KEMMLER 12.27
Materialgruppen
Material groups
Groupes matières
N/mm² HB Ø 1 Ø 2 Ø 3 Ø 4 Ø 6 Ø 8 Ø 10 Ø 12 Ø 16 Ø 20
P
Nicht legierter Stahl
Non-alloyed steel
Acier non allié ≤ 700 ≤ 210 0,02-0,03 0,05-0,055 0,07-0,084 0,09-0,102 0,12-0,13 0,12-0,13 0,13-0,16 0,13-0,16 0,14-0,17 0,14-0,17
Wenig legierter Stahl
Low-alloyed steel
Acier faible allié 700-1000 210-300 0,02-0,03 0,05-0,055 0,07-0,084 0,09-0,102 0,12-0,13 0,12-0,13 0,13-0,16 0,13-0,16 0,14-0,17 0,14-0,17
Hoch legierter Stahl
High-alloyed steel
Acier fortement allié ≤ 1000 ≤ 300 0,02-0,03 0,05-0,055 0,07-0,084 0,09-0,102 0,12-0,13 0,12-0,13 0,13-0,16 0,13-0,16 0,14-0,17 0,14-0,17
Stahl 30-38HRC
Steel 30-38HRC
Acier 30-38HRC 0,02-0,025 0,04-0,045 0,06-0,074 0,08-0,09 0,11-0,12 0,11-0,12 0,12-0,15 0,12-0,15 0,13-0,16 0,13-0,16
H
Stahl 38-48 HRC
Steel 38-48 HRC
Acier 38-48 HRC 0,02-0,025 0,04-0,045 0,06-0,074 0,08-0,09 0,11-0,12 0,11-0,12 0,12-0,15 0,12-0,15 0,13-0,16 0,13-0,16
Stahl 48-56 HRC
Steel 48-56 HRC
Acier 48-56 HRC 0,015-0,02 0,03-0,04 0,04-0,05 0,06-0,08 0,08-0,1 0,08-0,1 0,1-0,12 0,1-0,12 0,11-0,13 0,11-0,13
Stahl 56-68 HRC
Steel 56-68 HRC
Acier 56-68 HRC 0,015-0,02 0,03-0,04 0,04-0,05 0,06-0,08 0,08-0,1 0,08-0,1 0,1-0,12 0,1-0,12 0,11-0,13 0,11-0,13
M
Edelstahl
Stainless Steel
Acier inoxydable 500-950 250-320 0,02-0,025 0,04-0,045 0,06-0,074 0,08-0,09 0,11-0,12 0,11-0,12 0,12-0,15 0,12-0,15 0,13-0,16 0,13-0,16
K
Gusseisen
Cast Iron
Fonte 180-280 0,02-0,03 0,05-0,055 0,07-0,084 0,09-0,102 0,12-0,13 0,12-0,13 0,13-0,16 0,13-0,16 0,14-0,17 0,14-0,17
Aluminium
Aluminium
Aluminium Si 0,5-12% 0,03-0,05 0,05-0,07 0,06-0,09 0,12-0,15 0,15-0,2 0,18-0,24 0,22-0,26 0,25-0,3 0,28-0,32 0,3-0,35
Kupfer
Copper
Cuivre 180-250 0,03-0,05 0,05-0,07 0,06-0,09 0,12-0,15 0,15-0,2 0,18-0,24 0,22-0,26 0,25-0,3 0,28-0,32 0,3-0,35
N
Plastik
Plastic
Plastique 0,03-0,05 0,05-0,07 0,06-0,09 0,12-0,15 0,15-0,2 0,18-0,24 0,25-0,35 0,3-0,4 0,4-0,5 0,5-0,6
Gusswerkstoffe
Composite material
Matériaux de moulage
0,03-0,05 0,05-0,07 0,06-0,09 0,12-0,15 0,15-0,2 0,18-0,24 0,25-0,35 0,3-0,4 0,4-0,5 0,5-0,6
Graphit
Graphite
Graphite 0,04-0,08 0,06-0,08 0,1-0,12 0,1-0,13 0,15-0,18 0,2-0,23 0,24-0,28 0,26-0,3 0,3-0,33 0,32-0,36
Titanium
Titanium
Titanium 700-1250 210-370 0,015-0,02 0,03-0,04 0,04-0,05 0,06-0,08 0,08-0,1 0,08-0,1 0,1-0,12 0,1-0,12 0,11-0,13 0,11-0,13
S
Nickel
Nickel
Nickel 900-1200 260-350 0,015-0,02 0,03-0,04 0,04-0,05 0,06-0,08 0,08-0,1 0,08-0,1 0,1-0,12 0,1-0,12 0,11-0,13 0,11-0,13
Hitzeresistenter Stahl
Heat resistant steel
Acier thermorésistant 900-1400 210-400 0,015-0,02 0,03-0,04 0,04-0,05 0,06-0,08 0,08-0,1 0,08-0,1 0,1-0,12 0,1-0,12 0,11-0,13 0,11-0,13
Aluminium Feinstkorn VHM Stirnradiusfräser 2 Schneiden
Aluminium UMG Solid carbide ball nose end mill 2 fl utes
Fraise aluminium à bout hémisphérique en carbure monobloc 2 dents
