mark: Standard stocked item
mark:
To be replaced with the new item featured on the same page
mark: To be replaced by new item
(Please confirm stock availability)
* mark:
Semi-standard stock (Please confirm stock availability)
mark:
Stock or planned stock (Please confirm stock availability)
No mark: Made-to-order item
mark: We cannot produce
Stock Indications and Symbols
D1
Special Tool Holders For Machining Small Parts
SEC-Round Shanke Holders
SEC-Mini Tool Zero Offset Holders
SEC-Mini Tool Holders PC Type
SEC-Mini Tool Holders SC Type
SEC-Mini Tool Holders PD Type
SEC-Mini Tool Holders SD Type (7 Positive)
SEC-Mini Tool Holders SS Type
SEC-Mini Tool Holders ST Type
SEC-Mini Tool Holders SV Type
Small Product Machining Selection Guide .................... D2
Small Product Machining Overview ..............................D4
Insert Grade Selection Guide .......................................D6
Chipbreaker Selection Guide ........................................D7
SEC-PB Tool Holders SPB Type ....................................D8
SEC-Wide Tool Holders SGW Type ............................. D10
SEC-Mini Tool Holders SBT Type /
Expanded
PBT Type ........ D11
SEC-Front Turning Tool Holders SFT Type .................. D12
RS-SCLL Type ............................................................ D13
RS-SDUL Type / RS-SDXL Type .................................. D14
RS-SVXL Type / RS-SVVP Type / RS-PTXN Type ......... D15
PCLC-X Type / SCLC-X Type / SCAC-X Type ................ D16
PDJC-X Type / SDJC-X Type / SDAC-X Type / SDPC-X Type
...... D17
SVJC-X Type / PTXN-X Type ........................................ D18
PCLC Type ................................................................. D19
SCLC Type / SCAC Type ............................................. D19
PDJC Type .................................................................. D23
SDJC Type / SDAC Type / SDNC Type ......................... D23
SSBC Type .................................................................D28
STGC Type / STAC Type .............................................. D29
SVLC Type / SVPC Type .............................................. D31
SVLP Type / SVPP Type .............................................. D33
External Holders D1 to D33
SEC-Grooving Tools (For External Grooving) F4
SEC-Grooving Tools (For Internal Grooving) F36
SEC-Small Cut-off Tools F54
SEC-Threading Tools (For External Threading) F68, F76
SEC-Threading Tools (For Internal Threading) F68, F81
Small Product Machining
External Holders
Grooving / Cut-off Tools
G
Boring Bars
Multifunctional Small Lathe Tools E10
SEC-Boring Bars (For Bottom Facing) E12
SEC-Boring Bars (For Profiling) E27
SEC-Boring Bars (For Through Hole Boring) E49
SEC-Boring Bars (For Blind Hole Boring) E58
SEC-Very Small Boring Bars E71
Expanded
Small Product
Machining
D
D2
D
Small Product
Machining
F54 D11 D31 D23 F4 F10
117.5
95 93 93
0.05,
0.15 mm
0
0.2,
0.4 mm
0.5
32
100
D12 D18 F30 F76 F68 F80
1.4 mm
E10 E11D13
20
Expanded
Twin Head Holders
ID + OD
CKBE Type
ID + ID
CKBB Type
This is a sleeve holder (for front and back faces) for external machining.
This holder allows two types of machining to be performed with one holder.
External Machining
External Machining
External Machining
Multifunctional Tools
Pitch
0.8–3.0 mm
0–0.2 mm
3.0–6.0 mm
Negative
0.4–1.25 mm
Pitch
0.2–1.58 mm
0.8–1.5 mm
0.6–1.3 mm
Pitch
0.5–3.0 mm
Cut-Off Profiling
Back Turning
SBT Type
PBT Type
Grooving
Grooving and Cut-Off
General Turning
SCT Type SV Type P Type
S Type GWC Type GND Type
Max. machining diameter
ø5–16 mm
0.5–2.0 mm
SVLC Type SVPC Type
7 Positive
11 Positive
2.5–5.2 mm
3.5–
8.0 mm
Back side
clamp
Screw-on
PDJC Type SDJC Type
0.75–2.5 mm
1.25–
3.0 mm
Use / Type /
Page
Cutting edge
shape
Use / Type /
Page
Cutting edge
shape
THE Type
Threading
Front Turning Front Turning
PTXN-X Type
SGE Type
Grooving
Traverse Turning
STH Type
Threading
SSTE TypeSFT Type
Threading
Round Shank Holder
RS Type
1.25–3.00 mm
20–32 mm
Use / Type /
Page
Use / Type /
Page
Small Product Machining
Selection Guide
D3
D
Small Product
Machining
E73 E73 E75
E72
E76 E78E77 E80 E80
F36 F82 F68E12 to E70 F37
E38
10
20
1.5, 2.0, 3.0mm
1.0, 2.0mm
5
10
20
SUMIBORON (CBN) Small Diameter Boring
SUMIBORON (PCD) Small Diameter Boring
Very Small Diameter Boring
CKB Type
KBMZ Type
Back Turning
KBMG Type
GroovingGeneral
KBMX Type
1.0 mm–
General
BXBR Type
2.0 mm–
KBMFR Type
End Grooving
Internal Machining Machining very small inner diameters greater than 1 mm
Carbide Solid Bar
BXBR Type
Small Diameter Boring
BSME Type
Small Diameter Boring
BNBX Type
Small Diameter Boring
DABB-C Type
Small Diameter Boring
DABB-N Type
Very Small Diameter Boring (Round Shank)
S-CKB Type / S-CKB-S Type CKBS Type
For Gang-Type Tool Posts
Very Small Diameter Boring
Small Diameter Boring
SEXC Type
3
2.5 mm–
BNBX Type
5
50
3.0 mm–
DABB-C Type
25
25
3.0 mm–
DABB-N Type
10
4.0 mm–
SEXC Type
10
2.5 mm–
BSME Type
Internal Machining
Machining small inner
diameters greater than 5 mm
Grooving and Threading
5.5– SWUB Type
8.0– STUP(B) Type
5.0– SCLC Type
12.0– SCLP Type
13.0– SD Type
SV Type
25.0– SVJB Type
Blind Hole Boring Bottom Facing Profiling
Concave Facing
and Hole Bottom Facing
Units (mm)
5.5– SWUB Type
16.0– SSKP Type
20.0– SSKC Type
Through Hole Boring
Boring
Use / Type /
Page
Cutting edge shape
SW Type / ST Type / SC Type /
SD Type / SV Type / SS Type
From E58 From E12 From E27
From E49
Internal Grooving
SGIT Type
0.5–2.0 mm
Max. groove depth
0.8–2.8 mm
10.0–
Internal Threading
STHI Type
Pitch 0.4–1.0 mm
8.0–
Internal Threading
SSTI Type
Pitch 0.5–3.0 mm
18.0–
Internal Grooving
GNDIS Type
1.5–3.0 mm
Max. groove depth
2.6–6.6 mm
14.0–
Use / Type /
Page
Cutting edge
shape
Use / Type /
Page
Cutting edge
shape
Use / Type /
Page
Cutting edge
shape
Small Product Machining
Selection Guide
D4
D
Small Product
Machining
Overview
This is a series of very small (mini) indexable inserts for machining
small products on small NC autolathes. Our company was the first
in the industry to sell this product in 1984. Through our many years
of experience, we have worked hard to expand our product offering
in these series and have added new tool designs that are capable of
handling all types of machining processes, from back turning, profiling,
and cutting-off, and have added tools with clamps on the back side.
Full Lineup of Grades
from Carbide to PCD
Very Small Diameter Boring Bars: CKB Type
For Machining Very Small Parts: SPB Type
For Plunging: SGW Type
Minimum machinable diameter ø1–ø5 mm
Optimal for machining very small parts less than ø10 mm
Optimal for efficiently machining long parts, solves chip control
Special Small Lathe Tools For Various Types of Machining
From D6
Expanded
From E71
From D8
D10
Small Product Machining
D5
D
Small Product
Machining
Back Side Clamp Tools: PC Type / PD Type
Back Turning Tools: SBT Type / PBT Type
Cut-off Tools: SCT Type
A Wide Selection of Easy-To-Use Holders
Produces a good finish with a sharp cut
Maximum machining step size 8.0 mm, edge width 2.5 mm
Easy insert replacement at the back simply by loosening a screw
Max. cut-off dia. ø5 mm, ø12 mm, ø16 mm
Easy and reliable
lever locking system
Easily insert replacement at the back
D19 D23
Zero Offset Holders The part number ends with -X
Unnecessary to edit the program for small gang tool lathes
D11
Twin Head Holders
Multifunctional tools for autolathes
Makes it possible to perform two types of machining with a single holder
Round Shank Holders: RS Type
Enables external turning with sleeve holders
F54
SEC-Grooving Tools: GND Type
Lineup also includes shanks for small lathes
Handles grooving of 1.25 mm and above.
Expanded
From D16
From E10
From D13
From F10
Small Product Machining
Small Product
Machining
D6
D
Small Product Machining
Insert Grade Selection Guide
This is a series of very small (mini) indexable inserts for machining
small products on small NC autolathes. Our company was the first
in the industry to sell this product in 1984. Available in a full range
of materials, including mainly AC530U/AC1030U, cermet T1500A,
carbide BL130, SUMIBORON BN2000, and SUMIDIA DA1000, this
series can handle diverse machining tasks.
In addition, based on our experience with technology for machining
precision parts, we have added ACZ150, a grade for high precision
machining, to our lineup. We support machining operations for a wide
range of industries, from automobile parts to electronic device parts.
Insert grade selection guide
Recommended Cutting Conditions
P
Free-cutting steel
P Carbon steel M Stainless steel H Hardened steel N Aluminum N Brass
vcm/min fmm/rev vcm/min fmm/rev vcm/min fmm/rev vcm/min fmm/rev vcm/min fmm/rev vcm/min fmm/rev
ACZ150 50–200
0.02–0.10
50–150
0.01–0.08
50–150
0.01–0.05
70–300
0.05–0.20
70–300
0.05–0.20
AC510U 50–200
0.02–0.15
50–200
0.02–0.10
50–200
0.02–0.10
70–300
0.05–0.20
AC520U 50–200
0.02–0.15
50–200
0.02–0.10
50–200
0.02–0.10
70–300
0.05–0.20
AC530U 50–200
0.02–0.15
50–200
0.02–0.10
50–200
0.02–0.10
70–300
0.05–0.20
AC1030U 50–200
0.02–0.15
50–200
0.02–0.10
50–150
0.02–0.10
70–300
0.05–0.20
T1000A 50–200
0.02–0.15
50–200
0.02–0.10
50–150
0.02–0.10
70–300
0.05–0.20
70–300
0.05–0.20
T1500A 50–200
0.02–0.15
50–200
0.02–0.10
50–150
0.02–0.10
70–300
0.05–0.20
70–300
0.05–0.20
T1500Z 50–200
0.02–0.15
50–200
0.02–0.10
50–150
0.02–0.10
70–300
0.05–0.20
70–300
0.05–0.20
BN1000
50–200
0.02–0.10
BN2000
50–120
0.02–0.10
DA1000 70–300
0.02–0.10
70–300
0.02–0.10
DA2200 70–300
0.02–0.10
70–300
0.02–0.10
Grade
Work
material
Grade
Coated carbide
(PVD)
Non-coated cermet
Coated cermet
Carbide
CBN
(SUMIBORON)
Polycrystalline diamond
(SUMIDIA)
Application range Work material
ACZ150
AC510U
AC520U
AC530U
AC1030U
T1000A
T1500A/T1500Z
BL130
H1
EH510
BN1000/BN2000
DA1000
DA2200
High precision
Finishing to light cutting
Medium cutting
: 1st recommended : 2nd recommended
General steel
Stainless steel
Cast iron
Heat resistant
alloy
Hardened steel
Non-ferrous
metal
Values in red: 1st recommendation Values in blue: 2nd recommendation
Positive type, M class
Positive type, G class, Ground type
Positive type, G class
D7
D
Small Product
Machining
Small Product Machining
Chipbreaker Selection Guide
Chipbreaker selection guide
Chipbreakers for Finish Cutting to Light Cutting
Finishing–Light cutting Feature
Parallel
type
FX type
For general external turning, optimal
for finishing for large grooves.
Wide type
Suppresses burrs during
undercutting Suppresses chatter
during external turning and facing
Mould type
FC type SI type
A three-dimensional chipbreaker
with excellent chip control and
cutting performance. FC type for fine
finishing, SI type for varying grooves
AG type
Chipbreaker for machining aluminum
alloys
Good cutting performance, low welding
Chipbreaker Application Range For Finish Cutting to Light Cutting
Insert Series
Insert accuracy selection guide
Class
M class G class E class
Thickness
tolerance 0.13 mm 0.13 mm 0.025 mm
Characteristics In general, the side
has sintered surface
Side has ground surface
Side has ground surface
Thickness allowable error
is smaller than for G Class.
Application Rough machining–
Light cutting
Finishing–Light cutting
High precision–Finishing
Example of part
numbers
CCMT09T304N-LU
DCMT070208N-SU
CCGT09T304R-FX
DCGT11T302MN-SI
CCET09T302R-FX
DCET0702018L-FY
*
The letter M in the part number before the feed direction indicates a nose radius with negative tolerance.
M class Finishing to light cutting G class Ground type G class Chipbreaker
0.2 0.4
0
2
4
Feed rate (mm/rev)
Depth of cut (mm)
SI Type
FC Type
SC Type
0.2 0.4
0
2
4
FX Type
SDW Type
FY Type
SD Type
Feed rate (mm/rev)
Depth of cut (mm)
W Type
FYS Type
FYS Type
0.2 0.4
0
2
4
Feed rate (mm/rev)
Depth of cut (mm)
LU Type
LUW Type
FP Type
FK Type
SU Type
7° 11°
Relief angle
5° 7° 11°
Relief angle
11°
Relief angle
7° 11°
Relief angle
PMKNS
LU type
0.8
15°
LUW type
1.5
10°
SU type
General purpose chipbreaker
with excellent cutting
performance
1.45
8°
FK type
Finishing breaker with excellent
cutting performance and chip
control
1.1
Wiper Insert
FP type
A stepped chipbreaker
for fine cutting
7°
Relief angle
1.4
0.7
10°
CCMT09T3 type CCMT09T3 type CCMT09T3 type TPMT1604 type TPMT1604 type
PMKNS PMKNS PMKNSPMKNS
5° 7° 11°
Relief angle
5° 7° 11°
Relief angle
5° 7°
Relief angle
7° 11°
Relief angle
FX type
FYS type
Parallel chipbreaker
with sharp edge
Chipbreaker for fine
cutting with sharp edge
0.9
15°
FY type
Wide chipbraker with
sharp edge
1.5
15°
0.5
15°
SD type
Stepped parallel ground
type chipbreaker
0.9
TPGT1103 type
TPGT1103 typeCCGT04X1 type TPGT1103 type
PMKNSPMK N SP MK N S P MKNS
7°
Relief angle
7° 11°
Relief angle
7°
Relief angle
7°
Relief angle
3D breaker for peripheral grinding
with excellent chip control and cutting
performance
FC type
0.9
15°
SI type SC type
For light cutting
Stepped chipbreaker
1.0
6°
AG type
Blade for providing a chip-free
mirror finish on aluminum alloys
20°
0.8 15°
High performance breaker for a
wide range of cutting applications
from finishing to light cutting
CCGT09T3 type CCGT09T3 type TCGT1103 type CCGT09T3 type
P P PMKNSPMKNSMKNSMKNS
Work materials:
P
Steel
M
Stainless steel
K
Cast iron
N
Non-ferrous metal
S
Exotic alloy
FB type
LB type
5° 7° 11°
Relief angle
5° 7° 11°
Relief angle
PMKNS PMKNS
20°
0.5
15°
0.8
AY type
15°
2.5
5° 7° 11°
Relief angle
PMKNS
High quality ground type breaker
for finishing aluminum alloys
CCGT09T3
type
Breaker for light cutting with
excellent cutting performance
and chip control
CCMT09T3 typeCCMT09T3 type
FY typeFYS type
Breaker with significantly improved
chip control in fine cutting
High performance finishing
breaker with wiper edge
Soft steel finishing breaker with
excellent chip control in high quality
surface machining
D8
D
Small Product
Machining
Tool Holders For Machining Very Small Parts
For Machining Very Small Parts
Features
Expanded selection of high rigidity tools for gang tool NC lathes!
Possible to use multiple inserts for different purposes on a
single holder
Compatible with turrets
Blank inserts available
Non-coated surface allows inserts to be ground freely
Wear-resistance comparable to coated surfaces
The cutting performance of a non-coated edge BL130
Most popular brazed tools, fine-grained carbide F1 is used for
indexable inserts
SPB
Very Small
Dia. Turning
B
H
3
LF
1˚
1˚
1
LF
3
BH
Fig. 1 Fig. 2
Offset: 0
Height offset
below center:
0.1
Offset: 0
Height offset
below center:
0.1
B
H
3
LF
1˚
Fig. 3
Offset: 0
Height offset
below center:
0.1
Applicable Grades Cutting Applications
Tool: BL130
(PBVFN1102R)
Work material:
SUS420F
Cutting conditions:vc = 7 to 11 m/min
f = 0.006 mm/rev
Clock parts
ø0.3 0.05
ø0.54 0.05
BL130
0 50,000 100,000
F0
(Brazed tool)
Output (pcs/c)
Parts
Toolpost
Cat. No. Stock Height Width Length
Relief angle
Fig Screw N m Wrench
RL H B LF
Turret t ype
SPB R/L0707-70 77140701
BFTX02505N
1. 1
LT08-06
SPB R/L0808-60 88140602
BFTX02506N
1. 5
SPB R/L0808-70 88140702
BFTX02505N
1. 1
SPB R/L0909-70 9.5 9.5 140 70 2
BFTX02505N
1. 1
SPB R/L1010-60 10 10 140 60 2
BFTX02506N
1. 5
SPB R/L1212-60 12 12 140 60 2
BFTX02506N
1. 5
Gang-type
SPB R0808 88140 3
BFTX02506N
1. 5
SPB R1010 10 10 140 3
BFTX02506N
1. 5
SPB R1212 12 12 140 3
BFTX02506N
1. 5
Holders
This figure shows right handed tools.
SEC-PB Tool Holders
SPB Type
General steel, SK material
Stainless steel
Brass, aluminum
Austenite
Martensite
Ferrite
BL130
F1
Insert
Grade
Application
Work
material
Recommended tightening torque (N m)
Dimensions (mm)
D9
D
Small Product
Machining
SEC-PB Tool Holders
SPB Type
Cat. No.
Dimensions (mm)
Wiper edge
Fig BL
130 F1
Effective length
PBVFW 1102R 1. 0 Yes 1
PBVFW 1102L
PBVFN 1102R 1. 0 No 2
PBVFN 1102L
Cat. No. Dimensions (mm) Fig BL
130 F1
Max. cut-off dia.
Edge width CW
PBVC 1102R-50 ø5.0 1.0 1
PBVC 1102L-50 2
Cat. No.
Dimensions (mm)
Application
Fig BL
130 F1
Length (L)
PBVX 1102R-NB 17.2
A wide range
of applications
1
PBVX 1102L-NB
PBVX 1102R-SB 20.14 Sharp
products 2
PBVX 1102L-SB
PBVX 1102R-BB 17.2 Special
products 3
PBVX 1102L-BB
Cat. No. Dimensions (mm) Fig BL
130 F1
Pitch
PBVTF 1102R
0.2 0.5
1
PBVTF 1102L
PBVTB 1102R
0.2 0.5
2
PBVTB 1102L
Cat. No.
Dimensions (mm)
Wiper edge
Fig BL
130 F1
Effective length
PBVBW 1102R 1. 0 Yes (2 )1
PBVBW 1102L
PBVBN 1102R 1. 0 No (5 )2
PBVBN 1102L
17.0
6.35
6.35
2.5
CW
20˚ 2.38
30˚
30˚
Fig 1 Fig 2
Sharp
Cat. No. Dimensions (mm) BL
130 F1
Groove depth CDX
Edge width CW
PBVG 1102R-030 0.5 0.3
PBVG 1102L-030
PBVG 1102R-050 1.0 0.5
PBVG 1102L-050
PBVG 1102R-100 2.0 1.0
PBVG 1102L-100
Blank inserts
(1.0)
17.2 (20.14)
1. 0
3.0
17.2
6.35
35˚
6.35
2.38
Fig 1 Fig 2 Fig 3
L
Sharp
Inserts for grooving
CDX
CW
17.0
6.35
6.35
35˚
2.38
Max. depth of cut
Sharp
Inserts for front turning
17.0
6.35
35˚
6.35
10˚
2˚
0.1
5˚
(1.2)
2.38
Fig 1 Fig 2
Sharp Sharp
Inserts for cut-off
0.35±0.03
17.0
6.35
6.35
3.0
1. 0
1. 0
0.35±0.03
60˚ 60˚
2.38
Fig 1 Fig 2
0.35±0.03
Max. depth
2.5
Max. RE0.03
Max. RE0.03
Inserts for back-turning
5˚
0.3
1. 0
50˚
Max. depth
2.0
Max. depth
2.0
2˚
50˚
1. 0
0.1
17.0
6.35
35˚
6.35
2.38
Fig 1 Fig 2
Sharp
Sharp
Inserts for threading
Work material P Carbon steel P
Free-cutting steel
M Stainless steel N
Non-ferrous metal
Cutting speed Vc (m/min) 5–80 5–80 5–50 5–100
Feed rate f (mm/rev) 0.003–0.05
Coolant Oil-base
Recommended Cutting Conditions
Inserts
D10
D
Small Product
Machining
SEC-Wide Tool Holders
SGW Type
Enables efficient roughing of components with long shank
Produces coin-shaped chips that will not tangle with the
machinery or the work piece
Achieves excellent chip control during traverse cutting/
grooving of aluminum alloy
Greatly improves work efficiency through eliminating
problems caused by chips
Stability and long tool life achieved through using high
strength material SUMIDIA DA1000
Features
SUMIDIA Multifunctional Tools With Chipbreakers
SUMIDIA Break Master LD Type
Multifunctional External Machining (Grooving / Traverse cutting)
SGW
General Turning
*
Parts
Cat. No. Stock Height Width Length
Depth of cut
Stem Screw Wrench
H B LF LH2 LH
SGW R1212 12 12 120 7.0 24.5
BFTX0410T8R
1. 1 TRX08
SGW R1616 16 16 120 7.0 24.5
Note: The LF, LH2, and LH dimensions above indicate the dimensions when the carbide insert is attached. (The dimensions for when the SUMIDIA insert is attached is shown in the table below)
Holders (For Torx holes)
Application Examples
Work material: Valve (A6061) Tool Cat. No.: KGV R2004-LD (DA1000)
Cutting conditions: vc = 250 m/min f = 0.10 mm/rev ap = 0.5 mm Wet
9.0
10.0
LD Type + DA1000
Conventional chipbreaker
LF
LH
45˚
CW
BH
LF
LH
45˚
CW
LH2 LH2
Offset: 0Height offset
above center:
0.05
Offset: 0
Height offset
above center:
0.35
When SUMIDIA insert is installed
Note:
Use the SUMIDIA insert
when performing traverse
cutting.
Cat. No.
Coated carbide
Edge width
Length Length
Depth of cut
Stem
Effective
Length
AC1030U
AC530U
CW L LF LH2 LH
KGV R400
4.0 21.0 120 7.0 24.5 6.3
KGV R500
5.0 21.0 120 7.0 24.5 6.3
KGV R600
6.0 21.0 120 7.0 24.5 6.3
Cat. No.
SUMIDIA
Edge width
Length Length
Depth of cut
Stem
Effective
Length
DA1000
CW L LF LH2 LH
KGV R2004-LD
2.0 19.7
118.7
5.7 23.2 4.0
KGV R2504-LD
2.5 19.7
118.7
5.7 23.2 4.0
KGV R2506-LD
2.5 21.2
120.2
7.2 24.7 5.5
Note: The LF, LH2, and LH dimensions above indicate the holder dimensions when the insert is attached.
Inserts (Carbide) Inserts (SUMIDIA)
Recommended Cutting Conditions
8.0
45˚ L
2-RE0.1
CW
6.3
Effective length
8.0 CW
45˚ L
6.3
2-RE0.1
Effective length
Work material PMNN
Grade AC1030U DA1000
Machining details Grooving Grooving Traverse cutting
Rotation speed n (min-1)4,000 6,000 4,500 8,000 4,500 8,000
Feed rate f (mm/rev) 0.05 0.15 0.07 0.15 0.07 0.15
Coolant Wet
Note:
Use caution in regards to the spindle power when using this. If this tool is used with a small lathe, the machine may stop during machining due to insufficient spindle power.
Please use caution especially when machining carbon steel and stainless steel.
Recommended tightening torque (N m) Caution: Re-griding the cutting edges of the SUMIDIA BreakMaster LD type may affect the chip control performance. mark: Standard stock (expanded produ ct)
Dimensions (mm)
Dimensions
(mm)
Dimensions
(mm)
Expanded
D11
D
Small Product
Machining
( Coated carbide / Cermet)
SEC-Mini Tools
SBT Type / PBT Type
SBT
Back Turning
WF
HF
HB
LF
0˚
0˚ Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
H B LF WF HF
SBT35 R1010 10 10
120
2.5 10
BTR35
BFTX0307N
2.0 TRX10
SBT35 R1212 12 12
120
9.5 12
SBT35 R1616 16 16
120
13.5 16
SBT35 R2020 20 20
125
17.5 20
Holders
This figure shows right handed tools.
Back Turning
PBT
Back Turning
HF
HB
LF
0˚
0˚
WF
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Head
Applicable
inserts
Lever
pin
Tightening
bolt
Locking
pin Wrench
H B LF WF HF
HBKL
PBT35 R1010 10 10
120
2.5 10 20
BTR35 LCL09
BTT0407
LP07 TH020
PBT35 R1212 12 12
120
2.5 12
PBT35 R1616 16 16
120
2.5 16
BTT0411
PBT35 R2020 20 20
120
2.5 20
PBT55 R1010 10 10
120
3.7 10 22
BTR55 LCL09
BTT0407
LP07 TH020
PBT55 R1212 12 12
120
3.7 12
PBT55 R1616 16 16
120
3.7 16
BTT0411
PBT55 R2020 20 20
120
3.7 20
PBT80 R1010 10 10
120
5.2 10 25
BTR80 LCL09
BTT0407
LP07 TH020
PBT80 R1212 12 12
120
5.2 12
PBT80 R1616 16 16
120
5.2 16
BTT0411
PBT80 R2020 20 20
120
5.2 20
Holders
Side lever
locking
holders
22
HBKL
HBKL
WF
12
HF
12
L
3.8
4.0
ø6.8
CW
CDX
RE
Inserts
Stock
Dimensions (mm)
Applicable tools
Coated carbide
Cermet
Length
Depth of cut
Edge width
Nose radius
U0301CA
U035CA
051ZCA
A0051T
Cat. No. L
CDX
CW
RE
BT R3505 15 3.5 2.5
0.05
SBT35R
PBT35R
BT R3515 15 3.5 2.5
0.15
BT R5505 19 5.5 3.7
0.05
PBT55R
BT R5515 19 5.5 3.7
0.15
BT R8005 24 8.0 5.2
0.05
PBT80R
BT R8015 24 8.0 5.2
0.15
60
0.5
3
15
Max. depth of cut CDX
Work material P Carbon steel P
Free-cutting steel
M Stainless steel
Tooling Plunging
Traverse cut ting
Plunging
Traverse cut ting
Plunging
Traverse cut ting
Cutting speed v
c
(m/min)
50–150 50–150 50–150
Feed rate f (mm/rev)
0.02–0.05 0.02–0.10 0.02–0.10 0.02–0.15 0.02–0.04 0.02–0.06
Coolant Oil-base
Recommended Cutting Conditions
For PBT R1010
For SBT35 R1010
The amount of tool protrusion can be shortened when attaching to the tool post.
Shank Tolerance of SBT Model / PBT Type
To prevent interference of the cutting edge and tool post, the
tolerance of the shank height (h) is positive (0.1 - 0.3).
Tool
overhang
The shank height (H) is larger than
the cutting edge height (HF)
Toolpost
HF
H
2
20
WF
12
2
20
12
HF
(For Torx holes)
Recommended tightening torque (N m) mark: Standard stock (expanded product)
This figure shows right handed tools.
Dimensions (mm)
Dimensions (mm)
Expanded
D12
D
Small Product
Machining
SEC-Front Turning Tool Holders
SFT Type
Cat. No. Stock Height Width
Length
Cutting edge
distance
Cutting edge
height
Step
Applicable inserts
Screw Wrench
H B LF WF HF HBH
SFT R1010 10 10 120 10 10 3
TFR33 BFTX0410NSW RT08
SFT R1212 12 12 120 12 12 1
SFT R1616 16 16 120 16 16
SFT R2020 20 20 120 20 20
Holders
Parts
General Turning
SFT
LF
HBH
15
BH
WF
HF
3°
6°
0
Front Turning
Cat. No. Stock
Inscribed
circle
Width
of cut
Nose
radius
Applicable holders
IC
60°
0.5
32°
*2
CW
RE
ACZ150 IC CW RE
TF R3300 9.525 4.76
SFT R
TF R3305 9.525 4.76 0.05
TF R3315 9.525 4.76 0.15
TF R3320 9.525 4.76 0.20
Inserts
*1 Maximum cutting amount is 4.0 mm
*2 Indicates the angle when the holder is set
(For Torx holes)
Dimensions (mm)
Dimensions (mm)
D13
D
Small Product
Machining
SEC-Round Shank Holders
RS-SCLL Type
Front Turning
Characteristics
The ø14 to 25 mm shank diameter holders were made into
standard stock items, and are able to fit on sleeve toolposts of
other machine manufacturers.
They also fit on back side sleeve toolposts, expanding the
range of tooling.
Cat. No. Stock
Diameter
Height
Length
Cutting edge
distance
Stem
Applicable inserts
Screw Wrench
DCON
HLFWFLH
RS15H -SCLL06
15.875
15 100 6.0 20
CC 0602
BFTX02507NT
RT08
RS19X -SCLL06 19.05 18 120 6.0 20
RS20X -SCLL06X 20 19 95 6.0 20
RS20X -SCLL06 20 19 120 6.0 20
RS22X -SCLL06 22 21 120 6.0 20
RS25X -SCLL06 25 24 120 6.0 20
RS25M-SCLL06 25.4 24 150 6.0 20
RS15H -SCLL09
15.875
15 100 6.0 20
CC 09T3
BFTX0408NT
LT25NT
RS19X -SCLL09 19.05 18 120 6.0 20
RS20X -SCLL09S 20 19 95 6.0 20
RS20X -SCLL09 20 19 120 6.0 20
RS22X -SCLL09 22 21 120 6.0 20
RS25X -SCLL09 25 24 120 6.0 20
RS25M-SCLL09 25.4 24 150 6.0 20
Holders
Parts
Note: Right handed (R) and neutral (N) inserts are applicable.
RS-SCLL
General Turning
& Profiling
5°
0°
0° 80°
DCON
H
LF
WF
H
0
LH
This figure shows left handed tools.
95˚
95˚
Insert lists
From D20
(For Torx holes)
RT08 LT25NT
Dimensions (mm)
D14
D
Small Product
Machining
SEC-Round Shank Holders
RS-SDUL Type / RS-SDXL Type
Front Turning
Cat. No. Stock
Diameter
Height
Length
Cutting edge
distance
Stem
Applicable inserts
Screw Wrench
DCON
HLFWFLH
RS14F -SDUL07 14 13 80 6.0 20
DC 0702 BFTX02507NT RT08
RS15H -SDUL07
15.875
15 100 6.0 20
RS16F -SDUL07 16 15 80 6.0 20
RS16X -SDUL07 16 15 120 6.0 20
RS19X -SDUL07 19.05 18 120 6.0 20
RS20X -SDUL07S 20 19 95 6.0 20
RS20X -SDUL07 20 19 120 6.0 20
RS22X -SDUL07 22 21 120 6.0 20
RS19X -SDUL11 19.05 18 120 10.0 20
DC 11T3 BFTX0410NT LT25NT
RS20X -SDUL11S 20 19 95 10.0 20
RS20X -SDUL11 20 19 120 10.0 20
RS22X -SDUL11 22 21 120 10.0 20
RS25X -SDUL11 25 24 120 10.0 20
RS25M -SDUL11 25.4 24 150 10.0 20
Holders
Parts
Note: Right handed (R) and neutral (N) inserts are applicable.
Cat. No. Stock
Diameter
Height
Length
Cutting edge
distance
Stem
Applicable inserts
Screw Wrench
DCON
HLFWFLH
RS19X-SDXL11 19.05 18 120 10.0 20
DC 11T3
BFTX0410NT
LT25NT
RS20X-SDXL11S 20 19 95 10.0 20
RS20X-SDXL11 20 19 120 10.0 20
RS25X-SDXL11 25 24 120 10.0 20
Holders
Parts
Note: Right handed (R) and neutral (N) inserts are applicable.
RS-SDUL
General Turning
& Profiling
55°
3°
DCON
H
LF
WF
H
0
0°
0°
LH
RS-SDXL
General Turning
& Profiling
55°
6°
DCON
H
LF
LH
WF
H
0
0°
0°
This figure shows left handed tools.
This figure shows left handed tools.
93˚ 96˚
(For Torx holes)
RT08 LT25NT
(For Torx holes)
Dimensions (mm)
Dimensions (mm)
Insert lists
From D24
Insert lists
From D24
D15
D
Small Product
Machining
SEC-Round Shank Holders
RS-SVXL Type / RS-SVVP Type / RS-PTXN Type
Cat. No. Stock
Diameter
Height
Length
Cutting edge
distance
Stem
Applicable inserts
Screw Wrench
DCON
HLFWFLH
RS15H-SVXL11
15.875
15 100 10.0 20
VC 110 3
BFTX02507NT
RT08
RS19X-SVXL11 19.05 18 120 10.0 20
RS20X-SVXL11S 20 19 95 10.0 20
RS20X-SVXL11 20 19 120 10.0 20
RS22X-SVXL11 22 21 120 10.0 20
RS25X-SVXL11 25.4 24 150 10.0 20
Holders
Parts
Front Turning
Note: Right handed (R) and neutral (N) inserts are applicable.
RS-SVXL
General Turning
& Profiling
9°
DCON
H
LF
LH
WF
H
0
0°
0°
35°
Cat. No. Stock
Diameter
Height Length Stem
Applicable inserts
Screw Wrench
DCON
HLFLH
RS19X-SVVPN11 19.05 18 120 27 VP 1103
BFTX02507NT
RT08
RS22X-SVVPN11 22 21 120 27
Holders
Parts
RS-SVVP
General Turning
& Facing
35°
72.5°
DCON
H
LF
LH
H
0
0°
0°
Cat. No. Stock
Diameter
Height
Length
Cutting edge
distance
Applicable inserts
Lever pin
Bolt Wrench
DCON
HLFWF
RS19X -PTXNL16 19.05 18 120 11.0
TN 1604
LCL33NT
LCS33NT LH020NT
RS20X -PTXNL16 20 19 120 11.0
RS25M -PTXNL16 25.4 24 150 13.0
Holders
Parts
Note: Right handed (R) and neutral (N) inserts are applicable.
General Turning
& Facing
RS-PTXN
−6°
10°
60°
−6°
0
DCON
H
LF
WF
H
This figure shows left handed tools.
This figure shows left handed tools.
1
00°
72.5˚
99˚
Insert lists D32
Insert lists D33
(For Torx holes)
(For Torx holes)
Dimensions (mm)
Dimensions (mm)
Dimensions (mm)
Insert lists
From B56
D16
D
Small Product
Machining
95˚
95˚
91˚
SEC-Mini Tool Holders
Zero Offset Holders
0˚
0˚
95˚
80˚
LF
B
H
WF
HF WF2
SCLC-X
General Turning
& Facing Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Offset Applicable
inserts Screw N m Wrench
R L H B LF WF HF
WF2
SCLC R/L1010-H06X 10 10 100 10 10 0 CC T0602
BFTX02506N
1. 5 TRX08
SCLC R/L1215-K09X 12 15 125 15 12 0 CC T09T3
BFTX0409N
3.4 TRX15
SCLC R/L1215-F09X 12 15 85 15 12 0 CC T09T3
Holders
This figure shows
right handed tools.
SCAC-X
General Turning 0˚
0˚
91˚
80˚
LF
B
H
WF
HF
WF2
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Offset Applicable
inserts Screw N m Wrench
R L H B LF WF HF
WF2
SCAC R/L1010-H06X 10 10 100 10 10 0 CC T0602
BFTX02506N
1. 5 TRX08
SCAC R/L1215-K09X 12 15 125 15 12 0 CC T09T3
BFTX0409N
3.4 TRX15
SCAC R/L1215-F09X 12 15 85 15 12 0 CC T09T3
Holders
This figure shows right
handed tools.
0˚
0˚
22
95˚
80˚
LF
B
H
WF
WF
HF WF2
PCLC-X
General Turning
& Facing
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Offset Applicable
inserts
Lever
Pin
Set Screw
Locking
pin Wrench
R L H B LF WF HF
WF2
PCLC R/L1010-K06X 10 10 125 10 10 0 CC T0602 LCL06
BTT0407
LP07
TH020
PCLC R/L1212-K09X 12 12 125 15 12 0 CC T09T3 LCL09
BTT0411
LP06
PCLC R/L1616-K09X 16 16 125 16 16 0 CC T09T3
Holders
This figure shows right handed tools.
Dimensions (mm)
For PCLC R/L1212-K09X
Side lever
locking
holders
85 mm shank
85 mm shank
(For Torx holes)
(For Torx holes)
0
Offset
zero
0
Offset
zero
0
Offset
zero
Recommended tightening torque (N m)
Dimensions (mm)
Dimensions (mm)
Insert lists
From D20
Insert lists
From D20
Insert lists
From D20
D17
D
Small Product
Machining
93° 91˚ 107.5˚
SEC-Mini Tool Holders
Zero Offset Holders
0˚
0˚
93˚
LF
B
H
WF
HF
55˚
WF2
SDJC-X
General Turning
& Profiling
SDAC-X
General Turning
& Profiling
SDPC-X
Necking
0˚
0˚
91˚
55˚
LF
B
H
WF
HF WF2
0˚
0˚ LF
B
H
HBKW
HF WF
17.5˚
17.5˚
55˚
WF2
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Offset Applicable
inserts Screw N m Wrench
R L H B LF WF HF
WF2
SDJC R/L1010-H07X 10 10 100 10 10 0 DC T0702
BFTX02506N
1. 5 TRX08
SDJC R/L1215-K11X 12 15 125 15 12 0 DC T11T3
BFTX0409N
3.4 TRX15
SDJC R/L1215-F11X 12 15 85 15 12 0 DC T11T3
Holders
This figure shows right
handed tools.
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Offset Applicable
inserts Screw N m Wrench
R L H B LF WF HF
WF2
SDAC R/L1010-H07X 10 10 100 10 10 0 DC T0702
BFTX02506N
1. 5 TRX08
SDAC R/L1215-K11X 12 15 125 15 12 0 DC T11T3
BFTX0409N
3.4 TRX15
SDAC R/L1215-F11X 12 15 85 15 12 0 DC T11T3
Holders
This figure shows right
handed tools.
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Level
difference
Offset
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
HBKW
WF2
SDPC R/L1010-H11X 10 10 100 10 10 10 0 DC T11T3
BFTX0409N
3.4 TRX15
Holder
This figure shows right
handed tools.
0˚
22
0˚
93˚
55˚
LF
B
H
WF
WF
HF WF2
PDJC-X
General Turning
& Profiling
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Offset Applicable
inserts
Lever
Pin
Set Screw
Locking
pin Wrench
R L H B LF WF HF
WF2
PDJC R/L1010-K07X 10 10 125 10 10 0 DC T0702 LCL06
BTT0407
LP04
TH020
PDJC R/L1212-K11X 12 12 125 15 12 0 DC T11T3 LCL09
BTT0411
LP07
PDJC R/L1616-K11X 16 16 125 16 16 0 DC T11T3
Holders
This figure shows right
handed tools.
For PDJC R/L1212-K11X
Side lever
locking
holders
85 mm shank
85 mm shank
(For Torx holes)
(For Torx holes)
(For Torx holes)
0
Offset
zero
0
Offset
zero
0
Offset
zero
0
Offset
zero
Recommended tightening torque (N m)
Dimensions (mm)
Dimensions (mm)
Dimensions (mm)
Dimensions (mm)
Insert lists
From D24
Insert lists
From D24
Insert lists
From D24
Insert lists
From D24
D18
D
Small Product
Machining
SVJC-X
General Turning
& Profiling
0˚
0˚
93˚
35˚
LF
B
H
WF
HF
WF2
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Offset Applicable
inserts Screw N m Wrench
R L H B LF WF HF
WF2
SVJC R/L1010-H11X 10 10 100 10 10 0 VC T1103
BFTX02508NV
1. 5 TRX08
SVJC R/L1212-K11X 12 12 125 12 12 0 VC T1103
SVJC R/L1212-F11X 12 12 85 12 12 0 VC T1103
Holders
This figure shows
right handed tools.
PTXN-X
General Turning
& Facing LF
100˚
60˚
18
17.5
HF
HB
WF
HBKW
-6˚
-6˚
WF2
HBH
Parts
Cat. No.
Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Step
Level
difference
Offset
Applicable
inserts Lever pin Bolt Wrench
H B LF WF HF
HBH
HBKW
WF2
PTXN R1016-X16X 10 16 120 20 10 2 4 0 TN 1604
LCL33NT LCS33NT LH020NT
PTXN R1216-X16X 12 16 120 20 12 0 4 0 TN 1604
PTXN R1616-X16X 16 16 120 20 16 0 4 0 TN 1604
PTXN R2020-X16X 20 20 120 20 20 0 0 0 TN 1604
Holders
SEC-Mini Tool Holders
Zero Offset Holders
85 mm shank
93° 100˚
Insert lists D32
(For Torx holes)
0
Offset
zero
0
Offset
zero
Recommended tightening torque (N m)
Dimensions (mm)
Dimensions (mm)
Insert lists
From B56
D19
D
Small Product
Machining
PCLC
General Turning
& Facing
SCLC
General Turning
& Facing
SCAC
General Turning
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts
Lever
Pin
Set screw
Locking
pin Wrench
R L H B LF WF HF
PCLC R/L0810-K06 8 10 125 10.5 8 CC 0602 LCL06
BTT0407
LP07
TH020
PCLC R/L1010-K06 10 10 125 10.5 10 CC 0602
PCLC R/L1212-M09 12 12 150 12.5 12 CC 09T3
LCL09 LP06
PCLC R/L1616-M09 16 16 150 16.5 16 CC 09T3
BTT0411
PCLC R/L2020-M09 20 20 150 20.5 20 CC 09T3
Holders
This figure shows right
handed tools.
General Turning
95
˚
80
˚
WFHF
BH
LF
0
˚
0
˚
WFHF
B
H
LF
0
˚
0
˚
91
˚
80
˚
HF
LF
B
H
95
˚
80
˚
WF
0
˚
0
˚
17
For PCLC R/L0810-K06
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
SCLC R/L0808-06 8 8 100 10 8 CC 0602
BFTX02506N
1. 5 TRX08
SCLC R/L1010-06 10 10 100 12 10 CC 0602
SCLC R/L1212-09 12 12 100 16 12 CC 09T3
BFTX0409N
3.4 TRX15
SCLC R/L1616-09 16 16 100 20 16 CC 09T3
SCLC R/L2020-09 20 20 125 24 20 CC 09T3
Holders
This figure shows right
handed tools.
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
SCAC R/L0808-06 8 8 100 8.5 8 CC 0602
BFTX02506N
1. 5 TRX08
SCAC R/L1010-06 10 10 100 10.5 10 CC 0602
SCAC R/L1212-09 12 12 100 12.5 12 CC 09T3
BFTX0409N
3.4 TRX15
SCAC R/L1616-09 16 16 100 16.5 16 CC 09T3
SCAC R/L2020-09 20 20 125 20.5 20 CC 09T3
Holders
This figure shows right
handed tools.
Side lever
locking
holders
(For Torx holes)
(For Torx holes)
SEC-Mini Tool Holders
PC Type / SC Type
95˚
95˚
91˚
Dimensions (mm)
Dimensions (mm)
Dimensions (mm)
Recommended tightening torque (N m)
D20
D
Small Product
Machining
Inserts ( Coated carbide / Cermet / Carbide)
CCGT Stock Dimensions (mm)
AC1030U
AC530U
ACZ150
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FC
Cat. No.
CCGT 060201MN-FC
6.35 2.38
0.1
060202MN-FC
0.2
060204MN-FC
0.4
CCGT 09T301MN-FC
9.525 3.97
0.1
09T302MN-FC
0.2
09T304MN-FC
0.4
Nose radii RE with a sign "<" indicate negative tolerances.
7 Positive G Class
7 Positive G Class
CCGT Stock Dimensions (mm)
AC1030U
AC530U
T1500Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FX
Cat. No.
CCGT 0602003R-FX
6.35 2.38
0.03
0602003L-FX
0.03
060201R -FX
0.1
060201L -FX
0.1
060202R -FX
0.2
060202L -FX
0.2
060204R -FX
0.4
060204L -FX
0.4
CCGT 09T3003R-FX
9.525 3.97
0.03
09T3003L-FX
0.03
09T301R -FX
0.1
09T301L -FX
0.1
09T302R -FX
0.2
09T302L -FX
0.2
09T304R -FX
0.4
09T304L -FX
0.4
09T308R -FX
0.8
09T308L -FX
0.8
CCGT Dimensions (mm)
AC610M
AC630M
AC510U
AC520U
AC1030U
AC530U
T1500Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
SI
Cat. No.
CCGT 09T301MN-SI
9.525 3.97
0.1
09T302MN-SI
0.2
09T304MN-SI
0.4
Nose radii RE with a sign "<" indicate negative tolerances.
CCGT Stock Dimensions (mm)
H1
Inscribed
circle
Thickness
Nose radius
AG
Cat. No.
CCGT 060202N-AG
6.35 2.38 0.2
060204N-AG
0.4
CCGT 09T302N-AG
9.525 3.97
0.2
09T304N-AG
0.4
09T308N-AG
0.8
CCGT Stock Dimensions (mm)
H1
Inscribed
circle
Thickness
Nose radius
AY
Cat. No.
CCGT 060201R-AY
6.35 2.38
0.1
060201L-AY
0.1
060202R-AY
0.2
060202L-AY
0.2
060204R-AY
0.4
060204L-AY
0.4
CCGT 09T301R-AY
9.525 3.97
0.1
09T301L-AY
0.1
09T302R-AY
0.2
09T302L-AY
0.2
09T304R-AY
0.4
09T304L-AY
0.4
7 Positive E Class
CCET Stock Dimensions (mm)
ACZ150
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FY
Cat. No.
CCET 0602003R-FY
6.35 2.38
0.03
0602003L-FY
0.03
060201R -FY
0.1
060201L -FY
0.1
060202R -FY
0.2
060202L -FY
0.2
060204R -FY
0.4
060204L -FY
0.4
CCET 09T3003R-FY
9.525 3.97
0.03
09T3003L-FY
0.03
09T301R -FY
0.1
09T301L -FY
0.1
09T302R -FY
0.2
09T302L -FY
0.2
09T304R -FY
0.4
09T304L -FY
0.4
CCET Stock Dimensions (mm)
ACZ150
Inscribed
circle
Thickness
Nose radius
FX
Cat. No.
CCET 0602003R-FX
6.35 2.38
0.03
0602003L-FX
0.03
060201R -FX
0.1
060201L -FX
0.1
060202R -FX
0.2
060202L -FX
0.2
060204R -FX
0.4
060204L -FX
0.4
CCET 09T3003R-FX
9.525 3.97
0.03
09T3003L-FX
0.03
09T301R -FX
0.1
09T301L -FX
0.1
09T302R -FX
0.2
09T302L -FX
0.2
09T304R -FX
0.4
09T304L -FX
0.4
SEC-Mini Tool Holders
PC Type / SC Type
CCGT Stock Dimensions (mm)
AC1030U
AC530U
ACZ150
T1500Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
SC
Cat. No.
CCGT 0602003N-SC
6.35 2.38
0.03
09T3003N-SC
9.525 3.97
0.03
CCGT 060201MN-SC
6.35 2.38
0.1
060202MN-SC
0.2
060204MN-SC
0.4
CCGT 09T301MN-SC
9.525 3.97
0.1
09T302MN-SC
0.2
Nose radii RE with a sign "<" indicate negative tolerances.
D21
D
Small Product
Machining
2NU-
CCGW
Stock Dimensions (mm)
BN2000
BN7000
BN7500
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
2NU-CCGW 060204
6.35 2.38 0.4
2NU-CCGW 09T304
9.525 3.97
0.4
09T308
0.8
09T304WG
0.4
09T308WG
0.8
09T304WH
0.4
09T308WH
0.8
Note: The part number suffixes stand for the following: WG/WH: Wiper insert
SEC-Mini Tool Holders
PC Type / SC Type
CCMT
Stock Dimensions (mm)
AC530U
T1500Z
T3000Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FB
Cat. No.
CCMT 060202N-FB
6.35 2.38 0.2
060204N-FB
0.4
CCMT 09T302N-FB
9.525 3.97
0.2
09T304N-FB
0.4
09T308N-FB
0.8
CCMT
Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC630M
AC6030M
AC6040M
AC530U
T1500Z
T3000Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
LU
Cat. No.
CCMT 060202N-LU
6.35 2.38 0.2
060204N-LU
0.4
CCMT 09T304N-LU
9.525 3.97 0.4
09T308N-LU
0.8
Inserts ( Coated carbide / Cermet / Carbide / SUMIBORON)
7 Positive M Class 7 Positive M Class
CCMT Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC630M
T1500Z
T3000Z
T1500A
Inscribed
circle
Thickness
Nose radius
LUW
Cat. No.
CCMT 09T304N-LUW
9.525 3.97 0.4
09T308N-LUW
0.8
CCMT Stock Dimensions (mm)
AC820P
AC8025P
AC830P
AC6020M
AC6030M
AC6040M
T1500Z
T3000Z
T1500A
Inscribed
circle
Thickness
Nose radius
LB
Cat. No.
CCMT 060202N-LB
6.35 2.38
0.2
060204N-LB
0.4
060208N-LB
0.8
CCMT 09T302N-LB
9.525 3.97
0.2
09T304N-LB
0.4
09T308N-LB
0.8
CCMT Stock Dimensions (mm)
T1500A
Inscribed
circle
Thickness
Nose radius
FP
Cat. No.
CCMT 060202N-FP
6.35 2.38 0.2
060208N-FP
0.8
CCMT 09T302N-FP
9.525 3.97 0.2
09T304N-FP
0.4
CCMT
Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC830P
AC610M
AC630M
AC6020M
AC6030M
AC6040M
AC520U
AC530U
T1500Z
T3000Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
SU
Cat. No.
CCMT 060202N-SU
6.35 2.38
0.2
060204N-SU
0.4
060208N-SU
0.8
CCMT 09T302N-SU
9.525 3.97
0.2
09T304N-SU
0.4
09T308N-SU
0.8
CCMT Stock Dimensions (mm)
AC820P
AC8025P
A30
Inscribed
circle
Thickness
Nose radius
SC
Cat. No.
CCMT 060204N-SC
6.35 2.38 0.4
CCMT Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC830P
AC630M
AC6020M
AC6030M
AC405K
AC415K
AC420K
Inscribed
circle
Thickness
Nose radius
MU
Cat. No.
CCMT 09T304N-MU
9.525 3.97 0.4
09T308N-MU
0.8
CCMW
Stock Dimensions (mm)
AC405K
AC415K
AC420K
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
CCMW 060204
6.35 2.38 0.4
CCMW 09T304
9.525 3.97 0.4
09T308
0.8
Wiper
NU-
CCGW
Stock Dimensions (mm)
BN1000
BN2000
BN7000
BN700
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
NU-CCGW 060202
6.35 2.38
0.2
060204
0.4
060208
0.8
060202LT
0.2
060204LT
0.4
060208LT
0.8
060202HS
0.2
060204HS
0.4
NU-CCGW 09T302
9.525 3.97
0.2
09T304
0.4
09T308
0.8
09T302LT
0.2
09T304LT
0.4
09T308LT
0.8
09T302HS
0.2
09T304HS
0.4
09T308HS
0.8
Note: The part number suffixes stand for the following:
LE: Sharp edge type W: Wiper insert LFW: Wiper insert with sharp edge
7 Positive G Class
SUMIBORON One Use Inserts (Non-Coated)
( mark: Only packages containing one piece are in stock, mark: Packages containing
one piece and packages containing 10 pieces are in stock) SUMIBORON Multi Corner One Use Inserts (Non-Coated)
2NU-
CCGT
Stock Dimensions (mm)
BN2000
Inscribed
circle
Thickness
Nose radius
FV/LV
Cat. No.
2NU-CCGT 060204N-FV
6.35 2.38 0.4
2NU-CCGT 09T304N-FV
9.525 3.97
0.4
09T308N-FV
0.8
09T304N-LV
0.4
09T308N-LV
0.8
SUMIBORON Break Master (Non-Coated)
D22
D
Small Product
Machining
SEC-Mini Tool Holders
PC Type / SC Type
Inserts (Coated carbide / Cermet / Carbide / SUMIBORON / SUMIDIA)
2NC-
CCGW
Stock Dimensions (mm)
BNC2010
BNC2020
BNC300
BNC100
BNC160
BNC200
BNC500
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
2NC-CCGW 060202
6.35 2.38
0.2
060204
0.4
060208
0.8
060202LE
0.2
060204LE
0.4
060202LT
0.2
060204LT
0.4
060202LS
0.2
060204LS
0.4
2NC-CCGW 09T302
9.525 3.97
0.2
09T304
0.4
09T308
0.8
09T304WG
0.4
09T308WG
0.8
09T304WH
0.4
09T308WH
0.8
09T302LE
0.2
09T304LE
0.4
09T308LE
0.8
09T302LT
0.2
09T304LT
0.4
09T308LT
0.8
09T302LS
0.2
09T304LS
0.4
09T308LS
0.8
09T304HS
0.4
09T308HS
0.8
Note: The part number suffixes stand for the following:
WG/WH: Wiper insert LE: Low resistance type LT/LS: Cutting performance focused type HS: Strengthened cutting edge type
7 Positive G Class
SUMIBORON Multi Corner One Use Inserts (Coated)
NF-
CCMT
Stock Dimensions (mm)
DA1000
DA2200
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
NF-CCMT 060201
6.35 2.38
0.1
060202
0.2
060204
0.4
NF-CCMT 09T301
9.525 3.97
0.1
09T302
0.2
09T304
0.4
09T308
0.8
7 Positive M Class
SUMIDIA NF Inserts
NU-
CCMT
Stock Dimensions (mm)
DA150
Inscribed
circle
Thickness
Nose radius
DM
Cat. No.
NU-CCMT 060202R -DM
6.35 2.38
0.2
060202L -DM
0.2
060204R -DM
0.4
060204L -DM
0.4
NU-CCMT 09T302R -DM
9.525 3.97
0.2
09T302L -DM
0.2
09T304R -DM
0.4
09T304L -DM
0.4
SUMIDIA Break Master
CCMT Stock Dimensions (mm)
DA150
DA2200
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
CCMT 060201
6.35 2.38
0.1
060202
0.2
060204
0.4
CCMT 09T301
9.525 3.97
0.1
09T302
0.2
09T304
0.4
SUMIDIA
CCMW
Stock Dimensions (mm)
NPD10
Inscribed
circle
Thickness
Nose radius
RH
Cat. No.
CCMW 060202RH
6.35 2.38 0.2
060204RH
0.4
CCMW 09T302RH
9.525 3.97
0.2
09T304RH
0.4
09T308RH
0.8
SUMIDIA Binderless
mark: To be replaced by a new item, shifted to made-to-order production, discontinued, etc. (Confirm the stock availability.)
2NC-
CCGT
Stock Dimensions (mm)
BNC2010
BNC2020
BNC160
BNC200
Inscribed
circle
Thickness
Nose radius
FV/LV
Cat. No.
2NC-CCGT 060204N-FV
6.35 2.38 0.4
2NC-CCGT 09T304N-FV
9.525 3.97
0.4
09T308N-FV
0.8
09T304N-LV
0.4
09T308N-LV
0.8
SUMIBORON Break Master (Coated)
NF
CCMT
Stock Dimensions (mm)
DA1000
Inscribed
circle
Thickness
Nose radius
LD/GD
Cat. No.
NF-CCMT 060202N-LD
6.35 2.38
0.2
060204N-LD
0.4
060202N-GD
0.2
060204N-GD
0.4
NF-CCMT 09T302N-LD
9.525 3.97
0.2
09T304N-LD
0.4
09T308N-LD
0.8
09T302N-GD
0.2
09T304N-GD
0.4
09T308N-GD
0.8
D23
D
Small Product
Machining
PDJC
General Turning
& Profiling
SDJC
General Turning
& Profiling
SDAC
General Turning
& Profiling
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts
Lever
pin
Set
screw
Locking
pin Wrench
R L H B LF WF HF
PDJC R/L0810-K07 8 10 125 10.5 8 DC 0702 LCL06
BTT0407
LP04
TH020
PDJC R/L1010-K07 10 10 125 10.5 10 DC 0702
PDJC R/L1212-M11 12 12 150 12.5 12 DC 11T3
LCL09 LP07
PDJC R/L1616-M11 16 16 150 16.5 16 DC 11T3
BTT0411
PDJC R/L2020-M11 20 20 150 20.5 20 DC 11T3
Holders
This figure shows right
handed tools.
SDNC
General Turning
& Profiling
93
˚
55
˚
WF
B
HF
H
LF
0
˚
0
˚
91
˚
55
˚
WF
HF
BH
LF
0
˚
0
˚
62.5
˚
55
˚
WF
HF
BH
LF
0
˚
0
˚
93
˚
55
˚
WF
B
HF
H
LF
0
˚
0
˚
17
For PDJC R/L0810-K07
SDNC N1616
For SDNC N2020
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
SDJC R/L0808-07 8 8 100 10 8 DC 0702
BFTX02506N
1. 5 TRX08
SDJC R/L1010-07 10 10 100 12 10 DC 0702
SDJC R/L1212-11 12 12 100 16 12 DC 11T3
BFTX0409N
3.4 TRX15
SDJC R/L1616-11 16 16 100 20 16 DC 11T3
SDJC R/L2020-11 20 20 125 24 20 DC 11T3
Holders
This figure shows right
handed tools.
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
SDAC R/L0808-07 8 8 100 8.5 8 DC 0702
BFTX02506N
1. 5 TRX08
SDAC R/L1010-07 10 10 100 10.5 10 DC 0702
SDAC R/L1212-11 12 12 100 12.5 12 DC 11T3
BFTX0409N
3.4 TRX15
SDAC R/L1616-11 16 16 100 16.5 16 DC 11T3
SDAC R/L2020-11 20 20 125 20.5 20 DC 11T3
Holders
This figure shows right
handed tools.
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
H B LF WF HF
SDNC N0808-07 8 8 100 4 8 DC 0702
BFTX02506N
1. 5 TRX08
SDNC N1010-07 10 10 100 5 10 DC 0702
SDNC N1212-11 12 12 100 6 12 DC 11T3
BFTX0409N
3.4 TRX15
SDNC N1616-11 16 16 100 8 16 DC 11T3
SDNC N2020-11 20 20 125 10 20 DC 11T3
Holders
Side lever
locking
holders
(For Torx holes)
(For Torx holes)
(For Torx holes)
SEC-Mini Tool Holders
PD Type / SD Type (7 Positive)
93° 62.5˚
91˚
Dimensions (mm)
Dimensions (mm)
Dimensions (mm)
Dimensions (mm)
Recommended tightening torque (N m)
General Turning and Profiling
D24
D
Small Product
Machining
DCET Stock Dimensions (mm)
ACZ150
Inscribed
circle
Thickness
Nose radius
FX
Cat. No.
DCET 0702003R -FX
6.35 2.38
0.03
0702003L -FX
0.03
0702008R -FX
0.08
0702008L -FX
0.08
070201R-FX
0.1
070201L-FX
0.1
0702018R -FX
0.18
0702018L -FX
0.18
070204R-FX
0.4
070204L-FX
0.4
DCET 11T3003R -FX
9.525 3.97
0.03
11T3003L -FX
0.03
11T3008R -FX
0.08
11T3008L -FX
0.08
11T301R-FX
0.1
11T301L-FX
0.1
11T3018R -FX
0.18
11T3018L -FX
0.18
11T304R-FX
0.4
11T304L-FX
0.4
Inserts (Coated carbide / Cermet)
7 Positive E Class 7 Positive G Class
DCGT Stock Dimensions (mm)
AC520U
AC1030U
AC530U
T1500Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FX
Cat. No.
DCGT 0702003R-FX
6.35 2.38
0.03
0702003L-FX
0.03
070201R -FX
0.1
070201L -FX
0.1
070202R -FX
0.2
070202L -FX
0.2
070204R-FX
0.4
070204L-FX
0.4
DCGT 11T3003R-FX
9.525 3.97
0.03
11T3003L-FX
0.03
11T301R -FX
0.1
11T301L -FX
0.1
11T302R -FX
0.2
11T302L -FX
0.2
11T304R -FX
0.4
11T304L -FX
0.4
DCGT Stock Dimensions (mm)
AC1030U
Inscribed
circle
Thickness
Nose radius
FYS
Cat. No.
DCGT 0702003R-FYS
6.35 2.38
0.03
0702003L-FYS
0.03
070201R-FYS
0.1
070201L-FYS
0.1
070202R-FYS
0.2
070202L-FYS
0.2
070204R-FYS
0.4
070204L-FYS
0.4
DCGT 11T3003R-FYS
9.525 3.97
0.03
11T3003L-FYS
0.03
11T301R-FYS
0.1
11T301L-FYS
0.1
11T302R-FYS
0.2
11T302L-FYS
0.2
11T304R-FYS
0.4
11T304L-FYS
0.4
DCET Stock Dimensions (mm)
ACZ150
Inscribed
circle
Thickness
Nose radius
FY
Cat. No.
DCET 0702003R -FY
6.35 2.38
0.03
0702003L -FY
0.03
0702008R -FY
0.08
0702008L -FY
0.08
070201R-FY
0.1
070201L-FY
0.1
0702018R -FY
0.18
0702018L -FY
0.18
070204R-FY
0.4
070204L-FY
0.4
DCET 11T3003R -FY
9.525 3.97
0.03
11T3003L -FY
0.03
11T3008R -FY
0.08
11T3008L -FY
0.08
11T301R-FY
0.1
11T301L-FY
0.1
11T3018R -FY
0.18
11T3018L -FY
0.18
11T304R-FY
0.4
11T304L-FY
0.4
DCGT Stock Dimensions (mm)
AC520U
AC1030U
AC530U
ACZ150
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FC
Cat. No.
DCGT 070201MN-FC
6.35 2.38
0.1
070202MN-FC
0.2
070204MN-FC
0.4
DCGT 11T301MN-FC
9.525 3.97
0.1
11T302MN-FC
0.2
11T304MN-FC
0.4
Nose radii RE with a sign "<" indicate negative tolerances.
7 Positive G Class
DCGT Stock Dimensions (mm)
AC520U
AC1030U
AC530U
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FY
Cat. No.
DCGT 0702003R-FY
6.35 2.38
0.03
0702003L-FY
0.03
070201R -FY
0.1
070201L -FY
0.1
070202R -FY
0.2
070202L -FY
0.2
070204R -FY
0.4
070204L -FY
0.4
DCGT 11T3003R-FY
9.525 3.97
0.03
11T3003L-FY
0.03
11T301R -FY
0.1
11T301L -FY
0.1
11T302R -FY
0.2
11T302L -FY
0.2
11T304R -FY
0.4
11T304L -FY
0.4
SEC-Mini Tool Holders
PD Type / SD Type
D25
D
Small Product
Machining
Inserts (Coated carbide / Cermet / Carbide)
7 Positive G Class 7 Positive G Class
DCGT Stock Dimensions (mm)
AC1030U
AC530U
ACZ150
T1500Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
SC
Cat. No.
DCGT 0702003N-SC
6.35 2.38
0.03
070201MN-SC
0.1
070202MN-SC
0.2
070204MN-SC
0.4
DCGT 11T3003N-SC
9.525 3.97
0.03
11T301MN-SC
0.1
11T302MN-SC
0.2
11T304MN-SC
0.4
11T308MN-SC
0.8
Nose radii RE with a sign "<" indicate negative tolerances.
DCGT Stock Dimensions (mm)
H1
Inscribed
circle
Thickness
Nose radius
AG
Cat. No.
DCGT 070202N-AG
6.35 2.38 0.2
070204N-AG
0.4
DCGT 11T302N-AG
9.525 3.97
0.2
11T304N-AG
0.4
11T308N-AG
0.8
DCGT Stock Dimensions (mm)
H1
Inscribed
circle
Thickness
Nose radius
AY
Cat. No.
DCGT 070201R-AY
6.35 2.38
0.1
070201L-AY
0.1
070202R-AY
0.2
070202L-AY
0.2
070204R-AY
0.4
070204L-AY
0.4
DCGT 11T301R-AY
9.525 3.97
0.1
11T301L-AY
0.1
11T302R-AY
0.2
11T302L-AY
0.2
11T304R-AY
0.4
11T304L-AY
0.4
DCGW
Stock Dimensions (mm)
AC503U
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
DCGW 070202
6.35 2.38
0.2
070204
0.4
070208
0.8
DCGW 11T302
9.525 3.97
0.2
11T304
0.4
11T308
0.8
DCMT
Stock Dimensions (mm)
AC530U
T1500Z
T3000Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FB
Cat. No.
DCMT 070202N-FB
6.35 2.38
0.2
070204N-FB
0.4
070208N-FB
0.8
DCMT 11T302N-FB
9.525 3.97
0.2
11T304N-FB
0.4
11T308N-FB
0.8
7 Positive M Class
SEC-Mini Tool Holders
PD Type / SD Type
DCMT
Stock Dimensions (mm)
AC820P
AC8025P
AC830P
AC6020M
AC6030M
AC6040M
T1500Z
T3000Z
T1500A
Inscribed
circle
Thickness
Nose radius
LB
Cat. No.
DCMT 070202N-LB
6.35 2.38
0.2
070204N-LB
0.4
070208N-LB
0.8
DCMT 11T302N-LB
9.525 3.97
0.2
11T304N-LB
0.4
11T308N-LB
0.8
DCMT
Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC830P
AC610M
AC630M
AC6020M
AC6030M
AC6040M
AC530U
T1500Z
T3000Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
SU
Cat. No.
DCMT 070202N-SU
6.35 2.38
0.2
070204N-SU
0.4
070208N-SU
0.8
DCMT 11T302N-SU
9.525 3.97
0.2
11T304N-SU
0.4
11T308N-SU
0.8
DCMT
Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC630M
AC6030M
AC6040M
AC530U
T1500Z
T3000Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
LU
Cat. No.
DCMT 070202N-LU
6.35 2.38 0.2
070204N-LU
0.4
DCMT 11T302N-LU
9.525 3.97
0.2
11T304N-LU
0.4
11T308N-LU
0.8
DCMT
Stock Dimensions (mm)
T1500A
Inscribed
circle
Thickness
Nose radius
FP
Cat. No.
DCMT 070202N-FP
6.35 2.38 0.2
070204N-FP
0.4
DCMT 11T308N-FP
9.525 3.97 0.8
DCGT Stock Dimensions (mm)
T1500Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
SD
Cat. No.
DCGT 070202R -SD
6.35 2.38
0.2
070202L -SD
0.2
070204R -SD
0.4
070204L -SD
0.4
DCGT 11T304R -SD
9.525 3.97
0.4
11T304L -SD
0.4
11T308R -SD
0.8
11T308L -SD
0.8
DCGT Stock Dimensions (mm)
AC610M
AC630M
AC510U
AC520U
AC1030U
AC530U
T1500Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
SI
Cat. No.
DCGT 070201MN-SI
6.35 2.38
0.1
070202MN-SI
0.2
070204MN-SI
0.4
DCGT 11T301MN-SI
9.525 3.97
0.1
11T302MN-SI
0.2
11T304MN-SI
0.4
11T308MN-SI
0.8
Nose radii RE with a sign "<" indicate negative tolerances.
D26
D
Small Product
Machining
SEC-Mini Tool Holders
PD Type / SD Type
Inserts (Coated carbide / Cermet / Carbide / SUMIBORON / SUMIDIA)
NU-
DCGW
Stock Dimensions (mm)
BN1000
BN2000
BN7000
BN700
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
NU-DCGW 070202
6.35 2.38
0.2
070204
0.4
070208
0.8
070202LT
0.2
070204LT
0.4
070208LT
0.8
070202HS
0.2
070204HS
0.4
NU-DCGW 11T302
9.525 3.97
0.2
11T304
0.4
11T308
0.8
11T312
1. 2
11T302LF
0.2
11T304LF
0.4
11T302LT
0.2
11T304LT
0.4
11T308LT
0.8
11T312LT
1. 2
11T302HS
0.2
11T304HS
0.4
11T308HS
0.8
Note: The part number suffixes stand for the following:
LF: Sharp edge LT: Cutting performance focused type LS: Continuous cut general purpose type HS: Strengthened cutting edge type
SUMIBORON One Use Inserts (Non-Coated)
( mark: Only packages containing one piece are in stock, A mark: Packages containing one piece and packages containing 10 pieces are in stock)
2NU-
DCGW
Stock Dimensions (mm)
BN2000
BN7000
BN7500
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
2NU-DCGW 070204
6.35 2.38 0.4
070208
0.8
2NU-DCGW 11T302
9.525 3.97
0.2
11T304
0.4
11T308
0.8
11T304WG
0.4
11T308WG
0.8
11T304WH
0.4
11T308WH
0.8
11T302LF
0.2
11T304LF
0.4
11T308LF
0.8
11T302LE
0.2
11T304LE
0.4
11T308LE
0.8
11T302LS
0.2
11T304LS
0.4
11T308LS
0.8
Note: The part number suffixes stand for the following:
WG/WH: Wiper insert LF/LE: Sharp edge LS: Continuous cut general purpose type
SUMIBORON Multi Corner One Use Inserts (Non-Coated)
2NU-
DCGT
Stock Dimensions (mm)
BN2000
Inscribed
circle
Thickness
Nose radius
FV/LV
Cat. No.
2NU-DCGT 070204N-FV
6.35 2.38 0.4
2NU-DCGT 11T304N-FV
9.525 3.97
0.4
11T308N-FV
0.8
11T304N-LV
0.4
11T308N-LV
0.8
SUMIBORON Break Master (Non-Coated)
DCMT
Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC830P
AC630M
AC6020M
AC6030M
AC405K
AC415K
AC420K
Inscribed
circle
Thickness
Nose radius
MU
Cat. No.
DCMT 11T304N-MU
9.525 3.97 0.4
11T308N-MU
0.8
DCMW
Stock Dimensions (mm)
AC405K
AC415K
AC420K
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
DCMW 070204
6.35 2.38 0.4
070208
0.8
DCMW 11T304
9.525 3.97 0.4
11T308
0.8
7 Positive M Class
D27
D
Small Product
Machining
SEC-Mini Tool Holders
PD Type / SD Type
Inserts (Coated carbide / Cermet / Carbide / SUMIBORON / SUMIDIA)
2NC-
DCGW
Stock Dimensions (mm)
BNC2010
BNC2020
BNC300
BNC100
BNC160
BNC200
BNC500
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
2NC-DCGW 070202
6.35 2.38
0.2
070204
0.4
070202LS
0.2
070204LS
0.4
2NC-DCGW 11T302
9.525 3.97
0.2
11T304
0.4
11T308
0.8
11T304WG
0.4
11T308WG
0.8
11T304WH
0.4
11T308WH
0.8
2NC-DCGW 11T302LE
9.525 3.18
0.2
11T304LE
0.4
11T308LE
0.8
11T302LT
0.2
11T304LT
0.4
11T308LT
0.8
2NC-DCGW 11T302LS
9.525 3.97
0.2
11T304LS
0.4
11T308LS
0.8
11T304HS
0.4
11T308HS
0.8
Note: The part number suffixes stand for the following:
WG/WH: Wiper insert LE: Low resistance type LT/LS: Cutting performance focused type HS: Strengthened cutting edge type
SUMIBORON Multi Corner One Use Inserts (Coated)
mark: To be replaced by a new item, shifted to made-to-order production, discontinued, etc. (Confirm the stock availability.)
2NC-
DCGT
Stock Dimensions (mm)
BNC2010
BNC2020
BNC160
BNC200
Inscribed
circle
Thickness
Nose radius
FV/LV
Cat. No.
2NC-DCGT 070204N-FV
6.35 2.38 0.4
11T304N-FV
9.525 3.97
0.4
11T308N-FV
0.8
11T304N-LV
0.4
11T308N-LV
0.8
SUMIBORON Break Master (Coated)
NF
DCMT
Stock Dimensions (mm)
DA1000
DA2200
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
NF-DCMT 070201
6.35 2.38
0.1
070202
0.2
070204
0.4
NF-DCMT 11T301
9.525 3.97
0.1
11T302
0.2
11T304
0.4
11T308
0.8
SUMIDIA NF Inserts
NU-
DCMT
Stock Dimensions (mm)
DA150
Inscribed
circle
Thickness
Nose radius
DM
Cat. No.
NU-DCMT 070202R -DM
6.35 2.38
0.2
070202L -DM
0.2
070204R -DM
0.4
070204L -DM
0.4
NU-DCMT 11T302R -DM
9.525 3.97
0.2
11T302L -DM
0.2
11T304R -DM
0.4
11T304L -DM
0.4
NF
DCMT
Stock Dimensions (mm)
DA1000
Inscribed
circle
Thickness
Nose radius
LD/GD
Cat. No.
NF-DCMT 070202N-LD
6.35 2.38
0.2
070204N-LD
0.4
070202N-GD
0.2
070204N-GD
0.4
NF-DCMT 11T302N-LD
9.525 3.97
0.2
11T304N-LD
0.4
11T308N-LD
0.8
11T302N-GD
0.2
11T304N-GD
0.4
11T308N-GD
0.8
SUMIDIA Break Master
DCMT Stock Dimensions (mm)
DA150
DA2200
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
DCMT 070201
6.35 2.38
0.1
070202
0.2
070204
0.4
DCMT 11T301
9.525 3.97
0.1
11T302
0.2
11T304
0.4
SUMIDIA
DCMW
Stock Dimensions (mm)
NPD10
Inscribed
circle
Thickness
Nose radius
RH
Cat. No.
DCMW 070202RH
6.35 2.38 0.2
070204RH
0.4
DCMW 11T302RH
9.525 3.97
0.2
11T304RH
0.4
11T308RH
0.8
SUMIDIA Binderless
D28
D
Small Product
Machining
SEC-Mini Tool Holders
SS Type 75˚
SSBC
General Turning
General Turning
0˚
0˚
LF
WF
HF
75˚
90˚
BH
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
SSBC R/L1010-07 10 10 100 9 10 SC 0702
BFTX0307N
2.0 TRX10
SSBC R/L1212-09 12 12 100 11 12 SC 09T3
BFTX0409N
3.4 TRX15
SSBC R/L1616-09 16 16 100 15 16 SC 09T3
SSBC R/L2020-09 20 20 125 19 20 SC 09T3
Holders
This figure shows right
handed tools.
SCGT Stock Dimensions (mm)
AC1030U
AC530U
Inscribed
circle
Thickness
Nose radius
FX
Cat. No.
SCGT 09T302R-FX
9.525 3.97
0.2
09T302L-FX
0.2
09T304R-FX
0.4
09T304L-FX
0.4
Inserts (Coated carbide / Cermet / SUMIDIA)
7 Positive G Class
SCMT Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC830P
AC610M
AC630M
AC6020M
AC6030M
AC6040M
Inscribed
circle
Thickness
Nose radius
SU
Cat. No.
SCMT 09T304N-SU
9.525 3.97 0.4
09T308N-SU
0.8
7 Positive M Class
SCGT Stock Dimensions (mm)
AC1030U
AC530U
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
SC
Cat. No.
SCGT 070201MN-SC
7.94 2.38 0.1
070202MN-SC
0.2
SCGT 09T301MN-SC
9.525 3.97 0.1
09T302MN-SC
0.2
Nose radii RE with a sign "<" indicate negative tolerances.
SCMT Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC630M
AC6020M
AC6030M
AC405K
AC415K
AC420K
Inscribed
circle
Thickness
Nose radius
MU
Cat. No.
SCMT 09T308N-MU
9.525 3.97 0.8
SCMW
Stock Dimensions (mm)
AC405K
AC415K
AC420K
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
SCMW 09T308
9.525 3.97 0.8
SCMT Stock Dimensions (mm)
DA150
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
SCMT 070201
7.94 2.38
0.1
070202
0.2
070204
0.4
SUMIDIA
NF-
SCMT
Stock Dimensions (mm)
DA1000
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
NF-SCMT 070201
7.94 2.38
0.1
070202
0.2
070204
0.4
SUMIDIA NF Inserts
(For Torx holes)
SCMT Stock Dimensions (mm)
AC530U
T1500Z
T3000Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FB
Cat. No.
SCMT 09T304N-FB
9.525 3.97 0.4
09T308N-FB
0.8
SCMT Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC630M
AC6030M
AC6040M
T1500Z
T3000Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
LU
Cat. No.
SCMT 09T304N-LU
9.525 3.97 0.4
09T308N-LU
0.8
SCMT Stock Dimensions (mm)
AC820P
AC8025P
AC830P
AC6020M
AC6030M
AC6040M
T1500Z
T3000Z
T1500A
Inscribed
circle
Thickness
Nose radius
LB
Cat. No.
SCMT 09T304N-LB
9.525 3.97 0.4
09T308N-LB
0.8
7 Positive M Class
SCMT Stock Dimensions (mm)
T1500A
Inscribed
circle
Thickness
Nose radius
FP
Cat. No.
SCMT 09T304N-FP
9.525 3.97 0.4
09T308N-FP
0.8
Recommended tightening torque (N m)
Dimensions (mm)
D29
D
Small Product
Machining
91˚
60˚
WF
HF
BH
LF
0˚
0˚
STGC
General Turning
STAC
General Turning
WFHF
LF
0˚
0˚
91˚
60˚
BH
General Turning
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
STGC R/L0808-09 8 8 100 10 8 TC 0902
BFTX02205N
0.5 TRX06
STGC R/L1010-09 10 10 100 12 10 TC 0902
STGC R/L1212-11 12 12 100 16 12 TC 1102
BFTX02506N
1. 5 TRX08
STGC R/L1616-11 16 16 100 20 16 TC 1102
STGC R/L2020-11 20 20 125 25 20 TC 110 2
Holders
This figure shows right handed tools.
Parts
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
STAC R/L0808-09 8 8 100 8.5 8 TC 0902
BFTX02205N
0.5 TRX06
STAC R/L1010-09 10 10 100 10.5 10 TC 0902
STAC R/L1212-11 12 12 100 12.5 12 TC 110 2
BFTX02506N
1. 5 TRX08
STAC R/L1616-11 16 16 100 16.5 16 TC 110 2
STAC R/L2020-11 20 20 125 20.5 20 TC 1102
Holders
This figure shows right handed tools.
SEC-Mini Tool Holders
ST Type
91˚ 91˚
(For Torx holes)
(For Torx holes)
Recommended tightening torque (N m)
Dimensions (mm)
Dimensions (mm)
D30
D
Small Product
Machining
SEC-Mini Tool Holders
ST Type
TCGT Stock Dimensions (mm)
AC1030U
AC530U
Inscribed
circle
Thickness
Nose radius
FX
Cat. No.
TCGT 090201R -FX
5.56 2.38
0.1
090201L -FX
0.1
090202R -FX
0.2
090202L -FX
0.2
TCGT 110201R -FX
6.35 2.38
0.1
110201L -FX
0.1
110202R -FX
0.2
110202L -FX
0.2
Inserts (Coated carbide / Cermet / SUMIDIA)
7 Positive G Class
TCGT Stock Dimensions (mm)
AC1030U
AC530U
Inscribed
circle
Thickness
Nose radius
FY
Cat. No.
TCGT 090201R -FY
5.56 2.38
0.1
090201L -FY
0.1
090202R -FY
0.2
090202L -FY
0.2
TCGT 110201R -FY
6.35 2.38
0.1
110201L -FY
0.1
110202R -FY
0.2
110202L -FY
0.2
TCGT Stock Dimensions (mm)
AC610M
AC630M
AC510U
AC520U
AC1030U
AC530U
T1500Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
SI
Cat. No.
TCGT 110204MN-SI
6.35 2.38 0.4
Nose radii RE with a sign "<" indicate negative tolerances.
TCMT
Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC830P
AC610M
AC630M
AC6020M
AC6030M
AC6040M
AC520U
AC530U
Inscribed
circle
Thickness
Nose radius
SU
Cat. No.
TCMT 110204N-SU
6.35 2.38 0.4
110208N-SU
0.8
TCMW
Stock Dimensions (mm)
AC405K
AC415K
AC420K
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
TCMW 110204
6.35 2.38 0.4
110208
0.8
TCMT Stock Dimensions (mm)
DA150
DA2200
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
TCMT 090201
5.56 2.38
0.1
090202
0.2
090204
0.4
TCMT 110201
6.35 2.38
0.1
110202
0.2
110204
0.4
SUMIDIA
NF
TCMT
Stock Dimensions (mm)
DA1000
DA2200
Inscribed
circle
Thickness
Nose radius
—
Cat. No.
NF-TCMT 090202
5.56 2.38 0.2
090204
0.4
NF-TCMT 110201
6.35 2.38
0.1
110202
0.2
110204
0.4
SUMIDIA NF Inserts
7 Positive M Class
TCMT
Stock Dimensions (mm)
T1500A
Inscribed
circle
Thickness
Nose radius
FP
Cat. No.
TCMT 110204N-FP
6.35 2.38 0.4
110208N-FP
0.8
TCMT
Stock Dimensions (mm)
AC820P
AC8025P
AC830P
AC6020M
AC6030M
AC6040M
T1500Z
T3000Z
T1500A
Inscribed
circle
Thickness
Nose radius
LB
Cat. No.
TCMT 110204N-LB
6.35 2.38 0.4
110208N-LB
0.8
mark: To be replaced by a new item, shifted to made-to-order production, discontinued, etc. (Confirm the stock availability.)
TCGT Stock Dimensions (mm)
AC1030U
AC530U
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
SC
Cat. No.
TCGT 090201MN-SC
5.56 2.38 0.1
090202MN-SC
0.2
TCGT 110201MN-SC
6.35 2.38 0.1
110202MN-SC
0.2
Nose radii RE with a sign "<" indicate negative tolerances.
TCMT
Stock Dimensions (mm)
AC810P
AC820P
AC8025P
AC630M
AC6030M
AC6040M
T1500Z
T3000Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
LU
Cat. No.
TCMT 110204N-LU
6.35 2.38 0.4
110208N-LU
0.8
7 Positive M Class
TCMT
Stock Dimensions (mm)
AC530U
T1500Z
T3000Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FB
Cat. No.
TCMT 110204N-FB
6.35 2.38 0.4
110208N-FB
0.8
D31
D
Small Product
Machining
SVLC
General Turning
& Profiling
SVPC
Necking
B
H
95˚
35˚
LF
HF WF
0˚
0˚
HB
HF WF
117. 5
˚
35
˚
LF
0˚
0˚
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
SVLC R/L1010-H11 10 10 100 10.5 10 VC 110 3
BFTX02508NV
1. 5 TRX08
SVLC R/L1212-H11 12 12 100 12.5 12 VC 1103
SVLC R/L1616-H11 16 16 100 16.5 16 VC 1103
SVLC R/L2020-K11 20 20 125 20.5 20 VC 110 3
Holders
This figure shows right
handed tools.
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
SVPC R/L1010-H11 10 10 100 14.5 10 VC 110 3
BFTX02508NV
1. 5 TRX08
SVPC R/L1212-H11 12 12 100 16.5 12 VC 110 3
SVPC R/L1616-H11 16 16 100 20.5 16 VC 1103
SVPC R/L2020-K11 20 20 125 24.5 20 VC 110 3
Holders
This figure shows right
handed tools.
General Turning and Profiling
* Old Cat. No. is SVLC R/L 2020-H11
* Old Cat. No. is SVPC R/L 2020-H11
SEC-Mini Tool Holders
SV Type (7 Positive)
95˚ 117.5˚
(For Torx holes)
(For Torx holes)
Recommended tightening torque (N m)
Dimensions (mm)
Dimensions (mm)
D32
D
Small Product
Machining
SEC-Mini Tool Holders
SV Type
Inserts (Coated carbide / Cermet / Carbide / SUMIBORON / SUMIDIA)
VCET Stock Dimensions (mm)
ACZ150
Inscribed
circle
Thickness
Nose radius
FX
Cat. No.
VCET 1103008R -FX
6.35 3.18
0.08
1103008L -FX
0.08
110301R-FX
0.1
110301L-FX
0.1
1103018R -FX
0.18
1103018L -FX
0.18
7 Positive E Class
VCGT Stock Dimensions (mm)
AC520U
AC1030U
AC530U
Inscribed
circle
Thickness
Nose radius
FY
Cat. No.
VCGT 110301R-FY
6.35 3.18
0.1
110301L-FY
0.1
110302R-FY
0.2
110302L-FY
0.2
110304R-FY 0.4
110304L-FY 0.4
NF
VCMT
Stock Dimensions (mm)
DA1000
DA2200
Inscribed
circle
Thickness
Nose radius
-
Cat. No.
NF-VCMT 110301
6.35 3.18
0.1
110302
0.2
110304
0.4
7 Positive M Class
SUMIDIA NF Inserts
VCGT Stock Dimensions (mm)
AC520U
AC1030U
AC530U
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FX
Cat. No.
VCGT 110301R-FX
6.35 3.18
0.1
110301L-FX
0.1
110302R-FX
0.2
110302L-FX
0.2
110304R-FX 0.4
110304L-FX 0.4
NU-
VCGW
Stock Dimensions (mm)
BN2000
BN1000
Inscribed
circle
Thickness
Nose radius
-
Cat. No.
NU-VCGW 110302
6.35 3.18
0.2
110304
0.4
110302HS 0.2
110304HS 0.4
Note: The part number suffixes stand for the following: HS: Strengthened cutting edge type
7 Positive G Class
SUMIBORON One Use Inserts (Non-Coated)
VCGT Stock Dimensions (mm)
AC520U
AC1030U
AC530U
ACZ150
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
FC
Cat. No.
VCGT 110301MN-FC
6.35 3.18
0.1
110302MN-FC
0.2
110304MN-FC
0.4
Nose radii RE with a sign "<" indicate negative tolerances.
7 Positive G Class
VCMT Stock Dimensions (mm)
AC8025P
AC630M
AC6020M
AC6030M
AC6040M
Inscribed
circle
Thickness
Nose radius
SU
Cat. No.
VCMT 110302N-SU
6.35 3.18
0.2
110304N-SU
0.4
110308N-SU
0.8
7 Positive M Class
VCET Stock Dimensions (mm)
ACZ150
Inscribed
circle
Thickness
Nose radius
FY
Cat. No.
VCET 1103008R -FY
6.35 3.18
0.08
1103008L -FY
0.08
110301R-FY
0.1
110301L-FY
0.1
1103018R -FY
0.18
1103018L -FY
0.18
NF
VCMT
Stock Dimensions (mm)
DA1000
Inscribed
circle
Thickness
Nose radius
LD/GD
Cat. No.
NF-VCMT 110302N-LD
6.35 3.18
0.2
110304N-LD
0.4
110302N-GD
0.2
110304N-GD
0.4
SUMIDIA Break Master
VCMT Stock Dimensions (mm)
DA2200
Inscribed
circle
Thickness
Nose radius
-
Cat. No.
VCMT 110301
6.35 3.18
0.1
110302
0.2
110304
0.4
SUMIDIA
VCMW
Stock Dimensions (mm)
NPD10
Inscribed
circle
Thickness
Nose radius
RH
Cat. No.
VCMW 110302RH
6.35 3.18 0.2
110304RH
0.4
SUMIDIA Binderless
mark: To be replaced by a new item, shifted to made-to-order production, discontinued, etc. (Confirm the stock availability.)
7 Positive G Class
VCGT Stock Dimensions (mm)
AC610M
AC630M
AC510U
AC520U
AC1030U
AC530U
T1500Z
T1000A
T1500A
Inscribed
circle
Thickness
Nose radius
SI
Cat. No.
VCGT 110301MN-SI
6.35 3.18
0.1
110302MN-SI
0.2
110304MN-SI
0.4
110308MN-SI
0.8
Nose radii RE with a sign "<" indicate negative tolerances.
VCGT Stock Dimensions (mm)
H1
Inscribed
circle
Thickness
Nose radius
AG
Cat. No.
VCGT 110302N-AG
6.35 3.18 0.2
110304N-AG
0.4
D33
D
Small Product
Machining
SVLP
General Turning
& Profiling
SVPP
Necking
B
H
95˚
35˚
LF
HF WF
0˚
0˚
HB
HF WF
117.5
˚
35
˚
LF
0˚
0˚
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
SVLP R/L1010-H11 10 10 100 10.5 10 VP T1103
BFTX02508NV
1. 5 TRX08
SVLP R/L1212-H11 12 12 100 12.5 12 VP T1103
SVLP R/L1616-H11 16 16 100 16.5 16 VP T1103
Holders
This figure shows right
handed tools.
Parts
Cat. No. Stock
Height
Width
Length
Cutting edge
distance
Cutting edge
height
Applicable
inserts Screw N m Wrench
R L H B LF WF HF
SVPP R/L1010-H11 10 10 100 14.5 10 VP T1103
BFTX02508NV
1. 5 TRX08
SVPP R/L1212-H11 12 12 100 16.5 12 VP T1103
SVPP R/L1616-H11 16 16 100 20.5 16 VP T1103
Holders
This figure shows right
handed tools.
General Turning and Profiling
VPET Stock Dimensions (mm)
ACZ150
Inscribed
circle
Thickness
Nose radius
FX
Cat. No.
VPET 1103003R-FX
6.35 3.18
0.03
1103003L-FX
0.03
110301R -FX
0.1
110301L -FX
0.1
110302R -FX
0.2
110302L -FX
0.2
Inserts (Coated carbide)
11 Positive E Class
VPET Stock Dimensions (mm)
ACZ150
Inscribed
circle
Thickness
Nose radius
FY
Cat. No.
VPET 1103003R-FY
6.35 3.18
0.03
1103003L-FY
0.03
110301R -FY
0.1
110301L -FY
0.1
110302R -FY
0.2
110302L -FY
0.2
95˚ 117.5˚
(For Torx holes)
(For Torx holes)
SEC-Mini Tool Holders
SV Type (11 Positive)
Recommended tightening torque (N m)
Dimensions (mm)
Dimensions (mm)
D34
