Vol.21IE
● Rich inventory for standard product lines.
● Integrated manufacturing : designing, pressing, sintering,
grinding and coating.
● Customized insert development technologies - 3d drawing
and die designs.
Integrated
manufacturing
High CP
Value
Plentiful
stock
2021 Indexable Inserts
Milling / Holemaking / Turning / Threading
WINSTAR CUTTING TECHNOLOGIES CORP.
Integrated Carbide Insert
Production Line
3D & Tooling Design
Powder Selection & Pressing
Sintering
Grinding Coating
Inspection & Packing
Customized Carbide Inserts Serivce
In addition to the integrated manufacturing process of indexable inserts, Winstar
Cutting Technology also provides customized indexable insert services.
We use drawings or samples provided by customers, no matter what kinds of
inserts which are including milling, drilling, turning, threading, etc, not only mold
design, but also pressing and sintering, beside , we also provide special form
grinding and various coating services, are completed in the factory.
The services we can provide include automobiles, molds, aerospace, wind power,
electronic products and steel structures.
Welcome to develop together.
Index
Milling
Indexable milling cutter specications...............................................
Insert grades and chip breakers........................................................
Shoulder milling inserts.....................................................................
Face milling inserts...........................................................................
Copy milling inserts...........................................................................
Chamfering & engraving inserts........................................................
Holemaking
Indexable drilling inserts...................................................................
Modular drilling inserts......................................................................
Spotting & countersinking inserts......................................................
Turning
Insert grades and chip breakers........................................................
ISO Positive turning inserts...............................................................
ISO Negative turning inserts.............................................................
Parting & grooving inserts.................................................................
Threading
60° Threading inserts........................................................................
55° Threading inserts........................................................................
Technical Data
Troubleshooting in Insert...................................................................
Cutting Tools Evaluation Report........................................................
01
05
06
09
12
17
18
19
20
21
23
27
30
35
45
47
48
for Double Sided Insserts
CXXNE Ø20 ~ Ø32 XNMX0403
A296
CXXNF Ø50 ~ Ø125 XNMX0403 / XNMX0806
CXXNM Ø17 ~ Ø32 XNMX0403
CXSNE Ø50 ~ Ø80 SNMX1205
A354
for Single Sided Inserts
CAXOE Ø10 ~ Ø32 XOMT0602 / XOMT10T3
A300
CAXOM Ø10 ~ Ø20 XOMT0602
CARTE Ø10 ~ Ø26
WRT0702 / WRT1003 A304
CARTM Ø10 ~ Ø21
CASPE Ø12 ~ Ø32
SPMG..
A308
CASPF Ø50 ~ Ø80
CR39E Ø16 ~ Ø32
W39011T3 A311
CR39F Ø50 ~ Ø80
CR39M Ø16 ~ Ø32
CAPKE Ø16 ~ Ø32
APKT1003 / APKT1604 / APET1604
A315
CAPKF Ø50 ~ Ø100
CAPKM Ø16 ~ Ø32
CWEXE Ø16 ~ Ø32
AXMT1235 / AXMT1705 A319
CWEXF Ø50 ~ Ø100
CBAPE Ø16 ~ Ø32
APMT1135 / APMT1604 / APGT1604
A323
CBAPF Ø50 ~ Ø80
CBAPM Ø16 ~ Ø33
CATPE Ø20 ~ Ø40 TPMX1004 / TPMX1505
A326
CATPF Ø50 ~ Ø63
TPMX1004
CATPM Ø21 ~ Ø33
CR49F Ø50 ~ Ø80 W4901404 A330
Cutter Series Cutter Range Inserts Page
Shoulder Milling
Indexable milling cutter specications
Milling
01
High Feed Application
CXBNE Ø15 ~ Ø32
BNMX0603 / BNMX0904
A333
CXBNF Ø40 ~ Ø80
CXBNM Ø16 ~ Ø42
CXLNE Ø16 ~ Ø32
LNMX0303
A337
CXLNF Ø50
CXLNM Ø17 ~ Ø32
CXLOE Ø16 ~ Ø35
LOGX0303
A341
CXLOF Ø50
CXLOM Ø17 ~ Ø35
CXWNE Ø25 ~ Ø32 WNMX09T3
A344
CXWNF Ø50 ~ Ø80 WNMX09T3 / WNMX1305
CASRF Ø50 ~ Ø80 SDNW1205 / SDMT1205 A348
CAJXE Ø32 JDMW1204
A350
CAJXF Ø50 ~ Ø100 JDMW1204 / JDMW1405
CF23E Ø32 ~ Ø50 WP26339 / WP26379
A352
CF23F Ø50 ~ Ø160 WP26379
General Application
CXSNF Ø50 ~ Ø102.9 SNMX1205 / ONMX0505 A354
CXHNF Ø50 ~ Ø100 HNMX0704 A358
CASXF Ø50 ~ Ø100 SEET13T3 / SEMT13T3 A360
CAOFF Ø50 ~ Ø100 OFMT05T3 A362
CASEF Ø50 ~ Ø120 SEKT1204 / SEKW1204 A364
Face Milling
Cutter Series Cutter Range Inserts Page
Indexable milling cutter specications
Milling
02
Corner Radius Type
CARDE Ø10 ~ Ø32
RDKW0501 / RDKW0702
RDMT1003 / RDMX1003
RDMT10T3 / RDMW10T3
RDMT1204 / RDMW1204
A367
CARDF Ø50 ~ Ø100
RDMT1003 / RDMX1003
RDMT10T3 / RDMW10T3
RDMT1204 / RDMW1204
RDMT1604 / RDMW1604
CARDM Ø12 ~ Ø42
RDKW0501 / RDKW0702
RDMT1003 / RDMX1003
RDMT10T3 / RDMW10T3
CARPE Ø16 ~ Ø32
RPMT08T2
RPMW1003
RPMT10T3
RPMT1204 / RPMW1204
A373
CARPF Ø50 ~ Ø80 RPMT10T3
RPMT1204 / RPMW1204
Ball Nose Type
CF21E Ø12 ~ Ø32
WP32.. A377
CF21M Ø12 ~ Ø32
CF22M Ø25 ~ Ø50 WP26339 / WP26379 A380
Copy Milling
Cutter Series Cutter Range Inserts Page
Indexable milling cutter specications
Milling
03
Disc Milling
DTS6 Ø10 ~ Ø12 DCEX11T3 A384
DTS9 Ø10 ~ Ø20 SCGX09T3 / SCMX09T3
TCGX16T3 / TCMX16T3 A385
CSPCE Ø11 ~ Ø50 SPMG... A388
Chamfering & Engraving
CBAHE Ø20 ~ Ø50 APMT1135 / APMT1604 / APGT1604
A390
CBAHM Ø50 ~ Ø63 APMT1604 / APGT1604
CAPHE Ø20 ~ Ø32 APKT1003
A392
CAPHM Ø50 ~ Ø63 APKT1604 / APET1604
C39HE Ø25 ~ Ø32 W39011T3 A394
Helical Milling
CSPTE Ø19 ~ Ø32 SPMG... A396
CSPDE Ø80 ~ Ø200
SPMG... A398
CSPDF Ø80 ~ Ø125
Cutter Series Cutter Range Inserts Page
Cutter Series Cutter Range Inserts Page
Cutter Series Cutter Range Inserts Page
Indexable milling cutter specications
Milling
04
Milling Insert Grades and Chip Breakers
05
Milling
Milling Insert Grades
Grade
Type
Coating
Type Properties Application Working Material Industry Area
P M K N S H
CX22HS
PVD ●
High Wear resistance
● Continuous nishing
machining
● For Hardened steel and
Cast iron
●●● ○●
● Die and mould
● Hardened parts
● Aircraft parts
CX23TS ●●● ●●
CX31NS
PVD ● Wear resistance
● Impact resistance
● Medium machining
●
For Carbon steel, Alloy steel,
Stainless steel and
High temperature alloy
● ● ● ○
● Auto parts
● Machinery parts
● Aircraft parts
CX32HS ●●● ○○
CX33TS ●●● ●●
CX43TS PVD
● High Impact
resistance
● High toughness
● Roughing or interrupted
machining
●
For Carbon steel, Alloy steel,
Stainless steel and
High temperature alloy
● ● ● ●
● Auto parts
● Machinery parts
● Aircraft parts
CX10 Uncoated ●
Superior Wear
resistance
● Finishing and medium
cutting
● For Aluminum alloy
●●
Bike and auto parts
● Electronic parts
Milling Insert Chip Breakers
for Aluminum Semi-Finishing Medium Roughing
Heavy-Roughing
Finishing
Shoulder Milling - Double-sided Inserts
XNMX040304-SG ✓ ✓ ✓ ✓ 6.7 -
3.285
0.4 3.15 -
s
r
d1
A296
XNMX040304-MG ✓ ✓ ✓ 6.7 -
3.285
0.4 3.15 -
XNMX040308-MG ✓✓ ✓✓✓ 6.7 -
3.285
0.8 3.15 -
XNMX080608-MG ✓✓ ✓✓✓
12.53
- 6.5 0.8 4.5 -
XNMX080608-RG ✓✓✓
12.53 -
6.5 0.8 4.5 -
Shoulder Milling - Single-sided Insert
APKT
100304PDER-AL
✓10.5 6.7 3.5 0.4 2.8 -
A315
A392
APKT
100304PDER-SG
✓10.5 6.7 3.5 0.4 2.8 -
APKT
100304PDER-MG
✓✓ ✓✓✓ 10.5 6.7 3.5 0.4 2.8 -
APKT
100308PDER-MG
✓✓ ✓✓✓ 10.5 6.7 3.5 0.8 2.8 -
APKT
100304PDER-RG
✓ ✓ 10.5 6.7 3.5 0.4 2.8 -
APKT
160408PDER-MG
✓ ✓ ✓ ✓ 16.3
9.525
5.25 0.8 4.5 -
APKT
160408PDER-RG
✓ ✓ ✓ ✓ 16.3
9.525
5.25 0.8 4.5 -
APKT
170516PEER-RG
✓✓ ✓✓✓ 18.5
10.7
5.56 1.6 4.5 -
APET
160402PDFR-AL
✓16.3
9.525
5.25 0.2 4.5 -
APET
160404PDFR-AL
✓16.3
9.525
5.25 0.4 4.5 -
Milling Inserts
Milling
06
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
I
S
S
S
S
S
I
I
I
I
I
I
I
I
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
T
07
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
Shoulder Milling - Single-sided Insert
APET
160402PDFR-FG
✓16.3
9.525
5.25 0.2 4.5 -
A315
A392
APET
160404PDFR-FG
✓16.3
9.525
5.25 0.4 4.5 -
APMT
103508PDER-RG
✓ ✓ ✓ ✓
10.64
6.5 3.5 0.8 3 - -
APMT
113508PDER-MG
✓✓ ✓✓✓ 11.0 6.35 3.5 0.8 2.8 -
A323
A390
APMT
113516PDER-MG
✓ ✓ 11.0 6.35 3.5 1.6 2.8 -
APMT
113508PDER-RG
✓✓ ✓✓✓ 11.0 6.35 3.5 0.8 2.8 -
APMT
113508PDER-HG
✓✓✓ 11.0 6.35 3.5 0.8 2.8 -
APMT
160408PDER-MG
✓ ✓ ✓ ✓ 16.5
9.525
4.76 0.8 4.4 -
APMT
160416PDER-MG
✓ ✓ 16.5
9.525
4.76 1.6 4.4 -
APMT
160408PDER-RG
✓✓ ✓✓✓ 16.5
9.525
4.76 0.8 4.4 -
APMT
160408PDER-HG
✓ ✓ ✓ ✓ 16.5
9.525
4.76 0.8 4.4 -
APGT
160408PDER-AL
✓16.5
9.525
4.76 0.8 4.4 -
APGT
160408PDER-FG
✓16.5
9.525
4.76 0.8 4.4 -
AXMT
123508PEER-RG
✓ ✓ ✓ ✓
12.18
6.93 3.58 0.8 3.4 -
A319
AXMT
170508PEER-RG
✓✓✓
17.50
10.2 5.56 0.8 4.6 -
AXMT
170516PEER-RG
✓✓✓
17.50
10.2 5.56 1.6 4.6 -
S
M
M
M
M
M
M
S
S
S
M
M
M
M
I
I
Milling Inserts
Milling
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
08
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
Shoulder Milling - Single-sided Insert
CPMT090308-MG ✓
9.525
- 3.18 0.8 4.4 -
11° -
CPMT120408-MG ✓12.7 - 4.76 0.8 5.5 -
JDMT150508R-MG ✓✓✓ 15.1 9.12 5.0 0.8 4.5 - -
W49008T308-SG ✓5.6 8.5 3.3 0.8 2.8 1.2
A330
W490140408-SG ✓ ✓ 10.3 13.8 3.9 0.8 4.1 2.0
SPMG050204-MG ✓✓✓ 5.00 - 2.38 0.4 2.30 -
11°
A308
A388
A396
A398
SPMG060204-MG ✓✓✓ 6.00 - 2.38 0.4 2.65 -
SPMG07T308-MG ✓✓✓ 7.94 - 3.97 0.8 2.85 -
SPMG090408-MG ✓✓✓ 9.80 - 4.3 0.8 4.05 -
SPMG090408-RG ✓✓✓ 9.80 - 4.3 0.8 4.05 -
SPMG110408-MG ✓✓✓
11.50
- 4.8 0.8 4.45 -
SPMG110408-RG ✓✓✓
11.50
- 4.8 0.8 4.45 -
TPKR1603PPR-MG ✓ ✓ 16.5
9.525
3.1 - 2.2
1.423
t1
-
TPKR1603PPR-RG ✓✓✓ 16.5
9.525
3.1 - 2.2
1.423
TPMX100408-SG ✓ ✓ 6.9 - 4 0.8 3 -
A326
TPMX100408-MG ✓✓ ✓✓✓ 6.9 - 4 0.8 3 -
TPMX150508-MG ✓✓ ✓✓✓ 10.7 - 5 0.8 4.85 -
H
H
H
S
T
T
T
T
T
T
T
I
I
T
T
S
T
Milling Inserts
Milling
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
09
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
Shoulder Milling - Single-sided Insert
W39011T308-MG ✓✓ ✓✓✓ 11 6.9 3.59 0.8 2.8 -
A311
W39011T320-MG ✓ ✓ ✓ ✓ 11 6.9 3.59 2.0 2.8 -
W390180612-SG ✓✓✓ 15.4 11 6.33 1.2 4.2 -
WRT070204-RG ✓✓ ✓✓✓ 4.30 6.4 2.38 0.4 2.2 1.3 s
d1
15°
r
t1
90°
A304
WRT100308-RG ✓✓ ✓✓✓ 6.35 9.3 3.4 0.8 2.9 1.8
XOMT060208-SG ✓ ✓ 7 4.09 2.45 0.8 2 -
A300
XOMT060204-MG ✓ ✓ ✓ 7 4.09 2.45 0.4 2 -
XOMT060208-MG ✓✓ ✓✓✓ 7 4.09 2.45 0.8 2 -
XOMT060216-MG ✓ ✓ 7 4.09 2.45 1.6 2 -
XOMT10T308-SG ✓✓✓
11.08
6.86 3.8 0.8 3 -
High Feed Face Milling - Double-sided Inserts
BNMX0603-SG ✓✓ ✓✓✓ 9.0 6.38 3.75 - 3.2 -
A333
BNMX0603-MG ✓✓ ✓✓✓ 9.0 6.38 3.75 - 3.2 -
BNMX0603-RG ✓✓ ✓✓✓ 9.0 6.38 3.75 - 3.2 -
BNMX0904-MG ✓✓ ✓✓✓ 11.9 9.18 4.8 - 4.2 -
LNMX0303-SG ✓✓ ✓✓✓
11.59
6.0 4.29 - 2.85 -
A337
LNMX0303-MG ✓✓ ✓✓✓
11.59
6.0 4.29 - 2.85 -
Milling Inserts
Milling
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
10
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
Milling Inserts
Milling
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
High Feed Face Milling - Double-sided Inserts
LOGX030310-SG ✓✓✓ 11.9 6.2 3.96 - 3.45 -
A341
WNMX09T316-MG ✓ ✓ ✓ ✓
9.525
- 3.97 1.6 3.6 -
A344
WNMX09T316-RG ✓✓ ✓✓✓
9.525
- 3.97 1.6 3.6 -
WNMX130516-MG ✓✓ ✓✓✓ 12.7 - 6.02 1.6 4.7 -
High Feed Face Milling - Single-sided Inserts
ISR145 ✓ ✓ ✓ ✓ 12 7.0 3.0 1.45 3.4 -
-
ISR145-F ✓ ✓ ✓ ✓ 12 7.0 3.0 1.45 3.4 -
JDMW
120420ZDSR-MF
✓ ✓ ✓ ✓ 2.5 12.0 4.76 2.0 4.75 -
A350
JDMW
120420ZDSR-RG
✓✓ ✓✓✓ 2.5 12.0 4.76 2.0 4.75 -
JDMW
140520ZDSR-MF
✓ ✓ 2.8 14.0 5.56 2.0 5.75 -
JDMW
140520ZDSR-RG
✓ ✓ 2.8 14.0 5.56 2.0 5.75 -
JDMT
140520ZDSR-MG
✓✓✓ 2.8 14.0 5.56 2.0 5.75 -
SDMT1205ZDSN-MF ✓ ✓ ✓ ✓ 12.7 - 5.56 15 4.6 -
A348
SDMT1205ZDTN-MG ✓ ✓ ✓ ✓ 12.7 - 5.56 15 4.6 -
SDMT1205ZDTN-RG ✓ ✓ ✓ ✓ 12.7 - 5.56 15 4.6 -
SDNW1205ZDSN-MF ✓ ✓ 12.7 - 5.56 15 4.6 -
SDNW1205ZDTN-RG ✓✓ ✓✓✓ 12.7 - 5.56 15 4.6 -
K
K
S
S
S
M
M
M
M
H
H
H
H
M
H
K
11
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
High Feed Face Milling - Single-sided Inserts
WPMW
080615ZPSR-MF
✓ ✓ 8
12.87
6.35 1.5 5.5 -
-
WPMW
080615ZPSR-RG
✓ ✓ 8
12.87
6.35 1.5 5.5 -
Face Milling - Double-sided Inserts
HNMX0704-SG ✓✓✓ 6.8 12.7 4.45 1.2 4.9 1.4
A358
ONMX0505-RG ✓ ✓ ✓ ✓ 12.7 12.7 6.4 - 6 -
A354
SNMX1205-MG ✓ ✓ ✓ ✓ 12.7 1.5 6.4 - 6 -
SNMX1205-RG ✓ ✓ ✓ ✓ 12.7 1.5 6.4 - 6 -
Face Milling - Single-sided Inserts
OFMT05T3TN-MG ✓✓✓ 12.7 - 3.8 0.6 4.6 -
A362
OFMT05T3TN-RG ✓✓✓ 12.7 - 3.8 0.6 4.6 -
SEMR1203AFSN-RG ✓ ✓ 12.7 1.6 3.18 1 2 - -
SEKT1204AFEN-MF ✓ ✓ 12.7 - 4.76 0.8 5.5 -
A364
SEKT1204AFTN-RG ✓✓✓ 12.7 - 4.76 0.8 5.5 -
SEKW1204AFEN ✓ ✓ 12.7 - 4.76 0.8 5.5 -
SEKW1204AFSN-F ✓ ✓ 12.7 - 4.76 0.8 5.5 -
SEKW1204AFTN ✓ ✓ 12.7 - 4.76 0.8 5.5 -
T
T
W
W
W
W
T
T
T
K
K
K
K
K
Milling Inserts
Milling
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
Milling Inserts
12
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
Face Milling - Single-sided Inserts
SEET1204AFFN-AL ✓12.7 - 4.76 0.8 5.5 -
A364
SEET1204AFFN-FG ✓12.7 - 4.76 0.8 5.5 -
SEMT13T3AGEN-MF ✓ ✓ ✓ ✓ 13.4 1.9 3.97 1.5 4.2 -
A360
SEMT13T3AGSN-MF ✓ ✓ ✓ ✓ 13.4 1.9 3.97 1.5 4.2 -
SEMT13T3AGEN-MG ✓ ✓ ✓ ✓ 13.4 1.9 3.97 1.5 4.2 -
SEMT13T3AGTN-MG ✓ ✓ ✓ ✓ 13.4 1.9 3.97 1.5 4.2 -
SEMT13T3AGTN-RG ✓✓✓ 13.4 1.9 3.97 1.5 4.2 -
SEMT13T3AGTN-HG ✓✓✓ 13.4 1.9 3.97 1.5 4.2 -
SEET13T3AGFN-AL ✓13.4 1.9 3.97 1.5 4.2 -
SEET13T3AGFN-FG ✓13.4 1.9 3.97 1.5 4.2 -
SPMN120308 ✓12.7 - 3.18 0.8 2 - -
Copy Milling - Single-sided Inserts
RCMT1204MO-FG ✓ ✓ 12 - 4.76 - 4.2 - -
K
K
M
M
M
M
M
M
M
M
S
Milling Inserts
Milling
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
13
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
Copy Milling - Single-sided Inserts
RDKW0501MOE ✓ ✓ ✓ ✓ 5 - 1.59 - 2.2 -
A367
RDKW0501MOT ✓ ✓ ✓ ✓ 5 - 1.59 - 2.2 -
RDKW0702MOE ✓ ✓ ✓ ✓ 7 - 2.38 - 2.8 -
RDKW0702MOS-F ✓ ✓ 7 - 2.38 - 2.8 -
RDKW0702MOT ✓ ✓ ✓ ✓ 7 - 2.38 - 2.8 -
RDMT1003MOE ✓ ✓ ✓ ✓ 10 - 3.18 - 3.9 -
RDMT1003MOT ✓✓ ✓✓✓ 10 - 3.18 - 3.9 -
RDMX1003MOE ✓ ✓ ✓ ✓ 10 - 3.18 - 4.15 -
RDMX1003MOT ✓ ✓ ✓ ✓ 10 - 3.18 - 4.15 -
RDMT10T3MOE ✓ ✓ ✓ ✓ 10 - 3.97 - 4.5 -
RDMT10T3MOT ✓ ✓ ✓ ✓ 10 - 3.97 - 4.5 -
RDMW10T3MOE ✓ ✓ 10 - 3.97 - 4.5 -
RDMW10T3MOT ✓ ✓ 10 - 3.97 - 4.5 -
S
S
S
T
T
S
H
H
K
K
H
H
S
Milling Inserts
Milling
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
14
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
Copy Milling - Single-sided Inserts
RDMT12T3MOE ✓ ✓ ✓ 12 - 3.97 - 4.1 -
A367
RDMT12T3MOT ✓ ✓ ✓ 12 - 3.97 - 4.1 -
RDMX12T3MOE ✓ ✓ ✓ ✓ 12 - 3.97 - 4.1 -
RDMX12T3MOT ✓ ✓ ✓ ✓ 12 - 3.97 - 4.1 -
RDMT1204MOE ✓ ✓ ✓ ✓ 12 - 4.76 - 4.4 -
RDMT1204MOT ✓ ✓ ✓ ✓ 12 - 4.76 - 4.4 -
RDMW1204MOE ✓ ✓ ✓ ✓ 12 - 4.76 - 4.4 -
RDMW1204MOS-F ✓ ✓ 12 - 4.76 - 4.4 -
RDMW1204MOT ✓ ✓ ✓ ✓ 12 - 4.76 - 4.4 -
RDMT1604MOT ✓ ✓ ✓ ✓ 16 - 4.76 - 5.5 -
RDMW1604MOE ✓ ✓ ✓ ✓ 16 - 4.76 - 5.5 -
RDMW1604MOS-F ✓ ✓ ✓ ✓ 16 - 4.76 - 5.5 -
RDMW1604MOT ✓✓ ✓✓✓ 16 - 4.76 - 5.5 -
H
W
H
W
H
H
H
H
T
T
L
L
W
Milling Inserts
Milling
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
15
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
Copy Milling - Single-sided Inserts
RPMT08T2MOE ✓✓✓ 8 - 2.78 - 3.2 -
A373
RPMT08T2MOT ✓✓✓ 8 - 2.78 - 3.2 -
RPMW1003MOE ✓ ✓ ✓ ✓ 10 - 3.18 - 4.6 -
RPMW1003MOS-F ✓10 - 3.18 - 4.6 -
RPMW1003MOT ✓ ✓ ✓ ✓ 10 - 3.18 - 4.6 -
RPMT10T3MOE ✓✓✓ 10 - 3.97 - 4.5 -
RPMT10T3MOT ✓✓✓ 10 - 3.97 - 4.3 -
RPMT1204MOE ✓ ✓ ✓ ✓ 12 - 4.76 - 4.3 -
RPMT1204MOT ✓ ✓ ✓ ✓ 12 - 4.76 - 4.3 -
RPMW1204MOE ✓✓✓ 12 - 4.76 - 4.3 -
RPMW1204MOT ✓✓✓ 12 - 4.76 - 4.3 -
M
M
M
M
M
M
M
M
M
M
M
Milling Inserts
Milling
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
16
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
Copy Milling - Single-sided Inserts
WP26339R14-RG ✓✓ ✓✓✓ - 9.52 3.97 1.2 4.4 -
A352
A380
WP26379R25-RG ✓✓ ✓✓✓ 1.1 13 5.56 2.0 5.5 -
WP3212-SM ✓12 6 2.5
-
5 -
A377
WP3216-SM ✓16 6 3
-
5 -
WP3220-SM ✓20 6 3
-
5 -
WP3225-SM ✓25 9 4
-
6 -
WP3232-SM ✓32 10 5
-
8 -
WP3212-MM ✓12 6 2.5
-
5 -
WP3216-MM ✓16 6 3
-
5 -
WP3220-MM ✓20 6 3
-
5 -
WP3225-MM ✓25 9 4
-
6 -
WP3232-MM ✓32 10 5
-
8 -
W
W
W
W
W
W
W
W
W
W
W
W
Milling Inserts
Milling
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
17
*Customized insert is acceptable.
Chamfering & Engraving Inserts
DCEX11T301-XF ✓- - - 0.1 - -
A384
DCEX11T302-XF ✓- - - 0.2 - -
DCEX11T304-XF ✓- - - 0.4 - -
DCEX11T304-XR ✓- - - 0.4 - -
DCEX11T308-XR ✓- - - 0.8 - -
SCGX09T304-AG ✓- - - 0.4 - -
A385
SCGX09T304-FG ✓- - - 0.4 - -
SCMX09T304-SM ✓- - - 0.4 - -
TCGX16T308-AG ✓- - - 0.8 - -
TCGX16T308-FG ✓- - - 0.8 - -
TCMX16T308-MP ✓- - - 0.8 - -
Milling Inserts
Milling
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Cutter Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
Holemaking Inserts
Holemaking
18
*Customized insert or other grade (CX21NS, CX31NA or CX31NS) are acceptable.
Indexable Drilling Inserts
SPMG050204-MG ✓✓✓ 5.00 - 2.38 0.4 2.30 -
11°
B055
~
B061
SPMG060204-MG ✓✓✓ 6.00 - 2.38 0.4 2.65 -
SPMG07T308-MG ✓✓✓ 7.94 - 3.97 0.8 2.85 -
SPMG090408-MG ✓✓✓ 9.80 - 4.3 0.8 4.05 -
SPMG090408-RG ✓✓✓ 9.80 - 4.3 0.8 4.05 -
SPMG110408-MG ✓✓✓
11.50
- 4.8 0.8 4.45 -
SPMG110408-RG ✓✓✓
11.50
- 4.8 0.8 4.45 -
WCMT030208-MM ✓✓✓ 3.8 5.56 2.38 0.8 2.8 -
B066
~
B072
WCMT040208-MM ✓✓✓ 4.3 6.35 2.38 0.8 3.0 -
WCMT050308-MM ✓✓✓ 5.4 7.94 3.18 0.8 3.4 -
WCMT06T308-SG ✓6.5 9.53 3.97 0.8 4.0 -
WCMT06T308-MM ✓✓✓ 6.5 9.53 3.97 0.8 4.0 -
WCMT080412-MM ✓✓✓ 8.7 12.7 4.76 1.2 4.3 -
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Holder Page
CX22HS
CX23TS
CX32HS
CX33TS
CX43TS
A B S r d1 t1
T
T
T
T
T
T
T
S
S
S
S
S
S
19
*Customized sizes (two decimal places) are acceptable.
Modular Drilling Inserts
DMWA1400-FM ✓
14.00
- 4.0 - - -
B050
DMWA1450-FM ✓
14.50
- 4.0 - - -
DMWA1500-FM ✓
15.00
- 4.0 - - -
DMWA1550-FM ✓
15.50
- 4.0 - - -
DMWA1587-FM ✓
15.875
(5/8")
- 4.0 - - -
DMWA1600-FM ✓
16.00
- 4.5 - - -
DMWA1630-FM ✓
16.30
- 4.5 - - -
DMWA1650-FM ✓
16.50
- 4.5 - - -
DMWA1700-FM ✓
17.00
- 4.5 - - -
DMWA1750-FM ✓
17.50
- 4.5 - - -
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Holder Page
CX22HS
CX23TS
CX32HS
CX33TS
CX43TS
A B S r d1 t1
Holemaking Inserts
Holemaking
Holemaking Inserts
Holemaking
20
Spotting & Countersinking Inserts
DCEX11T301-XF ✓- - - 0.1 - -
B081
DCEX11T302-XF ✓- - - 0.2 - -
DCEX11T304-XF ✓- - - 0.4 - -
DCEX11T304-XR ✓- - - 0.4 - -
DCEX11T308-XR ✓- - - 0.8 - -
SCGX09T304-AG ✓- - - 0.4 - -
B082
SCGX09T304-FG ✓- - - 0.4 - -
SCMX09T304-SM ✓- - - 0.4 - -
TCGX16T308-AG ✓- - - 0.8 - -
TCGX16T308-FG ✓- - - 0.8 - -
TCMX16T308-MP ✓- - - 0.8 - -
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Holder Page
CX22HS
CX23TS
CX31NS
CX32HS
CX33TS
CX43TS
CX10
A B S r d1 t1
*Customized insert is acceptable.
Turning Insert Grades
Turning
21
Continuous Cutting Light Interrupted Interrupted
200
130
60
250
(m/min)
Cutting Speed (Vc)
Finishing Roughing
CX2560
CX2555 CX3560
CX3575
Application Range for Steel
Grade
Type
Coating
Type
Substrate
Classication
Application Working Material Industry Area
P M K N S H
CX1060 PVD K05 ~ K10 ● Continuous nishing cutting
● For nishing application ●●●○○ ●
Auto and machinery parts
● Aircraft parts
CX1555 PVD K10 ~ K20 ● Continuous nishing cutting
● For nishing application ●●●○●● ●
Auto and machinery parts
● Aircraft parts
CX2545 PVD K20 ~ K30
●
Medium or light interrupted cutting
● For Stainless steel &
High temperature alloy
○ ● ● ○ ●
Auto and machinery parts
● Aircraft parts
CX2560
(CX2555) PVD K20 ~ K30 ●
Medium or light interrupted cutting
● For Carbon steel ●○○ ○○ ●
Carbon steel parts
manufacturing
CX3560 PVD K30 ~ K40 ● Roughing or interrupted cutting
● For Carbon steel ●○○ ○○ ● Steel parts
manufacturing
CX3575 CVD K30 ~ K40
● Roughing or interrupted cutting
● For Alloy steel, Cast iron and
Hardened steel
●○● ○● ●
Auto and machinery parts
● Mold & die
CX1010 CVD K05 ~ K10 ● Finishing and medium cutting
●
For Aluminum alloy with Silicon
●● Bike and auto parts
● Aluminium rim
CX10 Uncoated K05 ~ K10 ● Finishing and medium cutting
● For Aluminum alloy ●● Bike and auto parts
● Electronic parts
Turning Insert Grades
Turning Insert Chip Breakers
Turning
22
Finishing Semi-finishing Medium
．Negative
ap
(mm)
fn
(mm/rev)
Finishing RoughingSemi-finishing Medium
AG / FG / XF / YF
SM / SG
MG / MP
FG / FP
SM / SP
MP / ME
RK / RG / RP / HG
Turning Insert Chip Breakers
．Positive
ap
(mm)
fn
(mm/rev)
ISO Positive Turning Inserts
Turning
23
CCGT 060202-AG ✓ ✓ 6.35 6.4 2.38 0.2 2.8
C032
~
C035
C057
~
C059
060204-AG ✓ ✓ 6.35 6.4 2.38 0.4 2.8
09T304-AG ✓ ✓ 9.53 9.7 3.97 0.4 4.4
09T308-AG ✓ ✓ 9.53 9.7 3.97 0.8 4.4
120404-AG ✓ ✓ 12.7 12.9 4.76 0.4 5.5
CCGT 060202-FG ✓6.35 6.4 2.38 0.2 2.8
060204-FG ✓6.35 6.4 2.38 0.4 2.8
09T304-FG ✓9.53 9.7 3.97 0.4 4.4
09T308-FG ✓9.53 9.7 3.97 0.8 4.4
120404-FG ✓12.7 12.9 4.76 0.4 5.5
CCMT 060204-MP ✓ ✓ 6.35 6.4 2.38 0.4 2.8
09T304-MP ✓ ✓ 9.53 9.7 3.97 0.4 4.4
09T308-MP ✓ ✓ 9.53 9.7 3.97 0.8 4.4
CCMT 060204-MG ✓✓✓ 6.35 6.4 2.38 0.4 2.8
09T304-MG ✓✓✓ 9.53 9.7 3.97 0.4 4.4
09T308-MG ✓✓✓ 9.53 9.7 3.97 0.8 4.4
120408-MG ✓✓✓ 12.7 12.9 4.76 0.8 5.5
DCET 11T301R-XF ✓9.53 11.6 3.97 0.1 4.4
C036
~
C040
C059
~
C061
11T302R-XF ✓9.53 11.6 3.97 0.2 4.4
11T304R-XF ✓9.53 11.6 3.97 0.4 4.4
DCET 11T301L-XF ✓9.53 11.6 3.97 0.1 4.4
11T302L-XF ✓9.53 11.6 3.97 0.2 4.4
11T304L-XF ✓9.53 11.6 3.97 0.4 4.4
DCET 11T301R-YF ✓9.53 11.6 3.97 0.1 4.4
11T302R-YF ✓9.53 11.6 3.97 0.2 4.4
11T304R-YF ✓9.53 11.6 3.97 0.4 4.4
DCET 11T301L-YF ✓9.53 11.6 3.97 0.1 4.4
11T302L-YF ✓9.53 11.6 3.97 0.2 4.4
11T304L-YF ✓9.53 11.6 3.97 0.4 4.4
DCEW 11T301 ✓9.53 11.6 3.97 0.1 4.4
11T302 ✓9.53 11.6 3.97 0.2 4.4
11T304 ✓9.53 11.6 3.97 0.4 4.4
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Holder Page
CX1060
CX1555
CX2545
CX2555
CX2560
CX1010
CX10
d l S r h
24
DCGT 070202-AG ✓ ✓ 6.35 7.75 2.38 0.2 2.8
C036
~
C040
C059
~
C061
070204-AG ✓ ✓ 6.35 7.75 2.38 0.4 2.8
11T302-AG ✓ ✓ 9.53 11.6 3.97 0.2 4.4
11T304-AG ✓ ✓ 9.53 11.6 3.97 0.4 4.4
11T308-AG ✓ ✓ 9.53 11.6 3.97 0.8 4.4
DCGT 070202-FG ✓6.35 7.75 2.38 0.2 2.8
070204-FG ✓6.35 7.75 2.38 0.4 2.8
11T302-FG ✓9.53 11.6 3.97 0.2 4.4
11T304-FG ✓9.53 11.6 3.97 0.4 4.4
11T308-FG ✓9.53 11.6 3.97 0.8 4.4
DCMT 11T304-MP ✓ ✓ 9.53 11.6 3.97 0.4 4.4
11T308-MP ✓ ✓ 9.53 11.6 3.97 0.8 4.4
DCMT 070204-MG ✓✓✓ 6.35 7.75 2.38 0.4 2.8
11T304-MG ✓✓✓ 9.53 11.6 3.97 0.4 4.4
11T308-MG ✓✓✓ 9.53 11.6 3.97 0.8 4.4
RCMT 1204MO-FG ✓12 - 3.97 - 4.2
-
SCGT 09T304-AG ✓ ✓ 9.53 9.53 3.97 0.4 4.4
C062
~
C064
09T308-AG ✓ ✓ 9.53 9.53 3.97 0.8 4.4
SCGT 09T304-FG ✓9.53 9.53 3.97 0.4 4.4
09T308-FG ✓9.53 9.53 3.97 0.8 4.4
SCMT 09T304-SM ✓9.53 9.53 3.97 0.4 4.4
SCMT 09T304-MP ✓ ✓ 9.53 9.53 3.97 0.4 4.4
SCMT 09T304-MG ✓✓✓ 9.53 9.53 3.97 0.4 4.4
09T308-MG ✓✓✓ 9.53 9.53 3.97 0.8 4.4
ISO Positive Turning Inserts
Turning
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Holder Page
CX1060
CX1555
CX2545
CX2555
CX2560
CX1010
CX10
d l S r h
25
TCGT 090204-AG ✓ ✓ 5.56 9.6 2.38 0.4 2.5
C041
~
C043
C065
~
C066
110204-AG ✓ ✓ 6.35 11.0 2.38 0.4 2.8
16T304-AG ✓ ✓ 9.53 16.5 3.97 0.4 4.4
16T308-AG ✓ ✓ 9.53 16.5 3.97 0.8 4.4
TCGT 090204-FG ✓5.56 9.6 2.38 0.4 2.5
110204-FG ✓6.35 11.0 2.38 0.4 2.8
16T304-FG ✓9.53 16.5 3.97 0.4 4.4
16T308-FG ✓9.53 16.5 3.97 0.8 4.4
TCMT 110204-MP ✓ ✓ 6.35 11.0 2.38 0.4 2.8
TCMT 110204-MG ✓✓✓ 6.35 11.0 2.38 0.4 2.8
16T304-MG ✓✓✓ 9.53 16.5 3.97 0.4 4.4
16T308-MG ✓✓✓ 9.53 16.5 3.97 0.8 4.4
TPMH 160304-MP ✓ ✓ 9.53 16.5 3.18 0.4 4.4
C042
VBET 110301R-XF ✓11.1 6.35 3.18 0.1 2.8
C044
~
C047
C067
~
C068
110302R-XF ✓11.1 6.35 3.18 0.2 2.8
110304R-XF ✓11.1 6.35 3.18 0.4 2.8
VBET 110301L-XF ✓11.1 6.35 3.18 0.1 2.8
110302L-XF ✓11.1 6.35 3.18 0.2 2.8
110304L-XF ✓11.1 6.35 3.18 0.4 2.8
VBET 110301R-YF ✓11.1 6.35 3.18 0.1 2.8
110302R-YF ✓11.1 6.35 3.18 0.2 2.8
110304R-YF ✓11.1 6.35 3.18 0.4 2.8
VBET 110301L-YF ✓11.1 6.35 3.18 0.1 2.8
110302L-YF ✓11.1 6.35 3.18 0.2 2.8
110304L-YF ✓11.1 6.35 3.18 0.4 2.8
VBEW 110301 ✓11.1 6.35 3.18 0.1 2.8
110302 ✓11.1 6.35 3.18 0.2 2.8
110304 ✓11.1 6.35 3.18 0.4 2.8
VBMT 160404-MG ✓✓✓ 9.53 16.6 4.76 0.4 4.4
160408-MG ✓✓✓ 9.53 16.6 4.76 0.8 4.4
ISO Positive Turning Inserts
Turning
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Holder Page
CX1060
CX1555
CX2545
CX2555
CX2560
CX1010
CX10
d l S r h
26
VCET 110301R-XF ✓11.1 6.35 3.18 0.1 2.8
C044
~
C047
C067
~
C068
110302R-XF ✓11.1 6.35 3.18 0.2 2.8
110304R-XF ✓11.1 6.35 3.18 0.4 2.8
VCET 110301L-XF ✓11.1 6.35 3.18 0.1 2.8
110302L-XF ✓11.1 6.35 3.18 0.2 2.8
110304L-XF ✓11.1 6.35 3.18 0.4 2.8
VCET 110301R-YF ✓11.1 6.35 3.18 0.1 2.8
110302R-YF ✓11.1 6.35 3.18 0.2 2.8
110304R-YF ✓11.1 6.35 3.18 0.4 2.8
VCET 110301L-YF ✓11.1 6.35 3.18 0.1 2.8
110302L-YF ✓11.1 6.35 3.18 0.2 2.8
110304L-YF ✓11.1 6.35 3.18 0.4 2.8
VCEW 110301 ✓11.1 6.35 3.18 0.1 2.8
110302 ✓11.1 6.35 3.18 0.2 2.8
110304 ✓11.1 6.35 3.18 0.4 2.8
VCGT 110302-AG ✓ ✓ 11.1 6.35 3.18 0.2 2.8
110304-AG ✓ ✓ 11.1 6.35 3.18 0.4 2.8
160402-AG ✓ ✓
9.525
16.6 4.76 0.2 4.4
160404-AG ✓ ✓
9.525
16.6 4.76 0.4 4.4
160408-AG ✓ ✓
9.525
16.6 4.76 0.8 4.4
VCGT 110302-FG ✓11.1 6.35 3.18 0.2 2.8
110304-FG ✓11.1 6.35 3.18 0.4 2.8
160402-FG ✓
9.525
16.6 4.76 0.2 4.4
160404-FG ✓
9.525
16.6 4.76 0.4 4.4
160408-FG ✓
9.525
16.6 4.76 0.8 4.4
VCGT 110301-SG ✓11.1 6.35 3.18 0.1 2.8
110302-SG ✓11.1 6.35 3.18 0.2 2.8
110304-SG ✓11.1 6.35 3.18 0.4 2.8
ISO Positive Turning Inserts
Turning
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Holder Page
CX1060
CX1555
CX2545
CX2555
CX2560
CX1010
CX10
d l S r h
ISO Negative Turning Inserts
Turning
27
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Holder Page
CX2545
CX2555
CX2560
CX3560
CX3575
CX1555
d l S r h
CNMG 120404-FP ✓ ✓ 12.7 12.9 4.76 0.4 5.16
C025
~
C027
C048
~
C049
120408-FP ✓✓✓ 12.7 12.9 4.76 0.8 5.16
CNMG 120404-SM ✓✓✓ 12.7 12.9 4.76 0.4 5.16
120408-SM ✓✓✓ 12.7 12.9 4.76 0.8 5.16
CNMG 120404-SP ✓ ✓ 12.7 12.9 4.76 0.4 5.16
120408-SP ✓ ✓ 12.7 12.9 4.76 0.8 5.16
CNMG 120404-MP ✓✓✓✓✓ 12.7 12.9 4.76 0.4 5.16
120408-MP ✓✓✓✓✓ 12.7 12.9 4.76 0.8 5.16
120412-MP ✓✓✓✓✓ 12.7 12.9 4.76 1.2 5.16
CNMG 120408-RK ✓ ✓ 12.7 12.9 4.76 0.8 5.16
CNMG 120408-RG ✓✓✓ 12.7 12.9 4.76 0.8 5.16
CNMG 120408-RP ✓✓✓ 12.7 12.9 4.76 0.8 5.16
CNMG 120408-HG ✓✓✓ 12.7 12.9 4.76 0.8 5.16
120412-HG ✓ ✓ 12.7 12.9 4.76 1.2 5.16
DNGX 110401-FG ✓
9.525
11.6 4.76 0.1 4.5
C027
C050
110402-FG ✓
9.525
11.6 4.76 0.2 4.5
DNMG 150404-SP ✓ ✓ 12.7 15.5 4.76 0.4 5.16
DNMG 150404-MP ✓12.7 15.5 4.76 0.4 5.16
150408-MP ✓127. 15.5 4.76 0.8 5.16
DNMG 110408-RG ✓ ✓
9.525
11.6 4.76 0.8 3.81
150408-RG ✓✓✓ 12.7 15.5 4.76 0.8 5.16
150608-RG ✓12.7 15.5 6.35 0.8 5.16
28
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Holder Page
CX2545
CX2555
CX2560
CX3560
CX3575
d l S r h
SNMG 120404-SM ✓ ✓ 12.7 12.7 4.76 0.4 5.16
C028
C051
SNMG 120404-MP ✓12.7 12.7 4.76 0.4 5.16
120408-MP ✓12.7 12.7 4.76 0.8 5.16
120412-MP ✓12.7 12.7 4.76 1.2 5.16
SNMG 120408-RG ✓✓✓ 12.7 12.7 4.76 0.8 5.16
120412-RG ✓ ✓ 12.7 12.7 4.76 1.2 5.16
TNMG 160408-FP ✓✓✓ 9.53 16.5 4.76 0.8 3.81
C028
~
C030
C050
~
C053
TNMG 160408-SM ✓✓✓ 9.53 16.5 4.76 0.8 3.81
TNMG 160404-SP ✓ ✓ 9.53 16.5 4.76 0.4 3.81
160408-SP ✓ ✓ 9.53 16.5 4.76 0.8 3.81
TNMG 160404R-ME ✓ ✓ 9.53 16.5 4.76 0.4 3.81
160408R-ME ✓ ✓ 9.53 16.5 4.76 0.8 3.81
TNMG 160404L-ME ✓ ✓ 9.53 16.5 4.76 0.4 3.81
160408L-ME ✓ ✓ 9.53 16.5 4.76 0.8 3.81
TNMG 160404-MP ✓ ✓ ✓ ✓ 9.53 16.5 4.76 0.4 3.81
160408-MP ✓ ✓ ✓ ✓ 9.53 16.5 4.76 0.8 3.81
160412-MP ✓✓✓ 9.53 16.5 4.76 1.2 3.81
TNMG 160408-RP ✓ ✓ 9.53 16.5 4.76 0.8 3.81
TNMG 160408-HG ✓✓✓ 9.53 16.5 4.76 0.8 3.81
160412-HG ✓ ✓ 9.53 16.5 4.76 1.2 3.81
TNMG 220408-RK ✓ ✓ 12.7 22 4.76 0.8 5.16
ISO Negative Turning Inserts
Turning
29
VNMG 160404-MP ✓ ✓ ✓ ✓ 9.53 16.5 4.76 0.4 3.81
C030
C054
~
C055
160408-MP ✓9.53 16.5 4.76 0.8 3.81
VNMG 160408-RG ✓✓✓ 9.53 16.5 4.76 0.8 3.81
WNMG
080408-FP ✓✓✓ 12.7 8.7 4.76 0.8 5.16
C031
C055
~
C056
WNMG
080404-SP ✓✓✓ 12.7 8.7 4.76 0.4 5.16
080408-SP ✓ ✓ 12.7 8.7 4.76 0.8 5.16
WNMG
080404-MP ✓ ✓ ✓ ✓ 12.7 8.7 4.76 0.4 5.16
080408-MP ✓ ✓ ✓ ✓ 12.7 8.7 4.76 0.8 5.16
080412-MP ✓ ✓ ✓ ✓ 12.7 8.7 4.76 1.2 5.16
WNMG
080408-RP ✓ ✓ 12.7 8.7 4.76 0.8 5.16
WNMG
080408-HG ✓✓✓ 12.7 8.7 4.76 0.8 5.16
080412-HG ✓✓✓ 12.7 8.7 4.76 1.2 5.16
Inserts Designation
Grade No. Dimensions (mm)
Drawing
Holder Page
CX2545
CX2555
CX2560
CX3560
CX3575
d l S r h
ISO Negative Turning Inserts
Turning
Parting & Grooving Inserts
Turning
30
Inserts Designation
Grade No. Dimensions (mm)
Drawing
CX32HS
CX33TS
CX43TS
w r l h m
MGMN200-SG ✓✓✓ 2.0 0.2 16 3.5 1.60
MGMN300-MG ✓✓✓ 3.0 0.4 21 4.8 2.35
MGMN400-MG ✓✓✓ 4.0 0.4 21 4.8 3.30
MRMN200-MG ✓✓✓ 2.0 1.0 16 3.5 1.60
MRMN300-MG ✓✓✓ 3.0 1.5 21 4.8 2.35
MRMN400-MG ✓✓✓ 4.0 2.0 21 4.8 3.30
GMM2020-MR ✓✓✓ 2.0 0.20 20 4.3 1.5
GMM2520-MR ✓ ✓ 2.5 0.20 20 4.3 1.9
GMM3020-MR ✓ ✓ 3.0 0.25 20 4.3 2.3
TGTN0220 ✓✓✓ 2.2 0.2 - - -
TGTN0310 ✓✓✓ 3.1 0.2 - - -
TGTN0410 ✓✓✓ 4.1 0.25 - - -
Holder C071 ~ C075
K
K
K
K
K
K
K
K
K
I
I
I
31
Right hand Left hand
Holder C078 ~ C079
Order No. Designation
Dimensions (mm) Max
Depth of Cut
Working Material
w h r S d d1 O.D. I.D. P M K N S H
K
ITGF32R0331555 TGF32R033-CX1555 0.33 1.0 0.05 3.18 9.525 4.4 0.8 0.5 ●●● ○○
ITGF32L0331555 TGF32L033-CX1555 0.33 1.0 0.05 3.18 9.525 4.4 0.8 0.5 ●●● ○○
ITGF32R0501555 TGF32R050-CX1555 0.50 1.4 0.05 3.18 9.525 4.4 1.2 0.8 ●●● ○○
ITGF32L0501555 TGF32L050-CX1555 0.50 1.4 0.05 3.18 9.525 4.4 1.2 0.8 ●●● ○○
ITGF32R0751555 TGF32R075-CX1555 0.75 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L0751555 TGF32L075-CX1555 0.75 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R0951555 TGF32R095-CX1555 0.95 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L0951555 TGF32L095-CX1555 0.95 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R1001555 TGF32R100-CX1555 1.00 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L1001555 TGF32L100-CX1555 1.00 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R1101555 TGF32R110-CX1555 1.10 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L1101555 TGF32L110-CX1555 1.10 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R1251555 TGF32R125-CX1555 1.25 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L1251555 TGF32L125-CX1555 1.25 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R1351555 TGF32R135-CX1555 1.35 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L1351555 TGF32L135-CX1555 1.35 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R1451555 TGF32R145-CX1555 1.45 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L1451555 TGF32L145-CX1555 1.45 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R1501555 TGF32R150-CX1555 1.50 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L1501555 TGF32L150-CX1555 1.50 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R1651555 TGF32R165-CX1555 1.65 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L1651555 TGF32L165-CX1555 1.65 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R1751555 TGF32R175-CX1555 1.75 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L1751555 TGF32L175-CX1555 1.75 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R1801555 TGF32R180-CX1555 1.80 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L1801555 TGF32L180-CX1555 1.80 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R1851555 TGF32R185-CX1555 1.85 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L1851555 TGF32L185-CX1555 1.85 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R2001555 TGF32R200-CX1555 2.00 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L2001555 TGF32L200-CX1555 2.00 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R2501555 TGF32R250-CX1555 2.50 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L2501555 TGF32L250-CX1555 2.50 2.5 0.1 3.18 9.525 4.4 2.0 1.5 ●●● ○○
※ To choose CX10(uncoated) for material machining.
Parting & Grooving Inserts
Turning
32
Order No. Designation
Dimensions (mm) Max
Depth of Cut
Working Material
w h r S d d1 O.D. I.D. P M K N S H
※ To choose CX10(uncoated) for material machining.
ITGF32R025R1555 TGF32R025R-CX1555 0.50 1.4 0.25 3.18 9.525 4.4 1.2 0.8 ●●● ○○
ITGF32L025R1555 TGF32L025R-CX1555 0.50 1.4 0.25 3.18 9.525 4.4 1.2 0.8 ●●● ○○
ITGF32R037R1555 TGF32R037R-CX1555 0.75 2.5 0.375 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L037R1555 TGF32L037R-CX1555 0.75 2.5 0.375 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R050R1555 TGF32R050R-CX1555 1.00 2.5 0.5 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L050R1555 TGF32L050R-CX1555 1.00 2.5 0.5 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R062R1555 TGF32R062R-CX1555 1.25 2.5 0.625 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L062R1555 TGF32L062R-CX1555 1.25 2.5 0.625 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32R075R1555 TGF32R075R-CX1555 1.50 2.5 0.75 3.18 9.525 4.4 2.0 1.5 ●●● ○○
ITGF32L075R1555 TGF32L075R-CX1555 1.50 2.5 0.75 3.18 9.525 4.4 2.0 1.5 ●●● ○○
Holder C078 ~ C079
K
Right hand Left hand
Parting & Grooving Inserts
Turning
33
Holder C111
Inserts Designation
Grade No. Dimensions (mm)
Drawing
CX1555
CX1560
w r l k t
Back turning
SAKBR20005 ✓2.0 - 5.0 35 0.5
SAKBR20015 ✓2.0 0.1 5.0 35 0.5
SAKBR20025 ✓2.0 0.2 5.0 35 0.5
SAKBR30015 ✓3.0 0.1 5.0 35 0.5
SAKBR30025 ✓3.0 0.2 5.0 35 0.5
Parting o
SAKCR15018 ✓1.5 0.1 8.5 15 -
SAKCR20019 ✓2.0 0.1 9.0 15 -
SAKCR25019 ✓2.5 0.1 9.0 15 -
SAKCR30019 ✓3.0 0.1 9.0 15 -
Parting o
Back turning
Parting & Grooving Inserts
Turning
34 Holder C111
Inserts Designation
Grade No. Dimensions (mm)
Drawing
CX1555
CX1560
w r l k t
Grooving
SAKGR10013 ✓1.0 0.1 3.0 - -
SAKGR15013 ✓1.5 0.1 3.0 - -
SAKGR15025 ✓1.5 0.2 5.0 - -
SAKGR15027 ✓1.5 0.2 7.0 - -
SAKGR20015 ✓2.0 0.1 5.0 - -
SAKGR20025 ✓2.0 0.2 5.0 - -
SAKGR20027 ✓2.0 0.2 7.0 - -
SAKGR20029 ✓2.0 0.2 9.0 - -
SAKGR25015 ✓2.5 0.1 5.0 - -
SAKGR25025 ✓2.5 0.2 5.0 - -
SAKGR25029 ✓2.5 0.2 9.0 - -
SAKGR30015 ✓3.0 0.1 5.0 - -
SAKGR30019 ✓3.0 0.1 9.0 - -
SAKGR30025 ✓3.0 0.2 5.0 - -
SAKGR30027 ✓3.0 0.2 7.0 - -
SAKGR30029 ✓3.0 0.2 9.0 - -
Proling
SAKPR10053 ✓1.0 0.5 3.0 - -
SAKPR15075 ✓1.5 0.75 5.0 - -
SAKPR20105 ✓2.0 1.0 5.0 - -
SAKPR25125 ✓2.5 1.25 5.0 - -
SAKPR30158 ✓3.0 1.5 8.0 - -
Threading
SAKTR20655 ✓2.0 0.05 6.0 55 0.5~2
SAKTR30655 ✓3.0 0.1 6.0 55 1~3
SAKTR20660 ✓2.0 0.05 6.0 60 0.5~2
SAKTR30660 ✓3.0 0.1 6.0 60 1~3
Grooving
Threading
Proling
Parting & Grooving Inserts
Turning
60° Threading Inserts
Threading
35
Partial Prole 60°
Order No. Designation
Pitch Dimensions (mm) Working Material
TP (mm) TPI d l r x y P M K N S H
External
Right hand Left hand
Holder D029 ~ D033
I11ERA601555 11ERA60-CX1555 0.5 ~ 1.5 48 ~ 16 1/4" 11 0.05 0.8 0.9 ●●● ○○
I11ELA601555 11ELA60-CX1555 0.5 ~ 1.5 48 ~ 16 1/4" 11 0.05 0.8 0.9 ●●● ○○
I16ERA601555 16ERA60-CX1555 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●● ○○
I16ERA601560 16ERA60-CX1560 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●●○●●
I16ELA601555 16ELA60-CX1555 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●● ○○
I16ELA601560 16ELA60-CX1560 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●●○●●
I16ERAG601555 16ERAG60-CX1555 0.5 ~ 3.0 48 ~ 8 3/8" 16 0.05 1.2 1.7 ●●● ○○
I16ELAG601555 16ELAG60-CX1555 0.5 ~ 3.0 48 ~ 8 3/8" 16 0.05 1.2 1.7 ●●● ○○
I16ERG601555 16ERG60-CX1555 1.75 ~ 3.0 14 ~ 8 3/8" 16 0.17 1.2 1.7 ●●● ○○
I16ELG601555 16ELG60-CX1555 1.75 ~ 3.0 14 ~ 8 3/8" 16 0.17 1.2 1.7 ●●● ○○
I16ELG601560 16ELG60-CX1560 1.75 ~ 3.0 14 ~ 8 3/8" 16 0.17 1.2 1.7 ●●●○●●
36
Order No. Designation
Pitch Dimensions (mm) Working Material
TP (mm) TPI d l r x y P M K N S H
Internal
I11IRA601555 11IRA60-CX1555 0.5 ~ 1.5 48 ~ 16 1/4" 11 0.05 0.8 0.9 ●●● ○○
I11ILA601555 11ILA60-CX1555 0.5 ~ 1.5 48 ~ 16 1/4" 11 0.05 0.8 0.9 ●●● ○○
I16IRA601555 16IRA60-CX1555 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●● ○○
I16IRA601560 16IRA60-CX1560 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●●○●●
I16ILA601555 16ILA60-CX1555 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●● ○○
I16ILA601560 16ILA60-CX1560 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●●○●●
I16IRAG601555 16IRAG60-CX1555 0.5 ~ 3.0 48 ~ 8 3/8" 16 0.05 1.2 1.7 ●●● ○○
I16IRAG601560 16IRAG60-CX1560 0.5 ~ 3.0 48 ~ 8 3/8" 16 0.05 1.2 1.7 ●●●○●●
I16ILAG601555 16ILAG60-CX1555 0.5 ~ 3.0 48 ~ 8 3/8" 16 0.05 1.2 1.7 ●●● ○○
I16ILAG601560 16ILAG60-CX1560 0.5 ~ 3.0 48 ~ 8 3/8" 16 0.05 1.2 1.7 ●●●○●●
I16IRG601555 16IRG60-CX1555 1.75 ~ 3.0 14 ~ 8 3/8" 16 0.12 1.2 1.7 ●●● ○○
I16IRG601560 16IRG60-CX1560 1.75 ~ 3.0 14 ~ 8 3/8" 16 0.12 1.2 1.7 ●●●○●●
I16ILG601555 16ILG60-CX1555 1.75 ~ 3.0 14 ~ 8 3/8" 16 0.12 1.2 1.7 ●●● ○○
I16ILG601560 16ILG60-CX1560 1.75 ~ 3.0 14 ~ 8 3/8" 16 0.12 1.2 1.7 ●●●○●●
Holder D029 ~ D033
60° Threading Inserts
Threading
Partial Prole 60°
Right hand Left hand
60° Threading Inserts
Threading
37
ISO Metric 60°
Order No. Designation
Pitch Dimensions (mm) Working Material
TP (mm) d l r x y P M K N S H
External
Tolerance Class : 6g/6H
I11ER035ISO1555 11ER0.35ISO-CX1555 0.35 1/4" 11 0.04 0.8 0.4 ●●● ○○
I11EL035ISO1555 11EL0.35ISO-CX1555 0.35 1/4" 11 0.04 0.8 0.4 ●●● ○○
I11ER040ISO1555 11ER0.40ISO-CX1555 0.40 1/4" 11 0.04 0.7 0.4 ●●● ○○
I11ER045ISO1555 11ER0.45ISO-CX1555 0.45 1/4" 11 0.05 0.7 0.4 ●●● ○○
I11ER050ISO1555 11ER0.50ISO-CX1555 0.50 1/4" 11 0.05 0.6 0.6 ●●● ○○
I11EL050ISO1555 11EL0.50ISO-CX1555 0.50 1/4" 11 0.05 0.6 0.6 ●●● ○○
I11ER060ISO1555 11ER0.60ISO-CX1555 0.60 1/4" 11 0.07 0.6 0.6 ●●● ○○
I11ER070ISO1555 11ER0.70ISO-CX1555 0.70 1/4" 11 0.07 0.6 0.6 ●●● ○○
I11ER075ISO1555 11ER0.75ISO-CX1555 0.75 1/4" 11 0.08 0.6 0.6 ●●● ○○
I11EL075ISO1555 11EL0.75ISO-CX1555 0.75 1/4" 11 0.08 0.6 0.6 ●●● ○○
I11ER080ISO1555 11ER0.80ISO-CX1555 0.80 1/4" 11 0.09 0.6 0.6 ●●● ○○
I11ER100ISO1555 11ER1.00ISO-CX1555 1.00 1/4" 11 0.12 0.7 0.7 ●●● ○○
I11EL100ISO1555 11EL1.00ISO-CX1555 1.00 1/4" 11 0.12 0.7 0.7 ●●● ○○
I11ER125ISO1555 11ER1.25ISO-CX1555 1.25 1/4" 11 0.15 0.8 0.9 ●●● ○○
I11ER150ISO1555 11ER1.50ISO-CX1555 1.50 1/4" 11 0.18 0.8 1.0 ●●● ○○
I11EL150ISO1555 11EL1.50ISO-CX1555 1.50 1/4" 11 0.18 0.8 1.0 ●●● ○○
I16ER075ISO1555 16ER0.75ISO-CX1555 0.75 3/8" 16 0.08 0.6 0.6 ●●● ○○
I16ER075ISO1560 16ER0.75ISO-CX1560 0.75 3/8" 16 0.08 0.6 0.6 ●●●○●●
I16EL075ISO1555 16EL0.75ISO-CX1555 0.75 3/8" 16 0.08 0.6 0.6 ●●● ○○
I16EL075ISO1560 16EL0.75ISO-CX1560 0.75 3/8" 16 0.08 0.6 0.6 ●●●○●●
I16ER080ISO1555 16ER0.80ISO-CX1555 0.80 3/8" 16 0.09 0.6 0.6 ●●● ○○
I16ER080ISO1560 16ER0.80ISO-CX1560 0.80 3/8" 16 0.09 0.6 0.6 ●●●○●●
I16EL080ISO1555 16EL0.80ISO-CX1555 0.80 3/8" 16 0.09 0.6 0.6 ●●● ○○
I16EL080ISO1560 16EL0.80ISO-CX1560 0.80 3/8" 16 0.09 0.6 0.6 ●●●○●●
I16ER100ISO1555 16ER1.00ISO-CX1555 1.00 3/8" 16 0.12 0.7 0.7 ●●● ○○
I16ER100ISO1560 16ER1.00ISO-CX1560 1.00 3/8" 16 0.12 0.7 0.7 ●●●○●●
I16EL100ISO1555 16EL1.00ISO-CX1555 1.00 3/8" 16 0.12 0.7 0.7 ●●● ○○
I16EL100ISO1560 16EL1.00ISO-CX1560 1.00 3/8" 16 0.12 0.7 0.7 ●●●○●●
Holder D029 ~ D033
Right hand Left hand
38
External
Tolerance Class : 6g/6H
Holder D029 ~ D033
I16ER125ISO1555 16ER1.25ISO-CX1555 1.25 3/8" 16 0.15 0.8 0.9 ●●● ○○
I16EL125ISO1555 16EL1.25ISO-CX1555 1.25 3/8" 16 0.15 0.8 0.9 ●●● ○○
I16EL125ISO1560 16EL1.25ISO-CX1560 1.25 3/8" 16 0.15 0.8 0.9 ●●●○●●
I16ER150ISO1555 16ER1.50ISO-CX1555 1.50 3/8" 16 0.18 0.8 1.0 ●●● ○○
I16ER150ISO1560 16ER1.50ISO-CX1560 1.50 3/8" 16 0.18 0.8 1.0 ●●●○●●
I16EL150ISO1555 16EL1.50ISO-CX1555 1.50 3/8" 16 0.18 0.8 1.0 ●●● ○○
I16EL150ISO1560 16EL1.50ISO-CX1560 1.50 3/8" 16 0.18 0.8 1.0 ●●●○●●
I16ER175ISO1555 16ER1.75ISO-CX1555 1.75 3/8" 16 0.21 0.9 1.2 ●●● ○○
I16ER175ISO1560 16ER1.75ISO-CX1560 1.75 3/8" 16 0.21 0.9 1.2 ●●●○●●
I16EL175ISO1555 16EL1.75ISO-CX1555 1.75 3/8" 16 0.21 0.9 1.2 ●●● ○○
I16EL175ISO1560 16EL1.75ISO-CX1560 1.75 3/8" 16 0.21 0.9 1.2 ●●●○●●
I16ER200ISO1555 16ER2.00ISO-CX1555 2.00 3/8" 16 0.25 1.0 1.3 ●●● ○○
I16EL200ISO1555 16EL2.00ISO-CX1555 2.00 3/8" 16 0.25 1.0 1.3 ●●● ○○
I16EL200ISO1560 16EL2.00ISO-CX1560 2.00 3/8" 16 0.25 1.0 1.3 ●●●○●●
I16ER250ISO1555 16ER2.50ISO-CX1555 2.50 3/8" 16 0.31 1.1 1.5 ●●● ○○
I16ER250ISO1560 16ER2.50ISO-CX1560 2.50 3/8" 16 0.31 1.1 1.5 ●●●○●●
I16EL250ISO1555 16EL2.50ISO-CX1555 2.50 3/8" 16 0.31 1.1 1.5 ●●● ○○
I16EL250ISO1560 16EL2.50ISO-CX1560 2.50 3/8" 16 0.31 1.1 1.5 ●●●○●●
I16ER300ISO1555 16ER3.00ISO-CX1555 3.00 3/8" 16 0.38 1.2 1.6 ●●● ○○
I16EL300ISO1555 16EL3.00ISO-CX1555 3.00 3/8" 16 0.38 1.2 1.6 ●●● ○○
I16EL300ISO1560 16EL3.00ISO-CX1560 3.00 3/8" 16 0.38 1.2 1.6 ●●●○●●
Order No. Designation
Pitch Dimensions (mm) Working Material
TP (mm) d l r x y P M K N S H
Right hand Left hand
60° Threading Inserts
Threading
ISO Metric 60°
39
Internal
Tolerance Class : 6g/6H
Order No. Designation
Pitch Dimensions (mm) Working Material
TP (mm) d l r x y P M K N S H
I11IR035ISO1555 11IR0.35ISO-CX1555 0.35 1/4" 11 0.02 0.8 0.3 ●●● ○○
I11IL035ISO1555 11IL0.35ISO-CX1555 0.35 1/4" 11 0.02 0.8 0.3 ●●● ○○
I11IR040ISO1555 11IR0.40ISO-CX1555 0.40 1/4" 11 0.02 0.8 0.4 ●●● ○○
I11IR050ISO1555 11IR0.50ISO-CX1555 0.50 1/4" 11 0.03 0.6 0.6 ●●● ○○
I11IL050ISO1555 11IL0.50ISO-CX1555 0.50 1/4" 11 0.03 0.6 0.6 ●●● ○○
I11IR070ISO1555 11IR0.70ISO-CX1555 0.70 1/4" 11 0.04 0.6 0.6 ●●● ○○
I11IR075ISO1555 11IR0.75ISO-CX1555 0.75 1/4" 11 0.04 0.6 0.6 ●●● ○○
I11IL075ISO1555 11IL0.75ISO-CX1555 0.75 1/4" 11 0.04 0.6 0.6 ●●● ○○
I11IR080ISO1555 11IR0.80ISO-CX1555 0.80 1/4" 11 0.04 0.6 0.6 ●●● ○○
I11IR100ISO1555 11IR1.00ISO-CX1555 1.00 1/4" 11 0.05 0.6 0.7 ●●● ○○
I11IL100ISO1555 11IL1.00ISO-CX1555 1.00 1/4" 11 0.05 0.6 0.7 ●●● ○○
I11IR125ISO1555 11IR1.25ISO-CX1555 1.25 1/4" 11 0.07 0.8 0.8 ●●● ○○
I11IL125ISO1555 11IL1.25ISO-CX1555 1.25 1/4" 11 0.07 0.8 0.8 ●●● ○○
I11IR150ISO1555 11IR1.50ISO-CX1555 1.50 1/4" 11 0.08 0.8 1.0 ●●● ○○
I11IL150ISO1555 11IL1.50ISO-CX1555 1.50 1/4" 11 0.08 0.8 1.0 ●●● ○○
I16IR075ISO1555 16IR0.75ISO-CX1555 0.75 3/8" 16 0.04 0.6 0.6 ●●● ○○
I16IR075ISO1560 16IR0.75ISO-CX1560 0.75 3/8" 16 0.04 0.6 0.6 ●●●○●●
I16IL075ISO1555 16IL0.75ISO-CX1555 0.75 3/8" 16 0.04 0.6 0.6 ●●● ○○
I16IL075ISO1560 16IL0.75ISO-CX1560 0.75 3/8" 16 0.04 0.6 0.6 ●●●○●●
I16IR080ISO1555 16IR0.80ISO-CX1555 0.80 3/8" 16 0.04 0.6 0.6 ●●● ○○
I16IR080ISO1560 16IR0.80ISO-CX1560 0.80 3/8" 16 0.04 0.6 0.6 ●●●○●●
I16IL080ISO1555 16IL0.80ISO-CX1555 0.80 3/8" 16 0.04 0.6 0.6 ●●● ○○
I16IL080ISO1560 16IL0.80ISO-CX1560 0.80 3/8" 16 0.04 0.6 0.6 ●●●○●●
I16IR100ISO1555 16IR1.00ISO-CX1555 1.00 3/8" 16 0.05 0.6 0.7 ●●● ○○
I16IR100ISO1560 16IR1.00ISO-CX1560 1.00 3/8" 16 0.05 0.6 0.7 ●●●○●●
I16IL100ISO1555 16IL1.00ISO-CX1555 1.00 3/8" 16 0.05 0.6 0.7 ●●● ○○
I16IL100ISO1560 16IL1.00ISO-CX1560 1.00 3/8" 16 0.05 0.6 0.7 ●●●○●●
Holder D029 ~ D033
Right hand Left hand
60° Threading Inserts
Threading
ISO Metric 60°
40
Internal
Tolerance Class : 6g/6H
Order No. Designation
Pitch Dimensions (mm) Working Material
TP (mm) d l r x y P M K N S H
Holder D029 ~ D033
I16IR125ISO1555 16IR1.25ISO-CX1555 1.25 3/8" 16 0.07 0.8 0.9 ●●● ○○
I16IR125ISO1560 16IR1.25ISO-CX1560 1.25 3/8" 16 0.07 0.8 0.9 ●●●○●●
I16IL125ISO1555 16IL1.25ISO-CX1555 1.25 3/8" 16 0.07 0.8 0.9 ●●● ○○
I16IL125ISO1560 16IL1.25ISO-CX1560 1.25 3/8" 16 0.07 0.8 0.9 ●●●○●●
I16IR150ISO1555 16IR1.50ISO-CX1555 1.50 3/8" 16 0.10 0.8 1.0 ●●● ○○
I16IR150ISO1560 16IR1.50ISO-CX1560 1.50 3/8" 16 0.10 0.8 1.0 ●●●○●●
I16IL150ISO1555 16IL1.50ISO-CX1555 1.50 3/8" 16 0.10 0.8 1.0 ●●● ○○
I16IL150ISO1560 16IL1.50ISO-CX1560 1.50 3/8" 16 0.10 0.8 1.0 ●●●○●●
I16IR175ISO1555 16IR1.75ISO-CX1555 1.75 3/8" 16 0.12 0.9 1.2 ●●● ○○
I16IR175ISO1560 16IR1.75ISO-CX1560 1.75 3/8" 16 0.12 0.9 1.2 ●●●○●●
I16IL175ISO1555 16IL1.75ISO-CX1555 1.75 3/8" 16 0.12 0.9 1.2 ●●● ○○
I16IL175ISO1560 16IL1.75ISO-CX1560 1.75 3/8" 16 0.12 0.9 1.2 ●●●○●●
I16IR200ISO1555 16IR2.00ISO-CX1555 2.00 3/8" 16 0.13 1.0 1.3 ●●● ○○
I16IR200ISO1560 16IR2.00ISO-CX1560 2.00 3/8" 16 0.13 1.0 1.3 ●●●○●●
I16IL200ISO1555 16IL2.00ISO-CX1555 2.00 3/8" 16 0.13 1.0 1.3 ●●● ○○
I16IL200ISO1560 16IL2.00ISO-CX1560 2.00 3/8" 16 0.13 1.0 1.3 ●●●○●●
I16IR250ISO1555 16IR2.50ISO-CX1555 2.50 3/8" 16 0.15 1.1 1.5 ●●● ○○
I16IR250ISO1560 16IR2.50ISO-CX1560 2.50 3/8" 16 0.15 1.1 1.5 ●●●○●●
I16IL250ISO1555 16IL2.50ISO-CX1555 2.50 3/8" 16 0.15 1.1 1.5 ●●● ○○
I16IL250ISO1560 16IL2.50ISO-CX1560 2.50 3/8" 16 0.15 1.1 1.5 ●●●○●●
I16IR300ISO1555 16IR3.00ISO-CX1555 3.00 3/8" 16 0.18 1.1 1.5 ●●● ○○
I16IR300ISO1560 16IR3.00ISO-CX1560 3.00 3/8" 16 0.18 1.1 1.5 ●●●○●●
I16IL300ISO1555 16IL3.00ISO-CX1555 3.00 3/8" 16 0.18 1.1 1.5 ●●● ○○
I16IL300ISO1560 16IL3.00ISO-CX1560 3.00 3/8" 16 0.18 1.1 1.5 ●●●○●●
Right hand Left hand
60° Threading Inserts
Threading
ISO Metric 60°
41
American UN 60°
External
Tolerance Class : 2A/2B
Order No. Designation
Pitch Dimensions (mm) Working Material
TPI d l r x y P M K N S H
Holder D029 ~ D033
I11ER32UN1555 11ER32UN-CX1555 32 1/4" 11 0.09 0.6 0.6 ●●● ○○
I11ER28UN1555 11ER28UN-CX1555 28 1/4" 11 0.10 0.6 0.7 ●●● ○○
I11EL28UN1555 11EL28UN-CX1555 28 1/4" 11 0.10 0.6 0.7 ●●● ○○
I11ER18UN1555 11ER18UN-CX1555 18 1/4" 11 0.17 0.8 1.0 ●●● ○○
I11ER16UN1555 11ER16UN-CX1555 16 1/4" 11 0.18 0.9 1.1 ●●● ○○
I16ER40UN1555 16ER40UN-CX1555 40 3/8" 16 0.06 0.6 0.6 ●●● ○○
I16EL40UN1555 16EL40UN-CX1555 40 3/8" 16 0.06 0.6 0.6 ●●● ○○
I16ER36UN1555 16ER36UN-CX1555 36 3/8" 16 0.07 0.6 0.6 ●●● ○○
I16EL36UN1555 16EL36UN-CX1555 36 3/8" 16 0.07 0.6 0.6 ●●● ○○
I16ER32UN1555 16ER32UN-CX1555 32 3/8" 16 0.09 0.6 0.6 ●●● ○○
I16EL32UN1555 16EL32UN-CX1555 32 3/8" 16 0.09 0.6 0.6 ●●● ○○
I16ER28UN1555 16ER28UN-CX1555 28 3/8" 16 0.10 0.6 0.7 ●●● ○○
I16EL28UN1555 16EL28UN-CX1555 28 3/8" 16 0.10 0.6 0.7 ●●● ○○
I16ER26UN1555 16ER26UN-CX1555 26 3/8" 16 0.11 0.7 0.8 ●●● ○○
I16EL26UN1555 16EL26UN-CX1555 26 3/8" 16 0.11 0.7 0.8 ●●● ○○
I16ER24UN1555 16ER24UN-CX1555 24 3/8" 16 0.12 0.7 0.8 ●●● ○○
I16EL24UN1555 16EL24UN-CX1555 24 3/8" 16 0.12 0.7 0.8 ●●● ○○
I16ER20UN1555 16ER20UN-CX1555 20 3/8" 16 0.15 0.8 0.9 ●●● ○○
I16EL20UN1555 16EL20UN-CX1555 20 3/8" 16 0.15 0.8 0.9 ●●● ○○
Right hand Left hand
60° Threading Inserts
Threading
42
External
Tolerance Class : 2A/2B
I16ER18UN1555 16ER18UN-CX1555 18 3/8" 16 0.17 0.8 1.0 ●●● ○○
I16EL18UN1555 16EL18UN-CX1555 18 3/8" 16 0.17 0.8 1.0 ●●● ○○
I16ER16UN1555 16ER16UN-CX1555 16 3/8" 16 0.18 0.9 1.1 ●●● ○○
I16EL16UN1555 16EL16UN-CX1555 16 3/8" 16 0.18 0.9 1.1 ●●● ○○
I16ER14UN1555 16ER14UN-CX1555 14 3/8" 16 0.22 1.0 1.2 ●●● ○○
I16EL14UN1555 16EL14UN-CX1555 14 3/8" 16 0.22 1.0 1.2 ●●● ○○
I16ER13UN1555 16ER13UN-CX1555 13 3/8" 16 0.24 1.0 1.3 ●●● ○○
I16EL13UN1555 16EL13UN-CX1555 13 3/8" 16 0.24 1.0 1.3 ●●● ○○
I16ER12UN1555 16ER12UN-CX1555 12 3/8" 16 0.26 1.1 1.4 ●●● ○○
I16EL12UN1555 16EL12UN-CX1555 12 3/8" 16 0.26 1.1 1.4 ●●● ○○
I16ER115UN1555 16ER11.5UN-CX1555 11.5 3/8" 16 0.27 1.1 1.5 ●●● ○○
I16EL115UN1555 16EL11.5UN-CX1555 11.5 3/8" 16 0.27 1.1 1.5 ●●● ○○
I16ER11UN1555 16ER11UN-CX1555 11 3/8" 16 0.28 1.1 1.5 ●●● ○○
I16EL11UN1555 16EL11UN-CX1555 11 3/8" 16 0.28 1.1 1.5 ●●● ○○
I16ER10UN1555 16ER10UN-CX1555 10 3/8" 16 0.32 1.1 1.5 ●●● ○○
I16EL10UN1555 16EL10UN-CX1555 10 3/8" 16 0.32 1.1 1.5 ●●● ○○
I16ER9UN1555 16ER9UN-CX1555 9 3/8" 16 0.36 1.2 1.7 ●●● ○○
I16EL9UN1555 16EL9UN-CX1555 9 3/8" 16 0.36 1.2 1.7 ●●● ○○
I16ER8UN1555 16ER8UN-CX1555 8 3/8" 16 0.41 1.2 1.6 ●●● ○○
I16EL8UN1555 16EL8UN-CX1555 8 3/8" 16 0.41 1.2 1.6 ●●● ○○
Order No. Designation
Pitch Dimensions (mm) Working Material
TPI d l r x y P M K N S H
Holder D029 ~ D033
Right hand Left hand
American UN 60°
60° Threading Inserts
Threading
43
Internal
Tolerance Class : 2A/2B
Order No. Designation
Pitch Dimensions (mm) Working Material
TPI d l r x y P M K N S H
Holder D029 ~ D033
I11IR32UN1555 11IR32UN-CX1555 32 1/4" 11 0.04 0.6 0.6 ●●● ○○
I11IL32UN1555 11IL32UN-CX1555 32 1/4" 11 0.04 0.6 0.6 ●●● ○○
I11IR28UN1555 11IR28UN-CX1555 28 1/4" 11 0.04 0.6 0.7 ●●● ○○
I11IL28UN1555 11IL28UN-CX1555 28 1/4" 11 0.04 0.6 0.7 ●●● ○○
I11IR24UN1555 11IR24UN-CX1555 24 1/4" 11 0.05 0.7 0.8 ●●● ○○
I11IL24UN1555 11IL24UN-CX1555 24 1/4" 11 0.05 0.7 0.8 ●●● ○○
I11IR20UN1555 11IR20UN-CX1555 20 1/4" 11 0.06 0.8 0.9 ●●● ○○
I11IL20UN1555 11IL20UN-CX1555 20 1/4" 11 0.06 0.8 0.9 ●●● ○○
I11IR18UN1555 11IR18UN-CX1555 18 1/4" 11 0.07 0.8 1.0 ●●● ○○
I11IL18UN1555 11IL18UN-CX1555 18 1/4" 11 0.07 0.8 1.0 ●●● ○○
I11IR16UN1555 11IR16UN-CX1555 16 1/4" 11 0.09 0.9 1.1 ●●● ○○
I11IL16UN1555 11IL16UN-CX1555 16 1/4" 11 0.09 0.9 1.1 ●●● ○○
I16IR40UN1555 16IR40UN-CX1555 40 3/8" 16 0.03 0.6 0.6 ●●● ○○
I16IL40UN1555 16IL40UN-CX1555 40 3/8" 16 0.03 0.6 0.6 ●●● ○○
I16IR36UN1555 16IR36UN-CX1555 36 3/8" 16 0.03 0.6 0.6 ●●● ○○
I16IL36UN1555 16IL36UN-CX1555 36 3/8" 16 0.03 0.6 0.6 ●●● ○○
I16IR32UN1555 16IR32UN-CX1555 32 3/8" 16 0.04 0.6 0.6 ●●● ○○
I16IL32UN1555 16IL32UN-CX1555 32 3/8" 16 0.04 0.6 0.6 ●●● ○○
I16IR28UN1555 16IR28UN-CX1555 28 3/8" 16 0.04 0.6 0.7 ●●● ○○
I16IL28UN1555 16IL28UN-CX1555 28 3/8" 16 0.04 0.6 0.7 ●●● ○○
I16IR26UN1555 16IR26UN-CX1555 26 3/8" 16 0.04 0.7 0.8 ●●● ○○
I16IL26UN1555 16IL26UN-CX1555 26 3/8" 16 0.04 0.7 0.8 ●●● ○○
I16IR24UN1555 16IR24UN-CX1555 24 3/8" 16 0.05 0.7 0.8 ●●● ○○
I16IL24UN1555 16IL24UN-CX1555 24 3/8" 16 0.05 0.7 0.8 ●●● ○○
I16IR20UN1555 16IR20UN-CX1555 20 3/8" 16 0.06 0.8 0.9 ●●● ○○
I16IL20UN1555 16IL20UN-CX1555 20 3/8" 16 0.06 0.8 0.9 ●●● ○○
Right hand Left hand
American UN 60°
60° Threading Inserts
Threading
44
Internal
Tolerance Class : 2A/2B
Order No. Designation
Pitch Dimensions (mm) Working Material
TPI d l r x y P M K N S H
Holder D029 ~ D033
I16IR18UN1555 16IR18UN-CX1555 18 3/8" 16 0.07 0.8 1.0 ●●● ○○
I16IL18UN1555 16IL18UN-CX1555 18 3/8" 16 0.07 0.8 1.0 ●●● ○○
I16IR16UN1555 16IR16UN-CX1555 16 3/8" 16 0.09 0.9 1.1 ●●● ○○
I16IL16UN1555 16IL16UN-CX1555 16 3/8" 16 0.09 0.9 1.1 ●●● ○○
I16IR14UN1555 16IR14UN-CX1555 14 3/8" 16 0.10 0.9 1.2 ●●● ○○
I16IL14UN1555 16IL14UN-CX1555 14 3/8" 16 0.10 0.9 1.2 ●●● ○○
I16IR13UN1555 16IR13UN-CX1555 13 3/8" 16 0.11 1.0 1.3 ●●● ○○
I16IL13UN1555 16IL13UN-CX1555 13 3/8" 16 0.11 1.0 1.3 ●●● ○○
I16IR12UN1555 16IR12UN-CX1555 12 3/8" 16 0.12 1.1 1.4 ●●● ○○
I16IL12UN1555 16IL12UN-CX1555 12 3/8" 16 0.12 1.1 1.4 ●●● ○○
I16IR115UN1555 16IR11.5UN-CX1555 11.5 3/8" 16 0.13 1.1 1.5 ●●● ○○
I16IL115UN1555 16IL11.5UN-CX1555 11.5 3/8" 16 0.13 1.1 1.5 ●●● ○○
I16IR11UN1555 16IR11UN-CX1555 11 3/8" 16 0.14 1.1 1.5 ●●● ○○
I16IL11UN1555 16IL11UN-CX1555 11 3/8" 16 0.14 1.1 1.5 ●●● ○○
I16IR10UN1555 16IR10UN-CX1555 10 3/8" 16 0.15 1.1 1.5 ●●● ○○
I16IL10UN1555 16IL10UN-CX1555 10 3/8" 16 0.15 1.1 1.5 ●●● ○○
I16IR9UN1555 16IR9UN-CX1555 9 3/8" 16 0.17 1.2 1.7 ●●● ○○
I16IL9UN1555 16IL9UN-CX1555 9 3/8" 16 0.17 1.2 1.7 ●●● ○○
I16IR8UN1555 16IR8UN-CX1555 8 3/8" 16 0.19 1.1 1.5 ●●● ○○
I16IL8UN1555 16IL8UN-CX1555 8 3/8" 16 0.19 1.1 1.5 ●●● ○○
Right hand Left hand
American UN 60°
60° Threading Inserts
Threading
45
Partial Prole 55°
External
I11ERA551555 11ERA55-CX1555 0.5 ~ 1.5 48 ~ 16 1/4" 11 0.05 0.8 0.9 ●●● ○○
I11ELA551555 11ELA55-CX1555 0.5 ~ 1.5 48 ~ 16 1/4" 11 0.05 0.8 0.9 ●●● ○○
I16ERA551555 16ERA55-CX1555 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●● ○○
I16ELA551555 16ELA55-CX1555 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●● ○○
I16ERAG551555 16ERAG55-CX1555 0.5 ~ 3.0 48 ~ 8 3/8" 16 0.05 1.2 1.7 ●●● ○○
I16ELAG551555 16ELAG55-CX1555 0.5 ~ 3.0 48 ~ 8 3/8" 16 0.05 1.2 1.7 ●●● ○○
I16ERG551555 16ERG55-CX1555 1.75 ~ 3.0 14 ~ 8 3/8" 16 0.17 1.2 1.7 ●●● ○○
I16ELG551555 16ELG55-CX1555 1.75 ~ 3.0 14 ~ 8 3/8" 16 0.17 1.2 1.7 ●●● ○○
Holder D029 ~ D033
Order No. Designation
Pitch Dimensions (mm) Working Material
TP (mm) TPI d l r x y P M K N S H
Right hand Left hand
55° Threading Inserts
Threading
46
Partial Prole 55°
Internal Holder D029 ~ D033
Order No. Designation
Pitch Dimensions (mm) Working Material
TP (mm) TPI d l r x y P M K N S H
Right hand Left hand
I11IRA551555 11IRA55-CX1555 0.5 ~ 1.5 48 ~ 16 1/4" 11 0.05 0.8 0.9 ●●● ○○
I11ILA551555 11ILA55-CX1555 0.5 ~ 1.5 48 ~ 16 1/4" 11 0.05 0.8 0.9 ●●● ○○
I16IRA551555 16IRA55-CX1555 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●● ○○
I16ILA551555 16ILA55-CX1555 0.5 ~ 1.5 48 ~ 16 3/8" 16 0.05 0.8 0.9 ●●● ○○
I16IRAG551555 16IRAG55-CX1555 0.5 ~ 3.0 48 ~ 8 3/8" 16 0.05 1.2 1.7 ●●● ○○
I16ILAG551555 16ILAG55-CX1555 0.5 ~ 3.0 48 ~ 8 3/8" 16 0.05 1.2 1.7 ●●● ○○
I16IRG551555 16IRG55-CX1555 1.75 ~ 3.0 14 ~ 8 3/8" 16 0.12 1.2 1.7 ●●● ○○
I16ILG551555 16ILG55-CX1555 1.75 ~ 3.0 14 ~ 8 3/8" 16 0.12 1.2 1.7 ●●● ○○
55° Threading Inserts
Threading
✽Pictures from Kennametal Tooling Catalogue
47
Troubleshooting in Insert
Technical Data
Trouble Occurrences Countermeasures
Thermal Crackin
Intermittent heating of the cutting edge.
High speed, high volume metal removal.
1.Use heat resistant grades
2.Use positive or large rake tools
3.Increase nose radius
4.Reduce speed, feed or depth of cut
Chipping
Cutting tool excessively brittle.
1.Use tougher grades
2.Use negative or smaller rake tools
3.Increase nose radius
4.Use increased edge land
5.Increase cutting speed
Excessive Flank Wear
Cutting tool too soft.
Surface speed too fast.
1.
Use harder and more wear resistant grade
2.Reduce cutting speed
3.Increase feed
4.Use coolant
Notching
Cutting material working harden cause
serious wear of insert.
1.Increase approach angle
2.Reduce cutting speed and feed
3.Use high lubricity coolant
Built-Up-Edge
Cutting speed too slow for material
being machined.
1.Increase cutting speed
2.Use friction reducing grade
3.Use high lubricity coolant
Deformation
Heavy feeds or higher cutting speed.
1.Reduce cutting speed or feed
2.Use polished tools to reducing friction
3.Use more heat resistant grade
Crater Wear
Excessive heat and pressure welding of
chip to rake.
1.Use a harder grade
2.Reduce cutting speed and feed
3.Use high lubricity coolant
