Каталог Sumitomo монолитные фрезы

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

mark: Standard stocked item

mark:

To be replaced by a new item featured on the same page.

mark: To be replaced by new item

(Please confirm stock availability)

mark:

Semi-standard stock (Please confirm stock availability)

mark:

Stock or planned stock (Please confirm stock availability)

No mark: Made-to-order item

mark: We cannot produce

Stock Indications and Symbols

Endmills

GSX MILL 2 Flutes

GSX MILL 3 Flutes

GSX MILL Slot 3 Flutes

UP MILL 3 Flutes

GSX MILL 4 Flutes

GSX MILL Anti-vibration 4 Flutes

GSX MILL 4 Flutes

GS MILL Roughing 4 Flutes

GS MILL Hard 4 /6 /8 Flutes

Hard HHM 4 /6 /8 Flutes

Hard LHHM 4 /6 /8 Flutes

Hard EHHM 4 /6 /8 Flutes

UP MILL 4 Flutes

Deep Shoulder UP MILL 4 Flutes

GSX MILL 4 Flutes

GSX MILL Anti-vibration 4 Flutes

SSEH Anti-vibration for Exotic Alloys 4 Flutes

SSEH for Exotic Alloys 4 Flutes

UP MILL 4 Flutes

Deep Shoulder UP MILL 4 Flutes

GS MILL Hard 6 /8 Flutes

GSX MILL Ballnose 2 Flutes

GS MILL Ballnose 2 Flutes

GS MILL Hard Ballnose 2 Flutes

AURORA Coat for Non-Ferrous Metal 2 /4 Flutes

AURORA Coat Ballnose for Non-Ferrous Metal 2 Flutes

AURORA Coat Long Neck Ballnose for Copper Electrodes 2 Flutes

Spiral SSM/LSM/ELSM 2 Flutes

Non-Ferrous Metals 2 Flutes

Spiral SSM/LSM/ELSM 4 Flutes

SSEH Anti-vibration for Exotic Alloys 4 Flutes

SSEH for Exotic Alloys 4 Flutes

Mold Finish Master 1 Flute

SUMIDIA Coated Ballnose Endmills

Mold Finish Master 2 Flutes

SUMIDIA Coated Endmills for CFRP 4 Flutes

SUMIBORON Helical Master 2 Flutes

SUMIBORON Ballnose 2 Flutes

SUMIDIA for Non-Ferrous Metal 2 /4 Flutes

SUMIDIA for Non-Ferrous Metal 1 Flute/2 Flutes

Endmills

I1 to I145

Square

Binderless PCD for

Carbide /

Diamond Coat /

Hardened Steel CBN /

Non-Ferrous Metal PCD

Radius

Solid Carbide

(Uncoated)

List of Maximum Depth of Cut by Diameter

1-1

Endmill Selection Guide

Coatings for Endmills

GSX MILL Series

SUMIDIA Coated Endmill Series

SSEH Series

SAFE-LOCK Applicable Endmill Series

GS MILL HARD Series

AURORA Coat Endmill Series

MOLD FINISH MASTER Series

GSX 20000C-1.5D

GSX 20000S-2D/20000C-2D

22,

GSX 20000S-3D/20000C-3D

28,

GSX 20000S-4D/20000C-4D

32,

GSX 30000C-1.5D

GSX 30000C-2D

GSXSLT 30000C-1.5D

SSUP 3000ZX

GSX 40000C-1.5D

GSX 40000S-2D/40000C-2D

46,

GSV 4000-2.5D

GSXVL 4000-2.5D/4000S-2.5D

52,

GSX 40000S-3D/40000C-3D

56,

GSX 40000S-4D/40000C-4D

60,

GSRE 4000SF

GSH 4000SF/6000SF/8000SF

66,

67,

HHM 4000ZX/6000ZX/8000ZX

69,

70,

LHHM 4000ZX/6000ZX/8000ZX

72,

73,

EHHM 4000ZX/6000ZX/8000ZX

75,

76,

SSUP 4000ZX

SSUPR 4000ZX

GSX 40000-R-2D

GSV 4000-R-2.5D

GSXVL 4000-R-2.5D/4000S-R-2.5D

84,

SSEHVL 4000W-R/4000WS-R

88,

SSEH 4000W-R/4000WS-R

92,

SSUP 4000ZX-R

SSUPR 4000ZX-R

GSH 6000SF-R/8000SF-R

100,

101

GSXB 20000

102

GLB 2000SF

104

GSBH 20000SF

106

ASM 2000DL/4000DL

107,

108

SNB 2000DL

109

SNB2

110

SSM 2000 / LSM 2000 / ELSM 2000

112,

116,

118

ASM 2000

120

SSM 4000 / LSM 4000 / ELSM 4000

122,

124,

126

SSEHVL 4000-R

128

SSEH 4000-R

129

NPDBS / NPDB / NPDRS

130,

131,

132

SDCB

133

BNBR / BNBP / BNBC

134,

136,

138

SSDC 4000(RL)

139

Helical Master BNES

140

Ball Endmills BNBS

141

DFE

142,

143

DAE

144,

145

DLC Coat /

Long Neck

Ballnose

I1-1

List of Maximum Depth of Cut by Diameter

FLUTE LENGTH BY DRILL DIAMETER

Endmills

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

0.2 0.5

SSM 2002

40.0 I112

0.3 0.6

GSX 20030S-2D

40.0 I22

1.0

SSM 2003

40.0 I112

0.4 0.8

GSX 20040S-2D

40.0 I22

1.0

SSM 2004

40.0 I112

0.5

1.0

GSX 20050C-1.5D

40.0 I20

GSX 20050C-2D

40.0 I26

1.3

GSX 20050S-2D

40.0 I22

1.5

GSX 20050C-3D

40.0 I30

GSX 20050S-3D

40.0 I28

SSM 2005

40.0 I112

2.0

GSX 20050C-4D

40.0 I34

GSX 20050S-4D

40.0 I32

0.6 1.3

GSX 20060S-2D

40.0 I22

1.5

SSM 2006

40.0 I112

0.7 1.4

GSX 20070S-2D

40.0 I22

1.5

SSM 2007

40.0 I112

0.8 1.6

GSX 20080S-2D

40.0 I22

2.0

SSM 2008

40.0 I112

0.9 1.8

GSX 20090S-2D

40.0 I22

2.0

SSM 2009

40.0 I112

1.0

1.5

GSX 20100C-1.5D

40.0 I20

GSX 30100C-1.5D

40.0 I36

GSX 40100C-1.5D

40.0 I44

GSXSLT 30100C-1.5D

40.0 I40

2.0

GSX 20100C-2D

40.0 I26

GSX 40100C-2D

40.0 I48

2.5

GSX 20100S-2D

40.0 I22

GSX 30100C-2D

40.0 I38

GSX 40100S-2D

40.0 I46

GSX 40100S-2D-S3

38.0 I46

3.0

GSH 4010SF

50.0 I66

GSX 20100C-3D

40.0 I30

GSX 20100S-3D

40.0 I28

GSX 40100C-3D

40.0 I58

GSX 40100S-3D

40.0 I56

SSM 2010

40.0 I112

4.0

GSX 20100C-4D

40.0 I34

GSX 40100C-4D

40.0 I62

GSX 40100S-4D

40.0 I60

5.0

GSX 20100S-4D

40.0 I32

1.1 2.5

GSX 20110S-2D

40.0 I22

3.0

SSM 2011

40.0 I112

1.2 2.5

GSX 20120S-2D

40.0 I22

3.0

SSM 2012

40.0 I112

1.3 2.6

GSX 20130S-2D

40.0 I22

3.0

SSM 2013

40.0 I112

1.4 2.8

GSX 20140S-2D

40.0 I22

3.0

SSM 2014

40.0 I112

1.5

2.3

GSX 20150C-1.5D

40.0 I20

GSX 30150C-1.5D

40.0 I36

GSX 40150C-1.5D

40.0 I44

GSXSLT 30150C-1.5D

40.0 I40

3.0

GSX 20150C-2D

40.0 I26

GSX 40150C-2D

40.0 I48

3.8

GSX 20150S-2D

40.0 I22

GSX 20150S-2D-S3

38.0 I22

GSX 30150C-2D

40.0 I38

GSX 40150S-2D

40.0 I46

4.0

GSH 4015SF

50.0 I66

4.5

GSX 20150C-3D

40.0 I30

GSX 20150S-3D

40.0 I28

GSX 40150C-3D

40.0 I58

GSX 40150S-3D

40.0 I56

5.0

SSM 2015

40.0 I112

SSM 4015

40.0 I122

6.0

GSX 20150C-4D

40.0 I34

GSX 40150C-4D

40.0 I62

GSX 40150S-4D

40.0 I60

7.0

GSX 20150S-4D

40.0 I32

1.6 3.8

GSX 20160S-2D

40.0 I22

5.0

SSM 2016

40.0 I112

1.7 3.8

GSX 20170S-2D

40.0 I22

5.0

SSM 2017

40.0 I112

1.8 3.8

GSX 20180S-2D

40.0 I22

5.0

SSM 2018

40.0 I112

1.9 3.8

GSX 20190S-2D

40.0 I22

5.0

SSM 2019

40.0 I112

2.0 3.0

GSX 20200C-1.5D

40.0 I20

GSX 30200C-1.5D

40.0 I36

Diameter ø0.2 to ø2.0mm

Square

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

2.0

3.0

GSX 40200C-1.5D

40.0 I44

GSXSLT 30200C-1.5D

40.0 I40

4.0

GSX 20200C-2D

40.0 I26

GSX 40200C-2D

40.0 I48

5.0

GSV 4020-2.5D

50.0 I50

GSX 20200S-2D

40.0 I22

GSX 20200S-2D-S3

38.0 I22

GSX 30200C-2D

40.0 I38

GSX 40200S-2D

40.0 I46

GSX 40200S-2D-S3

38.0 I46

GSXVL 4020-2.5D

50.0 I52

6.0

ASM 2020

40.0 I120

ASM 2020DL

40.0 I107

ASM 4020DL

40.0 I108

GSH 4020SF

50.0 I66

GSX 20200C-3D

40.0 I30

GSX 20200S-3D

40.0 I28

GSX 40200C-3D

40.0 I58

GSX 40200S-3D

40.0 I56

SSM 2020

40.0 I112

SSM 4020

40.0 I122

SSUP 3020ZX

50.0 I42

SSUP 4020ZX

50.0 I78

8.0

GSX 20200C-4D

40.0 I34

GSX 40200C-4D

40.0 I62

GSX 40200S-4D

40.0 I60

9.0

GSX 20200S-4D

40.0 I32

2.1 6.0

GSX 20210S-2D

40.0 I22

SSM 2021

40.0 I112

2.2 6.0

GSX 20220S-2D

40.0 I22

SSM 2022

40.0 I112

2.3 6.0

GSX 20230S-2D

40.0 I22

SSM 2023

40.0 I112

2.4 6.0

GSX 20240S-2D

40.0 I22

SSM 2024

40.0 I112

2.5

3.8

GSX 20250C-1.5D

40.0 I20

GSX 30250C-1.5D

40.0 I36

GSX 40250C-1.5D

40.0 I44

GSXSLT 30250C-1.5D

40.0 I40

5.0

GSX 20250C-2D

40.0 I26

GSX 40250C-2D

40.0 I48

6.3

GSX 20250S-2D

40.0 I22

GSX 30250C-2D

40.0 I38

GSX 40250S-2D

40.0 I46

7.5

GSX 20250C-3D

40.0 I30

GSX 20250S-3D

40.0 I28

GSX 40250C-3D

40.0 I58

8.0

GSX 40250S-3D

40.0 I56

SSM 2025

40.0 I112

SSM 4025

40.0 I122

SSUP 3025ZX

50.0 I42

10.0

GSX 20250C-4D

50.0 I34

GSX 40250C-4D

50.0 I62

GSX 40250S-4D

50.0 I60

12.0

GSX 20250S-4D

50.0 I32

2.6

7.0

GSX 20260S-2D

40.0 I22

8.0

GSX 20260S-3D

50.0 I28

SSM 2026

40.0 I112

2.7

7.0

GSX 20270S-2D

40.0 I22

8.0

SSM 2027

40.0 I112

8.5

GSX 20270S-3D

50.0 I28

2.8

7.0

GSX 20280S-2D

40.0 I22

8.0

SSM 2028

40.0 I112

9.0

GSX 20280S-3D

50.0 I28

2.9

7.0

GSX 20290S-2D

40.0 I22

8.0

SSM 2029

40.0 I112

9.0

GSX 20290S-3D

50.0 I28

3.0

4.5

GSX 20300C-1.5D

45.0 I20

GSX 30300C-1.5D

45.0 I36

GSX 40300C-1.5D

45.0 I44

GSXSLT 30300C-1.5D

45.0 I40

SSUPR 4030ZX

60.0 I79

6.0

GSX 20300C-2D

45.0 I26

GSX 40300C-2D

45.0 I48

7.5

GSX 20300S-2D

45.0 I22

GSX 20300S-2D-S3

38.0 I22

GSX 30300C-2D

45.0 I38

GSX 40300S-2D

45.0 I46

GSX 40300S-2D-S3

38.0 I46

8.0

GSH 6030SF

50.0 I67

Diameter ø2.0 to ø3.0mm

Square

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

3.0

8.0

GSV 4030-2.5D

50.0 I50

GSXVL 4030-2.5D

50.0 I52

HHM 4030ZX

50.0 I69

SSM 2030

45.0 I112

SSM 4030

45.0 I122

SSUP 3030ZX

50.0 I42

SSUP 4030ZX

50.0 I78

9.0

GSX 20300C-3D

50.0 I30

GSX 20300S-3D

50.0 I28

GSX 40300C-3D

50.0 I58

GSX 40300S-3D

50.0 I56

10.0

ASM 2030

45.0 I120

ASM 2030DL

45.0 I107

ASM 4030DL

45.0 I108

12.0

GSX 20300C-4D

50.0 I34

GSX 20300S-4D

50.0 I32

GSX 40300C-4D

50.0 I62

GSX 40300S-4D

50.0 I60

LHHM 4030ZX

55.0 I72

20.0

EHHM 4030ZX

60.0 I75

3.1 7.5

GSX 20310S-2D

45.0 I22

8.0

SSM 2031

45.0 I112

3.2 7.5

GSX 20320S-2D

45.0 I22

8.0

SSM 2032

45.0 I112

3.3 7.5

GSX 20330S-2D

45.0 I22

8.0

SSM 2033

45.0 I112

3.4 7.5

GSX 20340S-2D

45.0 I22

8.0

SSM 2034

45.0 I112

3.5

5.3

GSX 20350C-1.5D

45.0 I20

GSX 40350C-1.5D

45.0 I44

7.0

GSX 20350C-2D

45.0 I26

GSX 40350C-2D

45.0 I48

8.0

SSM 2035

45.0 I112

SSM 4035

45.0 I122

8.8

GSX 20350S-2D

45.0 I22

GSX 40350S-2D

45.0 I46

10.0

SSUP 3035ZX

50.0 I42

11.0

GSX 20350C-3D

50.0 I30

GSX 40350C-3D

50.0 I58

GSX 40350S-3D

50.0 I56

12.0

GSX 20350S-3D

50.0 I28

14.0

GSX 20350C-4D

50.0 I34

GSX 20350S-4D

50.0 I32

GSX 40350C-4D

50.0 I62

GSX 40350S-4D

50.0 I60

3.6 8.8

GSX 20360S-2D

45.0 I22

10.0

SSM 2036

45.0 I112

3.7 8.8

GSX 20370S-2D

45.0 I22

10.0

SSM 2037

45.0 I112

3.8 8.8

GSX 20380S-2D

45.0 I22

10.0

SSM 2038

45.0 I112

3.9 8.8

GSX 20390S-2D

45.0 I22

10.0

SSM 2039

45.0 I112

4.0

6.0

GSX 20400C-1.5D

45.0 I20

GSX 30400C-1.5D

45.0 I36

GSX 40400C-1.5D

45.0 I44

GSXSLT 30400C-1.5D

45.0 I40

SSUPR 4040ZX

60.0 I79

8.0

GSX 20400C-2D

45.0 I26

GSX 40400C-2D

45.0 I48

10.0

GSV 4040-2.5D

50.0 I50

GSXVL 4040-2.5D

50.0 I52

HHM 4040ZX

50.0 I69

SSM 2040

45.0 I112

SSM 4040

45.0 I122

11.0

GSH 6040SF

50.0 I67

GSX 20400S-2D

45.0 I22

GSX 20400S-2D-S4

45.0 I22

GSX 30400C-2D

45.0 I38

GSX 40400S-2D

45.0 I46

GSX 40400S-2D-S4

45.0 I46

SSUP 3040ZX

50.0 I42

SSUP 4040ZX

50.0 I78

12.0

ASM 2040

45.0 I120

ASM 2040DL

45.0 I107

ASM 4040DL

45.0 I108

GSX 20400C-3D

50.0 I30

GSX 20400S-3D

50.0 I28

GSX 40400C-3D

50.0 I58

GSX 40400S-3D

50.0 I56

Diameter ø3.0 to ø4.0mm

Square

I1-2

List of Maximum Depth of Cut by Diameter

FLUTE LENGTH BY DRILL DIAMETER

Endmills

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

4.0

15.0

LHHM 4040ZX

60.0 I72

16.0

GSX 20400C-4D

50.0 I34

GSX 20400S-4D

50.0 I32

GSX 40400C-4D

50.0 I62

GSX 40400S-4D

50.0 I60

25.0

EHHM 4040ZX

65.0 I75

4.1 10.0

SSM 2041

45.0 I112

11.0

GSX 20410S-2D

45.0 I22

4.2 10.0

SSM 2042

45.0 I112

11.0

GSX 20420S-2D

45.0 I22

4.3 10.0

SSM 2043

45.0 I112

11.0

GSX 20430S-2D

45.0 I22

4.4 10.0

SSM 2044

45.0 I112

11.0

GSX 20440S-2D

45.0 I22

4.5

6.8

GSX 20450C-1.5D

50.0 I20

GSX 40450C-1.5D

50.0 I44

9.0

GSX 20450C-2D

50.0 I26

GSX 40450C-2D

50.0 I48

10.0

SSM 2045

45.0 I112

SSM 4045

45.0 I122

11.0

SSUP 3045ZX

50.0 I42

11.3

GSX 20450S-2D

50.0 I22

GSX 40450S-2D

50.0 I46

14.0

GSX 20450C-3D

50.0 I30

GSX 40450C-3D

50.0 I58

15.0

GSX 20450S-3D

50.0 I28

GSX 40450S-3D

50.0 I56

18.0

GSX 20450C-4D

60.0 I34

GSX 20450S-4D

60.0 I32

GSX 40450C-4D

60.0 I62

GSX 40450S-4D

60.0 I60

4.6 11.3

GSX 20460S-2D

50.0 I22

12.0

SSM 2046

50.0 I112

4.7 11.3

GSX 20470S-2D

50.0 I22

12.0

SSM 2047

50.0 I112

4.8 11.3

GSX 20480S-2D

50.0 I22

12.0

SSM 2048

50.0 I112

4.9 11.3

GSX 20490S-2D

50.0 I23

12.0

SSM 2049

50.0 I112

5.0

7.5

GSX 20500C-1.5D

50.0 I20

GSX 30500C-1.5D

50.0 I36

GSX 40500C-1.5D

50.0 I44

GSXSLT 30500C-1.5D

50.0 I40

SSUPR 4050ZX

60.0 I79

10.0

GSX 20500C-2D

50.0 I26

GSX 40500C-2D

50.0 I48

12.0

HHM 4050ZX

50.0 I69

SSM 2050

50.0 I112

SSM 4050

50.0 I122

13.0

GSH 6050SF

50.0 I67

GSV 4050-2.5D

60.0 I50

GSX 20500S-2D

50.0 I23

GSX 30500C-2D

50.0 I38

GSX 40500S-2D

50.0 I46

GSXVL 4050-2.5D

60.0 I52

SSUP 3050ZX

60.0 I42

SSUP 4050ZX

60.0 I78

15.0

ASM 2050

50.0 I120

ASM 2050DL

50.0 I107

ASM 4050DL

50.0 I108

GSX 20500C-3D

50.0 I30

GSX 20500S-3D

50.0 I28

GSX 40500C-3D

50.0 I58

GSX 40500S-3D

50.0 I56

18.0

LHHM 4050ZX

60.0 I72

20.0

GSX 20500C-4D

60.0 I34

GSX 20500S-4D

60.0 I32

GSX 40500C-4D

60.0 I62

GSX 40500S-4D

60.0 I60

30.0

EHHM 4050ZX

70.0 I75

5.1 12.0

SSM 2051

50.0 I112

13.0

GSX 20510S-2D

50.0 I23

5.2 12.0

SSM 2052

50.0 I113

13.0

GSX 20520S-2D

50.0 I23

5.3 12.0

SSM 2053

50.0 I113

13.0

GSX 20530S-2D

50.0 I23

5.4 12.0

SSM 2054

50.0 I113

13.0

GSX 20540S-2D

50.0 I23

5.5 8.3

GSX 20550C-1.5D

50.0 I20

GSX 40550C-1.5D

50.0 I44

Diameter ø4.0 to ø5.5mm

Square

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

5.5

11.0

GSX 20550C-2D

50.0 I26

GSX 40550C-2D

50.0 I48

12.0

SSM 2055

50.0 I113

SSM 4055

50.0 I122

13.0

GSX 20550S-2D

50.0 I23

GSX 40550S-2D

50.0 I46

13.0

SSUP 3055ZX

60.0 I42

17.0

GSX 20550C-3D

50.0 I30

GSX 40550C-3D

50.0 I58

18.0

GSX 20550S-3D

50.0 I28

GSX 40550S-3D

50.0 I56

22.0

GSX 20550C-4D

60.0 I34

GSX 20550S-4D

60.0 I32

GSX 40550C-4D

60.0 I62

GSX 40550S-4D

60.0 I60

5.6 12.0

SSM 2056

50.0 I113

13.0

GSX 20560S-2D

50.0 I23

5.7 12.0

SSM 2057

50.0 I113

13.0

GSX 20570S-2D

50.0 I23

5.8 12.0

SSM 2058

50.0 I113

13.0

GSX 20580S-2D

50.0 I23

5.9 12.0

SSM 2059

50.0 I113

13.0

GSX 20590S-2D

50.0 I23

6.0

9.0

GSX 20600C-1.5D

50.0 I20

GSX 30600C-1.5D

50.0 I36

GSX 40600C-1.5D

50.0 I44

GSXSLT 30600C-1.5D

50.0 I40

SSUPR 4060ZX

60.0 I79

12.0

GSX 20600C-2D

50.0 I26

GSX 40600C-2D

50.0 I48

HHM 6060ZX

50.0 I70

SSM 2060

50.0 I113

SSM 4060

50.0 I122

13.0

GSH 6060SF

50.0 I67

GSRE 4060SF

50.0 I64

GSX 20600S-2D

50.0 I23

GSX 30600C-2D

50.0 I38

GSX 40600S-2D

50.0 I46

SSUP 3060ZX

60.0 I42

SSUP 4060ZX

60.0 I78

15.0

ASM 2060

50.0 I120

ASM 2060DL

50.0 I107

ASM 4060DL

50.0 I108

GSV 4060-2.5D

60.0 I50

GSXVL 4060-2.5D

60.0 I52

18.0

GSX 20600C-3D

50.0 I30

GSX 20600S-3D

50.0 I28

GSX 40600C-3D

50.0 I58

GSX 40600S-3D

50.0 I56

LHHM 6060ZX

60.0 I73

24.0

GSX 20600C-4D

60.0 I34

GSX 20600S-4D

60.0 I32

GSX 40600C-4D

60.0 I62

GSX 40600S-4D

60.0 I60

30.0

EHHM 6060ZX

70.0 I76

6.1 12.0

SSM 2061

50.0 I113

13.0

GSX 20610S-2D

50.0 I23

6.2 12.0

SSM 2062

50.0 I113

13.0

GSX 20620S-2D

50.0 I23

6.3 12.0

SSM 2063

50.0 I113

13.0

GSX 20630S-2D

50.0 I23

6.4 12.0

SSM 2064

50.0 I113

13.0

GSX 20640S-2D

50.0 I23

6.5

10.0

GSX 20650C-1.5D

60.0 I20

GSX 40650C-1.5D

60.0 I44

12.0

SSM 2065

50.0 I113

SSM 4065

50.0 I122

13.0

GSX 20650C-2D

60.0 I26

GSX 20650S-2D

60.0 I23

GSX 40650C-2D

60.0 I48

GSX 40650S-2D

60.0 I46

16.0

SSUP 3065ZX

70.0 I42

20.0

GSX 20650C-3D

70.0 I30

GSX 20650S-3D

70.0 I28

GSX 40650C-3D

70.0 I58

GSX 40650S-3D

70.0 I56

26.0

GSX 20650C-4D

70.0 I34

GSX 20650S-4D

70.0 I32

GSX 40650C-4D

70.0 I62

GSX 40650S-4D

70.0 I60

Diameter ø5.5 to ø6.5mm

Square

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

6.6 13.2

GSX 20660S-2D

60.0 I23

15.0

SSM 2066

55.0 I113

6.7 13.4

GSX 20670S-2D

60.0 I23

15.0

SSM 2067

55.0 I113

6.8 13.6

GSX 20680S-2D

60.0 I23

15.0

SSM 2068

55.0 I113

6.9 13.8

GSX 20690S-2D

60.0 I23

15.0

SSM 2069

55.0 I113

7.0

10.5

SSUPR 4070ZX

80.0 I79

11.0

GSX 20700C-1.5D

60.0 I20

GSX 30700C-1.5D

60.0 I36

GSX 40700C-1.5D

60.0 I44

GSXSLT 30700C-1.5D

60.0 I40

14.0

GSX 20700C-2D

60.0 I26

GSX 40700C-2D

60.0 I48

15.0

SSM 2070

55.0 I113

SSM 4070

55.0 I122

16.0

GSRE 4070SF

60.0 I64

GSX 20700S-2D

60.0 I23

GSX 30700C-2D

60.0 I38

GSX 40700S-2D

60.0 I46

SSUP 3070ZX

70.0 I42

SSUP 4070ZX

70.0 I78

18.0

GSV 4070-2.5D

70.0 I50

GSXVL 4070-2.5D

70.0 I52

21.0

GSX 20700C-3D

70.0 I30

GSX 20700S-3D

70.0 I28

GSX 40700C-3D

70.0 I58

GSX 40700S-3D

70.0 I56

28.0

GSX 20700C-4D

80.0 I34

GSX 20700S-4D

80.0 I32

GSX 40700C-4D

80.0 I62

GSX 40700S-4D

80.0 I60

7.1 15.0

SSM 2071

55.0 I113

16.0

GSX 20710S-2D

60.0 I23

7.2 15.0

SSM 2072

55.0 I113

16.0

GSX 20720S-2D

60.0 I23

7.3 15.0

SSM 2073

55.0 I113

16.0

GSX 20730S-2D

60.0 I23

7.4 15.0

SSM 2074

55.0 I113

16.0

GSX 20740S-2D

60.0 I23

7.5

12.0

GSX 20750C-1.5D

60.0 I20

GSX 40750C-1.5D

60.0 I44

15.0

GSX 20750C-2D

60.0 I26

GSX 40750C-2D

60.0 I48

SSM 2075

55.0 I113

SSM 4075

55.0 I122

16.0

GSX 20750S-2D

60.0 I23

GSX 40750S-2D

60.0 I46

SSUP 3075ZX

70.0 I42

23.0

GSX 20750C-3D

70.0 I30

GSX 20750S-3D

70.0 I28

GSX 40750C-3D

70.0 I58

GSX 40750S-3D

70.0 I56

30.0

GSX 20750C-4D

80.0 I34

GSX 20750S-4D

80.0 I32

GSX 40750C-4D

80.0 I62

GSX 40750S-4D

80.0 I60

7.6 15.0

SSM 2076

55.0 I113

16.0

GSX 20760S-2D

60.0 I23

7.7 15.0

SSM 2077

55.0 I113

16.0

GSX 20770S-2D

60.0 I23

7.8 15.0

SSM 2078

55.0 I113

16.0

GSX 20780S-2D

60.0 I23

7.9 15.0

SSM 2079

55.0 I113

16.0

GSX 20790S-2D

60.0 I23

8.0

12.0

GSX 20800C-1.5D

60.0 I20

GSX 30800C-1.5D

60.0 I36

GSX 40800C-1.5D

60.0 I44

GSXSLT 30800C-1.5D

60.0 I40

SSUPR 4080ZX

80.0 I79

15.0

SSM 2080

55.0 I113

SSM 4080

55.0 I122

16.0

GSX 20800C-2D

60.0 I26

GSX 40800C-2D

60.0 I48

HHM 6080ZX

60.0 I70

18.0

ASM 2080

60.0 I120

ASM 2080DL

60.0 I107

ASM 4080DL

60.0 I108

19.0

GSH 6080SF

60.0 I67

Diameter ø6.6 to ø8.0mm

Square

I1-3

List of Maximum Depth of Cut by Diameter

FLUTE LENGTH BY DRILL DIAMETER

Endmills

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

8.0

19.0

GSRE 4080SF

60.0 I64

GSX 20800S-2D

60.0 I23

GSX 30800C-2D

60.0 I38

GSX 40800S-2D

60.0 I46

SSUP 3080ZX

80.0 I42

SSUP 4080ZX

80.0 I78

20.0

GSV 4080-2.5D

80.0 I50

GSXVL 4080-2.5D

80.0 I52

24.0

GSX 20800C-3D

70.0 I30

GSX 20800S-3D

70.0 I28

GSX 40800C-3D

70.0 I58

GSX 40800S-3D

70.0 I56

25.0

LHHM 6080ZX

75.0 I73

32.0

GSX 20800C-4D

80.0 I34

GSX 20800S-4D

80.0 I32

GSX 40800C-4D

80.0 I62

GSX 40800S-4D

80.0 I60

40.0

EHHM 6080ZX

90.0 I76

8.1 15.0

SSM 2081

55.0 I113

19.0

GSX 20810S-2D

60.0 I23

8.2 15.0

SSM 2082

55.0 I113

19.0

GSX 20820S-2D

60.0 I23

8.3 15.0

SSM 2083

55.0 I113

19.0

GSX 20830S-2D

60.0 I23

8.4 15.0

SSM 2084

55.0 I113

19.0

GSX 20840S-2D

60.0 I23

8.5

13.0

GSX 20850C-1.5D

70.0 I20

GSX 40850C-1.5D

70.0 I44

15.0

SSM 2085

55.0 I113

SSM 4085

55.0 I122

17.0

GSX 20850C-2D

70.0 I26

GSX 40850C-2D

70.0 I48

19.0

GSX 20850S-2D

70.0 I23

GSX 40850S-2D

70.0 I46

SSUP 3085ZX

90.0 I42

26.0

GSX 20850C-3D

75.0 I30

GSX 20850S-3D

75.0 I28

GSX 40850C-3D

75.0 I58

GSX 40850S-3D

75.0 I56

34.0

GSX 20850C-4D

90.0 I34

GSX 20850S-4D

90.0 I32

GSX 40850C-4D

90.0 I62

GSX 40850S-4D

90.0 I60

8.6 15.0

SSM 2086

55.0 I113

19.0

GSX 20860S-2D

70.0 I23

8.7 15.0

SSM 2087

55.0 I113

19.0

GSX 20870S-2D

70.0 I23

8.8 15.0

SSM 2088

55.0 I113

19.0

GSX 20880S-2D

70.0 I23

8.9 15.0

SSM 2089

55.0 I113

19.0

GSX 20890S-2D

70.0 I23

9.0

13.5

SSUPR 4090ZX

90.0 I79

14.0

GSX 20900C-1.5D

70.0 I20

GSX 30900C-1.5D

70.0 I36

GSX 40900C-1.5D

70.0 I44

GSXSLT 30900C-1.5D

70.0 I40

15.0

SSM 2090

55.0 I113

SSM 4090

55.0 I122

18.0

GSX 20900C-2D

70.0 I26

GSX 40900C-2D

70.0 I48

19.0

GSRE 4090SF

70.0 I64

GSX 20900S-2D

70.0 I23

GSX 30900C-2D

70.0 I38

GSX 40900S-2D

70.0 I46

SSUP 3090ZX

90.0 I42

SSUP 4090ZX

90.0 I78

23.0

GSV 4090-2.5D

90.0 I50

GSXVL 4090-2.5D

90.0 I52

27.0

GSX 20900C-3D

75.0 I30

GSX 20900S-3D

75.0 I28

GSX 40900C-3D

75.0 I58

GSX 40900S-3D

75.0 I56

36.0

GSX 20900C-4D

90.0 I34

GSX 20900S-4D

90.0 I32

GSX 40900C-4D

90.0 I62

GSX 40900S-4D

90.0 I60

9.1 15.0

SSM 2091

55.0 I113

19.0

GSX 20910S-2D

70.0 I23

9.2 15.0

SSM 2092

55.0 I113

19.0

GSX 20920S-2D

70.0 I23

Diameter ø8.0 to ø9.2mm

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

9.3 15.0

SSM 2093

55.0 I113

19.0

GSX 20930S-2D

70.0 I23

9.4 15.0

SSM 2094

55.0 I113

19.0

GSX 20940S-2D

70.0 I23

9.5

15.0

GSX 20950C-1.5D

70.0 I20

GSX 40950C-1.5D

70.0 I44

SSM 2095

55.0 I113

SSM 4095

55.0 I122

19.0

GSX 20950C-2D

70.0 I26

GSX 40950C-2D

70.0 I48

GSX 40950S-2D

70.0 I46

SSUP 3095ZX

90.0 I42

20.0

GSX 20950S-2D

70.0 I23

29.0

GSX 20950C-3D

75.0 I30

GSX 20950S-3D

75.0 I28

GSX 40950C-3D

75.0 I58

GSX 40950S-3D

75.0 I56

38.0

GSX 20950C-4D

90.0 I34

GSX 20950S-4D

90.0 I32

39.0

GSX 40950C-4D

90.0 I62

GSX 40950S-4D

90.0 I60

9.6 18.0

SSM 2096

65.0 I113

20.0

GSX 20960S-2D

70.0 I23

9.7 18.0

SSM 2097

65.0 I113

20.0

GSX 20970S-2D

70.0 I23

9.8 18.0

SSM 2098

65.0 I113

20.0

GSX 20980S-2D

70.0 I23

9.9 18.0

SSM 2099

65.0 I113

20.0

GSX 20990S-2D

70.0 I24

10.0

15.0

GSX 21000C-1.5D

70.0 I20

GSX 31000C-1.5D

70.0 I36

GSX 41000C-1.5D

70.0 I44

GSXSLT 31000C-1.5D

70.0 I40

SSUPR 4100ZX

100.0 I79

18.0

SSM 2100

65.0 I113

SSM 4100

65.0 I122

20.0

GSX 21000C-2D

70.0 I26

GSX 41000C-2D

70.0 I48

HHM 6100ZX

71.0 I70

22.0

ASM 2100

71.0 I120

ASM 2100DL

71.0 I107

GSH 6100SF

70.0 I67

GSRE 4100SF

70.0 I64

GSX 21000S-2D

70.0 I24

GSX 31000C-2D

70.0 I38

GSX 41000S-2D

70.0 I46

SSUP 3100ZX

90.0 I42

SSUP 4100ZX

90.0 I78

25.0

GSV 4100-2.5D

90.0 I50

GSXVL 4100-2.5D

90.0 I52

30.0

GSX 21000C-3D

90.0 I30

GSX 21000S-3D

90.0 I28

GSX 41000C-3D

90.0 I58

GSX 41000S-3D

90.0 I56

LHHM 6100ZX

80.0 I73

40.0

GSX 21000C-4D

90.0 I34

GSX 21000S-4D

90.0 I32

GSX 41000C-4D

90.0 I62

GSX 41000S-4D

90.0 I60

50.0

EHHM 6100ZX

100.0 I76

22.0

ASM 4100DL

71.0 I108

10.5

16.0

GSX 21050C-1.5D

75.0 I20

GSX 41050C-1.5D

75.0 I44

18.0

SSM 2105

70.0 I113

21.0

GSX 21050C-2D

75.0 I26

GSX 41050C-2D

75.0 I48

22.0

GSX 21050S-2D

75.0 I24

GSX 41050S-2D

75.0 I46

32.0

GSX 21050C-3D

90.0 I30

GSX 21050S-3D

90.0 I28

GSX 41050C-3D

90.0 I58

GSX 41050S-3D

90.0 I56

42.0

GSX 21050C-4D

100.0 I34

GSX 21050S-4D

100.0 I32

GSX 41050C-4D

100.0 I62

GSX 41050S-4D

100.0 I60

11.0

16.5

SSUPR 4110ZX

120.0 I79

17.0

GSX 21100C-1.5D

75.0 I20

GSX 41100C-1.5D

75.0 I44

18.0

SSM 2110

70.0 I114

Diameter ø9.3 to ø11.0mm

Square Square

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

11.0

18.0

SSM 4110

70.0 I122

22.0

GSRE 4110SF

75.0 I64

GSX 21100C-2D

75.0 I26

GSX 21100S-2D

75.0 I24

GSX 41100C-2D

75.0 I48

GSX 41100S-2D

75.0 I46

SSUP 3110ZX

90.0 I42

SSUP 4110ZX

90.0 I78

28.0

GSV 4110-2.5D

90.0 I50

GSXVL 4110-2.5D

90.0 I52

33.0

GSX 21100C-3D

90.0 I30

GSX 21100S-3D

90.0 I28

GSX 41100C-3D

90.0 I58

GSX 41100S-3D

90.0 I56

44.0

GSX 21100C-4D

100.0 I34

GSX 21100S-4D

100.0 I32

GSX 41100C-4D

100.0 I62

GSX 41100S-4D

100.0 I60

11.5

18.0

GSX 21150C-1.5D

75.0 I20

GSX 41150C-1.5D

75.0 I44

SSM 2115

70.0 I114

23.0

GSX 21150C-2D

75.0 I26

GSX 21150S-2D

75.0 I24

GSX 41150C-2D

75.0 I48

GSX 41150S-2D

75.0 I46

35.0

GSX 21150C-3D

90.0 I30

GSX 21150S-3D

90.0 I28

GSX 41150C-3D

90.0 I58

GSX 41150S-3D

90.0 I56

46.0

GSX 21150C-4D

100.0 I34

GSX 21150S-4D

100.0 I32

GSX 41150C-4D

100.0 I62

GSX 41150S-4D

100.0 I60

12.0

18.0

GSX 21200C-1.5D

75.0 I20

GSX 31200C-1.5D

75.0 I36

GSX 41200C-1.5D

75.0 I44

GSXSLT 31200C-1.5D

75.0 I40

SSM 2120

70.0 I114

SSM 4120

70.0 I122

SSUPR 4120ZX

120.0 I79

24.0

GSX 21200C-2D

75.0 I26

GSX 41200C-2D

75.0 I48

HHM 6120ZX

75.0 I70

25.0

ASM 2120

75.0 I120

ASM 2120DL

75.0 I107

ASM 4120DL

75.0 I108

26.0

GSH 6120SF

75.0 I67

GSRE 4120SF

75.0 I64

GSX 21200S-2D

75.0 I24

GSX 31200C-2D

75.0 I38

GSX 41200S-2D

75.0 I46

SSUP 3120ZX

90.0 I42

SSUP 4120ZX

90.0 I78

30.0

GSV 4120-2.5D

90.0 I50

GSXVL 4120-2.5D

90.0 I52

LHHM 6120ZX

100.0 I73

36.0

GSX 21200C-3D

90.0 I30

GSX 21200S-3D

90.0 I28

GSX 41200C-3D

90.0 I58

GSX 41200S-3D

90.0 I56

48.0

GSX 21200C-4D

100.0 I34

GSX 21200S-4D

100.0 I32

GSX 41200C-4D

100.0 I62

GSX 41200S-4D

100.0 I60

50.0

EHHM 6120ZX

120.0 I76

12.5 20.0

SSM 2125

80.0 I114

26.0

GSX 21250S-2D

75.0 I24

13.0

19.5

SSUPR 4130ZX

130.0 I79

20.0

GSX 21300C-1.5D

90.0 I20

GSX 41300C-1.5D

90.0 I44

SSM 2130

80.0 I114

SSM 4130

80.0 I122

26.0

GSX 21300C-2D

90.0 I26

GSX 21300S-2D

90.0 I24

GSX 41300C-2D

90.0 I48

GSX 41300S-2D

90.0 I46

SSUP 3130ZX

100.0 I42

39.0

GSX 21300C-3D

100.0 I30

GSX 21300S-3D

100.0 I28

GSX 41300C-3D

100.0 I58

Diameter ø11.0 to ø13.0mm

Square

I1-4

List of Maximum Depth of Cut by Diameter

FLUTE LENGTH BY DRILL DIAMETER

Endmills

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

13.0

39.0

GSX 41300S-3D

100.0 I56

52.0

GSX 21300C-4D

110.0 I34

GSX 21300S-4D

110.0 I32

GSX 41300C-4D

110.0 I62

GSX 41300S-4D

110.0 I60

13.5 20.0

SSM 2135

80.0 I114

27.0

GSX 41350S-2D

90.0 I46

14.0

20.0

SSM 2140

80.0 I114

SSM 4140

80.0 I122

21.0

GSX 21400C-1.5D

90.0 I20

GSX 41400C-1.5D

90.0 I44

26.0

GSRE 4140SF

90.0 I64

SSUP 3140ZX

110.0 I42

SSUP 4140ZX

110.0 I78

28.0

GSX 21400C-2D

90.0 I26

GSX 21400S-2D

90.0 I24

GSX 41400C-2D

90.0 I48

GSX 41400S-2D

90.0 I46

32.0

ASM 2140

90.0 I120

35.0

GSV 4140-2.5D

110.0 I50

GSXVL 4140-2.5D

110.0 I52

42.0

GSX 21400C-3D

110.0 I30

GSX 21400S-3D

110.0 I28

GSX 41400C-3D

110.0 I58

GSX 41400S-3D

110.0 I56

56.0

GSX 21400C-4D

120.0 I34

GSX 21400S-4D

120.0 I32

GSX 41400C-4D

120.0 I62

GSX 41400S-4D

120.0 I60

14.5 25.0

SSM 2145

80.0 I114

15.0

23.0

GSX 21500C-1.5D

90.0 I20

GSX 41500C-1.5D

90.0 I44

25.0

SSM 2150

80.0 I114

SSM 4150

80.0 I122

26.0

SSUP 3150ZX

110.0 I42

SSUP 4150ZX

110.0 I78

30.0

GSX 21500C-2D

90.0 I26

GSX 21500S-2D

90.0 I24

GSX 41500C-2D

90.0 I48

GSX 41500S-2D

90.0 I46

32.0

ASM 2150

90.0 I120

38.0

GSV 4150-2.5D

110.0 I50

GSXVL 4150-2.5D

110.0 I52

45.0

GSX 21500C-3D

110.0 I30

GSX 21500S-3D

110.0 I28

GSX 41500C-3D

110.0 I58

GSX 41500S-3D

110.0 I56

60.0

GSX 21500C-4D

120.0 I34

GSX 21500S-4D

120.0 I32

GSX 41500C-4D

120.0 I62

GSX 41500S-4D

120.0 I60

15.5 35.0

SSM 2155

90.0 I114

16.0

24.0

GSX 21600C-1.5D

90.0 I20

GSX 41600C-1.5D

90.0 I44

SSUPR 4160ZX

160.0 I79

32.0

ASM 2160

90.0 I120

ASM 2160DL

90.0 I107

ASM 4160DL

90.0 I108

GSH 8160SF

90.0 I68

GSRE 4160SF

90.0 I64

GSX 21600C-2D

90.0 I26

GSX 21600S-2D

90.0 I24

GSX 41600C-2D

90.0 I48

GSX 41600S-2D

90.0 I46

HHM 8160ZX

90.0 I71

SSUP 3160ZX

115.0 I42

SSUP 4160ZX

115.0 I78

35.0

SSM 2160

90.0 I114

SSM 4160

90.0 I122

40.0

GSV 4160-2.5D

115.0 I50

GSXVL 4160-2.5D

115.0 I52

48.0

GSX 21600C-3D

110.0 I30

GSX 21600S-3D

110.0 I28

GSX 41600C-3D

110.0 I58

GSX 41600S-3D

110.0 I56

50.0

LHHM 8160ZX

105.0 I74

64.0

GSX 21600C-4D

120.0 I34

GSX 21600S-4D

120.0 I32

GSX 41600C-4D

120.0 I62

GSX 41600S-4D

120.0 I60

Diameter ø13.0 to ø16.0mm

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

16.0 70.0

EHHM 8160ZX

140.0 I77

16.5 35.0

SSM 2165

90.0 I114

17.0

25.5

SSUPR 4170ZX

170.0 I79

26.0

GSX 21700C-1.5D

100.0 I20

GSX 41700C-1.5D

100.0 I44

34.0

GSX 21700C-2D

100.0 I26

GSX 41700C-2D

100.0 I48

35.0

GSX 21700S-2D

100.0 I24

GSX 41700S-2D

100.0 I46

35.0

SSM 2170

90.0 I114

51.0

GSX 21700C-3D

110.0 I30

GSX 21700S-3D

110.0 I28

GSX 41700C-3D

110.0 I58

GSX 41700S-3D

110.0 I56

68.0

GSX 21700C-4D

130.0 I34

GSX 21700S-4D

130.0 I32

GSX 41700C-4D

130.0 I62

GSX 41700S-4D

130.0 I60

17.5 40.0

SSM 2175

105.0 I114

18.0

27.0

GSX 21800C-1.5D

100.0 I20

GSX 41800C-1.5D

100.0 I44

32.0

GSRE 4180SF

100.0 I64

SSUP 4180ZX

120.0 I78

36.0

GSX 21800C-2D

100.0 I26

GSX 41800C-2D

100.0 I48

40.0

GSX 21800S-2D

100.0 I24

GSX 41800S-2D

100.0 I46

SSM 2180

105.0 I114

SSM 4180

105.0 I122

45.0

GSV 4180-2.5D

120.0 I50

GSXVL 4180-2.5D

120.0 I52

54.0

GSX 21800C-3D

120.0 I30

GSX 21800S-3D

120.0 I28

GSX 41800C-3D

120.0 I58

GSX 41800S-3D

120.0 I56

72.0

GSX 21800C-4D

130.0 I34

GSX 21800S-4D

130.0 I32

GSX 41800C-4D

130.0 I62

GSX 41800S-4D

130.0 I60

18.5 40.0

SSM 2185

105.0 I114

19.0

29.0

GSX 21900C-1.5D

100.0 I20

GSX 41900C-1.5D

100.0 I44

38.0

GSX 21900C-2D

100.0 I26

GSX 41900C-2D

100.0 I48

40.0

GSX 21900S-2D

100.0 I24

GSX 41900S-2D

100.0 I46

SSM 2190

105.0 I114

57.0

GSX 21900C-3D

120.0 I30

GSX 21900S-3D

120.0 I28

GSX 41900C-3D

120.0 I58

GSX 41900S-3D

120.0 I56

76.0

GSX 21900C-4D

140.0 I34

GSX 21900S-4D

140.0 I32

GSX 41900C-4D

140.0 I62

GSX 41900S-4D

140.0 I60

19.5 40.0

SSM 2195

105.0 I114

20.0

30.0

GSX 22000C-1.5D

100.0 I20

GSX 42000C-1.5D

100.0 I44

SSUPR 4200ZX

200.0 I79

38.0

GSH 8200SF

100.0 I68

GSRE 4200SF

100.0 I64

SSUP 4200ZX

125.0 I78

40.0

GSX 22000C-2D

100.0 I26

GSX 22000S-2D

100.0 I24

GSX 42000C-2D

100.0 I48

GSX 42000S-2D

100.0 I46

HHM 8200ZX

106.0 I71

SSM 2200

105.0 I114

SSM 4200

105.0 I122

50.0

GSV 4200-2.5D

125.0 I50

GSXVL 4200-2.5D

125.0 I52

55.0

LHHM 8200ZX

120.0 I74

60.0

GSX 22000C-3D

120.0 I30

GSX 22000S-3D

120.0 I28

GSX 42000C-3D

120.0 I58

GSX 42000S-3D

120.0 I56

80.0

GSX 22000C-4D

140.0 I34

GSX 22000S-4D

140.0 I32

GSX 42000C-4D

140.0 I62

GSX 42000S-4D

140.0 I60

Diameter ø16.0 to ø20.0mm

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

20.0 85.0

EHHM 8200ZX

165.0 I77

21.0 40.0

SSM 2210

105.0 I114

42.0

GSX 22100S-2D

110.0 I24

22.0

40.0

SSM 2220

105.0 I114

44.0

GSX 22200S-2D

110.0 I24

GSX 42200S-2D

110.0 I46

66.0

GSX 42200S-3D

130.0 I56

23.0 45.0

SSM 2230

115.0 I114

46.0

GSX 22300S-2D

120.0 I24

24.0

45.0

SSM 2240

115.0 I114

48.0

GSX 22400S-2D

120.0 I24

GSX 42400S-2D

120.0 I46

72.0

GSX 22400S-3D

130.0 I28

25.0

38.0

GSX 22500C-1.5D

120.0 I20

GSX 42500C-1.5D

120.0 I44

50.0

GSX 22500C-2D

120.0 I26

GSX 22500S-2D

120.0 I24

GSX 42500C-2D

120.0 I48

GSX 42500S-2D

120.0 I46

SSM 2250

120.0 I114

SSM 4250

120.0 I122

63.0

GSV 4250-2.5D

140.0 I50

GSXVL 4250-2.5D

140.0 I52

65.0

LHHM 8250ZX

140.0 I74

75.0

GSX 22500C-3D

130.0 I30

GSX 22500S-3D

130.0 I28

GSX 42500C-3D

130.0 I58

GSX 42500S-3D

130.0 I56

100.0

EHHM 8250ZX

185.0 I77

GSX 22500C-4D

160.0 I34

GSX 22500S-4D

160.0 I32

GSX 42500C-4D

160.0 I62

GSX 42500S-4D

160.0 I60

30.0

55.0

SSM 2300

130.0 I114

75.0

LHHM 8300ZX

160.0 I74

110.0

EHHM 8300ZX

205.0 I77

32.0

64.0

HHM 8320ZX

130.0 I71

85.0

LHHM 8320ZX

170.0 I74

110.0

EHHM 8320ZX

205.0 I77

Diameter ø20.0 to ø32.0mm

Square Square Square

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

3.0

4.5

SSUPR 4030ZX-R02

60.0 I98

SSUPR 4030ZX-R05

60.0 I98

8.0

GSV 4030-R02-2.5D

50.0 I82

GSV 4030-R05-2.5D

50.0 I82

GSX 40300-R02-2D

45.0 I80

GSX 40300-R05-2D

45.0 I80

GSXVL 4030-R02-2.5D

50.0 I84

GSXVL 4030-R05-2.5D

50.0 I84

SSUP 4030ZX-R02

50.0 I96

SSUP 4030ZX-R05

50.0 I96

4.0

6.0

SSUPR 4040ZX-R02

60.0 I98

SSUPR 4040ZX-R05

60.0 I98

10.0

GSV 4040-R02-2.5D

50.0 I82

GSV 4040-R05-2.5D

50.0 I82

GSV 4040-R10-2.5D

50.0 I82

GSXVL 4040-R02-2.5D

50.0 I84

GSXVL 4040-R05-2.5D

50.0 I84

GSXVL 4040-R10-2.5D

50.0 I84

11.0

GSX 40400-R02-2D

45.0 I80

GSX 40400-R05-2D

45.0 I80

GSX 40400-R10-2D

45.0 I80

SSUP 4040ZX-R02

50.0 I96

SSUP 4040ZX-R05

50.0 I96

SSUP 4040ZX-R10

50.0 I96

4.5 12.0

SSEH 4045-R05

50.0 I129

SSEH 4045W-R05

50.0 I92

SSEHVL 4045-R05

50.0 I128

SSEHVL 4045-R10

50.0 I128

SSEHVL 4045W-R05

50.0 I88

SSEHVL 4045W-R10

50.0 I88

5.0

7.5

SSUPR 4050ZX-R02

60.0 I98

SSUPR 4050ZX-R05

60.0 I98

13.0

GSV 4050-R02-2.5D

60.0 I82

GSV 4050-R05-2.5D

60.0 I82

GSV 4050-R10-2.5D

60.0 I82

GSX 40500-R02-2D

50.0 I80

GSX 40500-R05-2D

50.0 I80

GSX 40500-R10-2D

50.0 I80

Diameter ø3.0 to ø8.0mm

Radius

I1-5

List of Maximum Depth of Cut by Diameter

FLUTE LENGTH BY DRILL DIAMETER

Endmills

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

0.1 0.1 SNB2 0005 0034DL 45.0 I110

SNB2 0005 0064DL 45.0 I110

0.2 0.2

SNB2 0010 0054DL 45.0 I110

SNB2 0010 0104DL 45.0 I110

SNB2 0010 0204DL 45.0 I110

0.3 0.3

SNB2 0015 0054DL 45.0 I110

SNB2 0015 0104DL 45.0 I110

SNB2 0015 0204DL 45.0 I110

SNB2 0015 0304DL 45.0 I110

0.4 0.4

GSBH 20020SF 50.0 I106

SNB2 0020 0104DL 45.0 I110

SNB2 0020 0204DL 45.0 I110

SNB2 0020 0304DL 45.0 I110

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

5.0 13.0

GSXVL 4050-R02-2.5D

60.0 I84

GSXVL 4050-R05-2.5D

60.0 I84

GSXVL 4050-R10-2.5D

60.0 I84

SSEH 4050-R05

60.0 I129

SSEH 4050W-R05

60.0 I92

SSEHVL 4050-R05

60.0 I128

SSEHVL 4050-R10

60.0 I128

SSEHVL 4050W-R05

60.0 I88

SSEHVL 4050W-R10

60.0 I88

SSUP 4050ZX-R02

60.0 I96

SSUP 4050ZX-R05

60.0 I96

SSUP 4050ZX-R10

60.0 I96

6.0

9.0

SSUPR 4060ZX-R03

60.0 I98

SSUPR 4060ZX-R05

60.0 I98

13.0

GSH 6060SF-R02

50.0 I100

GSH 6060SF-R05

50.0 I100

GSH 6060SF-R10

50.0 I100

GSX 40600-R02-2D

50.0 I80

GSX 40600-R05-2D

50.0 I80

GSX 40600-R10-2D

50.0 I80

GSX 40600-R15-2D

50.0 I80

SSEH 4060-R10

60.0 I129

SSEH 4060W-R10

60.0 I92

SSEHVL 4060-R10

60.0 I128

SSEHVL 4060W-R10

60.0 I88

SSUP 4060ZX-R03

60.0 I96

SSUP 4060ZX-R05

60.0 I96

SSUP 4060ZX-R10

60.0 I96

SSUP 4060ZX-R15

60.0 I96

15.0

GSV 4060-R03-2.5D

60.0 I82

GSV 4060-R05-2.5D

60.0 I82

GSV 4060-R10-2.5D

60.0 I82

GSV 4060-R15-2.5D

60.0 I82

GSXVL 4060-R03-2.5D

60.0 I84

GSXVL 4060-R05-2.5D

60.0 I84

GSXVL 4060-R10-2.5D

60.0 I84

GSXVL 4060-R15-2.5D

60.0 I84

7.0 10.5

SSUPR 4070ZX-R03

80.0 I98

SSUPR 4070ZX-R05

80.0 I98

8.0

12.0

SSUPR 4080ZX-R05

80.0 I98

SSUPR 4080ZX-R10

80.0 I98

19.0

GSH 6080SF-R02

60.0 I100

GSH 6080SF-R05

60.0 I100

GSH 6080SF-R10

60.0 I100

GSX 40800-R02-2D

60.0 I80

GSX 40800-R05-2D

60.0 I80

GSX 40800-R10-2D

60.0 I80

GSX 40800-R15-2D

60.0 I80

SSEH 4080-R10

80.0 I129

SSEH 4080W-R10

80.0 I92

SSEHVL 4080-R10

80.0 I128

SSEHVL 4080W-R10

80.0 I88

SSUP 4080ZX-R03

80.0 I96

SSUP 4080ZX-R05

80.0 I96

SSUP 4080ZX-R10

80.0 I96

SSUP 4080ZX-R15

80.0 I96

SSUP 4080ZX-R20

80.0 I96

20.0

GSV 4080-R03-2.5D

80.0 I82

GSV 4080-R05-2.5D

80.0 I82

GSV 4080-R10-2.5D

80.0 I82

GSV 4080-R15-2.5D

80.0 I82

GSV 4080-R20-2.5D

80.0 I82

GSXVL 4080-R03-2.5D

80.0 I84

GSXVL 4080-R05-2.5D

80.0 I84

GSXVL 4080-R10-2.5D

80.0 I84

GSXVL 4080-R15-2.5D

80.0 I84

GSXVL 4080-R20-2.5D

80.0 I84

9.0 13.5

SSUPR 4090ZX-R05

90.0 I98

SSUPR 4090ZX-R10

90.0 I98

10.0

15.0

SSUPR 4100ZX-R05

100.0 I98

SSUPR 4100ZX-R10

100.0 I98

SSUPR 4100ZX-R15

100.0 I98

22.0

GSH 6100SF-R05

70.0 I100

GSH 6100SF-R10

70.0 I100

GSH 6100SF-R15

70.0 I100

GSH 6100SF-R20

70.0 I100

GSX 41000-R02-2D

70.0 I80

GSX 41000-R05-2D

70.0 I80

GSX 41000-R10-2D

70.0 I80

GSX 41000-R15-2D

70.0 I80

Diameter ø10.0 to ø16.0mm

Radius Radius

Diameter ø5.0 to ø10.0mm

Radius

Diameter ø0.1 to ø0.4mm

Ballnose

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

10.0

22.0

GSX 41000-R20-2D

70.0 I80

SSEH 4100-R10

90.0 I129

SSEH 4100-R30

90.0 I129

SSEH 4100W-R10

90.0 I92

SSEH 4100W-R30

90.0 I92

SSEHVL 4100-R10

90.0 I128

SSEHVL 4100-R30

90.0 I128

SSEHVL 4100W-R10

90.0 I88

SSEHVL 4100W-R30

90.0 I88

SSUP 4100ZX-R03

90.0 I96

SSUP 4100ZX-R05

90.0 I96

SSUP 4100ZX-R10

90.0 I96

SSUP 4100ZX-R15

90.0 I96

SSUP 4100ZX-R20

90.0 I96

25.0

GSV 4100-R03-2.5D

90.0 I82

GSV 4100-R05-2.5D

90.0 I82

GSV 4100-R10-2.5D

90.0 I82

GSV 4100-R15-2.5D

90.0 I82

GSV 4100-R20-2.5D

90.0 I82

GSXVL 4100-R03-2.5D

90.0 I84

GSXVL 4100-R05-2.5D

90.0 I84

GSXVL 4100-R10-2.5D

90.0 I84

GSXVL 4100-R15-2.5D

90.0 I84

GSXVL 4100-R20-2.5D

90.0 I84

11.0 16.5

SSUPR 4110ZX-R05

120.0 I98

SSUPR 4110ZX-R10

120.0 I98

SSUPR 4110ZX-R15

120.0 I98

12.0

18.0

SSUPR 4120ZX-R05

120.0 I98

SSUPR 4120ZX-R10

120.0 I98

SSUPR 4120ZX-R15

120.0 I98

26.0

GSH 6120SF-R05

75.0 I100

GSH 6120SF-R10

75.0 I100

GSH 6120SF-R15

75.0 I100

GSH 6120SF-R20

75.0 I100

GSX 41200-R02-2D

70.0 I80

GSX 41200-R05-2D

70.0 I80

GSX 41200-R10-2D

70.0 I80

GSX 41200-R15-2D

70.0 I80

GSX 41200-R20-2D

70.0 I80

SSEH 4120-R10

90.0 I129

SSEH 4120-R30

90.0 I129

SSEH 4120W-R10

90.0 I92

SSEH 4120W-R30

90.0 I92

SSEH 4120WS-R10

90.0 I94

SSEH 4120WS-R30

90.0 I94

SSEHVL 4120-R10

90.0 I128

SSEHVL 4120-R30

90.0 I128

SSEHVL 4120W-R10

90.0 I88

SSEHVL 4120W-R30

90.0 I88

SSEHVL 4120WS-R10

90.0 I90

SSEHVL 4120WS-R30

90.0 I90

SSUP 4120ZX-R05

90.0 I96

SSUP 4120ZX-R10

90.0 I96

SSUP 4120ZX-R15

90.0 I96

SSUP 4120ZX-R20

90.0 I96

SSUP 4120ZX-R30

90.0 I96

30.0

GSV 4120-R05-2.5D

90.0 I82

GSV 4120-R10-2.5D

90.0 I82

GSV 4120-R15-2.5D

90.0 I82

GSV 4120-R20-2.5D

90.0 I82

GSV 4120-R30-2.5D

90.0 I82

GSXVL 4120-R05-2.5D

90.0 I84

GSXVL 4120-R10-2.5D

90.0 I84

GSXVL 4120-R15-2.5D

90.0 I84

GSXVL 4120-R20-2.5D

90.0 I84

GSXVL 4120-R30-2.5D

90.0 I84

13.0 19.5

SSUPR 4130ZX-R05

130.0 I98

SSUPR 4130ZX-R10

130.0 I98

SSUPR 4130ZX-R15

130.0 I98

16.0

24.0

SSUPR 4160ZX-R10

160.0 I98

SSUPR 4160ZX-R15

160.0 I98

SSUPR 4160ZX-R20

160.0 I98

32.0

GSH 8160SF-R10

90.0 I101

GSH 8160SF-R15

90.0 I101

GSH 8160SF-R20

90.0 I101

SSEH 4160-R10

115.0 I129

SSEH 4160-R30

115.0 I129

SSEH 4160W-R10

115.0 I92

SSEH 4160W-R30

115.0 I92

SSEH 4160WS-R10

115.0 I94

Diameter ø16.0 to ø25.0mm

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

16.0

32.0

SSEH 4160WS-R30

115.0 I94

SSEHVL 4160-R10

115.0 I128

SSEHVL 4160-R30

115.0 I128

SSEHVL 4160W-R10

115.0 I88

SSEHVL 4160W-R30

115.0 I88

SSEHVL 4160WS-R10

115.0 I90

SSEHVL 4160WS-R30

115.0 I90

SSUP 4160ZX-R10

115.0 I96

SSUP 4160ZX-R15

115.0 I96

SSUP 4160ZX-R20

115.0 I96

SSUP 4160ZX-R30

115.0 I96

40.0

GSV 4160-R10-2.5D

115.0 I82

GSV 4160-R15-2.5D

115.0 I82

GSV 4160-R20-2.5D

115.0 I82

GSV 4160-R30-2.5D

115.0 I82

GSXVL 4160-R10-2.5D

115.0 I84

GSXVL 4160-R15-2.5D

115.0 I84

GSXVL 4160-R20-2.5D

115.0 I84

GSXVL 4160-R30-2.5D

115.0 I84

17.0 25.5

SSUPR 4170ZX-R10

170.0 I98

SSUPR 4170ZX-R15

170.0 I98

SSUPR 4170ZX-R20

170.0 I98

20.0

30.0

SSUPR 4200ZX-R10

200.0 I98

SSUPR 4200ZX-R15

200.0 I98

SSUPR 4200ZX-R20

200.0 I98

38.0

GSH 8200SF-R10

100.0 I101

GSH 8200SF-R15

100.0 I101

GSH 8200SF-R20

100.0 I101

SSUP 4200ZX-R10

125.0 I96

SSUP 4200ZX-R15

125.0 I96

SSUP 4200ZX-R20

125.0 I96

SSUP 4200ZX-R30

125.0 I96

40.0

SSEH 4200W-R10

125.0 I92

SSEH 4200W-R30

125.0 I92

SSEH 4200WS-R10

125.0 I94

SSEH 4200WS-R30

125.0 I94

SSEHVL 4200W-R10

125.0 I88

SSEHVL 4200W-R30

125.0 I88

SSEHVL 4200WS-R10

125.0 I90

SSEHVL 4200WS-R30

125.0 I90

50.0

GSV 4200-R10-2.5D

125.0 I82

GSV 4200-R15-2.5D

125.0 I82

GSV 4200-R20-2.5D

125.0 I82

GSV 4200-R30-2.5D

125.0 I82

GSXVL 4200-R10-2.5D

125.0 I84

GSXVL 4200-R15-2.5D

125.0 I84

GSXVL 4200-R20-2.5D

125.0 I84

GSXVL 4200-R30-2.5D

125.0 I84

25.0

50.0

SSEH 4250W-R10

140.0 I92

SSEH 4250W-R30

140.0 I92

SSEH 4250WS-R10

140.0 I94

SSEH 4250WS-R30

140.0 I94

SSEHVL 4250W-R10

140.0 I88

SSEHVL 4250W-R30

140.0 I88

SSEHVL 4250WS-R10

140.0 I90

SSEHVL 4250WS-R30

140.0 I90

63.0

GSV 4250-R10-2.5D

140.0 I82

GSV 4250-R15-2.5D

140.0 I82

GSV 4250-R20-2.5D

140.0 I82

GSV 4250-R30-2.5D

140.0 I82

GSXVL 4250-R10-2.5D

140.0 I84

GSXVL 4250-R15-2.5D

140.0 I84

GSXVL 4250-R20-2.5D

140.0 I84

GSXVL 4250-R30-2.5D

140.0 I84

I1-6

List of Maximum Depth of Cut by Diameter

FLUTE LENGTH BY DRILL DIAMETER

Endmills

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

Diameter ø0.4 to ø20.0mm

Ballnose

Diameter

Max. D.O.C.

APMX

Cat. No.

Total Length

Page

0.4 0.4 SNB2 0020 0404DL 45.0 I110

0.6 GSXB 20020 50.0 I102

0.5 0.45

SNB2 0025 0104DL 45.0 I110

SNB2 0025 0204DL 45.0 I110

SNB2 0025 0304DL 45.0 I110

SNB2 0025 0404DL 45.0 I110

0.6 0.6

GSBH 20030SF 50.0 I106

SNB2 0030 0204DL 45.0 I110

SNB2 0030 0304DL 45.0 I110

SNB2 0030 0404DL 45.0 I110

SNB2 0030 0504DL 45.0 I110

SNB2 0030 0604DL 45.0 I110

0.9 GSXB 20030 50.0 I102

1.0

1.0 GSBH 20050SF 50.0 I106

1.5

GSXB 20050 50.0 I102

SNB2 0050 0304DL 45.0 I110

SNB2 0050 0404DL 45.0 I110

SNB2 0050 0604DL 45.0 I110

SNB2 0050 0804DL 50.0 I110

SNB2 0050 1004DL 50.0 I110

1.5

1.5 GSBH 20075SF 50.0 I106

2.3

SNB2 0075 0304DL 45.0 I110

SNB2 0075 0604DL 45.0 I110

SNB2 0075 1004DL 50.0 I110

2.5 GSXB 20075 50.0 I102

2.0

2.0 GSBH 20100SF 60.0 I106

3.0

GSXB 20100 60.0 I102

SNB 2020DL 60.0 I109

SNB2 0100 0304DL 50.0 I110

SNB2 0100 0604DL 50.0 I110

SNB2 0100 1004DL 50.0 I110

SNB2 0100 1504DL 60.0 I110

SNB2 0100 2004DL 60.0 I110

2.5 2.5 GSBH 20125SF 60.0 I106

4.0 GSXB 20125 60.0 I102

3.0

3.0 GSBH 20150SF 60.0 I106

4.5 GSXB 20150 60.0 I102

SNB 2030DL 80.0 I109

4.0

4.0 GSBH 20200SF 70.0 I106

6.0

GSXB 20200 70.0 I102

SNB 2040DL 80.0 I109

SNB2 0200 1606DL 80.0 I110

SNB2 0200 2006DL 80.0 I110

SNB2 0200 3006DL 80.0 I110

5.0

5.0 GSBH 20250SF 80.0 I106

7.5 GSXB 20250 80.0 I102

SNB 2050DL 90.0 I109

6.0

6.0 GSBH 20300SF 80.0 I106

9.0 GSXB 20300 80.0 I102

SNB 2060DL 100.0 I109

7.0 11.0 GSXB 20350 90.0 I102

8.0

8.0 GSBH 20400SF 90.0 I106

12.0 GSXB 20400 90.0 I102

SNB 2080DL 100.0 I109

10.0

10.0 GSBH 20500SF 100.0 I106

15.0 GSXB 20500 100.0 I102

SNB 2100DL 120.0 I109

12.0

12.0 GSBH 20600SF 110.0 I106

18.0 GSXB 20600 110.0 I102

SNB 2120DL 120.0 I109

14.0 21.0 GSXB 20700 110.0 I102

16.0 24.0 GSXB 20800 140.0 I102

SNB 2160DL 160.0 I109

18.0 27.0 GSXB 20900 140.0 I102

20.0 30.0 GSXB 21000 160.0 I102

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

Endmills

Square Endmill Selection Guide

First Recommendation

: Optimal : Suitable Blank: Not recommended : Unsuitable

Application

Feature

No. of

Flutes

Diameter

(Min to Max)

(mm)

Flute Length/

Type

Product Type

Series

Grades

Coating / Cutting Edge

Appearance

Work Material

PHMSK N

Long Neck / Relief Shank

Extra-Long Series

Long Series

Medium

Standard

Short Flute

General Structure Rolled Steel

Carbon Steel

Alloy Steel

Pre-hardened Steel

Tempered Steel / Die Steel

Hardened Steel

Stainless Steel

Ti Alloy / Heat Resistant Alloy

Cast Iron

Aluminum Alloy

Copper Alloy

Graphite

CFRP

30 to 45 HRC

45 to 55 HRC

55 to 60 HRC

From 60 HRC

General

Purpose

ø1 to 25

GSXMILL 2 Flutes

GSX 20000C I20

Coated

Carbide

ø1 to 20

GSXMILL 2 Flutes

GSX 20000S I22

ø0.2 to 30

Solid Carbide Spiral 2 Flutes

SSM 2000 I112

Carbide

ø3 to 25

Extra-Long Series

Solid Carbide Spiral 2 Flutes

ELSM 2000 I118

ø1 to 20

GSXMILL 3 Flutes

GSX 30000C I36

Coated

Carbide

ø1 to 25

GSXMILL 4 Flutes

GSX 40000C I44

Coated

Carbide

ø1 to 20

GSXMILL 4 Flutes

GSX 40000S I46

ø1.5 to 25

Solid Carbide Spiral 4 Flutes

SSM 4000 I122

Carbide

ø3 to 25

Extra-Long Series

Solid Carbide Spiral 4 Flutes

ELSM 4000 I126

High

Efficiency

ø2 to 25

GSV Type Anti-vibration 4 Flutes

GSV 4000 I50

Coated

Carbide

ø2 to 25

GSX MILL Anti-vibration 4 Flutes

GSXVL 4000 I52

ø2 to 20

UPMILL

SSUP 4000ZX I78

ø3 to 20

Relief Shank

UPMILL Deep Shoulder

SSUPR 4000ZX I79

Hardened

Steel

ø6 to 16

SUMIBORON

Helical Master BNES Type

BNES I140

ø1 to 20

GSMILL HARD

GSH 4/6/8000SF

I66

Coated

Carbide

ø3 to 32

HARD

HHM 4/6/8000ZX

I69

ø3 to 32

Long Hard

LHHM 4/6/8000ZX

I72

ø3 to 32

Extra-Long Hard

EHHM 4/6/8000ZX

I75

Roughing

ø6 to 20

GSMILL Roughing

GSRE 4000SF I64

Coated

Carbide

(Ref. Page)

Endmills

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

Square Endmill Selection Guide

First Recommendation

: Optimal : Suitable Blank: Not recommended : Unsuitable

Application

Feature

No. of

Flutes

Diameter

(Min to Max)

(mm)

Flute Length/

Type

Product Type

Series

Grades

Coating / Cutting Edge

Appearance

Work Material

PHMSK N

Long Neck / Relief Shank

Extra-Long Series

Long Series

Medium

Standard

Short Flute

General Structure Rolled Steel

Carbon Steel

Alloy Steel

Pre-hardened Steel

Tempered Steel / Die Steel

Hardened Steel

Stainless Steel

Ti Alloy / Heat Resistant Alloy

Cast Iron

Aluminum Alloy

Copper Alloy

Graphite

CFRP

30 to 45 HRC

45 to 55 HRC

55 to 60 HRC

From 60 HRC

Aluminum

and

Non-ferrous

Metal

ø4 to 12

SUMIDIA

Endmills DAE Type

DAE I144

ø2 to 16

AURORA Coat 2 Flutes

ASM 2000DL I107

Coated

Carbide

ø2 to 16

Solid Carbide Endmills for

Non-ferrous cutting

ASM 2000 I120

Carbide

ø4 to 13

SUMIDIA

Endmills DFE Type

DFE I142

ø2 to 16

AURORA Coat 4 Flutes

ASM 4000DL I108

Coated

Carbide

CFRP

ø6 to 12

SUMIDIA COAT

SSDC Type

SSDC 4000 I139

Coated

Carbide

ø6 to 12

SUMIDIA COAT

SSDCRL Type

SSDC 4000RL I139

Coated

Carbide

Compound

Endmilling

ø1 to 16

GSXMILL Slot 3 Flutes

GSXSLT 30000C

I40

Coated

Carbide

ø2 to 16

UPMILL Slot

SSUP 3000ZX I42

(Ref. Page)

Our square endmills have

concave ends.

Therefore, they do not make

at bottoms in spot facing.

If a at bottom is required,

we recommend using the Flat Multidrill

MDF Type.J34

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

Endmills

First Recommendation

: Optimal : Suitable Blank: Not recommended : Unsuitable

Application

Feature

No. of

Flutes

Radius

Diameter

Min to Max

Ballnose

Radius

(Min to Max)

Tolerance

(mm)

Flute Length/Type

Product Type

Series

Grades

Coating / Cutting Edge

Appearance

Work Material

PHMSK N

Long Neck / Relief Shank

Extra-Long Series

Long Series

Medium

Standard

Short Flute

General Structure Rolled Steel

Carbon Steel

Alloy Steel

Pre-hardened Steel

Tempered Steel / Die Steel

Hardened Steel

Stainless Steel

Ti Alloy / Heat Resistant Alloy

Cast Iron

Aluminum Alloy

Copper Alloy

Graphite

CFRP

30 to 45 HRC

45 to 55 HRC

55 to 60 HRC

From 60 HRC

General

Endmilling With

Corner Radius

ø3 to 12

GSXMILL Radius

GSX 40000-R I80

Coated

Carbide

High Efficiency

Endmilling With

Corner Radius

ø3 to 25

GSV type Anti-vibration Radius

GSV 4000-R I82

Coated

Carbide

ø3 to 25

GSX MILL Anti-vibration Radius

GSXVL 4000-R I84

ø3 to 20

UPMILL Radius

SSUP 4000ZX-R

I96

ø3 to 20

Relief Shank

UPMILL Deep Shoulder, Radius

SSUPR 4000ZX-R I98

Hardened Steel

Endmilling With

Corner Radius

ø6 to 20

GSMILL HARD Radius

GSH 6/8000SF-R

I100

Coated

Carbide

Exotic

Alloy

ø4.5 to 25

SSEH Anti-vibration Radius

SSEHVL 4000W-R

I88

Coated

Carbide

ø4.5 to 25

SSEH Radius

SSEH 4000W-R I92

ø4.5 to 16

SSEH Anti-vibration Radius

SSEHVL 4000-R

I128

Carbide

ø4.5 to 16

SSEH Radius

SSEH 4000-R I129

High Precision

Mold Profiling

ø0.2 to 2

Mold Finish Master

SUMIBORON Radius Endmills

BNBR I134

Carbide and Hard

Brittle Material

ø0.2 to 2

Mold Finish Master

SUMIDIA Binderless Radius Endmills

NPDRS I132

Binderless

Corner Radius Endmill Selection Guide

Corner Radius Endmill

Ballnose Endmill

General Purpose

R0.2 to 12.5

± 0.01

GSX MILL Ballnose

GSXB 20000 I102

Coated

Carbide

R0.5 to 6

± 0.01

GSMILL Ballnose

GLB 2000SF I104

Hardened

Steel

R0.2 to 6

0.003

0.007

GSMILL HARD Ballnose

GSBH 20000SF

I106

Coated

Carbide

Aluminum and

Non-Ferrous

Metal

R1 to 8

± 0.01

AURORA COAT Ballnose

SNB 2000DL I109

Coated

Carbide

Copper

Electrodes

R0.05 to 2

± 0.005

Long Neck

AURORA COAT

Long Neck Ballnose

SNB2 I110

Coated

Carbide

R0.1 to 0.5

± 0.005

Mold Finish Master

SUMIBORON Ball Endmills

BNBC I138

High Precision

Mold Profiling

R0.2 to 1

± 0.005

Mold Finish Master

SUMIBORON Ball Endmills

BNBP I136

R1 to 10

± 0.02

SUMIBORON Endmills BNBS Type

BNBS I141

Carbide and

Hard Brittle

Material

R0.1 to 1

Mold Finish Master

SUMIDIA BINDERLESS Ballnose Endmills

NPDB/NPDBS

I130

Binderless

R0.5 to 1

SUMIDIA Coated Ballnose Endmills

SDCB I133

Ballnose Endmill Selection Guide

Ref. Page)

Carbide

Hard Brittle Material

Selection Guide

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

Endmills

Coating Name GSX Coat GS Hard Coat ZX Coat AURORA Coat SUMIDIA Coat

Coating Type TiAlCrN Type TiAlCrSiCN Type TiAlN Type Diamond

Wear Resistance

Adhesion Resistance

Thermal Resistance

Coating Thickness

Characteristics

Excellent in thermal resistance and adhesion resistance Excellent in rigidity, thermal resistance, and adhesion resistance

General Purpose

Low friction coefficient and excellent adhesion resistance

Excellent in rigidity and wear resistance

Main Application

For general steel/stainless steel milling

For general steel/hardened steel milling

For general steel/cast iron milling

For aluminum alloy/copper alloy milling For CFRP milling

Main Applicable Product

Up to 2 m Up to 2 m Up to 2 m Up to 0.5 m Up to 15 m

TiAlCrN Oxidation Resistance Coating

TiAlN Wear Resistance Coating

Ultra-fine Grained Carbide Substrate

[Coating Structure]

Hardened SteelSoft Steel

Cutting Speed (m/min)

Hardness of Work MaterialHRC)

Starting Temperature For Oxidisation

Coating Hardness (GPa)

GSX Coat

Conventional ZX

Coating

Comp. A

Comp. B

[Coating Surface Comparison]

[Oxidisation Evaluation](Scratches from calotest performed after one-hour exposure to the air of 1,100 )

Conventional Coating

GS Hard Coat

Micro Particle

Conventional Coating

Oxidised layer of approx. 0.3

Oxidised layer of approx. 1.0

20 30 35 40

Conventional

TiN Coat

Conventional

TiCN Coat

Conventional

TiAlN Coat

CBN

ZX Coat

Coating Hardness GPa

ZX Coat

Coating Hardness (GPa)

Starting Temperature

For Oxidisation (

)

Competitor's Diamond CoatingAURORA Coat

Coatings For Endmills

GSX Coat

GS Hard Coat

DLC Coat SUMIDIA Coat

ZX Coat

Fine carbide substrate provides high traverse rupture strength and excellent thermal shock resistance improving reliability in wet cutting applications.

GSX Coating provides improved reliability and longer tool life.

Super smooth AURORA Coat reduces adhesion and provides good surface finish.

Low milling resistance enables high feed machining and

milling of low rigidity works.

Perfect for machining non-ferrous metal/copper electrodes

Our original polycrystalline diamond coating technology achieves

over 10 times higher wear resistance than uncoated carbide.

Realising fine diamond coating that provides both high strength and

high wear resistance with smooth surface required for CFRP milling.

Hardness almost equivalent to that of CBN

Improvement in wear resistance, Oxidisation resistance, and peel-off resistance

Approx. 6 times longer life compared with uncoated products

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

Endmills

Characteristics and Applications

Wide variation of three flute types and four flute lengths enable

use in a wide variety of applications.

Fine carbide substrate provides high traverse rupture strength

and excellent thermal shock resistance improving reliability in

wet cutting applications.

GSX Coat provides improved reliability and longer tool life.

Large rake angle and unique flute design improve sharpness

and chip evacuation.

Corner edge with gash land improves cutting edge strength.

Expanded lineup with the radius type and the 4D size S type

2 cutting edge designs expand machining applications

"Global Standard" Solid Endmill

GSX MILL Series

0.3

0.02

Ex.: Corner on a 10mm hole

Note : When using endmills with gash land,

some material remains as shown

on the right. If you need sharp

corners, use the S Type.

(mm)

*1 : GSXSLT30000C is recommended for 50 HRC or less.

Optimal Suitable Blank Not recommended

CFRP

General Structure Rolled Steel

Carbon Steel

Alloy Steel

Pre-hardened Steel

Die Steel

45 to 55 HRC

55 to 60 HRC

60 HRC

Stainless Steel

Ti Alloy

Heat Resistant Alloy

Cast Iron

Aluminum Alloy

Copper Alloy

Graphite

Hardened Steel

Application Range

S Type is best for removing inside corners

Use with small depth of cut.

S Type

C Type

Application Surface Milling Groove Milling Groove Finishing

Form

Roughing

Finishing

Roughing

Finishing

Roughing

Finishing

Recommended Milling Examples

20 30 40 50 55

400

300

200

100

Hardened Steel

Soft Steel

Cutting Speed (m/min)

Hardness of Work Material (HRC)

Comp. A

Comp. B TiCN

TiN

TiN/AIN

TiAIN

600 800 1,000 1,200

GSX

Coat

GSX

Coat

Conventional ZX

Coating

Starting Temperature For Oxidization( )

Coating Hardness (GPa)

Large Rake Angle

Original Flute Shape

Improved Chip Evacuation

Gash Land: Fracture Resistant Design

Type

S Type

Sharp Corner: Sharper Edge Design

Sharper edge S type and fracture resistant C type added to the 2D size series.

Large rake angle combined with our unique flute

design improves sharpness and chip evacuation.

Wear Resistance Thermal Resistance

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

Endmills

Multi-Purpose

Optimized flute design of slotted 3 flute

(short) type reduces cutting resistance.

Allows drilling, slot milling and other

continuous (compound) applications.

Perfect for use on thin walls and small

machining centers.

High Precision

Diametrical tolerance held to 2/3 of the previous type. Also features reduced

variation and does not require tool diameter correction when replacing tools.

Product Range

Long, High Rigidity Flutes

Incline 44μm

Undulation 18μm

Wall Height 35mm

Undulation 34μm

Incline 62μm

Wall Height 35mm

GSX MILL-4D

Tool Dimensions : ø10 (2 Flutes)

Work Material : S50C

Cutting Speed : 44m/min (1,400min-1)

Feed Rate :

240mm/min (0.086mm/t)

Competitor's Product

Depth of cut:ap=35mm

ae=0.1mm×25 times

Coolant : Wet

BT30 Vertical Machining Center

GSX MILL

Competitor's Product

Breakage

Gash land for stronger cutting edge.

Tool Dimension

62 Flutes

Work Material S50C

Cutting Speed 87m/min 4615min

-1

Feed Rate

553mm/min 0.06mm/t

Depth of cut

=3mm

=6mm

Coolant Dry

Vertical Machining Center

BT50

Carbon Steel Grooving with GSX20000C

Tool Dimension

10 2 Flutes

Work Material

Equivalent to FCD600

Cutting Speed 66m/min 2100min-1

Feed Rate

302mm/min 0.072mm/t

Depth of cut p=5mm 5 passes

e=10mm

Coolant Dry

Vertical Machining Center BT40

GSX Coat for improved wear resistance.

High Wear

GSX MILL

Competitor's Product

Cast Iron Grooving with GSX20000C

Improved reliability even under wet machining.

Tool Dimension

10 2 Flutes

Work Material

SUS304

Cutting Speed

50m/min 1591min-1

Feed Rate

127mm/min 0.04mm/t

Depth of cut

p=10mm

e=0.5mm

Coolant

Wet

Vertical Machining Center

BT50

Coating peel off

GSX MILL

Competitor's Product

Stainless Steel Machining with GSX20000C

GSX MILL

Competitor's Product

S type delivers optimum cutting performance.

Tool Dimension

62 Flutes

Work Material S50C

Cutting Speed 87m/min 4615min-1

Feed Rate 553mm/min 0.06mm/t

Depth of cut p=10mm

e=0.3mm

Coolant Dry

Vertical Machining Center BT50

Chipping

Surface Milling S50C with GSX20000S

Application Examples

"Global Standard" Solid Endmill

GSX MILL Series

GSX20000C-1. 5 D GSX20000S-2D GSX20000C-2D

GSX30000C-1. 5 D

GSX40000C-1. 5 D GSX40000S-2D GSX40000C-2D

GSXSLT30000C-1. 5 D

GSX20000C-3D

GSX40000C-3D

GSX20000C-4DGSX20000S-4D

1.5D 3D 4D

C Type S Type C Type C TypeS Type S Type C Type

GSX40000C-4DGSX40000S-4D

I20ø0.5 to ø25.0mm ø0.3 to ø25.0mm ø0.5 to ø25.0mm

ø1.0 to ø20.0mm

ø1.0 to ø25.0mm

ø1.0 to ø16.0mm

ø1.0 to ø25.0mm ø1.0 to ø25.0mm ø1.0 to ø25.0mm ø1.0 to ø25.0mm ø1.0 to ø25.0mm

ø1.0 to ø20.0mm

ø0.5 to ø25.0mm ø0.5 to ø25.0mm ø0.5 to ø25.0mmI26

I36

I44

I24

I46

GSX40000-R-2D

ø3.0 to ø12.0mm I80

I48

I40

GSX30000C-2D

I38

I30

I58

GSX20000S-3D

GSX40000S-3D

I28

I56

I34

I62ø1.0 to ø25.0mm

ø0.5 to ø25.0mm I32

I60

Application

General

Purpose

No. of

Flutes

Compound

Endmilling

Radius

Flute Length

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

Endmills

Roughing

Finishing

Application

Groove Milling

Side Milling Groove Finishing

Roughing

Finishing

Roughing

Finishing

GSV Type

GSXVL Type

"Global Standard" Solid Endmill

GSX MILL Series

Recommended Milling Examples

Diameter

GSXVL/GSV Applications

The GSXVL type demonstrates excellent performance in high load milling. The GSV type achieves both chattering resistance performance and cost-effectiveness.

Cutting Area

2 to 25

2 to 25 4

Coating Corner

Side Milling Cutting Resistance Groove Milling

I52, I50

GSXVL

GSXMILL Series

Anti-vibration type

GSV

GSXMILL Series

Anti-vibration type

GSX

GSV

GSXVL

Chattering Resistance Performance (Grooving)

Chattering Resistance Performance (Side Milling)

General Purpose v

CD.O.C. ap

Squareness

Cost-Effectiveness

Anti-Vibration

High-Load Milling

Anti-Vibration/General Purpose

Easily Regrindable

General Purpose

b1° b2° b2° b2°

a1° a2°

Irregular Pitch

01D

100

150

2D 3D

GSX

D.O.C. (ap)D.O.C. (ap)

00.5D 0.8D 1D

100

(120)

150

GSXVL GSV

GSX

GSX GSV

GSV

GSV GSXVL

GSXVL

Cutting Conditions :

Work Material :

vc=150m/min

f =0.1mm/t

ap=18mm

ae=2.4mm

Dry

S50C

GSX : Occurrence of Chattering

GSXVL : Stable Milling GSV : Stable Milling

Irregular Lead Regular Lead

GSV

GSVGSXVL

GSXVL

Rounded Land

(Used on sizes ø5mm and up)

a1° ≠ a2° b1° ≠ b2° b2° = b2°

Cutting Speed (m/min)

Cutting Resistance (N)Cutting Resistance (N)

Cutting Resistance (N)

Cutting Speed (m/min)

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

Endmills

Helical Milling x 2

Seat Face Expansion Milling

Ramping

Side Milling

High Speed Side Milling

Groove Milling

Engraving

Helical Milling to Slot

Expansion Milling x 2

Work Material: S50C, Tool Diameter :

12, Cutting Conditions: Dry, Air Blow

Seat Face Expansion Milling

Helical Milling x 2

90m/min ( =2,400min-1 )

Cutting Conditions

=960mm/min ( 0.1mm/t )

=90m/min ( =2,400min-1 )

Cutting Conditions

=480mm/min ( 0.05mm/t )

Ramp Angle 3

90m/min ( =2,400min-1 )

Cutting Conditions

=480mm/min ( 0.05mm/t )

Ramp Angle 5

=24mm, =0.1mm

90m/min ( =2,400min-1 )

Cutting Conditions

= 480mm/min ( 0.05mm/t )

Ramp Angle 3

Helical

=672mm/min ( 0.07mm/t )

Slot Expansion

=1,920mm/min ( 0.2mm/t )

Finishing

Engraving

79m/min ( =2,100min-1 )

Cutting Conditions

=588mm/min ( 0.07mm/t )

=12mm

Side Milling

High Speed Side Milling

Groove Milling

102m/min ( =4,100min-1 )

Cutting Conditions

f=1,080mm/min ( 0.1mm/t )

p=24mm, =2.0mm

151m/min ( =4,000min

-1

)

Cutting Conditions

=4,800mm/min ( 0.3mm/t )

=12mm, =2.0mm

90m/min ( =2,400min-1 )

Cutting Conditions

=960mm/min ( 0.1mm/t )

=12mm

nnn

Helical Milling to Slot Expansion Milling x 2

GSXVL / GSV GSXVL / GSV GSXVL / GSV

GSXVL / GSV GSXVL / GSV

Tool Diameter

: ø8

Tool Diameter

: ø

Tool Diameter

: ø12

Tool Diameter

: ø12

Tool Diameter

: ø12

Tool Diameter

: ø12

Tool Diameter

: ø12

Tool Diameter

: ø12

Ramping

"Global Standard" Solid Endmill

GSX MILL Series

Application Examples

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

I10

Endmills

"Global Standard" Solid Endmill

GSX MILL Series

MOLD FINISH MASTER

(CBN Ballnose)

Ball

Original Pocket Shape

Chip Removal Rate Q (cc/min)

Small Large

GS MILL

HARD Ball

GS MILL

HARD Ball

GS MILL

HARD Ball

GS MILL

MILL

Workpiece Hardness (HRC)

MOLD FINISH MASTER

(CBN Ballnose)

Large Helix Angle

Roughing Roughing Roughing

Finishing Finishing Finishing

Application

Ballnose Type

Radius Milling Proling Millimg Pocket Millimg

Recommended Milling Examples

Diameter

Ballnose Type

Improved Thermal Resistance and Wear Resistance

New coating combined with a fine-grained carbide substrate exhibit better thermal and wear resistance.

Application Range

Improved Chip Evacuation

Unique pocket design and expanded pocket area

promotes better chip evacuation.

Reduced Cutting Force

Application Examples

0.05

60 80 100 120 140

0.04

0.03

0.02

0.01

0.00

MILL BallMILL Ball

Cutting Length (m)

Comp. A

Comp. B

GSXMILL

Ball

Comp. C

Flank Wear

Wear (mm)

GSX Ball (Cutting Length 140 m)

Conventional Tool (Cutting Length 80 m)

Able to continue Unable to continue

Chipping at the center,

large flank wear

Work Material: SKD61 (50HRC)

Tool Dimensions: R3 (2 Flutes)

Cutting Conditions: =179m/min( =9,500min-1), =2,250mm/min( =0.12mm/t)

=0.2 to 1.0mm, =0.3mm, Wet

Equipment: Vertical Machining Center BT40

Coating

Helix Angle

0.4 to 25

Large helix angle on cutting edge reduces cutting resistance.

102

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

I11

Endmills

Endmills for CFRP

SUMIDIA Coated SSDC Series

2mm 2mm

Ra93 to 99 inch

Ra115 to 139 inch

Competitor's Product

High surface quality with no burrs

Burrs are formed. Low surface quality

Results

:ø10 (4 Flutes)

:=314m/min

=10,000min-1

=1,000mm/min

=0.025mm/t

Dry

Competitor's Product

Work Material

: CFRP

Tool Diameter

Cutting Conditions

SSDC Type

Characteristics and Applications

Two different types of flute shapes are available.

SSDC Type (Right-hand Helix Type)

Achieves both higher cutting performance and longer tool life

through optimisation of rake angle and relief angle.

SSDCRL Type (Righ/Left-hand Helix Type)

Right/left-hand helix prevents delamination on top and bottom surfaces.

Cutting resistance is dispersed even with unstable clamping, improving

surface quality.

For CFRP

SSDC 4000

I139

SSDC 4000RL

I139

Type

No. of Flutes

Shape

Diameter (mm)

Right-hand Helix

Right/Left-hand Helix

ø6 to ø12

139

Series

Performance

Surface Finish Comparison

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

I12

Endmills

Radius Endmill for Exotic Alloys

SSEH Series

SSEH Radius

Characteristics and Applications

High helix (45° helix) improves sharpness.

Combination of unique flute design and semi-mirrored surface

improves chip evacuation and adhesion resistance.

Ultra-smooth coating with improved hardness and

heat resistance combined with tough carbide substrate

improves tool life when working with heat resistant alloys.

Unique, smooth radius shape mitigates cutting impact and

improves fracture resistance.

Both coated and uncoated types are available in stock to meet various conditions.

Inconel 718 (Side Milling)

0.25

0.2

0.15

0.1

0.05

0123456

Conventional Tool

SSEH4060-R10

Conventional tool

stopped due to

chipping

Notch Wear (mm)

Cuttin

Len

th (m)

Inconel 713 (Side Milling)

SSEH 4100W-R10

Competitor's Product

In Sumitomo Electric Hardmetal tests,

the special coating with excellent

adhesion resistance provided less

cutting edge adhesion than the

competitor's product and enabled

fracture free machining.

The competitor's product suffered from

edge adhesion leading to breakage.

Tool Diameter ø10×R1 Output : 150pcs/tool

Cutting Conditions: c=32m/min, z=0.018mm/t,

p=20mm, e=0.8mm, Dry

Application Examples

20mm

0.8mm

Tool Diameter : ø6×R1

Cutting Conditions: vc=20m/min, fz=0.025mm/t,

ap=5mm, ae=0.5mm, wet

SSEH Radius Anti-vibration Type

Characteristics and Applications

New anti-vibration type added to the SSEH type endmill for exotic alloys.

Builds on the same features of existing endmills by adding an irregular lead for exceptionally good anti-vibration performance.

Compatible with wide range of milling for exotic alloys including SUS, Inconel, and Titanium.

Reduces chattering for high-speed, high-feed cutting.

Both coated and uncoated types are available in stock to meet various conditions.

Irregular Pitch Irregular Lead

Unique, smooth radius design

Original Wide Arc Flute

Large

Core

Diameter

Semi-mirrored Rake Face

SSEH Anti-vibration Radius

Endmill

SSEHVL 4120W-30

No Anti-vibration Mechanism

Endmill

ø12×R3.0

Machined

Surface

Vibration Data

Tool Breakage

Cutting Conditions: c=42.4m/min =1,125min-1

f=200mm/min z=0.044min/t

p=5.0mm, e=12mm, Wet

Application Examples

No chattering

Chattering occurs

Stable cutting

Increases chattering at

entry point corner

Corner Finishing for Titanium Alloy

No breakage

Chipping caused by

chattering

I92, I94, I129 I88, I90, I128

Anti-vibration Type

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

I13

Endmills

Endmill Anti-drop Mechanism

Tool does not come off.

Type

No. of Flutes

Shape

Diameter (mm)

GSXVL 4000S-2.5D

Square I54

ø12.0 to ø25.0

GSXVL 4000S-R-2.5D

Square I86

ø12.0 to ø25.0

Applicable Products

Type

No. of Flutes

Shape

Diameter (mm)

SSEHVL 4000WS-R

Radius I90

ø12.0 to ø25.0

SSEH 4000WS-R

Radius I94

ø12.0 to ø25.0

Applicable Holders

Shrink-fit Chuck Holder Collet Chuck Holder

· High runout accuracy ensures

long tool life.

· Easy setup with a dedicated

shrink-fit unit

· High rigidity provides high

resistance to chattering.

· Tool change-over is simple.

· Specially designed collet

provides strong grip.

· High rigidity provides high

resistance to chattering.

Stable Milling

Failure occurs due

to fallen tool.

Concept Illustration during slotting

With Anti-drop Mechanism

Without Anti-drop Mechanism

I54, I86, I90, I94

Characteristics and Applications

Incorporating prevents tools from

coming off even during high load machining such as slotting

and roughing, resulting in highly efficient machining.

Work damage caused by tool that has come off can be avoided, which prevents failures.

Endmill can be pushed out after regrinding so that clamping

can always be performed at the same tool height.

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

I14

Coated

Endmills

Endmills for Hardened Steel

GS MILL HARD Series

Characteristics

GS MILL HARD (Square / Ballnose / Radius)

With the high-Al content Al-Ti-Cr coating, GS Hard Coat, oxidation

resistance is now 3 times higher than the conventional grade at 1,100°C.

This improves thermal and wear resistance in ultra-high-speed machining.

The coating surface roughness is similar to that of the conventional GS

Coat, which reduces cutting friction while enhancing smooth cutting.

Ultra-fine grained carbide substrate with low cobalt content has been newly developed

to improve substrate strength. This increases tool durability and prevents the micro-

plastic deformation of the cutting edge that occurs during ultra-high-speed machining.

New unique cross-sectional design promotes better chip evacuation and tool rigidity.

Hard (Radius) / New endmill series with improved fracture resistance.

Hard (Ballnose) / Utilizes a new coating with excellent lubricity as well as

thermal resistance. Achieves precision finishing of hardened steel, with a

precise radial tolerance of +3 to -7μm and a seamless ball-to-periphery profile.

Side Milling of SKD61 (53HRC) with GS MILL Hard Radius

Type

No. of Flutes

Shape Diameter (mm)

GSH 4000SF

GSH 6000SF

GSH 8000SF

Flutes

I66, I67, I68

ø1 to ø20

GSBH 20000SF

Flutes

I106

R0.2

R6.0

ø0.4

ø12

GS MILL HARD (Square/Ballnose)

Series

Type

No. of Flutes

Shape Diameter (mm)

GSH 6000SF-R

GSH 8000SF-R

Flutes

I100, I101

ø6 to ø20

GS MILL HARD (Radius)

Seamless ball-to-

periphery profile

Radius Precision 3 to -7μ

Corner Wear

Flank Wear

Boundary Wear

GS MILL HARD

(Square)

Competitor's Product

100

120

140

160

0.2

Units (mm)

Wear ( m)

GS MILL HARD (Square)

Cutting Performance (6 Flutes, ø10 Side Face Milling)

Work Material: SKD61 53HRC

Tool: GSH 6100SF ø10

Cutting Length: 75m

Cutting Conditions:

vc=800m/min n=25,460min-1

z=0.07 mm/t

=10,500mm/min

ap=10mmࠉࠉ ae=0.2mm

Dry (Air Blown), Down Cut

GS MILL HARD (Ballnose)

Application Example(Automotive Component Precision Forging Die)

Work Material: SKH51 62HRC

Tool: GSBH 20300SF R3

Cutting Length: Approx. 150m

Cutting Conditions:

vc=75m/min n=4,000min-1

n=4,000min-1

=0.075 mm/t

=600mm/min

ap= 0.16mmࠉࠉ pf=1mm

0.16

GS MILL HARD

(Ballnose)

Competitor’s Product

Very small wear

Tip is worn flat

Units (mm)

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

I15

Endmills

Tool Wear Comparison

Life Difference

AURORA Coat Long Neck Ballnose

0.01

0.02

0.03

0.04

4 8 12 20 30 40 60 80 100

Flank Wear Width (mm)

Uniform Wear

Cutting Length (m)

SNB2 Type

Competitor's CrN-coated Product

Tool

Cutting Length 100 m

Cutting Conditions

SNB2 Type

Competitor's

CrN-coated

Product

Work Material Tough-pitch Copper

Tool

ࠉ

R0.3mm Ballnose Endmill

Cutting Conditions

vc = 57m/min

n = 30,000min-1

vf = 700mm/min

ap = 0.035mm

ae = 0.03mm

Oil Mist

High Wear

DLC (Diamond Like Carbon) Coating

AURORA Coat Endmill Series

Excellent in adhesion resistance in copper alloy milling and achieves long tool life!

Characteristics and Applications

Super smooth AURORA Coat results in low adhesion as well as good surface finish!

With lower cutting forces and high rigidity, this series is suitable for low rigidity machine!

Available in 2 and 4 flutes square type as well as ballnose type endmills

Added R0.05 to R2.00mm long neck ball endmills for machining copper electrodes!!

Series

No. of Flutes

Shape

External Diameter (mm)

ASM 2000DL

Square

I107

ø2 to ø16

ASM 4000DL

Square

I108

ø2 to ø16

SNB 2000DL

Ballnose

I109

R1 to R8

ø2 to ø16

SNB2

Long Neck Ball

I110

R0.05 to R2

ø0.1 to ø4

Product Range

AURORA Coat Long Neck Ballnose SNB2 Type

Performance

Comparison of Cutting Resistance

150

100

200

250

300

180

125

252

130

DryWet

Emulsion Type

Cutting Resistance (N)

Uncoated

30%

Decrease

48%

Decrease

AURORA

Coat

AURORA

Coat

Vibration

Surface Finish Comparison

0.5

1. 5

2.5

0.34 0.34 0.32

2.17

Finishing Ra (μm)

Uncoated

Vibration

Good finish even

with Dry cut

Wet

Emulsion Type

Dry

Uncoated

AURORA

Coat

AURORA

Coat

Work Material: A5052

Tool: ASM 4100DL

ø10 (4 Flutes)

Cutting Conditions:

vc=200m/min

n=6,300min-1

fz=0.05mm/t

vf =1,300mm/min

ap=10mm

ae=1mm

Down Cut

ool

Cut

tin

Achieves longer tool life compared with chromium nitride (CrN)-coated carbide tools.

Ballnose radii of 0.05 to 2.00mm are covered in this product line.

Reduced friction coefficient

Extremely smooth coating structure

Tool Wear Comparison

I107, I108, I109

I110

For Copper

Electrodes

For Copper

Electrodes

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

Endmills

I16

SUMIDIA BinderlessEndmills

NPDRS Type /NPDBS Type /NPDB Type

Expansion

SUMIDIA Coated Endmills

SDCB

Type

SUMIBORON Endmills

BNBR Type /BNBP Type /BNBC Type

MOLD FINISH MASTER

Expansion

SUMIBORON Radius EndmillsSUMIBORON Radius Endmills

BNBRBNBR Type Type

I134

SUMIBORON Ballnose EndmillsSUMIBORON Ballnose Endmills

BNBPBNBP Type Type

I136

For Hardened Steel For Copper Electrodes

Achieving longer tool life in high speed, high precision machining of pre-hardened steel (up to 60HRC)

Excellent surface finish drastically reduces the grinding process.

Optimized cutting edge design and CBN grade for copy and face milling, caters to a wide range of applications.

Radius

Ballnose

SUMIDIA Coated Ballnose Endmills

SDCBSDCBTypeType

I133

For Roughing and Medium Finishing of Carbide and Hard Brittle Materials

Enables high efficiency roughing and medium finishing of carbide molds.

Newly developed diamond coating offers long

and stable tool life.

Achieves the highest machining precision in

combination with SUMIDIA binderless endmills.

Ballnose

SUMIBORON Ballnose EndmillsSUMIBORON Ballnose Endmills

BNBCBNBC Type Type

I138

For Copper Electrodes

Ballnose radii of 0.1 to 0.5mm are covered in this series.

Utilizing high CBN content grade for excellent

edge sharpness and wear resistance.

Achieves high quality milling with high precision cutting edge.

Ballnose

SUMIDIA Binderless Radius Endmills

NPDRSNPDRS Type Type

I132

SUMIDIA Binderless Ballnose Endmills

NNPDBSPDBS Type Type //NPDBNPDB Type Type

I130, I131

For Finishing of Carbide and Hard Brittle Materials For Finishing of Carbide and Hard Brittle Materials

Employs nano-polycrystalline diamond, which is harder than single-crystal diamond, for the cutting edge.

Enables direct cutting of carbide, which is impossible for existing single-crystal or polycrystalline

diamonds.

Ideal for finishing of hard, brittle materials including carbide. Enables high precision machining and long tool life.

The standard finishing NPDBS type greatly reduces milling costs.

The precision finishing NPDB type prevents shape deformation with a polishless endmill.

Radius

Ballnose

SUMIDIA Binderless Ballnose Endmills

NPDBS Type / NPDB Type

Radius

SUMIDIA Binderless Radius Endmills

NPDRS Type

Hard Brittle

Material

Hard Brittle

Material

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

Endmills

I17

SUMIDIA Binderless is a type of polycrystalline diamond, produced

by directly binding nano-order diamond grains without using any

binders.

SUMIDIA Binderless is harder than single-crystal diamond and

has no cleavability. Therefore, it enables machining of hard, brittle

materials such as carbides and enables new machining methods.

General Features

SUMIDIA Binderless is a pure diamond, but unlike single-crystal

diamonds, has no anisotropy. Therefore, it displays excellent

wear resistance with less uneven wear.

Thanks to its polycrystalline structure, SUMIDIA Binderless has no cleavability

peculiar to single-crystal diamonds and displays excellent fracture resistance.

Characteristic

150100500

Single

Crystal Diamond

Conventional PCD

Load 4.9N

No anisotropy and ultra-hard

SUMIDIA

Binderless

Hardness depends on face orientation

Knoop Hardness HK(GPa)

Hardness

Application to Optical Use (Fly-Eye Lens Mold)Application to Medical Use (

μ-TAS Mold)

Work Material : Carbide AF1(Ultra-fine Grain Carbide)

Tool

: Finishing NPDB1050-020( 0.5)

Roughing

Diamond-Coated Endmill ( 0.5)

Cutting Conditions

: n=60,000min-1, vf=300mm/min

pf=0.005mm, Oil Mist

Surface Roughness

: Ra 0.015μm

Cutting Time : Finishing 2 hours 40 minutes

Roughing 55 minutes

Work Material : Carbide AF1(Ultra-fine Grain Carbide)

Conditions

: ø6 (Hemispherical Surface Milling)

Tool

: NPDB1050-020

NPDBS1050-020

SDCB2R050-020

R0.5, #400

Cutting Conditions

: n=40,000min-1, vf=120mm/min

pf=0.005mm, Oil Mist

Cutting Time : 1 hour 30 minutes

Work Material : Carbide AF1(Ultra-fine Grain Carbide)

Conditions

: 10mm×10mm×Depth 2mm

Tool

: NPDRS1100R005-030

Cutting Conditions

: n=40,000min-1, vf=200mm/min

pf=0.005mm, Oil Mist

Surface Roughness

: Ra 0.015μm

Cutting Time : 2 hours

Work Material : Carbide AF1(Ultra-fine Grain Carbide)

Tool

: NPDB1030-010( 0.3)

Cutting Conditions

: n=38,000min-1, vf=95mm/min

pf=0.001mm, Wet(Oil based)

Machining Allowance

: 0.003mm

Surface Roughness

: Ra 0.016 - 0.020μm

Cutting Length

: 8.3m

Cutting Time : Finishing 1 hour 28 minutes

1mm

MOLD FINISH MASTER

Pocket Millimg

Hemispherical Surface Milling

NPDBS TypeNPDB Type

Ra 0.017μm Ra 0.060μm

Ra 0.078μm Ra 0.110μm

SDCB Type

(SUMIDIA Coated) Electroplated Grinding Wheel

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

I18

Endmills

MOLD FINISH MASTER

Radius

Ballnose

SUMIBORON MOLD FINISH MASTER

BNBR Type

SUMIDIA Coated Ballnose Endmills

SDCB Type

Improved machining surface quality through use of wiper edge (available on ø1.0mm endmills and larger).

Enables high efficiency roughing and medium finishing of carbide molds.

Newly developed diamond coating offers long and stable tool life.

Achieves the highest machining precision in combination

with SUMIDIA binderless endmills.

ø10-mm Hemisphere Milling

No. of ø2.0 (R1.0) Product Workpieces and Tool Wear (Delamination)

Machined Surface Comparison

With Wiper Edge Without Wiper Edge

Ra 0.08 m

Rz 0.62 m

Ra 0.14 m

Rz 1.04 m

Combination of CBN SUMIBORON BNX20 with excellent wear

resistance and optimal cutting edge design realises longer tool life.

MOLD FINISH MASTER Coated Carbide

No Chipping Chipping

Work Material : STAVAX(52HRC)

Tool : BNBR 2D200R050-0604(ø2×r0.5)

Cutting Conditions

: n=20,000min-1, vf=400mm/min

ap=0.03mm, pf=0.70mm Oil Mist

Work Material : Carbide AF1 Ultra-fine Grain Carbide

Tool SDCB 2R100-060

Cutting Conditions : n=30,000min

-1

, vf=300mm/min

ae=0.3mm, ap=0.1mm, Air blow

Excellent wear resistance delivers almost 10 times longer

tool life than carbide endmills.

0 30 60 90 120

0.06

0.05

0.04

0.03

0.02

0.01

Cutting Distance (m)

10x Tool

Life

6x Efficiency!

Low Wear

Breakage

Coated Carbide

Flank Wear Width (mm)

MOLD FINISH MASTER

Tool Wear Comparison

MOLD FINISH MASTER Coated Carbide

Small Wear Chipping

Work Material : STAVAX(52HRC)

Tool : BNBR 2D200R050-0604(ø2×r0.5)

MOLD FINISH MASTER

Cutting Conditions

: n=20,000min-1, vf=800mm/min

ap=0.03mm, pf=0.70mm Oil Mist

Coated Carbide

Cutting Conditions

: n=4,800min-1, vf=120mm/min

ap=0.03mm, pf=0.70mm Oil Mist

Tool Life

Material Removal Volume (cm3)

0 1,000 2,000

2,408

2,355

1,466

1,387

3,000

Competitor's Product

Mold Finish Master

SDCB

Hard Brittle

Material

Mold Finish Master

Rz 4.792μm

Comp. A (Roughing)

Rz 8.976μm

Comp. A (Finishing)

Rz 8.784μm

Comp. B

Rz 13.88μm

7 Holes Milled

Roughness

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

I19

Endmills

MOLD FINISH MASTER

0.01

0.02

0.03

0.04

4 8 12 20 30 40 60 80

100 120 200 250 300 350

㸦0.5h㸧㸦1h㸧㸦2h㸧㸦4h㸧㸦11h㸧㸦14h㸧

400

Cutting Distance m Cutting Time

Carbide+CrN-coated

Difference in Tool Life

MOLD FINISH MASTER

Longer Tool Life

Flank Wear Width (mm)

SUMIBORON MOLD FINISH MASTER

BNBP Type

SUMIBORON MOLD FINISH MASTER

BNBC Type

Ballnose

Achieves high precision machining with precise ball profile of ±0.005 mm.

Combination of SUMIBORON BN350 with excellent fracture resistance and cutting

edge designed with negative rake angle provides stable interrupted cutting.

Large Negative Rake Angle

Strong

Cutting Edge!

Strong

Cutting Edge!

Center cutting edge, stable machined surface quality

Strong cutting edge enables use in roughing applications

MOLD FINISH MASTER Coated Carbide

Work Material : STAVAX(52HRC)

Tool : BNBP 2R100-0554 (R1.0)

Cutting Conditions

: n=25,000min-1, vf=1,500mm/min

ap=0.10mm, pf=0.20mm Oil Mist

No Chipping Chipping at center portion

Excellent Wear Resistance and Machined Surface Quality

0.04

0.03

0.02

0.01

050

100 150 200 250

Low Wear

Cutting Distance (m)

Coated Carbide

MOLD FINISH MASTER

Flank Wear Width (mm)

High Wear Burr

Work Material : STAVAX(52HRC)

Tool : BNBP 2R030-0154 (R0.3)

Cutting Conditions

: n=25,000min-1, vf=1,500mm/min

ap=0.05mm, pf=0.10mm Oil Mist

Tool Wear and Machined Surface Comparisons

MOLD FINISH MASTER (6 Uses)

Coated Carbide (2 Uses)

Low Wear High Wear

Good Machined Surface Burr

Tool Wear Comparison

MOLD FINISH MASTER

Competitor's Carbide+CrN-coated Product

Minimal wear, Able to Continue

High Wear

Work Material : Tough-pitch Copper

Tool : BNBC 2R030-0304 (R0.3)

Cutting Conditions

: vc=57m/min, n=30,000min-1

fz=0.007mm/t, vf=400mm/min

ap=0.005mm, ae=0.05mm Oil Mist

Good cutter mark surface on BNBC Type

Ra 0.347 Ra 1.368

Ballnose

Ballnose radii of 0.1 to 0.5mm are covered in this series.

Achieves high quality milling with high precision cutting edge.

Sharp cutting edge with high sharpness

and wear resistance

For Copper

Electrodes

Work Material : Tough-pitch Copper (Side Milling)

Tool : BNBC 2R030-0304 (R0.3)

Cutting Conditions

: n=30,000min-1, vf=700mm/min

ap=0.035mm, ae=0.03mm Oil Mist

Achieving further improved tool life

MOLD FINISH MASTER

Competitor's Carbide+CrN-coated Product

Low Wear (Cutting Length 400mm)

High Wear (Cutting Length 100mm)

Utilizing high CBN content grade for excellent edge sharpness and wear resistance.

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

I20

Coated

Endmills

Endmill Identification (GSXMILL Series Only)

Series Code

GSX 2 1000 C - 1.5D

No. of Flutes

Diameter

Cutting Edge

Cutting Edge Length

S: Sharp Edge

C: Gash Land

GSX MILL Endmills (2 Flutes)

GSX 20000C-1.5D Type

DC Tolerance

D ≤ 3.0 0 –0.015

3.0 < D ≤ 12 0 –0.020

12.0 < D 0 –0.030

Flutes

Coating

Flutes

Flutes Corner

Side Milling Face Milling

Helical Milling

Ramping

Spot Facing

Groove Milling

Groove Finishing

Spot Facing

Coated

Carbide

Carbon

Steel

Alloy

Steel

Pre-hardened

Steel

Tempered Steel

Die Steel

Stainless

Steel

Ti Alloy

Heat Resistant Alloy

Cast Iron

Aluminum

Alloy

Copper

Alloy

Graphite

CFRP

Hardened Steel

45 to 55

HRC

55 to 60

HRC 60 to 65

HRC

Cat. No. Stock

Dimensions (mm)

Cutting diameter

Depth of cut

APMX

Cutting Edge Length

Total Length

Shank diameter

DMM

GSX 20050C-1.5D 0.5 1.0 1.4 40 4

20100C-1.5D 1.0 1.5 2.5 40 4

20150C-1.5D 1.5 2.3 3.3 40 4

20200C-1.5D 2.0 3.0 4.0 40 4

20250C-1.5D 2.5 3.8 4.8 40 4

GSX 20300C-1.5D 3.0 4.5 6.0 45 6

20350C-1.5D 3.5 5.3 6.8 45 6

20400C-1.5D 4.0 6.0 7.5 45 6

20450C-1.5D 4.5 6.8 8.3 50 6

20500C-1.5D 5.0 7.5 9.5 50 6

GSX 20550C-1.5D 5.5 8.3 10.3 50 6

20600C-1.5D 6.0 9.0 50 6

20650C-1.5D 6.5 10.0 12.0 60 8

20700C-1.5D 7.0 11.0 13.0 60 8

20750C-1.5D 7.5 12.0 14.0 60 8

GSX 20800C-1.5D 8.0 12.0 60 8

20850C-1.5D 8.5 13.0 15.0 70 10

20900C-1.5D 9.0 14.0 16.0 70 10

20950C-1.5D 9.5 15.0 17.0 70 10

21000C-1.5D 10.0 15.0 70 10

GSX 21050C-1.5D 10.5 16.0 18.5 75 12

21100C-1.5D 11.0 17.0 19.5 75 12

21150C-1.5D 11.5 18.0 20.5 75 12

21200C-1.5D 12.0 18.0 75 12

21300C-1.5D 13.0 20.0 23.5 90 16

GSX 21400C-1.5D 14.0 21.0 24.5 90 16

21500C-1.5D 15.0 23.0 26.5 90 16

21600C-1.5D 16.0 24.0 90 16

21700C-1.5D 17.0 26.0 30.5 100 20

21800C-1.5D 18.0 27.0 31.5 100 20

GSX 21900C-1.5D 19.0 29.0 33.5 100 20

22000C-1.5D 20.0 30.0 100 20

22500C-1.5D 25.0 38.0 120 25

Grade: ACF20

Body

DMM h5

APMX

Helix Angle

Expansion

mark: Standard stocked item (expanded item)

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

I21

Coated

Endmills

Recommended Cutting Conditions

1. For stable machining performance use rigid, high-precision machines and holders.

2. Use air blow when dry machining.

3. Use wet machining for stainless steel, heat resistant alloy, and titanium alloy applications.

If the machine cannot achieve the recommended spindle speed, please use the max. spindle speed available.

aeDC

GSX MILL Endmills (2 Flutes)

GSX 20000C-1.5D Type

Side Milling

(mm)

Work Material

Cond.

Structural Steel

Carbon Steel

(150 to 250HB)

Cast Iron

Alloy Steel

SCM

(25 to 35HRC)

Tempered Steel, Hardened Steel

NAK, HPM

(35 to 45HRC)

Hardened Steel

(45 to 55HRC)

Stainl

ss Steel

SUS304, SUS316

Heat Resistant Alloy

Titanium Alloy

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

1.0 19,600 250 19,600 250 19,600 250 18,300 180 12,700 100 9,000 60 11,000 70 9,000 50

2.0 11,200 340 11,200 340 11,200 340 10,500 240 7,300 130 5,300 80 6,400 90 5,300 70

4.0 6,400 460 6,400 460 6,400 460 6,000 320 4,200 180 3,000 110 3,600 120 3,000 90

6.0 4,600 560 4,600 560 4,600 560 4,300 400 3,000 210 2,200 130 2,700 140 2,200 100

8.0 3,400 560 3,400 560 3,400 560 3,200 400 2,200 210 1,600 130 2,000 140 1,600 100

10.0 2,800 560 2,800 560 2,800 560 2,600 400 1,800 210 1,300 130 1,600 140 1,300 100

12.0 2,300 560 2,300 560 2,300 560 2,200 400 1,500 210 1,100 130 1,300 140 1,100 100

16.0 1,700 450 1,700 450 1,700 450 1,600 320 1,100 180 800 100 1,000 110 800 85

20.0 1,350 380 1,350 380 1,350 380 1,300 280 900 160 650 90 800 100 650 75

25.0 1,080 300 1,080 300 1,080 300 1,040 220 720 130 520 70 640 80 520 60

Standard

Depth-of-cut

1.5DC 1.0DC

0.05DC 0.02DC

Groove Milling

(mm)

Work Material

Cond.

Structural Steel

Carbon Steel

(150 to 250HB)

Cast Iron

Alloy Steel

SCM

(25 to 35HRC)

Tempered Steel, Hardened Steel

NAK, HPM

(35 to 45HRC)

Hardened Steel

(45 to 55HRC)

Stainl

ss Steel

SUS304, SUS316

Heat Resistant Alloy

Titanium Alloy

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

1.0 19,600 200 19,600 250 19,600 250 18,300 180 12,700 100 9,000 60 11,000 50 4,500 20

2.0 11,200 270 11,200 340 11,200 340 10,500 240 7,300 130 5,300 80 6,400 65 2,650 25

4.0 6,400 370 6,400 460 6,400 460 6,000 320 4,200 180 3,000 110 3,600 80 1,500 35

6.0 4,600 450 4,600 560 4,600 560 4,300 400 3,000 210 2,200 130 2,700 100 1,100 40

8.0 3,400 450 3,400 560 3,400 560 3,200 400 2,200 210 1,600 130 2,000 100 800 40

10.0 2,800 450 2,800 560 2,800 560 2,600 400 1,800 210 1,300 130 1,600 100 650 40

12.0 2,300 450 2,300 560 2,300 560 2,200 400 1,500 210 1,100 130 1,300 100 500 40

16.0 1,700 360 1,700 450 1,700 450 1,600 320 1,100 180 800 100 1,000 80 400 35

20.0 1,350 300 1,350 380 1,350 380 1,300 280 900 160 650 90 800 70 320 30

25.0 1,080 240 1,080 304 1,080 304 1,040 224 720 128 520 72 640 56 256 24

Standard Depth-of-cut

0.2DC 0.5DC 0.2DC 0.05DC 0.2DC

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

I22

Coated

Endmills

GSX MILL 2 Flute Endmills Sharp Edge

GSX 20000S-2D Type

Coating

Flutes

Corner

Groove Finishing

Side Milling

Flutes

Cat. No. Stock

Dimensions (mm)

Cutting diameter

Depth of cut

APMX

Cutting Edge Length

Total Length

Shank diameter

DMM

GSX 20030S-2D 0.3 0.6 1.0 40 4

20040S-2D 0.4 0.8 1.2 40 4

20050S-2D 0.5 1.3 1.7 40 4

20060S-2D 0.6 1.3 1.8 40 4

20070S-2D 0.7 1.4 1.9 40 4

GSX 20080S-2D 0.8 1.6 2.1 40 4

20090S-2D 0.9 1.8 2.3 40 4

20100S-2D 1.0 2.5 3.5 40 4

20110S-2D 1.1 2.5 3.5 40 4

20120S-2D 1.2 2.5 3.5 40 4

GSX 20130S-2D 1.3 2.6 3.6 40 4

20140S-2D 1.4 2.8 3.8 40 4

20150S-2D 1.5 3.8 4.8 40 4

20150S-2D-S3 1.5 3.8 4.8 38 3

20160S-2D 1.6 3.8 4.8 40 4

GSX 20170S-2D 1.7 3.8 4.8 40 4

20180S-2D 1.8 3.8 4.8 40 4

20190S-2D 1.9 3.8 4.8 40 4

20200S-2D 2.0 5.0 6.0 40 4

20200S-2D-S3 2.0 5.0 6.0 38 3

GSX 20210S-2D 2.1 6.0 7.0 40 4

20220S-2D 2.2 6.0 7.0 40 4

20230S-2D 2.3 6.0 7.0 40 4

20240S-2D 2.4 6.0 7.0 40 4

20250S-2D 2.5 6.3 7.3 40 4

GSX 20260S-2D 2.6 7.0 8.0 40 4

20270S-2D 2.7 7.0 8.0 40 4

20280S-2D 2.8 7.0 8.0 40 4

20290S-2D 2.9 7.0 8.0 40 4

20300S-2D 3.0 7.5 9.0 45 6

GSX 20300S-2D-S3 3.0 7.5 38 3

20310S-2D 3.1 7.5 9.0 45 6

20320S-2D 3.2 7.5 9.0 45 6

20330S-2D 3.3 7.5 9.0 45 6

20340S-2D 3.4 7.5 9.0 45 6

GSX 20350S-2D 3.5 8.8 10.3 45 6

20360S-2D 3.6 8.8 10.3 45 6

20370S-2D 3.7 8.8 10.3 45 6

20380S-2D 3.8 8.8 10.3 45 6

20390S-2D 3.9 8.8 10.3 45 6

GSX 20400S-2D 4.0 11.0 14.0 45 6

20400S-2D-S4 4.0 11.0 45 4

20410S-2D 4.1 11.0 14.0 45 6

20420S-2D 4.2 11.0 14.0 45 6

20430S-2D 4.3 11.0 14.0 45 6

GSX 20440S-2D 4.4 11.0 14.0 45 6

20450S-2D 4.5 11.3 12.8 50 6

20460S-2D 4.6 11.3 12.8 50 6

20470S-2D 4.7 11.3 12.8 50 6

20480S-2D 4.8 11.3 12.8 50 6

Grade: ACF20

Body Diameter ø0.3 to 4.8mm

DMM h5

APMX

Helix Angle

Expansion

mark: Standard stocked item (expanded item)

Coated

Carbide

Carbon

Steel

Alloy

Steel

Pre-hardened

Steel

Tempered Steel

Die Steel

Stainless

Steel

Ti Alloy

Heat Resistant Alloy

Cast Iron

Aluminum

Alloy

Copper

Alloy

Graphite

CFRP

Hardened Steel

45 to 55

HRC

55 to 60

HRC 60 to 65

HRC

DC Tolerance

D ≤ 3.0 0 –0.015

3.0 < D ≤ 12 0 –0.020

12.0 < D 0 –0.030

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

Coated

Endmills

Coating

Corner

GSX MILL 2 Flute Endmills Sharp Edge

GSX 20000S-2D Type

Groove Finishing

Side Milling

Flutes

I23

Cat. No. Stock

Dimensions (mm)

Cutting diameter

Depth of cut

APMX

Cutting Edge Length

Total Length

Shank diameter

DMM

GSX 20490S-2D 4.9 11.3 12.8 50 6

20500S-2D 5.0 13.0 19.6 50 6

20510S-2D 5.1 13.0 19.6 50 6

20520S-2D 5.2 13.0 19.6 50 6

20530S-2D 5.3 13.0 19.6 50 6

GSX 20540S-2D 5.4 13.0 19.6 50 6

20550S-2D 5.5 13.0 19.6 50 6

20560S-2D 5.6 13.0 19.6 50 6

20570S-2D 5.7 13.0 19.6 50 6

20580S-2D 5.8 13.0 19.6 50 6

GSX 20590S-2D 5.9 13.0 19.6 50 6

20600S-2D 6.0 13.0 50 6

20610S-2D 6.1 13.0 19.6 50 8

20620S-2D 6.2 13.0 19.6 50 8

20630S-2D 6.3 13.0 19.6 50 8

GSX 20640S-2D 6.4 13.0 19.6 50 8

20650S-2D 6.5 13.0 19.6 60 8

20660S-2D 6.6 13.2 19.8 60 8

20670S-2D 6.7 13.4 20.0 60 8

20680S-2D 6.8 13.6 20.2 60 8

GSX 20690S-2D 6.9 13.8 20.4 60 8

20700S-2D 7.0 16.0 21.1 60 8

20710S-2D 7.1 16.0 21.1 60 8

20720S-2D 7.2 16.0 21.1 60 8

20730S-2D 7.3 16.0 21.1 60 8

GSX 20740S-2D 7.4 16.0 21.1 60 8

20750S-2D 7.5 16.0 21.1 60 8

20760S-2D 7.6 16.0 21.1 60 8

20770S-2D 7.7 16.0 21.1 60 8

20780S-2D 7.8 16.0 21.1 60 8

GSX 20790S-2D 7.9 16.0 21.1 60 8

20800S-2D 8.0 19.0 60 8

20810S-2D 8.1 19.0 24.1 60 10

20820S-2D 8.2 19.0 24.1 60 10

20830S-2D 8.3 19.0 24.1 60 10

GSX 20840S-2D 8.4 19.0 24.1 60 10

20850S-2D 8.5 19.0 24.1 70 10

20860S-2D 8.6 19.0 24.1 70 10

20870S-2D 8.7 19.0 24.1 70 10

20880S-2D 8.8 19.0 24.1 70 10

GSX 20890S-2D 8.9 19.0 24.1 70 10

20900S-2D 9.0 19.0 24.1 70 10

20910S-2D 9.1 19.0 24.1 70 10

20920S-2D 9.2 19.0 24.1 70 10

20930S-2D 9.3 19.0 24.1 70 10

GSX 20940S-2D 9.4 19.0 24.1 70 10

20950S-2D 9.5 20.0 25.1 70 10

20960S-2D 9.6 20.0 25.1 70 10

20970S-2D 9.7 20.0 25.1 70 10

20980S-2D 9.8 20.0 25.1 70 10

Grade: ACF20

Body Diameter ø4.9 to 9.8mm

DMM h5

APMX

Helix Angle

Expansion

mark: Standard stocked item (expanded item)

Coated

Carbide

Carbon

Steel

Alloy

Steel

Pre-hardened

Steel

Tempered Steel

Die Steel

Stainless

Steel

Ti Alloy

Heat Resistant Alloy

Cast Iron

Aluminum

Alloy

Copper

Alloy

Graphite

CFRP

Hardened Steel

45 to 55

HRC

55 to 60

HRC 60 to 65

HRC

DC Tolerance

D ≤ 3.0 0 –0.015

3.0 < D ≤ 12 0 –0.020

12.0 < D 0 –0.030

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

PCD

CBN

Coated

Endmills

GSX MILL 2 Flute Endmills Sharp Edge

GSX 20000S-2D Type

Coating

Flutes

Corner

Endmill Identification (GSXMILL Series Only)

GSX 2 0150 S - 2D - S3

Groove Finishing

Side Milling

Flutes

Cat. No. Stock

Dimensions (mm)

Cutting diameter

Depth of cut

APMX

Cutting Edge Length

Total Length

Shank diameter

DMM

GSX 20990S-2D 9.9 20.0 25.1 70 10

21000S-2D 10.0 22.0 70 10

21050S-2D 10.5 22.0 24.5 75 12

21100S-2D 11.0 22.0 24.5 75 12

21150S-2D 11.5 23.0 25.5 75 12

GSX 21200S-2D 12.0 26.0 75 12

21250S-2D 12.5 26.0 29.5 75 16

21300S-2D 13.0 26.0 29.5 90 16

21400S-2D 14.0 28.0 31.5 90 16

21500S-2D 15.0 30.0 33.5 90 16

GSX 21600S-2D 16.0 32.0 90 16

21700S-2D 17.0 35.0 39.5 100 20

21800S-2D 18.0 40.0 44.5 100 20

21900S-2D 19.0 40.0 44.5 100 20

22000S-2D 20.0 40.0 100 20

GSX 22100S-2D 21.0 42.0 47.0 110 25

22200S-2D 22.0 44.0 49.0 110 25

22300S-2D 23.0 46.0 51.0 120 25

22400S-2D 24.0 48.0 53.0 120 25

22500S-2D 25.0 50.0 120 25

Grade: ACF20

Body Diameter ø9.9 to 25.0mm

DMM h5

APMX

Helix Angle

I24 mark: Standard stocked item (expanded item)

Coated

Carbide

Carbon

Steel

Alloy

Steel

Pre-hardened

Steel

Tempered Steel

Die Steel

Stainless

Steel

Ti Alloy

Heat Resistant Alloy

Cast Iron

Aluminum

Alloy

Copper

Alloy

Graphite

CFRP

Hardened Steel

45 to 55

HRC

55 to 60

HRC 60 to 65

HRC

DC Tolerance

D ≤ 3.0 0 –0.015

3.0 < D ≤ 12 0 –0.020

12.0 < D 0 –0.030

Series Code

No. of Flutes

Diameter

Cutting Edge

Cutting Edge Length

S: Sharp Edge

C: Gash Land

Shank Diameter

Square

2 Flutes

3 Flutes

4 Flutes

6 Flutes

8 Flutes

Radius

Ballnose

DLC

SUMIDIA

Coat

Long

Neck

Uncoated

CBN

PCD

Coated

Endmills

GSX MILL 2 Flute Endmills Sharp Edge

GSX 20000S-2D Type

I25

Recommended Cutting Conditions

1. For stable machining performance use rigid, high-precision machines and holders.

2. Use air blow when dry machining.

3. Use wet machining for stainless steel, heat resistant alloy, and titanium alloy applications.

If chattering is a pr oblem, reduce the spindle speed and feed rate indicated in the table below by the same ratio, or reduce the depth of cut.

5. This series is not recommended for groove milling.

6. If the machine cannot achieve the recommended spindle speed, please use the max. spindle speed available.

Side Milling

(mm)

Work Material

Cond.

Structural Steel

Carbon Steel

(150 to 250HB)

Cast Iron

Alloy Steel

SCM

(25 to 35HRC)

Tempered Steel, Hardened Steel

NAK, HPM

(35 to 45HRC)

Hardened Steel

(45 to 55HRC)

Stainl

ss Steel

SUS304, SUS316

Heat Resistant Alloy

Titanium Alloy

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

Spindle Speed

(min-1)

Feed Rate

(mm/min)

1.0 16,600 180 16,600 180 16,600 180 15,500 130 10,500 70 7,500 45 9,400 50 7,500 35

2.0 9,500 250 9,500 250 9,500 250 9,000 200 6,200 100 4,500 60 5,400 70 4,500 50

4.0 5,400 330 5,400 330 5,400 330 5,000 250 3,400 120 2,500 75 3,000 90 2,500 65

6.0 4,000 400 4,000 400 4,000 400 3,700 300 2,550 150 1,900 100 2,300 110 1,900 80

8.0 3,000 400 3,000 400 3,000 400 2,800 300 1,900 150 1,400 100 1,700 110 1,400 80

10.0 2,400 400 2,400 400 2,400 400 2,200 300 1,500 150 1,100 100 1,300 110 1,100 80

12.0 2,000 400 2,000 400 2,000 400 1,850 300 1,300 150 950 100 1,100 110 950 80

16.0 1,500 330 1,500 330 1,500 330 1,400 250 950 120 700 75 850 85 700 60

20.0 1,200 280 1,200 280 1,200 280 1,100 220 750 110 550 65 650 75 550 55

25.0 960 220 960 220 960 220 880 170 600 85 440 50 520 60 440 45

Standard

Depth-of-cut

2.0DC

0.02DC 0.01DC
