ISO
TURNING GROOVING PARTING FACE
GR
OO
VING
TOOL
BLOCKS THREADING TOOL
HOLDERS GRADES
ISCAR TURNING LINES
Metric Catalog
www.iscar.com
Quality Standard
ISCAR has been certified by the prestigious Standards Institution,
as being in full compliance to ensure delivery of the finest quality
goods. Quality control facilities include the metallurgical laboratory,
raw metal testing, an online testing procedure and a machining
center for tool performance testing and final product inspection.
Only the finest products are packaged for entry into
ISCAR’s inventory.
C
E
R
T
I
F
I
E
D
Q
M
S
SI
ISO 9001:
2015
THE STANDARDS INSTITUTION OF ISRAEL
C
E
R
T
I
F
I
E
D
O
H
S
S
Y
S
T
E
M
SI
ISO
45001:2018
THE STANDARDS INSTITUTION OF ISRAEL
C
E
R
T
I
F
I
E
D
E
N
E
R
G
Y
M
A
N
A
G
E
M
E
N
T
S
Y
S
T
E
M
SI
ISO
50001
THE STANDARDS INSTITUTION OF ISRAEL
C
E
R
T
I
F
I
E
D
E
M
S
SI
ISO 14001:
2015
THE STANDARDS INSTITUTION OF ISRAEL
C
E
R
T
I
F
I
E
D
Q
M
S
AS 9100
THE STANDARDS INSTITUTION OF ISRAEL
TABLE OF CONTENTS
TABLE OF CONTENTS
ISOTURN TOOLS AND INSERTS 3
GROOVE-TURN 255
TOOLS FOR MINIATURE PARTS 361
BROACHING TOOLS 439
PARTING 459
FACE GROOVING 549
THREADING TOOLS & INSERTS 635
NON-ROTATING TOOL HOLDERS 729
MATERIALS 783
INDEX 816
Learn More...
Download
ISCAR WORLD App
Find The NEOFind The NEOLOGIQLOGIQAL Tool AL Tool
For Your Application!For Your Application!
• The virtual tool advisor features advanced AI
and ‘Big Data’ analytics
• Supports with complicated machining tasks and challenges
• Offers a wide range of functions and recommendations
to operate machining centers
• Features online service 24/7 in more than 30 languages
• Functions according to ISO 13399
www.iscar.com
Play Store App Store
ISOTURN
Tools and Inserts
ISCAR
4
ISOTURN TOOLS
ISOTURN Tools .................................................................................................... 5
Tool Identification System ...................................................................................... 6
External Tools ......................................................................................................... 8
Jet High-Pressure Tools ........................................................................................ 78
Tools for Ceramic Inserts ...................................................................................... 88
Boring Bars ......................................................................................................... 91
ISOTURN Inserts ............................................................................................. 121
Insert Identification System ................................................................................. 122
Selection Guide for Chipformers and Grades ..................................................... 124
Negative Inserts .................................................................................................. 135
Positive Inserts ................................................................................................... 183
Inserts for Machining Aluminum .......................................................................... 209
Pipe Skiving Inserts ............................................................................................ 215
CBN, PCD and Ceramic Inserts ......................................................................... 216
ISOTURN User Guide ...................................................................................... 236
Cutting Speed Recommendations ...................................................................... 246
Turning Grades Chart ......................................................................................... 248
TABLE OF CONTENTS
5
ISOTURN TOOLS
ISOTURN TOOLS
ISCAR
6
USER GUIDE
ISOTURN TOOLS
Toolholder Identification System
Toolholder
MW L N R 25 25 M -08 W
4 5 6 7 8 9 10 3 11 12
Boring Bar
S 25 S M W L N R -08 W
1 2 3 4 5 6 7 8 11 12
1 Boring Bar
SSteel Shank
ACoolant Through Steel Shank
CSolid Carbide Shank
ECoolant Through Carbide Shank
2 Bar Diameter
d
3 Tool Length
I1
I1
A = 32 H = 100 Q = 180
B = 40 J = 110 R = 200
C = 50 K = 125 S = 250
D = 60 L = 140 T = 300
E = 70 M = 150 U = 350
F = 80 N = 160 V = 400
G = 90 P = 170 W = 450
Y = 500
X = Special
4 Clamping System
C P
Top Clamp Iscadex Lever Lock
S M...W
SC-Screw Clamping Top Wedge Lock
D
Rigid Clamp
5 Insert Shape
W
80˚
V
35˚
C
80˚
D
55˚
T
60˚
S
R K
55˚
L
L
Q
80˚
6 Approach Angle
A
90°
B
75°
D
45°
E
60°
F
90°
G
91°
J
93°
K
75°
L
95°
95°
N
62.5°
Q
107.5˚
R
75°
S
45°
U
93°
V
72.5°
X
Special
7
USER GUIDE
ISOTURN TOOLS
7 Insert Clearance Angle
N
0º
B
5º
C
7º
P
11º
O
Other
D
15º
8 Hand of Tool
R
R
N
N
L
L
9 Shank Height
H
10 Shank Width
b
11 Insert Size
Cutting edge length
ll
l
l
l
TR
CD
EV
W
S
12 Wedge Lock
W-Top wedge MW-Multi-wedge
S- for Swiss-type machines
Axial Ga and Radial Gr Rake angles
Toolholder Boring Bar
Gr
(GAMF)
-
+
-
+
Ga
(GAMP)
-
+
-
+
Gr
(GAMF)
Ga
(GAMP)
ISCAR
8
ISOTURN TOOLS
95°
WF
HF
LH
LF
H
B
Right-hand shown
95°
95°
Designation
H HF B LF LH WF Insert
PWLNR/L 1010X-04S
10.0 10.0 10.0 120.00 11.0 10.00 WNGP 04 SR 10400611 HW 2.0/5 SL LV-2 SL PI-2 PIN
PWLNR/L 1212F-04S
12.0 12.0 12.0 85.00 11.0 12.00 WNGP 04 SR 10400611 HW 2.0/5 SL LV-2 SL PI-2 PIN
PWLNR/L 1212X-04S
12.0 12.0 12.0 120.00 11.0 12.00 WNGP 04 SR 10400611 HW 2.0/5 SL LV-2 SL PI-2 PIN
PWLNR/L 1616X-04S
16.0 16.0 16.0 120.00 13.0 16.00 WNGP 04 SR 10400611 HW 2.0/5 SL LV-2 SL PI-2 PIN
• Use a left-hand insert on a right-hand tool and vice versa.
For inserts, see pages: WNGP-F2M (137) • WNGP-F2P (135)
PWLNR/L-S
Lever Lock External Turning
Tools Carrying WNGP 0403..
Double-Sided Trigon Inserts
LF
PWLNR-S
WF
HF
LH
B
H
LF Right-hand shown
95°
95°
Designation
H HF B LF LH WF Insert
PWLNR/L 1616H-06
16.0 16.0 16.0 100.00 16.0 20.00 WN..06T3
PWLNR/L 1616H-06S (1)
16.0 16.0 16.0 100.00 20.3 16.00 WN..06T3
PWLNR/L 2020K-06
20.0 20.0 20.0 125.00 20.0 25.00 WN..06T3
PWLNR/L 2525M-06
25.0 25.0 25.0 150.00 20.0 32.00 WN..06T3
PWLNR/L 2020K-08
20.0 20.0 20.0 125.00 19.0 25.00 WN..0804
PWLNR/L 2525M-08
25.0 25.0 25.0 150.00 20.5 32.00 WN..0804
PWLNR/L 3232P-08
32.0 32.0 32.0 170.00 19.0 40.00 WN..0804
(1) Can be used on automatics
For inserts, see pages: WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137) • WNMG-M3M (138) • WNMG-TF (141)
• WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-SF (138) • WNMG-NF (139) • WNMM-NM (142)
• WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224)
• WNMG-CERMET (136)
Spare Parts
Designation
PWLNR/L 1616H-06
TWN 322 SP 3 PN 3-4 HW 2.5/5 SR 117-2014 LR 3
PWLNR/L 1616H-06S
TWN 322 SP 3 PN 3-4 HW 2.5/5 SR 117-2014 LR 3
PWLNR/L 2020K-06
TWN 322 SP 3 PN 3-4 HW 2.5/5 SR 117-2014 LR 3
PWLNR/L 2525M-06
TWN 322 SP 3 PN 3-4 HW 2.5/5 SR 117-2014 LR 3
PWLNR/L 2020K-08
TWN 423 SP 4 PN 3-4 HW 3.0 SR 117-2010 LR 4
PWLNR/L 2525M-08
TWN 423 SP 4 PN 3-4 HW 3.0 SR 117-2010 LR 4
PWLNR/L 3232P-08
TWN 423 SP 4 PN 3-4 HW 3.0 SR 117-2010 LR 4
PWLNR/L
Lever Lock External
Turning Tools Carrying 80°
Negative Trigon Inserts
Holder
WF
OAW
HF
GAMF
GAMP
LH
95˚ OAL (assembly)
95°
95°
Bar Max
Designation
WF HF LH OAL OAW GAMP GAMF Insert
NQCH12-SWLNR/L-04S-JHP
12.15 12.0 20.0 120.00 20.15 11.0 1.0 WNGP.. 0403
NQCH16-SWLNR/L-04S-JHP
16.15 16.0 20.0 120.00 20.15 11.0 1.0 WNGP.. 0403
For user guide, see pages 6-7, 78-84
For holders, see pages: NQCH-JHP (61)
Spare Parts
Designation
NQCH-SWLNR/L-S-JHP
SR 34-514 T-7/5
NQCH-SWLNR/L-S-JHP
Screw Lock Modular Heads
with High-Pressure Coolant -
Positive Double-Sided Trigon
Inserts for SwissType Machines
9
ISOTURN TOOLS
WF
LF
B
KAPR
LH
H
HF
G 1/8"-28
GAMF
Central coolant direction
4°
4° (8° rotation adjustment)
Frontal coolant
on/off screw
Frontal coolant hole
95°
95°
Bar Max
Designation
H HF B LF LH WF GAMF Insert
PWLNR/L 2525M-08-JHP
25.0 25.0 25.0 150.00 33.0 32.00 -6.0 WNMG 0804..
PWLNL 3232P-08-JHP
32.0 32.0 32.0 170.00 33.0 40.00 -6.0 WNMG 0804..
PWLNR 3232P-08-JHP
32.0 32.0 32.0 170.00 33.0 40.00 -6.0 WNMG 0804
• For user guide, see pages 78-84
For inserts, see pages: WNMG-CERMET (136) • WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137) • WNMG-M3M (138)
• WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-NF (139) • WNMM-NM (142)
• WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224)
Spare Parts
Designation
PWLNR/L 2525M-08-JHP
TWN 423 SP 4 PN 3-4 LR 4 SR 117-2010 SR M4X4 DIN913 TL360 CU-CW-JHP HW 2.0 HW 3.0 T-8/5
PWLNR/L 3232P-08-JHP
TWN 423 SP 4 PN 3-4 LR 4 SR 117-2010 SR M4X4 DIN913 TL360 OR 6.4X0.9N CU-CW-JHP HW 2.0 HW 3.0 T-8/5
PWLNR/L-08-JHP
Lever Lock Tools with Channels
for High-Pressure Coolant
Carrying Trigon Inserts
GAMF
WF
ECA
DCONMS
L3
LF
Central coolant direction
4°
4° (8° rotation adjustment)
Right-hand shown
95°
95°
Bar Max
Designation
DCONMS WF OHN(1) L3 ECA GAMF Insert CDI(2) CP(3)
C6 PWLNR/L-45065-08-JHP
63.00 45.00 65.00 37.00 55.0 -6.0 WNMG 08.. 1 300
• For user guide, see pages 78-84
(1) Minimum overhang
(2) 1 - Hole for data chip, 0 - Without hole for data chip
(3) Coolant pressure (Bar)
For inserts, see pages: WNGG-F3N (209) • WNMG-CERMET (136) • WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137)
• WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-SF (138)
• WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216) • WNGA-M3 (CBN) (224)
• WNGA-MC/M6 (CBN) (224)
Spare Parts
Designation
C#-PWLNR/L-08-JHP
TWN 423 SP 4 LR 4 SR 117-2010 T-8/5 PN 3-4 CU-CW-JHP OR 6.4X0.9N HW 3.0 LR 4DHTL (MR INJ)*
* Optional, should be ordered separately
C#-PWLNR/L-08-JHP
Lever Lock Tools with CAMFIX
Exchangeable Shanks and
Channels for High-Pressure
Coolant Carrying Trigon Inserts
ISCAR
10
ISOTURN TOOLS
LH
HF
WF
LF
B
H
Right-hand shown
95°
95°
Designation
H HF B LF LH WF Insert
DWLNR/L 1616H-06
16.0 16.0 16.0 100.00 26.0 16.00 WNMG 0604
DWLNR/L 2020K-06
20.0 20.0 20.0 125.00 26.0 25.00 WNMG 0604
DWLNR/L 2525M-06
25.0 25.0 25.0 150.00 24.0 32.00 WNMG 0604
DWLNR/L 2020K-08
20.0 20.0 20.0 125.00 35.0 25.00 WNMG 0804
DWLNR/L 2525M-08
25.0 25.0 25.0 150.00 35.0 32.00 WNMG 0804
DWLNR/L 3232P-08
32.0 32.0 32.0 170.00 35.0 40.00 WNMG 0804
For inserts, see pages: WNMG-F3S (138) • WNMX-M3/4MW (143) • WNMX-M3/4PW (143) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-CERMET (136)
• WNGG-F3N (209) • WNMG-F3M (137) • WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-VL (139)
• WNMG-TNM (142) • WNMG-SF (138) • WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216)
• WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224)
Spare Parts
Designation
DWLNR/L 1616H-06
RWT 322 RWT 3-2(b)*SR 40090I LCGR-3 SR RC3 KSP 3 HW 2.5
DWLNR/L 2020K-06
RWT 322 RWT 3-2(b)*SR 40090I LCGR-3 SR RC3 KSP 3 HW 2.5
DWLNR/L 2525M-06
RWT 322 RWT 3-2(b)*SR 40090I LCGR-3 SR RC3 KSP 3 HW 2.5
DWLNR/L 2020K-08
RWT 443 RWT 443-TNM(a)*TWH 4(c)*SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DWLNR/L 2525M-08
RWT 443 RWT 443-TNM(a)*TWH 4(c)*SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DWLNR/L 3232P-08
RWT 443 RWT 443-TNM(a)*TWH 4(c)*SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
* Optional, should be ordered separately
(a) RWT 3-2 seat, for WNMG 06T3 insert
(b) RWT 443-TNM seat, for WNMG 0804...-TNM insert
(c) TWH 4 seat, for WNMX 0807... insert
DWLNR/L
External 95° Lead Tools Carrying
Negative WNMG Trigon Inserts
GAMP
GAMF
B
H
WF
HF
LF
LH
95˚
95°
95°
Bar Max
Designation
B H HF LF LH WF GAMP GAMF MIID(1)
DWLNR/L 2020X-08-JHP-MC
20.0 20.0 20.0 106.00 36.0 25.00 6.0 6.0 WNMG 0804
DWLNR/L 2525X-08-JHP-MC
25.0 25.0 25.0 121.00 36.0 32.00 6.0 6.0 WNMG 0804
(1) Master insert identification
For inserts, see pages: WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224) • WNMA/WNMA-WG (143) • WNMG-CERMET (136)
• WNMG-F3M (137) • WNMG-F3P (135) • WNMG-F3S (138) • WNMG-GN (141) • WNMG-M3M (138) • WNMG-M3P (135) • WNMG-NF (139) • WNMG-NR (142)
• WNMG-PP (140) • WNMG-TF (141) • WNMG-TNM (142) • WNMG-VL (139) • WNMG-WF (140) • WNMG-WG (139) • WNMM-NM (142) • WNMX-M3/4MW (143)
• WNMX-M3/4PW (143)
Spare Parts
Designation
DWLNR/L-JHP-MC
RWT 443 TWH 4* RWT 443-TNM* LCGR/L-4JC SET(a) SR 14-506 PLG G1/8 TL360 OR 4X3 NBR70
* Optional, should be ordered separately
(a) Recommended tightening torque 4Nm for R-Clamp Screw
DWLNR/L-JHP-MC
Rigid Clamp Tools with Channels
for High-Pressure Coolant
Carrying 80° Trigon Inserts
11
ISOTURN TOOLS
WF
HF
LH
B
H
LF Right-hand shown
95°
95°
Designation
H HF B LF LH WF Insert
PWLNR/L 2020K-06X (1)
20.0 20.0 20.0 125.00 25.0 25.00 WNMX 0606, WNMG 0604
PWLNR/L 2525M-06X (1)
25.0 25.0 25.0 150.00 25.0 32.00 WNMX 0606, WNMG 0604
PWLNR/L 2020K-08X (2)
20.0 20.0 20.0 125.00 30.0 25.00 WNMX 0807, WNMG 0804
PWLNR/L 2525M-08X (2)
25.0 25.0 25.0 150.00 30.0 32.00 WNMX 0807, WNMG 0804
PWLNR 3232P-08X (2)
32.0 32.0 32.0 170.00 30.0 40.00 WNMX 0807, WNMG 0804
(1) Supplied with TWX 3 seat for WNMX 0606.. inserts and TWN 3 seat for WNMG 0604.. inserts.
(2) Supplied with TWX 4 seat for WNMX 0807.. inserts and TWN 443 seat for WNMG 0804.. inserts.
For inserts, see pages: WNGG-F3N (209) • WNMG-CERMET (136) • WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMX-M3/4PW (143)
• WNMG-F3M (137) • WNMG-M3M (138) • WNMX-M3/4MW (143) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-VL (139)
• WNMG-TNM (142) • WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216)
• WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224)
TWN 3
TWN 443
WNMG 0604...
WNMG 0804... TWX 3
TWX 4
WNMX 0606...
WNMX 0807...
Spare Parts
Designation
PWLNR/L 2020K-06X
TWX 3 TWN 3 SP 3 LR 3 SR 117-2014 HW 2.5/5 PN 3-4
PWLNR/L 2525M-06X
TWX 3 TWN 3 SP 3 LR 3 SR 117-2014 HW 2.5 PN 3-4
PWLNR/L 2020K-08X
TWX 4 TWN 443 SP 4 LR 4DH SR 117-2010 HW 3.0 PN 3-4L LR 4DHTL (MR INJ)*
PWLNR/L 2525M-08X
TWX 4 TWN 443 SP 4 LR 4DH SR 117-2010 HW 3.0 PN 3-4L LR 4DHTL (MR INJ)*
PWLNR 3232P-08X
TWX 4 TWN 443 SP 4 LR 4DH SR 117-2010 HW 3.0 PN 3-4L LR 4DHTL (MR INJ)*
* Optional, should be ordered separately
PWLNR/L-X
Lever Lock External Turning
Tools Carrying HELITURN LD
WNMX or WNMG Trigon Inserts
ISCAR
12
ISOTURN TOOLS
LH
WF
LF
B
H
HF
G 1/8"-28
Central coolant direction
4°
4° (8° rotation adjustment)
KAPR
GAMF
Frontal coolant
on/off screw
Frontal
coolant hole
Internal coolant for
PWLNR/L... 06X
95°
95°
Bar Max
Designation
H HF B LF LH WF GAMF KAPR(3) Insert
PWLNR/L 2020K-06X-JHP (1)
20.0 20.0 20.0 125.00 25.0 25.00 -6.0 95.0 WNMX 0606, WNMG 0604
PWLNR/L 2525M-06X-JHP (1)
25.0 25.0 25.0 150.00 25.0 32.00 -6.0 95.0 WNMX 0606, WNMG 0604
PWLNR/L 2525M-08X-JHP (2)
25.0 25.0 25.0 150.00 33.0 32.00 -6.0 95.0 WNMX 0807, WNMG 0804
PWLNR/L 3232P-08X-JHP (2)
32.0 32.0 32.0 170.00 33.0 40.00 -6.0 95.0 WNMX 0807, WNMG 0804
• For user guide, see pages 78-84
(1) Supplied with TWX 3 seat for WNMX 0606.. inserts and TWN 3 seat for WNMG 0604.. inserts.
(2) Supplied with TWX 4 seat for WNMX 0807.. inserts and TWN 443 seat for WNMG 0804.. inserts.
(3) Tool cutting edge angle
For inserts, see pages: WNGG-F3N (209) • WNMG-CERMET (136) • WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMX-M3/4PW (143)
• WNMG-F3M (137) • WNMG-M3M (138) • WNMX-M3/4MW (143) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-VL (139)
• WNMG-TNM (142) • WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216)
• WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224)
Screw
Housing: UNH-JHP
Nozzle: NZ-CW-JHP
CU-CW-JHP
Screw: SR M3
O-Ring: OR 6.4x0.9N
Screw: M3
TWN 3
TWN 443
WNMG 0604...
WNMG 0804... TWX 3
TWX 4
WNMX 0606...
WNMX 0807...
Spare Parts
Designation
PWLNR/L 2020K-06X-JHP
TWX 3 TWN 3 SP 3 LR 3 SR 117-2014 PN 3-4 HW 2.5/5
PWLNR/L 2525M-06X-JHP
TWX 3 TWN 3 SP 3 LR 3 SR 117-2014 PN 3-4 HW 2.5/5
PWLNR/L 2525M-08X-JHP
TWX 4 TWN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L CU-CW-JHP T-8/5 LR 4DHTL (MR INJ)* HW 2.0 HW 3.0 SR M4X4 DIN913 TL360
PWLNR/L 3232P-08X-JHP
TWX 4 TWN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L CU-CW-JHP T-8/5 LR 4DHTL (MR INJ)* HW 2.0 HW 3.0 SR M4X4 DIN913 TL360
* Optional, should be ordered separately
PWLNR/L-X-JHP
Lever Lock Tools with Channels
for High-Pressure Coolant
Carrying HELITURN LD WNMX
or WNMG Trigon Inserts
13
ISOTURN TOOLS
LH L5
WF
LF
B
H
HF
Central coolant direction
4°
4° (8° rotation adjustment)
95° Frontal coolant
on/off screw
Frontal
coolant hole
95°
95°
Bar Max
Designation
H HF B LF LH L5 WF Insert
PWLNR/L 2020X-06X-JHP-MC
20.0 20.0 20.0 97.00 27.0 29.00 25.00 WNMX 0606, WNMG 0604
PWLNR/L 2525X-06X-JHP-MC
25.0 25.0 25.0 118.00 33.0 35.00 32.00 WNMX 0606, WNMG 0604
PWLNR/L 2020X-08X-JHP-MC
20.0 20.0 20.0 97.00 27.0 29.00 25.00 WNMX 0807, WNMG 0804
PWLNR/L 2525X-08X-JHP-MC
25.0 25.0 25.0 118.00 33.0 35.00 32.00 WNMX 0807, WNMG 0804
• For user guide, see pages 78-84
For inserts, see pages: WNGG-F3N (209) • WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMX-M3/4PW (143) • WNMG-F3M (137)
• WNMG-M3M (138) • WNMX-M3/4MW (143) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-TNM (142) • WNMG-NF (139)
• WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224)
Spare Parts
Designation
PWLNR/L 2020X-06X-JHP-MC
TWX 3 TWN 3 SP 3 LR 3 SR 117-2014 PN 3-4 HW 2.5 CU-CW-JHP T-8/5 SR M5X5 DIN913 TL360
PWLNR/L 2525X-06X-JHP-MC
TWX 3 TWN 3 SP 3 LR 3 SR 117-2014 PN 3-4 HW 2.5 CU-CW-JHP T-8/5 SR M5X5 DIN913 TL360
PWLNR/L 2020X-08X-JHP-MC
TWX 4 TWN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L HW 2.5 CU-CW-JHP T-8/5 SR M5X5 DIN913 TL360 HW 3.0 LR 4DHTL (MR INJ)*
PWLNR/L 2525X-08X-JHP-MC
TWX 4 TWN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L HW 2.5 CU-CW-JHP T-8/5 SR M5X5 DIN913 TL360 HW 3.0 LR 4DHTL (MR INJ)*
* Optional, should be ordered separately
PWLNR/L-X-JHP-MC
Lever Lock Tools with Bottom
Inlets for High-Pressure Coolant
Channels Carrying HELITURN LD
WNMX and WNMG Trigon Inserts
GAMF
20
95°
ECA
DCONMS
LF
WF
Right-hand shown
95°
95°
70
Bar Max
Designation
DCONMS WF OHN(3) ECA GAMF Insert CDI(4) CP(5)
C4 PWLNR/L-27050-06X (1)
40.00 27.00 50.00 45.0 6.0 WNMX 0606, WNMG 0604 1 70
C5 PWLNL-25060-06X (1)
50.00 25.00 60.00 48.0 6.0 WNMX 0606, WNMG 0604 1 70
C4 PWLNR/L-27050-08X (2)
40.00 27.00 50.00 45.0 6.0 WNMX 0807, WNMG 0804 1 70
C5 PWLNR/L-35060-08X (2)
50.00 35.00 60.00 48.0 6.0 WNMX 0807, WNMG 0804 1 70
(1) Supplied with TWX 3 seat for WNMX 0606.. inserts and TWN 3 seat for WNMG 0604.. inserts.
(2) Supplied with TWX 4 seat for WNMX 0807.. inserts and TWN 443 seat for WNMG 0804.. inserts.
(3) Minimum overhang
(4) 1 - Hole for data chip, 0 - Without hole for data chip
(5) Coolant pressure (Bar)
For inserts, see pages: WNGG-F3N (209) • WNMG-F3S (138) • WNMX-M3/4MW (143) • WNMX-M3/4PW (143) • WNMG-F3P (135) • WNMG-M3P (135)
• WNMG-F3M (137) • WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-PP (140) • WNMG-NF (139) • WNMG-WF (140) • WNMA/WNMA-WG (143)
• WNMG-WG (139)
Spare Parts
Designation
C4 PWLNL-27050-06X
TWX 3 TWN 3 SP 3 LR 3 SR 117-2014 PN 3-4 EZ 62 HW 2.5/5
C4 PWLNR-27050-06X
TWX 3 TWN 3 SP 3 LR 3 SR 117-2014 PN 3-4 EZ 62 HW 2.5/5
C5 PWLNL-25060-06X
TWX 3 TWN 3 SP 3 LR 3 SR 117-2014 PN 3-4 EZ 83 HW 2.5/5
C4 PWLNL-27050-08X
TWX 4 TWN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L EZ 62 HW 3.0 LR 4DHTL (MR INJ)*
C4 PWLNR-27050-08X
TWX 4 TWN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L EZ 62 HW 3.0 LR 4DHTL (MR INJ)*
C5 PWLNL-35060-08X
TWX 4 TWN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L EZ 83 HW 3.0 LR 4DHTL (MR INJ)*
C5 PWLNR-35060-08X
TWX 4 TWN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L EZ 83 HW 3.0 LR 4DHTL (MR INJ)*
* Optional, should be ordered separately
C#-PWLNR/L-X
Lever Lock Tools with CAMFIX
Shanks Carrying HELITURN
LD WNMX or WNMG Inserts
ISCAR
14
ISOTURN TOOLS
GAMF
WF
DCONMS
L3
LF
Central coolant direction
4°
4° (8° rotation adjustment)
95°
95°
Bar Max
Designation
DCONMS LF WF L3 GAMF Insert CDI(3)
C3 PWLNR-22045-06X-JHP (1)
32.00 45.00 22.00 26.00 -6.0 WNMX 0606, WNMG 0604 0
C3 PWLNR-22045-08X-JHP (2)
32.00 45.00 22.00 22.00 -6.0 WNMX 0807, WNMG 0804 0
C4 PWLNR/L-27050-08X-JHP (2)
40.00 50.00 27.00 22.00 -6.0 WNMX 0807, WNMG 0804 1
C5 PWLNR/L-35060-08X-JHP (2)
50.00 60.00 35.00 25.00 -6.0 WNMX 0807, WNMG 0804 1
C6 PWLNR/L-45065-08X-JHP (2)
63.00 65.00 45.00 37.00 -6.0 WNMX 0807, WNMG 0804 1
• For user guide, see pages 78-84
(1) Supplied with TWX 3 seat for WNMX 0606.. inserts and TWN 3 seat for WNMG 0604.. inserts.
(2) Supplied with TWX 4 seat for WNMX 0807.. inserts and TWN 443 seat for WNMG 0804.. inserts.
(3) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: WNMG-F3S (138) • WNMX-M3/4MW (143) • WNMX-M3/4PW (143) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137)
• WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-PP (140) • WNMG-NF (139) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139)
TWN 3
TWN 443
WNMG 0604...
WNMG 0804...
TWX 3
TWX 4
WNMX 0606...
WNMX 0807...
Spare Parts
Designation
C3 PWLNR-22045-06X-JHP
TWX 3 TWN 3 SP 3 PN 3-4 LR 3 SR 117-2014 CU-CW-JHP T-8/5 HW 2.5
C3 PWLNR-22045-08X-JHP
TWX 4 TWN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
C4 PWLNL-27050-08X-JHP
TWX 4 TWN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
C4 PWLNR-27050-08X-JHP
TWX 4 TWN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
C5 PWLNL-35060-08X-JHP
TWX 4 TWN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
C5 PWLNR-35060-08X-JHP
TWX 4 TWN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
C6 PWLNL-45065-08X-JHP
TWX 4 TWN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
C6 PWLNR-45065-08X-JHP
TWX 4 TWN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
* Optional, should be ordered separately
C#-PWLNR/L-X-JHP
Lever Lock Tools with CAMFIX
Shanks and Channels for High-
Pressure Coolant, Carrying
WNMX or WNMG Inserts
15
ISOTURN TOOLS
HF
WF
LF
LH
H
B
Right-hand shown
95º
95º
95°
95°
75°
Designation
H HF B LF LH WF
MULNR/L 2525M-12MW
25.0 25.0 25.0 150.00 35.0 32.00
• The wedge for the WNMG insert is supplied with the holder, order the others separately
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-CERMET (145) • CNMG-F3S (147) • SNMG-F3S (175) • WNMG-CERMET (136)
• WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137) • WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142)
• WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139)
• WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224) • CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMM-M4PW (152)
• CNMG-F3M (146) • CNMG-M3M (146) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147)
• CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216)
• CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225)
• CNMA (PCD) (221) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174) • SNMG-TF (176) • SNMG-GN (177)
• SNMG-NR (177) • SNMG-PP (175) • SNMG-VL (175) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
MULNR/L ##-4MW
MULNR/L ##-12MW
SR 17-307
DK 17-307
SPR 17-307
ZNW-4CM
TCN 423
LC WN08
(WNM_08_43)
LCR CN12 / LCL CN12
(CNM_12_43)
LCR SN12 / LCL SN12
(SNM_12_43)
SNMG
CNMG
WNMG
Toolholder Options
Spare Parts
Designation
MULNR/L 2525M-12MW
TCN 423 ZNW 4CM LC WN08 LCR/L CN12* LCR/L SN12* SR 17-307 SR M4X8 HW 3.0 DK 17-307 SPR 17-307
* Optional, should be ordered separately
MULNR/L-12MW
MULTI-WEDGE Lock
External Tools Carrying
80° Negative Rhombic or
Trigon or Square Inserts
ISCAR
16
ISOTURN TOOLS
GAMF
DCONMS
WF
LF Right-hand shown
95°
95°
75º
95º
95º
70
Bar Max
Designation
DCONMS WF LF GAMF Insert CDI(1)
C4 MULNR/L 27050-12MW
40.00 27.00 50.00 6.0 W/C/SNMG 1204.. 1
C5 MULNR/L 35060-12MW
50.00 35.00 60.00 6.0 W/C/SNMG 1204.. 1
C6 MULNR/L-45065-12MW
63.00 45.00 65.00 6.0 W/C/SNMG 1204.. 1
• R.H. wedge for R.H. tool, L.H. wedge for L.H. tool
(1) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-CERMET (145) • CNMG-F3S (147) • SNMG-F3S (175) • WNMG-CERMET (136)
• WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137) • WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142)
• WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139)
• WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224) • CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMM-M4PW (152)
• CNMG-F3M (146) • CNMG-M3M (146) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147)
• CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216)
• CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
• SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174) • SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177)
• SNMG-PP (175) • SNMG-VL (175) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
Spare Parts
Designation
C4 MULNL 27050-12MW
TCN 423 ZNW 4CMI LC WN08 HW 3.0 SR 17-307 DK 17-307 SPR 17-307 EZ 62
C4 MULNR 27050-12MW
TCN 423 ZNW 4CMI LC WN08 HW 3.0 SR 17-307 DK 17-307 SPR 17-307 EZ 62
C5 MULNL 35060-12MW
TCN 423 ZNW 4CMI LC WN08 HW 3.0 SR 17-307 DK 17-307 SPR 17-307 EZ 83
C5 MULNR 35060-12MW
TCN 423 ZNW 4CMI LC WN08 HW 3.0 SR 17-307 DK 17-307 SPR 17-307 EZ 83
C6 MULNL-45065-12MW
TCN 423 ZNW 4CMI LC WN08 HW 3.0 SR 17-307 DK 17-307 SPR 17-307 EZ 104
C6 MULNR-45065-12MW
TCN 423 ZNW 4CMI LC WN08 HW 3.0 SR 17-307 DK 17-307 SPR 17-307 EZ 104
C#-MULNR/L-MW
MULTI-WEDGE Tools with
CAMFIX Exchangeable Shanks
Carrying 80° Negative Rhombic
or Trigon or Square Inserts
GAMF
80°
WF DCONMS
LF Right-hand shown
95°
95°
75º
95º
95º
Designation
DCONMS LF WF GAMF Insert CDI(1)
HSK A63WH MULNR/L J12MW
63.00 110.00 25.00 -6.0 W/C/SNMG 1204 0
• Complies with ICTM standard (ISO 12164-3) • A cooling tube must be used with all coolant through HSK spindles (should be ordered separately)
• For shank dimensions, see page 735
(1) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-CERMET (145) • CNMG-F3S (147) • SNMG-F3S (175) • WNMG-CERMET (136)
• WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137) • WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142)
• WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139)
• WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224) • CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMM-M4PW (152)
• CNMG-F3M (146) • CNMG-M3M (146) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147)
• CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMA (149) • CNMG-Ceramic (216) • CNGA-2 (CBN) (226)
• CNGA-4 (CBN) (225) • CNGA-Ceramic (217) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
• SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174) • SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177)
• SNMG-PP (175) • SNMG-VL (175) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
Spare Parts
Designation
HSK A63WH-MULNR/L-MW
TCN 423 LCR/L CN12* LCR/L SN12* LC WN08 ZNW 4CM SR 17-307 HW 3.0 DK 17-307 SPR 17-307 SR M4X8 EZ 104
* Optional, should be ordered separately
HSK A63WH-MULNR/L-MW
MULTI-WEDGE Toolholders
with HSK Taper Shanks
for 80° Rhombic, Trigon
and Square Inserts
17
ISOTURN TOOLS
30°
Typ.x2
6°
DMIN
10°
95°DCONMS
LF
LF
WF
WF
WF
Right-hand shown
95°
95°
75º
95º
95º
Designation
DCONMS LF WF DMIN Insert CDI(1)
HSK A63WH-MULNR-J12MWX2
63.00 110.00 35.00 72.00 W/C/SNMG 1204 0
• Complies with ICTM standard (ISO 12164-3) • A cooling tube must be used with all coolant through HSK spindles (should be ordered separately).
• For shank dimensions, see page 735
(1) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-CERMET (145) • CNMG-F3S (147) • SNMG-F3S (175) • WNMG-CERMET (136)
• WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137) • WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142)
• WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139)
• WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224) • CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMM-M4PW (152)
• CNMG-F3M (146) • CNMG-M3M (146) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147)
• CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216)
• CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
• SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174) • SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177)
• SNMG-PP (175) • SNMG-VL (175) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
Spare Parts
Designation
HSK A63WH-MULNR-J12MWX2
TCN 423 LC WN08 LCR CN12* LCR SN12* ZNW 4CMI DK 17-307 SPR 17-307 SR 17-307 HW 3.0
* Optional, should be ordered separately
HSK A63WH-MULNR-
J12MWX2
MULTI-WEDGE Twin
Toolholders with HSK Taper
Shanks for 80° Rhombic,
Trigon and Square Inserts
7°
50°
DCONMS
LF Complies with ICTM standard (ISO 12164-3)
95º
95º
75º
95°
95°
Designation
DCONMS LF Insert CDI(1)
HSK A63WH MUMNN J12MW
63.00 110.00 W/C/SNMG 1204 0
• A cooling tube must be used with all coolant through HSK spindles (should be ordered separately). • For shank dimensions, see page 735
(1) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-CERMET (145) • CNMG-F3S (147) • SNMG-F3S (175) • WNMG-CERMET (136)
• WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137) • WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142)
• WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139)
• WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224) • CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMM-M4PW (152)
• CNMG-F3M (146) • CNMG-M3M (146) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147)
• CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216)
• CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225)
• CNMA (PCD) (221) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174) • SNMG-TF (176) • SNMG-GN (177)
• SNMG-NR (177) • SNMG-PP (175) • SNMG-VL (175) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
Spare Parts
Designation
HSK A63WH MUMNN J12MW
LC WN08 LCR CN12* LCR SN12* TCN 423 ZNW 4CM SR 17-307 HW 3.0 DK 17-307 SPR 17-307 EZ 83 SR M4X8
* Optional, should be ordered separately
HSK A63WH-MUMNN-MW
MULTI-WEDGE Tools with
HSK Exchangeable Shanks
Carrying 80° Negative Rhombic
or Trigon or Square Inserts
ISCAR
18
ISOTURN TOOLS
LH
HF
WF
LF
B
H
WF
MWLNR..-W MWLNR..-06SW Right-hand shown
95°
95°
Designation
H HF B LF LH WF Insert
MWLNR/L 1616H-06SW
16.0 16.0 16.0 100.00 23.0 16.00 WNMG 06T3
MWLNR/L 2020K-06W
20.0 20.0 20.0 125.00 25.0 25.00 WNMG 06T3
MWLNR/L 2525M-06W
25.0 25.0 25.0 150.00 25.0 32.00 WNMG 06T3
MWLNR/L 2020K-08W
20.0 20.0 20.0 125.00 30.0 25.00 WNMG 0804
MWLNR/L 2525M-08W
25.0 25.0 25.0 150.00 30.0 32.00 WNMG 0804
MWLNR/L 3232P-08W
32.0 32.0 32.0 170.00 35.0 40.00 WNMG 0804
For inserts, see pages: WNGG-F3N (209) • WNMG-CERMET (136) • WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137)
• WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-SF (138)
• WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216) • WNGA-M3 (CBN) (224)
• WNGA-MC/M6 (CBN) (224)
Spare Parts
Designation
MWLNR/L 1616H-06SW
IWSN 322W IWSN 3-2W(a)*ZNW 3W SR 14-564 LC 250 SET 1 HW 2.5
MWLNR/L 2020K-06W
IWSN 322W IWSN 3-2W(a)*ZNW 3W SR 14-564 LC 250 SET 1 HW 2.5
MWLNR/L 2525M-06W
IWSN 322W IWSN 3-2W(a)*ZNW 3W SR 14-564 LC 250 SET 1 HW 2.5
MWLNR/L 2020K-08W
IWSN 433 IWSN 433M(b)*ZNW 4W SR M4X8 LC 252 SET 1 HW 3.0
MWLNR/L 2525M-08W
IWSN 433 IWSN 433M(b)*ZNW 4W SR M4X8 LC 252 SET 1 HW 3.0
MWLNR/L 3232P-08W
IWSN 433 IWSN 433M(b)*ZNW 4W SR M4X8 LC 252 SET 1 HW 3.0
* Optional, should be ordered separately
(a) Use IWSN 3-2W optional seat for WNMG 0604.. inserts
(b) Use IWSN 433M optional seat for WNMG 0804..-TNM inserts
MWLNR/L-W
Top Wedge Lock External
Tools Carrying Trigon Inserts
WF
HF
LF
LH
B
H
Right-hand shown
95°
95°
Designation
H B HF LF LH WF Insert
MWLNR/L 3232P-13W
32.0 32.0 32.0 170.00 45.0 40.00 WNMG 1306
MWLNR/L 4040R-13W
40.0 40.0 40.0 200.00 45.0 50.00 WNMG 1306
For inserts, see pages: WNMA/WNMA-WG (143) • WNMG-TNM (142)
Spare Parts
Designation
MWLNR/L-13W
IWSN 635 ZNW 6W SR 14-570 LC 253 HW 4P SPR 17-362 SR 17-362 WA M8
MWLNR/L-13W
Top Wedge Lock External
Toolholders for Large
Trigon Inserts
GAMF GAMP
95˚
HF
WF
LH
LF
B
H
Right-hand shown
95°
95°
Designation
H HF B LF LH WF GAMP GAMF Insert
PWLOR/L 2525M-10-IQ
25.0 25.0 25.0 150.00 25.0 32.00 -6.0 -6.0 WOMG 1007-IQ
PWLOR/L 3232P-10-IQ
32.0 32.0 32.0 170.00 30.0 40.00 -6.0 -6.0 WOMG 1007-IQ
PWLOR/L 3232P-13-IQ
32.0 32.0 32.0 170.00 30.0 40.00 -6.5 -6.5 WOMG 1306-IQ
PWLOR/L 4040S-13-IQ
40.0 40.0 40.0 250.00 30.0 48.00 -6.5 -6.5 WOMG 1306-IQ
For inserts, see pages: WOMG-10-T3P-IQ (136) • WOMG-13-R3P-IQ (137)
Spare Parts
Designation
PWLOR/L 2525M-10-IQ
TWN 5-4-IQ SP D1.5-L10(a) SR LCS 5 LR 5 HW 3.0
PWLOR/L 3232P-10-IQ
TWN 5-4-IQ SP D1.5-L10(a) SR LCS 5 LR 5 HW 3.0
PWLOR/L 3232P-13-IQ
TWX 6-IQ SP 5(a) SR 10402352 LCL 20C-NX HW 4.0
PWLOR/L 4040S-13-IQ
TWX 6-IQ SP 5(a) SR 10402352 LCL 20C-NX HW 4.0
(a) Seat Pin
PWLOR/L-IQ
Lever Lock and Dovetail Pocket
Rigid Clamping Tools Carrying
Unique Double-Sided
Trigon Inserts
19
ISOTURN TOOLS
95°
GAMF
WF
DCONMS
LF Right-hand shown
95°
95°
Designation
DCONMS WF LF GAMF Insert
C6 PWLOR/L-45065-13-IQ
63.00 45.00 65.00 -6.5 WOMG 1306-IQ
For inserts, see pages: WOMG-13-R3P-IQ (137)
Spare Parts
Designation
C#-PWLOR/L-IQ
TWX 6-IQ LCL 20C-NX SR 10402352 HW 4.0 SP 5 SATZ-M10X1-M5
C#-PWLOR/L-IQ
Lever Lock and Dovetail Rigid
Clamping Pocket with CAMFIX
Shank Tools Carrying Unique
Double-Sided Trigon Inserts
18.5°
HF
WF
GAMF
LH
LF
B
H
GAMP
Right-hand shown
18°
Designation
H HF B LF LH WF GAMP GAMF Insert
PWXOR/L 2525M-10-TF-IQ
25.0 25.0 25.0 150.00 31.0 29.00 -6.0 -6.0 WOMG 1007-IQ TWN 5-4-IQ SP D1.5-L10(a) SR LCS 5 LR 5 HW 3.0
PWXOR/L 3232P-10-TF-IQ
32.0 32.0 32.0 170.00 31.0 36.00 -6.0 -6.0 WOMG 1007-IQ TWN 5-4-IQ SP D1.5-L10(a) SR LCS 5 LR 5 HW 3.0
PWXOR/L 4040S-10-TF-IQ
40.0 40.0 40.0 250.00 31.0 44.00 -6.0 -6.0 WOMG 1007-IQ TWN 5-4-IQ SP D1.5-L10(a) SR LCS 5 LR 5 HW 3.0
(a) Seat Pin
For inserts, see pages: WOMG-10-T3P-IQ (136)
Lever
Seat pin
Lever screw
Seat
PWXOR/L-TF-IQ
Lever Lock Tools for Fast
Feed Longitudinal Turning
ISCAR
20
ISOTURN TOOLS
LH
HF
WF
LF
H
B
Right-hand shown
95º
95º
Designation
H HF B LF LH WF Insert
PCLNR/L 2020K-12
20.0 20.0 20.0 125.00 27.5 25.00 CNMG 1204..
PCLNR/L 2525M-12
25.0 25.0 25.0 150.00 27.8 32.00 CNMG 1204..
PCLNR/L 3232P-12
32.0 32.0 32.0 170.00 27.6 40.00 CNMG 1204..
PCLNR/L 3232P-19
32.0 32.0 32.0 170.00 38.0 40.00 CNMG 1906..
PCLNR/L 4040S-25
40.0 40.0 40.0 250.00 47.0 50.00 CNMG 2509..
PCLNR 5050T-25
50.0 50.0 50.0 300.00 47.0 60.00 CNMG 2509..
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-F3S (147) • CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153)
• CNMM-M4PW (152) • CNMG-CERMET (145) • CNMG-F3M (146) • CNMG-M3M (146) • CNMG-R3M (147) • CNMG/CNGG-TF (150) • CNMG-GN (151)
• CNMG-NR (151) • CNMM-NR (154) • CNMG/CNGG-PP (150) • CNMG-VL (147) • CNMG-MR (151) • CNMG/CNGG-SF (148) • CNMG-NF (148)
• CNMG-WF (148) • CNMG-WG/NRW (149) • CNMS-12 (214) • CNMM-H3P (153) • CNMM-H4P (153) • CNMM-H5P (154) • CNMA (149) • CNGA-Ceramic (217)
• CNMG-Ceramic (216) • CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225)
• CNMA (PCD) (221)
Spare Parts
Designation
PCLNR/L 2020K-12
TCN 423 SP 4 LR 4 SR 117-2010 HW 3.0 PN 3-4
PCLNR/L 2525M-12
TCN 423 SP 4 LR 4 SR 117-2010 HW 3.0 PN 3-4
PCLNR/L 3232P-12
TCN 423 SP 4 LR 4 SR 117-2010 HW 3.0 PN 3-4
PCLNR/L 3232P-19
TCN 63 SP 66 LR 6 SR 10402352 HW 4.0
PCLNR/L 4040S-25
TCN 84N TCN 85N* SP 8 LR 8 SR 10402264
PCLNR 5050T-25
TCN 84N TCN 85N* SP 8 LR 8 SR 10402264
* Optional, should be ordered separately
PCLNR/L
Lever Lock Tools Carrying 80°
Negative Rhombic Inserts
21
ISOTURN TOOLS
GAMF
HF
G 1/8"-28
H
B
LF
LH
WF
Central coolant direction
(8° rotation adjustment)
4°
4°
Frontal coolant
on/off screw
Frontal coolant hole
95º
95º
Bar Max
Designation
H HF B LF LH WF GAMF Insert
PCLNR/L 2525M-12-JHP
25.0 25.0 25.0 150.00 33.0 32.00 -6.0 CNMG 1204
PCLNR/L 3232P-12-JHP
32.0 32.0 32.0 170.00 33.0 40.00 -6.0 CNMG 1204
• For user guide, see pages 78-84
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-CERMET (145) • CNMG-F3S (147) • CNMG-F3P (144) • CNMG-M3P (144)
• CNMM-R3P (153) • CNMM-M4PW (152) • CNMG-F3M (146) • CNMG-M3M (146) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151)
• CNMG/CNGG-PP (150) • CNMG-VL (147) • CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMS-12 (214)
• CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216) • CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226)
• CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
Spare Parts
Designation
PCLNR/L-12-JHP
TCN 423 SP 4 LR 4 SR 117-2010 PN 3-4 CU-CW-JHP SR M4X4 DIN913 TL360 HW 2.0 HW 3.0 T-8/5
PCLNR/L-12-JHP
Lever Lock Tools with
Channels for High-Pressure
Coolant Carrying 80°
Negative Rhombic Inserts
LH
HF
WF
LF
B
H
Right-hand shown
95º
95º
Designation
H HF B LF LH WF Insert
MCLNR 2525M-16
25.0 25.0 25.0 150.00 30.0 32.00 CNMG 1606..
MCLNR 3232P-16
32.0 32.0 32.0 170.00 30.0 40.00 CNMG 1606..
MCLNL 3232P-19
32.0 32.0 32.0 170.00 35.0 40.00 CNMG 1906..
For inserts, see pages: CNMG-M3P (144) • CNMM-R3P (153) • CNMG-M3M (146) • CNMG-R3M (147) • CNMG/CNGG-TF (150) • CNMG-GN (151)
• CNMG-NR (151) • CNMM-NR (154) • CNMG/CNGG-PP (150) • CNMG-MR (151) • CNMM-H3P (153) • CNMM-H4P (153) • CNMA (149)
Spare Parts
Designation
MCLNR 2525M-16
TCT 533 LC 30 SET 1 ZN 54M HW 3.0
MCLNR 3232P-16
TCT 533 LC 30 SET 1 ZN 54M HW 3.0
MCLNL 3232P-19
TCT 634 LC80 SET-1 ZN 64 HW 4.0
MCLNR/L
Pin and Clamp Tools Carrying
80° Negative Rhombic Inserts
ECA
95°
L3
GAMF
WF
DCONMS
LF
Central coolant direction
(8° rotation adjustment)
4°
4°
95º
95º
Bar Max
Designation
DCONMS WF LF L3 ECA GAMF Insert CDI(1) CP(2)
C6 PCLNR/L-45065-12-JHP
63.00 45.00 65.00 20.00 54.0 -6.0 CNMG 1204 1 300
• For user guide, see pages 78-84
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-CERMET (145) • CNMG-F3S (147) • CNMG-F3P (144) • CNMG-M3P (144)
• CNMM-R3P (153) • CNMM-M4PW (152) • CNMG-F3M (146) • CNMG-M3M (146) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151)
• CNMG/CNGG-PP (150) • CNMG-VL (147) • CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMS-12 (214)
• CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216) • CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226)
• CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
Spare Parts
Designation
C6 PCLNL-45065-12-JHP
TCN 423 SP 4 LR 4 SR 117-2010 PN 3-4 CU-CW-JHP HW 3.0 T-8/5
C6 PCLNR-45065-12-JHP
TCN 423 SP 4 LR 4 SR 117-2010 PN 3-4 CU-CW-JHP HW 3.0 T-8/5 SR M5X5 DIN913 TL360
C#-PCLNR/L-12-JHP
Lever Lock Tools with Channels
for High-Pressure Coolant and
CAMFIX Shanks Carrying 80°
Negative Rhombic Inserts
ISCAR
22
ISOTURN TOOLS
LH
HF
WF
LF
H
B
Right-hand shown
75º
Designation
H HF B LF LH WF Insert
PCBNR/L 2525M-12
25.0 25.0 25.0 150.00 27.7 22.00 CNMG 1204..
PCBNR/L 3232P-19
32.0 32.0 32.0 170.00 37.0 27.00 CNMG 1906..
PCBNR 4040S-19
40.0 40.0 40.0 250.00 37.0 37.00 CNMG 1906..
For inserts, see pages: CNMG-CERMET (145) • CNMG-F3S (147) • CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMM-M4PW (152)
• CNMG-F3M (146) • CNMG-M3M (146) • CNMG-R3M (147) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMM-NR (154) • CNMG/CNGG-PP (150)
• CNMG-VL (147) • CNMG-MR (151) • CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMS-12 (214)
• CNMM-H3P (153) • CNMM-H4P (153) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216)
Spare Parts
Designation
PCBNR/L 2525M-12
TCN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
PCBNR/L 3232P-19
TCN 63 SP 66 LR 6 SR 10402352 HW 4.0
PCBNR 4040S-19
TCN 63 SP 66 LR 6 SR 10402352 HW 4.0
PCBNR/L
Lever Lock Tools using the
100° Corner of CNMG Inserts
WF
HF
LH
B
H
LF Right-hand shown
95º
95º
Designation
B H LF LH WF Insert
PCLNR 1616H-09X
16.0 16.0 150.00 25.0 25.00 CNMX 0906 CNMG 0904
PCLNR/L 2020K-09X
20.0 20.0 125.00 25.0 25.00 CNMX 0906 CNMG 0904
PCLNR/L 2525M-09X
25.0 25.0 150.00 25.0 32.00 CNMX 0906 CNMG 0904
PCLNR/L 2020K-12X
20.0 20.0 125.00 31.0 25.00 CNMX 1207 CNMG 1204
PCLNR/L 2525M-12X
25.0 25.0 150.00 31.0 32.00 CNMX 1207 CNMG 1204
PCLNR/L 3232P-12X
32.0 32.0 170.00 32.0 40.00 CNMX 1207 CNMG 1204
PCLNR/L 3232P-16X
32.0 32.0 170.00 32.0 40.00 CNMX 1607 CNMG 1606
• Supplied with TCX 3 seat for CNMX 0906.. inserts and TCN 323 seat for CNMG 0904.. inserts, TCX 4 seat for CNMX 1207.. inserts and TCN 443 seat for CNMG 1204..
inserts, TCX 5 seat for CNMX 1607.. inserts and TCN 53 seat for CNMG 1606.. inserts.
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-F3N (209) • CNGG-J(CBN) (227) • CNGX-M3N (209) • CNMG-CERMET (145) • CNMG-F3S (147)
• CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMX-M3/4PW (152) • CNMM-M4PW (152) • CNMG-F3M (146) • CNMG-M3M (146)
• CNMG-R3M (147) • CNMX-M3/4MW (152) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147)
• CNMG-MR (151) • CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMS-12 (214) • CNMA (149) • CNGA-Ceramic (217)
• CNMG-Ceramic (216) • CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225)
• CNMA (PCD) (221)
CNMX 0906, CNMX 1207, CNMX 1607
TCX 3, TCX 4, TCX 5
CNMG 0904, CNMG 1204, CNMG 1606
TCN 323, TCN 443, TCN 53
Spare Parts
Designation
PCLNR/L 2020K-09X
TCX 3(a) TCN 323 SP 3 LR 3 SR 117-2014 HW 2.5 PN 3-4
PCLNR/L 2525M-09X
TCX 3(a) TCN 323 SP 3 LR 3 SR 117-2014 HW 2.5 PN 3-4
PCLNR/L 2020K-12X
TCX 4 TCN 443 SP 4 LR 4DH SR 117-2010 HW 3.0 PN 3-4L LR 4DHTL (MR INJ)*
PCLNR/L 2525M-12X
TCX 4 TCN 443 SP 4 LR 4DH SR 117-2010 HW 3.0 PN 3-4L LR 4DHTL (MR INJ)*
PCLNR/L 3232P-12X
TCX 4 TCN 443 SP 4 LR 4DH SR 117-2010 HW 3.0 PN 3-4L LR 4DHTL (MR INJ)*
PCLNR/L 3232P-16X
TCX 5 TCN 53 SP 5 LR 5 SR LCS 5 HW 3.0 SPP 5-6
* Optional, should be ordered separately
(a) For CNMX 0906.. (CNMX 34.) inserts
PCLNR/L-X
Lever Lock Tools Carrying CNMX/
CNMG 80° Rhombic Inserts
23
ISOTURN TOOLS
H
B
LF
LH
HF
G 1/8"-28
GAMF
WF
Central coolant direction
(8° rotation adjustment)
4°
4°
Frontal coolant
on/off screw
Frontal coolant
hole
PCLNR/L…-09X-JHP
95º
95º
Bar Max
Designation
B H HF LF LH WF GAMF Insert
PCLNR/L 1616H-09X-JHP
16.0 16.0 16.0 100.00 20.0 20.00 -6.0 CNMX 0906, CNMG 0904
PCLNR/L 2020K-09X-JHP
20.0 20.0 20.0 125.00 25.0 25.00 -6.0 CNMX 0906, CNMG 0904
PCLNR/L 2525M-09X-JHP
25.0 25.0 25.0 150.00 25.0 32.00 -6.0 CNMX 0906, CNMG 0904
PCLNR/L 2525M-12X-JHP
25.0 25.0 25.0 150.00 25.0 32.00 -6.0 CNMX 1207, CNMG 1204
PCLNR/L 3232P-12X-JHP
32.0 32.0 32.0 170.00 33.0 40.00 -6.0 CNMX 1207, CNMG 1204
• Supplied with TCX 3 seat for CNMX 0906.. inserts and TCN 323 seat for CNMG 0904.. inserts. TCX 4 seat for CNMX 1207..
inserts and TCN 443 seat for CNMG 1204.. inserts.
• For user guide, see pages 78-84
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNGX-M3N (209) • CNMG-F3S (147) • CNMG-F3P (144) • CNMG-M3P (144)
• CNMM-R3P (153) • CNMX-M3/4PW (152) • CNMM-M4PW (152) • CNGG-F3N (209) • CNMG-CERMET (145) • CNMG-F3M (146) • CNMG-M3M (146)
• CNMX-M3/4MW (152) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147) • CNMG/CNGG-SF (148)
• CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMS-12 (214) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216)
• CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
Spare Parts
Designation
PCLNR/L 1616H-09X-JHP
TCX 3(a) TCN 323(d) SP 3 LR 3 SR 117-2014 PN 3-4 HW 2.5
PCLNR/L 2020K-09X-JHP
TCX 3(a) TCN 323(d) SP 3 LR 3 SR 117-2014 PN 3-4 HW 2.5
PCLNR/L 2525M-09X-JHP
TCX 3(a) TCN 323(d) SP 3 LR 3 SR 117-2014 PN 3-4 HW 2.5
PCLNR/L 2525M-12X-JHP
TCX 4(b) TCN 443(c) SP 4 LR 4DH SR 117-2010 PN 3-4L CU-CW-JHP T-8/5 LR 4DHTL (MR INJ)* HW 2.0 HW 3.0 SR M4X4 DIN913 TL360
PCLNR/L 3232P-12X-JHP
TCX 4(b) TCN 443(c) SP 4 LR 4DH SR 117-2010 PN 3-4L CU-CW-JHP T-8/5 LR 4DHTL (MR INJ)* HW 2.0 HW 3.0 SR M4X4 DIN913 TL360
* Optional, should be ordered separately (a) For CNMX 0906.. (CNMX 34.) inserts (b) For CNMX 1207.. (CNMX 45.) inserts
(c) For CNMG 0904.. (CNMG 33.) inserts (d) For CNMG 1204.. (CNMG 43.) inserts
PCLNR/L-X-JHP
Lever Lock Tools with
Channels for High-Pressure
Coolant Carrying CNMX/
CNMG 80° Rhombic Inserts
H
B
LF
LH L5
HF
WF
Central coolant direction
(8° rotation adjustment)
4°
4°
Frontal coolant
on/off screw
Frontal coolant
hole
95º
95º
Bar Max
Designation
B H HF LF LH L5 WF Insert
PCLNR/L 2020X-09X-JHP-MC
20.0 20.0 20.0 97.00 27.0 29.00 25.00 CNMX 0906, CNMG 0904
PCLNR/L 2525X-09X-JHP-MC
25.0 25.0 25.0 118.00 33.0 35.00 32.00 CNMX 0906, CNMG 0904
PCLNR/L 2020X-12X-JHP-MC
20.0 20.0 20.0 97.00 27.0 29.00 25.00 CNMX 1207, CNMG 1204
PCLNR/L 2525X-12X-JHP-MC
25.0 25.0 25.0 118.00 33.0 35.00 32.00 CNMX 1207, CNMG 1204
• Supplied with TCX 3 seat for CNMX 0906.. inserts and TCN 323 seat for CNMG 0904.. inserts. TCX 4 seat for CNMX 1207..
inserts and TCN 443 seat for CNMG 1204.. inserts.
• For user guide, see pages 78-84
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-F3S (147) • CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153)
• CNMG-CERMET (145) • CNGG-F3N (209) • CNMX-M3/4PW (152) • CNMM-M4PW (152) • CNGX-M3N (209) • CNMG-F3M (146) • CNMG-M3M (146)
• CNMX-M3/4MW (152) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147) • CNMG/CNGG-SF (148)
• CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMS-12 (214) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216)
• CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
Spare Parts
Designation
PCLNR/L 2020X-09X-JHP-MC
TCX 3(a) TCN 323(c) SP 3 LR 3 SR 117-2014 PN 3-4 HW 2.5 CU-CW-JHP SR M5X5 DIN913 TL360 T-8/5
PCLNR/L 2525X-09X-JHP-MC
TCX 3(a) TCN 323(c) SP 3 LR 3 SR 117-2014 PN 3-4 HW 2.5 CU-CW-JHP SR M5X5 DIN913 TL360 T-8/5
PCLNR/L 2020X-12X-JHP-MC
TCX 4(a) TCN 443(d) SP 4 LR 4DH SR 117-2010 PN 3-4L HW 2.5 CU-CW-JHP SR M5X5 DIN913 TL360 HW 3.0 T-8/5 LR 4DHTL (MR INJ)*
PCLNR/L 2525X-12X-JHP-MC
TCX 4(a) TCN 443(d) SP 4 LR 4DH SR 117-2010 PN 3-4L HW 2.5 CU-CW-JHP SR M5X5 DIN913 TL360 HW 3.0 T-8/5 LR 4DHTL (MR INJ)*
* Optional, should be ordered separately (a) For CNMX 0906.. (CNMX 34.) inserts (b) For CNMX 1207.. (CNMX 45.) inserts
(c) For CNMG 0904.. (CNMG 33.) inserts (d) For CNMG 1204.. (CNMG 43.) inserts
PCLNR/L-X-JHP-MC
Lever Lock Tools with Bottom
Inlets for High-Pressure Coolant
Channels Carrying CNMX/CNMG
80° Rhombic Inserts
ISCAR
24
ISOTURN TOOLS
95°
ECA
L3
GAMF
WF
DCONMS
LF Right-hand shown
95º
95º
70
Bar Max
Designation
DCONMS WF LF GAMF L3 ECA Insert CDI(2) CP(3)
C4 PCLNR/L-27050-12X (1)
40.00 27.00 50.00 6.0 20.00 40.0 CNMX 1207, CNMG 1204 1 70
C5 PCLNR/L-35060-12X (1)
50.00 35.00 60.00 6.0 20.00 45.0 CNMX 1207, CNMG 1204 1 70
C6 PCLNR/L-45065-12X (1)
63.00 45.00 65.00 6.0 20.00 54.0 CNMX 1207, CNMG 1204 1 70
C4 PCLNR/L-27050-16X
40.00 27.00 50.00 6.0 21.00 40.0 CNMX 1607, CNMG 1606 1 70
C5 PCLNR/L-35060-16X
50.00 35.00 60.00 6.0 21.00 45.0 CNMX 1607, CNMG 1606 1 70
C6 PCLNR/L-45065-16X
63.00 45.00 65.00 6.0 21.00 54.0 CNMX 1607, CNMG 1606 1 70
(1) Supplied with TCX 4 seat for CNMX 1207.. inserts and TCN 443 seat for CNMG 1204.. inserts.
(2) 1 - Hole for data chip, 0 - Without hole for data chip
(3) Coolant pressure (Bar)
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-CERMET (145) • CNMG-F3S (147) • CNMX-M3/4PW (152) • CNMX-M3/4MW (152)
• CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMM-M4PW (152) • CNMG-F3M (146) • CNMG-M3M (146) • CNMG-R3M (147) • CNMG/CNGG-TF (150)
• CNMG-GN (151) • CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147) • CNMG-MR (151) • CNMG/CNGG-SF (148) • CNMG-NF (148)
• CNMG-WF (148) • CNMG-WG/NRW (149) • CNMS-12 (214) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216) • CNGA-2 (CBN) (226)
• CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
Spare Parts
Designation
C4 PCLNL-27050-12X
TCX 4 TCN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 HW 3.0 EZ 62 LR 4DHTL (MR INJ)*
C4 PCLNR-27050-12X
TCX 4 TCN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 HW 3.0 EZ 62 LR 4DHTL (MR INJ)*
C5 PCLNL-35060-12X
TCX 4 TCN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 HW 3.0 EZ 83 LR 4DHTL (MR INJ)*
C5 PCLNR-35060-12X
TCX 4 TCN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 HW 3.0 EZ 83 LR 4DHTL (MR INJ)*
C6 PCLNL-45065-12X
TCX 4 TCN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 HW 3.0 EZ 83 LR 4DHTL (MR INJ)*
C6 PCLNR-45065-12X
TCX 4 TCN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 HW 3.0 EZ 83 LR 4DHTL (MR INJ)*
C4 PCLNL-27050-16X
TCX 5 TCN 53 SP 5 LR 5 SR LCS 5 HW 3.0 EZ 104
C4 PCLNR-27050-16X
TCX 5 TCN 53 SP 5 LR 5 SR LCS 5 HW 3.0 EZ 104
C5 PCLNL-35060-16X
TCX 5 TCN 53 SP 5 SPP 5-6 LR 5 SR LCS 5 HW 3.0 EZ 125
C5 PCLNR-35060-16X
TCX 5 TCN 53 SP 5 LR 5 SR LCS 5 HW 3.0 EZ 125
C6 PCLNL-45065-16X
TCX 5 TCN 53 SP 5 SPP 5-6 LR 5 SR LCS 5 HW 3.0 EZ 125
C6 PCLNR-45065-16X
TCX 5 TCN 53 SP 5 SPP 5-6 LR 5 SR LCS 5 HW 3.0 EZ 125
* Optional, should be ordered separately
C#-PCLNR/L-X
Lever Lock Tools with
CAMFIX Exchangeable
Shanks Carrying CNMX and
CNMG Rhombic Inserts
95°
ECA
L3
GAMF
WF
DCONMS
LF
Central coolant direction
(8° rotation adjustment)
4°
4°
95º
95º
Bar Max
Designation
DCONMS WF LF L3 ECA GAMF Insert CDI(3) CP(4)
C3 PCLNR-22045-09X-JHP (1)
32.00 22.00 45.00 22.00 45.0 -6.0 CNMX 0906, CNMG 0904 0 300
C4 PCLNR/L-27050-09X-JHP (1)
40.00 27.00 50.00 24.00 45.0 -6.0 CNMX 0906, CNMG 0904 1 300
C5 PCLNR/L-35060-09X-JHP (1)
50.00 35.00 60.00 26.00 45.0 -6.0 CNMX 0906, CNMG 0904 1 300
C4 PCLNR/L-27050-12X-JHP (2)
40.00 27.00 50.00 18.00 54.0 -6.0 CNMX 1207, CNMG 1204 1 300
C5 PCLNR/L-35060-12X-JHP (2)
50.00 35.00 60.00 20.00 50.0 -6.0 CNMX 1207, CNMG 1204 1 300
C6 PCLNR/L-45065-12X-JHP (2)
63.00 45.00 65.00 20.00 54.0 -6.0 CNMX 1207, CNMG 1204 1 300
• For user guide, see pages 78-84
(1) Supplied with TCX 3 seat for CNMX 0906.. inserts and TCN 323 seat for CNMG 0904.. inserts.
(2) Supplied with TCX 4 seat for CNMX 1207.. inserts and TCN 443 seat for CNMG 1204.. inserts.
(3) 1 - Hole for data chip, 0 - Without hole for data chip
(4) Coolant pressure (Bar)
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-F3N (209) • CNGG-J(CBN) (227) • CNGX-M3N (209) • CNMG-CERMET (145) • CNMG-F3S (147)
• CNMX-M3/4MW (152) • CNMX-M3/4PW (152) • CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMM-M4PW (152) • CNMG-F3M (146)
• CNMG-M3M (146) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147) • CNMG/CNGG-SF (148)
• CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMS-12 (214) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216)
• CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
Spare Parts
Designation
C3 PCLNR-22045-09X-JHP
TCX 3(a) TCN 323 SP 3 LR 3 SR 117-2014 PN 3-4 CU-CW-JHP T-8/5 HW 2.5
C4 PCLNL-27050-09X-JHP
TCX 3(a) TCN 323 SP 3 LR 3 SR 117-2014 PN 3-4 CU-CW-JHP T-8/5 HW 2.5
C4 PCLNR-27050-09X-JHP
TCX 3(a) TCN 323 SP 3 LR 3 SR 117-2014 PN 3-4 CU-CW-JHP T-8/5 HW 2.5
C5 PCLNL-35060-09X-JHP
TCX 3(a) TCN 323 SP 3 LR 3 SR 117-2014 PN 3-4 CU-CW-JHP T-8/5 HW 2.5
C5 PCLNR-35060-09X-JHP
TCX 3(a) TCN 323 SP 3 LR 3 SR 117-2014 PN 3-4 CU-CW-JHP T-8/5 HW 2.5
C4 PCLNL-27050-12X-JHP
TCX 4 TCN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
C4 PCLNR-27050-12X-JHP
TCX 4 TCN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
C5 PCLNL-35060-12X-JHP
TCX 4 TCN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
C5 PCLNR-35060-12X-JHP
TCX 4 TCN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
C6 PCLNL-45065-12X-JHP
TCX 4 TCN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
C6 PCLNR-45065-12X-JHP
TCX 4 TCN 443 SP 4 LR 4DH SR 117-2010 PN 3-4L CU-CW-JHP LR 4DHTL (MR INJ)* T-8/5 HW 3.0
* Optional, should be ordered separately
(a) For CNMX 0906.. (CNMX 34.) inserts
C#-PCLNR/L-X-JHP
Lever Lock Tools with CAMFIX
Shanks and Channels for
High-Pressure Coolant Carrying
CNMX or CNMG Inserts
25
ISOTURN TOOLS
LH
HF
LF
H
B
WF
Right-hand shown
95º
95º
Designation
H HF B LF LH WF Insert
DCLNR/L-2020K-09X (1)
20.0 20.0 20.0 125.00 25.0 25.00 CNMG 0904 CNMX 0906
DCLNR/L-2525M-09X (1)
25.0 25.0 25.0 150.00 25.0 32.00 CNMG 0904 CNMX 0906
DCLNR/L 2020K-12 (2)
20.0 20.0 20.0 125.00 35.0 25.00 CNMG 1204 CNMX 1207
DCLNR/L 2525M-12 (2)
25.0 25.0 25.0 150.00 35.0 32.00 CNMG 1204 CNMX 1207
DCLNR/L 3232P-12 (2)
32.0 32.0 32.0 170.00 35.0 40.00 CNMG 1204 CNMX 1207
DCLNR/L 2525M-16
25.0 25.0 25.0 150.00 36.0 32.00 CNMG 1606..
DCLNL 3232P-16
32.0 32.0 32.0 170.00 36.0 40.00 CNMG 1606..
DCLNR 3232P-16
32.0 32.0 32.0 170.00 33.0 40.00 CNMG 1606..
DCLNR/L 3232P-19
32.0 32.0 32.0 170.00 42.0 40.00 CNMG 1906..
DCLNR/L 4040S-19
40.0 40.0 40.0 250.00 42.0 50.00 CNMG 1906..
(1) Supplied with TCX 3 seat for CNMX 0906.. inserts and TCN 323 seat for CNMG 0904.. inserts.
(2) Use TCH 4 seat (optional) for CNMX 1207... insert.
For inserts, see pages: CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMM-M4PW (152) • CNMX-M3/4PW (152) • CNMG-F3M (146)
• CNMG-M3M (146) • CNMG-R3M (147) • CNMX-M3/4MW (152) • CNGG-F3N (209) • CNMG-CERMET (145) • CNGX-M3N (209) • CNMG/CNGG-TF (150)
• CNMG-GN (151) • CNMG-NR (151) • CNMM-NR (154) • CNMG/CNGG-PP (150) • CNMG-VL (147) • CNMG-MR (151) • CNMG/CNGG-SF (148)
• CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMM-H3P (153) • CNMM-H4P (153) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216)
• CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
• CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-F3S (147)
Spare Parts
Designation
DCLNR/L-2525M-09X
TCN 323 TCX 3(a) HW 2.5 SR RC3 LCGR-3 KSP 3 SP 3 PN 3-4
DCLNR/L 2020K-12
RCT 443 TCH 4(b)*SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DCLNR/L 2525M-12
RCT 443 TCH 4(b)*SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DCLNR/L 3232P-12
RCT 443 TCH 4(b)*SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DCLNR/L 2525M-16
RCT 544 HW 4.0 SR 10402265 LCGR-5 KSP 5 SR 10402267
DCLNR/L 3232P-16
RCT 544 HW 4.0 SR 10402265 LCGR-5 KSP 5 SR 10402267
DCLNR/L 3232P-19
TCN 63 HW 4.0 SR 10402266 LCGR-6 KSP 5 SR 10402267
DCLNR/L 4040S-19
TCN 63 HW 4.0 SR 10402266 LCGR-6 KSP 5 SR 10402267
* Optional, should be ordered separately
(a) For CNMX 0906.. (CNMX 34.) inserts
(b) TCH 4 seat for CNMX 1207.. (CNMX 45.) insert.
DCLNR/L
R-Clamp Tools with 95°
Lead Angle Carrying 80°
Negative Rhombic Inserts
GAMP
B
WF
95˚
LF
LH
H
GAMF
HF
95º
95º
Bar Max
Designation
B H HF LF LH WF GAMP GAMF Insert
DCLNR/L 2020X-12-JHP-MC
20.0 20.0 20.0 105.00 35.0 25.00 6.0 6.0 CNMG 1204
DCLNR/L 2525X-12-JHP-MC
25.0 25.0 25.0 120.00 35.0 32.00 6.0 6.0 CNMG 1204
For inserts, see pages: CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGA-Ceramic (217) • CNGA-J(CBN) (226) • CNGG-J(CBN) (227)
• CNGG-M4HF/M4HM (CBN) (226) • CNMA (149) • CNMA (PCD) (221) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMG-Ceramic (216)
• CNMG-CERMET (145) • CNMG-F3M (146) • CNMG-F3P (144) • CNMG-F3S (147) • CNMG-GN (151) • CNMG-M3M (146) • CNMG-M3P (144) • CNMG-NF (148)
• CNMG-NR (151) • CNMG-VL (147) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMG/CNGG-PP (150) • CNMG/CNGG-SF (148) • CNMG/CNGG-TF (150)
• CNMM-M4PW (152) • CNMM-R3P (153) • CNMX-M3/4MW (152) • CNMX-M3/4PW (152)
Spare Parts
Designation
DCLNL 2020X-12-JHP-MC
RCT 443 TCH 4(a)*LCGR/L-4JC SET(b) PLG G1/8 TL360 OR 4X3 NBR70 SR 14-506
DCLNR 2020X-12-JHP-MC
RCT 443 TCH 4(a)*LCGR/L-4JC SET(b) PLG G1/8 TL360 OR 4X3 NBR70 SR 14-506 LCGR-C-4JC SET
DCLNL 2525X-12-JHP-MC
RCT 443 TCH 4(a)*LCGL-4JC SET(b) PLG G1/8 TL360 OR 4X3 NBR70 SR 14-506
DCLNR 2525X-12-JHP-MC
RCT 443 PLG G1/8 TL360 SR 14-506 LCGR-C-4JC SET
* Optional, should be ordered separately
(a) For CNMX 1207.. (CNMX 45.) inserts
(b) Recommended tightening torque 4Nm for R-Clamp Screw
DCLNR/L-JHP-MC
Rigid Clamp Tools with Channels
for High-Pressure Coolant
Carrying 80° Rhombic Inserts
ISCAR
26
ISOTURN TOOLS
LH
HF
WF
LF
H
B
Right-hand shown
75º
Designation
H HF B LF LH WF Insert
DCBNR/L 2525M-12
25.0 25.0 25.0 150.00 36.0 22.00 CNMG 1204
DCBNR/L 3232P-19
32.0 32.0 32.0 170.00 42.0 27.00 CNMG 1906
For inserts, see pages: CNMG-CERMET (145) • CNMG-F3S (147) • CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMM-M4PW (152)
• CNMG-F3M (146) • CNMG-M3M (146) • CNMG-R3M (147) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMM-NR (154) • CNMG/CNGG-PP (150)
• CNMG-VL (147) • CNMG-MR (151) • CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMM-H3P (153)
• CNMM-H4P (153) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216)
Spare Parts
Designation
DCBNR/L 2525M-12
RCT 443 SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DCBNR/L 3232P-19
TCN 63 SR 10402266 LCGR-6 KSP 5 SR 10402267 HW 4.0
DCBNR/L
R-Clamp Tools with 75°
Lead Angle Using the 100°
Corner of CNMG Inserts
95°
GAMF GAMP
WF
HF
LH
LF
B
H
Right-hand shown
95º
95º
Designation
H HF B LF LH WF GAMP GAMF Insert
PCLOR/L 3232P-16-IQ
32.0 32.0 32.0 170.00 33.0 40.00 -6.0 -6.0 COMG 1606
PCLOR/L 3232P-19-IQ (1)
32.0 32.0 32.0 170.00 38.0 40.00 -6.0 -6.0 COMG 1906
PCLOR/L 4040S-19-IQ (1)
40.0 40.0 40.0 250.00 38.0 50.00 -6.0 -6.0 COMG 1906
PCLOR/L 4040S-25-IQ
40.0 40.0 40.0 250.00 50.0 50.00 -6.0 -6.0 COMG 2509
PCLOR/L 5050T-25-IQ
50.0 50.0 50.0 300.00 50.0 60.00 -6.0 -6.0 COMG 2509
(1) Supplied with TCX 6-IQ seat for COMG inserts, optional TCN 6-IQ seat should be ordered separately for COMM inserts
For inserts, see pages: COMG-R3P-IQ (145) • COMM-R3P-IQ (146)
New Dovetail
OMG-R3P-IQ Inserts
4 Cutting Edges for 80°
and 4 Cutting Edges for 100°
f (mm/rev)
D.O.C. (mm)
0.30.1 0.5 0.7 0.9 1.1
DOVETAIL Clamping
65
1
4
2
3
7 8
Insert
Shim
7°
Spare Parts
Designation
PCLOR/L 3232P-16-IQ
TCX 5-IQ SR LCS 5-L25.5 LCL 16-NX SP 5 HW 3.0
PCLOR/L 3232P-19-IQ
TCX 6-IQ TCN 6-IQ* SR 10402352 LCL 20C-NX SP 5 HW 4.0
PCLOR/L 4040S-19-IQ
TCX 6-IQ TCN 6-IQ* SR 10402352 LCL 20C-NX SP 5 HW 4.0
PCLOR/L 4040S-25-IQ
TCX 8-IQ SR LCS 8-L39 LCL 32-NX SP 8 HW 5.0
PCLOR/L 5050T-25-IQ
TCX 8-IQ SR LCS 8-L39 LCL 32-NX SP 8 HW 5.0
* Optional, should be ordered separately
PCLOR/L-IQ
Lever Lock and Dovetail Pocket
Rigid Clamping Toolholders
for Unique Double-Sided
80° Rhombic Inserts
27
ISOTURN TOOLS
95°
GAMF
WF
DCONMS
LF
Right-hand shown
95º
95º
Designation
DCONMS WF LF GAMF Insert
C6 PCLOR/L-45065-16-IQ
63.00 45.00 65.00 -6.0 COMG 1606
C6 PCLOR/L-45065-19-IQ
63.00 45.00 65.00 -6.0 COMG 1906
C8 PCLOR/L-55080-19-IQ
80.00 55.00 80.00 -6.0 COMG 1906
C8 PCLOR/L-55080-25-IQ
80.00 55.00 80.00 -6.0 COMG 2509
For inserts, see pages: COMG-R3P-IQ (145) • COMM-R3P-IQ (146)
Spare Parts
Designation
C6 PCLOR/L-45065-16-IQ
TCX 5-IQ LCL 16-NX SP 5 SATZ-M10X1-M5 HW 3.0 SR LCS 5-L25.5 SPP 5-6
C6 PCLOR/L-45065-19-IQ
TCX 6-IQ LCL 20C-NX SP 5 SATZ-M10X1-M5 HW 4.0 SR 10402352
C8 PCLOR/L-55080-19-IQ
TCX 6-IQ LCL 20C-NX SP 5 SATZ-M10X1-M5 HW 4.0 SR 10402352 SPP 5-6
C8 PCLOR/L-55080-25-IQ
TCX 8-IQ LCL 32-NX SP 8 SATZ-M12X1-M6 HW 5.0 SR LCS 8-L39
C#-PCLOR/L-IQ
Lever Lock and Dovetail Pocket
Tools with CAMFIX Shanks
Carrying Unique Double-Sided
80° Rhombic Inserts
75°
GAMF GAMP
WF
HF
LH
LF
B
H
Right-hand shown
75º
Designation
H HF B LF LH WF GAMP GAMF Insert
PCBOR/L 3232P-16-IQ
32.0 32.0 32.0 170.00 32.0 27.00 -6.0 -6.0 COMG 1606
PCBOR/L 3232P-19-IQ
32.0 32.0 32.0 170.00 38.0 28.00 -6.0 -6.0 COMG 1906
PCBOR/L 4040S-19-IQ
40.0 40.0 40.0 250.00 38.0 37.00 -6.0 -6.0 COMG 1906
PCBOR/L 4040S-25-IQ
40.0 40.0 40.0 250.00 50.0 35.00 -6.0 -6.0 COMG 2509
For inserts, see pages: COMG-R3P-IQ (145) • COMM-R3P-IQ (146)
Spare Parts
Designation
PCBOR/L 3232P-16-IQ
TCX 5-IQ SP 5 SR LCS 5-L25.5 LCL 16-NX HW 3.0
PCBOR/L 3232P-19-IQ
TCX 6-IQ SP 5 SR 10402352 LCL 20C-NX HW 4.0
PCBOR/L 4040S-19-IQ
TCX 6-IQ SP 5 SR 10402352 LCL 20C-NX HW 4.0
PCBOR/L 4040S-25-IQ
TCX 8-IQ SP 8 SR LCS 8-L39 LCL 32-NX HW 5.0
PCBOR/L-IQ
Lever Lock and Dovetail Pocket
Rigid Clamping Tools Carrying
Unique Double-Sided
80° Rhombic Inserts
OAL
LH
OAW
93˚
H
HF
GAMF
HBH M6
G1/8
OAH
GAMP
B
4
G 1/8
93º
15°
MAX
Designation
H HF HBH LH OAW OAH BOAL GAMP GAMF Insert
DXJNL 2020X-09-JHP-MC
20.0 20.0 4.0 37.0 25.00 33.00 20.0 107.00 6.0 6.0 XNMG
DXJNL 2020X-12-JHP-MC
20.0 20.0 4.0 37.0 25.00 33.00 20.0 107.00 6.0 6.0 XNMG
DXJNR 2020X-09-JHP-MC
20.0 20.0 4.0 37.0 25.00 33.00 25.0 122.00 6.0 6.0 XNMG
DXJNR 2020X-12-JHP-MC
20.0 20.0 4.0 37.0 25.00 33.00 25.0 122.00 6.0 6.0 XNMG
DXJNL 2525X-09-JHP-MC
25.0 25.0 9.0 37.0 32.00 33.00 20.0 107.00 6.0 6.0 XNMG LCGL-3JC-SET LCGL-3JC-AM OR 4X3 NBR70
DXJNL 2525X-12-JHP-MC
25.0 25.0 4.0 37.0 32.00 33.00 20.0 107.00 6.0 6.0 XNMG
DXJNR 2525X-09-JHP-MC
25.0 25.0 9.0 37.0 32.00 33.00 25.0 122.00 6.0 6.0 XNMG
DXJNR 2525X-12-JHP-MC
25.0 25.0 4.0 37.0 32.00 33.00 25.0 122.00 6.0 6.0 XNMG
DXJNR/L 3232X-12-JHP-MC
32.0 32.0 0.0 37.0 40.00 33.00 32.0 137.00 6.0 6.0 XNMG
For inserts, see pages: XNMG-F3M (155) • XNMG-F3P (154) • XNMG-M3M (155) • XNMG-M3P (154)
DXJNR/L-X-JHP-MC
Rigid Clamp Tools with Channels
for High-Pressure Coolant
Carrying 70° Rhombic Inserts
ISCAR
28
ISOTURN TOOLS
LH
HF
WF
LF
B
H
Right-hand shown
93º
27°
MAX
Designation
H HF B LF LH WF Insert
PDJNR/L 1616H-11
16.0 16.0 16.0 100.00 30.0 20.00 DNMG 1104
PDJNR/L 2020K-11
20.0 20.0 20.0 125.00 30.0 25.00 DNMG 1104
PDJNR/L 2525M-11
25.0 25.0 25.0 150.00 30.0 32.00 DNMG 1104
PDJNR/L 2020K-15
20.0 20.0 20.0 125.00 34.0 25.00 DNMG 1506
PDJNR/L 2525M-15
25.0 25.0 25.0 150.00 34.0 32.00 DNMG 1506
PDJNR/L 3232P-15
32.0 32.0 32.0 170.00 34.0 40.00 DNMG 1506
For inserts, see pages: DNGA-J(CBN) (229) • DNGG-M3N (210) • DNMG-CERMET (158) • DNMG-F3S (157) • DNMG-F3P (156) • DNMG-M3P (156)
• DNMX-M3P (162) • DNMM-R3P (162) • DNMG-F3M (157) • DNMG-M3M (157) • DNMG/DNGG-TF (160) • DNMG-GN (161) • DNMG-NR (161)
• DNMG/DNGG-PP (160) • DNMG-VL (160) • DNMG-PF (159) • DNMG/DNGG-SF (159) • DNMG-NF (158) • DNMM-NM (162) • DNMG-WG (159)
• DNMS-12 (214) • DNMA (161) • DNGA-Ceramic (218) • DNGA-2 (CBN) (229) • DNGA-4 (CBN) (229) • DNGG-M4HF/M4HM (CBN) (230) • DNMA (CBN) (228)
Spare Parts
Designation
PDJNR/L 1616H-11
TDN 322 SP 3 PN 3-4 LR 3D SR 117-2014 HW 2.5/5
PDJNR/L 2020K-11
TDN 322 SP 3 PN 3-4 LR 3D SR 117-2014 HW 2.5/5
PDJNR/L 2525M-11
TDN 322 SP 3 PN 3-4 LR 3D SR 117-2014 HW 2.5/5
PDJNR/L 2020K-15
TDN 422 TDN 432(a)*SP 4 PN 3-4 LR 4D SR 117-2010 HW 3.0
PDJNR/L 2525M-15
TDN 422 TDN 432(a)*SP 4 PN 3-4 LR 4D SR 117-2010 HW 3.0
PDJNR/L 3232P-15
TDN 422 TDN 432(a)*SP 4 PN 3-4 LR 4D SR 117-2010 HW 3.0
* Optional, should be ordered separately
(a) Use for DNMG 1504.. inserts.
PDJNR/L
Lever Lock Tools Carrying 55°
Negative Rhombic Inserts
93°
WF
HF
LH
LF
H
B
Right-hand shown
93º
27°
MAX
Designation
H HF B LF LH WF Insert
PDJNR/L 1010X-07S
10.0 10.0 10.0 120.00 14.0 10.00 DNGP 07 SR 10400611 HW 2.0/5 SL LV-2 SL PI-2 PIN
PDJNR/L 1212F-07S
12.0 12.0 12.0 80.00 14.0 12.00 DNGP 07 SR 10400611 HW 2.0/5 SL LV-2 SL PI-2 PIN
PDJNR/L 1212X-07S
12.0 12.0 12.0 120.00 14.0 12.00 DNGP 07 SR 10400611 HW 2.0/5 SL LV-2 SL PI-2 PIN
PDJNR/L 1616X-07S
16.0 16.0 16.0 120.00 18.0 16.00 DNGP 07 SR 10400611 HW 2.0/5 SL LV-2 SL PI-2 PIN
• Use a left-hand insert on a right-hand tool and vice versa.
For inserts, see pages: DNGP-F2M (156) • DNGP-F2P (155)
PDJNR/L-S
Lever Lock Tools Carrying
DNGP 0703.. Double-Sided
55° Rhombic Inserts
Holder
WF
OAW
HF
GAMF GAMP
LH
93˚ OAL (assembly)
93º
27°
MAX
Bar Max
Designation
WF HF LH OAL OAW GAMP GAMF Insert
NQCH12-SDJNR/L-07S-JHP
12.15 12.0 20.0 120.00 20.15 10.0 0.0 DNGP.. 0703
NQCH16-SDJNR/L-07S-JHP
16.15 16.0 20.0 120.00 20.15 10.0 0.0 DNGP.. 0703
For user guide, see pages 6-7, 78-84
For holders, see pages: NQCH-JHP (61)
Spare Parts
Designation
NQCH-SDJNR/L-S-JHP
SR 34-514 T-7/5
NQCH-SDJNR/L-S-JHP
Screw Lock Modular Heads with
High-Pressure Coolant, Positive
Double-Sided 55° Rhombic
Inserts for Swiss-Type Machines
29
ISOTURN TOOLS
GAMF
HF
G 1/8"-28
LH LF
B
H
WF
KAPR
Central coolant direction
4°
4° (8° rotation adjustment) Frontal coolant
on/off screw Frontal
coolant hole
93º
27°
MAX
Bar Max
Designation
B H HF LF LH WF GAMF KAPR(1) Insert
PDJNR/L 2525M-11-JHP
25.0 25.0 25.0 150.00 36.0 32.00 -6.0 93.0 DNMG 1104
PDJNR/L 2525M-15-JHP
25.0 25.0 25.0 150.00 36.0 32.00 -6.0 93.0 DNMG 1506
• For user guide, see pages 78-84
(1) Tool cutting edge angle
For inserts, see pages: DNGA-J(CBN) (229) • DNGG-M3N (210) • DNMG-CERMET (158) • DNMG-F3S (157) • DNMG-F3P (156) • DNMG-M3P (156)
• DNMX-M3P (162) • DNMM-R3P (162) • DNMG-F3M (157) • DNMG-M3M (157) • DNMG/DNGG-TF (160) • DNMG-GN (161) • DNMG-NR (161)
• DNMG/DNGG-PP (160) • DNMG-VL (160) • DNMG-PF (159) • DNMG/DNGG-SF (159) • DNMG-NF (158) • DNMM-NM (162) • DNMG-WG (159)
• DNMS-12 (214) • DNMA (161) • DNGA-Ceramic (218) • DNGA-2 (CBN) (229) • DNGA-4 (CBN) (229) • DNGG-M4HF/M4HM (CBN) (230) • DNMA (CBN) (228)
Spare Parts
Designation
PDJNR/L 2525M-11-JHP
TDN 322 PN 3-4 LR 3D SR 117-2014 SP 3 CU-D-JHP SR M4X4 DIN913 TL360 T-8/5 HW 2.0 HW 2.5/5
PDJNR/L 2525M-15-JHP
TDN 422 TDN 432(a)*PN 3-4 LR 4D SR 117-2010 SP 4 CU-D-JHP SR M4X4 DIN913 TL360 T-8/5 HW 2.0 HW 3.0
* Optional, should be ordered separately
(a) Use for DNMG 1504.. inserts
PDJNR/L-JHP
Lever Lock Tools with
Channels for High-Pressure
Coolant Carrying 55°
Negative Rhombic Inserts
Central coolant direction
4°
4° (8° rotation adjustment)
ECA
GAMF
WF
DCONMS
LF
93º
27°
MAX
Bar Max
Designation
DCONMS WF LF GAMF ECA Insert CDI(1) CP(2)
C3 PDJNR-22045-11-JHP
32.00 22.00 45.00 -6.0 58.0 DN.. 11.. 0 300
C4 PDJNL 27050-11-JHP
40.00 27.00 55.00 -6.0 58.0 DN.. 11.. 1 300
C4 PDJNR 27050-11-JHP
40.00 27.00 50.00 -6.0 58.0 DN.. 11.. 1 300
C5 PDJNR/L 35060-11-JHP
50.00 35.00 60.00 -6.0 58.0 DN.. 11.. 1 300
C4 PDJNR/L 27055-15-JHP
40.00 27.00 55.00 -6.0 58.0 DN.. 15.. 1 300
C5 PDJNR/L 35060-15-JHP
50.00 35.00 60.00 -6.0 58.0 DN.. 15.. 1 300
C6 PDJNR/L 45065-15-JHP
63.00 45.00 65.00 -6.0 58.0 DN.. 15.. 1 300
• For user guide, see pages 78-84
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: DNGA-J(CBN) (229) • DNMG-F3S (157) • DNMG-F3P (156) • DNMG-M3P (156) • DNMX-M3P (162) • DNMM-R3P (162)
• DNMG-F3M (157) • DNMG-M3M (157) • DNMG/DNGG-TF (160) • DNMG-GN (161) • DNMG-NR (161) • DNMG/DNGG-PP (160) • DNMG-VL (160)
• DNMG-PF (159) • DNMG/DNGG-SF (159) • DNMG-NF (158) • DNMM-NM (162) • DNMG-WG (159) • DNMS-12 (214) • DNMA (161) • DNGA-Ceramic (218)
• DNGA-2 (CBN) (229) • DNGA-4 (CBN) (229) • DNGG-M4HF/M4HM (CBN) (230) • DNMA (CBN) (228) • DNGG-M3N (210) • DNMG-CERMET (158)
Spare Parts
Designation
C3 PDJNR-22045-11-JHP
TDN 322 LR 3D SR 117-2014 SP 3 PN 3-4 CU-D-JHP T-8/5 HW 2.5/5
C4 PDJNR/L 27050-11-JHP
TDN 322 LR 3D SR 117-2014 SP 3 PN 3-4 CU-D-JHP T-8/5 HW 2.5/5
C5 PDJNR/L 35060-11-JHP
TDN 322 LR 3D SR 117-2014 SP 3 PN 3-4 CU-D-JHP T-8/5 HW 2.5/5
C4 PDJNR/L 27055-15-JHP
TDN 422 TDN 432(a)*LR 4D SR 117-2010 SP 4 PN 3-4 CU-D-JHP T-8/5 HW 3.0
C5 PDJNR/L 35060-15-JHP
TDN 422 TDN 432(a)*LR 4D SR 117-2010 SP 4 PN 3-4 CU-D-JHP T-8/5 HW 3.0
C6 PDJNR/L 45065-15-JHP
TDN 422 TDN 432(a)*LR 4D SR 117-2010 SP 4 PN 3-4 CU-D-JHP T-8/5 HW 3.0
* Optional, should be ordered separately
(a) Use for DNMG 1504.. inserts
C#-PDJNR/L-JHP
Lever Lock Tools with CAMFIX
Exchangeable Shanks and
Channels for High-Pressure Coolant
Carrying Negative 55° Insert
ISCAR
30
ISOTURN TOOLS
LH
HF
WF
LF
B
H
Right-hand shown
93º
27°
MAX
15°
Designation
H HF B LF LH WF Insert
DDJNR/L 1616H-11
16.0 16.0 16.0 100.00 30.0 20.00 DNMG 1104
DDJNR/L 2020K-11
20.0 20.0 20.0 125.00 30.0 25.00 DNMG 1104
DDJNR/L 2525M-11
25.0 25.0 25.0 150.00 30.0 32.00 DNMG 1104
DDJNR/L 2020K-15
20.0 20.0 20.0 125.00 39.0 25.00 DNMG 1506
DDJNR/L 2525M-15
25.0 25.0 25.0 150.00 40.0 32.00 DNMG 1506
DDJNR/L 3232P-15
32.0 32.0 32.0 170.00 41.0 40.00 DNMG 1506
For inserts, see pages: DNMG-F3S (157) • DNMG-F3P (156) • DNMG-M3P (156) • DNMX-M3P (162) • DNMM-R3P (162) • DNMG-CERMET (158)
• DNGG-M3N (210) • DNMG-F3M (157) • DNMG-M3M (157) • DNMG/DNGG-TF (160) • DNMG-GN (161) • DNMG-NR (161) • DNMG/DNGG-PP (160)
• DNMG-VL (160) • DNMG-PF (159) • DNMG/DNGG-SF (159) • DNMG-NF (158) • DNMM-NM (162) • DNMG-WG (159) • DNMA (161) • DNGA-Ceramic (218)
• DNGA-4 (CBN) (229) • DNMA (CBN) (228)
Spare Parts
Designation
DDJNR/L 1616H-11
RDT 3-2 SR 40085I LCGR-3 SR RC3 HW 2.5 KSP 3
DDJNR/L 2020K-11
RDT 3-2 SR 40085I LCGR-3 SR RC3 HW 2.5 KSP 3
DDJNR/L 2525M-11
RDT 3-2 SR 40085I LCGR-3 SR RC3 HW 2.5 KSP 3
DDJNR/L 2020K-15
RDT 433 RDT 443* SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DDJNR/L 2525M-15
RDT 433 RDT 443* SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DDJNR/L 3232P-15
RDT 433 RDT 443* SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
* Optional, should be ordered separately
DDJNR/L
R-Clamp Tools with 93°
Lead Angle Carrying 55°
Negative Rhombic Inserts
GAMP
B
H
LF
LH
93°
WF
HF
GAMF
93º
27°
MAX
Bar Max
Designation
B HF LF LH WF GAMP GAMF Insert
DDJNR/L 2020X-15-JHP-MC
20.0 20.0 110.00 40.0 25.00 6.0 6.0 DNMG/X 1506
DDJNR/L 2525X-15-JHP-MC
25.0 25.0 125.00 40.0 32.00 6.0 6.0 DNMG/X 1506
For inserts, see pages: DNGA-2 (CBN) (229) • DNGA-4 (CBN) (229) • DNGA-Ceramic (218) • DNGA-J(CBN) (229) • DNGG-M4HF/M4HM (CBN) (230)
• DNMA (161) • DNMA (CBN) (228) • DNMG-CERMET (158) • DNMG-F3M (157) • DNMG-F3P (156) • DNMG-F3S (157) • DNMG-GN (161) • DNMG-M3M (157)
• DNMG-M3P (156) • DNMG-NF (158) • DNMG-NR (161) • DNMG-PF (159) • DNMG-VL (160) • DNMG-WG (159) • DNMG/DNGG-PP (160) • DNMG/DNGG-SF (159)
• DNMG/DNGG-TF (160) • DNMM-NM (162) • DNMM-R3P (162) • DNMX-M3P (162)
Spare Parts
Designation
DDJNR/L-JHP-MC
RDT 433 RDT 443* LCGR/L-4JC SET(a) PLG G1/8 TL360 SR 14-506 OR 4X3 NBR70
* Optional, should be ordered separately
(a) Recommended tightening torque 4Nm for R-Clamp Screw
DDJNR/L-JHP-MC
Rigid Clamp Tools with Channels
for High-Pressure Coolant
Carrying 55° Rhombic Inserts
31
ISOTURN TOOLS
GAMF
DCONMS
WF
LF Right-hand shown
93º
27°
MAX
15°
Bar Max
Designation
DCONMS WF LF Insert GAMF CP(1) CDI(2)
C4 DDJNR/L-27060-15
40.00 27.00 60.00 DN..15 6.0 140 1
C5 DDJNR/L-35060-15
50.00 35.00 60.00 DN..15 6.0 140 1
C6 DDJNR/L-45065-15
63.00 45.00 65.00 DN..15 6.0 140 1
• Use RDT 443 seat for DN.. 1504.. inserts
(1) Coolant pressure (Bar)
(2) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: DNGA-J(CBN) (229) • DNMG-F3S (157) • DNMG-F3P (156) • DNMG-M3P (156) • DNMX-M3P (162) • DNMM-R3P (162)
• DNMG-F3M (157) • DNMG-M3M (157) • DNMG/DNGG-TF (160) • DNMG-GN (161) • DNMG-NR (161) • DNMG/DNGG-PP (160) • DNMG-VL (160)
• DNMG-PF (159) • DNMG/DNGG-SF (159) • DNMG-NF (158) • DNMM-NM (162) • DNMG-WG (159) • DNMA (161) • DNGA-Ceramic (218) • DNGA-2 (CBN) (229)
• DNGA-4 (CBN) (229) • DNGG-M4HF/M4HM (CBN) (230) • DNMA (CBN) (228) • DNMG-CERMET (158)
Spare Parts
Designation
C4 DDJNL-27060-15
RDT 433 RDT 443* T-15/5 LCGR-4 SR 10400270-25.5 SR 14-506 M4X0.7 EZ 62
C4 DDJNR-27060-15
RDT 433 T-15/5 LCGR-4 SR 10400270-25.5 SR 14-506 M4X0.7 EZ 62
C5 DDJNL-35060-15
RDT 433 T-15/5 LCGR-4 SR 10400270-25.5 SR 14-506 M4X0.7 EZ 83
C5 DDJNR-35060-15
RDT 433 RDT 443* T-15/5 LCGR-4 SR 10400270-25.5 SR 14-506 M4X0.7 EZ 83
C6 DDJNR/L-45065-15
RDT 433 RDT 443* T-15/5 LCGR-4 SR 10400270-25.5 SR 14-506 M4X0.7 EZ 104
* Optional, should be ordered separately
C#-DDJNR/L
Tools with CAMFIX Exchangeable
Tapered Shanks Carrying
Negative 55° Rhombic Inserts
78°
WF DCONMS
LF
GAMF
Right-hand shown
93º
27°
MAX
15°
Designation
DCONMS LF WF Insert CDI(2) GAMF
HSK A63WH DDJNR/L J15 (1)
63.00 110.00 25.00 DN.. 15 0 7.5 RDT 433 RDT 443* SR 14-506 M4X0.7 LCGR-4 SR 10400270-25.5 T-15/5 EZ 104
• Complies with ICTM standard (ISO 12164-3). • A cooling tube must be used with all coolant through HSK spindles (should be ordered separately).
• For shank dimensions, see page 735
(1) RDT 443 for DN__ 1504.. insert.
(2) 1 - Hole for data chip, 0 - Without hole for data chip
* Optional, should be ordered separately
For inserts, see pages: DNGA-J(CBN) (229) • DNMG-CERMET (158) • DNMG-F3S (157) • DNMG-F3P (156) • DNMG-M3P (156) • DNMX-M3P (162)
• DNMM-R3P (162) • DNMG-F3M (157) • DNMG-M3M (157) • DNMG/DNGG-TF (160) • DNMG-GN (161) • DNMG-NR (161) • DNMG/DNGG-PP (160)
• DNMG-VL (160) • DNMG-PF (159) • DNMG/DNGG-SF (159) • DNMG-NF (158) • DNMM-NM (162) • DNMA (161) • DNGA-Ceramic (218) • DNGA-2 (CBN) (229)
• DNGA-4 (CBN) (229) • DNGG-M4HF/M4HM (CBN) (230) • DNMA (CBN) (228)
HSK A63WH-DDJNR/L
R-Clamp Turning Tools with
HSK Taper Shank Carrying
Negative DNMG Inserts for 15°
Mounting on Turn-Mill Machines
62.5°
GAMF
DCONMS
LF Complies with ICTM standard (ISO 12164-3)
62.5º
60°
MAX
93º
27°
MAX
Designation
LF Insert DCONMS GAMF CDI(2)
HSK A63WH DDNNN J15 (1)
110.00 DN.. 15 63.00 10.0 0 RDT 433 RDT 443* SR 14-506 M4X0.7 LCGR-4 SR 10400270-25.5(a) T-15/5 EZ 104
• A cooling tube must be used with all coolant through HSK spindles (should be ordered separately). • For shank dimensions, see page 735
(1) RDT 443 for DN__ 1504.. insert.
(2) 1 - Hole for data chip, 0 - Without hole for data chip
* Optional, should be ordered separately
(a) Recommended tightening torque:3 N*m
For inserts, see pages: DNGA-J(CBN) (229) • DNMG-CERMET (158) • DNMG-F3S (157) • DNMG-F3P (156) • DNMG-M3P (156) • DNMX-M3P (162)
• DNMM-R3P (162) • DNMG-F3M (157) • DNMG-M3M (157) • DNMG/DNGG-TF (160) • DNMG-GN (161) • DNMG-NR (161) • DNMG/DNGG-PP (160)
• DNMG-VL (160) • DNMG-PF (159) • DNMG/DNGG-SF (159) • DNMG-NF (158) • DNMM-NM (162) • DNMG-WG (159) • DNMA (161) • DNGA-Ceramic (218)
• DNGA-2 (CBN) (229) • DNGA-4 (CBN) (229) • DNGG-M4HF/M4HM (CBN) (230) • DNMA (CBN) (228)
HSK A63WH-DDNNN
R-Clamp Turning Tools with
HSK Taper Shank Carrying
Negative DNMG Inserts
ISCAR
32
ISOTURN TOOLS
LH
HF
WF
LF
KAPR
H
B
Right-hand shown
93º
27°
MAX
Designation
H HF B LF LH WF KAPR(1) Insert
CKJNR/L 2020K-16
20.0 20.0 20.0 125.00 32.0 25.00 93.0 KNMX/KNUX 1604
CKJNR/L 2525M-16
25.0 25.0 25.0 150.00 32.0 32.00 93.0 KNMX/KNUX 1604
CKJNR/L 3232P-16
32.0 32.0 32.0 170.00 32.0 40.00 93.0 KNMX/KNUX 1604
(1) Tool cutting edge angle
For inserts, see pages: KNMX (163) • KNUX (163)
Spare Parts
Designation
CKJNR/L
CSK 1604 R/L SR M3X0.5X10DIN7991 10.9 KSP 90 KSP 48 KSP 48S CL 16KR/L CLS 16K HW 4.0
CKJNR/L
Top Clamp Tools with 93° Lead
Angle Carrying 55° Negative
Parallelogram Inserts
HF
WF
LF
LH
B
H
Right-hand shown
93º
27°
MAX
Designation
H HF B LF LH WF Insert
SKJNR/L 2525M-16
25.0 25.0 25.0 150.00 32.0 32.00 KNMX 1604 TKX 160310R/L SR TC-3 HW 2.5 SR 16-236 P T-15/5
SKJNL 3232P-16
32.0 32.0 32.0 170.00 32.0 40.00 KNMX 1604 TKX 160310L SR TC-3 HW 2.5 SR 16-236 P T-15/5
For inserts, see pages: KNMX (163)
SKJNR/L
Screw Clamp Tools with 93°
Lead Angle Carrying 55°
Negative Parallelogram Inserts
LH
HF
WF
LF
H
B
75˚
Right-hand shown
62.5º
60°
MAX
Designation
H HF B LF LH WF Insert
CKNNR 2525M-16
25.0 25.0 25.0 150.00 33.0 14.40 KNUX/KNMX 1604
For inserts, see pages: KNMX (163) • KNUX (163)
Spare Parts
Designation
CKNNR/L
CSK 1604 R CL 16KR CLS 16K KSP 90 KSP 48 KSP 48S SR M3X0.5X10DIN7991 10.9 HW 4.0
CKNNR/L
Top Clamp Tools with 63° Lead
Angle Carrying 55° Negative
Parallelogram Inserts
HF
WF
H
B
LH LF
50°
MAX
93°
Designation
H HF B LF LH WF
SVANR/L 1212K-12FS
12.0 12.0 12.0 125.00 25.4 12.20 AV 12 PA 12 SR 14-551 T-9/5
SVANR/L 1616K-12FS
16.0 16.0 16.0 125.00 25.4 16.20 AV 12 PA 12 SR 14-551 T-9/5
For inserts, see pages: VNMG-F3M (164) • VNMG-F3P (163) • VNMG-F3S (164) • VNMG-FNF-CERMET (165) • VNMG-M3M (164) • VNMG-SF (165)
• VNMG/VNGG-NF (165) • VNMM-PP (166)
SVANR/L-FS
Screw Lock Holders for Negative,
35° Inserts with a Wedge for High
Rigidity in Profiling Applications
33
ISOTURN TOOLS
HF
WF
LF
LH
H
B
Right-hand shown
50°
MAX
93°
Designation
H HF B LF LH WF Insert
SVJNR/L 1616H-12F
16.0 16.0 16.0 100.00 25.0 20.00 VNMG 12T3 SR 14-551 T-9/5 AV 12 PA 12
SVJNR/L 2020K-12F
20.0 20.0 20.0 125.00 25.0 25.00 VNMG 12T3 SR 14-551 T-9/5 AV 12 PA 12
SVJNR/L 2525M-12F
25.0 25.0 25.0 150.00 25.0 32.00 VNMG 12T3 SR 14-551 T-9/5 AV 12 PA 12
• Repeatability: for VNMG is ±0.06 mm, for VNGG is ±0.02 mm
For inserts, see pages: VNMG-F3M (164) • VNMG-F3P (163) • VNMG-F3S (164) • VNMG-FNF-CERMET (165) • VNMG-M3M (164) • VNMG-SF (165)
• VNMG/VNGG-NF (165) • VNMM-PP (166)
SVJNR/L-F
Screw Lock Tools with a
Wedge for High Rigidity
Carrying 35° Negative Inserts
for Profiling Applications
LH
HF
WF
LF
B
H
Right-hand shown
50°
MAX
93°
Designation
H HF B LF LH WF Insert
MVJNR/L 2020K-16
20.0 20.0 20.0 125.00 41.0 25.00 VNMG 1604
MVJNR/L 2525M-16
25.0 25.0 25.0 150.00 41.0 32.00 VNMG 1604
For inserts, see pages: VNGG-M3N (210) • VNMG-F3M (164) • VNMG-F3P (163) • VNMG-M3M (164) • VNMG-TF (166) • YNMG-F3P (166)
• VNMG/VNGG-NF (165) • VNMS-12 (214) • VNGA-Ceramic (219) • VNGA-2 (CBN) (231) • VNGA-4 (CBN) (231) • VNGG-M4HM (CBN) (231)
Spare Parts
Designation
MVJNR/L
IVSN 322 IVSN 323(a)*IYSN 322(b)*NL 34-L HW 5/32" CL 30-INJ XNS 510 HW 5/64"
* Optional, should be ordered separately
(a) Use for VNMG 160412 inserts
(b) Use for YNMG inserts
MVJNR/L
Pin and Clamp Tools Carrying
35° Negative Rhombic Inserts
GAMF
DCONMS
LF
WF
Right-hand shown
50°
MAX
93°
70
Bar Max
Designation
DCONMS WF LF Insert GAMF CDI(1) CP(2)
C4 SVJNR/L-27050-12F
40.00 27.00 50.00 VN.. 12T3 12.0 1 70 AV 12 PA 12 SR 14-551 T-9/5 EZ 83
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: VNMG-F3M (164) • VNMG-F3P (163) • VNMG-F3S (164) • VNMG-FNF-CERMET (165) • VNMG-M3M (164) • VNMG-SF (165)
• VNMG/VNGG-NF (165) • VNMM-PP (166)
C#-SVJNR/L-F
Screw Lock Tools with CAMFIX
Exchangeable Shanks Carrying
35° Negative Rhombic Inserts
ISCAR
34
ISOTURN TOOLS
HF
WF
LF
LH
H
B
72.5º
70°MAX
Designation
H HF B LF LH WF Insert
SVVNN 1616H-12F
16.0 16.0 16.0 100.00 26.0 8.00 VNMG 12T3 SR 14-551 T-9/5 PA 12 AV 12
SVVNN 2020K-12F
20.0 20.0 20.0 125.00 26.0 10.00 VNMG 12T3 SR 14-551 T-9/5 PA 12 AV 12
SVVNN 2525M-12F
25.0 25.0 25.0 150.00 26.0 12.50 VNMG 12T3 SR 14-551 T-9/5 PA 12 AV 12
• Repeatability: for VNMG is ±0.06 mm, for VNGG is ± 0.02 mm
For inserts, see pages: VNMG-F3M (164) • VNMG-F3P (163) • VNMG-F3S (164) • VNMG-FNF-CERMET (165) • MG-M3M (164) • VNMG-SF (165)
• VNMG/VNGG-NF (165) • VNMM-PP (166)
4 contact points
ensure secure and
precise clamping
Conventional
clamping
SVVNN-F
Screw Lock Tools with a
Wedge for High Rigidity in
Profiling Applications Carrying
35° Negative Inserts
H
GAMF
HF
GAMP
LF
107.5˚
LH
WF B
107.5º
Bar Max
Designation
H B HF LF LH WF GAMP GAMF MIID(1)
SVHNR/L 2525M-22-AL-JHP
25.0 25.0 25.0 146.34 36.3 30.03 7.0 6.0 VNGU 220630-R3N
• For user guide, see pages 78-84
(1) Master insert identification
For inserts, see pages: VNGU-R3N (210)
Spare Parts
Designation
SVHNR/L 2525M-22-AL-JHP
TVX 2230(a) SR 14-591/L-SN SW6-T-SH BLD T20/S7 HW 3.0 SR TC-4 CH-1.9D-JHP-A SET TVX 2212(b)*TVX 2216(c)*
* Optional, should be ordered separately
(a) For VNGU 220630-R3N insert
(b) For VNGU 220612-R3N insert
(c) For VNGU 220616-R3N insert
SVHNR/L-AL-JHP
Screw Lock Tools with Channels
for High-Pressure Coolant
Carrying 35° Rhombic Inserts
LF
B72.5˚
WF
LH
GAMF
HF H
GAMP
Thread G1/8
72.5º
70°MAX
Bar Max
Designation
H HF B LF LH WF GAMP GAMF MIID(1)
SVVNN 2525M-22-AL-JHP
25.0 25.0 25.0 150.00 41.0 12.50 0.0 -13.5 VNGU 220630-R3N
(1) Master insert identification
For inserts, see pages: VNGU-R3N (210)
Spare Parts
Designation
SVVNN 2525M-22-AL-JHP
TVX 2230(a) HW 3.0 BLD T20/S7 SW6-T-SH SR TC-4 SR 14-591/L-SN CH-1.9D-JHP-A SET TVX 2212(b)*TVX 2216(c)*
* Optional, should be ordered separately
(a) For VNGU 220630-R3N insert
(b) For VNGU 220612-R3N insert
(c) For VNGU 220616-R3N insert
SVVNN-AL-JHP
Screw Lock Tools with Channels
for High-Pressure Coolant
Carrying 35° Rhombic Inserts
35
ISOTURN TOOLS
LH
H
HF
LF
WF B
72.5º
70°MAX
Designation
H HF B LF LH WF Insert
MVVNN 2020K-16
20.0 20.0 20.0 125.00 48.0 10.00 VNMG 1604..
MVVNN 2525M-16
25.0 25.0 25.0 150.00 48.0 12.50 VNMG 1604..
For inserts, see pages: VNGA-J(CBN) (231) • VNGG-M3N (210) • VNMG-F3M (164) • VNMG-F3P (163) • VNMG-M3M (164) • VNMG-TF (166)
• YNMG-F3P (166) • VNMG/VNGG-NF (165) • VNMS-12 (214) • VNGA-Ceramic (219) • VNGA-2 (CBN) (231) • VNGA-4 (CBN) (231) • VNGG-M4HM (CBN) (231)
Spare Parts
Designation
MVVNN
IVSN 322 IVSN 323(a)*IYSN 322(b)*NL 34-L CL 30-INJ XNS 510 HW 5/32" HW 5/64"
* Optional, should be ordered separately
(a) Use for VNMG 160412 inserts
(b) Use for YNMG inserts
MVVNN
Pin and Clamp Tools Carrying
35° Negative Rhombic Inserts
LF
WF B
LH
H
HF
Right-hand shown
91º
Designation
H HF B LF LH WF Insert
PTGNR/L 2020K-16
20.0 20.0 20.0 125.00 22.0 25.00 TNMG 16..
PTGNR/L 2525M-16
25.0 25.0 25.0 150.00 22.0 32.00 TNMG 16..
PTGNR/L 2525M-22
25.0 25.0 25.0 150.00 32.0 32.00 TNMG 2204
PTGNR 3232P-22
32.0 32.0 32.0 170.00 32.0 40.00 TNMG 2204
For inserts, see pages: TNGA-J(CBN) (233) • TNGG-M3N (210) • TNMG-F3S (169) • TNMG-FFG-CERMET (169) • TNMG-F3P (167) • TNMG-M3P (167)
• TNMG-F3M (168) • TNMG-M3M (168) • TNMG-TF (170) • TNMG-GN (171) • TNMM-NR (172) • TNMG/TNGG-PP (171) • TNMG-VL (170) • TNMG-PF (170)
• TNMG-SF (169) • TNMG-NF (171) • TNMS-12 (214) • TNMA (172) • TNGA-Ceramic (219) • TNGA-M3 (CBN) (234) • TNGA-MC/M6 (CBN) (233)
• TNMA (CBN) (233)
Spare Parts
Designation
PTGNR/L 2020K-16
TTN 322 TTN 332(a)*SP 3 LR 3 SR 117-2014 HW 2.5/5 PN 3-4
PTGNR/L 2525M-16
TTN 322 TTN 332(a)*SP 3 LR 3 SR 117-2014 HW 2.5/5 PN 3-4
PTGNR/L 2525M-22
TTN 422 SP 4 LR 4 SR 117-2010 HW 3.0 PN 3-4
PTGNR 3232P-22
TTN 422 SP 4 LR 4 SR 117-2010 HW 3.0 PN 3-4
* Optional, should be ordered separately
(a) TTN 332 for inserts 3.18 mm thick
PTGNR/L
91° Lead Angle Lever Lock
External Turning Tools Carrying
Negative Triangular Inserts
GAMF
72.5°
DCONMS
LF
72.5º
70°MAX
Designation
DCONMS LF Insert GAMF CDI(1)
HSK A63WH-SVVNN-J12F
63.00 110.00 VNM. 12T3 14.0 0 SR 14-551 T-9/5 AV 12 PA 12 EZ 104
• Complies with ICTM standard (ISO 12164-3) • A cooling tube must be used with all coolant through HSK spindles (should be ordered separately)
• For shank dimensions, see page 735
(1) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: VNMG-F3M (164) • VNMG-F3P (163) • VNMG-F3S (164) • VNMG-FNF-CERMET (165) • VNMG-M3M (164) • VNMG-SF (165)
• VNMG/VNGG-NF (165) • VNMM-PP (166)
HSK A63WH-SVVNN-F
72.5° Lead Angle Tools with HSK
Exchangeable Tapered Shanks
Carrying 35° Negative Inserts
ISCAR
36
ISOTURN TOOLS
WF
HF
LH
LF
B
H
Right-hand shown
91º
Designation
H HF B LF LH WF Insert
PTGNR/L 2020K-16X
20.0 20.0 20.0 125.00 20.0 25.00 TNMX 1606, TNMG 1604
PTGNR/L 2525M-16X
25.0 25.0 25.0 150.00 20.0 32.00 TNMX 1606, TNMG 1604
PTGNR/L 2525M-22X
25.0 25.0 25.0 150.00 32.0 32.00 TNMX 2207, TNMG 2204
PTGNR/L 3232P-22X
32.0 32.0 32.0 170.00 32.0 40.00 TNMX 2207, TNMG 2204
• Use TTX 3 seat for TNMX 1606.. inserts and TTN 3 seat for TNMG 1604.. inserts
For inserts, see pages: TNGA-J(CBN) (233) • TNGG-M3N (210) • TNMG-F3S (169) • TNMG-FFG-CERMET (169) • TNMG-F3P (167) • TNMG-M3P (167)
• TNMX-M3/4PW (167) • TNMG-F3M (168) • TNMG-M3M (168) • TNMX-M3/4MW (168) • TNMG-TF (170) • TNMG-GN (171) • TNMM-NR (172)
• TNMG/TNGG-PP (171) • TNMG-VL (170) • TNMG-PF (170) • TNMG-SF (169) • TNMG-NF (171) • TNMS-12 (214) • TNMA (172) • TNGA-Ceramic (219)
• TNGA-M3 (CBN) (234) • TNGA-MC/M6 (CBN) (233) • TNMA (CBN) (233)
TNMG 1604... (33...)
TNMG 2204... (43...)
TNMX 1606... (34...)
TNMX 2207... (45...)
TTX 3
TTX 4
TTN 3
TTN 4
Spare Parts
Designation
PTGNR/L 2020K-16X
TTX 3 TTN 3 SP 3 LR 3 SR 117-2014 HW 2.5 PN 3-4
PTGNR/L 2525M-16X
TTX 3 TTN 3 SP 3 LR 3 SR 117-2014 HW 2.5 PN 3-4
PTGNR/L 2525M-22X
TTX-4 TTN-4 SP 4 LR 4DH SR 117-2010 HW 3.0 PN 3-4L
PTGNR/L 3232P-22X
TTX-4 TTN-4 SP 4 LR 4DH SR 117-2010 HW 3.0 PN 3-4L
PTGNR/L-X
91° Lead Angle Lever Lock
External Turning Tools Carrying
Negative Triangular Inserts
G 1/8"-28
OAW WF
LF
LH
GAMF GAMP
B
H
HF
Right-hand shown
91º
Bar Max
Designation
H HF B LF LH WF OAW GAMP GAMF Insert
PTGNR/L 2020K-16X-JHP
20.0 20.0 20.0 125.00 20.0 25.00 31.7 -6.0 -6.0 TNMX 1606, TNMG 1604
PTGNR/L 2525M-16X-JHP
25.0 25.0 25.0 150.00 20.0 32.00 - -6.0 -6.0 TNMX 1606, TNMG 1604
• Supplied with TTX 3 seat for TNMX 1606.. inserts and TTN 3 seat for TNMG 1604.. inserts • For user guide, see pages 78-84
For inserts, see pages: TNGA-J(CBN) (233) • TNGG-M3N (210) • TNMG-F3S (169) • TNMG-FFG-CERMET (169) • TNMG-F3P (167) • TNMG-M3P (167)
• TNMX-M3/4PW (167) • TNMG-F3M (168) • TNMG-M3M (168) • TNMX-M3/4MW (168) • TNMG-TF (170) • TNMG-GN (171) • TNMG/TNGG-PP (171)
• TNMG-VL (170) • TNMG-PF (170) • TNMG-SF (169) • TNMG-NF (171) • TNMS-12 (214) • TNMA (172) • TNGA-Ceramic (219) • TNGA-M3 (CBN) (234)
• TNGA-MC/M6 (CBN) (233) • TNMA (CBN) (233)
Spare Parts
Designation
PTGNR/L-X-JHP
TTX 3 TTN 3 SP 3 LR 3 SR 117-2014 HW 2.5 PN 3-4
PTGNR/L-X-JHP
91° Lead Lever Lock Tools with
Channels for High-Pressure
Coolant Carrying Negative
Triangular Inserts
37
ISOTURN TOOLS
Frontal coolant
on/off screw
Frontal coolant hole
WF B
LF
LH L5
HF H
Right-hand shown
91º
Bar Max
Designation
H HF B LF LH L5 WF Insert
PTGNR/L 2020X-16X-JHP-MC
20.0 20.0 20.0 95.00 25.0 29.00 25.00 TNMX 1606, TNMG 1604
PTGNR/L 2525X-16X-JHP-MC
25.0 25.0 25.0 110.00 25.0 35.00 32.00 TNMX 1606, TNMG 1604
• Supplied with TTX 3 seat for TNMX 1606.. inserts and TTN 3 seat for TNMG 1604.. inserts. • For user guide, see pages 78-84
For inserts, see pages: TNGA-J(CBN) (233) • TNGG-M3N (210) • TNMG-F3S (169) • TNMG-FFG-CERMET (169) • TNMG-F3P (167) • TNMG-M3P (167)
• TNMX-M3/4PW (167) • TNMG-F3M (168) • TNMG-M3M (168) • TNMX-M3/4MW (168) • TNMG-TF (170) • TNMG-GN (171) • TNMG/TNGG-PP (171)
• TNMG-VL (170) • TNMG-PF (170) • TNMG-SF (169) • TNMG-NF (171) • TNMS-12 (214) • TNMA (172) • TNGA-Ceramic (219) • TNGA-M3 (CBN) (234)
• TNGA-MC/M6 (CBN) (233) • TNMA (CBN) (233)
Spare Parts
Designation
PTGNR/L-X-JHP-MC
TTX 3 TTN 3 SP 3 LR 3 SR 117-2014 T-8/5 SR M5X5 DIN913 TL360 PN 3-4 HW 2.5 CU-S-JHP
PTGNR/L-X-JHP-MC
Tools with Bottom Inlets for
High-Pressure Coolant
Carrying TNMX and TNMG
Triangular Inserts
HF
LH
H
LF
WF B
Right-hand shown
91º
Designation
H HF B LF LH WF Insert
PTFNR/L 2020K-16
20.0 20.0 20.0 125.00 20.0 25.00 TNMG 16..
PTFNR/L 2525M-16
25.0 25.0 25.0 150.00 20.0 32.00 TNMG 16..
PTFNR/L 2525M-22
25.0 25.0 25.0 150.00 26.0 32.00 TNMG 2204
For inserts, see pages: TNGA-J(CBN) (233) • TNGG-M3N (210) • TNMG-F3S (169) • TNMG-FFG-CERMET (169) • TNMG-F3P (167) • TNMG-M3P (167)
• TNMG-F3M (168) • TNMG-M3M (168) • TNMG-TF (170) • TNMG-GN (171) • TNMM-NR (172) • TNMG/TNGG-PP (171) • TNMG-VL (170) • TNMG-PF (170)
• TNMG-SF (169) • TNMG-NF (171) • TNMS-12 (214) • TNMA (172) • TNGA-Ceramic (219) • TNGA-M3 (CBN) (234) • TNGA-MC/M6 (CBN) (233)
• TNMA (CBN) (233)
Spare Parts
Designation
PTFNR/L 2020K-16
TTN 322 TTN 332(a)*LR 3 SR 117-2014 HW 2.5/5 SP 3 PN 3-4
PTFNR/L 2525M-16
TTN 322 TTN 332(a)*LR 3 SR 117-2014 HW 2.5/5 SP 3 PN 3-4
PTFNR/L 2525M-22
TTN 422 LR 4 SR 117-2010 HW 3.0 SP 4 PN 3-4
* Optional, should be ordered separately
(a) TTN 332 for inserts 3.18 mm thick.
PTFNR/L
91° Lead Angle Lever Lock
Face Turning Tools Carrying
Negative Triangular Inserts
ISCAR
38
ISOTURN TOOLS
LH
HF
WF
LF
H
B
Right-hand shown
93º
22°MAX
Designation
H HF B LF LH WF Insert
MTJNR/L 1616H-16W-M
16.0 16.0 16.0 100.00 32.0 20.00 TNMG 1604
MTJNR/L 2020K-16W-M
20.0 20.0 20.0 125.00 32.0 25.00 TNMG 1604
MTJNR/L 2525M-16W-M
25.0 25.0 25.0 150.00 32.0 32.00 TNMG 1604
MTJNR/L 2525M-22W
25.0 25.0 25.0 150.00 38.0 32.00 TNMG 2204
MTJNR/L 3225P-22W
32.0 32.0 25.0 170.00 38.0 32.00 TNMG 2204
For inserts, see pages: TNGA-J(CBN) (233) • TNGG-M3N (210) • TNMG-F3S (169) • TNMG-FFG-CERMET (169) • TNMG-F3P (167) • TNMG-M3P (167)
• TNMG-F3M (168) • TNMG-M3M (168) • TNMG-TF (170) • TNMG-GN (171) • TNMM-NR (172) • TNMG/TNGG-PP (171) • TNMG-VL (170) • TNMG-PF (170)
• TNMG-SF (169) • TNMG-NF (171) • TNMA (172) • TNGA-Ceramic (219) • TNGA-M3 (CBN) (234) • TNGA-MC/M6 (CBN) (233) • TNMA (CBN) (233)
Spare Parts
Designation
MTJNR/L 1616H-16W-M
TTT 322N TTT 332N(a)*ZNW 3WNS LC 291N CLAMP E RING N SR 17-317NS HW 3.0
MTJNR/L 2020K-16W-M
TTT 322N TTT 332N(a)*ZNW 3WN HW 2.5 LC 291N CLAMP E RING N SR 17-317N HW 3.0
MTJNR/L 2525M-16W-M
TTT 322N TTT 332N(a)*ZNW 3WN LC 291N CLAMP E RING N SR 17-317N HW 3.0
MTJNR/L 2525M-22W
TTT 434 ZNW 4 HW 2.5 LC 281 SET 1 SR 17-295 HW 3.0
MTJNR/L 3225P-22W
TTT 434 ZNW 4 HW 2.5 LC 281 SET 1 SR 17-295 HW 3.0
* Optional, should be ordered separately
(a) Use for inserts TNMG 1603.. 3.18 mm thick
MTJNR/L-W
93° Lead Angle Wedge
Lock Turning Tools Carrying
Negative Triangular Inserts
LH
HF
WF
LF
B
H
60º
55°
MAX
Designation
H HF B LF LH WF Insert
MTENN 1618H-16W-M
16.0 16.0 18.0 100.00 32.0 9.00 TNMG 1604
MTENN 2020K-16W-M
20.0 20.0 20.0 125.00 35.0 10.00 TNMG 1604
MTENN 2525M-16W-M
25.0 25.0 25.0 150.00 32.0 12.50 TNMG 1604
MTENN 2525M-22W
25.0 25.0 25.0 150.00 40.0 12.50 TNMG 2204
MTENN 3232P-22W
32.0 32.0 32.0 170.00 40.0 16.00 TNMG 2204
For inserts, see pages: TNGA-J(CBN) (233) • TNGG-M3N (210) • TNMG-F3S (169) • TNMG-FFG-CERMET (169) • TNMG-F3P (167) • TNMG-M3P (167)
• TNMG-F3M (168) • TNMG-M3M (168) • TNMG-TF (170) • TNMG-GN (171) • TNMM-NR (172) • TNMG/TNGG-PP (171) • TNMG-VL (170) • TNMG-PF (170)
• TNMG-SF (169) • TNMG-NF (171) • TNMA (172) • TNGA-Ceramic (219) • TNGA-M3 (CBN) (234) • TNGA-MC/M6 (CBN) (233) • TNMA (CBN) (233)
Spare Parts
Designation
MTENN 1618H-16W-M
TTT 322N TTT 332N(a)*ZNW 3WNS LC 291N CLAMP E RING N SR 17-317NS HW 3.0
MTENN 2020K-16W-M
TTT 322N TTT 332N(a)*ZNW 3WN LC 291N CLAMP E RING N SR 17-317N HW 3.0
MTENN 2525M-16W-M
TTT 322N TTT 332N(a)*ZNW 3WN LC 291N CLAMP E RING N SR 17-317N HW 3.0
MTENN 2525M-22W
TTT 434 ZNW 4 HW 2.5 LC 281 SET 1 SR 17-295 HW 3.0
MTENN 3232P-22W
TTT 434 ZNW 4 HW 2.5 LC 281 SET 1 SR 17-295 HW 3.0
* Optional, should be ordered separately
(a) Use for inserts TNMG 1603.. 3.18 mm thick
MTENN-W
Neutral Wedge Lock Turning
Tools Carrying Negative
Triangular Inserts
39
ISOTURN TOOLS
LH
HF
WF B
H
LF
45°
Designation
H HF B LF LH WF Insert
DSDNN 2525M-12
25.0 25.0 25.0 150.00 38.0 12.80 SNMG 1204
DSDNN 2525M-15
25.0 25.0 25.0 150.00 42.0 12.50 SNMG 1506
DSDNN 3232P-19
32.0 32.0 32.0 170.00 44.0 16.00 SNMG 1906
For inserts, see pages: SNMG-F3S (175) • SNMG-R3M (174) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174)
• SNMG-M3M (174) • SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177) • SNMM-NR (179) • SNMG-PP (175) • SNMG-VL (175) • SNMG-EM-M/R (176)
• SNMM-NM (179) • SNMM-H3P (178) • SNMM-H4P (178) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
Spare Parts
Designation
DSDNN 2525M-12
RST 443 RST 443R/L SET(a)*SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DSDNN 2525M-15
RST 54 SR 10402265 LCGR-5 SR 10402267 KSP 5 HW 4.0
DSDNN 3232P-19
RST 634 SR 10402266 LCGR-6 SR 10402267 KSP 5 HW 4.0
* Optional, should be ordered separately
(a) Optional, required for SNMG ...-EM-R/M inserts
DSDNN
45° Lead Angle R-Clamp
External Turning Tools Carrying
ISO Negative SNMG Inserts
LH
HF
WF
LF
H
B
Right-hand shown
75º
Designation
H HF B LF LH WF Insert
DSKNR/L 2525M-12
25.0 25.0 25.0 150.00 31.0 32.00 SNMG 1204 RST 443 T-15/5 SR 10400270-25.5 LCGR-4 SR 14-506
For inserts, see pages: SNMG-F3S (175) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174)
• SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177) • SNMG-PP (175) • SNMG-VL (175) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
DSKNR/L
75° Lead Angle R-Clamp Face
Turning Tools Carrying ISO
Negative SNMG Inserts
HF
LH
LF
OAL
H
WF B
Right-hand shown
45
º
45º
Designation
H HF B LF LH WF OAL Insert
DSSNR/L 2020K-12 (1)
20.0 20.0 20.0 125.00 38.0 25.00 133.30 SNMG 1204
DSSNR/L 2525M-12 (1)
25.0 25.0 25.0 150.00 39.0 32.00 158.30 SNMG 1204
DSSNR/L 3232P-15
32.0 32.0 32.0 170.00 34.0 40.00 170.00 SNMG 1506
DSSNR/L 3232P-19
32.0 32.0 32.0 170.00 38.0 40.00 170.00 SNMG 1906
(1) Using SNMG.....-EM-M/R inserts requires the use of RST 443R/L SET.
For inserts, see pages: SNMG-F3S (175) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174)
• SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177) • SNMM-NR (179) • SNMG-PP (175) • SNMG-R3M (174) • SNMG-VL (175) • SNMG-EM-M/R (176)
• SNMM-NM (179) • SNMM-H3P (178) • SNMM-H4P (178) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
Spare Parts
Designation
DSSNR/L 2020K-12
RST 443 SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DSSNR/L 2525M-12
RST 443 SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DSSNR/L 3232P-15
RST 54 SR 10402265 LCGR-5 SR 10402267 KSP 5 HW 4.0
DSSNR/L 3232P-19
RST 634 SR 10402266 LCGR-6 SR 10402267 KSP 5 HW 4.0
DSSNR/L
45° Lead Angle R-Clamp
Tools Carrying Negative
Square Inserts for Longitudinal
and Facing Applications
ISCAR
40
ISOTURN TOOLS
H
HF
WF B
LH LF Right-hand shown
75º
Designation
H HF B LF LH WF Insert
DSBNR/L 2525M-12
25.0 25.0 25.0 150.00 38.0 22.00 SNMG 1204
DSBNL 3232P-12
32.0 32.0 32.0 170.00 38.0 27.00 SNMG 1204
DSBNR/L 2525M-15
25.0 25.0 25.0 150.00 40.0 22.00 SNMG 1506
DSBNR/L 3232P-19
32.0 32.0 32.0 170.00 43.0 27.00 SNMG 1906
DSBNR/L 4040S-19
40.0 40.0 40.0 250.00 43.0 37.00 SNMG 1906
For inserts, see pages: SNMG-F3S (175) • SNMG-R3M (174) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174)
• SNMG-M3M (174) • SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177) • SNMM-NR (179) • SNMG-PP (175) • SNMG-VL (175) • SNMM-NM (179)
• SNMM-H3P (178) • SNMM-H4P (178) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
Spare Parts
Designation
DSBNR/L 2525M-12
RST 443 SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DSBNL 3232P-12
RST 443 SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DSBNR/L 2525M-15
RST 54 SR 10402265 LCGR-5 SR 10402267 KSP 5 HW 4.0
DSBNR/L 3232P-19
RST 634 SR 10402266 LCGR-6 SR 10402267 KSP 5 HW 4.0
DSBNR/L 4040S-19
RST 634 SR 10402266 LCGR-6 SR 10402267 KSP 5 HW 4.0
DSBNR/L
75° Lead Angle R-Clamp Tools
Carrying Negative Square Inserts
45°
GAMF GAMP
WF
HF
LH
LF
B
H
45°
Designation
H HF B LF LH WF GAMP GAMF Insert
PSDON 3232P-15-IQ
32.0 32.0 32.0 170.00 35.0 17.00 0.0 -8.5 SOMG 1506
PSDON 3232P-19-IQ
32.0 32.0 32.0 170.00 39.5 17.00 0.0 -8.5 SOMG 1906
PSDON 4040S-19-IQ
40.0 40.0 40.0 250.00 39.5 21.00 0.0 -8.5 SOMG 1906
For inserts, see pages: SOMG-R3P-IQ (173)
Spare Parts
Designation
PSDON 3232P-15-IQ
TSX 5-IQ SP 5 SR LCS 5-L25.5 LCL 16-NX HW 3.0
PSDON 3232P-19-IQ
TSX 6-IQ SP 5 SR 10402352 LCL 20C-NX HW 4.0
PSDON 4040S-19-IQ
TSX 6-IQ SP 5 SR 10402352 LCL 20C-NX HW 4.0
PSDON-IQ
Lever Lock and Dovetail Pocket
Rigid Clamping Tools Carrying
Unique Double-Sided
Square Inserts
41
ISOTURN TOOLS
H
HF
WF
B
LH LF
45°
Designation
H HF B LF LH WF Insert
PSDNN 2020K-12
20.0 20.0 20.0 125.00 27.0 10.00 SNMG 1204/SNGA 1204
PSDNN 2525M-12
25.0 25.0 25.0 150.00 27.0 12.50 SNMG 1204/SNGA 1204
PSDNN 3232P-19
32.0 32.0 32.0 170.00 41.0 16.00 SNMG 1906
PSDNN 4040S-25 (1)
40.0 40.0 40.0 250.00 49.0 20.00 SNMG 2507
(1) For SN.. 2509... inserts, use TSN 84 seat
For inserts, see pages: SNMG-F3S (175) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174)
• SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177) • SNMM-NR (179) • SNMG-EM-M/R (176) • SNMG-PP (175) • SNMG-R3M (174) • SNMG-VL (175)
• SNMM-NM (179) • SNMM-H3P (178) • SNMM-H4P (178) • SNMM-H5P (179) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
Spare Parts
Designation
PSDNN 2020K-12
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
PSDNN 2525M-12
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
PSDNN 3232P-19
RST 634 SP 66 LR 6 SR 10402352 HW 4.0
PSDNN 4040S-25
TSN 84N TSN 85N* SP 8 LR 8 SR 10402264
* Optional, should be ordered separately
PSDNN
45° Lead Angle Lever Lock
External Turning Tools Carrying
ISO Negative SNMG Inserts
G 1/8"-28
WF
HF
LH
LF
B
H
45°
Bar Max
Designation
H HF B LF LH WF Insert
PSDNN 2525M-12-JHP
25.0 25.0 25.0 150.00 40.0 12.50 SNMG 1204
• For user guide, see pages 78-84
For inserts, see pages: SNMG-F3S (175) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174)
• SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177) • SNMG-EM-M/R (176) • SNMG-PP (175) • SNMG-VL (175) • SNMA (177) • SNGA-Ceramic (218)
• SNMA (CBN) (235)
Spare Parts
Designation
PSDNN 2525M-12-JHP
TSN 423 TSN 423M SET(a) SP 4 PN 3-4 LR 4 SR 117-2010 CU-CW-JHP HW 3.0 T-8/5
(a) When SNMG-EM-M/-R inserts are used, replace the standard seat.
PSDNN-JHP
45° Lead Angle Lever Lock Tools
with Channels for High-Pressure
Coolant Carrying ISO
Negative SNMG Inserts
LF
WF B
LH
H
HF
Right-hand shown
75º
Designation
H HF B LF LH WF Insert
PSKNR/L 2525M-12
25.0 25.0 25.0 150.00 23.5 32.00 SNMG 1204/SNGA 1204
For inserts, see pages: SNMG-F3S (175) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174)
• SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177) • SNMG-PP (175) • SNMG-VL (175) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
Spare Parts
Designation
PSKNR/L
TSN 423 LR 4 SR 117-2010 HW 3.0 SP 4 PN 3-4
PSKNR/L
75° Lead Angle Lever Lock
Tools Carrying ISO Negative
Square Inserts for Face Turning
ISCAR
42
ISOTURN TOOLS
H
HF
WF B
LH
LF
OAL Right-hand shown
45
º
45º
Designation
H HF B LF LH WF Insert OAL
PSSNR/L 2020K-09
20.0 20.0 20.0 125.00 25.0 25.00 SNMG 0904 131.40
PSSNR/L 2525M-09
25.0 25.0 25.0 150.00 25.0 32.00 SNMG 0904 156.40
PSSNR/L 2020K-12
20.0 20.0 20.0 125.00 29.0 25.00 SNMG 1204 133.30
PSSNR/L 2525M-12
25.0 25.0 25.0 150.00 29.0 32.00 SNMG 1204 158.30
PSSNR/L 3232P-19
32.0 32.0 32.0 157.50 42.0 40.00 SNMG 1906 170.00
PSSNR/L 4040S-19
40.0 40.0 40.0 237.50 42.0 50.00 SNMG 1906 250.00
PSSNR/L 4040S-2507 (1)
40.0 40.0 40.0 234.00 53.0 50.00 SNMG 2507 250.00
(1) For SN.. 2509... inserts, use TSN 84 seat
For inserts, see pages: SNMG-F3S (175) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174)
• SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177) • SNMM-NR (179) • SNMG-EM-M/R (176) • SNMG-PP (175) • SNMG-R3M (174) • SNMG-VL (175)
• SNMM-NM (179) • SNMM-H3P (178) • SNMM-H4P (178) • SNMM-H5P (179) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
Spare Parts
Designation
PSSNR/L 2020K-09
TSN 323 TSN 333 SP 3 LR 3 SR 117-2014 HW 2.5 PN 3-3L
PSSNR/L 2525M-09
TSN 323 TSN 333 SP 3 LR 3 SR 117-2014 HW 2.5 PN 3-3L
PSSNR/L 2020K-12
TSN 423 SP 4 LR 4 SR 117-2010 HW 3.0 PN 3-4
PSSNR/L 2525M-12
TSN 423 SP 4 LR 4 SR 117-2010 HW 3.0 PN 3-4
PSSNR/L 3232P-19
RST 634 SP 66 LR 6 SR 10402352 HW 4.0
PSSNR/L 4040S-19
RST 634 SP 66 LR 6 SR 10402352 HW 4.0
PSSNR/L 4040S-2507
TSN 85 TSN 84* SP 8 LR 8 SR 10402264 HW 5.0
* Optional, should be ordered separately
PSSNR/L
45° Lead Angle Lever Lock
Tools Carrying Negative
Square Inserts for Longitudinal
and Facing Applications
LF
OAL
B
H
LH
H
WF
Inside coolant for
PSSNR/L... 09
G 1/8"-28
Right-hand shown
45º
45º
Bar Max
Designation
H B LF LH WF OAL Insert
PSSNR/L 2020K-09-JHP
20.0 20.0 125.00 35.0 25.00 131.40 SNMG 09..
PSSNR/L 2525M-12-JHP
25.0 25.0 150.00 38.0 32.00 158.40 SNMG 1204
• For user guide, see pages 78-84
For inserts, see pages: SNMG-F3S (175) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174) • SNMG-M3M (174)
• SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177) • SNMG-EM-M/R (176) • SNMG-PP (175) • SNMG-VL (175) • SNMA (177) • SNGA-Ceramic (218)
• SNMA (CBN) (235)
SNMG 1204##-EM-M/RSNMG 1204##-standard insert
TSN 423-PIN SETTSN 423
Spare Parts
Designation
PSSNR/L 2020K-09-JHP
TSN 323 TSN 333 SP 3 PN 3-3L LR 3 SR 117-2014 HW 2.5
PSSNR/L 2525M-12-JHP
TSN 423 TSN 423M SET(a)*SP 4 PN 3-4 LR 4 SR 117-2010 OR 6.4X0.9N CU-S-JHP HW 3.0 T-8/5
* Optional, should be ordered separately
(a) When SNMG-EM-M/-R inserts are used, replace the standard seat.
PSSNR/L-JHP
45° Tools with Channels for
High-Pressure Coolant Carrying
Negative Square Inserts for
Longitudinal and Facing Turning
43
ISOTURN TOOLS
75°
GAMF
GAMP
WF
HF
LH
LF
B
H
Right-hand shown
75º
Designation
H HF B LF LH WF GAMP GAMF Insert
PSBOR/L 3232P-15-IQ
32.0 32.0 32.0 170.00 35.0 27.00 -4.7 -7.5 SOMG 1506
PSBOR/L 3232P-19-IQ
32.0 32.0 32.0 170.00 38.0 27.00 -4.7 -7.5 SOMG 1906
PSBOR/L 4040S-19-IQ
40.0 40.0 40.0 250.00 38.0 35.00 -4.7 -7.5 SOMG 1906
PSBOR/L 4040S-25-IQ
40.0 40.0 40.0 250.00 50.0 35.00 -4.7 -7.5 SOMG 2509
For inserts, see pages: SOMG-R3P-IQ (173)
Spare Parts
Designation
PSBOR/L 3232P-15-IQ
TSX 5-IQ SP 5 SR LCS 5-L25.5 LCL 16-NX HW 3.0
PSBOR/L 3232P-19-IQ
TSX 6-IQ SP 5 SR 10402352 LCL 20C-NX HW 4.0
PSBOR/L 4040S-19-IQ
TSX 6-IQ SP 5 SR 10402352 LCL 20C-NX HW 4.0
PSBOR/L 4040S-25-IQ
TSX 8-IQ SP 8 SR LCS 8-L39 LCL 32-NX HW 5.0
PSBOR/L-IQ
Lever Lock and Dovetail
Pocket Rigid Clamping Tools
Carrying Unique SOMG
Double-Sided Square Inserts
H
HF
WF B
LH LF=OAL Right-hand shown
75º
Designation
H HF B LF LH WF Insert
PSBNR/L 2020K-09
20.0 20.0 20.0 125.00 20.0 17.00 SNMG 0904
PSBNR/L 2525M-09
25.0 25.0 25.0 150.00 20.0 22.00 SNMG 0904
PSBNR 2525M-12
25.0 25.0 25.0 150.00 26.8 22.00 SNMG 1204
PSBNR/L 3232P-19
32.0 32.0 32.0 170.00 39.0 27.00 SNMG 1906
PSBNR/L 4040S-25 (1)
40.0 40.0 40.0 250.00 48.0 35.00 SNMG 2507
(1) For SN.. 2509... inserts, use TSN 84 seat
For inserts, see pages: SNMG-F3S (175) • SNMG-R3M (174) • SNMG-F3P (173) • SNMG-M3P (173) • SNMM-R3P (178) • SNMG-F3M (174)
• SNMG-M3M (174) • SNMG-TF (176) • SNMG-GN (177) • SNMG-NR (177) • SNMM-NR (179) • SNMG-PP (175) • SNMG-VL (175) • SNMM-NM (179)
• SNMM-H3P (178) • SNMM-H4P (178) • SNMM-H5P (179) • SNMA (177) • SNGA-Ceramic (218) • SNMA (CBN) (235)
Spare Parts
Designation
PSBNR/L 2020K-09
TSN 323 TSN 333 SP 3 PN 3-3L LR 3 SR 117-2014 HW 2.5
PSBNR/L 2525M-09
TSN 323 TSN 333 SP 3 PN 3-3L LR 3 SR 117-2014 HW 2.5
PSBNR 2525M-12
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
PSBNR/L 3232P-19
RST 634 SP 66 LR 6 SR 10402352 HW 4.0
PSBNR/L 4040S-25
TSN 84N TSN 85N* SP 8 LR 8 SR 10402264 HW 5.0
* Optional, should be ordered separately
PSBNR/L
Lever Lock 75° Lead Angle
Turning Tools Carrying ISO
Negative Square Inserts
75°
GAMF
WF
DCONMS
LF Right-hand shown
75º
Designation
DCONMS WF LF GAMP GAMF Insert
C6 PSROR/L-35065-15-IQ
63.00 35.00 65.00 -4.7 -7.5 SOMG 1506
C6 PSROR/L-35065-19-IQ
63.00 35.00 65.00 -4.7 -7.5 SOMG 1906
C8 PSROR/L-45080-19-IQ
80.00 55.00 80.00 -4.7 -7.5 SOMG 1906
C8 PSROR/L-45085-25-IQ
80.00 55.00 80.00 -4.7 -7.5 SOMG 2509
For inserts, see pages: SOMG-R3P-IQ (173)
Spare Parts
Designation
C6 PSROR/L-35065-15-IQ
TSX 5-IQ LCL 16-NX SP 5 SATZ-M10X1-M5 HW 3.0 SR LCS 5-L25.5
C6 PSROR/L-35065-19-IQ
TSX 6-IQ LCL 20C-NX SP 5 SATZ-M10X1-M5 HW 4.0 SR 10402352
C8 PSROR/L-45080-19-IQ
TSX 6-IQ LCL 20C-NX SP 5 SATZ-M10X1-M5 HW 4.0 SR 10402352 SPP 5-6
C8 PSROR/L-45085-25-IQ
TSX 8-IQ LCL 32-NX SP 8 SATZ-M12X1-M6 HW 5.0 SR LCS 8-L39
C#-PSROR/L-IQ
Lever Lock and Dovetail
Pocket Tools with CAMFIX
Shanks Carrying Unique SOMG
Double-Sided Square Inserts
ISCAR
44
ISOTURN TOOLS
LH
HF
WF
LF
B
H
Right-hand shown
91º
Designation
H HF B LF LH WF Insert
DTGNR/L 2020K-16
20.0 20.0 20.0 125.00 25.0 25.00 TNMG 1604
DTGNR/L 2525M-16
25.0 25.0 25.0 150.00 25.0 32.00 TNMG 1604
DTGNR 2525M-22
25.0 25.0 25.0 150.00 32.0 32.00 TNMG 2204
For inserts, see pages: TNGA-J(CBN) (233) • TNGG-M3N (210) • TNMG-F3S (169) • TNMG-FFG-CERMET (169) • TNMG-F3P (167) • TNMG-M3P (167)
• TNMG-F3M (168) • TNMG-M3M (168) • TNMG-TF (170) • TNMG-GN (171) • TNMM-NR (172) • TNMG/TNGG-PP (171) • TNMG-VL (170) • TNMG-PF (170)
• TNMG-SF (169) • TNMG-NF (171) • TNMA (172) • TNGA-Ceramic (219) • TNGA-M3 (CBN) (234) • TNGA-MC/M6 (CBN) (233) • TNMA (CBN) (233)
Spare Parts
Designation
DTGNR/L 2020K-16
RTT 322 SR 35080I LCGR-3 SR RC3 KSP 3 HW 2.5
DTGNR/L 2525M-16
RTT 322 SR 35080I LCGR-3 SR RC3 KSP 3 HW 2.5
DTGNR 2525M-22
RTT 443 SR 14-506 LCGR-4 SR 10400270-25.5 T-15/5
DTGNR/L
91° Lead Angle R-Clamp
External Turning Tools Carrying
Negative Triangular Inserts
6°
WF
DCONMS
LF Right-hand shown
91º
70
Bar Max
Designation
DCONMS WF LF Insert CP(1) CDI(2)
C6 DTGNR/L-45065-22
63.00 45.00 65.00 TN.. 22 70 1 RTT 443 SR 14-506 M4X0.7 LCGR-4 SR 10400270-25.5 T-15/5 EZ 104
(1) Coolant pressure (Bar)
(2) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: TNMG-F3S (169) • TNMG-F3P (167) • TNMG-M3P (167) • TNMG-F3M (168) • TNMG-M3M (168) • TNMG-TF (170) • TNMG-GN (171)
• TNMM-NR (172) • TNMG/TNGG-PP (171) • TNMA (172) • TNGA-Ceramic (219)
C#-DTGNR/L
91° Lead R-Clamp External
Turning Tools with CAMFIX
Exchangeable Shanks Carrying
Negative Triangular Inserts
45
ISOTURN TOOLS
75˚
WF
HF
LH
LF
B
H
Right-hand shown
75°
Designation
H HF B LF LH WF Insert
PLBOR/L 5050T-40
50.0 50.0 50.0 300.00 60.0 50.00 LOMX 4022
PLBOR/L 6060V-40
60.0 60.0 60.0 400.00 60.0 60.00 LOMX 4022
For inserts, see pages: LOMX-H6P (180)
ISCAR’s tangential LOMX 402224-H6P insert for very heavy turning applications.
This tangentially clamped insert with 4 cutting edges is made from the tough grade
IC8250. It can machine at up to 35 mm depth of cut and up to 2 mm/rev feed. The insert
is clamped on a very rigid lever lock pocket equipped with a protective seat.
Tangentially Clamped Insert
Protective SeatClamping Surfaces
Lever Lock Accessible
from Both Tool Sides
Double-sided with
4 cutting edges
2
3
1
4
Application Range H6P Chipformer
10
1 2
20
30
35
45
40
15
25
F (mm/rev)
a
p
(mm)
Spare Parts
Designation
PLBOR/L
TLN 40 SR 10402265 LR 8 SR 10643960 SP D7.5XL23 T-20/5 HW 6.0
PLBOR/L
Lever Lock Tools Carrying
LOMX Tangentially Clamped
Super Heavy Turning Inserts
ISCAR
46
ISOTURN TOOLS
LF
LH
B
H
WF
HF
Right-hand shown
93º
Designation
H HF B LF LH WF Insert
PLANR/L 2525M-15 TANG
25.0 25.0 25.0 150.00 25.0 30.00 LNMX 1506..R/L
PLANR/L 3232P-15 TANG
32.0 32.0 32.0 170.00 32.0 37.00 LNMX 1506..R/L
PLANR/L 3232P-22 TANG
32.0 32.0 32.0 170.00 32.0 37.00 LNMX 2210..R/L
PLANR/L 4040R-22 TANG
40.0 40.0 40.0 200.00 40.0 47.00 LNMX 2210..R/L
For inserts, see pages: LNMX-HM (181) • LNMX-HT (180) • LNMX-WG (181)
Spare Parts
Designation
PLANR/L 2525M-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 LR T15 SR TL-15 HW 3.5
PLANR/L 3232P-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 LR T15 SR TL-15 HW 3.5
PLANR/L 3232P-22 TANG
TLN 22R/L-HT SR 10500401 T-7/5 LR T22 SR TL22 HW 5.0
PLANR/L 4040R-22 TANG
TLN 22R/L-HT SR 10500401 T-7/5 LR T22 SR TL22 HW 5.0
PLANR/L-TANG
Lever Lock Tools Carrying LNMX..
Tangentially Clamped Inserts
47
ISOTURN TOOLS
3.7°
B
LH
LF
LH
WF
H
HF HF
WF
HBH
SLANR/L 1616M-11S
16 mm Shank Configuration
Right-hand shown
93º
Designation
H HF B LF LH WF Insert HBH
SLANR/L 1616H-11 TANG
16.0 16.0 16.0 100.00 20.0 20.00 LNMX 1104.. 4.0
SLANR/L 1616M-11S TANG
16.0 16.0 16.0 150.00 20.0 16.20 LNMX 1104.. 4.0
SLANR/L 2020K-11 TANG
20.0 20.0 20.0 125.00 20.0 25.00 LNMX 1104.. 4.0
SLANR/L 2525M-11 TANG
25.0 25.0 25.0 150.00 25.0 30.00 LNMX 1104.. 4.0
SLANR/L 2020K-15 TANG
20.0 20.0 20.0 125.00 25.0 25.00 LNMX 1506.. 4.0
SLANR/L 2525M-15 TANG
25.0 25.0 25.0 150.00 25.0 30.00 LNMX 1506.. 4.0
SLANR/L 3232P-15 TANG
32.0 32.0 32.0 170.00 35.0 37.00 LNMX 1506.. 4.0
SLANR/L 4040R-15 TANG
40.0 40.0 40.0 200.00 35.0 45.00 LNMX 1506.. 4.0
SLANR/L 3232P-22 TANG
32.0 32.0 32.0 170.00 35.0 38.00 LNMX 2210.. 4.0
SLANR/L 4040R-22 TANG
40.0 40.0 40.0 200.00 40.0 47.00 LNMX 2210.. 4.0
• ap max for facing: LNMX 11-2.8 mm, LNMX 15-3.8 mm, LNMX 22-5.8 mm
For inserts, see pages: LNMX-HM (181) • LNMX-HT (180) • LNMX-WG (181)
The HELITURN system features a unique, double-sided insert
with 4 cutting edges for Fast Metal Removal (FMR) turning.
HELITURN
is a tangentially clamped insert with a unique helical
shaped cutting edge, useful for large depths of cut and higher than
normal feed rates.
The LNMX...-HT
HELITURN insert is a screw clamped into the
SLANR toolholder and supported by the TLN ..-HT carbide seat.
This seat has ground surfaces on the top and bottom to ensure
perfect contact of the insert with the toolholder.
The upper rake face of this insert is mounted level with the
top of the toolholder to enable chips to flow across the insert
without being disturbed by clamps or the toolholder body.
The 4 curved helical cutting edges ensure positive radial rake
angles and soft penetration into the material being cut.
The lower forces and smaller loads ensure better tool life,
higher stability and the ability to use very large depths of cut and
higher feeds.
The chipformer (with small bumps), deforms and breaks the chip
into rib type curved segments which can easily be removed from
the cutting area.
The insert has a frontal clearance angle of 3.7° with a 6° side
clearance angle to enable machining at a 90° shoulder.
Depths of cut up to 8 mm and facing depths up to 3.2 mm and up
to 1.2 mm/rev are achievable with HELITURN.
The high positive rake angle of these tools allows 10-15% less
power usage than conventional tools with the same parameters.
By using HELITURN tools, huge cost savings and
profitability in lathe operations are guaranteed.
Spare Parts
Designation
SLANL 1616H-11 TANG
TLN 11R/L-HT SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD
SLANL 1616M-11S TANG
TLN 11R/L-HT SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD
SLANR 1616H-11 TANG
TLN 11R/L-HT SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD
SLANR 1616M-11S TANG
TLN 11R/L-HT SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD
SLANL 2020K-11 TANG
TLN 11R/L-HT SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD
SLANR 2020K-11 TANG
TLN 11R/L-HT SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD
SLANL 2525M-11 TANG
TLN 11R/L-HT SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD
SLANR 2525M-11 TANG
TLN 11R/L-HT SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD
SLANL 2020K-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH
SLANR 2020K-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH
SLANL 2525M-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH
SLANR 2525M-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH
SLANL 3232P-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH
SLANR 3232P-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH
SLANL 4040R-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH
SLANR 4040R-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH
SLANL 3232P-22 TANG
TLN 22R/L-HT SR 10500401 T-7/5 SR 14-591/L-SN BLD T20/S7 SW6-T-SH
SLANR 3232P-22 TANG
TLN 22R/L-HT SR 10500401 T-7/5 SR 14-591/L-SN BLD T20/S7 SW6-T-SH
SLANL 4040R-22 TANG
TLN 22R/L-HT SR 10500401 T-7/5 SR 14-591/L-SN BLD T20/S7 SW6-T-SH
SLANR 4040R-22 TANG
TLN 22R/L-HT SR 10500401 T-7/5 SR 14-591/L-SN BLD T20/S7 SW6-T-SH
SLANR/L-TANG
Screw-Lock Tools Carrying
the LNMX.. Tangentially
Clamped Inserts
ISCAR
48
ISOTURN TOOLS
HF
GAMP
G 1/8"-28
GAMF
H
B
LH LF
WF
93ºBar Max
Designation
H HF B LF LH WF GAMP GAMF Insert
SLANR/L 3232P-15 TANG-JHP
32.0 32.0 32.0 170.00 30.0 40.00 -6.0 -6.0 LNMX 1506
• ap max for facing 3.8 mm • For user guide, see pages 78-84
For inserts, see pages: LNMX-HM (181) • LNMX-HT (180) • LNMX-WG (181)
The tools with LNMX 1506...
inserts feature fixed coolant holes
Fixed Coolant Holes
Spare Parts
Designation
SLANR/L 3232P-15 TANG-JHP
TLN 15R/L-HT SR RS4 SR 34-535-SN BLD T15/S7 SW6-T-SH T-6/5
SLANR/L-15-TANG-JHP
Screw-Lock Tools with
Channels for High-Pressure
Coolant Carrying LNMX
Tangentially Clamped Inserts
DCONMS
6°
LF
WF
Right-hand shown
93º
70
Bar Max
Designation
DCONMS LF WF Insert CP(2) CDI(3)
C4 SLANR-27050-11 TANG
40.00 50.00 27.00 LNMX 1104.. 70 1
C6 SLANR 25110-11 TANG (1)
63.00 110.00 25.00 LNMX 1104.. 70 1
C4 SLANR/L-27050-15 TANG
40.00 50.00 27.00 LNMX 1506.. 70 1
C5 SLANR/L-35060-15 TANG
50.00 60.00 35.00 LNMX 1506.. 70 1
C6 SLANR 25110-15 TANG (1)
63.00 110.00 25.00 LNMX 1506.. 70 1
C6 SLANR/L-45065-15 TANG
63.00 65.00 45.00 LNMX 1506.. 70 1
C6 SLANR/L-45065-22 TANG
63.00 65.00 45.00 LNMX 2210.. 70 1
• ap max for facing: LNMX 11-2.8 mm, LNMX 15-3.8 mm
(1) Designed for mill-turn machines
(2) Coolant pressure (Bar)
(3) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: LNMX-HM (181) • LNMX-HT (180) • LNMX-WG (181)
Spare Parts
Designation
C4 SLANR-27050-11 TANG
TLN 11R-HT SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD EZ 83
C6 SLANR 25110-11 TANG
TLN 11R-HT SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD EZ 146
C4 SLANL-27050-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH EZ 104
C4 SLANR-27050-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH EZ 104
C5 SLANL-35060-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH EZ 104
C5 SLANR-35060-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH EZ 104
C6 SLANR 25110-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH EZ 146
C6 SLANL-45065-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH EZ 104
C6 SLANR-45065-15 TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH EZ 104
C6 SLANL-45065-22 TANG
TLN 22R/L-HT SR 10500401 T-7/5 SR 14-591/L-SN BLD T20/S7 SW6-T-SH EZ 104
C6 SLANR-45065-22 TANG
TLN 22R/L-HT SR 10500401 T-7/5 SR 14-591/L-SN BLD T20/S7 SW6-T-SH EZ 104
C#-SLANR/L-TANG
Tools with CAMFIX Shanks
Carrying the LNMX-HT
Tangentially Screw Clamped
Inserts for High Production Cutting
49
ISOTURN TOOLS
HF
WF
LF
LH
B
H
Right-hand shown
9 1°
93°
Designation
H HF B LF LH WF Insert(1)
SLFNR/L 2525M-15 TANG
25.0 25.0 25.0 150.00 20.0 30.00 LNMX 1506..L/R
SLFNR/L 3232P-15 TANG
32.0 32.0 32.0 170.00 20.0 37.00 LNMX 1506..L/R
• ap max for longitudinal turning is 5.8 mm
(1) Right-hand insert for left-hand holder, left-hand insert for right-hand holder
For inserts, see pages: LNMX-HM (181) • LNMX-HT (180) • LNMX-WG (181)
Spare Parts
Designation
SLFNR/L-TANG
TLN 15R/L-HT SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH
SLFNR/L-TANG
Tools Carrying LNMX
Tangentially Clamped Inserts
6°
87°
84°
B
H
OAL
HF
WF
Right-hand shown
Designation
H HF B OAL WF
PRWR/L 50-55
50.0 44.0 55.0 210.00 55.00 SR M6X1X16 HW 3.0
• Cartridges should be ordered separately
For tools, see pages: PRWR/L 175-CA (50) • PRWR/L 177-CA (50)
PRWR/L
Toolholders with Cartridges for
Under Floor Railroad Wheel
Re-Turning Lathes (Model 106
Thread Profile Machine)
HF
WF
LF
LH
H
B
75˚
Right-hand shown
75°
Designation
H HF B LF LH WF Insert
SLBNR/L 4040R-22 TANG
40.0 40.0 40.0 200.00 35.0 35.00 LNMX 2210..R/L
For inserts, see pages: LNMX-HT (180)
Spare Parts
Designation
SLBNR/L-TANG
TLN 22R/L-HT SR 10500401 T-7/5 SR 14-591/L-SN BLD T20/S7 SW6-T-SH
SLBNR/L-TANG
External 75° Lead Tools
Carrying Tangentially
Screw Clamped Inserts
ISCAR
50
ISOTURN TOOLS
HF
LH
LF
WF B
Right-hand shown
Designation
HF B LF LH WF Insert
PRWR/L 177-CA-19
32.0 18.6 43.00 35.0 19.10 LNMX 191940 SR LCS 5 LR 5 HW 3.0
For inserts, see pages: LNMX 19/30 (182)
PRWR/L 177-CA
Cartridges for PRWR/L 50-55
Railroad Wheel Re-Turning Tools
LH
HF
WF
LF
B
H
TRight-hand shown
95°
Designation
H HF B LF LH WF T(1) Insert
PQLNR/L 1616H-09
16.0 16.0 16.0 100.00 21.0 20.00 8 QNMG 0904
PQLNR/L 2020K-09
20.0 20.0 20.0 125.00 26.6 25.00 8 QNMG 0904
PQLNR/L 2525M-09
25.0 25.0 25.0 150.00 26.6 32.00 8 QNMG 0904
PQLNR/L 2020K-12
20.0 20.0 20.0 125.00 26.6 25.00 10 QNMG 1204
PQLNR/L 2525M-12
25.0 25.0 25.0 150.00 26.6 32.00 10 QNMG 1204
(1) T for r 0.8
For inserts, see pages: QNMG-GN (183) • QNMG-NF (182) • QNMG-PP (182) • QNMG-TF (182)
EXTERNAL
FACE TURNING
PQFNR/L
TOOLHOLDERS
INTERNAL
FACE TURNING
S...PQFNR/L
BORING BARS
INTERNAL
LONGITUDINAL TURNING
S...PQLNR/L S...SQLCR/L
BORING BARS
EXTERNAL
LONGITUDINAL TURNING
PQLNR/L PQLCR/L
TOOLHOLDERS
Depth of shoulder T with angles over 92
º is unlimited in both directions.
Spare Parts
Designation
PQLNR/L 1616H-09
TXC 322 SP 3 PN 3-4 LR 3 SR 117-2014 HW 2.5
PQLNR/L 2020K-09
TXC 322 SP 3 PN 3-4 LR 3 SR 117-2014 HW 2.5
PQLNR/L 2525M-09
TXC 322 SP 3 PN 3-4 LR 3 SR 117-2014 HW 2.5
PQLNR/L 2020K-12
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
PQLNR/L 2525M-12
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
PQLNR/L
Lever Lock Tools Carrying
Negative Inserts with
Four 80° Corners
LH
LF
HF WF B
INSL Right-hand shown
Designation
HF B LF LH WF INSL Insert
PRWR/L 175-CA-19
32.0 22.6 43.00 35.0 23.00 19.00 LNMX 191940 SR LCS 5 LR 5 HW 3.0
PRWR/L 175-CA-30
32.0 22.6 43.00 35.0 23.00 30.00 LNMX 301940 SR LCS 5 LR 5 HW 3.0
For inserts, see pages: LNMX 19/30 (182)
PRWR/L 175-CA
Cartridges for PRWR/L 50-55
Railroad Wheel Re-Turning Tools
51
ISOTURN TOOLS
LH
HF
WF
LF
H
BT
Right-hand shown
95°
Designation
H HF B LF LH WF T(1) Insert
PQFNR/L 2020K-09
20.0 20.0 20.0 125.00 26.0 25.00 8 QNMG 0904
PQFNR/L 2020K-12
20.0 20.0 20.0 125.00 26.0 25.00 10 QNMG 1204
PQFNR/L 2525M-12
25.0 25.0 25.0 150.00 26.0 25.00 10 QNMG 1204
(1) T for r 0.8
For inserts, see pages: QNMG-GN (183) • QNMG-NF (182) • QNMG-PP (182) • QNMG-TF (182)
Spare Parts
Designation
PQFNR/L 2020K-09
TXC 322 SP 3 PN 3-4 LR 3 SR 117-2014 HW 2.5
PQFNR/L 2020K-12
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
PQFNR/L 2525M-12
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
PQFNR/L
Lever Lock Face Turning Tools
Carrying Negative Inserts
with Four 80° Corners
H
25
LH
HF
B
WF
25
LF
Right-hand shown
Designation
H B HF LF LH WF Insert
PSANR/L 2525M-15 (1)
25.0 25.0 26.0 150.00 38.0 25.00 SNMX 1507
(1) TXN 5-2 for SNMX 150608R-.. inserts without chipbreaker for hard materials.
For inserts, see pages: SNMX 150608R-.. (215) • SNMX 150708R-.. (215)
Spare Parts
Designation
PSANR/L 2525M-15
TXN 532 TXN 5-2* SR 117-2020 LR 5S HW 3.0
* Optional, should be ordered separately
PSANR/L
Lever Lock Tools Carrying
Negative Square Pipe
Skiving Inserts
LH
HF
WF
LF
KAPR
B
H
Right-hand shown
45º
45º
Designation
H HF B LF LH WF Insert KAPR(1)
PQSNR/L 2525M-12
25.0 25.0 25.0 150.00 30.0 32.00 QNMG 1204 45.0
(1) Tool cutting edge angle
For inserts, see pages: QNMG-GN (183) • QNMG-NF (182) • QNMG-PP (182) • QNMG-TF (182)
Spare Parts
Designation
PQSNR/L
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
PQSNR/L
External 45° Lead Tools
Carrying Negative Inserts
with Four 80° Corners
ISCAR
52
ISOTURN TOOLS
GAMP
GAMF
WF
HF
LF
LH
B
H
95º
95º
Bar Max
Designation
B H HF LF LH WF GAMP GAMF Insert
PCLXR/L 1212F-09X-JHP
12.0 12.0 12.0 80.00 20.0 16.00 6.0 6.0 CXMG 09...
PCLXR/L 1616H-09X-JHP
16.0 16.0 16.0 100.00 20.0 20.00 6.0 6.0 CXMG 09...
PCLXR/L 2020K-12X-JHP
20.0 20.0 20.0 125.00 25.0 25.00 6.0 6.0 CXMG 12...
PCLXR/L 2525M-12X-JHP
25.0 25.0 25.0 150.00 25.0 32.00 6.0 6.0 CXMG 12...
• For user guide, see pages 78-84
For inserts, see pages: CXMG-F3M (184) • CXMG-F3P (183) • CXMG-M3M (184) • CXMG-M3P (183)
Spare Parts
Designation
PCLXR/L 1212F-09X-JHP
LR 3X SET SR M6XL11.5V T-8/5 S-CU-JHP-A SET
PCLXR/L 1616H-09X-JHP
LR 3X SET SR M6XL11.5V T-8/5 S-CU-JHP-A SET
PCLXR/L 2020K-12X-JHP
TCNX 423 LR 4X SR LCS 5 HW 3.0 PN 3-4 SP 4 CH-1.9D-JHP-A SET
PCLXR/L 2525M-12X-JHP
TCNX 423 LR 4X SR LCS 5 HW 3.0 PN 3-4 SP 4 CH-1.9D-JHP-A SET
PCLXR/L-JHP
Lever Lock Tools with
Channels for High-Pressure
Coolant Carrying CXMG
80° Rhombic Inserts
H
GAMP
B
LH
GAMF
HF
WF
LF
95º
95º
Designation
B H HF LF LH WF GAMP GAMF Insert
PCLXR/L 1212F-09X
12.0 12.0 12.0 80.00 19.0 16.00 6.0 6.0 CXMG 09...
PCLXR/L 1616H-09X
16.0 16.0 16.0 100.00 19.0 20.00 6.0 6.0 CXMG 09...
PCLXR/L 2020K-12X
20.0 20.0 20.0 125.00 25.0 25.00 6.0 6.0 CXMG 12...
PCLXR/L 2525M-12X
25.0 25.0 25.0 150.00 25.0 32.00 6.0 6.0 CXMG 12...
For inserts, see pages: CXMG-F3M (184) • CXMG-F3P (183) • CXMG-M3M (184) • CXMG-M3P (183)
Spare Parts
Designation
PCLXR/L 1212F-09X
LR 3X SET SR M6XL11.5V T-8/5
PCLXR/L 1616H-09X
LR 3X SET SR M6XL11.5V T-8/5
PCLXR/L 2020K-12X
TCNX 423 LR 4X SR LCS 5 HW 3.0 PN 3-4 SP 4
PCLXR/L 2525M-12X
TCNX 423 LR 4X SR LCS 5 HW 3.0 PN 3-4 SP 4
PCLXR/L
Lever Lock Tools Carrying
CXMG 80° Rhombic Inserts
H
HF
GAMF GAMP
B
WF
LF
LH
95º
95º
Designation
B H HF LF LH WF GAMP GAMF MIID(1)
PCLXR/L 1212H-09XS
12.0 12.0 12.0 100.00 20.0 12.15 6.0 6.0 CXMG 090402-F3P
PCLXL 1616K-09XS
16.0 16.0 16.0 125.00 20.0 16.00 6.0 6.0 CXMG 090402-F3P
PCLXR 1616K-09XS
16.0 16.0 16.0 125.00 20.0 16.15 6.0 6.0 CXMG 090402-F3P
(1) Master insert identification
For inserts, see pages: CXMG-F3M (184) • CXMG-F3P (183) • CXMG-M3M (184) • CXMG-M3P (183)
Spare Parts
Designation
PCLXR/L-S
LR 3X SET SR-SW-M4X0.7 PIN-SW LR-3X SR M5X5 SPR T-8/5 SPRING-.55X2.9X6X6.8
PCLXR/L-S
Lever Lock Tools Carrying
CXMG 80° Rhombic Inserts for
Swiss-Type Automatic Lathes
53
ISOTURN TOOLS
GAMP
GAMF
WF
HF
LF
LH
B
H
95º
95º
Bar Max
Designation
B H HF LF LH WF GAMP GAMF Insert MIID(1)
PCLXR/L 2020X-09X-JHP-MC
20.0 20.0 20.0 90.00 20.0 25.00 6.0 6.0 CXMG 09... CXMG 09...
PCLXR/L 2525X-09X-JHP-MC
25.0 25.0 25.0 105.00 20.0 32.00 6.0 6.0 CXMG 09... CXMG 09...
PCLXR/L 2020X-12X-JHP-MC
20.0 20.0 20.0 95.00 25.0 25.00 6.0 6.0 CXMG 12... CXMG 12...
PCLXR/L 2525X-12X-JHP-MC
25.0 25.0 25.0 110.00 25.0 32.00 6.0 6.0 CXMG 12... CXMG 12...
• For user guide, see pages 78-84
(1) Master insert identification
For inserts, see pages: CXMG-F3M (184) • CXMG-F3P (183) • CXMG-M3M (184) • CXMG-M3P (183)
Spare Parts
Designation
PCLXL 2020X-09X-JHP-MC
TSN 323 S-CU-JHP-A SET SR M5X5 DIN913 TL360 SR M6X6 DIN913 TL360 PLG G1/8 TL360 SR 117-2014 PN 3-4 SP 3 HW 2.5/5
PCLXR 2020X-09X-JHP-MC
TSN 323 S-CU-JHP-A SET SR M5X5 DIN913 TL360 SR M6X6 DIN913 TL360 PLG G1/8 TL360 SR 117-2014 PN 3-4 SP 3 HW 2.5/5
PCLXL 2525X-09X-JHP-MC
TSN 323 S-CU-JHP-A SET SR M5X5 DIN913 TL360 SR M6X6 DIN913 TL360 PLG G1/8 TL360 SR 117-2014 LR 3XL PN 3-4 SP 3 HW 2.5/5
PCLXR 2525X-09X-JHP-MC
TSN 323 S-CU-JHP-A SET SR M5X5 DIN913 TL360 SR M6X6 DIN913 TL360 PLG G1/8 TL360 SR 117-2014 LR 3XL PN 3-4 SP 3 HW 2.5/5
PCLXL 2020X-12X-JHP-MC
TCNX 423 CH-1.9D-JHP-A SET SR M5X5 DIN913 TL360 SR M6X6 DIN913 TL360 PLG G1/8 TL360 SR LCS 5 LR 4X PN 3-4 SP 4 HW 3.0
PCLXR 2020X-12X-JHP-MC
TCNX 423 CH-1.9D-JHP-A SET SR M5X5 DIN913 TL360 SR M6X6 DIN913 TL360 PLG G1/8 TL360 SR LCS 5 LR 4X PN 3-4 SP 4 HW 3.0
PCLXL 2525X-12X-JHP-MC
TCNX 423 CH-1.9D-JHP-A SET SR M5X5 DIN913 TL360 SR M6X6 DIN913 TL360 PLG G1/8 TL360 SR LCS 5 LR 4X PN 3-4 SP 4 HW 3.0
PCLXR 2525X-12X-JHP-MC
TCNX 423 CH-1.9D-JHP-A SET SR M5X5 DIN913 TL360 SR M6X6 DIN913 TL360 PLG G1/8 TL360 SR LCS 5 LR 4X PN 3-4 SP 4 HW 3.0
PCLXR/L-JHP-MC
Lever Lock Tools with
Channels for High-Pressure
Coolant Carrying CXMG
80° Rhombic Inserts
GAMP
GAMF
WF
OAW B
LF
HF
LH
H
95º
95º
Bar Max
Designation
B H HF LF LH WF OAW GAMP GAMF MIID(1)
PCLXR/L 1212H-09XS-JHP
12.0 12.0 12.0 100.00 20.0 12.15 23.00 6.0 6.0 CXMG 090402-F3P
PCLXR/L 1616K-09XS-JHP
16.0 16.0 16.0 125.00 20.0 16.15 23.00 6.0 6.0 CXMG 090402-F3P
• For user guide, see pages 78-84
(1) Master insert identification
For inserts, see pages: CXMG-F3M (184) • CXMG-F3P (183) • CXMG-M3M (184) • CXMG-M3P (183)
Spare Parts
Designation
PCLXR/L-S-JHP
LR 3X SET SR-SW-M4X0.7 PIN-SW LR-3X SR M5X5 SPR SR 5/16UNF TL360 T-8/5 SPRING-.55X2.9X6X6.8 CH-1.9D-JHP-A SET SR M3X3 DIN913 TL360
PCLXR/L-S-JHP
Lever Lock Tools with JETCUT
Coolant System Carrying
CXMG 80° Rhombic Inserts for
Swiss-Type Automatic Lathes
Holder
WF
OAW
HF
GAMF
GAMP
LH
95˚
OAL (assembly)
95º
95º
Bar Max
Designation
WF HF LH OAL OAW GAMP GAMF Insert
NQCH12-PCLXR/L-09X-JHP
12.15 12.0 20.0 120.00 20.15 6.0 6.0 CXMG.. 0904
NQCH16-PCLXR/L-09X-JHP
16.15 16.0 20.0 120.00 20.15 6.0 6.0 CXMG.. 0904
• For user guide, see pages 6-7, 78-84
For inserts, see pages: CXMG-F3M (184) • CXMG-F3P (183) • CXMG-M3M (184) • CXMG-M3P (183)
For holders, see pages: NQCH-JHP (61)
Spare Parts
Designation
NQCH-PCLXR/L-S-JHP
LR 3X SET SR M6XL11.5V T-8/5
NQCH-PCLXR/L-S-JHP
Lever Lock Modular Heads with
High-Pressure Coolant, Positive
Double-Sided 80° Rhombic
Inserts for SwissType Machines
ISCAR
54
ISOTURN TOOLS
LH
HF
WF
LF
B
H
Right-hand shown
45
º
45º
95°
95º
95º
Designation
H HF B LF LH WF
SUXCR/L 1616H-10 CM
16.0 16.0 16.0 100.00 24.0 20.00
SUXCR/L 2020K-10 CM
20.0 20.0 20.0 125.00 25.0 25.00
SUXCR/L 2525M-10 CM
25.0 25.0 25.0 150.00 25.0 32.00
For inserts, see pages: CC95MT-SM (208) • SC45MT-SM (209)
Clamping direction for SC45MT...
SC45MT
• Unique, versatile ISCAR pocket
• For external applications
• Covers most common operations
• Simplifies tool selection
• Simple screw clamping
• Minimum spare parts
Multifunction Tool Can
Carry Two Different Inserts
Designation
H HF LF LH WF Inserts
SUXCR/L 1616H-10 CM
16.0 16.0 100.00 24.0 20 CC95MT...
21.2 SC45MT...
SUXCR/L 2020K-10 CM
20.0 20.0 125.00 25.0 25 CC95MT...
26.2 SC45MT...
SUXCR/L 2525M-10 CM
25.0 25.0 150.00 25.0 32 CC95MT...
33.2 SC45MT...
Spare Parts
Designation
SUXCR/L-CM
SR 14-544/S T-15/5
SUXCR/L-CM
Screw Lock Tools Carrying Four
Different 7° Clearance Geometries
LH
HF
WF
LF
H
B
Right-hand shown
95º
95º
Designation
H HF B LF LH WF Insert
SCLCR/L 0808F-06
8.0 8.0 8.0 80.00 10.0 10.00 CC.. 0602 SR 14-548 T-7/5
SCLCR/L 1010F-06
10.0 10.0 10.0 80.00 10.0 12.00 CC.. 0602 SR 14-548 T-7/5
SCLCR/L 1212F-09
12.0 12.0 12.0 80.00 14.0 16.00 CC.. 09T3 SR 16-236 T-15/5
SCLCR/L 1616H-09
16.0 16.0 16.0 100.00 14.0 20.00 CC.. 09T3 SR 16-236 T-15/5
SCLCR/L 2020K-12
20.0 20.0 20.0 125.00 18.0 25.00 CC.. 1204 SR 16-212 T-20/5
SCLCR/L 2525M-12
25.0 25.0 25.0 150.00 20.0 32.00 CC.. 1204 SR 16-212 T-20/5 TCC 4-2 SR TC-4 HW 3.0
For inserts, see pages: CCMT-CERMET (187) • CCMT-F3P (185) • CCMT-M3P (185) • CCMT-F3M (186) • CCMT-M3M (186) • CCMT-PF (188)
• CCMT/CCGT-SM (187) • CCET-WF (189) • CCMT-WG (189) • CCGT-AS (212) • CCGT-AF (212) • CCMT-14 (188) • CCMT/CCGT (188) • CCGW/CCMT (CBN) (227)
• CCGW/CCMW-2 (CBN) (228) • CCMT (PCD) (222)
SCLCR/L
Screw Lock Tools Carrying
80° Diamond Inserts with
7° Clearance Angle
95°
55°
GAMF
WF
DCONMS
LF Right-hand shown
95º
95º
Bar Max
Designation
DCONMS WF LF GAMF Insert CDI(1) CP(2)
C3 SCLCR-22045-09-JHP
32.00 22.00 45.00 0.0 CC.. 09T3 0 300 SR 16-236 T-15/5 CU-CW-JHP T-8/5
C4 SCLCR/L 27050-09-JHP
40.00 27.00 50.00 0.0 CC.. 09T3 1 300 SR 16-236 T-15/5 CU-CW-JHP SR M5X5 DIN913 TL360 T-8/5
C5 SCLCR/L 35060-09-JHP
50.00 35.00 60.00 0.0 CC.. 09T3 1 300 SR 16-236 T-15/5 CU-CW-JHP SR M5X5 DIN913 TL360 T-8/5
• For user guide, see pages 78-84
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: CCMT-CERMET (187) • CCMT-F3P (185) • CCMT-M3P (185) • CCMT-F3M (186) • CCMT-M3M (186) • CCMT-PF (188)
• CCMT/CCGT-SM (187) • CCET-WF (189) • CCMT-WG (189) • CCGT-AS (212) • CCGT-AF (212) • CCMT-14 (188) • CCMT/CCGT (188) • CCGW/CCMT (CBN) (227)
• CCGW/CCMW-2 (CBN) (228) • CCMT (PCD) (222)
C#-SCLCR/L-JHP
Screw Clamp Tools with CAMFIX
Shanks and Channels for
High-Pressure Coolant Carrying
Positive 80° Rhombic Inserts
55
ISOTURN TOOLS
WF WB_2
OAL
HF OAH
Holder: MAHPL
Holder: MAHR
WF (assembly)WF (holder)
WF
19.5
95º
95º
Designation
HF OAL OAH WF WB_2 Insert
SCLCR-09-PAD
24.0 42.00 28.0 7.50 5.2 CCGT/CCMT 09T3 SR 16-236 T-15/5
For inserts, see pages: CCMT-CERMET (187) • CCMT-F3P (185) • CCMT-M3P (185) • CCMT-F3M (186) • CCMT-M3M (186) • CCMT-PF (188)
• CCMT/CCGT-SM (187) • CCET-WF (189) • CCMT-WG (189) • CCGT-AS (212) • CCGT-AF (212) • CCMT-14 (188) • CCMT/CCGT (188) • CCGW/CCMT (CBN) (227)
• CCGW/CCMW-2 (CBN) (228) • CCMT (PCD) (222)
For holders, see pages: C#-MAHPD-JHP (625) • MAHR/L-JHP-MC (280) • C#-MAHD-JHP (624) • MAHPR/L-JHP (281) • MAHR/L-JHP (279)
• MAHR/L (279) • MAHPR/L (280) • C#-MAHD (624) • C#-MAHPD (625) • C#-MAHDR-45 (623) • C#-MAHDOR (624) • HSK A63WH-MAHUR/L (632)
• HSK A63WH-MAHDR-45 (631) • HSK A63WH-MAHDOR (631) • IM-MAHD (633) • IM-MAHPD (633) • HMSN-New Britain (478) • DGHAL-DECO (478)
SCLCR-PAD
Screw Lock Adapter Carrying
80° Diamond Inserts with
7° Clearance Angle
H
HF
LF
B
OAW WF
LH
Right-hand shown
99°
91°
Designation
H HF B LF LH WF OAW Insert
SCACR/L 0808K-06S
8.0 8.0 8.0 125.00 8.0 8.20 - CC.. 0602 SR 14-548 T-7/5
SCACR 1010K-06S
10.0 10.0 10.0 150.00 - 10.00 - CC.. 0602 SR 14-548 T-7/5
SCACR/L 1616K-06S
16.0 16.0 16.0 125.00 - 16.20 - CC.. 0602 SR 14-548 T-7/5
SCACR/L 1010K-09S
10.0 10.0 10.0 125.00 15.2 10.20 - CC.. 09T3 SR 16-236 T-15/5
SCACR 1212K-09S
12.0 12.0 12.0 125.00 14.0 12.15 12.5 CC.. 09T3 SR 16-236 T-15/5
SCACR/L 1616K-09S
16.0 16.0 16.0 125.00 - 16.20 - CC.. 09T3 SR 16-236 T-15/5
For inserts, see pages: CCMT-CERMET (187) • CCMT-F3P (185) • CCMT-M3P (185) • CCMT-F3M (186) • CCMT-M3M (186) • CCMT-PF (188)
• CCMT/CCGT-SM (187) • CCET-WF (189) • CCMT-WG (189) • CCGT-AS (212) • CCMT-14 (188) • CCMT/CCGT (188) • CCGW/CCMT (CBN) (227)
• CCGW/CCMW-2 (CBN) (228) • CCMT (PCD) (222)
SCACR/L-S
Screw Lock Tools for
Swiss-Type Machines Carrying 7°
Clearance 80° Diamond Inserts
HF
WF
LF
B
H
Right-hand shown
95º
95º
Designation
H HF B LF WF Insert
PCLCR 0808M-06S
8.0 8.0 8.0 150.00 8.00 CC.. 0602 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PCLCR/L 1010M-06S
10.0 10.0 10.0 150.00 10.20 CC.. 0602 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PCLCR/L 1212M-06S
12.0 12.0 12.0 150.00 12.20 CC.. 0602 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PCLCR/L 1616M-06S
16.0 16.0 16.0 150.00 16.20 CC.. 0602 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PCLCR/L 1012M-09S
10.0 10.0 12.0 150.00 12.20 CC.. 09T3 SL LV-3 SL PI-3 SR 10400150 HW 2.5/5
PCLCR/L 1212M-09S
12.0 12.0 12.0 150.00 12.20 CC.. 09T3 SL LV-3 SL PI-3 SR 10400150 HW 2.5/5
PCLCR/L 1616M-09S
16.0 16.0 16.0 150.00 16.20 CC.. 09T3 SL LV-3 SL PI-3 SR 10400150 HW 2.5/5
PCLCR/L 2020K-09S
20.0 20.0 20.0 125.00 20.20 CC.. 09T3 SL LV-3 SL PI-3 SR 10400150 HW 2.5/5
• The clamping screw may by transferred to the opposite side if needed
For inserts, see pages: CCMT-CERMET (187) • CCMT-F3P (185) • CCMT-M3P (185) • CCMT-F3M (186) • CCMT-M3M (186) • CCMT-PF (188)
• CCMT/CCGT-SM (187) • CCET-WF (189) • CCMT-WG (189) • CCGT-AS (212) • CCGT-AF (212) • CCMT-14 (188) • CCMT/CCGT (188) • CCGW/CCMT (CBN) (227)
• CCGW/CCMW-2 (CBN) (228) • CCMT (PCD) (222)
PCLCR/L-S
Side Lever Lock Tools Carrying
80° Positive Rhombic Inserts
for Swiss Automatic Machines
WF
OAW
HF
Holder
LH OAL (assembly)
91˚
99°
91°
Bar Max
Designation
WF HF LH OAL OAW Insert
NQCH12-SCACR/L-09S-JHP
12.15 12.0 20.0 120.00 20.15 CC.. 09T3 SR 16-236 T-15/5
NQCH16-SCACR/L-09S-JHP
16.15 16.0 20.0 120.00 20.15 CC.. 09T3 SR 16-236 T-15/5
For user guide, see pages 6-7, 78-84
For holders, see pages: NQCH-JHP (61)
NQCH-SCACR/L-JHP
Screw Lock Modular Heads
with High-Pressure Coolant - 7°
Clearance 80° Rhombic Inserts
for SwissType Machines
ISCAR
56
ISOTURN TOOLS
HF
OAW WF
LH
95°
LF
UNF 5/16”-24 typex3
B
H
GAMP
GAMF
Right-hand shown
95º
95º
Bar Max
Designation
H HF B LF LH WF OAW GAMP GAMF Insert
PCLCR/L 1010H-06S-JHP
10.0 10.0 10.0 100.00 22.3 10.20 - 0.0 0.0 CC.. 0602
PCLCR/L 1212H-09S-JHP
12.0 12.0 12.0 100.00 22.3 12.20 14.0 0.0 0.0 CC.. 09T3
PCLCR/L 1616K-09S-JHP
16.0 16.0 16.0 125.00 22.3 16.20 - 0.0 0.0 CC.. 09T3
PCLCR/L 2020K-09S-JHP
20.0 20.0 20.0 125.00 22.3 20.20 - 0.0 0.0 CC.. 09T3
• For user guide, see pages 78-84
For inserts, see pages: CCMT-F3P (185) • CCMT-M3P (185) • CCMT-F3M (186) • CCMT-M3M (186) • CCMT-PF (188) • CCMT/CCGT-SM (187)
• CCET-WF (189) • CCMT-WG (189) • CCGT-AS (212) • CCGT-AF (212) • CCMT-14 (188) • CCMT/CCGT (188) • CCGW/CCMT (CBN) (227)
• CCGW/CCMW-2 (CBN) (228) • CCMT (PCD) (222) • CCMT-CERMET (187)
Spare Parts
Designation
PCLCR/L-S-JHP
SL LV-3 SL PI-3 SR 10400150 HW 2.5/5 SR 5/16UNF TL360 S-CU-JHP-A SET
PCLCR/L-S-JHP
Tools with Channels for
High-Pressure Coolant Carrying
80° Positive Rhombic Inserts
for Swiss Automatic Machines
H
GAMP
GAMF
HF
WF
HBKW LH L5
B
LF
95°
95º
95º
Bar Max
Designation
H HF B LF LH L5 WF HBKW GAMP GAMF Insert
PCLCR/L 1212X-09S-JHP-MC
12.0 12.0 12.0 67.00 23.0 20.00 12.20 1.80 0.0 0.0 CC.. 09T3
PCLCR/L 1616X-09S-JHP-MC
16.0 16.0 16.0 71.00 23.0 17.00 16.20 - 0.0 0.0 CC.. 09T3
• For user guide, see pages 78-84
For inserts, see pages: CCET-WF (189) • CCGT-AF (212) • CCGT-AS (212) • CCGW/CCMT (CBN) (227) • CCGW/CCMW-2 (CBN) (228) • CCMT (PCD) (222)
• CCMT-14 (188) • CCMT-CERMET (187) • CCMT-F3M (186) • CCMT-F3P (185) • CCMT-M3M (186) • CCMT-M3P (185) • CCMT-PF (188) • CCMT-WG (189)
• CCMT/CCGT (188) • CCMT/CCGT-SM (187)
Spare Parts
Designation
PCLCR/L-JHP-MC
SL LV-3 SL PI-3 SR 10400150 HW 2.5/5 SR 5/16UNF TL360 S-CU-JHP-A SET
PCLCR/L-JHP-MC
Tools with Channels for
High-Pressure Coolant Carrying
80° Positive Rhombic Inserts
for Swiss Automatic Machines
57
ISOTURN TOOLS
HF
WF
HBKW
LF
LH HBH
B
H
Right-hand shown
9 1°
29°
MAX
Designation
H HF LH HBH B LF WF HBKW Insert
PDACR/L 0808M-07S
8.0 8.0 16.0 2.0 8.0 150.00 8.00 - DC..0702 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PDACR/L 1010M-07S
10.0 10.0 - - 10.0 150.00 10.00 - DC..0702 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PDACR/L 1212M-07S
12.0 12.0 - - 12.0 150.00 12.00 - DC..0702 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PDACR/L 1616M-07S
16.0 16.0 - - 16.0 150.00 16.00 - DC..0702 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PDACR/L 1012M-11S
10.0 10.0 22.0 2.5 12.0 150.00 12.00 2.00 DC..11T3 SL LV-3 SL PI-3 SR 10400150 HW 2.5/5
PDACR/L 1212M-11S
12.0 12.0 - - 12.0 150.00 12.00 2.00 DC..11T3 SL LV-3 SL PI-3 SR 10400150 HW 2.5/5
PDACR/L 1616M-11S
16.0 16.0 - - 16.0 150.00 16.00 - DC..11T3 SL LV-3 SL PI-3 SR 10400150 HW 2.5/5
PDACR/L 2020K-11S
20.0 20.0 - - 20.0 125.00 20.00 - DC..11T3 SL LV-3 SL PI-3 SR 10400150 HW 2.5/5
• The clamping screw may by transferred to the opposite side if needed
For inserts, see pages: DCGT-F1M-20P (192) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194)
• DCET-WF (195) • DCGT-AS (213) • DCGT-AF (213) • DCMT-14 (194) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
PDACR/L-S
Side Lever Lock Tools Carrying
55° Positive Rhombic Inserts
for Swiss Automatic Machines
93°
WF
HF
LH
LF
B
H
Right-hand shown
93º
27°
MAX
Designation
H HF B LF LH WF Insert
SDJCR/L 1616H-13-SL
16.0 16.0 16.0 100.00 24.0 21.00 DCMT 13T5-SL SR M4X0.7-L9.6 IP15 TORX PLUS IP15X45
SDJCR/L 2020K-13-SL
20.0 20.0 20.0 125.00 24.0 27.00 DCMT 13T5-SL SR M4X0.7-L9.6 IP15 TORX PLUS IP15X45
SDJCR/L 2525M-13-SL
25.0 25.0 25.0 150.00 24.0 32.00 DCMT 13T5-SL SR M4X0.7-L9.6 IP15 TORX PLUS IP15X45
• Insert clamping torque 3 Nxm
For inserts, see pages: DCMT-F3P-SL (190) • DCMT-M3M-SL (191) • DCMT-PF-SL (193) • DCMT-SM-SL (193)
SDJCR/L-13-SL
Screw Lock Tools Carrying
55° Diamond Inserts with 7°
Clearance Angle for High Rigidity
in Profiling Applications
58°
93°
WF
DCONMS
GAMF
LF Right-hand shown
93º
27°
MAX
Bar Max
Designation
DCONMS WF LF GAMF Insert CDI(1)
C3 SDJCR-22040-13-SL-JHP
32.00 22.00 40.00 0.0 DCMT 13T5-SL 0
C4 SDJCR/L-27055-13-SL-JHP
40.00 27.00 55.00 0.0 DCMT 13T5-SL 1
C5 SDJCR/L-35060-13-SL-JHP
50.00 35.00 60.00 0.0 DCMT 13T5-SL 1
• For user guide, see pages 78-84
(1) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: DCMT-F3P-SL (190) • DCMT-M3M-SL (191) • DCMT-PF-SL (193) • DCMT-SM-SL (193)
Spare Parts
Designation
C3 SDJCR-22040-13-SL-JHP
CH-1.9D-JHP SR M4X4 DIN913 TL360 SR M4X0.7-L9.5 IP15
C4 SDJCR/L-27055-13-SL-JHP
CU-D-JHP SR M5X5 DIN913 TL360 TORX PLUS IP15X45 SR M4X0.7-L9.6 IP15 T-8/5
C5 SDJCR/L-35060-13-SL-JHP
CU-D-JHP SR M5X5 DIN913 TL360 TORX PLUS IP15X45 SR M4X0.7-L9.6 IP15 T-8/5
C#-SDJCR/L-13-SL-JHP
Screw Clamp Tools with CAMFIX
Shanks and Channels for High
Pressure Coolant Carrying
Positive 55° Rhombic Inserts
ISCAR
58
ISOTURN TOOLS
LH
HF
WF
LF
B
H
SDJCR ...S
Right-hand shown
93º
27°
MAX
Designation
H HF B LF LH WF Insert
SDJCR/L 0808F-07
8.0 8.0 8.0 80.00 11.5 10.00 DC..0702 SR 14-548 T-7/5
SDJCR/L 1010F-07
10.0 10.0 10.0 80.00 11.5 12.00 DC..0702 SR 14-548 T-7/5
SDJCR/L 1212K-07S (1)
12.0 12.0 12.0 125.00 - 12.20 DC..0702 SR 14-548 T-7/5
SDJCR/L 1616K-07S (1)
16.0 16.0 16.0 125.00 - 16.20 DC..0702 SR 14-548 T-7/5
SDJCR/L 1010K-11S (1)
10.0 10.0 10.0 125.00 21.4 10.20 DC..11T3 SR 16-236 T-15/5
SDJCR/L 1212F-11
12.0 12.0 12.0 80.00 20.0 16.00 DC..11T3 SR 16-236 P T-15/5
SDJCR/L 1616H-11
16.0 16.0 16.0 100.00 20.0 20.00 DC..11T3 SR 16-236 P T-15/5
SDJCR/L 2020K-11
20.0 20.0 20.0 125.00 20.0 25.00 DC..11T3 SR 16-236 P T-15/5
SDJCR/L 2525M-11
25.0 25.0 25.0 150.00 20.0 32.00 DC..11T3 SR 16-236 P T-15/5 TDC 3-1P SR TC-3P HW 4.0
(1) For Swiss-type machines
For inserts, see pages: DCGT-F1M-20P (192) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194)
• DCET-WF (195) • DCGT-AS (213) • DCGT-AF (213) • DCMT-14 (194) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
SDJCR/L
Screw Lock Tools Carrying
55° Diamond Inserts with
7° Clearance Angle
OAH
OAW
LF
LH WF
93˚
H
B
93º
27°
MAX
Designation
H B LF LH OAH OAW WF Insert
Y-SDJCR 1212K-11S
12.0 12.0 125.00 21.0 20.00 16.00 0.00 DCMT 11T3..
Y-SDJCR 1616K-11S
16.0 16.0 125.00 21.0 20.00 16.00 0.00 DCMT 11T3..
For inserts, see pages: DCET-WF (195) • DCGT-AF (213) • DCGT-AS (213) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
• DCMT-14 (194) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT (194) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194)
Y-SDJCR
Y-Axis Screw Lock Tools
Carrying 55° Diamond Inserts
with 7° Clearance Angle for
Swiss-Type Machines
OAH
OAW
LH LF
H
UNF 5/16
93˚
B
WF
93º
27°
MAX
Bar Max
Designation
H B LF LH OAH OAW WF Insert
Y-SDJCR 1212K-11S-JHP
12.0 12.0 125.00 21.0 25.50 16.00 0.00 DCMT 11T3..
Y-SDJCR 1616K-11S-JHP
16.0 16.0 125.00 21.0 25.50 16.00 0.00 DCMT 11T3..
For inserts, see pages: DCET-WF (195) • DCGT-AF (213) • DCGT-AS (213) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
• DCMT-14 (194) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT (194) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194)
Y-SDJCR-JHP
Y-Axis Screw Lock Tools
with High-Pressure Coolant
Carrying 55° Diamond Inserts
with 7° Clearance Angle
WF
OAW
HF
OAH
LH
93˚
90˚
90˚ OAL (assembly)
93º
27°
MAX
Bar Max
Designation
WF HF LH OAL OAW Insert
NQCH12-Y-SDJCR-11S-JHP
12.15 12.2 20.0 120.00 20.00 DC.. 11T3 SR 16-236 P T-15/5
NQCH16-Y-SDJCR-11S-JHP
16.15 16.2 20.0 120.00 20.00 DC.. 11T3 SR 16-236 P T-15/5
For user guide, see pages 6-7, 78-84
For inserts, see pages: DCET-WF (195) • DCGT-AF (213) • DCGT-AS (213) • DCGT-F1M-20P (192) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230)
• DCMT (PCD) (222) • DCMT-14 (194) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT (194) • DCMT/DCGT-PF (193)
• DCMT/DCGT-SM (194)
For holders, see pages: NQCH-JHP (61)
NQCH-Y-SDJCR-S-JHP
Y-Axis Screw Lock Modular
Heads with High-Pressure Coolant
- 7° Clearance 55° Rhombic
Inserts for SwissType Machines
59
ISOTURN TOOLS
Holder: MAHPL
Holder: MAHR
17.2
WF WB_2
OAL
HF OAH
WF (assembly) WF (holder)
WF
WF(Assembly)=WF(Holder)+WF
93º
27°
MAX
Designation
HF OAH OAL WF WB_2 Insert
SDJCR-07-PAD
24.0 28.0 42.00 7.50 5.2 DCMT/DCGT 0702 SR 14-548 T-7/5
For inserts, see pages: • DCGT-F1M-20P (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194)
• DCET-WF (195) • DCGT-AS (213) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230)
For holders, see pages: C#-MAHPD-JHP (625) • MAHR/L-JHP-MC (280) • C#-MAHD-JHP (624) • MAHPR/L-JHP (281) • MAHR/L-JHP (279)
• MAHR/L (279) • MAHPR/L (280) • C#-MAHD (624) • C#-MAHPD (625) • C#-MAHDR-45 (623) • C#-MAHDOR (624) • HSK A63WH-MAHUR/L (632)
• HSK A63WH-MAHDR-45 (631) • HSK A63WH-MAHDOR (631) • IM-MAHD (633) • IM-MAHPD (633) • HMSN-New Britain (478) • DGHAL-DECO (478)
SDJCR-PAD
Screw Lock Adapter Carrying
55° Diamond Inserts with
7° Clearance Angle
H
B
LF
LH
HF
107.5°
OAW WF
Right-hand shown
10 7. 5 °
Designation
H HF B LF LH WF OAW Insert
SDHCR/L 1010K-07S
10.0 10.0 10.0 125.00 12.5 10.20 - DC..0702 SR 14-548 T-7/5
SDHCR/L 1212K-07S
12.0 12.0 12.0 125.00 12.0 12.20 - DC..0702 SR 14-548 T-7/5
SDHCR/L 1616K-07S
16.0 16.0 16.0 125.00 12.0 16.20 - DC..0702 SR 14-548 T-7/5
SDHCR/L 1212K-11S
12.0 12.0 12.0 125.00 19.0 12.20 17.0 DC..11T3 SR 16-236 T-15/5
SDHCR/L 1616K-11S
16.0 16.0 16.0 125.00 20.0 16.20 - DC..11T3 SR 16-236 T-15/5
For inserts, see pages: DCGT-F1M-20P (192) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194)
• DCET-WF (195) • DCGT-AS (213) • DCGT-AF (213) • DCMT-14 (194) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
SDHCR/L
Screw Lock Tools Carrying
55° Diamond Inserts with
7° Clearance Angle for
Swiss-Type Machines
WF
DCONMS
LF
Right-hand shown
93º
27°
MAX
70
Bar Max
Designation
DCONMS WF LF Insert CDI(1) CP(2)
C4 SDJCR-27050-11
40.00 27.00 50.00 DC.. 11T3 1 70 TDC 3-1P SR TC-3P HW 4.0 SR 16-236 P T-15/5 EZ 83
C5 SDJCR-35060-11
50.00 35.00 60.00 DC.. 11T3 1 70 TDC 3-1P SR TC-3P HW 4.0 SR 16-236 P T-15/5 EZ 104
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194) • DCET-WF (195)
• DCGT-AS (213) • DCGT-AF (213) • DCMT-14 (194) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
C#-SDJCR/L
Screw Lock Tools with
CAMFIX Exchangeable Shanks
Carrying 55° Rhombic Inserts
with 7° Clearance Angle
58°
93°
WF
DCONMS
LF
Right-hand shown
93º
27°
MAX
Bar Max
Designation
DCONMS WF LF Insert CDI(1) CP(2)
C3 SDJCR-22040-11-JHP
32.00 22.00 40.00 DC.. 11T3 0 140
• For user guide, see pages 78-84
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194) • DCET-WF (195)
• DCGT-AS (213) • DCGT-AF (213) • DCMT-14 (194) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
Spare Parts
Designation
C3 SDJCR-22040-11-JHP
TDC 3-1P SR TC-3P SR 16-236 P T-15/5 CH-1.9D-JHP WASHER 4.2X5.6X0.5 SR M4X4 DIN913 TL360 HW 4.0
C#-SDJCR-JHP
Screw Clamp Tools with CAMFIX
Shanks and Channels for High
Pressure Coolant Carrying
Positive 55° Rhombic Inserts
ISCAR
60
ISOTURN TOOLS
H
B
HF
LF
WF
OAW
LH
Right-hand shown
9 1°
29°
MAX
Designation
H HF B LF LH WF OAW Insert
SDACR/L 1010K-07S
10.0 10.0 10.0 125.00 - 10.00 - DC..0702 SR 14-548 T-7/5
SDACR/L 1212K-07S
12.0 12.0 12.0 125.00 - 12.00 - DC..0702 SR 14-548 T-7/5
SDACR/L 1212K-11S
12.0 12.0 12.0 125.00 20.0 12.00 14.0 DC..11T3 SR 16-236 P T-15/5
SDACR/L 1616K-11S
16.0 16.0 16.0 125.00 - 16.00 - DC..11T3 SR 16-236 P T-15/5
For inserts, see pages: DCGT-F1M-20P (192) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193)
• DCMT/DCGT-SM (194) • DCET-WF (195) • DCGT-AS (213) • DCGT-AF (213) • DCMT-14 (194) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230)
• DCMT (CBN) (230) • DCMT (PCD) (222)
SDACR/L
Screw Lock Tools Carrying
55° Diamond Inserts with
7° Clearance Angle
Holder
WF
OAW
HF
LH
91˚ OAL (assembly)
9 1°
29°
MAX
Bar Max
Designation
WF HF LH OAL OAW Insert
NQCH12-SDACR/L-11S-JHP
12.15 12.0 20.0 120.00 20.15 DC.. 11T3
NQCH16-SDACR/L-11S-JHP
16.15 16.0 20.0 120.00 20.15 DC.. 11T3
• For user guide, see pages 6-7, 78-84
For inserts, see pages: DCET-WF (195) • DCGT-AF (213) • DCGT-AS (213) • DCGT-F1M-20P (192) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230)
• DCMT (PCD) (222) • DCMT-14 (194) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT (194) • DCMT/DCGT-PF (193)
• DCMT/DCGT-SM (194)
For holders, see pages: NQCH-JHP (61)
Spare Parts
Designation
NQCH-SDACR/L-S-JHP
SR 16-236 P T-15/5
NQCH-SDACR/L-S-JHP
Screw Lock Modular Heads
with High-Pressure Coolant - 7°
Clearance 55° Rhombic Inserts
for SwissType Machines
61
ISOTURN TOOLS
LH
GAMF
B
UNF 5/16" typ. 3
H
WF
LF
HF
HBKW HBH
GAMP
Right-hand shown
9 1°
29°
MAX
Bar Max
Designation
H HF B LF LH WF HBKW HBH GAMP GAMF Insert CNT
SDACR/L 1212H-13S-SL-JHP
12.0 12.0 12.0 100.00 27.0 12.15 2.35 3.0 0.0 0.0 DCMT 13T5-SL UNF 5/16 "
SDACR/L 1616K-13S-SL-JHP
16.0 16.0 16.0 125.00 27.0 16.15 - - 0.0 0.0 DCMT 13T5-SL UNF 5/16 "
• For user guide, see pages 78-84
For inserts, see pages: DCMT-F3P-SL (190) • DCMT-M3M-SL (191) • DCMT-PF-SL (193) • DCMT-SM-SL (193)
Spare Parts
Designation
SDACR/L-13S-SL-JHP
CH-1.9D-JHP SR 5/16UNF TL360 TORX PLUS IP15X45 SR M3 CONE SR M4X0.7-L9.6 IP15
SDACR/L-13S-SL-JHP
Tools with Channels for
High-Pressure Coolant Carrying
55° Positive Rhombic Inserts
for Swiss Automatic Machines
CNT
OAL
H
B
OAW
Bar Max
Designation
B H OAL OAW CNT
NQCH-1212-JHP
12.0 12.0 100.00 20.00 UNF 5/16-24
NQCH-1616-JHP
16.0 16.0 100.00 20.00 UNF 5/16-24
For tools, see pages: NQCH-DGTR/L-D-SH-JHP (472) • NQCH-GHSR/L-JHP (374) • NQCH-PCHR/L-S-JHP (378) • NQCH-PCLXR/L-S-JHP (53) • NQCH-SCACR/L-JHP
(55) • NQCH-SCHR/L-BF-JHP (364) • NQCH-SDACR/L-S-JHP (60) • NQCH-SDJNR/L-S-JHP (28) • NQCH-SVACR/L-S-JHP (67) • NQCH-SWLNR/L-S-JHP (8) •
NQCH-Y-SCHR-BF-JHP (364) • NQCH-Y-SDJCR-S-JHP (58) • NQCH-Y-SVJCR-S-JHP (65)
Recommended
Torque7-8 Nm
Clamping Operation Steps
3 - Lock
1 - Unlock
2 - Mount
Attention: The clamping screw is not removable. To avoid undesired
damage, do not apply excessive force when opening or clamping.
Supplied
Accessories
Item No: 7003805
SW6-T-SH
Item No: 7002553
BLD IP20/S7
Recommended
(Optional)
Accessories
Item No: 7007221
TSA 6 44.1-123.5
LBF.IN
(TSA 6 5-14NM)
Item No: 7007027
BLD
6
T20IP
Spare Parts
Designation
NQCH-JHP
SR 5/16UNF TL360 SW6-T-SH BLD IP20/S7 SR M4X4 DIN913 TL360
NQCH-JHP
Square Shank with High-Pressure
Coolant for NEOSWISS Modular
Heads - Swiss Type Machines
ISCAR
62
ISOTURN TOOLS
B
H
GAMP
WF
HBKW
HF
LF
L5
LH
91°
GAMF
Right-hand shown
9 1°
29°
MAX
Bar Max
Designation
H HF B LF LH L5 WF HBKW GAMP GAMF Insert
PDACR/L 1212X-11S-JHP-MC
12.0 12.0 12.0 67.00 28.0 15.00 12.20 2.00 0.0 0.0 DC..11T3
PDACR/L 1616X-11S-JHP-MC
16.0 16.0 16.0 76.00 28.0 17.00 16.20 - 0.0 0.0 DC..11T3
• For user guide, see pages 78-84
For inserts, see pages: DCET-WF (195) • DCGT-AF (213) • DCGT-AS (213) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
• DCMT-14 (194) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT (194) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194)
Spare Parts
Designation
PDACR/L 1212X-11S-JHP-MC
SL LV-3 SL PI-3 SR 10400150 HW 2.5/5 SR 5/16UNF TL360 S-CU-JHP-A SET
PDACR/L 1616X-11S-JHP-MC
SL LV-3 SL PI-3 SR 10400150 HW 2.5/5 SR 5/16UNF TL360 S-CU-JHP-A SET
PDACR/L-JHP-MC
Tools with Channels for
High-Pressure Coolant Carrying
55° Positive Rhombic Inserts
for Swiss Automatic Machines
HF
GAMF
WF HBKW
90°LH LF
UNF 5/16”-24 typex3
B
H
GAMP
Right-hand shown
9 1°
29°
MAX
Bar Max
Designation
H HF B LF LH WF HBKW GAMP GAMF Insert
PDACR/L 1010H-07S-JHP
10.0 10.0 10.0 100.00 20.4 10.20 6.10 0.0 0.0 DC..0702
PDACR/L 1212H-11S-JHP
12.0 12.0 12.0 100.00 28.0 12.20 2.00 0.0 0.0 DC..11T3
PDACR/L 1616K-11S-JHP
16.0 16.0 16.0 125.00 28.0 16.20 - 0.0 0.0 DC..11T3
PDACR/L 2020K-11S-JHP
20.0 20.0 20.0 125.00 28.0 20.20 - 0.0 0.0 DC..11T3
• For user guide, see pages 78-84
For inserts, see pages: DCGT-F1M-20P (192) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194)
• DCET-WF (195) • DCGT-AS (213) • DCGT-AF (213) • DCMT-14 (194) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
Spare Parts
Designation
PDACR/L 1010H-07S-JHP
SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 SR 5/16XUNF-TL-S S-CU-JHP-A SET
PDACR/L 1212H-11S-JHP
SL LV-3 SL PI-3 SR 10400150 HW 2.5/5 SR 5/16UNF TL360 S-CU-JHP-A SET
PDACR/L 1616K-11S-JHP
SL LV-3 SL PI-3 SR 10400150 HW 2.5/5 SR 5/16UNF TL360 S-CU-JHP-A SET
PDACR/L 2020K-11S-JHP
SL LV-3 SL PI-3 SR 10400150 HW 2.5/5 SR 5/16UNF TL360 S-CU-JHP-A SET
PDACR/L-JHP
Tools with Channels for
High-Pressure Coolant Carrying
55° Positive Rhombic Inserts
for Swiss Automatic Machines
63
ISOTURN TOOLS
HF
WF
LH
LF
B
H62.5º
60°
MAX
Designation
H HF B LF LH WF Insert
SDNCN 1616H-13-SL
16.0 16.0 16.0 100.00 25.0 8.00 DCMT 13T5-SL SR M4X0.7-L9.6 IP15 TORX PLUS IP15X45
SDNCN 2020K-13-SL
20.0 20.0 20.0 125.00 25.0 10.00 DCMT 13T5-SL SR M4X0.7-L9.6 IP15 TORX PLUS IP15X45
SDNCN 2525M-13-SL
25.0 25.0 25.0 150.00 25.0 12.50 DCMT 13T5-SL SR M4X0.7-L9.6 IP15 TORX PLUS IP15X45
• Insert clamping torque 3 Nxm
For inserts, see pages: DCMT-F3P-SL (190) • DCMT-M3M-SL (191) • DCMT-PF-SL (193) • DCMT-SM-SL (193)
SDNCN-13-SL
Screw Lock Tools Carrying
55° Diamond Inserts with 7°
Clearance Angle for High Rigidity
in Profiling Applications
GAMF
WF
DCONMS
LF
62.5º
60°
MAX
Bar Max
Designation
DCONMS WF LF GAMF Insert CDI(1) CP(2)
C3 SDNCN-00045-13-SL-JHP
32.00 0.50 45.00 0.0 DCMT 13T5-SL 0 140
C4 SDNCN-00060-13-SL-JHP
40.00 0.50 60.00 0.0 DCMT 13T5-SL 1 140
C5 SDNCN-00060-13-SL-JHP
50.00 0.50 60.00 0.0 DCMT 13T5-SL 1 140
• For user guide, see pages 78-84
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: DCMT-F3P-SL (190) • DCMT-M3M-SL (191) • DCMT-PF-SL (193) • DCMT-SM-SL (193)
Spare Parts
Designation
C3 SDNCN-00045-13-SL-JHP
CH-1.9D-JHP WASHER 4.2X5.6X0.5 SR M4X4 DIN913 TL360 SR M4X0.7-L9.5 IP15
C4 SDNCN-00060-13-SL-JHP
CU-D-JHP TORX PLUS IP15X45 SR M4X0.7-L9.6 IP15 T-8/5
C5 SDNCN-00060-13-SL-JHP
CU-D-JHP TORX PLUS IP15X45 SR M4X0.7-L9.6 IP15 T-8/5
C#-SDNCN-13-SL-JHP
Screw Clamp Tools with CAMFIX
Shanks and Channels for High
Pressure Coolant Carrying
Positive 55° Rhombic Inserts
ISCAR
64
ISOTURN TOOLS
LH
H
HF
LF
WF B
62.5º
60°
MAX
Designation
H HF B LF LH WF Insert
SDNCN 0808F-07
8.0 8.0 8.0 80.00 14.0 4.00 DC..0702 SR 14-548 T-7/5
SDNCN 1010F-07
10.0 10.0 10.0 80.00 14.5 5.00 DC..0702 SR 14-548 T-7/5
SDNCN 1010K-11S (1)
10.0 10.0 10.0 120.00 20.0 5.00 DC..11T3 SR 16-236 T-15/5
SDNCN 1212F-11
12.0 12.0 12.0 80.00 21.3 6.00 DC..11T3 SR 16-236 P T-15/5
SDNCN 1616H-11
16.0 16.0 16.0 100.00 21.0 8.00 DC..11T3 SR 16-236 P T-15/5
SDNCN 2020K-11
20.0 20.0 20.0 125.00 21.0 10.00 DC..11T3 SR 16-236 P T-15/5
SDNCN 2525M-11
25.0 25.0 25.0 150.00 30.0 12.50 DC..11T3 SR 16-236 P T-15/5 TDC 3-1P SR TC-3P HW 4.0
(1) For Swiss-type machines
For inserts, see pages: DCGT-F1M-20P (192) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194)
• DCGT-AS (213) • DCGT-AF (213) • DCMT-14 (194) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
SDNCN
Screw Lock Tools Carrying
55° Diamond Inserts with
7° Clearance Angle
H
HF
LF
WF B
Right-hand shown
9 1°
52°
MAX
Designation
H HF B LF WF Insert
PVACR/L 0808M-11S
8.0 8.0 8.0 150.00 8.00 VC..1103 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PVACR/L 1010M-11S
10.0 10.0 10.0 150.00 10.20 VC..1103 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PVACR/L 1212M-11S
12.0 12.0 12.0 150.00 12.20 VC..1103 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PVACR/L 1616M-11S
16.0 16.0 16.0 150.00 16.20 VC..1103 SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5
PVACR 2020K-11S
20.0 20.0 20.0 125.00 20.20 VC..1103
• The clamping screw may by transferred to the opposite side if needed
For inserts, see pages: VCGT-F1M-20P (196) • VCMT-F3P (195) • VCMT-F3M (195) • VCMT-SM (197) • VCET-WF (197) • VCGT-AS (211)
PVACR/L-S
Side Lever Lock Tools Carrying
35° Positive Rhombic Inserts
for Swiss Automatic Machines
DCONMS
LF
62.5º
60°
MAX
70
Bar Max
Designation
DCONMS LF Insert CDI(1) CP(2)
C4 SDNCN-00050-11
40.00 50.00 DC.. 11T3 1 70 TDC 3-1P SR TC-3P HW 4.0 SR 16-236 P T-15/5 EZ 104
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194) • DCGT-AS (213)
• DCGT-AF (213) • DCMT-14 (194) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
C#-SDNCN
Screw Lock Tools with
CAMFIX Exchangeable Shanks
Carrying 55° Rhombic Inserts
with 7° Clearance Angle
65
ISOTURN TOOLS
LH
HF
WF
LF
B
SVJCR ...S
H
Right-hand shown
50°
MAX
93°
105°
Designation
H HF B LF LH WF Insert
SVJCR/L 0808K-11S (1)
8.0 8.0 8.0 125.00 11.5 8.20 VC..1103 SR 14-560 T-8/5
SVJCR/L 1010K-11S (1)
10.0 10.0 10.0 125.00 22.0 10.20 VC..1103 SR 14-560 T-8/5
SVJCR/L 1212K-11S (1)
12.0 12.0 12.0 125.00 - 12.20 VC..1103 SR 14-560 T-8/5
SVJCR/L 1616K-11
16.0 16.0 16.0 125.00 25.0 20.00 VC..1103 SR 14-560 T-8/5
SVJCR/L 2020K-11
20.0 20.0 20.0 125.00 30.0 25.00 VC..1103 SR 14-560 T-8/5
SVJCR/L 2525M-11
25.0 25.0 25.0 150.00 30.0 32.00 VC..1103 SR 14-560 T-8/5
SVJCR/L 2020K-16
20.0 20.0 20.0 125.00 30.0 25.00 VC..1604 SR 16-236 P T-15/5 TVC 3-1 SR TC-3 HW 2.5
SVJCR/L 2525M-16
25.0 25.0 25.0 150.00 30.0 32.00 VC..1604 SR 16-236 P T-15/5 TVC 3-1 SR TC-3 HW 2.5
(1) For Swiss-type machines
For inserts, see pages: VCGT-F1M-20P (196) • VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196)
• VCMT-SM (197) • VCET-WF (197) • VCGT-AS (211) • VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)
SVJCR/L
93° Lead Angle Screw Lock
Tools Carrying 35° Diamond
Inserts with 7° Clearance Angle
WF
H93˚
LF
LH
OAH
B
OAW
50°
MAX
93°
Designation
H B LF LH OAH OAW WF Insert
Y-SVJCR 1212K-11S
12.0 12.0 125.00 21.0 20.00 16.00 0.00 VCMT 1103..
Y-SVJCR 1616K-11S
16.0 16.0 125.00 21.0 20.00 16.00 0.00 VCMT 1103..
For inserts, see pages: VCET-WF (197) • VCGT-AS (211) • VCGT-F1M-20P (196) • VCMT-F3M (195) • VCMT-F3P (195) • VCMT-SM (197)
Y-SVJCR
Y-Axis 93° Lead Angle Screw
Lock Tools Carrying 35° Diamond
Inserts with 7° Clearance Angle
for Swiss-Type Machines
H
LF
LH
OAH
B
OAW
WF
UNF 5/16
93˚
50°
MAX
93°
Bar Max
Designation
H B LF LH OAH OAW WF Insert
Y-SVJCR 1212K-11S-JHP
12.0 12.0 125.00 21.0 25.50 16.00 0.00 VCMT 1103..
Y-SVJCR 1616K-11S-JHP
16.0 16.0 125.00 21.0 25.50 16.00 0.00 VCMT 1103..
For inserts, see pages: VCET-WF (197) • VCGT-AS (211) • VCGT-F1M-20P (196) • VCMT-F3M (195) • VCMT-F3P (195) • VCMT-SM (197)
Y-SVJCR-JHP
Y-Axis 93° Lead Angle Screw
Lock Tools with High-Pressure
Coolant Carrying 35° Diamond
Inserts with 7° Clearance Angle
WF
OAW
HF
OAH
LH
90˚
93˚
90˚ OAL (assembly)
50°
MAX
93°
Bar Max
Designation
WF HF LH OAL OAW Insert
NQCH12-Y-SVJCR-11S-JHP
12.15 12.2 20.0 120.00 20.15 VC.. 1103
NQCH16-Y-SVJCR-11S-JHP
16.15 16.2 20.0 120.00 20.15 VC.. 1103
• For user guide, see pages 6-7, 78-84
For inserts, see pages: VCET-WF (197) • VCGT (PCD) (223) • VCGT-AS (211) • VCGT-DW (PCD) (223) • VCGT-F1M-20P (196) • VCGW-2 (CBN) (232) • VCMT (CBN) (222)
• VCMT-14 (198) • VCMT-F3M (195) • VCMT-F3P (195) • VCMT-FPC-CERMET (196) • VCMT-M3M (196) • VCMT-SM (197) • VCMW (198)
For holders, see pages: NQCH-JHP (61)
Spare Parts
Designation
NQCH-Y-SVJCR-S-JHP
SR 14-560 T-8/5
NQCH-Y-SVJCR-S-JHP
Y-Axis Screw Lock Modular
Heads with High-Pressure Coolant
- 7° Clearance 35° Rhombic
Inserts for SwissType Machines
ISCAR
66
ISOTURN TOOLS
H
LF
LH
B
WF
HF
G 1/8"-28
GAMF GAMP
KAPR
Central coolant direction
4°
4° (8° rotation adjustment)
50°
MAX
93°
105°
Bar Max
Designation
H B HF LF LH WF KAPR(1) GAMP GAMF Insert
SVJCR/L 2525M-16-JHP
25.0 25.0 25.0 150.00 42.0 32.00 93.0 0.0 0.0 VCMT 1604
• For user guide, see pages 78-84
(1) Tool cutting edge angle
For inserts, see pages: VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197) • VCGT-AS (211)
• VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)
Spare Parts
Designation
SVJCR/L 2525M-16-JHP
TVC 3-1 SR TC-3 SR 16-236 P CU-V-JHP T-15/5 HW 2.5 T-8/5
SVJCR/L-16-JHP
Screw Lock Tools with Channels
for High-Pressure Coolant
Carrying 35° Rhombic Inserts
with 7° Clearance Angle
ECA
L3
GAMF
WF
DCONMS
LF
Central coolant direction
4°
4° (8° rotation adjustment)
50°
MAX
93°
105°
Bar Max
Designation
DCONMS WF LF GAMF ECA L3 Insert CDI(1) CP(2)
C3 SVJCR-22040-11-JHP
32.00 22.00 40.00 0.0 55.0 - VCMT 1103 0 300
C4 SVJCR/L-27055-16-JHP
40.00 27.00 55.00 0.0 55.0 - VCMT 1604 1 300
C5 SVJCR/L-35060-16-JHP
50.00 35.00 60.00 0.0 55.0 - VCMT 1604 1 300
C6 SVJCR-45065-16-JHP
63.00 45.00 65.00 0.0 70.0 16.80 VCMT 1604 1 300
• For user guide, see pages 78-84
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: VCGT-F1M-20P (196) • VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196)
• VCMT-SM (197) • VCET-WF (197) • VCGT-AS (211) • VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)
Spare Parts
Designation
C3 SVJCR-22040-11-JHP
SR 14-560 CH-1.9D-JHP T-8/5
C4 SVJCR/L-27055-16-JHP
TVC 3-1 SR TC-3 T-15/5 SR 16-236 P CU-V-JHP T-8/5 HW 2.5
C5 SVJCR/L-35060-16-JHP
TVC 3-1 SR TC-3 T-15/5 SR 16-236 P CU-V-JHP OR 6.4X0.9N T-8/5 HW 2.5
C6 SVJCR-45065-16-JHP
TVC 3-1 SR TC-3 T-15/5 SR 16-236 P CU-V-JHP T-8/5 HW 2.5
C#-SVJCR/L-JHP
Screw Lock Tools with
CAMFIX Exchangeable Shanks
Carrying 35° Rhombic Inserts
with 7° Clearance Angle
WF
DCONMS
LF Right-hand shown
50°
MAX
93°
105°
70
Bar Max
Designation
DCONMS WF LF Insert CDI(1) CP(2)
C4 SVJCR/L-27050-11
40.00 27.00 50.00 VC.. 1103 1 70 SR 14-560/S M2.5X0.45 T-8/5 EZ 83
C4 SVJCR/L-27050-16
40.00 27.00 50.00 VC.. 1604 1 70 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 83
C5 SVJCR-35060-11
50.00 35.00 60.00 VC.. 1103 1 70 SR 14-560/S M2.5X0.45 T-8/5 EZ 104
C5 SVJCR/L-35060-16
50.00 35.00 60.00 VC.. 1604 1 70 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 104
C6 SVJCR/L-45065-16
63.00 45.00 65.00 VC.. 1604 1 70 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 125
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: VCGT-F1M-20P (196) • VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196)
• VCMT-SM (197) • VCET-WF (197) • VCGT-AS (211) • VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)
C#-SVJCR/L
Screw Lock Tools with
CAMFIX Exchangeable Shanks
Carrying 35° Rhombic Inserts
with 7° Clearance Angle
67
ISOTURN TOOLS
93º
WF WB_2
OAL
HF OAH
WF (assembly)
WF (holder)
WF
HOLDER: MAHPL HOLDER: MAHR
19.5
WF(Assembly)=WF(Holder)+WF
50°
MAX
93°
105°
Designation
HF OAH OAL WF WB_2 Insert
SVJCR-11-PAD
24.0 28.0 42.00 7.50 5.2 VC.. 1103 SR 14-560 T-8/5
For inserts, see pages: VCGT-F1M-20P (196) • VCMT-F3P (195) • VCMT-F3M (195) • VCMT-SM (197) • VCET-WF (197) • VCGT-AS (211)
For holders, see pages: C#-MAHPD-JHP (625) • MAHR/L-JHP-MC (280) • C#-MAHD-JHP (624) • MAHPR/L-JHP (281) • MAHR/L-JHP (279)
• MAHR/L (279) • MAHPR/L (280) • C#-MAHD (624) • C#-MAHPD (625) • C#-MAHDR-45 (623) • C#-MAHDOR (624) • HSK A63WH-MAHUR/L (632)
• HSK A63WH-MAHDR-45 (631) • HSK A63WH-MAHDOR (631) • IM-MAHD (633) • IM-MAHPD (633) • HMSN-New Britain (478) • DGHAL-DECO (478)
SVJCR-PAD
93° Lead Angle Screw Lock
Adapters Carrying 35° Diamond
Inserts with 7° Clearance Angle
HF H
B
WF
LF
Right-hand shown
9 1°
52°
MAX
Designation
H B HF LF WF Insert
SVACR/L 1212K-11S
12.0 12.0 12.0 125.00 12.00 VC..11.. SR 14-560 T-8/5
SVACR 1616K-11S
16.0 16.0 16.0 125.00 16.00 VC..11.. SR 14-560 T-8/5
SVACR/L 1212K-13S
12.0 12.0 12.0 125.00 12.00 VC..13.. SR 14-513 T-8/5
SVACR/L 1616K-13S
16.0 16.0 16.0 125.00 16.00 VC..13.. SR 14-513 T-8/5
SVACR/L 2020K-13S
20.0 20.0 20.0 125.00 20.00 VC..13.. SR 14-513 T-8/5
For inserts, see pages: VCGT-F1M-20P (196) • VCMT-F3P (195) • VCMT-F3M (195) • VCGT-MD/PF (197) • VCMT-SM (197) • VCET-WF (197) • VCGT-AS (211)
SVACR/L
91° Lead Angle Screw Lock
Tools Carrying 35° Diamond
Inserts with 7° Clearance Angle
20
78°
WF DCONMS
LF Right-hand shown
50°
MAX
93°
105°
Designation
DCONMS LF WF Insert CDI(1)
HSK A63WH-SVJCR/L-J16
63.00 110.00 25.00 VC.. 1604 0TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 104
• Complies with ICTM standard (ISO 12164-3). • A cooling tube must be used with all coolant through HSK spindles (should be ordered separately).
• For shank dimensions, see page 735
(1) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197)
• VCGT-AS (211) • VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)
HSK A63WH-SVJCR/L
Tools with HSK Exchangeable
Tapered Shanks Carrying
Positive 35° Inserts for 15°
Mounting on Turn-Mill Machines
Holder
WF
OAW
HF
LH
91˚
OAL (assembly)
9 1°
52°
MAX
Bar Max
Designation
WF HF LH OAL OAW Insert
NQCH12-SVACR/L-11S-JHP
12.15 12.0 20.0 120.00 20.15 VC.. 1103 SR 14-560 T-8/5
NQCH16-SVACR/L-11S-JHP
16.15 16.0 20.0 120.00 20.15 VC.. 1103 SR 14-560 T-8/5
• For user guide, see pages 6-7, 78-84
For inserts, see pages: VCET-WF (197) • VCGT (PCD) (223) • VCGT-AS (211) • VCGT-DW (PCD) (223) • VCGT-F1M-20P (196) • VCGT-MD/PF (197)
• VCGW-2 (CBN) (232) • VCMT (CBN) (222) • VCMT-14 (198) • VCMT-F3M (195) • VCMT-F3P (195) • VCMT-FPC-CERMET (196) • VCMT-M3M (196) • VCMT-SM (197)
• VCMW (198)
For holders, see pages: NQCH-JHP (61)
NQCH-SVACR/L-S-JHP
Screw Lock Modular Heads with
High-Pressure Coolant Carrying
7° Clearance 35° Rhombic
Inserts for SwissType Machines
ISCAR
68
ISOTURN TOOLS
HF
WF
HBKW
LH LF
B
H
UNF 5/16”-24 typx3
91°
GAMF GAMP
Right-hand shown
9 1°
52°
MAX
Bar Max
Designation
H HF B LF LH WF HBKW GAMP GAMF Insert
PVACR 1010H-11S-JHP
10.0 10.0 10.0 100.00 20.0 10.20 5.80 0.0 0.0 VC..1103
PVACR/L 1212H-11S-JHP
12.0 12.0 12.0 100.00 20.0 12.20 3.80 0.0 0.0 VC..1103
PVACR/L 1616K-11S-JHP
16.0 16.0 16.0 125.00 20.0 16.20 - 0.0 0.0 VC..1103
PVACR/L 2020K-11S-JHP
20.0 20.0 20.0 125.00 25.0 20.20 - 0.0 0.0 VC..1103
• For user guide, see pages 78-84
For inserts, see pages: VCGT-F1M-20P (196) • VCMT-F3P (195) • VCMT-F3M (195) • VCMT-SM (197) • VCET-WF (197) • VCGT-AS (211)
Spare Parts
Designation
PVACR/L 1212H-11S-JHP
SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 SR 5/16UNF TL360 S-CU-JHP-A SET
PVACR/L 1616K-11S-JHP
SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 SR 5/16UNF TL360 S-CU-JHP-A SET
PVACR 2020K-11S-JHP
SL LV-2 SL PI-2 PIN SR 10400611 HW 2.5/5 SR 5/16UNF TL360 S-CU-JHP-A SET
PVACR/L-JHP
Tools with Channels for
High-Pressure Coolant Carrying
35° Positive Rhombic Inserts
for Swiss Automatic Machines
H
LF
LH L5
WF
KAPR
B
H
HBKW
9 1°
52°
MAX
Bar Max
Designation
H B LF LH L5 WF HBKW Insert KAPR(1)
PVACR/L 1212X-11S-JHP-MC
12.0 12.0 70.00 25.0 21.00 12.20 3.80 VC..1103 91.0
PVACR/L 1616X-11S-JHP-MC
16.0 16.0 73.00 26.0 16.00 16.20 - VC..1103 91.0
• For user guide, see pages 78-84
(1) Tool cutting edge angle
For inserts, see pages: VCET-WF (197) • VCGT-AS (211) • VCGT-F1M-20P (196) • VCMT-F3M (195) • VCMT-F3P (195) • VCMT-SM (197)
Spare Parts
Designation
PVACR/L-JHP-MC
SL LV-2 SL PI-2 PIN SR 10400611 HW 2.0/5 SR 5/16UNF TL360 S-CU-JHP-A SET
PVACR/L-JHP-MC
Tools with Channels for
High-Pressure Coolant Carrying
35° Positive Rhombic Inserts
for Swiss Automatic Machines
69
ISOTURN TOOLS
LH
HF
WF
LF
B
H
72.5º
70°MAX
Designation
H HF B LF LH WF Insert
SVVCN 0808K-11S (1)
8.0 8.0 8.0 125.00 - 4.30 VC..1103 SR 14-560 T-8/5
SVVCN 1010K-11S (1)
10.0 10.0 10.0 125.00 - 5.30 VC..1103 SR 14-560 T-8/5
SVVCN 1212K-11S (1)
12.0 12.0 12.0 125.00 - 6.30 VC..1103 SR 14-560 T-8/5
SVVCN 1616K-11S (1)
16.0 16.0 16.0 125.00 - 8.30 VC..1103 SR 14-560 T-8/5
SVVCN 2020K-16
20.0 20.0 20.0 125.00 34.0 10.00 VC..1604 SR 16-236 P T-15/5 TVC 3-1 SR TC-3 HW 2.5
SVVCN 2525M-16
25.0 25.0 25.0 150.00 38.1 12.50 VC..1604 SR 16-236 P T-15/5 TVC 3-1 SR TC-3 HW 2.5
(1) For Swiss-type machines
For inserts, see pages: VCGT-F1M-20P (196) • VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196)
• VCMT-SM (197) • VCGT-AS (211) • VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)
SVVCN
72.5° Lead Angle Screw Lock
Tools Carrying 35° Diamond
Inserts with 7° Clearance Angle
LH
HF
WF
LF
B
H
Right-hand shown
112°
31°
MAX
Designation
H HF B LF LH WF Insert
SVXCR/L 2020K-16
20.0 20.0 20.0 125.00 25.0 25.00 VC..1604 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5
SVXCR/L 2525M-16
25.0 25.0 25.0 150.00 30.0 32.00 VC..1604 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5
For inserts, see pages: VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197) • VCGT-AS (211)
• VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)
SVXCR/L
112° Lead Angle Screw Lock
Tools Carrying 35° Diamond
Inserts with 7° Clearance Angle
H
B
LF
LH
HF
WF
117.5˚
Right-hand shown
11 7. 5 °
Designation
H HF B LF LH WF Insert
SVPCR/L 1212K-11S
12.0 12.0 12.0 125.00 19.0 12.20 VC..1103 SR 14-560 T-8/5
SVPCR/L 1616K-11S
16.0 16.0 16.0 125.00 - 16.20 VC..1103 SR 14-560 T-8/5
For inserts, see pages: VCGT-F1M-20P (196) • VCMT-F3P (195) • VCMT-F3M (195) • VCMT-SM (197) • VCGT-AS (211)
SVPCR/L
117° Lead Angle Screw Lock
Tools Carrying 35° Diamond
Inserts with 7° Clearance Angle
DCONMS
LF
72.5º
70°MAX
70
Bar Max
Designation
DCONMS LF Insert CDI(1) CP(2)
C4 SVVCN-00050-16
40.00 40.00 VC.. 1604 1 70 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 83
C5 SVVCN-00060-16
50.00 50.00 VC.. 1604 1 70 TVC 3-1 SR TC-3 HW 2.5 SR 16-236 P T-15/5 EZ 125
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197)
• VCGT-AS (211) • VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)
C#-SVVCN
Screw Lock Tools with
CAMFIX Exchangeable Shanks
Carrying 35° Rhombic Inserts
with 7° Clearance Angle
ISCAR
70
ISOTURN TOOLS
LH
HF
WF
LF
B
H
Right-hand shown
75º
Designation
H HF B LF LH WF Insert
SSBCR/L 1616H-09
16.0 16.0 16.0 100.00 15.0 13.00 SC.. 09T3 SR 16-236 T-15/5
SSBCR/L 2020K-12
20.0 20.0 20.0 125.00 19.0 17.00 SC..1204 SR 16-212 T-20/5
SSBCR/L 2525M-12
25.0 25.0 25.0 150.00 19.0 22.00 SC..1204 SR 16-212 T-20/5 TSC 4-2 SR TC-4 HW 3.0
For inserts, see pages: SCMT-F3P (198) • SCMT-M3P (199) • SCMT-F3M (199) • SCMT-M3M (199) • SCMT-SM (200) • SCGT-AS (211)
• SCMT-14 (200) • SCMT-19 (200)
SSBCR/L
75° Lead Angle Screw Lock
Tools Carrying Square Inserts
with 7° Clearance Angle
LH
HF
WF
LF
B
H
Right-hand shown
45
º
45º
Designation
H HF B LF LH WF Insert
SSSCR/L 1212F-09
12.0 12.0 12.0 80.00 18.0 16.00 SC.. 09T3 SR 16-236 T-15/5
SSSCR/L 1616H-09
16.0 16.0 16.0 100.00 18.0 20.00 SC.. 09T3 SR 16-236 T-15/5
SSSCR/L 2020K-12
20.0 20.0 20.0 125.00 22.0 25.00 SC.. 1204 SR 16-212 T-20/5
SSSCR/L 2525M-12
25.0 25.0 25.0 150.00 25.0 32.00 SC.. 1204 SR 16-212 T-20/5 TSC 4-2 SR TC-4 HW 3.0
For inserts, see pages: SCMT-F3P (198) • SCMT-M3P (199) • SCMT-F3M (199) • SCMT-M3M (199) • SCMT-SM (200) • SCGT-AS (211)
• SCMT-14 (200) • SCMT-19 (200)
SSSCR/L
45° Lead Angle Screw Lock
Tools Carrying Square Inserts
with 7° Clearance Angle
LH
HF
WF
LF
B
H
Right-hand shown
91º
Designation
H HF B LF LH WF Insert
STFCR/L 1212F-11
12.0 12.0 12.0 80.00 13.0 16.00 TC.. 1102 SR 14-548 T-7/5
STFCR/L 2020K-16
20.0 20.0 20.0 125.00 18.0 25.00 TC.. 16T3 SR 16-236 T-15/5
STFCR/L 2525M-16
25.0 25.0 25.0 150.00 20.0 32.00 TC.. 16T3 SR 16-236 T-15/5 TTC 3-2 SR TC-3 HW 2.5
For inserts, see pages: TCMT-F3P (201) • TCMT-M3M (201) • TCMT-PF (201) • TCMT-SM (202) • TCGT-AS (211) • TCMT (CBN) (234)
• TCMT (PCD) (223)
STFCR/L
Screw Lock Tools Carrying
Triangular Inserts with 7°
Clearance Angle for Face Turning
LH
HF
WF
LF
B
H
Right-hand shown
91º
Designation
H HF B LF LH WF Insert
STGCR/L 1212F-11
12.0 12.0 12.0 80.00 13.0 16.00 TC.. 1102 SR 14-548 T-7/5
STGCR/L 1616H-11
16.0 16.0 16.0 100.00 13.0 20.00 TC.. 1102 SR 14-548 T-7/5
STGCR/L 2020K-16
20.0 20.0 20.0 125.00 18.0 25.00 TC.. 16T3 SR 16-236 T-15/5
STGCR/L 2525M-16
25.0 25.0 25.0 150.00 18.0 32.00 TC.. 16T3 SR 16-236 T-15/5 TTC 3-2 SR TC-3 HW 2.5
For inserts, see pages: TCMT-F3P (201) • TCMT-M3M (201) • TCMT-PF (201) • TCMT-SM (202) • TCGT-AS (211) • TCMT (CBN) (234) • TCMT (PCD) (223)
STGCR/L
91° Lead Angle Screw Lock
Tools Carrying Triangular Inserts
with 7° Clearance Angle
71
ISOTURN TOOLS
LH
HF
WF
LF
B
H
Right-hand shown
Designation
H HF B LF LH WF Insert
SRGCR/L 1616H-08
16.0 16.0 16.0 100.00 11.0 20.00 RCMT 0803MO
SRGCR/L 2020K-10
20.0 20.0 20.0 125.00 14.0 25.00 RCMT 10T3MO
SRGCR 2525M-10
25.0 25.0 25.0 150.00 18.0 32.00 RCMT 10T3MO
SRGCR/L 2525M-12
25.0 25.0 25.0 150.00 18.0 32.00 RCMT 1204MO
SRGCR/L 2525M-16
25.0 25.0 25.0 150.00 20.0 32.00 RCMT 1606MO
SRGCR/L 3232P-20
32.0 32.0 32.0 170.00 25.0 40.00 RCMT 2006MO
For inserts, see pages: RCGT-AS (213) • RCMT-14 (202) • RCMT-SR (202)
Spare Parts
Designation
SRGCR/L 1616H-08
SR 14-513 T-8/5
SRGCR/L 2020K-10
T-15/5
SRGCR 2525M-10
TRC 3-0 SR TC-3 T-15/5
SRGCR/L 2525M-12
SR 16-212 TRC 4-0 SR TC-4 T-20/5 HW 3.0
SRGCR/L 2525M-16
SR 16-212 TRC 5-0 SR TC-4 T-20/5 HW 3.0
SRGCR/L 3232P-20
SR 14-519 TRC 6-0 SR TC-6 HW 4.0 BLD T20/S7 SW6-T-SH
SRGCR/L
Screw Lock Tools Carrying Round
Inserts with 7° Clearance Angle
HF
GAMF
WF
H
GAMP
Frontal coolant
on/off screw
Frontal coolant hole
B
LH
G 1/8"-28
LF
Central coolant direction
(8° rotation adjustment)
4°
4°
Bar Max
Designation
H B HF LF LH WF GAMP GAMF Insert
SRGCR 2525M-12-JHP
25.0 25.0 25.0 150.00 30.0 32.00 0.0 0.0 RCMT 1204
• For user guide, see pages 78-84
For inserts, see pages: RCMT-14 (202)
Spare Parts
Designation
SRGCR 2525M-12-JHP
TRC 4-0 SR TC-4 T-8/5 SR 16-212 T-20/5 CU-R-JHP SR M4X4 DIN913 TL360 HW 2.0 HW 3.0
SRGCR-12-JHP
Screw Lock Tools with
Channels for High-Pressure
Coolant Carrying Round Inserts
with 7° Clearance Angle
WF
DCONMS
LF Right-hand shown
70
Bar Max
Designation
DCONMS WF LF Insert CDI(1) CP(2)
C5 SRGCR-35060-12
50.00 35.00 60.00 RCMT 1204MO 1 70 TRC 4-0 SR TC-4 HW 3.0 SR 16-212 T-20/5 EZ 104
(1) 1 - Hole for data chip, 0 - Without hole for data chip
(2) Coolant pressure (Bar)
For inserts, see pages: RCMT-14 (202)
C#-SRGCR/L
Screw Lock Tools with
CAMFIX Exchangeable Shanks
Carrying Round Inserts
with 7° Clearance Angle
ISCAR
72
ISOTURN TOOLS
LF
H
B
H
WF
LH
Designation
H HF B LF LH WF Insert
PRDCN 4040S-25
40.0 40.0 40.0 250.00 80.0 20.00 RCMX 2507 TRC 25 SP 66 HW 4.0 SR 10402289 LR 25C
PRDCN 5050U-32
50.0 50.0 50.0 350.00 90.0 25.00 RCMX 3209 TRC 32 SP 8 HW 5.0 SR 10402264 LR 32C
For inserts, see pages: RCMX-NR (203)
PRDCN
Lever Lock Tools Carrying
RCMX Round Inserts
LH
HF
WF
LF
B
H
Designation
H HF B LF LH WF Insert
SRDCN 1616H-08
16.0 16.0 16.0 100.00 33.0 8.00 RCMT 0803MO
SRDCN 2020K-10
20.0 20.0 20.0 125.00 38.0 10.00 RCMT 10T3MO
SRDCN 2525M-12
25.0 25.0 25.0 150.00 50.0 12.50 RCMT 1204MO
SRDCN 3225P-12
32.0 32.0 25.0 170.00 50.0 12.50 RCMT 1204MO
SRDCN 3225P-16
32.0 32.0 25.0 170.00 50.0 12.50 RCMT 1606MO
SRDCN 3232P-20
32.0 32.0 32.0 170.00 50.0 16.00 RCMT 2006MO
For inserts, see pages: RCGT-AS (213) • RCMT-14 (202) • RCMT-SR (202)
Spare Parts
Designation
SRDCN 1616H-08
SR 14-513 T-8/5
SRDCN 2020K-10
SR 16-236 T-15/5
SRDCN 2525M-12
SR 16-212 T-20/5 TRC 4-0 SR TC-4 HW 3.0
SRDCN 3225P-12
SR 16-212 T-20/5 TRC 4-0 SR TC-4 HW 3.0
SRDCN 3225P-16
SR 16-212 T-20/5 TRC 5-0 SR TC-4 HW 3.0
SRDCN 3232P-20
SR 14-519 TRC 6-0 SR TC-6 HW 4.0 BLD T20/S7 SW6-T-SH
SRDCN
Screw Lock Neutral Tools
Carrying Round Inserts
with 7° Clearance Angle
LF
H
WF
H
B
LH
Right-hand shown
Designation
H B HF LF LH WF Insert
PRGCR 4040S-25
40.0 40.0 40.0 250.00 30.0 50.00 RCMX 2507 TRC 25 SP 66 SR 10402289 LR 25C HW 4.0
For inserts, see pages: RCMX-NR (203)
PRGCR
Lever Lock Tools Carrying
RCMX Round Inserts
ECA
L3
WF
DCONMS
LF
Central coolant direction
(8° rotation adjustment)
4°
4°
Bar Max
Designation
DCONMS WF LF ECA L3 Insert CDI(2) CP(1)
C6 SRGCR-45065-12-JHP
63.00 45.00 65.00 60.0 16.00 RCMT 1204MO 1 300 TRC 4-0 SR TC-4 T-20/5 SR 16-212 HW 3.0 CU-R-JHP T-8/5
• For user guide, see pages 78-84
(1) Coolant pressure (Bar)
(2) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: RCMT-14 (202)
C#-SRGCR-12-JHP
Screw Lock Tools with
CAMFIX Exchangeable Shanks
Carrying Round Inserts
with 7° Clearance Angle
73
ISOTURN TOOLS
HF
WF
LF
B
H
T
Right-hand shown
95°
Designation
H B HF LF WF T Insert
PQLCR/L 1212M-09S
12.0 12.0 12.0 150.00 12.00 8.5 QCMT 09T3 SL LV-3 SL PI-3 SR 10400150 HW 2.5/5
For inserts, see pages: QCMT-PF (203) • QCMT-SM (203)
PQLCR/L-S
Side Lever Lock Tools Carrying
80° Positive 4-Cornered Inserts
for Swiss Automatic Machines
HF
WF
LH
LF
B
H
TRight-hand shown
95°
Designation
H HF B LF LH WF T Insert
PQLCR/L 1616H-09
16.0 16.0 16.0 100.00 22.0 20.00 8.5 QCMT 09T3
PQLCR/L 2020K-09
20.0 20.0 20.0 125.00 25.0 25.00 8.5 QCMT 09T3
PQLCR/L 2525M-09
25.0 25.0 25.0 150.00 26.0 32.00 8.5 QCMT 09T3
For inserts, see pages: QCMT-PF (203) • QCMT-SM (203)
Spare Parts
Designation
PQLCR/L
TXC 322 SP 3 PN 3-4 LR 3 SR 117-2014 HW 2.5/5
PQLCR/L
Lever Lock Tools Carrying 80°
Positive 4-Cornered Inserts
HF
WF
LF
KAPR
B
H
Right-hand shown
90°
Designation
H HF B LF WF KAPR(1) Insert
SWAPR/L 0808-04
8.0 8.0 8.0 140.00 8.10 90.0 WPEB/X 04.. T-8/5 SR M3.0R/L
SWAPR 1010-04
10.0 10.0 10.0 150.00 10.10 90.0 WPEB/X 04.. T-8/5 SR M3.0R
SWAPR/L 1010-05
10.0 10.0 10.0 150.00 10.10 90.0 WPEB/X 05.. T-8/5 SR M3.5R/L
SWAPL 1212-05
12.0 12.0 12.0 150.00 12.10 90.0 WPEB/X 05.. T-8/5 SR M3.5R/L
SWAPR/L 1212-06
12.0 12.0 12.0 150.00 12.10 90.0 WPEB/X 06.. T-8/5 SR M3.5R/L
SWAPR 1414-06
14.0 14.0 14.0 150.00 14.10 90.0 WPEB/X 06.. T-8/5 SR M3.5R/L
SWAPR/L 1616-06
16.0 16.0 16.0 150.00 16.10 90.0 WPEB/X 06.. T-8/5 SR M3.5R/L
• For R.H. tool use -R screw, for L.H. tool use -L screw.
(1) Tool cutting edge angle
For inserts, see pages: WPEX (208)
SWAPR/L
90° Lead Angle Screw Lock
Tools Carrying Trigon Inserts for
Swiss Automatic Machines
Holder: MAHPL
Holder: MAHR
17.2
WF WB_2
OAL
HF OAH
WF (assembly) WF (holder)
WF
WF(Assembly)=WF(Holder)+WF
90°
Designation
HF OAH OAL WF WB_2 Insert
SWAPR-06-PAD
24.0 28.0 42.00 7.50 5.2 WPEX/B 0604 SR M3.5R T-8/5
For inserts, see pages: WPEX (208)
For holders, see pages: C#-MAHD-JHP (624) • C#-MAHPD-JHP (625) • MAHR/L-JHP-MC (280) • MAHPR/L-JHP (281) • MAHR/L-JHP (279)
• MAHR/L (279) • MAHPR/L (280) • C#-MAHD (624) • C#-MAHPD (625) • C#-MAHDR-45 (623) • C#-MAHDOR (624) • HSK A63WH-MAHUR/L (632)
• HSK A63WH-MAHDR-45 (631) • HSK A63WH-MAHDOR (631) • IM-MAHD (633) • IM-MAHPD (633) • HMSN-New Britain (478) • DGHAL-DECO (478)
SWAPR-PAD
90° Lead Angle Screw Lock
Adapters Carrying Trigon Inserts
for Swiss Automatic Machines
ISCAR
74
ISOTURN TOOLS
HF
WF
KAPR LF
B
H
Right-hand shown
45°
Designation
H HF B LF WF KAPR(1) Insert
SWDPR 1010-04
10.0 10.0 10.0 150.00 10.10 45.0 WPEB/X 04.. T-8/5 SR M3.0R
SWDPR/L 1212-05
12.0 12.0 12.0 150.00 12.10 45.0 WPEB/X 05.. T-8/5 SR M3.5R/L
SWDPR 1616-06
16.0 16.0 16.0 150.00 16.10 45.0 WPEB/X 06.. T-8/5 SR M3.5R
• For R.H. tool use -R screw, for L.H. tool use -L screw
(1) Tool cutting edge angle
For inserts, see pages: WPEX (208)
SWDPR/L
45° Lead Angle Screw Lock
Tools Carrying Trigon Inserts for
Swiss Automatic Machines
LH
HF
WF
LF
B
H
Right-hand shown
45
º
45º
Designation
H HF B LF LH WF Insert
CSSPR 1212F-09
12.0 12.0 12.0 80.00 21.0 16.00 SPMR 0903 LC 15 SET 1 HW 2.5
CSSPR 1616H-12 (1)
16.0 16.0 16.0 100.00 26.0 20.00 SPMR 1203 ISQP 162 SP 16 LC 30 SET 2 HW 3.0
CSSPR 2020K-12 (1)
20.0 20.0 20.0 125.00 26.0 25.00 SPMR 1203 ISQP 162 SP 16 LC 30 SET 1 HW 3.0
CSSPR/L 2525M-12 (1)
25.0 25.0 25.0 150.00 28.0 32.00 SPMR 1203 ISQP 162 SP 16 LC 30 SET 1 HW 3.0
(1) ISQP 163 for inserts with corner radii 1.6-2.4 mm.
For inserts, see pages: SPMR (204)
CSSPR/L
Clamp Lock Tools Carrying 11°
Clearance Square Inserts for
Longitudinal and Face Turning
LH
HF
WF
LF
B
H
45°
Designation
H HF B LF LH WF Insert
CSDPN 2020K-12
20.0 20.0 20.0 125.00 30.0 10.00 SPMR 1203 ISQP 162(a) SP 16 LC 30 SET 1 HW 3.0
CSDPN 2525M-12
25.0 25.0 25.0 150.00 30.0 12.50 SPMR 1203 ISQP 162(a) SP 16 LC 30 SET 1 HW 3.0
(a) Use ISQP 163 seat for inserts with corner radii 1.6-2.4 mm
For inserts, see pages: SPMR (204)
CSDPN
45° Lead Angle Clamp
Lock Tools Carrying 11°
Clearance Square Inserts
LH
HF
WF
LF
B
H
Right-hand shown
91º
Designation
H HF B LF LH WF Insert
CTGPR/L 1212F-11
12.0 12.0 12.0 80.00 17.0 16.00 TPMR/TPGN 1103 LC 15 SET 1 HW 2.5
CTGPR 1616H-11
16.0 16.0 16.0 100.00 16.0 20.00 TPMR/TPGN 1103 LC 15 SET 1 HW 2.5
CTGPR/L 2020K-16
20.0 20.0 20.0 125.00 26.0 25.00 TPMR/TPGN 1603 ITBP 122 ITBP 123* SP 16(a) LC 30 SET 1 HW 3.0
CTGPR/L 2525M-16
25.0 25.0 25.0 150.00 26.0 32.00 TPMR/TPGN 1603 ITBP 122 ITBP 123* SP 16(a) LC 30 SET 1 HW 3.0
* Optional, should be ordered separately
(a) Use ITBP 123 seat for inserts with corner radii 1.6-2.4 mm
For inserts, see pages: TPGN-Ceramic (220) • TPMR (204) • TPMR-FTF (205) • TPMR-PF (204)
CTGPR/L
Clamp Lock Tools Carrying 11°
Clearance Triangular Inserts
75
ISOTURN TOOLS
LH
HF
WF
LF
B
H
Right-hand shown
91º
Designation
H HF B LF LH WF GAMP GAMF Insert
CTFPR 1212F-11
12.0 12.0 12.0 80.00 16.0 16.00 0.0 6.0 TPMR/TPGN 1103
CTFPR/L 1616H-11
16.0 16.0 16.0 100.00 16.0 20.00 0.0 6.0 TPMR/TPGN 1103
CTFPR 2020K-16
20.0 20.0 20.0 125.00 22.0 25.00 0.0 6.0 TPMR/TPGN 1603
CTFPR/L 2525M-16
25.0 25.0 25.0 150.00 22.0 32.00 0.0 6.0 TPMR/TPGN 1603
For inserts, see pages: TPGN-Ceramic (220) • TPMR (204) • TPMR-FTF (205) • TPMR-PF (204)
Spare Parts
Designation
CTFPR 1212F-11
HW 2.5 LC 15 SET 1
CTFPR/L 1616H-11
HW 2.5 LC 15 SET 1
CTFPR 2020K-16
ITBP 122 HW 3.0 SP 16 LC 30 SET 1 ITBP 123*
CTFPL 2525M-16
ITBP 122 HW 3.0 SP 16 LC 30 SET 1
CTFPR 2525M-16
ITBP 122 HW 3.0 SP 16 LC 30 SET 1 ITBP 123*
* Optional, should be ordered separately
CTFPR/L
Clamp Lock Tools Carrying
11° Clearance Triangular
Inserts for Face Turning
DCONMS
LF
LB
LU
WF
WF2
Rotation Range 120˚ MDX
Designation
DCONMS LU LB LF WF WF2 MDX(1) MIID(2) CDI(3)
HSK A63WH-SDJCN-13SL-100Y
63.00 39.60 67.40 100.00 13.44 18.1 215.00 DCMT 13T504-F3P-SL 0
HSK A63WH-SDJCN-13SL-125Y
63.00 64.60 92.40 125.00 13.44 18.1 390.00 DCMT 13T504-F3P-SL 0
• A cooling tube must be used with all coolant through HSK spindles (should be ordered separately). • For shank dimensions, see page 735
(1) Machinable diameter maximum
(2) Master insert identification
(3) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: DCMT-F3P-SL (190) • DCMT-M3M-SL (191) • DCMT-PF-SL (193) • DCMT-SM-SL (193)
120°
Spare Parts
Designation
HSK A63WH-SDJCN-13-Y
CH-1.9D-JHP-A SET BLD IP15/S7 SW6-T-SH SR M4X4 DIN913 TL360 SR M4X0.7-L9.6 IP15
HSK A63WH-SDJCN-13-Y
Y-Axis Turning Tools Carrying
55° Diamond Inserts with
7° Clearance Angle
ISCAR
76
ISOTURN TOOLS
BD
Fitting Tube
DCONMS
JHP Coolant
LF Rotation Range 60˚
Designation
DCONMS BD LF MIID(1) CSP(2)
AVC-D25-SDJCN-13-SL-Y
25.00 26.00 20.00 DCMT 13T504-F3P-SL 1
AVC-D32-SDJCN-13-SL-Y
32.00 33.00 23.00 DCMT 13T504-F3P-SL 1
AVC-D40-SDJCN-13-SL-Y
40.00 41.00 25.00 DCMT 13T504-F3P-SL 1
(1) Master insert identification
(2) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: DCMT-F3P-SL (190) • DCMT-M3M-SL (191) • DCMT-PF-SL (193) • DCMT-SM-SL (193)
For holders, see pages: C#-SH-E-JHP (630) • C#-SH-JHP (630)
Spare Parts
Designation
AVC-SDJCN-Y
CH-1.9D-JHP-A SET SR M5X5 DIN913 TL360 BLD IP15/S7 SW6-T-SH SR M4X0.7-L9.6 IP15 PIN FT39 D6-5X11
AVC-SDJCN-Y
Interchangeable Heads Carrying
55° Rhombic Inserts
WF2
WF DCONMS
LB
LF
LU
MDX
Rotation Range 120˚
Designation
DCONMS LU LB LF WF WF2 MDX(1) Insert CDI(2)
HSK A63WH-SRDCN-16-100Y
63.00 34.90 69.80 100.00 15.00 16.5 240.00 RCMT 1606MO-14 0
HSK A63WH-SRDCN-16-125Y
63.00 60.00 93.40 125.00 15.00 16.5 380.00 RCMT 1606MO-14 0
• A cooling tube must be used with all coolant through HSK spindles (should be ordered separately). • For shank dimensions, see page 735
(1) Machinable diameter maximum
(2) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: RCMT-14 (202) • RCMT-SR (202)
Spare Parts
Designation
HSK A63WH-RCMT-Y
TRC 5-0 SR TC-4 CH-1.9D-JHP-A SET SR 16-212 HW 3.0 BLD T20/S7 SW6-T-SH
HSK A63WH-RCMT-Y
Y-Axis Turning Tools
Carrying Round Inserts
with 7° Clearance Angle
DCONMS
MDX
LF
WF2 LU
LB
WF
Rotation Range 120˚
70
Bar Max
Designation
DCONMS LU LB LF WF WF2 MDX(1) MIID(2) CDI(3)
C4-SDJCN-13-SL-H65-Y
40.00 18.80 40.20 65.00 8.64 11.4 120.00 DCMT 13T504-F3P-SL 0
C4-SDJCN-13-SL-H80-Y
40.00 30.30 54.40 80.00 8.64 11.4 210.00 DCMT 13T504-F3P-SL 0
C5-SDJCN-13-SL-H80-Y
50.00 28.20 53.70 80.00 10.76 14.2 180.00 DCMT 13T504-F3P-SL 0
C5-SDJCN-13-SL-H100-Y
50.00 48.20 73.70 100.00 10.76 14.2 320.00 DCMT 13T504-F3P-SL 0
C6-SDJCN-13-SL-H100-Y
63.00 46.80 73.80 100.00 13.44 18.1 260.00 DCMT 13T504-F3P-SL 0
C6-SDJCN-13-SL-H125-Y
63.00 71.30 98.30 125.00 13.44 18.1 420.00 DCMT 13T504-F3P-SL 0
• For user guide, see page 622
(1) Machinable diameter maximum
(2) Master insert identification
(3) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: DCMT-F3P-SL (190) • DCMT-M3M-SL (191) • DCMT-PF-SL (193) • DCMT-SM-SL (193)
Spare Parts
Designation
C#-SDJCN-13-Y
CH-1.9D-JHP-A SET BLD IP15/S7 SW6-T-SH SR M4X4 DIN913 TL360 SR M4X0.7-L9.6 IP15
C#-SDJCN-13-Y
Y-Axis Turning Tools Carrying
55° Diamond Inserts with
7° Clearance Angle
77
ISOTURN TOOLS
WF2
WF DCONMS
LB
LF
LU
MDX
Rotation Range 120˚
70
Bar Max
Designation
DCONMS LU LB LF WF WF2 MDX(1) Insert CDI(2)
C4-SRDCN-16-H65-Y
40.00 21.90 41.50 65.00 9.50 10.5 130.00 RCMT 1606M0-14 0
C4-SRDCN-16-H80-Y
40.00 36.80 56.70 80.00 9.50 10.5 210.00 RCMT 1606M0-14 0
C5-SRDCN-16-H80-Y
50.00 27.00 56.20 80.00 12.00 13.0 180.00 RCMT 1606M0-14 0
C5-SRDCN-16-H100-Y
50.00 44.40 76.20 100.00 12.00 13.0 350.00 RCMT 1606M0-14 0
C6-SRDCN-16-H100-Y
63.00 40.50 74.00 100.00 15.00 16.5 260.00 RCMT 1606M0-14 0
C6-SRDCN-16-H125-Y
63.00 65.50 98.90 125.00 15.00 16.5 450.00 RCMT 1606M0-14 0
• For user guide, see page 622
(1) Machinable diameter maximum
(2) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: RCMT-14 (202) • RCMT-SR (202)
Spare Parts
Designation
C#-RCMT-16-Y
TRC 5-0 SR TC-4 CH-1.9D-JHP-A SET SR 16-212 HW 3.0 BLD T20/S7 SW6-T-SH
C#-RCMT-16-Y
Y-Axis Turning Tools
Carrying Round Inserts
with 7° Clearance Angle
BD
Fitting Tube
DCONMS
JHP Coolant
LF
Rotation Range 90˚
Designation
DCONMS BD LF MIID(1) CSP(2)
AVC-D16-SRDCN-08-Y
16.00 17.00 12.00 RCMT 0803M0-14 1
AVC-D20-SRDCN-10-Y
20.00 21.00 20.00 RCMT 10T3M0-14 1
AVC-D25-SRDCN-12-Y
25.00 26.00 20.00 RCMT 1204M0-14 1
AVC-D32-SRDCN-16-Y
32.00 33.00 23.00 RCMT 1606M0-14 1
AVC-D40-SRDCN-16-Y
40.00 41.00 25.00 RCMT 1606M0-14 1
(1) Master insert identification
(2) 0 - Without coolant supply, 1 - With coolant supply
For holders, see pages: C#-SH-E-JHP (630) • C#-SH-JHP (630)
AVC-SRDCN-Y
Interchangeable Heads
Carrying Round Inserts
ISCAR
78
USER GUIDE
ISOTURN TOOLS
JET HIGH-PRESSURE TOOLS
High-Pressure Coolant
Important Features
• Up to 200% increased cutting speed when
machining titanium and heat resistant alloys.
• Effective chip control on problematic materials.
• Up to 100% increased tool life when machining
titanium, heat resistant alloys and alloy steel.
JHP tools are essential and important for the
aviation, aerospace and medical industries.
The coolant channels of the JHP tools feature
outlets very close to the cutting edges, thus
gaining the following advantages:
• Shorter machining time – cutting speed may
be increased by up to 200% when machining
titanium and heat resistant alloys.
• Longer tool life – increased tool life by up to
100% not only on titanium and heat resistant
alloys, but also on stainless and alloy steels.
• Improved chip control – small chips can be obtained
even on the most ductile and problematic materials
• Effective cooling down of the cutting edge,
reducing sensitivity to heat fluctuations.
• Safer and more stable process.
JHP tools provide advantageous performance,
also when conventional pressure is applied.
Pressure vs. Flow
• Each JHP tool is designed to work at a certain flow rate,
depending on the pressure. The flow rates are listed in
the catalog pages for each tool. The user should verify
that the pump can supply the required flow in order to
achieve the optimal results. The pump data sheet will
usually list the maximum flow rate for each pressure range.
Chips & Pressure
• The coolant flow will start to break the chips at a
certain pressure, depending on the specific tool and
the workpiece material. If the chips are not breaking,
the pressure should be increased until chip control
is achieved. As the pressure is increased, the chips
become smaller and smaller. It is possible to control
the size of the chips by modifying the pressure.
79
USER GUIDE
ISOTURN TOOLS
There are 4 various telescopic tubes intended for various insert geometries (see attached table).
Each tube possesses a different profile optimized for the specific geometry of the insert.
Fixed Cooling Holes
(1) Frontal
Coolant Hole
The flow rate for each tube is listed in the table below.
Flow Rate for Various JHP Nozzles
Insert Channel Shape Inside
the Nozzle Tube Nozzle Tube Flow Rate liter/min
70 Bar 100 Bar 140 Bar 300 Bar
NZ-CW-JHP 19-23.5 22.5-28 26.5-33 46-52
NZ-D-JHP 19-23.5 22.5-28 26.5-33 46-52
NZ-V-JHP 9.5-11.8 11.3-14 13.4-16.7 22-26
NZ-R-JHP 19-23.5 22.5-28 26.5-33 46-52
Holes 14-16 18-23 23-26 33-37
Frontal Coolant Hole (1) Hole 5.4-6.6 6.4-8 7.5-9.5 10-14
The tools with LNMX 1506… inserts feature fixed cooling channels.
ISCAR
80
USER GUIDE
ISOTURN TOOLS
For most of the tools that have a square shank, a frontal
coolant hole has been added underneath the seat of the
insert to enable coolant flow directed to the flank area of
the insert. The frontal coolant jet increases the amount of
coolant to the cutting zone. By closing or opening a screw,
it acts as a valve that monitors the rate of coolant flow.
Frontal Coolant Hole
SLAN-15-TANG JHP tools for LNMX 1506… inserts,
SVJCR/L-16-JHP for VCMT 1604.. inserts and all
high-pressire coolant tools with CAMFIX shanks
do not have the frontal cooling channel option.
Frontal Coolant Hole
Frontal Coolant
On/Off Screw
Housing
Mounting Screw
Frontal
Coolant
Hole
O-Ring
Copper Seal
Washer 1/8”
1/8" BSP
Adaptation Nipple
Frontal Coolant
Channel
On/Off Screw
H.P. Coolant Hose
Plug
Screw
Nozzle Tube
81
USER GUIDE
ISOTURN TOOLS
Inconel 718-Chip Control with
CNMX 120708-M4MW IC807 Vc = 70 (mm/min)
Normal Pressure
ap (mm)
2
1
0.5
0.25
0.15 0.2 0.25
f (mm/rev)
High-Pressure 80 bar
ap (mm)
2
1
0.5
0.25
0.15 0.2 0.35
f (mm/rev)
Test Report
Material: Titanium (Ti6Al4V)
Operation: Turning
Tool: PCLNL 2525M-12-JHP
Insert: CNMG 120412-PP IC20
ap: 2.5 (mm)
f: 0.3 (mm/rev)
Pressure Influence on Tool Life
Cutting speed - Vc (m/min)
t (min)
0
10
50 60 75
20
30
40
50
60
70
Vc (m/min)
Normal pressure (6-8 bars)
High-Pressure (70 bars)
Pressure Influence on Chip Control
High-Pressure Normal Pressure
ISCAR
82
USER GUIDE
ISOTURN TOOLS
Test Report
Material: Stainless steel 316L
Operation: Turning
Tool: PCLNL 2525M-12-JHP
Insert: CNMG 120408-TF IC908
ap: 2.5 (mm)
f: 0.3 (mm/rev)
Pressure Influence on Tool Life
Cutting speed - Vc (m/min)
t (min)
0
5
10
15
20
25
30
175 200 225 250
Vc (m/min)
Normal pressure (6-8 bars)
High-Pressure (70 bars)
Pressure Influence on Chip Control
High-Pressure Normal Pressure
Test Report
Material: Inconel 718 (46 HRC)
Operation: Turning
Tool: PCLNL 2525M-12-JHP
Insert: CNMG 120408-TF IC808
ap: 2.5 (mm)
f: 0.3 (mm/rev)
Pressure Influence on Tool Life
Cutting speed - Vc (m/min)
t (min)
0
5
50 60
10
15
20
25
Vc (m/min)
Normal pressure (6-8 bars)
High-Pressure (70 bars)
Pressure Influence on Chip Control
High-Pressure Normal Pressure
83
USER GUIDE
ISOTURN TOOLS
Assembly and Safety Guidelines when using JET HP ISO
Turning and Grooving tools.Before use, please ensure that:
• The machine door is in a fully closed position
• The coolant hose is in the correct location and
fully tightened with all seals in position
• A blank plug is inserted into the unused coolant hole
• All O-rings and washers are in place
• The coolant hose is tightened securely to the tool
holder and tool block to prevent coolant leakage
Important
Always pay attention not to exceed the maximum
safe working pressure of 300 bar.
Maximum Pressure 300 Bar Maximum Pressure 300 Bar
Housing
Mounting Screw
O-Ring
Copper Seal Washer 1/8”
H.P. Coolant Hose
Frontal Coolant Channel
On/Off Screw
Plug Screw
Nozzle Tube
1/8" BSPP Adapting Nipple
Mounting
Screw
Housing
O-Ring
Plug Screw
Nozzle Tube
ISCAR
84
USER GUIDE
ISOTURN TOOLS
ISOTURN JHP Tools
The unique High-Pressure coolant system is composed
of a static housing and telescopic tube to direct the
coolant exactly to the cutting edge of the insert. The
telescopic tube embedded in the housing skews right
and left, according to the working direction of the tool
(see drawing). The advantage of this system is that
there is no need to detach the housing of the tool
when changing an insert. This reduces setup time.
To mount or change an insert, press on the
telescopic tube in a backward direction.
After indexing the cutting edge of the insert,
starting the coolant will extract the tube
automatically to its operating position.
Central Coolant Direction
4°
4° (8° rotation adjustment)
Insert Indexing Procedure
1
2
3
4
85
ISOTURN TOOLS
Thread
Size (CXT)
Thread
Size (CNT)
2
1
BB
BS
OAL
OAL
Bar Max
Designation
OAL Fig. CXT CNT
JHP HOSE G1/8-7/16-200BS
200.00 1 G1/8"-28 BSPP UNF7/16"-20FLARE 37°
JHP HOSE 5/16-G1/8-200BS
200.00 1 5/16"-24 UNF G1/8"-28 BSPP
JHP HOSE 5/16-7/16-200BS
200.00 1 5/16"-24 UNF UNF7/16"-20FLARE 37°
JHP HOSE G1/8-G1/8-200BB
200.00 2 G1/8"-28 BSPP G1/8"-28 BSPP
JHP HOSE G1/8-7/16-250BS
250.00 1 G1/8"-28 BSPP UNF7/16"-20FLARE 37°
JHP HOSE G1/8-G1/8-250BB
250.00 2 G1/8"-28 BSPP G1/8"-28 BSPP
Spare Parts
Designation
JHP HOSE 5/16-7/16-200BS
JHP BANJO BOLT 5/16" UNF JHP COPPER SEAL 5/16"
JHP HOSE G1/8-G1/8-200BB
JHP COPPER SEAL 1/8"*
JHP HOSE G1/8-G1/8-250BB
JHP BANJO BOLT G1/8"* JHP COPPER SEAL 1/8"*
* Optional, should be ordered separately
JHP HOSE
High-Pressure Coolant Hose
DRVS
CXD
CNT CND
CXT
Bar Max
Designation
CNT CND CXT CXD DRVS(2)
JHP ELBOW TUB3/16-5/16UNF (1)
- 3.10 5/16"-24 UNF 4.00 12.7
JHP ELBOW 90-5/16-7/16UNF
7/16"-20 UNF 4.40 5/16"-24 UNF 4.00 12.7
JHP ELBOW 90-G1/8-7/16UNF
7/16"-20 UNF 4.40 1/8"-28 BSPP 4.00 15.9
(1) For connection to a simple 3/16" stainless or copper tube
(2) Torque key size
Spare Parts
Designation
JHP ELBOW 90-5/16-7/16UNF
JHP COPPER SEAL 5/16"-2.5
JHP ELBOW 90-G1/8-7/16UNF
JHP COPPER SEAL 1/8"
JHP ELBOW
High-Pressure Adaptation Elbow
CXD CXT
OAL
DRVS
CND
CNT
Bar Max
Designation
CXT CNT OAL CND CXD DRVS(1)
JHP NIPPLE G1/8"-7/16"UNF
1/8"-28 BSPP 7/16"-20 UNF 28.75 4.00 4.00 14.3
JHP NIPPLE 1/8NPT-7/16UNF
1/8"-27 NPT 7/16"-20 UNF 31.00 4.80 4.40 12.7
JHP NIPPLE 1/4NPT-7/16UNF
1/4"-18 NPT 7/16"-20 UNF 36.00 4.40 4.40 14.3
JHP NIPPLE5/16UNF-7/16UNF
5/16"-24 UNF 7/16"-20 UNF 29.50 4.40 4.00 12.7
(1) Torque key size
JHP NIPPLE
High-Pressure Adaptation Nipple
ISCAR
86
ISOTURN TOOLS
DINNDIOUT
LB
Designation
DIOUT DINN LB
JHP COPPER SEAL 5/16"-2.5
9.40 8.00 2.50
JHP COPPER SEAL 5/16"
11.90 8.15 1.35
JHP COPPER SEAL 1/8"
15.00 10.00 1.00
JHP COPPER SEAL
High-Pressure Copper Seal
DRVS
13
411
5/16”-24 UNF
6
9
G1/8”-28 BSPP
OAL
Bar Max
Designation
OAL DRVS(1)
JHP CONECTOR 5/16"-G1/8"
25.00 12.0
(1) Torque key size
JHP CONNECTOR
High-Pressure Connector
87
ISOTURN TOOLS
SS
IC IC IC
S
KITS
Designation
IC S
AD-CL-4/3-WIP-SET
12.70 4.76
AD-CL-S-4/3-WIP-SET
12.70 4.76
AD-CL-4/3-SET
12.70 4.76
AD-CL-4/3-W-SET
12.70 4.76
AD-CL-4/3X SET
12.70 4.76
AD-SS-4/3-SET
12.70 4.76
AD-WL-4/3-SET
12.70 4.76
AD-CL-6/5IQ-SET
19.00 5.60
• Tools with K-type coolant cannot be used for facing applications
Toolholder Set Designation Item No.
Pocket Size Reducer
From To
PCLNR/L...12
AD-CL-4/3-SET
LR 4-3
+
AD-CL-4/3
3351719
CNMG 12... CNMG 09...
PCLNR/L...12
LR 4-3
+
AD-CL-W-4/3
AD-CL-4/3-W-SET
3362999
CNMG 12... WNMG 06...
PCLNR/L...12
LR 4-3X
+ +
AD-CL-4/3X TCN 4/3X
AD-CL-4/3X-SET
3362630
CNMG 12... CXMG 09...
PWLNR/L...08
LR 4-3
+
AD-WL-4/3
AD-WL-4/3-SET
3363000
WNMG 08... WNMG 06...
PSKNR/L...12
LR 4-3
+
AD-SS-4/3
AD-SS-4/3-SET
3364103
SNMG 12... SNMG 09...
PCLNR/L...19
LR 6/5IQ
++
AD-CL-6/5IQ TCX 6/5IQ
AD-CL-6/5IQ-SET
3364102
CNMG 19... COMG 16...
PCLNR/L...12
LR 4-3
+ +
AD-CL-4/3-WIP TCN-432-WIP
AD-CL-4/3-WIP-SET
3373957
CNMG 12... CNMG 09...
PCLNR/L...12
LR 4-3
+ +
AD-CL-4/3-WIP TCN-432-WIP
AD-CL-S-4/3-WIP-SET
3382096
SNMG 12... SNMG 09...
Spare Parts
Designation
AD-CL-4/3-WIP-SET
LR 4/3 HW 3.0/5 TCN-432-WIP
AD-CL-S-4/3-WIP-SET
LR 4/3 HW 3.0/5 TCN-432-WIP
AD-CL-4/3-SET
LR 4/3 HW 3.0/5
AD-CL-4/3-W-SET
LR 4/3 HW 3.0/5
AD-CL-4/3X SET
LR 4/3X HW 3.0/5 TCN 4/3X
AD-WL-4/3-SET
LR 4/3 HW 3.0/5
AD-CL-6/5IQ-SET
LR 6/5IQ TCX 6/5IQ
AD-SET
Pocket Reducer Adapter
for Turning Inserts
SNMG 09...
LR 4-3
AD-CL-4/3-WIP
Spring
TCN-432-WIP
PCLNR/L...12
ISCAR
88
ISOTURN TOOLS
H
B
KAPR
WF
LF
HF
Right-hand shown
95º
95º
Designation
H HF B LF WF KAPR(1) Insert
CCLNR 2020K-12CEA
20.0 20.0 20.0 125.00 25.00 95.0 CNGN 1204
CCLNR/L 2525M-12CEA
25.0 25.0 25.0 150.00 32.00 95.0 CNGN 1204
(1) Tool cutting edge angle
For inserts, see pages: CNGN-Ceramic (216)
Spare Parts
Designation
CCLNR/L
S 48 HW 4.0 BCL 6 CLAMP SR M6X1X25ISO7380 SR M5X0.8X10
CCLNR/L
Clamp Lock Tools Carrying
Negative 80° Rhombic
Ceramic Inserts
H
B
KAPR
WF
LF
HF
Right-hand shown
95º
95º
Designation
H HF B LF WF KAPR(1) Insert
TCLNR/L 2525M-12CH
25.0 25.0 25.0 150.00 32.00 95.0 CNGX 1207...T S 48 SR M5X0.8X10 CCL 4 KSP 5 CSC 4 HW 4.0
(1) Tool cutting edge angle
For inserts, see pages: CNGX-Ceramic (217)
TCLNR/L-CH
95° Lead Angle Tools Carrying
Negative CNGX 80° Rhombic
Ceramic Dimpled Inserts
H
B
KAPR
WF
LF
HF
Right-hand shown
75º
Designation
H HF B LF WF KAPR(1) Insert
TCBNR/L 2525M-12CH
25.0 25.0 25.0 150.00 22.00 75.0 CNGX 1207...T S 48 SR M5X0.8X10 CCL 4 KSP 5 CSC 4 HW 4.0
(1) Tool cutting edge angle
For inserts, see pages: CNGX-Ceramic (217)
TCBNR/L-CH
75° Lead Angle Toolholders
Using the 100° Corner of
CNGX 80° Negative Rhombic
Ceramic Dimpled Inserts
H
B
KAPR
WF
LF
HF
Right-hand shown
75°
Designation
H HF B LF WF KAPR(1) Insert
TCKNL 2525M-12CH
25.0 25.0 25.0 150.00 32.00 75.0 CNGX 1207...T S 48 SR M5X0.8X10 CCL 4 KSP 5 CSC 4 HW 4.0
(1) Tool cutting edge angle
For inserts, see pages: CNGX-Ceramic (217)
TCKNR/L-CH
75° Lead Angle Tools Carrying
the 100° Corner of CNGX 80°
Negative Rhombic Ceramic
Dimpled Inserts for Facing
Tools for Ceramic Inserts
89
ISOTURN TOOLS
H
B
KAPR
WF
LF
HF
45°
Designation
H HF B LF WF KAPR(1) Insert
CSDNN 2020K-12CEA
20.0 20.0 20.0 125.00 10.00 45.0 SNGN 1204
CSDNN 2525M-12CEA
25.0 25.0 25.0 150.00 12.50 45.0 SNGN 1204
(1) Tool cutting edge angle
For inserts, see pages: SNGN-Ceramic (217)
Spare Parts
Designation
CSDNN 2020K-12CEA
S 40 (SEAT) SR M5X0.8X10 BCL 6 CLAMP SR M6X1X25ISO7380 HW 4.0
CSDNN 2525M-12CEA
S 40 (SEAT) SR M5X0.8X10 BCL 6 CLAMP SR M6X1X25ISO7380 HW 4.0 HW 3.0
CSDNN-CE/CEA
45° Lead Angle Tools Carrying
Square Ceramic Inserts
H
B
KAPR
WF
LF
HF
45°
Designation
H HF B LF WF KAPR(1)
TSDNN 2525M-12CH
25.0 25.0 25.0 150.00 12.50 45.0 S 40 (SEAT) SR M5X0.8X10 CCL 4 KSP 5 CSC 4 HW 4.0
(1) Tool cutting edge angle
For inserts, see pages: SNGX-Ceramic (218)
TSDNN-CH
45° Lead Angle Tools Carrying
Square Ceramic Dimpled Inserts
H
B
KAPR
WF
OAL
LF
HF
Right-hand shown
45º
45º
Designation
H HF B OAL WF KAPR(1) Insert LF
TSSNR/L 2525M-12CH
25.0 25.0 25.0 150.00 32.00 45.0 SNGX 1207..T 141.52 S 40 (SEAT) SR M5X0.8X10 CCL 4 KSP 5 CSC 4 HW 4.0
(1) Tool cutting edge angle
For inserts, see pages: SNGX-Ceramic (218)
TSSNR/L-CH
45° Lead Angle Tools Carrying
Square Ceramic Dimpled Inserts
for Longitudinal and Face Turning
ISCAR
90
ISOTURN TOOLS
DBC
DCONWS
OAL
LH
H
OAH
L5
H
B
4xCNT
Designation
DCONWS LH OAH OAL H B DBC L5 CNT
SH-S2020-N-AVC-D20-JHP-MC
20.00 21.0 30.00 92.00 20.0 20.0 13.00 30.00 G 1/8
SH-S2020-N-AVC-D25-JHP-MC
25.00 21.0 32.50 92.00 20.0 20.0 16.00 30.00 G 1/8
SH-S2020-N-AVC-D32-JHP-MC
32.00 21.0 36.00 92.00 20.0 20.0 22.00 30.00 G 1/8
SH-S2525-N-AVC-D25-JHP-MC
25.00 21.0 37.50 107.00 25.0 25.0 16.00 36.00 G 1/8
SH-S2525-N-AVC-D32-JHP-MC
32.00 21.0 41.00 107.00 25.0 25.0 22.00 36.00 G 1/8
SH-S2525-N-AVC-D40-JHP-MC
40.00 21.0 45.00 107.00 25.0 25.0 28.00 36.00 G 1/8
SH-S3232-N-AVC-D32-JHP-MC
32.00 21.0 48.00 152.00 32.0 32.0 22.00 - G 1/8
SH-S3232-N-AVC-D40-JHP-MC
40.00 26.0 52.00 152.00 32.0 32.0 28.00 - G 1/8
SH-S4040-N-AVC-D40-JHP-MC
40.00 26.0 60.00 200.00 40.0 40.0 28.00 - G 1/8
For tools, see pages: AVC-DDUNR/L (97) • AVC-DVUNR/L (97) • AVC-GAIR/L (347) • AVC-GEAIR/L (346) • AVC-PCLNR/L (96) • AVC-PCLXR/L (96)
• AVC-SCLCR/L (95) • AVC-SDUCR/L (95) • AVC-SVLCR/L (96) • AVC-SVUCR/L (95)
Spare Parts
Designation
SH-S2020-N-AVC-D20-JHP-MC
SR M3.5X10 DIN912 SR M6X6 DIN913 TL360 HW 2.5 OR 5.6X1.8 NBR PLG G1/8 TL360
SH-S2020-N-AVC-D25-JHP-MC
SR M4X12DIN912 SR M6X6 DIN913 TL360 HW 3.0 OR 5.6X1.8 NBR PLG G1/8 TL360
SH-S2020-N-AVC-D32-JHP-MC
SR M5X12 DIN912 SR M6X6 DIN913 TL360 HW 4.0 OR 5.6X1.8 NBR PLG G1/8 TL360
SH-S2525-N-AVC-D25-JHP-MC
SR M4X12DIN912 SR M6X6 DIN913 TL360 HW 3.0 OR 5.6X1.8 NBR PLG G1/8 TL360
SH-S2525-N-AVC-D32-JHP-MC
SR M5X12 DIN912 SR M6X6 DIN913 TL360 HW 4.0 OR 5.6X1.8 NBR PLG G1/8 TL360
SH-S2525-N-AVC-D40-JHP-MC
SR M6X16 DIN912 SR M6X6 DIN913 TL360 HW 5.0 OR 5.6X1.8 NBR PLG G1/8 TL360
SH-S#-N-AVC
Square shank with
serrated connection
H
B
WF
LF
HF
Designation
H HF B LF WF Insert
CRDNN 2525M-12CE
25.0 25.0 25.0 150.00 12.50 RNGN 120700 S 43 SR M5X0.8X10 BCL 6 CLAMP SR M6X1X25ISO7380 HW 4.0
CRDNN 2525M-12CEA
25.0 25.0 25.0 150.00 12.50 RNGN 120400 S 43 SR M5X0.8X10 BCL 6 CLAMP SR M6X1X25ISO7380 HW 4.0
CRDNN 3225P-12CE
32.0 32.0 25.0 170.00 12.50 RNGN 120700
For inserts, see pages: RNGN-Ceramic (220)
CRDNN
Clamp Lock Neutral Tools
Carrying Round Negative
Ceramic Inserts
H
B
WF
LF
HF
Right-hand shown
Designation
H HF B LF WF Insert
CRGNR/L 2525M-12CE
25.0 25.0 25.0 150.00 32.00 RNGN 120700 S 43 SR M5X0.8X10 BCL 6 CLAMP SR M6X1X25ISO7380 HW 4.0
CRGNR/L 2525M-12CEA
25.0 25.0 25.0 150.00 32.00 RNGN 120400 S 43 SR M5X0.8X10 BCL 6 CLAMP SR M6X1X25ISO7380 HW 4.0
CRGNR/L 3225P-12CE
32.0 32.0 25.0 170.00 32.00 RNGN 120700 S 43 SR M5X0.8X10 BCL 6 CLAMP SR M6X1X25ISO7380 HW 4.0
For inserts, see pages: RNGN-Ceramic (220)
CRGNR/L
Clamp Lock Tools Carrying
Round Negative Ceramic Inserts
91
USER GUIDE
ISOTURN TOOLS
ISCAR boring bars are equipped with internal
coolant. A unique plastic seal is supplied
for insertion into the channel which:
• Features a threaded tube fitting connection
• Performs a sealing role while clamped
in a cylindrical adapter
• Requires no re-threading after shortening the bar
This unique design is a simple and versatile solution
for installing coolant supply and extends tool life,
improves chip flow and machining reliability.
ADAPTER
PLASTIC SEAL
BORING BAR
COOLANT SUPPLY
FIXING SCREW CAVITIES
PLASTIC SEAL
COOLANT SUPPLY
TUBE FITTING
BORING BAR
ADAPTER
PLASTIC SEAL BORING BAR
ISOTURN Boring Bars
ISCAR
92
ISOTURN TOOLS
OHX
DCONWS
OAL
CNT
DCONMS
H
A-A
A
A
DCONWS
DCONMS
50 & 60 mm
shanks
Designation
DCONWS DCONMS OAL OHX(1) CNT H BMC(2)
SH-D16-4D-A
16.00 16.00 105.00 44.0 UNC-2B 3/8"-16 15.0 S
SH-D20-4D-A
20.00 20.00 140.00 60.0 UNFC-2B 3/8"-24 18.0 S
SH-D25-4D-A
25.00 25.00 200.00 80.0 UNF-2B 1/2"-20 23.0 S
SH-D32-4D-A
32.00 32.00 218.00 96.0 UNF-2B 1/2"-20 29.0 S
SH-D40-4D-A
40.00 40.00 283.00 128.0 UNF-2B 1/2"-20 36.0 S
SH-D50-4D-40-A
40.00 50.00 368.00 168.0 UNF-2B 1/2"-20 46.0 S
SH-D60-4D-40-A
40.00 60.00 468.00 208.0 UNF-2B 1/2"-20 57.0 S
(1) Maximum overhang
(2) S-steel body, H-solid carbide body
For tools, see pages: AVC-D-SIR/L (707) • AVC-DDUNR/L (97) • AVC-DVUNR/L (97) • AVC-GAIR/L (347) • AVC-GEAIR/L (346) • AVC-PCLNR/L (96)
• AVC-PCLXR/L (96) • AVC-SCLCR/L (95) • AVC-SDUCR/L (95) • AVC-SVLCR/L (96) • AVC-SVUCR/L (95)
Spare Parts
Designation
SH-D16-4D-A
SR M3X10DIN912 HW 2.5 PL 16
SH-D20-4D-A
HW 2.5 PL 20 OR 5.6X1.8 NBR
SH-D25-4D-A
SR M4X12DIN912 HW 3.0 PL 25 OR 5.6X1.8 NBR
SH-D32-4D-A
SR M5X12 DIN912 HW 4.0 PL 32 OR 5.6X1.8 NBR
SH-D40-4D-A
SR M6X16 DIN912 HW 5.0 PL 40 OR 5.6X1.8 NBR
SH-D50-4D-40-A
SR M6X16 DIN912 HW 5.0 PL 40 OR 5.6X1.8 NBR
SH-D60-4D-40-A
SR M6X16 DIN912 HW 5.0 PL 40 OR 5.6X1.8 NBR
SH-D
Steel boring bars with serrated
connection for AVC Heads
Boring Bars
93
ISOTURN TOOLS
OAL
DCONWS
OHX
DCONMS DCONWS
50 & 60 mm shanks
CNT
DCONMS
DCONWS
Designation
DCONWS DCONMS OAL OHN(1) OHX(2) CNT BMC(3) CP(4)
AV-D16-7D-C
16.00 16.00 156.30 55.0 92.0 G1/8 S 30
AV-D16-10D-E
16.00 16.00 204.30 96.0 140.0 - H 30
AV-D20-7D-C
20.00 20.00 200.30 70.0 120.0 G1/4 S 30
AV-D20-10D-E
20.00 20.00 260.30 120.0 180.0 - H 30
AV-D25-7D-C
25.00 25.00 257.50 88.0 155.0 G1/4 S 40
AV-D25-10D-C
25.00 25.00 332.50 155.0 230.0 G1/4 S 40
AV-D32-7D-C
32.00 32.00 323.00 120.0 192.0 G3/8 S 50
AV-D32-10D-C
32.00 32.00 419.00 192.0 288.0 G3/8 S 50
AV-D40-7D-C
40.00 40.00 411.00 128.0 251.0 G1/2 S 70
AV-D40-10D-C
40.00 40.00 531.00 248.0 368.0 G1/2 S 70
AV-D50-7D-C
40.00 50.00 523.00 168.0 318.0 G1/2 S 70
AV-D50-10D-C
40.00 50.00 673.00 318.0 468.0 G1/2 S 70
AV-D60-7D-C
40.00 60.00 633.00 208.0 388.0 G3/4 S 70
AV-D60-10D-C
40.00 60.00 813.00 388.0 568.0 G3/4 S 70
• The bars can be shortened. For details, see table below
(1) Minimum overhang
(2) Maximum overhang
(3) S-steel body, H-solid carbide body
(4) Coolant pressure (Bar)
For tools, see pages: AVC-D-SIR/L (707) • AVC-DDUNR/L (97) • AVC-DVUNR/L (97) • AVC-GAIR/L (347) • AVC-GEAIR/L (346) • AVC-PCLNR/L (96) • AVC-PCLXR/L (96)
• AVC-SCLCR/L (95) • AVC-SDUCR/L (95) • AVC-SVLCR/L (96) • AVC-SVUCR/L (95)
Bar Diameter Minimum Length After Shortening
DCONMS (mm) OAL 7D (mm) OAL 10D (mm)
16 100 - (1)
20 125 - (1)
25 155 255
32 190 320
40 240 410
50 305 520
60 380 630
(1) Cannot be shortened
Spare Parts
Designation
AV-D16-7D-C
SR M3X10DIN912
AV-D16-10D-E
SR M3X10DIN912
AV-D20-7D-C
SR M3.5XL10-D5.5
AV-D20-10D-E
SR M3.5XL10-D5.5
AV-D25-7D-C
SR M4X12DIN912
AV-D25-10D-C
SR M4X12DIN912
AV-D32-7D-C
SR M5X12 DIN912
AV-D32-10D-C
SR M5X12 DIN912
AV-D40-7D-C
SR M6X16 DIN912
AV-D40-10D-C
SR M6X16 DIN912
AV-D50-7D-C
SR M6X16 DIN912
AV-D50-10D-C
SR M6X16 DIN912
AV-D60-7D-C
SR M6X16 DIN912
AV-D60-10D-C
SR M6X16 DIN912
AV-D
Anti-Vibration Bars with
Through Coolant for
Interchangeable Turning Heads
ISCAR
94
ISOTURN TOOLS
A
A
OAL
LB
DCONMS HTB OAH
OAW
Designation
DCONMS HTB OAL LB Shank OAH OAW
AVC-SET 16-25-LEV
20.00 38.0 27.50 16.00 16, 20, 25 50.50 41.00
AVC-SET 32-60-LEV
29.00 49.0 28.00 16.00 32, 40, 50, 60 59.00 49.00
Features
•
Serrated head with magnetic core ensures
fixed position of the shank.
•
The setting head is simply connected
to the shank without screws.
•
The bubble level indicates the tool position and easily
enables adjustment of the boring bar to the center.
•
Significant time saving can be achieved by using this
unique setting head.
• High setting accuracy can be easily attained and ensure
excellent performance for
WHISPERLINE
boring bars.
• During tool assembly and the positioning process on
the machine, please pay attention to the angle position
selector. It must be set to the angle that is defined for
each head - while most ISO turning heads have a 0°
angle, CUT-GRIP heads need to be set to 15° or 30°.
ISO turning head CUT-GRIP head
Spare Parts
Designation
AVC-SET-LEV
SR M6X10 DIN1835B HW 3.0
AVC-SET-LEV
Center Height Set Up Device
OAL
LB
View A
A
HTB
DCONMS
Designation
DCONMS HTB OAL LB Shank
AVC-SET 16-25
20.00 15.0 14.50 9.00 16, 20, 25
AVC-SET 32-60
29.00 16.0 17.50 11.50 32, 40, 50, 60
AVC-SET
Center Height Set Up Device
95
ISOTURN TOOLS
DMIN
WF 93°
LF
DCONMS
93º
30°
MAX
Designation
WF DCONMS DMIN LF CSP(1) MIID(2)
AVC-D20-SVUCR/L-11
16.00 20.00 27.00 20.00 0 CVMT 221-F3P SR 14-560* T-8/5*
AVC-D25-SVUCR/L-11
17.00 25.00 32.00 25.00 1 CVMT 221-F3P SR 14-560* T-8/5*
(1) 0 - Without coolant supply, 1 - With coolant supply
(2) Master insert identification
* Optional, should be ordered separately
For inserts, see pages: VCGT-AS (211) • VCGT-F1M-20P (196) • VCMT-F3M (195) • VCMT-SM (197)
For holders, see pages: AV-D (93) • C#-SH-E-JHP (630) • C#-SH-JHP (630) • SH-D (92) • SH-S#-N-AVC (90)
AVC-SVUCR/L
Interchangeable Boring
Heads Carrying 35° Rhombic
Inserts with 7° Clearance
DMIN
DCONMS
LF
WF 95°
93º-95º
50º
MAX
Designation
WF DCONMS DMIN LF CSP(2) MIID(3)
AVC-D16-SDUCR/L-07
11.00 16.00 20.00 20.00 0 DCMT 2-1 SR 14-548* T-7/5*
AVC-D20-SDUCR/L-11
13.00 20.00 25.00 20.00 0 DCMT 3-2-14 SR 16-236 P* T-15/5*
AVC-D25-SDUCR/L-11
17.00 25.00 32.00 20.00 1 DCMT 3-2-14 SR 16-236 P* T-15/5*
AVC-D32-SDUCR/L-11T
22.00 32.00 40.00 32.00 1 DCMT 3-2-14 SR 16-236 P* T-15/5* SR TC-3P* TDC 3-1P*
AVC-D40-SDUCR/L-11T (1)
27.00 40.00 50.00 32.00 1 DCMT 3-2-14 SR 16-236 P* T-15/5* SR TC-3P* TDC 3-1P*
(1) DMIN of 50mm shank is DMIN of requested head + 10mm • DMIN of 60mm shanks is DMIN of requested head + 20mm
(2) 0 - Without coolant supply, 1 - With coolant supply
(3) Master insert identification
* Optional, should be ordered separately
For inserts, see pages: DCET-WF (195) • DCGT-AF (213) • DCGT-AS (213) • DCGT-F1M-20P (192) • DCGW/DCMW-2 (CBN) (230)
• DCMT (CBN) (230) • DCMT (PCD) (222) • DCMT-14 (194) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT (194)
• DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194)
For holders, see pages: AV-D (93) • C#-SH-E-JHP (630) • C#-SH-JHP (630) • SH-D (92) • SH-S#-N-AVC (90)
AVC-SDUCR/L
Interchangeable Boring
Heads Carrying 55° Rhombic
Inserts with 7° Clearance
DMIN
DCONMS
LF
WF 95°
95º
Designation
WF DCONMS DMIN LF CSP(2) MIID(3)
AVC-D16-SCLCR/L-06
11.00 16.00 20.00 20.00 0 CCMT 2-1-14 SR 14-548* T-7/5*
AVC-D20-SCLCR/L-09
13.00 20.00 25.00 20.00 0 CCMT 3-2-M3M SR 16-236* T-15/5*
AVC-D25-SCLCR/L-09
17.00 25.00 32.00 20.00 1 CCMT 3-2-M3M SR 16-236* T-15/5*
AVC-D32-SCLCR/L-09
22.00 32.00 40.00 32.00 1 CCMT 3-2-M3M SR 16-236* T-15/5
AVC-D40-SCLCR/L-12T (1)
27.00 40.00 50.00 38.00 1 CCMT 432-SM SR 16-212* T-20/5* SR TC-4* TCC 4-2*
(1) DMIN of 50mm shank is DMIN of requested head + 10mm • DMIN of 60mm shanks is DMIN of requested head + 20mm
(2) 0 - Without coolant supply, 1 - With coolant supply
(3) Master insert identification
* Optional, should be ordered separately
For inserts, see pages: CCET-WF (189) • CCGT-AF (212) • CCGT-AS (212) • CCGW/CCMT (CBN) (227) • CCGW/CCMW-2 (CBN) (228) • CCMT (PCD) (222)
• CCMT-14 (188) • CCMT-F3M (186) • CCMT-M3M (186) • CCMT-M3P (185) • CCMT-PF (188) • CCMT-WG (189) • CCMT/CCGT (188) • CCMT/CCGT-SM (187)
For holders, see pages: AV-D (93) • C#-SH-E-JHP (630) • C#-SH-JHP (630) • SH-D (92) • SH-S#-N-AVC (90)
AVC-SCLCR/L
Interchangeable Boring
Heads Carrying 80° Rhombic
Inserts with 7° Clearance
ISCAR
96
ISOTURN TOOLS
DMIN
DCONMS
WF
LF
95º
Designation
WF DCONMS DMIN LF MIID(2)
AVC-D20-PCLXR/L-09X
13.00 20.00 25.00 26.00 CXMG 09 LR 3X SET SR M6XL11.5V T-8/5
AVC-D25-PCLXR/L-09X
17.00 25.00 32.00 28.00 CXMG 09 LR 3X SET SR M6XL11.5V T-8/5
AVC-D32-PCLXR/L-09X
22.00 32.00 40.00 32.00 CXMG 09 TSN 323 LR 3XL SR 117-2014 HW 2.5/5 SP 3 PN 3-4
AVC-D40-PCLXR/L-12X (1)
27.00 40.00 50.00 35.00 CXMG 12 TCNX 423 LR 4X SR LCS 5 HW 3.0 SP 4 PN 3-4
(1) DMIN of 50mm shank is DMIN of requested head + 10mm • DMIN of 60mm shanks is DMIN of requested head + 20mm
(2) Master insert identification
For inserts, see pages: CXMG-F3M (184) • CXMG-F3P (183) • CXMG-M3M (184) • CXMG-M3P (183)
For holders, see pages: AV-D (93) • C#-SH-E-JHP (630) • C#-SH-JHP (630) • SH-D (92) • SH-S#-N-AVC (90)
AVC-PCLXR/L
Interchangeable Boring Heads
Carrying 80° Rhombic Inserts
DMIN
DCONMS
LF
WF
95°
95º
48°
MAX
Designation
WF DCONMS DMIN LF CSP(2) MIID(3)
AVC-D32-SVLCR/L-16T
22.00 32.00 40.00 32.00 1 VCMT 332-F3M SR 16-236 P* T-15/5* SR TC-3P* TVC 3-1P*
AVC-D40-SVLCR/L-16T (1)
27.00 40.00 50.00 32.00 1 VCMT 332-F3M SR 16-236 P* T-15/5* SR TC-3P* TVC 3-1P*
• For positive "V" insert geometry with radius 1.2mm please use set: TVC 3-76 * 3312824
* Optional, should be ordered separately (1) DMIN of 50mm shank is DMIN of requested head + 10mm • DMIN of 60mm shanks is DMIN of requested head + 20mm
(2) 0 - Without coolant supply, 1 - With coolant supply
(3) Master insert identification
For inserts, see pages: VCGT (PCD) (223) • VCGT-AS (211) • VCGT-DW (PCD) (223) • VCGW-2 (CBN) (232) • VCMT (CBN) (222) • VCMT-14 (198)
• VCMT-F3M (195) • VCMT-F3P (195) • VCMT-FPC-CERMET (196) • VCMT-M3M (196) • VCMT-SM (197) • VCMW (198)
For holders, see pages: AV-D (93) • C#-SH-E-JHP (630) • C#-SH-JHP (630) • SH-D (92) • SH-S#-N-AVC (90)
AVC-SVLCR/L
Interchangeable Boring
Heads Carrying 35° Rhombic
Inserts with 7° Clearance
WF
DCONMS
LF
DMIN
95º
Designation
WF DCONMS DMIN LF MIID(1)
AVC-D20-PCLNR/L-09
13.00 20.00 25.00 26.00 CNMG 09 LR 3S SR 117-2009 HW 2.0
AVC-D25-PCLNR/L-09
17.00 25.00 32.00 28.00 CNMG 09 LR 3S SR 117-2009 HW 2.0
AVC-D32-PCLNR/L-09
22.00 32.00 40.00 32.00 CNMG 09 TCN 323 TCX 3(a) LR 3 SR 117-2014 HW 2.5 SP 3 PN 3-4
(1) Master insert identification
(a) For CNMX 0906.. (CNMX 34.) inserts
For inserts, see pages: CNMG-F3S (147) • CNGG-F3N (209) • CNMG-F3M (146) • CNMG-F3P (144) • CNMG-M3M (146) • CNMG-M3P (144)
For holders, see pages: AV-D (93) • C#-SH-E-JHP (630) • C#-SH-JHP (630) • SH-D (92) • SH-S#-N-AVC (90)
AVC-PCLNR/L
Interchangeable Boring Heads
Carrying 80° Rhombic Inserts
97
ISOTURN TOOLS
DMIN
WF
93°
LF
DCONMS
93º
30°
MAX
Designation
WF DCONMS DMIN LF CSP MIID(3)
AVC-D40-DVUNR/L-16T (1)
34.00 40.00 56.00 38.00 1 VNMG 332-F3M
(1) DMIN of 50mm shank is DMIN of requested head + 10mm • DMIN of 60mm shanks is DMIN of requested head + 20mm
(2) 0 - Without coolant supply, 1 - With coolant supply
(3) Master insert identification
For inserts, see pages: VNGG-M3N (210) • VNMG-F3M (164) • VNMG-F3P (163) • VNMG-M3M (164) • VNMG-TF (166) • VNMG/VNGG-NF (165)
For holders, see pages: AV-D (93) • C#-SH-E-JHP (630) • C#-SH-JHP (630) • SH-D (92) • SH-S#-N-AVC (90)
Spare Parts
Designation
AVC-D40-DVUNL-16T
DLM 3V SR 10402267 HW 4.0 KSP 5 T-15/5 SR 35080I
AVC-D40-DVUNR-16T
DLM 3V* SR 10402267* HW 4.0* KSP 5* T-15/5* SR 35080I*
* Optional, should be ordered separately
AVC-DVUNR/L
Interchangeable Boring Heads
Carrying 35° Rhombic Inserts
DMIN
WF
93°
LF
DCONMS
93º-95º
50º
MAX
Designation
WF DCONMS DMIN LF MIID(2) CSP(3)
AVC-D32-DDUNR/L-11T
22.00 32.00 40.00 32.00 DNMG 332-NF 1RDT 3-2* SR RC3* SR 40085I* HW 2.5* T-15/5* LCGR-3* KSP 3*
AVC-D40-DDUNR/L-15T (1)
27.00 40.00 50.00 38.00 DNMG 442-F3M 1RDT 433* DLS 4* SR 14-506* T-15/5* DLM 4* DSP 4*
* Optional, should be ordered separately (1) DMIN of 50mm shank is DMIN of requested head + 10mm • DMIN of 60mm shanks is DMIN of requested head + 20mm
(2) Master insert identification
(3) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: DNGA-4 (CBN) (229) • DNGA-Ceramic (218) • DNGG-M3N (210) • DNMA (161) • DNMA (CBN) (228) • DNMG-F3M (157)
• DNMG-F3P (156) • DNMG-F3S (157) • DNMG-GN (161) • DNMG-M3M (157) • DNMG-M3P (156) • DNMG-NF (158) • DNMG-NR (161) • DNMG-PF (159)
• DNMG-VL (160) • DNMG-WG (159) • DNMG/DNGG-PP (160) • DNMG/DNGG-SF (159) • DNMG/DNGG-TF (160) • DNMM-NM (162) • DNMM-R3P (162)
For holders, see pages: AV-D (93) • C#-SH-E-JHP (630) • C#-SH-JHP (630) • SH-D (92) • SH-S#-N-AVC (90)
AVC-DDUNR/L
Interchangeable Boring Heads
Carrying 55° Rhombic Inserts
OAL
OHX
DCONWS DCONMSCNT
Designation
DCONMS DCONWS OAL OHX(1) CNT CP(2)
AV-D80-7D-C-VH
80.00 80.00 880.00 515.0 G3/4" 70
AV-D80-10D-C-VH
80.00 80.00 1200.00 755.0 G3/4" 70
• The bars can be shortened. For details, see table below
(1) Maximum overhang
(2) Coolant pressure (Bar)
For tools, see pages: AVC-DDUNR/L-VH (98) • AVC-SDUCR/L-VH (98) • AVC-SVLCR/L-VH (98)
Bar Diameter Minimum Length After Shortening
DCONMS (mm) AV-D80-7D-C-VH AV-D80-10D-V-AV
80 630 630
AV-D-VH
Anti-Vibration Bars with
Through Coolant for
Interchangeable Turning Heads
ISCAR
98
ISOTURN TOOLS
DMIN
WF
LF
93˚
DCONMS
93º-95º
50º
MAX
Designation
WF DCONMS DMIN LF MIID(1)
AVC-D80-SDUCR/L-11T-VH
57.00 77.00 100.00 45.00 DCMT 11T304
(1) Master insert identification
For inserts, see pages: DCET-WF (195) • DCGT-AF (213) • DCGT-AS (213) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222)
• DCMT-14 (194) • DCMT-CERMET (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT (194) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194)
For holders, see pages: AV-D-VH (97)
AVC-SDUCR/L-VH
Interchangeable Boring
Heads Carrying 55° Rhombic
Inserts with 7° Clearance
DMIN
WF
LF
95˚
DCONMS
95º
48°
MAX
Designation
WF DCONMS DMIN LF MIID(1)
AVC-D80-SVLCR/L-16T-VH
57.00 77.00 100.00 45.00 VCMT 160404 T-15/5 SR 16-236 P TVC 3-1P SR TC-3P
(1) Master insert identification
For inserts, see pages: VCGT (PCD) (223) • VCGT-AS (211) • VCGT-DW (PCD) (223) • VCGW-2 (CBN) (232) • VCMT (CBN) (222) • VCMT-14 (198)
• VCMT-F3M (195) • VCMT-F3P (195) • VCMT-FPC-CERMET (196) • VCMT-M3M (196) • VCMT-SM (197) • VCMW (198)
For holders, see pages: AV-D-VH (97)
AVC-SVLCR/L-VH
Interchangeable Boring
Heads Carrying 35° Rhombic
Inserts with 7° Clearance
DMIN
DCONMS
WF
93˚
LF
93º-95º
50º
MAX
Designation
WF DCONMS DMIN LF MIID(1)
AVC-D80-DDUNR/L-15T-VH
57.00 77.00 100.00 46.00 DNMG 442-F3M
(1) Master insert identification
For inserts, see pages: DNGA-4 (CBN) (229) • DNGA-Ceramic (218) • DNMA (161) • DNMA (CBN) (228) • DNMG-F3M (157) • DNMG-F3P (156)
• DNMG-F3S (157) • DNMG-GN (161) • DNMG-M3M (157) • DNMG-M3P (156) • DNMG-NF (158) • DNMG-NR (161) • DNMG-PF (159) • DNMG-WG (159)
• DNMG/DNGG-PP (160) • DNMG/DNGG-TF (160) • DNMM-NM (162) • DNMM-R3P (162)
For holders, see pages: AV-D-VH (97)
Spare Parts
Designation
AVC-D80-DDUNL-15T-VH
RDT 443 RDT 433 HW 3.0 SR 14-506 T-15/5 DSP 4 DLS 4 DLM 4
AVC-DDUNR/L-VH
Interchangeable Boring Heads
Carrying 55° Rhombic Inserts
DCONMS
LSCWS
OAH
HF
RHCAL
OAL
LF
Designation
LSCWS OAH DCONMS LF HF OAL RHCAL
AVC-D80-2020-80-VH
67.80 55.50 77.00 20.50 20.0 40.50 25.0
Spare Parts
Designation
AVC-D80-VH
SR M10X16 DIN913
AVC-D80-VH
Perpendicular Adaptor for
External Square-Shank Tools
99
ISOTURN TOOLS
LDRED
WF
LF H
DCONMS
HFB
HF DMIN
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF DMIN HF Insert
S25R DCLNR-12
25.00 200.00 45.0 23.0 12.3 17.00 32.00 0.8 CNMG 1204..
S32T DCLNR/L-12
32.00 300.00 45.0 28.0 15.8 22.00 40.00 1.8 CNMG 1204..
S40U DCLNR/L-12
40.00 350.00 55.0 36.0 19.8 27.00 48.00 1.8 CNMG 1204..
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-CERMET (145) • CNMG-F3S (147) • CNMG-F3P (144) • CNMG-M3P (144)
• CNMM-R3P (153) • CNMM-M4PW (152) • CNMG-F3M (146) • CNMG-M3M (146) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151)
• CNMG/CNGG-PP (150) • CNMG-VL (147) • CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMA (149)
• CNGA-Ceramic (217) • CNMG-Ceramic (216) • CNGA-2 (CBN) (226) • CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226)
• CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
Spare Parts
Designation
S-DCLNR/L
TCN 423 SP 4 LCGR-4 SR 10400270-25.5 T-15/5
S-DCLNR/L
R-Clamp Boring Bars Carrying
Negative 80° Diamond Inserts
HFB
HF
WF
LF H
DMIN
DCONMS
LDRED Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB HF WF DMIN Insert
S25T DWLNR/L-08
25.00 300.00 50.0 23.0 12.3 0.8 17.00 32.00 WNMG 0804
S32U DWLNR/L-08
32.00 350.00 55.0 29.0 15.8 1.3 22.00 40.00 WNMG 0804
S40V DWLNR/L-08
40.00 400.00 55.0 36.0 19.8 1.8 27.00 60.00 WNMG 0804
For inserts, see pages: WNMG-CERMET (136) • WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137) • WNMG-M3M (138)
• WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-NF (139) • WNMM-NM (142)
• WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224)
Spare Parts
Designation
S-DWLNR/L
TWN 423 SP 4 LCGR-4 SR 10400270-25.5 T-15/5
S-DWLNR/L
R-Clamp Boring Bars Carrying
Negative Trigon Inserts
GAMP A
CNT
A
DMIN
LF
LDRED
WF
DCONMS
GAMF
A-A
95º
Designation
DCONMS LF LDRED WF GAMP GAMF DMIN CNT Insert
A16Q PCLXR/L-09X
16.00 180.00 30.0 11.00 8.0 10.0 20.00 UNC 3/8"-16 CXMG 09..
A20R PCLXR/L-09X
20.00 200.00 30.0 13.00 5.0 10.0 25.00 UNC 3/8"-24 CXMG 09..
A25S PCLXR/L-09X
25.00 250.00 40.0 17.00 5.0 10.0 32.00 UNC 1/2"-20 CXMG 09..
A25R PCLXR/L-12X
25.00 200.00 40.0 17.00 6.0 9.0 32.00 UNF-2B 1/2"-20 CXMG 12..
A32T PCLXR/L-12X
32.00 300.00 48.0 22.00 6.0 9.0 40.00 UNF-2B 1/2"-20 CXMG 12..
A40U PCLXR/L-12X
40.00 350.00 50.0 27.00 6.0 10.0 50.00 UNF-2B 1/2"-20 CXMG 12..
For inserts, see pages: CXMG-F3M (184) • CXMG-F3P (183) • CXMG-M3M (184) • CXMG-M3P (183)
Spare Parts
Designation
A16Q PCLXR/L-09X
LR 3X SET PL 16 SR M6XL11.5V T-8/5
A20R PCLXR/L-09X
LR 3X SET PL 20 SR M6XL11.5V T-8/5
A25S PCLXR/L-09X
LR 3X SET PL 25 SR M6XL11.5V T-8/5
A25R PCLXR/L-12X
LR 4MX PL 25 SR 117-2010-S HW 3.0
A32T PCLXR/L-12X
LR 4MX PL 32 SR 117-2010-S HW 3.0
A40U PCLXR/L-12X
LR 4X PL 40 SR LCS 5 HW 3.0 TCNX 423 PN 3-4 SP 4
A-PCLXR/L
Lever Lock Boring Bars
Carrying Negative CXMG
80° Rhombic Inserts
ISCAR
100
ISOTURN TOOLS
WF
LF H
DCONMS
LDRED
HFB
HF DMIN
Right-hand shown
93º
Designation
DCONMS LF LDRED H HFB WF DMIN HF Insert
S25T SLANR/L-11 TANG
25.00 300.00 40.0 23.0 1.0 17.00 53.00 1.0 LNMX 1104..
S32U SLANR-11 TANG
32.00 350.00 45.0 30.0 1.0 22.00 53.00 1.0 LNMX 1104..
S40V SLANR/L-11 TANG
40.00 400.00 60.0 37.0 1.5 27.00 53.00 1.5 LNMX 1104..
S50U SLANR/L-15 TANG
50.00 350.00 60.0 47.0 1.5 37.00 85.00 1.5 LNMX 1506..
• Right-hand inserts for left-hand bars. Left-hand inserts for right-hand bars. • ap max for facing: LNMX 11-2.8 mm, LNMX 15-3.8 mm.
For inserts, see pages: LNMX-HM (181) • LNMX-HT (180) • LNMX-WG (181)
Spare Parts
Designation
S25T SLANR/L-11 TANG
TLN 11R/L-HTI SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD
S32U SLANR-11 TANG
TLN 11R/L-HTI SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD
S40V SLANR/L-11 TANG
TLN 11R/L-HTI SR RS4 T-6/5 SR 34-550-C BLD T10/S7 SW6-SD
S50U SLANR/L-15 TANG
TLN 15R/L-HTI SR RS4 T-6/5 SR 34-535-SN BLD T15/S7 SW6-T-SH
S-SLANR/L-TANG
Boring Bars Carrying LNMX
Tangentially Screw Clamped
Inserts with 4 Cutting Edges
for High Metal Removal Rates
DMIN
HFB
HF
LF
LDRED
WF
DCONMS
H
93º
Designation
DCONMS LF LDRED H HFB WF DMIN HF Insert
S50U PLANR-15 TANG
50.00 350.00 60.0 47.0 1.5 37.00 85.00 1.5 LNMX 1506...
• Right-hand inserts for left-hand bars. Left-hand inserts for right-hand bars. • ap max for facing 3.8 mm.
For inserts, see pages: LNMX-HM (181) • LNMX-HT (180) • LNMX-WG (181)
Spare Parts
Designation
S50U PLANR-15 TANG
TLN 15L-HTI SR RS4 T-6/5 LR T15 SR TL-15 HW 3.5
S-PLANR-TANG
Boring Bars Carrying LNMX
... Tangentially Clamped
Inserts with 4 Cutting Edges
for High Production Rates
LDRED T
WF
LF
H
DCONMS
HFB
DMIN
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF T DMIN Insert
S20Q PQFNR/L-09
20.00 180.00 40.0 18.0 9.0 13.00 7.5 28.00 QNMG 0904...
S32R PQFNR-09
32.00 200.00 45.0 29.0 14.5 22.00 7.5 40.00 QNMG 0904...
S25R PQFNL-12
25.00 200.00 40.0 23.0 11.5 17.00 9.0 32.00 QNMG 1204...
S32R PQFNR-12
32.00 200.00 45.0 29.0 14.5 22.00 9.0 40.00 QNMG 1204...
S40S PQFNL-12
40.00 250.00 50.0 36.0 18.0 27.00 9.0 50.00 QNMG 1204...
For inserts, see pages: QNMG-GN (183) • QNMG-NF (182) • QNMG-PP (182) • QNMG-TF (182)
Spare Parts
Designation
S20Q PQFNR/L-09
LR 3S SR 117-2016 HW 2.0
S32R PQFNR-09
TXC 322 SP 3 PN 3-4 LR 3 SR 117-2014 HW 2.5
S25R PQFNL-12
LR 4M SR 117-2011 HW 2.5/5
S32R PQFNR-12
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
S40S PQFNL-12
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
S-PQFNR/L
Lever Lock Boring Bars Carrying
Negative Square Inserts with
80° Corners for Internal Facing
101
ISOTURN TOOLS
LDRED
WF
LF
H
DCONMS
HFB
HF DMIN
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF HF CSP(1) DMIN Insert
A25R PCLNR/L-12
25.00 200.00 40.0 23.0 11.5 17.00 0.0 1 32.00 CNMG 1204..
S25S PCLNR/L-12
25.00 250.00 48.0 23.0 11.5 17.00 0.0 0 32.00 CNMG 1204..
A32T PCLNR/L-12
32.00 300.00 45.0 30.0 14.5 22.00 -0.5 1 40.00 CNMG 1204..
S32T PCLNR/L-12
32.00 300.00 51.0 30.0 14.5 22.00 -0.5 0 40.00 CNMG 1204..
S40U PCLNR/L-12
40.00 350.00 51.0 36.0 18.0 27.00 0.0 0 49.00 CNMG 1204..
S50W PCLNR-19
50.00 450.00 70.0 47.0 23.5 35.00 0.0 0 63.00 CNMG 1906..
(1) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-CERMET (145) • CNMG-F3S (147) • CNMG-F3P (144) • CNMG-M3P (144)
• CNMM-R3P (153) • CNMM-M4PW (152) • CNMG-F3M (146) • CNMG-M3M (146) • CNMG-R3M (147) • CNMG/CNGG-TF (150) • CNMG-GN (151)
• CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147) • CNMG/CNGG-SF (148) • CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149)
• CNMS-12 (214) • CNMM-H3P (153) • CNMM-H4P (153) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216) • CNGA-2 (CBN) (226)
• CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
Spare Parts
Designation
A25R PCLNR/L-12
LR 4M SR 117-2011 HW 2.5/5 HW 2.0 PL 25
S25S PCLNL-12
LR 4M SR 117-2011 HW 2.5/5 HW 2.5
S25S PCLNR-12
LR 4M SR 117-2011 HW 2.5/5
A32T PCLNR/L-12
TCN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 2.0 HW 3.0 PL 32
S32T PCLNR/L-12
TCN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
S40U PCLNR/L-12
TCN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
S50W PCLNR-19
TCN 63 SP 66 LR 6 SR 10402352 HW 4.0
A/S-PCLNR/L
Lever Lock Boring Bars Carrying
Negative 80° Rhombic Inserts
T
WF
LF
H
DCONMS
LDRED
HFB
DMIN
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF T DMIN Insert
S20S PQLNR/L-09
20.00 250.00 40.0 18.0 9.0 13.00 6.5 25.00 QNMG 0904
S25T PQLNR-09
25.00 300.00 40.0 23.0 11.5 17.00 6.5 32.00 QNMG 0904
S32U PQLNR-09
32.00 350.00 45.0 29.0 14.5 22.00 6.5 40.00 QNMG 0904
S25T PQLNR/L-12
25.00 300.00 40.0 23.0 11.5 17.00 8.5 32.00 QNMG 1204
S32U PQLNR/L-12
32.00 350.00 45.0 29.0 14.5 22.00 8.5 40.00 QNMG 1204
S40V PQLNR/L-12
40.00 400.00 50.0 36.0 18.0 27.00 8.5 50.00 QNMG 1204
For inserts, see pages: QNMG-GN (183) • QNMG-NF (182) • QNMG-PP (182) • QNMG-TF (182)
Spare Parts
Designation
S20S PQLNR/L-09
LR 3S SR 117-2016 HW 2.0
S25T PQLNR-09
LR 3S SR 117-2016 HW 2.0
S32U PQLNR-09
TXC 322 SP 3 PN 3-4 LR 3 SR 117-2014 HW 2.5
S25T PQLNR/L-12
LR 4M SR 117-2011 HW 2.5/5
S32U PQLNR/L-12
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
S40V PQLNR/L-12
TSN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
S-PQLNR/L
Lever Lock Boring Bars
Carrying Negative Square
Inserts with 80° Corners
ISCAR
102
ISOTURN TOOLS
WF
LF
H
DCONMS
LDRED
HFB
DMIN
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF DMIN CSP(5) Insert
A16M PCLNR/L-09G (1)
16.00 150.00 30.0 15.0 7.5 11.00 21.00 1 CNMG 0904..
A20Q PCLNR/L-09G (1)
20.00 180.00 30.0 18.0 9.0 13.00 25.00 1 CNMG 0904..
A25R PCLNR/L-09X (2)
25.00 200.00 35.0 23.0 11.5 17.00 32.00 1 CNMX 0906, CNMG 0904
A32S PCLNR/L-09X (2)
32.00 250.00 40.0 29.0 14.5 22.00 40.00 1 CNMX 0906, CNMG 0904
A25R PCLNR/L-12X (3)
25.00 200.00 51.0 23.0 11.5 21.00 50.00 1 CNMX 1207, CNMG 1204
A32S PCLNR/L-12X (3)
32.00 250.00 51.0 29.0 14.5 21.00 54.00 1 CNMX 1207, CNMG 1204
S50W PCLNR-16X (4)
50.00 450.00 70.0 47.0 23.5 35.00 63.00 0 CNMX 1607, CNMG 1606
(1) For CNMG 0904.. inserts only
(2) Supplied with TCX 3 seat for CNMX 0906.. inserts and TCN 323 seat for CNMG 0904.. inserts.
(3) Supplied with TCX 4 seat for CNMX 1207.. inserts and TCN 443 seat for CNMG 1204.. inserts.
(4) Supplied with TCN 53 seat for CNMG 1606.. inserts. Use TCX 5 seat (optional) for CNMX 1607.. inserts.
(5) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNGX-M3N (209) • CNMG-F3S (147) • CNMX-M3/4MW (152) • CNMX-M3/4PW (152)
• CNMG-F3P (144) • CNMG-M3P (144) • CNMG-F3M (146) • CNMG-M3M (146) • CNMG-R3M (147) • CNMM-R3P (153) • CNGA-2 (CBN) (226)
• CNGA-4 (CBN) (225) • CNGA-Ceramic (217) • CNGG-M4HF/M4HM (CBN) (226) • CNMA (149) • CNMA (PCD) (221) • CNMA-MW4 (CBN) (225)
• CNMA-T/M1/WG (CBN) (225) • CNMG-Ceramic (216) • CNMG-GN (151) • CNMG-MR (151) • CNMG-NF (148) • CNMG-NR (151) • CNMG-VL (147) • CNMG-WF (148)
• CNMG-WG/NRW (149) • CNMG/CNGG-PP (150) • CNMG/CNGG-SF (148) • CNMG/CNGG-TF (150) • CNMS-12 (214)
• CNGG-F3N (209) • CNMG-CERMET (145)
CNMG 0904..
CNMG 1204..
CNMG 1606..
TCN 323
TCN 443
TCN 53
CNMX 0906..
CNMX 1207..
CNMX 1607..
TCX 3
TCX 4
TCX 5
Spare Parts
Designation
A16M PCLNR/L-09G
LR 3S SR 117-2009 HW 2.0 PL 16
A20Q PCLNR/L-09G
LR 3S SR 117-2009 HW 2.0 PL 20
A25R PCLNR/L-09X
TCX 3(a) TCN 323 SP 3 PN 3-4 LR 3 SR 117-2014 HW 2.5 PL 25
A32S PCLNR/L-09X
TCX 3(a) TCN 323 SP 3 PN 3-4 LR 3 SR 117-2014 HW 2.5 PL 32
A25R PCLNR/L-12X
TCX 4 TCN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 HW 3.0 PL 25 LR 4DHTL (MR INJ)*
A32S PCLNR/L-12X
TCX 4 TCN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 HW 3.0 PL 32 LR 4DHTL (MR INJ)*
S50W PCLNR-16X
TCX 5* TCN 53 SP 5 LR 5 SR LCS 5 HW 3.0
* Optional, should be ordered separately
(a) For CNMX 0906.. (CNMX 34.) inserts
A/S-PCLNR/L-X/G
Lever Lock Boring Bars Carrying
Negative CNMX/CNMG
80° Rhombic Inserts
103
ISOTURN TOOLS
DCONMS
WF
LF
H
LDRED
HFB DMIN
95º
Designation
DCONMS LF LDRED H HFB WF DMIN Insert
A10K SWLNR/L-04
10.00 125.00 20.0 9.0 5.5 6.00 12.00 WNGP 04 SR 34-514 T-7F
A12M SWLNR/L-04
12.00 150.00 24.0 11.0 6.5 7.00 14.00 WNGP 04 SR 34-514 T-7F
A16Q SWLNR/L-04
16.00 180.00 32.0 15.0 8.5 9.00 18.00 WNGP 04 SR 34-514 T-7F
A20R SWLNR/L-04
20.00 200.00 36.0 18.0 10.5 11.00 22.00 WNGP 04 SR 34-514 T-7F
E10M SWLNR/L-04
10.00 150.00 25.0 9.0 5.5 6.00 12.00 WNGP 04 SR 34-514 T-7F
E12Q SWLNR/L-04
12.00 180.00 27.0 11.0 6.5 7.00 14.00 WNGP 04 SR 34-514 T-7F
E16R SWLNR/L-04
16.00 200.00 32.0 15.0 8.5 9.00 18.00 WNGP 04 SR 34-514 T-7F
E20S SWLNR/L-04
20.00 250.00 36.0 18.0 10.5 11.00 22.00 WNGP 04 SR 34-514 T-7F
• Use left-hand inserts on right-hand bars and vice versa. • A - steel shank with coolant hole, E - carbide shank with coolant hole.
For inserts, see pages: WNGP-F2M (137) • WNGP-F2P (135)
A/E-SWLNR/L-04
Boring Bars Carrying
WNGP 0403.. Double-Sided
Trigon Inserts for Small Diameters
H
DCONMS
LDRED
WF
HFB
HF
LF
DMIN
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF DMIN HF CSP(2) Insert
A20 MWLNR/L-06W-AD (1)
20.00 100.00 28.0 18.0 9.0 13.00 25.00 0.0 1 WNMG 06T3
A20Q MWLNR/L-06W
20.00 180.00 28.0 18.0 9.2 13.00 25.00 0.2 1 WNMG 06T3
A25R MWLNR/L-06W
25.00 200.00 34.0 23.0 11.7 17.00 32.00 0.2 1 WNMG 06T3
A32S MWLNR/L-06W
32.00 250.00 28.0 29.0 14.7 19.00 36.00 0.2 1 WNMG 06T3
S20S MWLNR/L-06W
20.00 250.00 28.0 18.0 9.2 13.00 25.00 0.2 0 WNMG 06T3
S25T MWLNL-06W
25.00 300.00 28.0 23.0 11.7 17.00 32.00 0.2 0 WNMG 06T3
S25T MWLNR-06W
25.00 300.00 28.0 23.0 11.7 17.00 32.00 0.2 0 WNMG 06T3
S32U MWLNL-06W
32.00 350.00 40.0 29.0 14.7 19.00 36.00 0.2 0 WNMG 06T3
S32U MWLNR-06W
32.00 350.00 28.0 29.0 14.7 19.00 36.00 0.2 0 WNMG 06T3
A25R MWLNR/L-08W
25.00 200.00 40.0 23.0 11.7 17.00 32.00 0.2 1 WNMG 0804
A25 MWLNR-08W-AD (1)
25.00 120.00 35.0 23.0 11.7 17.00 32.00 0.2 1 WNMG 0804
A32S MWLNR/L-08W
32.00 250.00 45.0 29.0 14.7 22.00 40.00 0.2 1 WNMG 0804
A40T MWLNR/L-08W
40.00 300.00 50.0 36.0 18.2 27.00 50.00 0.2 1 WNMG 0804
S25T MWLNR/L-08W
25.00 300.00 35.0 23.0 11.7 17.00 32.00 0.2 0 WNMG 0804
S32U MWLNR/L-08W
32.00 350.00 45.0 28.0 14.7 22.00 40.00 0.7 0 WNMG 0804
S40V MWLNR/L-08W
40.00 400.00 50.0 36.0 18.2 27.00 50.00 0.2 0 WNMG 0804
S50V MWLNR/L-13W
50.00 400.00 63.0 47.0 23.5 35.00 63.00 0.0 0 WNMG 1306
(1) AD - short tool for adapter holders
(2) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3S (138) • WNMG-F3M (137) • WNMG-M3M (138) • WNMM-NM (142)
• WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-SF (138) • WNMG-NF (139)
• WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224)
• WNMG-CERMET (136) • WNGG-F3N (209)
Spare Parts
Designation
A20 MWLNR/L-06W-AD
ZNW 3WI LC 250 SET 1 HW 2.5 PL 20
A20Q MWLNR/L-06W
ZNW 3WI LC 250 SET 1 HW 2.5 PL 20
A25R MWLNR/L-06W
IWSN 322W IWSN 3-2W(a)*ZNW 3W LC 250 SET 1 HW 2.5 PL 25
A32S MWLNR/L-06W
IWSN 322W IWSN 3-2W(a)*ZNW 3W LC 250 SET 1 HW 2.5 PL 32
S20S MWLNR/L-06W
ZNW 3WI LC 250 SET 1 HW 2.5
S25T MWLNR/L-06W
IWSN 322W IWSN 3-2W(a)*ZNW 3W LC 250 SET 1 HW 2.5
S32U MWLNR/L-06W
IWSN 322W IWSN 3-2W(a)*ZNW 3W LC 250 SET 1 HW 2.5
A25R MWLNR/L-08W
TWN 423 ZNW-4WI LC 252 SET 2 HW 3.0 PL 25
A25 MWLNR-08W-AD
TWN 423 ZNW-4WI LC 252 SET 2 HW 3.0 PL 25
A32S MWLNR/L-08W
TWN 423 ZNW-4WI LC 252 SET 1 HW 3.0 PL 32
A40T MWLNR/L-08W
IWSN 433 IWSN 433M(b)*ZNW 4W LC 252 SET 1 HW 3.0 PL 40
S25T MWLNR/L-08W
TWN 423 ZNW-4WI LC 252 SET 2 HW 3.0
S32U MWLNR/L-08W
TWN 423 ZNW-4WI LC 252 SET 1 HW 3.0
S40V MWLNR/L-08W
IWSN 433 IWSN 433M(b)*ZNW 4W LC 252 SET 1 HW 3.0
S50V MWLNL-13W
IWSN 635 ZNW 6W LC 253 SPR 17-362 WA M8 HW 4P
S50V MWLNR-13W
IWSN 635 ZNW 6W LC 253 SPR 17-362 WA M8 HW 4P
* Optional, should be ordered separately
(a) Use IWSN 3-2W optional seat for WNMG 0604.. inserts
(b) Use IWSN 433M optional seat for WNMG 0804..-TNM inserts
A/S-MWLNR/L-W
Top Wedge Lock Boring Bars
Carrying Double-Sided
Trigon Inserts
ISCAR
104
ISOTURN TOOLS
LDRED
DCONMS
WF
H
LF
HFB
HF DMIN
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF DMIN HF CSP(1) Insert
A16M PWLNR/L-06
16.00 150.00 27.0 15.0 8.0 11.00 20.00 0.5 1 WNMG 06T3
A20Q PWLNR/L-06
20.00 180.00 36.0 18.0 9.2 13.00 25.00 0.2 1 WNMG 06T3
A25R PWLNR/L-06
25.00 200.00 35.0 23.0 11.7 17.00 32.00 0.2 1 WNMG 06T3
S16Q PWLNR/L-06
16.00 180.00 27.0 15.0 8.0 11.00 20.00 0.5 0 WNMG 06T3
S20R PWLNR/L-06
20.00 200.00 36.0 18.0 9.0 13.00 27.00 0.0 0 WNMG 06T3
S25S PWLNR/L-06
25.00 250.00 40.4 23.0 11.5 17.00 32.00 0.0 0 WNMG 06T3
S32T PWLNR-06
32.00 300.00 50.0 29.0 14.5 19.00 39.00 0.0 0 WNMG 06T3
A25R PWLNL-08
25.00 200.00 47.0 23.0 11.5 17.00 32.00 0.5 1 WNMG 0804
A25R PWLNR-08
25.00 200.00 47.5 23.0 11.7 17.00 32.00 0.2 1 WNMG 0804
A32S PWLNR/L-08
32.00 250.00 50.0 28.0 14.7 22.00 39.00 0.7 1 WNMG 0804
S25S PWLNR/L-08
25.00 250.00 47.0 23.0 11.5 17.00 32.00 0.0 0 WNMG 0804
S32T PWLNR/L-08
32.00 300.00 50.0 29.0 14.5 22.00 39.00 0.0 0 WNMG 0804
S40U PWLNR/L-08
40.00 350.00 59.0 36.0 18.0 27.00 49.00 0.0 0 WNMG 0804
(1) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: WNMG-F3S (138) • WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137) • WNMG-M3M (138) • WNMG-TF (141)
• WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140) • WNMG-VL (139) • WNMG-TNM (142) • WNMG-SF (138) • WNMG-NF (139) • WNMM-NM (142)
• WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216) • WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224)
• WNMG-CERMET (136)
Spare Parts
Designation
A16M PWLNR/L-06
LR 3S SR 117-2009 PL 16 HW 2.0/5
A20Q PWLNR/L-06
TWN 322 SP 3 PN 3-4 LR 3W SR 117-2014 PL 20 HW 2.5/5
A25R PWLNR/L-06
TWN 322 SP 3 PN 3-4 LR 3 SR 117-2014 PL 25 HW 2.5/5
S16Q PWLNR/L-06
LR 3S SR 117-2009 HW 2.0/5
S20R PWLNR/L-06
TWN 322 SP 3 PN 3-4 LR 3W SR 117-2014 HW 2.5/5
S25S PWLNR/L-06
TWN 322 SP 3 PN 3-4 LR 3 SR 117-2014 HW 2.5/5
S32T PWLNR-06
TWN 322 SP 3 PN 3-4 LR 3 SR 117-2014 HW 2.5/5
A25R PWLNR/L-08
LR 4M SR 117-2011 PL 25 HW 2.5/5
A32S PWLNR/L-08
TWN 423 SP 4 PN 3-4 LR 4 SR 117-2010 PL 32 HW 3.0
S25S PWLNR/L-08
LR 4M SR 117-2011 HW 2.5/5
S32T PWLNR/L-08
TWN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
S40U PWLNR/L-08
TWN 423 SP 4 PN 3-4 LR 4 SR 117-2010 HW 3.0
A/S-PWLNR/L
Lever Lock Boring Bars Carrying
Double-Sided Trigon Inserts
WF
LF
H
DCONMS
LDRED
HFB
HF DMIN 95º
Designation
DCONMS H HFB LF LDRED WF DMIN HF Insert
A16M PWLNR/L-06G (1)
16.00 15.0 8.0 150.00 30.0 11.00 25.00 0.5 WNMG 0604
A20Q PWLNR/L-06G (1)
20.00 18.0 9.2 180.00 35.0 13.00 25.00 0.2 WNMG 0604
A25R PWLNR-06G (1)
25.00 23.0 11.5 200.00 35.0 17.00 32.00 0.0 WNMG 0604
A32S PWLNR-06G (1)
32.00 29.0 14.5 250.00 48.0 22.00 40.00 0.0 WNMG 0604
A32S PWLNR/L-08X (2)
32.00 29.0 14.5 250.00 51.0 21.00 54.00 0.0 WNMX 0807, WNMG 0804
(1) For WNMG 0604.. inserts only
(2) Supplied with TWX 4 seat for WNMX 0807.. inserts and TWN 443 seat for WNMG 0804.. inserts
For inserts, see pages: WNGG-F3N (209) • WNMA/WNMA-WG (143) • WNMG-F3M (137) • WNMG-F3P (135) • WNMG-F3S (138) • WNMG-GN (141)
• WNMG-M3M (138) • WNMG-M3P (135) • WNMG-NF (139) • WNMG-PP (140) • WNMG-TF (141) • WNMG-WF (140) • WNMG-WG (139) • WNMX-M3/4MW (143)
• WNMX-M3/4PW (143)
Spare Parts
Designation
A16M PWLNR/L-06G
LR 3S SR 117-2009 PL 16 HW 2.0
A20Q PWLNR/L-06G
LR 3S SR 117-2009 PL 20 HW 2.0
A25R PWLNR-06G
TWN 3 SP 3 PN 3-4 LR 3W SR 117-2014 PL 25 HW 2.5
A32S PWLNR-06G
TWN 3 SP 3 PN 3-4 LR 3W SR 117-2014 PL 32 HW 2.5
A32S PWLNR/L-08X
TWX 4 TWN 443 SP 4 PN 3-4L LR 4DH SR 117-2010 PL 32 HW 3.0 LR 4DHTL (MR INJ)*
* Optional, should be ordered separately
A-PWLNR/L-X/G
Lever Lock Boring Bars
with Coolant Holes Carrying
HELITURN LD WNMX or
WNMG Trigon Inserts
105
ISOTURN TOOLS
GAMF
GAMP HFB
WF
LF
LDRED
H
DCONMS
DMIN
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF GAMP GAMF DMIN Insert
E16 PWLNR-06 HEAD
16.00 200.00 37.0 15.0 8.0 11.00 -14.0 -6.0 20.00 WNMG/WNGG 06T3
For inserts, see pages: WNMG-CERMET (136) • WNMG-M3P (135) • WNMG-TF (141) • WNMG-GN (141) • WNMG-PP (140) • WNMG-VL (139)
• WNMG-SF (138) • WNMG-NF (139) • WNMA/WNMA-WG (143) • WNMG-WG (139)
Spare Parts
Designation
E-PWLNR/L-HEAD
LR 3S SR 117-2009 HW 2.0/5
E-PWLNR/L-HEAD
Lever Lock Interchangeable
Boring Heads Clamped on a
Solid Carbide Shank Carrying
Negative WNMG Trigon Inserts
HFB
GAMP
WF
LF H
DMIN
GAMF
DCONMS
LDRED
HF
Right-hand shown
95º95º
Designation
DCONMS LF LDRED H HFB WF HF GAMP GAMF DMIN Insert
S25T MULNR-12MW
25.00 300.00 45.0 23.0 11.6 17.00 -11.4 -6.0 -12.0 36.00 WM..0804/CN..1204
• Only LC WN08 is supplied with the boring bar. The other wedge should be ordered separately.
For inserts, see pages: CNGA-J(CBN) (226) • CNGG-J(CBN) (227) • CNMG-CERMET (145) • CNMG-F3S (147) • WNMG-CERMET (136) • WNMG-F3S (138)
• WNMG-F3P (135) • WNMG-M3P (135) • WNMG-F3M (137) • WNMG-M3M (138) • WNMG-TF (141) • WNMG-GN (141) • WNMG-NR (142) • WNMG-PP (140)
• WNMG-VL (139) • WNMG-TNM (142) • WNMG-NF (139) • WNMM-NM (142) • WNMG-WF (140) • WNMA/WNMA-WG (143) • WNMG-WG (139) • WNGA-Ceramic (216)
• WNGA-M3 (CBN) (224) • WNGA-MC/M6 (CBN) (224) • CNMG-F3P (144) • CNMG-M3P (144) • CNMM-R3P (153) • CNMM-M4PW (152) • CNMG-F3M (146)
• CNMG-M3M (146) • CNMG/CNGG-TF (150) • CNMG-GN (151) • CNMG-NR (151) • CNMG/CNGG-PP (150) • CNMG-VL (147) • CNMG/CNGG-SF (148)
• CNMG-NF (148) • CNMG-WF (148) • CNMG-WG/NRW (149) • CNMA (149) • CNGA-Ceramic (217) • CNMG-Ceramic (216) • CNGA-2 (CBN) (226)
• CNGA-4 (CBN) (225) • CNGG-M4HF/M4HM (CBN) (226) • CNMA-MW4 (CBN) (225) • CNMA-T/M1/WG (CBN) (225) • CNMA (PCD) (221)
SPR 17-307
S-MULNR/L
MULNR/L-12M
####
SR 17-307
TCN 423
DK 17-307
ZNW-4CMI
LC WN08
(_WNM_ 08(43
LCR CN12 / LCL CN12
(_CNM_ 12(43
WNMG
CNMG
7102122
Toolholder Options
Spare Parts
Designation
S-MULNR-MW
TCN 423 ZNW 4CMI LC WN08 LCR CN12* SR 17-307 SPR 17-307 DK 17-307 HW 3.0
* Optional, should be ordered separately
S-MULNR-MW
MULTI-WEDGE Lock Boring Bars
Carrying 80° Negative Rhombic
or Trigon or Square Inserts
ISCAR
106
ISOTURN TOOLS
WF
LF H
DCONMS
LDRED
HFB
GAMP
HF DMIN
GAMF
Right-hand shown
93º-95º
50º
MAX
Designation
DCONMS LF LDRED H HFB WF DMIN HF GAMP GAMF Insert
S32T DDUNR/L-15
32.00 300.00 45.0 29.0 15.8 22.00 42.00 1.3 -6.0 -11.0 DNMG 1506
S40U DDUNR/L-15
40.00 350.00 50.0 36.0 19.8 27.00 48.00 1.8 -6.0 -10.0 DNMG 1506
For inserts, see pages: DNGA-J(CBN) (229) • DNMG-F3S (157) • DNMG-F3P (156) • DNMG-M3P (156) • DNMX-M3P (162) • DNMM-R3P (162)
• DNMG-CERMET (158) • DNMG-F3M (157) • DNMG-M3M (157) • DNMG/DNGG-TF (160) • DNMG-GN (161) • DNMG-NR (161) • DNMG/DNGG-PP (160)
• DNMG-VL (160) • DNMG-PF (159) • DNMG-NF (158) • DNMM-NM (162) • DNMA (161) • DNGA-Ceramic (218) • DNGA-2 (CBN) (229) • DNGA-4 (CBN) (229)
• DNGG-M4HF/M4HM (CBN) (230) • DNMA (CBN) (228)
Spare Parts
Designation
S-DDUNR/L
TDN 422(a) TDN 432(b)*SP 4 LCGR-4 SR 10400270-25.5 T-15/5
* Optional, should be ordered separately
(a) Use for DNMG 1506.. inserts
(b) Use for DNMG 1504.. inserts
S-DDUNR/L
R-Clamp Boring Bars Carrying
ISO Negative DNMG Inserts
WF
LDRED LF
H
DCONMS
HFB
GAMP
HF DMIN
GAMF
Right-hand shown
93º-95º
50º
MAX
Designation
DCONMS LF LDRED H HFB HF WF GAMP GAMF DMIN CSP(1) Insert
A20Q PDUNR/L-11
20.00 180.00 35.0 18.0 9.2 0.2 16.00 -6.0 -14.0 27.00 1 DNMG 1104
A25R PDUNR/L-11
25.00 200.00 40.0 23.0 11.5 0.0 17.00 -6.0 -13.0 32.00 1 DNMG 1104
A32S PDUNR/L-11
32.00 250.00 45.0 29.0 14.5 0.0 22.00 -6.0 -11.0 40.00 1 DNMG 1104
S32T PDUNR/L-15
32.00 300.00 51.0 29.0 15.5 1.0 22.00 -6.0 -13.0 40.00 0 DNMG 1506
S40U PDUNR/L-15
40.00 350.00 50.0 36.0 18.0 0.0 27.00 -6.0 -11.5 50.00 0 DNMG 1506
(1) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: DNGA-J(CBN) (229) • DNGG-M3N (210) • DNMG-CERMET (158) • DNMG-F3S (157) • DNMG-F3P (156) • DNMG-M3P (156)
• DNMX-M3P (162) • DNMM-R3P (162) • DNMG-F3M (157) • DNMG-M3M (157) • DNMG/DNGG-TF (160) • DNMG-GN (161) • DNMG-NR (161)
• DNMG/DNGG-PP (160) • DNMG-VL (160) • DNMG-PF (159) • DNMG/DNGG-SF (159) • DNMG-NF (158) • DNMM-NM (162) • DNMG-WG (159)
• DNMS-12 (214) • DNMA (161) • DNGA-Ceramic (218) • DNGA-4 (CBN) (229) • DNMA (CBN) (228)
Spare Parts
Designation
A20Q PDUNR/L-11
LR 3DS SR 117-2011 HW 2.5/5 PL 20
A25R PDUNR/L-11
TDN 3P2 SP 3 LR 3D SR 117-2014 HW 2.5/5 PL 25 PN 3-4
A32S PDUNR/L-11
TDN 322 SP 3 LR 3D SR 117-2014 HW 2.5/5 PL 32 PN 3-4
S32T PDUNR/L-15
TDN 422(a) TDN 432(b)*SP 4 LR 4D SR 117-2010 HW 3.0 PN 3-4
S40U PDUNR/L-15
TDN 422(a) TDN 432(b)*SP 4 LR 4D SR 117-2010 HW 3.0 PN 3-4
* Optional, should be ordered separately
(a) Use for DNMG 1506.. inserts
(b) Use for DNMG 1504.. inserts
A/S-PDUNR/L
Lever Lock Boring Bars Carrying
55° Negative Rhombic Inserts
107
ISOTURN TOOLS
DCONMS
WF
LF
H
LDRED
GAMP DMIN GAMF
10 0 º
Designation
DCONMS LF LDRED H WF DMIN GAMP GAMF Insert
A10K SDXNR/L-07
10.00 125.00 20.0 9.0 7.60 13.00 -14.0 -16.0 DNGP 07 SR 34-514 T-7F
A12M SDXNR/L-07
12.00 150.00 24.0 11.0 8.60 16.00 -14.0 -14.0 DNGP 07 SR 34-514 T-7F
A16Q SDXNR/L-07
16.00 180.00 32.0 15.0 10.60 20.00 -13.0 -13.0 DNGP 07 SR 34-514 T-7F
A20R SDXNR/L-07
20.00 200.00 36.0 18.0 12.60 24.00 -13.0 -12.0 DNGP 07 SR 34-514 T-7F
E10M SDXNR/L-07
10.00 150.00 20.0 9.0 7.60 13.00 -14.0 -16.0 DNGP 07 SR 34-514 T-7F
E12Q SDXNR/L-07
12.00 180.00 24.0 11.0 8.60 16.00 -14.0 -14.0 DNGP 07 SR 34-514 T-7F
E16R SDXNR/L-07
16.00 200.00 32.0 15.0 10.60 20.00 -13.0 -13.0 DNGP 07 SR 34-514 T-7F
E20S SDXNR/L-07
20.00 250.00 36.0 18.0 12.60 24.00 -13.0 -12.0 DNGP 07 SR 34-514 T-7F
• Use left-hand inserts on right-hand bars and vice versa. • A - steel shank with coolant hole, E - carbide shank with coolant hole.
For inserts, see pages: DNGP-F2M (156) • DNGP-F2P (155)
A/E-SDXNR/L-07
Boring Bars Carrying DNGP
0703.. Double-Sided
55° Rhombic Inserts for
Small Diameters
l Ref.
DCONMS
WF
HFB
GAMP
LF
H
LDRED
DMIN GAMF 93º
Designation
DCONMS LF LDRED l Ref. H HFB WF DMIN GAMP GAMF Insert
A12M SDZNR/L-07
12.00 150.00 38.0 13.00 11.0 5.5 10.50 14.00 -10.0 -14.0 DNGP 07 SR 34-514 T-7F
A16Q SDZNR/L-07
16.00 180.00 43.0 13.00 15.0 7.5 12.50 16.00 -10.0 -12.5 DNGP 07 SR 34-514 T-7F
A20R SDZNR/L-07
20.00 200.00 48.0 12.50 18.0 9.0 14.50 20.00 -10.0 -10.5 DNGP 07 SR 34-514 T-7F
E12Q SDZNR/L-07
12.00 180.00 - 13.00 11.0 5.5 10.50 18.00 -11.0 -11.0 DNGP 07 SR 34-514 T-7F
E16R SDZNR/L-07
16.00 200.00 - 13.00 15.0 7.5 12.50 22.00 -11.0 -9.0 DNGP 07 SR 34-514 T-7F
• Use right-hand inserts on right-hand bars and vice versa. • A - steel shank with coolant hole, E - carbide shank with coolant hole.
For inserts, see pages: DNGP-F2M (156) • DNGP-F2P (155)
A/E-SDZNR/L-07
Back Turning Boring Bars
Carrying DNGP 0703..
Double-Sided 55° Rhombic
Inserts for Small Diameters
DMIN
GAMF
H
DCONMS
LF
LDRED
WF
HFB
GAMP
Right-hand shown
93º
30°
MAX
Designation
DCONMS LF LDRED H HFB WF DMIN GAMP GAMF
A20Q SVUNR/L-12
20.00 180.00 38.0 18.0 9.0 16.00 26.50 -6.5 -14.0 SR 14-551 T-9/5 PL 20
A25R SVUNR/L-12
25.00 200.00 35.0 23.0 11.5 18.50 31.50 -6.5 -14.0 SR 14-551 T-9/5 PL 25
A32S SVUNR/L-12
32.00 250.00 50.0 29.0 14.5 23.00 37.00 -6.5 -14.0 SR 14-551 T-9/5 PL 32
• For inserts with corner radius of 0.8 mm and larger, seat needs to be modified to ensure clearance.
For inserts, see pages: VNMG-F3M (164) • VNMG-F3P (163) • VNMG-F3S (164) • VNMG-FNF-CERMET (165) • VNMG-M3M (164) • VNMG-SF (165)
• VNMG/VNGG-NF (165) • VNMM-PP (166)
A-SVUNR/L
Boring Bars with Internal
Coolant Holes Carrying 35°
Negative Rhombic Inserts
ISCAR
108
ISOTURN TOOLS
DCONMS
GAMP
DMIN
GAMF
WF 95°
LF
LDRED
95º
48°
MAX
Bar Max
Designation
DCONMS LF LDRED H WF DMIN GAMP GAMF MIID(1)
A40U SVLFNR-22-AL-JHP
40.00 350.00 60.0 36.0 22.50 48.00 4.5 11.0 VNGU 220630-R3N
(1) Master insert identification
For inserts, see pages: VNGU-R3N (210)
Spare Parts
Designation
A40U SVLFNR-22-AL-JHP
TVX 2230(a) SR 14-591/L-SN HW 3.0 PL 40 SW6-T-SH BLD T20/S7 SR TC-4 TVX 2212(b)*TVX 2216(c)*
* Optional, should be ordered separately
(a) For VNGU 220630-R3N insert
(b) For VNGU 220612-R3N insert
(c) For VNGU 220616-R3N insert
A-SVLFNR-AL-JHP
Screw Lock Boring Bars
Carrying 35° Rhombic
Inserts with 7° Clearance
HF
GAMP
DMIN
GAMF
WF 107.5˚
LDRED LF
DCONMS
H
107.5º
35°
MAX
Bar Max
Designation
DCONMS LF LDRED H HF WF DMIN GAMP GAMF MIID(1)
A40U SVQNR/L-22-AL-JHP
40.00 348.10 60.0 36.0 0.1 23.40 49.00 14.5 6.5 VNGU 220630-R3N
(1) Master insert identification
For inserts, see pages: VNGU-R3N (210)
Spare Parts
Designation
A40U SVQNR/L-22-AL-JHP
TVX 2230(a) SR 14-591/L-SN HW 3.0 SW6-T-SH BLD T20/S7 PL 40 SR TC-4 TVX 2212(b)*TVX 2216(c)*
* Optional, should be ordered separately
(a) For VNGU 220630-R3N insert
(b) For VNGU 220612-R3N insert
(c) For VNGU 220616-R3N insert
A-SVQNR/L-AL-JHP
Screw Lock Boring Bars
Carrying 35° Rhombic Inserts
GAMF
DMIN
DCONMS
H
H/2
Optional Coolant
Outlet
GAMP
HFB
WF
LDRED LF Right-hand shown
91º
Designation
DCONMS LF LDRED H HFB WF GAMP GAMF DMIN Insert
A16M PTFNR/L-16G
16.00 150.00 31.0 15.0 7.5 11.00 -12.0 -16.0 20.00 TNMG 1604
A20Q PTFNR/L-16G
20.00 180.00 31.0 18.0 9.0 13.00 -6.0 -14.0 25.00 TNMG 1604
A25S PTFNR/L-16X
25.00 250.00 37.5 23.0 11.5 17.00 -6.0 -14.0 32.00 TNMX 1606, TNMG 1604
A32T PTFNR/L-16X
32.00 300.00 48.0 29.0 14.5 22.00 -6.0 -12.0 40.00 TNMX 1606, TNMG 1604
A40U PTFNR/L-16X
40.00 350.00 50.0 36.0 18.0 27.00 -6.0 -12.0 50.00 TNMX 1606, TNMG 1604
• Use TTX 3 seat for TNMX 1606.. inserts and TTN 3 seat for TNMG 1604.. inserts
For inserts, see pages: TNGA-J(CBN) (233) • TNMG-F3S (169) • TNMX-M3/4PW (167) • TNMX-M3/4MW (168) • TNMG-F3P (167) • TNMG-M3P (167)
• TNMG-F3M (168) • TNMG-M3M (168) • TNMG-FFG-CERMET (169) • TNGG-M3N (210) • TNMG-TF (170) • TNMG-GN (171) • TNMG/TNGG-PP (171)
• TNMG-VL (170) • TNMG-PF (170) • TNMG-SF (169) • TNMG-NF (171) • TNMS-12 (214) • TNMA (172) • TNGA-Ceramic (219) • TNGA-M3 (CBN) (234)
• TNGA-MC/M6 (CBN) (233) • TNMA (CBN) (233)
Spare Parts
Designation
A16M PTFNR/L-16G
LR 3S SR 117-2009 HW 2.0 PL 16
A20Q PTFNR/L-16G
LR 3S SR 117-2009 SR M4X4 DIN913 TL360 HW 2.0 PL 20
A25S PTFNR/L-16X
TTX 3 TTN 3 SP 3 PN 3-4 LR 3 SR 117-2014 SR M4X4 DIN913 TL360 HW 2.5 PL 25
A32T PTFNR/L-16X
TTX 3 TTN 3 SP 3 PN 3-4 LR 3 SR 117-2014 SR M4X4 DIN913 TL360 HW 2.5 PL 32
A40U PTFNR/L-16X
TTX 3 TTN 3 SP 3 PN 3-4 LR 3 SR 117-2014 SR M4X4 DIN913 TL360 HW 2.5 PL 40
A-PTFNR/L-X/G
91° Lead Angle Lever Lock Boring
Bars Carrying Negative TNMX
or TNMG Triangular Inserts
109
ISOTURN TOOLS
WF
LF
H
DCONMS
LDRED
HFB GAMP
DMIN
GAMF
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF GAMP GAMF DMIN Insert
S25S MTLNR/L-16W-M
25.00 250.00 40.0 23.0 11.5 17.00 -6.0 -12.0 32.00 TNMG 1604
S32T MTLNR/L-16W-M
32.00 300.00 50.0 30.0 15.0 22.00 -6.0 -12.0 40.00 TNMG 1604
S40U MTLNR/L-22W
40.00 350.00 50.0 36.0 18.0 27.00 -6.0 -10.0 49.00 TNMG 2204
For inserts, see pages: TNGA-J(CBN) (233) • TNGG-M3N (210) • TNMG-F3S (169) • TNMG-FFG-CERMET (169) • TNMG-F3P (167) • TNMG-M3P (167)
• TNMG-F3M (168) • TNMG-M3M (168) • TNMG-TF (170) • TNMG-GN (171) • TNMM-NR (172) • TNMG/TNGG-PP (171) • TNMG-VL (170) • TNMG-PF (170)
• TNMG-SF (169) • TNMG-NF (171) • TNMA (172) • TNGA-Ceramic (219) • TNGA-M3 (CBN) (234) • TNGA-MC/M6 (CBN) (233) • TNMA (CBN) (233)
Spare Parts
Designation
S25S MTLNR/L-16W-M
ZNW 3WNS SR 17-317NS LC 291N CLAMP HW 3.0 E RING N
S32T MTLNR/L-16W-M
TTT 322N TTT 332N(a)*ZNW 3WN SR 17-317N LC 291N CLAMP HW 3.0 E RING N
S40U MTLNR/L-22W
TTT 434 ZNW 4 SR 17-295 HW 2.5 LC 281 SET 1 HW 3.0
* Optional, should be ordered separately
(a) Use for TNMG 1603.. inserts
S-MTLNR/L-W
95° Lead Angle Wedge
Lock Boring Bars Carrying
Negative Triangular Inserts
LDRED
DMIN
GAMF
WF
LF
H
DCONMS
HFB
GAMP
Right-hand shown
91º
Designation
DCONMS LF LDRED H HFB WF GAMP GAMF DMIN Insert
S20R PTFNR/L-11
20.00 200.00 32.0 18.0 9.0 13.00 -6.0 -14.0 24.00 TNMG 1103
S25S PTFNR/L-16
25.00 250.00 48.0 23.0 11.5 17.00 -6.0 -13.0 32.50 TNMG 1604
S32T PTFNL-16
32.00 300.00 63.0 30.0 15.0 22.00 -6.0 -13.0 40.00 TNMG 1604
S32T PTFNR-16
32.00 300.00 63.0 30.0 15.0 22.00 -6.0 -10.0 40.00 TNMG 1604
S40U PTFNR-16
40.00 350.00 30.0 36.0 18.0 27.00 -6.0 -10.0 49.00 TNMG 1604
S40U PTFNR-22
40.00 350.00 62.0 36.0 18.0 27.00 -6.0 -10.0 49.00 TNMG 2204
For inserts, see pages: TNGA-J(CBN) (233) • TNGG-M3N (210) • TNMG-F3S (169) • TNMG-FFG-CERMET (169) • TNMG-F3P (167) • TNMG-M3P (167)
• TNMG-F3M (168) • TNMG-M3M (168) • TNMG-TF (170) • TNMG-GN (171) • TNMM-NR (172) • TNMG/TNGG-PP (171) • TNMG-VL (170) • TNMG-PF (170)
• TNMG-SF (169) • TNMG-NF (171) • TNMS-12 (214) • TNMA (172) • TNGA-Ceramic (219) • TNGA-M3 (CBN) (234) • TNGA-MC/M6 (CBN) (233)
• TNMA (CBN) (233)
Spare Parts
Designation
S20R PTFNR/L-11
LR 2 SR 117-2015 HW 2.0/5
S25S PTFNR/L-16
TTN 322 TTN 332* SP 3 LR 3 SR 117-2014 HW 2.5/5 PN 3-4
S32T PTFNR/L-16
TTN 322 TTN 332* SP 3 LR 3 SR 117-2014 HW 2.5/5 PN 3-4
S40U PTFNR-16
TTN 322 SP 3 LR 3 SR 117-2014 HW 2.5/5 PN 3-4
S40U PTFNR-22
TTN 422 SP 4 LR 4 SR 117-2010 HW 3.0 PN 3-4
* Optional, should be ordered separately
S-PTFNR/L
91° Lead Angle Lever
Lock Boring Bars Carrying
Negative Triangular Inserts
ISCAR
110
ISOTURN TOOLS
DMIN
GAMF
HFB
GAMP
LF
LDRED
WF
H
DCONMS
Right-hand shown
45º
90º
95º
95º
Designation
DCONMS LF LDRED H HFB DMIN GAMP GAMF WF
S16Q SUXCR/L-10 CM
16.00 180.00 45.0 15.0 7.5 20.00 0.0 -12.0 11.00
S20R SUXCR/L-10 CM
20.00 200.00 52.0 18.0 9.0 25.00 0.0 -6.0 13.00
S25S SUXCR/L-10 CM
25.00 250.00 55.0 23.0 11.5 32.00 0.0 -4.0 17.00
For inserts, see pages: CC95MT-SM (208) • SC45MT-SM (209)
Clamping direction for SC45MT...
• Unique, versatile ISCAR pocket
• For external applications
• Covers most common operations
• Simplifies tool selection
• Simple screw clamping
• Minimum spare parts
Multifunction Tool Can
Carry Two Different Inserts
SC45MT
Designation
DCONMS LF LDRED H HEB DMIN GAMP GAMF WF Inserts
S16Q SUXCR/L-10 CM
16.00 180.00 45.0 15.0 7.5 20.00 0 -12 11 CC95MT...
12.14 SC45MT...
S20R SUXCR/L-10 CM
20.00 200.00 52.0 18.0 9.0 25.00 0 -6 13 CC95MT...
14.14 SC45MT...
S25S SUXCR/L-10 CM
25.00 250.00 55.0 23.0 11.5 32.00 0 -4 17 CC95MT...
18.14 SC45MT...
Spare Parts
Designation
S-SUXCR/L-CM
SR 14-544/S T-15/5
S-SUXCR/L-CM
Screw Lock Boring Bars
Carrying Four Different 7°
Clearance Geometries
T
WF
LF
LDRED H
DCONMS
HFB
GAMP DMIN
GAMF
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF T GAMP GAMF DMIN CSP(1) Insert
S16Q SQLCR/L-09
16.00 180.00 45.0 15.0 7.5 11.00 8.5 0.0 -12.0 20.00 0 QCMT 09T304
S20R SQLCR-09
20.00 200.00 45.0 15.0 7.5 13.00 8.5 0.0 -6.0 25.00 0 QCMT 09T304
S25S SQLCR-09
25.00 250.00 55.0 15.0 7.5 17.00 8.5 0.0 -6.0 32.00 0 QCMT 09T304
(1) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: QCMT-PF (203) • QCMT-SM (203)
Spare Parts
Designation
S/A-SQLCR/L
SR 16-236 T-15/5
S/A-SQLCR/L
Screw Lock Boring Bars
Carrying 80° Square Inserts
with 7° Clearance
GAMP
WF
LF
H
GAMF
DCONMS
LDRED
HFB
DMIN
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF GAMP GAMF DMIN Insert
E12 SCLCR/L-06 HEAD
12.00 179.00 24.8 11.0 5.5 9.00 0.0 -7.0 15.80 CCMT/CCGT 0602 SR 14-548 T-7/5
E16 SCLCR-09 HEAD
16.00 200.00 37.0 15.0 7.5 11.00 0.0 -9.0 20.00 CCMT/CCGT 09T3 SR 16-236 T-15/5
For inserts, see pages: CCMT-CERMET (187) • CCMT-F3P (185) • CCMT-M3P (185) • CCMT-F3M (186) • CCMT-M3M (186) • CCMT-PF (188)
• CCMT/CCGT-SM (187) • CCET-WF (189) • CCMT-WG (189) • CCGT-AS (212) • CCGT-AF (212) • CCMT-14 (188) • CCMT/CCGT (188) • CCGW/CCMT (CBN) (227)
• CCGW/CCMW-2 (CBN) (228) • CCMT (PCD) (222)
E-SCLCR/L-HEAD
Screw Clamped Boring Heads
Carrying 80° Rhombic Inserts
with Positive 7° Clearance
Mounted on Carbide Bars
111
ISOTURN TOOLS
WF
LDRED LF
H
DCONMS
HFB
GAMP
HF DMIN
GAMF
95º
Designation
DCONMS LF LDRED WF H HFB HF DMIN CSP(1) GAMP GAMF TQ Insert
A04F SCLCR/L-03
4.00 80.00 8.0 2.50 3.8 1.9 0.0 5.00 1 0.0 -15.0 0.6 CCGT 03X1
A05F SCLCR/L-03
5.00 80.00 9.0 3.00 4.8 2.4 0.0 6.00 1 0.0 -13.0 0.6 CCGT 03X1
A06G SCLCR/L-04
6.00 90.00 10.0 3.50 5.8 2.9 0.0 7.00 1 0.0 -13.0 0.6 CCGT 04T1
A07G SCLCR/L-04
7.00 90.00 11.0 4.00 6.8 3.4 0.0 8.00 1 0.0 -11.0 0.6 CCGT 04T1
A20R SCLCR/L-09
20.00 200.00 35.0 13.00 18.0 9.0 0.0 25.00 1 0.0 -4.0 3.0 CC.. 09T3
A25S SCLCR/L-09
25.00 250.00 35.0 17.00 23.0 11.5 0.0 32.00 1 0.0 -4.0 3.0 CC.. 09T3
E04G SCLCR/L-03
4.00 90.00 9.0 2.50 3.8 1.9 0.0 5.00 1 0.0 -15.0 0.6 CCGT 03X1
E05G SCLCR/L-03
5.00 90.00 10.0 3.00 4.8 2.4 0.0 6.00 1 0.0 -13.0 0.6 CCGT 03X1
E06H SCLCR/L-04
6.00 100.00 12.0 3.50 5.8 2.9 0.0 7.00 1 0.0 -13.0 0.6 CCGT 04T1
E07H SCLCR/L-04
7.00 100.00 14.0 4.00 6.8 3.4 0.0 8.00 1 0.0 -11.0 0.6 CCGT 04T1
E08K SCLCR/L-06
8.00 125.00 - 5.00 7.6 3.8 0.0 10.00 1 3.0 -11.0 1.0 CC.. 0602
E10M SCLCR/L-06
10.00 150.00 - 7.00 9.2 4.6 0.0 14.00 1 3.0 -7.0 1.0 CC.. 0602
E12Q SCLCR/L-06
12.00 180.00 - 9.00 11.0 5.5 0.0 16.00 1 0.0 -7.0 1.0 CC.. 0602
E16R SCLCR/L-06
16.00 200.00 - 11.00 14.0 7.0 0.0 20.00 1 0.0 -7.0 1.0 CC.. 0602
E16R SCLCR/L-09
16.00 200.00 - 11.00 15.0 7.5 0.0 20.00 1 0.0 -6.0 3.0 CC.. 09T3
S08K SCLCR/L-06
8.00 125.00 12.0 5.00 8.0 3.8 0.0 10.50 0 0.0 -11.0 1.0 CC.. 0602
S10L SCLCL-06
10.00 140.00 20.0 7.00 9.0 4.5 0.0 13.00 0 0.0 -7.0 1.0 CC.. 0602
S10L SCLCR-06
10.00 140.00 20.0 7.00 9.0 4.5 0.0 13.00 0 3.0 -7.0 1.0 CC.. 0602
S12M SCLCR/L-06
12.00 150.00 12.0 9.00 12.0 5.5 0.0 16.00 0 0.0 -7.0 1.0 CC.. 0602
S16Q SCLCR/L-09
16.00 180.00 45.0 11.00 15.0 7.5 0.0 20.00 0 0.0 -6.0 3.0 CC.. 09T3
S20R SCLCR/L-09
20.00 200.00 50.0 13.00 18.0 9.0 0.0 25.00 0 0.0 -4.0 3.0 CC.. 09T3
S25S SCLCR/L-09
25.00 250.00 55.0 17.00 23.0 11.5 0.0 35.00 0 0.0 -4.0 3.0 CC.. 09T3
• S - steel shank, A - steel shank with coolant hole, E - carbide shank with coolant hole
(1) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: • CCGT-F1M-20P (185) • CCMT-CERMET (187) • CCGT-F1P (184) • CCMT-F3P (185) • CCMT-M3P (185) • CCMT-F3M (186) • CCMT-M3M (186)
• CCMT-PF (188) • CCMT/CCGT-SM (187) • CCET-WF (189) • CCMT-WG (189) • CCGT-AS (212) • CCGT-AF (212) • CCMT-14 (188) • CCMT/CCGT (188)
• CCGW/CCMT (CBN) (227) • CCGW/CCMW-2 (CBN) (228) • CCMT (PCD) (222)
Spare Parts
Designation
A04F SCLCR/L-03
CSTA-1.6 T-6F
A05F SCLCR/L-03
CSTA-1.6 T-6F
A06G SCLCR/L-04
CSTB-2 T-6F
A07G SCLCR/L-04
CSTB-2 T-6F
A20R SCLCR/L-09
SR 16-236 T-15/5 HW 2.0 PL 20
A25S SCLCR/L-09
SR 16-236 T-15/5 HW 2.0 PL 25
E04G SCLCR/L-03
CSTA-1.6 T-6F
E05G SCLCR/L-03
CSTA-1.6 T-6F
E06H SCLCR/L-04
CSTB-2 T-6F
E07H SCLCR/L-04
CSTB-2 T-6F
E08K SCLCR/L-06
SR 14-548 T-7/5
E10M SCLCR/L-06
SR 14-548 T-7/5
E12Q SCLCR/L-06
SR 14-548 T-7/5
E16R SCLCR/L-06
SR 14-548 T-7/5
E16R SCLCR/L-09
SR 16-236 T-15/5
S08K SCLCR/L-06
SR 14-548 T-7/5
S10L SCLCR/L-06
SR 14-548 T-7/5
S12M SCLCR/L-06
SR 14-548 T-7/5
S16Q SCLCR/L-09
SR 16-236/L8.6 T-15/5
S20R SCLCR/L-09
SR 16-236 T-15/5
S25S SCLCR/L-09
SR 16-236 T-15/5
A/E/S-SCLCR/L
Screw Lock Boring Bars
Carrying 80° Rhombic Inserts
with 7° Clearance for 20 mm
Minimum Bore Diameter
ISCAR
112
ISOTURN TOOLS
DMIN
GAMF
DCONMS
WF
LF H
LDRED
GAMP
10 0 º
Designation
DCONMS LF LDRED H WF DMIN GAMP GAMF Insert
A04F SEXPR/L-03
4.00 80.00 8.0 3.8 2.30 4.50 0.0 -15.0 EPGT03 CSTA-1.6 T-6F
E04G SEXPR/L-03
4.00 90.00 9.0 3.8 2.30 4.50 0.0 -15.0 EPGT03 CSTA-1.6 T-6F
• A - steel shank with coolant hole, E - carbide shank with coolant hole
For inserts, see pages: EPGT-F1P (189)
A/E-SEXPR/L-03
Screw Lock Boring Bars
Carrying 75° Rhombic Inserts
with 11° Clearance for 4.5 mm
Minimum Bore Diameter
93°
HFB
GAMP
HF
LDRED
WF
LF
DCONMS
H
DMIN
GAMF
Right-hand shown
93º-95º
50º
MAX
Designation
DCONMS LF LDRED H HFB WF HF DMIN GAMP GAMF Shank m.(1) Insert
A20R SDUCR/L-13-SL
20.00 200.00 36.0 18.0 9.1 14.50 0.1 25.00 0.0 -7.0 S DCMT 13T5-SL
A25S SDUCR/L-13-SL
25.00 250.00 45.0 23.0 11.5 17.00 0.0 32.00 0.0 -6.0 S DCMT 13T5-SL
(1) S-Steel
For inserts, see pages: DCMT-F3P-SL (190) • DCMT-M3M-SL (191) • DCMT-PF-SL (193) • DCMT-SM-SL (193)
Spare Parts
Designation
A20R SDUCR/L-13-SL
SR M4X0.7-L9.6 IP15 TORX PLUS IP15X45 PL 20
A25S SDUCR/L-13-SL
SR M4X0.7-L9.6 IP15 TORX PLUS IP15X45 PL 25
A-SDUCR/L-13-SL
Boring Bars Carrying 55°
Rhombic Inserts with 7°
Clearance Angle for High Rigidity
in Profiling Applications
WF
LF
H
DCONMS
LDRED
HFB
GAMP
HF DMIN
GAMF
Right-hand shown
93º-95º
50º
MAX
Designation
DCONMS LF LDRED H HFB WF HF DMIN GAMP GAMF Shank m.(1) CSP(2) Insert
A20R SDUCR/L-11
20.00 200.00 50.0 18.0 8.5 14.50 -0.5 25.00 0.0 -6.0 S 1 DC.. 11T3
A25S SDUCR/L-11
25.00 250.00 45.0 23.0 12.0 17.00 0.5 32.00 0.0 -5.0 S 1 DC.. 11T3
E10M SDUCR/L-07
10.00 150.00 25.0 9.2 5.1 8.00 0.5 14.00 3.0 -7.0 C 1 DC.. 0702
E12Q SDUCR/L-07
12.00 180.00 - 11.0 5.5 9.00 0.0 16.00 0.0 -7.0 C 1 DC.. 0702
E16R SDUCR/L-07
16.00 200.00 - 15.0 8.1 11.00 0.6 20.00 0.0 -8.0 C 1 DC.. 0702
S10L SDUCR/L-07
10.00 140.00 18.0 9.2 5.0 8.00 0.4 14.00 -3.0 -9.0 S 0 DC.. 0702
S12M SDUCR/L-07
12.00 150.00 20.0 12.0 5.5 9.00 -0.5 16.00 -7.0 -9.0 S 0 DC.. 0702
S16Q SDUCR/L-07
16.00 180.00 25.0 15.0 8.0 11.00 0.5 20.00 0.0 -8.0 S 0 DC.. 0702
S20R SDUCR/L-11
20.00 200.00 50.0 18.0 8.5 13.00 -0.5 25.00 0.0 -6.0 S 0 DC.. 11T3
S25S SDUCR/L-11
25.00 250.00 55.0 23.0 12.0 17.00 0.5 32.00 0.0 -5.0 S 0 DC.. 11T3
• S - steel shank, A - steel shank with coolant hole, E - carbide shank with coolant hole
(1) S-Steel, C-carbide
(2) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: DCGT-F1M-20P (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194) • DCET-WF (195)
• DCGT-AS (213) • DCGT-AF (213) • DCMT-14 (194) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230) • DCMT (CBN) (230) • DCMT (PCD) (222) • DCMT-CERMET (192)
Spare Parts
Designation
A20R SDUCR/L-11
HW 2.0 SR 16-236 P T-15/5 PL 20
A25S SDUCR/L-11
HW 2.0 SR 16-236 P T-15/5 PL 25
E10M SDUCR/L-07
SR 14-548 T-7/5
E12Q SDUCR/L-07
SR 14-548 T-7/5
E16R SDUCR/L-07
SR 14-548 T-7/5
S10L SDUCR/L-07
SR 14-548 T-7/5
S12M SDUCR/L-07
SR 14-548 T-7/5
S16Q SDUCR/L-07
SR 14-548 T-7/5
S20R SDUCR/L-11
SR 16-236 P T-15/5
S25S SDUCR/L-11
TDC 3-1P SR TC-3P HW 4.0 SR 16-236 P T-15/5
A/E/S-SDUCR/L
Screw Lock Boring Bars
Carrying 55° Rhombic
Inserts with 7° Clearance
113
ISOTURN TOOLS
HFB
HF
GAMP
WF
LF
H
GAMF
DCONMS
LDRED DMIN
Right-hand shown
93º-95º
50º
MAX
Designation
DCONMS LF LDRED H HFB WF HF GAMP GAMF DMIN Insert
E12 SDUCR/L-07 HEAD
12.00 179.00 24.8 11.0 5.5 9.00 0.0 0.0 -9.0 15.80 DCMT/DCGT 0702 SR 14-548 T-7/5
E16 SDUCR/L-07 HEAD
16.00 200.00 29.7 15.0 8.0 11.00 0.5 0.0 -9.0 20.00 DCMT/DCGT 0702 SR 14-548 T-7/5
For inserts, see pages: • DCGT-F1M-20P (192) • DCMT-F3P (190) • DCMT-M3M (191) • DCMT/DCGT-PF (193) • DCMT/DCGT-SM (194) • DCET-WF (195)
• DCGT-AS (213) • DCMT/DCGT (194) • DCGW/DCMW-2 (CBN) (230)
E-SDUCR/L-HEAD
Interchangeable Screw Clamped
Boring Heads Carrying Positive 7°
Clearance 55° Rhombic Inserts
Mounted on Carbide Bars
WF
LF
H
DCONMS
LDRED
HFB
GAMP
HF DMIN
GAMF
Right-hand shown
107.5º
35°
MAX
Designation
DCONMS LF LDRED H HFB WF HF DMIN GAMP GAMF CSP(1) Insert
S25S SVQCR/L-16
25.00 250.00 61.0 23.0 12.0 17.00 0.5 32.00 0.0 -5.0 0 VC.. 1604
S32T SVQCR/L-16
32.00 300.00 70.0 30.0 15.0 22.00 0.0 40.00 0.0 -5.0 0 VC.. 1604
A40U SVQCR/L-22
40.00 350.00 64.0 36.0 18.0 27.00 0.0 47.50 0.0 -8.0 1 VCGT 2205
(1) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197) • VCGT-AS (211)
• VCGT-AF (212) • VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)
Spare Parts
Designation
S25S SVQCR/L-16
SR 16-236 P T-15/5
S32T SVQCR/L-16
SR 16-236 P T-15/5 TVC 3-1P SR TC-3P HW 4.0
A40U SVQCR/L-22
SR 14-536 T-20/5 TVC 22T330 SR TC-3 HW 2.5 PL 40
A/S-SVQCR/L
Screw Lock Boring Bars
Carrying 35° Rhombic
Inserts with 7° Clearance
WF
LF
H
DCONMS
LDRED
HFB
GAMP DMIN
GAMF
Right-hand shown
95º
48°
MAX
Designation
DCONMS LF LDRED H HFB WF DMIN GAMP GAMF CSP(2) Insert
A32T SVUCR/L-16 (1)
32.00 300.00 50.0 29.0 14.5 22.00 40.00 0.0 -8.0 1 VC.. 1604
S32T SVLFCR/L-16
32.00 300.00 56.0 29.0 14.5 22.00 39.50 0.0 -8.0 0 VC.. 1604
S40U SVLFCR/L-16
40.00 350.00 - 36.0 18.0 27.00 49.00 0.0 -5.0 0 VC.. 1604
A40U SVLFCR/L-22
40.00 350.00 70.0 36.0 18.0 27.00 48.00 0.0 -8.0 1 VC.. 2205
(1) 93° approach angle
(2) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: VCMT-F3P (195) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197) • VCGT-AS (211) • VCGT-AF (212) • VCMT-14 (198) • VCMW (198)
• VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223) • VCMT-FPC-CERMET (196) • VCGW-2 (CBN) (232)
Spare Parts
Designation
A32T SVUCR/L-16
TVC 3-1P SR TC-3P HW 1.5 HW 4.0 SR 16-236 P PL 32 T-15/5
S32T SVLFCR/L-16
TVC 3-1P SR TC-3P HW 4.0 SR 16-236 P T-15/5
S40U SVLFCR/L-16
TVC 3-1P SR TC-3P HW 4.0 SR 16-236 P T-15/5
A40U SVLFCR/L-22
TVC 22T330 SR TC-3 HW 2.5 SR 14-536 PL 40 T-20/5
A/S-SVLFCR/L; A-SVUCR/L
Screw Lock Boring Bars
Carrying 35° Rhombic
Inserts with 7° Clearance
ISCAR
114
ISOTURN TOOLS
52° HFB
HF
WF
LF
LDRED
H
DMIN DMIN
DCONMS
Right-hand shown
142º
93º
Designation
DCONMS LF LDRED H HFB WF HF DMIN CSP(2) Insert
A16R SVJCR/L-11
16.00 200.00 47.5 15.0 7.5 8.50 0.0 20.00 1 VC.. 1103
S16R SVJCR/L-11 (1)
16.00 200.00 20.0 15.0 8.0 7.00 0.5 19.00 0 VC.. 1103
A20R SVJCR/L-11
20.00 200.00 43.0 18.0 9.0 11.00 0.0 25.00 1 VC.. 1103
S20R SVJCR/L-11
20.00 200.00 37.0 19.0 9.5 2.00 0.0 25.00 0 VC.. 1103
(1) Cannot be used for internal sphere turning • Center height - 0.5mm above the center
(2) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: VCGT-F1M-20P (196) • VCMT-F3P (195) • VCMT-F3M (195) • VCMT-SM (197) • VCET-WF (197) • VCGT-AS (211)
Spare Parts
Designation
A16R SVJCR/L-11
SR 14-560/S T-8/5 PL 16
S16R SVJCR/L-11
SR 14-560/S T-8/5
A20R SVJCR/L-11
SR 14-560 T-8/5 PL 20
S20R SVJCR/L-11
SR 14-560 T-8/5
S/A-SVJCR/L
Screw Lock Boring Bars
Carrying 35° Rhombic
Inserts with 7° Clearance
LDRED
l Ref.
WF
LF
H
DCONMS
HFB
DMIN
Right-hand shown
95º
Designation
DCONMS LF LDRED l Ref. H HFB WF DMIN CSP(1) Insert
A32T SVLBCL-16
32.00 300.00 76.5 18.50 29.0 14.5 27.50 40.00 1 VC.. 1604
A32T SVLBCR-16
32.00 300.00 76.5 18.50 29.0 14.5 27.50 40.00 0 VC.. 1604
S32T SVLBCR/L-16
32.00 300.00 63.2 18.50 29.0 14.5 22.00 40.00 0 VC.. 1604
S40U SVLBCR/L-16
40.00 350.00 60.0 20.00 36.0 18.0 27.00 49.50 0 VC.. 1604
(1) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: VCMT-FPC-CERMET (196) • VCMT-F3P (195) • VCGW-2 (CBN) (232) • VCMT-F3M (195) • VCMT-M3M (196) • VCMT-SM (197) • VCGT-AS (211)
• VCMT-14 (198) • VCMW (198) • VCMT (CBN) (222) • VCGT (PCD) (223) • VCGT-DW (PCD) (223)
Spare Parts
Designation
A/S-SVLBCR/L
TVC 3-1P SR TC-3P HW 4.0 SR 16-236 P T-15/5
A/S-SVLBCR/L
Screw Lock Back Boring
Bars Carrying 35° Rhombic
Inserts with 7° Clearance
WF
DCONMS
LF
H
LDRED
HFB
HF DMIN
95º
Designation
DCONMS LF LDRED H HFB WF HF DMIN Insert
S25S MTLCR/L-16W
25.00 250.00 43.0 23.0 13.1 17.00 1.6 34.00 TC.. 16T3
S32T MTLCR/L-16W
32.00 300.00 45.0 29.0 14.5 22.00 0.0 39.00 TC.. 16T3
For inserts, see pages: TCMT-F3P (201) • TCMT-M3M (201) • TCMT-SM (202) • TCGT-AS (211)
Spare Parts
Designation
S-MTLCR/L-W
TTC 331 HW 2.0 ZNW 3C LC 291-MIM SET 1 SR 17-319 HW 2.5
S-MTLCR/L-W
Wedge Lock Boring Bars Carrying
7° Clearance Triangular Inserts
115
ISOTURN TOOLS
WF
LF
H
DCONMS
LDRED
HFB
DMIN
Right-hand shown
91º
Designation
DCONMS LF LDRED H HFB WF DMIN Insert
S10K STFCR/L-11
10.00 125.00 29.0 9.0 4.5 7.00 13.00 TC.. 1102 SR 14-548 T-7/5
S12M STFCR/L-11
12.00 150.00 30.0 11.0 5.5 9.00 15.80 TC.. 1102 SR 14-548 T-7/5
For inserts, see pages: TCMT-F3P (201) • TCMT-M3M (201) • TCMT-PF (201) • TCMT-SM (202) • TCGT-AS (211) • TCMT (CBN) (234)
• TCMT (PCD) (223)
S-STFCR/L
Screw Lock Boring Bars Carrying
7° Clearance Triangular Inserts
HFB
GAMP
WF
LF
H
GAMF
DCONMS
LDRED
HF DMIN
Right-hand shown
91º
Designation
DCONMS LF LDRED H HFB WF HF GAMP GAMF DMIN Insert
E12 STFCR-11 HEAD
12.00 179.00 24.8 11.0 6.0 6.80 0.0 0.0 -6.0 13.80 TCMT 1102 SR 14-548 T-7/5
E16 STFCR-11 HEAD
16.00 200.00 37.0 15.0 8.0 9.00 0.0 0.0 -6.0 20.00 TCMT 1102 SR 14-548 T-7/5
For inserts, see pages: TCMT-F3P (201) • TCMT-M3M (201) • TCMT-PF (201) • TCMT-SM (202) • TCGT-AS (211) • TCMT (CBN) (234)
• TCMT (PCD) (223)
E-STFCR-HEAD
Interchangeable Screw Clamped
Boring Heads Carrying Positive
7° Clearance Triangular Inserts
Mounted on Carbide Bars
WF
LF
LDRED
H
DCONMS
HFB
DMIN
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB WF DMIN Insert
S16Q STLCR/L-11
16.00 180.00 45.0 15.0 7.5 11.00 20.00 TC.. 1102 SR 14-548 T-7/5
S20R STLCR/L-16
20.00 200.00 50.0 18.0 9.0 13.00 25.00 TC.. 16T3 SR 16-236 T-15/5
For inserts, see pages: TCMT-F3P (201) • TCMT-M3M (201) • TCMT-PF (201) • TCMT-SM (202) • TCGT-AS (211) • TCMT (CBN) (234)
• TCMT (PCD) (223)
S-STLCR/L
Screw Clamp Boring Bars
Carrying 7° Clearance
Triangular Inserts
DCONMS
75°
WF
LDRED LF
H
HFB
GAMP
DMIN
GAMF 75º
Designation
DCONMS LF LDRED H HFB WF GAMP GAMF DMIN Insert
A25R PSKNR/L-09
25.00 200.00 35.0 23.0 11.5 17.00 -6.0 -15.0 32.00 SNMG 0903 SNMG 0904
A32S PSKNR/L-09
32.00 250.00 43.0 30.0 15.0 22.00 -6.0 -13.0 40.00 SNMG 0903 SNMG 0904
For inserts, see pages: SNMG-F3S (175) • SNMG-F3P (173) • SNMG-M3P (173) • SNMG-F3M (174) • SNMG-M3M (174)
Spare Parts
Designation
A25R PSKNR/L-09
TSN 323 TSN 333 SP 3 PN 3-3L LR 3 SR 117-2014 HW 2.5 PL 25
A32S PSKNR/L-09
TSN 323 TSN 333 SP 3 PN 3-3L LR 3 SR 117-2014 HW 2.5 PL 32
A-PSKNR/L-09
Lever Lock Boring Bars Carrying
90° Negative Square Inserts
ISCAR
116
ISOTURN TOOLS
LDRED
H
DCONMS
LF
WF
HFB
HF DMIN
Right-hand shown
75º
Designation
DCONMS LF LDRED H HFB WF HF DMIN Insert
S16Q CSKPR-09
16.00 180.00 34.0 15.0 8.0 11.00 0.5 20.00 SPMR 0903 LC 15 SET 1 HW 2.5
S25S CSKPR-12
25.00 250.00 48.0 23.0 11.5 17.00 0.0 30.00 SPMR 1203 LC 30 SET 2 HW 3.0
For inserts, see pages: SPMR (204)
S-CSKPR
Clamp Lock Boring Bars Carrying
11° Clearance Square Inserts
WF
LF
H
DCONMS
LDRED
HFB
HF DMIN
Right-hand shown
91º
Designation
DCONMS LF LDRED H HFB WF HF DMIN Insert
S12L CTFPR/L-09
12.00 140.00 34.0 11.0 6.0 9.00 0.5 15.60 TPMR 0902
S16Q CTFPR/L-11
16.00 180.00 38.0 15.0 8.0 11.00 0.5 20.00 TPMR 1103
S20Q CTFPR-16
20.00 180.00 38.0 18.0 9.5 13.00 0.5 24.00 TPMR 1603
S20R CTFPR/L-16
20.00 200.00 46.0 18.0 9.5 13.00 0.5 24.00 TPMR 1603
S25R CTFPR-16
25.00 200.00 48.0 23.0 11.5 17.00 0.0 31.00 TPMR 1603
S25S CTFPR-16
25.00 250.00 48.0 23.0 11.5 17.00 0.0 31.00 TPMR 1603
S32T CTFPR/L-16
32.00 300.00 62.0 29.0 14.5 22.00 0.0 40.00 TPMR 1603
S40T CTFPR-16
40.00 300.00 62.0 36.0 18.0 27.00 0.0 48.00 TPMR 1603
For inserts, see pages: TPGN-Ceramic (220) • TPMR (204) • TPMR-FTF (205) • TPMR-PF (204)
Spare Parts
Designation
S12L CTFPR/L-09
LC12 SET1 HW 2.5
S16Q CTFPR/L-11
LC 15 SET 1 HW 2.5
S20Q CTFPR-16
LC 30 SET 2 HW 3.0
S20R CTFPR/L-16
LC 30 SET 2 HW 3.0
S25R CTFPR-16
LC 30 SET 2 HW 3.0
S25S CTFPR-16
LC 30 SET 2 HW 3.0
S32T CTFPR/L-16
LC 30 SET 1 HW 3.0 ITBP 122 SP 16
S40T CTFPR-16
LC 30 SET 1 HW 3.0 ITBP 122 SP 16
S-CTFPR/L
Clamp Lock Boring Bars Carrying
11° Clearance Triangular Inserts
HFB
GAMP
WF
LF
H
GAMF
DCONMS
HF DMIN
LDRED
Right-hand shown
91º
Designation
DCONMS LF LDRED H HFB WF HF GAMP GAMF DMIN Insert
E12 STFPR-11 HEAD
12.00 179.00 24.8 11.0 6.0 6.80 0.0 4.0 -6.0 13.00 TPMT/TPGH 1102 SR 14-505 T-7/5
E16 STFPR-11 HEAD
16.00 200.00 37.0 15.0 8.0 8.80 0.5 4.0 -6.0 20.00 TPGB 1102 SR 14-505 T-7/5
For inserts, see pages: TPMT-PF (205) • TPGT-SP (205) • TPGB-XL (206) • TPGH-XL (206) • TPGB (206) • TPMT (205)
E-STFPR-HEAD
Interchangeable Boring
Heads Carrying Positive
11° Clearance Triangular
Inserts on a Carbide Bar
117
ISOTURN TOOLS
A/E STFPR S-STFPR
DMIN_2
H
DCONMS
LF
LDRED
WF
HFB
HF
DMIN
DMIN
Right-hand shown
91º
Designation
DCONMS LF LDRED H HFB HF WF DMIN DMIN_2 CSP(1)
Shank
m.(2)
A10K STFPR-11
10.00 125.00 - 9.0 5.3 0.8 6.00 11.00 12.00 1 S SR 14-505 T-7/5
A12Q STFPR-11
12.00 180.00 - 11.0 6.3 0.8 7.00 13.00 14.00 1 S SR 14-505 T-7/5
E10M STFPR-11
10.00 150.00 - 9.0 5.3 0.8 6.00 12.00 12.00 1 C SR 14-505 T-7/5
E12Q STFPR/L-11
12.00 180.00 - 11.0 6.3 0.8 7.00 14.00 14.00 1 C SR 14-505 T-7/5
S12K STFPR/L-11
12.00 125.00 35.0 11.0 6.3 0.8 5.60 11.00 11.00 0 S SR 14-505 T-7/5
S12M STFPR/L-11
12.00 150.00 27.0 11.0 6.3 0.8 7.00 15.00 15.00 0 S SR 14-505 T-7/5
S16Q STFPR/L-11
16.00 180.00 27.0 15.0 8.0 0.5 9.20 18.00 18.00 0 S SR 14-505 T-7/5
S20R STFPR/L-16
20.00 200.00 63.0 18.0 10.0 1.0 10.20 21.50 21.50 0 S SR 14-541 T-15/5
• (a1) When used with insert TPG. 110204-XL (a2) When used with insert TP.. 110204-..
(1) 0 - Without coolant supply, 1 - With coolant supply
(2) S-Steel, C-Carbide
For inserts, see pages: TPMT-PF (205) • TPGB-XL (206) • TPGH-R/L (206) • TPGH-XL (206) • TPGB (206) • TPMT (205)
A/E/S-STFPR/L
Screw Lock Boring Bars
Carrying Triangular Inserts
with 11° Clearance
DCONMS
LF
91˚
B
H
WF B
B-B
HFB
GAMP
DMIN
GAMF
Right-hand shown
91º
Designation
DCONMS LF WF H HFB DMIN GAMP GAMF
Shank
m.(1) Insert
A08J STFPR-09X
8.00 110.00 5.00 7.2 3.6 9.50 5.0 -15.0 S TPGX 0902 SR 14-298 T-8/5
A10K STFPR-09X
10.00 125.00 5.70 9.0 4.5 10.90 5.0 -8.0 S TPGX 0902 SR 14-298 T-8/5
A12M STFPR-09X
12.00 150.00 6.70 11.0 5.5 13.00 5.0 -8.0 S TPGX 0902 SR 14-298 T-8/5
A10K STFPR-11X
10.00 125.00 6.00 9.0 4.5 11.40 3.0 -15.0 S TPGX 1103 SR 10400052 T-8/5
A12M STFPR-11X
12.00 150.00 6.80 11.0 5.5 13.50 3.0 -10.0 S TPGX 1103 SR 10400052 T-8/5
A16Q STFPR-11X
16.00 180.00 8.80 14.0 7.0 17.30 3.0 -5.0 S TPGX 1103 SR 10400052 T-8/5
E08K STFPR-09X
8.00 125.00 5.00 7.2 3.6 9.50 5.0 -15.0 C TPGX 0902 SR 14-298 T-8/5
E10M STFPR-09X
10.00 150.00 5.70 9.0 4.5 10.90 5.0 -8.0 C TPGX 0902 SR 14-298 T-8/5
E12Q STFPR-09X
12.00 180.00 6.70 11.0 5.5 13.00 5.0 -8.0 C TPGX 0902 SR 14-298 T-8/5
E10M STFPR-11X
10.00 150.00 6.00 9.0 4.5 11.40 3.0 -15.0 C TPGX 1103 SR 10400052 T-8/5
E12Q STFPR-11X
12.00 180.00 6.80 11.0 5.5 13.50 3.0 -10.0 C TPGX 1103 SR 10400052 T-8/5
E16R STFPR-11X
16.00 200.00 8.80 14.0 7.0 17.30 3.0 -5.0 C TPGX 1103 SR 10400052 T-8/5
(1) S-Steel, C-Carbide
For inserts, see pages: TPGW-M3 (CBN) (235) • TPGX (207) • TPGX (CBN) (234) • TPGX (PCD) (224)
A/E-STFPR-X
Boring Bars Carrying Triangular
TPGX 11° Clearance Inserts
for Small Diameters
DCONMS
91˚
LF
OHX/OHN
GAMP
WF
WF
RE0.2
LF A
A
DMIN
GAMF
Right-hand shown
91º
Designation
DCONMS LF OHN(1) OHX(2) WF GAMP GAMF DMIN
MG 08-STFPR-09X
8.00 79.00 20.0 56.0 4.90 5.0 -15.0 9.50 SR 14-298 T-8/5
(1) Minimum overhang in adjustment range
(2) Maximum overhang in adjustment range
For inserts, see pages: TPGX (207) • TPGX (CBN) (234) • TPGX (PCD) (224)
MG STFPR-X
Solid Carbide Boring Bar Carrying
TPGX Inserts for Small Diameters
ISCAR
118
ISOTURN TOOLS
DMIN_2(a2)
H
DCONMS
LF
WF
LDRED
LDRED
HF
WF
A-STLPR S-STLPR
LF
HFB
HF
DMIN DMIN(a1)
Right-hand shown
95º
Designation
DCONMS LF LDRED H HFB HF WF DMIN DMIN_2 CSP(1)
A10K STLPR-11
10.00 125.00 18.0 9.5 5.8 1.1 6.00 12.00 11.00 1 SR 14-505 T-7/5
A12Q STLPR-11
12.00 180.00 18.0 11.5 6.0 0.3 7.00 14.00 13.00 1 SR 14-505 T-7/5
S12K STLPR/L-11
12.00 125.00 35.0 11.0 6.3 0.8 5.60 11.00 9.70 0 SR 14-505 T-7/5
S12M STLPR/L-11
12.00 150.00 27.0 11.0 6.3 0.8 7.00 15.00 14.00 0 SR 14-505 T-7/5
S16Q STLPR-11
16.00 180.00 27.0 15.0 8.0 0.5 9.00 18.00 17.00 0 SR 14-505 T-7/5
S20R STLPR-16
20.00 200.00 63.0 18.0 10.0 1.0 10.20 21.50 21.50 0 SR 14-541 T-15/5
• (a1) When used with insert TP.. 110204-.. (a2) When used with insert TPG. 110204-XL
(1) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: TPMT-PF (205) • TPGB-XL (206) • TPGH-R/L (206) • TPGH-XL (206) • TPGB (206) • TPMT (205)
A/S-STLPR/L
Screw Lock Boring Bars
Carrying Triangular Inserts
with 11° Clearance
WF
LF
H
DCONMS
LDRED
HFB
DMIN
Right-hand shown
93º
Designation
DCONMS LF LDRED H HFB WF DMIN CSP(1) Shank m.(2) MIID(3)
E06H SWUBL-06
6.00 100.00 - 5.2 2.6 3.30 6.50 1 C WBMT 060101R SR 14-552 T-6/5
E06H SWUBR-06
6.00 100.00 - 5.2 2.6 3.30 6.50 1 C WBMT 060101L
E08K SWUBR-06
8.00 125.00 - 7.6 3.8 4.30 8.70 1 C WBMT 060101L SR 14-552 T-6/5
E10M SWUBR-06
10.00 150.00 - 9.0 4.5 5.20 10.90 1 C WBMT 060101L SR 14-552 T-6/5
S0606H SWUBR-06
6.00 100.00 - 5.2 2.6 3.30 6.50 0 S WBMT 060101L SR 14-552 T-6/5
S0610H SWUBL-06
10.00 100.00 20.0 9.0 4.5 3.00 6.00 0 S WBMT 060101R SR 14-552 T-6/5
S0610H SWUBR-06
10.00 100.00 20.0 9.0 4.5 3.00 6.00 0 S WBMT 060101L
S0710H SWUBL-06
10.00 100.00 24.0 9.0 4.5 3.50 7.00 0 S WBMT 060101R SR 14-552 T-6/5
S0710H SWUBR-06
10.00 100.00 24.0 9.0 4.5 3.50 7.00 0 S WBMT 060101L
S0808J SWUBR-06
8.00 100.00 - 7.4 3.7 4.30 8.50 0 S WBMT 060101L SR 14-552 T-6/5
S0812J SWUBL-06
12.00 110.00 32.0 11.0 5.5 4.00 8.00 0 S WBMT 060101R SR 14-552 T-6/5
S0812J SWUBR-06
12.00 110.00 32.0 11.0 5.5 4.00 8.00 0 S WBMT 060101L
S1010K SWUBL-06
10.00 125.00 - 9.0 4.5 5.20 11.00 0 S WBMT 060101R SR 14-552 T-6/5
S1010K SWUBR-06
10.00 125.00 - 9.0 4.5 5.20 11.00 0 S WBMT 060101L
• Use right-hand WBMT 06...R inserts on left-hand tools and left-hand WBMT 06...L inserts on right-hand tools.
(1) 0 - Without coolant supply, 1 - With coolant supply
(2) S-Steel, C-Carbide
(3) Master insert identification
For inserts, see pages: WBGT (207) • WBMT (207)
E/S-SWUBR/L
Screw Clamp Miniature
Boring Bars Carrying Small
WBMT Trigon Inserts
DMIN
WF
LF
OHX/OHN
DCONMS
Right-hand shown
Designation
DCONMS LF OHN(1) OHX(2) WF DMIN
MGSIR/L 06-06
6.00 59.00 16.0 42.0 3.90 7.00 SR 14-552 T-6/5
MGSIR/L 08-06
8.00 72.00 20.0 56.0 5.00 9.20 SR 14-552 T-6/5
• In order to maintain high machining reliability, we strongly recommend replacing the clamping screw every 10 insert indexes
(1) Minimum overhang in adjustment range
(2) Maximum overhang in adjustment range
For inserts, see pages: IR/L-55° (640) • IR/L-60° (645) • IR/L-BSPT (673) • IR/L-ISO (655) • IR/L-NPT (670) • IR/L-NPTF (672)
• IR/L-UN (662) • IR/L-W (667)
MGSIR/L
Solid Carbide Bars for Internal
Turning and Threading
119
ISOTURN TOOLS
WF
LF
OHX/OHN
DCONMS DMIN
Right-hand shown
93º
Designation
DCONMS LF OHN(1) OHX(2) WF DMIN
MG 06-SWUBR/L-06
6.00 59.00 16.0 42.0 3.30 6.60 SR 14-552 T-6/5
MG 08-SWUBR/L-06
8.00 72.00 20.0 56.0 4.30 8.70 SR 14-552 T-6/5
• Use right-hand WBMT 06...R inserts on left-hand tools and left-hand WBMT 06...L inserts on right-hand tools
(1) Minimum overhang in adjustment range
(2) Maximum overhang in adjustment range
For inserts, see pages: WBGT (207) • WBMT (207)
MG-SWUBR/L
Solid Carbide Bars for
Internal Turning
B
B
93˚
DCONMS
LF
H
WF
HFB DMIN
Right-hand shown
93º
Designation
DCONMS LF H HFB WF DMIN Shank m.(1) Insert
A06H SWUCR-02
6.00 100.00 5.4 2.7 3.30 6.60 S WCGT 0201 SR 14-299 T-6/5
A08J SWUCR-02
8.00 110.00 7.2 3.6 4.25 8.70 S WCGT 0201 SR 14-299 T-6/5
A10K SWUCR-02
10.00 125.00 9.0 4.5 5.20 10.90 S WCGT 0201 SR 14-299 T-6/5
E06H SWUCR-02
6.00 100.00 5.4 2.7 3.30 6.60 C WCGT 0201 SR 14-299 T-6/5
E08K SWUCR-02
8.00 125.00 7.2 3.6 4.30 8.70 C WCGT 0201 SR 14-299 T-6/5
E10M SWUCR-02
10.00 150.00 9.0 4.5 5.20 10.90 C WCGT 0201 SR 14-299 T-6/5
(1) S-Steel, C-Carbide
For inserts, see pages: WCGT (208)
A/E-SWUCR
Boring Bars Carrying WCGT
Trigon Inserts for Small Diameters
DCONMS
WF
93˚
GAMP
LF
OHX/OHN
DMIN
GAMF
Right-hand shown
93º
Designation
DCONMS LF OHN(1) OHX(2) WF GAMP GAMF DMIN Insert
MG 06-SWUCR-02
6.00 60.00 16.0 42.0 3.30 0.0 15.0 6.60 WCGT 0201 SR 14-299 T-6/5
MG 08-SWUCR-02
8.00 75.70 20.0 56.0 4.30 0.0 12.0 8.80 WCGT 0201 SR 14-299 T-6/5
(1) Minimum overhang in adjustment range
(2) Maximum overhang in adjustment range
For inserts, see pages: WCGT (208)
MG-SWUCR
Solid Carbide Boring Bars
Carrying WCGT Trigon Inserts
for Small Diameters
DCONMS
GAMF
WF
LF
LDRED
HFB
GAMP
DMIN
Right-hand shown
88º
Designation
DCONMS LF LDRED HFB WF GAMP GAMF DMIN Insert
A10J SXFOR/L-06
10.00 110.00 28.5 5.0 4.90 6.0 1.8 10.00 XOMT 0602 SR 34-508 T-7/5
A12K SXFOR/L-06
12.00 125.00 28.5 5.0 4.90 6.0 1.8 10.00 XOMT 0602 SR 34-508 T-7/5
For inserts, see pages: XOMT-DT (200)
A-SXFOR/L
Boring Bars with Coolant
Holes Carrying XOMT Inserts
ISCAR
120
ISOTURN TOOLS
HF
GAMP
DCONMS
OAL=LF
WF
LU
H
GAMF
LPR
Right-hand shown
Designation
DCONMS LF LPR LU WF HF GAMP GAMF H DCN(1) Insert
A1612M SXFOR-06DR
16.00 180.00 31.0 21.0 6.00 8.5 0.0 0.0 15.0 12.50 XOMT 0602
(1) Cutting diameter minimum
For inserts, see pages: XOMT-DT (200)
Drilling Solid Material
Range:
Dmin=12.5 mm
Dmax=14 mm
To achieve required diameter øD, position tool as shown at D + x (x=0.10) to compensate for tool deflection.
Use pecking cycle, pulling back 0.1 mm after each 1 mm of DOC.
Maximum feed for steel: 0.05 mm/rev;
For stainless steel: 0.03 mm/rev
D
D+x
x
Spare Parts
Designation
A-SXFOR-DR
SR 34-508 T-7/51 PL 16
A-SXFOR-DR
Boring and Drilling Bars
with Coolant Holes
Carrying XOMT Inserts
DCONWS DCONMS
BD
10
OAL H
Designation
DCONMS DCONWS BD H OAL
SBB D16-4
16.00 4.00 15.00 15.0 100.00 SR M4X4 HW 2.0 PL 16*
SBB D16-5
16.00 5.00 15.00 15.0 100.00 SR M4X4 HW 2.0 PL 16*
SBB D16-6
16.00 6.00 15.00 15.0 100.00 SR M4X4 HW 2.0 PL 16*
SBB D16-7
16.00 7.00 15.00 15.0 100.00 SR M4X4 HW 2.0 PL 16*
SBB D20-4
20.00 4.00 13.00 19.0 100.00 SR M4X4 HW 2.0 PL 16*
SBB D20-5
20.00 5.00 14.00 19.0 100.00 SR M4X4 HW 2.0 PL 16*
SBB D20-6
20.00 6.00 15.00 19.0 100.00 SR M4X4 HW 2.0 PL 16*
SBB D20-7
20.00 7.00 16.00 19.0 100.00 SR M4X4 HW 2.0 PL 16*
SBB D22-4
22.00 4.00 13.00 21.0 125.00 SR M4X4 HW 2.0 PL 16*
SBB D22-5
22.00 5.00 14.00 21.0 125.00 SR M4X4 HW 2.0 PL 16*
SBB D22-6
22.00 6.00 15.00 21.0 125.00 SR M4X4 HW 2.0 PL 16*
SBB D22-7
22.00 7.00 16.00 21.0 125.00 SR M4X4 HW 2.0 PL 16*
SBB D25-4
25.00 4.00 13.00 24.0 125.00 HW 2.0
SBB D25-5
25.00 5.00 14.00 24.0 125.00 HW 2.0
SBB D25-6
25.00 6.00 15.00 24.0 125.00 HW 2.0
SBB D25-7
25.00 7.00 16.00 24.0 125.00 HW 2.0
• Holders are suitable for right- and left-hand inserts, and boring bars
* Optional, should be ordered separately
For tools, see pages: A/E-SEXPR/L-03 (112) • A/E-SWUCR (119) • A/E/S-SCLCR/L (111) • E/S-SWUBR/L (118) • MG-SWUBR/L (119)
• MG-SWUCR (119) • MGCH (414) • MGSIR/L (118)
SBB
Holders for Small
Diameter Boring Bars
