185
FACE MILLS
FACE MILLS
ISCAR
186
FACE MILLS
PICTORIAL TOOL
REFERENCE
HP F90AN-07
page 195
T490 FLN
pages 196,201,207,212
F90SP-10
page 198
HM90 F90AP
page 200
F90LN-N11
page 203
F90SD-12
page 204
HM390 FT
pages 193,199,209,212
H690 FWN
pages 193,195
H690 F90AX
pages 201,214
H490 F90A
pages 197,206,213
F90LN-N15
page 208
T290 FLN
pages 198, 207
HM90 F90A
page 210
F90
page 214
P290 FPW/FCT
page 215
HP F90AT
pages 215,216
T890HT-R13
page 202
S890 FSZ-R08
page 194
Face Mills 90°
187
FACE MILLS
PICTORIAL TOOL
REFERENCE
S890 FSN-13
page 205
F75-M
page 216
S865 FSN-13
page 217
HOF/HOE...R06
page 218
HOF...R07
page 219
F45WG
page 220
F45NM
page 221
F45E
page 225
F45ST
page 225
S845 F45SX
page 227
IQ845
pages 219,220,226
SOF45
pages 222,223
SOF45-R18
page 229
SOF45-26
page 228
Face Mills 88°, 75°, 65°, 45°
ISCAR
188
SELECTION GUIDE
FACE MILLS
Face Mills 90° Selection Guide
90˚
DC
APMX
Tools Pages
DC
25 32 40 50 63 80 100 125 160 200 250 315
Inserts
APMX
Number of Teeth (Effective)
H690 FWN 193
195
4
765
7
4
5
7
9
5
6
7
8
10
7
9
8
11 10
H690 WN..04../07..
S890 FSZ-R08 194
55
6
6
8
7
10
8
12
10
14
12
18
S890 SZMU-08...
HM390 FTC-07 193
54
5
5
6
HM390 TCKT 07..
HP F90AN-07 195
7.7 68
10
HP AN..0702..
T490 FLN-08 196
83
5
4
6
5
7
10
6
910
T490 LN..08..
H490 F90AX-09 197
84
5
5
6
6
7
8
9
H490 AN..09..
HM390 FTP-10 199
83
5
4
6
6
711 13
HM390 TP.. 10..
T290 FLN-10 198
9567
T290 LNMT 10
F90SP-10 198
9.6 44
6
6
7
6
9
SPMT/R 10...
QPMT/R 10..
XPMT 10..
SPCT 10...
HM90 F90AP-10 200
10 3
5
5
6
6
7
7
98 9
HM90 AP..10
AP...10
H690 F90AX-10 201
84
5
5
6
6
78
H690 TN.. 10..
F90LN-N11 203
10 4
6
5
7
6
9
8
11
9
14
10
18
LN.. 11…
T490 FLN-11 201
10 4
5
5
6
6
9
7
11
8
13
T490 LN.. 11…
F90SD-12 204
11.8 3
5
4
656
8
7
911 13
SDMT 12…
SDMR 12…
QDMT 12…
QDCT 12…
H490 F90AX-12 206
12 43
5
4
6
5
7
6
99
H490 AN.. 12…
189
SELECTION GUIDE
FACE MILLS
Face Mills 90° Selection Guide
90˚
DC
APMX
Tools Pages
DC
25 32 40 50 63 80 100 125 160 200 250 315
Inserts
APMX
Number of Teeth (Effective)
T490 FLN-13 207
12.5 4
5
5
6
6
8
7
10
8
13
9
17 12 15
T490 LNMT 13..
T290 FLN-15 207
14 4 5
T290 LN.. 15…
F90LN-N15 208
14 55
8
7
10
8
12
9
15
10
20 12 15
30
LN.. 15…
HM390 FTD-15 209
13 3
4
3
4
5
4
5
6
5
6
7
6
8
7
9
8
10 9
HM390 TDKT 1505..
HM90 F90A-15 210
14.3 3
4
3
5
4
6
5
7
6
89
HM90 AD.. 15…
T490FLN-16 212
16 3
465
7
6
8
7
10 12 12
T490 LNMT 16…
HM390 FTD-19 212
16 5 10
HM390 TDKT 1907
H490 F90AX-17 213
16.3 33
4
4
6
5
7
5
8
7
10
8
12 10 12
H490 AN.. 17…
H690 F90AX-16 214
13.5 3
4
4
5
5
6
6
8
7
9
8
10 11
HM690 TNKX 1606
F90 214
18 6 8 8 10 12
TPK…22
P290 FPW/FCT 215
12
18 44
5
5
6689
P290 ACCT
P290 ACKT
HP F90AT-19 215
18 4
HP AD.. 19…
HP F90AT-22 216
21 3
4
HP AD.. 22…
ISCAR
190
SELECTION GUIDE
FACE MILLS
Endmills and Face Mills 88°, 75°, 65° Selection Guide
88˚
DC
APMX
75˚
DC
APMX
65˚
DC
APMX
Tools Pages
DC
25 32 40 50 63 80 100 125 160 200 250 315
Inserts
APMX
Number of Teeth (Effective)
S890 FSN-13 205
10 44
5
5
7
7
9
8
11
9
14 10
S890 SN.. 13…
88°
F75-M 216
9.5 45678
SPKN/SPKR 12...
75°
S865 FSN-13 217
64
6
6
8
7
10
8
12
10
16
S865 SNMU 13...
65°
APMX
DC
45˚
Tools Pages
DC
25 32 40 50 63 80 100 125 160 200 250 315
Inserts
APMX
Number of Teeth (Effective)
HOE / HOF 218
219
2.5
5.5 343
4
4
5
5
6
6
78 10 12 15 18
OE.. 06..
OF.. 07…
RF.. 19…
IQ845
219
220
226
2.6
4.6
3
4
4
5
4
5
6
7
4
5
9
5
7
11
6
8
7
10
9
12
11
15 14 17 20
IQ845 SYHU 05,07...
F45WG 220
5.5 10 14 18 22
ON.. 08…
F45NM 221
5.5 56
8
7
10
8
12
10
15 12 14
ON.. 08…
SOF45 222
3.5
6.0 4
3
4
6
4
6
8
7
10
8
12
10
16 12 14 16 20
ON.. 05…
S845 SN.. 13…
Endmills and Face Mills 45° Selection Guide
191
SELECTION GUIDE
FACE MILLS
Face Mills 45° Selection Guide
45˚
Tools Pages
DC
25 32 40 50 63 80 100 125 160 200 250 315
Inserts
APMX
Number of Teeth (Effective)
F45ST 225
6.5 3456677
SE.T 12…
F45E 225
6.5 456668
SE.. 12…
S845 F45SX-16 227
7.1 44
5
5
797
11
8
14
10
18 12 15
S845 SX.. 16…
SOF45-R18 229
5
8456
7
7
9
8
12
10
15
12
18
14
21
18
24
SNMU 18
ONMU 07
S845
SOF45-R26 228
7
11 45
6
6
8
8
10
10
12
12
14
14
16
SNMU 26
ONMU 10
S845
ISCAR
192
FACE MILLS
THSZMS
DC
LF
RE
APMX
Dimensions Recommended
Machining Data
Designation
DC APMX RE NOF(1) THSZMS LF
IC908
fz
(mm/t)
MM FM120-36R0.2-06T05
12.00 3.60 0.20 6 T05 4.40 T-20/3*
•
0.04-0.10
MM FM160-48R0.4-06T06
16.00 4.80 0.40 6 T06 5.60 T-25/3*
•
0.05-0.10
MM FM200-60R0.4-06T08
20.00 6.00 0.40 6 T08 6.80 T-40/3 L*
•
0.05-0.10
MM FM250-75R0.4-06T10
25.00 7.50 0.40 6 T10 8.40 T-50/3 L*
•
0.05-0.10
(1) Number of flutes
* Optional, should be ordered separately
MM FM
Interchangeable Solid Carbide
Face Milling Heads with
MULTI-MASTER Threaded
Connections
OAL
APMX
RE
DCONMS
D1
DC
Dimensions Recommended
Machining Data
Designation
DC APMX NOF(1) RE D1 DCONMS OAL
IC908
fz
(mm/t)
SD FM D32-8-R0.4-SP15
31.25 8.00 8 0.40 8.40 15.00 8.00
•
0.04-0.15
SD FM D40-10-R0.4SP17
39.25 10.00 10 0.40 9.80 17.00 10.00
•
0.04-0.15
SD FM D50-12-R0.4SP19
49.25 12.00 12 0.40 9.80 19.00 14.00
•
0.04-0.15
• For shanks, see page 192 • For user guide, see pages 542-547
(1) Number of flutes
SD FM
Interchangeable Solid Carbide
Face Milling Heads
THSZWS DCONMS
LF
OAL
LB
DCONWS
Designation
DCONMS DCONWS THSZWS LB LF OAL Shank(1)
kg
SD FM-S-A-L100-C25-SP15
25.00 15.00 M5x0.5 10.10 104.90 104.90 C 0.37
SD FM-S-A-L120-W25-SP15
25.00 15.00 M5x0.5 10.10 92.90 124.90 W 0.44
SD FM-S-A-L125-W32-SP17
32.00 17.00 M6x0.5 12.50 95.00 131.00 W 0.75
SD FM-S-A-L140-C32 SP17
32.00 17.00 M6x0.5 12.50 146.00 146.00 C 0.85
SD FM-S-A-L140-C32-SP19
32.00 19.00 M6x0.5 10.00 148.50 148.50 C 1.41
SD FM-S-A-L130-W40-SP19
40.00 19.00 M6x0.5 14.00 98.50 138.50 W 1.21
• Apply lubricant to the clamping screw
(1) C-Cylindrical, W-Weldon
Spare Parts
Designation
SD FM-S-A-L100-C25-SP15
SR M5X0.5-SP15-IP20-HG BLD IP20/S7 SW6-T-SH
SD FM-S-A-L120-W25-SP15
SR M5X0.5-SP15-IP20-HG BLD IP20/S7 SW6-T-SH
SD FM-S-A-L125-W32-SP17
SR M6X0.5-SP17-IP20-HG BLD IP20/S7 SW6-T-SH
SD FM-S-A-L140-C32 SP17
SR M6X0.5-SP17-IP20-HG BLD IP20/S7 SW6-T-SH
SD FM-S-A-L140-C32-SP19
SR M6X0.5-SP17-IP20-HG BLD IP20/S7 SW6-T-SH
SD FM-S-A-L130-W40-SP19
SR M6X0.5-SP17-IP20-HG BLD IP20/S7 SW6-T-SH
SD FM-S-A-SP
Stepped Cylindrical Shanks
for Interchangeable Solid
Carbide Face Milling Heads
193
FACE MILLS
DC
OAL
DCONMS
DHUB
APMX
Rd°
Designation
DC CICT(1) APMX OAL DHUB DCONMS Arbor(2) RMPX°(3)
kg
HM390 FTC D032-04-16-07
32.00 4 5.00 35.00 30.40 16.00 A 0.8 0.11 SR M2.5X6-T7-60 T-7/51 SR M8X25DIN912
HM390 FTC D032-05-16-07
32.00 5 5.00 35.00 30.40 16.00 A 0.8 0.10 SR M2.5X6-T7-60 T-7/51 SR M8X25DIN912
HM390 FTC D040-05-16-07
40.00 5 5.00 35.00 38.00 16.00 A 0.6 0.20 SR M2.5X6-T7-60 T-7/51 SR M8X25DIN912
HM390 FTC D040-06-16-07
40.00 6 5.00 35.00 38.00 16.00 A 0.6 0.20 SR M2.5X6-T7-60 T-7/51 SR M8X25DIN912
• Insert clamping screw must be lubricated every indexing • Tightening torque 0.9 Nxm • For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
(3) Maximum ramping angle
For inserts, see pages: HM390 TCKT/CT 0703 (446)
HM390 FTC-07
90° Face Mills Carrying HM390
TCKT 0703 Triangular Inserts
with 3 Helical Cutting Edges
APMX
DCONMS
DHUB
OAL
DC
Rd°
Designation
DC CICT(1) APMX DHUB DCONMS OAL Arbor(2) RMPX°(3)
kg
H690 FWN D32-06-16-R04
32.00 6 4.00 30.40 16.00 35.00 A 0.8 0.16 SR M8X27-CSH50 SR M2.5X6-T7-60 T-7/51
H690 FWN D40-05-16-R04
40.00 5 4.00 38.00 16.00 35.00 A 0.6 0.20 SR M8X25DIN912 SR M2.5X6-T7-60 T-7/51
H690 FWN D40-07-16-R04
40.00 7 4.00 38.00 16.00 35.00 A 0.6 0.21 SR M8X25DIN912 SR M2.5X6-T7-60 T-7/51
H690 FWN D50-07-22-R04
50.00 7 4.00 48.00 22.00 40.00 A 0.5 0.37 SR M10X25 DIN912 SR M2.5X6-T7-60 T-7/51
H690 FWN D50-09-22-R04
50.00 9 4.00 48.00 22.00 40.00 A 0.5 0.38 SR M10X25 DIN912 SR M2.5X6-T7-60 T-7/51
H690 FWN D63-08-27-R04
63.00 8 4.00 60.00 27.00 40.00 B 0.2 0.39 SR M2.5X6-T7-60 T-7/51
H690 FWN D63-10-27-R04
63.00 10 4.00 60.00 27.00 40.00 B 0.2 0.39 SR M2.5X6-T7-60 T-7/51
• Insert clamping screw must be lubricated every indexing. • Tightening torque 0.9 Nxm. • For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
(3) Maximum ramping angle
For inserts, see pages: H690 WNMU 0403 (468)
H690 FWN-04
90° Face Mills Carrying
H690 WNMU 0403 Double-Sided
Trigonal Inserts with 6
Helical Cutting Edges
ISCAR
194
FACE MILLS
DC
APMX
90˚
OAL
DHUB
DCONMS
Designation
DC APMX OAL CICT(1) DCONMS DHUB Arbor MIID(2)
kg
S890 FSZ D040-05-16-R08
40.00 5.00 35.00 5 16.00 38.00 A S890 SZMU 0804... 0.24
S890 FSZ D040-06-16-R08
40.00 5.00 35.00 6 16.00 38.00 A S890 SZMU 0804... 0.34
S890 FSZ D050-06-22-R08
50.00 5.00 40.00 6 22.00 48.00 A S890 SZMU 0804... 0.35
S890 FSZ D050-08-22-R08
50.00 5.00 40.00 8 22.00 48.00 A S890 SZMU 0804... 0.39
S890 FSZ D063-07-22-R08
63.00 5.00 40.00 7 22.00 48.00 A S890 SZMU 0804... 0.60
S890 FSZ D063-10-22-R08
63.00 5.00 40.00 10 22.00 48.00 A S890 SZMU 0804... 0.58
S890 FSZ D080-08-27-R08
80.00 5.00 50.00 8 27.00 60.00 B S890 SZMU 0804... 0.98
S890 FSZ D080-12-27-R08
80.00 5.00 50.00 12 27.00 60.00 B S890 SZMU 0804... 0.93
S890 FSZ D100-10-32-R08
100.00 5.00 50.00 10 32.00 78.00 B S890 SZMU 0804... 1.52
S890 FSZ D100-14-32-R08
100.00 5.00 50.00 14 32.00 78.00 B S890 SZMU 0804... 1.50
S890 FSZ D125-12-40-R08
125.00 5.00 50.00 12 40.00 92.00 B S890 SZMU 0804... 2.29
S890 FSZ D125-18-40-R08
125.00 5.00 50.00 18 40.00 92.00 B S890 SZMU 0804... 2.32
• For user guide, see pages 542-547
(1) Number of inserts
(2) Master insert identification
For inserts, see pages: S890 SZMU-0804PN (503)
When stepdown milling is performed by use of passes, the depth of cut per pass should not
exceed the depth of cut as recommended in the ISCAR catalog.
Fig. 1- Generated profile for a
depth of cut of up to 5mm
Fig. 2- Generated profile for a depth
of cut in stepdown milling
90˚
5
90˚
0.28
0.28
93˚
5
10
15
Starting feed per tooth F
z for S890 face mills with inserts S890 SZMU 08...
Workpiece Material Fz, mm/Tooth for Grades*
ISO Class
DIN/ISO 513 Description
Typical Representstive Hardness,
HB
ISCAR Mat.
Group** IC 5100 IC810 IC808 IC845 IC5400AISI/SAE/ASTM DIN W.-Nr.
P
Non-alloy steel 1020 1.044 130-180 1 0.1-0.25 0.1-0.25 0.1-0.25
Alloy steel 4340 1.658 260-300 8 0.1-0.2 0.1-0.2 0.1-0.2
4340 1.658 HRC 35-42* 9 0.1-0.2 0.1-0.2 0.1-0.2
High alloy steel H13 1.234 200-220 10 0.08-0.15 0.08-0.15 0.08-0.15
Martensitic s.s 420 1.402 200 12 0.08-0.15 0.08-0.15 0.08-0.15
MAustenitic s.s. 304L 1.431 200 14 0.1-0.15 0.1-0.15 0.1-0.15
316L 1.440 140 14 0.1-0.15 0.1-0.15 0.1-0.15
KGrey cast iron Class 40 0.6025 (GG25) 250 16 0.15-0.25 0.15-0.25
Nodular cast iron Class 65-45-12 0.7050 (GGG50) 200 17 0.12-0.2 0.12-0.2
HHard steel and
cast iron
H11 1.234 HRC 45-49 38.1 0.06-0.12 0.06-0.12 0.06-0.12
P20 1.2330 HRC 50-55 38.2 0.05-0.1 0.05-0.1 0.05-0.1
* Quenched and tempered
** ISCAR material group in accordance with VDI 3323 standard
Spare Parts
Designation
S890 FSZ D040-05-16-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M8X25DIN912
S890 FSZ D040-06-16-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M8X25DIN912
S890 FSZ D050-06-22-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M10X25 DIN912
S890 FSZ D050-08-22-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M10X25 DIN912
S890 FSZ D063-07-22-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M10X25 DIN912
S890 FSZ D063-10-22-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M10X25 DIN912
S890 FSZ D080-08-27-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151
S890 FSZ D080-12-27-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151
S890 FSZ D100-10-32-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151
S890 FSZ D100-14-32-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151
S890 FSZ D125-12-40-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151
S890 FSZ D125-18-40-R08
SR M3X0.5-L7.4 IP9(a) IP-9/151
(a) Recommended tightening torque:2 N*m (17.7 lbf*in)
S890 FSZ-R08
Face Mills Carrying
Double-Sided Square Inserts
with 8 Cutting Edges
195
FACE MILLS
DCONMS
DHUB
OAL
APMX
DC
Rd°
Designation
DC CICT(1) APMX OAL DHUB DCONMS RMPX°(2) Arbor(3) RPMX(4)
kg
HP F90AN D32-06-16-07
32.00 6 7.70 35.00 30.40 16.00 1.4 A 26600 0.10
HP F90AN D40-08-22-07
40.00 8 7.70 40.00 38.00 22.00 1.0 B 23799 0.16
HP F90AN D40-10-22-07
40.00 10 7.70 40.00 38.00 22.00 1.0 B 23799 0.17
• Insert tightening torque: 0.62 Nxm • For user guide, see pages 542-547
(1) Number of inserts
(2) Maximum ramping angle
(3) For adaptation options, see page 548
(4) Maximum RPM
For inserts, see pages: HP ANCR 0702PNFR (444) • HP ANKT 0702...-FF (445) • HP ANKT/ANCT 0702..PN-R/PNTR (444) • HP ANKW 070204PNTR (444)
Spare Parts
Designation
HP F90AN D32-06-16-07
SR 34-533/L/HG T-6/51 SR M8X20DIN912
HP F90AN D40-08-22-07
SR 34-533/L/HG T-6/51 SR M10X25 DIN912
HP F90AN D40-10-22-07
SR 34-533/L/HG T-6/51 SR M10X25 DIN912
HP F90AN-07
90° Face Mills Carrying HP
ANKT 0702.. Inserts
APMX
DCONMS
DHUB
OAL
DC
Rd°
Designation
DC CICT(1) APMX DHUB DCONMS OAL Arbor(2) RMPX°(3)
kg
H690 FWN D050-04-22-R07
50.00 4 7.00 48.00 22.00 40.00 A 1.2 0.33
H690 FWN D050-05-22-R07
50.00 5 7.00 48.00 22.00 40.00 A 1.2 0.33
H690 FWN D063-05-22-R07
63.00 5 7.00 48.00 22.00 40.00 A 1.1 0.50
H690 FWN D063-06-27-R07
63.00 6 7.00 60.00 27.00 50.00 A 1.1 0.72
H690 FWN D063-07-22-R07
63.00 7 7.00 48.00 22.00 40.00 A 1.1 0.50
H690 FWN D080-07-27-R07
80.00 7 7.00 60.00 27.00 50.00 B 1.0 1.00
H690 FWN D080-09-27-R07
80.00 9 7.00 60.00 27.00 50.00 B 1.0 0.98
H690 FWN D100-08-32-R07
100.00 8 7.00 70.00 32.00 50.00 B 0.8 1.57
H690 FWN D100-11-32-R07
100.00 11 7.00 70.00 32.00 50.00 B 0.8 1.62
H690 FWN D125-10-40-R07
125.00 10 7.00 82.00 40.00 63.00 B 0.5 2.82
• For cutting speed recommendations, see pages 542-547
(1) Number of inserts (2) For adaptation options, see page 548 (3) Maximum ramping angle For inserts, see pages: H690 WNHU/WNMU 0705 (469)
Examples of Cutting Speed for H690 FWN/EWN...07 Cutters
ISO Class
DIN/ ISO
513
Workpiece Material Cutting Speed Vc, SFM, for Grades
Description
ISCAR Mat.
Group*
Typical Materials
Hardness HB IC808 IC5100 IC810 IC5400 IC830 IC330AISI/SAE/ ASTM DIN W.-Nr.
P
Non-alloy steel 1 1020 1.044 130-180 180-250 150-220 150-220 130-200 120-180
Alloy steel 8 4340 1.6582 260-300 150-200 130-180 130-180 120-170 100-140
Alloy steel 9 4340 1.6582 HRC 35-42** 100-170 100-150 100-150 100-130 100-120
High alloy steel 10 H13 1.2344 200-220 100-170 100-150 100-150 100-130 100-120
Martensitic s.s. 12 420 1.4021 200 100-150 100-130 100-120
K
Grey cast iron 16 Class 40 0.6025 (GG25) 250 200-250 220-300 220-300 180-230
Nodular cast iron 17 Class 65-45-12 0.7050
(GGG50) 200 160-220 180-250 180-250 150-200
* ISCAR material group in accordance with VDI 3323 standard
** Quenched and tempered
•
First choice for grades
Spare Parts
Designation
H690 FWN D050-04-22-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
H690 FWN D050-05-22-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
H690 FWN D063-05-22-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
H690 FWN D063-06-27-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
H690 FWN D063-07-22-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
H690 FWN D080-07-27-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
H690 FWN D080-09-27-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
H690 FWN D100-08-32-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
H690 FWN D100-11-32-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
H690 FWN D125-10-40-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
H690 FWN-07
90° Face Mills Carrying
H690 WNMU 0705
Double-Sided Trigonal Inserts
with 6 Helical Cutting Edges
ISCAR
196
FACE MILLS
OAL
DC
DCONMS
DHUB
APMX
Designation
DC CICT(3) APMX OAL DHUB DCONMS Arbor(4) CSP(5)
kg
T490 FLN D032-03-16-08
32.00 3 8.00 35.00 30.40 16.00 A 1 0.11
T490 FLN D032-05-16-08 (1)
32.00 5 8.00 35.00 30.40 16.00 A 1 0.11
T490 FLN D040-04-16-08
40.00 4 8.00 40.00 38.40 16.00 A 1 0.23
T490 FLN D040-06-16-08 (1)
40.00 6 8.00 40.00 38.40 16.00 A 1 0.32
T490 FLN D050-05-22-08
50.00 5 8.00 40.00 48.00 22.00 A 1 0.36
T490 FLN D050-07-22-08 (1)
50.00 7 8.00 40.00 48.00 22.00 A 1 0.37
T490 FLN D050-10-22-08 (2)
50.00 10 8.00 40.00 48.00 22.00 A 0 0.39
T490 FLN D063-06-27-08
63.00 6 8.00 40.00 60.00 27.00 A 1 0.60
T490 FLN D063-09-27-08 (1)
63.00 9 8.00 40.00 60.00 27.00 A 1 0.62
T490 FLN D080-10-27-08
80.00 10 8.00 50.00 60.00 27.00 B 0 0.84
• When machining slots, regular pitch cutters should be used • For user guide, see pages 542-547
(1) Fine pitch
(2) Extra fine pitch
(3) Number of inserts
(4) For adaptation options, see page 548
(5) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT/LNHT 0804 (476)
Spare Parts
Designation
T490 FLN D032-03-16-08
SR 10502813-HG-M IP-7/51 SR M8X20DIN912
T490 FLN D032-05-16-08
SR 10502813-HG-M IP-7/51 SR M8X20DIN912
T490 FLN D040-04-16-08
SR 10502813-HG-M IP-7/51 SR M8X30DIN912
T490 FLN D040-06-16-08
SR 10502813-HG-M IP-7/51 SR M8X30DIN912
T490 FLN D050-05-22-08
SR 10502813-HG-M IP-7/51 SR M10X25 DIN912
T490 FLN D050-07-22-08
SR 10502813-HG-M IP-7/51 SR M10X25 DIN912
T490 FLN D050-10-22-08
SR 10502813-HG-M IP-7/51 SR M10X20DIN912
T490 FLN D063-06-27-08
SR 10502813-HG-M IP-7/51 SR DIN 912 M12X25
T490 FLN D063-09-27-08
SR 10502813-HG-M IP-7/51 SR DIN 912 M12X25
T490 FLN D080-10-27-08
SR 10502813-HG-M IP-7/51
T490 FLN-08
90° Face Mills with Tangentially
Clamped Inserts
APMX
DC
LF
DCONMS
Shank
Designation
DC DCONMS APMX LF CICT(1) Shank CDI(2)
kg
T490 FLN D44-06-C4-08
44.00 40.00 8.00 45.00 6 CAMFIX 1 0.23 SR 10502813-HG-M IP-7/51
T490 FLN D54-07-C5-08
54.00 50.00 8.00 52.00 7 CAMFIX 1 1.58 SR 10502813-HG-M IP-7/51
• For user guide, see pages 542-547
(1) Number of inserts
(2) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT/LNHT 0804 (476)
T490 FLN-C#-08
90° Face Mills with CAMFIX
Shanks Carrying Tangentially
Clamped Inserts
197
FACE MILLS
DCONMS
DHUB
DC
OAL
APMX
Designation
DC CICT(1) APMX DHUB DCONMS OAL Arbor(2)
kg
H490 F90AX D032-4-16-09
32.00 4 8.00 30.40 16.00 35.00 A 0.10
H490 F90AX D032-5-16-09
32.00 5 8.00 30.40 16.00 35.00 A 0.10
H490 F90AX D040-5-16-09
40.00 5 8.00 38.40 16.00 40.00 A 0.22
H490 F90AX D040-6-16-09
40.00 6 8.00 38.40 16.00 40.00 A 0.22
H490 F90AX D050-6-22-09
50.00 6 8.00 48.00 22.00 40.00 A 0.36
H490 F90AX D050-7-22-09
50.00 7 8.00 48.00 22.00 40.00 A 0.37
H490 F90AX D063-8-22-09
63.00 8 8.00 60.00 22.00 40.00 A 0.62
H490 F90AX D063-9-22-09
63.00 9 8.00 60.00 22.00 40.00 A 0.64
• For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
For inserts, see pages: H490 ANKX 0904-FF (470) • H490 ANKX/ANCX-09 (469)
Spare Parts
Designation
H490 F90AX D032-4-16-09
SR 10508082-HG BLD T08/M7 SW4-SD SR M8X20DIN912
H490 F90AX D032-5-16-09
SR 10508082-HG BLD T08/M7 SW4-SD SR M8X20DIN912
H490 F90AX D040-5-16-09
SR 10508082-HG BLD T08/M7 SW4-SD SR M8X30DIN912
H490 F90AX D040-6-16-09
SR 10508082-HG BLD T08/M7 SW4-SD SR M8X30DIN912
H490 F90AX D050-6-22-09
SR 10508082-HG BLD T08/M7 SW4-SD SR M10X25 DIN912
H490 F90AX D050-7-22-09
SR 10508082-HG BLD T08/M7 SW4-SD SR M10X25 DIN912
H490 F90AX D063-8-22-09
SR 10508082-HG BLD T08/M7 SW4-SD SR M10X25 DIN912
H490 F90AX D063-9-22-09
SR 10508082-HG BLD T08/M7 SW4-SD SR M10X25 DIN912
H490 F90AX-09
90° Face Mills Carrying H490
ANKX 09.. Double-Sided
Rectangular Inserts with 4
Helical Cutting Edges
DC APMX
OAL
DCONMS
DHUB
Designation
DC APMX CICT(1) OAL DHUB DCONMS Arbor(2) CSP(3)
kg
HTF D050-05-22-R-LN10
50.00 0.25 5 40.00 48.00 22.00 A 1 0.31
HTF D063-06-22-R-LN10
63.00 0.30 6 40.00 48.00 22.00 A 1 0.43
HTF D080-07-27-R-LN10
80.00 0.35 7 50.00 60.00 27.00 B 1 0.81
HTF D100-08-32-R-LN10
100.00 0.40 8 50.00 78.00 32.00 B 1 1.44
HTF D125-09-40-R-LN10
125.00 0.45 9 63.00 92.00 40.00 B 1 2.55
HTF D160-10-40-R-LN10
160.00 0.50 10 63.00 95.00 40.00 C 0 3.75
• For best surface finish it is highly recommended to operate the cutter at maximal depth of cut • For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation see page 548
(3) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: HTP LN.. 1006 (537)
Spare Parts
Designation
HTF D050-05-22-R-LN10
SR 34-550 BLD T10/S7 SW6-SD SR M10X25 DIN912
HTF D063-06-22-R-LN10
SR 34-550 BLD T10/S7 SW6-SD SR M10X25 DIN912
HTF D080-07-27-R-LN10
SR 34-550 BLD T10/S7 SW6-SD
HTF D100-08-32-R-LN10
SR 34-550 BLD T10/S7 SW6-SD
HTF D125-09-40-R-LN10
SR 34-550 BLD T10/S7 SW6-SD
HTF D160-10-40-R-LN10
SR 34-550 BLD T10/S7 SW6-SD
HTF-R-LN10
Face Mills Carrying Tangentially
Clamped Inserts with 4
Cutting Edges for Extra
Fine Milling Applications
ISCAR
198
FACE MILLS
DCONMS
APMX
DHUB
OAL
DC
Designation
DC CICT(1) APMX OAL DHUB DCONMS Arbor(2)
kg
T290 FLN D32-05-16-10
32.00 5 9.00 35.00 30.00 16.00 A 0.09
T290 FLN D40-06-16-10
40.00 6 9.00 35.00 34.00 16.00 A 0.16
T290 FLN D50-07-22-10
50.00 7 9.00 40.00 46.00 22.00 A 0.29
• For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
For inserts, see pages: T290 LNMT/LNHT 1004 (474)
Spare Parts
Designation
T290 FLN D32-05-16-10
SR 10504970 BLD IP15/M7 SW6-T-SH SR M8X20DIN912
T290 FLN D40-06-16-10
SR 10504970 BLD IP15/M7 SW6-T-SH SR M8X20DIN912
T290 FLN D50-07-22-10
SR 10504970 BLD IP15/M7 SW6-T-SH SR M10X25 DIN912
T290 FLN-10
90° Face Mills Carrying T290
LNMT 1004... Tangentially
Clamped Inserts
DC
OAL
APMX
DCONMS
DHUB
Designation
DC(1) CICT(2) APMX OAL DHUB DCONMS Arbor(3)
kg
F90SP D 40-04-16-10
40.00 4 9.60 40.00 38.00 16.00 A 0.42
F90SP D 50-04-22-10
50.00 4 9.60 40.00 48.00 22.00 A 0.37
F90SP D 50-06-22-10
50.00 6 9.60 40.00 48.00 22.00 A 0.39
F90SP D 63-06-22-10
63.00 6 9.60 40.00 48.00 22.00 A 0.48
F90SP D 63-07-22-10
63.00 7 9.60 40.00 48.00 22.00 A 0.42
F90SP D 80-06-27-10
80.00 6 9.60 50.00 60.00 27.00 B 0.88
F90SP D 80-09-27-10
80.00 9 9.60 50.00 60.00 27.00 B 1.50
• For user guide, see pages 542-547
(1) D is 0.2 mm larger when QPMT inserts are used
(2) Number of inserts
(3) For adaptation options, see page 548
For inserts, see pages: QPMR 1004-HQ-M (495) • QPMT 100408PDTN (495) • SPCT/SPMR PDR (496) • SPMT-HQ (495) • XPMT-HQ (496)
Spare Parts
Designation
F90SP D 40-04-16-10
SR 10514114 SW6-T-SH BLD IP15/M7 SR M8X30DIN912
F90SP D 50-04-22-10
SR 10514114 SW6-T-SH BLD IP15/M7 SR M10X25 DIN912
F90SP D 50-06-22-10
SR 10514114 SW6-T-SH BLD IP15/M7 SR M10X25 DIN912
F90SP D 63-06-22-10
SR 10514114 SW6-T-SH BLD IP15/M7 SR M10X25 DIN912
F90SP D 63-07-22-10
SR 10514114 SW6-T-SH BLD IP15/M7 SR M10X25 DIN912
F90SP D 80-06-27-10
SR 10514114 SW6-T-SH BLD IP15/M7
F90SP D 80-09-27-10
SR 10514114 SW6-T-SH BLD IP15/M7
F90SP-10
90° Face Mills Carrying S/X/
QPMT 1004... Inserts
199
FACE MILLS
DC
OAL
DCONMS
DHUB
APMX
Rd°
Designation
DC CICT(1) APMX OAL DHUB DCONMS Arbor(2) RMPX°(3)
kg
HM390 FTP D040-3-16-10
40.00 3 8.00 40.00 38.40 16.00 A 1.6 0.50
HM390 FTP D040-5-16-10
40.00 5 8.00 40.00 38.40 16.00 A 1.6 0.23
HM390 FTP D050-4-22-10
50.00 4 8.00 40.00 48.00 22.00 A 1.2 0.33
HM390 FTP D050-6-22-10
50.00 6 8.00 40.00 48.00 22.00 A 1.2 0.34
HM390 FTP D063-6-22-10
63.00 6 8.00 45.00 59.00 22.00 A 0.9 0.69
HM390 FTP D063-6-27-10
63.00 6 8.00 45.00 61.00 27.00 A 0.9 0.63
HM390 FTP D063-7-22-10
63.00 7 8.00 45.00 61.00 22.00 A 0.9 0.69
HM390 FTP D063-7-27-10
63.00 7 8.00 45.00 61.00 27.00 A 0.9 0.68
HM390 FTP D080-11-27-10
80.00 11 8.00 50.00 60.00 27.00 A 0.8 0.98
HM390 FTP D100-13-27-10
100.00 13 8.00 50.00 60.00 27.00 A 0.8 1.38
• For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation see page 548
(3) Maximum ramping angle
For inserts, see pages: HM390 TPKT/CT 1003 (447)
Spare Parts
Designation
HM390 FTP D040-3-16-10
SR 14-562/S BLD T10/S7 SW6-SD SR M8X25DIN912
HM390 FTP D040-5-16-10
SR 14-562/S BLD T10/S7 SW6-SD SR M8X25DIN912
HM390 FTP D050-4-22-10
SR 14-562/S BLD T10/S7 SW6-SD SR M10X25 DIN912
HM390 FTP D050-6-22-10
SR 14-562/S BLD T10/S7 SW6-SD SR M10X25 DIN912
HM390 FTP D063-6-22-10
SR 14-562/S BLD T10/S7 SW6-SD SR M10X25 DIN912
HM390 FTP D063-6-27-10
SR 14-562/S BLD T10/S7 SW6-SD SR M12X35DIN912
HM390 FTP D063-7-22-10
SR 14-562/S BLD T10/S7 SW6-SD SR M10X25 DIN912
HM390 FTP D063-7-27-10
SR 14-562/S BLD T10/S7 SW6-SD SR M12X35DIN912
HM390 FTP D080-11-27-10
SR 14-562/S BLD T10/S7 SW6-SD SR M12X35DIN912
HM390 FTP D100-13-27-10
SR 14-562/S BLD T10/S7 SW6-SD SR M12X35DIN912
HM390 FTP-10
90° Face Mills Carrying HM390
TPKT 1003 Triangular Inserts
with 3 Helical Cutting Edges
ISCAR
200
FACE MILLS
DCONMS
DHUB
DC
OAL
APMX
Rd°
Designation
DC CICT(2) APMX OAL DHUB DCONMS RMPX°(3) RPMX(4) Arbor(5)
kg
HM90 F90AP D32-3-16
32.00 3 10.00 35.00 30.40 16.00 2.2 35355 A 0.10
HM90 F90AP D32-5-16
32.00 5 10.00 35.00 30.40 16.00 2.2 35355 A 0.10
HM90 F90AP D40-5-22
40.00 5 10.00 40.00 38.40 22.00 1.9 31623 A 0.19
HM90 F90AP D40-6-22
40.00 6 10.00 40.00 38.40 22.00 1.9 31623 A 0.18
HM90 F90AP D50-6-22
50.00 6 10.00 40.00 48.40 22.00 1.4 28284 A 0.34
HM90 F90AP D50-7-22
50.00 7 10.00 40.00 48.40 22.00 1.4 28284 A 0.35
HM90 F90AP D63-7-22 (1)
63.00 7 10.00 40.00 59.00 22.00 1.0 25198 B 0.52
HM90 F90AP D63-9-22
63.00 9 10.00 40.00 59.00 22.00 1.0 25198 B 0.52
HM90 F90AP D80-8-27 (1)
80.00 8 10.00 50.00 70.00 27.00 0.9 22361 B 0.94
HM90 F90AP D100-9-32 (1)
100.00 9 10.00 50.00 78.00 32.00 0.7 20100 B 1.51
• For user guide, see pages 542-547
(1) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(2) Number of inserts
(3) Maximum ramping angle
(4) Maximum RPM
(5) For adaptation options, see page 548
For inserts, see pages: APCR 1003PDFR-P (450) • APCT 1003PDR-HM (450) • APKR 1003PDR-HM (451) • APKT 1003..R (453) • APKT 1003..TR-RM (452)
• APKT 1003PDR-HM (451) • APKT 1003PDR-HM-CS (451) • APKT 1003PDTR-76 (452) • APKT 1003PDTR/L-RM (452) • APKT 1003R8T-FF (454)
• APKW 100304 PDR (PCD) (450) • HM90 APCR 100304PDFR-P/DP (449) • HM90 APCT 1003 (448) • HM90 APKT 1003 (449) • HM90 APKT 1003PD-W (453)
• HM90 APKW 1003PDR (453)
Spare Parts
Designation
HM90 F90AP D32-3-16
SR 34-505/HG SW4-SD BLD T08/M7 SR M8X20DIN912
HM90 F90AP D32-5-16
SR 34-505/HG SW4-SD BLD T08/M7 SR M8X20DIN912
HM90 F90AP D40-5-22
SR 34-505/HG SW4-SD BLD T08/M7 SR M10X25 DIN912
HM90 F90AP D40-6-22
SR 34-505/HG SW4-SD BLD T08/M7 SR M10X25 DIN912
HM90 F90AP D50-6-22
SR 34-505/HG SW4-SD BLD T08/M7 SR M10X25 DIN912
HM90 F90AP D50-7-22
SR 34-505/HG SW4-SD BLD T08/M7 SR M10X25 DIN912
HM90 F90AP D63-7-22
SR 34-505/HG SW4-SD BLD T08/M7
HM90 F90AP D63-9-22
SR 34-505/HG SW4-SD BLD T08/M7
HM90 F90AP D80-8-27
SR 34-505/HG SW4-SD BLD T08/M7
HM90 F90AP D100-9-32
SR 34-505/HG SW4-SD BLD T08/M7
HM90 F90AP-10
90° Face Mills Carrying HM90
APKT 1003... Inserts
DC
OAL
APMX
DCONMS
DHUB
Rd°
Designation
DC CICT(1) APMX OAL DHUB DCONMS RMPX°(2) Arbor MIID(3)
kg
HM90 F90AP D032-05-16-JHP
32.00 5 10.00 45.00 30.40 16.00 2.2 A APKT 1003PDR-HM 0.17
HM90 F90AP D040-06-22-JHP
40.00 6 10.00 50.00 38.00 22.00 1.9 A APKT 1003PDR-HM 0.27
HM90 F90AP D050-07-22-JHP
50.00 7 10.00 50.00 48.00 22.00 1.4 A APKT 1003PDR-HM 0.49
• Use adaptation only with face coolant outlets • For user guide, see pages 542-547
(1) Number of inserts
(2) Maximum ramping angle
(3) Master insert identification
For inserts, see pages: APCR 1003PDFR-P (450) • APCT 1003PDR-HM (450) • APKR 1003PDR-HM (451) • APKT 1003..R (453) • APKT 1003..TR-RM (452)
• APKT 1003PDR-HM (451) • APKT 1003PDR-HM-CS (451) • APKT 1003PDTR-76 (452) • APKT 1003PDTR/L-RM (452) • APKT 1003R8T-FF (454)
• APKW 100304 PDR (PCD) (450) • HM90 APCR 100304PDFR-P/DP (449) • HM90 APCT 1003 (448) • HM90 APKT 1003 (449) • HM90 APKT 1003PD-W (453)
• HM90 APKW 1003PDR (453)
Spare Parts
Designation
HM90 F90AP D032-05-16-JHP
SR 34-505/HG(a) SR PS 118-0416 BLD T08/M7 SW4-SD
HM90 F90AP D040-06-22-JHP
SR 34-505/HG(a) SR PS 118-0273 BLD T08/M7 SW4-SD
HM90 F90AP D050-07-22-JHP
SR 34-505/HG(a) SR PS 118-0271C BLD T08/M7 SW4-SD
(a) Recommended tightening torque for this item: 1.2 Nxm
HM90 F90AP-10-JHP
90° JHP Face Mills Carrying
HELI2000 and HELIMILL Inserts
201
FACE MILLS
DC
OAL
DHUB
DCONMS
APMX
Rd°
Designation
DC CICT(1) APMX DHUB DCONMS OAL Arbor(2) RMPX°(3)
kg
H690 F90AX D032-4-16-10
32.00 4 8.00 30.40 16.00 35.00 A 1.6 0.10
H690 F90AX D032-5-16-10
32.00 5 8.00 30.40 16.00 35.00 A 1.6 0.10
H690 F90AX D040-5-16-10
40.00 5 8.00 38.00 16.00 40.00 A 1.1 0.22
H690 F90AX D040-6-16-10
40.00 6 8.00 38.00 16.00 40.00 A 1.1 0.21
H690 F90AX D050-6-22-10
50.00 6 8.00 48.00 22.00 40.00 A 1.0 0.35
H690 F90AX D050-7-22-10
50.00 7 8.00 48.00 22.00 40.00 A 1.0 0.36
H690 F90AX D063-8-22-10
63.00 8 8.00 48.00 22.00 40.00 A 0.7 0.47
(1) Number of inserts
(2) For adaptation options, see page 548
(3) Maximum ramping angle
For inserts, see pages: H690 TNKX/TNCX 1005 (472)
Spare Parts
Designation
H690 F90AX D032-4-16-10
SR 10508082-HG BLD T08/M7 SW4-SD SR M8X38-1515
H690 F90AX D032-5-16-10
SR 10508082-HG BLD T08/M7 SW4-SD SR M8X38-1515
H690 F90AX D040-5-16-10
SR 10508082-HG BLD T08/M7 SW4-SD SR M8X30DIN912
H690 F90AX D040-6-16-10
SR 10508082-HG BLD T08/M7 SW4-SD SR M8X30DIN912
H690 F90AX D050-6-22-10
SR 10508082-HG BLD T08/M7 SW4-SD SR M10X25 DIN912
H690 F90AX D050-7-22-10
SR 10508082-HG BLD T08/M7 SW4-SD SR M10X25 DIN912
H690 F90AX D063-8-22-10
SR 10508082-HG BLD T08/M7 SW4-SD SR M10X25 DIN912
H690 F90AX-10
90° Face Mills Carrying H690
TNKX 1005.. Triangular Inserts
with 6 Helical Cutting Edges
DCONMS
DHUB
APMX
DC
OAL
Designation
DC CICT(1) APMX OAL DHUB DCONMS Arbor(2) RMPX°(3)
kg
T490 FLN D040-04-16-R-11
40.00 4 9.00 40.00 38.00 16.00 A 1.4 0.23
T490 FLN D040-05-16-R-11
40.00 5 9.00 40.00 38.00 16.00 A 1.4 0.22
T490 FLN D050-05-22-R-11
50.00 5 9.00 40.00 48.00 22.00 A 1.1 0.33
T490 FLN D050-06-22-R-11
50.00 6 9.00 40.00 48.00 22.00 A 1.1 0.33
T490 FLN D063-06-22-R-11
63.00 6 9.00 40.00 59.20 22.00 A 0.7 0.55
T490 FLN D063-09-22-R-11
63.00 9 9.00 40.00 59.20 22.00 A 0.7 0.55
T490 FLN D080-07-27-R-11
80.00 7 9.00 50.00 70.00 27.00 A - 1.01
T490 FLN D080-11-27-R-11
80.00 11 9.00 50.00 70.00 27.00 A - 1.04
T490 FLN D100-08-32-R-11
100.00 8 9.00 50.00 78.00 32.00 B - 1.48
T490 FLN D100-13-32-R-11
100.00 13 9.00 50.00 78.00 32.00 B - 1.55
• For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
(3) Maximum ramping angle - valid only with T490 LNHT 1106PNTR-RD insert
For inserts, see pages: T490 LNMT/LNHT 1106 (477)
Spare Parts
Designation
T490 FLN D040-04-16-R-11
SR 34-535-SN BLD T15/S7(a) SW6-SD SR M8X30DIN912
T490 FLN D040-05-16-R-11
SR 34-535-SN BLD T15/S7(a) SW6-SD SR M8X30DIN912
T490 FLN D050-05-22-R-11
SR 34-535-SN BLD T15/S7(a) SW6-SD SR M10X25 DIN912
T490 FLN D050-06-22-R-11
SR 34-535-SN BLD T15/S7(a) SW6-SD SR M10X25 DIN912
T490 FLN D063-06-22-R-11
SR 34-535-SN BLD T15/S7(a) SW6-SD SR M10X25 DIN912
T490 FLN D063-09-22-R-11
SR 34-535-SN BLD T15/S7(a) SW6-SD SR M10X25 DIN912
T490 FLN D080-07-27-R-11
SR 34-535-SN BLD T15/S7(a) SW6-SD
T490 FLN D080-11-27-R-11
SR 34-535-SN BLD T15/S7(a) SW6-SD
T490 FLN D100-08-32-R-11
SR 34-535-SN BLD T15/S7(a) SW6-SD
T490 FLN D100-13-32-R-11
SR 34-535-SN BLD T15/S7(a) SW6-SD
(a) Recommended key handle for limiting torque to 3.2 N*m for this item is HSD 4-3.2NM (to be used with BLD 4 T15-4.8 blade)
T490 FLN-11
90° Face Mills Carrying
T490 LN#T 11... Tangentially
Clamped Inserts
ISCAR
202
FACE MILLS
DC
DHUB
DCOMNS
APMX
OAL
Designation
DC APMX CICT(1) DCONMS DHUB OAL Arbor
kg
T890HT FLN D040-03-16-R13
40.00 9.50 3 16.00 38.00 40.00 A 0.22
T890HT FLN D040-04-16-R13
40.00 9.50 4 16.00 38.00 40.00 A 0.21
T890HT FLN D040-05-16-R13
40.00 9.50 5 16.00 38.00 40.00 A 0.21
T890HT FLN D050-04-22-R13
50.00 9.50 4 22.00 48.00 40.00 A 0.33
T890HT FLN D050-05-22-R13
50.00 9.50 5 22.00 48.00 40.00 A 0.33
T890HT FLN D050-06-22-R13
50.00 9.50 6 22.00 48.00 40.00 A 0.35
T890HT FLN D063-06-22-R13
63.00 9.50 6 22.00 48.00 40.00 A 0.48
T890HT FLN D063-07-22-R13
63.00 9.50 7 22.00 48.00 40.00 A 0.48
T890HT FLN D063-08-22-R13
63.00 9.50 8 22.00 48.00 40.00 A 0.50
T890HT FLN D080-06-27-R13
80.00 9.50 6 27.00 60.00 50.00 B 0.88
T890HT FLN D080-07-27-R13
80.00 9.50 7 27.00 60.00 50.00 B 0.89
T890HT FLN D080-09-27-R13
80.00 9.50 9 27.00 60.00 50.00 B 0.91
T890HT FLN D100-08-32-R13
100.00 9.50 8 32.00 78.00 50.00 B 1.49
T890HT FLN D100-12-32-R13
100.00 9.50 12 32.00 78.00 50.00 B 1.62
T890HT FLN D125-09-40-R13
125.00 9.50 9 40.00 92.00 63.00 B 2.83
T890HT FLN D125-15-40-R13
125.00 9.50 15 40.00 92.00 63.00 B 2.93
T890HT FLN D160-12-40-R13
160.00 9.50 12 40.00 95.00 63.00 C 3.24
T890HT FLN D160-20-40-R13
160.00 9.50 20 40.00 95.00 63.00 C 3.53
• For user guide, see pages 542-547
(1) Number of inserts
For inserts, see pages: T890 LN.. 1306 (475)
Spare Parts
Designation
T890HT FLN D040-03-16-R13
SR 10513105-L10.5(a) BLD IP20/M7 SW6-T-SH SR M8X30DIN912
T890HT FLN D040-04-16-R13
SR 10513105-L10.5(a) BLD IP20/M7 SW6-T-SH SR M8X30DIN912
T890HT FLN D040-05-16-R13
SR 10513105-L10.5(a) BLD IP20/M7 SW6-T-SH SR M8X30DIN912
T890HT FLN D050-04-22-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH SR M10X25 DIN912
T890HT FLN D050-05-22-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH SR M10X25 DIN912
T890HT FLN D050-06-22-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH SR M10X25 DIN912
T890HT FLN D063-06-22-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH SR M10X25 DIN912
T890HT FLN D063-07-22-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH SR M10X25 DIN912
T890HT FLN D063-08-22-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH SR M10X25 DIN912
T890HT FLN D080-06-27-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH
T890HT FLN D080-07-27-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH
T890HT FLN D080-09-27-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH
T890HT FLN D100-08-32-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH
T890HT FLN D100-12-32-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH
T890HT FLN D125-09-40-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH
T890HT FLN D125-15-40-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH
T890HT FLN D160-12-40-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH
T890HT FLN D160-20-40-R13
SR 10513105(a) BLD IP20/M7 SW6-T-SH
(a) Recommended tightening torque: 8.0 N*m (71.0 lbf*in)
T890HT FLN-R13
90° Face Mills Carrying
T890 LN.T 1306...
Tangentially Clamped Inserts
with 8 Cutting Edges
203
FACE MILLS
DCONMS
DHUB
DC
OAL
KAPR DC=40, a=6˚, KAPR=91˚
DC=50, a=6˚, KAPR=90˚
DC≥63, a=5˚, KAPR=90˚
a°
5.0 KAPR
APMX
Designation
DC CICT(3) APMX OAL DHUB DCONMS Arbor(4)
kg
F90LN D040-04-16-R/L-N11
40.00 4 10.00 40.00 38.40 16.00 A 0.22
F90LN D040-06-16-R/L-N11 (1)
40.00 6 10.00 40.00 38.40 16.00 A 0.21
F90LN D050-05-22-R/L-N11
50.00 5 10.00 40.00 47.00 22.00 A 0.32
F90LN D050-07-22-L-N11 (1)
50.00 7 10.00 40.00 47.00 22.00 A 0.32
F90LN D050-07-22-R-N11 (1)
50.00 7 10.00 40.00 47.00 22.00 A 0.33
F90LN D063-06-22-R/L-N11
63.00 6 10.00 40.00 59.20 22.00 B 0.47
F90LN D063-09-22-R/L-N11 (1)
63.00 9 10.00 40.00 59.20 22.00 B 0.50
F90LN D080-08-27-R/L-N11 (2)
80.00 8 10.00 50.00 70.00 27.00 B 0.98
F90LN D080-11-27-R/L-N11 (2)
80.00 11 10.00 50.00 70.00 27.00 B 1.02
F90LN D100-09-32-L-N11 (2)
100.00 9 10.00 50.00 77.00 32.00 B 1.40
F90LN D100-09-32-R-N11 (2)
100.00 9 10.00 50.00 77.00 32.00 B 1.41
F90LN D100-14-32-R-N11 (2)
100.00 14 10.00 50.00 77.00 32.00 B 1.48
F90LN D125-10-40-L-N11 (2)
125.00 10 10.00 63.00 95.00 40.00 B 2.73
F90LN D125-10-40-R-N11 (2)
125.00 10 10.00 63.00 95.00 40.00 B 2.67
F90LN D125-18-40-R-N11 (2)
125.00 18 10.00 63.00 95.00 40.00 B 2.88
• For user guide, see pages 542-547
(1) Fine pitch
(2) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(3) Number of inserts
(4) For adaptation options, see page 548
For inserts, see pages: LNAR 1106 (482) • LNAR 1106 (PCD) (483) • LNAR 1106PN-R-S-W (PCD) (483) • LNAT 1106-W (482) • LNAW-11 (CBN) (484)
• LNHT 1106 PN-N HT (482) • LNHT 1106 PN-R HT (481) • LNKX/LNMT 1106 (481)
Spare Parts
Designation
F90LN D040-04-16-R/L-N11
SR 34-550 SW6-SD BLD T10/S7 SR M8X30DIN912
F90LN D040-06-16-R/L-N11
SR 34-550 SW6-SD BLD T10/S7 SR M8X30DIN912
F90LN D050-05-22-R/L-N11
SR 34-550 SW6-SD BLD T10/S7 SR M10X25 DIN912
F90LN D050-07-22-R/L-N11
SR 34-550 SW6-SD BLD T10/S7 SR M10X25 DIN912
F90LN D063-06-22-R/L-N11
SR 34-550 SW6-SD BLD T10/S7
F90LN D063-09-22-R/L-N11
SR 34-550 SW6-SD BLD T10/S7
F90LN D080-08-27-R/L-N11
SR 34-550 SW6-SD BLD T10/S7
F90LN D080-11-27-R/L-N11
SR 34-550 SW6-SD BLD T10/S7
F90LN D100-09-32-R/L-N11
SR 34-550 SW6-SD BLD T10/S7
F90LN D100-14-32-R-N11
SR 34-550 SW6-SD BLD T10/S7
F90LN D125-10-40-R/L-N11
SR 34-550 SW6-SD BLD T10/S7
F90LN D125-18-40-R-N11
SR 34-550 SW6-SD BLD T10/S7
F90LN-N11
90° Face Mills Carrying
LN..1106... Tangentially
Clamped Inserts
ISCAR
204
FACE MILLS
DCONMS
OAL
DC
DHUB
APMX
Designation
DC CICT(1) APMX OAL DHUB DCONMS Arbor(2)
kg
F90SD D050-05-22-12
50.00 5 11.80 40.00 48.00 22.00 A 0.28
F90SD D063-04-22-12
63.00 4 11.80 40.00 48.00 22.00 A 0.41
F90SD D063-06-22-12
63.00 6 11.80 40.00 48.00 22.00 A 0.43
F90SD D080-05-27-12
80.00 5 11.80 50.00 60.00 27.00 B 0.79
F90SD D100-06-32-12
100.00 6 11.80 50.00 78.00 32.00 B 1.44
F90SD D100-08-32-12
100.00 8 11.80 50.00 78.00 32.00 B 1.43
F90SD D125-07-40-12
125.00 7 11.80 50.00 92.00 40.00 B 2.13
F90SD D125-09-40-12
125.00 9 11.80 50.00 92.00 40.00 B 2.16
F90SD D160-11-40-12
160.00 11 11.80 50.00 95.00 40.00 C 2.95
F90SD D200-13-60-12
200.00 13 11.80 55.00 135.00 60.00 C 5.40
• For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
For inserts, see pages: QDCT-PDN (497) • QDMT 1205..PDTN-M (498) • SDMR-HQ (497) • SDMT-PDR-HQ (496) • SDMT-PDR-RM (497)
Spare Parts
Designation
F90SD D050-05-22-12
SR M4X0.7-L9.6 IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
F90SD D063-04-22-12
SR M4X0.7-L9.6 IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
F90SD D063-06-22-12
SR M4X0.7-L9.6 IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
F90SD D080-05-27-12
SR M4X0.7-L9.6 IP15 BLD IP15/M7 SW6-T-SH
F90SD D100-06-32-12
SR M4X0.7-L9.6 IP15 BLD IP15/M7 SW6-T-SH
F90SD D100-08-32-12
SR M4X0.7-L9.6 IP15 BLD IP15/M7 SW6-T-SH
F90SD D125-07-40-12
SR M4X0.7-L9.6 IP15 BLD IP15/M7 SW6-T-SH
F90SD D125-09-40-12
SR M4X0.7-L9.6 IP15 BLD IP15/M7 SW6-T-SH
F90SD D160-11-40-12
SR M4X0.7-L9.6 IP15 BLD IP15/L7 SW6-T-SH
F90SD D200-13-60-12
SR M4X0.7-L9.6 IP15 BLD IP15/L7 SW6-T-SH
F90SD-12
90° Face Mills Carrying
Square Inserts
205
FACE MILLS
DC
DCONMS
DHUB
OAL
88°
APMX
Designation
DC APMX OAL CICT(2) DCONMS DHUB Arbor(3) CSP(4)
kg
S890 FSN D040-04-16-R13
40.00 9.00 40.00 4 16.00 38.00 A 1 0.19
S890 FSN D050-04-22-R13
50.00 9.00 40.00 4 22.00 48.00 A 1 0.28
S890 FSN D050-05-22-R13 (1)
50.00 9.00 40.00 5 22.00 48.00 A 1 0.29
S890 FSN D063-05-22-R13
63.00 9.00 40.00 5 22.00 48.00 A 1 0.39
S890 FSN D063-07-22-R13 (1)
63.00 9.00 40.00 7 22.00 48.00 B 1 0.39
S890 FSN D080-07-27-R13
80.00 9.00 50.00 7 27.00 60.00 B 1 0.74
S890 FSN D080-09-27-R13 (1)
80.00 9.00 50.00 9 27.00 60.00 B 1 0.74
S890 FSN D100-08-32-R13
100.00 9.00 50.00 8 32.00 70.00 B 1 1.25
S890 FSN D100-11-32-R13 (1)
100.00 9.00 50.00 11 32.00 70.00 B 1 1.27
S890 FSN D125-09-40-R13
125.00 9.00 63.00 9 40.00 82.00 B 1 2.29
S890 FSN D125-14-40-R13 (1)
125.00 9.00 63.00 14 40.00 82.00 B 1 2.30
S890 FSN D160-10-40-R13
160.00 9.00 63.00 10 40.00 106.00 C 0 4.28
• Use only Torx Plus keys • For user guide, see pages 542-547
(1) Fine pitch
(2) Number of inserts
(3) For adaptation options, see page 548
(4) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: S890 SNMU 1305PN... (504)
Spare Parts
Designation
S890 FSN D040-04-16-R13
SR 11800745 BLD IP15/S7 SW6-T-SH SR M8X38-1515
S890 FSN D050-04-22-R13
SR 11800745 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
S890 FSN D050-05-22-R13
SR 11800745 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
S890 FSN D063-05-22-R13
SR 11800745 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
S890 FSN D063-07-22-R13
SR 11800745 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
S890 FSN D080-07-27-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S890 FSN D080-09-27-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S890 FSN D100-08-32-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S890 FSN D100-11-32-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S890 FSN D125-09-40-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S890 FSN D125-14-40-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S890 FSN D160-10-40-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S890 FSN-13
Face Mills Carrying
Double-Sided Square Inserts
with 8 Cutting Edges
ISCAR
206
FACE MILLS
OAL
DC
DCONMS
DHUB
APMX
Designation
DC CICT(1) APMX OAL DHUB DCONMS Arbor(2) RMPX°(3) CSP(4)
kg
H490 F90AX D040-4-16-12
40.00 4 12.00 40.00 38.00 16.00 A 1.5 1 0.20
H490 F90AX D050-3-22-12
50.00 3 12.00 40.00 48.00 22.00 A 1.5 1 0.33
H490 F90AX D050-5-22-12
50.00 5 12.00 40.00 48.00 22.00 A 1.5 1 0.32
H490 F90AX D063-4-27-12
63.00 4 12.00 50.00 59.20 27.00 A 1.5 1 0.68
H490 F90AX D063-6-27-12
63.00 6 12.00 50.00 59.20 27.00 A 1.5 1 0.65
H490 F90AX D080-5-27-12
80.00 5 12.00 50.00 63.00 27.00 B - 1 0.83
H490 F90AX D080-7-27-12
80.00 7 12.00 50.00 63.00 27.00 B - 1 0.85
H490 F90AX D100-6-32-12
100.00 6 12.00 50.00 80.00 32.00 B - 1 1.41
H490 F90AX D100-9-32-12
100.00 9 12.00 50.00 80.00 32.00 B - 1 1.47
H490 F90AX D160-9-40-12
160.00 9 12.00 63.00 105.00 40.00 C - 0 3.87
• For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
(3) Maximum ramping angle - valid only when the H490 ANKX1205R 15T-FF insert is used
(4) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: H490 ANKX 1205-FF (471) • H490 ANKX/ANCX-12 (470)
Spare Parts
Designation
H490 F90AX D040-4-16-12
SR 14-544 BLD T15/M7 SW6-T SR M8X30DIN912
H490 F90AX D050-3-22-12
SR 14-544 BLD T15/M7 SW6-T SR M10X30 DIN912
H490 F90AX D050-5-22-12
SR 14-544 BLD T15/M7 SW6-T SR M10X30 DIN912
H490 F90AX D063-4-27-12
SR 14-544 BLD T15/M7 SW6-T SR M12X35DIN912
H490 F90AX D063-6-27-12
SR 14-544 BLD T15/M7 SW6-T SR M12X35DIN912
H490 F90AX D080-5-27-12
SR 14-544 BLD T15/M7 SW6-T
H490 F90AX D080-7-27-12
SR 14-544 BLD T15/M7 SW6-T
H490 F90AX D100-6-32-12
SR 14-544 BLD T15/M7 SW6-T
H490 F90AX D100-9-32-12
SR 14-544 BLD T15/M7 SW6-T
H490 F90AX D160-9-40-12
SR 14-544 BLD T15/M7 SW6-T
H490 F90AX-12
90° Face Mills Carrying H490
ANKX 12.. Double-Sided
Rectangular Inserts with 4
Helical Cutting Edges
207
FACE MILLS
DCONMS
DHUB
DC
APMX
OAL
Rd°
Designation
DC CICT(1) APMX OAL DHUB DCONMS Arbor(2) RMPX°(3) CSP(4)
kg
T490 FLN D040-04-16-R-13
40.00 4 12.50 40.00 38.00 16.00 A 2.0 1 0.22
T490 FLN D040-05-16-R-13
40.00 5 12.50 40.00 38.00 16.00 A 2.0 1 0.22
T490 FLN D050-05-22-R-13
50.00 5 12.50 40.00 47.00 22.00 A 1.5 1 0.31
T490 FLN D050-06-22-R-13
50.00 6 12.50 40.00 47.00 22.00 A 1.5 1 0.31
T490 FLN D063-06-22-R-13
63.00 6 12.50 40.00 59.20 22.00 A 1.1 1 0.55
T490 FLN D063-08-22-R-13
63.00 8 12.50 40.00 59.20 22.00 A 1.1 1 0.56
T490 FLN D080-07-27-R-13
80.00 7 12.50 50.00 70.00 27.00 B 0.9 1 0.98
T490 FLN D080-10-27-R-13
80.00 10 12.50 50.00 70.00 27.00 B 0.9 1 1.00
T490 FLN D100-08-32-R-13
100.00 8 12.50 50.00 78.00 32.00 B 0.7 1 1.45
T490 FLN D100-13-32-R-13
100.00 13 12.50 50.00 78.00 32.00 B 0.7 1 1.49
T490 FLN D125-09-40-R-13
125.00 9 12.50 63.00 82.00 40.00 B 0.5 1 2.16
T490 FLN D125-17-40-R-13
125.00 17 12.50 63.00 82.00 40.00 B 0.5 1 2.30
T490 FLN D160-12-40-R-13
160.00 12 12.50 63.00 120.00 40.00 C 0.5 0 4.32
T490 FLN D200-15-60-R-13
200.00 15 12.50 63.00 135.00 60.00 C 0.5 0 5.84
• When machining slots, coarse pitch cutters should be used • For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
(3) Maximum ramping angle - valid only when the T490 LNHT 1306 PNTR-RD insert is used. For the -FF insert, refer to -FF insert information
(4) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT 1306PNR-FF (479) • T490 LNMT 1306PNTR-FW (479) • T490 LNMT/LNHT/LNAR 1306 (478)
Spare Parts
Designation
T490 FLN D040-04-16-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M8X30DIN912
T490 FLN D040-05-16-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M8X30DIN912
T490 FLN D050-05-22-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X25 DIN912
T490 FLN D050-06-22-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X25 DIN912
T490 FLN D063-06-22-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X25 DIN912
T490 FLN D063-08-22-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X25 DIN912
T490 FLN D080-07-27-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 FLN D080-10-27-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 FLN D100-08-32-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 FLN D100-13-32-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 FLN D125-09-40-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 FLN D125-17-40-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 FLN D160-12-40-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 FLN D200-15-60-R-13
SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 FLN-13
90° Face Mills Carrying
Tangentially Clamped Inserts
with 4 Helical 13 mm
Long Cutting Edges
DCONMS
APMX
DC
DHUB
OAL
Designation
DC CICT(1) APMX OAL DHUB DCONMS Arbor(2)
kg
T290 FLN D040-04-16-15
40.00 4 14.00 40.00 36.00 16.00 A 0.20 SR 10505427 BLD IP20/S7 SW6-T SR M8X25DIN912
T290 FLN D050-05-22-15
50.00 5 14.00 40.00 48.00 22.00 A 0.33 SR 10505427 BLD IP20/S7 SW6-T SR M10X25DIN7984
• For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
For inserts, see pages: T290 LNMT 1506 (475)
T290 FLN-15
90° Face Mills Carrying T290
LNMT 1506... Tangentially
Clamped Inserts
ISCAR
208
FACE MILLS
DCONMS
DHUB
OAL
APMX
DC
a°
KAPR
7
APMX
DC=50, a=8˚, KAPR=91˚
DC=63, a=6˚, KAPR=90˚
DC≥100, a=4.5˚, KAPR=90˚
Designation
DC CICT(2) APMX OAL DHUB DCONMS Arbor(3)
kg
F90LN D050-05-22-R/L-N15
50.00 5 14.00 40.00 47.00 22.00 A 0.33
F90LN D063-05-22-R/L-N15
63.00 5 14.00 40.00 59.20 22.00 B 0.48
F90LN D063-08-22-R/L-N15
63.00 8 14.00 40.00 59.20 22.00 B 0.50
F90LN D080-07-27-L-N15 (1)
80.00 7 14.00 50.00 70.00 27.00 B 1.01
F90LN D080-07-27-R-N15 (1)
80.00 7 14.00 50.00 70.00 27.00 B 1.02
F90LN D080-10-27-L-N15 (1)
80.00 10 14.00 50.00 70.00 27.00 B 1.05
F90LN D080-10-27-R-N15 (1)
80.00 10 14.00 50.00 70.00 27.00 B 1.06
F90LN D100-08-32-L-N15 (1)
100.00 8 14.00 50.00 78.00 32.00 B 0.50
F90LN D100-08-32-R-N15 (1)
100.00 8 14.00 50.00 78.00 32.00 B 1.52
F90LN D100-12-32-L-N15 (1)
100.00 12 14.00 50.00 78.00 32.00 B 1.59
F90LN D100-12-32-R-N15 (1)
100.00 12 14.00 50.00 78.00 32.00 B 1.60
F90LN D125-09-40-R/L-N15 (1)
125.00 9 14.00 63.00 95.00 40.00 B 2.95
F90LN D125-15-40-L-N15 (1)
125.00 15 14.00 63.00 95.00 40.00 B 3.06
F90LN D125-15-40-R-N15 (1)
125.00 15 14.00 63.00 95.00 40.00 B 3.07
F90LN D160-10-40-L-N15
160.00 10 14.00 63.00 120.00 40.00 C 4.30
F90LN D160-10-40-R-N15
160.00 10 14.00 63.00 120.00 40.00 C 4.29
F90LN D160-20-40-L-N15
160.00 20 14.00 63.00 120.00 40.00 C 4.48
F90LN D160-20-40-R-N15
160.00 20 14.00 63.00 120.00 40.00 C 4.50
F90LN D200-12-60-L-N15
200.00 12 14.00 63.00 135.00 60.00 C 6.67
F90LN D200-12-60-R-N15
200.00 12 14.00 63.00 135.00 60.00 C 6.64
F90LN D250-15-60-R-N15
250.00 15 14.00 63.00 150.00 60.00 C 10.39
F90LN D250-30-60-R-N15
250.00 30 14.00 63.00 150.00 60.00 C 10.83
• Left-hand cutters are designated by a red groove • For user guide, see pages 542-547
(1) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(2) Number of inserts
(3) For adaptation options, see page 548
For inserts, see pages: LNAR 1506 (488) • LNAR 1506 PN-R-S (PCD) (489) • LNAT 1506-W (489) • LNAT 1506..PN-N MM (489) • LNAW-15 (CBN) (485)
• LNHW 1506 PNTN (ceramic) (488) • LNKX 1506 1.5X45 PN-N (487) • LNKX 1506PN-N PL (486) • LNKX/LNMT 1506PNTN/PN-N MM (486)
• LNMT 1506PN-R-TS (485) • LNMT/LNHT 1506...-N HT (488) • LNMT/LNHT 1506PN-R HT (487) • LNMW 1506 PNTN (486)
Spare Parts
Designation
F90LN D050-05-22-R/L-N15
SR 34-535 SW6-T BLD T15/M7 SR M10X25 DIN912
F90LN D063-05-22-R/L-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D063-08-22-R/L-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D080-07-27-R/L-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D080-10-27-R/L-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D100-08-32-R/L-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D100-12-32-R/L-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D125-09-40-R/L-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D125-15-40-L-N15
SR 34-535 SW6-T BLD T15/M7
F90LN D125-15-40-R-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D160-10-40-R/L-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D160-20-40-L-N15
SR 34-535 SW6-T BLD T15/M7
F90LN D160-20-40-R-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D200-12-60-R/L-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D250-15-60-R-N15
SR 34-535 SW6-T-SH BLD T15/M7
F90LN D250-30-60-R-N15
SR 34-535 SW6-T BLD T15/M7
F90LN-N15
90° Face Mills Carrying
LN..1506... Tangentially
Clamped Inserts
209
FACE MILLS
DC
OAL
APMX
DCONMS
DHUB
Rd°
Designation
DC CICT(2) APMX OAL DHUB DCONMS Arbor(3) RMPX°(4) CSP(5)
kg
HM390 FTD D040-3-16-15
40.00 3 13.00 40.00 38.40 16.00 A 2.0 1 0.20
HM390 FTD D040-4-16-15
40.00 4 13.00 40.00 38.40 16.00 A 2.0 1 0.19
HM390 FTD D050-3-22-15
50.00 3 13.00 40.00 46.00 22.00 A 1.6 1 0.25
HM390 FTD D050-4-22-15
50.00 4 13.00 40.00 46.00 22.00 A 1.6 1 0.28
HM390 FTD D050-5-22-15
50.00 5 13.00 40.00 46.00 22.00 A 1.6 1 0.28
HM390 FTD D063-4-27-15
63.00 4 13.00 45.00 59.00 27.00 A 1.2 1 0.53
HM390 FTD D063-5-22-15
63.00 5 13.00 45.00 59.00 22.00 A 1.2 1 0.58
HM390 FTD D063-5-27-15
63.00 5 13.00 45.00 59.00 27.00 A 1.2 1 0.53
HM390 FTD D063-6-22-15
63.00 6 13.00 45.00 59.00 22.00 A 1.2 1 0.62
HM390 FTD D063-6-27-15
63.00 6 13.00 45.00 59.00 27.00 A 1.2 1 0.57
HM390 FTD D080-5-27-15
80.00 5 13.00 50.00 74.00 27.00 A 0.9 1 1.11
HM390 FTD D080-6-27-15
80.00 6 13.00 50.00 74.00 27.00 A 0.9 1 0.14
HM390 FTD D080-7-27-15
80.00 7 13.00 50.00 74.00 27.00 A 0.9 1 1.18
HM390 FTD D100-6-32-15
100.00 6 13.00 50.00 80.00 32.00 B 0.7 1 1.31
HM390 FTD D100-8-32-15
100.00 8 13.00 50.00 80.00 32.00 B 0.7 1 1.46
HM390 FTD D125-7-40-15
125.00 7 13.00 63.00 82.00 40.00 B 0.5 1 2.12
HM390 FTD D125-9-40-15
125.00 9 13.00 63.00 82.00 40.00 B 0.5 1 2.29
HM390 FTD D160-8-40-15 (1)
160.00 8 13.00 63.00 105.00 40.00 C 0.3 0 3.57
HM390 FTD D160-10-40-15 (1)
160.00 10 13.00 63.00 105.00 40.00 C 0.3 0 4.02
HM390 FTD D200-9-60-15
200.00 9 13.00 63.00 135.00 60.00 C 0.2 0 5.23
• When assembled the HM390 TDKT 1505PDR-FW insert, tool diameter enlarges by 1.0 mm • For user guide, see pages 542-547
(1) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(2) Number of inserts
(3) For adaptation options, see page 548
(4) Maximum ramping angle
(5) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: HM390 TDCR 1505 (448) • HM390 TDKT/CT 1505 (447)
Spare Parts
Designation
HM390 FTD D040-3-16-15
SR 10511869 BLD IP20/S7 SW6-T SR M8X37-1515
HM390 FTD D040-4-16-15
SR 10511869 BLD IP20/S7 SW6-T SR M8X37-1515
HM390 FTD D050-3-22-15
SR 10505427 BLD IP20/S7 SW6-T SR M10X30 DIN912
HM390 FTD D050-4-22-15
SR 10505427 BLD IP20/S7 SW6-T SR M10X30 DIN912
HM390 FTD D050-5-22-15
SR 10511869 BLD IP20/S7 SW6-T SR M10X30 DIN912
HM390 FTD D063-4-27-15
SR 10505427 BLD IP20/S7 SW6-T SR M12X35DIN912
HM390 FTD D063-5-22-15
SR 10511869 BLD IP20/S7 SW6-T SR M10X30 DIN912
HM390 FTD D063-5-27-15
SR 10505427 BLD IP20/S7 SW6-T SR M12X35DIN912
HM390 FTD D063-6-22-15
SR 10511869 BLD IP20/S7 SW6-T SR M10X30 DIN912
HM390 FTD D063-6-27-15
SR 10505427 BLD IP20/S7 SW6-T SR M12X35DIN912
HM390 FTD D080-5-27-15
SR 10505427 BLD IP20/S7 SW6-T SR M12X40DIN912
HM390 FTD D080-6-27-15
SR 10505427 BLD IP20/S7 SW6-T SR M12X40DIN912
HM390 FTD D080-7-27-15
SR 10505427 BLD IP20/S7 SW6-T SR M12X40DIN912
HM390 FTD D100-6-32-15
SR 10505427 BLD IP20/S7 SW6-T
HM390 FTD D100-8-32-15
SR 10505427 BLD IP20/S7 SW6-T
HM390 FTD D125-7-40-15
SR 10505427 BLD IP20/S7 SW6-T
HM390 FTD D125-9-40-15
SR 10505427 BLD IP20/S7 SW6-T
HM390 FTD D160-8-40-15
SR 10505427 BLD IP20/S7 SW6-T
HM390 FTD D160-10-40-15
SR 10505427 BLD IP20/S7 SW6-T
HM390 FTD D200-9-60-15
SR 10505427 BLD IP20/S7 SW6-T
HM390 FTD-15
90° Face Mills Carrying HM390
TDKT 1505 Triangular Inserts
with 3 Helical Cutting Edges
ISCAR
210
FACE MILLS
DCONMS
DHUB
DC
OAL
APMX
Rd°
Designation
DC CICT(2) APMX OAL DHUB DCONMS RMPX°(3) Arbor(4)
kg
HM90 F90A D 40-3-16
40.00 3 14.30 40.00 38.60 16.00 4.0 A 0.20
HM90 F90A D 40-4-16
40.00 4 14.30 40.00 38.60 16.00 4.0 A 0.19
HM90 F90A D 50-3-22
50.00 3 14.30 40.00 48.00 22.00 2.6 A 0.32
HM90 F90A D 50-5-22
50.00 5 14.30 40.00 48.00 22.00 2.6 A 0.30
HM90 F90A D 63-4-22
63.00 4 14.30 40.00 59.20 22.00 2.0 A 0.55
HM90 F90A D 63-6-22
63.00 6 14.30 40.00 59.20 22.00 2.0 A 0.52
HM90 F90A D 80-5-27 (1)
80.00 5 14.30 50.00 70.00 27.00 0.8 B 0.91
HM90 F90A D 80-7-27 (1)
80.00 7 14.30 50.00 70.00 27.00 0.8 B 0.88
HM90 F90A D100-6-32 (1)
100.00 6 14.30 50.00 78.00 32.00 0.7 B 1.54
HM90 F90A D100-8-32 (1)
100.00 8 14.30 50.00 78.00 32.00 0.7 B 1.49
HM90 F90A D125-9-40 (1)
125.00 9 14.30 63.00 90.00 40.00 0.5 B 2.95
• For user guide, see pages 542-547
(1) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(2) Number of inserts
(3) Maximum ramping angle
(4) For adaptation options, see page 548
For inserts, see pages: ADCR 1505PDFR (456) • ADCT 1505PDFR-HM (457) • ADKR 1505PDR/L-HM (456) • ADKT 1505-FF (459) • ADKT 1505..R/L-HM (459)
• ADKT 1505PD-W (460) • ADKT 1505PDR/L-HM (458) • ADKT 1505PDTR-76 (459) • ADKT 1505PDTR/L-RM (458) • ADKW (CBN) (457) • ADKW (PCD) (457)
• ADMT 1505PDR-HS (458) • HM90 ADCR 1505PDFR-P (456) • HM90 ADCT 1505 (455) • HM90 ADCT 1505PDR-CF (455) • HM90 ADKT 1505 (454)
• HM90 ADKT 1505PD-W (460) • HM90 ADKW 1505PDR (462)
Spare Parts
Designation
HM90 F90A D 40-3-16
SR 14-544/S BLD T15/M7 SW6-T-SH SR M8X25DIN912
HM90 F90A D 40-4-16
SR 14-544/S BLD T15/M7 SW6-T-SH SR M8X25DIN912
HM90 F90A D 50-3-22
SR 14-544/S BLD T15/M7 SW6-T-SH SR M10X25 DIN912
HM90 F90A D 50-5-22
SR 14-544/S BLD T15/M7 SW6-T-SH SR M10X25 DIN912
HM90 F90A D 63-4-22
SR 14-544 BLD T15/M7 SW6-T-SH SR M10X25 DIN912
HM90 F90A D 63-6-22
SR 14-544 BLD T15/M7 SW6-T-SH SR M10X25 DIN912
HM90 F90A D 80-5-27
SR 14-544 BLD T15/M7 SW6-T-SH
HM90 F90A D 80-7-27
SR 14-544 BLD T15/M7 SW6-T-SH
HM90 F90A D100-6-32
SR 14-544 BLD T15/M7 SW6-T-SH
HM90 F90A D100-8-32
SR 14-544 BLD T15/M7 SW6-T-SH
HM90 F90A D125-9-40
SR 14-544 BLD T15/M7 SW6-T-SH
HM90 F90A-15
90° Face Mills Carrying HM90
ADKT 1505... Inserts
DC
OAL
APMX
DCONMS
DHUB
Rd°
Designation
DC CICT(1) APMX OAL DHUB DCONMS RMPX°(2) Arbor MIID(3)
kg
HM90 F90A D050-05-22-JHP
50.00 5 14.30 50.00 48.00 22.00 2.6 A ADKT 1505PDTR 0.50
HM90 F90A D063-06-22-JHP
63.00 6 14.30 50.00 48.00 22.00 2.0 A ADKT 1505PDTR 0.76
• Use adaptation only with face coolant outlets • For user guide, see pages 542-547
(1) Number of inserts
(2) Maximum ramping angle
(3) Master insert identification
For inserts, see pages: ADCR 1505PDFR (456) • ADCT 1505PDFR-HM (457) • ADKR 1505PDR/L-HM (456) • ADKT 1505-FF (459) • ADKT 1505..R/L-HM (459)
• ADKT 1505PD-W (460) • ADKT 1505PDR/L-HM (458) • ADKT 1505PDTR-76 (459) • ADKT 1505PDTR/L-RM (458) • ADKW (CBN) (457) • ADKW (PCD) (457)
• ADMT 1505PDR-HS (458) • HM90 ADCR 1505PDFR-P (456) • HM90 ADCT 1505 (455) • HM90 ADCT 1505PDR-CF (455) • HM90 ADKT 1505 (454)
• HM90 ADKT 1505PD-W (460) • HM90 ADKW 1505PDR (462)
Spare Parts
Designation
HM90 F90A D050-05-22-JHP
SR 14-544/S(a) SR PS 118-0273 BLD T15/M7 SW6-T-SH
HM90 F90A D063-06-22-JHP
SR 14-544(a) SR PS 118-0273 BLD T15/M7 SW6-T-SH
(a) Recommended tightening torque for this item: 4.8 Nxm
HM90 F90A-15-JHP
90° JHP Face Mills Carrying
HELI2000 and HELIMILL Inserts
211
FACE MILLS
DCONMS
DHUB
OAL
DC
Designation
DC CICT(1) OAL DHUB DCONMS Arbor(2) RPMX(3)
kg
F90AD D050-04-22-SFR
50.00 4 40.00 49.00 22.00 A 23000 0.31
F90AD D063-04-22-SFR
63.00 4 40.00 50.00 22.00 A 20600 0.43
F90AD D063-06-22-SFR
63.00 6 40.00 50.00 22.00 A 20600 0.49
F90AD D080-06-27-SFR
80.00 6 50.00 60.00 27.00 B 18200 0.89
• These tools may also be used for regular HELI2000 AD.. 1505... inserts, for applications that require precise frontal edge adjustment
• Thinner insert ADM. 1503.. mounted on TSP-15R seat • For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
(3) Maximum RPM
For inserts, see pages: ADKW (CBN) (457) • ADKW (PCD) (457) • ADCR 1505PDFR (456) • ADCT 1505PDFR-HM (457) • ADKR 1505PDR/L-HM (456)
• ADKT 1505-FF (459) • ADKT 1505..R/L-HM (459) • ADKT 1505PD-W (460) • ADKT 1505PDR/L-HM (458) • ADKT 1505PDTR-76 (459) • ADKT 1505PDTR/L-RM (458)
• ADMT 1505PDR-HS (458) • HM90 ADCR 1505PDFR-P (456) • HM90 ADCT 1505 (455) • HM90 ADCT 1505PDR-CF (455) • HM90 ADKT 1505 (454)
• HM90 ADKT 1505PD-W (460) • HM90 ADKW 1505PDR (462)
0.002 mm
Spare Parts
Designation
F90AD D050-04-22-SFR
SR 14-544/S SR 11800782 BLD T15/S7 SW6-T-SH SR M10X20DIN912
F90AD D063-04-22-SFR
SR 14-544/S SR 11800782 BLD T15/S7 SW6-T-SH SR M10X20DIN912
F90AD D063-06-22-SFR
SR 14-544/S SR 11800782 BLD T15/S7 SW6-T-SH SR M10X20DIN912
F90AD D080-06-27-SFR
SR 14-544/S SR 11800782 BLD T15/S7 SW6-T-SH
F90AD-SFR
Adjustable Face Mills (used
mainly for PCD/CBN inserts)
ISCAR
212
FACE MILLS
OAL
DCONMS
DHUB
APMX
DC
Designation
DC CICT(2) APMX OAL DHUB DCONMS Arbor(3) CSP(4)
kg
T490 FLN D050-03-22-16
50.00 3 16.00 40.00 48.00 22.00 A 1 0.30
T490 FLN D050-04-22-16 (1)
50.00 4 16.00 40.00 48.00 22.00 A 1 0.32
T490 FLN D063-06-27-16
63.00 6 16.00 45.00 60.00 27.00 A 1 0.62
T490 FLN D080-05-27-16
80.00 5 16.00 50.00 63.00 27.00 B 1 0.84
T490 FLN D080-07-27-16 (1)
80.00 7 16.00 50.00 63.00 27.00 B 1 0.91
T490 FLN D100-06-32-16
100.00 6 16.00 50.00 80.00 32.00 B 1 1.44
T490 FLN D100-08-32-16 (1)
100.00 8 16.00 50.00 80.00 32.00 B 1 1.50
T490 FLN D125-07-40-16
125.00 7 16.00 63.00 82.00 40.00 B 1 2.42
T490 FLN D125-10-40-16 (1)
125.00 10 16.00 63.00 82.00 40.00 B 1 2.46
T490 FLN D160-12-40-16 (1)
160.00 12 16.00 63.00 105.00 40.00 C 0 4.28
T490 FLN D200-12-60-16 (1)
200.00 12 16.00 63.00 135.00 60.00 C 0 5.40
• When machining slots, regular pitch cutters should be used. • For user guide, see pages 542-547
(1) Fine pitch
(2) Number of inserts
(3) For adaptation options, see page 548
(4) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT/LNHT 1607 (480)
Spare Parts
Designation
T490 FLN D050-03-22-16
SR 14-591 BLD T20/M7 SW6-T SR M10X25DIN7984
T490 FLN D050-04-22-16
SR 14-591 BLD T20/M7 SW6-T SR M10X25DIN7984
T490 FLN D063-06-27-16
SR 14-591 BLD T20/M7 SW6-T SR M12X30DIN912
T490 FLN D080-05-27-16
SR 14-591 BLD T20/M7 SW6-T
T490 FLN D080-07-27-16
SR 14-591 BLD T20/M7 SW6-T
T490 FLN D100-06-32-16
SR 14-591 BLD T20/M7 SW6-T
T490 FLN D100-08-32-16
SR 14-591 BLD T20/M7 SW6-T
T490 FLN D125-07-40-16
SR 14-591 BLD T20/M7 SW6-T
T490 FLN D125-10-40-16
SR 14-591 BLD T20/M7 SW6-T
T490 FLN D160-12-40-16
SR 14-591 BLD T20/M7 SW6-T
T490 FLN D200-12-60-16
SR 14-591 BLD T20/M7 SW6-T
T490 FLN-16
90° Face Mills Carrying
Tangentially Clamped Inserts
with 4 Helical 16 mm
Long Cutting Edges
DC
APMX
OAL
DCONMS
DHUB
Rd°
Designation
DC CICT(1) APMX OAL DHUB DCONMS Arbor(2) CSP(3) RMPX°(4)
kg
HM390 FTD D063-05-27-19
63.00 5 16.00 50.00 48.00 27.00 A 1 1.1 0.63
HM390 FTD D160-10-40-19
160.00 10 16.00 63.00 105.00 40.00 C 0 0.4 4.22
• For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
(3) 0 - Without coolant supply, 1 - With coolant supply
(4) Maximum ramping angle
For inserts, see pages: HM390 TDKT 1907 (448)
Spare Parts
Designation
HM390 FTD D063-05-27-19
SR 14-591/H BLD T20/S7 SW6-T SR DIN 912 M12X25
HM390 FTD D160-10-40-19
SR 14-591/H BLD T20/M7 SW6-T
HM390 FTD-19
90° Face Mills Carrying HM390
TDKT 1907 Triangular Inserts
with 3 Helical Cutting Edges
213
FACE MILLS
DCONMS
DHUB
DC
OAL
APMX
Rd°
Designation
DC CICT(2) APMX OAL DHUB DCONMS Arbor(3) RMPX°(4) CSP(5)
kg
H490 F90AX D040-3-16-17
40.00 3 16.30 40.00 36.00 16.00 A 4.4 1 0.18
H490 F90AX D050-3-22-17
50.00 3 16.30 40.00 48.00 22.00 A 3.8 1 0.32
H490 F90AX D050-4-22-17
50.00 4 16.30 40.00 48.00 22.00 A 3.8 1 0.30
H490 F90AX D050-5-22-17
50.00 5 16.30 40.00 48.00 22.00 A 3.8 1 0.48
H490 F90AX D063-4-27-17
63.00 4 16.30 50.00 59.20 27.00 A 2.0 1 0.63
H490 F90AX D063-6-27-17
63.00 6 16.30 50.00 59.20 27.00 A 2.0 1 0.67
H490 F90AX D080-5-27-17
80.00 5 16.30 50.00 63.00 27.00 B 1.5 1 0.79
H490 F90AX D080-7-27-17
80.00 7 16.30 50.00 63.00 27.00 B 1.5 1 0.80
H490 F90AX D100-5-32-17
100.00 5 16.30 50.00 80.00 32.00 B 1.0 1 1.39
H490 F90AX D100-8-32-17
100.00 8 16.30 50.00 80.00 32.00 B 1.0 1 1.47
H490 F90AX D125-7-40-17
125.00 7 16.30 63.00 82.00 40.00 B - 1 2.24
H490 F90AX D125-10-40-17
125.00 10 16.30 63.00 82.00 40.00 B - 1 5.41
H490 F90AX D160-8-40-17 (1)
160.00 8 16.30 63.00 105.00 40.00 C - 0 3.64
H490 F90AX D160-12-40-17 (1)
160.00 12 16.30 63.00 105.00 40.00 C - 0 4.09
H490 F90AX D200-10-60-17
200.00 10 16.30 63.00 135.00 60.00 C - 0 5.99
H490 F90AX D250-12-60-17
250.00 12 16.30 63.00 144.00 60.00 C - 0 9.36
• Ramping angle is valid only when H490 ANKX 1706R15T-FF insert is used (tool diameter is then 1.5 mm larger) • For user guide, see pages 542-547
(1) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(2) Number of inserts
(3) For adaptation options, see page 548
(4) Maximum ramping angle
(5) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: H490 ANKX 1706-FF (472) • H490 ANKX/ANCX-17 (472)
Spare Parts
Designation
H490 F90AX D040-3-16-17
SR 14-591 BLD T20/M7 SW6-T SR M8X25DIN912
H490 F90AX D050-3-22-17
SR 14-591 BLD T20/M7 SW6-T SR M10X25 DIN912
H490 F90AX D050-4-22-17
SR 14-591 BLD T20/M7 SW6-T SR M10X25 DIN912
H490 F90AX D050-5-22-17
SR 14-591 BLD T20/M7 SW6-T SR M10X25 DIN912
H490 F90AX D063-4-27-17
SR 14-591 BLD T20/M7 SW6-T SR M12X30DIN912
H490 F90AX D063-6-27-17
SR 14-591 BLD T20/M7 SW6-T SR M12X30DIN912
H490 F90AX D080-5-27-17
SR 14-591 BLD T20/M7 SW6-T
H490 F90AX D080-7-27-17
SR 14-591 BLD T20/M7 SW6-T
H490 F90AX D100-5-32-17
SR 14-591 BLD T20/M7 SW6-T
H490 F90AX D100-8-32-17
SR 14-591 BLD T20/M7 SW6-T
H490 F90AX D125-7-40-17
SR 14-591 BLD T20/M7 SW6-T
H490 F90AX D125-10-40-17
SR 14-591 BLD T20/M7 SW6-T
H490 F90AX D160-8-40-17
SR 14-591 BLD T20/M7 SW6-T
H490 F90AX D160-12-40-17
SR 14-591 BLD T20/M7 SW6-T
H490 F90AX D200-10-60-17
SR 14-591 BLD T20/M7 SW6-T
H490 F90AX D250-12-60-17
SR 14-591 BLD T20/M7 SW6-T
H490 F90AX-17
90° Face Mills Carrying H490
ANKX 17.. Double-Sided
Rectangular Inserts with 4
Helical Cutting Edges
ISCAR
214
FACE MILLS
DC
OAL
DHUB
DCONMS
APMX
Rd°
Designation
DC CICT(1) APMX OAL DHUB DCONMS Arbor(2) RMPX°(3) CSP(4)
kg
H690 F90AX D050-3-22-16
50.00 3 13.50 40.00 48.00 22.00 A 3.0 1 0.31
H690 F90AX D050-4-22-16
50.00 4 13.50 40.00 48.00 22.00 A 3.0 1 0.30
H690 F90AX D063-4-27-16
63.00 4 13.50 50.00 59.00 27.00 A 2.0 1 0.63
H690 F90AX D063-5-27-16
63.00 5 13.50 50.00 59.00 27.00 A 2.0 1 0.64
H690 F90AX D080-5-27-16
80.00 5 13.50 50.00 76.00 27.00 A 1.0 1 1.20
H690 F90AX D080-6-27-16
80.00 6 13.50 50.00 76.00 27.00 A 1.0 1 1.21
H690 F90AX D100-6-32-16
100.00 6 13.50 50.00 80.00 32.00 B 1.0 1 1.29
H690 F90AX D100-8-32-16
100.00 8 13.50 50.00 80.00 32.00 B 1.0 1 1.41
H690 F90AX D125-7-40-16
125.00 7 13.50 63.00 82.00 40.00 B 0.5 1 2.14
H690 F90AX D125-9-40-16
125.00 9 13.50 63.00 82.00 40.00 B 0.5 1 2.29
H690 F90AX D160-8-40-16
160.00 8 13.50 63.00 105.00 40.00 C - 0 3.03
H690 F90AX D160-10-40-16
160.00 10 13.50 63.00 105.00 40.00 C - 0 3.46
H690 F90AX D200-11-60-16
200.00 11 13.50 63.00 135.00 60.00 C - 0 5.09
• For cutting speed recommendations, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
(3) Maximum ramping angle
(4) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: H690 TNKX 1606 (474)
Spare Parts
Designation
H690 F90AX D050-3-22-16
SR 14-591 BLD T20/M7 SW6-T SR M10X40-1638
H690 F90AX D050-4-22-16
SR 14-591 BLD T20/M7 SW6-T SR M10X40-1638
H690 F90AX D063-4-27-16
SR 14-591 BLD T20/M7 SW6-T SR M12X30DIN912
H690 F90AX D063-5-27-16
SR 14-591 BLD T20/M7 SW6-T SR M12X30DIN912
H690 F90AX D080-5-27-16
SR 14-591 BLD T20/M7 SW6-T SR M12X35DIN912
H690 F90AX D080-6-27-16
SR 14-591 BLD T20/M7 SW6-T SR M12X35DIN912
H690 F90AX D100-6-32-16
SR 14-591 BLD T20/M7 SW6-T
H690 F90AX D100-8-32-16
SR 14-591 BLD T20/M7 SW6-T
H690 F90AX D125-7-40-16
SR 14-591 BLD T20/M7 SW6-T
H690 F90AX D125-9-40-16
SR 14-591 BLD T20/M7 SW6-T
H690 F90AX D160-8-40-16
SR 14-591 BLD T20/M7 SW6-T
H690 F90AX D160-10-40-16
SR 14-591 BLD T20/M7 SW6-T
H690 F90AX D200-11-60-16
SR 14-591 BLD T20/M7 SW6-T
H690 F90AX-16
90° Face Mills Carrying H690
TNKX 1606.. Triangular Inserts
with 6 Helical Cutting Edges
OAL
APMX
DCONMS
DHUB
DC
Designation
DC CICT(1) OAL APMX DHUB DCONMS Arbor(2)
kg
F90 D080-27
80.00 6 50.00 18.00 55.00 27.00 B 1.05
F90 D100-32
100.00 8 50.00 18.00 70.00 32.00 B 1.57
F90 D160-40
160.00 10 63.00 18.00 110.00 40.00 B 5.13
• For user guide, see pages 542-547
(1) Number of inserts
(2) For adaptation options, see page 548
For inserts, see pages: TPKN/TPKR (468)
Spare Parts
Designation
F90 D080-27
NTP 43-R SR 35-342.3 HW 4P LW 35-342 T SR 35-343.4 HW 2.0
F90 D100-32
NTP 43-R SR 35-342.3 HW 4P LW 35-342 T SR 35-403 HW 2.0
F90 D160-40
NTP 43-R SR 35-342.3 HW 4P LW 35-342 T SR 35-343.4 HW 2.0
F90
90° Face Mills Carrying
TPKN/R Inserts
215
FACE MILLS
DCONMS
OAL
APMX
DHUB
DC
Rd°
Designation
DC APMX CICT(2) OAL DHUB DCONMS Arbor(3) RMPX°(4)
kg
P290 FPW D032-04-16-12
32.00 12.00 4 50.00 30.40 16.00 A 1.0 0.16
P290 FPW D040-05-16-12
40.00 12.00 5 35.00 38.00 16.00 A 0.7 0.17
P290 FPW D050-06-22-12
50.00 12.00 6 40.00 48.00 22.00 A 0.5 0.31
P290 FPW D040-04-16-18
40.00 18.00 4 40.00 35.00 16.00 A 1.5 0.15
P290 FPW D050-05-22-18
50.00 18.00 5 40.00 45.00 22.00 A 1.0 0.27
P290 FCT D050-05-22-18 (1)
50.00 18.00 5 40.00 45.00 22.00 A 1.0 0.27
P290 FPW D063-06-22-18
63.00 18.00 6 40.00 48.00 22.00 A 0.8 0.47
P290 FPW D080-08-27-18
80.00 18.00 8 50.00 60.00 27.00 B 0.5 1.02
P290 FPW D100-09-32-18
100.00 18.00 9 55.00 78.00 32.00 B 0.3 1.87
• For user guide, see pages 542-547
(1) To be used only with P290 ACCT 1806PDR-HL/TL straight-edged inserts
(2) Number of inserts
(3) For adaptation options, see page 548
(4) Maximum ramping angle
For inserts, see pages: P290 ACCT/KT (461) • P290 ACKT (461)
Spare Parts
Designation
P290 FPW D032-04-16-12
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M8X40-D11.5 DIN912
P290 FPW D040-05-16-12
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M8X25DIN912
P290 FPW D050-06-22-12
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M10X25 DIN912
P290 FPW D040-04-16-18
SR 14-544/S BLD T15/M7 SW6-T SR M8X30DIN912
P290 FPW D050-05-22-18
SR 14-544/S BLD T15/M7 SW6-T SR M10X25 DIN912
P290 FCT D050-05-22-18
SR 14-544/S BLD T15/M7 SW6-T SR M10X25 DIN912
P290 FPW D063-06-22-18
SR 14-544/S BLD T15/M7 SW6-T SR M10X25 DIN912
P290 FPW D080-08-27-18
SR 14-544/S BLD T15/M7 SW6-T SR M12X30DIN912
P290 FPW D100-09-32-18
SR 14-544/S BLD T15/M7 SW6-T SR M16X40DIN912
(a) Recommended tightening torque:2.0 N*m
P290 FPW/FCT
90° Face Mills Carrying 12 and
18 mm Long Edged Inserts
DCONMS
DHUB
APMX
DC
OAL
Rd°
Designation
DC CICT(1) APMX OAL DHUB DCONMS RMPX°(2) Arbor(3)
kg
HP F90AT D50-4-22-19
50.00 4 18.00 50.00 46.50 22.00 5.0 A 0.33
• Insert clamping/unclamping procedure: First loosely attach the rear clamping screw, then the face screw. In the same order, tighten them both.
• For user guide, see pages 542-547
(1) Number of inserts
(2) Maximum ramping angle
(3) For adaptation options, see page 548
For inserts, see pages: HP ADCR 1906 (464) • HP ADKT/ADCT 1906 (464)
Spare Parts
Designation
HP F90AT-19
SR 14-571/L BLD T10/S7 SW6-SD SR M10X30 DIN912
HP F90AT-19
90° Face Mills Carrying HP AD..
1906... Long Edged Inserts
ISCAR
216
FACE MILLS
DCONMS
DHUB
APMX
DC
OAL
Rd°
Designation
DC CICT(1) APMX OAL DHUB DCONMS RMPX°(2) Arbor(3) CSP(4)
kg
HP F90AT D50-3-22-22
50.00 3 21.00 50.00 48.00 22.00 5.0 A 1 0.36
HP F90AT D50-4-22-22
50.00 4 21.00 50.00 48.00 22.00 5.0 A 0 0.33
• Insert clamping/unclamping procedure: First loosely attach the rear clamping screw, then the face screw. In the same order, tighten them both.
• For user guide, see pages 542-547
(1) Number of inserts
(2) Maximum ramping angle
(3) For adaptation options, see page 548
(4) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: HP ADCR 2207 (465) • HP ADKT/ADCT 2207 (464)
Spare Parts
Designation
HP F90AT-22
SR 14-544 BLD T15/M7 SW6-T-SH SR M10X30 DIN912
HP F90AT-22
90° Face Mills Carrying HP AD..
2207... Long Edged Inserts
DC
DCX
DCONMS
DHUB
75˚
OAL
APMX
Designation
DC DCX(1) CICT(2) APMX OAL DHUB DCONMS Arbor MIID(3)
kg
F75 D050-04-16-M
50.00 55.70 4 9.50 40.00 38.00 16.00 A SPKN 1203EDTR 0.50
F75 D063-05-22-M
63.00 68.70 5 9.50 40.00 48.00 22.00 A SPKN 1203EDTR 0.62
F75 D080-06-27-M
80.00 85.70 6 9.50 50.00 60.00 27.00 B SPKN 1203EDTR 1.09
F75 D100-07-32-M
100.00 105.70 7 9.50 50.00 78.00 32.00 B SPKN 1203EDTR 2.20
F75 D125-08-40-M
125.00 130.70 8 9.50 63.00 92.00 40.00 B SPKN 1203EDTR 4.10
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Cutting item count
(3) Master insert identification
For inserts, see pages: SPKN ED.. (513) • SPKR ED..-76 (513) • SPKR EDTR-HS (513)
Spare Parts
Designation
F75 D050-04-16-M
SR M8X30DIN912 BLD IP20/S7 SW6-T LW35-475/8M SR-118-069-CH
F75 D063-05-22-M
SR M10X25 DIN912 BLD IP20/S7 SW6-T LW35-475/8M SR-118-069-CH
F75 D080-06-27-M
BLD IP20/S7 SW6-T LW35-475/8M SR-118-069-CH
F75 D100-07-32-M
BLD IP20/S7 SW6-T LW35-475/8M SR-118-069-CH
F75 D125-08-40-M
BLD IP20/S7 SW6-T LW35-475/8M SR-118-069-CH
F75-M
75° Face Mills with SPKN/
SPKR 1203.. Inserts
217
FACE MILLS
APMX
65°
OAL
DCX
DC
DCONMS
DHUB
Designation
DC DCX(2) CICT(3) OAL DHUB DCONMS APMX(4) Arbor(5)
kg
S865 FSN D050-04-22-R13
50.00 59.70 4 40.00 48.00 22.00 6.00 A 0.36
S865 FSN D050-06-22-R13 (1)
50.00 59.70 6 40.00 48.00 22.00 6.00 A 0.36
S865 FSN D063-06-22-R13
63.00 72.70 6 40.00 48.00 22.00 6.00 A 0.51
S865 FSN D063-08-22-R13 (1)
63.00 72.70 8 40.00 48.00 22.00 6.00 A 0.50
S865 FSN D080-07-27-R13
80.00 89.70 7 50.00 60.00 27.00 6.00 B 0.92
S865 FSN D080-10-27-R13 (1)
80.00 89.70 10 50.00 60.00 27.00 6.00 B 0.93
S865 FSN D100-08-32-R13
100.00 109.70 8 50.00 70.00 32.00 6.00 B 1.37
S865 FSN D100-12-32-R13 (1)
100.00 109.70 12 50.00 70.00 32.00 6.00 B 1.37
S865 FSN D125-10-40-R13
125.00 134.70 10 63.00 82.00 40.00 6.00 B 2.58
S865 FSN D125-16-40-R13 (1)
125.00 134.70 16 63.00 82.00 40.00 6.00 B 2.59
• For user guide, see pages 542-547
(1) Fine pitch
(2) Cutting diameter maximum
(3) Number of inserts
(4) Depth of cut on steel with coarse pitch cutters and on cast iron with fine pitch cutters may be increased to 8 mm.
(5) For adaptation options, see page 548
For inserts, see pages: S865 SNMU 1305ZNTR (503)
APMX=8 mm
65°
Spare Parts
Designation
S865 FSN D050-04-22-R13
SR 11800745 BLD IP15/S7 SW6-T-SH SR M10X20DIN912
S865 FSN D050-06-22-R13
SR 11800745 BLD IP15/S7 SW6-T-SH SR M10X20DIN912
S865 FSN D063-06-22-R13
SR 11800745 BLD IP15/S7 SW6-T-SH SR M10X20DIN912
S865 FSN D063-08-22-R13
SR 11800745 BLD IP15/S7 SW6-T-SH SR M10X20DIN912
S865 FSN D080-07-27-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S865 FSN D080-10-27-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S865 FSN D100-08-32-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S865 FSN D100-12-32-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S865 FSN D125-10-40-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S865 FSN D125-16-40-R13
SR 11800745 BLD IP15/S7 SW6-T-SH
S865 FSN-13
65° Face Mills Carrying Inserts
with 8 Cutting Edges
ISCAR
218
FACE MILLS
DCONMS
OAL OAL_3
OAL_2
42° 42°
2.50
DC
DCX DC_3
DCX_3
DC_2
DCX_2 8.05.5
A B C
Rd°
Designation
DC DCX(1) OAL RMPX°(2) DC_2 DCX_2 OAL_2 RMPX°_2 DC_3 DCX_3 OAL_3 RMPX°_3 DCONMS CICT(3)
kg
HOE D32-03-W32-R06
32.00 41.40 95.00 5.9 29.40 44.10 96.2 9.0 26.80 42.70 95.50 7.6 32.00 3 0.54
HOE D40-04-W40-R06
40.00 49.40 115.00 5.0 37.40 52.10 116.2 6.8 34.80 50.70 115.50 5.0 40.00 4 1.09
HOE D50-04-W40-R06
50.00 59.40 115.00 4.2 47.40 62.10 116.2 5.0 44.80 60.70 115.50 5.7 40.00 4 1.23
• A - with OEM. 060405... insert • B - with SECT/SEMT 1404... insert • C - with REM. 1505... round insert
(1) Cutting diameter maximum
(2) Maximum ramping angle
(3) Number of inserts
For inserts, see pages: OECR (505) • OEMT/OEKT 060405 (506) • OEMW-AETN (506) • REMT-76 (527) • SECT/SEMT 1404 (512)
Spare Parts
Designation
HOE D32-03-W32-R06
SR 14-544/S BLD T15/S7 SW6-T-SH
HOE D40-04-W40-R06
SR 14-544/S BLD T15/S7 SW6-T-SH
HOE D50-04-W40-R06
SR 14-544 BLD T15/S7 SW6-T-SH
HOE-R06
Endmills Carrying Octagonal,
Square and Round Inserts
DCX
DC
DCONMS
OAL OAL_2
42° 42°
2.5 5.5
DHUB
DC_2
DCX_2
DC_3
DCX_3
8.0
OAL_3
A B C
Rd°
Designation
DC DCX(1) OAL RMPX°(2) DC_2 DCX_2 OAL_2 RMPX°_2 DC_3 DCX_3 OAL_3 RMPX°_3 CICT(3) DHUB DCONMS Arbor(4)
kg
HOF D040-04-22-R06
40.00 49.40 40.00 5.0 37.40 52.10 41.2 6.8 34.80 50.70 40.50 5.0 4 48.00 22.00 A 0.33
HOF D050-04-22-R06
50.00 59.40 40.00 4.2 47.40 62.10 41.2 5.0 44.80 60.70 40.50 5.7 4 48.00 22.00 A 0.44
HOF D063-05-22-R06
63.00 72.40 40.00 3.2 60.40 75.10 41.2 4.0 57.80 73.70 40.50 4.0 5 52.00 22.00 A 0.58
HOF D080-06-27-R06
80.00 89.40 50.00 2.5 77.40 92.10 51.2 3.0 74.80 90.70 50.50 3.0 6 60.00 27.00 B 1.13
HOF D100-07-32-R06
100.00 109.40 50.00 1.9 97.40 112.10 51.2 2.3 94.80 110.70 50.50 2.2 7 70.00 32.00 B 1.65
HOF D125-08-40-R06
125.00 134.40 63.00 1.4 122.40 137.10 64.2 1.8 119.80 135.70 63.50 1.6 8 82.00 40.00 B 3.19
• A - with OEM. 060405...\ OECR 06.. inserts • B - with SECT/SEMT 1404... inserts • C - with REM. 1505... round insert
(1) Cutting diameter maximum
(2) Maximum ramping angle
(3) Number of inserts
(4) For adaptation options, see page 548
For inserts, see pages: OECR (505) • OEMT/OEKT 060405 (506) • OEMW-AETN (506) • REMT-76 (527) • SECT/SEMT 1404 (512)
Spare Parts
Designation
HOF D040-04-22-R06
SR 14-544/S BLD T15/S7 SW6-T-SH SR M10X25DIN7984
HOF D050-04-22-R06
SR 14-544 BLD T15/S7 SW6-T-SH SR M10X25 DIN912
HOF D063-05-22-R06
SR 14-544 BLD T15/S7 SW6-T-SH SR M10X25 DIN912
HOF D080-06-27-R06
SR 14-544 BLD T15/M7 SW6-T-SH
HOF D100-07-32-R06
SR 14-544 BLD T15/M7 SW6-T-SH
HOF D125-08-40-R06
SR 14-544 BLD T15/M7 SW6-T-SH
HOF-R06
Face Mills Carrying Octagonal
or Square or Round Inserts
219
FACE MILLS
DCONMS
DHUB OFMW FF
DCX
OAL
DC
42°
OAL_2
DCX_2
DC_2
RF..1905
OF.. 07..
DCX_3
DC_3
9.8
4.6 max 2.2 max
OAL_3
Rd°
Designation
DC DCX(2) OAL RMPX°(3) DCX_2 DC_2 OAL_2 RMPX°_2(4) DC_3 DCX_3 OAL_3 RMPX°_3(5) CICT(6) DHUB DCONMS Arbor(7)
kg
HOF D050-03-22-R07
50.00 62.50 40.00 6.5 63.30 43.56 40.50 9.0 44.80 64.00 40.60 9.0 3 48.00 22.00 A 0.30
HOF D063-04-22-R07
63.00 75.50 40.00 5.0 76.30 56.56 40.50 6.0 57.80 77.00 40.60 6.0 4 48.00 22.00 A 0.48
HOF D080-05-27-R07 (1)
80.00 92.50 50.00 3.5 93.30 73.56 50.50 4.5 92.50 94.00 50.60 4.5 5 60.00 27.00 B 0.91
HOF D100-06-32-R07 (1)
100.00 112.50 50.00 2.5 113.30 93.56 50.50 3.0 94.80 114.00 50.60 3.0 6 70.00 32.00 B 1.33
HOF D125-08-40-R07 (1)
125.00 137.50 63.00 2.5 138.30 118.56 63.50 2.5 119.80 139.00 63.60 2.5 8 82.00 40.00 B 2.70
HOF D160-10-40-R07
160.00 172.50 63.00 1.9 173.30 153.56 63.50 1.9 154.80 174.00 63.60 - 10 92.00 40.00 C 3.83
HOF D200-12-60-R07
200.00 212.50 63.00 1.5 213.30 193.56 63.50 1.5 194.80 214.00 63.60 - 12 150.00 60.00 C 7.03
HOF D250-15-60-R07
250.00 262.50 63.00 1.2 263.30 243.56 63.50 1.2 244.80 264.00 63.60 - 15 150.00 60.00 C 10.08
HOF D315-18-60-R07
315.00 327.50 80.00 0.9 328.30 308.56 80.50 0.9 309.80 329.00 80.60 - 18 215.00 60.00 C 21.00
• Helical interpolation is applicable up to and including 100 mm diameter • For user guide, see pages 542-547
(1) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(2) Cutting diameter maximum
(3) Maximum ramping angle with OF..07.. inserts
(4) Dimensions with RF.. 1905 round inserts
(5) Dimensions with OFMW FF inserts
(6) Number of inserts
(7) For adaptation options, see page 548
For inserts, see pages: OFCR/OFCT-AEN/AETN (507) • OFCR/OFCT-RW/AER (wiper) (508) • OFMT 07 (506) • OFMW-AETN (507) • OFMW-FF (508)
• RFMT 1905-76 (529)
Spare Parts
Designation
HOF D050-03-22-R07
SR 14-591/H BLD T20/S7 SW6-T THOF-07R SR M2.5X8 DIN912 TUFLOK HW 2.0 SR M10X25 DIN912
HOF D063-04-22-R07
SR 14-591/H BLD T20/S7 SW6-T THOF-07R SR M2.5X10 DIN912 TUFLOK HW 2.0 SR M10X25 DIN912
HOF D080-05-27-R07
SR 14-591/H BLD T20/S7 SW6-T THOF-07R SR M2.5X8 DIN912 TUFLOK HW 2.0
HOF D100-06-32-R07
SR 14-591/H BLD T20/M7 SW6-T THOF-07R SR M2.5X10 DIN912 TUFLOK HW 2.0
HOF D125-08-40-R07
SR 14-591/H BLD T20/M7 SW6-T THOF-07R SR M2.5X10 DIN912 TUFLOK HW 2.0
HOF D160-10-40-R07
SR 14-591/H BLD T20/L7 SW6-T THOF-07R SR M2.5X10 DIN912 TUFLOK HW 2.0
HOF D200-12-60-R07
SR 14-591/H BLD T20/L7 SW6-T THOF-07R SR M2.5X10 DIN912 TUFLOK HW 2.0
HOF D250-15-60-R07
SR 14-591/H BLD T20/L7 SW6-T THOF-07R SR M2.5X10 DIN912 TUFLOK HW 2.0
HOF D315-18-60-R07
SR 14-591/H BLD T20/L7 SW6-T THOF-07R SR M2.5X10 DIN912 TUFLOK HW 2.0
HOF-R07
Face Mills Carrying Octagonal
Round and Fast Feed
Segmented Radius Inserts
APMX
DCONMS
OAL
LH
DC
DCX
Designation
DC DCX(1) CICT(2) APMX OAL LH DCONMS Shank(3)
kg
IQ845 ESY D016-03-W20-R05
16.00 21.40 3 2.60 85.00 26.0 20.00 W 0.16 SR M2.5X6-T7-60 T-7/51
IQ845 ESY D020-03-W20-R05
20.00 25.50 3 2.60 90.00 26.0 20.00 W 0.19 SR M2.5X6-T7-60 T-7/51
IQ845 ESY D025-03-W25-R05
25.00 30.60 3 2.60 95.00 26.0 25.00 W 0.32 SR M2.5X6-T7-60 T-7/51
IQ845 ESY D025-04-W25-R05
25.00 30.60 4 2.60 95.00 26.0 25.00 W 0.31 SR M2.5X6-T7-60 T-7/51
IQ845 ESY D032-04-W32-R05
32.00 37.70 4 2.60 100.00 26.0 32.00 W 0.56 SR M2.5X6-T7-60 T-7/51
IQ845 ESY D032-05-W32-R05
32.00 37.70 5 2.60 100.00 26.0 32.00 W 0.56 SR M2.5X6-T7-60 T-7/51
IQ845 ESY D040-05-W40-R05
40.00 45.70 5 2.60 110.00 26.0 40.00 W 0.97 SR M2.5X6-T7-60 T-7/51
IQ845 ESY D040-06-W40-R05
40.00 45.70 6 2.60 110.00 26.0 40.00 W 1.05 SR M2.5X6-T7-60 T-7/51
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) W-Weldon
For inserts, see pages: IQ845 SYHU-05 (499)
IQ845 ESY-R05
50° Endmills Carrying Square
Inserts with 8 Cutting Edges
ISCAR
220
FACE MILLS
DCONMS
OAL
50°
APMX
DHUB
DCX
DC
Designation
DC DCX(1) CICT(2) APMX OAL DHUB DCONMS Arbor(3)
kg
IQ845 FSY D040-04-16-R05
40.00 45.70 4 2.60 40.00 38.00 16.00 A 0.28 SR M8X25DIN912 SR M2.5X6-T7-60 T-7/51
IQ845 FSY D040-07-16-R05
40.00 45.70 7 2.60 40.00 38.00 16.00 A 0.26 SR M8X25DIN912 SR M2.5X6-T7-60 T-7/51
IQ845 FSY D050-05-22-R05
50.00 55.80 5 2.60 40.00 48.00 22.00 A 0.44 SR M10X20DIN912 SR M2.5X6-T7-60 T-7/51
IQ845 FSY D050-09-22-R05
50.00 55.80 9 2.60 40.00 48.00 22.00 A 0.41 SR M10X20DIN912 SR M2.5X6-T7-60 T-7/51
IQ845 FSY D063-07-22-R05
63.00 68.80 7 2.60 40.00 48.00 22.00 B 0.57 SR M10X20DIN912 SR M2.5X6-T7-60 T-7/51
IQ845 FSY D063-11-22-R05
63.00 68.80 11 2.60 40.00 48.00 22.00 B 0.55 SR M10X20DIN912 SR M2.5X6-T7-60 T-7/51
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) For adaptation options, see page 548
For inserts, see pages: IQ845 SYHU-05 (499)
IQ845 FSY-R05
50° Face Mills Carrying Square
Inserts with 8 Cutting Edges
OAL
DC
DCX
APMX
44.3°
DCONMS
DHUB
Designation
DC DCX(2) CICT(3) APMX OAL DHUB DCONMS Arbor(4)
kg
F45WG D080-10-27-FX-R08 (1)
80.00 92.00 10 5.50 50.00 60.00 27.00 B 1.11
F45WG D100-14-32-FX-R08 (1)
100.00 112.00 14 5.50 50.00 70.00 32.00 B 1.64
F45WG D125-18-40-FX-R08 (1)
125.00 137.00 18 5.50 63.00 82.00 40.00 B 3.00
F45WG D160-22-40-FX-R08
160.00 172.00 22 5.50 63.00 92.00 40.00 C 4.58
• Note: Recommended wedge clamping torque: 8.5-9.0 Nxm • For user guide, see pages 542-547
(1) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(2) Cutting diameter maximum
(3) Number of inserts
(4) For adaptation options, see page 548
For inserts, see pages: ONHQ-TN (498) • ONHU 0806-N-PL (499) • ONHU 0806AN-W (499) • ONHU/ONMU 080608 AN-N-HP (499) • ONHU/ONMU-08-TN-MM (498)
• ONHU/ONMU-08-TN/HL (498)
Mounting instructions have been included in each insert
package in order to avoid incorrect clamping orientation.
Only correct mounting will provide high surface finish!
Wiper inserts are used on face mill cutters, providing improved surface finish
and thus eliminating the use of other finishing cutters.
ONHU 0806AN-14R-W mounted on F45WG and F45NM milling
cutters. This insert provides 4 right-hand wiper edges.
Wiper Inserts
Mounting of Wiper Insert on
Face Mills
W1
W2
W1
W2
W1
W2
W1
W2
ONHU 0806AN-14R-W
Spare Parts
Designation
F45WG
SR 118-069 BLD IP20/S7 SW6-T LW 35-475/M
F45WG
45° Face Mills Carrying
Octagonal ONHU/MU 0806...
Inserts with 16 Cutting Edges
221
FACE MILLS
OAL
DC
DCX
DCONMS
DHUB
APMX
44.3°
Designation
DC DCX(2) CICT(3) APMX OAL DHUB DCONMS Arbor(4)
kg
F45NM D063-05-22-R08
63.00 75.00 5 5.50 40.00 48.00 22.00 A 0.46
F45NM D080-06-27-R08 (1)
80.00 92.00 6 5.50 50.00 60.00 27.00 B 0.95
F45NM D080-08-27-R08 (1)
80.00 92.00 8 5.50 50.00 60.00 27.00 B 0.92
F45NM D100-07-32-R08 (1)
100.00 112.00 7 5.50 50.00 70.00 32.00 B 1.40
F45NM D100-10-32-R08 (1)
100.00 112.00 10 5.50 50.00 70.00 32.00 B 1.39
F45NM D125-08-40-R08 (1)
125.00 137.00 8 5.50 63.00 82.00 40.00 B 2.68
F45NM D125-12-40-R08 (1)
125.00 137.00 12 5.50 63.00 82.00 40.00 B 2.63
F45NM D160-10-40-R08
160.00 172.00 10 5.50 63.00 92.00 40.00 C 4.10
F45NM D160-15-40-R08
160.00 172.00 15 5.50 63.00 92.00 40.00 C 4.17
F45NM D200-12-60-R08
200.00 212.00 12 5.50 63.00 150.00 60.00 C 7.12
F45NM D250-14-60-R08
250.00 262.00 14 5.50 63.00 137.00 60.00 C 8.95
• Wiper inserts are used on face mill cutters, providing improved surface finish, thus eliminating the use of other finishing cutters
• For user guide, see pages 542-547
(1) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(2) Cutting diameter maximum
(3) Number of inserts
(4) For adaptation options, see page 548
For inserts, see pages: ONHQ-TN (515) • ONHU 0806-N-PL (516) • ONHU 0806AN-W (516) • ONHU/ONMU 080608 AN-N-HP (516) • ONHU/ONMU-08-TN-MM (515)
• ONHU/ONMU-08-TN/HL (515)
Spare Parts
Designation
F45NM D063-05-22-R08
SR 14-591/H BLD T20/S7 SW6-T SR M10X25 DIN912
F45NM D080-06-27-R08
SR 14-591/H BLD T20/S7 SW6-T
F45NM D080-08-27-R08
SR 11800771 BLD IP15/S7 SW6-T-SH
F45NM D100-07-32-R08
SR 14-591/H BLD T20/S7 SW6-T
F45NM D100-10-32-R08
SR 11800771 BLD IP15/S7 SW6-T-SH
F45NM D125-08-40-R08
SR 14-591/H BLD T20/S7 SW6-T
F45NM D125-12-40-R08
SR 11800771 BLD IP15/S7 SW6-T-SH
F45NM D160-10-40-R08
SR 14-591/H BLD T20/L7 SW6-T
F45NM D160-15-40-R08
SR 11800771 BLD IP15/M7 SW6-T-SH
F45NM D200-12-60-R08
SR 14-591/H BLD T20/L7 SW6-T
F45NM D250-14-60-R08
SR 14-591/H BLD T20/L7 SW6-T
F45NM
45° Face Mills Carrying
Octagonal ONHU/MU 0806...
Inserts with 16 Cutting Edges
ISCAR
222
FACE MILLS
OAL
BD
DCX
DC APMX
44˚
DCONMS
DHUB
OAL_2
DC_2
DCX_2
APMX_2
44˚
15˚
45˚
OAL_3
DCX_3
DC_3 APMX_3
OAL_4 OAL_5
D4
DC_4
DCX_4
DC_5
DCX_5
APMX_4 APMX_5
1
2 3 4 5
Rd°
SOF45
Multifunction Face Mills for
Octagonal, Square and
Round Insert Contours with
Various Entry Angles
• 1- with ONMU 0505... insert • 2- with S845 SNMU 1305... insert • 3- with RXMT 1607N insert • 4- with OXMT 0507R08-FF insert
• 5- with OXMT 050705-R-HP insert • Use only Torx Plus keys • For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) Valid only with RXMT 1607N insert
(4) For adaptation options, see page 548
(5) 0 - Without coolant supply, 1 - With coolant supply
(6) Master insert identification
(7) Master insert identification 2
(8) Master insert identification 3
(9) Master insert identification 4
(10) Master insert identification 5
For inserts, see pages: ONHU 0505-W (505) • ONHU/ONMU-05 (504) • OXMT 0507 (505) • RXMT 1607 (527) • S845 SNHU 1305-W (501)
• S845 SNMU/SNHU-13 (500)
Designation
DC DCX(1) DC_2 DC_3 DCX_3 DC_4 DCX_4 BD_4 DC_5 APMX APMX_2 APMX_3 APMX_4 APMX_5
SOF45 8/16-D040-04-22R
40.00 50.40 37.65 35.40 51.20 34.50 44.00 50.50 40.30 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D050-03-22R
50.00 60.40 47.65 45.40 61.20 44.50 54.00 60.50 50.30 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D050-04-22R
50.00 60.40 47.65 45.40 61.20 44.50 54.00 60.50 50.30 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D050-06-22R
50.00 60.40 47.65 45.40 61.20 44.50 54.00 60.50 50.30 3.50 6.00 7.90 1.20 2.90
SOF45 D050-04-22-R13
52.35 62.70 50.00 47.75 63.55 46.95 56.35 62.90 52.65 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D063-04-22R
63.00 73.40 60.65 58.40 74.20 57.50 67.00 73.50 63.30 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D063-06-22R
63.00 73.40 60.65 58.40 74.20 57.50 67.00 73.50 63.30 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D063-08-22R
63.00 73.40 60.65 58.40 74.20 57.50 67.00 73.50 63.30 3.50 6.00 7.90 1.20 2.90
SOF45 D063-06-22-R13
65.35 75.70 63.00 60.75 76.55 59.95 69.35 75.90 63.65 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D080-07-27R
80.00 90.40 77.65 65.40 91.20 74.50 84.00 90.50 80.30 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D080-10-27R
80.00 90.40 77.65 65.40 91.20 74.50 84.00 90.50 80.30 3.50 6.00 7.90 1.20 2.90
SOF45 D080-07-27-R13
82.35 92.70 80.00 77.60 93.40 76.95 86.35 92.90 82.65 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D100-08-32R
100.00 110.40 97.65 95.40 111.20 94.50 104.00 110.50 100.30 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D100-12-32R
100.00 110.40 97.65 95.40 111.20 94.50 104.00 110.50 100.30 3.50 6.00 7.90 1.20 2.90
SOF45 D100-08-32-R13
102.35 112.70 100.00 97.75 113.55 96.95 106.35 112.90 102.65 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D125-10-40R
125.00 135.40 122.65 120.40 136.20 119.50 129.00 135.50 125.30 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D125-16-40R
125.00 135.40 122.65 120.40 136.20 119.50 129.00 135.50 125.30 3.50 6.00 7.90 1.20 2.90
SOF45 D125-10-40-R13
127.35 137.70 125.00 122.75 138.55 121.95 131.35 137.90 127.65 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D160-12-40R
160.00 170.40 157.65 155.40 171.20 154.50 164.00 171.50 160.30 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D200-14-60R
200.00 210.40 197.65 195.40 211.20 194.50 204.00 211.50 200.50 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D250-16-60R
250.00 260.40 247.65 245.40 261.20 244.50 254.00 261.50 250.30 3.50 6.00 7.90 1.20 2.90
SOF45 8/16-D315-20-60R
315.00 329.40 312.65 310.40 326.20 309.50 319.00 326.50 315.30 3.50 6.00 7.90 1.20 2.90
Designation
OAL OAL_2 OAL_3 OAL_4 OAL_5 CICT(2) DHUB DCONMS RMPX°_3(3) Arbor(4) CSP(5)
kg
SOF45 8/16-D040-04-22R
40.00 41.2 41.60 41.30 41.20 4 45.00 22.00 3.7 A 1 0.29
SOF45 8/16-D050-03-22R
40.00 41.2 41.60 41.30 41.20 3 48.00 22.00 5.6 A 1 0.38
SOF45 8/16-D050-04-22R
40.00 41.2 41.60 41.30 41.20 4 48.00 22.00 5.6 A 1 0.39
SOF45 8/16-D050-06-22R
40.00 41.2 41.60 41.30 41.20 6 48.00 22.00 5.6 A 1 0.38
SOF45 D050-04-22-R13
38.80 40.0 40.40 40.10 40.20 4 48.00 22.00 5.4 A 1 0.38
SOF45 8/16-D063-04-22R
40.00 41.2 41.60 41.30 41.20 4 48.00 22.00 6.3 A 1 0.54
SOF45 8/16-D063-06-22R
40.00 41.2 41.60 41.30 41.20 6 48.00 22.00 6.3 B 0 0.47
SOF45 8/16-D063-08-22R
40.00 41.2 41.60 41.30 41.20 8 48.00 22.00 6.3 B 0 0.46
SOF45 D063-06-22-R13
38.80 40.0 40.40 40.10 40.20 6 48.00 22.00 5.7 B 1 0.50
SOF45 8/16-D080-07-27R
50.00 51.2 51.60 51.30 51.20 7 60.00 27.00 6.2 B 0 1.01
SOF45 8/16-D080-10-27R
50.00 51.2 51.60 51.30 51.20 10 60.00 27.00 6.2 B 0 0.96
SOF45 D080-07-27-R13
48.80 50.0 50.40 50.10 50.20 7 60.00 27.00 6.0 B 1 1.00
SOF45 8/16-D100-08-32R
50.00 51.2 51.60 51.30 51.20 8 70.00 32.00 4.7 B 0 1.39
SOF45 8/16-D100-12-32R
50.00 51.2 51.60 51.30 51.20 12 70.00 32.00 4.7 B 0 1.35
SOF45 D100-08-32-R13
48.80 50.0 50.40 50.10 50.00 8 70.00 32.00 4.6 B 1 1.47
SOF45 8/16-D125-10-40R
63.00 64.2 64.60 64.30 64.20 10 82.00 40.00 3.6 B 0 2.63
SOF45 8/16-D125-16-40R
63.00 64.2 64.60 64.30 64.20 16 82.00 40.00 3.6 B 0 2.53
SOF45 D125-10-40-R13
61.80 63.0 63.40 63.10 63.20 10 82.00 40.00 3.5 B 1 2.63
SOF45 8/16-D160-12-40R
63.00 64.2 64.60 64.30 64.20 12 92.00 40.00 2.6 C 0 3.35
SOF45 8/16-D200-14-60R
63.00 64.2 64.60 64.30 64.20 14 135.00 60.00 2.0 C 0 5.77
SOF45 8/16-D250-16-60R
63.00 64.2 64.60 64.30 64.20 16 137.00 60.00 1.5 C 0 7.98
SOF45 8/16-D315-20-60R
80.00 81.2 81.60 81.30 81.20 20 222.00 60.00 1.0 C 0 18.97
223
FACE MILLS
OAL
BD
DCX
DC APMX
44˚
DCONMS
DHUB
OAL_2
DC_2
DCX_2
APMX_2
44˚
15˚
45˚
OAL_3
DCX_3
DC_3 APMX_3
OAL_4 OAL_5
D4
DC_4
DCX_4
DC_5
DCX_5
APMX_4 APMX_5
1
2 3 4 5
Rd°
SOF45
Multifunction Face Mills for
Octagonal, Square and
Round Insert Contours with
Various Entry Angles
• 1- with ONMU 0505... insert • 2- with S845 SNMU 1305... insert • 3- with RXMT 1607N insert • 4- with OXMT 0507R08-FF insert
• 5- with OXMT 050705-R-HP insert • Use only Torx Plus keys • For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) Valid only with RXMT 1607N insert
(4) For adaptation options, see page 548
(5) 0 - Without coolant supply, 1 - With coolant supply
(6) Master insert identification
(7) Master insert identification 2
(8) Master insert identification 3
(9) Master insert identification 4
(10) Master insert identification 5
For inserts, see pages: ONHU 0505-W (505) • ONHU/ONMU-05 (504) • OXMT 0507 (505) • RXMT 1607 (527) • S845 SNHU 1305-W (501)
• S845 SNMU/SNHU-13 (500)
Designation
MIID(6) MIID_2(7) MIID_3(8) MIID_4(9) MIID_5(10)
SOF45 8/16-D040-04-22R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D050-03-22R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D050-04-22R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D050-06-22R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 D050-04-22-R13
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D063-04-22R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D063-06-22R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D063-08-22R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 D063-06-22-R13
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D080-07-27R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D080-10-27R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 D080-07-27-R13
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D100-08-32R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D100-12-32R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 D100-08-32-R13
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D125-10-40R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D125-16-40R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 D125-10-40-R13
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D160-12-40R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D200-14-60R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D250-16-60R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
SOF45 8/16-D315-20-60R
ONHU 050500-PL S845 SNHU 1305ANR-M RXMT 1607N OXMT 0507R08-FF OXMT 050705-R-HP
(a) IMPORTANT: Use only Torx Plus keys.
Spare Parts
Designation
SOF45 8/16-D040-04-22R
SR 11800745 BLD IP15/S7(a) SW6-T-SH SR M10X25 DIN912
SOF45 8/16-D050-03-22R
SR 11800745 BLD IP15/S7(a) SW6-T-SH SR M10X20DIN912
SOF45 8/16-D050-04-22R
SR 11800745 BLD IP15/S7(a) SW6-T-SH SR M10X20DIN912
SOF45 8/16-D050-06-22R
SR 11800745 BLD IP15/S7(a) SW6-T-SH SR M10X20DIN912
SOF45 D050-04-22-R13
SR 11800745 BLD IP15/S7(a) SW6-T-SH SR M10X20DIN912
SOF45 8/16-D063-04-22R
SR 11800745 BLD IP15/S7(a) SW6-T-SH SR M10X25 DIN912
SOF45 8/16-D063-06-22R
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 8/16-D063-08-22R
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 D063-06-22-R13
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 8/16-D080-07-27R
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 8/16-D080-10-27R
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 D080-07-27-R13
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 8/16-D100-08-32R
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 8/16-D100-12-32R
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 D100-08-32-R13
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 8/16-D125-10-40R
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 8/16-D125-16-40R
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 D125-10-40-R13
SR 11800745 BLD IP15/S7(a) SW6-T-SH
SOF45 8/16-D160-12-40R
SR 11800745 BLD IP15/M7(a) SW6-T-SH
SOF45 8/16-D200-14-60R
SR 11800745 BLD IP15/M7(a) SW6-T-SH
SOF45 8/16-D250-16-60R
SR 11800745 BLD IP15/M7(a) SW6-T-SH
SOF45 8/16-D315-20-60R
SR 11800745 BLD IP15/M7(a) SW6-T-SH
ISCAR
224
USER GUIDE
FACE MILLS
Wiper Inserts
Wiper inserts are used on face mill cutters, providing improved surface finish
and thus eliminating the use of other finishing cutters.
• ONHU 0505AN-R-W mounted on standard SOF45 milling cutters. This insert provides
8 right-hand wiper edges.
• ONHU 0505AN-N-W mounted on SOF45 milling cutters. This insert provides 4 right-hand wiper edges to be
used on standard tools and 4 left-hand wiper edges to be used on special left-hand SOF45 cutters.
3377
Mounting of Wiper Insert on
Face Mills
77
33
ONHU 0505AN-N-W
ONHU 0505AN-R-W
Mount on SOF45 8/16...Cutters
• S845 SNHU 1305AN-N-W mounted on SOF45 milling cutters when the square S845 SNMU/HU 1305AN...
inserts are used. This insert provides 2 right-hand and 2 left-hand wiper edges.
Mounting of Wiper Insert on
Face Mills
77
33
S845 SNHU 1305AN-N-W
Mount on SOF45 8/16...Cutters
225
FACE MILLS
DCONMS
DCX
OAL
DC
DHUB
45°
APMX
Designation
DC DCX(2) CICT(3) APMX OAL DHUB DCONMS Arbor(4)
kg
F45ST D040-22
40.00 50.00 3 6.50 40.00 44.00 22.00 A 0.30
F45ST D050-22
50.00 62.70 4 6.50 40.00 41.80 22.00 A 0.35
F45ST D063-22
63.00 75.00 5 6.50 40.00 50.00 22.00 A 0.57
F45ST D080-27 (1)
80.00 90.90 6 6.50 50.00 63.00 27.00 B 1.08
F45ST D100-32 (1)
100.00 110.00 6 6.50 50.00 72.00 32.00 B 1.61
F45ST D125-40 (1)
125.00 135.00 7 6.50 62.50 75.00 40.00 B 2.70
F45ST D160-40 (1)
160.00 170.70 7 6.50 63.00 92.00 40.00 C 4.06
• SE..1204 inserts are mounted directly on the cutter • SE..12T3 optional thinner inserts are mounted on a seat - TSE 12T3-N
• For user guide, see pages 542-547
(1) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(2) Cutting diameter maximum
(3) Number of inserts
(4) For adaptation options, see page 548
For inserts, see pages: SEHT-AFN (511) • SEHW-AFTN (510) • SEKT-AF-R (510) • SEKT-AFTN (510) • SEMT 12..AFTN-76 (511) • SEMT 1204AF-R-HS (510)
Spare Parts
Designation
F45ST D040-22
SR 14-536/S BLD T20/M7 SW6-T SR M10X25DIN7984 HW 7.0
F45ST D050-22
SR 34-523 BLD T15/M7 SW6-T SR M10X25DIN7984 HW 7.0 SR 14-601* TSE 12T3-N(a)*SR TC-606(a)*HW 3.5(a)*
F45ST D063-22
SR 34-523 BLD T15/M7 SW6-T SR M10X25DIN7984 HW 7.0 SR 14-601* TSE 12T3-N(a)*SR TC-606(a)*HW 3.5(a)*
F45ST D080-27
SR 34-523 BLD T15/M7 SW6-T SR 14-601* TSE 12T3-N(a)*SR TC-606(a)*HW 3.5(a)*
F45ST D100-32
SR 34-523 BLD T15/M7 SW6-T SR 14-601* TSE 12T3-N(a)*SR TC-606(a)*
F45ST D125-40
SR 34-523 BLD T15/M7 SW6-T SR 14-601* TSE 12T3-N(a)*SR TC-606(a)*HW 3.5(a)*
F45ST D160-40
SR 34-523 BLD T15/M7 SW6-T SR 14-601* TSE 12T3-N(a)*SR TC-606(a)*HW 3.5(a)*
* Optional, should be ordered separately
(a) Optional for insert SE..12T3
F45ST
45° Screw Clamped Face Mills
Carrying SEK/MT 12... Inserts
DCONMS
DHUB
APMX
DC
BD
45° OAL
Designation
DC BD APMX CICT(2) OAL DHUB DCONMS Arbor(3)
kg
F45E D 50-22
50.00 67.30 6.50 4 43.00 42.00 22.00 A 0.59
F45E D 63-22
63.00 81.20 6.50 5 40.00 42.50 22.00 A 0.81
F45E D 80-27 (1)
80.00 98.20 6.50 6 50.00 63.00 27.00 B 1.43
F45E D100-32 (1)
100.00 118.00 6.50 6 50.00 72.00 32.00 B 2.31
F45E D125-40 (1)
125.00 143.00 6.50 6 63.00 75.00 40.00 B 3.40
F45E D160-40
160.00 178.00 6.50 8 63.00 92.00 40.00 C 5.28
• For user guide, see pages 542-547
(1) For internal coolant through the holder, use a matching coolant set (should be ordered separately)
(2) Number of inserts
(3) For adaptation options, see page 548
For inserts, see pages: SEKN-AF.. (511) • SEKR-AF-N-42 (512) • SEKR-AF..-76 (512) • SEKR-AFTR-HS (512)
Spare Parts
Designation
F45E D 50-22
NSE 42-R SR 35-343.4 HW 2.0 LW 35-2620-S SR 35-2011 HW 3P SR M10X25DIN7984 HW 7.0
F45E D 63-22
NSE 42-R SR 35-343.4 HW 2.0 LW 35-2620-S SR 35-2011 HW 3P SR M10X25DIN7984 HW 7.0
F45E D 80-27
NSE 42-R SR 35-343.4 HW 2.0 LW 35-2620-S SR 35-2011 HW 3P
F45E D100-32
NSE 42-R SR 35-343.4 HW 2.0 LW 35-2620-S SR 35-2011 HW 3P
F45E D125-40
NSE 42-R SR 35-343.4 HW 2.0 LW 35-2620-S SR 35-2011 HW 3P
F45E D160-40
NSE 42-R SR 35-343.4 HW 2.0 LW 35-2620-S SR 35-2011 HW 3P
F45E
45° Face Mills Carrying
SEKN/R 12... Inserts
ISCAR
226
FACE MILLS
DCONMS
OAL
50°
APMX
DHUB
DCX
DC
Designation
DC DCX(1) CICT(2) APMX OAL DHUB DCONMS Arbor(3) CSP(4)
kg
IQ845 FSY D050-04-22-R07
50.00 59.40 4 4.60 40.00 48.00 22.00 A 1 0.39
IQ845 FSY D050-05-22-R07
50.00 59.40 5 4.60 40.00 48.00 22.00 A 1 0.38
IQ845 FSY D063-05-22-R07
63.00 72.40 5 4.60 40.00 48.00 22.00 A 1 0.51
IQ845 FSY D063-07-22-R07
63.00 72.40 7 4.60 40.00 48.00 22.00 A 1 0.47
IQ845 FSY D080-06-27-R07
80.00 89.40 6 4.60 50.00 60.00 27.00 B 1 1.00
IQ845 FSY D080-08-27-R07
80.00 89.40 8 4.60 50.00 60.00 27.00 B 1 0.95
IQ845 FSY D100-07-32-R07
100.00 109.40 7 4.60 50.00 70.00 32.00 B 1 1.36
IQ845 FSY D100-10-32-R07
100.00 109.40 10 4.60 50.00 70.00 32.00 B 1 1.34
IQ845 FSY D125-09-40-R07
125.00 134.40 9 4.60 63.00 82.00 40.00 B 1 2.52
IQ845 FSY D125-12-40-R07
125.00 134.40 12 4.60 63.00 82.00 40.00 B 1 2.49
IQ845 FSY D160-11-40-R07
160.00 169.40 11 4.60 63.00 92.00 40.00 C 0 3.31
IQ845 FSY D160-15-40-R07
160.00 169.40 15 4.60 63.00 92.00 40.00 C 0 3.28
IQ845 FSY D200-14-60-R07
200.00 209.40 14 4.60 63.00 135.00 60.00 C 0 5.80
IQ845 FSY D250-17-60-R07
250.00 259.40 17 4.60 63.00 135.00 60.00 C 0 8.18
IQ845 FSY D315-20-60-R07
315.00 324.40 20 4.60 80.00 220.00 60.00 D 0 16.87
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) For adaptation options, see page 548
(4) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: IQ845 SYHU-07 (499)
Spare Parts
Designation
IQ845 FSY D050-04-22-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH SR M10X20DIN912
IQ845 FSY D050-05-22-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH SR M10X20DIN912
IQ845 FSY D063-05-22-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
IQ845 FSY D063-07-22-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
IQ845 FSY D080-06-27-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
IQ845 FSY D080-08-27-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
IQ845 FSY D100-07-32-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
IQ845 FSY D100-10-32-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
IQ845 FSY D125-09-40-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
IQ845 FSY D125-12-40-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
IQ845 FSY D160-11-40-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
IQ845 FSY D160-15-40-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
IQ845 FSY D200-14-60-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
IQ845 FSY D250-17-60-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
IQ845 FSY D315-20-60-R07
SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
IQ845 FSY-R07
50° Face Mills Carrying Square
Inserts with 8 Cutting Edges
50°
APMX
LF
DCONMS
DC
DCX
Designation
DC DCX(1) CICT(2) APMX LF SS CDI(3)
kg
IQ845 FSY D063-05-C6-R07
63.00 72.40 5 4.60 55.00 63 1 1.53 SR M4X0.7IP15 BLD IP15/S7 SW6-T-SH
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: IQ845 SYHU-07 (499)
IQ845 FSY-C#-R07
50° Face Mills Carrying Square
Inserts with 8 Cutting Edges
227
FACE MILLS
APMX
OAL
45°
DC
DCX
DCONMS
DHUB
Designation
DC DCX(2) CICT(3) APMX OAL DHUB DCONMS Arbor(4) CSP(5)
kg
S845 F45SX D040-04-16-R16 (1)
40.00 54.80 4 7.15 45.00 48.00 16.00 A 1 0.39
S845 F45SX D050-04-22-R16
50.00 64.80 4 7.15 45.00 48.00 22.00 A 1 0.46
S845 F45SX D050-05-22-R16 (1)
50.00 64.80 5 7.15 45.00 48.00 22.00 A 1 0.44
S845 F45SX D063-05-22-R16
63.00 77.80 5 7.15 45.00 60.00 22.00 B 1 0.72
S845 F45SX D063-07-22-R16 (1)
63.00 77.90 7 7.15 45.00 60.00 22.00 A 1 0.72
S845 F45SX D080-09-27-R16 (1)
80.00 93.10 9 7.15 50.00 63.00 27.00 B 1 1.01
S845 F45SX D100-11-32-R16 (1)
100.00 114.60 11 7.15 50.00 80.00 32.00 B 1 1.65
S845 F45SX D100-07-32-R16
100.00 114.80 7 7.15 50.00 80.00 32.00 B 1 1.62
S845 F45SX D125-08-40-R16
125.00 139.80 8 7.15 63.00 82.00 40.00 B 1 2.68
S845 F45SX D125-14-40-R16 (1)
125.00 139.80 14 7.15 63.00 82.00 40.00 B 1 2.72
S845 F45SX D160-10-40-R16
160.00 174.80 10 7.15 63.00 105.00 40.00 C 0 4.16
S845 F45SX D160-18-40-R16 (1)
160.00 174.80 18 7.15 63.00 105.00 40.00 C 0 4.30
S845 F45SX D200-12-60-R16
200.00 214.80 12 7.15 63.00 135.00 60.00 C 0 5.82
S845 F45SX D250-15-60-R16
250.00 264.80 15 7.15 63.00 144.00 60.00 C 0 8.58
• Wiper inserts are used on face mill cutters, providing improved surface finish, thus eliminating the use of other finishing cutters.
• For user guide, see pages 542-547
(1) Fine pitch cutters, recommended for machining cast iron and for machining steel - up to 4 mm D.O.C.
(2) Cutting diameter maximum
(3) Number of inserts
(4) For adaptation options, see page 548
(5) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: S845 SXHU 1606-W (501) • S845 SXMU/SXCU-16 (501)
Spare Parts
Designation
S845 F45SX D040-04-16-R16
SR 14-591 BLD T20/M7 SW6-T SR M8X25DIN912
S845 F45SX D050-04-22-R16
SR 14-591 BLD T20/M7 SW6-T SR M10X25DIN7984
S845 F45SX D050-05-22-R16
SR 14-591-M BLD T20/M7 SW6-T SR M10X25DIN7984
S845 F45SX D063-05-22-R16
SR 14-591 BLD T20/M7 SW6-T SR M10X25DIN7984
S845 F45SX D063-07-22-R16
SR 14-591-M BLD T20/M7 SW6-T SR M10X25DIN7984
S845 F45SX D080-09-27-R16
SR 14-591-M BLD T20/M7 SW6-T
S845 F45SX D100-11-32-R16
SR 14-591-M BLD T20/M7 SW6-T
S845 F45SX D100-07-32-R16
SR 14-591 BLD T20/M7 SW6-T
S845 F45SX D125-08-40-R16
SR 14-591 BLD T20/M7 SW6-T
S845 F45SX D125-14-40-R16
SR 14-591-M BLD T20/M7 SW6-T
S845 F45SX D160-10-40-R16
SR 14-591 BLD T20/M7 SW6-T
S845 F45SX D160-18-40-R16
SR 14-591-M BLD T20/M7 SW6-T
S845 F45SX D200-12-60-R16
SR 14-591 BLD T20/M7 SW6-T
S845 F45SX D250-15-60-R16
SR 14-591 BLD T20/M7 SW6-T
S845 F45SX-16
45° Face Mills Carrying
Economical Inserts with 8 Helical
Right-Hand Cutting Edges
ISCAR
228
FACE MILLS
DHUB
ONMU 1008... S845 SNMU...
DCON
DCX
DC
OAL
44°
APMX
DCX_2
DC_2
OAL_2
45°
APMX_2
Designation
DC DCX(1) APMX OAL DC_2 APMX_2 OAL_2 CICT(2) DHUB DCONMS Arbor(3) CSP(4)
kg
SOF45 D080-04-32-R26
84.10 104.50 7.00 60.80 80.00 11.00 63.0 4 70.00 32.00 A 1 1.68
SOF45 D100-05-32-R26
104.10 124.50 7.00 60.80 100.00 11.00 63.0 5 70.00 32.00 B 1 2.25
SOF45 D125-06-40-R26
129.10 149.50 7.00 60.80 125.00 11.00 63.0 6 82.00 40.00 B 1 3.08
SOF45 D160-08-40-R26
164.10 184.50 7.00 60.80 160.00 11.00 63.0 8 92.00 40.00 C 0 4.05
SOF45 D200-10-60-R26
204.10 224.50 7.00 60.80 200.00 11.00 63.0 10 135.00 60.00 C 0 6.52
SOF45 D250-12-60-R26
254.10 274.50 7.00 60.80 250.00 11.00 63.0 12 135.00 60.00 C 0 9.48
SOF45 D315-14-60-R26
319.10 339.50 7.00 77.80 315.00 11.00 80.0 14 220.00 60.00 C 0 19.73
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) For adaptation options, see page 548
(4) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: ONMU 1008 (509) • S845 SNMU 2608 (502)
Spare Parts
Designation
SOF45 D080-04-32-R26
SR 1/4-28XIP25 TSOF 26-N SR M3.5X0.6-6.5 T10 BLD IP25/S7 SW6-T SR M16-40C
SOF45 D100-05-32-R26
SR 1/4-28XIP25 TSOF 26-N SR M3.5X0.6-6.5 T10 BLD IP25/S7 SW6-T SR M16-40C
SOF45 D125-06-40-R26
SR 1/4-28XIP25 TSOF 26-N SR M3.5X0.6-6.5 T10 BLD IP25/S7 SW6-T
SOF45 D160-08-40-R26
SR 1/4-28XIP25 TSOF 26-N SR M3.5X0.6-6.5 T10 BLD IP25/M7 SW6-T
SOF45 D200-10-60-R26
SR 1/4-28XIP25 TSOF 26-N SR M3.5X0.6-6.5 T10 BLD IP25/M7 SW6-T
SOF45 D250-12-60-R26
SR 1/4-28XIP25 TSOF 26-N SR M3.5X0.6-6.5 T10 BLD IP25/L7 SW6-T
SOF45 D315-14-60-R26
SR 1/4-28XIP25 TSOF 26-N SR M3.5X0.6-6.5 T10 BLD IP25/L7 SW6-T
SOF45-26
Heavy Duty 45° Face Mills
Carrying Square or Octagonal
Double-Sided Inserts with
8/16 Cutting Edges
ONMU 1008... DCONMS
OAL
APMX DC_2
DCX_2
DHUB
APMX_2
BD
DC
DCX
OAL_2
S845 SNMU 2608...
Designation
DC BD DCX(1) APMX OAL DC_2 DCX_2 APMX_2 OAL_2 DCONMS DHUB Arbor
kg
SOF45WG D100-05-32-R26
104.10 123.50 118.80 7.00 60.80 100.00 123.50 11.00 63.00 32.00 78.00 B 2.46
SOF45WG D100-06-32-R26
104.10 123.50 118.80 7.00 60.80 100.00 123.50 11.00 63.00 32.00 78.00 B 2.33
SOF45WG D125-06-40-R26
129.10 148.50 143.80 7.00 60.80 125.00 148.50 11.00 63.00 40.00 92.00 B 3.67
SOF45WG D125-08-40-R26
129.10 148.50 143.80 7.00 60.80 125.00 148.50 11.00 63.00 40.00 92.00 B 3.41
SOF45WG D160-08-40-R26
164.10 183.80 178.80 7.00 60.80 160.00 183.80 11.00 63.00 40.00 95.00 C 4.84
SOF45WG D160-10-40-R26
164.10 183.80 178.80 7.00 60.80 160.00 183.80 11.00 63.00 40.00 95.00 C 4.58
SOF45WG D200-10-60-R26
204.10 223.50 218.80 7.00 60.80 200.00 223.50 11.00 63.00 60.00 180.00 C 9.47
SOF45WG D200-12-60-R26
204.10 223.50 218.80 7.00 60.80 200.00 223.50 11.00 63.00 60.00 180.00 C 9.20
SOF45WG D250-12-60-R26
254.10 273.30 268.80 7.00 60.80 250.00 273.30 11.00 63.00 60.00 180.00 C 12.68
SOF45WG D250-14-60-R26
254.10 273.30 268.80 7.00 60.80 250.00 273.30 11.00 63.00 60.00 180.00 C 12.44
SOF45WG D315-14-60-R26
319.10 338.50 333.80 7.00 77.80 315.00 338.50 11.00 80.00 60.00 230.00 C 22.43
SOF45WG D315-16-60-R26
319.10 338.50 333.80 7.00 77.80 315.00 338.50 11.00 80.00 60.00 230.00 C 22.22
• For user guide, see pages 542-547
(1) Cutting diameter maximum
For inserts, see pages: ONMU 1008 (509) • S845 SNMU 2608 (502)
Spare Parts
Designation
SOF45WG-R26
TSOF 26-N SR M3.5X0.6-6.5 T10 LW CL-13 INJ SR UNC 5/16-18X1 L/R BLD IP25/S7 SW6-T
SOF45WG-R26
Heavy Duty 45° Face Mills
Carrying Wedge Clamped Square
or Octagonal Double-Sided
Inserts with 8/16 Cutting Edges
229
FACE MILLS
45°44°
APMX APMX_2
DCONMS
DHUB
OAL OAL_2
DC
DCX DC_2
DCX_2
Designation
DC DCX(1) APMX OAL DC_2 DCX_2 APMX_2 OAL_2 CICT(2) DHUB DCONMS Arbor CSP(3)
kg
SOF45 D050-04-22-R18
50.00 67.00 8.00 50.00 52.80 67.00 5.00 48.5 4 48.00 22.00 A 1 0.55
SOF45 D063-05-22-R18
63.00 80.00 8.00 50.00 65.80 80.00 5.00 48.5 5 52.00 22.00 A 1 0.80
SOF45 D063-05-27-R18
63.00 80.00 8.00 50.00 65.80 80.00 5.00 48.5 5 60.00 27.00 A 1 0.83
SOF45 D080-06-27-R18
80.00 97.00 8.00 55.00 82.80 97.00 5.00 53.5 6 60.00 27.00 A 1 1.29
SOF45 D080-07-27-R18
80.00 97.00 8.00 55.00 82.80 97.00 5.00 53.5 7 60.00 27.00 A 1 1.29
SOF45 D100-07-32-R18
100.00 117.00 8.00 55.00 102.80 117.00 5.00 53.5 7 78.00 32.00 B 1 1.95
SOF45 D100-09-32-R18
100.00 117.00 8.00 55.00 102.80 117.00 5.00 53.5 9 78.00 32.00 B 1 1.94
SOF45 D125-08-40-R18
125.00 142.00 8.00 63.00 127.80 142.00 5.00 61.5 8 92.00 40.00 B 1 3.38
SOF45 D125-12-40-R18
125.00 142.00 8.00 63.00 127.80 142.00 5.00 61.5 12 92.00 40.00 B 1 3.35
SOF45 D160-10-40-R18
160.00 177.00 8.00 63.00 162.80 177.00 5.00 61.5 10 95.00 40.00 C 0 4.20
SOF45 D160-15-40-R18
160.00 177.00 8.00 63.00 162.80 177.00 5.00 61.5 15 95.00 40.00 C 0 4.30
SOF45 D200-12-60-R18
200.00 217.00 8.00 63.00 202.80 217.00 5.00 61.5 12 135.00 60.00 C 0 6.88
SOF45 D200-18-60-R18
200.00 217.00 8.00 63.00 202.80 217.00 5.00 61.5 18 135.00 60.00 C 0 6.99
SOF45 D250-14-60-R18
250.00 267.00 8.00 63.00 252.80 267.00 5.00 61.5 14 135.00 60.00 C 0 10.50
SOF45 D250-21-60-R18
250.00 267.00 8.00 63.00 252.80 267.00 5.00 61.5 21 135.00 60.00 C 0 11.35
SOF45 D315-18-60-R18
315.00 332.00 8.00 80.00 317.80 332.00 5.00 78.5 18 230.00 60.00 C 0 22.36
SOF45 D315-24-60-R18
315.00 332.00 8.00 80.00 317.80 332.00 5.00 78.5 24 230.00 60.00 C 0 22.22
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: ONHU 0706AN-R-W (509) • ONMU/ONHU 0706 (509) • S845 SNHU 1806AN-N-W (502) • S845 SNMU/SNHU 1806 (502)
Spare Parts
Designation
SOF45 D050-04-22-R18
SR M5X0.8 16 IP20(a) BLD IP20/S7 SW6-T SR M10X25 DIN912
SOF45 D063-05-22-R18
SR M5X0.8 16 IP20(a) BLD IP20/S7 SW6-T SR M10X25 DIN912
SOF45 D063-05-27-R18
SR M5X0.8 16 IP20(a) BLD IP20/S7 SW6-T SR DIN 912 M12X25
SOF45 D080-06-27-R18
SR M5X0.8 16 IP20(a) BLD IP20/S7 SW6-T SR DIN 912 M12X25
SOF45 D080-07-27-R18
SR M5X0.8 16 IP20(a) BLD IP20/S7 SW6-T SR DIN 912 M12X25
SOF45 D100-07-32-R18
SR M5X0.8 16 IP20(a) BLD IP20/S7 SW6-T
SOF45 D100-09-32-R18
SR M5X0.8 16 IP20(a) BLD IP20/S7 SW6-T
SOF45 D125-08-40-R18
SR M5X0.8 16 IP20(a) BLD IP20/S7 SW6-T
SOF45 D125-12-40-R18
SR M5X0.8 16 IP20(a) BLD IP20/S7 SW6-T
SOF45 D160-10-40-R18
SR M5X0.8 16 IP20(a) BLD IP20/M7 SW6-T
SOF45 D160-15-40-R18
SR M5X0.8 16 IP20(a) BLD IP20/M7 SW6-T
SOF45 D200-12-60-R18
SR M5X0.8 16 IP20(a) BLD IP20/M7 SW6-T
SOF45 D200-18-60-R18
SR M5X0.8 16 IP20(a) BLD IP20/M7 SW6-T
SOF45 D250-14-60-R18
SR M5X0.8 16 IP20(a) BLD IP20/M7 SW6-T
SOF45 D250-21-60-R18
SR M5X0.8 16 IP20(a) BLD IP20/M7 SW6-T
SOF45 D315-18-60-R18
SR M5X0.8 16 IP20(a) BLD IP20/M7 SW6-T
SOF45 D315-24-60-R18
SR M5X0.8 16 IP20(a) BLD IP20/M7 SW6-T
(a) Recommended tightening torque: 9 N*m
SOF45-R18
45° Face Mills Carrying Square
or Octagonal Double-Sided
Inserts with 8/16 Cutting Edges
ISCAR
230
FACE MILLS
Key 1Key 2Key
THOD BD
LB_2
LB
L
min
max
CXT
Designation
BD THOD CXT LB LB_2 L min L max Key(1) Key 1(2) DRVS(3)
COOLANT SET SR M10X1.5-22
28.00 M10 M4 25.00 18.00 2.0 17.0 7.00 6.00 21.00
COOLANT SET SRM12X1.75-27
35.00 M12 M4 31.00 22.00 2.0 17.0 7.00 6.00 27.00
COOLANT SET SR M16X2-32
42.00 M16 M8 37.00 26.00 3.0 25.0 13.00 10.00 30.00
COOLANT SET SR M20X2.5-40
52.00 M20 M8 45.00 30.00 3.0 25.0 13.00 10.00 36.00
(1) For the nut
(2) For the nozzle
(3) For the screw
Clamping Screws with
Adjustable Protrusion Nozzles for Shell-Type Face Mills
The protrusion of the nozzle screw can be easily
adjusted according to countersink depth, insert size
or any other application requirement. The nozzle
screw position can be secured by a locking nut.
Tests show that cutting fluid supplied through
the axis of a tool and directed radially at the
bottom of the tool dramatically improves both
the cooling effect and chip evacuation.
The screws are offered as sets, comprising a nozzle
screw, locking screw, a locking nut and washers.
The locking nut can be tightened by a standard
open-ended wrench, or preferably by an offset ring
wrench (ISO 10104, DIN 838 or DIN 897 standards).
If desired, the following ring wrenches
can also be ordered from ISCAR:
• 7000783 Ring Wrench 10X13 mm for coolant set
SR M20X2.5-40 and Coolant set SR M16X2-32
• 7000788 Ring Wrench 6X7 mm for
coolant set SRM12X1.75-27 and
coolant set SR M10X1.5-22.
7103284 06/08
1
1
2
2
3
3
4
4
5
5
6
6
7
7
Assembly with a Lock Nut
1
1
2
2
3
3
4
4
5
5
6
6
7
7
Assembly without a Lock Nut
COOLANT SET
Clamping Screws with
Adjustable Protrusion Nozzles
for Shell-Type Face Mills
Spare Parts
Designation
COOLANT SET SR M10X1.5-22
WASHER FLAT M4 DIN 433 SPRING PLUNGER
COOLANT SET SRM12X1.75-27
WASHER FLAT M4 DIN 433 SPRING PLUNGER
COOLANT SET SR M16X2-32
WASHER M8 DIN 433 A4 NOZZLE M8 NUT M8 DIN 934 A2
COOLANT SET SR M20X2.5-40
WASHER M8 DIN 433 A4 NOZZLE M8 NUT M8 DIN 934 A2
231
EXTENDED FLUTE CUTTERS
EXTENDED FLUTE CUTTERS
ISCAR
232
EXTENDED FLUTE CUTTERS
PICTORIAL TOOL
REFERENCE
Extended Flute Mills
HP ANK
page 235
H490 ANK
page 235
HM390 TPK/SM
pages 235-236
T490 LNK/LNM
pages 236-238, 246-247
XNK-XN13
page 239
APK-FE
page 239
SPK
page 239
P290 ACK/SM
pages 240-242
T490 SM
pages 243-244, 248
H490 SM
pages 243,249
SM-XN13
page 246
SDK-C/HP
pages 249-250
SM
page 250
233
EXTENDED FLUTE CUTTERS
90° Extended Flute Mills Selection Guide
APMX
DC
Tools Pages
APMX / Flutes
Inserts
DC
20 25 32 40 50 63 80 100
HP ANK-07 235
28/2
HP AN.. 07…
H490 ANK-09 235
35/2 42/3
H490 AN..09..
HM390 TPK-10 235
28/2 42/2 49/4
HM390 TP.. 10..
HM390 SM-10 236
49/4 49/5
HM390 TP.. 10..
T490 LNM-08 236
15/2 30/2
30/3 36/3 44/4
T490 LN.T 08…
T490 LNK-11 237
34/2 51/3 51/4
T490 LN..T1106
T490 LNK-13 237
36/2
36/3
48/3
47/3
59/4
82/3
105/3
81/4
117/4
82/4
128/4
T490 LN.. 13…
XNK-XN13 239
46/3
XNMU 13…
SELECTION GUIDE
ISCAR
234
EXTENDED FLUTE CUTTERS
APMX
DC
Tools Pages
APMX / Flutes
Inserts
DC
20 25 32 40 50 63 80 100
APK-FE 239
29/1 37/2 46/2 55/3
AP.. 10…
FPKT 10...
SPK 239
43/3
SPMT 10...
XPMT 10..
QPMT 10..
P290 ACK 241
24/3
36/3
24/3
36/3
48/3
60/3
84/3
53/3
71/3
87/3
90/3
125/3
53/4
105/4
160/3
87/5
P290 AC...T
P290 SM 242
24/3
24/4
36/4
48/4
36/4
53/4
71/4
53/5
71/5 71/6 36/6
71/7
P290 AC...T
T490 SM 243
244
36/3
24/2
36/3
44/4
51/3
36/2
36/3
44/5
47/4
51/3
59/4
36/4
47/4
59/4
59/5
68/5
58/5
70/5 59/6
T490 LN..
H490 SM 243
249
35/3
46/3
47/4
58/3
46/4
1
3
H490 AN..
SM-XN13 246
69/3
69/4 69/5
XNMU 13
SDK-C/HP 249
250
48/3
48/4
55/5
56/4
66/4
98/4
64/5
66/5
109/5
76/6
130/6
SD.. 10
SD..12
QD..12
SM 250
25/3 38/4
HM AD.. 15...
AD.. 15…
90° Extended Flute Mills Selection Guide
SELECTION GUIDE
235
EXTENDED FLUTE CUTTERS
APMX
OAL
LH
DC DCONMS
Designation
DC APMX NOF(1) CICT(2) LH OAL DCONMS Shank(3)
kg
H490 ANK D25-35-2-W25-09C
25.00 35.00 2 10 38.0 100.00 25.00 W 0.30 SR 10508082-HG BLD T08/M7 SW4-SD
H490 ANK D32-42-3-W32-09C
32.00 42.00 3 18 50.0 115.00 32.00 W 0.52 SR 10508082-HG BLD T08/M7 SW4-SD
• AE(max)=0.25xDC
(1) Number of flutes
(2) Number of inserts
(3) W-Weldon
For inserts, see pages: H490 ANKX/ANCX-09 (469)
H490 ANK-09
Extended Flute Endmills Carrying
H490 ANKX 09... Double-Sided
Rectangular Inserts with 4
Helical Cutting Edges
APMX
LH
OAL
DC DCONMS
Designation
DC APMX NOF(1) CICT(2) LH OAL DCONMS Shank(3)
kg
HP ANK D20-28-02-W20-7
20.00 28.60 2 8 40.0 90.00 20.00 W 0.18 SR 34-533/L/HG T-6/51
(1) Number of flutes
(2) Number of inserts
(3) W-Weldon
For inserts, see pages: HP ANCR 0702PNFR (444) • HP ANKT/ANCT 0702..PN-R/PNTR (444) • HP ANKW 070204PNTR (444)
HP ANK-07
Extended Flute Endmills
Carrying HP ANK-07... Inserts
OAL
LH
DC
APMX
DCONMS
Designation
DC APMX NOF(1) CICT(2) LH OAL DCONMS Shank(3)
kg
HM390 TPK D25-28-2-W25-10
25.00 28.00 2 8 35.0 95.00 25.00 W 0.30 SR 14-562/S(a) BLD T10/S7 SW6-SD
HM390 TPK D32-42-2-W32-10
32.00 42.00 2 12 50.0 110.00 32.00 W 0.53 SR 14-562/S(a) BLD T10/S7 SW6-SD
HM390 TPK D40-49-4-W32-10
40.00 49.00 4 28 59.0 125.00 32.00 W 0.75 SR 14-562/S(a) BLD T10/S7 SW6-SD
(1) Number of flutes
(2) Number of inserts
(3) W-Weldon
(a) Recommended tightening torque:3.2 Nxm
For inserts, see pages: HM390 TPKT/CT 1003 (447)
AP/AE Application Range for Extended Flute
HELI-3-MILL HM390-10 Cutters with HM390 TPKT 1003
… Inserts
50
5
42
49
28
610
8
HM390 TPK D025...10
HM390 TPK D032...10
HM390 TPK / SM D040...10
HM390 SM D050...10
Depth of Cut
( AP mm)
Width of Cut
( AE mm)
Dia. 40 and 50 mm
Dia. 32 mm
Dia. 25 mm
HM390 TPK-10
Extended Flute Endmills
Carrying HM390 TPKT 1003
Triangular Inserts with 3
Helical Cutting Edges
ISCAR
236
EXTENDED FLUTE CUTTERS
DCONMS
APMX
OAL
LH
DC
Designation
DC APMX NOF(1) CICT(2) LH OAL DCONMS Shank(3)
kg
T490 LNM D20-15-2-C20-08C
20.00 15.00 2 4 30.0 80.00 20.00 C 0.16 SR 10502813-HG-M IP-7/51
T490 LNM D20-15-2-W20-08C
20.00 15.00 2 4 30.0 80.00 20.00 W 0.16 SR 10502813-HG-M IP-7/51
T490 LNM D25-30-2-C25-08C
25.00 30.00 2 8 40.0 100.00 25.00 C 0.31 SR 10502813-HG-M IP-7/51
T490 LNM D25-30-2-W25-08C
25.00 30.00 2 8 40.0 100.00 25.00 W 0.30 SR 10502813-HG-M IP-7/51
T490 LNM D32-36-3-C32-08C
32.00 36.00 3 15 45.0 110.00 32.00 C 0.55 SR 10502813-HG-M IP-7/51
T490 LNM D32-36-3-W32-08C
32.00 36.00 3 15 45.0 110.00 32.00 W 0.55 SR 10502813-HG-M IP-7/51
T490 LNM D40-44-4-W32-08C
40.00 44.00 4 24 53.0 120.00 32.00 W 0.73 SR 10502813-HG-M IP-7/51
(1) Number of flutes
(2) Number of inserts
(3) W-Weldon, C-Cylindrical
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT/LNHT 0804 (476)
Ø40
Ø32
Ø25
Ø20
5 910 12
43
35
27
AP
AE
5
15
7
T490 LNM D40-45-4...
T490 LNM D25-30-2...
T490 LNM D32-38-3...
T490 LNM D20-15-2...
5 8 9
43
35
27
AP
AE
5
15
6.5
Ø40
Ø32
Ø25
Ø20
T490 LNM D40-44-4...
T490 LNM D25-30-2... T490 LNM D32-36-3...
T490 LNM D20-15-2...
AP/AE Application Range with
T490 LNMT 0804PNR Insert
Depth of Cut
mm Depth of Cut
mm
Width of Cut
mm Width of Cut
mm
AP/AE Application Range with
T490 LNMT080404-CS Chip Splitting Insert
T490 LNM-08
Extended Flute Endmills
Carrying T490 LNMT/HT 08...
Tangentially Clamped Inserts
OAL
DCONMS
APMX
DC DHUB
Designation
DC APMX NOF(1) CICT(2) OAL DHUB DCONMS Arbor(3)
kg
HM390 SM D040-49-4-16-10
40.00 49.00 4 28 65.00 38.80 16.00 A 0.30 SR 14-562/S(a) SR M8X55DIN912 BLD T10/S7 SW6-SD
HM390 SM D050-49-5-22-10
50.00 49.00 5 35 66.00 48.80 22.00 A 0.58 SR 14-562/S(a) SR M10X60DIN912 BLD T10/S7 SW6-SD
(1) Number of flutes
(2) Number of inserts
(3) For adaptation options, see page 548
(a) Recommended tightening torque:3.2 Nxm
For inserts, see pages: HM390 TPKT/CT 1003 (447)
AP/AE Application Range for Extended Flute
HELI 3 MILL HM390-10 Cutters with HM390 TPKT 1003
… Inserts
50
5
42
49
28
610
8
HM390 TPK D025...10
HM390 TPK D032...10
HM390 TPK / SM D040...10
HM390 SM D050...10
Width of Cut
( AE mm)
Depth of Cut
( AP mm)
Dia. 40 and 50 mm
Dia. 32 mm
Dia. 25 mm
HM390 SM-10
Extended Flute Shell Mills
Carrying HM390 TPKT 1003
Triangular Inserts with 3
Helical Cutting Edges
237
EXTENDED FLUTE CUTTERS
LF
OAL
DCONMS
DRVS
DC
APMX
THSZMS
Designation
DC APMX NOF(1) CICT(2) LF OAL DHUB THSZMS DRVS(3) TQ_3(4)
kg
T490 LNM D25-30-2-M12-08
25.00 30.00 2 8 52.00 74.00 21.00 M12 17.0 33 0.12 SR 10502813-HG-M IP-7/51
T490 LNM D32-36-3-M16-08
32.00 36.00 3 15 57.00 82.00 30.00 M16 25.0 40 0.26 SR 10502813-HG-M IP-7/51
• For adaptation options, see page 311 • For user guide see pages 542-547
(1) Number of flutes
(2) Number of inserts
(3) Clamping wrench size
(4) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT/LNHT 0804 (476)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
T490 LNM-M-08
Extended Flute Endmills
with a FLEXFIT Threaded
Adaptation Carrying
Tangentially Clamped Inserts
OAL
LH
APMX
DCONMS
DC
Designation
DC APMX NOF(1) CICT(2) LH OAL DCONMS Shank(3)
kg
T490 LNK-D32-34-2-W32-11
32.00 34.00 2 8 45.0 105.00 32.00 W 0.49 SR 34-535/L10.5-SN BLD T15/S7(a) SW6-SD
T490 LNK-D40-51-3-C32-11
40.00 51.00 3 18 60.0 120.00 32.00 C 0.66 SR 34-535/L10.5-SN BLD T15/S7(a) SW6-SD
T490 LNK-D40-51-3-W32-11
40.00 51.00 3 18 60.0 120.00 32.00 W 0.66 SR 34-535/L10.5-SN BLD T15/S7(a) SW6-SD
T490 LNK-D50-51-4-C40-11
50.00 51.00 4 24 60.0 130.00 40.00 C 1.18 SR 34-535-SN BLD T15/S7(a) SW6-SD
T490 LNK-D50-51-4-W40-11
50.00 51.00 4 24 60.0 130.00 40.00 W 1.18 SR 34-535-SN BLD T15/S7(a) SW6-SD
• Important: Maximum clamping torque 3.2 Nxm
(1) Number of flutes
(2) Number of inserts
(3) C-Cylindrical, W-Weldon
(a) Recommended key handle for limiting torque to 3.2 Nxm for this item is HSD 4-3.2NM (to be used with BLD 4 T15-4.8 blade)
For inserts, see pages: T490 LNMT/LNHT 1106 (461)
T490 LNK-11
Extended Flute Endmills
Carrying T490 LN#T 11...
Tangentially Clamped Inserts
OAL
LH
APMX
DCONMS
DC
Designation
DC APMX NOF(1) CICT(2) LH OAL DCONMS Shank(3)
kg
T490 LNK-D40-36-2-W32-13
40.00 36.00 2 6 50.0 115.00 32.00 W 0.68 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 LNK-D40-48-3-C32-13
40.00 48.00 3 12 65.0 140.00 32.00 C 0.80 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 LNK-D40-48-3-W32-13
40.00 48.00 3 12 65.0 125.00 32.00 W 0.70 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 LNK-D50-47-3-W40-13
50.00 47.00 3 12 65.0 135.00 40.00 W 1.24 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490 LNK-D50-59-4-W40-13
50.00 59.00 4 20 65.0 135.00 40.00 W 1.21 SR 34-535-SN BLD T15/S7 SW6-T-SH
(1) Number of flutes
(2) Number of inserts
(3) C-Cylindrical, W-Weldon
For inserts, see pages: T490 LNAR-P (464) • T490 LNMT 1306PNTR-FW (463) • T490 LNMT/LNHT/LNAR 1306 (462)
T490 LNK-13
Extended Flute Endmills
Carrying T490 LNMT/HT 13...
Tangentially Clamped Inserts
ISCAR
238
EXTENDED FLUTE CUTTERS
DC
LH LF
Shank
APMX
DF
Designation
DC APMX NOF(1) CICT(2) LH LPR Shank DF CSP(3)
kg
T490LNK-D50-059-4-BT50-13
50.00 59.00 4 20 80.5 120.00 BT MAS-403 100.00 1 4.34 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490LNK-D50-082-3-BT50-13
50.00 82.00 3 21 107.0 145.00 BT MAS-403 100.00 1 4.57 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490LNK-D50-105-3-BT50-13
50.00 105.00 3 27 130.0 168.00 BT MAS-403 100.00 0 4.99 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490LNK-D63-117-4-BT50-13
63.00 117.00 4 40 150.0 188.00 BT MAS-403 100.00 1 6.07 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490LNK-D80-082-4-BT50-13
80.00 82.00 4 28 135.0 173.00 BT MAS-403 100.00 1 7.65 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490LNK-D80-128-4-BT50-13
80.00 128.00 4 44 162.0 200.00 BT MAS-403 100.00 1 8.25 SR 34-535-SN BLD T15/S7 SW6-T-SH
(1) Number of flutes
(2) Number of inserts
(3) 0 - Without coolant supply, 1 - With coolant supply
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT 1306PNTR-FW (479) • T490 LNMT/LNHT/LNAR 1306 (478)
T490 LNK-13-BT
Extended Flute Endmills with
BT MAS-403 Tapered Shanks
Carrying T490 LNMT/HT 13...
Tangentially Clamped Inserts
DC
LH
LF
APMX
Shank
DF
Designation
DC APMX NOF(1) CICT(2) LH LF Shank DF
kg
T490LNKD50-082-3-INT50-13
50.00 82.00 3 21 126.0 145.00 DIN 69871 97.50 3.85 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490LNKD63-081-4-INT50-13
63.00 81.00 4 28 107.0 126.10 DIN 69871 97.50 4.34 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490LNKD63-117-4-INT50-13
63.00 117.00 4 40 169.0 188.00 DIN 69871 97.50 5.46 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490LNKD80-082-4-INT50-13
80.00 82.00 4 28 154.0 173.00 DIN 69871 97.50 7.61 SR 34-535-SN BLD T15/S7 SW6-T-SH
T490LNKD80-128-4-INT50-13
80.00 128.00 4 44 180.9 200.00 DIN 69871 97.50 7.92 SR 34-535-SN BLD T15/S7 SW6-T-SH
(1) Number of flutes
(2) Number of inserts
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT 1306PNTR-FW (479) • T490 LNMT/LNHT/LNAR 1306 (478)
T490 LNK-13-INT
Extended Flute Endmills with
DIN69871 Tapered Shanks
Carrying T490 LNMT/HT 13...
Tangentially Clamped Inserts
DC
APMX LF OAL
DCONMS
DRVS
THSZMS
Designation
DC APMX NOF(1) CICT(2) LF OAL DCONMS THSZMS DRVS(3)
kg
T490 LNK-D40-36-3-M16-13
40.00 36.00 3 9 63.00 88.00 30.00 M16 25.0 0.37 SR 34-535-SN BLD T15/S7 SW6-T-SH
• For adaptation options, see page 311 • For user guide, see pages 542-547
(1) Number of flutes
(2) Number of inserts
(3) Clamping wrench size
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT 1306PNTR-FW (479) • T490 LNMT/LNHT/LNAR 1306 (478)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
T490 LNK-M-13
Endmills with a FLEXFIT
Threaded Adaptation Carrying
Tangentially Clamped Inserts
DC
APMX
LH
LF OAL
DCONMS
Shank
Designation
DC APMX NOF(1) CICT(2) LH LF OAL DCONMS Shank
kg
T490 LNK-D50-59-4-CF4-13
50.00 59.00 4 20 - 73.00 115.00 44.00 CF4 0.82 SR 34-535-SN BLD T15/S7 SW6-T-SH
(1) Number of flutes
(2) Number of inserts
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT 1306PNTR-FW (479) • T490 LNMT/LNHT/LNAR 1306 (478)
T490 LNK-13-CF
Extended Flute Endmills with
CLICKFIT Shanks Carrying
T490 LNMT/HT 1306...
Tangentially Clamped Inserts
239
EXTENDED FLUTE CUTTERS
DCONMS
OAL
LF
APMX
DC
Designation
DC APMX LF NOF(1) CICT(2) OAL DCONMS Shank(3)
kg
XNK D050-46-3-W40 XN13
50.00 46.00 85.00 3 12 125.00 40.00 W 1.09 SR M4-L15-D4.5 BLD IP15/S7 SW6-T-SH
• Radial W.O.C. < 0.3xDC
(1) Number of flutes
(2) Number of inserts
(3) W-Weldon
For inserts, see pages: XNMU 13 (514)
XNK-XN13
Extended Flute Endmills
Carrying XNMU 1306... Inserts
DC
OAL
APMX
LH
DCONMS
Rd°
Designation
DC APMX NOF(1) CICT(2) LH OAL DCONMS Shank(3) RMPX°(4)
kg
APK D20-28-W20-FE
20.00 29.00 1 4 36.0 87.00 20.00 W 4.0 0.17 SR 34-505/HG T-8/53
APK D25-36-W25-FE
25.00 37.00 2 8 47.0 105.00 25.00 W 4.0 0.31 SR 34-505/MHG T-8/53
APK D32-45-W32-FE
32.00 46.00 2 12 55.0 115.00 32.00 W 1.4 0.57 SR 34-505/LHG T-8/53
APK D40-50-W32-FE
40.00 55.00 3 18 65.0 130.00 32.00 W 1.3 0.80 SR 34-505/LHG T-8/53
• Inserts with large corner radii can only be mounted in the face position of the cutter
(1) Number of flutes
(2) Number of inserts
(3) W-Weldon
(4) Maximum ramping angle
For inserts, see pages: APCR 1003PDFR-P (450) • APCT 1003PDR-HM (450) • APKR 1003PDR-HM (451) • APKT 1003..R (453) • APKT 1003..TR-RM (452)
• APKT 1003PDR-HM (451) • APKT 1003PDR-HM-CS (451) • APKT 1003PDTR-76 (452) • APKT 1003PDTR/L-RM (452) • HM90 APKW 1003PDR (453)
APK-FE
Extended Flute Endmills
Carrying APKT/R-10... Inserts
LF
LH
DC
APMX
Shank
DF
Designation
DC APMX NOF(1) CICT(2) LH LF DF Shank
kg
FIN LNK D050-100-4-INT50
50.00 102.00 4 28 123.2 142.30 97.50 DIN 69871 3.73 SR 34-535 BLD T15/M7 SW6-T
FIN LNK D063-130-4-INT50
63.00 130.00 4 36 157.0 176.10 97.50 DIN 69871 5.21 SR 34-535 BLD T15/M7 SW6-T
(1) Number of flutes
(2) Number of inserts
For inserts, see pages: FIN LNAT 1607PN-R (491)
FIN LNK-INT
Extended Flute Endmills with
Tangentially Clamped Inserts
and DIN69871 Shanks for Semi-
Finishing Long Shoulders
DC
LH OAL
DCONMS
APMX
Rd°
Designation
DC APMX NOF(1) CICT(2) LH OAL DCONMS Shank(3) RMPX°(4)
kg
SPK D40-42-W32-10
40.00 43.00 3 15 55.0 125.00 32.00 W 1.5 0.70 SR 14-544/S BLD T15/M7 SW6-SD
(1) Number of flutes
(2) Number of inserts
(3) W-Weldon
(4) Maximum ramping angle
For inserts, see pages: QPMR 1004-HQ-M (495) • QPMT 100408PDTN (495) • SPCT/SPMR PDR (496) • SPMT-HQ (495) • XPMT-HQ (496)
SPK
Extended Flute Endmills
Carrying Square Inserts
ISCAR
240
EXTENDED FLUTE CUTTERS
THSZMS
APMX
DRVS
LF
DCONMS
OAL
DC
Rd°
Designation
DC APMX NOF(1) CICT(2) LF DCONMS THSZMS OAL DRVS(3) RMPX°(4) TQ_3(5)
kg
P290 ACK D32-3-24-M16-12
32.00 24.00 3 6 40.00 29.00 M16 65.00 25.0 1.0 40 0.17 SR M3X0.5-L7.4 IP9(a) IP-9/151
• Note: recommended ae up to 0.2xDC • For adaptation options, see page 311 • For user guide, see pages 542-547 • When mounting items with FLEXFIT threaded
adaptation to their holders, the mating surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening torque to eliminate a gap between the mating
faces. Estimated torque values are specified in the TQ_3 parameter
(1) Number of flutes
(2) Number of inserts
(3) Clamping wrench size
(4) Maximum ramping angle
(5) Tool tightening torque Nxm (lbfxin)
(a) Recommended tightening torque:2.0 N*m (20.0lbf*in)
For inserts, see pages: P290 ACCT/KT (461) • P290 ACKT (461)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
P290 ACK-M
Extended Flute Endmills with
FLEXFIT Threaded Adaptation
Carrying 12 mm
Long Edged Inserts
LF
LH
DC
APMX
DF
Shank
Designation
DC APMX NOF(1) CICT(2) LH LPR DF Shank
kg
FIN LNK D050-100-4-BT50
50.00 102.00 4 28 123.2 161.20 100.00 BT MAS-403 4.72 SR 34-535 BLD T15/M7 SW6-T
(1) Number of flutes
(2) Number of inserts
For inserts, see pages: FIN LNAT 1607PN-R (491)
FIN LNK-BT
Extended Flute Endmills with
Tangentially Clamped Inserts
and BT MAS-403 Shanks for
Semi-Finishing Long Shoulders
241
EXTENDED FLUTE CUTTERS
DC
APMX
LH
OAL
DCONMS
Rd°
Designation
DC APMX NOF(2) CICT(3) LH OAL DCONMS RMPX°(4) Shank(5)
kg
P290 ACK D25-3-24-W20-12
25.00 24.00 3 6 40.0 95.00 20.00 1.4 W 0.20
P290 ACK D25-3-36-W25-12
25.00 36.00 3 9 50.0 110.00 25.00 1.4 W 0.29
P290 ACK D32-3-36-W32-12
32.00 36.00 3 9 50.0 110.00 32.00 1.0 W 0.50
P290 ACK D32-3-48-W32-12
32.00 48.00 3 12 65.0 125.00 32.00 1.0 W 0.55
P290 ACK D32-3-60-W32-12
32.00 60.00 3 15 80.0 140.00 32.00 1.0 W 0.59
P290 ACK D32-3-84-W32-12
32.00 84.00 3 21 100.0 160.00 32.00 1.0 W 0.66
P290 ACK D32-3-36-W25-18 (1)
32.00 36.00 3 6 55.0 115.00 25.00 2.0 W 0.36
P290 ACK D40-3-53-W32-18
40.00 53.00 3 9 80.0 140.00 32.00 1.5 W 0.77
P290 ACK D40-3-71-W40-18
40.00 71.00 3 12 95.0 165.00 40.00 1.5 W 1.14
P290 ACK D40-3-90-W40-18
40.00 90.00 3 15 115.0 185.00 40.00 1.5 W 1.23
P290 ACK D40-3-125-W40-18
40.00 125.00 3 21 150.0 220.00 40.00 1.5 W 1.39
P290 ACK D50-4-53-W40-18
50.00 53.00 4 12 80.0 150.00 40.00 1.0 W 1.33
P290 ACK D50-4-105-W50-18
50.00 105.00 4 24 130.0 210.00 50.00 1.0 W 2.23
P290 ACK D50-3-160-W50-18
50.00 160.00 3 27 185.0 265.00 50.00 1.0 W 2.82
(1) Do not use with P290 ACKT...-FWR insert
(2) Number of flutes
(3) Number of inserts
(4) Maximum ramping angle
(5) W-Weldon
For inserts, see pages: P290 ACCT/KT (461) • P290 ACKT (461)
Maximum Width of Cut AE Max (AEMX)* for P290 ACK...
Extended Flute Cutters
* Designation in accordance with standard ISO 13399 are given in parentheses
APMX
DC Up to 1.5 Over 1.5 up to 2.5 Over 2.5
AEMX 0.2xDC 0.15xDC 0.1xDC
DC
AEMX
APMX
Spare Parts
Designation
P290 ACK D25-3-24-W20-12
SR M3X0.5-L7.4 IP9(a) IP-9/151
P290 ACK D25-3-36-W25-12
SR M3X0.5-L7.4 IP9(a) IP-9/151
P290 ACK D32-3-36-W32-12
SR M3X0.5-L7.4 IP9(a) IP-9/151
P290 ACK D32-3-48-W32-12
SR M3X0.5-L7.4 IP9(a) IP-9/151
P290 ACK D32-3-60-W32-12
SR M3X0.5-L7.4 IP9(a) IP-9/151
P290 ACK D32-3-84-W32-12
SR M3X0.5-L7.4 IP9(a) IP-9/151
P290 ACK D32-3-36-W25-18
SR 14-544/S BLD T15/M7 SW6-T
P290 ACK D40-3-53-W32-18
SR 14-544/S BLD T15/M7 SW6-T
P290 ACK D40-3-71-W40-18
SR 14-544/S BLD T15/M7 SW6-T
P290 ACK D40-3-90-W40-18
SR 14-544/S BLD T15/M7 SW6-T
P290 ACK D40-3-125-W40-18
SR 14-544/S BLD T15/M7 SW6-T
P290 ACK D50-4-53-W40-18
SR 14-544/S BLD T15/M7 SW6-T
P290 ACK D50-4-105-W50-18
SR 14-544/S BLD T15/M7 SW6-T
P290 ACK D50-3-160-W50-18
SR 14-544/S BLD T15/M7 SW6-T
(a) Recommended tightening torque:2.0 N*m
P290 ACK
Extended Flute Endmills
Carrying 12 and 18 mm
Long Edged Inserts
ISCAR
242
EXTENDED FLUTE CUTTERS
APMX
DC DCONMS
OAL
DHUB
Rd°
Designation
DC APMX NOF(1) CICT(2) OAL DHUB DCONMS RMPX°(3) Arbor(4)
kg
P290 SM D032-03-24-16-12
32.00 24.00 3 6 65.00 38.00 16.00 1.0 A 0.27
P290 SM D040-04-24-16-12
40.00 24.00 4 8 45.00 38.00 16.00 0.7 A 0.23
P290 SM D040-04-36-16-12
40.00 36.00 4 12 60.00 38.00 16.00 0.7 A 0.30
P290 SM D040-04-48-22-12
40.00 48.00 4 16 85.00 48.00 22.00 0.7 A 0.47
P290 SM D050-04-36-22-18
50.00 36.00 4 8 65.00 46.40 22.00 1.0 A 0.47
P290 SM D050-04-53-22-18
50.00 53.00 4 12 80.00 46.40 22.00 1.0 A 0.57
P290 SM D050-04-71-27-18
50.00 71.00 4 16 105.00 48.00 27.00 1.0 A 0.73
P290 SM D063-05-53-27-18
63.00 53.00 5 15 80.00 55.00 27.00 0.8 A 1.00
P290 SM D063-05-71-27-18
63.00 71.00 5 20 100.00 55.00 27.00 0.8 A 1.30
P290 SM D080-06-71-32-18
80.00 71.00 6 24 100.00 74.00 32.00 0.5 A 2.21
P290 SM D100-06-36-32-18
100.00 36.00 6 12 70.00 78.00 32.00 0.3 A 2.48
P290 SM D100-07-71-40-18
100.00 71.00 7 28 100.00 85.00 40.00 0.3 A 3.50
• Note: recommended ae up to 0.2xDC
(1) Number of flutes
(2) Number of inserts
(3) Maximum ramping angle
(4) For adaptation options, see page 548
For inserts, see pages: P290 ACCT/KT (461) • P290 ACKT (461)
Spare Parts
Designation
P290 SM D032-03-24-16-12
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M8X55-D11.5 DIN912
P290 SM D040-04-24-16-12
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M8X35 DIN912
P290 SM D040-04-36-16-12
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M8X45DIN912
P290 SM D040-04-48-22-12
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M10X70DIN912
P290 SM D050-04-36-22-18
SR 14-544/S BLD T15/M7 SW6-T SR M10X50 DIN 912
P290 SM D050-04-53-22-18
SR 14-544/S BLD T15/M7 SW6-T SR M10X60DIN912
P290 SM D050-04-71-27-18
SR 14-544/S BLD T15/M7 SW6-T SR M12X70DIN912
P290 SM D063-05-53-27-18
SR 14-544/S BLD T15/M7 SW6-T SR M12X70DIN912
P290 SM D063-05-71-27-18
SR 14-544/S BLD T15/M7 SW6-T SR M12X70DIN912
P290 SM D080-06-71-32-18
SR 14-544/S BLD T15/M7 SW6-T SR M16X80 DIN 912
P290 SM D100-06-36-32-18
SR 14-544/S BLD T15/M7 SW6-T SR M16X50 DIN912
P290 SM D100-07-71-40-18
SR 14-544/S BLD T15/M7 SW6-T SR M20X80DIN912
(a) Recommended tightening torque:2.0 N*m
P290 SM
Extended Flute Shell Mills
Carrying 12 and 18 mm
Long Edged Inserts
DC
LU LF
DCONMS
APMX
Shank
Rd°
Designation
DC APMX NOF(2) CICT(3) LU LF RMPX°(4) DCONMS Shank CDI(5)
kg
P290 ACK D32-3-36-C5-18 (1)
32.00 36.00 3 9 64.0 90.00 2.0 50.00 CAMFIX 1 0.79 SR 14-544/S BLD T15/M7 SW6-T
P290 ACK D40-3-87-C6-18
40.00 87.00 3 15 106.0 134.60 1.5 63.00 CAMFIX 1 1.66 SR 14-544/S BLD T15/M7 SW6-T
P290 ACK D63-5-87-C8-18
63.00 87.00 5 25 104.0 140.00 0.8 80.00 CAMFIX 1 4.00 SR 14-544/S BLD T15/M7 SW6-T
• Note: recommended ae up to 0.2xDC
(1) Do not use with P290 ACKT...-FWR insert
(2) Number of flutes
(3) Number of inserts
(4) Maximum ramping angle
(5) 1 - Hole for data chip, 0 - Without hole for data chip
For inserts, see pages: P290 ACCT/KT (461) • P290 ACKT (461)
P290 ACK-C#-18
Extended Flute Endmills with
CAMFIX Shanks Carrying 18 mm
Long Edged Inserts
243
EXTENDED FLUTE CUTTERS
DC DCONMS DHUB
APMX
OAL
Designation
DC CICT(1) NOF(2) APMX OAL DHUB DCONMS Arbor(3)
kg
H490 SM D050-36-3-22-12
50.00 9 3 35.00 60.00 48.00 22.00 A 0.45 SR 14-544 BLD T15/M7 SW6-T SR M10X40DIN912
H490 SM D063-48-4-27-12
63.00 16 4 47.00 70.00 60.00 27.00 A 0.89 SR 14-544 BLD T15/M7 SW6-T SR M12X50DIN912
(1) Number of inserts
(2) Number of flutes
(3) For adaptation see page 548
For inserts, see pages: H490 ANKX/ANCX-12 (470)
H490 SM-12
Extended Flute Shell Mills
Carrying H490 ANKX 12..
Double-Sided Rectangular Inserts
with 4 Helical Cutting Edges
DC
APMX
DCONMS DHUB
OAL
Designation
DC APMX NOF(1) CICT(2) OAL DHUB DCONMS Arbor(3)
kg
T490 SM D032-36-3-16-08
32.00 36.00 3 15 58.00 38.00 16.00 A 0.23 SR 10502813-HG-M IP-7/51 SR M8X45DIN912
T490 SM D040-44-4-16-08
40.00 44.00 4 24 65.00 38.00 16.00 A 0.38 SR 10502813-HG-M IP-7/51 SR M8X55DIN912
T490 SM D050-44-5-22-08
50.00 44.00 5 30 65.00 47.00 22.00 A 0.61 SR 10502813-HG-M IP-7/51 SR M10X50 DIN 912
(1) Number of flutes
(2) Number of inserts
(3) For adaptation options, see page 548
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT/LNHT 0804 (476)
T490 SM-08
Extended Flute Shell Mills
Carrying T490 LNMT/HT 0804...
Tangentially Clamped Inserts
DCONMS DHUB
APMX
DC
OAL
Designation
DC APMX NOF(1) CICT(2) OAL DHUB DCONMS Arbor(3)
kg
T490 SM-D40-51-3-22-11
40.00 51.00 3 18 72.00 38.00 22.00 A 0.31 SR 34-535/L10.5-SN BLD T15/S7(a) SW6-SD SR M10X60DIN912
T490 SM-D50-51-3-22-11
50.00 51.00 3 18 71.00 48.00 22.00 A 0.59 SR 34-535-SN BLD T15/S7(a) SW6-SD SR M10X60DIN912
T490 SM-D50-59-4-22-11
50.00 59.00 4 28 80.00 48.00 22.00 A 0.66 SR 34-535-SN BLD T15/S7(a) SW6-SD SR M10X70DIN912
T490 SM-D63-59-4-27-11
63.00 59.00 4 28 81.00 60.00 27.00 A 1.16 SR 34-535-SN BLD T15/S7(a) SW6-SD SR M12X70DIN912
T490 SM-D63-68-5-27-11
63.00 68.00 5 40 90.00 60.00 27.00 A 1.30 SR 34-535-SN BLD T15/S7(a) SW6-SD SR M12X80DIN912
• Important: Maximum clamping torque 3.2 Nxm
(1) Number of flutes
(2) Number of inserts
(3) For adaptation see page 548
(a) Recommended key handle for limiting torque to 3.2 Nxm for this item is HSD 4-3.2NM (to be used with BLD 4 T15-4.8 blade)
For inserts, see pages: T490 LNMT/LNHT 1106 (477)
T490 SM-11
Extended Flute Shell Mills
Carrying T490 LN#T 11...
Tangentially Clamped Inserts
ISCAR
244
EXTENDED FLUTE CUTTERS
APMX
OAL
DCONMS DHUB
DC
Designation
DC APMX NOF(1) CICT(2) OAL DHUB DCONMS Arbor(3)
kg
T490 SM-D40-24-2-22-13
40.00 24.00 2 4 50.00 38.00 22.00 A 0.24
T490 SM-D40-36-3-22-13
40.00 36.00 3 9 62.00 38.00 22.00 A 0.29
T490 SM-D50-36-2-27-13
50.00 36.00 2 6 56.00 48.00 27.00 A 0.38
T490 SM-D50-36-3-22-13
50.00 36.00 3 9 56.00 48.00 22.00 A 0.43
T490 SM-D50-36-3-27-13
50.00 36.00 3 9 56.00 48.00 27.00 A 0.39
T490 SM-D50-47-4-22-13
50.00 47.00 4 16 68.00 48.00 22.00 A 0.54
T490 SM-D50-47-4-27-13
50.00 47.00 4 16 68.00 48.00 27.00 A 0.49
T490 SM-D63-36-4-27-13
63.00 36.00 4 12 60.00 58.00 27.00 A 0.79
T490 SM-D63-59-5-27-13
63.00 59.00 5 25 80.00 58.00 27.00 A 1.09
T490 SM-D80-58-5-32-13
80.00 58.00 5 25 75.00 74.00 32.00 A 1.73
T490 SM-D80-70-5-32-13
80.00 70.00 5 30 111.00 74.00 32.00 A 2.65
T490 SM-D100-59-6-40-13
100.00 59.00 6 30 86.00 88.00 40.00 A 3.11
(2) Number of flutes
(3) Number of inserts
(4) For adaptation options, see page 548
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT 1306PNTR-FW (479) • T490 LNMT/LNHT/LNAR 1306 (478)
Spare Parts
Designation
T490 SM-D40-24-2-22-13
SR 34-535/L10.5-SN BLD T15/S7 SW6-T-SH SR M10X40DIN912
T490 SM-D40-36-3-22-13
SR 34-535/L10.5-SN BLD T15/S7 SW6-T-SH SR M10X50 DIN 912
T490 SM-D50-36-2-27-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X45DIN912
T490 SM-D50-36-3-22-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X40DIN912
T490 SM-D50-36-3-27-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X45DIN912
T490 SM-D50-47-4-22-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X50 DIN 912
T490 SM-D50-47-4-27-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X50DIN912
T490 SM-D63-36-4-27-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X50DIN912
T490 SM-D63-59-5-27-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X70DIN912
T490 SM-D80-58-5-32-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M16X55DIN912
T490 SM-D80-70-5-32-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M16X90DIN912
T490 SM-D100-59-6-40-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M20X60DIN912
T490 SM-13
Extended Flute Shell Mills
Carrying T490 LNMT/HT 1306...
Tangentially Clamped Inserts
DCONMS DHUB
OAL
APMX
DC
Designation
DC APMX NOF(1) CICT(2) OAL DHUB DCONMS Arbor(3)
kg
T490 SM-D50-47-2-27-13FT
50.00 47.00 2 8 66.50 58.00 27.00 A 0.59
T490 SM-D63-59-3-27-13FT
63.00 59.00 3 15 80.00 58.00 27.00 A 1.10
T490 SM-D80-70-4-32-13FT
80.00 70.00 4 24 95.00 74.00 32.00 A 2.23
(1) Number of flutes
(2) Number of inserts
(3) For adaptation options, see page 548
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT 1306PNTR-FW (479) • T490 LNMT/LNHT/LNAR 1306 (478)
Spare Parts
Designation
T490 SM-D50-47-2-27-13FT
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X50DIN912
T490 SM-D63-59-3-27-13FT
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M3X0.5X10DIN7991 10.9 PG D63 SR M12X60DIN912
T490 SM-D80-70-4-32-13FT
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M3X0.5X10DIN7991 10.9 PG D63 SR M16X70DIN912
T490 SM-13FT
Basic Units for Modular
Extended Flute Shell Mills
245
EXTENDED FLUTE CUTTERS
SS
APMX
DC
Designation
DC APMX NOF(1) CICT(2) SS
kg
T490 CAP-D50-24-2-20-13FT
50.00 24.00 2 4 20 0.21 SR 34-535-SN
T490 CAP-D50-36-2-20-13FT
50.00 36.00 2 6 20 0.32 SR 34-535-SN
T490 CAP-D63-24-3-20-13FT
63.00 24.00 3 6 20 0.33 SR 34-535-SN
T490 CAP-D63-24-4-2W0-13FT
63.00 24.00 4 8 20 0.34 SR 34-535-SN SR M6X6 DIN916
T490 CAP-D63-36-3-20-13FT
63.00 36.00 3 9 20 0.51 SR 34-535-SN
T490 CAP-D63-36-4-20-13FT
63.00 36.00 4 12 20 0.50 SR 34-535-SN SR M6X6 DIN916
T490 CAP-D80-24-4-25-13FT
80.00 24.00 4 8 25 0.59 SR 34-535-SN SR M6X8 DIN916
T490 CAP-D80-36-4-25-13FT
80.00 36.00 4 12 25 0.88 SR 34-535-SN SR M6X8 DIN916
(1) Number of flutes
(2) Number of inserts
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT 1306PNTR-FW (479) • T490 LNMT/LNHT/LNAR 1306 (478)
T490 SM-D50-47-2-27-13FT
T490 SM-D50-47-3-27-13FT
T490 CAP-D50-36-2-20-13FT
T490 SM-D50-47-2-27-13FT
T490 CAP-D50-24-2-20-13FT
T490 SM-D50-47-3-27-13FT
T490 CAP-D50-36-2-20-13FT
T490 CAP-D50-24-2-20-13FT
10 15 18 25 50
105
83
70
AP
AE
35
47
8
115
90
75
AP
AE
40
59
14 15 20 25 63 10
T490 SM-D63-59-3-27-13FT
T490 SM-D63-59-3-27-13FT
T490 CAP-D63-36-3-20-13FT
T490 SM-D63-59-3-27-13FT
T490 CAP-D63-24-3-20-13FT
T490 SM-D63-59-3-27-13FT
T490 CAP-D63-36-3-20-13FT
T490 CAP-D63-24-3-20-13FT
T490 SM-D80-70-4-32-13FT
T490 SM-D80-70-4-32-13FT
T490 CAP-D80-36-4-25-13FT
T490 SM-D80-70-4-32-13FT
T490 CAP-D80-24-4-25-13FT
T490 SM-D80-70-4-32-13FT
T490 CAP-D80-36-4-25-13FT
T490 CAP-D80-24-4-25-13FT
15 12 20 25 50
125
105
93
AP
AE
40
70
AP/AE Application Range for 50 mm
Modular Extended Flute Cutters
AP/AE Application Range for 63 mm
Modular Extended Flute Cutters
Shell Base Unit
Extension 1 Extension 2 DC APMX OAL NOF CICT Assembly Screw
T490 SM-D50-47-2-27-13FT
47 66.5
2
8SR M12x50 DIN912
T490 CAP-D50-24-2-20-13FT 50 71 90 12 SR M12x70 DIN912
T490 CAP-D50-36-2-20-13FT 50 83 102 14 SR M12x80 DIN912
T490 CAP-D50-24-2-20-13FT T490 CAP-D50-24-2-20-13FT 50 94 113 16 SR M12x100 DIN912
T490 CAP-D50-24-2-20-13FT T490 CAP-D50-36-2-20-13FT 50 106 125 18 SR M12x110 DIN912
T490 SM-D63-59-3-27-13FT
59 80
3
15 SR M12x60 DIN912
T490 CAP-D63-24-3-20-13FT 63 82 103 21 SR M12x80 DIN912
T490 CAP-D63-36-3-20-13FT 63 94 115 24 SR M12x100 DIN912
T490 CAP-D63-24-3-20-13FT T490 CAP-D63-24-3-20-13FT 63 106 127 27 SR M12x110 DIN912
T490 CAP-D63-24-3-20-13FT T490 CAP-D63-36-3-20-13FT 63 117 138 30 SR M12x120 DIN912
Modular Extended Flute
Assembly
DC
APMX
OAL
Assembly screw
AP/AE Application Range for 80 mm
Modular Extended Flute Cutters
Workpiece: Alloy Steel
Depth of Cut mm
Depth of Cut mm
Depth of Cut mm
Width of Cut mm Width of Cut mm
Width of Cut mm
T490 CAP-13FT
Extension Units for Modular
Extended Flute Shell Mills
ISCAR
246
EXTENDED FLUTE CUTTERS
DCONMS DHUB
OAL
APMX
DC
Designation
DC APMX NOF(1) DCONMS CICT(2) LF DHUB Arbor
kg
SM D063-69-3-27R XN13
63.00 69.00 3 27.00 18 80.00 61.30 A 1.05 SR M4-L15-D4.5 BLD IP15/S7 SW6-T-SH SR M12X70DIN912
SM D063-69-4-27R XN13
63.00 69.00 4 27.00 24 80.00 61.30 A 0.95 SR M4-L15-D4.5 BLD IP15/S7 SW6-T-SH SR M12X70DIN912
SM D080-69-5-32R XN13
80.00 69.00 5 32.00 30 85.00 78.30 A 2.50 SR M4-L15-D4.5 BLD IP15/M7 SW6-T-SH SR M16X70DIN912
• Radial W.O.C. < 0.3xDC
(1) Number of flutes
(2) Number of inserts
For inserts, see pages: XNMU 13 (514)
SM-XN13
Extended Flute Shell Mills
Carrying XNMU 1306... Inserts
T490 CAP-FT
APMX
LBX
LF
DC
Shank
DF
Designation
DC APMX LBX LF DF NOF(1) CICT(2) Shank
kg
T490LNKD63-082-4-INT50-FT
63.00 82.00 125.9 145.00 97.50 4 28 DIN69871 5.15
T490LNK-D80-82-5-INT50-FT
80.00 82.00 125.5 144.60 97.50 5 35 DIN69871 6.08
T490LNKD80-105-4-INT50-FT
80.00 105.00 154.1 173.20 97.50 4 36 DIN69871 7.04
• Remove coolant plug screws (SR M6X..DIN916) prior to attaching extension units
(1) Number of flutes
(2) Number of inserts
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT 1306PNTR-FW (479) • T490 LNMT/LNHT/LNAR 1306 (478)
Shell Base Unit
Extension DC APMX OAL NOF CICT Assembly Screw
T490 LNK-D63-082-4-INT50-FT
63
82 126
4
28
T490 CAP-24-4-20-13FT 106 150 36 SR M12x30 DIN912
T490 CAP-36-4-20-13FT 118 162 40 SR M12X45DIN912 12.9
T490 LNK-D80-082-5-INT50-FT
80
82 125
5
45
T490 CAP-D80-24-25-13FT 106 149 55 SR M16x40 DIN912
105 135 36
T490 LNK-D80-105-4-INT50-FT
T490 CAP-D80-24-4-25-13FT 80 129 159 444 SR M16x40 DIN912
T490 CAP-D80-36-4-25-13FT 141 171 48 SR M16x40 DIN912
Shell locking screw
Coolant plug
screw SR M6x...
Cover screw
SR M3x10DIN7991
screw
SR 34-535-SN
Cover
Spare Parts
Designation
T490LNKD63-082-4-INT50-FT
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M6X6 DIN916 SR M12X12 DIN912
T490LNK-D80-82-5-INT50-FT
SR 34-535-SN BLD T15/S7 SW6-T-SH PG D63 SR M3X0.5X10DIN7991 10.9
T490LNKD80-105-4-INT50-FT
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M6X8 DIN916 PG D63 SR M3X0.5X10DIN7991 10.9
T490 LNK-INT50-FT
Basic Units of Modular Extended
Flute Endmills with DIN 69871
Tapered Shanks Carrying
T490 LNMT/HT 1306 Inserts
247
EXTENDED FLUTE CUTTERS
T490 CAP-FT
DC
LBX
LF
APMX
Shank
DF
Designation
DC APMX LBX LF DF NOF(1) CICT(2) Shank
kg
T490LNK-D63-082-4-BT50-FT
63.00 82.00 107.0 145.00 100.00 4 28 BT MAS-403 5.32
T490LNK-D80-105-4-BT50-FT
80.00 105.00 135.2 173.20 100.00 4 36 BT MAS-403 7.35
• Remove coolant plug screws (SR M6X..DIN916) prior to attaching extension units
(1) Number of flutes
(2) Number of inserts
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT 1306PNTR-FW (479) • T490 LNMT/LNHT/LNAR 1306 (478)
Shell Base Unit
Extension DC APMX OAL NOF CICT NOFAssembly Screw
T490 LNK-D63-082-4-BT50-FT
63
82 107
4
28
T490 CAP-D63-24-4-20-13FT 106 131 36 SR M12x30 DIN912
T490 CAP-D63-36-4-20-13FT 118 143 40 SR M12X45DIN912 12.9
T490 LNK-D80-105-4-BT50-FT
80
105 135
4
36
T490 CAP-D80-24-4-25-13FT 129 159 44 SR M16x40 DIN912
T490 CAP-D80-36-4-25-13FT 141 171 48 SR M16x40 DIN912
Spare Parts
Designation
T490LNK-D63-082-4-BT50-FT
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M6X6 DIN916 SR M12X12 DIN912
T490LNK-D80-105-4-BT50-FT
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M6X8 DIN916 PG D63 SR M3X0.5X10DIN7991 10.9
T490 LNK-BT-FT
Basic Units of Modular Extended
Flute Endmills with BT MAS-403
Tapered Shanks Carrying T490
LNMT/HT 1306 Inserts
DHUB
DCONMS
DC
OAL
KAPR
APMX
DCX
Designation
DC KAPR(2) APMX DCX(3) NOF(4) ZNP(5) OAL DHUB DCONMS Arbor(6)
kg
T422 SM-D050-12-3-32-13 (1)
50.00 22.5 12.20 110.10 3 9 60.00 78.00 32.00 A 1.92
T425 SM-D050-13-3-32-13
50.00 25.0 13.55 109.20 3 9 60.00 78.00 32.00 A 1.85
T430 SM-D050-16-3-32-13
50.00 30.0 16.00 107.20 3 9 60.00 78.00 32.00 A 1.81
T440 SM-D050-28-3-27-13
50.00 40.0 28.88 118.80 3 12 65.00 60.00 27.00 A 1.99
T445 SM-D050-23-3-27-13
50.00 45.0 23.50 98.20 3 9 55.00 60.00 27.00 A 1.17
T445 SM-D050-47-3-32-13
50.00 45.0 47.50 145.60 3 18 76.00 80.00 32.00 A 3.41
T450 SM-D050-25-3-27-13
50.00 50.0 26.12 94.30 3 9 55.00 60.00 27.00 A 0.13
T460 SM-D050-30-3-27-13
50.00 60.0 30.00 85.20 3 9 55.00 60.00 27.00 A 0.96
T470 SM-D050-33-3-27-13
50.00 70.0 33.20 74.30 3 9 60.00 58.00 27.00 A 0.86
T475 SM-D050-34-3-27-13
50.00 75.0 34.50 68.60 3 9 55.00 60.00 27.00 A 0.73
T475 SM-D050-56-3-32-13
50.00 75.0 57.70 81.00 3 15 83.50 78.00 32.00 A 1.52
• Note: RPM should be considered according to the recommended speed applied on the outer diameter obtained by the specific D.O.C.
• For user guide, see pages 542-547
(1) On request
(2) Tool cutting edge angle
(3) Cutting diameter maximum
(4) Number of flutes
(5) Number of peripheral inserts
(6) For adaptation options, see page 548
For inserts, see pages: T490 LNAR-P (464) • T490 LNMT 1306PNTR-FW (463) • T490 LNMT/LNHT/LNAR 1306 (462)
Spare Parts
Designation
T422 SM-D050-12-3-32-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M16X40DIN912
T425 SM-D050-13-3-32-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M16X40DIN912
T430 SM-D050-16-3-32-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M16X40DIN912
T440 SM-D050-28-3-27-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X45DIN912
T445 SM-D050-23-3-27-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X35DIN912
T445 SM-D050-47-3-32-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M16X50 DIN912
T450 SM-D050-25-3-27-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X35DIN912
T460 SM-D050-30-3-27-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X35DIN912
T470 SM-D050-33-3-27-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X50DIN912
T475 SM-D050-34-3-27-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M12X35DIN912
T475 SM-D050-56-3-32-13
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M16X60DIN912
T4..-SM Conical Shell Mills
Conical Extended Flute Shell Mills
Carrying T490 LNMT/LNHT 13...
Tangentially Clamped Inserts
ISCAR
248
EXTENDED FLUTE CUTTERS
APMX
OAL
DCONMS DHUB
DC
Designation
DC APMX OAL NOF(1) CICT(2) DHUB DCONMS Arbor(3)
kg
T490 SM D63-47-3-27-16
63.00 47.00 68.00 3 9 58.00 27.00 A 0.93 SR 14-591 BLD T20/M7 SW6-T
(1) Number of flutes
(2) Number of inserts
(3) For adaptation options, see page 548
For inserts, see pages: T490 LNAR-P (480) • T490 LNMT/LNHT 1607 (480)
T490 SM-16
Extended Flute Shell Mills
Carrying T490 LNMT/HT 1607...
Tangentially Clamped Inserts
The table and figures below show the applicability of the conical extended
flute cutters carrying inserts with different corner radii.
Recommended Applications
KAPR
RE RE
For indexable inserts T490 LNHT 1306… with a corner
radius of 4 mm and more, the tool body mast be modified
according to Fig. 3.
KAPR - Tool cutting edge angle
Required to make a modification in the tool body
Fig. 2
Fig. 1
RE
KAPR
Fig. 3
R=RE+0.7
Machined
surface
Description
KAPR
Application Fig. for RE
0.8 1.2 1.6 2.4 3.1 4.0 5.0 6.0 6.4
T422 SM-D050-12-3-32-13
22.5 Fig. 1 & 2 Fig. 2 Fig. 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 2 Fig. 2 Fig. 2 Fig. 2
T425 SM-D050-13-3-32-13
25 Fig. 1 & 2 Fig. 2 Fig. 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2
T430 SM-D050-16-3-32-13
30 Fig. 1 & 2 Fig. 2 Fig. 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2
T440 SM-D050-28-3-27-13
40 Fig. 2 Fig. 2 Fig. 2 Fig. 2 Fig. 2 Fig. 2 Fig. 2 Fig. 2 Fig. 2
T445 SM-D050-23-3-27-13
45 Fig. 1 & 2 Fig. 2 Fig. 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 2 Fig. 2 Fig. 2 Fig. 2
T450 SM-D050-25-3-27-13
50 Fig. 1 & 2 Fig. 2 Fig. 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 2 Fig. 2 Fig. 2 Fig. 2
T460 SM-D050-30-3-27-13
60 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2
T470 SM-D050-33-3-27-13
70 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2
T475 SM-D050-34-3-27-13
75 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2 Fig. 1 & 2
KAPR
249
EXTENDED FLUTE CUTTERS
DC DCONMS DHUB
APMX
OAL
Designation
DC APMX NOF(1) CICT(2) OAL DHUB DCONMS Arbor(3)
kg
H490 SM D063-48-3-27-17C
63.00 46.50 3 9 70.00 59.40 27.00 A 1.93 SR 14-591 BLD T20/M7 SW6-T SR M12X50DIN912
H490 SM D063-60-3-27-17C
63.00 58.50 3 12 85.00 59.40 27.00 A 1.13 SR 14-591 BLD T20/M7 SW6-T SR M12X60DIN912
H490 SM D080-48-4-32-17C
80.00 46.50 4 12 70.00 76.40 32.00 A 1.56 SR 14-591 BLD T20/M7 SW6-T SR M16X40DIN912
(1) Number of flutes
(2) Number of inserts
(3) For adaptation options, see page 548
For inserts, see pages: H490 ANKX/ANCX-17 (472)
H490 SM-17
Extended Flute Shell Mills
Carrying H490 ANKX 17..
Double-Sided Rectangular Inserts
with 4 Helical Cutting Edges
OAL
APMX
DC DCONMS DHUB
Designation
DC APMX NOF(2) DCONMS CICT(3) OAL DHUB Arbor(4)
kg
SDK D050-48-03-22-10-C
50.00 48.00 3 22.00 18 75.00 48.00 A 0.54 SR M3.5X0.6-L8.5 IP10 BLD IP10/S7 SW6-SD SR M10X60DIN912
SDK D050-48-03-27-10-C
50.00 48.00 3 27.00 18 80.00 49.00 A 0.57 SR M3.5X0.6-L8.5 IP10 BLD IP10/S7 SW6-SD SR M12X65 DIN912
SDK D050-48-04-27-10-C
50.00 48.00 4 27.00 24 80.00 49.00 A 0.56 SR M3.5X0.6-L8.5 IP10 BLD IP10/S7 SW6-SD SR M12X65 DIN912
SDK D050-48-04-27-10-HP (1)
50.00 48.00 4 27.00 24 80.00 49.00 A 0.57 SR M3.5X0.6-L8.5 IP10 BLD IP10/S7 SW6-SD SR M12X65 DIN912
SDK D063-56-04-27-10-C
63.00 56.00 4 27.00 28 80.00 60.00 A 0.90 SR M3.5X0.6-L8.5 IP10 BLD IP10/S7 SW6-SD SR M12X65 DIN912
SDK D080-64-05-32-10-C
80.00 64.00 5 32.00 40 85.00 78.00 A 1.61 SR M3.5X0.6-L8.5 IP10 BLD IP10/S7 SW6-SD SR M16X65 DIN912
(1) Designed with coolant nozzles for high pressure coolant
(2) Number of flutes
(3) Number of inserts
(4) For adaptation see page 548
For inserts, see pages: SDHT/W 100408 (498)
SDK-10-C/HP
Extended Flute Shell Mills Carrying
SDHW/T 100408... Inserts
ISCAR
250
EXTENDED FLUTE CUTTERS
OAL
APMX
DC DCONMS DHUB
Designation
DC APMX NOF(2) DCONMS CICT(3) OAL DHUB Arbor(4)
kg
SDK D63-55-05-27-12-C
63.00 55.00 5 27.00 25 80.00 60.00 A 0.94
SDK D63-55-05-27-12-HP (1)
63.00 55.00 5 27.00 25 80.00 60.00 A 0.94
SDK D63-66-04-27-12-C
63.00 66.00 4 27.00 24 93.00 60.00 A 1.07
SDK D63-98-04-27-12-C
63.00 98.00 4 27.00 36 125.00 60.00 A 1.38
SDK D80-66-05-32-12-C
80.00 66.00 5 32.00 30 95.00 77.60 A 2.06
SDK D80-109-05-32-12-C
80.00 109.00 5 32.00 50 143.00 77.60 A 3.06
SDK D100-76-06-40-12-C
100.00 76.00 6 40.00 42 110.00 92.00 A 3.97
SDK D100-130-06-40-12-C
100.00 130.00 6 40.00 72 165.00 92.00 A 5.87
(1) With coolant nozzles for high pressure coolant
(2) Number of flutes
(3) Number of inserts
(4) For adaptation see page 548
For inserts, see pages: QDCT-PDN (497) • QDMT 1205..PDTN-M (498) • SDHT/X 120508 (498)
Spare Parts
Designation
SDK D63-55-05-27-12-C
SR M4X0.7-L9.5 IP15-4623 BLD IP15/M7 SW6-T SR M12X65 DIN912
SDK D63-55-05-27-12-HP
SR M4X0.7-L9.5 IP15-4623 BLD IP15/M7 SW6-T SR M12X65 DIN912
SDK D63-66-04-27-12-C
SR M4X0.7-L9.5 IP15-4623 BLD IP15/M7 SW6-T SR M12X80DIN912
SDK D63-98-04-27-12-C
SR M4X0.7-L9.5 IP15-4623 BLD IP15/M7 SW6-T SR M12X110DIN912
SDK D80-66-05-32-12-C
SR M4X0.7-L9.5 IP15-4623 BLD IP15/M7 SW6-T SR M16X70DIN912
SDK D80-109-05-32-12-C
SR M4X0.7-L9.5 IP15-4623 BLD IP15/M7 SW6-T SR M16X120 DIN912
SDK D100-76-06-40-12-C
SR M4X0.7-L9.5 IP15-4623 BLD IP15/M7 SW6-T SR M20X85 DIN912
SDK D100-130-06-40-12-C
SR M4X0.7-L9.5 IP15-4623 BLD IP15/M7 SW6-T SR M20X140 DIN912
SDK-12-C/HP
Extended Flute Shell Mills
Carrying SDHT 1205... Inserts
OAL
APMX
DC DCONMS DHUB
Rd°
Designation
DC APMX NOF(1) CICT(2) OAL DHUB DCONMS Arbor(3) RMPX°(4)
kg
SM D50-25-27-M
50.00 25.00 3 6 56.00 47.70 27.00 A 0.9 0.43
SM D63-38-27-M
63.00 38.00 4 12 60.00 55.00 27.00 A 0.7 0.67
(1) Number of flutes
(2) Number of inserts
(3) For adaptation options, see page 548
(4) Maximum ramping angle
For inserts, see pages: ADCR 1505PDFR (456) • ADCT 1505PDFR-HM (457) • ADKR 1505PDR/L-HM (456) • ADKT 1505..R/L-HM (459)
• ADKT 1505PDR/L-HM (458) • ADKT 1505PDTR-76 (459) • ADKT 1505PDTR/L-RM (458) • ADMT 1505PDR-HS (458) • HM90 ADCT 1505 (455)
• HM90 ADCT 1505PDR-CF (455) • HM90 ADKT 1505 (454) • HM90 ADKW 1505PDR (462)
Spare Parts
Designation
SM D50-25-27-M
SR 14-544/S BLD T15/M7 SW6-T SR M12X50DIN912
SM D63-38-27-M
SR 14-544/S BLD T15/M7 SW6-T
SM
Extended Flute Shell
Mills Carrying HM90
ADKT 1505... Inserts
251
PLUNGING CUTTERSPLUNGING CUTTERS
PLUNGING CUTTERS
ISCAR
252
PLUNGING CUTTERS
DCONMS
LH
OAL
DC
AE
APMX
Designation
DC AE APMX CICT(1) LH OAL DCONMS Shank(2)
kg
HTP D016-2-L120-C16-LN06
16.00 4.5 2.50 2 32.0 120.00 16.00 C 0.17 SR 14-560-HG T-8/53
HTP D020-3-L150-C20-LN06
20.00 5.0 2.50 3 40.0 150.00 20.00 C 0.33 SR 14-560-HG T-8/53
HTP D025-3-L150-C25-LN06
25.00 5.0 2.50 3 50.0 150.00 25.00 C 0.51 SR 14-560-HG T-8/53
HTP D025-4-L130-C25-LN06
25.00 5.0 2.50 4 50.0 130.00 25.00 C 0.44 SR 14-560-HG T-8/53
• 5 mm side plunging capacity and 2.5 mm maximum face milling DOC • For user guide, see pages 255-257
(1) Number of inserts
(2) C-Cylindrical
For inserts, see pages: HTP LN.. 0604 (536))
Side Step as a Function of the Width of the Plunge
Cutter Diameter (mm)
16 20 25
AE - Width of plunge (mm)
L1 max - Step (effective diameter)
1
7.75 8.72 9.80
2
10.58 12.00 13.56
3
12.49 1428 16.25
4
13.86 16.00 18.33
5
14.83 17.32 20.00
The relationship between the maximal step L1 max and the width of plunge AE is given by the following formula:
L1 max = 2x √DC x AE-AE2
DC: cutter diameter
L1
AE
HTP-LN06
Side Plungers Carrying
Tangentially Clamped Inserts
with 4 Cutting Edges
DC
AE
LF
OAL
DCONMS
APMX DRVS
THSZMS
Designation
DC AE APMX NOF(1) LF OAL DCONMS THSZMS DRVS(2) TQ_3(3)
kg
HTP D16/.62-2-M08-LN06
15.95 4.5 2.50 2 30.00 47.50 13.00 M08 10.0 20 0.03 SR 14-560-HG T-8/53
HTP D20-3-M10-LN06
20.00 5.0 2.50 3 30.00 50.00 18.00 M10 15.0 29 0.06 SR 14-560-HG T-8/53
HTP D25/1.00-3-M12-LN06
25.20 5.0 2.50 3 35.00 57.00 21.00 M12 17.0 33 0.10 SR 14-560-HG T-8/53
• 5 mm side plunging capacity and 2.5 mm maximum face milling DOC • When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and
threaded areas must be thoroughly cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are specified in the
TQ_3 parameter
• For user guide, see pages 255-257
(1) Number of flutes
(2) Clamping wrench size
(3) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: HTP LN.. 0604 (536)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
HTP-M-LN06
Side Plungers with FLEXFIT
Threaded Connection Carrying
Tangentially Clamped Inserts
with 4 Cutting Edges
253
PLUNGING CUTTERS
DC DCONMS
LH
OAL
AE
APMX
Designation
DC AE APMX CICT(1) LH OAL DCONMS Shank(2)
kg
HTP D025-2-L200-C25-LN10
25.00 7.0 3.00 2 120.0 200.00 25.00 C 0.64 SR 34-550 BLD T10/S7 SW6-SD
HTP D032-3-L190-C25-LN10
32.00 8.0 3.00 3 50.0 190.00 25.00 C 0.68 SR 34-550 BLD T10/S7 SW6-SD
HTP D032-3-L210-C32-LN10
32.00 8.0 3.00 3 120.0 210.00 32.00 C 1.09 SR 34-550 BLD T10/S7 SW6-SD
HTP D032-3-L210-W32-LN10
32.00 8.0 3.00 3 120.0 210.00 32.00 W 1.09 SR 34-550 BLD T10/S7 SW6-SD
HTP D040-4-L250-C32-LN10
40.00 8.0 3.00 4 50.0 250.00 32.00 C 1.49 SR 34-550 BLD T10/S7 SW6-SD
• 8 mm side plunging capacity and 3 mm maximum face milling DOC • For user guide, see pages 255-257
(1) Number of inserts
(2) C-Cylindrical, W-Weldon
For inserts, see pages: HTP LN.. 1006 (537)
HTP-LN10
Side Plungers Carrying
Tangentially Clamped Inserts
with 4 Cutting Edges
DC
AE
LF
OAL
DCONMS
APMX DRVS
THSZMS
Designation
DC AE APMX CICT(1) LF OAL DCONMS THSZMS DRVS(2) TQ_3(3)
kg
HTP D025-2-M12-LN10
25.00 7.0 3.00 2 35.00 57.00 21.00 M12 17.0 33 0.09 SR 34-550 BLD T10/S7 SW6-SD
HTP D032-3-M16-LN10
32.00 8.0 3.00 3 35.00 60.00 29.00 M16 25.0 40 0.16 SR 34-550 BLD T10/S7 SW6-SD
HTP D035-3-M16-LN10
35.00 8.0 3.00 3 43.00 68.00 29.00 M16 25.0 40 0.22 SR 34-550 BLD T10/S7 SW6-SD
HTP D042-4-M16-LN10
42.00 8.0 3.00 4 43.00 68.00 29.00 M16 25.0 40 0.26 SR 34-550 BLD T10/S7 SW6-SD
• 8 mm side plunging capacity and 3 mm maximum face milling DOC • When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and
threaded areas must be thoroughly cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are specified in the
TQ_3 parameter
• For user guide, see pages 255-257
(1) Number of inserts
(2) Clamping wrench size
(3) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: HTP LN.. 1006 (537)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
HTP-M-LN10
Side Plungers with FLEXFIT
Threaded Connection Carrying
Tangentially Clamped Inserts
with 4 Cutting Edges
ISCAR
254
PLUNGING CUTTERS
OAL
DHUB
DCONMS
DC AE
A
APMX
0.5
Designation
DC AE APMX CICT(1) OAL DHUB DCONMS Arbor(2)
kg
HTP D050-04-22-R-LN16
50.00 13.0 3.00 4 50.00 48.00 22.00 A 0.37 SR 34-535 BLD T15/S7 SW6-T-SH SR PS 118-0271C
HTP D052-04-22-R-LN16
52.00 13.0 3.00 4 50.00 48.00 22.00 A 0.39 SR 34-535 BLD T15/S7 SW6-T-SH SR PS 118-0271C
HTP D063-05-27-R-LN16
63.00 14.0 3.00 5 50.00 59.00 27.00 A 0.53 SR 34-535 BLD T15/S7 SW6-T-SH SR M12X30C
HTP D066-05-27-R-LN16
66.00 14.0 3.00 5 50.00 62.00 27.00 A 0.60 SR 34-535 BLD T15/S7 SW6-T-SH SR M12X30C
HTP D080-06-27-R-LN16
80.00 14.0 3.00 6 50.00 65.00 27.00 A 0.81 SR 34-535 BLD T15/S7 SW6-T-SH SR M12X30C
HTP D080-06-31.75-R-LN16
80.00 14.0 3.00 6 63.00 76.00 31.75 A 1.20 SR 34-535 BLD T15/S7 SW6-T-SH SR M16X40C
HTP D080-06-32-R-LN16
80.00 14.0 3.00 6 50.00 72.00 32.00 A 0.90 SR 34-535 BLD T15/S7 SW6-T-SH SR M16X40C
HTP D100-07-31.75-R-LN16
100.00 14.0 3.00 7 63.00 96.00 31.75 B 2.23 SR 34-535 BLD T15/S7 SW6-T-SH SR M16X40C
HTP D100-07-32-R-LN16
100.00 14.0 3.00 7 50.00 78.00 32.00 B 1.28 SR 34-535 BLD T15/S7 SW6-T-SH
• 14 mm side plunging capacity and 3 mm maximum face milling DOC • For user guide, see pages 255-257
(1) Number of inserts
(2) For adaptation see page 548
For inserts, see pages: HTP LN.. 1606 (537)
Slot / Bore ShoulderFace Milling Spot Face
A
Fz max =
0.3 mm/tooth
Reverse
Unique ISCAR
Feature
Rear Cutting Edge
HTP-R-LN16
Shell Mill Plungers Carrying
Tangentially Clamped Inserts
with 4 Cutting Edges
DHUB
DC
DCONMS
OAL
AE
APMX
Designation
DC APMX AE CICT(1) OAL DHUB DCONMS Arbor(2)
kg
HTP D040-4-16-R-LN10
40.00 3.00 8.0 4 40.00 38.00 16.00 A 0.20 SR 34-550 BLD T10/S7 SW6-SD SR M8X30DIN912
HTP D050-5-22-R-LN10
50.00 3.00 8.0 5 40.00 48.00 22.00 A 0.31 SR 34-550 BLD T10/S7 SW6-SD SR M10X25C
HTP D052-5-22-R-LN10
52.00 3.00 8.0 5 40.00 48.00 22.00 A 0.34 SR 34-550 BLD T10/S7 SW6-SD SR M10X25C
• 8 mm side plunging capacity and 3 mm maximum face milling DOC • For user guide, see pages 255-257
(1) Number of inserts
(2) For adaptation see page 548
For inserts, see pages: HTP LN.. 1006 (537)
Slot/Bore Shoulder
Face Milling Spot Facing
HTP-R-LN10
Shell Mill Plungers Carrying
Tangentially Clamped Inserts
with 4 Cutting Edges
255
PLUNGING CUTTERS
Plunging Cycle:
Step 1 Step 2 Step 3
Plunge in (axially-Z direction) Back stroke (rapid) at an angle b≥2° Move to the next cycle
β
β
Control movement
Rapid movement
- Exit angle from the material
TANGPLUNGE - SIDE PLUNGING
Workpiece Material
Insert
HTP LN…
type
Carbide
grade
for
inserts
Cutting
speed Vc,
m/min
Feed Fz,
mm/t Coolant
ISO
class
Description
ISCAR mat.
group*
Typical Representative
Hardness
HB
DIN/
ISO
513
AISI/SAE/
ASTM
DIN
W.-Nr.
P
Non-alloy steel and cast
steel, free cutting steel 4 1060 1.1221 180-200
…ER
IC830/
IC928
80-130 0.12-0.15
Air blow
Low alloy and cast steel (less
than 5% of alloying elements) 8 4340 1.6582 260-300 80-120 0.1-0.15
Low alloy and cast steel (less
than 5% of alloying elements) 9 3135 1.571 HRC
35-40** 80-120 0.08-0.15
High alloy steel 10 H13 1.2344 200-220 80-100 0.08-0.12
Martensitic s.s. 12 420 1.4021 200
IC830/
IC330/
IC328
80-100 0.08-0.12 Air blow/wet
MAustenitic s.s. 14 304L 1.4306 200 …ER
IC830/
IC330/
IC328
60-80 0.08-0.1 Wet (emulsion)
K
Grey cast iron 16 Class 40 0.6025
(GG25) 250
…ER IC810/
IC910
150-200 0.12-0.2
Air blow
Nodular cast iron 17 Class
65-45-12
0.7050
(GGG50) 200 100-180 0.1-0.17
S
Ni-based HTSA 34 Inconel 718 2.4668 350
…ER IC328/
IC330
20-25 0.07-0.1
Wet (emulsion)
Ti alloys 37 Ti6Al4V
(Grade 5) 3.7164 HRC
34-36 35-40 0.07-0.1
HHardened steel 38 4340 1.6582 HRC 45
max …ETR IC808/
IC908 70-100 0.08-0.1 Air blow
The table data refers to a cutter overhang of up to 4D (D-the diameter of a cutter)
* ISCAR material group in accordance with VDI 3323 standard
** Quenched and tempered
Table 1: L1 as a Function of the Width of Cut and Cutter Diameter
L1max = 2x Dxae-ae2
ae -
Width of
Plunge (mm)
Cutter Diameter (mm)
50 52 63 66 80 100
L1max - Step (effective diameter)
ae
L1
114.0 14.3 15.75 16.1 17.8 19.9
323.8 24.3 26.8 27.5 30.4 34.1
530.0 30.6 34.0 34.9 38.7 43.6
632.5 33.2 37.0 37.9 42.1 47.5
734.7 35.5 39.6 40.6 45.2 51.0
836.6 37.5 41.9 43.0 48.0 54.3
938.5 39.3 43.10 45.3 50.5 57.2
10 40.0 41.0 46.0 47.3 52.9 60.0
11 41.4 42.5 47.8 49.2 55.1 62.6
12 42.7 43.8 49.5 50.9 57.1 65.0
L1- Side step over
ae- Width of plunge
13 43.8 45.0 51.0 52.5 59.0 67.3
14 - - 52.4 53.9 60.8 69.4
Recommended Cutting Conditions for Side Plunging
ISCAR
256
PLUNGING CUTTERS
Recommended Cutting Conditions for Slot Plunging
L max
L- Width of Cut (mm)
TANGPLUNGE - SLOT PLUNGING
Workpiece Material
Insert
HTP LN…
type
Carbide
grade for
inserts
Cutting
speed Vc,
m/min
Feed Fz,
mm/t Coolant
ISO
class
Description
ISCAR
mat.
group*
Typical Representative
Hardness
HB
DIN/
ISO
513
AISI/SAE/
ASTM DIN W.-Nr.
P
Non-alloy steel and cast
steel, free cutting steel 4 1060 1.1221 180-200
…ER
IC830/
IC928
80-120 0.1-0.15
Air blow
Low alloy and cast
steel (less than 5% of
alloying elements)
8 4340 1.6582 260-300 80-120 0.1-0.12
Low alloy and cast
steel (less than 5% of
alloying elements)
9 3135 1.571 HRC
35-40** 80-120 0.08-0.12
High alloy steel 10 H13 1.2344 200-220 80-100 0.08-0.1
Martensitic s.s. 12 420 1.4021 200
IC830/
IC330/
IC328
80-100 0.08-0.1 Air blow/
wet
MAustenitic s.s. 14 304L 1.4306 200 …ER
IC830/
IC330/
IC328
60-80 0.08-0.1 Wet
(emulsion)
K
Grey cast iron 16 Class 40 0.6025 (GG25) 250
…ER IC810/
IC910
150-200 0.12-0.18
Air blow
Nodular cast iron 17 Class
65-45-12
0.7050
(GGG50) 200 100-180 0.1-0.15
S
Ni-based HTSA 34 Inconel
718 2.4668 350
…ER IC328/
IC330
20-25 0.07-0.09 Wet
(emulsion)
Ti alloys 37 Ti6Al4V
(Grade 5) 3.7164 HRC 34-36 35-40 0.07-0.09
HHardened steel 38 4340 1.6582 HRC 45
max …ETR IC808/
IC908 70-100 0.08-0.09 Air blow
The table data refers to a cutter overhang of up to 4D (D-the diameter of a cutter)
* ISCAR material group in accordance with VDI 3323 standard
** Quenched and tempered
257
PLUNGING CUTTERS
Recommended Cutting Conditions for Face Milling
Ae
Ap
TANGPLUNGE - FACE MILLING
Workpiece Material
Insert HTP
LN… type
Carbide
grade for
inserts
Cutting
speed Vc,
m/min
Feed Fz,
mm/t Coolant
ISO
class
Description
ISCAR
mat.
group*
Typical Representative
Hardness
HB
DIN/
ISO
513
AISI/SAE/
ASTM DIN W.-Nr.
P
Non-alloy steel and cast
steel, free cutting steel 4 1060 1.1221 180-200
…ER
IC830/
IC928
80-120 0.1-0.2
Air blow
Low alloy and cast
steel (less than 5% of
alloying elements)
8 4340 1.6582 260-300 80-120 0.1-0.18
Low alloy and cast
steel (less than 5% of
alloying elements)
9 3135 1.571 HRC
35-40** 80-120 0.1-0.15
High alloy steel 10 H13 1.2344 200-220 80-100 0.08-
0.15
Martensitic s.s. 12 420 1.4021 200
IC830/
IC330/
IC328
80-100 0.08-
0.15
Air blow/
wet
MAustenitic s.s. 14 304L 1.4306 200 …ER
IC830/
IC330/
IC328
60-80 0.08-0.1 Wet
(emulsion)
K
Grey cast iron 16 Class 40 0.6025 (GG25) 250
…ER IC810/
IC910
150-200 0.12-0.2
Air blow
Nodular cast iron 17 Class
65-45-12
0.7050
(GGG50) 200 100-180 0.1-0.18
S
Ni-based HTSA 34 Inconel
718 2.4668 350
…ER IC328/
IC330
20-25 0.08-
0.12 Wet
(emulsion)
Ti alloys 37 Ti6Al4V
(Grade 5) 3.7164 HRC 34-36 35-40 0.08-
0.12
HHardened steel 38 4340 1.6582 HRC 45
max …ETR IC808/
IC908 70-100 0.08-0.1 Air blow
The table data refers to a cutter overhang of up to 4xD and the maximal width of cut Ae=0.7xD (D-the diameter of a cutter)
The maximal depth of cut Ap is 2.5 mm for hardened steel and 3 mm for other material groups
* ISCAR material group in accordance with VDI 3323 standard
** Quenched and tempered
ISCAR
258
PROFILING TOOLS
PROFILING TOOLS
259
PROFILING TOOLS
Ball Nose Selection Guide
Tools Pages
DCX
Inserts
0.4-7 8 9 10 12 16 20 25 30 32 40 50
EB...
Solid Carbide
Multi-Master
163
70 • •••••••
HCM D..
HCM-M
HCM-MM
262
264
265
•••••
HBF-QF
HBR-QF
HCR-QF
HCR-QP
BCM 267 •••••••• BCR D...-QT
BCR D...-CS
BLP
BLP -M
265
266 ••••••• BLR D...-QT
BLR D...-MFW
BLR D...-QCS
SELECTION GUIDE
TABLE OF CONTENTS
Ball Nose Endmills .....................................................................................262
TORMILL - Toroidal Endmills and Face Mills ...............................................269
TOR6MILL - Multifunction Cutters ..............................................................272
Round Cornered Cutters ...........................................................................277
MILLSHRED ..............................................................................................279
HELIDO ROUND H400 Line ....................................................................... 282
FLEXFIT Adaptation Systems ..................................................................... 312
ISCAR
260
PROFILING TOOLS
Face Mills 90° Selection Guide
IC
DCX
Tools Pages
DCX 10 12 15 16 20 25 32 35 40 42 50 52 63 66 80 100 125 160
Inserts
IC
Toroidal
E93CN
F93CN
269
271 • • • • • • • • CNHT
ENHT
TR6 ER
TR6 FR
272
275
5-7
••••••••••••
TR6 TNCU
TR90 TXMT
TRFF TXMT
TR45 TXMT
ER 277
5-8
•••••••••• RXCR...
RXCW...
FRMT 278
10-12
• • • RPHX/RPMX
FRN 278
12
••• RNGN
H400 ER-10
H400 FR-10
ER-10
282
283
277
10
••••• •
H400 RNHU 10…
RXCW 10...
RXCR 10...
RXMT 10...
H400 ER-12
H400 FR-12
ERW-12
FRW-12
282
284
279
281
12
•• • •••••
RCMT 12…
RCCW 12…
RCCT 12…
R90MT 12…
H400 RNHU 12…
H606 ER-M
H606 FR-12
285
286
12
• • • • • • H606 RXCU 1206
H400 FR-16
FRW-16
ER-16
285
281
277
16
• • • • • • • • H400 RNHU 16…
RCMW 16…
RCCW 16…
FRW-20 281
20
• • • • RCCW 20…
RCMW 20…
SELECTION GUIDE
261
PROFILING TOOLS
MULTI-MASTER and FLEXFIT Connection Options
MILLING HEADS ADAPTERS SHANKS
FLEXFIT (M)
MULTI-MASTER (MM)
Features
Modular system reduces stock cost by using the same head with different shank options, enables machining
with larger overhang, and the same head can be mounted on metric and inch combinations.
ISCAR
262
PROFILING TOOLS
BD
DCX
RE
LH
OAL
DCONMS
A
B/D
BHTA
Designation
DCX(1) RE LH(2) OAL(3) DCONMS Shank(4) BHTA BD Type
kg
HCM D10-A-L090-C10
10.00 5.00 25.0 90.00 10.00 C - 9.20 A 0.05 SR 10504694 BLD T15/S7 SW6-T-SH
HCM D10-B-L125-C16
10.00 5.00 40.0 125.00 16.00 C 6.0 - B 0.16 SR 10504694 BLD T15/S7 SW6-T-SH
HCM D10-D-L150-C12
10.00 5.00 50.0 150.00 12.00 C 1.8 - D 0.12 SR 10504694 BLD T15/S7 SW6-T-SH
• The dimensions are for HBR inserts • For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Refers to HBR inserts
(3) Refers to HBR inserts
(4) C-Cylindrical
For inserts, see pages: HBR-QF (533) • HCR (533)
HCM D10
Ball Nose Multifunction
Endmills D=10 mm
BD
DCX
RE
BHTA
LH OAL
DCONMS
A
B/D
Designation
DCX(1) RE LH(2) OAL(3) DCONMS Shank(4) BHTA BD Type
kg
HCM D12-A-L120-C12
12.00 6.00 30.0 120.00 12.00 C - 10.60 A 0.10 SR 34-540 BLD T15/S7 SW6-T
HCM D12-B-L160-C20
12.00 6.00 50.0 160.00 20.00 C 5.0 - B 0.32 SR 34-540 BLD T15/S7 SW6-T
HCM D12-D-L160-C16
12.00 6.00 60.0 160.00 16.00 C 1.0 - D 0.21 SR 34-540 BLD T15/S7 SW6-T
• The dimensions are for HBR inserts • For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Refers to HBR inserts
(3) Refers to HBR inserts
(4) C-Cylindrical
For inserts, see pages: HBF-QF (533) • HBR-QF (533) • HCC-QF (534) • HCD-QF (534) • HCR (533)
HCM D12
Ball Nose Multifunction
Endmills D=12 mm
A
B/D
BD
DCX
RE
LH OAL
DCONMS
BHTA
Designation
DCX(1) LH(2) OAL(3) DCONMS Shank(4) BHTA BD Type
kg
HCM D16-A-L130-C16
16.00 36.0 130.00 16.00 C - 14.40 A 0.18 SR 10503579 BLD T20/S7 SW6-T
HCM D16-B-L160-C25
16.00 60.0 160.00 25.00 C 5.0 - B 0.49 SR 10503579 BLD T20/S7 SW6-T
HCM D16-D-L160-C20
16.00 65.0 160.00 20.00 C 1.0 - D 0.32 SR 10503579 BLD T20/S7 SW6-T
• The dimensions are for HBR inserts • For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Refers to HBR inserts
(3) Refers to HBR inserts
(4) C-Cylindrical
For inserts, see pages: HBF-QF (533) • HBR-QF (533) • HCC-QF (534) • HCD-QF (534) • HCR (533)
HCM D16
Ball Nose Multifunction
Endmills D=16 mm
263
PROFILING TOOLS
BD
DCX
RE
LH
OAL
DCONMS
A
D
BHTA
Designation
DCX(1) LH(2) OAL(3) DCONMS Shank(4) BHTA BD Type
kg
HCM D20-A-L150-C20
20.00 60.0 150.00 20.00 C - 18.00 A 0.32 SR 1052964 BLD T25/S7 SW6-T
HCM D20-D-L200-C25
20.00 90.0 200.00 25.00 C 1.0 - D 0.61 SR 1052964 BLD T25/S7 SW6-T
• The dimensions are for HBR inserts • For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Refers to HBR inserts
(3) Refers to HBR inserts
(4) C-Cylindrical
For inserts, see pages: HBF-QF (533) • HBR-QF (533) • HCC-QF (534) • HCD-QF (534) • HCR (533)
HCM D20
Ball Nose Multifunction
Endmills D=20 mm
BD
DCX
RE
LH OAL
DCONMS
A
D
BHTA
Designation
DCX(1) LH(2) OAL(3) DCONMS Shank(4) BHTA BD Type
kg
HCM D25-A-L170-C25
25.00 70.0 170.00 25.00 C - 22.00 A 0.55 SR 1051666 BLD T25/S7 SW6-T
HCM D25-D-L250-C32
25.00 125.0 250.00 32.00 C 1.8 - D 1.20 SR 1051666 BLD T25/S7 SW6-T
• The dimensions are for HBR inserts • For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Refers to HBR inserts
(3) Refers to HBR inserts
(4) C-Cylindrical
For inserts, see pages: HBF-QF (533) • HBR-QF (533) • HCC-QF (534) • HCD-QF (534) • HCR (533)
HCM D25
Ball Nose Multifunction
Endmills D=25 mm
ISCAR
264
PROFILING TOOLS
DCONMS
DRVS
DCX
OAL
LF
THSZMS
Designation
DCX(1) LF(2) OAL(3) DCONMS DRVS(4) THSZMS TQ_3(5)
kg
HCM D12/.50-M08
12.00 26.00 43.50 14.40 11.0 M08 20 0.03
HCM D16/.62-M08
16.00 30.00 47.50 14.40 11.0 M08 20 0.03
HCM D16/.62-M10
16.00 35.00 55.00 18.00 15.0 M10 29 0.05
HCM D20/.75-M10
20.00 37.00 57.00 18.00 15.0 M10 29 0.06
HCM D20/.75-M12
20.00 37.00 59.00 22.50 17.0 M12 33 0.07
HCM D25/1.0-M12
25.00 46.00 68.00 21.00 19.0 M12 33 0.11
HCM D25/1.0-M16
25.00 46.00 71.00 29.00 25.0 M16 40 0.16
• The dimensions are for HBR inserts • For user guide, see pages 542-547• When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces
and threaded areas must be thoroughly cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are specified in the
TQ_3 parameter
(1) Cutting diameter maximum
(2) Refers to HBR inserts
(3) Refers to HBR inserts
(4) Clamping wrench size
(5) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: HBF-QF (533) • HBR-QF (533) • HCC-QF (534) • HCD-QF (534) • HCR (533)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
Parts for Assembly
Milling Head Adapter Shank Assembly Dimensions
DCX LH OAL BHTA DCONMS Shank Inserts
HCM D12/.50-M8
–—
S M08-L73-C16 12 51 99 4 16 C
HBR HBF
HCR
HCD
HCC
S M08-L128-C16 12 106 154 4 16 C
S M08-L170-C20 12 93 196 4 20 C
HCM D12/.50-M8
CAB M08M10
S M10-L80-C20 12 96 146 4 20 C
S M10-L130-C20 12 146 196 4 20 C
S M10-L200-C25 12 123 266 4 25 C
HCM D16/.62-M8
–—
S M8-L73-C16 16 55 103 —16 C
S M8-L128-C16 16 110 158 —16 C
S M8-L170-C20 16 97 200 0.96 20 C
HCM D16/.62-M8
CAB M08M10
S M10-L80-C20 16 100 150 1.24 20 C
S M10-L130-C20 16 150 200 0.8 20 C
S M10-L200-C25 16 127 270 2.16 25 C
HCM D16/.62-M10
S M10-L80-C20 16 60 110 2.5 20 C
S M10-L130-C20 16 110 160 2.5 20 C
S M10-L200-C25 16 87 230 3.26 25 C
HCM D16/.62-M10
CAB M10M12 S M12-L86-C25 16 105 161 2.65 25 C
S M12-C32-L200 16 153 275 3.157 32 C
HCM D20/.75-M10
–—
S M10-L80-C20 20 67 117 –20 C
S M10-L130-C20 20 117 167 –20 C
S M10-L200-C25 20 94 237 1.7 25 C
HCM D20/.75-M10
CAB M10M12 S M12-L86-C25 20 112 168 1.4 25 C
S M12-L200-C32 20 160 282 2.3 32 C
HCM D20/.75-M12
–— S M12-L86-C25 20 67 123 3.0 25 C
S M12-L200-C32 20 115 237 3.3 32 C
HCM D25/1.0-M12
CAB M12M16 S M16-L95 C32 25 131 191 1.8 32 C
S M16-L230 C32 25 146 326 1.5 32 C
HCM D25/1.0-M16
—S M16-L95 C32 25 81 141 3.5 32 C
S M16-L230 C32 25 96 276 3.5 32 C
HCM-M
Ball Nose Multifunction
Endmills with FLEXFIT
Threaded Adaptation
265
PROFILING TOOLS
DCX
OAL
LF
DCONMS
DRVS
THSZMS
Designation
DCX(1) OAL(2) LF(3) DCONMS THSZMS DRVS(4) TQ TQ_3(5)
kg
HCM D12/.50-MMT08
12.00 28.00 20.00 11.50 T08 10.0 15.0 20 0.01 SR 34-540 BLD T15/S7 SW6-T
HCM D16/.62-MMT10
16.00 36.75 25.00 15.20 T10 13.0 28.0 33 0.03 SR 10503579 BLD T20/S7 SW6-T
HCM D20/.75-MMT12
20.00 48.80 35.00 18.50 T12 15.0 28.0 20 0.06 SR 1052964 BLD T25/S7 SW6-T
HCM D25/1.0-MMT15
25.00 63.00 46.00 24.00 T15 20.0 40.0 33 0.13 SR 1051666 BLD T25/S7 SW6-T
• The dimensions are for HBR inserts • Do not apply lubricant to the MULTI-MASTER threaded connection • For adaptation options, see page 261
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Refers to HBR inserts
(3) Refers to HBR inserts
(4) Width across flats (wrench should be ordered separately)
(5) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: HBF-QF (533) • HBR-QF (533) • HCC-QF (534) • HCD-QF (534) • HCR (533)
For holders, see pages: MM CAB (667) • MM GRT (shanks) (86) • MM S-A (stepped shanks) (84) • MM S-A (straight shanks) (87)
• MM S-A-C# (86) • MM S-A-HSK (609) • MM S-A-N (85) • MM S-A-SK (90) • MM S-B (85° conical shanks) (87) • MM S-D (89° conical shanks) (88)
• MM S-ER (89) • MM S-ER-H (89) • MM TS-A (86)
HCM-MM
Ball Nose Multifunction
Endmills with MULTI-MASTER
Threaded Adaptation
DCONMS
DCX 240°
OAL
LH
APMX
RE
Rd°
Designation
DCX(1) RE APMX NOF(2) OAL LH DCONMS Shank(3) MIID(4)
kg
BLP D16-40-100-C16
16.00 8.00 12.00 3 100.00 40.0 16.00 C BLR D160-MFW 0.12
BLP D20-70-130-C20
20.00 10.00 15.00 3 130.00 70.0 20.00 C BLR D200-MFW 0.24
BLP D25-90-170-W25
25.00 12.50 18.75 3 170.00 90.0 25.00 W BLR D250-MFW 0.49
BLP D30-90-150-W32
30.00 15.00 22.50 3 150.00 90.0 32.00 W BLR D320-QCS 0.60
BLP D32-80-160-W32
32.00 16.00 24.00 3 160.00 80.0 32.00 W BLR D320-QCS 0.74
BLP D40-100-180-W40
40.00 20.00 30.00 3 180.00 100.0 40.00 W BLR D400-QCS 1.25
BLP D50-140-210-W40
50.00 25.00 37.50 3 210.00 140.0 40.00 W BLR D400-QCS 2.00
BLP D50-320-400-W50
50.00 25.00 37.50 3 400.00 320.0 50.00 W BLR D500-QCS 4.62
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of flutes
(3) C-Cylindrical, W-Weldon
(4) Master insert identification
For inserts, see pages: BLR (535)
Spare Parts
Designation
BLP D16-40-100-C16
SR M2.5X0.45-L6 IP7 IP-7/51
BLP D20-70-130-C20
SR M3X0.5-L7.4 IP9 IP-9/151
BLP D25-90-170-W25
SR M3.5X0.6-L8.5 IP10 BLD IP10/S7 SW6-SD
BLP D30-90-150-W32
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T
BLP D32-80-160-W32
SR M4X0.7-L9.6 IP15 BLD IP15/S7 SW6-T
BLP D40-100-180-W40
SR M5-14 IP20 BLD IP20/S7 SW6-T
BLP D50-140-210-W40
SR M6X1-L18 IP25 BLD IP25/S7 SW6-T
BLP D50-320-400-W50
SR M6X1-L18 IP25 BLD IP25/S7 SW6-T
BLP Endmills
Three Flute 240° Ball
Nose Endmills Carrying
Double-Sided Inserts
ISCAR
266
PROFILING TOOLS
DCX
RE
OAL
LF
DCONMS
APMX
DRVS
THSZMS
Rd°
Designation
DCX(1) RE NOF(2) APMX LF OAL THSZMS DCONMS DRVS(3) MIID(4) TQ_3(5)
kg
BLP D16-M08
16.00 8.00 3 12.00 23.00 40.50 M08 13.00 10.0 BLR D160-MFW 20 0.02
BLP D20-M08
20.00 10.00 3 15.00 28.00 45.50 M08 12.80 11.0 BLR D200-MFW 20 0.03
BLP D25-M12
25.00 12.50 3 18.75 35.00 57.00 M12 21.00 17.0 BLR D250-MFW 33 0.07
BLP D30-M12
30.00 15.00 3 22.50 40.00 62.00 M12 21.00 17.0 BLR D300-QCS 33 0.10
BLP D32-M12
32.00 16.00 3 24.00 40.00 62.00 M12 23.00 19.0 BLR D320-MFW 33 0.11
BLP D32-M16
32.00 16.00 3 24.00 40.00 65.00 M16 29.00 24.0 BLR D320-MFW 40 0.14
BLP D40-M16
40.00 20.00 3 30.00 53.00 78.00 M16 30.00 24.0 BLR D320-QCS 40 0.25
• For user guide, see pages 542-547• When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly
cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) Cutting diameter maximum
(2) Number of flutes
(3) Clamping wrench size
(4) Master insert identification
(5) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: BLR (535)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
Spare Parts
Designation
BLP D16-M08
SR M2.5X0.45-L6 IP7 IP-7/51
BLP D20-M08
SR M3X0.5-L7.4 IP9 IP-9/151
BLP D25-M12
SR M3.5X0.6-L8.5 IP10 BLD IP10/S7 SW6-SD
BLP D30-M12
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T
BLP D32-M12
SR M4X0.7-L9.6 IP15 BLD IP15/S7 SW6-T
BLP D32-M16
SR M4X0.7-L9.6 IP15 BLD IP15/S7 SW6-T
BLP D40-M16
SR M5-14 IP20 BLD IP20/S7 SW6-T
BLP-M
Three Flute Fully Effective
240° Ball Nose Endmills with
FLEXFIT Threaded Adaptation
APMX
OAL
DHUBDCONMS
LH
DCX
RE
Rd°
Designation
DCX(1) RE NOF(2) APMX LH OAL DHUB DCONMS MIID(3)
kg
BLP D50-22
50.00 25.00 3 37.50 50.0 83.00 47.00 22.00 BLR D500-MFW 0.61
• Use on face mill adapters with the supplied retention screw • For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of flutes
(3) Master insert identification
For inserts, see pages: BLR (535)
Spare Parts
Designation
BLP D50-22
SR M6X1-L18 IP25 BLD IP25/S7 SW6-T SR M10X1X14-10700(a) SR M10X20-10600(b) HW 5.0
(a) Recommended tightening torque:22 Nxm
(b) Retaining knob for adapters
BLP Shell Mill
Three Flute Fully Effective
240° Ball Nose Cutters with
Shell Hole Adaptation
267
PROFILING TOOLS
LH OAL
DCX
APMX
RE
DCONMS
BHTA
A
B
Rd°
Designation
DCX(2) RE APMX CICT(3) OAL LH DCONMS a° BHTA Shank(4) Type CSP(5) MIID(6)
kg
BCM D12-A-C12
12.00 6.00 11.40 2 120.00 30.0 12.00 - - C A 0 BCR D120-QT 0.10
BCM D12-B-C16
12.00 6.00 11.40 2 160.00 60.0 16.00 2.0 2.0 C B 0 BCR D120-QT 0.22
BCM D16-A-C16-C
16.00 8.00 13.00 2 130.00 36.0 16.00 - - C A 1 BCR D160-QT 0.54
BCM D16-B-C20-C
16.00 8.00 13.00 2 160.00 60.0 20.00 2.2 2.2 C B 1 BCR D160-QT 0.30
BCM D20-A-C20-C
20.00 10.00 17.00 2 160.00 65.0 20.00 - - C A 1 BCR D200-QT 0.29
BCM D20-A-C20-CC (1)
20.00 10.00 17.00 2 160.00 65.0 20.00 - - C A 1 BCR D200-QT 0.31
BCM D20-B-C25-C
20.00 10.00 17.00 2 200.00 90.0 25.00 1.5 1.5 C B 1 BCR D200-QT 0.55
BCM D20-B-C25-CC (1)
20.00 10.00 17.00 2 200.00 90.0 25.00 1.5 1.5 C B 1 BCR D200-QT 0.60
BCM D25-A-W25-C
25.00 12.50 20.00 2 170.00 70.0 25.00 - - W A 1 BCR D250-QT 0.51
BCM D25-B-C32-C
25.00 12.50 20.00 2 220.00 95.0 32.00 2.4 2.4 C B 1 BCR D250-QT 1.05
BCM D30-A-W32-C
30.00 15.00 26.00 2 160.00 67.0 32.00 - - W A 1 BCR D300-QT 0.73
BCM D32-A-W32-C
32.00 16.00 27.00 2 160.00 65.0 32.00 - - W A 1 BCR D320-CS 0.76
BCM D32-B-W40-C
32.00 16.00 27.00 2 250.00 125.0 40.00 2.1 2.1 W B 1 BCR D320-CS 1.75
BCM D40-A-W32-C
40.00 20.00 36.00 2 160.00 88.0 32.00 - - W A 1 BCR D400-CS 0.92
BCM D40-B-W40-C
40.00 20.00 36.00 2 250.00 125.0 40.00 - - W B 1 BCR D400-CS 1.95
BCM D50-A-W50-C
50.00 25.00 43.00 2 212.00 132.0 50.00 - - W A 1 BCR D500-CS 2.42
• For user guide, see pages 542-547
(1) Center Cutting
(2) Cutting diameter maximum
(3) Number of inserts
(4) C-Cylindrical, W-Weldon
(5) 0 - Without coolant supply, 1 - With coolant supply
(6) Master insert identification
For inserts, see pages: BCR (535)
Spare Parts
Designation
BCM D12-A-C12
SR 10503457 T-6/51
BCM D12-B-C16
SR 10503457 T-6/51
BCM D16-A-C16-C
SR 34-505/1 MHG 2.5X7.2 T-8/53
BCM D16-B-C20-C
SR 34-505/1 MHG 2.5X7.2 T-8/53
BCM D20-A-C20-C
SR 34-506/L T-9/51
BCM D20-A-C20-CC
SR 34-506/L T-9/51
BCM D20-B-C25-C
SR 34-506/L T-9/51
BCM D20-B-C25-CC
SR 34-506/L T-9/51
BCM D25-A-W25-C
SR 14-601 BLD T15/S7 SW6-T
BCM D25-B-C32-C
SR 14-601 BLD T15/S7 SW6-T
BCM D30-A-W32-C
SR 14-544 BLD T15/S7 SW6-T
BCM D32-A-W32-C
SR 14-544 BLD T15/S7 SW6-T
BCM D32-B-W40-C
SR 14-544 BLD T15/S7 SW6-T
BCM D40-A-W32-C
SR 14-591/L BLD T20/S7 SW6-T
BCM D40-B-W40-C
SR 14-591/L BLD T20/S7 SW6-T
BCM D50-A-W50-C
SR 10503750 BLD T25/S7 SW6-T
BCM
Ball Nose Endmills with
Tangent Straight Edge
Inserts for Finish Profiling
ISCAR
268
PROFILING TOOLS
DCX
RE APMX LF
OAL
DCONMS
DRVS
BHTA
THSZMS
Rd°
Designation
DCX(1) RE CICT(2) APMX LF OAL THSZMS DCONMS DRVS(3) MIID(4) TQ_3(5)
kg
BCM D25-M12
25.00 12.50 2 20.00 46.00 68.00 M12 23.00 19.0 BCR D250-QT 33 0.12
BCM D25-M16
25.00 12.50 2 20.00 46.00 71.00 M16 29.00 25.0 BCR D250-QT 40 0.16
BCM D32-M16
32.00 16.00 2 26.00 53.00 78.00 M16 29.00 25.0 BCR D320-CS 40 0.22
• For user guide, see pages 542-547 • When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly
cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) Cutting diameter maximum
(2) Number of inserts
(3) Clamping wrench size
(4) Master insert identification
(5) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: BCR (535)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
Spare Parts
Designation
BCM D25-M12
SR 14-601 BLD T15/S7 SW6-T
BCM D25-M16
SR 14-601 BLD T15/S7 SW6-T
BCM D32-M16
SR 14-544 BLD T15/S7 SW6-T
BCM-M
Ball Nose Endmills with
FLEXFIT Threaded Adaptation
Carrying Tangent Straight Edge
Inserts for Finish Profiling
DCONMS
DRVS
APMX
LF
OAL
RE
DCX THSZMS
Rd°
Designation
DCX(2) RE APMX CICT(3) LF OAL DRVS(4) DCONMS THSZMS CSP(5) MIID(6)
kg
BCM D12-MMT08
12.00 6.00 9.60 2 20.00 28.00 10.0 11.50 T08 0 BCR D120-QT 0.01
BCM D16-MMT10
16.00 8.00 12.70 2 25.00 36.80 13.0 15.20 T10 0 BCR D160-QT 0.03
BCM D20-MMT12
20.00 10.00 17.00 2 35.00 48.80 15.0 18.50 T12 0 BCR D200.. 0.06
BCM D20-MMT12-CC (1)
20.00 10.00 17.00 2 35.00 48.80 15.0 18.50 T12 0 BCR D200.. 0.10
BCM D25-MMT15-C
25.00 12.50 20.00 2 40.00 57.00 19.0 24.00 T15 1 BCR D250-QT 0.11
• Do not apply lubricant to the MULTI-MASTER threaded connection • For adaptation options, see page 261 • For user guide, see pages 542-547
(1) Center Cutting
(2) Cutting diameter maximum
(3) Number of inserts
(4) Clamping wrench size
(5) 0 - Without coolant supply, 1 - With coolant supply
(6) Master insert identification
For inserts, see pages: BCR (535)
For holders, see pages: MM CAB (667) • MM S-A (stepped shanks) (84) • MM S-A (straight shanks) (87) • MM S-A-C# (86) • MM S-A-HSK (609) • MM S-A-N (85)
• MM S-A-SK (90) • MM S-B (85° conical shanks) (87) • MM S-D (89° conical shanks) (88) • MM S-ER (89) • MM S-ER-H (89) • MM TS-A (86)
Spare Parts
Designation
BCM D12-MMT08
SR 10503457 T-6/51
BCM D16-MMT10
SR 34-505/1 MHG 2.5X7.2 T-8/53
BCM D20-MMT12
SR 34-506/L T-9/51
BCM D20-MMT12-CC
SR 34-506/L T-9/51
BCM D25-MMT15-C
SR 14-601 BLD T15/S7 SW6-T
BCM-MM
Ball Nose Endmills with MULTI-
MASTER Threaded Adaptation
Carrying Tangent Straight Edge
Inserts for Finish Profiling
269
PROFILING TOOLS
DCONMS
LH OAL
APMX
DC
3°
Rd°
Designation
DC(1) APMX CICT(2) LH OAL RMPX°(3) DCONMS Shank(4) MIID(5)
kg
E93CN D16-2-L100-C15-07
16.00 5.00 2 20.0 100.00 4.0 15.00 C CNHT 070315 0.13
E93CN D16-2-L110-C16-07
16.00 5.00 2 50.0 110.00 4.0 16.00 C CNHT 070315 0.15
E93CN D20-3-L140-C19-07
20.00 5.00 3 20.0 140.00 3.0 19.00 C CNHT 070315 0.29
E93CN D20-3-L160-C20-07
20.00 5.00 3 75.0 160.00 3.0 20.00 C CNHT 070315 0.34
E93CN D25-4-L160-C24-07
25.00 5.00 4 20.0 160.00 2.0 24.00 C CNHT 070315 0.54
E93CN D25-4-L180-C25-07
25.00 5.00 4 100.0 180.00 2.0 25.00 C CNHT 070315 0.60
(1) The specified diameter is for inserts with a 1.0 mm radius.
(2) Number of inserts
(3) Maximum ramping angle
(4) C-Cylindrical
(5) Master insert identification
For inserts, see pages: CNHT/MT 07 (538)
E93CN-07
Toroidal Bull Nose Endmills
with CNHT...Inserts
DCONMS
APMX
LF OAL
DC
3°
THSZMS
Rd°
Designation
DC(1) APMX CICT(2) LF OAL THSZMS RMPX°(3) DCONMS DRVS(4) MIID(5) TQ_3(6)
kg
E93CN D16-2-M08-07
16.00 5.00 2 30.00 47.50 M08 4.0 13.00 10.0 CNHT 070315 20 0.03
E93CN D20-3-M10-07
20.00 5.00 3 30.00 50.00 M10 3.0 18.00 15.0 CNHT 070315 29 0.05
E93CN D25-4-M12-07
25.00 5.00 4 35.00 57.00 M12 2.0 21.00 17.0 CNHT 070315 33 0.09
• When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening
torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) The specified diameter is for inserts with a 1.0 mm radius.
(2) Number of inserts
(3) Maximum ramping angle
(4) Clamping wrench size
(5) Master insert identification
(6) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: CNHT/MT 07 (538)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
E93CN-M-07
Bull Nose Endmills with
FLEXFIT Threaded Adaptation
Carrying Toroidal Inserts
DCONMS
LH OAL
APMX
DC
3°
Rd°
Designation
DC APMX CICT(1) LH OAL RMPX°(2) DCONMS Shank MIID(3)
kg
E93CN D25-2-L180-C25-10
25.00 8.00 2 100.0 180.00 7.0 25.00 C ENHT 100430 0.57 SR 34-506/L T-9/51
E93CN D35-3-L200-C32-10
35.00 8.00 3 50.0 200.00 4.0 32.00 C ENHT 100430 1.18 SR 34-506/L T-9/51
(1) Number of inserts
(2) Maximum ramping angle
(3) Master insert identification
For inserts, see pages: ENHT (538)
E93CN-10
Toroidal Bull Nose Endmills
with ENHT... Inserts
ISCAR
270
PROFILING TOOLS
DC
APMX
LF
DCONMS
OAL
DRVS
3°
THSZMS
Rd°
Designation
DC(1) APMX CICT(2) LF OAL RMPX°(3) THSZMS DCONMS DRVS(4) MIID(5)
kg
E93CN D16-2-MMT10-07
16.00 5.00 2 27.00 38.64 4.0 T10 15.00 13.0 CNHT 070315 0.03 SR 34-505/LHG T-8/53
E93CN D20-3-MMT12-07
20.00 5.00 3 27.00 41.00 3.0 T12 19.00 16.0 CNHT 070315 0.05 SR 34-505/LHG T-8/53
• Do not apply lubricant to the MULTI-MASTER threaded connection • For adaptation options, see page 261 • For user guide, see pages 542-547
(1) The specified diameter is for inserts with a 1.0 mm radius. For other radii options, see diameter change in the table below
(2) Number of inserts
(3) Maximum ramping angle
(4) Clamping wrench size
(5) Master insert identification
For inserts, see pages: CNHT/MT 07 (538)
For holders, see pages: MM S-A (stepped shanks) (84) • MM S-A (straight shanks) (87) • MM S-A-C# (86) • MM S-A-HSK (609) • MM S-A-N (85) • MM S-A-SK (90)
• MM S-B (85° conical shanks) (87) • MM S-D (89° conical shanks) (88) • MM S-ER (89) • MM S-ER-H (89) • MM TS-A (86)
R0.8 1.0 1.5 2.0 2.5 3.0
∆D +0.03 0.0 -0.07 -0.14 -0.21 -0.28
Diameter Change According to Insert Radius
E93CN-MM-07
Bull Nose Endmills with MULTI-
MASTER Threaded Adaptation
Carrying Toroidal Inserts
DCONMS
APMX
LF OAL
DC
3°
THSZMS
Rd°
Designation
DC APMX CICT(1) LF OAL THSZMS RMPX°(2) DCONMS DRVS(3) MIID(4) TQ_3(5)
kg
E93CN D25-2-M12-10
25.00 7.00 2 35.00 57.00 M12 7.0 21.00 17.0 ENHT 100430 33 0.09 SR 34-506/L T-9/51
E93CN D35-3-M16-10
35.00 8.50 3 43.00 68.00 M16 4.0 29.00 25.0 ENHT 100430 40 0.21 SR 34-506/L T-9/51
E93CN D42-5-M16-10
42.00 8.50 5 43.00 68.00 M16 3.0 29.00 25.0 ENHT 100430 40 0.24 SR 34-506/L T-9/51
• When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening
torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) Number of inserts
(2) Maximum ramping angle
(3) Torque key size
(4) Master insert identification
(5) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: ENHT (538)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
E93CN-M-10
Bull Nose Endmills with
FLEXFIT Threaded Adaptation
Carrying Toroidal Inserts
271
PROFILING TOOLS
DC
OAL
DCONMS
DHUB
APMX
93°
Rd°
Designation
DC(1) CICT(2) APMX OAL DHUB DCONMS RMPX°(3) Arbor(4)
kg
F93CN D52-6-22-R-10
52.00 6 8.00 40.00 47.00 22.00 2.5 A 0.28 SR 34-506/L BLD T09/M7 SW6-SD
F93CN D66-7-22-R-10
66.00 7 8.00 40.00 52.00 22.00 1.8 A 0.51 SR 34-506/L BLD T09/M7 SW6-SD
F93CN D80-8-27-R-10
80.00 8 8.00 50.00 60.00 27.00 1.5 B 0.81 SR 34-506/L BLD T09/M7 SW6-SD
(1) The specified diameter is for inserts with a 1.0 mm radius. For other radii options, see diameter change in the table below
(2) Number of inserts
(3) Maximum ramping angle
(4) For adaptation options, see page 548
For inserts, see pages: ENHT (538)
0
0.25xD 0.5xD
2
8
0.75xD D ae (mm)
0
4
6
10
APMX (mm)
fz=0.1 mm/t
fz=0.15 mm/t
fz=0.2 mm/t
AE
APMX
R0.8 1.0 1.5 2.0 2.5 3.0
∆D +0.03 0.0 -0.07 -0.14 -0.21 -0.28
Diameter Change According to Insert Radius
Recommended Feed Data
D-Cutting diameter
F93CN-10
93° Face Mills with Toroidal Inserts
ISCAR
272
PROFILING TOOLS
LH OAL
DCONMS
LU
APMXU
APMX
DCX
BHTA
DC
TR90 TXMT
TRFF TXMT
TR6 TNCU
TR45 TXMT
1
2
3
4
Tool shown with TR6 TNCU inserts
TR6 ER
Multifunction Endmills That
Can Carry Four Different
Insert Geometries
• Note: The data refers to master inserts , for other insert radii and geometries refer to the table below
(1) Cutting diameter maximum
(2) For undercutting with TR6 TNCU/TNMU inserts only
(3) For undercutting with TR6 TNCU/TNMU inserts only
(4) Number of inserts
(5) Master insert identification
(6) Master insert identification 2
(7) Master insert identification 3
(8) Master insert identification 4
For inserts, see pages: TR45 TXMT (540) • TR6 TNCU/MU (539) • TR90 TXMT (539) • TRFF TXMT (539)
Designation
DCX(1) DCX_2 DCX_3 DCX_4 DC DC_2 DC_4 APMXAPMX_2APMX_3 APMX_4 APMXU(2) BHTA(3) CICT(4) LU LU_2 LU_3 LU_4
TR6 ER D16-50-2-C16-07
16.00 16.00 16.00 - 14.00 12.10 - 1.00 0.60 2.50 - 2.00 21.0 2 46.50 46.70 46.80 -
TR6 ER D20-60-4-C20-07
20.00 20.00 20.00 - 18.00 16.10 - 1.00 0.60 2.50 - 2.00 21.0 4 56.50 56.70 56.80 -
TR6 ER D25-70-5-C25-07
25.00 25.00 25.00 - 23.00 21.10 - 1.00 0.60 2.50 - 2.00 21.0 5 65.50 65.70 65.80 -
TR6 ER D32-80-6-C32-07
32.00 32.00 32.00 - 30.00 28.10 - 1.00 0.60 2.50 - 2.00 21.0 6 75.50 75.70 75.80 -
TR6 ER D25-70-3-C25-10
25.00 24.60 25.00 26.80 20.00 19.00 20.60 2.50 0.80 4.00 3.00 4.20 20.5 3 65.00 65.15 64.91 65.12
TR6 ER D32-80-4-C32-10
32.00 31.60 32.00 33.80 27.00 26.00 27.60 2.50 0.80 4.00 3.00 4.20 20.5 4 75.00 75.15 74.91 75.12
Designation
LH LH_2 LH_3 LH_4 OAL OAL_2 OAL_3 OAL_4 DCONMS MIID(5) MIID_2(6) MIID_3(7) MIID_4(8)
kg
TR6 ER D16-50-2-C16-07
50.0 50.2 50.3 - 100.00 100.20 100.30 - 16.00 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 0.12
TR6 ER D20-60-4-C20-07
60.0 60.2 60.3 - 120.00 120.20 120.30 - 20.00 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 0.22
TR6 ER D25-70-5-C25-07
70.0 70.2 70.3 - 140.00 140.20 140.30 - 25.00 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 0.42
TR6 ER D32-80-6-C32-07
80.0 80.2 80.3 - 160.00 160.20 160.30 - 32.00 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 0.82
TR6 ER D25-70-3-C25-10
70.0 70.2 69.9 70.1 140.00 140.15 139.91 140.12 25.00 TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 0.41
TR6 ER D32-80-4-C32-10
80.0 80.2 79.9 80.1 160.00 160.15 159.91 160.12 32.00 TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 0.81
Spare Parts
Designation
TR6 ER D16-50-2-C16-07
SR M2.5X0.45-L6 IP7 IP-7/51
TR6 ER D20-60-4-C20-07
SR M2.5X0.45-L6 IP7 IP-7/51
TR6 ER D25-70-5-C25-07
SR M2.5X0.45-L6 IP7 IP-7/51
TR6 ER D32-80-6-C32-07
SR M2.5X0.45-L6 IP7 IP-7/51
TR6 ER D25-70-3-C25-10
SR 10508600 T-9/51
TR6 ER D32-80-4-C32-10
SR 10508600 T-9/51
(1)
Maximum ramp down angle
For undercutting
Tool
Insert DCX DC APMX LU LH OAL RMPX(1) APMX_2 BHTA
TR6 ER D16-50-2-C16-07
TR6 TNCU 070205
16.00
15.00 0.50 46.40 49.90 99.90 - 1.60 17.0
TR6 TNMU 070215 13.00 1.50 45.60 50.10 100.10 - 2.40 21.0
TRFF TXMT 0702 12.10 0.60 46.70 50.20 100.20 1.1 - -
TR90 TXMT 070204 - 2.50 46.80 50.30 100.30 1.6 - -
TR6 ER D20-60-4-C20-07
TR6 TNCU 070205
20.00
19.00 0.50 56.40 59.90 119.90 - 1.60 17.0
TR6 TNMU 070215 17.00 1.50 56.60 60.10 120.10 - 2.40 21.0
TRFF TXMT 0702 16.10 0.60 56.70 60.20 120.20 0.8 - -
TR90 TXMT 070204 - 2.50 56.80 60.30 120.30 1.2 - -
TR6 ER D25-70-5-C25-07
TR6 TNCU 070205
25.00
24.00 0.50 65.40 69.90 139.90 - 1.60 17.0
TR6 TNMU 070215 22.00 1.50 65.60 70.10 140.10 - 2.40 21.0
TRFF TXMT 0702 21.10 0.60 65.70 70.20 140.20 0.6 - -
TR90 TXMT 070204 - 2.50 65.80 70.30 140.30 0.9 - -
TR6 ER D32-80-6-C32-07
TR6 TNCU 070205
32.00
31.00 0.50 75.40 79.90 159.90 - 1.60 17.0
TR6 TNMU 070215 29.00 1.50 75.60 80.10 160.10 - 2.40 21.0
TRFF TXMT 0702 28.10 0.60 75.70 80.20 160.20 0.4 - -
TR90 TXMT 070204 - 2.50 75.80 80.30 160.30 0.7 - -
TR6 ER D25-70-3-C25-10
TR6 TNCU 100405
25.00
24.00 0.50 64.52 69.52 139.52 - 1.80 17.5
TR6 TNCU 100410 23.00 1.00 64.64 69.64 139.65 - 2.30 20.5
TR6 TNCU/MU 100415 22.00 1.50 64.76 69.76 139.76 - 2.70 20.5
TR6 TNCU 100420 21.00 2.00 64.88 69.88 139.88 - 3.50 20.5
TR6 TNCU 100430 19.00 3.00 65.12 70.12 140.12 - 4.50 20.5
TRFF TXMT 1004 19.00 0.80 65.15 70.15 140.15 1.7 - -
TR90 TXMT 100408 - 4.00 64.91 69.91 139.91 1.6 - -
TR45 TXMT 1004 26.80 20.60 3.00 65.12 70.12 140.12 1.4 - -
TR6 ER D32-80-4-C32-10
TR6 TNCU 100405
32.00
31.00 0.50 75.52 79.52 159.52 - 1.80 17.5
TR6 TNCU 100410 30.00 1.00 74.64 79.65 159.64 - 2.30 20.5
TR6 TNCU/MU 100415 29.00 1.50 76.76 79.76 159.76 - 2.70 20.5
TR6 TNCU 100420 28.00 2.00 74.88 79.88 159.88 - 3.50 20.5
TR6 TNCU 100430 26.00 3.00 75.12 80.12 160.12 - 4.50 20.5
TRFF TXMT 1004 26.00 0.80 75.15 80.15 160.15 1.2 - -
TR90 TXMT 100408 - 4.00 74.91 79.91 159.91 1.2 - -
TR45 TXMT 1004 33.80 27.60 3.00 75.12 80.12 160.12 1.0 - -
273
PROFILING TOOLS
LF
OAL
DCONMS
THSZMS
APMXU
APMX
DCX
BHTA
DC
TR90 TXMT
TRFF TXMT
TR6 TNCU
TR45 TXMT
1
2
3
4
Tool shown with TR6 TNCU inserts
TR6 ER-M
Multifunction Endmills with
FLEXFIT Threaded Adaptation
That Can Carry Four Different
Insert Geometries
• Note: The data refers to master inserts, for other insert radii and geometries refer to the table below • When mounting items with FLEXFIT threaded adaptation to their
holders, the mating surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated
torque values are specified in the TQ_3 parameter
(1) Cutting diameter maximum
(10) Tool tightening torque Nxm (lbfxin)
(2) For undercutting with TR6 TNCU/TNMU inserts only
(3) For undercutting with TR6 TNCU/TNMU inserts only
(4) Number of inserts
(5) Master insert identification
(6) Master insert identification 2
(7) Master insert identification 3
(8) Master insert identification 4
(9) Torque key size
For inserts, see pages: TR45 TXMT (540) • TR6 TNCU/MU (539) • TR90 TXMT (539) • TRFF TXMT (539)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
Designation
DCX(1) DCX_2 DCX_3 DCX_4 DC DC_2 DC_4 APMX APMX_2 APMX_3 APMX_4 APMXU(2) BHTA(3) CICT(4) LF LF_2 LF_3 LF_4 OAL
TR6 ER D16/0.63-2-M08-07
16.00 16.00 16.00 - 14.00 12.10 - 1.00 0.60 2.50 - 2.00 21.0 2 24.64 24.90 25.00 - 42.20
TR6 ER D20/0.79-4-M10-07
20.00 20.00 20.00 - 18.00 16.10 - 1.00 0.60 2.50 - 2.00 21.0 4 24.64 24.90 25.00 - 44.70
TR6 ER D25/0.98-5-M12-07
25.00 25.00 25.00 - 23.00 21.10 - 1.00 0.60 2.50 - 2.00 21.0 5 29.64 29.90 30.00 - 51.70
TR6 ER D32/1.26-6-M16-07
32.00 32.00 32.00 - 30.00 28.10 - 1.00 0.60 2.50 - 2.00 21.0 6 34.64 34.90 35.00 - 59.70
TR6 ER D35/1.38-6-M16-07
35.00 35.00 35.00 - 33.00 31.10 - 1.00 0.60 2.50 - 2.00 21.0 6 34.64 34.90 35.00 - 59.70
TR6 ER D25/0.98-3-M12-10
25.00 24.60 25.00 26.80 20.00 20.60 20.60 2.50 0.80 4.00 3.00 4.20 20.5 3 24.97 25.15 25.12 25.12 47.00
TR6 ER D32/1.26-4-M16-10
32.00 31.60 32.00 33.80 27.00 27.60 27.60 2.50 0.80 4.00 3.00 4.20 20.5 4 34.97 35.15 35.12 35.12 60.00
TR6 ER D35/1.38-5-M16-10
35.00 34.60 35.00 36.80 30.00 30.60 30.60 2.50 0.80 4.00 3.00 4.20 20.5 5 34.97 35.15 35.12 35.12 60.00
Designation
OAL_2 OAL_3 OAL_4 DCONMS THSZMS MIID(5) MIID_2(6) MIID_3(7) MIID_4(8) DRVS(9) TQ_3(10)
kg
TR6 ER D16/0.63-2-M08-07
42.40 42.50 - 13.00 M08 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 11.0 20 0.03
TR6 ER D20/0.79-4-M10-07
44.90 45.00 - 18.00 M10 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 15.0 29 0.05
TR6 ER D25/0.98-5-M12-07
51.90 52.00 - 21.00 M12 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 17.0 33 0.08
TR6 ER D32/1.26-6-M16-07
59.90 60.00 - 29.00 M16 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 25.0 40 0.18
TR6 ER D35/1.38-6-M16-07
59.90 60.00 - 29.00 M16 TR6 TNCU 070210 TRFF TXMT 0702 TR90 TXMT 070204 - 25.0 40 0.19
TR6 ER D25/0.98-3-M12-10
47.15 46.91 47.12 21.00 M12 TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 19.0 33 0.06
TR6 ER D32/1.26-4-M16-10
60.15 59.91 60.12 29.00 M16 TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 25.0 40 0.17
TR6 ER D35/1.38-5-M16-10
60.15 59.91 60.12 29.00 M16 TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 25.0 40 0.18
ISCAR
274
PROFILING TOOLS
Spare Parts
Designation
TR6 ER D16/0.63-2-M08-07
SR M2.5X0.45-L6 IP7 IP-7/51
TR6 ER D20/0.79-4-M10-07
SR M2.5X0.45-L6 IP7 IP-7/51
TR6 ER D25/0.98-5-M12-07
SR M2.5X0.45-L6 IP7 IP-7/51
TR6 ER D32/1.26-6-M16-07
SR M2.5X0.45-L6 IP7 IP-7/51
TR6 ER D35/1.38-6-M16-07
SR M2.5X0.45-L6 IP7 IP-7/51
TR6 ER D25/0.98-3-M12-10
SR 10508600 T-9/51
TR6 ER D32/1.26-4-M16-10
SR 10508600 T-9/51
TR6 ER D35/1.38-5-M16-10
SR 10508600 T-9/51
For undercutting
Tool
Insert DCX DC APMX LF OAL RMPX APMX_2 BHTA
TR6 ER D16/0.63-2-M08-07
TR6 TNCU 070205
16.00
15.00 0.50 24.6 42.1 - 1.60 17.0
TR6 TNMU 070215 13.00 1.50 24.8 42.3 - 2.40 21.0
TRFF TXMT 0702 12.10 0.60 24.9 42.4 1.1 - -
TR90 TXMT 070204 - 2.50 25.0 42.5 1.6 - -
TR6 ER D20/0.79-4-M10-07
TR6 TNCU 070205
20.00
19.00 0.50 24.6 44.6 - 1.60 17.0
TR6 TNMU 070215 17.00 1.50 24.8 44.8 - 2.40 21.0
TRFF TXMT 0702 16.10 0.60 24.9 44.9 0.8 - -
TR90 TXMT 070204 - 2.50 25.0 45.0 1.2 - -
TR6 ER D25/0.98-5-M12-07
TR6 TNCU 070205
25.00
24.00 0.50 29.6 51.6 - 1.60 17.0
TR6 TNMU 070215 22.00 1.50 29.8 51.8 - 2.40 21.0
TRFF TXMT 0702 21.10 0.60 29.9 51.9 0.6 - -
TR90 TXMT 070204 - 2.50 30.0 52.0 0.9 - -
TR6 ER D32/1.26-6-M16-07
TR6 TNCU 070205
32.00
31.00 0.50 34.6 59.6 - 1.60 17.0
TR6 TNMU 070215 29.00 1.50 34.8 59.8 - 2.40 21.0
TRFF TXMT 0702 28.10 0.60 34.9 59.9 0.4 - -
TR90 TXMT 070204 - 2.50 35.0 60.0 0.7 - -
TR6 ER D35/1.38-6-M16-07
TR6 TNCU 070205
35.00
34.00 0.50 34.6 59.6 - 1.60 17.0
TR6 TNMU 070215 32.00 1.50 34.8 59.8 - 2.40 21.0
TRFF TXMT 0702 31.10 0.60 34.9 59.9 0.4 - -
TR90 TXMT 070204 - 2.50 35 60 0.4 - -
TR6 ER D25/0.98-3-M12-10
TR6 TNCU 100405
25.00
24.00 0.50 24.52 46.52 - 1.80 17.5
TR6 TNCU 100410 23.00 1.00 24.64 46.64 - 2.30 20.5
TR6 TNCU/MU 100415 22.00 1.50 24.76 46.76 - 2.70 20.5
TR6 TNCU 100420 21.00 2.00 24.88 46.88 - 3.50 20.5
TR6 TNCU 100430 19.00 3.00 25.12 47.12 - 4.50 20.5
TRFF TXMT 1004 20.60 0.80 25.15 47.15 1.7 - -
TR90 TXMT 100408 - 4.00 24.91 46.91 1.6 - -
TR45 TXMT 1004 26.80 20.60 3.00 25.12 47.12 1.4 - -
TR6 ER D32/1.26-4-M16-10
TR6 TNCU 100405
32.00
31.00 0.50 34.52 59.52 - 1.80 17.5
TR6 TNCU 100410 30.00 1.00 34.64 59.64 - 2.30 20.5
TR6 TNCU/MU 100415 29.00 1.50 34.76 59.76 - 2.70 20.5
TR6 TNCU 100420 28.00 2.00 34.88 59.88 - 3.50 20.5
TR6 TNCU 100430 26.00 3.00 35.12 60.12 - 4.50 20.5
TRFF TXMT 1004 27.60 0.80 35.15 60.15 1.2 - -
TR90 TXMT 100408 - 4.00 34.91 59.91 1.1 - -
TR45 TXMT 1004 33.80 27.60 3.00 35.12 60.12 0.9 - -
TR6 ER D35/1.38-5-M16-10
TR6 TNCU 100405
35.00
34.00 0.50 34.52 59.52 - 1.80 17.5
TR6 TNCU 100410 33.00 1.00 34.64 59.64 - 2.30 20.5
TR6 TNCU/MU 100415 32.00 1.50 34.76 59.76 - 2.70 20.5
TR6 TNCU 100420 31.00 2.00 34.88 59.88 - 3.50 20.5
TR6 TNCU 100430 29.00 3.00 35.12 60.12 - 4.50 20.5
TRFF TXMT 1004 30.60 0.80 35.15 60.15 1.2 - -
TR90 TXMT 100408 - 4.00 34.91 59.91 1.1 - -
TR45 TXMT 1004 36.80 30.60 3.00 35.12 60.12 0.9 - -
275
PROFILING TOOLS
DHUB
TR90 TXMTTRFF TXMT TR45 TXMT
DCONMS
OAL
DCX
DC APMX
APMXU
BHTA TR6 TNCU
1 2 3 4
Tool shown with TR6 TNCU inserts
TR6 FR
Multifunction Face Mills That
Can Carry Four Different
Insert Geometries
• Note: The data refers to master inserts, for other insert radii and geometries refer to the table below
(1) Cutting diameter maximum
(2) For undercutting with TR6 TNCU/TNMU inserts only
(3) For undercutting with TR6 TNCU/TNMU inserts only
(4) Number of inserts
(5) Master insert identification
(6) Master insert identification 2
(7) Master insert identification 3
(8) Master insert identification 4
For inserts, see pages: TR45 TXMT (540) • TR6 TNCU/MU (539) • TR90 TXMT (539) • TRFF TXMT (539)
Designation
DCX(1) DCX_2 DCX_3 DCX_4 DC DC_2 DC_4 APMX APMX_2 APMX_3 APMX_4 APMXU(2) BHTA(3) CICT(4)
TR6 FR D40-06-16-10
40.00 39.60 40.00 41.80 35.00 34.00 35.60 2.50 0.80 4.00 3.00 4.20 20.5 6
TR6 FR D42-06-16-10
42.00 41.60 42.00 43.80 37.00 36.00 37.60 2.50 0.80 4.00 3.00 4.20 20.5 6
TR6 FR D50-07-22-10
50.00 49.60 50.00 51.80 45.00 44.00 45.60 2.50 0.80 4.00 3.00 4.20 20.5 7
TR6 FR D52-07-22-10
52.00 51.60 52.00 53.80 47.00 46.00 53.60 2.50 0.80 4.00 3.00 4.20 20.5 7
TR6 FR D63-08-22-10
63.00 62.60 63.00 64.80 58.00 57.00 56.60 2.50 0.80 4.00 3.00 4.20 20.5 8
TR6 FR D66-08-22-10
66.00 65.60 66.00 67.80 61.00 60.00 61.60 2.50 0.80 4.00 3.00 4.20 20.5 8
TR6 FR D80-10-27-10
80.00 79.60 80.00 81.80 75.00 74.00 75.60 2.50 0.80 4.00 3.00 4.20 20.5 10
Designation
OAL OAL_2 OAL_3 OAL_4 DCONMS DHUB Arbor MIID(5) MIID_2(6) MIID_3(7) MIID_4(8)
kg
TR6 FR D40-06-16-10
37.00 37.15 36.91 37.12 16.00 32.00 A TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 0.14
TR6 FR D42-06-16-10
37.00 37.15 36.91 37.12 16.00 32.00 A TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 0.15
TR6 FR D50-07-22-10
40.00 40.15 39.91 40.12 22.00 47.00 A TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 0.29
TR6 FR D52-07-22-10
40.00 40.15 39.91 40.12 22.00 47.00 A TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 0.33
TR6 FR D63-08-22-10
40.00 40.15 39.91 40.12 22.00 48.00 A TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 0.42
TR6 FR D66-08-22-10
40.00 40.15 39.91 40.12 22.00 48.00 A TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 0.46
TR6 FR D80-10-27-10
50.00 50.15 49.91 50.12 27.00 60.00 A TR6 TNCU 100425 TRFF TXMT 1004 TR90 TXMT 100408 TR45 TXMT 1004 0.91
Spare Parts
Designation
TR6 FR D40-06-16-10
SR 10508600 T-9/51 SR M8X25DIN912
TR6 FR D42-06-16-10
SR 10508600 T-9/51 SR M8X25DIN912
TR6 FR D50-07-22-10
SR 10508600 T-9/51 SR M10X25 DIN912
TR6 FR D52-07-22-10
SR 10508600 T-9/51 SR M10X25 DIN912
TR6 FR D63-08-22-10
SR 10508600 T-9/51 SR M10X25 DIN912
TR6 FR D66-08-22-10
SR 10508600 T-9/51 SR M10X25 DIN912
TR6 FR D80-10-27-10
SR 10508600 T-9/51 SR M12X30DIN912
ISCAR
276
PROFILING TOOLS
For undercutting
Tool
Insert DCX DC APMX OAL RMPX APMX_2 BHTA
TR6 FR D40-06-16-10
TR6 TNCU 100405
40.00
39.00 0.50 36.52 - 1.80 17.5
TR6 TNCU 100410 38.00 1.00 36.64 - 2.30 20.5
TR6 TNCU/MU 100415 37.00 1.50 36.76 - 2.70 20.5
TR6 TNCU 100420 36.00 2.00 36.88 - 3.50 20.5
TR6 TNCU 100430 34.00 3.00 37.12 - 4.50 20.5
TRFF TXMT 1004 34.00 0.80 37.15 0.9 - -
TR90 TXMT 100408 - 4.00 36.91 0.9 - -
TR45 TXMT 1004 41.80 35.60 3.00 37.12 0.7 - -
TR6 FR D42-06-16-10
TR6 TNCU 100405
42.00
41.00 0.50 36.52 - 1.80 17.5
TR6 TNCU 100410 40.00 1.00 36.64 - 2.30 20.5
TR6 TNCU/MU 100415 39.00 1.50 36.76 - 2.70 20.5
TR6 TNCU 100420 38.00 2.00 36.88 - 3.50 20.5
TR6 TNCU 100430 36.00 3.00 37.12 - 4.50 20.5
TRFF TXMT 1004 36.00 0.80 37.15 0.90 - -
TR90 TXMT 100408 - 4.00 36.91 0.90 - -
TR45 TXMT 1004 43.80 37.60 3.00 37.12 0.70 - -
TR6 FR D50-07-22-10
TR6 TNCU 100405
50.00
49.00 0.50 39.52 - 1.80 17.5
TR6 TNCU 100410 48.00 1.00 39.64 - 2.30 20.5
TR6 TNCU/MU 100415 47.00 1.50 39.76 - 2.70 20.5
TR6 TNCU 100420 46.00 2.00 39.88 - 3.50 20.5
TR6 TNCU 100430 44.00 3.00 40.12 - 4.50 20.5
TRFF TXMT 1004 44.00 0.80 40.15 0.70 - -
TR90 TXMT 100408 - 4.00 39.91 0.70 - -
TR45 TXMT 1004 51.80 45.60 3.00 40.12 0.60 - -
TR6 FR D52-07-22-10
TR6 TNCU 100405
52.00
51.00 0.50 39.52 - 1.80 17.5
TR6 TNCU 100410 50.00 1.00 39.64 - 2.30 20.5
TR6 TNCU/MU 100415 49.00 1.50 39.76 - 2.70 20.5
TR6 TNCU 100420 48.00 2.00 39.88 - 3.50 20.5
TR6 TNCU 100430 46.00 3.00 40.12 - 4.50 20.5
TRFF TXMT 1004 46.00 0.80 40.15 0.70 - -
TR90 TXMT 100408 - 4.00 39.91 0.70 - -
TR45 TXMT 1004 53.80 53.80 3.00 40.12 0.60 - -
TR6 FR D63-08-22-10
TR6 TNCU 100405
63.00
62.00 0.50 39.52 - 1.80 17.5
TR6 TNCU 100410 61.00 1.00 39.64 - 2.30 20.5
TR6 TNCU/MU 100415 60.00 1.50 39.76 - 2.70 20.5
TR6 TNCU 100420 59.00 2.00 39.88 - 3.50 20.5
TR6 TNCU 100430 57.00 3.00 40.12 - 4.50 20.5
TRFF TXMT 1004 57.00 0.80 40.15 0.50 - -
TR90 TXMT 100408 - 4.00 39.91 0.50 - -
TR45 TXMT 1004 64.80 58.60 3.00 40.12 0.40 - -
TR6 FR D66-08-22-10
TR6 TNCU 100405
66.00
65.00 0.50 39.52 - 1.80 17.5
TR6 TNCU 100410 64.00 1.00 39.64 - 2.30 20.5
TR6 TNCU/MU 100415 63.00 1.50 39.76 - 2.70 20.5
TR6 TNCU 100420 62.00 2.00 39.88 - 3.50 20.5
TR6 TNCU 100430 60.00 3.00 40.12 - 4.50 20.5
TRFF TXMT 1004 60.00 0.80 40.15 0.50 - -
TR90 TXMT 100408 - 4.00 39.91 0.50 - -
TR45 TXMT 1004 67.80 61.60 3.00 40.12 0.40 - -
TR6 FR D80-10-27-10
TR6 TNCU 100405
80.00
79.00 0.50 49.52 - 1.80 17.5
TR6 TNCU 100410 78.00 1.00 49.64 - 2.30 20.5
TR6 TNCU/MU 100415 77.00 1.50 49.76 - 2.70 20.5
TR6 TNCU 100420 76.00 2.00 49.88 - 3.50 20.5
TR6 TNCU 100430 74.00 3.00 50.12 - 4.50 20.5
TRFF TXMT 1004 74.00 0.80 50.15 0.40 - -
TR90 TXMT 100408 - 4.00 49.91 0.40 - -
TR45 TXMT 1004 81.80 75.60 3.00 50.12 0.30 - -
277
PROFILING TOOLS
DCX
LH
OAL
DC
IC
LH
LU
BD
DCONMS
ABBHTA
Rd°
Designation
DCX(1) DC IC BD CICT(2) LH DCONMS Shank(3) RMPX°(4) BHTA OAL LU Type MIID(5)
kg
ER D07A12-3-C12-05
12.00 7.00 5.00 11.70 3 40.0 12.00 C 6.0 - 100.00 - A RXCR 05T1 0.08
ER D08A15-2-C20-07
15.00 8.00 7.00 13.50 2 40.0 20.00 C 15.0 5.0 140.00 40.0 B RXCR 0702 0.26
ER D08A16-2-C16-08
16.00 8.00 8.00 13.50 2 40.0 16.00 C 27.0 - 120.00 - A RXCR 0802 0.16
ER D17A25-3-C32-08
25.00 17.00 8.00 22.50 3 60.0 32.00 C 5.4 - 160.00 - A RXCR 0802 0.80
ER D10A20-2-C20-10
20.00 10.00 10.00 17.90 2 60.0 20.00 C 13.0 - 160.00 - A RXCR 10T3 0.34
ER D15A25-2-C25-10
25.00 15.00 10.00 22.80 2 60.0 25.00 C 6.0 - 160.00 - A RXCR 10T3 0.55
ER D22A32-4-C25-10
32.00 22.00 10.00 29.90 4 40.0 25.00 C 4.0 - 160.00 - A RXCR 10T3 0.62
ER D24A40-3-C32-16
40.00 24.00 16.00 30.00 3 50.0 32.00 C 20.0 - 160.00 - A RCCW 1605 0.90
(1) Cutting diameter maximum
(2) Number of inserts
(3) C-Cylindrical
(4) Maximum ramping angle
(5) Master insert identification
For inserts, see pages: RXCR (526) • RXCW (526) • RXMT 10 (526)
Spare Parts
Designation
ER D07A12-3-C12-05
SR 34-533 T-6/51
ER D08A15-2-C20-07
SR 14-560/S T-8/53
ER D08A16-2-C16-08
SR 14-560/S T-8/53
ER D17A25-3-C32-08
T-8/53
ER D10A20-2-C20-10
SR 14-562/S T-10/51
ER D15A25-2-C25-10
SR 14-562/S T-10/51
ER D22A32-4-C25-10
SR 14-562 T-10/51
ER D24A40-3-C32-16
SR 14-536 BLD T20/M7 SW6-T
ER
Endmills with Round
Inserts for Profiling and
Milling Round Corners
LF
DCONMS
THSZMS
DCX
IC
DC
BD
Rd°
Designation
DCX(1) DC IC BD CICT(2) DCONMS LF THSZMS RMPX°(3) TQ_3(4)
kg
ER D10A15-4-M08-05
15.00 10.00 5.00 13.00 4 13.00 23.00 M08 13.0 20 0.03 SR 34-533 T-6/51
ER D15A20-5-M10-05
20.00 15.00 5.00 18.00 5 18.00 30.00 M10 4.3 29 0.06 SR 34-533 T-6/51
ER D08A15-3-M08-07
15.00 8.00 7.00 13.50 3 13.50 23.00 M08 15.0 20 0.03 SR 14-560/S T-8/53
ER D13A20-4-M10-07
20.00 13.00 7.00 18.00 4 18.00 30.00 M10 5.0 29 0.06 SR 14-560/S T-8/53
ER D08A16-2-M08-08
16.00 8.00 8.00 13.50 2 13.00 25.00 M08 27.0 20 0.02 SR 14-560/S T-8/53
ER D12A20-2-M10-08
20.00 12.00 8.00 17.20 2 18.00 32.00 M10 6.5 29 0.05 SR 14-560/S T-8/53
ER D10A20-2-M10-10
20.00 10.00 10.00 18.00 2 18.00 30.00 M10 28.0 29 0.05 SR 14-562/S T-10/51
ER D15A25-2-M12-10
25.00 15.00 10.00 21.00 2 21.00 35.00 M12 12.0 33 0.09 SR 14-562/S T-10/51
ER D15A25-3-M12-10
25.00 15.00 10.00 29.00 3 21.00 35.00 M12 12.0 33 0.09 SR 14-562/S T-10/51
ER D22A32-4-M16-10
32.00 22.00 10.00 29.00 4 29.00 43.00 M16 7.3 40 0.20 SR 14-562 T-10/51
ER D25A35-4-M16-10
35.00 25.00 10.00 29.00 4 29.00 43.00 M16 5.5 40 0.22 SR 14-562 T-10/51
ER D32A42-5-M16-10
42.00 32.00 10.00 29.00 5 29.00 43.00 M16 4.5 40 0.25 SR 14-562 T-10/51
• When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening
torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: R90CW (527) • RXCR (526) • RXCW (526) • RXMT 10 (526)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
ER-M
Endmills with FLEXFIT
Threaded Adaptation Carrying
Round Inserts for Profiling
and Milling Round Corners
ISCAR
278
PROFILING TOOLS
DHUB
DCONMS
OAL
RE
DCX
DC
APMX
Rd°
Designation
DCX(1) DC RE APMX CICT(2) OAL DCONMS RMPX°(3) Arbor(4) DHUB MIID(5)
kg
FRMT D030A040-05-16-10
40.00 30.00 5.00 3.10 5 40.00 16.00 1.0 A 38.00 RP...X 1003M0 ... 0.20
FRMT D028A040-04-16-12
40.00 28.00 6.00 3.80 4 40.00 16.00 1.0 A 38.00 RP...X 1204M0 ... 0.20
FRMT D038A050-05-22-12
50.00 38.00 6.00 3.80 5 40.00 22.00 2.5 A 48.00 RP...X 1204M0 ... 0.29
FRMT D038A050-06-22-12
50.00 38.00 6.00 3.80 6 40.00 22.00 1.0 A 48.00 RP...X 1204M0 ... 0.29
FRMT D040A052-05-22-12
52.00 40.00 6.00 3.80 5 40.00 22.00 2.5 A 48.00 RP...X 1204M0 ... 0.31
FRMT D040A052-06-22-12
52.00 40.00 6.00 3.80 6 40.00 22.00 1.0 A 48.00 RP...X 1204M0 ... 0.30
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) For adaptation see page 548
(5) Insert identification
For inserts, see pages: RPHX/RPMX (530)
Spare Parts
Designation
FRMT D030A040-05-16-10
SR 10504970 SW6-SD BLD IP15/S7
FRMT D028A040-04-16-12
SR 76-2067 SW6-T BLD T15/S7
FRMT D038A050-05-22-12
SR 76-2067 SW6-T BLD T15/S7
FRMT D038A050-06-22-12
SR 76-2067 SW6-T BLD T15/S7
FRMT D040A052-05-22-12
SR 76-2067 SW6-T BLD T15/S7
FRMT D040A052-06-22-12
SR 76-2067 SW6-T BLD T15/S7
FRMT
Face Mills for Productive
Machining of 3D Surfaces of
Blades in Turbomachinery
DCONMS
DHUB
DCX
DC
OAL
APMX
Rd°
Designation
DCX(1) DC APMX OAL DCONMS DHUB STDLET CICT(2) MDN(3) MDX(4) RMPX°(5)
kg
FRN D038A050-05-22-12
50.00 37.30 3.00 40.00 22.00 45.00 A 5 87.30 99.00 0.4 0.46
FRN D051A063-06-22-12
63.00 50.30 3.00 40.00 22.00 47.00 A 6 113.30 125.00 0.3 0.63
FRN D068A080-07-27-12
80.00 67.30 3.00 50.00 27.00 58.00 A 7 147.30 159.00 0.3 0.85
• Radius for programing: 6.35
(1) Cutting diameter maximum
(2) Number of inserts
(3) For interpolation
(4) For interpolation
(5) Maximum ramping angle
For inserts, see pages: RNGN-Ceramic (531)
Spare Parts
Designation
FRN
WEDGE SCREW(a) LW 1207C T-W3
(a) Recommended tightening torque:4.8 Nm
FRN
Face Mill for Wedge-Clamped
Double-Sided Round Insert
279
PROFILING TOOLS
A
BDC
DCX
IC
BD
LH OAL
DCONMS
Rd°
Designation
DCX(1) DC IC CICT(2) LH OAL DCONMS Shank(3) BD RMPX°(4) Type
ERW D015A025-B-3-C25-10
25.00 15.00 10.00 3 50.0 150.00 25.00 C - 3.0 B
ERW D022A032-A-4-C25-10
32.00 22.00 10.00 4 - 170.00 25.00 C - 4.0 A
ERW D030A040-A-5-C32-10
40.00 30.00 10.00 5 - 200.00 32.00 C - 3.0 A
ERW D013A025-B-2-C25-12
25.00 13.00 12.00 2 50.0 180.00 25.00 C - 2.0 B
ERW D020A032-A-3-C25-12
32.00 20.00 12.00 3 40.0 200.00 25.00 C 24.00 7.0 A
ERW D020A032-B-3-C32-12
32.00 20.00 12.00 3 140.0 300.00 32.00 C - 7.0 B
ERW D028A040-A-4-C32-12
40.00 28.00 12.00 4 50.0 250.00 32.00 C 31.00 5.0 A
• For user guide, see pages 287-289
(1) Cutting diameter maximum
(2) Number of inserts
(3) C-Cylindrical
(4) Maximum ramping angle
For inserts, see pages: RCMT/RCCT-MO (528) • RCMT/RCMW/RCCW-FW (529) • RCMW/RCCW-MO (528)
Spare Parts
Designation
ERW D015A025-B-3-C25-10
SR 34-506/L T-9/51
ERW D022A032-A-4-C25-10
SR 34-506/L T-9/51
ERW D030A040-A-5-C32-10
SR 34-506/L T-9/51
ERW D013A025-B-2-C25-12
SR 14-601 BLD T15/S7 SW6-T
ERW D020A032-A-3-C25-12
SR 14-601 BLD T15/S7 SW6-T
ERW D020A032-B-3-C32-12
SR 14-601 BLD T15/S7 SW6-T
ERW D028A040-A-4-C32-12
SR 14-601 BLD T15/S7 SW6-T
ERW
Rough Profiling Endmills with
Serrated or Regular Round Inserts
ISCAR
280
PROFILING TOOLS
DC
DCX
DRVS
DCONMS
DRVS
IC
LF
OAL
THSZMS
Rd°
Designation
DCX(1) DC IC APMX CICT(2) DCONMS OAL LF DRVS(3) THSZMS RMPX°(4) TQ_3(5)
kg
ERW D015A025-3-M12-10
25.00 15.00 10.00 5.00 3 21.00 52.00 30.00 17.0 M12 3.0 33 0.06
ERW D022A032-4-M16-10
32.00 22.00 10.00 5.00 4 29.00 55.00 30.00 25.0 M16 4.0 40 0.12
ERW D013A025-2-M12-12
25.00 13.00 12.00 6.00 2 21.00 57.00 35.00 17.0 M12 2.0 33 0.08
ERW D020A032-3-M16-12
32.00 20.00 12.00 6.00 3 29.00 65.00 40.00 25.0 M16 7.0 40 0.15
ERW D028A040-4-M16-12
40.00 28.00 12.00 6.00 4 29.00 65.00 40.00 25.0 M16 5.0 40 0.19
• For user guide, see pages 287-289 • When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly
cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) Cutting diameter maximum
(2) Number of inserts
(3) Clamping wrench size
(4) Maximum ramping angle
(5) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: RCMT/RCCT-MO (528) • RCMT/RCMW/RCCW-FW (529) • RCMW/RCCW-MO (528)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
D1
H
L
d
a°
Milling Head Adapter Shank Assembly Dimensions
D1 H L aºdRdºInserts
ERW D015A025-3-M12-10
S M12-L086-C25
S M12-L200-C32
25 60 116 - 25 3
RCMT 1004...
RCCT 1004...
25 108 230 1.9 32 3
ERW D022A032-4-M16-10
S M16-L95-C32
S M16-L230-C32
32 65 125 - 32 4
32 80 260 - 32 4
ERW D013A025-2-M12-12
S M12-L086-C25
S M12-L200-C32
25 70 126 - 25 2
RCMT 1206...
RCCW 1206...
RCCT 1206...
25 118 240 1.8 32 2
ERW D020A032-3-M16-12
S M16-L95-C32
S M16-L230-C32
32 75 85 - 32 7
32 90 220 - 32 7
ERW D028A040-4-M16-12
S M16-L95-C32
S M16-L230-C32
40 75 85 - 32 5
40 90 220 - 32 5
ERW-M
Assembly of Button and
Shredding Insert Endmills
with FLEXFIT Connection
Spare Parts
Designation
ERW D015A025-3-M12-10
SR 34-506/L T-9/51
ERW D022A032-4-M16-10
SR 34-506/L T-9/51
ERW D013A025-2-M12-12
SR 14-601 BLD T15/S7 SW6-T
ERW D020A032-3-M16-12
SR 14-601 BLD T15/S7 SW6-T
ERW D028A040-4-M16-12
SR 14-601 BLD T15/S7 SW6-T
ERW-M
Rough Profiling Tools with
a FLEXFIT Adaptation
281
PROFILING TOOLS
OAL
IC
APMX
DC
DCX
DCONMS
DHUB
Rd°
Designation
DCX(1) DC IC APMX CICT(2) OAL DHUB DCONMS RMPX°(3) CSP(4) Arbor(5) MIID(6)
kg
FRW D030A040-05-16-10
40.00 30.00 10.00 5.00 5 35.00 35.00 16.00 3.0 1 A RCCT 1004MO 0.16
FRW D028A040-04-16-12
40.00 28.00 12.00 6.00 4 40.00 35.00 16.00 6.5 1 A RCCT 1206MO 0.15
FRW D038A050-05-22-12
50.00 38.00 12.00 6.00 5 45.00 45.00 22.00 5.0 1 A RCCT 1206MO 0.29
FRW D040A052-05-22-12
52.00 40.00 12.00 6.00 5 45.00 45.00 22.00 5.0 1 A RCCT 1206MO 0.31
FRW D051A063-06-22-12
63.00 51.00 12.00 6.00 6 45.00 48.00 22.00 4.0 1 A RCCT 1206MO 0.46
FRW D054A066-06-27-12
66.00 54.00 12.00 6.00 6 50.00 50.00 27.00 4.0 1 A RCCT 1206MO 0.54
FRW D068A080-07-27-12
80.00 68.00 12.00 6.00 7 50.00 58.50 27.00 3.0 0 B RCCT 1206MO 0.71
FRW D034A050-04-22-16
50.00 34.00 16.00 8.00 4 54.00 42.00 22.00 11.0 1 A RCMT 1607MO 0.26
FRW D036A052-04-22-16
52.00 36.00 16.00 8.00 4 50.00 42.00 22.00 10.0 1 A RCMT 1607MO 0.26
FRW D047A063-05-22-16
63.00 47.00 16.00 8.00 5 45.00 48.00 22.00 7.0 1 A RCMT 1607MO 0.40
FRW D050A066-05-22-16
66.00 50.00 16.00 8.00 5 45.00 48.00 22.00 6.0 1 A RCMT 1607MO 0.42
FRW D050A066-05-27-16
66.00 50.00 16.00 8.00 5 50.00 50.00 27.00 6.0 1 A RCMT 1607MO 0.46
FRW D064A080-06-27-16
80.00 64.00 16.00 8.00 6 50.00 58.50 27.00 5.0 0 B RCMT 1607MO 0.65
FRW D084A100-07-32-16
100.00 84.00 16.00 8.00 7 50.00 70.00 32.00 4.0 0 B RCMT 1607MO 1.11
FRW D109A125-07-40-16
125.00 109.00 16.00 8.00 7 63.00 90.00 40.00 3.0 0 B RCMT 1607MO 2.33
FRW D060A080-05-27-20
80.00 60.00 20.00 10.00 5 50.00 58.50 27.00 7.0 0 B RCMT 2009MO 0.61
FRW D080A100-06-32-20
100.00 80.00 20.00 10.00 6 50.00 70.00 32.00 5.0 0 B RCMT 2009MO 0.98
FRW D105A125-07-40-20
125.00 105.00 20.00 10.00 7 63.00 82.00 40.00 4.0 0 B RCMT 2009MO 1.98
FRW D140A160-08-40-20
160.00 140.00 20.00 10.00 8 63.00 116.00 40.00 3.0 0 C RCMT 2009MO 3.55
• For user guide, see pages 287-289
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) 0 - Without coolant supply, 1 - With coolant supply
(5) For adaptation options, see page 548
(6) Master insert identification
For inserts, see pages: RCMT/RCCT-MO (528) • RCMT/RCMW/RCCW-FW (529) • RCMW/RCCW-MO (528)
Spare Parts
Designation
FRW D030A040-05-16-10
SR 34-506/L T-9/51 SR M8X25DIN912
FRW D028A040-04-16-12
SR 14-601 BLD T15/S7 SW6-T SR M8X25DIN912
FRW D038A050-05-22-12
SR 14-601 BLD T15/S7 SW6-T SR M10X25 DIN912
FRW D040A052-05-22-12
SR 14-601 BLD T15/M7 SW6-T SR M10X25 DIN912
FRW D051A063-06-22-12
SR 14-601 BLD T15/M7 SW6-T SR M10X25 DIN912
FRW D054A066-06-27-12
SR 14-601 BLD T15/M7 SW6-T
FRW D068A080-07-27-12
SR 14-601 BLD T15/M7 SW6-T
FRW D034A050-04-22-16
SR 14-536/M BLD T20/M7 SW6-T SR M10X30 DIN912
FRW D036A052-04-22-16
SR 14-536/M BLD T20/M7 SW6-T SR M10X30 DIN912
FRW D047A063-05-22-16
SR 14-536/M BLD T20/M7 SW6-T SR M10X25 DIN912
FRW D050A066-05-22-16
SR 14-536/M BLD T20/M7 SW6-T SR M10X25 DIN912
FRW D050A066-05-27-16
SR 14-536/M BLD T20/M7 SW6-T SR M12X30DIN912
FRW D064A080-06-27-16
SR 14-536/M BLD T20/M7 SW6-T
FRW D084A100-07-32-16
SR 14-536/M BLD T20/M7 SW6-T
FRW D109A125-07-40-16
SR 14-536/M BLD T20/L7 SW6-T
FRW D060A080-05-27-20
SR 14-2120(a) BLD IP25/M7(b) SW6-T
FRW D080A100-06-32-20
SR 14-2120(a) BLD IP25/M7(b) SW6-T
FRW D105A125-07-40-20
SR 14-2120(a) BLD IP25/L7(b) SW6-T
FRW D140A160-08-40-20
SR 14-2120(a) BLD IP25/L7(b) SW6-T
(a) Recommended tightening torque:9 N*m
(b) Torx Plus
FRW
Rough Profiling Face Mills with
Serrated or Regular Round Inserts
ISCAR
282
PROFILING TOOLS
BD
DCX DC
LH
APMX
DCONMS
OAL
Rd°
Designation
DCX(1) DC BD CICT(2) APMX LH OAL DCONMS Shank(3) RMPX°(4) MIID(5)
kg
H400 ER D20-2-060-C20-10
20.00 10.00 17.50 2 7.50 60.0 160.00 20.00 C - H400 RNHU 1004-ML 0.33
H400 ER D25-3-060-C25-10
25.00 15.00 21.60 3 7.50 60.0 120.00 25.00 C 5.8 H400 RNHU 1004-ML 0.35
H400 ER D32-5-060-C32-10
32.00 22.00 29.60 5 7.50 60.0 120.00 32.00 C 3.8 H400 RNHU 1004-ML 0.59
(1) Cutting diameter maximum
(2) Number of inserts
(3) C-Cylindrical
(4) Maximum ramping angle
(5) Master insert identification
For inserts, see pages: H400 RNHU (532)
Insert Clamping Orientation
Spare Parts
Designation
H400 ER-10
SR 10508600 T-9/51
H400 ER-10
Endmills Carrying Double-Sided
Inserts with Four 5 mm
Radius Cutting Edges
BD
DCX DC
LH
APMX
DCONMS
OAL
Rd°
Designation
DCX(1) DC BD CICT(2) APMX LH OAL DCONMS Shank(3) RMPX°(4) MIID(5)
kg
H400 ER D25-2-060-C25-12
25.00 13.00 21.60 2 8.70 60.0 120.00 25.00 C 5.6 H400 RNHU 1205-AX 0.34
H400 ER D32-4-060-C32-12
32.00 20.00 28.40 4 8.70 60.0 120.00 32.00 C 5.6 H400 RNHU 1205-AX 0.58
H400 ER D40-5-060-C32-12
40.00 28.00 31.50 5 8.70 60.0 150.00 32.00 C 3.7 H400 RNHU 1205-AX 0.80
(1) Cutting diameter maximum
(2) Number of inserts
(3) C-Cylindrical
(4) Maximum ramping angle
(5) Master insert identification
For inserts, see pages: H400 RNHU (532)
Spare Parts
Designation
H400 ER-12
SR 14-571 T-10/51
H400 ER-12
Endmills Carrying Double-Sided
Inserts with Four 6 mm
Radius Cutting Edges
283
PROFILING TOOLS
DCX DC
DRVS
DCONMS
OAL
LF
APMX
THSZMS
Rd°
Designation
DCX(1) DC DCONMS CICT(2) APMX LF OAL DRVS(3) RMPX°(4) THSZMS MIID(5) TQ_3(6)
kg
H400 ER D20-2-M10-10
20.00 10.00 16.60 2 7.50 25.00 45.00 15.0 - M10 H400 RNHU 1004-ML 29 0.04
H400 ER D25-3-M12-10
25.00 15.00 21.00 3 7.50 28.00 50.00 19.0 5.8 M12 H400 RNHU 1004-ML 33 0.07
H400 ER D32-5-M16-10
32.00 22.00 29.60 5 7.50 35.00 60.00 25.0 3.8 M16 H400 RNHU 1004-ML 40 0.17
H400 ER D25-2-M12-12
25.00 13.00 21.60 2 8.70 28.00 50.00 19.0 5.6 M12 H400 RNHU 1205-AX 33 0.07
H400 ER D32-4-M16-12
32.00 20.00 28.40 4 8.70 35.00 60.00 25.0 5.6 M16 H400 RNHU 1205-AX 40 0.15
H400 ER D40-5-M16-12
40.00 28.00 29.00 5 8.70 35.00 60.00 25.0 3.7 M16 H400 RNHU 1205-AX 40 0.19
• When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening
torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) Cutting diameter maximum
(2) Number of inserts
(3) Clamping wrench size
(4) Maximum ramping angle
(5) Master insert identification
(6) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: H400 RNHU (532)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314)• CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
Spare Parts
Designation
H400 ER D20-2-M10-10
SR 10508600 T-9/51
H400 ER D25-3-M12-10
SR 10508600 T-9/51
H400 ER D32-5-M16-10
SR 10508600 T-9/51
H400 ER D25-2-M12-12
SR 14-571 T-10/51
H400 ER D32-4-M16-12
SR 14-571 T-10/51
H400 ER D40-5-M16-12
SR 14-571 T-10/51
H400 ER-M
Endmills with FLEXFIT
Threaded Connection Carrying
Double-Sided Inserts with
Four Radius Cutting Edges
ISCAR
284
PROFILING TOOLS
DCONMS
DHUB
OAL
APMX
DCX
DC
Rd°
Designation
DCX(1) DC CICT(2) APMX OAL DHUB DCONMS RMPX°(3) Arbor(4) MIID(5)
kg
H400 FR D040-06-16-10
40.00 30.00 6 7.50 35.00 37.60 16.00 2.6 A H400 RNHU 1004-ML 0.18
H400 FR D050-07-22-10
50.00 40.00 7 7.50 40.00 47.00 22.00 1.9 A H400 RNHU 1004-ML 0.33
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) For adaptation options, see page 548
(5) Master insert identification
For inserts, see pages: H400 RNHU (532)
Spare Parts
Designation
H400 FR D040-06-16-10
SR 10508600 T-9/51 SR M8X25DIN912
H400 FR D050-07-22-10
SR 10508600 T-9/51 SR M10X25 DIN912
H400 FR-10
Face Mills Carrying Double-Sided
Inserts with Four 5 mm
Radius Cutting Edges
DCONMS
DHUB
OAL
APMX
DCX
DC
Rd°
Designation
DCX(1) DC CICT(2) APMX OAL DHUB DCONMS RMPX°(3) Arbor(4) MIID(5)
kg
H400 FR D040-05-16-12
40.00 28.00 5 8.70 40.00 38.00 16.00 3.7 A H400 RNHU 1205-AX 0.20
H400 FR D050-06-22-12
50.00 38.00 6 8.70 50.00 45.00 22.00 2.6 A H400 RNHU 1205-AX 0.39
H400 FR D052-06-22-12
52.00 40.00 6 8.70 50.00 45.00 22.00 2.5 A H400 RNHU 1205-AX 0.42
H400 FR D063-07-22-12
63.00 51.00 7 8.70 50.00 60.00 22.00 1.9 A H400 RNHU 1205-AX 0.79
H400 FR D066-07-27-12
66.00 54.00 7 8.70 50.00 61.00 27.00 1.8 A H400 RNHU 1205-AX 0.78
H400 FR D080-08-27-12
80.00 68.00 8 8.70 50.00 62.00 27.00 1.5 A H400 RNHU 1205-AX 1.03
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) For adaptation options, see page 548
(5) Master insert identification
For inserts, see pages: H400 RNHU (532)
Insert Clamping Orientation
Spare Parts
Designation
H400 FR D040-05-16-12
SR 14-571 T-10/51 SR M8X25DIN912
H400 FR D050-06-22-12
SR 14-571 T-10/51 SR M10X25 DIN912
H400 FR D052-06-22-12
SR 14-571 T-10/51 SR M10X25 DIN912
H400 FR D063-07-22-12
SR 14-571 T-10/51 SR M10X25 DIN912
H400 FR D066-07-27-12
SR 14-571 T-10/51 SR M12X30DIN912
H400 FR D080-08-27-12
SR 14-571 T-10/51 SR M12X30DIN912
H400 FR-12
Face Mills Carrying Double-Sided
Inserts with Four 6 mm
Radius Cutting Edges
285
PROFILING TOOLS
DCONMS
DHUB
OAL
APMX
DCX DC
Rd°
Designation
DCX(1) DC CICT(2) APMX OAL DHUB DCONMS RMPX°(3) Arbor(4)
kg
MIID(5)
H400 FR D050-05-22-16
50.00 34.00 5 12.00 50.00 47.00 22.00 3.3 A 0.41 H400 RNHU 1606-AX
H400 FR D063-06-22-16
63.00 47.00 6 12.00 50.00 48.00 22.00 2.5 A 0.74 H400 RNHU 1606-AX
H400 FR D066-06-27-16
66.00 50.00 6 12.00 50.00 60.60 27.00 2.3 A 0.79 H400 RNHU 1606-AX
H400 FR D080-07-27-16
80.00 64.00 7 12.00 50.00 63.60 27.00 1.8 A 1.09 H400 RNHU 1606-AX
H400 FR D100-09-32-16
100.00 84.00 9 12.00 49.60 84.00 32.00 1.3 A 0.00 H400 RNHU 1606-AX
H400 FR D125-11-40-16
125.00 109.00 11 12.00 55.00 84.00 40.00 1.0 A 3.02 H400 RNHU 1606-AX
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) For adaptation options, see page 548
(5) Master insert identification
For inserts, see pages: H400 RNHU (532)
Insert Clamping Orientation
Spare Parts
Designation
H400 FR D050-05-22-16
SR 14-591/H BLD T20/M7 SW6-T SR M10X25 DIN912
H400 FR D063-06-22-16
SR 14-591/H BLD T20/M7 SW6-T SR M10X25 DIN912
H400 FR D066-06-27-16
SR 14-591/H BLD T20/M7 SW6-T SR M12X30DIN912
H400 FR D080-07-27-16
SR 14-591/H BLD T20/M7 SW6-T SR M12X30DIN912
H400 FR D100-09-32-16
SR 14-591/H BLD T20/M7 SW6-T
H400 FR D125-11-40-16
SR 14-591/H BLD T20/M7 SW6-T
H400 FR-16
Face Mills Carrying Double-Sided
Inserts with Four 8 mm
Radius Cutting Edges
DRVS
DCX DCONMS
APMX
DC
R6.0
OAL
LF
THSZMS
Rd°
Designation
DCX(1) DC DCONMS CICT(2) APMX LF OAL DRVS(3) RMPX°(4) THSZMS TQ_3(5)
kg
H606 ER D032-03-M16-12
32.00 20.00 29.00 3 6.00 35.00 60.00 25.0 2.5 M16 40 0.15 SR 14-571 T-10/51(a)
• When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening
torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) Cutting diameter maximum
(2) Number of inserts
(3) Clamping wrench size
(4) Maximum ramping angle
(5) Tool tightening torque Nxm (lbfxin)
(a) For limiting torque, use optional 7007383 BLD 4 T10-3.2NM blade & 7007321 HSD 4-3.2NM handle
For inserts, see pages: H606 RXCU 1206 (532)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
H606 ER-M
Endmills with FLEXFIT Threaded
Connection Carrying
Double-Sided Inserts with Six
6 mm Radius Cutting Edges
ISCAR
286
PROFILING TOOLS
DCONMS
DHUB
OAL
APMX
DCX
DC R6.0
Rd°
Designation
DCX(1) DC CICT(2) APMX OAL DHUB DCONMS RMPX°(3) Arbor(4)
kg
H606 FR D040-04-16-12
40.00 28.00 4 6.00 45.00 38.00 16.00 2.0 A 0.22
H606 FR D050-06-22-12
50.00 38.00 6 6.00 50.00 47.00 22.00 1.3 A 0.38
H606 FR D052-06-22-12
52.00 40.00 6 6.00 50.00 47.00 22.00 1.3 A 0.39
H606 FR D063-07-22-12
63.00 51.00 7 6.00 50.00 48.00 22.00 1.0 A 0.52
H606 FR D080-08-27-12
80.00 68.00 8 6.00 50.00 58.00 27.00 0.7 A 0.83
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) For adaptation options, see page 548
For inserts, see pages: H606 RXCU 1206 (532)
Spare Parts
Designation
H606 FR D040-04-16-12
SR 14-571 T-10/51(a) SR PS 118-0416
H606 FR D050-06-22-12
SR 14-571 T-10/51(a) SR M10X25 DIN912
H606 FR D052-06-22-12
SR 14-571 T-10/51(a) SR M10X25 DIN912
H606 FR D063-07-22-12
SR 14-571 T-10/51(a) SR M10X25 DIN912
H606 FR D080-08-27-12
SR 14-571 T-10/51(a) SR M12X30DIN912
(a) For limiting torque, use optional 7007383 BLD 4 T10-3.2NM blade & 7007321 HSD 4-3.2NM handle
H606 FR-12
Face Mills Carrying Double-
Sided Inserts with Six 6 mm
Radius Cutting Edges
287
USER GUIDE
Machining Recommendations
• Excellent tool stability
• Chips split into small pieces
• Optimal chip flow with easy evacuation, even from deep cavities
• High tooth load capability, up to 8 mm depth-of-cut, which will significantly reduce machining time
• Small cutting forces, therefore the required machining power is low
RCMT 1607-FW
12˚
Material Group Hardness (HB) Typical Materials Depth Ap (mm) Vc (m/min) Fz (mm/tooth) Recommended
Low carbon steel 125-180 C15, ST37, 1.0401 4 150 0.3 33
Low alloy steel 170-220 CK45,1.1231,16MnCr5 4 150 0.3 33
High alloy steel 200-260 X20Cr13,1.4923 4 150 0.3 33
Tool & die steel 280-370 1.2379,1.2311 3 150 0.3 33
Stainless steel 150-270 1.4404,316,321 - - - -
Grey cast iron 200-250 GG25,GRADE220 5 150-180 0.3 3
S.G. iron 180-250 GGG60,SNG600/3 5 110-150 0.3 3
Titanium 450-500 TiAI4Mo4Sn4Si0.5 4 50 0.2 3
Aluminum 75-130 G-AISi12 - - - -
Hardened die steel 38-42 HRc 1.2344,1.2379 3 120 0.2 3
Hardened die steel 48-52 HRc 1.2762,1.1545 - - - -
RCMT 1607-FW-F20
20˚
Material Group Hardness (HB) Typical Materials Depth Ap (mm) Vc (m/min) Fz (mm/tooth) Recommended
Low carbon steel 125-180 C15,ST37,1.0401 3 150 0.3 3
Low alloy steel 170-220 CK45,1.1231,16MnCr5 - - - -
High alloy steel 200-260 X20Cr13,1.4923 - - - -
Tool & die steel 280-370 1.2379,1.2311 - - - -
Stainless steel 150-270 1.4306,304, 1.4404,316 6 100 0.1 33
Grey cast iron 200-250 GG25,GRADE220 - - - -
S.G. iron 180-250 GGG60,SNG600/3 - - - -
Titanium 450-500 TiAI4Mo4Sn4Si0.5 - - - -
Aluminum 75-130 G-AISi12 6 850 0.4 33
Hardened die steel 38-42 HRc 1.2344,1.2379 - - - 3
Hardened die steel 48-52 HRc 1.2762,1.1545 - - - -
RCMT 1607 FW-T20
0.15
20˚ 20
˚
Material Group Hardness (HB) Typical Materials Depth Ap (mm) Vc (m/min) Fz (mm/tooth) Recommended
Low carbon steel 125-180 C15,ST37,1.0401 3 150 0.3 3
Low alloy steel 170-220 CK45,1.1231,16MnCr5 3 150 0.3 3
High alloy steel 200-260 X20Cr13,1.4923 - - - -
Tool & die steel 280-370 1.2379,1.2311 - - - -
Stainless steel 150-270 1.4031, 420 6 120 0.2 33
Grey cast iron 200-250 GG25,GRADE220 - - - -
S.G. iron 180-250 GGG60,SNG600/3 - - - -
Titanium 450-500 TiAI4Mo4Sn4Si0.5 - - - -
Aluminum 75-130 G-AISi12 - - - -
Hardened die steel 38-42 HRc 1.2344,1.2379 - - - -
Hardened die steel 48-52 HRc 1.2762,1.1545 - - - -
33 Most Recommended
3 Second option
PROFILING TOOLS
ISCAR
288
USER GUIDE
RCCW 1607-FW
Material Group Hardness (HB) Typical Materials Depth Ap (mm) Vc (m/min) Fz (mm/tooth) Recommended
Low carbon steel 125-180 C15,ST37,1.0401 4 150 0.3 3
Low alloy steel 170-220 CK45,1.1231,16MnCr5 4 150 0.3 33
High alloy steel 200-260 X20Cr13,1.4923 4 150 0.3 33
Tool & die steel 280-370 1.2379,1.2311 4 150 0.3 33
Stainless steel 150-270 1.4404,316,321 - - - -
Grey cast iron 200-250 GG25,GRADE220 - - - -
S.G. iron 180-250 GGG60,SNG600/3 - - - -
Titanium 450-500 TiAI4Mo4Sn4Si0.5 - - - -
Aluminum 75-130 G-AISi12 - - - -
Hardened die steel 38-42 HRc 1.2344,1.2379 4 120 0.2 3
Hardened die steel 48-52 HRc 1.2762,1.1545 - - - -
RCMW 1607-T-FW
0.15
20
˚
Material Group Hardness (HB) Typical Materials Depth Ap (mm) Vc (m/min) Fz (mm/tooth) Recommended
Low carbon steel 125-180 C15,ST37,1.0401 - - - -
Low alloy steel 170-220 CK45,1.1231,16MnCr5 4 150 0.3 3
High alloy steel 200-260 X20Cr13,1.4923 4 150 0.3 33
Tool & die steel 280-370 1.2379,1.2311 3 150 0.3 33
Stainless steel 150-270 1.4404,316,321 - - - -
Grey cast iron 200-250 GG25,GRADE220 5 150-180 0.3 33
S.G. iron 180-250 GGG60,SNG600/3 5 110-150 0.3 33
Titanium 450-500 TiAI4Mo4Sn4Si0.5 - - - -
Alumnum 75-130 G-AISi12 - - - -
Hardened die steel 38-42 HRc 1.2344,1.2379 - - - -
Hardened die steel 48-52 HRc 1.2762,1.1545 - - - -
RCMW 1607-T-FPW
0.1
15
˚
Material Group Hardness (HB) Typical Materials Depth Ap (mm) Vc (m/min) Fz (mm/tooth) Recommended
Low carbon steel 125-180 C15,ST37,1.0401 4 150 0.3 3
Low alloy steel 170-220 CK45,1.1231,16MnCr5 4 150 0.3 33
High alloy steel 200-260 X20Cr13,1.4923 4 150 0.3 33
Tool & die steel 280-370 1.2379,1.2311 4 150 0.3 33
Stainless steel 150-270 1.4404,316,321 - - - -
Grey cast iron 200-250 GG25,GRADE220 - - - -
S.G. iron 180-250 GGG60,SNG600/3 - - - -
Titanium 450-500 TiAI4Mo4Sn4Si0.5 - - - -
Aluminum 75-130 G-AISi12 - - - -
Hardened die steel 38-42 HRc 1.2344,1.2379 4 120 0.25 33
Hardened die steel 48-52 HRc 1.2762,1.1545 4 80 0.1 33
33 Most Recommended
3 Second option
PROFILING TOOLS
289
USER GUIDE
Machining Recommendations
RCMT 1607MO
0.15
12˚ 20
˚
Material Group Hardness (HB) Typical Materials Depth Ap (mm) Vc (m/min) Fz (mm/tooth) Recommended
Low carbon steel 125-180 C15,ST37,1.0401 4 180 0.3 3
Low alloy steel 170-220 CK45,1.1231,16MnCr5 4 180 0.3 33
High alloy steel 200-260 X20Cr13,1.4923 4 180 0.3 33
Tool & die steel 280-370 1.2379,1.2311 - - - -
Stainless steel 150-270 1.4031, 420 6 120 0.3 33
Grey cast iron 200-250 GG25,GRADE220 - - - -
S.G. iron 180-250 GGG60,SNG600/3 - - - -
Titanium 450-500 TiAI4Mo4Sn4Si0.5 - - - -
Aluminum 75-130 G-AISi12 - - - -
Hardened die steel 38-42 HRc 1.2344,1.2379 - - - -
Hardened die steel 48-52 HRc 1.2762,1.1545 - - - -
RCMW 1607MO
0.3
20
˚
Material Group Hardness (HB) Typical Materials Depth Ap (mm) Vc (m/min) Fz (mm/tooth) Recommended
Low carbon steel 125-180 C15,ST37,1.0401 - - - -
Low alloy steel 170-220 CK45,1.1231,16MnCr5 2 180 0.7 33
High alloy steel 200-260 X20Cr13,1.4923 2 180 0.7 33
Tool & die steel 280-370 1.2379,1.2311 2 150 0.5 33
Stainless steel 150-270 1.4404,316,321 - - - -
Grey cast iron 200-250 GG25,GRADE220 2 300 0.7 33
S.G. iron 180-250 GGG60,SNG600/3 2 220 0.5 33
Titanium 450-500 TiAI4Mo4Sn4Si0.5 - - - -
Aluminum 75-130 G-AISi12 - - - -
Hardened die steel 38-42 HRc 1.2344,1.2379 2 150 0.4 3
Hardened die steel 48-52 HRc 1.2762,1.1545 - - - -
33 Most Recommended
3 Second option
PROFILING TOOLS
ISCAR
290
USER GUIDE
Feed Limit Recommendations as a Function of Overhang and Depth of Cut
Carbon and Alloy Steel Stainless Steel
L
300
250
200
150
4
fz=0.30-0.40
6
fz=0.25-0.30
8
fz=0.20-0.25
10
fz=0.15
ap (mm)
mm/tooth
L
Overhang (mm)
300
250
200
150
6
fz=0.12-0.20
8
fz=0.10-0.15
10
fz=0.07-0.12
ap (mm)
mm/tooth
L
Overhang (mm)
Insert Selection Guide
Insert Designation RCMT...FW RCMT...FW-T20 RCMT...FW-F20 RCCT...MO RCCW...MO
RC...1206
Workpiece
12° 20°
0.15
20°
20° 12°
15°
Geometry Positive rake face
Positive rake face
with T-Land
Positive rake face
sharp edge Positive rake face
Flat top face
with a T-Land
Alloy steel VVV V V V VVV
Mold steel VVV V V V VVV
Stainless steel VVV(1) VVV(2) VVV
Grey cast iron VV VVV
Aluminum VVV VV
High temp. alloys V VV VVV
Hardened mold steel
(45 HRc max) V V
Applications
Helical
Interpolation Shouldering
Contour
Milling
Ramping
Down Plunging Profiling
Pocket
Milling
(1) Recommended for martensitic stainless steel
(2) Recommended for austenitic stainless steel
V Least recommended
VV Second option
VVV Most recommended
PROFILING TOOLS
291
FAST FEED MILLIG TOOLS
FAST FEED MILLING TOOLS
ISCAR
292
FAST FEED MILLIG TOOLS
LH
OAL
DCONMS
LU
DCX
DC
APMX
14˚
Rd°
Designation
DCX(1) DC APMX AE(2) CICT(3) LU LH OAL DCONMS Shank(4) RMPX°(5) MDN(6) MDX(7) MIID(8) TQ(9)
kg
FFT3 EFM D08-2-060-C10-02
8.00 2.20 0.60 2.9 2 17.00 20.0 60.00 10.00 C 10.8 10.20 15.00 FFT3 TXMT 0201205T 0.5 0.03
FFT3 EFM D08-2-080-C12-02
8.00 2.20 0.60 2.9 2 26.00 30.0 80.00 12.00 C 10.8 10.20 15.00 FFT3 TXMT 0201205T 0.5 0.05
FFT3 EFM D10-3-070-C10-02
10.00 4.20 0.60 2.9 3 19.50 20.0 70.00 10.00 C 4.7 14.20 19.00 FFT3 TXMT 0201205T 0.5 0.04
FFT3 EFM D10-3-090-C12-02
10.00 4.20 0.60 2.9 3 30.00 33.0 90.00 12.00 C 4.7 14.20 19.00 FFT3 TXMT 0201205T 0.5 0.06
• Radius for programming 1.1 mm • To generate a straight surface without cusps, the width of cut must not exceed DC
(1) Cutting diameter maximum
(2) Maximum plunging width
(3) Number of inserts
(4) C-Cylindrical
(5) Maximum ramping angle
(6) Machinable diameter minimum for interpolation
(7) Machinable diameter maximum for interpolation
(8) Master insert identification
(9) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: FFT3 TXMT 02 (445)
Spare Parts
Designation
FFT3 EFM-02
SR M2X0.4-2.9 T6-HG(a) T-6/5 MAGNET 3X3
(a) Recommended tightening torque:0.5 N*m
FFT3 EFM-02
Small Diameter Endmills
Carrying Single-Sided Triangular
Inserts for Fast Feed Milling
DC
OAL
LF
DCX
APMX 14˚
THSZMS DCONMS
Rd°
Designation
DCX(1) DC APMX AE(2) CICT(3) LF DCONMS THSZMS OAL DRVS(4) RMPX°(5) MDN(6) MDX(7) MIID(8) TQ(9)
kg
FFT3 EFMD08/.31-2MMT05-02
8.00 2.20 0.60 2.9 2 10.00 7.60 T05 16.75 5.5 10.8 10.20 15.00 FFT3 TXMT 0201205T 0.5 0.01
FFT3 EFMD10/.39-3MMT06-02
10.00 4.20 0.60 2.9 3 10.00 9.70 T06 16.30 8.0 4.7 14.20 19.00 FFT3 TXMT 0201205T 0.5 0.01
• For adaptation, see pages 261 • For user guide, see pages 542-547 • Radius for programing 1.1 mm • To generate a straight surface without cusps, the width of cut
must not exceed DC
(1) Cutting diameter maximum
(2) Maximum plunging width
(3) Number of inserts
(4) Torque key size
(5) Maximum ramping angle
(6) Machinable diameter minimum for interpolation
(7) Machinable diameter maximum for interpolation
(8) Master insert identification
(9) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: FFT3 TXMT 02 (445)
For holders, see pages: MM CAB (667) • MM CAB-T-T (91) • MM GRT (shanks) (86) • MM S-A (stepped shanks) (84) • MM S-A (straight shanks) (87) • MM S-A-C# (86)
• MM S-A-HSK (609) • MM S-A-N (85) • MM S-A-SK (90) • MM S-B (85° conical shanks) (87) • MM S-D (89° conical shanks) (88) • MM S-ER (89) • MM S-ER-H (89)
• MM TS-A (86)
Spare Parts
Designation
FFT3 EFM-MM 02
SR M2X0.4-2.9 T6-HG T-6/5 MAGNET 3X3
FFT3 EFM-MM 02
Small Diameter Endmills with
a MULTI-MASTER Threaded
Adaptation Carrying Triangular
Inserts for Fast Feed Milling
293
FAST FEED MILLIG TOOLS
DC
OAL
LF
DRVS
DCX
THSZMS DCONMS
A
APMX
17°
Rd°
Designation
DCX(1) DC APMX AE(2) CICT(3) LF DCONMS THSZMS OAL DRVS(4) RMPX°(5) MDN(6) MDX(7) MIID(8)
kg
FFT3 EFMD10/.39-2MMT06-03
10.00 5.60 0.60 2.2 2 10.00 9.70 T06 16.30 8.0 6.9 15.60 19.00 FFT3 WXMT 030206T 0.02
FFT3 EFMD12/.47-3MMT08-03
12.00 7.60 0.60 2.2 3 15.00 11.70 T08 22.50 10.0 4.7 19.60 23.00 FFT3 WXMT 030206T 0.03
FFT3 EFMD16/.63-4MMT10-03
16.00 11.60 0.60 2.2 4 20.00 15.30 T10 31.30 13.0 2.9 27.60 31.00 FFT3 WXMT 030206T 0.05
FFT3 EFMD20/.78-5MMT12-03
20.00 15.60 0.60 2.2 5 25.00 19.00 T12 38.30 16.0 2.0 35.60 39.00 FFT3 WXMT 030206T 0.07
FFT3 EFMD25/.98-6MMT15-03
25.00 20.60 0.60 2.2 6 30.00 24.00 T15 47.00 20.0 1.5 45.60 49.00 FFT3 WXMT 030206T 0.00
• Radius for programming 1.1 mm • To generate a straight surface without cusps, the width of cut must not exceed DC
(1) Cutting diameter maximum
(2) Maximum plunging width
(3) Number of inserts
(4) Torque key size
(5) Maximum ramping angle
(6) Machinable diameter minimum for interpolation
(7) Machinable diameter maximum for interpolation
(8) Master insert identification
For inserts, see pages: FFT3 WXMT 03 (521)
For holders, see pages: MM CAB (667) • MM CAB-T-T (91) • MM GRT (shanks) (86) • MM S-A (stepped shanks) (84) • MM S-A (straight shanks) (87)
• MM S-A-C# (86) • MM S-A-HSK (609) • MM S-A-N (85) • MM S-A-SK (90) • MM S-B (85° conical shanks) (87) • MM S-D (89° conical shanks) (88)
• MM S-ER (89) • MM S-ER-H (89) • MM TS-A (86)
Spare Parts
Designation
FFT3 EFM-MM 03
TS 18041I/HG(a) T-6IP/51
(a) Recommended tightening torque: 0.5 Nxm
FFT3 EFM-MM 03
Endmills with a MULTI-MASTER
Threaded Adaptation Carrying
Single-Sided Small Trigon
Inserts for Fast Feed Milling
OAL
LH
DCX DC
APMX
17°
DCONMS
A
A
Rd°
Designation
DCX(1) DC APMX AE(2) CICT(3) LH OAL DCONMS Shank(4) RMPX°(5) MDN(6) MDX(7) MIID(8)
kg
FFT3 EFM D08-1-080-C12-03
8.00 3.60 0.60 2.2 1 20.0 80.00 12.00 C 1.1 11.60 15.00 FFT3 WXMT 030206T 0.00
FFT3 EFM D10-2-080-C10-03
10.00 5.60 0.60 2.2 2 20.0 80.00 10.00 C 6.9 15.60 19.00 FFT3 WXMT 030206T 0.11
FFT3 EFM D12-3-120-C12-03
12.00 7.60 0.60 2.2 3 25.0 120.00 12.00 C 4.7 19.60 23.00 FFT3 WXMT 030206T 0.14
FFT3 EFM D16-4-140-C16-03
16.00 11.60 0.60 2.2 4 35.0 140.00 16.00 C 2.9 27.60 31.00 FFT3 WXMT 030206T 0.18
FFT3 EFM D20-5-160-C20-03
20.00 15.60 0.60 2.2 5 43.0 160.00 20.00 C 2.0 35.60 39.00 FFT3 WXMT 030206T 0.37
FFT3 EFM D25-6-180-C25-03
25.00 20.60 0.60 2.2 6 53.0 180.00 25.00 C 1.5 45.60 49.00 FFT3 WXMT 030206T 0.62
• Radius for programming 1.1 mm • To generate a straight surface without cusps, the width of cut must not exceed DC
(1) Cutting diameter maximum
(2) Maximum plunging width
(3) Number of inserts
(4) C-Cylindrical
(5) Maximum ramping angle
(6) Machinable diameter minimum for interpolation
(7) Machinable diameter maximum for interpolation
(8) Master insert identification
For inserts, see pages: FFT3 WXMT 03 (521)
Spare Parts
Designation
FFT3 EFM-03
TS 18041I/HG(a) T-6IP/51
(a) Recommended tightening torque:0.5 Nxm
FFT3 EFM-03
Endmills Carrying Single-Sided
Small Trigon Inserts for
Fast Feed Milling
ISCAR
294
FAST FEED MILLIG TOOLS
DCX DC
17˚
LF
OAL
DRVS
DCONMS
THSZMS
APMX
Rd°
Designation
DCX(1) DC CICT(2) APMX AE(3) THSZMS LF OAL DCONMS RMPX°(4) MDN(5) MDX(6) DRVS(7) Rg(8) MIID(9) TQ(10) TQ_3(11)
kg
FFX4 ED20/.78-3-M10-04
20.00 12.60 3 0.80 3.7 M10 25.00 45.00 18.00 2.7 32.60 39.00 15.0 1.80 FFX4 XNMU 040310T 0.9 29 0.04
FFX4 ED25/.98-4-M12-04
25.00 17.60 4 0.80 3.7 M12 30.00 52.00 21.00 1.8 42.60 49.00 19.0 1.80 FFX4 XNMU 040310T 0.9 33 0.08
FFX4 ED32/1.26-5-M16-04
32.00 24.60 5 0.80 3.7 M16 35.00 60.00 29.00 1.2 56.60 63.00 27.0 1.80 FFX4 XNMU 040310T 0.9 40 0.18
FFX4 ED35/1.38-5-M16-04
35.00 27.60 5 0.80 3.7 M16 35.00 60.00 29.00 1.1 62.60 69.00 25.0 1.80 FFX4 XNMU 040310T 0.9 40 0.20
FFX4 ED42/1.65-6-M16-04
42.00 34.60 6 0.80 3.7 M16 40.00 65.00 29.00 0.8 76.60 83.00 25.0 1.80 FFX4 XNMU 040310T 0.9 40 0.30
• To generate a straight surface without cusps, the width of cut must not exceed DC • When mounting items with FLEXFIT threaded adaptation to their holders, the mating
surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are
specified in the TQ_3 parameter
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum plunging width
(4) Maximum ramping angle
(5) Machinable diameter minimum for interpolation
(6) Machinable diameter maximum for interpolation
(7) Torque key size
(8) Radius for programming
(9) Master insert identification
(10) Recommended tightening torque (N*m) for insert screw
(11) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: FFX4 XNMU-04 (523)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
Spare Parts
Designation
FFX4 ED-M
SR M2.5X6-T7-60 T-7/51
FFX4 ED-M
Endmills with FLEXFIT Adaptation
Carrying Small "Bone Shaped”
Inserts with 4 Cutting Edges
for Fast Feed Milling
17˚
DCONMS
APMX
OAL
LH
DCX DC
Rd°
Designation
DCX(1) DC APMX AE(2) CICT(3) LH KAPR(4) OAL DCONMS RMPX°(5) MDN(6) MDX(7) Shank(8) Rg(9) MIID(10) TQ(11)
kg
FFX4 ED12-1-030-C12-04
12.00 4.60 0.80 3.7 1 30.0 17.0 90.00 12.00 3.6 16.60 23.00 C 1.80 FFX4 XNMU 040310T 0.9 0.07
FFX4 ED16-2-030-C16-04
16.00 8.60 0.80 3.7 2 30.0 17.0 120.00 16.00 4.3 24.60 31.00 C 1.80 FFX4 XNMU 040310T 0.9 0.16
FFX4 ED16-2-050-W20-04
16.00 8.60 0.80 3.7 2 50.0 17.0 110.00 20.00 4.3 24.60 31.00 W 1.80 FFX4 XNMU 040310T 0.9 0.20
FFX4 ED20-3-050-C20-04
20.00 12.60 0.80 3.7 3 50.0 17.0 140.00 20.00 2.7 32.60 39.00 C 1.80 FFX4 XNMU 040310T 0.9 0.29
FFX4 ED20-3-060-W20-04
20.00 12.60 0.80 3.7 3 60.0 17.0 120.00 20.00 2.7 32.60 39.00 W 1.80 FFX4 XNMU 040310T 0.9 0.24
FFX4 ED25-4-060-C25-04
25.00 17.60 0.80 3.7 4 60.0 17.0 150.00 25.00 1.8 42.60 49.00 C 1.80 FFX4 XNMU 040310T 0.9 0.50
FFX4 ED25-4-080-W25-04
25.00 17.60 0.80 3.7 4 80.0 17.0 140.00 25.00 1.8 42.60 49.00 W 1.80 FFX4 XNMU 040310T 0.9 0.45
FFX4 ED32-5-080-W32-04
32.00 24.60 0.80 3.7 5 80.0 17.0 150.00 32.00 1.2 56.60 63.00 W 1.80 FFX4 XNMU 040310T 0.9 0.80
FFX4 ED32-5-120-C32-04
32.00 24.60 0.80 3.7 5 120.0 17.0 205.00 32.00 1.2 56.60 63.00 C 1.80 FFX4 XNMU 040310T 0.9 1.02
• To generate a straight surface without cusps, the width of cut must not exceed DC
(1) Cutting diameter maximum
(2) Maximum plunging width
(3) Number of inserts
(4) Tool cutting edge angle
(5) Maximum ramping angle
(6) Machinable diameter minimum for interpolation
(7) Machinable diameter maximum for interpolation
(8) C-Cylindrical, W-Weldon
(9) Radius for programming
(10) Master insert identification
(11) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: FFX4 XNMU-04 (523)
Spare Parts
Designation
FFX4 ED
SR M2.5X6-T7-60 T-7/51
FFX4 ED
Endmills Carrying Small
Double-Sided "Bone Shaped”
Inserts with 4 Cutting Edges
for Fast Feed Milling
295
FAST FEED MILLIG TOOLS
DCONMSTHSZMS
LF OAL
DRVS
APMX 17˚
DCX DC
Rd°
Designation
DCX(1) DC CICT(2) APMX AE(3) THSZMS LF OAL DCONMS RMPX°(4) MDN(5) MDX(6) DRVS(7) MIID(8) TQ(9) Rg(10)
kg
FFX4 ED16/.63-2-MMT10-04
16.00 8.60 2 0.80 3.7 T10 20.00 31.75 15.20 4.3 24.60 31.00 13.0 FFX4 XNMU 040310T 0.9 1.80 0.02
FFX4 ED20/.78-3-MMT12-04
20.00 12.60 3 0.80 3.7 T12 25.00 38.30 18.80 2.7 32.60 39.00 15.0 FFX4 XNMU 040310T 0.9 1.80 0.04
FFX4 ED25/.98-4-MMT15-04
25.00 17.60 4 0.80 3.7 T15 30.00 47.00 24.00 1.8 42.60 49.00 19.0 FFX4 XNMU 040310T 0.9 1.80 0.14
• To generate a straight surface without cusps,the width of cut must not exceed DC
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum plunging width
(4) Maximum ramping angle
(5) Machinable diameter minimum for interpolation
(6) Machinable diameter maximum for interpolation
(7) Torque key size
(8) Master insert identification
(9) Recommended tightening torque (N*m) for insert screw
(10) Radius for programming
For inserts, see pages: FFX4 XNMU-04 (523)
For holders, see pages: MM CAB-T-T (91) • MM S-A (stepped shanks) (84) • MM S-A (straight shanks) (87) • MM S-A-C# (86) • MM S-A-HSK (609) • MM S-A-N (85)
• MM S-A-SK (90) • MM S-B (85° conical shanks) (87) • MM S-D (89° conical shanks) (88) • MM S-ER (89) • MM S-ER-H (89) • MM TS-A (86)
Spare Parts
Designation
FFX4 ED-MM
SR M2.5X6-T7-60 T-7/51
FFX4 ED-MM
Endmills with MULTI-MASTER
Adaptation Carrying Small "Bone
Shaped” Inserts with 4 Cutting
Edges for Fast Feed Milling
DCX
DC
OAL
DHUB
DCONMS
17˚
APMX
Rd°
Designation
DCX(1) DC CICT(2) APMX AE(3) OAL DCONMS DHUB RMPX°(4) MDN(5) MDX(6) Arbor Rg(7) MIID(8)
kg
FFX4 FD032-5-16-04
32.00 24.60 5 0.80 3.7 40.00 16.00 38.00 1.2 56.60 63.00 A 1.80 FFX4 XNMU 040310T 0.12
FFX4 FD040-6-16-04
40.00 32.60 6 0.80 3.7 40.00 16.00 38.00 0.9 72.60 79.00 A 1.80 FFX4 XNMU 040310T 0.23
FFX4 FD042-6-16-04
42.00 34.60 6 0.80 3.7 40.00 16.00 38.00 0.8 76.60 83.00 A 1.80 FFX4 XNMU 040310T 0.50
FFX4 FD050-7-22-04
50.00 42.60 7 0.80 3.7 40.00 22.00 48.00 0.7 92.60 99.00 A 1.80 FFX4 XNMU 040310T 0.39
FFX4 FD052-7-22-04
52.00 44.60 7 0.80 3.7 40.00 22.00 48.00 0.7 96.60 103.00 A 1.80 FFX4 XNMU 040310T 0.44
• To generate a straight surface without cusps, the width of cut must not exceed DC
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum plunging width
(4) Maximum ramping angle
(5) Machinable diameter minimum for interpolation
(6) Machinable diameter maximum for interpolation
(7) Radius for programming
(8) Master insert identification
For inserts, see pages: FFX4 XNMU-04 (523)
Spare Parts
Designation
FFX4 FD032-5-16-04
SR M2.5X6-T7-60 T-7/51 SR M8X25-D11.5
FFX4 FD040-6-16-04
SR M2.5X6-T7-60 T-7/51 SR M8X25DIN912
FFX4 FD042-6-16-04
SR M2.5X6-T7-60 T-7/51 SR M8X25DIN912
FFX4 FD050-7-22-04
SR M2.5X6-T7-60 T-7/51 SR M10X25 DIN912
FFX4 FD052-7-22-04
SR M2.5X6-T7-60 T-7/51 SR M10X25 DIN912
FFX4 FD-04
Face Mills Carrying
"Bone Shaped” Inserts
with 4 Cutting Edges for
Fast Feed Milling
ISCAR
296
FAST FEED MILLIG TOOLS
DCONMS
DHUB
DC
DCX
OAL
APMX
18˚
Rd°
Designation
DCX(1) DC CICT(2) APMX AE OAL DCONMS DHUB Rd° MDN(3) MDX(4) Arbor Rg(5) MIID(6)
kg
FFX4 FD050-4-22-08
50.00 34.40 4 2.00 7.8 50.00 22.00 48.00 3.3 84.40 99.00 A 4.00 FFX4 XNMU 080620 0.58
FFX4 FD063-5-22-08
63.00 47.40 5 2.00 7.8 45.00 22.00 48.00 2.3 110.40 125.00 A 4.00 FFX4 XNMU 080620T 0.48
FFX4 FD080-7-27-08
80.00 64.40 7 2.00 7.8 50.00 27.00 60.00 1.6 144.40 159.00 B 4.00 FFX4 XNMU 080620T 0.95
FFX4 FD100-8-32-08
100.00 84.40 8 2.00 7.8 50.00 32.00 78.00 1.2 184.40 199.00 B 4.00 FFX4 XNMU 080620T 1.24
FFX4 FD125-10-40-08
125.00 109.40 10 2.00 7.8 63.00 40.00 92.00 0.9 234.40 249.00 B 4.00 FFX4 XNMU 080620T 2.40
• To generate a straight surface without cusps, the width of cut must not exceed DC
(1) Cutting diameter maximum
(2) Number of inserts
(3) For interpolation
(4) For interpolation
(5) Radius for programming
(6) Master insert identification
For inserts, see pages: FFX4 XNMU-08 (524)
Spare Parts
Designation
FFX4 FD050-4-22-08
SR M5-14 IP20 SW6-T BLD IP20/S7 SR PS 118-0273
FFX4 FD063-5-22-08
SR M5-14 IP20 SW6-T BLD IP20/S7 SR M10X25 DIN912
FFX4 FD080-7-27-08
SR M5-14 IP20 SW6-T BLD IP20/S7 SR M12X30DIN912
FFX4 FD100-8-32-08
SR M5-14 IP20 SW6-T BLD IP20/S7
FFX4 FD125-10-40-08
SR M5-14 IP20 SW6-T BLD IP20/S7
FFX4 FD-08
Face Mills Carrying
"Bone Shaped” Inserts
with 4 Cutting Edges for
Fast Feed Milling
297
FAST FEED MILLIG TOOLS
DCONMS
DC
DCX
17˚
LU
APMX
OAL
LH
BD
Fig. 1
Fig. 2
Rd°
Designation
DCX(1) DC APMX CICT(2) BD LU LH OAL DCONMS Shank(3) RMPX°(4) MDN(5) MDX(6) Fig. MIID(7) TQ(8)
kg
FF EWX D16-2-030-C16-04
16.00 8.60 0.80 2 14.90 30.0 - 113.00 16.00 C 5.0 24.60 31.00 2 H600 WXCU 040310T 0.9 0.15
FF EWX D16-2-030-W16-04
16.00 8.60 0.80 2 14.90 30.0 - 81.00 16.00 W 5.0 24.60 31.00 2 H600 WXCU 040310T 0.9 0.10
FF EWX D16-2-050-W20-04
16.00 8.60 0.80 2 14.90 50.0 - 109.00 20.00 W 5.0 24.60 31.00 2 H600 WXCU 040310T 0.9 0.19
FF EWX D16-2-070-C20-04
16.00 8.60 0.80 2 14.90 70.0 - 159.00 20.00 C 5.0 24.60 31.00 2 H600 WXCU 040310T 0.9 0.28
FF EWX D16-2-080-W20-04
16.00 8.60 0.80 2 14.90 80.0 - 139.00 20.00 W 5.0 24.60 31.00 2 H600 WXCU 040310T 0.9 0.22
FF EWX D20-3-040-W20-04
20.00 12.60 0.80 3 18.90 40.0 - 93.00 20.00 W 4.8 32.60 39.00 2 H600 WXCU 040310T 0.9 0.19
FF EWX D20-3-050-C20-04
20.00 12.60 0.80 3 18.90 50.0 - 133.00 20.00 C 4.8 32.60 39.00 2 H600 WXCU 040310T 0.9 0.28
FF EWX D20-3-060-W20-04
20.00 12.60 0.80 3 18.90 60.0 - 113.00 20.00 W 4.8 32.60 39.00 2 H600 WXCU 040310T 0.9 0.23
FF EWX D20-3-100-C20-04
20.00 12.60 0.80 3 18.90 100.0 - 183.00 20.00 C 4.8 32.60 39.00 2 H600 WXCU 040310T 0.9 0.38
FF EWX D20-3-100-W20-04
20.00 12.60 0.80 3 18.90 100.0 - 153.00 20.00 W 4.8 32.60 39.00 2 H600 WXCU 040310T 0.9 0.31
FF EWX D25-3-050-W25-05
25.00 15.00 1.00 3 23.60 50.0 53.0 110.00 25.00 W 5.0 40.00 49.00 2 H600 WXCU 05T312T 2.0 0.34
FF EWX D25-3-060-C25-05
25.00 15.00 1.00 3 23.60 60.0 63.0 145.00 25.00 C 5.0 40.00 49.00 2 H600 WXCU 05T312T 2.0 0.47
FF EWX D25-3-080-W25-05
25.00 15.00 1.00 3 23.60 80.0 83.0 140.00 25.00 W 5.0 40.00 49.00 2 H600 WXCU 05T312T 2.0 0.44
FF EWX D25-3-120-C25-05
25.00 15.00 1.00 3 23.60 120.0 123.0 205.00 25.00 C 5.0 40.00 49.00 2 H600 WXCU 05T312T 2.0 0.66
FF EWX D25-3-120-W25-05
25.00 15.00 1.00 3 23.60 120.0 123.0 180.00 25.00 W 5.0 40.00 49.00 2 H600 WXCU 05T312T 2.0 0.56
FF EWX D32-4-040-C25-05
32.00 22.00 1.00 4 27.00 - 40.0 180.00 25.00 C 4.0 54.00 63.00 1 H600 WXCU 05T312T 2.0 0.63
FF EWX D32-4-060-W25-05
32.00 22.00 1.00 4 27.00 60.0 63.0 120.00 25.00 W 4.0 54.00 63.00 1 H600 WXCU 05T312T 2.0 0.43
FF EWX D32-4-060-W32-05
32.00 22.00 1.00 4 27.00 - 63.0 125.00 32.00 W 4.0 54.00 63.00 2 H600 WXCU 05T312T 2.0 0.64
FF EWX D32-4-070-C32-05
32.00 22.00 1.00 4 30.60 70.0 73.0 155.00 32.00 C 4.0 54.00 63.00 2 H600 WXCU 05T312T 2.0 0.81
FF EWX D32-4-100-W25-05
32.00 22.00 1.00 4 27.00 - 100.0 160.00 25.00 W 4.0 54.00 63.00 1 H600 WXCU 05T312T 2.0 0.60
FF EWX D32-4-100-W32-05
32.00 22.00 1.00 4 30.60 100.0 103.0 165.00 32.00 W 4.0 54.00 63.00 2 H600 WXCU 05T312T 2.0 0.84
FF EWX D32-4-120-C32-05
32.00 22.00 1.00 4 30.60 120.0 123.0 205.00 32.00 C 4.0 54.00 63.00 2 H600 WXCU 05T312T 2.0 1.06
FF EWX D32-4-150-W32-05
32.00 22.00 1.00 4 30.60 150.0 153.0 215.00 32.00 W 4.0 54.00 63.00 2 H600 WXCU 05T312T 2.0 1.08
FF EWX D40-5-L50-C32-05
40.00 30.00 1.00 5 34.00 - 50.0 250.00 32.00 C 2.8 70.00 79.00 1 H600 WXCU 05T312T 2.0 1.40
FF EWX D40-5-S50-C32-05
40.00 30.00 1.00 5 34.00 - 50.0 150.00 32.00 C 2.8 70.00 79.00 1 H600 WXCU 05T312T 2.0 0.85
FF EWX D40-5-060-W32-05
40.00 30.00 1.00 5 34.00 - 60.0 125.00 32.00 W 2.8 70.00 79.00 1 H600 WXCU 05T312T 2.0 0.72
FF EWX D40-5-200-W40-05
40.00 30.00 1.00 5 38.60 200.0 203.0 275.00 40.00 W 2.8 70.00 79.00 2 H600 WXCU 05T312T 2.0 2.08
FF EWX D32-3-060-W32-07
32.00 19.00 1.50 3 30.70 60.0 63.0 125.00 32.00 W 6.3 51.00 63.00 2 H600 WXCU 070515T 4.8 0.60
FF EWX D32-3-070-C32-07
32.00 19.00 1.50 3 30.70 70.0 73.0 155.00 32.00 C 6.3 51.00 63.00 2 H600 WXCU 070515T 4.8 0.76
FF EWX D32-3-100-W32-07
32.00 19.00 1.50 3 30.70 100.0 103.0 165.00 32.00 W 6.3 51.00 63.00 2 H600 WXCU 070515T 4.8 0.78
FF EWX D32-3-120-C32-07
32.00 19.00 1.50 3 30.70 120.0 123.0 205.00 32.00 C 6.3 51.00 63.00 2 H600 WXCU 070515T 4.8 0.99
FF EWX D40-4-S50-C32-07
40.00 27.00 1.50 4 - 50.0 52.2 150.00 32.00 C 4.2 77.00 79.00 1 H600 WXCU 070515T 4.8 0.84
• For machining recommendations and radius for programming, see table on page 522 • To generate a straight surface without cusps, the width of cut must not exceed DC
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) C-Cylindrical, W-Weldon
(4) Maximum ramping angle
(5) For interpolation
(6) For interpolation
(8) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: H600 WXCU (522)
Spare Parts
Designation
FF EWX D...-04
SR M2.5X6-T7-60 T-7/51
FF EWX D...-05
SR 10508600 T-9/51
FF EWX D...-07
SR 34-535-SN BLD T15/S7 SW6-T-SH
FF EWX
Fast Feed Endmills Carrying
Double-Sided Inserts
with 6 Cutting Edges
ISCAR
298
FAST FEED MILLIG TOOLS
OAL
DRVS
LF
DC
DCX
17˚
APMX
THSZMS
Rd°
Designation
DCX(1) DC APMX CICT(2) LF OAL THSZMS RMPX°(3) MDN(4) MDX(5) DRVS(6) MIID(7) TQ(8) TQ_3(9)
kg
FF EWX D20-3-M10-04
20.00 12.60 0.80 3 25.00 45.00 M10 4.8 32.60 39.00 15.0 H600 WXCU 040310HP 0.9 29 0.05
FF EWX D25-4-M12-04
25.00 17.60 0.80 4 30.00 52.00 M12 3.3 42.60 49.00 19.0 H600 WXCU 040310HP 0.9 33 0.09
FF EWX D25-3-M12-05
25.00 15.00 1.00 3 30.00 52.00 M12 5.0 40.00 49.00 19.0 H600 WXCU 05T312T 2.0 33 0.09
FF EWX D32-4-M16-05
32.00 22.00 1.00 4 35.00 60.00 M16 4.0 54.00 63.00 25.0 H600 WXCU 05T312T 2.0 40 0.17
FF EWX D35-4-M16-05
35.00 25.00 1.00 4 35.00 60.00 M16 3.5 60.00 69.00 25.0 H600 WXCU 05T312T 2.0 40 0.19
FF EWX D40-5-M16-05
40.00 30.00 1.00 5 40.00 65.00 M16 2.8 70.00 79.00 25.0 H600 WXCU 05T312T 2.0 40 0.26
FF EWX D32-3-M16-07
32.00 19.00 1.50 3 35.00 60.00 M16 6.3 51.00 63.00 25.0 H600 WXCU 070515HP 4.8 40 0.16
FF EWX D40-4-M16-07
40.00 27.00 1.50 4 40.00 65.00 M16 4.2 67.00 79.00 25.0 H600 WXCU 070515HP 4.8 40 0.24
• For machining recommendations and radius for programming, see table on page 522 • To generate a straight surface without cusps, the width of cut must not exceed DC
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) Machinable diameter minimum for interpolation
(5) Machinable diameter maximum for interpolation
(6) Clamping wrench size
(7) Master insert identification
(8) Recommended tightening torque (N*m) for insert screw
(9) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: H600 WXCU (522)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
Spare Parts
Designation
FF EWX D20-3-M10-04
SR M2.5X6-T7-60 T-7/51
FF EWX D25-4-M12-04
SR M2.5X6-T7-60 T-7/51
FF EWX D25-3-M12-05
SR 10508600 T-9/51
FF EWX D32-4-M16-05
SR 10508600 T-9/51
FF EWX D35-4-M16-05
SR 10508600 T-9/51
FF EWX D40-5-M16-05
SR 10508600 T-9/51
FF EWX D32-3-M16-07
SR 34-535-SN BLD T15/S7 SW6-T-SH
FF EWX D40-4-M16-07
SR 34-535-SN BLD T15/S7 SW6-T-SH
FF EWX-M
Fast Feed Endmills with
FLEXFIT Threaded Connection
Carrying Double-Sided Inserts
with 6 Cutting Edges
299
FAST FEED MILLIG TOOLS
OAL
LF
DCONMS
DC
DCX
DRVS
APMX
THSZMS
17˚
Rd°
Designation
DCX(1) DC APMX CICT(2) THSZMS LF OAL DCONMS DRVS(3) TQ(4) RMPX°(5) MDN(6) MDX(7) MIID(8)
kg
FF EWX D16-2-MMT10-04
16.00 8.60 0.80 2 T10 19.50 31.25 15.20 12.0 0.9 5.0 24.60 31.00 H600 WXCU 040310HP 0.02
FF EWX D20-3-MMT12-04
20.00 12.60 0.80 3 T12 25.00 38.80 18.80 15.0 0.9 4.8 32.60 39.00 H600 WXCU 040310HP 0.05
FF EWX D25-4-MMT15-04
25.00 17.60 0.80 4 T15 30.00 47.00 23.90 19.0 0.9 3.3 42.60 49.00 H600 WXCU 040310HP 0.10
FF EWX D25-3-MMT15-05
25.00 15.00 1.00 3 T15 30.00 47.00 23.90 19.0 2.0 5.0 40.00 49.00 H600 WXCU 05T312T 0.09
• For machining recommendations and radius for programming, see table on page 522 • Do not apply lubricant to the MULTI-MASTER threaded connection.
• To generate a straight surface without cusps, the width of cut must not exceed DC • For adaptation options, see page 261
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) Width across flats (wrench should be ordered separately)
(4) Recommended tightening torque (N*m) for insert screw
(5) Maximum ramping angle
(6) For interpolation
(7) For interpolation
(8) Master insert identification
For inserts, see pages: H600 WXCU (522)
For holders, see pages: MM S-A (stepped shanks) (84) • MM S-A (straight shanks) (87) • MM S-A-C# (86) • MM S-A-HSK (609) • MM S-A-N (85) • MM S-A-SK (90)
• MM S-B (85° conical shanks) (87) • MM S-D (89° conical shanks) (88) • MM S-ER (89) • MM S-ER-H (89) • MM TS-A (86)
Spare Parts
Designation
FF EWX D16-2-MMT10-04
SR M2.5X6-T7-60 T-7/51
FF EWX D20-3-MMT12-04
SR M2.5X6-T7-60 T-7/51
FF EWX D25-4-MMT15-04
SR M2.5X6-T7-60 T-7/51
FF EWX D25-3-MMT15-05
SR 10508600 T-9/51
FF EWX-MM
Fast Feed Endmills with
MULTI-MASTER Threaded
Connection Carrying Double-Sided
Inserts with 6 Cutting Edges
DCONMS
DC
DCX
30°
LU
APMX
OAL
LH
BD
Fig. 1
Fig. 2
Rd°
Designation
DCX(1) DC APMX CICT(2) LU LH OAL DCONMS Shank(3) BD RMPX°(4) MDN(5) MDX(6) Fig. MIID(7) TQ(8)
kg
MF EWX D16-2-040-W20-04
16.00 9.00 1.50 2 40.0 47.0 99.00 20.00 W 14.90 3.8 25.00 31.00 2 H600 WXCU 040310T 0.9 0.16
MF EWX D20-3-050-C20-04
20.00 13.00 1.50 3 50.0 52.7 134.00 20.00 C 18.90 2.4 33.00 39.00 2 H600 WXCU 040310T 0.9 0.24
MF EWX D20-3-050-W20-04
20.00 13.00 1.50 3 50.0 52.7 104.00 20.00 W 18.90 2.4 33.00 39.00 2 H600 WXCU 040310T 0.9 0.18
MF EWX D25-3-060-W25-05
25.00 15.50 2.00 3 60.0 63.0 120.00 25.00 W 23.60 3.0 40.50 49.00 2 H600 WXCU 05T312T 2.0 0.33
MF EWX D32-4-080-W32-05
32.00 22.50 2.00 4 80.0 83.0 145.00 32.00 W 30.60 1.9 54.50 63.00 2 H600 WXCU 05T312T 2.0 0.70
MF EWX D32-3-080-C32-07
32.00 19.70 2.70 3 80.0 83.0 165.00 32.00 C 30.70 3.0 51.70 63.00 2 H600 WXCU 070515T 4.8 0.80
MF EWX D32-3-080-W32-07
32.00 19.70 2.70 3 80.0 83.0 145.00 32.00 W 30.70 3.0 51.70 63.00 2 H600 WXCU 070515T 4.8 0.70
MF EWX D40-4-090-C32-07
40.00 27.70 2.70 4 90.0 92.0 190.00 32.00 C 36.80 2.0 67.70 79.00 1 H600 WXCU 070515T 4.8 1.16
• For machining recommendations and radius for programming, see table on page 522 • To generate a straight surface without cusps, the width of cut must not exceed DC
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) C-Cylindrical, W-Weldon
(4) Maximum ramping angle
(5) For interpolation
(6) For interpolation
(7) Master insert identification
(8) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: H600 WXCU (522)
Spare Parts
Designation
MF EWX D16-2-040-W20-04
SR M2.5X6-T7-60 T-7/51
MF EWX D20-3-050-C20-04
SR M2.5X6-T7-60 T-7/51
MF EWX D20-3-050-W20-04
SR M2.5X6-T7-60 T-7/51
MF EWX D25-3-060-W25-05
SR 10508600 T-9/51
MF EWX D32-4-080-W32-05
SR 10508600 T-9/51
MF EWX D32-3-080-C32-07
SR 34-535-SN BLD T15/S7 SW6-T-SH
MF EWX D32-3-080-W32-07
SR 34-535-SN BLD T15/S7 SW6-T-SH
MF EWX D40-4-090-C32-07
SR 34-535-SN BLD T15/S7 SW6-T-SH
MF EWX
Moderate Feed Endmills
Carrying Double-Sided Inserts
with 6 Cutting Edges
ISCAR
300
FAST FEED MILLIG TOOLS
OAL
DRVS
LF
DC
DCX
30°
APMX
THSZMS
Rd°
Designation
DCX(1) DC APMX CICT(2) LF OAL THSZMS DRVS(3) RMPX°(4) MDN(5) MDX(6) MIID(7) TQ(8) TQ_3(9)
kg
MF EWX D20-3-M10-04
20.00 13.00 1.50 3 28.00 48.00 M10 14.0 2.4 33.00 39.00 H600 WXCU 040310T 0.9 29 0.05
MF EWX D25-4-M12-04
25.00 18.00 1.50 4 32.00 54.00 M12 17.0 1.7 43.00 49.00 H600 WXCU 040310T 0.9 33 0.09
MF EWX D25-3-M12-05
25.00 15.50 2.00 3 30.00 52.00 M12 17.0 3.0 40.50 49.00 H600 WXCU 05T312T 2.0 33 0.07
MF EWX D32-4-M16-05
32.00 22.50 2.00 4 35.00 60.00 M16 24.0 1.9 54.50 63.00 H600 WXCU 05T312T 2.0 40 0.16
MF EWX D32-3-M16-07
32.00 19.70 2.70 3 35.00 60.00 M16 24.0 3.0 51.70 63.00 H600 WXCU 070515HP 4.8 40 0.15
• For machining recommendations and radius for programming, see table on page 522 • To generate a straight surface without cusps, the width of cut must not exceed DC
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) Clamping wrench size
(4) Maximum ramping angle
(5) For interpolation
(6) For interpolation
(7) Master insert identification
(8) Recommended tightening torque (N*m) for insert screw
(9) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: H600 WXCU (522)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
Spare Parts
Designation
MF EWX D20-3-M10-04
SR M2.5X6-T7-60 T-7/51
MF EWX D25-4-M12-04
SR M2.5X6-T7-60 T-7/51
MF EWX D25-3-M12-05
SR 10508600 T-9/51
MF EWX D32-4-M16-05
SR 10508600 T-9/51
MF EWX D32-3-M16-07
SR 34-535-SN BLD T15/S7 SW6-T-SH
MF EWX-M
Moderate Feed Endmills with
FLEXFIT Threaded Connection
Carrying Double-Sided Inserts
with 6 Cutting Edges
OAL
DCONMS
LU
DCX DC
LH
APMX
Rd°
Designation
DC DCX(1) APMX AE(2) CICT(3) LU LH DCONMS OAL RMPX°(4) MDN(5) MDX(6) MIID(7) TQ(8)
kg
FFQ4 D022-2-044-W20-09
7.70 22.00 1.20 7.1 2 - 44.0 20.00 94.00 8.2 29.70 43.00 FFQ4 SOMT 090412T 2.0 0.19
FFQ4 D025-3-050-W25-09
10.70 25.00 1.20 7.1 3 - 50.0 25.00 110.00 5.5 35.70 49.00 FFQ4 SOMT 090412T 2.0 0.25
FFQ4 D032-4-064-W25-09
17.70 32.00 1.20 7.1 4 - 64.0 25.00 120.00 3.2 49.70 63.00 FFQ4 SOMT 090412T 2.0 0.50
FFQ4 D035-5-070-W32-09
20.70 35.00 1.20 7.1 5 68.50 70.0 32.00 130.00 2.7 55.70 69.00 FFQ4 SOMT 090412T 2.0 0.70
• To generate a straight surface without cusps, the width of cut must not exceed DC • Radius for programming: for insert SOMT 2.5 mm, for insert SOMW 3 mm
• When mounting insert SOMW, APMX=1.0 mm • For slot milling or machining with high tool overhang, the maximum depth of cut should be reduced by 50%
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Maximum plunging width
(3) Number of inserts
(4) Maximum ramping angle
(5) Machinable diameter minimum for interpolation
(6) Machinable diameter maximum for interpolation
(7) Master insert identification
(8) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: FFQ4 SOMT/W 0904 (517)
Spare Parts
Designation
FFQ4 D-W-09
SR M3X0.5-L7.4 IP9(a) IP-9/151
(a) Recommended tightening torque:2.0 N*m
FFQ4 D-W-09
Fast Feed Endmills Carrying
Single-Sided Inserts with
4 Cutting Edges
301
FAST FEED MILLIG TOOLS
LF
DC
DCX
APMX DRVS
THSZMS DCONMS
OAL
Rd°
Designation
DC DCX(1) APMX AE(2) CICT(3) LF OAL DCONMS THSZMS RMPX°(4) MDN(5) MDX(6) DRVS(7) MIID(8) TQ(9) TQ_3(10)
kg
FFQ4 D022-02-M10-09
7.70 22.00 1.20 7.1 2 25.00 45.00 18.00 M10 8.2 29.70 43.00 15.0 FFQ4 SOMT 090412T 2.0 29 0.04
FFQ4 D025-02-M12-09
10.70 25.00 1.20 7.1 2 30.00 52.00 21.00 M12 5.5 35.70 49.00 17.0 FFQ4 SOMT 090412T 2.0 33 0.05
FFQ4 D025-03-M12-09
10.70 25.00 1.20 7.1 3 30.00 52.00 21.00 M12 5.5 35.70 49.00 17.0 FFQ4 SOMT 090412T 2.0 33 0.07
FFQ4 D032-03-M16-09
17.70 32.00 1.20 7.1 3 35.00 60.00 29.00 M16 3.2 49.70 63.00 25.0 FFQ4 SOMT 090412T 2.0 40 0.14
FFQ4 D032-04-M16-09
17.70 32.00 1.20 7.1 4 35.00 60.00 29.00 M16 3.2 49.70 63.00 25.0 FFQ4 SOMT 090412T 2.0 40 0.14
FFQ4 D035-05-M16-09
20.70 35.00 1.20 7.1 5 35.00 60.00 29.00 M16 2.7 55.70 69.00 25.0 FFQ4 SOMT 090412T 2.0 40 0.16
FFQ4 D040-05-M16-09
25.70 40.00 1.20 7.1 5 35.00 60.00 29.00 M16 2.0 65.70 79.00 25.0 FFQ4 SOMT 090412T 2.0 40 0.18
• To generate a straight surface without cusps, the width of cut must not exceed DC • Radius for programming: for insert SOMT 2.5 mm, for insert SOMW 3 mm
• When mounting insert SOMW, APMX=1.0 mm • For slot milling or machining with high tool overhang, the maximum depth of cut should be reduced by 50%
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Maximum plunging width
(3) Number of inserts
(4) Maximum ramping angle
(5) Machinable diameter minimum for interpolation
(6) Machinable diameter maximum for interpolation
(7) Torque key size
(8) Master insert identification
(9) Recommended tightening torque (N*m) for insert screw
(10) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: FFQ4 SOMT/W 0904 (517)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
Spare Parts
Designation
FFQ4 D-M-09
SR M3X0.5-L7.4 IP9(a) IP-9/151
(a) Recommended tightening torque:2.0 N*m
FFQ4 D-M-09
Fast Feed Endmills with
FLEXFIT Threaded Adaptation
Carrying Single-Sided Inserts
with 4 Cutting Edges
DC
DCONMS
12°
OAL
APMX
DCX
DHUB
Rd°
Designation
DC DCX(1) APMX AE(2) CICT(3) OAL DCONMS DHUB RMPX°(4) MDN(5) MDX(6) Arbor MIID(7) TQ(8)
kg
FFQ4 D40-05-16-09
25.70 40.00 1.20 7.1 5 35.00 16.00 38.00 2.0 65.70 79.00 A FFQ4 SOMT 090412T 2.0 0.17
FFQ4 D50-07-22-09
35.70 50.00 1.20 7.1 7 40.00 22.00 48.00 1.5 85.70 99.00 A FFQ4 SOMT 090412T 2.0 0.36
FFQ4 D52-07-22-09
37.70 52.00 1.20 7.1 7 40.00 22.00 48.00 1.4 89.70 103.00 A FFQ4 SOMT 090412T 2.0 0.34
FFQ4 D63-08-22-09
48.70 63.00 1.20 7.1 8 45.00 22.00 48.00 1.1 111.70 125.00 A FFQ4 SOMT 090412T 2.0 0.49
• To generate a straight surface without cusps, the width of cut must not exceed DC • Radius for programming: for insert SOMT 2.5 mm, for insert SOMW 3 mm
• When mounting insert SOMW, APMX=1.0 mm • For slot milling or machining with high tool overhang, the maximum depth of cut should be reduced by 50%
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Maximum plunging width
(3) Number of inserts
(4) Maximum ramping angle
(5) Machinable diameter minimum for interpolation
(6) Machinable diameter maximum for interpolation
(7) Master insert identification
(8) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: FFQ4 SOMT/W 0904 (517)
Spare Parts
Designation
FFQ4 D40-05-16-09
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M8X25DIN912
FFQ4 D50-07-22-09
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M10X25 DIN912
FFQ4 D52-07-22-09
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M10X25 DIN912
FFQ4 D63-08-22-09
SR M3X0.5-L7.4 IP9(a) IP-9/151 SR M10X30 DIN912
(a) Recommended tightening torque:2.0 N*m
FFQ4 D-09
Fast Feed Face Mills
Carrying Single-Sided Inserts
with 4 Cutting Edges
ISCAR
302
FAST FEED MILLIG TOOLS
DC AE
APMX
DCONMS
9°
OAL
DCX
DHUB
Rd°
Designation
DC DCX(1) APMX AE(2) CICT(3) OAL DHUB DCONMS Arbor RMPX°(4) MDN(5) MDX(6) MIID(7) TQ(8)
kg
FFQ4 D040-3-16-12
18.00 40.00 1.50 10.0 3 45.00 38.00 16.00 A 4.3 58.00 79.00 FFQ4 SOMT 120516HP 4.8 0.23
FFQ4 D040-4-16-12
18.00 40.00 1.50 10.0 4 45.00 38.00 16.00 A 4.3 58.00 79.00 FFQ4 SOMT 120516HP 4.8 0.22
FFQ4 D050-4-22-12
28.00 50.00 1.50 10.0 4 50.00 48.00 22.00 A 2.7 78.00 99.00 FFQ4 SOMT 120516HP 4.8 0.38
FFQ4 D050-5-22-12
28.00 50.00 1.50 10.0 5 50.00 48.00 22.00 A 2.7 78.00 99.00 FFQ4 SOMT 120516HP 4.8 0.37
FFQ4 D052-5-22-12
29.00 52.00 1.50 10.0 5 50.00 48.00 22.00 A 2.5 81.00 103.00 FFQ4 SOMT 120516HP 4.8 0.39
FFQ4 D063-6-22-12
41.00 63.00 1.50 10.0 6 50.00 48.00 22.00 A 1.8 104.00 125.00 FFQ4 SOMT 120516HP 4.8 0.50
FFQ4 D066-6-27-12
43.00 66.00 1.50 10.0 6 50.00 60.00 27.00 A 1.6 109.00 131.00 FFQ4 SOMT 120516HP 4.8 0.65
FFQ4 D080-7-27-12
58.00 80.00 1.50 10.0 7 50.00 60.00 27.00 A 1.2 138.00 159.00 FFQ4 SOMT 120516HP 4.8 0.84
FFQ4 D100-8-32-12
78.00 100.00 1.50 10.0 8 50.00 78.00 32.00 B 0.9 178.00 199.00 FFQ4 SOMT 120516HP 4.8 1.30
FFQ4 D125-10-40-12
103.00 125.00 1.50 10.0 10 63.00 92.00 40.00 B 0.7 228.00 249.00 FFQ4 SOMT 120516HP 4.8 2.17
• To generate a straight surface without cusps, the width of cut must not exceed DC • Radius for programming: for insert SOMT 3 mm, for insert SOMW 4 mm
• When mounting insert SOMW, APMX=1.2 mm • For slot milling or machining with high tool overhang, the maximum depth of cut should be reduced by 50%
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Maximum plunging width
(3) Number of inserts
(4) Maximum ramping angle
(5) Machinable diameter minimum for interpolation
(6) Machinable diameter maximum for interpolation
(7) Master insert identification
(8) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: FFQ4 SOMT/W 1205 (518)
Spare Parts
Designation
FFQ4 D040-3-16-12
SR M4X0.7-L9.6 IP15 SW6-T BLD IP15/S7 SR PS 118-0416
FFQ4 D040-4-16-12
SR M4X0.7-L9.6 IP15 SW6-T BLD IP15/S7 SR PS 118-0416
FFQ4 D050-4-22-12
SR M4X0.7-L9.6 IP15 SW6-T BLD IP15/S7 SR M10X35 DIN912
FFQ4 D050-5-22-12
SR M4X0.7-L9.6 IP15 SW6-T BLD IP15/S7 SR M10X35 DIN912
FFQ4 D052-5-22-12
SR M4X0.7-L9.6 IP15 SW6-T BLD IP15/S7 SR M10X35 DIN912
FFQ4 D063-6-22-12
SR M4X0.7-L9.6 IP15 SW6-T BLD IP15/S7 SR M10X35 DIN912
FFQ4 D066-6-27-12
SR M4X0.7-L9.6 IP15 SW6-T BLD IP15/S7 SR M12X30DIN912
FFQ4 D080-7-27-12
SR M4X0.7-L9.6 IP15 SW6-T BLD IP15/S7 SR M12X30DIN912
FFQ4 D100-8-32-12
SR M4X0.7-L9.6 IP15 SW6-T BLD IP15/S7
FFQ4 D125-10-40-12
SR M4X0.7-L9.6 IP15 SW6-T BLD IP15/S7
FFQ4 D-12
Fast Feed Face Mills
Carrying Single-Sided Inserts
with 4 Cutting Edges
303
FAST FEED MILLIG TOOLS
DC
DCONMS
14°
OAL
APMX
DCX
DHUB
Rd°
Designation
DCX(1) DC APMX AE(2) CICT(3) OAL DCONMS Da DHUB RMPX°(4) MDN(5) MDX(6) CSP(7) Arbor MIID(8) TQ(9)
kg
FFQ4 D080-06-27-17
80.00 50.80 3.00 14.6 6 50.00 27.00 27.00 60.00 1.2 130.80 159.00 1 A FFQ4 SOMT 170625T 9.0 0.78
FFQ4 D100-07-32-17
100.00 70.80 3.00 14.6 7 50.00 32.00 32.00 78.00 0.8 170.80 199.00 1 A FFQ4 SOMT 170625T 9.0 1.18
FFQ4 D125-08-40-17
125.00 95.80 3.00 14.6 8 63.00 40.00 40.00 92.00 0.6 220.80 249.00 1 B FFQ4 SOMT 170625T 9.0 2.48
FFQ4 D160-10-40-17
160.00 130.80 3.00 14.6 10 63.00 40.00 40.00 95.00 0.2 290.80 319.00 0 C FFQ4 SOMT 170625T 9.0 2.90
• To generate a straight surface without cusps, the width of cut must not exceed DC • Radius for programming: for insert SOMT 5.5 mm, for insert SOMW 6.4 mm
• When mounting insert SOMW, APMX=2.5 mm • For slot milling or machining with high tool overhang, the maximum depth of cut should be reduced by 50%
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Maximum plunging width
(3) Number of inserts
(4) Maximum ramping angle
(5) Machinable diameter minimum for interpolation
(6) Machinable diameter maximum for interpolation
(7) 0 - Without coolant supply, 1 - With coolant supply
(8) Master insert identification
(9) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: FFQ4 SOMT/W 1706 (519)
Spare Parts
Designation
FFQ4 D080-06-27-17
SR M5-14 IP20 SW6-T BLD IP20/S7 SR M12X30DIN912
FFQ4 D100-07-32-17
SR M5-14 IP20 SW6-T BLD IP20/S7 SR M16X30 DIN912
FFQ4 D125-08-40-17
SR M5-14 IP20 SW6-T BLD IP20/S7
FFQ4 D160-10-40-17
SR M5-14 IP20 SW6-T BLD IP20/S7
FFQ4 D-17
Fast Feed Face Mills
Carrying Single-Sided Inserts
with 4 Cutting Edges
DCONMS
DHUB
APMX
12˚
DC
DCX
OAL
Rd°
Designation
DC DCX(1) APMX CICT(2) OAL DHUB DCONMS Arbor RMPX°(3) MDN(4) MDX(5) MIID(6)
kg
FFQ8 D050-05-22-12
30.60 50.00 1.50 5 40.00 48.00 22.00 A 0.3 80.60 99.00 FFQ8 SZMU 120520 0.46
FFQ8 D063-06-22-12
43.60 63.00 1.50 6 40.00 48.00 22.00 A 0.2 106.60 125.00 FFQ8 SZMU 120520 0.94
FFQ8 D080-07-27-12
60.60 80.00 1.50 7 50.00 60.00 27.00 A 0.2 140.60 159.00 FFQ8 SZMU 120520 1.98
FFQ8 D100-08-32-12
80.60 100.00 1.50 8 50.00 78.00 32.00 B 0.1 180.60 199.00 FFQ8 SZMU 120520 3.03
• Radius for programming 3.6 mm • For user guide, see pages 542-547 • To generate a straight surface without cusps, the width of cut must not exceed DC
• For slot milling or machining with high tool overhang, the maximum depth of cut should be reduced by 30%.
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) Machinable diameter minimum for interpolation
(5) Machinable diameter maximum for interpolation
(6) Master insert identification
For inserts, see pages: FFQ8 SZMU (520)
Spare Parts
Designation
FFQ8 D050-05-22-12
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
FFQ8 D063-06-22-12
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
FFQ8 D080-07-27-12
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T-SH SR M12X30DIN912
FFQ8 D100-08-32-12
SR M4X0.7-L11.5 IP15 BLD IP15/M7 SW6-T-SH
FFQ8-12
Fast Feed Face Mills Carrying
Double-Sided Inserts
with 8 Cutting Edges
ISCAR
304
FAST FEED MILLIG TOOLS
DC
DCX
LU
DF
DCONMS
LH OAL
APMX
Rd°
Designation
DCX(1) DC APMX CICT(2) LH LU OAL DF DCONMS Shank(3) RMPX°(4) TQ(5) MIID(6)
kg
FF EW D25-050-W25-06-C
25.00 11.00 1.30 2 53.0 - 118.00 - 25.00 W 5.0 2.0 FF WOMT0602 0.37
FF EW D25-080-C25-06-C
25.00 11.00 1.30 2 83.0 - 180.00 - 25.00 C 5.0 2.0 FF WOMT0602 0.58
FF EW D25-080-W25-06-C
25.00 11.00 1.30 2 83.0 - 148.00 - 25.00 W 5.0 2.0 FF WOMT0602 0.46
FF EW D25-120-C24-06-C
25.00 11.00 1.30 2 121.4 - 220.00 - 24.00 C 5.0 2.0 FF WOMT0602 0.68
FF EW D32-060-W25-06-C
32.00 18.00 1.30 3 63.0 - 128.00 30.40 25.00 W 4.0 2.0 FF WOMT0602 0.52
FF EW D32-100-C32-06-C
32.00 18.00 1.30 3 103.0 - 230.00 - 32.00 C 4.0 2.0 FF WOMT0602 1.28
FF EW D32-100-W25-06-C
32.00 18.00 1.30 3 103.0 - 168.00 30.40 25.00 W 4.0 2.0 FF WOMT0602 0.73
FF EW D40-150-W32-09-C
40.00 19.20 2.00 3 150.0 147.0 217.50 50.00 32.00 W 5.0 5.0 FF WOMT09T3 1.56
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) C-Cylindrical, W-Weldon
(4) Maximum ramping angle
(5) Insert tightening torque
(6) Master insert identification
For inserts, see pages: FF WOCT/WOMT/WOMW (521)
Cutting forces are directed axially
towards the spindle, enabling
cutting at very high feeds with
high stability and no vibrations.
A cylinder at the bottom of
the insert provides very rigid
clamping, absorbing most
of the forces usually exerted
on the clamping screw.
APMX=2 mm Max
for FF WO_T 09T320T
APMX=1.5 mm Max
for FF WOMT 060212T
Spare Parts
Designation
FF EW D25-050-W25-06-C
SR 34-506/M T-9/51
FF EW D25-080-C25-06-C
SR 34-506/M T-9/51
FF EW D25-080-W25-06-C
SR 34-506/M T-9/51
FF EW D25-120-C24-06-C
SR 34-506/M T-9/51
FF EW D32-060-W25-06-C
SR 34-506/M T-9/51
FF EW D32-100-C32-06-C
SR 34-506/M T-9/51
FF EW D32-100-W25-06-C
SR 34-506/M T-9/51
FF EW D40-150-W32-09-C
SR 34-535 BLD T15/S7 SW6-T
FF EW
Fast Feed Endmills with
FF WOMT... Inserts
DHUB
APMX
22˚
DCONMS
OAL
DC
DCX
Designation
DC DCX(1) APMX CICT(2) OAL DHUB DCONMS Arbor MIID(3)
kg
MFQ8 D050-05-22-12
31.60 50.00 3.00 5 40.00 48.00 22.00 A FFQ8 SZMU 120520 0.44
MFQ8 D063-06-22-12
44.60 63.00 3.00 6 40.00 48.00 22.00 A FFQ8 SZMU 120520 0.84
MFQ8 D080-07-27-12
61.60 80.00 3.00 7 50.00 60.00 27.00 A FFQ8 SZMU 120520 1.84
MFQ8 D100-08-32-12
81.60 100.00 3.00 8 50.00 78.00 32.00 B FFQ8 SZMU 120520 2.95
• Radius for programming 5.0 mm • For user guide, see pages 542-547 • To generate a straight surface without cusps, the width of cut must not exceed DC
• For slot milling or machining with high tool overhang, the maximum depth of cut should be reduced by 30%.
(1) Cutting diameter maximum
(2) Number of inserts
(3) Master insert identification
For inserts, see pages: FFQ8 SZMU (520)
Spare Parts
Designation
MFQ8 D050-05-22-12
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T-SH SR M10X40-1638
MFQ8 D063-06-22-12
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
MFQ8 D080-07-27-12
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T-SH SR M12X30DIN912
MFQ8 D100-08-32-12
SR M4X0.7-L11.5 IP15 BLD IP15/M7 SW6-T-SH
MFQ8-12
Moderate Feed Face Mills
Carrying Double-Sided Inserts
with 8 Cutting Edges
305
FAST FEED MILLIG TOOLS
Shank
OAL
LF
LH
LU
DCONMS
DC
DCX
APMX
Rd°
Designation
DCX(1) DC CICT(2) APMX LU LH LF OAL DCONMS RMPX°(3) Shank TQ(4) MIID(5)
kg
FF EW D32-060-CF4-06-C
32.00 18.00 3 1.30 60.0 64.00 72.00 114.00 44.00 4.0 CF4 2.0 FF WOMT0602 0.54
FF EW D32-100-CF4-06-C
32.00 18.00 3 1.30 100.0 104.00 112.00 154.00 44.00 4.0 CF4 2.0 FF WOMT0602 0.74
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) Insert tightening torque
(5) Master insert identification
For inserts, see pages: FF WOCT/WOMT/WOMW (521)
Spare Parts
Designation
FF EW-CF
SR 34-506/M T-9/51
FF EW-CF
Fast Feed Endmills with
CLICKFIT Shanks
DCDCX
OAL
LF
APMX
THSZMS
Rd°
Designation
DCX(1) DC CICT(2) APMX THSZMS LF OAL RMPX°(3) TQ(4) MIID(5) TQ_3(6)
kg
FF EW D25-M12-06-C
25.00 11.00 2 1.30 M12 25.00 47.00 5.0 2.0 FF WOMT0602 33 0.06
FF EW D32-M16-06-C
32.00 18.00 3 1.30 M16 35.00 60.00 4.0 2.0 FF WOMT0602 40 0.16
FF EW D40-M16-06-C
40.00 26.00 4 1.30 M16 40.00 65.00 2.5 2.0 FF WOMT0602 40 0.23
• For user guide, see pages 542-547 • When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly
cleaned. Apply appropriate tightening torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) Insert tightening torque
(5) Master insert identification
(6) Tool tightening torque Nxm (lbfxin)
For inserts, see pages: FF WOCT/WOMT/WOMW (521)
For holders, see pages: BT-ODP (FLEXFIT) (314) • C#-ODP (FLEXFIT) (314) • CAB M-M (FLEXFIT) (312) • DIN69871-ODP (315) • ER-ODP (315)
• HSK A-ODP (FLEXFIT) (316) • S M (312) • S M-C-H (312) • S M-CF (313)
Spare Parts
Designation
FF EW-M
SR 34-506/M T-9/51
FF EW-M
Fast Feed Endmills with
FLEXFIT Threaded Adaptation
ISCAR
306
FAST FEED MILLIG TOOLS
DCONMS
DHUB
DCX
DC
OAL
17°
APMX
Rd°
Designation
DC DCX(1) APMX CICT(2) OAL DHUB DCONMS Arbor(3) RMPX°(4) MDN(5) MDX(6) CSP(7) MIID(8) TQ(9)
kg
FF FWX D040-05-16-05
30.10 40.00 1.00 5 35.00 38.00 16.00 A 2.8 70.10 79.00 1 H600 WXCU 05T312T 2.0 0.20
FF FWX D050-06-22-05
40.10 50.00 1.00 6 40.00 48.00 22.00 A 2.0 90.10 99.00 1 H600 WXCU 05T312T 2.0 0.36
FF FWX D052-06-22-05
42.10 52.00 1.00 6 40.00 48.00 22.00 A 1.9 94.10 103.00 1 H600 WXCU 05T312T 2.0 0.37
FF FWX D040-04-16-07
27.00 40.00 1.50 4 35.00 38.00 16.00 A 4.2 67.00 79.00 1 H600 WXCU 070515HP 4.8 0.18
FF FWX D050-05-22-07
37.00 50.00 1.50 5 40.00 48.00 22.00 A 2.9 87.00 99.00 1 H600 WXCU 070515HP 4.8 0.33
FF FWX D052-05-22-07
39.00 52.00 1.50 5 40.00 48.00 22.00 A 2.8 91.00 103.00 1 H600 WXCU 070515HP 4.8 0.33
FF FWX D063-06-22-07
50.00 63.00 1.50 6 40.00 61.00 22.00 A 2.1 113.00 125.00 1 H600 WXCU 070515HP 4.8 0.58
FF FWX D080-07-32-07
67.00 80.00 1.50 7 55.00 76.00 32.00 A 1.6 147.00 159.00 1 H600 WXCU 070515HP 4.8 1.38
FF FWX D100-08-32-07
87.00 100.00 1.50 8 50.00 78.00 32.00 B 1.2 187.00 199.00 1 H600 WXCU 070515HP 4.8 1.47
FF FWX D050-04-22-08
34.00 50.00 2.00 4 45.00 48.00 22.00 A 4.8 84.00 99.00 1 H600 WXCU 080612T 9.0 0.34
FF FWX D052-04-22-08
36.00 52.00 2.00 4 45.00 48.00 22.00 A 4.5 88.00 103.00 1 H600 WXCU 080612T 9.0 0.37
FF FWX D063-05-22-08
47.00 63.00 2.00 5 45.00 61.00 22.00 A 3.3 110.00 125.00 1 H600 WXCU 080612T 9.0 0.61
FF FWX D063-05-27-08
47.00 63.00 2.00 5 50.00 61.00 27.00 A 3.3 110.00 125.00 1 H600 WXCU 080612T 9.0 0.65
FF FWX D066-05-22-08
50.00 66.00 2.00 5 45.00 61.00 22.00 A 3.1 116.00 131.00 1 H600 WXCU 080612T 9.0 0.68
FF FWX D066-05-27-08
50.00 66.00 2.00 5 50.00 61.00 27.00 A 3.1 116.00 131.00 1 H600 WXCU 080612T 9.0 0.72
FF FWX D080-06-32-08
64.00 80.00 2.00 6 55.00 76.00 32.00 A 2.3 144.00 159.00 1 H600 WXCU 080612T 9.0 1.24
FF FWX D100-07-32-08
84.00 100.00 2.00 7 50.00 78.00 32.00 B 1.7 184.00 199.00 1 H600 WXCU 080612T 9.0 1.42
FF FWX D125-09-40-08
109.00 125.00 2.00 9 55.00 90.00 40.00 B 1.3 234.00 249.00 1 H600 WXCU 080612T 9.0 2.37
FF FWX D160-11-40-08
144.00 160.00 2.00 11 55.00 95.00 40.00 C 1.0 304.00 319.00 0 H600 WXCU 080612T 9.0 0.00
• For machining recommendations and radius for programming, see table on page 522 • To generate a straight surface without cusps, the width of cut must not exceed DC
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) For adaptation options, see page 548
(4) Maximum ramping angle
(5) For interpolation
(6) For interpolation
(7) 0 - Without coolant supply, 1 - With coolant supply
(8) Master insert identification
(9) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: H600 WXCU (522)
Spare Parts
Designation
FF FWX D040-05-16-05
SR 10508600 T-9/51 SR M8X25DIN912
FF FWX D050-06-22-05
SR 10508600 T-9/51 SR M10X25 DIN912
FF FWX D052-06-22-05
SR 10508600 T-9/51 SR M10X25 DIN912
FF FWX D040-04-16-07
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M8X25-D11.5
FF FWX D050-05-22-07
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X25 DIN912
FF FWX D052-05-22-07
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X25 DIN912
FF FWX D063-06-22-07
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X25 DIN912
FF FWX D080-07-32-07
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M16X30 DIN912
FF FWX D100-08-32-07
SR 34-535-SN BLD T15/M7 SW6-T-SH
FF FWX D050-04-22-08
SR 14-591/H BLD T20/S7 SW6-T SR M10X25 DIN912
FF FWX D052-04-22-08
SR 14-591/H BLD T20/S7 SW6-T SR M10X25 DIN912
FF FWX D063-05-22-08
SR 14-591/H BLD T20/S7 SW6-T SR M10X25 DIN912
FF FWX D063-05-27-08
SR 14-591/H BLD T20/S7 SW6-T SR M12X30DIN912
FF FWX D066-05-22-08
SR 14-591/H BLD T20/S7 SW6-T SR M10X25 DIN912
FF FWX D066-05-27-08
SR 14-591/H BLD T20/S7 SW6-T SR M12X30DIN912
FF FWX D080-06-32-08
SR 14-591/H BLD T20/S7 SW6-T SR M16X30 DIN912
FF FWX D100-07-32-08
SR 14-591/H BLD T20/M7 SW6-T
FF FWX D125-09-40-08
SR 14-591/H BLD T20/L7 SW6-T
FF FWX D160-11-40-08
SR 14-591/H BLD T20/L7 SW6-T
FF FWX
Fast Feed Face Mills Carrying
Double-Sided Inserts
with 6 Cutting Edges
307
FAST FEED MILLIG TOOLS
DCONMS
DHUB
DC
DCX
OAL
APMX
30°
Rd°
Designation
DC DCX(1) APMX CICT(2) OAL DHUB DCONMS Arbor(3) RMPX°(4) MDN(5) MDX(6) CSP(7) MIID(8) TQ(9)
kg
MF FWX D040-05-16-05
30.60 40.00 2.00 5 35.00 38.00 16.00 A 1.4 70.60 79.00 1 H600 WXCU 05T312T 2.0 0.17
MF FWX D050-06-22-05
40.50 50.00 2.00 6 40.00 48.00 22.00 A 1.0 90.50 99.00 1 H600 WXCU 05T312T 2.0 0.30
MF FWX D052-06-22-05
42.50 52.00 2.00 6 40.00 48.00 22.00 A 1.0 94.50 103.00 1 H600 WXCU 05T312T 2.0 0.32
MF FWX D063-08-22-05
53.50 63.00 2.00 8 40.00 48.00 22.00 A 0.8 116.50 125.00 1 H600 WXCU 05T312T 2.0 0.41
MF FWX D040-04-16-07
27.70 40.00 2.70 4 35.00 38.00 16.00 A 2.0 67.70 79.00 1 H600 WXCU 070515HP 4.8 0.17
MF FWX D050-05-22-07
37.70 50.00 2.70 5 40.00 48.00 22.00 A 1.4 87.70 99.00 1 H600 WXCU 070515HP 4.8 0.31
MF FWX D052-05-22-07
39.70 52.00 2.70 5 40.00 48.00 22.00 A 1.3 91.70 103.00 1 H600 WXCU 070515HP 4.8 0.32
MF FWX D063-06-22-07
50.70 63.00 2.70 6 40.00 48.00 22.00 A 1.0 113.70 125.00 1 H600 WXCU 070515HP 4.8 0.42
MF FWX D080-07-32-07
67.70 80.00 2.70 7 55.00 76.00 32.00 A 0.8 147.70 159.00 1 H600 WXCU 070515HP 4.8 1.21
MF FWX D100-08-32-07
87.70 100.00 2.70 8 50.00 78.00 32.00 B 0.6 187.70 199.00 1 H600 WXCU 070515HP 4.8 1.46
MF FWX D050-04-22-08
34.70 50.00 3.50 4 45.00 48.00 22.00 A 2.5 84.70 99.00 1 H600 WXCU 080612T 9.0 0.32
MF FWX D063-05-27-08
47.70 63.00 3.50 5 50.00 61.00 27.00 A 1.7 110.70 125.00 1 H600 WXCU 080612T 9.0 0.63
MF FWX D066-05-27-08
50.70 66.00 3.50 5 50.00 61.00 27.00 A 1.7 116.70 131.00 1 H600 WXCU 080612T 9.0 0.64
MF FWX D080-06-32-08
64.70 80.00 3.50 6 55.00 76.00 32.00 A 1.2 144.70 159.00 1 H600 WXCU 080612T 9.0 1.13
MF FWX D100-07-32-08
84.70 100.00 3.50 7 50.00 78.00 32.00 B 0.9 184.70 199.00 1 H600 WXCU 080612T 9.0 1.37
MF FWX D125-09-40-08
109.70 125.00 3.50 9 55.00 90.00 40.00 B 0.7 234.70 249.00 1 H600 WXCU 080612T 9.0 2.36
MF FWX D160-11-40-08
144.70 160.00 3.50 11 55.00 95.00 40.00 C 0.5 304.70 319.00 0 H600 WXCU 080612T 9.0 3.63
• For machining recommendations and radius for programming, see table on page 522 • To generate a straight surface without cusps, the width of cut must not exceed DC
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) For adaptation options, see page 548
(4) Maximum ramping angle
(5) For interpolation
(6) For interpolation
(7) 0 - Without coolant supply, 1 - With coolant supply
(8) Master insert identification
(9) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: H600 WXCU (522)
Spare Parts
Designation
MF FWX D040-05-16-05
SR 10508600 T-9/51 SR M8X25DIN912
MF FWX D050-06-22-05
SR 10508600 T-9/51 SR M10X25 DIN912
MF FWX D052-06-22-05
SR 10508600 T-9/51 SR M10X25 DIN912
MF FWX D063-08-22-05
SR 10508600 T-9/51 SR M10X25 DIN912
MF FWX D040-04-16-07
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M8X25-D11.5
MF FWX D050-05-22-07
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X25 DIN912
MF FWX D052-05-22-07
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X25 DIN912
MF FWX D063-06-22-07
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M10X25 DIN912
MF FWX D080-07-32-07
SR 34-535-SN BLD T15/S7 SW6-T-SH SR M16X30 DIN912
MF FWX D100-08-32-07
SR 34-535-SN BLD T15/M7 SW6-T-SH
MF FWX D050-04-22-08
SR 14-591/H BLD T20/S7 SW6-T SR M10X25 DIN912
MF FWX D063-05-27-08
SR 14-591/H BLD T20/S7 SW6-T SR M12X30DIN912
MF FWX D066-05-27-08
SR 14-591/H BLD T20/S7 SW6-T SR M12X30DIN912
MF FWX D080-06-32-08
SR 14-591/H BLD T20/S7 SW6-T SR M16X30 DIN912
MF FWX D100-07-32-08
SR 14-591/H BLD T20/M7 SW6-T
MF FWX D125-09-40-08
SR 14-591/H BLD T20/L7 SW6-T
MF FWX D160-11-40-08
SR 14-591/H BLD T20/L7 SW6-T
MF FWX
Moderate Feed Face Mills
Carrying Double-Sided Inserts
with 6 Cutting Edges
ISCAR
308
FAST FEED MILLIG TOOLS
DHUB
DCX
BD
DC
DCONMS
OAL
APMX
34°
Designation
DCX(1) BD DC CICT(2) APMX OAL DHUB DCONMS Arbor(3) CSP(4) MIID(5) TQ(6)
kg
MF FHX D063-06-22-R06
63.00 65.40 53.40 6 3.00 40.00 48.00 22.00 A 1 H1200 HXCU 0606-HPR 9.0 0.46
MF FHX D080-07-27-R06
80.00 82.40 70.40 7 3.00 50.00 60.00 27.00 A 1 H1200 HXCU 0606-HPR 9.0 0.98
MF FHX D080-07-32-R06
80.00 82.40 70.40 7 3.00 50.00 66.00 32.00 A 1 H1200 HXCU 0606-HPR 9.0 0.86
MF FHX D100-09-32-R06
100.00 102.40 90.40 9 3.00 50.00 78.00 32.00 B 1 H1200 HXCU 0606-HPR 9.0 1.57
MF FHX D125-11-40-R06
125.00 127.40 115.40 11 3.00 50.00 92.00 40.00 B 1 H1200 HXCU 0606-HPR 9.0 2.44
MF FHX D160-13-40-R06
160.00 162.40 150.40 13 3.00 55.00 95.00 40.00 C 0 H1200 HXCU 0606-HPR 9.0 3.48
• Radius for programming according to D1 diameter is 5.4 mm • When machining next to shoulders, maximum width of cut should be 0.3xD
• To generate a straight surface without cusps, the width of cut must not exceed DC • For cutting speed recommendations, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) For adaptation options, see page 548
(4) 0 - Without coolant supply, 1 - With coolant supply
(5) Master insert identification
(6) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: H1200 HXCU 0606 (524)
Spare Parts
Designation
MF FHX D063-06-22-R06
SR 14-591/H BLD T20/S7 SW6-T SR M10X25 DIN912
MF FHX D080-07-27-R06
SR 14-591/H BLD T20/S7 SW6-T SR M12X30DIN912
MF FHX D080-07-32-R06
SR 14-591/H BLD T20/S7 SW6-T SR M16X30 DIN912
MF FHX D100-09-32-R06
SR 14-591/H BLD T20/M7 SW6-T
MF FHX D125-11-40-R06
SR 14-591/H BLD T20/M7 SW6-T
MF FHX D160-13-40-R06
SR 14-591/H BLD T20/M7 SW6-T
MF FHX-R06
34° Face Mills Carrying Hexagonal
Inserts with 12 Cutting Edges
DHUB
DCX
DC APMX
DCONMS
OAL
16˚
FFV D040-03-16-R-VN07
Rd°
Designation
DCX(2) DC APMX AE(3) CICT(4) OAL DCONMS DHUB RMPX°(5) MDN(6) MDX(7) Arbor MIID(8) TQ(9)
kg
FFV D040-03-16-R-VN07 (1)
40.00 25.00 1.50 7.5 3 60.00 16.00 25.00 3.0 65.00 79.00 Special FF VNMT 0706ZN-ER 4.8 0.36
FFV D050-05-22-R-VN07
50.00 35.00 1.50 7.5 5 50.00 22.00 48.00 3.2 85.00 99.00 A FF VNMT 0706ZN-ER 4.8 0.47
FFV D063-06-22-R-VN07
63.00 48.00 1.50 7.5 6 40.00 22.00 48.00 2.2 111.00 125.00 A FF VNMT 0706ZN-ER 4.8 0.00
FFV D080-07-27-R-VN07
80.00 65.00 1.50 7.5 7 50.00 27.00 60.00 1.5 145.00 159.00 B FF VNMT 0706ZN-ER 4.8 0.81
FFV D100-08-32-R-VN07
100.00 85.00 1.50 7.5 8 50.00 32.00 78.00 1.2 185.00 199.00 B FF VNMT 0706ZN-ER 4.8 1.61
• Radius for programming 2.8 mm • To generate a straight surface without cusps, the width of cut must not exceed DC
(1) Use with the supplied retention screw this screw was designed to be used instead of the standard cutter's frontal screw
(2) Cutting diameter maximum
(3) Maximum plunging width
(4) Number of inserts
(5) Maximum ramping angle
(6) Machinable diameter minimum for interpolation
(7) Machinable diameter maximum for interpolation
(8) Master insert identification
(9) Recommended tightening torque (N*m) for insert screw
For inserts, see pages: FF VNMT 0706 (525)
Spare Parts
Designation
FFV D040-03-16-R-VN07
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T-SH SR M8X17-13685 HW 4.0
FFV D050-05-22-R-VN07
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T-SH SR PS 118-0271C
FFV D063-06-22-R-VN07
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
FFV D080-07-27-R-VN07
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T-SH
FFV D100-08-32-R-VN07
SR M4X0.7-L11.5 IP15 BLD IP15/S7 SW6-T-SH
FFV-D-R-VN07
Fast Feed Shell Mill Carrying
Tangentially Clamped Inserts
with 4 Cutting Edges
309
FAST FEED MILLIG TOOLS
DCX
DCONMS
DHUB
DC
OAL
APMX
Rd°
Designation
DCX(1) DC APMX CICT(2) OAL DHUB DCONMS RMPX°(3) Arbor(4) MIID(5)
kg
FF FW D40-16-06-C
40.00 26.00 1.30 4 35.00 38.00 16.00 2.5 A FF WOMT0602 0.17
FF FW D50-22-06-C
50.00 36.00 1.30 5 40.00 48.00 22.00 2.0 A FF WOMT0602 0.31
FF FW D52-22-06-C
52.00 38.00 1.30 5 40.00 48.00 22.00 1.9 A FF WOMT0602 0.34
FF FW D50-22-09-C
50.00 29.20 2.00 4 50.00 47.00 22.00 4.0 A FF WOMT09T3 0.34
FF FW D52-22-09-C
52.00 31.20 2.00 4 40.00 47.00 22.00 4.0 A FF WOMT09T3 0.27
FF FW D63-22-09-C
63.00 42.20 2.00 5 40.00 58.00 22.00 3.0 A FF WOMT09T3 0.47
FF FW D63-27-09-C
63.00 42.20 2.00 5 50.00 61.00 27.00 3.0 A FF WOMT09T3 0.57
FF FW D66-22-09-C
66.00 45.20 2.00 5 40.00 61.00 22.00 2.8 A FF WOMT09T3 0.56
FF FW D66-27-09-C
66.00 45.20 2.00 5 50.00 61.00 27.00 2.8 A FF WOMT09T3 0.64
FF FW D80-32-09-C
80.00 59.20 2.00 5 50.00 75.00 32.00 2.0 A FF WOMT09T3 0.97
FF FW D100-32-09-C
100.00 79.20 2.00 6 50.00 78.00 32.00 1.5 B FF WOMT09T3 1.32
(1) Cutting diameter maximum
(2) Number of inserts
(3) Maximum ramping angle
(4) For adaptation options, see page 548
(5) Master insert identification
For inserts, see pages: FF WOCT/WOMT/WOMW (521)
Spare Parts
Designation
FF FW D40-16-06-C
SR 34-506/M T-9/51 SR M8X25DIN912
FF FW D50-22-06-C
SR 34-506/M T-9/51 SR M10X25 DIN912
FF FW D52-22-06-C
SR 34-506/M T-9/51 SR M10X25 DIN912
FF FW D50-22-09-C
SR 34-535 BLD T15/S7 SW6-T SR PS 118-0273
FF FW D52-22-09-C
SR 34-535 BLD T15/S7 SW6-T SR M10X25 DIN912
FF FW D63-22-09-C
SR 34-535 BLD T15/S7 SW6-T SR M10X25 DIN912
FF FW D63-27-09-C
SR 34-535 BLD T15/S7 SW6-T SR M12X30DIN912
FF FW D66-22-09-C
SR 34-535 BLD T15/S7 SW6-T SR M10X25 DIN912
FF FW D66-27-09-C
SR 34-535 BLD T15/S7 SW6-T SR M12X30DIN912
FF FW D80-32-09-C
SR 34-535 BLD T15/S7 SW6-T SR M16X30 DIN912
FF FW D100-32-09-C
SR 34-535 BLD T15/M7 SW6-T
FF FW
Fast Feed Face Mills
7.5
15°
DCONMS
OAL
DC APMX
DCX
BD
Designation
DCX(1) DC CICT(2) APMX OAL Rg(3) DCONMS Arbor(4) MIID(5)
kg
FF NM D080-06-27-R08
80.00 64.50 6 2.00 50.00 8.00 27.00 A ONHU 080608-TN 0.84 SR 14-591/H BLD T20/S7 SW6-T
(1) Cutting diameter maximum
(2) Number of inserts
(3) Radius for programming
(4) For adaptation options, see page 548
(5) Master insert identification
For inserts, see pages: ONHU/ONMU-08-TN-MM (515) • ONHU/ONMU-08-TN/HL (515)
Material
Vc [m/min]
Steel AISI 4340/34CrNiMO6
120-150
Nodular cast iron GGG 50
170
Cutting Data Recommendation
Recommended Application Range
0
2.52.01.51.00.50
Width of Cut (ae) = 56 mm
2.5
2.0
1.5
1.0
0.5
Ap[mm]
fz[mm/tooth]
FF NM
Fast Feed Face Mills Carrying
Octagonal ONHU/MU 0806...
Inserts with 16 Cutting Edges
ISCAR
310
FAST FEED MILLIG TOOLS
DCONMS
DHUB
APMX
OAL_2
BD
DC
OAL
15° 16°
APMX_2
DCX_2
DC_2 APMX_3
OAL_3
31º
DCX_3DCX
BD_3
DC_3
CA B
FF SOF
Multifunction Fast Feed
Milling Cutter for Octagonal
and Square Insert Contours
with Various Entry Angles
Application Range According to Insert Type
Material: SAE 4340
ae: 0.7xD
Vc: 150-170 m/min
2.5
1.5
0.5
2
1
00 0.5 1 21.5
ONMU 05...
OXMT 05... FF
S845 SNMU 13...
f
z
[mm/tooth]
ap [mm]
• A- with ONMU 0505... insert • B- with S845 SNMU 1305... insert • C- with OXMT 0507R08-FF insert • Use only Torx Plus keys
• For user guide, see pages 542-547
(1) Cutting diameter maximum
(2) Number of inserts
(3) For adaptation options, see page 548
(4) Master insert identification
For inserts, see pages: ONHU/ONMU-05 (504) • OXMT 0507 (505) • S845 SNMU/SNHU-13 (500)
Designation
DC DCX(1) BD APMX OAL DC_2 DCX_2 APMX_2 OAL_2 DC_3 DCX_3 BD_3 APMX_3 OAL_3
FF SOF 8/16-D063-06-22R
52.60 63.00 68.40 1.20 40.00 49.50 69.20 2.20 40.40 56.60 66.80 70.40 2.70 40.90
FF SOF 8/16 D080-07-27R
69.60 80.00 85.40 1.20 40.00 66.50 86.20 2.20 40.40 73.60 83.80 87.40 2.70 40.90
FF SOF 8/16 D100-08-32R
89.60 100.00 105.40 1.20 50.00 86.50 106.20 2.20 50.40 93.60 103.80 107.40 2.70 50.90
Designation
CICT(2) DHUB DCONMS Arbor(3) MIID(4)
kg
FF SOF 8/16-D063-06-22R
6 65.60 22.00 B ONHU 050500-N-HP 0.48 SR 11800745 BLD IP15/S7 SW6-T-SH SR M10X25 DIN912
FF SOF 8/16 D080-07-27R
7 82.60 27.00 B ONHU 050500-N-HP 1.04 SR 11800745 BLD IP15/S7 SW6-T-SH SR M12X30DIN912
FF SOF 8/16 D100-08-32R
8 102.60 32.00 B ONHU 050500-N-HP 1.47 SR 11800745 BLD IP15/S7 SW6-T-SH
311
USER GUIDE
FAST FEED MILLIG TOOLS
Milling Heads Extensions Adapter
M12
M12...CF4
D20/.75
M12
D25/1.00
M16
D25/1.00
M16
M16...CF4
ERCM D32-...
M16
ERCM D40-...
ISCAR
312
FAST FEED MILLIG TOOLS
BD
THSZWS
LDRED
OAL
DCONMS
BHTA
AB
A
0.005A
58-60 HRc
Designation
OAL LDRED DCONMS Shank BD BHTA THSZWS Type
kg
S M06-L60 C10
60.00 20.0 10.00 C 9.70 - M06 A 0.03
S M06-L105-C12
105.00 60.0 12.00 C 9.70 1.2 M06 B 0.06
S M06-L125-C16
125.00 60.0 16.00 C 9.70 3.3 M06 B 0.13
S M08-L73 C16
73.00 25.0 16.00 C 13.00 - M08 A 0.09
S M08-L128-C16
128.00 80.0 16.00 C 13.00 0.9 M08 B 0.15
S M08-L170-C20
170.00 66.8 20.00 C 13.00 3.3 M08 B 0.33
S M10-L80 C20
80.00 30.0 20.00 C 18.00 - M10 A 0.16
S M10-L130-C20
130.00 80.0 20.00 C 18.00 0.6 M10 B 0.25
S M10-L200-C25
200.00 57.2 25.00 C 19.00 3.3 M10 B 0.65
S M12-L86-C25
86.00 30.0 25.00 C 21.00 5.1 M12 A 0.27
S M12-L200-C32
200.00 78.0 32.00 C 21.00 4.4 M12 B 1.02
S M16-L95-C32
95.00 35.0 32.00 C 29.00 1.7 M16 A 0.50
S M16-L230-C32
230.00 50.0 32.00 C 29.00 1.8 M16 B 1.27
S M
Shanks for Tools with FLEXFIT
Threaded Connection
BD
OAL
LU
DCONMS
BD2 THSZWS
Designation
DCONMS THSZWS OAL LU BD BD_2
kg
S M08-L150-C16-C-H
16.00 M08 150.00 80.0 15.30 15.30 0.39
S M08-L200-C16-C-H
16.00 M08 200.00 140.0 15.30 15.30 0.59
S M08-L250-C16-C-H
16.00 M08 250.00 180.0 15.30 15.30 0.84
S M10-L150-C20-C-H
20.00 M10 150.00 80.0 18.50 18.50 0.73
S M10-L200-C20-C-H
20.00 M10 200.00 140.0 18.00 17.50 0.91
S M10-L250-C20-C-H
20.00 M10 250.00 180.0 18.00 17.50 1.04
S M12-L200-C25-C-H
25.00 M12 200.00 100.0 21.00 20.50 1.41
S M12-L250-C25-C-H
25.00 M12 250.00 180.0 24.00 24.00 1.78
S M12-L300-C25-C-H
25.00 M12 300.00 180.0 21.00 20.50 2.04
S M16-L200-C32-C-H
32.00 M16 200.00 100.0 29.00 29.00 2.11
S M16-L250-C32-C-H
32.00 M16 250.00 180.0 29.00 29.00 2.36
S M16-L300-C32-C-H
32.00 M16 300.00 180.0 29.00 29.00 2.81
• For adaptation options, see page 311
S M-C-H
Carbide Shanks with Coolant
Channels for Tools with FLEXFIT
Threaded Connection
LSCMS
LSCMS
LPR
LU
DRVS
BD
BD
DCONMS
THSZMS THSZWS THSZMS THSZWS
LPR
CAB M-M
BHTA
CAB M-M-C
DRVS 2 1 A
0.005A
58-60 HRc
Designation
THSZWS THSZMS BD LPR LU DCONMS LSCMS DRVS(1) Fig. BHTA
kg
CAB M06M08
M06 M08 9.70 30.00 24.80 13.00 17.50 9.5 1. 5.7 0.02
CAB M08M08-C
M08 M08 13.00 30.00 - - 17.50 9.6 2. - 0.02
CAB M08M10
M08 M10 13.00 40.00 33.40 18.00 20.20 15.0 1. 5.2 0.07
CAB M10M10-C
M10 M10 18.00 35.00 - - 20.00 15.0 2. - 0.06
CAB M10M12
M10 M12 18.00 45.00 36.40 21.00 22.00 17.0 1. 2.5 0.09
CAB M12M12-C
M12 M12 21.00 40.00 - - 22.00 17.0 2. - 0.08
CAB M12M16
M12 M16 21.00 50.00 42.50 29.00 25.00 25.0 1. 6.3 0.18
CAB M16M16-C
M16 M16 29.00 40.00 - - 25.00 25.0 2. - 0.16
(1) Clamping wrench size
SHANK CAB... HCM-M
SHANK S M...-CF4 CDP
CAB M-M (FLEXFIT)
Reducers and Extensions
with Coolant Holes for the
Modular FLEXFIT System
313
FAST FEED MILLIG TOOLS
BD
THSZWS
LBX8
LU
BHTA
LSCMS
DCONMS
DF
A
0.005A
58-60 HRc
Designation
THSZWS BD LBX LU DF LSCMS BHTA DCONMS
kg
S M12-L85/3.30-CF4
M12 21.00 85.0 81.30 44.00 42.00 4.4 25.00 0.23
S M12-L140/5.50-CF4
M12 21.00 140.0 139.10 44.00 42.00 4.4 25.00 0.98
S M16-L130/5.11-CF4
M16 29.00 130.0 126.80 44.00 42.00 2.6 25.00 0.23
S M16-L170/6.70-CF4
M16 29.00 170.0 168.60 44.00 42.00 2.0 25.00 1.30
SHANK SM...CF4 CDP...
S M-CF
CLICKFIT to FLEXFIT Adapters
BD
LSCMS OHN
DRVS
THSZMS DCONNWS
DCONXWS
CSI
A0.003A
58-60 HRc
Designation
CSI THSZMS DCONNWS(1) DCONXWS(2) OHN(3) LSCMS BD DRVS(4) TQ_3(5)
kg
CDP ER11 M10 M
ER11 M10 0.5 7.0 27.0 20.00 16.00 15.0 29 0.03
CDP ER11 M12 M
ER11 M12 0.5 7.0 27.0 22.00 16.00 17.0 33 0.04
CDP ER16 M10 M
ER16 M10 0.5 10.0 38.1 20.00 22.00 17.0 29 0.05
CDP ER16 M12 M
ER16 M12 0.5 10.0 37.1 22.00 22.00 17.0 33 0.06
CDP ER16 M16
ER16 M16 0.5 10.0 36.6 25.00 28.00 25.0 40 0.10
CDP ER20 M16
ER20 M16 1.0 13.0 45.5 25.00 34.00 25.0 40 0.19
CDP ER25 M16
ER25 M16 1.0 16.0 44.5 25.00 42.00 28.0 40 0.15
• When mounting items with FLEXFIT threaded adaptation to their holders, the mating surfaces and threaded areas must be thoroughly cleaned. Apply appropriate tightening
torque to eliminate a gap between the mating faces. Estimated torque values are specified in the TQ_3 parameter
(1) Minimum diameter
(2) Maximum diameter
(3) Minimum overhang
(4) Torque key size
(5) Tool tightening torque Nxm (lbfxin)
SHANK SM...CF4 CDP...
CDP ER-M
DIN 6499 ER Collet Chucks with
Threaded FLEXFIT Adaptations
ISCAR
314
FAST FEED MILLIG TOOLS
10
SS
CRKS
LB
BD_2
LPR LBX
BD
THSZWS
A0.003A
AT3 Taper
58-60 HRc
G2.5
G6.3
BT 40=20,000
RPM
RPM
BT 50=12,000
U<1.0 gmm
Designation
SS THSZWS BD BD_2 LPR LBX LB CRKS CDI(1)
kg
BT40 ODP 6X 66
40 M06 9.80 13.00 66.00 39.0 30.00 M16 0 0.98
BT40 ODP 6X106
40 M06 9.80 23.00 106.00 79.0 70.00 M16 0 0.14
BT40 ODP 8X 66
40 M08 13.00 15.00 66.00 30.0 30.00 M16 0 0.99
BT40 ODP10X 66
40 M10 18.00 20.00 66.00 30.0 30.00 M16 0 1.03
BT40 ODP10X106
40 M10 18.00 28.00 106.00 79.0 70.00 M16 0 1.24
BT40 ODP12X 66
40 M12 21.00 24.00 66.00 39.0 30.00 M16 0 1.05
BT40 ODP12X106
40 M12 21.00 31.00 106.00 79.0 70.00 M16 0 1.23
BT40 ODP16X 66
40 M16 29.00 28.60 66.00 39.0 35.00 M16 0 1.06
BT40 ODP16X106
40 M16 29.00 34.00 106.00 79.0 70.00 M16 0 1.32
BT50 ODP 12X 94
50 M12 23.00 30.00 94.00 56.0 50.00 M24 0 3.85
BT50 ODP 12X144
50 M12 23.00 40.00 144.00 106.0 100.00 M24 0 4.28
BT50 ODP 12X194
50 M12 23.00 40.00 194.00 156.0 150.00 M24 0 4.57
BT50 ODP 16X 94
50 M16 29.00 34.00 94.00 56.0 50.00 M24 0 3.75
BT50 ODP 16X144
50 M16 29.00 40.00 144.00 106.0 100.00 M24 0 4.19
BT50 ODP 16X194
50 M16 29.00 55.00 194.00 156.0 150.00 M24 0 5.24
BT50 ODP 16X244
50 M16 29.00 60.00 244.00 206.0 200.00 M24 0 5.60
• The coolant passages in the B-type flange are blocked with screws which can be removed when required.
(1) 1 - Hole for data chip, 0 - Without hole for data chip
BT-ODP (FLEXFIT)
FLEXFIT Threaded Adaptation
with Integral BT MAS-403
Tapered Shanks (ADB type)
10
LB
DCONMS
LPR
LBX
BD
BD_2 THSZWS
A0.003A
58-60 HRc
Designation
DCONMS THSZWS BD BD_2 LPR LBX LB CDI(1)
kg
C3 ODP 12X53
32.00 M12 21.00 26.00 53.00 38.0 23.00 0 0.32
C4 ODP 10X53
40.00 M10 18.00 23.00 53.00 33.0 23.00 1 0.33
C4 ODP 12X53
40.00 M12 21.00 26.00 53.00 33.0 23.00 1 0.33
C4 ODP 16X53
40.00 M16 29.00 34.00 53.00 33.0 23.00 1 0.40
C5 ODP 10X103
50.00 M10 18.00 28.00 103.00 83.0 75.00 1 0.10
C5 ODP 10X53
50.00 M10 18.00 19.50 53.00 33.0 25.00 1 0.49
C5 ODP 12X103
50.00 M12 21.00 31.00 103.00 83.0 75.00 1 0.72
C5 ODP 12X53
50.00 M12 21.00 23.50 53.00 33.0 25.00 1 0.50
C5 ODP 16X103
50.00 M16 29.00 36.00 103.00 83.0 75.00 1 0.85
C5 ODP 16X53
50.00 M16 29.00 34.00 53.00 33.0 25.00 1 0.65
C6 ODP 10X105
63.00 M10 18.00 28.00 105.00 83.0 75.00 1 1.00
C6 ODP 10X130
63.00 M10 18.00 32.00 130.00 108.0 100.00 1 0.00
C6 ODP 10X55
63.00 M10 18.00 19.50 55.00 33.0 25.00 1 0.82
C6 ODP 12X105
63.00 M12 21.00 31.00 105.00 83.0 75.00 1 1.07
C6 ODP 12X130
63.00 M12 21.00 36.00 130.00 108.0 100.00 1 1.26
C6 ODP 12X55
63.00 M12 21.00 23.50 55.00 33.0 25.00 1 0.84
C6 ODP 16X105
63.00 M16 29.00 34.00 105.00 83.0 75.00 1 1.20
C6 ODP 16X130
63.00 M16 29.00 41.00 130.00 108.0 100.00 1 1.49
C6 ODP 16X55
63.00 M16 29.00 34.00 55.00 33.0 25.00 1 0.89
(1) 1 - Hole for data chip, 0 - Without hole for data chip
C#-ODP (FLEXFIT)
FLEXFIT Threaded Connection
Shanks with CAMFIX (ISO
26623-1) Adaptation
315
FAST FEED MILLIG TOOLS
SS
10
BD
THSZWS
BD_2
LB
LBX
Fig. 1 Fig. 2
LBX
BD
THSZWS
BD_2
SS
Bar Max
A0.003A
58-60 HRc
Designation
SS THSZWS LB LBX BD BD_2 Fig.
kg
ER16 ODP M08X02
ER16 M08 2.50 2.50 12.00 12.00 2 0.04
ER16 ODP M08X10
ER16 M08 10.50 10.50 12.00 12.00 2 0.04
ER20 ODP M08X02
ER20 M08 2.00 2.00 13.00 13.00 2 0.05
ER20 ODP M08X10
ER20 M08 10.00 10.00 13.00 12.60 2 0.05
ER25 ODP M08X02
ER25 M08 2.00 2.00 13.00 13.00 2 0.05
ER25 ODP M08X10
ER25 M08 10.00 10.00 13.00 12.60 2 0.09
ER25 ODP M10X02
ER25 M10 2.00 2.00 18.00 18.00 2 0.05
ER25 ODP M10X25
ER25 M10 23.00 25.00 18.00 17.60 1 0.11
ER25 ODP M12X02
ER25 M12 2.70 2.70 20.60 19.20 2 0.08
ER25 ODP M12X10
ER25 M12 10.00 10.00 20.00 20.00 2 0.10
ER32 ODP M 8X25
ER32 M08 22.00 25.00 13.10 15.00 1 0.15
ER32 ODP M 8X50
ER32 M08 49.00 50.00 13.10 23.00 1 0.21
ER32 ODP M 8X75
ER32 M08 74.00 75.00 13.10 23.00 1 0.26
ER32 ODP M08X02
ER32 M08 2.00 2.00 13.00 13.00 2 0.15
ER32 ODP M08X10
ER32 M08 10.00 10.00 13.00 12.60 2 0.14
ER32 ODP M10X02
ER32 M10 2.00 2.00 18.00 18.00 2 0.15
ER32 ODP M10X10
ER32 M10 10.00 10.00 18.00 17.60 2 0.15
ER32 ODP M10X25
ER32 M10 23.00 25.00 18.00 20.00 1 0.17
ER32 ODP M10X50
ER32 M10 49.00 50.00 18.00 24.00 1 0.24
ER32 ODP M12X02
ER32 M12 2.00 2.00 21.00 21.00 2 0.15
ER32 ODP M12X10
ER32 M12 10.00 10.00 21.00 20.60 2 0.17
ER32 ODP M12X25
ER32 M12 24.00 25.00 21.00 24.00 1 0.18
ER32 ODP M12X50
ER32 M12 49.00 50.00 21.00 24.00 1 0.26
ER32 ODP M16X02
ER32 M16 2.50 2.50 27.00 27.00 2 0.15
ER32 ODP M16X10
ER32 M16 10.50 10.50 27.00 27.00 2 0.18
ER32 ODP M16X25
ER32 M16 25.50 25.50 27.00 27.00 1 0.20
ER-ODP
FLEXFIT Threaded Adaptation
with Integral ER Collet
for ER Collet Chucks
SS
10
BD
THSZWS
BD_2
LB
LBX
LPR
CRKS
A0.003A
AT3 Taper
58-60 HRc
G2.5
G6.3
SK 40=20,000
SK 50=12,000
RPM
RPM
U<1.0 gmm
Designation
SS THSZWS BD BD_2 LPR LBX LB CRKS CDI(1)
kg
DIN69871 40 ODP 6X58
40 M06 9.80 13.00 58.00 38.9 30.00 M16 0 0.82
DIN69871 40 ODP 6X98
40 M06 9.80 23.00 98.00 78.9 70.00 M16 0 0.91
DIN69871 40 ODP 8X58
40 M08 13.10 15.00 58.00 38.9 30.00 M16 0 0.82
DIN69871 40 ODP 8X98
40 M08 13.10 23.00 98.00 78.9 70.00 M16 0 0.92
DIN69871 40 ODP10X58
40 M10 18.00 20.00 58.00 38.9 30.00 M16 0 0.84
DIN69871 40 ODP10X98
40 M10 18.00 28.00 98.00 78.9 70.00 M16 0 1.00
DIN69871 40 ODP12X58
40 M12 21.00 24.00 58.00 38.9 30.00 M16 0 0.88
DIN69871 40 ODP12X98
40 M12 21.00 31.00 98.00 78.9 70.00 M16 0 1.07
DIN69871 40 ODP16X58
40 M16 29.00 28.60 58.00 38.9 35.00 M16 0 0.91
DIN69871 40 ODP16X98
40 M16 29.00 34.00 98.00 78.9 70.00 M16 0 1.15
DIN69871 50 ODP12X 78
50 M12 23.00 30.00 78.00 58.9 50.00 M24 0 2.74
DIN69871 50 ODP12X128
50 M12 23.00 40.00 128.00 108.9 100.00 M24 0 3.14
DIN69871 50 ODP12X178
50 M12 23.00 40.00 178.00 158.9 150.00 M24 0 3.38
DIN69871 50 ODP12X228
50 M12 23.00 46.00 228.00 208.9 200.00 M24 0 4.14
DIN69871 50 ODP16X 78
50 M16 29.00 34.00 78.00 58.9 50.00 M24 0 2.95
DIN69871 50 ODP16X128
50 M16 29.00 40.00 128.00 108.9 100.00 M24 0 3.20
DIN69871 50 ODP16X178
50 M16 29.00 55.00 178.00 158.9 150.00 M24 0 4.08
DIN69871 50 ODP16X228
50 M16 29.00 55.00 228.00 208.9 200.00 M24 0 4.64
(1) 1 - Hole for data chip, 0 - Without hole for data chip
DIN69871-ODP
FLEXFIT Threaded Connection
Shanks with Integral DIN 69871
Form ADB Taper Adaptation
ISCAR
316
FAST FEED MILLIG TOOLS
10
LB
BD_2 THSZWS
DCONMS
LPR
LBX
BD
.
A0.003A
58-60 HRc
G2.5
G6.3
HSK A63=20,000
RPM
HSK A100=12,000
RPM
U<1.0 gmm
Designation
DCONMS THSZWS BD BD_2 LPR LBX LB CDI(1)
kg
HSK A32 ODP12X42
32.00 M12 21.00 20.60 42.00 22.0 - 1 0.17
HSK A40 ODP12X30*
40.00 M12 21.00 20.60 30.00 10.0 - 1 0.21
HSK A50 ODP12X48
50.00 M12 21.00 20.60 48.00 22.0 - 1 0.46
HSK A63 ODP6X109
63.00 M06 9.80 23.00 109.00 83.0 75.00 1 0.74
HSK A63 ODP6X59
63.00 M06 9.80 11.50 59.00 33.0 25.00 1 0.66
HSK A63 ODP8X109
63.00 M08 13.10 23.00 109.00 83.0 75.00 1 0.77
HSK A63 ODP8X59
63.00 M08 13.10 15.00 59.00 33.0 25.00 1 0.68
HSK A63 ODP10X109
63.00 M10 18.00 28.00 109.00 83.0 75.00 1 0.87
HSK A63 ODP10X59
63.00 M10 18.00 20.00 59.00 33.0 25.00 1 0.70
HSK A63 ODP12X109
63.00 M12 21.00 31.00 109.00 83.0 75.00 1 0.93
HSK A63 ODP12X59
63.00 M12 21.00 23.50 59.00 33.0 25.00 1 0.71
HSK A63 ODP16X109
63.00 M16 29.00 34.00 109.00 83.0 75.00 1 1.05
HSK A63 ODP16X59
63.00 M16 29.00 34.60 59.00 33.0 25.00 1 0.79
HSK A100 ODP12X137
100.00 M12 23.00 30.00 137.00 108.0 100.00 1 2.58
HSK A100 ODP12X187
100.00 M12 23.00 40.00 187.00 158.0 150.00 1 2.86
HSK A100 ODP12X237
100.00 M12 23.00 46.00 237.00 208.0 200.00 1 3.40
HSK A100 ODP12X87
100.00 M12 23.00 30.00 87.00 58.0 50.00 1 2.23
HSK A100 ODP16X137
100.00 M16 29.00 41.50 137.00 108.0 100.00 1 2.68
HSK A100 ODP16X187
100.00 M16 29.00 55.00 187.00 158.0 150.00 1 3.58
HSK A100 ODP16X237
100.00 M16 29.00 55.00 237.00 208.0 200.00 1 4.07
HSK A100 ODP16X87
100.00 M16 29.00 31.50 87.00 58.0 50.00 1 2.20
• A cooling tube must be used with all coolant through HSK spindles (should be ordered separately).
(1) 1 - Hole for data chip, 0 - Without hole for data chip
HSK A-ODP (FLEXFIT)
FLEXFIT Threaded Adaptation
with HSK DIN 69893/A
Tapered Shanks
