.25-S DT-08-.25 DS-TP07B1
DJ5E-20R01 SM25-060-90 DS-TP07S SD-06-47 SD-06-A6 DS-A00-.25-S DT-08-.25 DS-TP07B1
DJ6E-20R01 SM25-060-90 DS-TP07S SD-06-47 SD-06-A6 DS-A00-.25-S DT-08-.25 DS-TP07B1
DJ5E-25R01 SM25-060-90 DS-TP07S SD-08-47 SD08-C9 DS-A00-.25-S DT-08-.25 DS-TP07B1
DJ6E-25R01 SM25-060-90 DS-TP07S SD-08-47 SD08-C9 DS-A00-.25-S DT-08-.25 DS-TP07B1
DJ5E-30R01 SM25-060-90 DS-TP07S SD-08-47 SD08-C9 DS-A00-.25-S DT-08-.25 DS-TP07B1
DJ6E-30R01 SM25-060-90 DS-TP07S SD-08-47 SD08-C9 DS-A00-.25-S DT-08-.25 DS-TP07B1
Screw Torx Screwdriver Retention Bolt Coolant Retention Bolt
**OPTIONAL**
Torque Driver Handle Preset Torque Bit Torque Driver Bit
**OPTIONAL** **OPTIONAL** **OPTIONAL**
SERIES DJ5G, DJ6G
12
WEP - See insert drawing for wiper options.
WEP
OAL
DC
DCX
DCON
KWW
90°KAPR
88°KAPR
.33APMX
CoolantChannelShoulderFacing
90° FACE MILL (12MM INSERT)
Part Number DC
Cutting
Diameter
DCX
Cutting
Dia. Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Bore
Dia.
KWW
Keyway CSP
Coolant
DJ5G-20R01 2.000 2.055 1.570 6 0.750 0.312 Yes
DJ6G-20R01 2.000 2.055 1.570 4 0.750 0.312 Yes
DJ5G-25R01 2.500 2.555 1.570 8 1.000 0.375 Yes
DJ6G-25R01 2.500 2.555 1.570 5 1.000 0.375 Yes
DJ5G-30R01 3.000 3.051 1.750 11 1.000 0.375 Yes
DJ6G-30R01 3.000 3.051 1.750 6 1.000 0.375 Yes
DJ5G-40R01 4.000 4.051 2.375 14 1.500 0.625 Yes
DJ6G-40R01 4.000 4.051 2.375 8 1.500 0.625 Yes
DJ5G-50R01 5.000 5.052 2.375 18 1.500 0.625 Yes
DJ6G-50R01 5.000 5.052 2.375 10 1.500 0.625 Yes
DJ5G-60R01 6.000 6.051 2.000 22 2.000 0.750 No
DJ6G-60R01 6.000 6.051 2.000 12 2.000 0.750 No
28
INSERTS
DJ5G-20R01 SM50-130-R0 DS-A00T DS-T206B SD-06-48 SD-06-89 DS-A00-.25-T DT-44-.25 DS-T20B1
DJ6G-20R01 SM50-130-R0 DS-A00T DS-T206B SD-06-48 SD-06-89 DS-A00-.25-T DT-44-.25 DS-T20B1
DJ5G-25R01 SM50-130-R0 DS-A00T DS-T206B SD-08-48 SD-08-92 DS-A00-.25-T DT-44-.25 DS-T20B1
DJ6G-25R01 SM50-130-R0 DS-A00T DS-T206B SD-08-48 SD-08-92 DS-A00-.25-T DT-44-.25 DS-T20B1
DJ5G-30R01 SM50-130-R0 DS-A00T DS-T206B SD-08-48 SD-08-92 DS-A00-.25-T DT-44-.25 DS-T20B1
DJ6G-30R01 SM50-130-R0 DS-A00T DS-T206B SD-08-48 SD-08-92 DS-A00-.25-T DT-44-.25 DS-T20B1
DJ5G-40R01 SM50-130-R0 DS-A00T DS-T206B SD-12-82 SD-12-99 DS-A00-.25-T DT-44-.25 DS-T20B1
DJ6G-40R01 SM50-130-R0 DS-A00T DS-T206B SD-12-82 SD-12-99 DS-A00-.25-T DT-44-.25 DS-T20B1
DJ5G-50R01 SM50-130-R0 DS-A00T DS-T206B SD-12-82 SD-12-99 DS-A00-.25-T DT-44-.25 DS-T20B1
DJ6G-50R01 SM50-130-R0 DS-A00T DS-T206B SD-12-82 SD-12-99 DS-A00-.25-T DT-44-.25 DS-T20B1
DJ5G-60R01 SM50-130-R0 DS-A00T DS-T206B SD-12-82 SD-12-99 DS-A00-.25-T DT-44-.25 DS-T20B1
DJ6G-60R01 SM50-130-R0 DS-A00T DS-T206B SD-12-82 SD-12-99 DS-A00-.25-T DT-44-.25 DS-T20B1
Part Number Application RE
Corner
Radius
BS
Wiper
Length
LE
Cutting Edge
Eff. Length
IC
Inscribed
Circle Dia.
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN6537
IN2505
IN2510
IN2504
SQXU120608R-M Medium Roughing 0.031 0.043 0.330 0.480 0.319 8 Right • • • •
SQGU120608R-MM Medium, pos. rake angle 0.031 0.043 0.330 0.480 0.319 8 Right • •
S
IC
BS RE
LE
SQXU12_M
12
HARDWARE
12
S
RE
IC
LE
BS
SQGU12_MM
Screw Driver Handle Torque Driver HandleTorx Driver Blade
**OPTIONAL**
Preset Torque Bit
**OPTIONAL**
Retention Bolt Coolant Retention Bolt
**OPTIONAL**
Torque Driver Bit
**OPTIONAL**
M
MM
29
milling
.13APMX
90°KAPR
OAL
LPR
LUX
DCON
DC
WEP - See insert drawing for wiper options.
.13APMX
90°KAPR
OAL
LPR
LUX
DCON
DC
WEP - See insert drawing for wiper options.
SERIES 1TJ1B (WELDON SHANK)
Part Number DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
Part Number DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
1TJ1B-05007S4R01 0.500 0.75 1.72 3.50 3 0.500
1TJ1B-06008S6R01 0.625 0.81 2.09 4.00 4 0.625
1TJ1B-07008S7R01 0.750 0.87 3.00 5.00 5 0.750
1TJ1B-08010S8R01 0.875 1.00 3.25 5.25 6 0.875
1TJ1B-10012S1R01 1.000 1.25 2.25 5.50 7 1.000
1TJ1B-0700784R01 0.750 1.00 2.00 4.00 5 0.750
1TJ1B-10017E1R01 1.000 1.25 1.75 4.75 7 1.000
1TJ1B-12020E2R01 1.250 1.50 2.00 5.00 8 1.250
1TJ1B-15025E2R01 1.500 1.75 2.50 5.50 10 1.500
90° END MILLS (4MM INSERT)
90° END MILLS (4MM INSERT)
CoolantPocketingCorkscrew FacingRampChannelShoulder
When using Hi-Feed Insert, modify body corner to R.047.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
When using Hi-Feed Insert, modify body corner to R.047.
Designed with modification in mind. Extend usable length by turning back the neck diameter or shorten the overall length by cutting off back end.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
04
SERIES 1TJ1B (CYLINDRICAL SHANK)
04
CoolantPocketingCorkscrew FacingRampChannelShoulder
90°, BACKDRAFT, HI-FEED & HI-RAMP VERSATILITY WITH 4-EDGE ECONOMY!
• All inserts feature 4 cutting edges. Integrated wiper flats produce 32-63 Ra surface finishes
• True 90° shoulder milling capability
• Same cutter body utilizes 90°, Backdraft & Hi-Feed inserts
• Concave face design accommodates ramping, interpolation & drill-mill functions
• Pockets designed with wide mounting area for utmost support behind the cutting edge
• Cutters plumbed with coolant through the tool
30
LF
DHUB
CCMS
.13APMX
90°KAPR
DC
WEP
WEP - See insert drawing for wiper options.
90° MODULAR END MILLS (4MM INSERT)
When using Hi-Feed Insert, modify body corner to R.047.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
SERIES 1TJ1B (TOP•ON STYLE)
SERIES 1TJ1B (CHIP•SURFER STYLE)
CCMS
DHUB
DC
LF
WEP 90°KAPR
.13APMX
WEP - See insert drawing for wiper options.
CoolantPocketingCorkscrew FacingRampChannelShoulder
90° MODULAR END MILLS (4MM INSERT)
04
04
Part Number DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
1TJ1B-05006T8R01 0.500 0.65 3 Chip Surfer T08 0.48
1TJ1B-06008TRR01 0.625 0.80 4 Chip Surfer T10 0.60
1TJ1B-07010TSR01 0.750 1.00 5 Chip Surfer T12 0.72
1TJ1B-10012TUR01 1.000 1.25 7 Chip Surfer T15 0.94
CoolantPocketingCorkscrew FacingRampChannelShoulder
Part Number DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
1TJ1B-05007X4R01 0.500 0.75 3 TopOn M06 0.46
1TJ1B-06008X5R01 0.625 0.88 4 TopOn M08 0.50
1TJ1B-07010X6R01 0.750 1.00 5 TopOn M10 0.69
1TJ1B-10012X7R01 1.000 1.13 7 TopOn M12 0.81
When using Hi-Feed Insert, modify body corner to R.047.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
31
milling
Part Number Application RE
Corner
Radius
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2530
IN2510
MNHU040202R-M Multi-Purpose 0.008 0.130 0.157 0.157 0.122 4 Right • •
MNHU040204R-M Multi-Purpose 0.015 0.130 0.157 0.157 0.122 4 Right •••
MNHU040208R-M Multi-Purpose 0.031 0.130 0.157 0.157 0.122 4 Right • •
W1 S
LE
INSL
RE
MNHU04_M
S
RE
IC
LE
INSERTS
Part Number Application REEQ
Program Radius
Equivalent
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2504
UNHU040212R-HF Hi-Feed 0.047 0.019 0.157 0.157 0.104 4 Right • •
HARDWARE
1TJ1B-0700784R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-10017E1R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-12020E2R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-15025E2R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-03006R8R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-05007S4R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-06008S6R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-07008S7R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-08010S8R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-10012S1R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-05007X4R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-06008X5R01 SM18-041-00 DS-TP06S-NEU 610MM - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-07010X6R01 SM18-041-00 DS-TP06S-NEU 615MM - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-10012X7R01 SM18-041-00 DS-TP06S-NEU 617MM - - DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-03006T6R01 SM18-041-00 DS-TP06S-NEU - WS-0029 DT-90-08 DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-05006T8R01 SM18-041-00 DS-TP06S-NEU - WS-0030 DT-130-10 DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-06008TRR01 SM18-041-00 DS-TP06S-NEU - WS-0044 DT-250-13 DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-07010TSR01 SM18-041-00 DS-TP06S-NEU - WS-0059 DT-250-16 DS-A00-.25-S DT-05-.25 DS-TP06B
1TJ1B-10012TUR01 SM18-041-00 DS-TP06S-NEU - WS-0061 DT-350-20 DS-A00-.25-S DT-05-.25 DS-TP06B
Screw Driver Torque Driver HandleWrench
**OPTIONAL****OPTIONAL**
04
04
Torque Wrench
**OPTIONAL**
Thin Wrench
**OPTIONAL**
M
HF
Preset Torque Bit Torque Driver Bit
**OPTIONAL**
**OPTIONAL**
UNHU04_HF
32
WEP - See insert drawing for wiper options.
OAL
LPR
.24APMX
DC
LUX
DCON
90°KAPR
WEP
Part Number DC
Cutting
Dia.
LPR
Protruding
Length
LUX
Usable
Length Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
1TJ1D-0600779R01 0.625 0.75 0.72 2.66 2 0.625
1TJ1D-0701284R01 0.750 1.25 1.20 3.25 3 0.750
1TJ1D-0801284R01 0.875 1.25 1.25 3.25 3 0.750
1TJ1D-1001780R01 1.000 1.75 1.72 4.00 4 1.000
1TJ1D-1001784R01 1.000 1.75 1.72 3.75 4 0.750
1TJ1D-1201781R01 1.250 1.75 1.72 4.00 5 1.250
1TJ1D-1201784R01 1.250 1.75 1.75 3.75 5 0.750
1TJ1D-1501784R01 1.500 1.75 1.75 3.75 6 0.750
1TJ1D-1502281R01 1.500 2.25 2.25 4.50 6 1.250
CoolantPocketingCorkscrew FacingRampChannelShoulder
90º END MILLS (6MM INSERT)
Cutter Body must be relieved for use with insert corner radii larger than R.031”; (Body R = Insert R -.02").
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
SERIES 1TJ1D (WELDON SHANK)
06
Cutter Body must be relieved for use with insert corner radii larger than R.031”; (Body R = Insert R -.02").
Designed with modification in mind. Extend usable length by turning back the neck diameter or shorten the overall length by cutting off back end.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
OAL
LPR
DC
LUX
DCON
.24APMX
90°KAPR WEP - See insert drawing for wiper options.
WEP
Part Number DC
Cutting
Dia.
LPR
Protruding
Length
LUX
Usable
Length Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
1TJ1D-06020S6R01 0.625 2.09 1.25 4.00 2 0.625
1TJ1D-07030S7R01 0.750 3.00 1.25 5.00 3 0.750
1TJ1D-10037S1R01 1.000 3.75 1.25 6.00 4 1.000
1TJ1D-12042S9R01 1.250 4.25 1.25 6.50 5 1.250
1TJ1D-15047S5R01 1.500 4.75 1.25 7.00 6 1.500
CoolantPocketingCorkscrew FacingRampChannelShoulder
90º END MILLS (6MM INSERT)
SERIES 1TJ1D (CYLINDRICAL SHANK)
06
FORMERLY
FORMERLY
33
milling
OAL
LF
.24APMX
DC
WEP
CCMS
90°KAPR WEP - See insert drawing for wiper options.
1TJ1D-2501940R01 2.500 1.90 5.90 5 Bridgeport R8
1TJ1D-3001940R01 3.000 1.90 5.90 5 Bridgeport R8
CoolantPocketingCorkscrew FacingRampChannelShoulder
90º END MILLS (6MM INSERT)
Part Number DC
Cutting
Dia.
LF
Functional
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
CCMS
Connection Code
Machine Side
Cutter Body must be relieved for use with insert corner radii larger than R.031”; (Body R = Insert R -.02").
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
SERIES 1TJ1D (KNEE MILL R8 STYLE)
06
DC DCON
.24APMX
90°KAPR
OAL
LPR
WEP - See insert drawing for wiper options.
WEP
1TJ1D-10012S7R01 1.000 1.25 3.25 3 0.750
1TJ1D-15012S7R01 1.500 1.25 3.25 4 0.750
1TJ1D-20012S7R01 2.000 1.25 3.25 5 0.750
CoolantPocketingCorkscrew FacingRampChannelShoulder
90º END MILLS (6MM INSERT)
Part Number DC
Cutting
Dia.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
Cutter Body must be relieved for use with insert corner radii larger than R.031”; (Body R = Insert R -.02").
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
Ideal on Knee mills when coupled with toolholder series R8ER.
SERIES 1TJ1D (KNEE MILL CYLINDRICAL SHANK)
06 FORMERLY
FORMERLY
34
CCMS
DHUB
DC
WEP
LF
90°KAPR
.24APMX
WEP - See insert drawing for wiper options.
1TJ1D-06008TRR01 0.625 0.80 2 T10 0.61
1TJ1D-07010TSR01 0.750 1.00 3 T12 0.73
1TJ1D-10012TUR01 1.000 1.25 4 T15 0.95
CoolantPocketingCorkscrew FacingRampChannelShoulder
90º MODULAR END MILLS (6MM INSERT)
Part Number DC
Cutting
Dia.
LF
Protruding
Length
ZEFF
Eff.
Teeth
CCMS
Connection
Code
DHUB
Hub
Dia.
Cutter Body must be relieved for use with insert corner radii larger than R.031”; (Body R = Insert R -.02").
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
DC
LF
DHUB
CCMS
.24APMX
90°KAPR WEP - See insert drawing for wiper options.
WEP
Part Number DC
Cutting
Dia.
LF
Functional
Length
ZEFF
Eff.
Teeth
CCMS
Connection
Code
DHUB
Hub
Dia.
1TJ1D-07015X6R01 0.750 1.50 3 M10 0.69
1TJ1D-10015X7R01 1.000 1.50 4 M12 0.81
1TJ1D-12017X8R01 1.250 1.75 5 M16 1.13
1TJ1D-15017X8R01 1.500 1.75 6 M16 1.13
CoolantPocketingCorkscrew FacingRampChannelShoulder
90º MODULAR END MILLS
Cutter Body must be relieved for use with insert corner radii larger than R.031”; (Body R = Insert R -.02").
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
SERIES 1TJ1D (TOP•ON STYLE)
06
SERIES 1TJ1D (CHIP•SURFER STYLE)
06
FORMERLY
FORMERLY
35
milling
DCON
KWW
90°KAPR
OAL
DC
.24APMX
WEP
WEP - See insert drawing for wiper options.
TJ1D-15R01 1.500 1.57 6 0.500 0.250
TJ1D-20R01 2.000 1.57 7 0.750 0.312
TJ1D-25R01 2.500 1.57 8 0.750 0.312
TJ1D-30R01 3.000 1.75 9 1.000 0.375
CoolantPocketingCorkscrew FacingRampChannelShoulder
90º FACE MILLS (6MM INSERT)
Part Number DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Bore
Dia.
KWW
Keyway
Cutter Body must be relieved for use with insert corner radii larger than R.031”; (Body R = Insert R -.02").
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
SERIES TJ1D
06 FORMERLY
36
Part Number Application RE/BCH
Corner Radius/
Chamfer
BS
Wiper
Length
LE
Cutting Edge
Length
INSL
Length W1
Width S
Thickness
NOI
Number of
Inserts
IH
Insert
Hand
Grade
IN10K
IN2035
IN2504
IN2505
IN2510
IN2530
IN6515
MNHU060304R Multi-Purpose 0.015 R - 0.240 0.260 0.260 0.184 4 Right • •
MNHU060308R Multi-Purpose 0.031 R - 0.230 0.260 0.260 0.184 4 Right • • • •
MNHU060312R Multi-Purpose 0.047 R - 0.220 0.260 0.260 0.177 4 Right •
MNHU060316R Multi-Purpose 0.062 R - 0.210 0.260 0.260 0.180 4 Right • • • •
MNHU060320R Multi-Purpose 0.079 R - 0.200 0.260 0.260 0.165 4 Right •
MNHU060304R-PH SS/Hi-Temp/Ti 0.015 R - 0.240 0.260 0.260 0.184 4 Right • •
MNHU060308R-PH SS/Hi-Temp/Ti 0.031 R - 0.230 0.260 0.260 0.184 4 Right •••
MNHU060312R-PH SS/Hi-Temp/Ti 0.047 R - 0.220 0.260 0.260 0.177 4 Right •
MNHU060316R-PH SS/Hi-Temp/Ti 0.062 R - 0.210 0.260 0.260 0.180 4 Right •••
MNHU060320R-PH SS/Hi-Temp/Ti 0.079 R - 0.200 0.260 0.260 0.165 4 Right •
MNHU060304R-HW SS/Hi-Temp/Ti - Face Wiper 0.015 R 0.039 0.240 0.260 0.260 0.184 4 Right •
MNHU060308R-HW SS/Hi-Temp/Ti - Face Wiper 0.031 R 0.023 0.240 0.260 0.260 0.184 4 Right • •
MNHU060310R-SW Backdraft - Side Wiper 0.039 0.043 0.082 0.260 0.260 0.185 4 Right • •
MNHU060315R-SW Backdraft - Side Wiper 0.059 0.070 0.130 0.260 0.260 0.177 4 Right • •
MNHU060320R-SW Backdraft - Side Wiper 0.079 0.039 0.120 0.260 0.260 0.170 4 Right • •
MNCU060304FR-P Aluminum - Face Wiper 0.015 R 0.039 0.240 0.260 - 0.196 4 Right •
MNCU060308FR-P Aluminum - Face Wiper 0.031 R 0.023 0.230 0.260 0.260 0.190 4 Right •
W1 S
LE
INSL
RE
MNHU06-R MNHU06-PH
W1 S
LE
INSL
RE S
LE
INSL
RE
W1
BS
MNCU06-P
S
LE
INSL
RE
W1
BS
MNHU06-SW
W1 S
LE
BS
Back taper
INSL
RE
INSERTS
06
MNHU06-HW
-P
HF
-PH
HW
-R
SW
UNHU06_HF
S
RE
IC
LE
Part Number Application REEQ
Program Radius
Equivalent
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2504
IN2530
IN2505
UNHU060320R-HF Hi-Feed 0.078 0.039 0.260 0.260 0.152 4 Right •••
FORMERLY
37
milling
Backdraft
.06APMX
(using R.06 insert)
90°KAPR
DC
CCMS
DHUB
LF
1TV1D-06208TRR10 0.625 0.80 2 T10 0.60 91
1TV1D-07010TSR02 0.750 1.00 3 T12 0.72 93
1TV1D-10012TUR02 1.000 1.25 4 T15 0.95 93
CoolantPocketingCorkscrew FacingRampChannelShoulder
BACKDRAFT END MILLS (6MM INSERT)
Part Number DC
Cutting
Dia.
LF
Protruding
Length
ZEFF
Eff.
Teeth
CCMS
Connection
Code
DHUB
Hub
Dia.
KAPR
Cutting
Edge Angle
Cutter Body must be relieved for use with insert corner radii larger than R.031”; (Body R = Insert R -.02").
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
Recommend .020” maximum axial stepdown on straight wall finish applications.
Well suited for long reach applications.
Part Number Application RE/BCH
Corner Radius/
Chamfer
LE
Cutting Edge
Length
INSL
Length W1
Width S
Thickness
NOI
Number of
Inserts
IH
Insert
Hand
Grade
IN2035
IN2505
IN2510
IN2530
IN6515
MNHU060304R Multi-Purpose 0.015 R 0.240 0.260 0.260 0.184 4 Right • •
MNHU060308R Multi-Purpose 0.031 R 0.230 0.260 0.260 0.184 4 Right • • • •
MNHU060312R Multi-Purpose 0.047 R 0.220 0.260 0.260 0.177 4 Right •
MNHU060316R Multi-Purpose 0.062 R 0.210 0.260 0.260 0.180 4 Right • • • •
MNHU060320R Multi-Purpose 0.079 R 0.200 0.260 0.260 0.165 4 Right •
MNHU060304R-PH SS/Hi-Temp/Ti 0.015 R 0.240 0.260 0.260 0.184 4 Right • •
MNHU060308R-PH SS/Hi-Temp/Ti 0.031 R 0.230 0.260 0.260 0.184 4 Right • • •
MNHU060312R-PH SS/Hi-Temp/Ti 0.047 R 0.220 0.260 0.260 0.177 4 Right •
MNHU060316R-PH SS/Hi-Temp/Ti 0.062 R 0.210 0.260 0.260 0.180 4 Right • • •
MNHU060320R-PH SS/Hi-Temp/Ti 0.079 R 0.200 0.260 0.260 0.165 4 Right •
W1 S
LE
INSL
RE
MNHU06-R MNHU06-PH
W1 S
LE
INSL
RE
SERIES 1TV1D (CHIP•SURFER STYLE)
06
SERIES 1TV1D INSERTS
06
-PH
-R
FORMERLY
FORMERLY
38
HARDWARE
06
1TJ1D-06020S6R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-07030S7R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-10037S1R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-12042S9R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-15047S5R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-0600779R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-0701284R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-0801284R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-1001780R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-1001784R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-1201781R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-1201784R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-1501784R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-1502281R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-10012S7R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-15012S7R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-20012S7R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-2501940R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-3001940R01 SM30-068-30 DS-T08W - - - - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-07015X6R01 SM30-068-30 DS-T08W - - 615MM - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-10015X7R01 SM30-068-30 DS-T08W - - 617MM - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-12017X8R01 SM30-068-30 DS-T08W - - 622MM - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-15017X8R01 SM30-068-30 DS-T08W - - 622MM - DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-06008TRR01 SM30-068-30 DS-T08W - - WS-0044 DT-250-13 DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-07010TSR01 SM30-068-30 DS-T08W - - WS-0059 DT-250-16 DS-A00-.25-S DT-11-.25 DS-T08B
1TJ1D-10012TUR01 SM30-068-30 DS-T08W - - WS-0061 DT-350-20 DS-A00-.25-S DT-11-.25 DS-T08B
1TV1D-06208TRR10 SM30-068-30 DS-T08W - - WS-0044 DT-250-13 DS-A00-.25-S DT-11-.25 DS-T08B
1TV1D-07010TSR02 SM30-068-30 DS-T08W - - WS-0059 DT-250-16 DS-A00-.25-S DT-11-.25 DS-T08B
1TV1D-10012TUR02 SM30-068-30 DS-T08W - - WS-0061 DT-350-20 DS-A00-.25-S DT-11-.25 DS-T08B
TJ1D-15R01 SM30-068-30 DS-T08W SD-04-46 - - - DS-A00-.25-S DT-11-.25 DS-T08B
TJ1D-20R01 SM30-068-30 DS-T08W SD-06-46 SD-06-89 - - DS-A00-.25-S DT-11-.25 DS-T08B
TJ1D-25R01 SM30-068-30 DS-T08W SD-06-46 SD-06-89 - - DS-A00-.25-S DT-11-.25 DS-T08B
TJ1D-30R01 SM30-068-30 DS-T08W SD-08-46 SD-08-92 - - DS-A00-.25-S DT-11-.25 DS-T08B
Screw Driver WrenchRetention Bolt Coolant Retention Bolt Torque Driver HandleTorque Wrench Preset Torque Bit Torque Driver Bit
**OPTIONAL** **OPTIONAL**
**OPTIONAL** **OPTIONAL** **OPTIONAL**
**OPTIONAL****OPTIONAL**
FORMERLY
39
milling
SERIES 1TJ1F (WELDON SHANK)
When using -HF insert, cutter body corner radius must be modified to R.12” for proper clearance.
Designed with modification in mind. Extend usable length by turning back the neck diameter or shorten the overall length by cutting off back end.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
09
OAL
LPR
.32APMX
DC
LUX
DCON
90°KAPR WEP - See insert drawing for wiper options.
WEP
OAL
LPR
.32APMX
DC
LUX
DCON
90°KAPR WEP - See insert drawing for wiper options.
WEP
Part Number DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
Part Number DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
1TJ1F-10057S1R01 1.000 2.40 5.75 8.00 3 1.000
1TJ1F-12077S9R01 1.250 2.90 7.75 10.00 4 1.250
1TJ1F-15073S5R01 1.500 2.90 7.34 10.00 5 1.500
1TJ1F-1001780R01 1.000 1.72 1.75 4.00 3 1.000
1TJ1F-1201781R01 1.250 1.72 1.75 4.00 4 1.250
1TJ1F-1502281R01 1.500 2.20 2.25 4.50 5 1.250
Coolant
Coolant
Pocketing
Pocketing
Corkscrew
Corkscrew
Facing
Facing
Ramp
Ramp
Channel
Channel
Shoulder
Shoulder
90° END MILLS (9MM INSERT)
90° END MILLS (9MM INSERT)
When using -HF insert, cutter body corner radius must be modified to R.12” for proper clearance.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
SERIES 1TJ1F (CYLINDRICAL SHANK)
09
40
SERIES 1TJ1F (TOP•ON STYLE)
09
DC
LF
DHUB
CCMS
.32APMX
90°KAPR WEP - See insert drawing for wiper options.
WEP
Part Number DC
Cutting
Dia.
LF
Functional
Length
ZEFF
Eff.
Teeth
CCMS
Connection
Code
DHUB
Hub
Dia.
1TJ1F-10015X7R01 1.000 1.50 3 TopOn M12 0.81
1TJ1F-12017X8R01 1.250 1.75 4 TopOn M16 1.13
1TJ1F-15017X9R01 1.500 1.75 5 TopOn M16 1.13
CoolantPocketingCorkscrew FacingRampChannelShoulder
90° MODULAR END MILLS (9MM INSERT)
When using -HF insert, cutter body corner radius must be modified to R.12” for proper clearance.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
SERIES TJ6F
DC
OAL
DCON KWW
.32APMX
90°KAPR
WEP
WEP - See insert drawing for wiper options.
TJ6F-15R01 1.500 1.570 5 0.500 0.250
TJ6F-20R01 2.000 1.570 6 0.750 0.312
TJ6F-25R01 2.500 1.570 7 0.750 0.312
TJ6F-30R01 3.000 1.750 9 1.000 0.375
TJ6F-40R01 4.000 2.375 11 1.500 0.625
CoolantPocketingCorkscrew FacingRampChannelShoulder
90° FACE MILLS (9MM INSERT)
Part Number DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Bore
Dia.
KWW
Keyway
When using -HF insert, cutter body corner radius must be modified to R.12” for proper clearance.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
09
41
milling
INSERTS
09
Part Number Application RE
Corner
Radius
BS
Wiper
Length
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2530
IN2510
IN2504
IN10K
MNHU090408R-M Multi-Purpose 0.031 - 0.314 0.338 0.338 0.232 4 Right ••••
MNHU090416R-M Multi-Purpose 0.062 - 0.314 0.338 0.338 0.224 4 Right •••
MNHU090404R-ML SS/Hi-Temp/Ti - Face Wiper 0.015 0.047 0.314 0.338 0.338 0.248 4 Right •
MNHU090408R-ML SS/Hi-Temp/Ti - Face Wiper 0.031 0.031 0.314 0.338 0.338 0.248 4 Right • •
MNCU090404FR-AL Grd/Pol for Al - Face Wiper 0.015 0.047 0.314 0.338 0.338 0.248 4 Right •
MNCU090408FR-AL Grd/Pol for Al - Face Wiper 0.031 0.031 0.314 0.338 0.338 0.244 4 Right •
W1 S
LE
INSL
RE
MNHU09-M
S
LE
INSL
RE
W1 BS
MNCU09_AL
W1 S
LE
INSL
RE
BS
S
RE
IC
LE
Part Number Application REEQ
Program Radius
Equivalent
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
UNHU090432R-HF Hi-Feed 0.125 0.059 0.338 0.338 0.187 4 Right •
HARDWARE
1TJ1F-1001780R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1
1TJ1F-1201781R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1
1TJ1F-1502281R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1
1TJ1F-10057S1R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1
1TJ1F-12077S9R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1
1TJ1F-15073S5R01 SM35-088-10 DS-A00T DS-T106B - - - DS-A00-.25-T DT-30-.25 DS-T10B1
1TJ1F-10015X7R01 SM35-088-10 DS-A00T DS-T106B - - 617MM DS-A00-.25-T DT-30-.25 DS-T10B1
1TJ1F-12017X8R01 SM35-088-10 DS-A00T DS-T106B - - 622MM DS-A00-.25-T DT-30-.25 DS-T10B1
1TJ1F-15017X9R01 SM35-088-10 DS-A00T DS-T106B - - 630MM DS-A00-.25-T DT-30-.25 DS-T10B1
TJ6F-15R01 SM35-088-10 DS-A00T DS-T106B SD-04-86 - - DS-A00-.25-T DT-30-.25 DS-T10B1
TJ6F-20R01 SM35-088-10 DS-A00T DS-T106B SD-06-46 SD-06-89 - DS-A00-.25-T DT-30-.25 DS-T10B1
TJ6F-25R01 SM35-088-10 DS-A00T DS-T106B SD-06-46 SD-06-89 - DS-A00-.25-T DT-30-.25 DS-T10B1
TJ6F-30R01 SM35-088-10 DS-A00T DS-T106B SD-08-46 SD-08-92 - DS-A00-.25-T DT-30-.25 DS-T10B1
TJ6F-40R01 SM35-088-10 DS-A00T DS-T106B SD-12-82 SD-12-99 - DS-A00-.25-T DT-30-.25 DS-T10B1
Screw Driver Handle Retention BoltTorx Driver Blade Wrench
Coolant Retention Bolt Torque Driver Handle Preset Torque Bit Torque Driver Bit
09
**OPTIONAL** **OPTIONAL**
**OPTIONAL****OPTIONAL** **OPTIONAL**
AL
ML
M
HF
MNHU09_ML
UNHU09_HF
42
SERIES 1TJ1G (WELDON SHANK)
.41APMX
90°KAPR
OAL
LPR
LUX
DCON
DC
WEP - See insert drawing for wiper options.
WEP
Part Number DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
1TJ1G-1001780R01 1.000 1.72 1.75 4.00 2 1.000
1TJ1G-1202281R01 1.250 2.22 2.25 4.50 3 1.250
1TJ1G-1502281R01 1.500 2.22 2.25 4.50 4 1.250
90° END MILLS (11MM INSERT)
When using -HF insert, cutter body corner radius must be modified to R.15” for proper clearance.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
11
CoolantPocketingCorkscrew FacingRampChannelShoulder
LF
DHUB
CCMS
.41APMX
90°KAPR
DC
WEP
WEP - See insert drawing for wiper options.
90° MODULAR END MILLS (11MM INSERT)
When using -HF insert, cutter body corner radius must be modified to R.15” for proper clearance.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
SERIES 1TJ1G (TOP•ON STYLE)
11
CoolantPocketingCorkscrew FacingRampChannelShoulder
Part Number DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
1TJ1G-10015X7R01 1.000 1.50 2 TopOn M12 0.81
1TJ1G-12017X8R01 1.250 1.75 3 TopOn M16 1.13
1TJ1G-15017X9R01 1.500 1.75 4 TopOn M20 1.41
43
milling
SERIES TJ5G, TJ6G
WEP - See insert drawing for wiper options.
WEP
OAL
DC
DCON
KWW
90°KAPR
.41APMX
TJ5G-20R01 2.000 1.750 5 0.750 0.312
TJ6G-20R01 2.000 1.750 4 0.750 0.312
TJ5G-25R01 2.500 1.750 6 1.000 0.375
TJ6G-25R01 2.500 1.750 4 1.000 0.375
TJ5G-30R01 3.000 1.750 8 1.000 0.375
TJ6G-30R01 3.000 1.750 6 1.000 0.375
TJ5G-40R01 4.000 2.375 10 1.500 0.625
TJ6G-40R01 4.000 2.375 7 1.500 0.625
CoolantPocketingCorkscrew FacingRampChannelShoulder
90° FACE MILLS (11MM INSERT)
Part Number DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Bore
Dia.
KWW
Keyway
When using -HF insert, cutter body corner radius must be modified to R.15” for proper clearance.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
11
Part Number Application RE
Corner
Radius
BS
Wiper
Length
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2530
IN2510
MNHU110608R-M Multi-Purpose 0.031 - 0.410 0.421 0.421 0.318 4 Right •••
MNHU110608PNR-M Multi-Purpose - Integrated Wiper 0.031 0.039 0.410 0.421 0.421 0.318 4 Right • •
S
LE
INSL
RE
W1 S
LE
INSL
RE
W1 BS
INSERTS
Part Number Application REEQ
Program Radius
Equivalent
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
UNHU110640R-HF Hi-Feed 0.157 0.078 0.421 0.421 0.240 4 Right •
11
S
RE
IC
LE
M
HF
MNHU11_M MNHU11_PNR-M UNHU11_HF
44
1TJ1G-1001780R01 SM40-100-10 DS-A00T DS-T156B - - - DS-A00-.25-T DT-35-.25 DS-T15B1
1TJ1G-1202281R01 SM40-100-10 DS-A00T DS-T156B - - - DS-A00-.25-T DT-35-.25 DS-T15B1
1TJ1G-1502281R01 SM40-100-10 DS-A00T DS-T156B - - - DS-A00-.25-T DT-35-.25 DS-T15B1
1TJ1G-10015X7R01 SM40-100-10 DS-A00T DS-T156B - - 617MM DS-A00-.25-T DT-35-.25 DS-T15B1
1TJ1G-12017X8R01 SM40-100-10 DS-A00T DS-T156B - - 622MM DS-A00-.25-T DT-35-.25 DS-T15B1
1TJ1G-15017X9R01 SM40-100-10 DS-A00T DS-T156B - - 630MM DS-A00-.25-T DT-35-.25 DS-T15B1
TJ5G-20R01 SM40-100-10 DS-A00T DS-T156B SD-06-46 SD-06-89 - DS-A00-.25-T DT-35-.25 DS-T15B1
TJ6G-20R01 SM40-100-10 DS-A00T DS-T156B SD-06-46 SD-06-89 - DS-A00-.25-T DT-35-.25 DS-T15B1
TJ5G-25R01 SM40-100-10 DS-A00T DS-T156B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-35-.25 DS-T15B1
TJ6G-25R01 SM40-100-10 DS-A00T DS-T156B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-35-.25 DS-T15B1
TJ5G-30R01 SM40-100-10 DS-A00T DS-T156B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-35-.25 DS-T15B1
TJ6G-30R01 SM40-100-10 DS-A00T DS-T156B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-35-.25 DS-T15B1
TJ5G-40R01 SM40-100-10 DS-A00T DS-T156B SD-12-82 SD-12-99 - DS-A00-.25-T DT-35-.25 DS-T15B1
TJ6G-40R01 SM40-100-10 DS-A00T DS-T156B SD-12-82 SD-12-99 - DS-A00-.25-T DT-35-.25 DS-T15B1
HARDWARE
11
Screw Driver Handle Retention BoltTorx Driver Blade Wrench
Coolant Retention Bolt Torque Driver Handle Preset Torque Bit Torque Driver Bit
**OPTIONAL** **OPTIONAL**
**OPTIONAL****OPTIONAL** **OPTIONAL**
.54APMX
90°KAPR
OAL
LPR
LUX
DCON
DC
WEP - See insert drawing for wiper options.
WEP
SERIES 1TJ1J (WELDON SHANK)
Part Number DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
1TJ1J-1202281R01 1.250 2.22 2.25 4.50 2 1.250
1TJ1J-1502281R01 1.500 2.22 2.25 4.50 3 1.250
90° END MILLS (14MM INSERT)
When using -HF insert, cutter body corner radius must be modified to R.19” for proper clearance.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
14
CoolantPocketingCorkscrew FacingRampChannelShoulder
45
milling
LF
DHUB
CCMS
.54APMX
90°KAPR
DC
WEP
WEP - See insert drawing for wiper options.
90° MODULAR END MILLS (14MM INSERT)
When using -HF insert, cutter body corner radius must be modified to R.19” for proper clearance.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
SERIES 1TJ1J (TOP•ON STYLE)
14
CoolantPocketingCorkscrew FacingRampChannelShoulder
Part Number DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
1TJ1J-12017X8R01 1.250 1.75 2 TopOn M16 1.13
1TJ1J-15017X9R01 1.500 1.75 3 TopOn M20 1.41
SERIES TJ5J, TJ6J
WEP - See insert drawing for wiper options.
90°KAPR
.54APMX
WEP
OAL
DC
DCON
KWW
TJ5J-20R01 2.000 1.750 4 0.750 0.312
TJ5J-25R01 2.500 1.750 6 1.000 0.375
TJ6J-25R01 2.500 1.750 4 1.000 0.375
TJ5J-30R01 3.000 1.750 7 1.000 0.375
TJ6J-30R01 3.000 1.750 5 1.000 0.375
TJ5J-40R01 4.000 2.375 9 1.500 0.625
TJ6J-40R01 4.000 2.375 6 1.500 0.625
CoolantPocketingCorkscrew FacingRampChannelShoulder
90° ROUGH & RAMP FACE MILL (14MM INSERT)
Part Number DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Bore
Dia.
KWW
Keyway
When using -HF insert, cutter body corner radius must be modified to R.19” for proper clearance.
Refer to New Product Announcement for Ramp Angle data (sorted by insert corner radius).
14
46
Part Number Application RE
Corner
Radius
BS
Wiper
Length
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2530
IN2510
MNHU140708R-M Multi-Purpose 0.031 - 0.540 0.551 0.551 0.362 4 Right • • •
MNHU140708PNR-M Multi-Purpose - Integrated Wiper 0.031 0.049 0.540 0.551 0.551 0.381 4 Right • •
S
LE
INSL
RE
W1
MNHU14_M MNHU14_PNR-M
S
LE
INSL
RE
W1 BS
INSERTS
Part Number Application REEQ
Program Radius
Equivalent
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
UNHU140750R-HF Hi-Feed 0.196 0.118 0.551 0.551 0.267 4 Right •
14
UNHU14_HF
S
RE
IC
LE
M
HF
HARDWARE
14
1TJ1J-1202281R01 SM50-127-10 DS-A00T DS-T206B - - - DS-A00-.25-T DT-44-.25 DS-T20B1
1TJ1J-1502281R01 SM50-127-10 DS-A00T DS-T206B - - - DS-A00-.25-T DT-44-.25 DS-T20B1
1TJ1J-12017X8R01 SM50-127-10 DS-A00T DS-T206B - - 622MM DS-A00-.25-T DT-44-.25 DS-T20B1
1TJ1J-15017X9R01 SM50-127-10 DS-A00T DS-T206B - - 630MM DS-A00-.25-T DT-44-.25 DS-T20B1
TJ5J-20R01 SM50-127-10 DS-A00T DS-T206B SD-06-47 SD-06-A6 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ5J-25R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ6J-25R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ5J-30R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ6J-30R01 SM50-127-10 DS-A00T DS-T206B SD-08-47 SD-08-C9 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ5J-40R01 SM50-127-10 DS-A00T DS-T206B SD-12-89 SD-12-99 - DS-A00-.25-T DT-44-.25 DS-T20B1
TJ6J-40R01 SM50-127-10 DS-A00T DS-T206B SD-12-89 SD-12-99 - DS-A00-.25-T DT-44-.25 DS-T20B1
Screw Driver Handle Retention BoltTorx Driver Blade Wrench
Coolant Retention Bolt Torque Driver Handle Preset Torque Bit Torque Driver Bit
**OPTIONAL** **OPTIONAL**
**OPTIONAL****OPTIONAL** **OPTIONAL**
47
milling
3-EDGED HIPOSTRIO INSERTS PRICED LIKE 2-EDGED HIPOS PRODUCT = 1 FREE EDGE!
• High positive cutting geometry; ideal for small machines and gummy materials
• Four insert sizes for complete cutter diameter, depth & density coverage
• Ramping capability for cutting versatility
• Inserts with integrated wiper flats typically produce surface finishes between 32-63 Ra
• Cutters ported with coolant
OAL
LPR
LUX
DCON
.13APMX
DC
WEP 90°KAPR
WEP - See insert drawing for wiper options.
Part Number DC
Cutting
Diameter
LUX
Usable Length
Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Shank
Diameter
RMPX
Ramp Angle
Max.
1KJ1B-03006R7R01 0.312 0.62 1.58 3.00 1 0.312 2.1
1KJ1B-03007R8R01 0.375 0.75 1.58 3.00 1 0.375 2.1
1KJ1B-04007S4R01 0.437 0.75 1.22 3.00 2 0.500 3.0
1KJ1B-05008S4R01 0.500 0.87 1.72 3.50 3 0.500 2.5
1KJ1B-05010S6R01 0.562 1.00 1.59 3.50 3 0.625 2.2
1KJ1B-06010S6R01 0.625 1.00 1.59 3.50 4 0.625 1.6
90° END MILL (4MM INSERT)
SERIES 1KJ1B (CYLINDRICAL SHANK)
DC
WEP .13APMX
LF
90°KAPR
DHUB
CCMS
WEP - See insert drawing for wiper options.
Part Number DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
RMPX
Ramp Angle
Max.
1KJ1B-03006T6R01 0.375 0.63 2 Chip Surfer T06 0.36 2.1
1KJ1B-05006T8R01 0.500 0.65 3 Chip Surfer T08 0.48 2.5
1KJ1B-06008TRR01 0.625 0.80 4 Chip Surfer T10 0.60 1.6
90° MODULAR END MILL (4MM INSERT)
SERIES 1KJ1B (CHIP•SURFER STYLE)
Designed with modification in mind. Extend usable length by turning back the neck diameter or shorten the overall length by cutting off back end.
Helical/Corkscrew
Helical/Corkscrew
Shoulder
Shoulder
Channeling
Channeling
Ramping
Ramping
Coolant
Coolant
Facing
Facing
04
04
48
WEP .13APMX
90°KAPR
DHUB
CCMS
DC
LF
WEP - See insert drawing for wiper options.
Part Number DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
RMPX
Ramp Angle
Max.
1KJ1B-05075X4R01 0.500 0.75 3 TopOn M06 0.46 2.5
1KJ1B-06087X5R01 0.625 0.88 4 TopOn M08 0.50 1.6
90° MODULAR END MILL (4MM INSERT)
04 SERIES 1KJ1B (TOP•ON STYLE)
S
BS
LE
RE
IC
THLS04_M
INSERTS
Part Number Application RE
Corner
Radius
BS
Wiper
Length
LE
Cutting Edge
Eff. Length
IC
Inscribed
Circle Dia.
S
Thickness
IH
Insert
Hand
Grade
IN2505
IN2530
THLS040202R-M Multi-Purpose 0.008 0.027 0.130 0.153 0.083 Right • •
THLS040204R-M Multi-Purpose 0.015 0.019 0.130 0.153 0.083 Right • •
Helical/Corkscrew
Shoulder Channeling Ramping Coolant
Facing
04
M
1KJ1B-03006R7R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1KJ1B-03007R8R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1KJ1B-04007S4R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1KJ1B-05008S4R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1KJ1B-05010S6R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1KJ1B-06010S6R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1KJ1B-03006T6R01 SM18-041-00 DS-TP06S-NEU - WS-0029 DT-90-08 DS-A00-.25-S DT-05-.25 DS-TP06B
1KJ1B-05006T8R01 SM18-041-00 DS-TP06S-NEU - WS-0030 DT-130-10 DS-A00-.25-S DT-05-.25 DS-TP06B
1KJ1B-06008TRR01 SM18-041-00 DS-TP06S-NEU - WS-0044 DT-250-13 DS-A00-.25-S DT-05-.25 DS-TP06B
1KJ1B-05075X4R01 SM18-041-00 DS-TP06S-NEU - - - DS-A00-.25-S DT-05-.25 DS-TP06B
1KJ1B-06087X5R01 SM18-041-00 DS-TP06S-NEU 610MM - - DS-A00-.25-S DT-05-.25 DS-TP06B
DriverInsert Screw
HARDWARE
Torque Driver Bit
**OPTIONAL**
Torque Driver Handle
**OPTIONAL**
Thin Wrench Torque Wrench
**OPTIONAL**
Wrench
**OPTIONAL** **OPTIONAL**
04
Preset Torque Bit
**OPTIONAL**
49
milling
OAL
WEP
LPR
LUX
DC DCON
.27APMX
90°KAPR WEP - See insert drawing for wiper options.
Part Number DC
Cutting
Diameter
LUX
Usable Length
Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Shank
Diameter
CSP
Coolant
RMPX
Ramp Angle
Max.
1KJ1D-0601279R01 0.625 1.22 1.25 3.25 1 0.625 Yes 4
1KJ1D-0702084R01 0.725 1.80 2.00 4.00 2 0.750 Yes 3.1
1KJ1D-0701184R01 0.750 1.05 1.25 3.25 2 0.750 Yes 3.1
1KJ1D-0701784R01 0.750 1.55 1.75 3.75 2 0.750 Yes 3.1
1KJ1D-0703084R01 0.750 2.80 3.00 5.00 2 0.750 Yes 3.1
1KJ1D-0801784R01 0.875 1.75 1.75 3.75 2 0.750 Yes 2.5
1KJ1D-1001780R01 1.000 1.55 1.75 4.00 3 1.000 Yes 2.1
1KJ1D-1001784R01 1.000 1.75 1.75 3.75 3 0.750 Yes 2.1
1KJ1D-1003780R01 1.000 3.38 3.75 6.00 3 1.000 Yes 2.1
1KJ1D-1003784R01 1.000 3.55 3.75 6.00 3 0.750 Yes 2.1
1KJ1D-1201780R01 1.250 1.75 1.75 4.00 5 1.000 Yes 1.5
1KJ1D-1201784R01 1.250 1.75 1.75 3.75 4 0.750 Yes 1.5
1KJ1D-1501780R01 1.500 1.75 1.75 4.00 6 1.000 Yes 1.3
1KJ1D-1501784R01 1.500 1.75 1.75 3.75 5 0.750 Yes 1.3
1KJ1D-1502281R01 1.500 2.25 2.25 4.50 6 1.250 Yes 1.3
Helical/Corkscrew
90° END MILL (06MM INSERT)
SERIES 1KJ1D (WELDON SHANK)
Shoulder Channeling Ramping Coolant
Facing
06 FORMERLY
50
WEP - See insert drawing for wiper options.
DHUB
CCMS
DC
LF
.27APMX
90°KAPR
WEP
Part Number DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
CSP
Coolant
RMPX
Ramp Angle
Max.
1KJ1D-07015X6R01 0.750 1.50 2 TopOn M10 .69 Yes 3.1
1KJ1D-10015X7R01 1.000 1.50 2 TopOn M12 .81 Yes 2.1
1KJ1D-10015X7R02 1.000 1.50 3 TopOn M12 .81 Yes 2.1
1KJ1D-12017X8R02 1.250 1.75 5 TopOn M16 1.13 Yes 1.5
1KJ1D-15017X8R01 1.500 1.75 5 TopOn M16 1.13 Yes 1.3
Helical/Corkscrew
90° MODULAR END MILL (06MM INSERT)
SERIES 1KJ1D (TOP•ON M-ADAPTION STYLE)
Shoulder Channeling Ramping Coolant
Facing
OAL
DC WEP
.27
APMX
90°
KAPR
DCON KWW
WEP - See insert drawing for wiper options.
Part Number DC
Cutting
Diameter
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Bore
Diameter
KWW
Keyway CSP
Coolant
RMPX
Ramp Angle
Max.
KJ5D-15R01 1.500 1.57 6 0.500 0.250 Yes 1.3
KJ5D-20R01 2.000 1.57 7 0.750 0.312 Yes 1.2
KJ6D-30R01 3.000 1.75 9 1.000 0.375 Yes .4
90° FACE MILL (06MM INSERT)
SERIES KJ5D, KJ6D
Helical/CorkscrewShoulder Channeling Ramping Coolant
Facing
06
06
FORMERLY
FORMERLY
51
milling
Part Number Application RE
Corner
Radius
BS
Wiper
Length
LE
Cutting
Edge
Length
IC
Inscribed
Circle
Diameter
S
Thickness
S
BS
LE
RE
IC
THES06 THES06_P THLS06
THES060404R Multi-Purpose; Ground Periphery 0.015 R 0.051 0.270 0.272 0.157 •
THES060408R Multi-Purpose; Ground Periphery 0.031 R 0.035 0.270 0.272 0.157 •
THES060404FR-P Grd/Pol for Al 0.015 R 0.051 0.270 0.272 0.157 •
THES060408FR-P Grd/Pol for Al 0.031 R 0.035 0.270 0.272 0.157 •
THLS060404R Multi-Purpose 0.015 R 0.051 0.270 0.272 0.157 • • • •
THLS060408R Multi-Purpose 0.031 R 0.035 0.270 0.272 0.157 • • • • • •
THLS060416R Multi-Purpose 0.062 R 0.022 0.270 0.272 0.157 • •
THLS060404R-HR SS/Hi-Temp/Ti 0.015 R 0.051 0.270 0.272 0.157 •
THLS060408R-HR SS/Hi-Temp/Ti 0.031 R 0.035 0.270 0.272 0.157 • • •
S
BS
LE
RE
IC
S
BS
LE
RE
IC
INSERTS
Grade
IN2510
IN2530
IN2540
IN4030
IN2505
IN10K
IN2035
IN2504
BS
LE
RE
IC
S
THLS06_HR
HARDWARE
1KJ1D-0601279R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-0702084R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-0701184R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-0701784R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-0703084R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-0801784R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-1001780R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-1001784R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-1003780R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-1003784R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-1201780R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-1201784R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-1501780R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-1501784R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-1502281R01 SM25-065-R0 DS-T08W - - - DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-07015X6R01 SM25-065-R0 DS-T08W - - 615MM DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-10015X7R01 SM25-065-R0 DS-T08W - - 617MM DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-10015X7R02 SM25-065-R0 DS-T08W - - 617MM DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-12017X8R02 SM25-065-R0 DS-T08W - - 622MM DS-A00-.25-S DT-11-.25 DS-TP08B
1KJ1D-15017X8R01 SM25-065-R0 DS-T08W - - 622MM DS-A00-.25-S DT-11-.25 DS-TP08B
KJ5D-15R01 SM25-065-R0 DS-T08W SD-04-46 - - DS-A00-.25-S DT-11-.25 DS-TP08B
KJ5D-20R01 SM25-065-R0 DS-T08W SD-06-46 SD-06-89 - DS-A00-.25-S DT-11-.25 DS-TP08B
KJ6D-30R01 SM25-065-R0 DS-T08W SD-08-46 SD-08-92 - DS-A00-.25-S DT-11-.25 DS-TP08B
Screw DriverInsert Screw Retention Bolt Retention Bolt w/Coolant Wrench
06
06
Torque Driver Bit
**OPTIONAL**
Torque Driver Handle
**OPTIONAL**
Preset Torque Bit
**OPTIONAL**
HR
P
R
FORMERLY
FORMERLY
52
OAL
WEP
LPR
LUX
DC DCON
.41APMX
90°KAPR WEP - See insert drawing for wiper options.
Part Number DC
Cutting
Diameter
LUX
Usable Length
Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Shank
Diameter
CSP
Coolant
RMPX
Ramp Angle
Max.
1KJ1G-1201784R01 1.250 1.75 1.75 3.75 3 0.750 Yes 2.3
1KJ1G-1202281R01 1.250 2.05 2.25 4.50 2 1.250 Yes 2.3
1KJ1G-1202281R02 1.250 2.05 2.25 4.50 3 1.250 Yes 2.3
1KJ1G-1204281R01 1.250 4.05 4.25 6.50 3 1.250 Yes 0
1KJ1G-1502281R01 1.500 2.20 2.25 4.50 3 1.250 Yes 1.8
1KJ1G-1502281R02 1.500 2.20 2.25 4.50 4 1.250 Yes 1.8
1KJ1G-1504281R01 1.500 4.25 4.25 6.50 3 1.250 Yes 0
1KJ1G-2002281R01 2.000 2.25 2.25 4.50 5 1.250 Yes 1.5
90° END MILL (10MM INSERT)
SERIES 1KJ1G (WELDON SHANK)
10
Helical/CorkscrewShoulder Channeling Ramping Coolant
Facing
DHUB
CCMS
DC
LF
WEP .41APMX
90°KAPR WEP - See insert drawing for wiper options.
Part Number DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
CSP
Coolant
RMPX
Ramp Angle
Max.
1KJ1G-12017X8R01 1.250 1.50 3 TopOn M16 1.13 Yes 2.3
1KJ1G-15017X8R01 1.500 1.75 4 TopOn M16 1.13 Yes 1.8
90° MODULAR END MILL (10MM INSERT)
SERIES 1KJ1G (TOP•ON M-ADAPTION STYLE)
10
Helical/CorkscrewShoulder Channeling Ramping Coolant
Facing
FORMERLY
FORMERLY
53
milling
OAL
DC WEP
.41
APMX
90°
KAPR
DCON
KWW
WEP - See insert drawing for wiper options.
Part Number DC
Cutting
Diameter
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Bore
Diameter
KWW
Keyway CSP
Coolant
RMPX
Ramp Angle
Max.
KJ6G-15R01 1.500 1.375 4 0.500 0.250 Yes 1.4
KJ5G-20R01 2.000 1.570 5 0.750 0.312 Yes 1.5
KJ6G-20R01 2.000 1.570 3 0.750 0.312 Yes .8
KJ5G-25R01 2.500 1.570 6 0.750 0.312 Yes 1.1
KJ5G-30R01 3.000 1.750 8 1.000 0.375 Yes .8
KJ6G-30R01 3.000 1.750 5 1.000 0.375 Yes .8
KJ6G-30R02 3.000 1.750 3 1.000 0.375 Yes .8
KJ5G-40R02 4.000 2.375 10 1.500 0.625 Yes .6
KJ6G-40R02 4.000 2.375 8 1.500 0.625 Yes .6
KJ6G-50R02 5.000 2.375 11 1.500 0.625 Yes .5
90° FACE MILL (10MM INSERT)
SERIES KJ5G, KJ6G
10
Helical/CorkscrewShoulder Channeling Ramping Coolant
Facing
FORMERLY
54
Part Number Application RE
Corner
Radius
BS
Wiper
Length
LE
Cutting Edge
Length
IC
Inscribed
Circle
Diameter
S
Thickness
Grade
IN10K
IN2035
IN2504
IN2505
IN2510
IN2530
IN2540
IN4030
S
BS
LE
RE
IC
THES10 THES10_P THLS10
THES100504R Multi-Purpose; Ground Periphery 0.015 R 0.078 0.430 0.421 0.197 •
THES100508R Multi-Purpose; Ground Periphery 0.031 R 0.062 0.430 0.421 0.197 •
THES100516R Multi-Purpose; Ground Periphery 0.062 R 0.031 0.430 0.421 0.197 •
THES100504FR-P Grd/Pol for Al 0.015 R 0.078 0.430 0.421 0.197 •
THES100508FR-P Grd/Pol for Al 0.031 R 0.062 0.430 0.421 0.197 •
THLS100508R Multi-Purpose 0.031 R 0.062 0.430 0.421 0.197 • • • • • • •
THLS100516R Multi-Purpose 0.062 R 0.031 0.430 0.421 0.197 • •
THLS100524R Multi-Purpose 0.094 R 0.020 0.430 0.421 0.197 •
THLS100508R-HR SS/Hi-Temp/Ti 0.031 R 0.062 0.430 0.421 0.197 • • •
S
BS
LE
RE
IC
S
BS
LE
RE
IC
INSERTS
BS
S
LE
RE
IC
THLS10_HR
10 HR
P
R
HARDWARE
1KJ1G-1201784R01 SM40-100-R0 DS-A00T DS-T156B - - - DS-A00-.25-T DS-T15B1 DT-35-.25
1KJ1G-1202281R01 SM40-100-R0 DS-A00T DS-T156B - - - DS-A00-.25-T DS-T15B1 DT-35-.25
1KJ1G-1202281R02 SM40-100-R0 DS-A00T DS-T156B - - - DS-A00-.25-T DS-T15B1 DT-35-.25
1KJ1G-1204281R01 SM40-100-R0 DS-A00T DS-T156B - - - DS-A00-.25-T DS-T15B1 DT-35-.25
1KJ1G-1502281R01 SM40-100-R0 DS-A00T DS-T156B - - - DS-A00-.25-T DS-T15B1 DT-35-.25
1KJ1G-1502281R02 SM40-100-R0 DS-A00T DS-T156B - - - DS-A00-.25-T DS-T15B1 DT-35-.25
1KJ1G-1504281R01 SM40-100-R0 DS-A00T DS-T156B - - - DS-A00-.25-T DS-T15B1 DT-35-.25
1KJ1G-2002281R01 SM40-100-R0 DS-A00T DS-T156B - - - DS-A00-.25-T DS-T15B1 DT-35-.25
1KJ1G-12017X8R01 SM40-100-R0 DS-A00T DS-T156B - - 622MM DS-A00-.25-T DS-T15B1 DT-35-.25
1KJ1G-15017X8R01 SM40-100-R0 DS-A00T DS-T156B - - 622MM DS-A00-.25-T DS-T15B1 DT-35-.25
KJ6G-15R01 SM40-100-R0 DS-A00T DS-T156B SE04-15 - - DS-A00-.25-T DS-T15B1 DT-35-.25
KJ5G-20R01 SM40-100-R0 DS-A00T DS-T156B SD-06-46 SD-06-89 - DS-A00-.25-T DS-T15B1 DT-35-.25
KJ6G-20R01 SM40-100-R0 DS-A00T DS-T156B SD-06-46 SD-06-89 - DS-A00-.25-T DS-T15B1 DT-35-.25
KJ5G-25R01 SM40-100-R0 DS-A00T DS-T156B SD-06-46 SD-06-89 - DS-A00-.25-T DS-T15B1 DT-35-.25
KJ5G-30R01 SM40-100-R0 DS-A00T DS-T156B SD-08-46 SD-08-92 - DS-A00-.25-T DS-T15B1 DT-35-.25
KJ6G-30R01 SM40-100-R0 DS-A00T DS-T156B SD-08-46 SD-08-92 - DS-A00-.25-T DS-T15B1 DT-35-.25
KJ6G-30R02 SM40-100-R0 DS-A00T DS-T156B SD-08-46 SD-08-92 - DS-A00-.25-T DS-T15B1 DT-35-.25
KJ5G-40R01 SM40-100-R0 DS-A00T DS-T156B SD-12-89 SD-12-99 - DS-A00-.25-T DS-T15B1 DT-35-.25
KJ6G-40R01 SM40-100-R0 DS-A00T DS-T156B SD-12-89 SD-12-99 - DS-A00-.25-T DS-T15B1 DT-35-.25
KJ6G-50R01 SM40-100-R0 DS-A00T DS-T156B SD-12-89 SD-12-99 - DS-A00-.25-T DS-T15B1 DT-35-.25
Insert Screw Driver Handle Torx Driver Blade Wrench
Retention Bolt Retention Bolt w/Coolant
10
Torque Driver Handle Torque Driver Bit Preset Torque Bit
**OPTIONAL** **OPTIONAL****OPTIONAL**
FORMERLY
FORMERLY
55
milling
OAL
WEP
LPR
LUX
DC DCON
.57APMX
90°KAPR WEP - See insert drawing for wiper options.
Part Number DC
Cutting
Diameter
LUX
Usable Length
Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Shank
Diameter
CSP
Coolant
RMPX
Ramp Angle
Max.
1KJ1P-2002281R01 2.000 2.00 2.25 4.50 4 1.250 Yes 1.5
Helical/Corkscrew
SERIES 1KJ1P (WELDON SHANK)
Shoulder Channeling Ramping Coolant
Facing
OAL
DC WEP
.57
APMX
90°
KAPR
DCON
KWW
WEP - See insert drawing for wiper options.
Part Number DC
Cutting
Diameter
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Bore
Diameter
KWW
Keyway CSP
Coolant
RMPX
Ramp Angle
Max.
KJ5P-20R01 2.000 1.750 5 .750 0.312 Yes 1.5
KJ6P-20R01 2.000 1.750 4 .750 0.312 Yes 1.5
KJ5P-25R01 2.500 1.750 6 .750 0.312 Yes 1.5
KJ5P-30R01 3.000 1.750 7 1.000 0.375 Yes 1.0
KJ6P-30R01 3.000 1.750 6 1.000 0.375 Yes 1.0
KJ5P-40R02 4.000 2.375 8 1.500 0.625 Yes .7
KJ6P-40R02 4.000 2.375 6 1.500 0.625 Yes .7
KJ6P-50R02 5.000 2.000 9 1.500 0.625 Yes .8
KJ5P-60R01 6.000 2.000 12 1.500 0.625 No .6
KJ6P-60R01 6.000 2.000 8 1.500 0.625 No .6
KJ6P-65R01* 6.500 2.000 10 1.500 0.625 No .4
90° FACE MILL (13MM INSERT)
90° END MILL (13MM INSERT)
SERIES KJ5P, KJ6P
Helical/CorkscrewShoulder Channeling Ramping Coolant
Facing
13
13
FORMERLY
FORMERLY
* Ideal for Boring Mills with a 6.0 Quill.
56
Part Number Application RE
Corner
Radius
BS
Wiper
Length
LE
Cutting Edge
Length
IC
Inscribed
Circle
Diameter
S
Thickness
BS S
LE
RE
IC
THES13_P THLS13 THLS13_HR
THES130604FR-P Grd/Pol for Al 0.015 R 0.078 0.590 0.531 0.236 •
THES130608FR-P Grd/Pol for Al 0.031 R 0.078 0.590 0.531 0.236 •
THLS130608R Multi-Purpose 0.031 R 0.078 0.590 0.531 0.236 • • • • •
THLS130616R Multi-Purpose 0.062 R 0.047 0.590 0.531 0.236 • •
THLS130624R Multi-Purpose 0.094 R 0.024 0.590 0.531 0.236 •
THLS130632R Multi-Purpose 0.125 R 0.020 0.590 0.531 0.236 •
THLS130608R-HR SS/Hi-Temp/Ti 0.031 R 0.078 0.590 0.531 0.236 • • •
THLS130616R-HR SS/Hi-Temp/Ti 0.062 R 0.047 0.590 0.531 0.236 •
THLS130624R-HR SS/Hi-Temp/Ti 0.094 R 0.024 0.590 0.531 0.236 •
THLS130632R-HR SS/Hi-Temp/Ti 0.125 R 0.020 0.590 0.531 0.236 •
BS S
LE
RE
IC
S
BS
LE
RE
IC
INSERTS
Grade
IN2510
IN2530
IN2540
IN4030
IN2505
IN10K
IN2035
13 HR
P
R
FORMERLY
HARDWARE
1KJ1P-2002281R01 SM45-120-R0 DS-A00T DS-T206B - - - DS-A00-.25-T DS-T20B1 DT-44-.25
KJ5P-20R01 SM45-100-R0 DS-A00T DS-T206B SB-04-15 - - DS-A00-.25-T DS-T20B1 DT-44-.25
KJ6P-20R01 SM45-100-R0 DS-A00T DS-T206B SB-04-15 - - DS-A00-.25-T DS-T20B1 DT-44-.25
KJ5P-25R01 SM45-120-R0 DS-A00T DS-T206B - SD-06-47 SD-06-89 DS-A00-.25-T DS-T20B1 DT-44-.25
KJ5P-30R01 SM45-120-R0 DS-A00T DS-T206B - SD-08-47 SD-08-92 DS-A00-.25-T DS-T20B1 DT-44-.25
KJ6P-30R01 SM45-120-R0 DS-A00T DS-T206B - SD-08-46 SD-08-92 DS-A00-.25-T DS-T20B1 DT-44-.25
KJ5P-40R02 SM45-120-R0 DS-A00T DS-T206B - - SD-12-99 DS-A00-.25-T DS-T20B1 DT-44-.25
KJ6P-40R02 SM45-120-R0 DS-A00T DS-T206B - - SD-12-99 DS-A00-.25-T DS-T20B1 DT-44-.25
KJ6P-50R02 SM45-120-R0 DS-A00T DS-T206B - - SD-12-99 DS-A00-.25-T DS-T20B1 DT-44-.25
KJ5P-60R01 SM45-120-R0 DS-A00T DS-T206B - - - DS-A00-.25-T DS-T20B1 DT-44-.25
KJ6P-60R01 SM45-120-R0 DS-A00T DS-T206B - - - DS-A00-.25-T DS-T20B1 DT-44-.25
KJ6P-65R01 SM45-120-R0 DS-A00T DS-T206B - - - DS-A00-.25-T DS-T20B1 DT-44-.25
Driver HandleInsert Screw Torx Driver Blade Retention Bolt
13
Torque Driver Handle Torque Driver Bit Preset Torque Bit
**OPTIONAL** **OPTIONAL**
**OPTIONAL**
Retention Bolt w/Coolant
Differential Screw
57
milling
MINI SIZED 90º SHOULDER AND HIGH-FEED MILLS WITH STRONG V-SHAPED INSERT
• FNKT-M is for 90°roughing, FNKT-L is for 90° finishing with lower cutting forces & UNKT-HF is for Hi-Feed Roughing
• 90° and Hi-Feed inserts fit the same pockets
• Integrated wiper flats produce 32-63 Ra surface finishes
• V-Bottom pocket fosters easy insert indexing, increased core diameter and minimizes insert screw stress
• High cutter densities with small IC insert sizes
• All cutters are plumbed with coolant through the tool
• Economical solid carbide alternative!
DC
LUX
LPR
OAL
DCON
.19APMX
90°KAPR
WEP - See insert drawing for wiper options.
WEP
SERIES 12J1A (WELDON SHANK)
Part Number DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
12J1A-0300977R01 0.375 0.90 0.94 2.50 3 0.375
12J1A-0400978R01 0.437 0.93 0.97 2.75 3 0.500
12J1A-0500978R01 0.500 0.93 0.97 2.75 4 0.500
12J1A-0501079R01 0.500 1.05 1.09 3.00 4 0.625
90° END MILL (5MM INSERT)
When using Hi-Feed Insert, modify body corner to R.070.
05
CoolantCorkscrew FacingRampChannelShoulder
58
DC
LUX
LPR
OAL
DCON
.19APMX
90°KAPR
WEP - See insert drawing for wiper options.
WEP
Part Number DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
12J1A-02005R6R01 0.250 0.45 1.08 2.50 1 0.250
12J1A-03005R7R01 0.312 0.45 1.08 2.50 2 0.312
12J1A-03006R8R01 0.375 0.60 1.08 2.50 3 0.375
12J1A-04006S4R01 0.437 0.60 1.22 3.00 3 0.500
12J1A-05006S4R01 0.500 0.60 1.22 3.00 4 0.500
90° END MILL (5MM INSERT)
CoolantCorkscrew FacingRampChannelShoulder
When using Hi-Feed Insert, modify body corner to R.070.
Designed with modification in mind. Extend usable length by turning back the neck diameter or shorten the overall length by cutting off back end.
SERIES 12J1A (CYLINDRICAL SHANK)
05
LF
DHUB
CCMS
.19APMX
90°KAPR
DC
WEP
WEP - See insert drawing for wiper options.
90° MODULAR END MILL (5MM INSERT)
When using Hi-Feed Insert, modify body corner to R.070.
CoolantCorkscrew FacingRampChannelShoulder
Part Number DC
Cutting
Diameter
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Teeth
KAPR
Cutting Edge
Angle
CCMS
Connection
Code
DHUB
Hub
Diameter
12J1A-05007X4R01 0.500 0.190 0.75 4 90 TopOn M06 0.38
SERIES 12J1A (TOP•ON STYLE)
05
59
milling
CCMS
DHUB
DC
LF
WEP 90°KAPR
.19APMX
WEP - See insert drawing for wiper options.
CoolantCorkscrew FacingRampChannelShoulder
90° MODULAR END MILL (5MM INSERT)
Part Number DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
12J1A-03006T6R01 0.375 0.63 3 Chip Surfer T06 0.36
12J1A-05006T8R01 0.500 0.65 4 Chip Surfer T08 0.48
When using Hi-Feed Insert, modify body corner to R.070.
SERIES 12J1A (CHIP•SURFER STYLE)
05
Part Number Application RE
Corner
Radius
BS
Wiper
Length
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2530
IN2005
FNKT050202R-M Multi-Purpose 0.008 0.013 0.190 0.248 0.165 0.102 2 Right • •
FNHT050202R-L Multi-Purpose, Keen Edge 0.008 0.013 0.190 0.248 0.165 0.102 2 Right • • •
W1
LE
INSL
RE
BS S
LE
INSL
RE S
W1
BS
Part Number Application REEQ
Program Radius
Equivalent
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2530
IN2504
UNKT0502TR-HF Hi-Feed 0.030 0.019 0.216 0.165 0.098 2 Right • • •
INSERTS
W1
LE
INSL
REEQ S
05
L
M
HF
FNKT05_M FNHT05_L UNKT05_HF
60
12J1A-0300977R01 SM18-033-00 DS-TP06S-NEU - - DS-A00-.25-S DT-06-.25 DS-TP06B
12J1A-0400978R01 SM18-033-00 DS-TP06S-NEU - - DS-A00-.25-S DT-06-.25 DS-TP06B
12J1A-0500978R01 SM18-033-00 DS-TP06S-NEU - - DS-A00-.25-S DT-06-.25 DS-TP06B
12J1A-0501079R01 SM18-033-00 DS-TP06S-NEU - - DS-A00-.25-S DT-06-.25 DS-TP06B
12J1A-02005R6R01 SM18-033-00 DS-TP06S-NEU - - DS-A00-.25-S DT-06-.25 DS-TP06B
12J1A-03005R7R01 SM18-033-00 DS-TP06S-NEU - - DS-A00-.25-S DT-06-.25 DS-TP06B
12J1A-03006R8R01 SM18-033-00 DS-TP06S-NEU - - DS-A00-.25-S DT-06-.25 DS-TP06B
12J1A-04006S4R01 SM18-033-00 DS-TP06S-NEU - - DS-A00-.25-S DT-06-.25 DS-TP06B
12J1A-05006S4R01 SM18-033-00 DS-TP06S-NEU - - DS-A00-.25-S DT-06-.25 DS-TP06B
12J1A-05007X4R01 SM18-033-00 DS-TP06S-NEU - - DS-A00-.25-S DT-06-.25 DS-TP06B
12J1A-03006T6R01 SM18-033-00 DS-TP06S-NEU WS-0029 DT-90-08 DS-A00-.25-S DT-06-.25 DS-TP06B
12J1A-05006T8R01 SM18-033-00 DS-TP06S-NEU WS-0030 DT-130-10 DS-A00-.25-S DT-06-.25 DS-TP06B
Screw Driver Thin Wrench
**OPTIONAL**
Torque Wrench
HARDWARE
**OPTIONAL**
05
Torque Driver Handle
**OPTIONAL**
Torque Driver Bit Preset Torque Bit
**OPTIONAL****OPTIONAL**
61
milling
THE EXPANSION OF OUR MOST POPULAR HIGH-FEED MILLING LINE TO INCLUDE
TWO NEW PRODUCT FAMILIES
• 3 distinct insert geometries provide an optimal solution across all material classes and application types
• Ingeniously designed insert mounting for reliabile and fast feed-rates
• All inserts include radial wipers for smooth profiling, shouldering and hole interpolation which can eliminate secondary operations
• End mills and face mills incorporating 5 distinct insert sizes and cutter diameters ranging from .375”- 7.000”
• GoldSFeed is the most complete and extensive High-Feed milling line in metalworking
Backdraft
90°KAPR2
REEQ
.02BS
.02APMX1 .065APMX2
.02BS
12°KAPR1
WEP - See insert drawing for wiper options.
DCX
DC
LUX
LPR
OAL
DCON
WEP
HIGH FEED END MILLS (4MM INSERT)
SERIES 15G1B (CYLINDRICAL SHANK)
04
Backdraft
90°KAPR2
REEQ
.02BS
.02APMX1 .065APMX2
.02BS
12°KAPR1
DCX DC
WEP
LF
DHUB
CCMS
WEP - See insert drawing for wiper options.
HIGH FEED END MILLS (4MM INSERT)
15G1B-03006T6R01 0.375 0.167 0.669 2 0.043 0.369 Chip Surfer T06 1.80
15G1B-05007T8R01 0.500 0.291 0.748 3 0.042 0.485 Chip Surfer T08 4.70
15G1B-06008TRR01 0.625 0.415 0.827 4 0.042 0.605 Chip Surfer T10 3.00
15G1B-07010TSR01 0.750 0.540 1.024 5 0.042 0.725 Chip Surfer T12 2.20
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
LF
Functional
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DHUB
Hub
Dia.
CCMS
Connection Code
Machine Side
RMPX
Ramp Angle
Max.
SERIES 15G1B (CHIP•SURFER STYLE)
04
15G1B-03015R8R01 0.375 0.167 1.300 1.500 0.043 2.920 2 0.375 1.80
15G1B-05015S4R01 0.500 0.291 1.300 1.500 0.042 3.280 3 0.500 4.70
15G1B-06015S6R01 0.625 0.415 1.300 1.500 0.042 3.410 4 0.625 3.00
15G1B-07015S7R01 0.750 0.540 1.300 1.500 0.042 3.500 5 0.750 2.20
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
LUX
Usuable Length
Max.
LPR
Protruding
Length
REEQ
Program Radius
Equivalent
OAL
Overall
Length
ZEFF
Effective
Teeth
DCON
Shank
Dia.
RMPX
Ramp Angle
Max.
Insert screw tightening torque: 10-14 in*lb.
Insert screw tightening torque: 10-14 in*lb.
Lead Angle Pocket Corkscrew Coolant
Facing Shoulder Ramp PlungeContour
Lead Angle Pocket Corkscrew Coolant
Facing Shoulder Ramp PlungeContour
62
DCX DC
WEP
LF
DHUB
CCMS
WEP - See insert drawing for wiper options.
Backdraft
90°KAPR2
REEQ
.02BS
.02APMX1 .065APMX2
.02BS
12°KAPR1
HIGH FEED END MILLS (4MM INSERT)
SERIES 15G1B (TOP•ON STYLE)
04
S
BS
RE
IC
SDXS0402MPR-MM
INSERTS
04
Part Number Application RE
Corner
Radius
BS
Wiper
Length
IC
Inscribed
Circle
S
Thickness
IH
Insert
Hand
Grade
IN2505
IN2530
SDXS0402MPR-MM Hi-Feed, Positive Geometry 0.021 0.022 04 mm 0.079 Right • •
SDXS0402MPR-MR High Feed, Heavy Duty 0.021 0.022 04 mm 0.079 Right • •
SDXS0402MPR-MR1 Hi-Feed, Heavy-Duty Keen Edge 0.021 0.022 04 mm 0.079 Right • •
15G1B-05007X4R01 0.500 0.291 0.75 3 0.042 0.465 TopOn M06 4.70
15G1B-06010X5R01 0.625 0.415 1.00 4 0.042 0.505 TopOn M08 3.00
15G1B-07010X6R01 0.750 0.540 1.00 5 0.043 0.704 TopOn M10 2.20
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
LF
Functional
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DHUB
Hub
Dia.
CCMS
Connection Code
Machine Side
RMPX
Ramp Angle
Max.
S
BS
RE
IC
SDXS0402MPR-MR1
IC
S
RE
BS
SDXS0402MPR-MR
Insert screw tightening torque: 10-14 in*lb.
Lead Angle Pocket Corkscrew Coolant
Facing Shoulder Ramp PlungeContour
MR1
MM
MR
63
milling
15G1B-03015R8R01 DS-TP06S-NEU TS18034I/HG-P
15G1B-05015S4R01 DS-TP06S-NEU TS18034I/HG-P
15G1B-06015S6R01 DS-TP06S-NEU SM18-041-00
15G1B-07015S7R01 DS-TP06S-NEU SM18-041-00
15G1B-03006T6R01 DS-TP06S-NEU TS18034I/HG-P
15G1B-05007T8R01 DS-TP06S-NEU TS18034I/HG-P
15G1B-06008TRR01 DS-TP06S-NEU SM18-041-00
15G1B-07010TSR01 DS-TP06S-NEU SM18-041-00
15G1B-05007X4R01 DS-TP06S-NEU TS18034I/HG-P
15G1B-06010X5R01 DS-TP06S-NEU SM18-041-00
15G1B-07010X6R01 DS-TP06S-NEU SM18-041-00
Driver Screw
HARDWARE
04
Insert screw tightening torque: 10-14 in*lb.
DCON
OAL
LPR
LUX
DCX DC
.06APMX
WEP
WEP - See insert drawing for wiper options.
Backdraft
90°KAPR2
.094REEQ
.150APMX2
12°KAPR1
.06BS
.06APMX1
.06BS
SERIES 15G1F (CYLINDRICAL SHANK)
15G1F-10019S1R01 1.000 0.524 1.78 1.97 7.00 3 0.094 12.0 1.000 5.5
15G1F-10020S1R01 1.000 0.524 1.81 2.00 10.00 3 0.094 12.0 1.000 5.5
15G1F-12047S9R01 1.250 0.773 4.55 4.75 8.00 3 0.094 12.0 1.250 3.3
15G1F-12047S9R02 1.250 0.773 4.55 4.75 8.00 4 0.094 12.0 1.250 3.3
15G1F-15060S9R01 1.500 1.022 6.00 6.00 10.00 4 0.094 12.0 1.250 2.3
15G1F-15060S9R02 1.500 1.022 6.00 6.00 10.00 5 0.094 12.0 1.250 2.3
HIGH FEED END MILLS (9MM INSERT)
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
KAPR
Cutting Edge
Angle
DCON
Shank
Dia.
RMPX
Ramp Angle
Max.
FORMERLY
09
Insert screw tightening torque: 14-18 in*lb.
Lead Angle Pocket Corkscrew CoolantFacing Shoulder Ramp PlungeContour
64
SERIES 15G1F (WELDON SHANK)
15G1F-12027E2R01 1.250 0.773 2.55 2.75 5.75 3 0.094 12° 1.250 3.3
15G1F-12027E2R02 1.250 0.773 2.55 2.75 5.75 4 0.094 12° 1.250 3.3
15G1F-12047E2R01 1.250 0.773 4.55 4.75 7.75 3 0.094 12° 1.250 3.3
15G1F-15016E2R01 1.500 1.022 1.69 1.69 6.00 4 0.094 12° 1.250 2.3
15G1F-15016E2R02 1.500 1.022 1.69 1.69 6.00 5 0.094 12° 1.250 2.3
HIGH FEED END MILLS (9MM INSERT)
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
KAPR
Cutting Edge
Angle
DCON
Shank
Dia.
RMPX
Ramp Angle
Max.
FORMERLY
09
DCX DC DCON
.06APMX
OAL
LPR
WEP
LUX
WEP - See insert drawing for wiper options.
Backdraft
90°KAPR2
.094REEQ
.150APMX2
12°KAPR1
.06BS
.06APMX1
.06BS
Insert screw tightening torque: 14-18 in*lb.
Lead Angle Pocket Corkscrew Coolant
Facing Shoulder Ramp PlungeContour
SERIES 15G1F (TOP•ON STYLE)
HIGH FEED END MILLS (9MM INSERT)
FORMERLY
09
DCX DHUBDC
.06APMX
WEP
CCMSLF
WEP - See insert drawing for wiper options.
Backdraft
90°KAPR2
.094REEQ
.150APMX2
12°KAPR1
.06BS
.06APMX1
.06BS
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
KAPR
Cutting Edge
Angle
DHUB
Hub
Diameter
CCMS
Connection
Code
RMPX
Ramp Angle
Max.
15G1F-10015X7R01 1.000 0.524 1.57 3 0.094 12.0 .82 TopOn M12 5.5
15G1F-12015X8R02 1.250 0.773 1.57 4 0.094 12.0 1.13 TopOn M16 3.3
15G1F-15017X9R01 1.500 1.022 1.57 5 0.094 12.0 1.42 TopOn M20 2.3
Insert screw tightening torque: 14-18 in*lb.
Lead Angle Pocket Corkscrew Coolant
Facing Shoulder Ramp PlungeContour
65
milling
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
KWW
Keyway
RMPX
Ramp
Angle Max.
5G5F-20R01 2.000 1.521 1.97 7 0.094 0.750 0.31 1.5
5G6F-20R01 2.000 1.521 1.97 6 0.094 0.750 0.31 1.5
5G5F-25R01 2.500 2.020 1.97 8 0.094 0.750 0.31 1.1
5G5F-30R01 3.000 2.520 2.00 9 0.094 1.000 0.38 .8
5G6F-30R01 3.000 2.520 2.00 7 0.094 1.000 0.38 .8
SERIES 5G5F, 5G6F
HIGH FEED FACE MILLS (9MM INSERT)
FORMERLY
09
OAL
DCX
.06APMX
DCON KWW
DC
WEP - See insert drawing for wiper options.
Backdraft
90°KAPR2
.094REEQ
.150APMX2
12°KAPR1
.06BS
.06APMX1
.06BS
Insert screw tightening torque: 14-18 in*lb.
Lead Angle Pocket Corkscrew Coolant
Facing Shoulder Ramp PlungeContour
SDXS0904MPR-MM SDXS0904MPR-MR SDXS0904MPR-MR1
S
BS
L
RE
S
BS
L
RE
S
BS
L
RE
SDXS0904MPR-MRH
S
BS
L
RE
INSERTS
09
Part Number Application RE
Corner
Radius
BS
Wiper
Length
L
Cutting Edge
Length
S
Thickness
Grade
IN2504
IN4005
IN2505
IN4030
IN2530
IN7035
IN4035
IN2535
SDXS0904MPR-MM Multi-Purpose .040 .060 .370 .158 •••••••
SDXS0904MPR-MR Heavy-Duty .040 .060 .370 .158 •••• ••
SDXS0904MPR-MR1 Flat-Top, Keen Edge .040 .060 .370 .158 •••••
SDXS0904MPR-MRH Hardened Steels .040 .060 .370 .158 •
FORMERLY
MR1
MM
MR
MRH
66
15G1F-10019S1R01 SM30-075-R0 DS-T09W - -
15G1F-10020S1R01 SM30-075-R0 DS-T09W - -
15G1F-10015X7R01 SM30-075-R0 DS-T09W - -
15G1F-12047S9R02 SM30-075-R0 DS-T09W - -
15G1F-12047S9R01 SM30-075-R0 DS-T09W - -
15G1F-12027E2R02 SM30-075-R0 DS-T09W - -
15G1F-12027E2R01 SM30-075-R0 DS-T09W - -
15G1F-12047E2R01 SM30-075-R0 DS-T09W - -
15G1F-12015X8R02 SM30-075-R0 DS-T09W - -
15G1F-15060S9R02 SM30-075-R0 DS-T09W - -
15G1F-15060S9R01 SM30-075-R0 DS-T09W - -
15G1F-15016E2R02 SM30-075-R0 DS-T09W - -
15G1F-15016E2R01 SM30-075-R0 DS-T09W - -
15G1F-15017X9R01 SM30-075-R0 DS-T09W - -
5G5F-20R01 SM30-075-R0 DS-T09W SD-06-48 SD06-A6
5G6F-20R01 SM30-075-R0 DS-T09W SD-06-48 SD06-A6
5G5F-25R01 SM30-075-R0 DS-T09W SD-06-48 SD06-A6
5G5F-30R01 SM30-075-R0 DS-T09W SD-08-47 SD-08-C9
5G6F-30R01 SM30-075-R0 DS-T09W SD-08-47 SD-08-C9
HARDWARE
09
Insert screw tightening torque: 14-18 in*lb.
DriverInsert Screw Coolant BoltRetention Bolt
**OPTIONAL**
FORMERLY
DCX
DC
DCON
WEP - See insert drawing for wiper options.
OAL
LPR
LUX
WEP
Backdraft
90°KAPR2
REEQ
12°KAPR1
.03BS
.078APMX1
.03BS
SERIES 15M1P
15M1P-1202781R01 1.250 0.423 2.00 2.75 5.00 2 0.125 1.250 Weldon 13.10
15M1P-12047S9R01 1.250 0.423 4.00 4.75 8.00 2 0.125 1.250 Cylindrical 13.10
15M1P-1502786R01 1.500 0.673 2.00 2.75 5.41 3 0.125 1.500 Weldon 7.10
15M1P-1505386R01 1.500 0.673 5.00 5.34 8.00 3 0.125 1.500 Weldon 7.10
HIGH FEED END MILLS (13MM INSERT)
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
RMPX*
Ramp Angle
Max.
FORMERLY
13
* All of the above data is with insert SDES1305MDR installed. Please see Technical Literature for dimensions when using other inserts.
Insert screw tightening torque: 30-35 in*lb.
Lead Angle Pocket Corkscrew CoolantFacing Shoulder Ramp PlungeContour
67
milling
SERIES 15M1P (TOP•ON STYLE) FORMERLY
13
Backdraft
90°KAPR2
REEQ
12°KAPR1
.03BS
.078
APMX1
.03BS
DCX DC
WEP
LF
DHUB
CCMS
WEP - See insert drawing for wiper options.
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DHUB
Hub
Diameter
CCMS
Connection
Code
RMPX*
Ramp Angle
Max.
15M1P-12017X8R01 1.250 0.423 0.088 1.75 2 0.125 1.13 TopOn M16 13.10
HIGH FEED END MILLS (13MM INSERT)
* All of the above data is with insert SDES1305MDR installed. Please see Technical Literature for dimensions when using other inserts.
Insert screw tightening torque: 30-35 in*lb.
Lead Angle Pocket Corkscrew CoolantFacing Shoulder Ramp PlungeContour
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Bore
Dia.
KWW
Keyway
RMPX*
Ramp
Angle Max.
REEQ
Program Radius
Equivalent
5M5P-20R01 2.000 1.170 2.000 5 0.750 0.313 3.90 0.125
5M6P-20R01 2.000 1.170 2.000 4 0.750 0.313 3.90 0.125
5M5P-25R01 2.500 1.670 2.000 6 0.750 0.313 2.70 0.125
5M6P-25R01 2.500 1.670 2.000 5 0.750 0.313 2.70 0.125
5M5P-30R01 3.000 2.170 2.000 8 1.000 0.375 1.60 0.125
5M5P-30R02 3.000 2.170 2.000 8 1.250 0.500 1.60 0.125
5M6P-30R01 3.000 2.170 2.000 6 1.000 0.375 1.60 0.125
5M6P-30R02 3.000 2.170 2.000 6 1.250 0.500 1.60 0.125
5M5P-40R01 4.000 3.170 2.500 10 1.500 0.625 1.10 0.125
5M6P-40R01 4.000 3.170 2.500 8 1.500 0.625 1.10 0.125
5M5P-50R01 5.000 4.170 2.500 11 1.500 0.625 0.80 0.125
5M6P-50R01 5.000 4.170 2.500 9 1.500 0.625 0.80 0.125
SERIES 5M5P, 5M6P FORMERLY
13
WEP - See insert drawing for wiper options.
Backdraft
90°KAPR2
REEQ
12°KAPR1
.03BS
.078
APMX1
.03BS
OAL
DCX
DC
DCON KWW
WEP
HIGH FEED END MILLS (13MM INSERT)
* All of the above data is with insert SDES1305MDR installed. Please see Technical Literature for dimensions when using other inserts.
Insert screw tightening torque: 30-35 in*lb.
Lead Angle Pocket Corkscrew CoolantFacing Shoulder Ramp PlungeContour
68
INSERTS
13
Part Number Application RE
Corner
Radius
BS
Wiper
Length
IC
Inscribed
Circle
S
Thickness
Grade
IN2505
IN2530
IN4005
IN4030
IN4035
SDES1305MDR Hi-Feed, Flat Face / Wiper - Facets .125 0.030 13 mm .200 • •
SDMS1305MDR-PH Hi-Feed, Pos Precision / Wiper - Facets .125 0.030 13 mm .200 •••••
SDES1305MDR-001 Hi-Feed, Precision Flat Face / Wiper - Facets .125 0.030 13 mm .200 • •
SDES1305MPR Hi-Feed, Heavy Duty - Standard .140 0.060 13 mm .200 • • • •
SDES1305MPR-001 Hi-Feed, Heavy Duty - Precision .140 0.060 13 mm .200 •••••
FORMERLY
SDMS1305MDR-PH
IC
S
BS
BS
60°
12°
SDES1305MDR
IC
S
BS
BS
60°
12°
SDES1305MDR-001
IC
S
BS
BS
60°
12°
SDES1305MPR-001
IC
S
RE
BS
SDES1305MPR
IC
S
RE
BS
15M1P-1202781R01 SM40-100-R0 DS-A00T BLD T15/S7 - -
15M1P-12047S9R01 SM40-100-R0 DS-A00T BLD T15/S7 - -
15M1P-1502786R01 SM40-100-R0 DS-A00T BLD T15/S7 - -
15M1P-1505386R01 SM40-100-R0 DS-A00T BLD T15/S7 - -
15M1P-12017X8R01 SM40-100-R0 DS-A00T BLD T15/S7 - -
5M5P-20R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-06-48 SD06-A6
5M6P-20R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-06-48 SD06-A6
5M5P-25R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-06-48 SD06-A6
5M6P-25R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-06-48 SD06-A6
5M5P-30R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-08-47 SD-08-92
5M6P-30R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-08-47 SD-08-92
5M5P-30R02 SM40-100-R0 DS-A00T BLD T15/S7 SD-10-47 SD-10-99
5M6P-30R02 SM40-100-R0 DS-A00T BLD T15/S7 SD-10-47 SD-10-99
5M5P-40R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-12-82 SD-12-99
5M6P-40R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-12-82 SD-12-99
5M5P-50R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-12-82 SD-12-99
5M6P-50R01 SM40-100-R0 DS-A00T BLD T15/S7 SD-12-82 SD-12-99
HARDWARE
13
DriverInsert Screw Coolant BoltRetention Bolt
**OPTIONAL**
FORMERLY
Driver Bit
Insert screw tightening torque: 30-35 in*lb.
001 PH
69
milling
WEP - See insert drawing for wiper options.
Backdraft
90°KAPR2
REEQ12°KAPR1
.107APMX1 .245APMX2
.08BS
.08BS
OAL
DCX
DC WEP
DCON KWW
5G5Q-25R01 2.500 1.645 0.107 2.000 5 0.167 0.750 0.31 3.3
5G5Q-25R02 2.500 1.645 0.107 2.000 5 0.167 1.000 0.38 3.3
5G5Q-30R01 3.000 2.144 0.107 2.000 6 0.167 1.000 0.38 2.4
5G6Q-30R01 3.000 2.144 0.107 2.000 5 0.167 1.000 0.38 2.4
5G5Q-30R02 3.000 2.144 0.107 2.000 6 0.167 1.250 0.50 2.4
5G5Q-40R01 4.000 3.144 0.107 2.500 8 0.166 1.500 0.63 1.6
5G6Q-40R01 4.000 3.144 0.106 2.500 6 0.166 1.500 0.63 1.6
5G6Q-50R01 5.000 4.144 0.106 2.500 8 0.166 1.500 0.63 1.2
5G6Q-60R01 6.000 5.144 0.106 2.500 9 0.166 1.500 0.63 0.9
Insert screw tightening torque: 40-45 in*lb.
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
APMX
Depth of Cut
Max.
OAL
Overall
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DCON
Bore Dia.
KWW
Keyway
RMPX
Ramp Angle
Max.
HIGH FEED END MILLS (16MM INSERT)
SERIES 5G5Q, 5G6Q
16
IC
S
RE
BS
SDXS1605MPR-MM
IC
S
RE
BS
SDXS1605MPR-MR
IC
S
RE
BS
SDXS1605MPR-MR1
INSERTS
16
Part Number Application RE
Corner
Radius
BS
Wiper
Length
IC
Inscribed
Circle
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2515
IN2530
IN2535
IN4005
IN4015
IN4030
IN4035
IN7035
SDXS1605MPR-MM Positive Geometry 0.210 0.079 16 mm 0.220 4 Right • • • • • • • • •
SDXS1605MPR-MR Utility Insert - Heavy Duty 0.210 0.079 16 mm 0.220 4 Right • • • • •
SDXS1605MPR-MR1 Utility Insert- Heavy Duty- Keen Edge 0.210 0.079 16 mm 0.220 4 Right • • • • • • • •
Lead Angle Pocket Corkscrew CoolantFacing Shoulder Ramp PlungeContour
MR1
MM
MR
70
5G5Q-25R01 SM50-130-R0 SD-06-48 DS-A00T DS-T206B
5G5Q-25R02 SM50-130-R0 SD-08-48 DS-A00T DS-T206B
5G5Q-30R01 SM50-130-R0 SD-08-47 DS-A00T DS-T206B
5G6Q-30R01 SM50-130-R0 SD-08-47 DS-A00T DS-T206B
5G5Q-30R02 SM50-130-R0 SD-10-47 DS-A00T DS-T206B
5G5Q-40R01 SM50-130-R0 SD-12-82 DS-A00T DS-T206B
5G6Q-40R01 SM50-130-R0 SD-12-82 DS-A00T DS-T206B
5G6Q-50R01 SM50-130-R0 SD-12-82 DS-A00T DS-T206B
5G6Q-60R01 SM50-130-R0 SD-12-82 DS-A00T DS-T206B
Screw Retention Bolt Driver Handle Torx Driver Blade
HARDWARE
16
Insert screw tightening torque: 40-45 in*lb.
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Bore
Dia.
KWW
Keyway
RMPX*
Ramp
Angle Max.
REEQ
Program Radius
Equivalent
5G5M-30R01 3.000 1.755 2.000 6 1.000 0.375 2.70 0.180
5G6M-30R01 3.000 1.755 2.000 5 1.000 0.375 4.40 0.180
5G5M-40R01 4.000 2.755 2.500 8 1.500 0.625 1.70 0.180
5G6M-40R01 4.000 2.755 2.500 6 1.500 0.625 2.60 0.180
5G5M-50R01 5.000 3.755 2.500 9 1.500 0.625 1.70 0.180
5G6M-50R01 5.000 3.755 2.500 7 1.500 0.625 1.90 0.180
5G5M-60R01 6.000 4.755 2.500 10 1.500 0.625 1.30 0.180
5G6M-60R01 6.000 4.755 2.500 8 1.500 0.625 1.50 0.180
5G6M-70R01 7.000 5.755 2.500 8 1.500 0.625 1.23 0.180
SERIES 5G5M, 5G6M FORMERLY
19
WEP - See insert drawing for wiper options.
Backdraft
90°KAPR2
REEQ
12°KAPR1
.043BS
.118
APMX1
.043BS
OAL
DCX
DC
DCON KWW
WEP
HIGH FEED END MILLS (19MM INSERT)
* All of the above data is with insert SDES1906MDR installed. Please see Technical Literature for dimensions when using other inserts.
Insert screw tightening torque: 72-77 in*lb.
Lead Angle Pocket Corkscrew CoolantFacing Shoulder Ramp PlungeContour
71
milling
INSERTS
19
Part Number Application RE
Corner
Radius
BS
Wiper
Length
IC
Inscribed
Circle
S
Thickness
Grade
IN2505
IN2530
IN4005
IN4030
IN4035
SDES1906MDR Hi-Feed, Flat Face / Wiper - Facets .180 0.043 19 mm .250 • •
SDMS1906MDR-PH Hi-Feed, Pos Precision / Wiper - Facets .180 0.043 19 mm .250 •••••
SDES1906MPR Hi-Feed, Heavy Duty - Standard .212 0.061 19 mm .250 • • • •
SDES1906MPR-001 Hi-Feed, Heavy Duty - Precision .212 0.061 19 mm .250 •••••
FORMERLY
SDMS1906MDR-PH
IC
BS
BS S
60°
12°
SDES1906MDR
IC
S
BS
BS
60°
12°
SDES1906MPR-001
IC
S
BS
RE
SDES1906MPR
IC
S
RE
BS
5G5M-30R01 SM60-135-R0 DS-T25T SD-08-47 SD-08-92
5G6M-30R01 SM60-135-R0 DS-T25T SD-08-47 SD-08-92
5G5M-40R01 SM60-135-R0 DS-T25T SD-12-82 SD-12-99
5G6M-40R01 SM60-135-R0 DS-T25T SD-12-82 SD-12-99
5G5M-50R01 SM60-135-R0 DS-T25T SD-12-82 SD-12-99
5G6M-50R01 SM60-135-R0 DS-T25T SD-12-82 SD-12-99
5G5M-60R01 SM60-135-R0 DS-T25T SD-12-82 SD-12-99
5G6M-60R01 SM60-135-R0 DS-T25T SD-12-82 SD-12-99
5G6M-70R01 SM60-135-R0 DS-T25T SD-12-82 SD-12-99
HARDWARE
19
DriverInsert Screw Coolant BoltRetention Bolt
**OPTIONAL**
FORMERLY
Insert screw tightening torque: 72-77 in*lb.
001 PH
72
NEW IC SIZES, NEW DIAMETER RANGES, NEW GRADE AND A NEW NAME, DIPOSFEED!
• Cutter body options include: End Mill, Top-On, Chip Surfer and Face Mill
• Cutter diameter range, .312 up to 4.00 inch
• Higher insert densities for super productivity!
• Depth of cut (DOC) capability from .5mm (.020) to 2mm (.078)
• APT ranges from .008 to .157 allow for extreme productivity!
• Optimal insert cutting edge preparations & rake face geometries for all material groups.
• Inserts offer 4 cutting edges for cost-effective machining and economy!
• Rigid clamping & high tensile clamping screws
• Lower cutting forces and efficient milling
• An expanded high-feed family under one new name, DIPOSFEED! (formerly, HiFeed Mini & Midi)
OAL
LPR
LUX
DCX
DC DCON
REEQ
APMX
90°
Backdraft
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
RMPX
Ramp Angle
Max.
APMX
Depth of
Cut Max.
1TG1B-03007R7R01 0.312 0.150 0.62 0.75 3.25 1 0.035 0.312 .64 0.020
1TG1B-03007R8R01 0.375 0.207 0.62 0.75 4.00 1 0.035 0.375 .75 0.020
1TG1B-04007R9R01 0.438 0.266 0.62 0.75 4.00 2 0.035 0.438 .85 0.020
1TG1B-05007S4R01 0.500 0.327 0.62 0.75 4.50 3 0.035 0.500 .9 0.020
1TG1B-06010S6R01 0.625 0.450 0.98 1.00 6.00 4 0.035 0.625 .7 0.020
1TG1B-07010S7R01 0.750 0.575 0.98 1.00 7.50 4 0.035 0.750 1.1 0.020
1TG1B-08010S8R01 0.875 0.700 0.98 1.00 7.50 5 0.035 0.875 1 0.020
1TG1B-10010S1R01 1.000 0.824 0.98 1.00 8.00 6 0.035 1.000 .85 0.020
END MILLS, 04MM IC INSERT SERIES
SERIES 1TG1B (CYLINDRICAL SHANK)
04
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
73
milling
DHUB
CCMS
LF
DCX
DC
REEQ
APMX
90°
Backdraft
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DHUB
Hub
Diameter
CCMS
Connection
Code
RMPX
Ramp Angle
Max.
APMX
Depth of
Cut Max.
1TG1B-03006X4R01 0.394 0.224 0.67 2 0.035 0.38 TopOn M06 .9 0.020
1TG1B-04006X4R01 0.438 0.266 0.67 2 0.035 0.41 TopOn M06 .8 0.020
1TG1B-05006X4R01 0.500 0.327 0.67 3 0.035 0.47 TopOn M06 1 0.020
1TG1B-06009X5R01 0.625 0.450 0.98 4 0.035 0.50 TopOn M08 .7 0.020
1TG1B-07011X6R01 0.750 0.575 1.18 4 0.035 0.70 TopOn M10 1.25 0.020
1TG1B-08011X6R01 0.875 0.700 1.18 5 0.035 0.70 TopOn M10 1 0.020
1TG1B-10013X7R01 1.000 0.824 1.37 6 0.035 0.82 TopOn M12 .85 0.020
1TG1B-12015X8R01 1.250 1.074 1.57 8 0.035 1.13 TopOn M16 .64 0.020
MODULAR END MILLS,
04MM IC INSERT SERIES
SERIES 1TG1B (TOP•ON STYLE)
04
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
LF
DCX
DC DHUB
CCMS
REEQ
APMX
90°
Backdraft
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DHUB
Hub
Diameter
CCMS
Connection
Code
RMPX
Ramp Angle
Max.
APMX
Depth of
Cut Max.
1TG1B-03006T6R01 0.394 0.224 0.63 2 0.035 0.37 Chip Surfer T06 .91 0.020
1TG1B-04006T6R01 0.438 0.266 0.63 2 0.035 0.37 Chip Surfer T06 .88 0.020
1TG1B-05006T8R01 0.500 0.327 0.65 3 0.035 0.49 Chip Surfer T08 1 0.020
1TG1B-06008TRR01 0.625 0.450 0.80 4 0.035 0.61 Chip Surfer T10 .7 0.020
1TG1B-07010TSR01 0.750 0.575 1.00 4 0.035 0.73 Chip Surfer T12 1.25 0.020
1TG1B-08010TSR01 0.875 0.700 1.00 5 0.035 0.73 Chip Surfer T12 1 0.020
1TG1B-10012TUR01 1.000 0.824 1.25 6 0.035 0.95 Chip Surfer T15 .85 0.020
HI-FEED MODULAR END MILLS
04MM IC INSERT SERIES
SERIES 1TG1B (CHIP•SURFER STYLE)
04
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
74
Part Number Application REEQ
Program Radius
Equivalent
INSL
Insert
Length
W1
Insert
Width
S1
Thickness
Overall
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2504
IN2505
IN2530
UNLU0402M0TR Multi-Purpose .035 .236 .165 .098 4 Right •••
UNLU0402M0TR-ML Precision .035 .236 .165 .098 4 Right • •
UNLU04
S1W1
INSL
INSERTS
04
MOTR-ML
MOTR
1TG1B-03007R7R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB -
1TG1B-03007R8R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB -
1TG1B-04007R9R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB -
1TG1B-05007S4R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB -
1TG1B-06010S6R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB -
1TG1B-07010S7R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB -
1TG1B-08010S8R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB -
1TG1B-10010S1R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB -
1TG1B-03006X4R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB -
1TG1B-04006X4R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB -
1TG1B-05006X4R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB -
1TG1B-06009X5R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB 610MM
1TG1G-07011X6R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB 615MM
1TG1G-08011X6R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB 615MM
1TG1B-10013X7R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB 617MM
1TG1B-12015X8R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB 622MM
1TG1B-03006T6R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB WS-0029
1TG1B-04006T6R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB WS-0029
1TG1B-05006T8R01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB WS-0030
1TG1B-06008TRR01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB WS-0044
1TG1B-07010TSR01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB WS-0059
1TG1B-08010TSR01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB WS-0059
1TG1B-10012TUR01 SM18-041-00 DS-TP06S DS-A00-.25S DT-05-.25 DS-TP06TB WS-0059
Screw Driver
HARDWARE
04
Preset Torque Bit Wrench
**OPTIONAL**
Torque Driver Handle
**OPTIONAL** **OPTIONAL**
Torque Driver Bit
**OPTIONAL**
75
milling
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
RMPX
Ramp Angle
Max.
APMX
Depth of
Cut Max.
1TG1F-06015S6R01 0.625 0.365 1.26 1.40 4.00 2 0.060 0.625 1.5 0.028
1TG1F-06015ULR01 0.625 0.365 1.26 1.40 4.00 2 0.060 15.50 mm 1.5 0.028
1TG1F-07017UMR01 0.750 0.476 1.50 1.66 5.00 3 0.060 18.50 mm 1.4 0.032
1TG1F-07017UMR02 0.750 0.476 1.50 1.66 6.25 3 0.060 18.50 mm 1.4 0.032
1TG1F-07022S7R01 0.750 0.476 2.00 2.17 5.00 3 0.060 0.750 1.4 0.032
1TG1F-07032S7R01 0.750 0.476 3.00 3.15 6.23 3 0.060 0.750 1.4 0.032
1TG1F-08019S7R01 0.875 0.573 1.82 1.93 7.75 3 0.060 0.750 1.1 0.043
1TG1F-08019UNR01 0.875 0.573 1.75 1.93 7.75 3 0.060 21.50 mm 1.1 0.043
1TG1F-10022S1R01 1.000 0.696 2.00 2.17 10.00 4 0.060 1.000 .8 0.043
1TG1F-10022T5R01 1.000 0.696 2.00 2.16 7.00 4 0.060 25.00 mm .8 0.043
1TG1F-10022T5R02 1.000 0.696 2.00 2.16 10.00 4 0.060 25.00 mm .8 0.043
1TG1F-10032S1R01 1.000 0.696 2.00 3.17 7.00 4 0.060 1.000 .8 0.043
1TG1F-1203281R01 1.250 0.946 3.00 3.17 5.50 5 0.060 1.250 .6 0.043
1TG1F-12050E2R01 1.250 0.946 4.75 4.92 8.00 5 0.060 1.250 .6 0.043
1TG1F-15015E2R01 1.500 1.196 2.88 3.00 6.00 6 0.060 1.250 .5 0.043
END MILLS, 06MM IC INSERT SERIES
SERIES 1TG1F (CYLINDRICAL SHANK)
06
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
OAL
LPR
LUX
DCX
DC DCON
REEQ
APMX
90°
Backdraft
FORMERLY
76
LF
DCX
DC DHUB
CCMS
REEQ
APMX
90°
Backdraft
REEQ
APMX
90°
Backdraft
DHUB
CCMS
LF
DCX
DC
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DHUB
Hub
Diameter
CCMS
Connection
Code
RMPX
Ramp Angle
Max.
APMX
Depth of
Cut Max.
1TG1F-06010X5R01 0.625 0.365 0.98 2 0.060 0.51 TopOn M08 1.5 0.028
1TG1F-07011X6R01 0.750 0.476 1.18 3 0.060 0.51 TopOn M10 1.4 0.032
1TG1F-10013X7R01 1.000 0.696 1.37 4 0.060 0.82 TopOn M12 .8 0.043
1TG1F-12015X8R01 1.250 0.946 1.57 5 0.060 1.14 TopOn M16 .6 0.043
1TG1F-15015X8R10 1.500 1.196 1.57 6 0.060 1.14 TopOn M16 .8 0.043
1TG1F-15017X9R01 1.500 1.196 1.75 6 0.060 1.42 TopOn M20 .8 0.043
MODULAR END MILLS,
06MM IC INSERT SERIES
SERIES 1TG1F (TOP•ON STYLE)
06
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DHUB
Hub
Diameter
CCMS
Connection
Code
RMPX
Ramp Angle
Max.
APMX
Depth of
Cut Max.
1TG1F-06008TRR01 0.625 0.365 0.83 2 0.060 0.60 Chip Surfer T10 1.5 0.028
1TG1F-07010TSR01 0.750 0.476 1.02 3 0.060 0.72 Chip Surfer T12 1.4 0.028
1TG1F-10012TUR01 1.000 0.706 1.26 4 0.060 0.95 Chip Surfer T15 .8 0.043
HI-FEED MODULAR END MILLS
WITH 4 INDEXES
SERIES 1TG1F (CHIP•SURFER STYLE)
06
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
FORMERLY
FORMERLY
77
milling
OAL
KWW
DCON
DCX
DC REEQ
APMX
90°
Backdraft
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
KWW
Keyway
RMPX
Ramp
Angle Max.
APMX
Depth of
Cut Max.
TG1F-20R01 2.000 1.696 1.97 7 0.060 0.750 0.31 .5 0.043
FACE MILLS, 06MM IC INSERT SERIES
SERIES TG1F
06
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
Part Number Application REEQ
Program Radius
Equivalent
INSL
Insert
Length
W1
Insert
Width
S1
Thickness
Overall
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2035
IN2504
IN2505
IN2510
IN2530
IN7035
UNLU0603M0TR Multi-Purpose 0.060 0.354 0.251 0.142 4 Right •••••
UNLU0603M0TR-MM Positive 0.060 0.354 0.251 0.142 4 Right ••• ••
UNLU0603M0TR-ML Precision 0.060 0.354 0.251 0.142 4 Right • • • •
INSERTS
06
S1
INSL
W1
UNLU06
MOTR-ML
MOTR-MM
MOTR
FORMERLY
FORMERLY
78
Insert Screw Driver
1TG1F-06015S6R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-06015ULR01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-07017UMR01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-07017UMR02 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-07022S7R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-07032S7R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-08019S7R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-08019UNR01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-10022S1R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-10022T5R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-10022T5R02 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-10032S1R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-1203281R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-12050E2R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-15015E2R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 -
1TG1F-06010X5R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 610MM
1TG1F-07011X6R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 615MM
1TG1F-10013X7R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 617MM
1TG1F-12015X8R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 622MM
1TG1F-15015X8R10 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 622MM
1TG1F-15017X9R01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 630MM
1TG1F-06008TRR01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 WS-0044
1TG1F-07010TSR01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 WS-0059
1TG1F-10012TUR01 SM25-075-20 DS-T08W - - DS-A00-.25T DT-11-.25 DS-0021 WS-0061
TG1F-20R01 SM25-075-20 DS-T08W SD-06-48 SD-06-A6 DS-A00-.25T DT-11-.25 DS-0021 -
Socket Head Cap Screw
HARDWARE
06
Coolant Bolt
**OPTIONAL**
Torque Driver Handle
**OPTIONAL**
Torque Driver Bit
**OPTIONAL**
Preset Torque Bit
**OPTIONAL**
Wrench
**OPTIONAL**
FORMERLY
79
milling
REEQ
APMX
90°
Backdraft
OAL
LPR
LUX
DCX
DC DCON
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
RMPX
Ramp Angle
Max.
APMX
Depth of
Cut Max.
1TG1G-10019S1R03 1.000 0.594 1.80 1.97 7.00 3 0.094 1.000 3 0.060
1TG1G-10020S1R03 1.000 0.594 1.83 2.00 10.00 3 0.094 1.000 3 0.060
1TG1G-12027E2R03 1.250 0.841 2.57 2.75 5.75 3 0.094 1.250 2 0.060
1TG1G-12027E2R04 1.250 0.841 2.57 2.75 5.75 4 0.094 1.250 2 0.060
1TG1G-12047E2R03 1.250 0.841 4.57 4.75 7.75 3 0.094 1.250 2 0.060
1TG1G-15016E2R04 1.500 1.090 1.45 1.69 6.00 4 0.094 1.250 1.5 0.060
1TG1G-15016E2R05 1.500 1.090 1.45 1.69 6.00 5 0.094 1.250 1.5 0.060
END MILLS, 09MM IC INSERT SERIES
SERIES 1TG1G (CYLINDRICAL SHANK)
09
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DHUB
Hub
Diameter
CCMS
Connection
Code
RMPX
Ramp Angle
Max.
APMX
Depth of
Cut Max.
1TG1G-10015X7R03 1.000 0.594 1.57 3 0.094 0.82 TopOn M12 3 0.060
1TG1G-12015X8R04 1.250 0.841 1.57 4 0.094 1.13 TopOn M16 2 0.060
1TG1G-15015X9R10 1.500 1.090 1.57 5 0.094 1.42 TopOn M20 1.5 0.060
MODULAR END MILLS,
09MM IC INSERT SERIES
SERIES 1TG1G (TOP•ON STYLE)
09
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
LF
DCX
DC DHUB
CCMS
REEQ
APMX
90°
Backdraft
FORMERLY
FORMERLY
80
REEQ
APMX
90°
Backdraft
OAL
KWW
DCON
DCX
DC
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
KWW
Keyway
RMPX
Ramp
Angle Max.
APMX
Depth of
Cut Max.
TG1G-20R01 2.000 1.593 1.97 7 0.094 0.750 0.31 1 0.060
TG2G-20R01 2.000 1.593 1.97 6 0.094 0.750 0.31 1 0.060
TG1G-25R01 2.500 2.090 1.97 8 0.094 0.750 0.31 .8 0.060
TG1G-30R01 3.000 2.566 1.75 9 0.094 1.000 0.38 .6 0.060
TG2G-30R01 3.000 2.566 1.75 7 0.094 1.000 0.38 .6 0.060
FACE MILLS, 09MM IC INSERT SERIES
SERIES TG1G, TG2G
09
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
Part Number Application REEQ
Program Radius
Equivalent
INSL
Insert
Length
W1
Insert
Width
S1
Thickness
Overall
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2035
IN2504
IN2505
IN2510
IN2530
IN7035
UNLU0904M0TR Multi-Purpose 0.094 0.469 0.361 .189 4 Right •••••
UNLU0904M0TR-MM Positive Geometry 0.094 0.469 0.361 .189 4 Right ••• ••
UNLU0904M0TR-ML Precision 0.094 0.469 0.361 .189 4 Right • • • •
INSERTS
09
S1
INSL
W1
UNLU09
MOTR-ML
MOTR-MM
MOTR
FORMERLY
FORMERLY
81
milling
HARDWARE
09
1TG1G-10019S1R03 SM35-088-10 DS-A00T DS-T106B - - DS-A00-.25-T DT-30-.25 DS-T10B1 -
1TG1G-10020S1R03 SM35-088-10 DS-A00T DS-T106B - - DS-A00-.25-T DT-30-.25 DS-T10B1 -
1TG1G-12027E2R03 SM35-088-10 DS-A00T DS-T106B - - DS-A00-.25-T DT-30-.25 DS-T10B1 -
1TG1G-12027E2R04 SM35-088-10 DS-A00T DS-T106B - - DS-A00-.25-T DT-30-.25 DS-T10B1 -
1TG1G-12047E2R03 SM35-088-10 DS-A00T DS-T106B - - DS-A00-.25-T DT-30-.25 DS-T10B1 -
1TG1G-15016E2R04 SM35-088-10 DS-A00T DS-T106B - - DS-A00-.25-T DT-30-.25 DS-T10B1 -
1TG1G-15016E2R05 SM35-088-10 DS-A00T DS-T106B - - DS-A00-.25-T DT-30-.25 DS-T10B1 -
1TG1G-10015X7R03 SM35-088-10 DS-A00T DS-T106B - - DS-A00-.25-T DT-30-.25 DS-T10B1 617MM
1TG1G-12015X8R04 SM35-088-10 DS-A00T DS-T106B - - DS-A00-.25-T DT-30-.25 DS-T10B1 622MM
1TG1G-15015X9R10 SM35-088-10 DS-A00T DS-T106B - - DS-A00-.25-T DT-30-.25 DS-T10B1 630MM
TG1G-20R01 SM35-088-10 DS-A00T DS-T106B SD-06-48 SD-06-A6 DS-A00-.25-T DT-30-.25 DS-T10B1 -
TG2G-20R01 SM35-088-10 DS-A00T DS-T106B SD-06-48 SD-06-A6 DS-A00-.25-T DT-30-.25 DS-T10B1 -
TG1G-25R01 SM35-088-10 DS-A00T DS-T106B SD-06-48 SD-06-A6 DS-A00-.25-T DT-30-.25 DS-T10B1 -
TG1G-30R01 SM35-088-10 DS-A00T DS-T106B SD-08-46 SD-08-92 DS-A00-.25-T DT-30-.25 DS-T10B1 -
TG2G-30R01 SM35-088-10 DS-A00T DS-T106B SD-08-46 SD-08-92 DS-A00-.25-T DT-30-.25 DS-T10B1 -
Screw Driver Handle Driver Blade Socket Head Cap Screw Coolant Bolt
**OPTIONAL**
Torque Driver Handle
**OPTIONAL**
Torque Driver Bit
**OPTIONAL**
Preset Torque Bit
**OPTIONAL**
Wrench
**OPTIONAL**
FORMERLY
REEQ
APMX
90°
Backdraft
OAL
LPR
LUX
DCX
DC
DCON
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
RMPX
Ramp
Angle Max.
APMX
Depth of
Cut Max.
1TG1J-12025E2R01 1.250 0.650 2.20 2.50 5.50 2 0.120 1.250 .48 0.078
1TG1J-12030E2R01 1.250 0.650 2.70 3.00 6.00 3 0.120 1.250 .48 0.078
1TG1J-15016E2R01 1.500 0.900 1.60 1.69 6.00 3 0.120 1.250 .54 0.078
END MILLS, 11MM IC INSERT SERIES
SERIES 1TG1J (WELDON SHANK)
11
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
82
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Diameter
LF
Functional
Length
ZEFF
Effective
Teeth
REEQ
Program Radius
Equivalent
DHUB
Hub
Diameter
CCMS
Connection
Code
RMPX
Ramp Angle
Max.
APMX
Depth of
Cut Max.
1TG1J-12015X8R01 1.250 0.650 1.57 2 0.120 1.13 TopOn M16 .48 0.078
1TG1J-15015X8R01 1.500 0.900 1.57 3 0.120 1.13 TopOn M16 .54 0.078
1TG1J-15015X9R01 1.500 0.900 1.57 3 0.120 1.42 TopOn M20 .54 0.078
REEQ
APMX
90°
Backdraft
DHUB
CCMS
LF
DCX
DC
MODULAR END MILLS,
11MM IC INSERT SERIES
SERIES 1TG1J (TOP•ON STYLE)
11
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
REEQ
APMX
90°
Backdraft
DCON KWW
OAL
DCX
DC
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
KWW
Keyway
RMPX
Ramp
Angle Max.
APMX
Depth of
Cut Max.
TG1J-20R01 2.000 1.384 1.970 5 0.120 0.750 0.31 .5 0.078
TG2J-20R01 2.000 1.384 1.970 4 0.120 0.750 0.31 .5 0.078
TG1J-25R01 2.500 1.884 1.970 6 0.120 0.750 0.31 .45 0.078
TG2J-25R01 2.500 1.884 1.970 5 0.120 0.750 0.31 .45 0.078
TG1J-30R01 3.000 2.384 1.750 7 0.120 1.000 0.38 .35 0.078
TG2J-30R01 3.000 2.384 1.750 6 0.120 1.000 0.38 .35 0.078
TG1J-40R01 4.000 3.384 2.375 7 0.120 1.000 0.38 .3 0.078
TG2J-40R01 4.000 3.384 2.375 6 0.120 1.000 0.38 .3 0.078
FACE MILLS, 11MM IC INSERT SERIES
SERIES TG1J, TG2J
11
CoolantPocketingCorkscrewFacing RampChannelContour
Shoulder Plunging
83
milling
Part Number Application REEQ
Program Radius
Equivalent
INSL
Insert
Length
W1
Insert
Width
S1
Thickness
Overall
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2504
IN2505
IN2530
IN6537
UNLU1105M0TR Multi-Purpose .120 .575 .441 .256 4 Right ••••
UNLU1105M0TR-ML Precision .120 .575 .441 .256 4 Right • •
UNLU11
S1W1
INSL
INSERTS
11
MOTR-ML
MOTR
1TG1J-12025E2R01 SM50-127-10 DS-A00T DS-T206B - - DS-A00-.25-T DT-44-.25 DS-T20B1 -
1TG1J-12030E2R01 SM50-127-10 DS-A00T DS-T206B - - DS-A00-.25-T DT-44-.25 DS-T20B1 -
1TG1J-15016E2R01 SM50-127-10 DS-A00T DS-T206B - - DS-A00-.25-T DT-44-.25 DS-T20B1 -
1TG1J-12015X8R01 SM50-127-10 DS-A00T DS-T206B - - DS-A00-.25-T DT-44-.25 DS-T20B1 622MM
1TG1J-15015X8R01 SM50-127-10 DS-A00T DS-T206B - - DS-A00-.25-T DT-44-.25 DS-T20B1 622MM
1TG1J-15015X9R01 SM50-127-10 DS-A00T DS-T206B - - DS-A00-.25-T DT-44-.25 DS-T20B1 630MM
TG2J-20R01 SM50-127-10 DS-A00T DS-T206B SD-06-48 SD-06-A6 DS-A00-.25-T DT-44-.25 DS-T20B1 -
TG1J-20R01 SM50-127-10 DS-A00T DS-T206B SD-06-48 SD-06-A6 DS-A00-.25-T DT-44-.25 DS-T20B1 -
TG2J-25R01 SM50-127-10 DS-A00T DS-T206B SD-06-48 SD-06-A6 DS-A00-.25-T DT-44-.25 DS-T20B1 -
TG1J-25R01 SM50-127-10 DS-A00T DS-T206B SD-06-48 SD-06-A6 DS-A00-.25-T DT-44-.25 DS-T20B1 -
TG2J-30R01 SM50-127-10 DS-A00T DS-T206B SD-08-46 SD-08-92 DS-A00-.25-T DT-44-.25 DS-T20B1 -
TG1J-30R01 SM50-127-10 DS-A00T DS-T206B SD-08-46 SD-08-92 DS-A00-.25-T DT-44-.25 DS-T20B1 -
TG2J-40R01 SM50-127-10 DS-A00T DS-T206B SD-12-82 SD-12-99 DS-A00-.25-T DT-44-.25 DS-T20B1 -
TG1J-40R01 SM50-127-10 DS-A00T DS-T206B SD-12-82 SD-12-99 DS-A00-.25-T DT-44-.25 DS-T20B1 -
Screw Driver Handle
HARDWARE
11
Driver Blade Socket Head Cap Screw Coolant Bolt
**OPTIONAL**
Torque Driver Handle
**OPTIONAL**
Torque Driver Bit
**OPTIONAL**
Preset Torque Bit
**OPTIONAL**
Wrench
**OPTIONAL**
84
FIXED POCKET (NON-ADJUSTING) SUPER FINISH MILLS
• Long crowned wiper produces 3-15 Ra surface finis
• Non-adjusting design reduces set up time
• Stepped insert orientation alleviates axial & radial forces; only one proud wiper insert
• Can mill up to 90° shoulder
• 12 mm Insert with up to 4 indexes
• High positive axial rake promotes chip evacuation and improves tool life
• Carbide, CBN & PCD insert offering for a wide variety of materials!
OAL
.020APMX
DC
DCX
DCON KWW
WEP - See insert drawing for wiper options.
SERIES TA3Q
Part Number DC
Cutting
Dia.
DCX
Cutting
Dia. Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
DCON
Shank
Dia.
KWW
Keyway CSP
Coolant
TA3Q-20R01 1.563 2.000 1.570 5 0.750 0.312 Yes
TA3Q-25R01 2.024 2.500 1.570 6 0.750 0.312 Yes
TA3Q-30R01 2.484 3.000 1.750 8 1.000 0.375 Yes
TA3Q-40R01 3.484 4.000 1.750 8 1.500 0.625 Yes
TA3Q-50R01 4.444 5.000 1.750 10 1.500 0.625 Yes
TA3Q-60R01 5.444 6.000 1.750 10 1.500 0.625 No
FIXED POCKET (NON-ADJUSTING) FINISH FACE MILL
Facing
85
milling
Part Number Application RE
Corner
Radius
BS
Wiper
Length
BSR
Wiper
Radius
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN2505
IN2510
IN10K
ANED1207-ML Finishing 0.031 0.412 39.400 0.020 0.472 0.413 0.358 4 Right • •
ANED1207-AL Finishing, Sharp 0.031 0.412 39.400 0.020 0.472 0.413 0.358 4 Right •
RE
INSL S
W1
BS BSR
ANED12_ML ANED12_AL
RE
INSL S
W1
BS BSR
INSERTS
Part Number Application BCH
Corner Chamfer
Length
BS
Wiper
Length
BSR
Wiper
Radius
LE
Cutting Edge
Eff. Length
INSL
Insert
Length
W1
Insert
Width
S
Thickness
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN80B
IN93D
ANED1207-CBN Finishing 0.030 0.412 39.400 0.020 0.472 0.413 0.264 1 Right •
ANED1207-PCD Finishing 0.030 0.412 39.400 0.020 0.472 0.413 0.264 1 Right •
INSL S
W1
BS BSR BCH
ANED12_CBN ANED12_PCD
INSL S
W1
BS BSR BCH
HARDWARE
TA3Q-20R01 SM40-115-00 DS-A00T DS-T156B1 SD-06-46 SD-06-89 DS-A00-.25-T DT-35-.25 DS-T15B1
TA3Q-25R01 SM40-115-00 DS-A00T DS-T156B1 SD-06-46 SD-06-89 DS-A00-.25-T DT-35-.25 DS-T15B1
TA3Q-30R01 SM40-115-00 DS-A00T DS-T156B1 SD-08-46 SD-08-92 DS-A00-.25-T DT-35-.25 DS-T15B1
TA3Q-40R01 SM40-115-00 DS-A00T DS-T156B1 SD-12-82 SD-12-99 DS-A00-.25-T DT-35-.25 DS-T15B1
TA3Q-50R01 SM40-115-00 DS-A00T DS-T156B1 SD-12-82 SD-12-99 DS-A00-.25-T DT-35-.25 DS-T15B1
TA3Q-60R01 SM40-115-00 DS-A00T DS-T156B1 - - DS-A00-.25-T DT-35-.25 DS-T15B1
Screw Driver Handle Torque Driver Handle
**OPTIONAL**
Torque Driver Bit
**OPTIONAL**
Preset Torque Bit
**OPTIONAL**
Retention Bolt
Torque Driver Bit Coolant Retention Bolt
**OPTIONAL**
PCD
AL
CBN
ML
86
BARREL-STYLE INDEXABLE END MILLS FOR FAST AND PRISTINE FINISHING OF
STRAIGHT AND PROFILED SURFACES
• Precisely crowned inserts decrease finishing time by allowing greater axial advance, “step-downs”
• The insert’s seating surfaces are precisely ground to minimize run-out and improved surface finish, even at high feed rates
• Cutter diameters of .625”, .750” and 1.00” are each available in our popular Top-On and ultra-precise Chip-Surfer adaptions
• Inclined inserts allow for the finishing of a larger range of stock conditions
• High sheer insert geometry and keen cutting edges are ideal for semi-finish and finish milling
DC
LF
DHUB
CCMS
APMX
RH
PRFRAD
INDEXABLE BARREL FORM, USING 20MM PROFILE RADIUS INSERT (CDHT090320R-M…)
SERIES 12L8J (CHIP•SURFER STYLE)
Shoulder Coolant
Part Number DC
Cutting
Diameter
PRFRAD
Profile
Radius
RH
Radius
Height
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
12L8J-06008TRR01 0.620 0.791 0.252 0.379 0.812 2 Chip Surfer T10 0.605
12L8J-07010TSR01 0.745 0.787 0.252 0.379 1.000 3 Chip Surfer T12 0.725
12L8J-10012TUR01 0.995 0.785 0.253 0.379 1.250 4 Chip Surfer T15 0.945
DC
LF
DHUB
CCMS
APMX
RH
PRFRAD
SERIES 12L8J (TOP•ON STYLE)
Part Number DC
Cutting
Diameter
PRFRAD
Profile
Radius
RH
Radius
Height
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
12L8J-06010X5R01 0.620 0.791 0.252 0.379 1.000 2 Top-On M8 0.502
12L8J-07011X6R01 0.745 0.787 0.252 0.379 1.125 3 Top-On M10 0.699
12L8J-10013X7R01 0.995 0.785 0.253 0.379 1.375 4 Top-On M12 0.817
Contouring
INDEXABLE BARREL FORM, USING 20MM PROFILE RADIUS INSERT (CDHT090320R-M…)
Shoulder CoolantContouring
87
milling
DC
LF
DHUB
CCMS
APMX
RH
PRFRAD
INDEXABLE BARREL FORM, USING 30MM PROFILE RADIUS INSERT (CDHT090330R-M…)
SERIES 12L8J (CHIP•SURFER STYLE)
Shoulder Coolant
Part Number DC
Cutting
Diameter
PRFRAD
Profile
Radius
RH
Radius
Height
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
12L8J-06008TRR01 0.623 1.189 0.285 0.379 0.813 2 Chip Surfer T10 0.605
12L8J-07010TSR01 0.748 1.181 0.285 0.379 1.000 3 Chip Surfer T12 0.725
12L8J-10012TUR01 0.998 1.170 0.285 0.379 1.250 4 Chip Surfer T15 0.945
DC
LF
DHUB
CCMS
APMX
RH
PRFRAD
SERIES 12L8J (TOP•ON STYLE)
Part Number DC
Cutting
Diameter
PRFRAD
Profile
Radius
RH
Radius
Height
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
12L8J-06010X5R01 0.623 1.189 0.285 0.379 1.000 2 Top-On M8 0.502
12L8J-07011X6R01 0.748 1.181 0.285 0.379 1.125 3 Top-On M10 0.699
12L8J-10013X7R01 0.998 1.170 0.285 0.379 1.375 4 Top-On M12 0.817
Contouring
INDEXABLE BARREL FORM, USING 30MM PROFILE RADIUS INSERT (CDHT090330R-M…)
Shoulder CoolantContouring
88
SW1
INSL PRFRAD
CDHT09-ML
Part Number Application PRFRAD
Profile
Radius
INSL
Insert
Length
W1
Insert
Width
S
Thickness
IH
Insert
Hand
NOI
Number
of Indexes
Grade
IN2504
IN2505
IN2530
IN05S
IN3004
CDHT090320R-ML Finishing .7874 0.375 0.256 0.118 Right 2 •••
CDHT090320R-MLP Sharp-For Aluminum .7874 0.375 0.256 0.118 Right 2 • •
CDHT090330R-ML Finishing 1.1811 0.375 0.256 0.118 Right 2 •••
CDHT090330R-MLP Sharp-For Aluminum 1.1811 0.375 0.256 0.118 Right 2 • •
INSERTS
HARDWARE
12L8J-06008TRR01 SE25-054-00 DS-T08W DS-A00-.25S DT-11-.25 DS-T08B
12L8J-07010TSR01 SE25-054-00 DS-T08W DS-A00-.25S DT-11-.25 DS-T08B
12L8J-10012TUR01 SE25-054-00 DS-T08W DS-A00-.25S DT-11-.25 DS-T08B
12L8J-06010X5R01 SE25-054-00 DS-T08W DS-A00-.25S DT-11-.25 DS-T08B
12L8J-07011X6R01 SE25-054-00 DS-T08W DS-A00-.25S DT-11-.25 DS-T08B
12L8J-10013X7R01 SE25-054-00 DS-T08W DS-A00-.25S DT-11-.25 DS-T08B
Insert Screw Screw Driver
ML / MLP
Torque Driver Handle Preset Torque Bit Torque Driver Bit
**OPTIONAL** **OPTIONAL****OPTIONAL**
Insert screw tightening torque: 10.6 in*lbs.
SW1
INSL PRFRAD
CDHT09-MLP
89
milling
NEW END MILL TIPS WITH 1.5XD FLUTE LENGTH
• 4-6 Flute Roughing Mills equipped with serrations to promote accelerated Feed rates and better chip evacuation with airblast
• 4 Flute Rough & Finish Mills equipped with variable pitch to reduce harmonic chatter
• 7-9 Flute Finish Mills equipped different helix and variable pitch to diffuse vibration
• Best suited with Weldon Shank for utmost rigidity and holding
• Tips repeat within +/-.0005” and can be indexed on the machine in seconds
• Feature variations can be quoted
LF
RE CCMS
DHUB
APMX
90°KAPR
DC
(e8)
47D-3146TQRQ01 0.312 0.015 R 0.469 0.709 4 46.5 Chip Surfer T05 0.300 90
47D-3756T6RQ01 0.375 0.015 R 0.563 0.866 4 46.5 Chip Surfer T06 0.366 90
47D-5075T8RQ01 0.500 0.015 R 0.750 1.063 4 46.5 Chip Surfer T08 0.488 90
47D-6293TRRQ01 0.625 0.015 R 0.938 1.319 4 46.5 Chip Surfer T10 0.602 90
47D-7511TSRQ03 0.750 0.031 R 1.125 1.614 4 46.5 Chip Surfer T12 0.726 90
47D-1015TURQ03 1.000 0.031 R 1.500 2.067 4 46.5 Chip Surfer T15 0.941 90
4 FLUTE, 46' HELIX, CENTER-CUTTING, 1.5XD FLUTE
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T05=60in*lbs, T06=90in*lbs, T08=130in*lbs, T10=250in*lbs, T12=250in*lbs, T15=350in*lbs.
No lubricant on adaption. Wrenches sold separately.
Shoulder Facing
SERIES 47D_RQ 90º VARIABLE PITCH END MILL
Slabbing Corkscrew PocketingRamping
Part Number DC
Cutting
Diameter
RE/CHW
Corner
Radius/Chamfer
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Flutes
FHA
Flute Helix
Angle
CCMS
Connection
Code
DHUB
Hub
Diameter
RMPX
Ramp Angle
Max.
47D-3146TQRQ01 WS-0043 DT-60-06
47D-3756T6RQ01 WS-0029 DT-90-08
47D-5075T8RQ01 WS-0030 DT-130-10
47D-6293TRRQ01 WS-0044 DT-250-13
47D-7511TSRQ03 WS-0059 DT-250-16
47D-1015TURQ03 WS-0061 DT-350-20
Thin Wrench Torque Wrench
**OPTIONAL**
47D HARDWARE
**OPTIONAL**
90
LF
CHW CCMS
DHUB
APMX
90°KAPR
DC
(e8)
Part Number DC
Cutting
Diameter
RE/CHW
Corner
Radius/Chamfer
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Flutes
FHA
Flute Helix
Angle
CCMS
Connection
Code
DHUB
Hub
Diameter
RMPX
Ramp Angle
Max.
47C-3146TQRN01 0.312 0.010 Chamfer 0.469 0.709 4 46 Chip Surfer T05 0.300 90
47C-3756T6RN01 0.375 0.012 Chamfer 0.563 0.866 4 46 Chip Surfer T06 0.366 90
47C-5075T8RN01 0.500 0.014 Chamfer 0.750 1.063 4 46 Chip Surfer T08 0.488 90
47C-6293TRRN01 0.625 0.016 Chamfer 0.938 1.319 5 40 Chip Surfer T10 0.602 7
48C-7511TSRN01 0.750 0.016 Chamfer 1.125 1.614 6 47 Chip Surfer T12 0.726 3
48C-1015TURN02 1.000 0.020 Chamfer 1.500 2.067 6 47 Chip Surfer T15 0.941 3
90° ROUGHING END MILL (1.5XD FLUTE)
Shoulder Facing
SERIES 47C, 48C 90º ROUGHING END MILL
Slabbing CorkscrewRamping
47C-3146TQRN01 WS-0043 DT-60-06
47C-3756T6RN01 WS-0029 DT-90-08
47C-5075T8RN01 WS-0030 DT-130-10
47C-6293TRRN01 WS-0044 DT-250-13
48C-7511TSRN01 WS-0059 DT-250-16
48C-1015TURN02 WS-0061 DT-350-20
Thin Wrench Torque Wrench
**OPTIONAL**
47C, 48C HARDWARE
**OPTIONAL**
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T05=60in*lbs, T06=90in*lbs, T08=130in*lbs, T10=250in*lbs, T12=250in*lbs, T15=350in*lbs.
No lubricant on adaption. Wrenches sold separately.
91
milling
49D-3146TQRQ01 WS-0043 DT-60-06
49D-3756T6RQ01 WS-0029 DT-90-08
49D-5075T8RQ01 WS-0030 DT-130-10
49D-6293TRRQ03 WS-0044 DT-250-13
49D-7511TSRQ03 WS-0059 DT-250-16
49D-1015TURQ03 WS-0061 DT-350-20
Thin Wrench Torque Wrench
**OPTIONAL**
49D HARDWARE
**OPTIONAL**
LF
RE CCMS
DHUB
APMX
90°KAPR
DC
(e8)
Part Number DC
Cutting
Diameter
RE/CHW
Corner
Radius/Chamfer
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Flutes
FHA
Flute Helix
Angle
CCMS
Connection
Code
DHUB
Hub
Diameter
RMPX
Ramp Angle
Max.
49D-3146TQRQ01 0.312 0.015 R 0.469 0.709 7 36 Chip Surfer T05 0.300 3
49D-3756T6RQ01 0.375 0.015 R 0.563 0.866 7 36 Chip Surfer T06 0.366 3
49D-5075T8RQ01 0.500 0.015 R 0.750 1.063 7 36 Chip Surfer T08 0.488 3
49D-6293TRRQ03 0.625 0.031 R 0.938 1.319 9 36 Chip Surfer T10 0.602 1
49D-7511TSRQ03 0.750 0.031 R 1.125 1.614 9 36 Chip Surfer T12 0.726 1
49D-1015TURQ03 1.000 0.031 R 1.500 2.067 9 36 Chip Surfer T15 0.941 1
90° FINISHING END MILL (1.5XD FLUTE)
Shoulder Facing
SERIES 49D
Slabbing CorkscrewRamping
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T05=60in*lbs, T06=90in*lbs, T08=130in*lbs, T10=250in*lbs, T12=250in*lbs, T15=350in*lbs.
No lubricant on adaption. Wrenches sold separately.
92
CCWS
DCON
BD
LB
LPR
OAL
WB050T05SA-00 Chip Surfer T05 0.170 0.40 2.185 0.300 0.500 Steel
WB062T06SA-00 Chip Surfer T06 0.230 0.65 2.560 0.360 0.625 Steel
WB062T08SA-00 Chip Surfer T08 0.130 0.65 2.560 0.480 0.625 Steel
WB075T10SA-00 Chip Surfer T10 0.130 0.76 2.750 0.600 0.750 Steel
WB100T12SA-00 Chip Surfer T12 0.300 0.75 3.000 0.720 1.000 Steel
WB125T15SA-00 Chip Surfer T15 0.300 1.75 4.000 0.940 1.250 Steel
STEEL, WELDON-STYLE, NECKED SHANKS
SERIES W*T*SA
Part Number CCWS
Conn. Code
Workpiece Side
LB
Body
Length 1
LPR
Protruding
Length
OAL
Overall
Length
BD
Body
Diameter
DCON
Shank
Diameter
BMC
Body Mat’l
Code
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T05=60in*lbs, T06=90in*lbs, T08=130in*lbs, T10=250in*lbs, T12=250in*lbs, T15=350in*lbs.
No lubricant on adaption. Wrenches sold separately.
93
milling
CIRCLE SEGMENT MILLS FINISH 3X FASTER THAN A BALL NOSE!
• Lens Form targets use on deck features of a part. For use on 3 & 5 Axis machines
• Barrel Form targets use on 90° & drafted walls. For use on 3 & 5 Axis machines
• Taper Form targets use on contoured surfaces. For use on 5 Axis machines
• Radius blends ensure minimum scallop height for superior finishes
• Precision cutting edge profile tolerance of +/-.0004”
• Tips repeat within +/-.0005” and can be indexed on the machine in seconds
• Steel, Heavy Metal & Carbide Shank options
DHUB
CCMS
APMX
LF
DC
PRFRAD1
PRFRAD2
PRFRAD3
70°PRFA
Part Number DC
Cutting
Diameter
PRFRAD1
Profile
Radius
PRFRAD2
Profile
Radius
PRFRAD3
Profile
Radius
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Flutes
FHA
Flute Helix
Angle
CCMS
Connection
Code
DHUB
Hub
Diameter
46W08009TQRB010 8.00 mm 1.50 mm 250.00 mm 4.00 mm 10 mm 15.40 mm 3 30 Chip Surfer T05 7.60 mm
46W10013T6RB020 10.00 mm 2.00 mm 250.00 mm 5.00 mm 14 mm 19.40 mm 3 30 Chip Surfer T06 9.30 mm
46W12013T8RB030 12.00 mm 3.00 mm 250.00 mm 6.00 mm 14 mm 23.40 mm 3 30 Chip Surfer T08 11.50 mm
46W16017TRRB040 16.00 mm 4.00 mm 500.00 mm 8.00 mm 17 mm 26.00 mm 3 30 Chip Surfer T10 15.20 mm
TAPER FORM FINISHER FOR STEELS AND HI-TEMPS
Shoulder Contouring Slabbing
SERIES 46W_0
46W08009TQRB010 WS-0043 DT-60-06
46W10013T6RB020 WS-0029 DT-90-08
46W12013T8RB030 WS-0030 DT-130-10
46W16017TRRB040 WS-0044 DT-250-13
Thin Wrench Torque Wrench
**OPTIONAL**
46W_0 HARDWARE
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T05=60in*lbs, T06=90in*lbs, T08=130in*lbs, T10=250in*lbs.
No lubricant on adaption. Wrenches sold separately.
94
DHUB
CCMS
APMX
LF
DC
PRFRAD1
PRFRAD2
PRFRAD3
70°PRFA
Part Number DC
Cutting
Diameter
PRFRAD1
Profile
Radius
PRFRAD2
Profile
Radius
PRFRAD3
Profile
Radius
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Flutes
FHA
Flute Helix
Angle
CCMS
Connection
Code
DHUB
Hub
Diameter
46W08009TQRB011 8.00 mm 1.50 mm 250.00 mm 4.00 mm 10 mm 15.40 mm 3 30 Chip Surfer T05 7.60 mm
46W10013T6RB021 10.00 mm 2.00 mm 250.00 mm 5.00 mm 14 mm 19.40 mm 3 30 Chip Surfer T06 9.30 mm
46W12013T8RB031 12.00 mm 3.00 mm 250.00 mm 6.00 mm 14 mm 23.40 mm 3 30 Chip Surfer T08 11.50 mm
46W16017TRRB041 16.00 mm 4.00 mm 500.00 mm 8.00 mm 17 mm 26.00 mm 3 30 Chip Surfer T10 15.20 mm
TAPER FORM FINISHER FOR NON-FERROUS
Shoulder Contouring Slabbing
SERIES 46W_1
46W08009TQRB011 WS-0043 DT-60-06
46W10013T6RB021 WS-0029 DT-90-08
46W12013T8RB031 WS-0030 DT-130-10
46W16017TRRB041 WS-0044 DT-250-13
Thin Wrench Torque Wrench
**OPTIONAL**
46W_1 HARDWARE
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T05=60in*lbs, T06=90in*lbs, T08=130in*lbs, T10=250in*lbs.
No lubricant on adaption. Wrenches sold separately.
95
milling
PRFA
DHUB
CCMS
APMX
PRFRAD1 PRFRAD2
LF
DC
Part Number DC
Cutting
Diameter
PRFRAD1
Profile
Radius
PRFRAD2
Profile
Radius
PRFA
Profile
Angle
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Flutes
FHA
Flute Helix
Angle
CCMS
Connection
Code
DHUB
Hub
Diameter
47W-3150TQRB06 0.312 0.060 3.150 78 0.530 0.709 4 30 Chip Surfer T05 0.312
47W-3760T6RB12 0.375 0.123 2.950 82 0.600 0.866 4 30 Chip Surfer T06 0.375
47W-5082T8RB16 0.500 0.157 7.500 82 0.820 1.063 4 30 Chip Surfer T08 0.500
TAPER FORM FINISHER FOR STEELS AND HI-TEMPS
Shoulder Contouring Slabbing
SERIES 47W_0
47W08014TQRB15 8.00 mm 1.50 mm 80.00 mm 78 14.20 mm 18.00 mm 4 30 Chip Surfer T05 8.00 mm
47W10016T6RB20 10.00 mm 2.00 mm 75.00 mm 78 21.30 mm 27.00 mm 4 30 Chip Surfer T06 10.00 mm
47W12021T8RB20 12.00 mm 2.00 mm 85.00 mm 78 16.50 mm 22.00 mm 4 30 Chip Surfer T08 12.00 mm
47W16027T8RB30 16.00 mm 3.00 mm 75.00 mm 78 27.00 mm 33.40 mm 4 30 Chip Surfer T10 16.00 mm
METRIC
47W-3150TQRB06 WS-0043 DT-60-06
47W-3760T6RB12 WS-0029 DT-90-08
47W-5082T8RB16 WS-0030 DT-130-10
47W08014TQRB15 WS-0043 DT-60-06
47W10016T6RB20 WS-0029 DT-90-08
47W12021T8RB20 WS-0030 DT-130-10
47W16027T8RB30 WS-0044 DT-250-13
Thin Wrench Torque Wrench
**OPTIONAL**
47W_0 HARDWARE
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T05=60in*lbs, T06=90in*lbs, T08=130in*lbs, T10=250in*lbs.
No lubricant on adaption. Wrenches sold separately.
96
LF
DC
(e8)
PRFRAD2
PRFRAD1 APMX
DHUB
CCMS
46D08005TQRB080 8.00 mm 15.00 mm 0.75 mm 0.10 mm 10.50 mm 3 30 Chip Surfer T05 7.75 mm
46D10007T6RB100 10.00 mm 20.00 mm 1.00 mm 0.10 mm 13.50 mm 3 30 Chip Surfer T06 9.40 mm
46D12009T8RB130 12.00 mm 25.00 mm 1.25 mm 0.15 mm 17.00 mm 3 30 Chip Surfer T08 11.40 mm
46D16013TRRB180 16.00 mm 35.00 mm 1.75 mm 0.30 mm 21.00 mm 3 30 Chip Surfer T10 15.40 mm
46D20016TSRB230 20.00 mm 45.00 mm 2.25 mm 0.40 mm 26.00 mm 3 30 Chip Surfer T12 18.40 mm
LENS FORM FINISHER
Shoulder Facing
SERIES 46D_RB
Channel Coolant
Part Number DC
Cutting
Diameter
PRFRAD1
Profile
Radius
PRFRAD2
Profile
Radius
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Flutes
FHA
Flute Helix
Angle
CCMS
Connection
Code
DHUB
Hub
Diameter
46D08005TQRB080 WS-0043 DT-60-06
46D10007T6RB100 WS-0029 DT-90-08
46D12009T8RB130 WS-0030 DT-130-10
46D16013TRRB180 WS-0044 DT-250-13
46D20016TSRB230 WS-0059 DT-250-16
Thin Wrench Torque Wrench
**OPTIONAL**
46D_RB HARDWARE
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T05=60in*lbs, T06=90in*lbs, T08=130in*lbs, T10=250in*lbs, T12=250in*lbs.
No lubricant on adaption. Wrenches sold separately.
97
milling
DHUB
CCMS
LF
APMX
PRFRAD1
PRFRAD2
DC
(e8)
47D-3119TQRB02 0.312 0.625 0.020 0.004 0.394 4 30 Chip Surfer T05 0.312
47D-3725T6RB04 0.375 0.750 0.039 0.004 0.512 4 30 Chip Surfer T06 0.375
47D-5035T8RB04 0.500 1.000 0.039 0.006 0.650 4 30 Chip Surfer T08 0.500
LENS FORM FINISHER
Shoulder Facing
SERIES 47D_RB
Channel
Part Number DC
Cutting
Diameter
PRFRAD1
Profile
Radius
PRFRAD2
Profile
Radius
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Flutes
FHA
Flute Helix
Angle
CCMS
Connection
Code
DHUB
Hub
Diameter
47D08004TQRB05 8.00 mm 16.00 mm 0.50 mm 0.10 mm 10.00 mm 4 30 Chip Surfer T05 8.00 mm
47D10006T6RB10 10.00 mm 20.00 mm 1.00 mm 0.10 mm 13.00 mm 4 30 Chip Surfer T06 10.00 mm
47D12008T8RB10 12.00 mm 24.00 mm 1.00 mm 0.15 mm 16.50 mm 4 30 Chip Surfer T08 12.00 mm
47D16011TRRB10 16.00 mm 32.00 mm 1.00 mm 0.30 mm 20.50 mm 4 30 Chip Surfer T10 16.00 mm
METRIC
47D-3119TQRB02 WS-0043 DT-60-06
47D-3725T6RB04 WS-0029 DT-90-08
47D-5035T8RB04 WS-0030 DT-130-10
47D08004TQRB05 WS-0043 DT-60-06
47D10006T6RB10 WS-0029 DT-90-08
47D12008T8RB10 WS-0030 DT-130-10
47D16011TRRB10 WS-0044 DT-250-13
Thin Wrench Torque Wrench
**OPTIONAL**
47D_RB HARDWARE
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T05=60in*lbs, T06=90in*lbs, T08=130in*lbs, T10=250in*lbs.
No lubricant on adaption. Wrenches sold separately.
98
DHUB
CCMS
APMX
LF
PRFRAD1PRFRAD2
DC
(e8)
48E12016T8RB271 12.00 mm 0.50 mm 70.00 mm 16.40 mm 27.00 mm 6 30 Chip Surfer T08 11.50 mm
48E16021TRRB342 16.00 mm 0.50 mm 100.00 mm 20.90 mm 33.50 mm 6 30 Chip Surfer T10 15.30 mm
BARREL FORM FINISHER
Shoulder Facing
SERIES 48E_RB
Slabbing Contouring
Part Number DC
Cutting
Diameter
PRFRAD1
Profile
Radius
PRFRAD2
Profile
Radius
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Flutes
FHA
Flute Helix
Angle
CCMS
Connection
Code
DHUB
Hub
Diameter
48E12016T8RB271 WS-0030 DT-130-10
48E16021TRRB342 WS-0044 DT-250-13
Thin Wrench Torque Wrench
**OPTIONAL**
48E_RB HARDWARE
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T08=130in*lbs, T10=250in*lbs.
No lubricant on adaption. Wrenches sold separately.
99
milling
NEW 1.250" DIAMETER END MILL TIPS WITH T21 THREAD ADAPTION
• Rigid and accurate T21 simultaneous fit T-Adaption with +/-.0005” repeatability
• Change tips on and off the machine within seconds
• Torque wrench required to index tips at 970 inch pounds (wrench head sold separately)
• Economical Steel and Long-Reach Carbide shank options
DC
(e8)
APMX
LF
90°KAPR
DHUB
CCMS
RE/CHW
47DE1215TWRQ06 1.250 0.060 R 1.500 2.165 5 36-38 Chip Surfer T21 1.181 1.5
47DE1215TWRQ12 1.250 0.120 R 1.500 2.165 5 36-38 Chip Surfer T21 1.181 1.3
47DE1215TWRQ25 1.250 0.250 R 1.500 2.165 5 36-38 Chip Surfer T21 1.181 0.7
47DE1215TWRQ37 1.250 0.375 R 1.500 2.165 5 36-38 Chip Surfer T21 1.181 0.5
90° VARIABLE PITCH TIP
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T21=970in/lbs.
No lubricant on adaption. Wrenches sold separately.
Shoulder Facing
SERIES 47D_RQ
Slabbing CorkscrewRamping
Part Number DC
Cutting
Diameter
RE/CHW
Corner
Radius/Chamfer
APMX
Depth of Cut
Max.
LF
Functional
Length
ZEFF
Effective
Flutes
FHA
Flute Helix
Angle
CCMS
Connection
Code
DHUB
Hub
Diameter
RMPX
Ramp Angle
Max.
Channel
47DE1215TWRQ06 DT-24
47DE1215TWRQ12 DT-24
47DE1215TWRQ25 DT-24
47DE1215TWRQ37 DT-24
Torque Wrench Head*
47D_RQ HARDWARE
24mm opening: 14x18mm drive.
Fits most third party adjustable torque wrench handles that can be set to 970 in/lbs.
100
S150T21SK-18 Chip Surfer T21 1.820 6.000 1.181 5.0 1.500 Steel
Part Number CCWS
Connection
Code
LB
Body
Length 1
OAL
Overall
Lengh
BD
Body
Dia.
BHTA
Body Half
Taper Angle
DCON
Shank
Dia.
BMC
Body
Material Code
OAL
BHTA
BD
LB
LBX
DCON
CCWS
STEEL SHANK, CONE NECK
SERIES S*T*SK
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T21=970in/lbs.
No lubricant on adaption. Wrenches sold separately.
S125T21SA-12 Chip Surfer T21 1.200 1.320 4.000 1.181 1.250 Steel
S125T21SA-15 Chip Surfer T21 1.500 1.630 6.000 1.181 1.250 Steel
Part Number CCWS
Connection
Code
LB
Body
Length 1
LBX
Body
Length Max.
OAL
Overall
Lengh
BD
Body
Dia.
DCON
Shank
Dia.
BMC
Body
Material Code
OAL
DCON
LB
LBX
BD
CCWS
STEEL SHANK, NECKED
SERIES S*T*SA
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T21=970in/lbs.
No lubricant on adaption. Wrenches sold separately.
101
milling
S125T21CA-25 Chip Surfer T21 2.500 2.630 5.000 1.181 1.250 Carbide
S125T21CA-40 Chip Surfer T21 4.000 4.130 7.000 1.181 1.250 Carbide
S125T21CA-80 Chip Surfer T21 8.000 8.130 11.000 1.181 1.250 Carbide
Part Number CCWS
Connection
Code
LB
Body
Length 1
LBX
Body
Length Max.
OAL
Overall
Lengh
BD
Body
Dia.
DCON
Shank
Dia.
BMC
Body
Material Code
OAL
DCON
LB
LBX
BD
CCWS
CARBIDE SHANK, NECKED
SERIES S*T*CA
When assembling, be sure tip is seated firmly on shank with no gap. Tightening Torque: T21=970in/lbs.
No lubricant on adaption. Wrenches sold separately.
102
QUICK-CHANGE INTERCHANGEABLE SOLID CARBIDE HEADS FOR
SLOTTING, FACING AND THREADING
• .970-1.560" slotters with .125”-.375” width range and 6-10 flutes
• 24-39mm facing heads with 6-10 flutes; Ideal for stubby applications
• 55° and 60° partial profile threading heads
• Cylindrical shanks with strong tri-lobe-drive and screw connection
• Steel shanks with various neck configurations and coolant options
2 x RE
DC
CCMS (Tri-Lobe Drive)
CW
LF
DHUB
CDX
SERIES 18T, 19T
T-SlottingSlotting
T-SLOT TIP
Part Number DC
Cutting
Diameter
RE
Corner
Radius
CW
Cutting
Width
CDX
Cutting
Depth Max.
LF
Functional
Length
ZEFF
Eff.
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
18T-9712LPRN01 0.970 0.015 0.125 0.210 0.315 6 Multi-Surfer LP 0.510
18T-9715LPRN01 0.970 0.015 0.156 0.210 0.315 6 Multi-Surfer LP 0.510
18T-9718LPRN01 0.970 0.015 0.187 0.210 0.315 6 Multi-Surfer LP 0.510
18T-9721LPRN01 0.970 0.015 0.218 0.210 0.315 6 Multi-Surfer LP 0.510
18T-9725LPRN01 0.970 0.015 0.250 0.210 0.315 6 Multi-Surfer LP 0.510
18T-9728LPRN01 0.970 0.015 0.281 0.210 0.315 6 Multi-Surfer LP 0.510
18T-9731LPRN01 0.970 0.015 0.312 0.210 0.315 6 Multi-Surfer LP 0.510
19T-1212LQRN01 1.250 0.015 0.125 0.310 0.315 8 Multi-Surfer LQ 0.590
19T-1215LQRN01 1.250 0.015 0.156 0.310 0.315 8 Multi-Surfer LQ 0.590
19T-1218LQRN01 1.250 0.015 0.187 0.310 0.315 8 Multi-Surfer LQ 0.590
19T-1221LQRN01 1.250 0.015 0.218 0.310 0.315 8 Multi-Surfer LQ 0.590
19T-1225LQRN01 1.250 0.015 0.250 0.310 0.315 8 Multi-Surfer LQ 0.590
19T-1228LQRN01 1.250 0.015 0.281 0.310 0.315 8 Multi-Surfer LQ 0.590
19T-1231LQRN01 1.250 0.015 0.312 0.310 0.315 8 Multi-Surfer LQ 0.590
19T-1515LRRN01 1.562 0.015 0.156 0.430 0.394 10 Multi-Surfer LR 0.670
19T-1518LRRN01 1.562 0.015 0.187 0.430 0.394 10 Multi-Surfer LR 0.670
19T-1521LRRN01 1.562 0.015 0.218 0.430 0.394 10 Multi-Surfer LR 0.670
19T-1525LRRN01 1.562 0.015 0.250 0.430 0.394 10 Multi-Surfer LR 0.670
19T-1528LRRN01 1.562 0.015 0.281 0.430 0.394 10 Multi-Surfer LR 0.670
19T-1531LRRN01 1.562 0.015 0.312 0.430 0.394 10 Multi-Surfer LR 0.670
19T-1537LRRN01 1.562 0.015 0.375 0.430 0.394 10 Multi-Surfer LR 0.670
103
milling
2 x RE
DC
CCMS (Tri-Lobe Drive)
CW
LF
DHUB
CDX
SERIES 18T, 19T (METRIC)
T-SlottingSlotting
T-SLOT TIP
Part Number DC
Cutting
Diameter
RE
Corner
Radius
CW
Cutting
Width
CDX
Cutting
Depth Max.
LF
Functional
Length
ZEFF
Eff.
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
18T24730LPRN04 24.70 mm 0.400 3.00 mm 5.50 mm 8.00 mm 6 Multi-Surfer LP 13.00 mm
18T24740LPRN04 24.70 mm 0.400 4.00 mm 5.50 mm 8.00 mm 6 Multi-Surfer LP 13.00 mm
18T24750LPRN04 24.70 mm 0.400 5.00 mm 5.50 mm 8.00 mm 6 Multi-Surfer LP 13.00 mm
18T24760LPRN04 24.70 mm 0.400 6.00 mm 5.50 mm 8.00 mm 6 Multi-Surfer LP 13.00 mm
18T24770LPRN04 24.70 mm 0.400 7.00 mm 5.50 mm 8.00 mm 6 Multi-Surfer LP 13.00 mm
18T24780LPRN04 24.70 mm 0.400 8.00 mm 5.50 mm 8.00 mm 6 Multi-Surfer LP 13.00 mm
19T31730LQRN04 31.70 mm 0.400 3.00 mm 8.00 mm 8.00 mm 8 Multi-Surfer LQ 15.00 mm
19T31740LQRN04 31.70 mm 0.400 4.00 mm 8.00 mm 8.00 mm 8 Multi-Surfer LQ 15.00 mm
19T31750LQRN04 31.70 mm 0.400 5.00 mm 8.00 mm 8.00 mm 8 Multi-Surfer LQ 15.00 mm
19T31760LQRN04 31.70 mm 0.400 6.00 mm 8.00 mm 8.00 mm 8 Multi-Surfer LQ 15.00 mm
19T31770LQRN04 31.70 mm 0.400 7.00 mm 8.00 mm 8.00 mm 8 Multi-Surfer LQ 15.00 mm
19T31780LQRN04 31.70 mm 0.400 8.00 mm 8.00 mm 8.00 mm 8 Multi-Surfer LQ 15.00 mm
19T39740LRRN04 39.70 mm 0.400 4.00 mm 11.00 mm 10.00 mm 10 Multi-Surfer LR 17.00 mm
19T39750LRRN04 39.70 mm 0.400 5.00 mm 11.00 mm 10.00 mm 10 Multi-Surfer LR 17.00 mm
19T39760LRRN04 39.70 mm 0.400 6.00 mm 11.00 mm 10.00 mm 10 Multi-Surfer LR 17.00 mm
19T39770LRRN04 39.70 mm 0.400 7.00 mm 11.00 mm 10.00 mm 10 Multi-Surfer LR 17.00 mm
19T39780LRRN04 39.70 mm 0.400 8.00 mm 11.00 mm 10.00 mm 10 Multi-Surfer LR 17.00 mm
19T39790LRRN04 39.70 mm 0.400 9.00 mm 11.00 mm 10.00 mm 10 Multi-Surfer LR 17.00 mm
19T39799LRRN04 39.70 mm 0.400 10.00 mm 11.00 mm 10.00 mm 10 Multi-Surfer LR 17.00 mm
104
BS
LF
APMX
90°KAPR
RE
CCMS (Tri-Lobe Drive)
DC DHUB
SERIES 18F, 19F (METRIC)
FacaingShoulder
90° FACE MILL TIP
Part Number DC
Cutting
Diameter
RE
Corner
Radius
BS
Wiper
Length
APMX
Depth of
Cut Max.
LF
Functional
Length
ZEFF
Eff.
Teeth
CCMS
Connection
Code
DHUB
Hub
Diameter
18F24280LPRA04 25.00 mm 0.400 3.60 mm 8.00 mm 8.0 mm 8 Multi-Surfer LP 13.0 mm
19F31280LQRA04 32.00 mm 0.400 3.60 mm 8.00 mm 8.0 mm 8 Multi-Surfer LQ 15.0 mm
19F39210LRRA04 40.00 mm 0.400 3.60 mm 10.00 mm 10.0 mm 10 Multi-Surfer LR 17.0 mm
60ºPNA
PDXLF
RE
DC
CCMS (Tri-Lobe Drive)
DHUB
CDX
SERIES 18Y_60, 19Y_60
External ThreadInternal Thread
THREAD MILL TIP
18Y24730LPRP60 24.70 mm 3.0 5.0 8 5 60 0.20mm 2.2mm 3.50mm 5.50mm 36.0 mm 6 Multi-Surfer LP 13.0mm
19Y31740LQRP60 31.70 mm 4.0 6.0 6 4 60 0.30mm 3.7mm 4.70mm 4.00mm 46.0 mm 8 Multi-Surfer LQ 15.0mm
19Y39760LRRP60 39.70 mm 6.0 8.0 4 3 60 0.40mm 4.5mm 6.20mm 5.00mm 57.0 mm 10 Multi-Surfer LR 17.0mm
Part Number DC
Cutting
Diameter
TPN
Thread
Pitch Min.
TPX
Thread
Pitch Max.
TPIN
Thread
Pitch
Inch Min.
TPIX
Thread
Pitch
Inch Max.
PNA
Profile
Included
Angle
RE
Corner
Radius
PDX
Profile
Distance
Ex.
CDX
Cutting
Depth
Max.
LF
Functional
Length.
DWN
Workpiece
Dia. Min.
ZEFF
Eff.
Flutes
CCMS
Connection
Code
DHUB
Hub
Diameter
105
milling
OAL
LF
DCON
LB
LBX
BD
CCWS
SERIES S*L*SA
STEEL SHANK, NECKED
Part Number CCWS
Connection
Code
LB
Body
Length 1
LBX
Body
Length Max.
LF
Functional
Length
OAL
Overall
Length
BD
Body
Diameter
DCON
Shank
Diameter
BMC
Body Material
Code
S062LPSA-05 Multi-Surfer LP 0.600 0.650 4.000 4.170 0.510 0.625 Steel
S062LQSA-06 Multi-Surfer LQ 0.700 0.720 4.000 4.190 0.590 0.625 Steel
S062LQSA-07 Multi-Surfer LQ 0.780 0.800 5.000 5.190 0.590 0.625 Steel
S075LRSA-08 Multi-Surfer LR 0.900 0.940 5.500 5.730 0.670 0.750 Steel
S016LPSA-16 Multi-Surfer LP 13.00 mm 16.60 mm 100.00 mm 104.35 mm 13.00 mm 16.00 mm Steel
S016LQSA-18 Multi-Surfer LQ 16.00 mm 18.20 mm 100.00 mm 104.90 mm 15.00 mm 16.00 mm Steel
S016LQSA-19 Multi-Surfer LQ 16.00 mm 18.20 mm 130.00 mm 134.90 mm 15.00 mm 16.00 mm Steel
S020LRSA-23 Multi-Surfer LR 20.20 mm 23.80 mm 140.00 mm 146.00 mm 17.00 mm 20.00 mm Steel
INCH
METRIC
Shank modifications can be made by cutting off the back to desired length or turning back the neck for more usable length.
106
OAL
LF
DCON
LB
LB2
LBX
BD
BD2
CCWS
SERIES S*L*SA
Coolant
STEEL SHANK
Part Number CCWS
Connection
Code
LB
Body
Length 1
LB2
Body
Length 2
LBX
Body
Length Max.
LF
Functional
Length
OAL
Overall
Length
BD
Body
Dia.
BD2
Body
Dia. 2
DCON
Shank
Dia.
CNSC
Coolant Entry
Style Code
CXSC
Coolant Exit
Style Code
BMC
Body Mat’l
Code
S075LPSA-03 Multi-Surfer LP 0.030 0.300 0.380 4.250 4.420 0.510 0.625 0.750 1 1, 3 Steel
S100LQSA-03 Multi-Surfer LQ 0.030 0.300 0.380 4.250 4.440 0.590 0.812 1.000 1 1, 3 Steel
S125LRSA-03 Multi-Surfer LR 0.030 0.300 0.380 5.750 5.980 0.670 1.125 1.250 1 1, 3 Steel
INCH
METRIC
S020LPSA-10 Multi-Surfer LP 0.76 mm 7.60 mm 10.00 mm 100.00 mm 104.35 mm 13.00 mm 16.00 mm 20.00 mm 1 1, 3 Steel
S025LQSA-10 Multi-Surfer LQ 0.76 mm 7.60 mm 10.00 mm 100.00 mm 104.90 mm 15.00 mm 21.00 mm 25.00 mm 1 1, 3 Steel
S032LRSA-10 Multi-Surfer LR 0.76 mm 7.60 mm 10.00 mm 140.00 mm 146.00 mm 17.00 mm 28.00 mm 32.00 mm 1 1, 3 Steel
Shank modifications can be made by cutting off the back to desired length.
S062LPSA-05 TS40T098/HG-P DS-A00T DS-TP156B
S062LQSA-06 TS50T110/HG-P DS-A00T DS-TP206B
S062LQSA-07 TS50T110/HG-P DS-A00T DS-TP206B
S075LRSA-08 TS60T130/HG-P DS-A00T DS-TP206B
S016LPSA-16 TS40T098/HG-P DS-A00T DS-TP156B
S016LQSA-18 TS50T110/HG-P DS-A00T DS-TP206B
S016LQSA-19 TS50T110/HG-P DS-A00T DS-TP206B
S020LRSA-23 TS60T130/HG-P DS-A00T DS-TP206B
S075LPSA-03 TS40T098/HG-P DS-A00T DS-TP156B
S100LQSA-03 TS50T110/HG-P DS-A00T DS-TP206B
S125LRSA-03 TS60T130/HG-P DS-A00T DS-TP206B
S020LPSA-10 TS40T098/HG-P DS-A00T DS-TP156B
S025LQSA-10 TS50T110/HG-P DS-A00T DS-TP206B
S032LRSA-10 TS60T130/HG-P DS-A00T DS-TP206B
Screw Driver Handle Torx Bit
HARDWARE
107
milling
NEW CERASFEED OFFERS EXCEPTIONAL PRODUCTIVITY GAINS!
• Cutter body options include: End Mill and Face Mill
• Cutter diameter range, 1.000" up to 3.000"
• Higher insert densities for super productivity!
• New SiAlON grade IN76N will SFEEDUP demanding milling processes!
• SFM up to 33 times greater than solid carbide (60-90 SFM Carbide versus 3000 SFM Ceramic)!
• Max. Depth of cut (DOC) capability from 1.5mm (.060) to 2.5mm (.098)
• Two unique and optimally designed high-feed insert geometries, double-sided
• Inserts offer 4 or 6 cutting edges for cost-effective machining and economy!
• Super strong insert clamping system ensures stable milling performance
• Lower cutting forces promote efficient and higher productivity milling!
OAL
LPR
LUX
DCON
DC
DCX
REEQ
APMX
90°
Backdraft
END MILL, 09MM IC INSERT SERIES
PocketingCorkscrew FacingRampContour
SERIES 1ZG3F (CYLINDRICAL SHANK)
09
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
APMX
Depth of
Cut Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Shank
Dia.
LUX
Usable
Length Max.
LPR
Protruding
Length
CSP
Coolant
RMPX
Ramp
Angle Max.
1ZG3F-10040S1R01 1.000 0.600 .060 (1.5mm) 4.000 2 0.134 1.000 1.600 1.76 Air .7
1ZG3F-10040S1R02 1.000 0.600 .060 (1.5mm) 4.000 3 0.134 1.000 1.600 1.76 Air .7
1ZG3F-12050S1R01 1.250 0.838 .060 (1.5mm) 5.000 3 0.134 1.250 1.600 2.72 Air .6
1ZG3F-15050S1R01 1.500 1.084 .060 (1.5mm) 5.000 4 0.134 1.250 1.600 2.72 Air .65
ShoulderChannel
REEQ
APMX
90°
Backdraft
DC
DCX
OAL
DCON
KWW
SERIES TG1Q, TG2Q
09
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
APMX
Depth of
Cut Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Bore
Dia.
KWW
Keyway CSP
Coolant
RMPX
Ramp
Angle Max.
TG1Q-20R01 2.000 1.583 .060 (1.5mm) 1.570 5 0.134 0.750 0.312 Air .55
TG2Q-20R01 2.000 1.583 .060 (1.5mm) 1.570 4 0.134 0.750 0.312 Air .55
FACE MILL, 09MM IC INSERT SERIES
PocketingCorkscrew FacingRampContour
ShoulderChannel
108
DC
DCX
OAL
DCON
KWW
REEQ
APMX
90°
SERIES DG1H, DG2H
12
Part Number DCX
Cutting
Dia. Max.
DC
Cutting
Dia.
APMX
Depth of
Cut Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
REEQ
Program Radius
Equivalent
DCON
Bore
Dia.
KWW
Keyway CSP
Coolant
RMPX
Ramp
Angle Max.
DG1H-20R01 2.000 1.320 .098 (2.5mm) 1.575 5 0.177 0.750 0.312 Air .6
DG2H-20R01 2.000 1.320 .098 (2.5mm) 1.575 4 0.177 0.750 0.312 Air .6
DG1H-25R01 2.500 1.820 .098 (2.5mm) 1.575 7 0.177 0.750 0.312 Air .5
DG2H-25R01 2.500 1.820 .098 (2.5mm) 1.575 6 0.177 0.750 0.312 Air .5
DG1H-30R01 3.000 2.315 .098 (2.5mm) 1.575 8 0.177 1.000 0.375 Air .45
DG2H-30R01 3.000 2.315 .098 (2.5mm) 1.575 7 0.177 1.000 0.375 Air .45
FACE MILL, 12MM IC INSERT SERIES
PocketingCorkscrew FacingRampContour
ShoulderChannel
Part Number Application REEQ
Program Radius
Equivalent
INSL
Insert
Length
IC
Inscribed
Circle Dia.
S
Thickness
Overall
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN76N
TNXN1207N01 Multi-Purpose .177 .535 .472 .276 6 Right •
TNXN12
S
IC
INSL
INSERT
12
Part Number Application REEQ
Program Radius
Equivalent
INSL
Insert
Length
W1
Insert
Width
IC
Inscribed
Circle Dia.
S1
Thickness
Overall
NOI
Number of
Indexes
IH
Insert
Hand
Grade
IN76N
LNXF0905R01 Multi-Purpose .134 .472 .165 .354 .197 4 Right •
LNXF09
S1
W1
INSL
INSERT
09
Suggested Operating Parameters
AP
Depth of Cut FZ
Feed Per Tooth (in) Grade
.040 ----> .080 .006 ----> .014 IN76N
Suggested Operating Parameters
AP
Depth of Cut FZ
Feed Per Tooth (in) Grade
.020 ----> .040 .006 ----> .014 IN76N
109
milling
1ZG3F-10040S1R01 CCL-3S-ASSY L-W2 -- -
1ZG3F-10040S1R02 CCL-3S-ASSY L-W2 -- -
1ZG3F-12050S1R01 CCL-3S-ASSY L-W2 -- -
1ZG3F-15050S1R01 CCL-3S-ASSY L-W2 -- -
TG1Q-16R01 CCL-3S-ASSY L-W2 -- -
TG1Q-20R01 CCL-3S-ASSY L-W2 -- -
TG2Q-20R01 CCL-3S-ASSY L-W2 -- -
DG1H-20R01 - - WFZ6-C WS6 DS-H03T
DG2H-20R01 - - WFZ6-C WS6 DS-H03T
DG1H-25R01 - - WFZ6-C WS6 DS-H03T
DG2H-25R01 - - WFZ6-C WS6 DS-H03T
DG1H-30R01 - - WFZ6-C WS6 DS-H03T
DG2H-30R01 - - WFZ6-C WS6 DS-H03T
Clamp Wedge Wedge Screw
HARDWARE
09/12
DriverWrench
110
HIGH NUMBER OF PCD CUTTING EDGES FOR HIGH PRODUCTIVITY!
• High rigidity double clamping system to support High-Feed machining
• Up to .024” (.6mm) total axial adjustment to ensure an excellent surface finish
• Multiple cutting edge geometries to cover any application, including 90° and 75° lead angle
• 1.5” (40mm) available in cylindrical shank
• 2.0-5.0” (50mm-125mm) range in shell mill or monoblock bodies
• DOC capability of .157” (4mm)
• Ability to re-tip cartridges
Minimum diameter guaranteed with standard inserts. Refer to related table of available cutting geometry for more detail.
1 Part number refers to body only, without inserts.
Part Number1DC (75º)
Cutting
Diameter
DC (90º)
Cutting
Diameter
DCX (75º)
Cutting
Diameter Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
Holder
Shape
DCON
Shank
Diameter
BMC
Body
Material Code Item
INCH
TXGSM22I020-10-00 1.94 2 2 2.17 10 A 22 mm Steel 2742926
TXGSM22I025-13-00 2.44 2.5 2.5 2.17 13 B 22 mm Steel 2742927
TXGSM27I030-16-00 2.94 3 3 2.28 16 A 27 mm Steel 2742928
TXGSM32I040-22-00 3.94 4 4 2.28 22 A 32 mm Aluminum & Steel 2742929
TXGSM40I050-28-00 4.94 5 5 2.28 28 A 40 mm Aluminum & Steel 2742930
METRIC
TXGSM22D050-10-00 48.6 50 50 55 10 B 22 mm Steel 2742926
TXGSM22D063U13-00 61.6 63 63 55 13 A 22 mm Steel 2747098
TXGSM27D080U16-00 78.6 80 80 58 16 A 27 mm Steel 2747099
TXGSM32D100U22-00 98.6 100 100 58 22 A 32 mm Aluminum & Steel 2747100
TXGSM40D125U28-00 123.6 125 125 58 28 A 40 mm Aluminum & Steel 2747101
SHELL MILL WITH AXIAL ADJUSTMENT
OAL
DCON
DC
DCX .10APMX1
APMX2
DCX
DC
90°KAPR2
75°KAPR1
111
milling
Minimum diameter guaranteed with standard inserts. Refer to related table of available cutting geometry for more detail.
1 Part number refers to body only, without inserts.
Monoblock mills available upon request.
Part Number1DC (75º)
Cutting
Diameter
DC (90º)
Cutting
Diameter
DCX (75º)
Cutting
Diameter Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
Holder
Shape
DCON
Shank
Diameter
BMC
Body
Material Code Item
METRIC
TXGHA63D063-13-00 63 64.4 64.4 100 13 HSK 63 A 52 Steel 2748906
TXGHA63D080-16-00 80 81.4 81.4 100 16 HSK 63 A 52 Steel 2748905
TXGHA63D100-22-00 100 101.4 101.4 100 22 HSK 63 A 52 Steel 2748907
MONOBLOCK MILL WITH AXIAL ADJUSTMENT
Minimum diameter guaranteed with standard inserts. Refer to related table of available cutting geometry for more detail.
1 Part number refers to body only, without inserts.
Part Number1DC (75º)
Cutting
Diameter
DC (90º)
Cutting
Diameter
DCX (75º)
Cutting
Diameter Max.
OAL
Overall
Length
ZEFF
Eff.
Teeth
Holder
Shape
DCON
Shank
Diameter
BMC
Body
Material Code Item
INCH
TXGSC01I015-07-00 1.44 1.5 1.5 3.94 7 Cylindrical 1.00 Steel 2742931
METRIC
TXGSC25D040U07-00 38.6 40 40 100 7 Cylindrical 25 mm Steel 2747102
CYLINDRICAL SHANK END MILL WITH AXIAL ADJUSTMENT
.10APMX1
APMX2
DCX
DC
90°KAPR2
75°KAPR1
DCON
DC
DCX
OAL
LPR
LUX
APMX
DCX
DC
90°KAPR
OAL
LF
LUX
DC
DCX
CCMS
DF
112
Part Number Availability Geometry Rotation Grade* Item
TXGPA01RPJ Stock 01 R PB 2717188
TXGPA02RPJ Stock 02 R PB 2717189
TXGPA05RPJ Stock 05 R PB 2717190
TXGPA45RPJ Stock 45 R PB 2747053
TXGPA07RPJ Stock 07 R PB 2717191
TXGPA09RPJ Stock 09 R PB 2724019
Alternative grades available. Please contact IT.TE.DI. for choosing the best grade.
PCD INSERTS
113
drilling
PREMIUM HOLE MACHINING WITH TPC SELF-CENTERING TIPS
• Unique geometry eliminates need for a pilot hole
• Excellent surface finish, hole cylindricity and straightness
• Fully compatible with existing GoldTwist drill bodies
• Diameter range: .236”- 1.020” (D6.0-25.9mm)
• For steel and cast iron applications
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES TPC
LPR
PL
BCH LF
DC
SELF-CENTERING DRILL TIPS
CoolantDrilling
TPC0600R01 0.2362 6.00 6 0.057 0.157 0.100 0.020 •
TPC0635R01 0.2500 6.35 6 0.059 0.169 0.108 0.020 •
TPC0650R01 0.2559 6.50 6.5 0.061 0.169 0.108 0.020 •
TPC0680R01 0.2677 6.80 6.5 0.063 0.169 0.107 0.020 •
TPC0700R01 0.2756 7.00 7 0.065 0.181 0.117 0.020 •
TPC0750R01 0.2953 7.50 7.5 0.067 0.181 0.114 0.020 •
TPC0790R01 0.3110 7.90 7.5 0.069 0.181 0.112 0.020 •
TPC0800R01 0.3150 8.00 8 0.071 0.213 0.141 0.020 •
TPC0850R01 0.3346 8.50 8.5 0.074 0.213 0.139 0.020 •
TPC0860R01 0.3386 8.60 8.5 0.074 0.213 0.138 0.020 •
TPC0870R01 0.3425 8.70 8.5 0.075 0.213 0.138 0.020 •
TPC0880R01 0.3465 8.80 8.5 0.076 0.213 0.137 0.020 •
TPC0890R01 0.3504 8.90 8.5 0.076 0.213 0.136 0.020 •
TPC0900R01 0.3543 9.00 9 0.078 0.228 0.150 0.020 •
TPC0950R01 0.3740 9.50 9.5 0.081 0.228 0.148 0.020 •
TPC0960R01 0.3780 9.60 9.5 0.081 0.228 0.147 0.020 •
TPC0970R01 0.3819 9.70 9.5 0.081 0.228 0.147 0.020 •
TPC0980R01 0.3858 9.80 9.5 0.082 0.228 0.146 0.020 •
TPC0990R01 0.3898 9.90 9.5 0.083 0.228 0.146 0.020 •
TPC1000R01 0.3937 10.00 10 0.092 0.244 0.152 0.028 •
TPC1020R01 0.4016 10.20 10 0.093 0.244 0.151 0.028 •
TPC1030R01 0.4055 10.30 10 0.093 0.244 0.151 0.028 •
TPC1040R01 0.4094 10.40 10 0.094 0.244 0.150 0.028 •
TPC1050R01 0.4134 10.50 10.5 0.094 0.244 0.150 0.028 •
TPC1060R01 0.4173 10.60 10.5 0.095 0.244 0.149 0.028 •
TPC1070R01 0.4213 10.70 10.5 0.095 0.244 0.149 0.028 •
TPC1080R01 0.4252 10.80 10.5 0.096 0.244 0.148 0.028 •
TPC1090R01 0.4291 10.90 10.5 0.096 0.244 0.148 0.028 •
TPC1100R01 0.4331 11.00 11 0.098 0.260 0.161 0.028 •
TPC1111R01 0.4374 11.11 11 0.099 0.260 0.161 0.028 •
•
:
Standard items
Part Number DC Cutting Diameter SSC
Seat Size
Code
PL
Point
Length
LPR
Projection
Length
LF
Functional
Length
BCH
Chamfer
Length
Grade
(inch) (mm) IN2505
114
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES TPC
LPR
PL
BCH LF
DC
SELF-CENTERING DRILL TIPS
CoolantDrilling
TPC1120R01 0.4409 11.20 11 0.100 0.260 0.160 0.028 •
TPC1130R01 0.4449 11.30 11 0.100 0.260 0.160 0.028 •
TPC1140R01 0.4488 11.40 11 0.100 0.260 0.159 0.028 •
TPC1150R01 0.4528 11.50 11.5 0.101 0.260 0.159 0.028 •
TPC1160R01 0.4567 11.60 11.5 0.102 0.260 0.158 0.028 •
TPC1170R01 0.4606 11.70 11.5 0.102 0.260 0.158 0.028 •
TPC1180R01 0.4646 11.80 11.5 0.103 0.260 0.157 0.028 •
TPC1190R01 0.4685 11.90 11.5 0.103 0.260 0.157 0.028 •
TPC1200R01 0.4724 12.00 12 0.105 0.276 0.170 0.028 •
TPC1210R01 0.4764 12.10 12 0.106 0.276 0.170 0.028 •
TPC1220R01 0.4803 12.20 12 0.106 0.276 0.169 0.028 •
TPC1230R01 0.4843 12.30 12 0.107 0.276 0.169 0.028 •
TPC1240R01 0.4882 12.40 12 0.107 0.276 0.169 0.028 •
TPC1250R01 0.4921 12.50 12.5 0.108 0.276 0.168 0.028 •
TPC1260R01 0.4961 12.60 12.5 0.108 0.276 0.167 0.028 •
TPC1270R01 0.5000 12.70 12.5 0.109 0.276 0.167 0.028 •
TPC1280R01 0.5039 12.80 12.5 0.109 0.276 0.166 0.028 •
TPC1300R01 0.5118 13.00 13 0.112 0.299 0.187 0.028 •
TPC1310R01 0.5157 13.10 13 0.113 0.299 0.187 0.028 •
TPC1320R01 0.5197 13.20 13 0.113 0.299 0.186 0.028 •
TPC1340R01 0.5276 13.40 13 0.114 0.299 0.185 0.028 •
TPC1350R01 0.5315 13.50 13.5 0.115 0.299 0.184 0.028 •
TPC1370R01 0.5394 13.70 13.5 0.116 0.299 0.183 0.028 •
TPC1380R01 0.5433 13.80 13.5 0.117 0.299 0.183 0.028 •
TPC1390R01 0.5472 13.90 13.5 0.117 0.299 0.182 0.028 •
TPC1400R01 0.5512 14.00 14 0.119 0.321 0.202 0.028 •
TPC1410R01 0.5551 14.10 14 0.119 0.321 0.202 0.028 •
TPC1420R01 0.5591 14.20 14 0.120 0.321 0.201 0.028 •
TPC1430R01 0.5630 14.30 14 0.120 0.321 0.200 0.028 •
TPC1440R01 0.5669 14.40 14 0.121 0.321 0.200 0.028 •
TPC1450R01 0.5709 14.50 14.5 0.122 0.321 0.199 0.028 •
•
:
Standard items
Part Number DC Cutting Diameter SSC
Seat Size
Code
PL
Point
Length
LPR
Projection
Length
LF
Functional
Length
BCH
Chamfer
Length
Grade
(inch) (mm) IN2505
115
drilling
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES TPC
LPR
PL
BCH LF
DC
SELF-CENTERING DRILL TIPS
CoolantDrilling
TPC1460R01 0.5748 14.60 14.5 0.122 0.321 0.199 0.028 •
TPC1470R01 0.5787 14.70 14.5 0.122 0.321 0.198 0.028 •
TPC1480R01 0.5827 14.80 14.5 0.123 0.321 0.198 0.028 •
TPC1500R01 0.5906 15.00 15 0.126 0.344 0.218 0.028 •
TPC1510R01 0.5945 15.10 15 0.126 0.344 0.218 0.028 •
TPC1520R01 0.5984 15.20 15 0.127 0.344 0.217 0.028 •
TPC1530R01 0.6024 15.30 15 0.127 0.344 0.217 0.028 •
TPC1540R01 0.6063 15.40 15 0.128 0.344 0.216 0.028 •
TPC1550R01 0.6102 15.50 15 0.128 0.344 0.215 0.028 •
TPC1560R01 0.6142 15.60 15 0.129 0.344 0.215 0.028 •
TPC1570R01 0.6181 15.70 15 0.129 0.344 0.215 0.028 •
TPC1580R01 0.6220 15.80 15 0.130 0.344 0.214 0.028 •
TPC1590R01 0.6260 15.90 15 0.130 0.344 0.213 0.028 •
TPC1600R01 0.6299 16.00 16 0.136 0.366 0.230 0.031 •
TPC1610R01 0.6339 16.10 16 0.137 0.366 0.229 0.031 •
TPC1620R01 0.6378 16.20 16 0.137 0.366 0.229 0.031 •
TPC1630R01 0.6417 16.30 16 0.138 0.366 0.228 0.031 •
TPC1640R01 0.6457 16.40 16 0.138 0.366 0.228 0.031 •
TPC1650R01 0.6496 16.50 16 0.139 0.366 0.227 0.031 •
TPC1660R01 0.6535 16.60 16 0.139 0.366 0.227 0.031 •
TPC1670R01 0.6575 16.70 16 0.140 0.366 0.226 0.031 •
TPC1680R01 0.6614 16.80 16 0.141 0.366 0.226 0.031 •
TPC1700R01 0.6693 17.00 17 0.143 0.390 0.247 0.031 •
TPC1710R01 0.6732 17.10 17 0.143 0.390 0.246 0.031 •
TPC1720R01 0.6772 17.20 17 0.144 0.390 0.246 0.031 •
TPC1730R01 0.6811 17.30 17 0.144 0.390 0.245 0.031 •
TPC1740R01 0.6850 17.40 17 0.145 0.390 0.245 0.031 •
TPC1750R01 0.6890 17.50 17 0.146 0.390 0.244 0.031 •
TPC1760R01 0.6929 17.60 17 0.146 0.390 0.244 0.031 •
TPC1770R01 0.6969 17.70 17 0.146 0.390 0.243 0.031 •
TPC1780R01 0.7008 17.80 17 0.147 0.390 0.243 0.031 •
•
:
Standard items
Part Number DC Cutting Diameter SSC
Seat Size
Code
PL
Point
Length
LPR
Projection
Length
LF
Functional
Length
BCH
Chamfer
Length
Grade
(inch) (mm) IN2505
116
TPC1790R01 0.7047 17.90 17 0.148 0.390 0.242 0.031 •
TPC1800R01 0.7087 18.00 18 0.150 0.413 0.263 0.031 •
TPC1810R01 0.7126 18.10 18 0.150 0.413 0.263 0.031 •
TPC1820R01 0.7165 18.20 18 0.151 0.413 0.262 0.031 •
TPC1830R01 0.7205 18.30 18 0.152 0.413 0.262 0.031 •
TPC1850R01 0.7283 18.50 18 0.153 0.413 0.261 0.031 •
TPC1860R01 0.7323 18.60 18 0.153 0.413 0.260 0.031 •
TPC1870R01 0.7362 18.70 18 0.154 0.413 0.260 0.031 •
TPC1880R01 0.7402 18.80 18 0.154 0.413 0.259 0.031 •
TPC1900R01 0.7480 19.00 19 0.157 0.433 0.276 0.031 •
TPC1905R01 0.7500 19.05 19 0.157 0.433 0.276 0.031 •
TPC1910R01 0.7520 19.10 19 0.157 0.433 0.276 0.031 •
TPC1920R01 0.7559 19.20 19 0.158 0.433 0.275 0.031 •
TPC1930R01 0.7598 19.30 19 0.158 0.433 0.275 0.031 •
TPC1940R01 0.7638 19.40 19 0.159 0.433 0.274 0.031 •
TPC1950R01 0.7677 19.50 19 0.159 0.433 0.274 0.031 •
TPC1960R01 0.7717 19.60 19 0.160 0.433 0.273 0.031 •
TPC1970R01 0.7756 19.70 19 0.160 0.433 0.273 0.031 •
TPC1980R01 0.7795 19.80 19 0.161 0.433 0.272 0.031 •
TPC1990R01 0.7835 19.90 19 0.161 0.433 0.272 0.031 •
TPC2000R01 0.7874 20.00 20 0.163 0.457 0.293 0.031 •
TPC2010R01 0.7913 20.10 20 0.164 0.457 0.293 0.031 •
TPC2020R01 0.7953 20.20 20 0.165 0.457 0.292 0.031 •
TPC2050R01 0.8071 20.50 20 0.166 0.457 0.291 0.031 •
TPC2060R01 0.8110 20.60 20 0.167 0.457 0.290 0.031 •
TPC2070R01 0.8150 20.70 20 0.167 0.457 0.290 0.031 •
TPC2100R01 0.8268 21.00 21 0.170 0.480 0.309 0.031 •
TPC2110R01 0.8307 21.10 21 0.170 0.480 0.309 0.031 •
TPC2120R01 0.8346 21.20 21 0.171 0.480 0.308 0.031 •
TPC2140R01 0.8425 21.40 21 0.172 0.480 0.307 0.031 •
TPC2150R01 0.8465 21.50 21 0.173 0.480 0.307 0.031 •
•
:
Standard items
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES TPC
LPR
PL
BCH LF
DC
Part Number DC Cutting Diameter SSC
Seat Size
Code
PL
Point
Length
LPR
Projection
Length
LF
Functional
Length
BCH
Chamfer
Length
Grade
(inch) (mm) IN2505
SELF-CENTERING DRILL TIPS
CoolantDrilling
117
drilling
TPC2200R01 0.8661 22.00 22 0.177 0.502 0.325 0.031 •
TPC2222R01 0.8748 22.22 22 0.178 0.502 0.324 0.031 •
TPC2250R01 0.8858 22.50 22 0.180 0.502 0.322 0.031 •
TPC2290R01 0.9016 22.90 22 0.182 0.502 0.320 0.031 •
TPC2300R01 0.9055 23.00 23 0.184 0.525 0.341 0.031 •
TPC2350R01 0.9252 23.50 23 0.187 0.525 0.338 0.031 •
TPC2380R01 0.9370 23.80 23 0.188 0.525 0.337 0.031 •
TPC2400R01 0.9449 24.00 24 0.191 0.547 0.357 0.031 •
TPC2450R01 0.9646 24.50 24 0.193 0.547 0.354 0.031 •
TPC2500R01 0.9843 25.00 25 0.197 0.571 0.374 0.031 •
TPC2540R01 1.0000 25.40 25 0.199 0.571 0.372 0.031 •
TPC2550R01 1.0039 25.50 25 0.200 0.571 0.371 0.031 •
TPC2560R01 1.0078 25.60 25 0.201 0.571 0.370 0.031 •
TPC2590R01 1.0197 25.90 25 0.202 0.571 0.369 0.031 •
•
:
Standard items
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES TPC
LPR
PL
BCH LF
DC
Part Number DC Cutting Diameter SSC
Seat Size
Code
PL
Point
Length
LPR
Projection
Length
LF
Functional
Length
BCH
Chamfer
Length
Grade
(inch) (mm) IN2505
SELF-CENTERING DRILL TIPS
CoolantDrilling
118
3-FLUTE QUICK CHANGE DRILLS FOR INCREASED PRODUCTIVITY!
• 3-Flute geometry allows for increased productivity by more than 50%
• Diameter range: .6299”-.8228” (D16.0-D20.9mm)
• Can accommodate 3xD and 5xD applications
• Self-Centering geometry
- Eliminates the need for piloting pre hole
- Excellent hole precision and finish
- Reduced spindle loads
• Multiple diameters accommodated with one, single body
• Coolant through for excellent chip evacuation
• New IN2205 grade for excellent tool life in steel and cast iron applications
• Simplified tip replacement provides reduced downtime
SERIES FD (UNIVERSAL FLAT SHANK)
FD160004818R01 0.6299 (16.00 mm) 0.6654 (16.90 mm) 16 2.05 2.76 1.97 0.750 0.98 KFD16-17
FD170005118R01 0.6693 (17.00 mm) 0.7047 (17.90 mm) 17 2.17 2.94 1.97 0.750 0.98 KFD16-17
FD1800054C8R01 0.7087 (18.00 mm) 0.7441 (18.90 mm) 18 2.28 3.15 2.20 1.000 1.26 KFD18-19
FD1900057C8R01 0.7480 (19.00 mm) 0.7835 (19.90 mm) 19 2.40 3.31 2.20 1.000 1.26 KFD18-19
FD2000060C8R01 0.7874 (20.00 mm) 0.8228 (20.90 mm) 20 2.52 3.47 2.20 1.000 1.26 KFD20-21
3XD UNIVERSAL FLAT SHANKS
Coolant
Part Number DCN
Cutting
Dia. Min.
DCX
Cutting
Dia. Max.
SSC
Seat Size
Code
LU
Usable
Length
LF
Functional
Length
LS
Shank
Length
DCON
Shank
Diameter
DF
Flange
Diameter Key
LU
LF LS
DCON
DCN-DCX
DF
Drilling
119
drilling
SERIES FD (UNIVERSAL FLAT SHANK)
FD160008018R01 0.6299 (16.00 mm) 0.6654 (16.90 mm) 16 3.31 4.02 1.97 0.750 0.98 KFD16-17
FD170008518R01 0.6693 (17.00 mm) 0.6693 (17.90 mm) 17 3.50 4.28 1.97 0.750 0.98 KFD16-17
FD1800090C8R01 0.7087 (18.00 mm) 0.7441 (18.90 mm) 18 3.70 4.56 2.20 1.000 1.26 KFD18-19
FD1900095C8R01 0.7480 (19.00 mm) 0.7835 (19.90 mm) 19 3.90 4.80 2.20 1.000 1.26 KFD18-19
FD2000100C8R01 0.7874 (20.00 mm) 0.8228 (20.90 mm) 20 4.09 5.04 2.20 1.000 1.26 KFD20-21
5XD UNIVERSAL FLAT SHANKS
Coolant
Part Number DCN
Cutting
Dia. Min.
DCX
Cutting
Dia. Max.
SSC
Seat Size
Code
LU
Usable
Length
LF
Functional
Length
LS
Shank
Length
DCON
Shank
Diameter
DF
Flange
Diameter Key
LF LS
LU
DCON
DCN-DCX
DF
SERIES FD (CYLINDRICAL SHANK)
FD1600048S7R01 0.6299 (16.00 mm) 0.6654 (16.90 mm) 16 2.05 2.76 1.97 0.750 0.98 KFD16-17
FD1700051S7R01 0.6693 (17.00 mm) 0.6693 (17.90 mm) 17 2.17 2.94 1.97 0.750 0.98 KFD16-17
FD1800054S1R01 0.7087 (18.00 mm) 0.7441 (18.90 mm) 18 2.28 3.15 2.20 1.000 1.26 KFD18-19
FD1900057S1R01 0.7480 (19.00 mm) 0.7835 (19.90 mm) 19 2.40 3.31 2.20 1.000 1.26 KFD18-19
FD2000060S1R01 0.7874 (20.00 mm) 0.8228 (20.90 mm) 20 2.52 3.47 2.20 1.000 1.26 KFD20-21
3XD CYLINDRICAL SHANKS
Coolant
Part Number DCN
Cutting
Dia. Min.
DCX
Cutting
Dia. Max.
SSC
Seat Size
Code
LU
Usable
Length
LF
Functional
Length
LS
Shank
Length
DCON
Shank
Diameter
DF
Flange
Diameter Key
LU
DCON
DCN-DCX
LF LS
DF
Drilling
Drilling
120
SERIES FD (CYLINDRICAL SHANK)
FD1600080S7R01 0.6299 (16.00 mm) 0.6654 (16.90 mm) 16 3.31 4.02 1.97 0.750 0.98 KFD16-17
FD1700085S7R01 0.6693 (17.00 mm) 0.6693 (17.90 mm) 17 3.50 4.28 1.97 0.750 0.98 KFD16-17
FD1800090S1R01 0.7087 (18.00 mm) 0.7441 (18.90 mm) 18 3.70 4.56 2.20 1.000 1.26 KFD18-19
FD1900095S1R01 0.7480 (19.00 mm) 0.7835 (19.90 mm) 19 3.90 4.80 2.20 1.000 1.26 KFD18-19
FD2000100S1R01 0.7874 (20.00 mm) 0.8228 (20.90 mm) 20 4.09 5.04 2.20 1.000 1.26 KFD20-21
5XD CYLINDRICAL SHANKS
Coolant
Part Number DCN
Cutting
Dia. Min.
DCX
Cutting
Dia. Max.
SSC
Seat Size
Code
LU
Usable
Length
LF
Functional
Length
LS
Shank
Length
DCON
Shank
Diameter
DF
Flange
Diameter Key
LF LS
LU
DCON
DCN-DCX
DF
Drilling
121
drilling
SERIES FPC
FPC1600R01 0.6299 (16.00 mm) 16 0.146 0.354 0.208 0.028 •
FPC1650R01 0.6496 (16.50 mm) 16 0.146 0.354 0.208 0.028 •
FPC1670R01 0.6575 (16.70 mm) 16 0.146 0.354 0.208 0.028 •
FPC1700R01 0.6693 (17.00 mm) 17 0.154 0.374 0.221 0.028 •
FPC1750R01 0.6890 (17.50 mm) 17 0.153 0.374 0.221 0.028 •
FPC1800R01 0.7087 (18.00 mm) 18 0.160 0.398 0.237 0.028 •
FPC1850R01 0.7283 (18.50 mm) 18 0.161 0.398 0.237 0.028 •
FPC1900R01 0.7480 (19.00 mm) 19 0.168 0.421 0.254 0.028 •
FPC1905R01 0.7500 (19.05 mm) 19 0.168 0.421 0.254 0.028 •
FPC1950R01 0.7677 (19.50 mm) 19 0.168 0.421 0.253 0.028 •
FPC2000R01 0.7874 (20.00 mm) 20 0.175 0.445 0.270 0.028 •
FPC2020R01 0.7952 (20.20 mm) 20 0.175 0.445 0.270 0.028 •
FPC2050R01 0.8071 (20.50 mm) 20 0.175 0.445 0.270 0.028 •
3-FLUTE DRILL TIPS
Coolant
Part Number DC
Cutting
Diameter
SSC
Seat Size
Code
PL
Point
Length
LPR
Projection
Length
LF
Functional
Length
BCH
Chamfer
Length
Grade
IN2205
•
:
Standard items
LPR
LFPL BCH
DC
30ºKCH
Drilling
122
NEW 3-FLUTE SOLID CARBIDE DRILL FOR 50% HIGHER FEED RATES!
• 3-flute geometry increases productivity by at least 50%
• Self-centering geometry provides precise and accurate holes
• Very high stability in the cut due to its specially designed edge geometry
- Reinforced cutting edge
- Side geometry that minimizes heat and reduces cutting forces
• 3 coolant outlet holes to maximum flow and evacuate chips
• New PVD-coated grade IN2205, blue in color for easy identification
• Suitable for steel and cast iron drilling
SERIES FR (3XD)
FR0397017T7R01 3.97 0.1563 5/32" 0.80 17 25 35 66 6 •
FR0400017T7R01 4.00 0.1575 - 0.82 17 25 35 66 6 •
FR0450017T7R01 4.50 0.1772 - 0.88 17 25 35 66 6 •
FR0476017T7R01 4.76 0.1875 3/16" 0.90 17 25 35 66 6 •
FR0500020T7R01 5.00 0.1969 - 0.96 20 29 36 66 6 •
FR0510020T7R01 5.10 0.2008 - 0.98 20 29 36 66 6 •
FR0550020T7R01 5.50 0.2165 - 1.08 20 29 36 66 6 •
FR0556020T7R01 5.56 0.2188 7/32" 1.09 20 29 36 66 6 •
FR0600020T7R01 6.00 0.2362 - 1.17 20 29 36 66 6 •
FR0635024T0R01 6.35 0.2500 1/4" 1.20 24 35 36 79 8 •
FR0650024T0R01 6.50 0.2559 - 1.26 24 35 36 79 8 •
FR0680024T0R01 6.80 0.2677 - 1.29 24 35 36 79 8 •
FR0700024T0R01 7.00 0.2756 - 1.35 24 35 36 79 8 •
FR0714024T0R01 7.14 0.2813 9/32" 1.38 29 42 36 79 8 •
FR0750029T0R01 7.50 0.2953 - 1.40 29 42 36 79 8 •
FR0794029T0R01 7.94 0.3126 5/16" 1.48 29 42 36 79 8 •
FR0800029T0R01 8.00 0.3150 - 1.49 29 42 36 79 8 •
FR0850035T1R01 8.50 0.3346 - 1.63 35 48 40 89 10 •
FR0860035T1R01 8.60 0.3386 - 1.64 35 48 40 89 10 •
FR0873035T1R01 8.73 0.3438 11/32" 1.65 35 48 40 89 10 •
FR0900035T1R01 9.00 0.3543 - 1.72 35 48 40 89 10 •
FR0950035T1R01 9.50 0.3740 - 1.75 35 48 40 89 10 •
FR0953035T1R01 9.53 0.3752 3/8" 1.76 35 48 40 89 10 •
FR1000035T1R01 10.00 0.3937 - 1.85 35 48 40 89 10 •
FR1030040T2R01 10.30 0.4063 13/32" 1.88 40 55 45 102 12 •
FR1050040T2R01 10.50 0.4134 - 1.98 40 55 45 102 12 •
FR1100040T2R01 11.00 0.4331 - 2.07 40 55 45 102 12 •
FR1111040T2R01 11.11 0.4375 7/16" 2.08 40 56 45 102 12 •
FR1150040T2R01 11.50 0.4528 - 2.12 40 56 45 102 12 •
FR1191040T2R01 11.91 0.4688 15/32" 2.20 40 56 45 102 12 •
FR1200040T2R01 12.00 0.4724 - 2.21 40 56 45 102 12 •
3-FLUTE SOLID CARBIDE DRILLS WITH COOLANT HOLES
Coolant
LCF LS
LU
OAL
PL
DCm7
140ºSIG DCON
Drilling
Part Number DC
Cutting Dia.
(mm)
DC
Cutting Dia.
(inch)
DC
Cutting Dia.
(fraction)
PL
Point
Length
(mm)
LU
Usable
Length
(mm)
LCF
Chip Flute
Length
(mm)
LS
Shank
Length
(mm)
OAL
Overall
Length
(mm)
DCON
Shank
Diameter
(mm)
Grade
IN2505
123
drilling
SERIES FR (5XD)
FR0397029T7R01 3.97 0.1563 5/32" 0.80 29 37 35 74 6 •
FR0400029T7R01 4.00 0.1575 - 0.82 29 37 35 74 6 •
FR0450029T7R01 4.50 0.1772 - 0.88 29 37 35 74 6 •
FR0476029T7R01 4.76 0.1875 3/16" 0.90 29 37 35 74 6 •
FR0500035T7R01 5.00 0.1969 - 0.96 35 45 36 82 6 •
FR0510035T7R01 5.10 0.2008 - 0.98 35 45 36 82 6 •
FR0550035T7R01 5.50 0.2165 - 1.08 35 45 36 82 6 •
FR0556035T7R01 5.56 0.2188 7/32" 1.09 35 45 36 82 6 •
FR0600035T7R01 6.00 0.2362 - 1.17 35 45 36 82 6 •
FR0635043T0R01 6.35 0.2500 1/4" 1.20 43 54 36 91 8 •
FR0650043T0R01 6.50 0.2559 - 1.26 43 54 36 91 8 •
FR0680043T0R01 6.80 0.2677 - 1.29 43 54 36 91 8 •
FR0700043T0R01 7.00 0.2756 - 1.35 43 54 36 91 8 •
FR0714043T0R01 7.14 0.2813 9/32" 1.38 43 54 36 91 8 •
FR0750043T0R01 7.50 0.2953 - 1.40 43 54 36 91 8 •
FR0794043T0R01 7.94 0.3126 5/16" 1.48 43 54 36 91 8 •
FR0800043T0R01 8.00 0.3150 - 1.49 43 54 36 91 8 •
FR0850049T1R01 8.50 0.3346 - 1.63 49 62 40 103 10 •
FR0860049T1R01 8.60 0.3386 - 1.64 49 62 40 103 10 •
FR0873049T1R01 8.73 0.3438 11/32" 1.65 49 62 40 103 10 •
FR0900049T1R01 9.00 0.3543 - 1.72 49 62 40 103 10 •
FR0950049T1R01 9.50 0.3740 - 1.75 49 62 40 103 10 •
FR0953049T1R01 9.53 0.3752 3/8" 1.76 49 62 40 103 10 •
FR1000049T1R01 10.00 0.3937 - 1.85 49 62 40 103 10 •
FR1030056T2R01 10.30 0.4063 13/32" 1.88 56 71 45 118 12 •
FR1050056T2R01 10.50 0.4134 - 1.98 56 71 45 118 12 •
FR1100056T2R01 11.00 0.4331 - 2.07 56 71 45 118 12 •
FR1111056T2R01 11.11 0.4375 7/16" 2.08 56 72 45 118 12 •
FR1150056T2R01 11.50 0.4528 - 2.12 56 72 45 118 12 •
FR1191056T2R01 11.91 0.4688 15/32" 2.20 56 72 45 118 12 •
FR1200056T2R01 12.00 0.4724 - 2.21 56 72 45 118 12 •
3-FLUTE SOLID CARBIDE DRILLS WITH COOLANT HOLES
Coolant
Part Number DC
Cutting Dia.
(mm)
DC
Cutting Dia.
(inch)
DC
Cutting Dia.
(fraction)
PL
Point
Length
(mm)
LU
Usable
Length
(mm)
LCF
Chip Flute
Length
(mm)
LS
Shank
Length
(mm)
OAL
Overall
Length
(mm)
DCON
Shank
Diameter
(mm)
Grade
IN2505
LU
LCF LS
OAL
PL
DCm7
140ºSIG DCON
Drilling
124
7XD AND 10XD ANTI-VIBRATION BORING BARS WITH EXCHANGEABLE HEADS
• Internal boring and threading with L/D ratios of 7xD and 10xD
• Significantly reduce and in some cases completely eliminate vibration
• Unique damping mechanism located inside the body of the bar
• Serrated coupling design for robust tightening
• Internal coolant supply improves chip control & evacuation
• Multiple head designs for different shape positive & negative inserts
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES DTA (INCH)
Spare Parts
Part Number
Screw Wrench Sleeves (Refer to page 133 for detailed dimensions)
1.25" OD 1.50" OD 2.00" OD 2.50" OD
DTA-D.625…
SHM3X0.5X10 L-W2.5 QSL31.8-15.9-L66 QSL38.1-15.9-L106 - -
DTA-D.750…
SRM3.5XL10-D5.5 L-W2.5 QSL31.8-19-L66 QSL38.1-19-L106 QSL50.8-19-L126 -
DTA-D1.00…
SHM4X0.7X12 L-W3 QSL31.8-25.4-L66 QSL38.1-25.4-L106 QSL50.8-25.4-L126 -
DTA-D1.25…
SHM5X0.8X12 L-W4 - QSL38.1-31.8-L106 QSL50.8-31.8-L126 QSL63.5-31.8-L156
DTA-D1.50…
SHM6X1X16 L-W5 - - QSL50.8-38.1-L126 QSL63.5-38.1-L156
DTA-D2.00…
SHM6X1X16 L-W5 - - - QSL63.5-50.8-L156
DTA-D2.50…
SHM6X1X16 L-W5 - - - -
OAL
BD
BD
DCONWS
OHX
LS
DCONMS
2 & 2.5” shanks
CNT
LS
DCONWS
Fig. 1
Fig. 2
Part Number
Dimension (inch) CNT
Coolant Entry
Thread Size
BMC (3)
Body Material
Code Figure
DCONMS
Connection Dia.
Machine Side
DCONWS (1)
Connection Dia.
Workpiece Side
BD
Body
Dia.
OAL (2)
Overall
Length
LS
Shank
Length
OHX
Max.
Overhang
DTA-D.625-7D-C 0.625 0.630 0.630 6.14 3.60 3.50 G1/8 S 1
DTA-D.625-10D-E 0.625 0.630 0.630 8.03 5.22 5.50 - H 1
DTA-D.750-7D-C 0.750 0.787 0.787 7.87 4.94 4.40 G1/4 S 1
DTA-D.750-10D-E 0.750 0.787 0.787 10.24 6.77 7.00 - H 1
DTA-D1.00-7D-C 1.000 0.984 0.984 10.20 6.83 6.20 G1/4 S 1
DTA-D1.00-10D-C 1.000 0.984 0.984 13.21 8.65 9.20 G1/4 S 1
DTA-D1.25-7D-C 1.250 1.260 1.260 12.48 7.37 7.50 G3/8 S 1
DTA-D1.25-10D-C 1.250 1.260 1.260 16.24 9.67 11.20 G3/8 S 1
DTA-D1.50-7D-C 1.500 1.575 1.575 15.26 9.13 9.20 G1/2 S 1
DTA-D1.50-10D-C 1.500 1.575 1.575 19.80 13.35 13.70 G1/2 S 1
DTA-D2.00-7D-C 2.000 1.575 2.000 20.74 - 12.70 G1/2 S 2
DTA-D2.00-10D-C 2.000 1.575 2.000 26.73 - 18.70 G1/2 S 2
DTA-D2.50-7D-C 2.500 1.575 2.500 26.20 - 16.20 G3/4 S 2
DTA-D2.50-10D-C 2.500 1.575 2.500 33.72 - 23.70 G3/4 S 2
(1)
DCONWS dimension of bar must match DCONMS dimension of head.
(2)
See New Product Announcement for details on cutting bars to shorter lengths.
(3)
S-steel body, H-solid carbide body.
125
turning
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES DTA (METRIC)
DCONWS DCONMS
DCONWS DCONMS
CNT
CNT
OHX
OHX
OAL
OAL
Fig. 1
Fig. 2
Part Number
Dimension (inch) CNT
Coolant Entry
Thread Size
BMC (3)
Body Material
Code Figure
DCONMS
Connection Dia.
Machine Side
DCONWS (1)
Connection Dia.
Workpiece Side
OAL (2)
Overall
Length
OHX
Max.
Overhang
DTA-D16-7D-C 16 16 156 3.50 G1/8 S 1
DTA-D16-10D-E 16 16 204 5.50 - H 1
DTA-D20-7D-C 20 20 200 4.40 G1/4 S 1
DTA-D20-10D-E 20 20 260 7.00 - H 1
DTA-D25-7D-C 25 25 258 6.20 G1/4 S 1
DTA-D25-10D-C 25 25 333 9.20 G1/4 S 1
DTA-D32-7D-C 32 32 323 7.50 G3/8 S 1
DTA-D32-10D-C 32 32 419 11.20 G3/8 S 1
DTA-D40-7D-C 40 40 411 9.20 G1/2 S 1
DTA-D40-10D-C 40 40 531 13.70 G1/2 S 1
DTA-D50-7D-C 50 40 523 12.70 G1/2 S 2
DTA-D50-10D-C 50 40 673 18.70 G1/2 S 2
DTA-D60-7D-C 60 40 633 16.20 G3/4 S 2
DTA-D60-10D-C 60 40 813 23.70 G3/4 S 2
(1)
DCONWS dimension of bar must match DCONMS dimension of head.
(2)
See New Product Announcement for details on cutting bars to shorter lengths.
(3)
S-steel body, H-solid carbide body.
Spare Parts
Part Number
Screw Wrench Sleeves (Refer to page 134 for detailed dimensions)
32mm OD 40mm OD 50mm OD 60mm OD
DTA-D16…
SHM3X0.5X10 L-W2.5 QSL32-16-L66 QSL40-16-L106 - -
DTA-D20…
SRM3.5XL10-D5.5 L-W2.5 QSL32-20-L66 QSL40-20-L106 QSL50-20-L126 -
DTA-D25…
SHM4X0.7X12 L-W3 QSL32-25-L66 QSL40-25-L106 QSL50-25-L126 -
DTA-D32…
SHM5X0.8X12 L-W4 - QSL40-32-L106 QSL50-32-L126 QSL60-32-L156
DTA-D40…
SHM6X1X16 L-W5 - - QSL50-40-L126 QSL60-40-L156
DTA-D50…
SHM6X1X16 L-W5 - - - QSL60-50-L156
DTA-D60…
SHM6X1X16 L-W5 - - - -
126
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES DTC-HDUNR/L
Marked: For RhinoTurn insert
Spare Parts
Part Number
Lever Lever Screw Shim Shim Pin Wrench
HDUNR/L-1305
LCL 11-NX LCS 4S LSD 3.52B - LSP 4 L-W 3
Approach angle Part Number
Dimension (inch)
Coolant Insert
DCONMS
Connection Dia.
Machine Side
LF
Functional
Length
WF
Functional
Width
DMIN
Min.
Bore Dia.
93°
DTC-D40-HDUNR/L-1305
1.575 1.496 1.063 1.968 Yes DN_G 3.53.5...
LF
DMIN
93°
DCONMS
WF
30°
max.
Coolant
HOOK LEVER TYPE BORING HEADS (DNMG INSERTS)
LF
DMIN
93°
DCONMS
WF
30°
max.
127
turning
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES DTC-HVUNR/L
Marked: For RhinoTurn insert
Spare Parts
Part Number
Lever Lever Screw Shim Shim Pin Wrench
HVUNR/L-1304
LCL 08-NX LCS 4-DH - LSV 2.51.8H LSP 3B L-W 2.5
Approach angle Part Number
Dimension (inch)
Coolant Insert
DCONMS
Connection Dia.
Machine Side
LF
Functional
Length
WF
Functional
Width
DMIN
Min.
Bore Dia.
93°
DTC-D40-HVUNR/L-1304
1.575 1.256 1.063 1.968 Yes VN_X 2.53...
Coolant
HOOK LEVER TYPE BORING HEADS (VNMX INSERTS)
LF
93°
WF
DCONMS
DMIN
50°
max.
LF
93°
WF
DCONMS
DMIN
50°
max.
128
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES DTC-SCLCR/L
Spare Parts
Part Number
Screw Shim Shim Screw Wrench
DTC16 SO 25065I - - T 7 -
DTC20, DTC25 SO 35080I - - T 15 -
DTC32 SO 45100I - - T 20 -
DTC40 SO 45130I SSC 43N SO 60105S T 20 L-W 5
Approach angle Part Number
Dimension (inch)
Coolant Fig. Insert
DCONMS
Connection Dia.
Machine Side
LF
Functional
Length
WF
Functional
Width
DMIN
Min.
Bore Dia.
95° DTC-D16-SCLCR/L-06
.630 .787 .433 .787
Yes
1CC_T 21.5…
DTC-D20-SCLCR/L-09
.787 .787 .512 .984
Yes
2CC_T 32.5…
DTC-D25-SCLCR/L-09
.984 .787 .664 1.260
Yes
2
DTC-D32-SCLCR/L-12
1.260 1.260 .866 1.575
Yes
2CC_T 43…
DTC-D40-SCLCR/L-12
1.575 1.496 1.063 1.968
Yes
2
Fig.1
LF
LF
95°
95°
WF
WF
DCONMS
DCONMS
DMIN
DMIN
LF
LF
95°
95° WF
WF
DCONMS
DCONMS
DMIN
DMIN
Coolant
SCREW TYPE BORING HEADS (CCMT INSERTS)
LF
LF
95°
95°
WF
WF
DCONMS
DCONMS
DMIN
DMIN
Fig.2
129
turning
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES DTC-SCLNR/L
Spare Parts
Part Number
Screw Wrench
DTC-D16... SM25-060-90 T 7P
DTC-20... SM25-060-90 T 7P
Approach angle Part Number
Dimension (inch)
Coolant Fig. Insert
DCONMS
Connection Dia.
Machine Side
LF
Functional
Length
WF
Functional
Width
DMIN
Min.
Bore Dia.
95°
DTC-D16-SCLNR/L-0703
.630 .787 .433 .787
Yes
1
CN_X 2.22…
DTC-D20-SCLNR/L-0703
.787 .787 .512 .984
Yes
2
Fig.1
LF
LF
95°
WF
DCONMS
DCONMS
DMIN
DMIN
95°
WF
LF LF
95°
WF
DCONMS
DCONMS
D
MIN
D
MIN
95°
WF
Marked: For RhinoTurnM insert
Coolant
SCREW TYPE BORING HEADS (CNMX INSERTS)
LF
LF
95°
WF
DCONMS
DCONMS
DMIN
D
MIN
95°
WF
Fig.2
130
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES DTC-SDUCR/L
Spare Parts
Part Number
Screw Shim Shim Screw Wrench
DTC16 SO 25065I - - T 7 -
DTC20, 25, 32 SO 35080I - - T 15 -
DTC40 SO 35124I SSD 32 SO 50090S T 15 L-W 3.5
Approach angle Part Number
Dimension (inch)
Coolant Fig. Insert
DCONMS
Connection Dia.
Machine Side
LF
Functional
Length
WF
Functional
Width
DMIN
Min.
Bore Dia.
93° DTC-D16-SDUCR/L-07
.630 .787 .433 .787
Yes
1DC_T 21.5…
DTC-D20-SDUCR/L-11
.787 .787 .512 .984
Yes
2
DC_T 32.5…
DTC-D25-SDUCR/L-11
.984 .787 .668 1.260
Yes
2
DTC-D32-SDUCR/L-11
1.260 1.260 .866 1.575
Yes
2
DTC-D40-SDUCR/L-11
1.575 1.496 1.063 1.968
Yes
2
LF
LF
93°
93° WF
WF
DCONMS
DCONMS
30°
max.
DMIN
DMIN
Coolant
SCREW TYPE BORING HEADS (DCMT INSERTS)
LF
LF
93°
93°
WF
WF
DCONMS
DCONMS
30°
max.
DMIN
DMIN
LF
LF
93°
93°
WF
WF
DCONMS
DCONMS
30°
max.
D
MIN
DMIN
Fig.1
Fig.2
131
turning
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES DTC-SDUNR/L
Spare Parts
Part Number
Screw Wrench
DTC-D16, D20 SM25-060-90 T 7P
DTC-32 SM40-110-00 T 15
Approach angle Part Number
Dimension (inch)
Coolant Fig. Insert
DCONMS
Connection Dia.
Machine Side
LF
Functional
Length
WF
Functional
Width
DMIN
Min.
Bore Dia.
95°
DTC-D16-SDUNR/L-0803
.630 .787 .433 .787
Yes
1
DN_X 2.22…
DTC-D20-SDUNR/L-0803
.787 .787 .512 .984
Yes
2
DTC-D32-SDUNR/L-1305
1.260 1.260 .866 1.575 Yes 2DN_G 3.53.5…
Marked: For RhinoTurnM insert
Marked: For RhinoTurn insert
LF
93°
WF
DCONMS
DMIN
30°
max
.
Coolant
SCREW TYPE BORING HEADS (DNMX & DNMG INSERTS)
30°
max.
DMIN
LF
LF
93°
WF
DCONMS
DCONMS
WF 93°
DMIN
30°
max.
DMIN
LF
LF
93°
WF
DCONMS
DCONMS
WF 93°
DMIN
Fig.1
Fig.2
132
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES DTC-SVUBR/L
Spare Parts
Part Number
Screw Shim Shim Screw Wrench
DTC-D...SVUBR/L-11 SO 25065I - - T 7 -
DTC-D...SVUBR/L-16 SO 35124I SSV 32 SO 50090S T 15 L-W 3.5
Approach angle Part Number
Dimension (inch)
Coolant Fig. Insert
DCONMS
Connection Dia.
Machine Side
LF
Functional
Length
WF
Functional
Width
DMIN
Min.
Bore Dia.
93° DTC-D20-SVUBR/L-11
.787 .787 .630 1.063
Yes
1VB_T 22…
DTC-D25-SVUBR/L-11
.984 .984 .670 1.220
Yes
1
DTC-D32-SVUBR/L-16
1.260 1.260 .866 1.575
Yes
2VB_T 33…
DTC-D40-SVUBR/L-16
1.575 1.260 1.063 1.968
Yes
2
LF
DMIN
DMIN
93°
93°
WF
WF
DCONMS
DCONMS
LF
50°
max.
Coolant
SCREW TYPE BORING HEADS (VBMT INSERTS)
Fig.1
Fig.2
LF
DMIN
DMIN
93°
93°
WF
WF
DCONMS
DCONMS
LF
50°
max.
LF
DMIN
DMIN
93°
93°
WF
WF
DCONMS
DCONMS
LF
50°
max.
133
turning
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES DTC-SWLNR/L
Spare Parts
Part Number
Screw Wrench
DTC-D... SM25-060-90 T 7P
Approach angle Part Number
Dimension (inch)
Coolant Fig. Insert
DCONMS
Connection Dia.
Machine Side
LF
Functional
Length
WF
Functional
Width
DMIN
Min.
Bore Dia.
95°
DTC-D16-SWLNR/L-0403
.630 .787 .433 .787
Yes
1
WN_X 2.22…
DTC-D20-SWLNR/L-0403
.787 .787 .512 .984
Yes
2
Coolant
SCREW TYPE BORING HEADS (WNMX INSERTS)
Marked: For RhinoTurnM insert
WF 95°
LF
DCONMS
DMIN
WF 95°
LF
DCONMS
DMIN
Fig.1
Fig.2
WF 95°
LF
DCONMS
DMIN
WF 95°
LF
DCONMS
DMIN
WF 95°
LF
DCONMS
DMIN
WF 95°
LF
DCONMS
DMIN
134
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES DTC-SIR/L
Spare Parts
Part Number
Anvil Ext.L/Int.R Anvil Ext.R/Int.L Anvil Screw Wrench Screw
DTC-D25-SIL-16
- AE16 A16 T-10/5 S16
DTC-D25-SIR-16
AI16 - A16 T-10/5 S16
DTC-D32-SIL-16
- AE16 A16 T-10/5 S16
DTC-D32-SIR-16
AI16 - A16 T-10/5 S16
DTC-D40-SIL-16
- AE16 A16 T-10/5 S16
DTC-D40-SIR-16
AI16 - A16 T-10/5 S16
DTC-D32-SIL-22
- AE22 A22 T-20/5 S22
DTC-D32-SIR-22
AI22 - A22 T-20/5 S22
DTC-D40-SIL-22
- AE22 A22 T-20/5 S22
DTC-D40-SIR-22
AI22 - A22 T-20/5 S22
Part Number
Dimension (inch)
Coolant Insert
DCONMS
Connection Dia.
Machine Side
LF
Functional
Length
WF
Functional
Width
DMIN
Min.
Bore Dia.
DTC-D25-SIR/L-16
.984 1.024 .638 1.142 Yes 16IR/L
DTC-D32-SIR/L-16
1.260 1.063 .776 1.417 Yes 16IR/L
DTC-D40-SIR/L-16
1.575 1.181 .433 1.733 Yes 16IR/L
DTC-D32-SIR/L-22
1.260 1.260 .850 1.417 Yes 22IR/L
DTC-D40-SIR/L-22
1.575 1.496 1.008 1.811 Yes 22IR/L
Coolant
SCREW TYPE BORING HEADS (LAYDOWN THREADING INSERTS)
DMIN
DCONMS
LF
WF
135
turning
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES QSL (INCH)
Part Number
Dimension (inch)
DCONMS
Connection Dia.
Machine Side
DCONWS
Connection Dia.
Work Piece Side
BD
Body
Diameter
LB
Body
Length
H
Height
QSL31.8-15.9-L66
1.250 0.625 1.654 2.362 1.210
QSL31.8-19-L66
1.250 0.750 1.654 2.362 1.210
QSL31.8-25.4-L66
1.250 1.000 1.654 2.362 1.210
QSL38.1-15.9-L106
1.500 0.625 1.969 3.937 1.461
QSL38.1-19-L106
1.500 0.750 1.969 3.937 1.461
QSL38.1-25.4-L106
1.500 1.000 1.969 3.937 1.461
QSL38.1-31.8-L106
1.500 1.250 1.969 3.937 1.461
QSL50.8-19-L126
2.000 0.750 2.362 4.724 1.941
QSL50.8-25.4-L126
2.000 1.000 2.362 4.724 1.941
QSL50.8-31.8-L126
2.000 1.250 2.362 4.724 1.941
QSL50.8-38.1-L126
2.000 1.500 2.362 4.724 1.941
QSL63.5-31.8-L156
2.500 1.250 2.756 5.906 2.441
QSL63.5-38.1-L156
2.500 1.500 2.756 5.906 2.441
QSL63.5-50.8-L156
2.500 2.000 2.756 5.906 2.441
Coolant
INCH SLEEVES
(Flat surface)
DCONWS
LB
BD
6
H
DCONMS
Additional Holder Options Available Upon Request:
VDI POWER
CHUCKS
TOOL
BLOCKS
136
Direct deep hole machining without the pilot hole
(over 8xD)
SERIES QSL (METRIC)
Part Number
Dimension (mm)
DCONMS
Connection Dia.
Machine Side
DCONWS
Connection Dia.
Work Piece Side
BD
Body
Diameter
LB
Body
Length
H
Height
QSL32-16-L66
32 16 42 60 30.5
QSL32-20-L66
32 20 42 60 30.5
QSL32-25-L66
32 25 42 60 30.5
QSL40-16-L106
40 16 50 100 38.5
QSL40-20-L106
40 20 50 100 38.5
QSL40-25-L106
40 25 50 100 38.5
QSL40-32-L106
40 32 50 100 38.5
QSL50-20-L126
50 20 60 120 48.5
QSL50-25-L126
50 25 60 120 48.5
QSL50-32-L126
50 32 60 120 48.5
QSL50-40-L126
50 40 60 120 48.5
QSL60-32-L156
60 32 70 150 58.5
QSL60-40-L156
60 40 70 150 58.5
QSL60-50-L156
60 50 70 150 58.5
Coolant
METRIC SLEEVES
(Flat surface)
DCONWS
LB
BD
6
H
DCONMS
Additional Holder Options Available Upon Request:
VDI POWER
CHUCKS
TOOL
BLOCKS
137
turning
THRU-COOLANT HOLDERS
• Pinpoint coolant delivery from top clamp (for cooling) and bottom of holder (for chip breaking)
• T-Type holding system with multi-directional clamping force provides 40% more stability over conventional lever lock
holders, plus simple & fast indexing. No additional components required.
• Up to 50% increase in tool life under the same machining conditions
• 20% increase in cutting speed capability in difficult-to-cut materials
• Increased productivity in high-speed machining of titanium and super alloys
• Excellent chip control
• Coolant pressure: Recommend 1000 psi for best results. Capable of 2000 psi.
• Efficient cooling of the insert cutting edge at two different locations
TCLNR/L-TB
T-HOLDERS WITH HIGH-PRESSURE COOLANT (CN_ _33X INSERTS)
Spare Parts
Part Number
Clamp Clamp Screw Spring Upper
O-ring Lower
O-ring Shim Shim
Screw Wrench
TCLNR/L-TB
TCRNR/L-TB
DLM 3-NX-TB BH M4x0.7x
16-TB DSP 3 O-RING ID4.47x
1.78
O-RING ID6.07x
1.78 LSC 32A SO 40085I L-W 3 T 15
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
HBH
Head Bottom
Offset Height
HBKW
Head Back
Offset Width
95° TCLNR/L 12-33B-TB
.750 .750 .750 4.5 1.000 1.10 .31 .12
CN... 33...
TCLNR/L 16-33D-TB
1.000 1.000 1.000 6.0 1.250 1.10 .25 -
TCLNR/L 20-33D-TB
1.250 1.250 1.250 6.0 1.500 1.10 - -
LF
WF
HBKW
1/8-27 NPTF
HF
HBH
LH
B
H
95°
LF
WF
HBKW
1/8-27 NPTF
HF
HBH
LH
B
H
95°
featuring
138
TCRNR/L-TB
T-HOLDERS WITH HIGH-PRESSURE COOLANT (CN_ _33X INSERTS)
Spare Parts
Part Number
Clamp Clamp Screw Spring Upper
O-ring Lower
O-ring Shim Shim
Screw Wrench
TCLNR/L-TB
TCRNR/L-TB
DLM 3-NX-TB BH M4x0.7x
16-TB DSP 3 O-RING ID4.47x
1.78
O-RING ID6.07x
1.78 LSC 32A SO 40085I L-W 3 T 15
WF
HBKW
LF
1/8-27 NPTF
HF
HBH
LH
75°
B
H
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
HBH
Head Bottom
Offset Height
HBKW
Head Back
Offset Width
75°
TCRNR/L 12-33B-TB
.750 .750 .750 4.5 .855 1.18 .31 .12
CN... 33...
TCRNR/L 16-33D-TB
1.000 1.000 1.000 6.0 1.048 1.18 .25 -
WF
HBKW
LF
1/8-27 NPTF
HF
HBH
LH
75°
B
H
featuring
139
turning
Spare Parts
Part Number
Clamp Clamp Screw Spring Upper
O-ring Lower
O-ring Shim Shim
Screw Wrench
12-3.53.5...-TB
DLM 3.5-NX-TB BH M5x0.8x
21-MO-TB DSP 4 O-RING ID5.28x
1.78
O-RING ID7.59x
2.62 LSD 3.52 SO 50090I-MO L-W 3 T 20
16-3.53.5...-TB
20-3.53.5...-TB
DLM 3.5-NX-TB BH M5x0.8x
21-MO-TB DSP 4 O-RING ID5.28x
1.78
O-RING ID7.59x
2.62 LSD 3.52 SO 50090I L-W 3 T 20
TDJNR/L-TB
T-HOLDERS WITH HIGH-PRESSURE COOLANT (DN_ _3.53.5X INSERTS)
27° max.
WF
1/8-27 NPTF
HF
LH
H
B
93° LF
HBH
HBKW
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
HBH
Head Bottom
Offset Height
HBKW
Head Back
Offset Width
93° TDJNR/L 12-3.53.5B-TB
.750 .750 .750 4.5 1.000 1.61 .31 .16
DN... 3.53...
TDJNR/L 16-3.53.5D-TB
1.000 1.000 1.000 6.0 1.250 1.61 .25 -
TDJNR/L 20-3.53.5D-TB
1.250 1.250 1.250 6.0 1.500 1.61 - -
27° max.
WF
1/8-27 NPTF
HF
LH
H
B
93° LF
HBH
HBKW
featuring
140
Spare Parts
Part Number
Clamp Clamp Screw Spring Upper
O-ring Lower
O-ring Shim Shim
Screw Wrench
TVJNR/L-TB
DLM 2.5V-NX-TB BH M5x0.8x
25-TB DSP 4 O-RING ID5.28x
1.78
O-RING ID7.59x
2.62
MSVI
2.522 SO 40085I L-W 3 T 15
TVJNR/L-TB
T-HOLDERS WITH HIGH-PRESSURE COOLANT (VN_ X2.53X INSERT)
44° max.
93°
LH
H
B
LF
1/8-27 NPTF
WF
HF
HBH
HBKW
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
HBH
Head Bottom
Offset Height
HBKW
Head Back
Offset Width
93° TVJNR/L 12-2.53B-TB
.750 .750 .750 4.5 1.000 1.73 .31 .256
VN... X2.53...
TVJNR/L 16-2.53D-TB
1.000 1.000 1.000 6.0 1.250 1.73 .25 -
TVJNR/L 20-2.53D-TB
1.250 1.250 1.250 6.0 1.500 1.73 - -
44° max.
93°
LH
H
B
LF
1/8-27 NPTF
WF
HF
HBH
HBKW
featuring
141
turning
Spare Parts
Part Number
Clamp Clamp Screw Spring Upper
O-ring Lower
O-ring Shim Shim
Screw Wrench
TWLNR/L-TB
DLM 3-NX-TB BH M4x0.7x
16-TB DSP 3 O-RING ID4.47x
1.78
O-RING ID6.07x
1.78 LSW 32A SO 40085I L-W 3 T 15
TWLNR/L-TB
T-HOLDERS WITH HIGH-PRESSURE COOLANT (WN_ _33X INSERT)
95°
WF
LF
HF
LH
H
B
HBH
1/8-27 NPTF
HBKW
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
HBH
Head Bottom
Offset Height
HBKW
Head Back
Offset Width
95° TWLNR/L 12-33B-TB
.750 .750 .750 4.5 1.000 1.18 .31 .10
WN... X33...
TWLNR/L 16-33D-TB
1.000 1.000 1.000 6.0 1.250 1.18 .25 -
TWLNR/L 20-33D-TB
1.250 1.250 1.250 6.0 1.500 1.18 - -
95°
WF
LF
HF
LH
H
B
HBH
1/8-27 NPTF
HBKW
featuring
142
Spare Parts
Part Number
Clamp Clamp Screw Spring Upper
O-ring Lower
O-ring Shim Shim
Screw Wrench
TXJNR/L 2.7...
DLM 3-NX-TB BH M4x0.7x
16-TB DSP 3 O-RING ID4.47x
1.78
O-RING ID6.07x
1.78 TSX 2.73 SO 40085I L-W 3 T 15
TXJNR/L 3.5...
DLM 3.5-NX-TB BH M5x0.8x
21-MO-TB DSP 4 O-RING ID5.28x
1.78
O-RING ID7.59x
2.62 TSX 3.53 SO 50090I L-W 3 T 20
TXJNR/L-TB
T-HOLDERS WITH HIGH-PRESSURE COOLANT (XNMG INSERT)
15° max.
WF
LF
B
HF
LH
H
93°
HBH
1/8-27 NPTF
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
HBH
Head Bottom
Offset Height
HBKW
Head Back
Offset Width
93°
TXJNR/L 16-2.7D-TB
1.000 1.000 1.000 6.0 1.250 1.18 .25 XNMG...
2.7... XNMG... 2.7...
TXJNR/L 16-3.5D-TB
1.000 1.000 1.000 6.0 1.250 1.18 .25 XNMG...
3.5... XNMG... 3.5...
15° max.
WF
LF
B
HF
LH
H
93°
HBH
1/8-27 NPTF
featuring
143
turning
Spare Parts
Part Number
Clamp Clamp screw Spring Upper
O-ring Lower
O-ring Shim Shim
screw Wrench
A-TCLNR/L-TB
DLM 3-NX-TB
BH
M4x0.7x
16-TB
DSP 3 O-RING ID4.47x
1.78
O-RING ID6.07x
1.78 LSC 32 SO 40073I L-W 3 T 15
A-TCLNR/L-TB
T-HOLDER TYPE BORING BARS WITH HIGH-PRESSURE COOLANT (CN_ _33X INSERT)
D
MIN
DCON
H
WF
LDRED
LF
95°
1/4-18 NPTF
Approach angle Part Number
Dimension (inch)
Insert
DCON
Shank
Diameter
DMIN
Min. Bore
Diameter
LF
Functional
Length
WF
Functional
Width
LDRED
Reduced Body
Dia. Length
H
Shank Height
95° A16T-TCLNR/L-33-TB
1.000 1.250 12.0 .64 1.38 .92
CN... 33...
A20U-TCLNR/L-33-TB
1.250 1.500 14.0 .77 1.38 1.17
DMIN
DCON
H
WF
LDRED
LF
95°
1/4-18 NPTF
featuring
144
Fig.1 - STRAIGHT MALE CONNECTOR
1 TB-4-FTX-S 1/8-27 NPTF 1/4 (37º Flare) 1/2" 1.22" 6000
Fig. Part Number End Size C
(hex) LMax Pressure
(psi)
E1 E2
Fig. 1
L
E1
C
E2
Fig. 2
L
E1
C
E2
M
Fig. 3
E2
E1
N
Y*
Y*- Across
wrench flats
M
Fig. 4
E2
E1
N
Y*
Y*- Across
wrench flats
Fig. 1
L
E1
C
E2
Fig. 2
L
E1
C
E2
M
Fig. 3
E2
E1
N
Y*
Y*- Across
wrench flats
M
Fig. 4
E2
E1
N
Y*
Y*- Across
wrench flats
2TB-4-CTX-S 1/8-27 NPTF 1/4 (37º Flare) 7/16" 0.89" 0.78" 6000
Fig. Part Number End Size Y M N Max Pressure
(psi)
E1 E2
All connectors ordered separately.
Fig.2 - ELBOW MALE CONNECTOR
L
E1
SS
E2
L
E1
SS
E2
All hoses ordered separately.
Part Number Dimension (inch)
Max Pressure
(psi)
L E1 E2
TB-HOSE-7/16-7/16-8.0SS 8.0 inch 1/4 (37º Flare) 1/4 (37º Flare) 3000
TB-HOSE-7/16-7/16-10.0SS 10.0 inch 1/4 (37º Flare) 1/4 (37º Flare) 3000
featuring
CONNECTORS
FLEXIBLE HIGH-PRESSURE HOSES
Fig.1 - STRAIGHT MALE CONNECTOR Fig.2 - ELBOW MALE CONNECTOR
145
turning
A NEW SERIES OF ECONOMICAL DOUBLE-SIDED INSERTS
FEATURING A 70° INCLUDED ANGLE
• 70° included angle XNMG insert can replace CNMG and DNMG inserts with a single solution
• Suitable for multiple applications including internal and external turning, face turning and profile turning
• Thick insert with wide face contact provides excellent rigidity and stability in the pocket
• Optimally designed for automotive parts such as bearings due to its wide cutting range and excellent
chip control in medium to finishing turning & boring
• Compared to CNMG inserts:
- Smaller included angle provides lower cutting forces, better chip control and improved surface finish
- Profiling capability with ramping angle up to 15°
- Deeper approach capability on live center (tail stock) end of work piece
• Compared to DNMG inserts:
- Larger included angle provides more strength
- Stronger lead angle in face turning allows higher feed rates and better chip control
• Optional thru-coolant external holders
LF
LH
WF
HF
93°KAPR
15° max.
B
H
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
93° TXJNR/L 12-2.7B
.750 .750 .750 4.5 1.00 .98
XNMG 2.73_
TXJNR/L 16-2.7D
1.000 1.000 1.000 6.0 1.25 .98
TXJNR/L 12-3.5D
.750 .750 .750 6.0 1.00 1.26
XNMG 3.53.5
TXJNR/L 16-3.5D
1.000 1.000 1.000 6.0 1.25 1.26
TXJNR/L
T-HOLDERS
TXJNR
Spare Parts
Part Number
Clamp Clamp Screw Spring Shim Shim Screw Wrench
2.73_
DLM 2.5-NX DLS 3 DSP 3 TSX 2.73 SO 40085I L-W 2.5 T 15
3.53.5_
DLM 3.5-NX DLS 4 DSP 4 TSX 3.53 SM 50-122-50 L-W 3 T 20
LF
LH
WF
HF H
B
93°
15° max.
KAPR
146
WF
LF
B
HF
HBH
LH
H
1/8-27 NPTF
15max
93°KAPR
15° max.
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
HBH
Head Bottom
Offset Height
93°
TXJNR/L 16-2.7D-TB
1.000 1.000 1.000 6.0 1.250 1.25 .28 XNMG 2.73
TXJNR/L 16-3.5D-TB
1.000 1.000 1.000 6.0 1.250 1.25 .28 XNMG 3.53.5
TXJNR/L-TB
T-HOLDERS WITH HIGH-PRESSURE COOLANT
TXJNR-TB
93°
WF
LF
B
HF
HBH
LH
H
1/8-27 NPTF
15max
15° max.
KAPR
Spare Parts
Part Number
Clamp Clamp Screw Spring Upper
O-ring Lower
O-ring Shim Shim
Screw Wrench
2.73_
DLM 3-NX-TB BH M4x0.7x
16-TB DSP 3 O-RING ID4.47x
1.78
O-RING ID6.07x
1.78 TSX 2.73 SO 40085I L-W 3 T 15
3.53.5_
DLM 3.5-NX-TB BH M5x0.8x
21-MO-TB DSP 4 O-RING ID5.28x
1.78
O-RING ID7.59x
2.62 TSX 3.53 SO 50090I L-W 3 T 20
147
turning
LF
LH
100°KAPR
WF
HF
B
H
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
100° TXQNR/L 12-2.7B
.750 .750 .750 4.5 1.00 .98
XNMG 2.73
TXQNR/L 16-2.7D
1.000 1.000 1.000 6.0 1.25 .98
TXQNR/L 12-3.5B
.750 .750 .750 4.5 1.00 1.26
XNMG 3.53.5
TXQNR/L 16-3.5D
1.000 1.000 1.000 6.0 1.25 1.26
TXQNR/L
T-HOLDERS
TXQNR
LF
LH
WF
HF H
B
100°
KAPR
Spare Parts
Part Number
Clamp Clamp Screw Spring Shim Shim Screw Wrench
2.73_
DLM 2.5-NX DLS 3 DSP 3 TSX 2.73 SO 40085I L-W 2.5 T 15
3.53.5_
DLM 3.5-NX DLS 4 DSP 4 TSX 3.53 SM 50-122-50 L-W 3 T 20
148
A-HXUNR/L
HOOK LEVER TYPE BORING BAR WITH THRU COOLANT
Spare Parts
Part Number
Lever Lever screw Shim Shim pin Wrench
3.53.5_
LCL 11-NX LCS 4S LSX 3.52B LSP 4 L-W 3
WF
LDRED
LF
D
MIN
DCON
H
15°
max.
CSP
93°KAPR
Approach angle Part Number
Dimension (inch)
Insert
DCON
Shank
Diameter
DMIN
Min. Bore
Diameter
LF
Functional
Length
WF
Functional
Width
LDRED
Reduced Body
Dia. Length
H
Shank
Height
93°
A20U-HXUNR/L-3.5
1.250 1.500 14.0 .861 1.38 1.17 XNMG 3.53.5_
A-HXUNR
DCON
H
15°
max.
D
MIN
93°
WF
LH
LF
Coolant
149
turning
Coolant
Coolant
A-SXQNR/L, A-SXUNR/L
SCREW TYPE BORING BARS WITH THRU COOLANT
Spare Parts
Part Number
Screw Wrench
2.73_
TS 30080I/HG T 9
3.53.5_
TS 40G110I T 15
Approach angle Part Number
Dimension (inch)
Insert
DCON
Shank
Diameter
DMIN
Min. Bore
Diameter
LF
Functional
Length
WF
Functional
Width
LDRED
Reduced Body
Dia. Length
H
Shank
Height
100° A10R-SXQNR/L-2.7
.625 .787 8.0 .431 .97 .46
XNMG 2.73_
A12S-SXQNR/L-2.7
.750 .980 10.0 .493 1.10 .58
A12S-SXQNR/L-3.5
.750 .980 10.0 .493 1.10 .58 XNMG 3.53.5_
A-SXQNR
A-SXUNR
H
DCON
WF
LDRED
LF
100°KAPR
DMIN
CSP
DCON
WF
LH
LF
100°
D
MIN
H
Approach angle Part Number
Dimension (inch)
Insert
DCON
Shank
Diameter
DMIN
Min. Bore
Diameter
LF
Functional
Length
WF
Functional
Width
LDRED
Reduced Body
Dia. Length
H
Shank
Height
93°
A16T-SXUNR/L-3.5
1.000 1.250 12.0 .677 1.32 .92 XNMG 3.53.5_
15°
max.
D
MIN
DCON
H
WF
LH
LF
93°
15°
max.
WF
LDRED
LF
DCON
H
DMIN
93°KAPR
CSP
150
A-TXQNR/L, A-TXUNR/L
T-HOLDER TYPE BORING BARS WITH THRU COOLANT
Approach angle Part Number
Dimension (inch)
Insert
DCON
Shank
Diameter
DMIN
Min. Bore
Diameter
LF
Functional
Length
WF
Functional
Width
LDRED
Reduced Body
Dia. Length
H
Shank
Height
100° A16T-TXQNR/L-3.5
1.000 1.250 12.0 .677 1.32 .92
XNMG 3.53.5_
A20U-TXQNR/L-3.5
1.250 1.500 14.0 .861 1.38 1.17
A-TXQNR
A-TXUNR
Approach angle Part Number
Dimension (inch)
Insert
DCON
Shank
Diameter
DMIN
Min. Bore
Diameter
LF
Functional
Length
WF
Functional
Width
LDRED
Reduced Body
Dia. Length
H
Shank
Height
93°
A20U-TXUNR/L-3.5
1.250 1.500 14.0 .861 1.38 1.17 XNMG 3.53.5_
DMIN
LF
DCON
H
100°
LH
WF
WF
LH
LF
93°
DCON
H
15°
max.
D
MIN
Spare Parts
Part Number
Clamp Clamp Screw Spring Shim Shim Screw Nozzle Wrench
A16T…3.5…
DLM 3.5-NX DLS 4 DSP 4 - - NZ 62 L-W 3 -
A20U…3.5…
DLM 3.5-NX DLS 4 DSP 4 LSX 3.52B SM 50-107-10 NZ 62 L-W 3 T 20
LDRED
WF
DMIN
DCON
100°KAPR
LF
H
CSP
15°
max.
DMIN
93°KAPR
WF
LDRED
LF
DCON
H
CSP
Coolant
Coolant
151
turning
Size
Dimensions (inch)
IC
Inscribed
Circle Dia.
S
Thickness
RE
Corner
Radius
2.731 .343 .187 .016
3.53.51 .437 .219 .016
3.53.52 .437 .219 .031
3.53.53 .437 .219 .047
Part Number
ANSI (ISO)
ap
(inch)
Feed
(ipr)
CVD Coated
TT8105B TT8115B TT8125B
XNMG 2.731 (090404) FLP
.008-.060
.003-.009
•••
XNMG 3.53.51 (110504) FGP
.010-.080 .003-.009
•••
XNMG 3.53.52 (110508) FGP
.012-.080 .004-.014
•••
XNMG 3.53.53 (110512) FGP
.014-.080 .006-.016
• •
XNMG 3.53.52 (110508) MLP
.020-.138 .004-.016
•••
XNMG 3.53.53 (110512) MLP
.024-.138 .006-.020
•••
XNMG
NEGATIVE 70º RHOMBIC INSERTS
RE
IC
70°
S
•
:
Standard items
FLP
MLP
FGP
152
A NEW DOUBLE-SIDED MINI-SIZE INSERT AND HOLDER LINE, AN ECONOMICAL ALTER-
NATIVE TO STANDARD POSITIVE TURNING AND BORING INSERTS
• Double-sided miniature inserts (7mm IC)
• Optimized turning for low depths of cut (up to 2mm)
• Inserts feature the same cutting edge angle as standard positive inserts (zero degrees)
• Low cutting forces promotes very good surface finish
• Excellent chip control at lower depths of cut
• Stable screw clamping
• Suitable for general purpose machining of small parts, especially on Swiss type automatic lathes
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
95°
SCLNR/L 08-2.2C-SH
.500 .500 .500 5.0 .500 .47
CNMX 2.22_
SCLNR/L 10-2.2C-SH
.625 .625 .625 5.0 .625 .47
SCLNR/L-SH, SCLNR/L
SCREW TYPE HOLDERS (CNMX INSERT)
WF
LF
LH
95°KAPR
B
H
HF
WF
LH
LF
95°KAPR
B
H
HF
SCLNR-SH SCLNR
WF
LF
LH
95°KAPR
B
H
HF
Spare Parts
Part Number
Shim
Screw Wrench Recommended
Torque
SCLNR/L
SM25-060-90 T 7P 8 in-lbs
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
95°
SCLNR/L 10-2.2B
.625 .625 .625 4.5 .750 .63
CNMX 2.22_
SCLNR/L 12-2.2B
.750 .750 .750 4.5 1.000 .78
WF
LH
LF
95°KAPR
B
H
HF
153
turning
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
93°
SDJNR/L 08-2.2C-SH
.500 .500 .500 5.0 .500 .59
DN...X 2.22_
SDJNR/L 10-2.2C-SH
.625 .625 .625 5.0 .625 .59
SDJNR/L-SH, SDJNR/L
SCREW TYPE HOLDERS (DN_X INSERT)
SDJNR-SH SDJNR
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
93°
SDJNR/L 10-2.2B
.625 .625 .625 4.5 .750 .63
DN...X 2.22_
SDJNR/L 12-2.2B
.750 .750 .750 4.5 1.000 .78
27° max.
LH
HF H
WF B
LF
93°
27° max.
LH
LF
93°KAPR
WF B
H
HF
27° max.
LH
HF H
WF B
LF
93°
27° max.
LH
HF
WF
H
B
LF
93°
Spare Parts
Part Number
Shim
Screw Wrench Recommended
Torque
SDJNR/L
SM25-060-90 T 7P 8 in-lbs
154
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
95°
SWLNR/L 08-2.2C-SH
.500 .500 .500 5.0 .500 .47
WNMX 2.22_
SWLNR/L 10-2.2C-SH
.625 .625 .625 5.0 .625 .47
SWLNR/L-SH, SWLNR/L
SCREW TYPE HOLDERS (WNMX INSERT)
SWLNR-SH SWLNR
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
LH
Head
Length
95°
SWLNR/L 10-2.2B
.625 .625 .625 4.5 .750 .63
WNMX 2.22_
SWLNR/L 12-2.2B
.750 .750 .750 4.5 1.000 .63
WF B
LF
HHF
LH
95°
WF B
H
HF
LH
LF
95°
WF B
LF
HHF
LH
95°
WF B
H
HF
LH
LF
95°
Spare Parts
Part Number
Shim
Screw Wrench Recommended
Torque
SWLNR/L
SM25-060-90 T 7P 8 in-lbs
155
turning
A-SCLNR/L
SCREW TYPE BORING BARS WITH THRU COOLANT (CNMX INSERT)
Approach angle Part Number
Dimension (inch)
Insert
DCON
Shank
Diameter
DMIN
Min. Bore
Diameter
LF
Functional
Length
WF
Functional
Width
LDRED
Reduced Body
Dia. Length
H
Shank Height
95° A08M-SCLNR/L-2.2
.500 .63 6.00 .312 .84 .46
CNMX 2.22
A10R-SCLNR/L-2.2
.625 .81 8.00 .406 .96 .58
DMIN
DCON
H
WF
LDRED
LF
95°
DMIN
DCON
H
WF
LDRED
LF
95°
Spare Parts
Part Number
Shim
Screw Wrench Recommended
Torque
A-SCLNR/L
SM25-060-90 T 7P 8 in-lbs
Coolant
156
A-SDUNR/L
SCREW TYPE BORING BARS WITH THRU COOLANT (DN_X INSERT)
Approach angle Part Number
Dimension (inch)
Insert
DCON
Shank
Diameter
DMIN
Min. Bore
Diameter
LF
Functional
Length
WF
Functional
Width
LDRED
Reduced Body
Dia. Length
H
Shank Height
93° A08M-SDUNR/L-2.2
.500 .63 6.00 .312 .84 .46
DN_X 2.22
A10R-SDUNR/L-2.2
.625 .81 8.00 .406 .96 .58
DCON
H
DMIN
30°
max.
LDRED
LF
WF 93°
DCON
H
D
MIN
30°
max.
LDRED
LF
WF 93°
Spare Parts
Part Number
Shim
Screw Wrench Recommended
Torque
A-SDUNR/L
SM25-060-90 T 7P 8 in-lbs
Coolant
157
turning
A-SWLNR/L
SCREW TYPE BORING BARS WITH THRU COOLANT (WNMX INSERT)
Approach angle Part Number
Dimension (inch)
Insert
DCON
Shank
Diameter
DMIN
Min. Bore
Diameter
LF
Functional
Length
WF
Functional
Width
LDRED
Reduced Body
Dia. Length
H
Shank Height
95° A08M-SWLNR/L-2.2
.500 .75 6.00 .375 .84 .46
WNMX 2.22
A10R-SWLNR/L-2.2
.625 .85 8.00 .438 .96 .58
DMIN
DCON
LF
LDRED H
WF 95°
DMIN
DCON
LF
LDRED H
WF 95°
Spare Parts
Part Number
Shim
Screw Wrench Recommended
Torque
A-SWLNR/L
SM25-060-90 T 7P 8 in-lbs
Size
Dimensions (inch)
IC
Inscribed
Circle Dia.
S
Thickness
RE
Corner
Radius
2.2 .276 .125 .016
Part Number
ANSI (ISO) ap
(inch) Feed
(ipr)
Cermet CVD Coated PVD Coated
PV3010 TT8115B TT8125B TT5080
CNMX 2.221 (070304) FGP
.012-.080 .002-.010
••••
CNMX
NEGATIVE 80º RHOMBIC INSERTS
S
RE
80°
IC
Coolant
•
:
Standard items
158
Size
Dimensions (inch)
IC
Inscribed
Circle Dia.
S
Thickness
RE
Corner
Radius
2.2 .276 .125 .008-.016
Part Number
ANSI (ISO) ap
(inch) Feed
(ipr)
Cermet CVD Coated PVD Coated
PV3010 TT8115B TT8125B TT5080 TT9020
DNGX 2.220.5 (080302) M-SM-F
.008-.047
.0008-.005
•
DNMX 2.221 (080304) FGP
.012-.080
.002-.010
••••
DNGX/DNMX
NEGATIVE 55º RHOMBIC INSERTS
S
RE
IC
55°
•
:
Standard items
Size
Dimensions (inch)
IC
Inscribed
Circle Dia.
S
Thickness
RE
Corner
Radius
2.2 .276 .125 .016
Part Number
ANSI (ISO) ap
(inch) Feed
(ipr)
Cermet CVD Coated PVD Coated
PV3010 TT8115B TT8125B TT5080
WNMX 2.221 (040304) FGP
.012-.080 .002-.010
••••
WNMX
NEGATIVE 80º TRIGON INSERTS
80°
RE S
IC
•
:
Standard items
DNGX
DNMX
159
turning
4-EDGE INSERTS AND HOLDERS FOR ALL-DIRECTIONAL TURNING
INCLUDING HIGH-FEED BACKWARD TURNING
• Multi-directional turning capabilities that include forward longitudinal turning, high feed backward turning, face turning, profiling
and undercutting all with the same tool
• Double-sided ZNMV inserts provide 4 cutting edges
• Insert/holder system uses the same axial and radial rake angle as comparable positive inserts, resulting in low cutting forces
• Serrated cutting edge provides excellent chip control at a variety of cutting depths
• Much higher productivity due to reduced downtime, fewer tool changes and optimized tool paths
• 1.00” and 1.25” holders feature rigid T-Type clamping and optional internal coolant supply
Spare Parts
Part Number
Clamp Clamp screw Spring Shim Shim screw Wrench
TZQNR/L
DLM 3.3Z-NV DLS 5 DSP 5 TSZ 140310 TS 35083I/HG L-W 4 T 10
Approach Angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
LH
Head
Length
WF
Functional
Width
TZQNR/L 16-3.3D
1.000 1.000 1.000 6.0 1.57 1.25
ZNMV 3-36.32
TZQNR/L 20-3.3D
1.250 1.250 1.250 6.0 1.57 1.50
TZQNR
ZNMV ZNMV Y
SERIES TZQNR/L
T-HOLDERS FOR ZNMV INSERTS
ZNMV
23°(BWT)
95°(FWT)
ZNMV Y
28°(BWT)
118°(FWT)
95°KAPR 118°KAPR
23°KAPR 28°KAPR
20° max.
20° max.
17° max.
25° max.
LF
LH
FWT
FWT
.080 max.
.059
.059
.100 max.
BWT
.040 max.
.060 max.
BWT
WF B
H
HF
BWT: Backward turning
FWT: Forward turning
95°KAPR 118°KAPR
23°KAPR 28°KAPR
20° max.
20° max.
17° max.
25° max.
LF
LH
FWT
FWT
.080 max.
.059
.059
.100 max.
BWT
.040 max.
.060 max.
BWT
WF B
H
HF
95°KAPR 118°KAPR
23°KAPR 28°KAPR
20° max.
20° max.
17° max.
25° max.
LF
LH
FWT
FWT
.080 max.
.059
.059
.100 max.
BWT
.040 max.
.060 max.
BWT
WF B
H
HF
95°KAPR 118°KAPR
23°KAPR 28°KAPR
20° max.
20° max.
17° max.
25° max.
LF
LH
FWT
FWT
.080 max.
.059
.059
.100 max.
BWT
.040 max.
.060 max.
BWT
WF B
H
HF
160
Spare Parts
Part Number
Clamp Clamp screw Spring Shim Shim screw Wrench
TZQNR/L
DLM 3.3Z-NV DLS 5 DSP 5 TSZ 140310 TS 35083I/HG L-W 4 T 10
Approach Angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
LH
Head
Length
WF
Functional
Width
HBH
Head Bottom
Offset Height
TZQNR/L 16-3.3D-TB
1.000 1.000 1.000 6.0 1.57 1.25 .28
ZNMV 3-36.32
TZQNR/L 20-3.3D-TB
1.250 1.250 1.250 6.0 1.57 1.50 -
TZQNR-TB
ZNMV ZNMV Y
SERIES TZQNR/L-TB
T-HOLDERS FOR ZNMV INSERTS WITH HIGH PRESSURE COOLANT
ZNMV
23°(BWT)
95°(FWT)
ZNMV Y
28°(BWT)
118°(FWT)
BWT: Backward turning
FWT: Forward turning
LF
WF B
Frontal
Coolant Hole
20° max.
20° max.
FWT BWT
23°KAPR
95°KAPR
.080 max.
.100 max.
FWT BWT
28°KAPR
.040 max.
.060 max.
17° max.
25° max.
.060
.060
LH
HF
HBH
H
NPTF 1/8-27
118°KAPR
LF
WF B
Frontal
Coolant Hole
20° max.
20° max.
FWT BWT
23°KAPR
95°KAPR
.080 max.
.100 max.
FWT BWT
28°KAPR
.040 max.
.060 max.
17° max.
25° max.
.060
.060
LH
HF
HBH
H
NPTF 1/8-27
118°KAPR
LF
WF B
Frontal
Coolant Hole
20° max.
20° max.
FWT BWT
23°KAPR
95°KAPR
.080 max.
.100 max.
FWT BWT
28°KAPR
.040 max.
.060 max.
17° max.
25° max.
.060
.060
LH
HF
HBH
H
NPTF 1/8-27
118°KAPR
LF
WF B
Frontal
Coolant Hole
20° max.
20° max.
FWT BWT
23°KAPR
95°KAPR
.080 max.
.100 max.
FWT BWT
28°KAPR
.040 max.
.060 max.
17° max.
25° max.
.060
.060
LH
HF
HBH
H
NPTF 1/8-27
118°KAPR
LF
WF B
Frontal
Coolant Hole
20° max.
20° max.
FWT BWT
23°KAPR
95°KAPR
.080 max.
.100 max.
FWT BWT
28°KAPR
.040 max.
.060 max.
17° max.
25° max.
.060
.060
LH
HF
HBH
H
NPTF 1/8-27
118°KAPR
161
turning
Spare Parts
Part Number
Clamp Clamp screw Spring Shim Shim screw Wrench
TZXNN
DLM 3.3Z-NV DLS 5 DSP 5 TSZ 140310 TS 35083I/HG L-W 4 T 10
Approach Angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
LH
Head
Length
WF
Functional
Width
TZXNN 16-3.3D
1.000 1.000 1.000 6.0 1.73 .500
ZNMV 3-36.32Y-BF
TZXNN 20-3.3D
1.250 1.250 1.250 6.0 1.73 .625
TZXNN
SERIES TZXNN
T-HOLDERS FOR ZNMV Y INSERTS
73º
LF
LH
WF
70° max.
73°
KAPR
.100 max.
B
H
HF
73°
KAPR
LH
WF
HBH
70° max.
Frontal
Coolant Hole
LF
.100 max.
NPTF1/8-27
B
H
HF
LF
LH
WF
70° max.
73°
KAPR
.100 max.
B
H
HF
162
Spare Parts
Part Number
Clamp Clamp screw Spring Shim Shim screw Wrench
TZXNN-TB
DLM 3.3Z-NV DLS 5 DSP 5 TSZ 140310 TS 35083I/HG L-W 4 T 10
Approach Angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
LH
Head
Length
WF
Functional
Width
HBH
Head Bottom
Offset Height
TZXNN 16-3.3D-TB
1.000 1.000 1.000 6.0 1.73 .500 .28
ZNMV 3.36.32Y-BF
TZXNN 20-3.3D-TB
1.250 1.250 1.250 6.0 1.73 .625 -
TZXNN-TB
SERIES TZXNN-TB
T-HOLDERS FOR ZNMV Y INSERTS WITH HIGH PRESSURE COOLANT
73º
73°
KAPR
LH
WF
HBH
70° max.
Frontal
Coolant Hole
LF
.100 max.
NPTF1/8-27
B
H
HF
73°
KAPR
LH
WF
HBH
70° max.
Frontal
Coolant Hole
LF
.100 max.
NPTF1/8-27
B
H
HF
73°
KAPR
LH
WF
HBH
70° max.
Frontal
Coolant Hole
LF
.100 max.
NPTF1/8-27
B
H
HF
163
turning
•
:
Standard items
Part Number
Backward Turning Forward Turning
CVD Coated PVD Coated
ap
(inch) Feed
(ipr) ap
(inch) Feed
(ipr)
TT8015
TT8115
TT8125
TT3010
TT3020
ZNMV 3.36.32-BM
.020-.100 .016-.040 .020-.080 .008-.024
•••
ZNMV 3.36.32-BS
.020-.100 .020-.040 .040-.080 .008-.016
• •
Size
Dimensions (inch)
IC
Insert
Size
S
Thickness
RE
Corner
Radius
3.36.3 .413 .394 .031
•
:
Standard items
Part Number
Backward Turning Forward Turning
CVD Coated
ap
(inch) Feed
(ipr) ap
(inch) Feed
(ipr)
TT8015
TT8115
TT8125
ZNMV 3.36.32Y-BF
.010-.060 .008-.020 .010-.040 .008-.014
•••
Size
Dimensions (inch)
IC
Insert
Size
S
Thickness
RE
Corner
Radius
3.36.3 .413 .394 .031
SERIES ZNMV
NEGATIVE RHOMBIC INSERTS WITH 80º CORNER ANGLE
SERIES ZNMV Y
NEGATIVE RHOMBIC INSERTS WITH 35º CORNER ANGLE
RE
80º
45º
S
IC
S
RE
35º
45º
IC
BM
BS
Refer to New Product Announcement for more detailed application guidelines.
Refer to New Product Announcement for more detailed application guidelines.
164
NEW HIGH-FEED TURNING PRODUCT LINE CAPABLE OF BI-DIRECTIONAL TURNING
• Productive, high feed turning with a maximum .120” (3mm) feed per revolution and up to .080” (2mm) depth of cut
• Positive, trigon-shaped insert with 6 cutting edges (3 indexes) and optimized chip breaker
• Bi-directional (left or right) continuous turning with one neutral holder.
- Dramatically reduced cycle time
- Less inventory of holders
• Anti-rotation groove design on the bottom of insert along with a special screw design provides very stable clamping & machining,
even at incredibly high feed rates
• high-pressure through coolant from above and below insert enhances chip control and prolongs tool life
• TT8115B, TT8125B, TT8135B two-tone colored CVD-coated grades protect against heat and crater wear
SERIES SFXCN
SCREW TYPE HOLDERS WITH HIGH PRESSURE COOLANT
Spare Parts
Part Number
Insert
Screw Wrench
SFXCN
SO 45130I T 20
Approach angle Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
LU
Usuable
Length
WF
Functional
Width
LH
Head
Length
HBH
Head Bottom
Offset Height
15°
SFXCN 16-4.9D
1.000 1.000 1.000 6.0 1.26 .500 1.46 1.26
FCMX 4.944
SFXCN 20-4.9D
1.250 1.250 1.250 6.0 1.26 .625 1.46 1.26
HF
LF
WF
.717"
CW
LU
H
B
LH
15°
KAPR
1/8-27 NPTF
HBH
HF
LF
WF
.717"CW
LU
H
B
LH
15°KAPR
1/8-27 NPTF
HBH
165
turning
•
:
Standard items
Size
Dimensions (inch)
IC
Inscribed
Circle Dia.
S1
Thickness
RE
Corner
Radius
4.9 (10)
.608 .256 .063
S1
IC
RE
90°
7°
SERIES FCMX
POSITIVE HIGH FEED INSERTS
Part Number
ANSI (ISO) ap
(inch) Feed
(ipr)
CVD Coated
TT8115B TT8125B TT8135B TT9225
FCMX 4.944 (100616) HFG
.020-.080
.060-.120
• • •
FCMX 4.944 (100616) HFP
.020-.080
.040-.100
•••
HFG
HFP
166
1 TB-4-FTX-S 1/8-27 NPTF 1/4 (37º Flare) 1/2" 1.22" 6000
Fig. Part Number End Size C
(hex) LMax Pressure
(psi)
E1 E2
CONNECTORS
Fig. 1
L
E1
C
E2
Fig. 2
L
E1
C
E2
M
Fig. 3
E2
E1
N
Y*
Y*- Across
wrench flats
M
Fig. 4
E2
E1
N
Y*
Y*- Across
wrench flats
Fig.1 - STRAIGHT MALE CONNECTOR
Fig. 1
L
E1
C
E2
Fig. 2
L
E1
C
E2
M
Fig. 3
E2
E1
N
Y*
Y*- Across
wrench flats
M
Fig. 4
E2
E1
N
Y*
Y*- Across
wrench flats
2 TB-4-CTX-S 1/8-27 NPTF 1/4 (37º Flare) 7/16" 0.89" 0.78" 6000
Fig. Part Number End Size Y M N Max Pressure
(psi)
E1 E2
All connectors ordered separately.
Fig.2 - ELBOW MALE CONNECTOR
TB-HOSE-7/16-7/16-8.0SS 8.0" 1/4 (37º Flare) 1/4 (37º Flare) 3000
TB-HOSE-7/16-7/16-10.0SS 10.0" 1/4 (37º Flare) 1/4 (37º Flare) 3000
Part Number
Dimensions
Max Pressure
(psi)
OAL E1 E2
L
E1
SS
E2
Hoses ordered separately.
FLEXIBLE HIGH-PRESSURE HOSES
167
parting &
grooving
GROOVING FAMILY EXPANDS WITH NEW SERIES OF SMALLER SIZE INSERTS AND
HOLDERS FOR SWISS-TYPE AUTOMATIC LATHES
• 4-edge miniature insert for grooving, parting, turning, profiling and threading on Swiss-type lathes
• Inserts are handed so they can part or groove next to a square shoulder
• Grooving width range of .020” ~ .118” (0.5 to 3.0 mm)
• Grooving depth range of .087” ~ .197” (2.2 to 5.0 mm)
• Superior insert position repeatability and strong clamping force results in long tool life
• Holders available with or without high pressure internal coolant supply
• Inserts feature new PVD-coated grade TT4430 and a sharp cutting edge
SERIES TQHR/L-20
Spare Parts
Designation
Screw Wrench
TQHR/L...20
TS 40A100L (1)
TS 40A100 (2)
T-1508/5
Right hand shown
LF
.73
.30
HBL HBH
B
H
WF
HF
Designation
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
HBL
Head Bottom
Offset Length
HBH
Head Bottom
Offset Height
TQHR/L 9.5-20
.375 .375 .375 5.0 .375 .73 0.16
TQS 20
TQJ 20
TQHR/L 12.7-20
.500 .500 .500 5.0 .500 .73 0.08
TQHR/L 15.9-20
.625 .625 .625 5.0 .625 - -
TQHR/L 19-20
.750 .750 .750 5.0 .750 - -
(1) For TQHR, (2) For TQHL
GROOVING AND TURNING HOLDERS FOR SWISS-TYPE AUTOMATIC LATHES
Grooving Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
Turning
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
Threading
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
Profiling
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
168
Right hand shown
WF B
CNT
LF
.73
.30
HF
HBL HBH
H
Spare Parts
Designation
Screw Wrench Plug Plug Wrench Coolant Accessories
(Fittings & Hoses)
TQHR/L 12.7/15.9-20-TB
TS 40A100L (1)
TS 40A100 (2) T-1508/5 PLG 5/16 UNF L-W 4 Refer to Ingersoll Website
TQHR/L 19-20-TB
TS 40A100L (1)
TS 40A100 (2) T-1508/5 NPTF 1/8-TQ19 L-W 3/16 Refer to Ingersoll Website
Designation
Dimension (inch)
CNT Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
WF
Functional
Width
HBL
Head Bottom
Offset Length
HBH
Head Bottom
Offset Height
TQHR/L 12.7-20-TB
.500 .500 .500 5.0 .500 .73 0.08 UNF 5/16-24
TQS 20
TQJ 20
TQHR/L 15.9-20-TB
.625 .625 .625 5.0 .625 - - UNF 5/16-24
TQHR/L 19-20-TB
.750 .750 .750 5.0 .750 - - 1/8 27 NPTF
(1) For TQHR, (2) For TQHL
Designation 1015 PSI Flow Rate (GPM) 1450 PSI Flow Rate (GPM) 2030 PSI Flow Rate (GPM)
TQHR/L...-TB
2.4-2.9 2.9-3.4 3.2-3.7
SERIES TQHR/L-20-TB
GROOVING AND TURNING HOLDERS WITH HIGH PRESSURE COOLANT FOR
SWISS-TYPE AUTOMATIC LATHES
Grooving Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
Turning
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
Threading
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
Profiling
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
HP Coolant
169
parting &
grooving
•
:
Standard items
RE RETOL
RE ≤ .004 .0008
.004 < RE ≤ .016 .0012
RE > .016 .0020
Right hand shown
CDX
CUTDIA
ø.79
Repeatability
±.001
CW ±.0008
RE ±RETOL
.157
4°
CDXCUTDIA
N.L. : No Limit
Full Radius Insert
Designation
Feed (ipr)
Dimension (inch) CUTDIA (Cutting Diameter)
Grade
Cutting
Feed
Min.
Cutting
Feed
Max.
CW
Cutting
Width
RE
Corner
Radius
CDX
Cutting
Depth Max.
CDX
≤ .087
CDX
≤ .106
CDX
≤ .138
CDX
≤ .157
CDX
≤ .177
CDX
≤ .197
TT4430
TQS20-0.50-0.05-R/L
.0010 .0030 0.020 0.002 0.087
N.L. - - - - - •
TQS20-1.00-0.10-R/L
.0010 .0030 0.039 0.004 0.106
N.L. N.L. - - - - •
TQS20-1.50-0.10-R/L
.0010 .0040 0.059 0.004 0.197
N.L. N.L. 2.75 1.96 1.18 0.63 •
TQS20-2.00-0.10-R/L
.0010 .0040 0.079 0.004 0.197
N.L. N.L. 2.75 1.96 1.18 0.63 •
TQS20-2.00-1.00-R/L*
.0015 .0055 0.079 0.039 0.197
N.L. N.L. 2.75 1.96 1.18 0.63 •
TQS20-2.50-0.10-R/L
.0020 .0050 0.098 0.004 0.197
N.L. N.L. 2.75 1.96 1.18 0.63 •
TQS20-3.00-0.10-R/L
.0015 .0060 0.118 0.004 0.197
N.L. N.L. 2.75 1.96 1.18 0.63 •
TQS20-3.00-1.50-R/L*
.0015 .0060 0.118 0.059 0.197
N.L. N.L. 2.75 1.96 1.18 0.63 •
SERIES TQS 20
PARTING AND GROOVING – PRECISION INSERTS WITH GROUND CHIP BREAKER
Grooving Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
Turning
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
Profiling
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
170
•
:
Standard items
RE RETOL
RE ≤ .004 .0008
.004 < RE ≤ .016 .0012
RE > .016 .0020
Right hand shown
CDX
CUTDIA
CDX
CUTDIA
ø.79
CW ±.0008 .157
4°
RE ±RETOL
Repeatability
±.001
N.L. : No Limit
Designation
Feed (ipr)
Dimension (inch) CUTDIA (Cutting Diameter)
Grade
Cutting
Feed
Min.
Cutting
Feed
Max.
CW
Cutting
Width
RE
Corner
Radius
CDX
Cutting
Depth Max.
CDX
≤ .106
CDX
≤ .138
CDX
≤ .157
CDX
≤ .177
CDX
≤ .197
TT4430
TQJ20-1.00-0.10-R/L
.0010 .0030 0.039 0.004 0.106
N.L. - - - - •
TQJ20-1.50-0.20-R/L
.0010 .0030 0.059 0.008 0.197
N.L. 2.75 1.96 1.18 0.63 •
TQJ20-2.00-0.20-R/L
.0015 .0040 0.079 0.008 0.197
N.L. 2.75 1.96 1.18 0.63 •
SERIES TQJ 20
PARTING AND GROOVING – PRECISION INSERTS WITH GROUND CHIP BREAKER
SERIES TQS 20-MT
PARTIAL PROFILE 60º THREADING INSERTS
•
:
Standard items
Designation
Dimension (inch)
Grade
TPN
Thread Pitch
Min. (mm)
TPX
Thread Pitch
Max. (mm)
TPIN
Threads Per
Inch Min.
TPIX
Threads Per
Inch Max.
RE
Corner
Radius
PDX
Profile
Distance Ex.
TT4430
TQS20-MT-0.05-R/L
0.30 1.75 48 14
.002 .031 •
Right hand shown
.157
4°
60°
RE
PDX
ø.79
Repeatability
±.001
Grooving Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
Turning
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
Threading
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill Channel Pocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMill Slab Chamfer
Face GrooveID fnr Groove/TurnID fnr Groove OD fnr Prole OD Part-O
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProleFace Groove/TurnID fnr Relief
Groove/Turn
ID GrooveID Groove/TurnID Groove/Thread
171
parting &
grooving
SMALL SIZE 4-CUTTING EDGE INSERT AND HOLDERS FOR INTERNAL GROOVING
• Efficient 4-cutting edge insert for internal grooving
• 3-point contact design with strong screw clamping
• Stable machining and long tool life
• Positive chip breaker controls chips and generates a very good surface finish
• Minimum bore diameters as small as .650” (16.5mm)
• Same insert can be mounted to both left and right-hand holders, reducing inventory requirements
• Internal coolant supply
SERIES TQHIR/L
CDX: Refer to insert dimension
Spare Parts
Part Number
Screw Wrench Seal
TQHIR/L 15.9
TS 25075I/HG T 8
PL 062
TQHIR/L 19
TS 25075I/HG T 8
PL 075
Part Number
Dimension (inch)
Insert
DCON
Shank
Diameter
DMIN
Min. Bore
Diameter
WF
Functional
Width
LDRED
Reduced Body
Dia. Length
OAL
Overall
Length
HF
Functional
Height
TQHIR/L 15.9-16.5-14
.625 .65 .433 1.57 5.0 .295 TQIS 14
TQHIR/L 19-16.5-14
.750 .65 .512 1.57 5.0 .354
INTERNAL GROOVING HOLDERS WITH COOLANT HOLE
OAL
WF
LDRED
CSP
DCON
HF
D
MIN
CDX
Right hand shown
ID Groove/Turn
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
ID Groove
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Coolant
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
172
•
:
Standard items
Part Number Feed
(ipr)
Dimension (inch)
Grade
CW
Cutting
Width
RE
Corner
Radius
CDX
Cutting
Depth Max.
TT9080
TQIS 14-1.50-0.10
.0008-.0025
.059 .004 .074 •
TQIS 14-2.00-0.10
.0010-.0030
.079 .004 .098 •
TQIS 14-2.00-0.20
.0010-.0030
.079 .008 .098 •
TQIS 14-2.50-0.20
.0010-.0035
.098 .008 .098 •
TQIS 14-3.00-0.20
.0010-.0040
.118 .008 .098 •
ø.571
RE ±.001 CDX
.146
.146
CW ±.0008
Repeatability
±.001
SERIES TQIS 14
4 CUTTING EDGE INSERTS FOR INTERNAL SHALLOW GROOVING
ID Groove/Turn
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
ID Groove
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
173
parting &
grooving
MINIATURE SIZE INSERTS AND HOLDERS FOR SHALLOW INTERNAL GROOVING
• Suitable for small diameter internal grooves with minimum bore diameter down to .394” (10mm)
• Robust, 3-point contact design with screw clamping prevents vibration and generates an excellent surface finish
• Neutral holder design allows inserts to be mounted in 4 different ways, eliminating the need for handed tools and allowing
either CW or CCW spindle rotation
• Internal coolant supply for longer tool life
• Steel and carbide shank options
• Economical alternative to solid carbide grooving tools
• Inserts feature new PVD-coated grade TT4430 and a sharp cutting edge
SERIES TMIHN
Spare Parts
Designation
Screw Wrench
TMIHN
TS 22052I/HG T 7
Designation
Dimension (inch)
Coolant
Inlet Insert
DCON
Shank
Diameter
DMin
Min. Bore
Diameter
WF
Functional
Width
LDRED
Reduced Body Dia.
Length
OAL
Overall
Length
TMIHN 12.7-16-8
.500 .394 .185 .63 3.0
Ø.118 TMIS 8
WF
D
MIN
CDX
OAL
LDRED
CSP
DCON
CDX: Refer to insert dimension
INTERNAL GROOVING HOLDER WITH COOLANT HOLES
ID Groove/Turn
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
ID Groove
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Coolant
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
174
SERIES TMIHN-C
Spare Parts
Designation
Screw Wrench
TMIHN-C
TS 22052I/HG T 7
Designation
Dimension (inch)
Coolant
Inlet Insert
DCON
Shank
Diameter
DMin
Min. Bore
Diameter
WF
Functional
Width
LDRED
Reduced Body Dia.
Length
OAL
Overall
Length
TMIHN 12.7C-24-8
.500 .394 .185 .94 3.6 Ø.079
TMIS 8
TMIHN 12.7C-32-8
.500 .394 .185 1.26 4.0 Ø.079
CDX: Refer to insert dimension
OAL
WF LDRED
CSP
DCON
D
MIN
CDX
INTERNAL GROOVING CARBIDE HOLDERS WITH COOLANT HOLES
ID Groove/Turn
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
ID Groove
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Coolant
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
175
parting &
grooving
•
:
Standard items
SERIES TMIS 8
Designation Feed
(ipr)
Dimension (inch)
Grade
CW
Cutting
Width
RE
Corner
Radius
CDX
Cutting
Depth Max.
INSL
Insert
Length
S1
Insert
Thickness
TT4430
TMIS 8-0.50-0.00
.0004-.0012 .0197 .000 .028 .307
.098 •
TMIS 8-1.00-0.00
.0004-.0012 .0394 .000 .059 .307
.098 •
TMIS 8-1.50-0.05
.0004-.0012 .0591 .002 .059 .307
.098 •
TMIS 8-2.00-0.10
.0004-.0012 .0787 .004 .059 .307
.098 •
CDX
INSL
RE
CW ±0.0008 S1
PRECISE INSERTS FOR INTERNAL SHALLOW GROOVING
ID Groove/Turn
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
ID Groove
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
176
FACE GROOVING, EXTERNAL GROOVING AND EXTERNAL THREADING SYSTEM
WITH INNOVATIVE 2-EDGE INSERT
• Robust clamping includes anti-rotation triangular grooves on the bottom side of the insert along with a strong screw clamping
design to eliminate movement in the pocket
• Thick insert design increases stiffness to protect against unpredictable breakage.
• In the event of an edge failure, the insert can be rotated 180° without impacting seating stability
• Holder is designed without a need for an upper or lower clamping jaw
- Excellent chip evacuation without interference of an upper jaw
- Holder breakage is eliminated due to absence of a lower jaw
- One holder used for multiple insert widths
• Wide variety of applications including face grooving and turning, external grooving and turning and external threading
• Insert widths 3mm & 4mm (.118” & .157”) and 60° partial profile threading
• 1.00” parallel and perpendicular style holders, left and right-hand
• Optional internal coolant supply for improved chip evacuation
SERIES TXFR/L
Spare Parts
Part Number
Screw Wrench
TXFR 25.4
SM35-110-00 T 15
TXFL 25.4
TS 35110IL T 15
HF
WF
CDX
LF
OAH H
B
Right hand shown
Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
OAH
Overall
Height
WF
Functional
Width
CDX
Cutting
Depth Max.
TXFR 25.4
1.000 1.000 1.000 6.28 1.04 1.020 .236 TD_X ...R
TD_X ...L
TXFL 25.4
1.000 1.000 1.000 6.28 1.04 1.020 .236
HOLDERS FOR SHALLOW FACE GROOVING, TURNING & EXTERNAL THREADING
OD GrooveFace Groove/Turn
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
OD Groove/Turn
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
OD Groove/ Thread
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Face Groove
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
177
parting &
grooving
SERIES TXFR/L-TB
Spare Parts
Part Number
Screw Wrench Cooling Unit
TXFR 25.4-TB
SM35-110-00 T 15 S-CU-TB
TXFL 25.4-TB
TS 35110IL T 15 S-CU-TB
Right hand shown
Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
OAH
Overall
Height
WF
Functional
Width
CDX
Cutting
Depth Max.
TXFR 25.4-TB
1.000 1.000 1.000 6.28 1.04 1.020 .236 TD_X ...R
TD_X ...L
TXFL 25.4-TB
1.000 1.000 1.000 6.28 1.04 1.020 .236
OAH HF
WF
CDX
NPTF 1/8-27
H
B
LF
Part Number 1000 psi flow rate (gpm) 1500 psi flow rate (gpm) 2000 psi flow rate (gpm)
TXFR 25.4-TB
19-26 26-34 30-38
TXFL 25.4-TB
19-26 26-34 30-38
HP Coolant
HOLDERS FOR SHALLOW FACE GROOVING, TURNING & EXTERNAL THREADING
WITH HIGH-PRESSURE COOLANT
OD GrooveFace Groove/Turn
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
OD Groove/Turn
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
OD Groove/ Thread
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Face Groove
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
178
SERIES TXFPR/L
Spare Parts
Part Number
Screw Wrench
TXFPR 25.4
SM35-110-00 T 15
TXFPL 25.4
TS 35110IL T 15
Right hand shown
Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
OAH
Overall
Height
WF
Functional
Width
CDX
Cutting
Depth Max.
TXFPR 25.4
1.000 1.000 1.000 6.0 1.04 1.275 .236 TDFX ...R
TDFX ...L
TXFPL 25.4
1.000 1.000 1.000 6.0 1.04 1.275 .236
OAH H
B
.590
.590
HF
WF
LF
CDX
PERPENDICULAR HOLDERS FOR SHALLOW FACE GROOVING & TURNING
Face Groove/Turn
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Face Groove
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
179
parting &
grooving
SERIES TXFPR/L-TB
Spare Parts
Part Number
Screw Wrench Cooling Unit
TXFPR-TB
SM35-110-00 T 15 S-CU-TB
TXFPL-TB
TS 35110IL T 15 S-CU-TB
Right hand shown
Part Number
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
OAH
Overall
Height
WF
Functional
Width
CDX
Cutting
Depth Max.
TXFPR 25.4-TB
1.000 1.000 1.000 6.0 1.40 1.275 .236 TDFX ...R
TDFX ...L
TXFPL 25.4-TB
1.000 1.000 1.000 6.0 1.40 1.275 .236
Part Number 1000 psi flow rate (gpm) 1500 psi flow rate (gpm) 2000 psi flow rate (gpm)
TXFPR 25.4-TB
19-26 26-34 30-38
TXFPL 25.4-TB
19-26 26-34 30-38
LF
HF
WF
NPTF 1/8-27
CDX
H
B
PERPENDICULAR HOLDERS FOR SHALLOW FACE GROOVING & TURNING WITH HIGH-PRESSURE COOLANT
Face Groove/Turn
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Face Groove
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
HP Coolant
180
•
:
Standard items
SERIES TDFX
DOUBLE-ENDED INSERTS FOR FACE GROOVING AND TURNING
Part Number
Turning
Grooving
Coated
ap
Depth of Cut
(inch)
Feed
(ipr) Feed
(ipr)
TT9080
TDFX 3E-0.3-D24R/L
.016-.071 .006-.008 .003-.008
•
TDFX 4E-0.4-D32R/L
.020-.095 .006-.010 .004-.010
•
.256S
.307
.315S1
RE
DAXN
DAXX
CW ±.002
CDX
7˚
Size
Dimensions (inch)
CW
Cutting
Width
RE
Corner
Radius
CDX
Cutting
Depth Max.
DAXN
Axial Groove
Outside Dia. Min.
DAXX
Axial Groove
Outside Dia. Max.
3 .118 .012 .236 .945 No Limit
4 .157 .016 .236 1.260 No Limit
Right hand shown
•
:
Standard items
SERIES TDGX
DOUBLE-ENDED THREADING INSERTS WITH 60º PARTIAL PROFILE
Part Number
Coated
TT9080
TDGX 4MT-0.05-R/L •
Size
Dimensions
RE
Corner
Radius
TPN
Thread Pitch
Min. (mm)
TPX
Thread Pitch
Max. (mm)
TPIN
Threads Per
Inch Min.
TPIX
Threads Per
Inch Max.
4 0.05mm (.002") 0.45 3.5 8 56
Right hand shown
RE
60˚
.307
.256S.315S1
181
parting &
grooving
HIGH-FEED CBN INSERTS FOR HARDENED MATERIALS
•
T-Clamp CBN inserts for high feed turning of high-hardened workpiece materials
•
Inclined chip breaker for good chip control at shallow depths of cut (Maximum .0047")
•
Optimized cutting edge design for high feed bi-directional turning
•
Excellent surface finish
•
Significantly improved productivity with a maximum feed rate from .031-.047 ipr
•
TB2015 CBN grade
- Excellent combination of high hardness and moderate fracture toughness
- Continuous and light interrupted machining of hardened steel
•
:
Standard items
INSL
7°AN
CW
WB
S1
RE
BSR
SERIES TSG-HF
Part Number
SSC
Insert
Seat Size
Dimensions (inch) CBN
CW
Cutting
Width
RE
Corner
Radius
WB
Body
Width
INSL
Insert
Length
BSR
Wiper Edge
Radius
ap
Depth of Cut
(inch)
Feed
(ipr)
TB2015
TSG 3.0-0.3-HF
3 .118 (3mm) 0.012 0.087 0.79 1.18 .003-.005 .016-.031
•
TSG 5.0-0.3-HF
5 .197 (5mm) 0.012 0.157 0.98 1.18 .003-.005 .016-.047
•
CBN INSERTS FOR HIGH FEED TURNING
Turning
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
T-Clamp CBN High Feed inserts feature 9-degree lead angles (left and right sides) along with a
large radius on the end of the insert in order to reduce vibration. The presence of these
features should be taken into consideration when programming the work piece.
.047" (1.2mm) for 3mm wide insert
.118" (3.0mm) for 5mm wide insert
R 30mm
9º
182
SINGLE-ENDED RIGID INSERTS AND HOLDERS FOR PARTING AND DEEP GROOVING
WITH UNIQUE ADAPTERS!
• Rigid clamping of the specialized 3-point contact area for excellent accuracy, repeatability and durability
• Insert’s increased height enhances strength and prolongs tool life
• User-friendly insert clamping system
• High rigidity triangular blades and dedicated holders
- Improved productivity due to high feed machining capability
- Stable tool life and impressive cutting performance
• Blades for T-Clamp Ultra+ inserts are also available.
• System is capable of parting off up to 4.72” (120mm) work piece diameter
• Available with internal coolant supply for longer tool life and improved chip evacuation
SERIES SFGB
Part Number Insert
Seat Size
Dimension (inch)
Fig. Block Insert
H
Shank
Height
HF
Functional
Height
LF
Functional
Length
WB
Body
Width
WB_2
Body
Width
CUTDIA
Cutting
Diameter
SFGB 32-1.6 1* 1.26 .97 5.9 .051 .098 1.496 2
TTBU SFC
SFJ
SFGB 32-2 2 1.26 .97 5.9 .071 .098 1.968 2
SFGB 32-3 3 1.26 .97 5.9 .098 - 3.937 1
CUTDIA
LF
Fig.1 Fig.2
WB
HF H
150˚ WB_2
WB
*: SFC 1.6 insert only
Spare Parts
Part Number
Extractor
SFGB ETG 3-4
Extractor sold separately.
BLADES FOR PARTING AND DEEP GROOVING
Grooving
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
183
parting &
grooving
Part Number Insert
Seat Size
Dimension (inch)
CSP
Coolant
Fig. Block Insert
H
Shank
Height
HF
Functional
Height
LF
Functional
Length
WB
Body
Width
WB_2
Body
Width
CUTDIA
Cutting
Diameter
SFGB 32-2-TB
2 1.26
.97 5.9 .051 .098 1.968
Yes 2 TTBU..-TB SF_2
SFGB 32-3-TB
3 1.26
.97 5.9 .071
- 3.937 Yes 1 SF_3
Spare Parts
Part Number
Sealing Screw Set Extractor
SFGB-TB SGC 340 ETG 3-4
Extractor sold separately.
Part Number 1000 psi flow rate (gpm) 1500 psi flow rate (gpm) 2000 psi flow rate (gpm)
SFGB 32-2-TB 2.6-3.2 3.2-3.7 4.0-4.5
SFGB 32-3-TB 5.0-5.5 6.0-6.6 7.1-7.6
CUTDIA
LF
WB
WB WB_2
HF H
150˚
Fig.1 Fig.2
SERIES SFGB-TB
BLADES FOR PARTING & DEEP GROOVING WITH HIGH PRESSURE COOLANT
Grooving
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
HP Coolant
184
Part Number
Dimension (inch)
CSP
Coolant
H
Shank
Height
HF
Functional
Height
HBLD
Blade
Height
B
Shank
Width
HBH
Head Bottom
Offset Height
OAH
Overall
Height
WBLD
Blade
Width
OAL
Overall
Length
OAW
Overall
Width
TTBU 19-32-TB
.75
.75 1.26 .75 .625 2.02 .209 3.44 1.5 Yes
TTBU 25.4-32-TB
1.00
1.00 1.26 .91 .300
1.95 .209 4.33 1.7 Yes
TTBU 31.8-32-TB
1.25
1.25 1.26 1.14 .207
2.10 .209 4.33 1.9 Yes
Spare Parts
Part Number
Screw Clamp O-Ring Wrench
TTBU 19-32-TB SR M6X16 DIN912 BKU 100 O-RING ID14X2.5 L-W 5
TTBU 25.4-32-TB SR M6X16 DIN912 BKU 110 O-RING ID14X2.5 L-W 5
TTBU 31.8-32-TB SR M6X16 DIN912 BKU 110 O-RING ID14X2.5 L-W 5
OAL
G 1/8 B
OAW
OAH
H
HBH
WBLD
HF
HBLD
SERIES TTBU-TB
BLOCKS FOR BLADES WITH HIGH-PRESSURE COOLANT
HP Coolant
185
parting &
grooving
Part Number Insert
Seat
Size
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
LH
Head
Length
WF
Functional
Width
WB
Body
Width
HBH
Head Bottom
Offset Height
CUTDIA
Cutting
Diameter
OAH
Overall
Height
SFER/L 19-1.6T22-D45 1 .75 .75 .75 6.0 1.16 .724 .051 .14 1.77 1.14 SF_1.6
SFER/L 25.4-2T25-D50 2 1.00 1.00 1.00 6.0 1.26 .965 .071 - 1.97 1.26 SF_2
SFER/L 25.4-3T30-D60 3 1.00 1.00 1.00 6.0 1.38 .953 .094 .18 2.36 1.44 SF_3
Spare Parts
Part Number
Extractor
SFER/L ETG 3-4
Extractor sold separately.
WB
LF
LH
H
B
HF
WF
HBH
OAH
CUTDIA
Right hand shown
SERIES SFER/L
EXTERNAL HOLDERS FOR PARTING AND DEEP GROOVING
Grooving
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
186
Spare Parts
Part Number
Plug Wrench Extractor
SFER/L-TB NPTF1/8 L-W3/16 ETG 3-4
Extractor sold separately.
Part Number 1000 psi flow rate (gpm) 1500 psi flow rate (gpm) 2000 psi flow rate (gpm)
SFER/L 25.4-2T25-D50-TB 2.6-3.2 3.2-3.7 4.0-4.5
SFER/L 25.4-3T30-D60-TB 3.7-4.2 4.5-5.0 5.5-6.0
1/8-27 NPTF
WB
OAH HF
LH
HBH
H
B
WF
CUTDIA
LF
SERIES SFER/L-TB
Part Number Insert
Seat
Size
Dimension (inch)
Insert
H
Shank
Height
HF
Functional
Height
B
Shank
Width
LF
Functional
Length
LH
Head
Length
WF
Functional
Width
WB
Body
Width
HBH
Head Bottom
Offset Height
CUTDIA
Cutting
Diameter
OAH
Overall
Height
CSP
Coolant
SFER/L 25.4-2T25-D50-TB 2 1.00 1.00 1.00 6.0 1.26 .965 .071 - 1.97 1.26 Yes
SF_2
SFER/L 25.4-3T30-D60-TB 3 1.00 1.00 1.00 6.0 1.38 .953 .094 .18 2.36 1.44 Yes
SF_3
Right hand shown
EXTERNAL HOLDERS FOR PARTING & DEEP GROOVING WITH HIGH-PRESSURE COOLANT
Grooving
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
HP Coolant
187
parting &
grooving
Spare Parts
Part Number
Screw Wrench
THTBR/L-TB SH M4X0.7X10-TX T 20
SERIES THTBR/L-TB
Part Number
Dimension (inch)
Blade
H
Shank
Height
HF
Functional
Height
B
Shank
Width
OAL
Overall
Length
OAH
Overall
Height
WF
Functional
Width
LF
Functional
Length
CUTDIA
Cutting
Diameter
THTBR/L 19-D52-TB .750 .750 .689 5.0 2.05 .925 1.57 2.05
SFTB
TGTB
THTBR/L 25.4-D52-TB 1.00 1.00 .886 5.4 2.05 1.122 1.57 2.05
THTBR/L 19-D82-TB .750 .750 .689 5.5 2.84 .925 2.03 3.23
THTBR/L 25.4-D82-TB 1.00 1.00 .886 6.0 2.84 1.122 2.03 3.23
THTBR/L 25.4-D120-TB 1.00 1.00 .886 6.5 3.74 1.122 2.64 4.72 SFTB
THTBR/L 31.8-D120-TB 1.25 1.25 1.142 6.5 3.74 1.378 2.64 4.72
Right hand shown
HOLDERS FOR TRIANGULAR BLADE
OAL
B
LF
WF
CUTDIA
OAH
HHF
Grooving
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
188
Part Number
Insert
Seat Size
Dimension (inch)
Insert
IC
Diameter
WB
Body
Width
CUTDIA
Cutting
Diameter
OAW
Overall
Width
SFTB D52-2 2 2.094 .071 2.05 .193
SFC
SFJ
SFTB D52-3 3 2.094 .098 2.05 .220
SFTB D82-2 2 2.531 .071 3.23 .193
SFTB D82-3 3 2.531 .098 3.23 .220
SFTB D120-2 2 3.364 .071 4.72 .193
SFTB D120-3 3 3.364 .098 4.72 .220
SERIES SFTB
TRIANGULAR BLADES FOR CUT-SFEED INSERT
Grooving
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Spare Parts
Part Number
Extractor
SFTB ETG 3-4
Extractor sold separately.
CUTDIA
WB
OAW
IC
189
parting &
grooving
Part Number
Insert
Seat Size
Dimension (inch)
Insert
IC
Diameter
WB
Body
Width
CUTDIA
Cutting
Diameter
OAW
Overall
Width
TGTB D52-2 2 2.094 .071 2.05 .193
* TDC / J / T
TDXU / XT
TSC / J
TGTB D52-3 3 2.094 .098 2.05 .220
TGTB D82-2 2 2.531 .071 3.23 .193
TGTB D82-3 3 2.531 .098 3.23 .220
SERIES TGTB
TRIANGULAR BLADES FOR T-CLAMP INSERT
Spare Parts
Part Number
Extractor
TGTB EDG-33B
Extractor sold separately.
* Refer to Ingersoll website for all T-ClampUltra+ insert options.
Grooving
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
IC
CUTDIA
WB
OAW
190
Part Number
Insert
Seat Size
CW
Cutting
Width
RE
Corner
Radius
Feed
(ipr)
Coated
TT9080 TT8020
SFC 1.6
1 .063" (1.6mm) .008" (.2mm)
.002-.006 • •
SFC 2
2 .079" (2mm) .008" (.2mm) .003-.008
• •
SFC 3
3 .118" (3mm) .008" (.2mm) .004-.010
• •
•
:
Standard items
SERIES SFC
CW ±.002"
RE
7˚AN
Part Number
Insert
Seat Size
CW
Cutting
Width
RE
Corner
Radius
Feed
(ipr)
Coated
TT9080 TT8020
SFJ 2
2 .079" (2mm) .008" (.2mm)
.002-.006 • •
SFJ 3
3 .118" (3mm) .008" (.2mm) .003-.008
• •
•
:
Standard items
SERIES SFJ
CW ±.002"
RE
7˚AN
SINGLE-ENDED INSERTS FOR PARTING & DEEP GROOVING WITH C-TYPE CHIP BREAKER
SINGLE-ENDED INSERTS FOR PARTING & DEEP GROOVING WITH J-TYPE CHIP BREAKER
Grooving
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Grooving
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
Parting
BalancedOD ThreadID Thread
Ream
Spot Drill Helical Interp. Facing Lead Angle Plunge Slot
Corner RndFlat Bottom Coutersink Contour Ramp Drill ChannelPocket
BalancedHole ChamferT-Slot Engrave Cooling Shoulder DrillMillSlab Chamfer
Face Groove ID fnr Groove/Turn ID fnr Groove OD fnr Profile OD Part-Off
OD Groove/Thread OD Groove
Face fnr ReliefOD Groove/Turn
OD fnr Groove/
Turn Taper
OD fnr Groove/Turn
OD fnr Groove
ID fnr ProfileFace Groove/Turn ID fnr Relief
Groove/Turn
ID Groove ID Groove/Turn ID Groove/Thread
191
parting &
grooving
L
E1
SS
E2
All hoses ordered separately.
L
E1
SS
E2
Part Number Dimension (inch)
Max Pressure
(psi)
L E1 E2
TB-HOSE-7/16-7/16-8.0SS 8.0 inch 1/4 (37º Flare) 1/4 (37º Flare) 3000
TB-HOSE-7/16-7/16-10.0SS 10.0 inch 1/4 (37º Flare) 1/4 (37º Flare) 3000
E1
C
C
E2
E1 E2
L
L
Fig. 1a Fig. 1b
E1
C
C
E2
E1 E2
L
L
Fig. 1a Fig. 1b
Fig.1 - STRAIGHT MALE CONNECTORS
Y* – Across wrench flats
Fig. 2a Fig. 2b
E1
E1
NN
MM
Y* Y*
E2
Y* – Across wrench flats
Fig. 2a Fig. 2b
E1
E1
NN
M M
Y* Y*
E2
Fig.2 - ELBOW MALE CONNECTORS
Fig. 1A Fig. 1B Fig. 2A Fig. 2B
1A TB-4-FTX-S 1/8-27 NPTF 1/4 (37º Flare) 1/2" 1.22" 6000
1B TB-4F42EDMX-S 1/8-28 BSPP 1/4 (37º Flare) 14mm 30.2mm 7200
Fig. Part Number End Size C
(hex) LMax Pressure
(psi)
E1 E2
2A TB-4-CTX-S 1/8-27 NPTF 1/4 (37º Flare) 7/16" 0.89" 0.78" 6000
2B TB-4C4OMX-S 1/8-28 BSPP 1/4 (37º Flare) 11mm 22.6mm 26.5mm 3600
Fig. Part Number End Size Y M N Max Pressure
(psi)
E1 E2
All connectors ordered separately.
CONNECTORS
FLEXIBLE HIGH-PRESSURE HOSES
