H147
mark: Standard stocked item
mark: To be replaced by a new item featured on the same page
mark: To be replaced by new item
(Please confirm stock availability)
mark:
Semi-standard stock (Please confirm stock availability)
mark:
Stock or planned stock (Please confirm stock availability)
No mark: Made-to-order item
mark: We cannot produce
Stock Indications and Symbols
Modular Tools H148
Shoulder Milling
Shoulder Milling for Steel, Die Steel, Cast Iron, Stainless Steel and Non-Ferrous Metal
High Efficiency Milling for Steel, Cast Iron, Stainless Steel and Non-Ferrous Meta
l
SEC-Wave Mill WFX Type H150
SEC-Wave Mill WEX Type H151
High Feed
Milling
High Feed Milling for Steel, Die Steel, Cast Iron, Stainless Steel and Non-Ferrous Metal
High Feed Milling for Steel, Cast Iron and Stainless Steel
SEC-Wave Mill WFXH Type H152
SEC-Metal Slash Mill MSX Type H153
Radius Milling for Exotic Alloy
Milling for Steel, Cast Iron, Stainless Steel and Non-Ferrous Metal
SEC-Wave Radius Mill RSX Type H154
SEC-Wave Radius Mill WRCX Type H155
Chamfering
Chamfering for Steel, Die Steel, Cast Iron, Stainless Steel and Non-Ferrous Metal
SEC-Wave Mill WFXC Type H156
H147 to H156 H
Modular Tools
H
Modular
Tools
Shoulder
Milling
Multi-Purpose
Radius
High Feed
Groove/
T-Slot
Chamfering
H148
Shoulder
Milling
Radius
Groove/
T-Slot
High Feed
Multi-Purpose
Chamfering
Modular
Tools
SEC-
Modular Tools
Shoulder
Reference Line
S
houlder
Re
f
erence Line
Deviation
1st Step
(8mm)
2nd Step
(8mm)
3rd Step
(8mm)
200
150
100
50
0
60 80 130 150 180
Overhang (mm)
Deviation (μm)
Carbide Arbor Steel Arbor
Low
vibration
Vibration Amplitude
Vibration Amplitude
Carbide Arbor
Steel Arbor
Work Material : S50C
Tool : WEX2025M12Z4 ø25×4 flutes
Cutting Conditions : c=100m/min z=0.1mm/t e=8mm 3 times p=2.0mm Equipment :M/C BT50
Vibration
Standard Type (Integrated unit)Modular Type + Carbide Arbors
Note : Overhang varies depending on cutting conditions such as the tool used, machine rigidity, and work clamp rigidity.
Shoulder Milling Squareness
General Features
Exchangeable head endmills are available in 7 types!
Endmill for Shoulder Milling
WFX Type
Expansion
Endmill for High Efficiency Milling
WFXH Type
Radius Endmills
RSX
Type
Endmill for Chamfering
WFXC Type
A wide variety of possible combinations with carbide arbors, steel
arbors, and BBT integrated arbors.
Endmill for Shoulder Milling
WEX
Type
Ultra-High Feed Endmill
MSX
Type
Multi-purpose Radius Endmill
WRCX Type
Performance
Carbide arbors achieve greater precision and stable milling compared to steel arbors.
Type Carbide Arbors
Type Carbide Arbors
Easy assembly, screw-on design
Suitable for long overhangslong overhangs
with carbide or steel arbors!
H
Expansion
Screw Size & Attached Cutter Size
Screw
CRKS Applicable Cutter Size (DC)
M8 ø16, ø18
M10 ø20, ø22
M12 ø24, ø28
M16 ø30, ø32, ø35, ø40
High load millingHigh load milling is supported with
the BBT integrated arbor combination!
Type BBT30 integrated arbor
Type BBT30 integrated arbor
H149
Modular
Tools
Shoulder
Milling
Multi-Purpose
Radius
High Feed
Groove/
T-Slot
Chamfering
SEC-
Modular Tools
Stock Listings (Steel Arbors)
Cat. No.
Stock
Screw
Hole Size
Shank
Total Length
Depth
Screw Depth
Overhang
CRKS
DCB
DMM
LF2 L4 L5 LF
MA16M08L120S M8 8.5 16 120 10 18 145
20M10L150S M10 10.5 20 150 10 20 180
25M12L200S M12 12.5 25 200 10 22 235
32M16L200S M16 17.0 32 200 10 24 240
Carbide Arbors
Cat. No.
Stock
Screw
Hole Size
Shank
Total Length
Depth
Screw Depth
Overhang
CRKS
DCB
DMM
LF2 L4 L5 LF
MA15M08L120C M8 8.5 15 120 10 18 145
15M08L160C M8 8.5 15 160 10 18 185
16M08L120C M8 8.5 16 120 10 18 145
16M08L160C M8 8.5 16 160 10 18 185
MA18M10L150C M10 10.5 18 150 10 20 180
18M10L200C M10 10.5 18 200 10 20 230
20M10L150C M10 10.5 20 150 10 20 180
20M10L200C M10 10.5 20 200 10 20 230
MA23M12L200C M12 12.5 23 200 10 22 235
23M12L250C M12 12.5 23 250 10 22 285
25M12L200C M12 12.5 25 200 10 22 235
25M12L250C M12 12.5 25 250 10 22 285
MA28M16L200C M16 17.0 28 200 10 24 240
28M16L300C M16 17.0 28 300 10 24 340
32M16L200C M16 17.0 32 200 10 24 240
32M16L300C M16 17.0 32 300 10 24 340
DMM h7
CRKS
DCB
LF2
L4
L5
Carbide Arbors
Steel Arbors
*Notes about tightening the head.
Recommended Tightening Torque (N m)
Screw Size Torque
(N·m)
M8 23
M10 46
M12 60
M16 80
Set Dimensions
LF (Dimensions of Head + Arbor)
Endmill Identification
MA 15 M08 L120 C
(1)
Cutter Series
(2)
Shank Diameter
(3)
Mounting Screw Size
(4)
Arbor Length
(5)
Materials
CCarbide
SSteel
SEC-Modular Tools Special Arbors (Carbide Arbors/Steel Arbors)
BBT Integrated Type (BIG-PLUSTM) - Special Arbor for SEC-Modular Tools
·
When attaching the head to an arbor, follow the standard tightening torque in the table below.
· Check the mounting screw size for the head and arbor beforehand.
H
DCB
BD
ø46
L7
LBX
LF
L6
CRKS
BBT Integrated Arbor
Cat. No. Stock Screw Hole Size
External Diameter
Body Overhang
Length
Screw Depth
Overhang
Coolant Hole
CRKS DCB BD L6 LBX L7 LF*
BBT30-M8-50 M8 8.5 15.9 73 50 18 98 Yes
M10-45 M10 10.5 19.9 68 45 20 98 Yes
M12-40 M12 12.5 24.9 63 40 22 98 Yes
M16-35 M16 17 31.9 58 35 24 98 Yes
* LF is the amount of overhang when the head is attached. * BIG-PLUSTM is a trademark of BIG DAISHOWA SEIKI CO., LTD.
* Can also be used with BT30 spindle machines.
Dimension (mm)
Dimension (mm)Dimension (mm)
Shoulder
Milling
Radius
Groove/
T-Slot
High Feed
Multi-Purpose
Chamfering
Modular
Tools
SEC-Wave Mill
WFX 08000M Type
SEC-
Modular
Tools
H150
H
DCON
CRKS
LF
OAL
LS
LS2
L11
DC
Head
Cat. No.
Stock
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of Teeth
DC
DCON CRKS
OAL
LF
LS2
LS
L11
H
WFX 08020M10Z2
20
10.5
M10
49 30 5 19 8 15 2
08022M10Z2
22
10.5
M10
49 30 5 19 8 15 2
WFX 08025M12Z2
25
12.5
M12
56 35 5 21 10 19 2
08028M12Z2
28
12.5
M12
56 35 5 21 10 19 2
WFX 08030M16Z3
30
17.0
M16
63 40 5 23 10 24 3
08032M16Z3
32
17.0
M16
63 40 5 23 10 24 3
08040M16Z3
40
17.0
M16
63 40 5 23 10 24 3
Inserts are not included.
Identification Details
WFX 08 020 M10 Z2
(1)
Cutter Series
(2)
Insert Size
(3)
Cutter Diameter
(4)
Mounting Screw Size
(5)
No. of Teeth
Recommended Cutting Conditions
ISO
Work Material
Hardness
Cutting Speed vc (m/min)
Min. - Optimum - Max.
Feed Rate fz (mm/t)
Min. - Optimum - Max.
Depth of Cut
(mm)
Grade
P
General Steel
180 to 280HB 150-200-250 0.08- 0.12 -0.18 6ACP200
ACP300
Soft Steel ≤180HB 180-250-350 0.10- 0.15 -0.20 6ACP200
ACP300
Die Steel
200 to 220HB
100- 150 -200 0.08- 0.12 -0.18 4ACP200
ACP300
M
Stainless Steel
160-200-250 0.10- 0.15 -0.20 6ACM300
KCast Iron 250HB 100- 175 -250 0.10- 0.15 -0.20 6ACK200
ACK300
N
Non-Ferrous Metal
300-500-1000 0.10- 0.15 -0.20 6H1
DL1000
Inserts P
Steel
M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
S
Exotic Alloy
H
Hardened Steel
Grade Coated Carbide
Cermet
DLC
Cermet
Application
High Speed/Light
PKN
General Purpose
KNP
Roughing K
Cat. No.
ACP100
ACP200
ACP300
ACK200
ACK300
ACM200
ACM300
H1
DL1000
T4500A
Corner
Radius
Fig
RE
3.175
8.0
3.3
8.1
R0.8
Fig 2
Fig 1
3.175
8.0
8.0
RE
Wiper Insert
SOMT 080304PZER-L 0.4 1
080308PZER-L 0.8 1
SOMT 080304PZER-G 0.4 1
080308PZER-G 0.8 1
080312PZER-G 1.2 1
SOMT 080308PZER-H 0.8 1
080312PZER-H 1.2 1
SOET 080304PZER-G 0.4 1
080308PZER-G 0.8 1
080312PZER-G 1.2 1
SOET 080302PZFR-S 0.2 1
080304PZFR-S 0.4 1
080308PZFR-S 0.8 1
XOEW 080308PZTR-W 2
Parts
Insert Screw Wrench
BFTX0306IP2.0 TRDR08IP
N m
The cutting conditions above are a guide. Actual conditions will need to be adjusted
according to machine rigidity, work clamp rigidity, cutting depth, and other factors.
Note
Axial
Radial 6
12
90
6mm
Rake
Angle
P
Steel M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
N
Aluminum
S
Exotic Alloy
H
Hardened Steel
H
N m
Recommended Tightening Torque N m
Dimensions (mm)
Dimensions (mm)
H64 (Notes
on Installation)
Arbor
H149
Shoulder
Milling
Multi-Purpose
Radius
High Feed
Groove/
T-Slot
Chamfering
Modular
Tools
H151
Inserts P
Steel
M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
S
Exotic Alloy
H
Hardened Steel
3.58
12.00
11°
7.00
RE
Grade Coated Carbide
Carbide
DLC
Application
High Speed/Light PKN
General Purpose KN
Roughing K
Cat. No.
ACP100
ACP200
ACP300
ACK200
ACK300
ACM200
ACM300
H1
DL1000
Corner
Radius
RE
AXMT 123504PEER-G
0.4
123508PEER-G
0.8
123512PEER-G
1.2
AXMT 123504PEER-H
0.4
123508PEER-H
0.8
123512PEER-H
1.2
AXMT 123504PEER-E
0.4
123508PEER-E
0.8
123512PEER-E
1.2
AXMT 123508PEER-EH
0.8
AXET 123502PEFR-S
0.2
123504PEFR-S
0.4
123508PEFR-S
0.8
H
Head (WEX 2000M)
Cat. No.
Stock
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of Teeth
DC
DCON
CRKS
OAL
LF
LS2
LS
L11
H
WEX 2016M08Z2 16 8.5
M8
42 25 5 17 8 13 2
2018M08Z2 18 8.5
M8
42 25 5 17 8 13 2
WEX 2020M10Z3 20 10.5
M10
49 30 5 19 8 15 3
2022M10Z3 22 10.5
M10
49 30 5 19 8 15 3
WEX 2025M12Z4 25 12.5
M12
56 35 5 21 10 19 4
2028M12Z4 28 12.5
M12
56 35 5 21 10 19 4
WEX 2030M16Z4 30 17.0
M16
63 40 5 23 10 24 4
2032M16Z5 32 17.0
M16
63 40 5 23 10 24 5
2040M16Z6 40 17.0
M16
63 40 5 23 10 24 6
DCON
DC
LF
OAL
LS
LS2
CRKS
H
L11
Head (WEX 3000M)
Cat. No.
Stock
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of Teeth
DC
DCON
CRKS
OAL
LF
LS2
LS
L11
H
WEX 3025M12Z2 25 12.5
M12
56 35 5 21 10 19 2
3028M12Z2 28 12.5
M12
56 35 5 21 10 19 2
WEX 3030M16Z3 30 17.0
M16
63 40 5 23 10 24 3
3032M16Z3 32 17.0
M16
63 40 5 23 10 24 3
3035M16Z3 35 17.0
M16
63 40 5 23 10 24 3
WEX 3040M16Z4 40 17.0
M16
63 40 5 23 10 24 4
Parts (WEX2000M)
Screws Wrench Applicable Endmills
N m
BFTX0305IP2.0 TRDR08IPWEX2016M WEX2018M
BFTX0306IP2.0 WEX2020M to WEX2040M
Anti-seizure cream SUMI-P included in the package.
Parts (WEX3000M)
Screws Wrench Applicable Endmills
N m
BFTX0407IP3.0 TRDR15IPWEX3025M to WEX3030M
BFTX0409IP3.0 WEX3032M to WEX3040M
Anti-seizure cream SUMI-P included in the package.
WEX3000M TypeWEX2000M Type
Inserts are not included.
Inserts are not included.
Identification Details
WEX 2 016 M08 Z2
(1)
Cutter Series
(2)
Insert size
(3)
Cutter Diameter
(4)
Mounting Screw Size
(5)
No. of Teeth
Inserts P
Steel
M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
S
Exotic Alloy
H
Hardened Steel
17.54 5.59
10.2
11°
RE
Grade Coated Carbide
Carbide
DLC
Application
High Speed/Light PKN
General Purpose KN
Roughing K
Cat. No.
ACP100
ACP200
ACP300
ACK200
ACK300
ACM200
ACM300
H1
DL1000
Corner
Radius
RE
AXMT 170508PEER-L
0.8
AXMT 170504PEER-G
0.4
170508PEER-G
0.8
170512PEER-G
1.2
170516PEER-G
1.6
170520PEER-G*
2.0
170530PEER-G*
3.0
AXMT 170508PEER-H
0.8
170512PEER-H
1.2
AXMT 170504PEER-E
0.4
170508PEER-E
0.8
170512PEER-E
1.2
170516PEER-E
1.6
170520PEER-E*
2.0
170530PEER-E*
3.0
AXMT 170508PEER-EH
0.8
AXET 170502PEFR-S
0.2
170504PEFR-S
0.4
170508PEFR-S
0.8
* Cutter body modification is required.
N m
Recommended Tightening Torque N m
N m
Recommended Tightening Torque N m
SEC-Wave Mill
WEX 2000M / 3000M Type
SEC-
Modular
Tools
90
10
mm
(2000M Type)
Max. Depth of Cut
90
14
mm
(3000M Type)
Max. Depth of Cut
(2000M Type)
Axial
Radial
10 to 18
14 to 25
8 to 15
16 to 24
Rake
Angle
(3000M Type)
P
Steel M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
N
Aluminum
S
Exotic Alloy
H
Hardened Steel
Dimensions (mm) Dimensions (mm)
Dimensions (mm) Dimensions (mm)
Recommended Cutting Conditions
H75
Arbor
H149
H152
Dimensions (mm)
Shoulder
Milling
Radius
Groove/
T-Slot
High Feed
Multi-Purpose
Chamfering
Cutter
Head (WFXH 12000M)
Cat. No.
Stock
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
Weight
(kg)
DC
DCON
CRKS
OAL
LF
LS2
LS
L11
H
WFXH 12040M16Z3
40 17.0
M16
63 40 5 23 10 24 3 0.2
Applicable Insert SOMT12 Type
SEC-Wave Mill
WFXH 08000M / 12000M Type
SEC-
Modular
Tools
P
Steel M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
N
Aluminum
S
Exotic Alloy
H
Hardened Steel
H
6
6
Axial
Radial
Rake
Angle
(08000M Type)
1.5
15
2.5
15
(12000M Type)
Identification Details
WFX H 08 025 M12 Z2
(1)
Cutter Series
(3)
Insert Size
(2)
High Feed
(4)
Cutter Diameter
(5)
Mounting Screw Size
(6)
No. of Teeth
Head (WFXH 08000M)
Cat. No.
Stock
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
Weight
(kg)
DC
DCON
CRKS
OAL
LF
LS2
LS
L11
H
WFXH 08025M12Z2
25 12.5
M12
56 35 5 21 10 19 2 0.1
08032M16Z3
32 17.0
M16
63 40 5 23 10 24 3 0.2
Applicable Insert SOMT08 Type
Recommended Cutting Conditions
Work
Material Grade
Cutting Speed
vc(m/min)
Insert
Cat. No.
ø25 ø32 ø40 ø50 ø63
ap
(mm)
Feed
(mm/rev)
ap
(mm)
Feed
(mm/rev)
ap
(mm)
Feed
(mm/rev)
ap
(mm)
Feed
(mm/rev)
ap
(mm)
Feed
(mm/rev)
P
General Steel
Below 200HB
ACP200 100-150-200
SOMT08
0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8
SOMT12
1.0 1.0 1.0 1.0 1.0 1.0
P
Alloy Steel
Below HRC45
ACP200 80-130-180
SOMT08
0.7 0.8 0.7 0.8 0.7 0.8 0.7 0.8
SOMT12
0.8 1.0 0.8 1.0 0.8 1.0
M
Stainless Steel
SUS304, Others
ACM300 80-120-150
SOMT08
0.8 0.7 0.8 0.7 0.8 0.7 0.8 0.7
SOMT12
1.0 0.8 1.0 0.8 1.0 0.8
K
Cast Iron
FC,FCD
ACK300 100-150-200
SOMT08
0.8 1.0 0.8 1.0 0.8 1.0 0.8 1.0
SOMT12
1.0 1.2 1.0 1.2 1.0 1.2
H
Hardened Steel
Below HRC50
ACK300 40- 80-100
SOMT08
0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
SOMT12
0.6 0.8 0.6 0.8 0.6 0.8
Th e above recommended cutting conditions may require adjustment according to machine rigidity and work rigidity.
The above figures are guidelines for use with the BT50 machine tool.
The above cutting conditions assume a tool overhang length of L/D=3 (i.e. overhang length is 3 times tool diameter) or less.
When tool overhang is more than L/D 3 and less than or equal L/D=5, settings should be adjusted to approximately 70 to 80% of those indicated in the above cutting conditions (i.e. ap and feed rate).
When tool overhang is more than L/D 5 and less than or equal L/D=8, settings should be adjusted to approximately 50 to 60% of those indicated in the above cutting conditions (i.e. ap and feed rate).
CAUTION
H96
Inserts P
Steel
M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
S
Exotic Alloy
H
Hardened Steel
Grade Coated Carbide Cermet DLC Cermet
Application
High Speed/Light
PKN
General Purpose
KNP
Roughing K
Cat. No.
ACP100
ACP200
ACP300
ACK200
ACK300
ACM200
ACM300
H1
DL1000
T4500A
Corner
Radius
Fig
RE
Fig 2
4.76
12.7
12.7
RE
Fig 1
3.175
8.0
8.0
RE
SOMT 080304PZER-L 0.4 1
080308PZER-L 0.8 1
SOMT 080304PZER-G 0.4 1
080308PZER-G 0.8 1
080312PZER-G 1.2 1
SOMT 080308PZER-H 0.8 1
080312PZER-H 1.2 1
SOET
080304PZER-G 0.4 1
080308PZER-G 0.8 1
080312PZER-G 1.2 1
SOET
080302PZFR-S 0.2 1
080304PZFR-S 0.4 1
080308PZFR-S 0.8 1
SOMT
120408PDER-L 0.8 2
SOMT
120404PDER-G 0.4 2
120408PDER-G 0.8 2
120412PDER-G 1.2 2
120416PDER-G 1.6 2
SOMT
120408PDER-H 0.8 2
SOET
120408PDFR-S 0.8 2
Parts
Applicable
Cutters
Screws
Wrenches
N m
WFXH08000M
BFTX0306IP
2.0
TRDR08IP
WFXH12000M
BFTX03512IP
3.0
TRDR15IP
N m
Recommended Tightening Torque (N m)
Anti-seizure cream SUMI-P included in the package.
CRKS
H
DCON
L11
LS2
OAL
LSLF
DC
Dimensions (mm)
Dimensions (mm)
Arbor
H149
H153
Modular
Tools
Shoulder
Milling
Multi-Purpose
Radius
High Feed
Groove/
T-Slot
Chamfering
Head (MSX 06000M)
Cat. No.
Stock
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
DC
DCON
CRKS
OAL
LF
LS2
LS
L11
H
MSX 06016M08Z2
16 8.5
M8
42255178132
06018M08Z2
18 8.5
M8
42255178132
MSX 06020M10Z3
20 10.5
M10
49305198153
06022M10Z3
22 10.5
M10
49305198153
MSX 06025M12Z3
25 12.5
M12
56 35 5 21 10 19 3
Inserts are not included.
Head (MSX 08000M)
Cat. No.
Stock
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
DC
DCON
CRKS
OAL
LF
LS2
LS
L11
H
MSX 08025M12Z2
25 12.5
M12
56 35 5 21 10 19 2
08028M12Z2
28 12.5
M12
56 35 5 21 10 19 2
MSX 08030M16Z3
30 17.0
M16
63 40 5 23 10 24 3
08032M16Z3
32 17.0
M16
63 40 5 23 10 24 3
08035M16Z3
35 17.0
M16
63 40 5 23 10 24 3
Inserts are not included.
Head (MSX 12000M)
Cat. No.
Stock
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
DC
DCON
CRKS
OAL
LF
LS2
LS
L11
H
MSX 12032M16Z2
32 17.0
M16
63 40 5 23 10 24 2
12035M16Z2
35 17.0
M16
63 40 5 23 10 24 2
12040M16Z3
40 17.0
M16
63 40 5 23 10 24 3
Inserts are not included.
H
H
DCON
DCX
LF
OAL
LS
LS2
CRKS
L11
MSX12000M Type
MSX06000M Type
Only the MSX06000M type is a
single-clamp type.
Applicable Insert WDMT06 Type
Applicable Insert WDMT08 Type
Parts
Screws Wrenches Clamps C Rings
Clamp Screws
Applicable Bodies
N m
BFTX02505IP
1.5 TRDR08IPMSX06000M Type
BFTX0306IP
2.0 CCH3.5 CR03
BFTX03510IP08
MSX08000M Type
BFTX0409IP
3.0 TRDR15IP CCH3.5 CR03
BFTX03510IP15
MSX12000M Type
Inserts
Grade
Coated Carbide
P
Steel
M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
S
Exotic Alloy
H
Hardened Steel
Application
General Purpose
K
Roughing K
Usage Cat. No.
ACP200
ACP300
ACK200
ACK300
Inscribed Circle
Thickness
Corner Radius
Applicable Cutter
IC S RE
General
Purpose
WDMT 0603 ZDTR 6.35 3.0 1.5 MSX06000M Type
RE
S
IC
0804 ZDTR 8.50 4.0 2.0 MSX08000M Type
1205 ZDTR 12.00 5.0 2.0 MSX12000M Type
Strong
Edged
WDMT 0603 ZDTR-H 6.35 3.0 1.5 MSX06000M Type
0804 ZDTR-H 8.50 4.0 2.0 MSX08000M Type
1205 ZDTR-H 12.00 5.0 2.0 MSX12000M Type
Identification Details
MSX 06 016 M08 Z2
(1)
Cutter Series
(2)
Insert Size
(3)
Cutter Diameter
(4)
Mounting Screw Size
(5)
No. of Teeth
MSX08000M Type
Applicable Insert WDMT12 Type
N m
Recommended Tightening Torque N m
3 to 6
8
Axial
Radial
Rake
Angle
1.0
20
(06000M Type)
1.5
20
(08000M Type)
2.0
20
(12000M Type)
P
Steel M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
N
Aluminum
S
Exotic Alloy
H
Hardened Steel
SEC-Metal Slash Mill
MSX 06000M / 08000M / 12000M Type
SEC-
Modular
Tools
Dimensions (mm)
Dimensions (mm)
Dimensions (mm)
Dimensions (mm)
Arbor
H149
Recommended Cutting Conditions
H101
H154
Shoulder
Milling
Radius
Groove/
T-Slot
High Feed
Multi-Purpose
Chamfering
Modular
Tools
Applicable Cutter Screws Wrench
N m
RSX(F)10000M Type
BFTX03584IP
3.0 TRDR15IP
RSX(F)12000M Type
BFTX0409IP
3.0
Anti-seizure cream SUMI-P included in the package
DCX
CRKS
OAL
LF LS
LS2
DCON
L11
H
SEC-Wave Radius Mill
RSX(F) 08000M / 10000M / 12000M Type
SEC-
Modular
Tools
Parts
5 to 8
10
Axial
Radial
Rake
Angle
5
(10000M Type)
6
(12000M Type)
P
Steel M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
N
Aluminum
S
Exotic Alloy
H
Hardened Steel
H
N m
Recommended Tightening Torque N m
4
(08000M Type)
Expansion
Head (RSXF10000M)
Extra-Fine Pitch
Applicable Insert RDET10 Type
Cat. No.
Stock
Max.
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
Weight
(kg)
DCX
DCON CRKS
OAL
LF
LS2
LS
L11
H
RSXF 10025M12Z3
25
12.5
M12
56 35 5 21 10 19 3 0.1
10032M16Z4
32
17.0
M16
63 40 5 23 10 24 4 0.2
Head (RSX12000M) Applicable Insert RDET12 Type
Cat. No.
Stock
Max.
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
Weight
(kg)
DCX
DCON CRKS
OAL
LF
LS2
LS
L11
H
RSX 12032M16Z2
32
17.0
M16
63 40 5 23 10 24 2 0.2
12040M16Z3
40
17.0
M16
63 40 5 23 10 24 3 0.3
Head (RSXF12000M)
Extra-Fine Pitch
Applicable Insert RDET12 Type
Cat. No.
Stock
Max.
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
Weight
(kg)
DCX
DCON CRKS
OAL
LF
LS2
LS
L11
H
RSXF 12032M16Z3
32
17.0
M16
63 40 5 23 10 24 3 0.2
12040M16Z4
40
17.0
M16
63 40 5 23 10 24 4 0.3
Head (RSX08000M) Applicable Insert RDET08 Type
Cat. No.
Stock
Max.
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
Weight
(kg)
DCX
DCON CRKS
OAL
LF
LS2
LS
L11
H
RSX 08020M10Z2
20
10.5
M10
49 30 5 19 8 15 2
0.1
08025M12Z3
25
12.5
M12
56 35 5 21 10 19 3
0.1
08032M16Z4
32
17.0
M16
63 40 5 23 10 24 4
0.2
Head (RSXF08000M)
Extra-Fine Pitch
Applicable Insert RDET08 Type
Cat. No.
Stock
Max.
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
Weight
(kg)
DCX
DCON CRKS
OAL
LF
LS2
LS
L11
H
RSXF 08020M10Z3
20
10.5
M10
49 30 5 19 8 15 3
0.1
08025M12Z4
25
12.5
M12
56 35 5 21 10 19 4
0.1
08032M16Z5
32
17.0
M16
63 40 5 23 10 24 5
0.2
Head (RSX10000M) Applicable Insert RDET10 Type
Cat. No.
Stock
Max.
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
Weight
(kg)
DCX
DCON CRKS
OAL
LF
LS2
LS
L11
H
RSX 10025M12Z2
25
12.5
M12
56 35 5 21 10 19 2 0.1
10032M16Z3
32
17.0
M16
63 40 5 23 10 24 3 0.2
Inserts are not included.
Inserts
S0.025
IC 0.025
IC 0.025
Grade
Coated Carbide
Application
High Speed/Light
General Purpose
Roughing
Cat. No.
Inscribed
Circle Thickness
Applicable Cutter
RDET
RDET
RDET
8
8
10
10
12
12
3.18
3.18
3.97
3.97
4.76
4.76
RSX(F)08000M
RSX(F)10000M
RSX(F)12000M
0803M0EN-G
0803M0EN-H
10T3M0EN-G
10T3M0EN-H
1204M0EN-G
1204M0EN-H
SIC
G Type H Type
Cross Section of Cutting Edge
ACP200
ACM100
ACM200
ACM300
K
ACK300
Dimensions (mm)
P Steel M Stainless Steel K Cast Iron S Exotic Alloy
Identification Details
RSX
F 10 025 M12 Z2
(1)
Cutter Series
(2)
Extra-Fine Pitch
(3)
Insert Size
(4)
Cutter Diameter
(5)
Mounting Screw Size
(6)
No. of Teeth
mark: Standard stocked item (expanded item)
Notes About Attaching Inserts
H108
Dimensions (mm) Dimensions (mm)
Dimensions (mm) Dimensions (mm)
Dimensions (mm) Dimensions (mm)
Recommended Cutting Conditions
H113
H154
Arbor
H149
H155
Shoulder
Milling
Multi-Purpose
Radius
High Feed
Groove/
T-Slot
Chamfering
Modular
Tools
Head (WRCX 08000M)
Cat. No.
Stock
Max.
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
DCX
DCON
CRKS
OAL
LF
LS2
LS
L11
H
WRCX 08020M10Z2
20 10.5
M10
49305198152
08025M12Z3
25 12.5
M12
56 35 5 21 10 19 3
Applicable Insert A = 8 mm Type
Inserts are not included.
Recommended Cutting Conditions
External Diameter: ø20 to ø32mm
Work
Material Hardness
Cutting Speed vc (m/min)
Min. - Optimum - Max.
Feed Rate fz (mm/t)
Min. - Optimum - Max.
Grade
P
Carbon Steel
180 to 280HB
80-120-160 0.10- 0.30 -0.40 ACP200
Alloy Steel
180 to 280HB
60-100-140 0.10- 0.20 -0.30 ACP200
M
Stainless Steel
60-100-120 0.10- 0.15 -0.20 ACP300
KCast Iron 250HB 60- 80 -120 0.10- 0.20 -0.30 ACK200
N
Non-Ferrous Metal
200-500-1000 0.10- 0.20 -0.30 DL1000
External Diameter: ø40mm
Work
Material Hardness
Cutting Speed vc (m/min)
Min. - Optimum - Max.
Feed Rate fz (mm/t)
Min. - Optimum - Max.
Grade
P
Carbon Steel
180 to 280HB
100-160-200 0.20- 0.40 -0.60 ACP200
Alloy Steel
180 to 280HB
100-140-180 0.20- 0.30 -0.40 ACP200
M
Stainless Steel
80-120-160 0.10- 0.20 -0.30 ACP300
KCast Iron 250HB 80-120-160 0.10- 0.20 -0.40 ACK200
N
Non-Ferrous Metal
200-500-1000 0.10- 0.30 -0.40 DL1000
SEC-Wave Radius Mill
WRCX 08000M / 10000M / 12000M Type
SEC-
Modular
Tools
P
Steel M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
N
Aluminum
S
Exotic Alloy
H
Hardened Steel
Inserts P
Steel
M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
S
Exotic Alloy
H
Hardened Stee
Grade
Coated Carbide
Carbide
DLC
90
Fig 1
S
Fig 2
Fig 3
S
IC
IC
RE
RE
IC
IC
RE
IC
IC S
Surfing Insert
Application
High Speed/Light
PKN
General Purpose
KN
Roughing K
Usage Cat. No.
ACP100
ACP200
ACP300
ACK200
ACK300
H1
DL1000
Inscribed
Circle
Corner
Radius
Thickness
Fig Applicable
Cutters
IC RE S
General
Purpose
*1
QPMT 080330 PPEN
8 3.0 3.18 1
WRCX08000M Type
080330 PPEN-H
8 3.0 3.18 1
QPMT 10T335 PPEN
10 3.5 3.97 1
WRCX10000M Type
10T335 PPEN-H
10 3.5 3.97 1
QPMT 120440 PPEN
12 4.0 4.76 1
WRCX12000M Type
120440 PPEN-H
12 4.0 4.76 1
Non-Ferrous
Metal
QPET
10T350 PPFR-S
10 5.0 3.97 2
WRCX10000M Type
QPET
120460 PPFR-S
12 6.0 4.76 2
WRCX12000M Type
Surfing
QPMT 120460 PPER-R
12 6.0 4.76 3
WRCX12000M Type
*1 -H: Strong edge.
4
(08000M Type)
5
(10000M Type)
6
(12000M Type)
0
3
Axial
Radial
Rake
Angle
Max. Depth of Cut Max. Depth of Cut Max. Depth of Cut
Parts
Screws Wrenches
Applicable Head
N m
BFTX02506IP
1.5 TRDR08IP WRCX08000M
BFTX03584IP
3.0 TRDR15IPWRCX10000M
BFTX0409IP
3.0 WRCX12000M
Anti-seizure cream SUMI-P included in the package.
Head (WRCX 12000M)
Cat. No.
Stock
Max.
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
DCX
DCON
CRKS
OAL
LF
LS2
LS
L11
H
WRCX 12040M16Z4
40 17.0
M16
63 40 5 23 10 24 4
Applicable Insert A = 12 mm Type
Inserts are not included.
Head (WRCX 10000M)
Cat. No.
Stock
Max.
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
DCX
DCON
CRKS
OAL
LF
LS2
LS
L11
H
WRCX 10025M12Z2
25 12.5
M12
56 35 5 21 10 19 2
10028M12Z2
28 12.5
M12
56 35 5 21 10 19 2
WRCX 10030M16Z3
30 17.0
M16
63 40 5 23 10 24 3
10032M16Z3
32 17.0
M16
63 40 5 23 10 24 3
Applicable Insert A = 10 mm Type
Inserts are not included.
Identification Details
WRCX 08 020 M10 Z2
(1)
Cutter Series
(2)
Insert size
(3)
Cutter Diameter
(4)
Mounting Screw Size
(5)
No. of Teeth
H
DCON
DCX
LF
OAL
LS
LS2
CRKS
L11
WRCX12000M Type
WRCX10000M Type
WRCX08000M Type
The cutting conditions above are a guide. Actual conditions will need to be adjusted
according to machine rigidity, work clamp rigidity, cutting depth, and other factors.
Note The cutting conditions above are a guide. Actual conditions will need to be adjusted
according to machine rigidity, work clamp rigidity, cutting depth, and other factors.
Note
H
N m
Recommended Tightening Torque N m
Dimensions (mm)
Dimensions (mm)
Dimensions (mm)
Dimensions mm
H155
Arbor
H149
H156H156
Shoulder
Milling
Radius
Groove/
T-Slot
High Feed
Multi-Purpose
Chamfering
Cutter
H156
Head (WFXC 08000M)
Cat. No.
Stock
Min.
Work Dia.
Max.
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
Weight
(kg)
DC1
DCX
DCON
CRKS
OAL
LF
LS2
LS
L11
H
WFXC 08016M08Z2
16 25.5 8.5
M8
42 25 5 17 8 13 2 0.1
* DC1 and DCON are the dimensions when a corner radius 0.8 insert is attached.
0
0
Axial
Radial
Rake
Angle
45
P
Steel M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
N
Aluminum
S
Exotic Alloy
H
Hardened Steel
SEC-Wave Mill
WFXC 08000M Type
SEC-
Modular
Tools
45
CRKS
H
DCON
L11
LS2
OAL
LSLF
DCX
DC1
Identification Details
WFX C 08 016 M08 Z2
(1)
Cutter Series
(3)
Insert Size
(2)
Chamfering
(4)
Cutter Diameter
(5)
Mounting Screw Size
(6)
No. of Teeth
Applicable Insert SOMT08 Type
Head (WFXC 12000M)
Cat. No.
Stock
Min.
Work Dia.
Max.
Diameter
Attachment
Diameter
Screw
To ta l
Length
Effective
Length
Length Shank
Side
Lock Flat
Width
No. of
Teeth
Weight
(kg)
DC1
DCX
DCON
CRKS
OAL
LF
LS2
LS
L11
H
WFXC 12025M12Z3
25 41.0 12.5
M12
56 32 5 21 10 19 3 0.1
12032M16Z3
32 48.0 17.0
M16
63 40 5 23 10 24 3 0.2
* DC1 and DCON are the dimensions when a corner radius 0.8 insert is attached.
Applicable Insert SOMT12 Type
H
Inserts P
Steel
M
Stainless Steel
K
Cast Iron
N
Non-Ferrous Metal
S
Exotic Alloy
H
Hardened Steel
Grade Coated Carbide Cermet DLC Cermet
Application
High Speed/Light
PKN
General Purpose
KNP
Roughing K
Cat. No.
ACP100
ACP200
ACP300
ACK200
ACK300
ACM200
ACM300
H1
DL1000
T4500A
Corner
Radius
Fig
RE
Fig 2
4.76
12.7
12.7
RE
Fig 1
3.175
8.0
8.0
RE
SOMT 080304PZER-L 0.4 1
080308PZER-L 0.8 1
SOMT 080304PZER-G 0.4 1
080308PZER-G 0.8 1
080312PZER-G 1.2 1
SOMT 080308PZER-H 0.8 1
080312PZER-H 1.2 1
SOET
080304PZER-G 0.4 1
080308PZER-G 0.8 1
080312PZER-G 1.2 1
SOET
080302PZFR-S 0.2 1
080304PZFR-S 0.4 1
080308PZFR-S 0.8 1
SOMT
120408PDER-L 0.8 2
SOMT
120404PDER-G 0.4 2
120408PDER-G 0.8 2
120412PDER-G 1.2 2
120416PDER-G 1.6 2
SOMT
120408PDER-H 0.8 2
SOET
120408PDFR-S 0.8 2
Recommended Cutting Conditions
ISO
Work
Material Hardness
Cutting Speed vc (m/min)
Min. - Optimum - Max.
Feed Rate
fz
(mm/t)
Min. - Optimum - Max.
P
General Steel
180 to 280HB 150-200-250 0.05-0.10-0.15
Soft Steel ≤180HB 180-265-350 0.10-0.15-0.20
Die Steel 200 to 220HB 100-150-200 0.05-0.10-0.15
M
Stainless Steel
150-200-250 0.05-0.10-0.15
KCast Iron 250HB 100-175-250 0.05-0.10-0.15
The cutting conditions above are a guide. Actual conditions will need to be adjusted
according to machine rigidity, work clamp rigidity, cutting depth, and other factors.
Note
Parts
Applicable Cutters
Screws Wrenches
N m
WFXC08000M BFTX0306IP1.5 TRDR08IP
WFXC12000M BFTX03512IP3.0 TRDR15IP
N m
Recommended Tightening Torque N m
Anti-seizure cream SUMI-P included in the package.
CAUTION
H124
Dimensions (mm)
Dimensions (mm)
Dimensions (mm)
Arbor
H149
