Holemaking Tools
Holemaking Tools
DG Series for General Purpose
● 3×D, 5×D Cutting depth.
● External Coolant.
●
130° Tip Angle, Straight Shank.
● UNIX Coating.
● 3×D, 5×D 加工深度。
● 冷卻方式 : 外冷。
● 130° 鑽尖 , 直柄。
● UNIX 塗層。
DP Series for Universal
● 3×D, 5×D, 7×D Cutting depth.
● Internal & External Coolant.
● 140° Tip Angle, Reinforced Shank.
● UNIX Coating.
● 3×D, 5×D, 7×D 加工深度。
● 冷卻方式 : 內冷孔 & 外冷。
● 140° 鑽尖 , 銑刀柄。
● UNIX 塗層。
DD Series for Deep Hole
● 10×D, 15×D, 20×D Cutting depth.
● Internal Coolant.
● 135° Tip Angle, Reinforced Shank.
● UNIX Coating.
● 10×D, 15×D, 20×D 加工深度。
● 冷卻方式 : 內冷孔。
● 135° 鑽尖 , 銑刀柄。
● UNIX 塗層。
DL Series for Mini Hole
● 3×D, 4×D Cutting depth.
● Internal & External Coolant.
●
130°, 140° Tip Angle, Reinforced Shank.
●
UNIX Coating.
● 3×D, 4×D 加工深度。
● 冷卻方式 : 內冷孔 & 外冷。
● 130°, 140° 鑽尖 , 銑刀柄。
● UNIX 塗層。
DM Series for Stainless Steel
● 3×D, 5×D Cutting depth.
● Internal Coolant.
● 140° Tip Angle, Reinforced Shank.
● UNIX Coating.
● 3×D, 5×D 加工深度。
● 冷卻方式 : 內冷孔。
● 140° 鑽尖 , 銑刀柄。
● UNIX 塗層。
DH Series for Hardened Steel
● 3×D, 5×D Cutting depth.
● Internal Coolant.
● 140° Tip Angle, Reinforced Shank.
● SINIX Coating.
● 3×D, 5×D 加工深度。
● 冷卻方式 : 內冷孔。
● 140° 鑽尖 , 銑刀柄。
● SINIX 塗層。
Holemaking Tools
Holemaking Tools
DR Series Machine Reamers
● Internal & External Coolant.
●
Specially for high accurate hole machining.
● UNIX Coating.
● Customized available.
● 冷卻方式 : 內冷孔 & 外冷。
● 專為高精度的孔加工設計。
● UNIX 塗層。
● 可客制化。
DWC Series Indexable Drills
● 2×D ~ 5×D Cutting depth.
● Diameter 14~60mm.
● Internal Coolant.
● Use WCMT insert.
● 2×D ~ 5×D 加工深度。
● 適用 14~60mm 孔徑加工。
● 冷卻方式 : 內冷孔。
● 使用 WCMT 刀片。
DZ Series for Step Hole
● Internal & External Coolant.
● Reinforced Shank.
● UNIX Coating.
● Customized available.
● 冷卻方式 : 內冷孔 & 外冷。
● 銑刀柄。
● UNIX 塗層。
● 可客制化。
DB Series Boring System
● Easy to adjust.
● High rigidity tool body.
● Various inserts available.
● Diameter 25mm to 610mm.
● 易於調整加工孔徑。
● 高剛性合金鋼本體。
● 可適用多種刀片。
● 適用 25-610mm 孔徑加工。
DSP Series Indexable Drills
● 2×D ~ 5×D Cutting depth.
● Diameter 12.5~50mm.
● Internal Coolant.
● Use SPMG insert.
● 2×D ~ 5×D 加工深度。
● 適用 12.5~50mm 孔徑加工。
● 冷卻方式 : 內冷孔。
● 使用 SPMG 刀片。
Holemaking Tools
Holemaking Tools
Appearance Items Series Coolant
ØRange
Degree Tip
Angle Page
Solid Carbide Drills
DP Series for Universal (Reinforced Shank)
DPC Solid Carbide Drills - 3×D (for Universal)
內冷泛用鎢鋼鑽頭 DPC Internal Ø3.17~Ø20 140 C006
DPC Solid Carbide Drills - 5×D (for Universal)
內冷泛用鎢鋼鑽頭 DPC Internal Ø3.17~Ø20 140 C008
DPC Solid Carbide Drills - 7×D (for Universal)
內冷泛用鎢鋼鑽頭 DPC Internal Ø4~Ø16 140 C010
DPN Solid Carbide Drills - 3×D (for Universal)
外冷泛用鎢鋼鑽頭 DPN External Ø3~Ø20 140 C011
DPN Solid Carbide Drills - 5×D (for Universal)
外冷泛用鎢鋼鑽頭 DPN External Ø3~Ø20 140 C013
DD Series for Deep Hole (Reinforced Shank)
DDC Solid Carbide Drills - 10×D (for Deep hole)
內冷深孔鎢鋼鑽頭 DDC Internal Ø3~Ø12 135 C016
DDC Solid Carbide Drills - 15×D (for Deep hole)
內冷深孔鎢鋼鑽頭 DDC Internal Ø3~Ø12 135 C017
DDC Solid Carbide Drills - 20×D (for Deep hole)
內冷深孔鎢鋼鑽頭 DDC Internal Ø3~Ø10 135 C018
DDC Solid Carbide Drills - 30×D (for Deep hole)
內冷深孔鎢鋼鑽頭 DDC Internal Ø3~Ø6 135 C019
DDC Solid Carbide Drills - 40×D (for Deep hole)
內冷深孔鎢鋼鑽頭 DDC Internal Ø3~Ø5 135 C020
DL Series for Mini Hole (Reinforced Shank)
DLC Solid Carbide Drills - 3~4×D (for Mini hole)
內冷小徑鎢鋼鑽頭 DLC Internal Ø2.0~Ø3.9 130, 140 C022
DLN Solid Carbide Drills - 3×D (for Mini hole)
外冷小徑鎢鋼鑽頭 DLN External Ø0.2~Ø2.9 130 C023
DM Series for Stainless Steel (Reinforced Shank)
DMC Solid Carbide Drills - 3×D (for Stainless Steel)
內冷不鏽鋼用鎢鋼鑽頭 DMC Internal Ø4~Ø20 140 C026
DMC Solid Carbide Drills - 5×D (for Stainless Steel)
內冷不鏽鋼用鎢鋼鑽頭 DMC Internal Ø4~Ø20 140 C028
DH Series for Hardened Steel (Reinforced Shank)
DHC Solid Carbide Drills - 3×D (for Hardened Steel)
內冷高硬用鎢鋼鑽頭 DHC Internal Ø4~Ø20 140 C032
DHC Solid Carbide Drills - 5×D (for Hardened Steel)
內冷高硬用鎢鋼鑽頭 DHC Internal Ø4~Ø20 140 C034
DHN Solid Carbide Drills - 3×D (for Hardened Steel)
外冷高硬用鎢鋼鑽頭 DHN External Ø4~Ø20 140 C036
DA Series for Straight Flute (with Straight Flute)
DAN Solid Carbide Drills - 3×D (with Straight Flute)
外冷直刃鑽鉸刀 DAN External Ø4~Ø16 130 C040
DAN Solid Carbide Drills - 5×D (with Straight Flute)
外冷直刃鑽鉸刀 DAN External Ø4~Ø16 130 C041
Index
C000
Holemaking Tools
Index
Appearance Items Series Coolant
ØRange
Degree Tip
Angle Page
DZ Series with for Step Hole (Reinforced Shank)
DZC Solid Carbide Drills (for Step hole)
內冷階梯鎢鋼鑽頭 DZC Internal Ø3.3~Ø8.5 140 C044
DZN Solid Carbide Drills (for Step hole)
外冷階梯鎢鋼鑽頭 DZN External Ø3.3~Ø8.5 140 C045
DF Series for General Purpose (with Flat Tip)
DFN Solid Carbide Drills - 3×D (with Flat Tip)
外冷平底鎢鋼鑽頭 DFN External Ø3~Ø20 180 C048
DG Series for General Purpose (Straight Shank)
DGN Solid Carbide Drills - 3×D (for General Purpose)
外冷泛用鎢鋼鑽頭 DGN External Ø2~Ø16 130 C052
DGN Solid Carbide Drills - 5×D (for General Purpose)
外冷泛用鎢鋼鑽頭 DGN External Ø5~Ø16 130 C054
DT Series for Spotting
DTN Solid Carbide Drills - Tip angle 90° (for Spotting)
外冷定點鎢鋼鑽頭 DTN External Ø1.3~Ø16 90 C056
DTN Solid Carbide Drills - Tip angle 120° (for Spotting)
外冷定點鎢鋼鑽頭 DTN External Ø3~Ø16 120 C057
DTN Solid Carbide Drills - Tip angle 140° (for Spotting)
外冷定點鎢鋼鑽頭 DTN External Ø3~Ø16 140 C060
DTN Solid Carbide Drills -
Tip angle 90°, Long shank (for Spotting)
外冷定點鎢鋼鑽頭 DTN External Ø4~Ø16 90 C058
DTN Solid Carbide Drills -
Tip angle 120°, Long shank (for Spotting)
外冷定點鎢鋼鑽頭 DTN External Ø4~Ø16 120 C059
DTN Solid Carbide Drills -
Tip angle 140°, Long shank (for Spotting)
外冷定點鎢鋼鑽頭 DTN External Ø4~Ø16 140 C060
DC Series for Centering
DCN Solid Carbide Drills - Countersink Angle 60° (for Centering)
外冷中心鎢鋼鑽頭 DCN External Ø1~Ø5 120 C062
DCN Solid Carbide Drills - Countersink Angle 90° (for Centering)
外冷中心鎢鋼鑽頭 DCN External Ø1~Ø5 120 C063
Solid Carbide Drills
C001
Drilling
Holemaking Tools
WCMT Inserts
WCMT 030208-MM
C068
040208-MM
050308-MM
06T308-MM
080412-MM
Appearance Item Code No. Coolant
ØRange
Page
DWC Indexable Drills
DWC Indexable Drills
- 2×D
內冷捨棄式快速鑽頭 IDWC
Internal
Ø14~Ø60 C078
DWC Indexable Drills
- 3×D
內冷捨棄式快速鑽頭 IDWC
Internal
Ø14~Ø60 C080
DWC Indexable Drills
- 4×D
內冷捨棄式快速鑽頭 IDWC
Internal
Ø14~Ø60 C082
DWC Indexable Drills
- 5×D
內冷捨棄式快速鑽頭 IDWC
Internal
Ø16~Ø44 C084
SPMG Inserts
SPMG 050204-MG
C067
060204-MG
07T308-MG
090408-MG
110408-MG
Indexable Drills
Appearance Item Code No. Coolant
ØRange
Page
DSP Indexable Drills
DSP Indexable Drills
- 2×D
內冷捨棄式快速鑽頭 IDSP
Internal
Ø12.5~Ø50 C070
DSP Indexable Drills
- 3×D
內冷捨棄式快速鑽頭 IDSP
Internal
Ø12.5~Ø50 C072
DSP Indexable Drills
- 4×D
內冷捨棄式快速鑽頭 IDSP
Internal
Ø12.5~Ø50 C074
DSP Indexable Drills
- 5×D
內冷捨棄式快速鑽頭 IDSP
Internal
Ø13~Ø44 C076
Index
Appearance Item Page
Appearance Item Page
C002
Holemaking Tools
Appearance Items Series Coolant
ØRange
Degree Tip
Angle Page
DR Series for Machine Reamers
DRC Solid Carbide Machine Reamers
內冷鎢鋼機械鉸刀 DRC Internal Ø3~Ø12 -C086
DRN Solid Carbide Machine Reamers
外冷鎢鋼機械鉸刀 DRN External Ø3~Ø12 -C087
Solid Carbide Reamers
Index
Appearance Item Page
CCMT Inserts
CCMT 060204-MP
C09009T304-MP
09T308-MP
CCMT 060202-MG
C090
060204-MG
09T304-MG
09T308-MG
120408-MG
SCMT Inserts
SCMT 09T304-MG
C09109T308-MG
TCMT Inserts
TCMT 110204-MP
C092
TCMT 110204-MG
C092
16T304-MG
16T308-MG
Boring System
C003
Drilling
Holemaking Tools
Index
Appearance Items Series Coolant
ØRange
Page
Boring System
DB Series for Boring System
DB Rough boring head
雙刃粗搪刀 DB External Ø25~Ø204 C093
DB Rough boring tool
雙刃粗搪刀含 BT 刀柄 DB External Ø25~Ø204 C094
DBLA Rough boring head for large hole
大徑雙刃粗搪刀 DBLA External Ø200~Ø610 C095
DBLA Rough boring tool for large hole
大徑雙刃粗搪刀含 BT 刀柄 DBLA External Ø200~Ø610 C096
DBBT series taper shank
DBBT 系列搪刀刀柄 DBBT - - C097
C004
Solid Carbide Drills
Drilling
C005
FEATURES
‧ 刀具剛性優異
‧高效能加工效率
‧ 提供客製化服務
‧適用於一般鋼料、不鏽鋼、鑄鐵
‧Superior Rigidity
‧High Cutting Performance
‧Customized Service
‧For Steel, Stainless steel, Cast iron
DPC, DPN Solid Carbide Drills (for Universal)
SPECS
‧UNIX Coating
‧140° TIP ANGLE
‧Reinfored Shank
內冷 & 外冷泛用鎢鋼鑽頭
Solid Carbide Drills
DPC Solid Carbide Drills - 3×D (for Universal)
C006
Order No. D L1 L Ds
DPC03170301 3.17(1/8") 20 60 4
DPC04000301 4.00 24 66 6
DPC04100301 4.10 24 66 6
DPC04200301 4.20 24 66 6
DPC04300301 4.30 24 66 6
DPC04400301 4.40 24 66 6
DPC04500301 4.50 24 66 6
DPC04600301 4.60 24 66 6
DPC04650301 4.65(13/71") 24 66 6
DPC04700301 4.70 24 66 6
DPC04760301 4.76(3/16") 2866 6
DPC04800301 4.80 28 66 6
DPC04900301 4.90 28 66 6
DPC05000301 5.00 28 66 6
DPC05100301 5.10 28 66 6
DPC05200301 5.20 28 66 6
DPC05300301 5.30 28 66 6
DPC05400301 5.40 28 66 6
DPC05500301 5.50 28 66 6
DPC05560301 5.56 28 66 6
DPC05600301 5.60 28 66 6
DPC05700301 5.70 28 66 6
DPC05800301 5.80 28 66 6
DPC05900301 5.90 28 66 6
DPC06000301 6.00 28 66 6
DPC06100301 6.10 34 79 8
DPC06200301 6.20 34 79 8
DPC06300301 6.30 34 79 8
DPC06350301 6.35(1/4") 34 79 8
DPC06400301 6.40 34 79 8
DPC06500301 6.50 34 79 8
DPC06600301 6.60 34 79 8
DPC06700301 6.70 34 79 8
DPC06800301 6.80 34 79 8
DPC06900301 6.90 34 79 8
DPC07000301 7.00 34 79 8
DPC07100301 7.10 41 79 8
DPC07200301 7.20 41 79 8
DPC07300301 7.30 41 79 8
DPC07400301 7.40 41 79 8
DPC07500301 7.50 41 79 8
DPC07600301 7.60 41 79 8
DPC07700301 7.70 41 79 8
DPC07800301 7.80 41 79 8
DPC07900301 7.90 41 79 8
DPC07940301 7.94(5/16) 41 79 8
Order No. D L1 L Ds
DPC08000301 8.00 41 79 8
DPC08100301 8.10 47 89 10
DPC08200301 8.20 47 89 10
DPC08300301 8.30 47 89 10
DPC08400301 8.40 47 89 10
DPC08500301 8.50 47 89 10
DPC08600301 8.60 47 89 10
DPC08700301 8.70 47 89 10
DPC08800301 8.80 47 89 10
DPC08900301 8.90 47 89 10
DPC09000301 9.00 47 89 10
DPC09100301 9.10 47 89 10
DPC09200301 9.20 47 89 10
DPC09250301 9.25(23/64") 47 89 10
DPC09300301 9.30 47 89 10
DPC09400301 9.40 47 89 10
DPC09500301 9.50 47 89 10
DPC09520301 9.52(3/8") 47 89 10
DPC09600301 9.60 47 89 10
DPC09700301 9.70 47 89 10
DPC09800301 9.80 47 89 10
DPC09900301 9.90 47 89 10
DPC10000301 10.00 47 89 10
DPC10100301 10.10 55 102 12
DPC10200301 10.20 55 102 12
DPC10300301 10.30 55 102 12
DPC10400301 10.40 55 102 12
DPC10500301 10.50 55 102 12
DPC10600301 10.60 55 102 12
DPC10700301 10.70 55 102 12
DPC10800301 10.80 55 102 12
DPC10900301 10.90 55 102 12
DPC11000301 11.00 55 102 12
DPC11100301 11.10 55 102 12
DPC11110301 11.11(7/16") 55 102 12
DPC11200301 11.20 55 102 12
DPC11300301 11.30 55 102 12
DPC11400301 11.40 55 102 12
DPC11500301 11.50 55 102 12
DPC11600301 11.60 55 102 12
DPC11700301 11.70 55 102 12
DPC11800301 11.80 55 102 12
DPC11900301 11.90 55 102 12
Unit:mm
P M K N S H
● ● ● ○
內冷泛用鎢鋼鑽頭
Product Specs
．3×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant ．UNIX Coating
．Tolerance h8 standard / m7 possible on request
．Double Margins Design
．SX Design
．For Steel, Alloy Steel, Cast Iron and 400 series Stainless Steel
.
Solid Carbide Drills
Drilling
DPC Solid Carbide Drills - 3×D (for Universal)
C007
Unit:mm
P M K N S H
● ● ● ○
Order No. D L1 L Ds
DPC12000301 12.00 55 102 12
DPC12100301 12.10 60 107 14
DPC12200301 12.20 60 107 14
DPC12300301 12.30 60 107 14
DPC12400301 12.40 60 107 14
DPC12500301 12.50 60 107 14
DPC12600301 12.60 60 107 14
DPC12700301 12.70(1/2") 60 107 14
DPC12800301 12.80 60 107 14
DPC12900301 12.90 60 107 14
DPC13000301 13.00 60 107 14
DPC13200301 13.20 60 107 14
DPC13300301 13.30 60 107 14
DPC13500301 13.50 60 107 14
DPC13700301 13.70 60 107 14
DPC13800301 13.80 60 107 14
DPC14000301 14.00 60 107 14
DPC14200301 14.20 65 115 16
DPC14290301 14.29(9/16") 65 115 16
DPC14300301 14.30 65 115 16
DPC14400301 14.40 65 115 16
DPC14500301 14.50 65 115 16
DPC14700301 14.70 65 115 16
DPC15000301 15.00 65 115 16
DPC15200301 15.20 65 115 16
DPC15500301 15.50 65 115 16
DPC15600301 15.60 65 115 16
DPC15700301 15.70 65 115 16
DPC15800301 15.80 65 115 16
DPC15870301 15.87(5/8") 65 115 16
DPC16000301 16.00 65 115 16
DPC16500301 16.50 73 123 18
DPC17000301 17.00 73 123 18
DPC17500301 17.50 73 123 18
DPC18000301 18.00 73 123 18
DPC18500301 18.50 79 131 20
DPC19000301 19.00 79 131 20
DPC19050301 19.05(3/4") 79 131 20
DPC19500301 19.50 79 131 20
DPC20000301 20.00 79 131 20
Order No. D L1 L Ds
內冷泛用鎢鋼鑽頭
Product Specs
．3×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant ．UNIX Coating
．Tolerance h8 standard / m7 possible on request
．Double Margins Design
．SX Design
．For Steel, Alloy Steel, Cast Iron and 400 series Stainless Steel
.
Solid Carbide Drills
DPC Solid Carbide Drills - 5×D (for Universal)
C008
Order No. D L1 L Ds
DPC03170501 3.17(1/8") 28 60 4
DPC04000501 4.00 36 74 6
DPC04100501 4.10 36 74 6
DPC04200501 4.20 36 74 6
DPC04300501 4.30 36 74 6
DPC04400501 4.40 36 74 6
DPC04500501 4.50 36 74 6
DPC04600501 4.60 36 74 6
DPC04650501 4.65(13/71") 36 74 6
DPC04700501 4.70 36 74 6
DPC04760501 4.76(3/16") 44 82 6
DPC04800501 4.80 44 82 6
DPC04900501 4.90 44 82 6
DPC05000501 5.00 44 82 6
DPC05100501 5.10 44 82 6
DPC05200501 5.20 44 82 6
DPC05300501 5.30 44 82 6
DPC05400501 5.40 44 82 6
DPC05500501 5.50 44 82 6
DPC05550501 5.55(7/32") 44 82 6
DPC05600501 5.60 44 82 6
DPC05700501 5.70 44 82 6
DPC05800501 5.80 44 82 6
DPC05900501 5.90 44 82 6
DPC06000501 6.00 44 82 6
DPC06100501 6.10 53 91 8
DPC06200501 6.20 53 91 8
DPC06300501 6.30 53 91 8
DPC06350501 6.35(1/4") 53 91 8
DPC06400501 6.40 53 91 8
DPC06500501 6.50 53 91 8
DPC06600501 6.60 53 91 8
DPC06700501 6.70 53 91 8
DPC06800501 6.80 53 91 8
DPC06900501 6.90 53 91 8
DPC07000501 7.00 53 91 8
DPC07100501 7.10 53 91 8
DPC07200501 7.20 53 91 8
DPC07300501 7.30 53 91 8
DPC07400501 7.40 53 91 8
DPC07500501 7.50 53 91 8
DPC07600501 7.60 53 91 8
DPC07700501 7.70 53 91 8
DPC07800501 7.80 53 91 8
DPC07900501 7.90 53 91 8
DPC07940501 7.94(5/16") 53 91 8
Order No. D L1 L Ds
DPC08000501 8.00 53 91 8
DPC08100501 8.10 61 103 10
DPC08200501 8.20 61 103 10
DPC08300501 8.30 61 103 10
DPC08400501 8.40 61 103 10
DPC08500501 8.50 61 103 10
DPC08600501 8.60 61 103 10
DPC08700501 8.70 61 103 10
DPC08800501 8.80 61 103 10
DPC08900501 8.90 61 103 10
DPC09000501 9.00 61 103 10
DPC09100501 9.10 61 103 10
DPC09200501 9.20 61 103 10
DPC09250501 9.25(23/64") 61 103 10
DPC09300501 9.30 61 103 10
DPC09400501 9.40 61 103 10
DPC09500501 9.50 61 103 10
DPC09520501 9.52(3/8") 61 103 10
DPC09600501 9.60 61 103 10
DPC09700501 9.70 61 103 10
DPC09800501 9.80 61 103 10
DPC09900501 9.90 61 103 10
DPC10000501 10.00 61 103 10
DPC10100501 10.10 71 118 12
DPC10200501 10.20 71 118 12
DPC10300501 10.30 71 118 12
DPC10400501 10.40 71 118 12
DPC10500501 10.50 71 118 12
DPC10600501 10.60 71 118 12
DPC10700501 10.70 71 118 12
DPC10800501 10.80 71 118 12
DPC10900501 10.90 71 118 12
DPC11000501 11.00 71 118 12
DPC11100501 11.10 71 118 12
DPC11110501 11.11(7/16") 71 118 12
DPC11200501 11.20 71 118 12
DPC11300501 11.30 71 118 12
DPC11400501 11.40 71 118 12
DPC11500501 11.50 71 118 12
DPC11600501 11.60 71 118 12
DPC11700501 11.70 71 118 12
DPC11800501 11.80 71 118 12
DPC11900501 11.90 71 118 12
Unit:mm
P M K N S H
● ● ● ○
內冷泛用鎢鋼鑽頭
Product Specs
．5×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant ．UNIX Coating
．Tolerance h8 standard / m7 possible on request
．Double Margins Design
．SX Design
．For Steel, Alloy Steel, Cast Iron and 400 series Stainless Steel
.
Solid Carbide Drills
Drilling
DPC Solid Carbide Drills - 5×D (for Universal)
Unit:mm
P M K N S H
● ● ● ○
Order No. D L1 L Ds
DPC12000501 12.00 71 118 12
DPC12100501 12.10 77 124 14
DPC12200501 12.20 77 124 14
DPC12300501 12.30 77 124 14
DPC12400501 12.40 77 124 14
DPC12500501 12.50 77 124 14
DPC12600501 12.60 77 124 14
DPC12700501 12.70(1/2") 77 124 14
DPC12800501 12.80 77 124 14
DPC12900501 12.90 77 124 14
DPC13000501 13.00 77 124 14
DPC13100501 13.10 77 124 14
DPC13300501 13.30 77 124 14
DPC13400501 13.40 77 124 14
DPC13500501 13.50 77 124 14
DPC13600501 13.60 77 124 14
DPC13700501 13.70 77 124 14
DPC13800501 13.80 77 124 14
DPC13900501 13.90 77 124 14
DPC14000501 14.00 77 124 14
DPC14100501 14.10 83 133 16
DPC14200501 14.20 83 133 16
DPC14290501 14.29(9/16") 83 133 16
DPC14300501 14.30 83 133 16
DPC14400501 14.40 83 133 16
DPC14500501 14.50 83 133 16
DPC14600501 14.60 83 133 16
DPC14700501 14.70 83 133 16
DPC14800501 14.80 83 133 16
DPC14900501 14.90 83 133 16
DPC15000501 15.00 83 133 16
DPC15100501 15.10 83 133 16
DPC15200501 15.20 83 133 16
DPC15300501 15.30 83 133 16
DPC15400501 15.40 83 133 16
DPC15500501 15.50 83 133 16
DPC15600501 15.60 83 133 16
DPC15700501 15.70 83 133 16
DPC15800501 15.80 83 133 16
DPC15870501 15.87(5/8") 83 133 16
DPC15900501 15.90 83 133 16
DPC16000501 16.00 83 133 16
DPC16500501 16.50 93 143 18
DPC17000501 17.00 93 143 18
DPC17500501 17.50 93 143 18
DPC18000501 18.00 93 143 18
DPC18500501 18.50 101 153 20
Order No. D L1 L Ds
DPC19000501 19.00 101 153 20
DPC19050501 19.05(3/4") 101 153 20
DPC19500501 19.50 101 153 20
DPC20000501 20.00 101 153 20
C009
內冷泛用鎢鋼鑽頭
Product Specs
．5×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant ．UNIX Coating
．Tolerance h8 standard / m7 possible on request
．Double Margins Design
．SX Design
．For Steel, Alloy Steel, Cast Iron and 400 series Stainless Steel
.
Solid Carbide Drills
Order No. D L1 L Ds
DPC04000701 4.00 40 75 6
DPC04100701 4.10 40 75 6
DPC04200701 4.20 40 75 6
DPC04300701 4.30 45 85 6
DPC04400701 4.40 45 85 6
DPC04500701 4.50 45 85 6
DPC04600701 4.60 45 85 6
DPC04650701 4.65(13/71") 45 85 6
DPC04700701 4.70 45 85 6
DPC04800701 4.80 50 90 6
DPC04900701 4.90 50 90 6
DPC05000701 5.00 50 90 6
DPC05100701 5.10 50 90 6
DPC05200701 5.20 50 90 6
DPC05300701 5.30 50 90 6
DPC05400701 5.40 57 97 6
DPC05500701 5.50 57 97 6
DPC05700701 5.70 57 97 6
DPC05800701 5.80 57 97 6
DPC05900701 5.90 57 97 6
DPC06000701 6.00 57 97 6
DPC06200701 6.20 66 106 8
DPC06300701 6.30 66 106 8
DPC06350701 6.35(1/4") 66 106 8
DPC06500701 6.50 66 106 8
DPC06600701 6.60 66 106 8
DPC06700701 6.70 66 106 8
DPC06800701 6.80 66 106 8
DPC06900701 6.90 76 116 8
DPC07000701 7.00 76 116 8
DPC07100701 7.10 76 116 8
DPC07200701 7.20 76 116 8
DPC07500701 7.50 76 116 8
DPC07600701 7.60 76 116 8
DPC07700701 7.70 76 116 8
DPC07800701 7.80 76 116 8
DPC08000701 8.00 76 116 8
DPC08100701 8.10 87 131 10
DPC08200701 8.20 87 131 10
DPC08400701 8.40 87 131 10
DPC08500701 8.50 87 131 10
DPC08600701 8.60 87 131 10
DPC08700701 8.70 87 131 10
DPC08800701 8.80 87 131 10
DPC08900701 8.90 87 131 10
Order No. D L1 L Ds
DPC09000701 9.00 95 139 10
DPC09100701 9.10 95 139 10
DPC09200701 9.20 95 139 10
DPC09300701 9.30 95 139 10
DPC09400701 9.40 95 139 10
DPC09500701 9.50 95 139 10
DPC09520701 9.52 95 139 10
DPC09700701 9.70 95 139 10
DPC09800701 9.80 95 139 10
DPC10000701 10.00 95 139 10
DPC10200701 10.20 106 155 12
DPC10300701 10.30 106 155 12
DPC10500701 10.50 106 155 12
DPC10720701 10.72(27/64") 106 155 12
DPC10800701 10.80 106 155 12
DPC11000701 11.00 106 155 12
DPC11200701 11.20 114 155 12
DPC11500701 11.50 114 155 12
DPC11800701 11.80 114 155 12
DPC12000701 12.00 114 155 12
DPC12100701 12.10 133 182 14
DPC12200701 12.20 133 182 14
DPC12300701 12.30 133 182 14
DPC12500701 12.50 133 182 14
DPC12700701 12.70 133 182 14
DPC13000701 13.00 133 182 14
DPC13500701 13.50 133 182 14
DPC14000701 14.00 133 182 14
DPC14100701 14.10 152 200 16
DPC14200701 14.20 152 200 16
DPC14500701 14.50 152 200 16
DPC15000701 15.00 152 200 16
DPC15500701 15.50 152 200 16
DPC15870701 15.87 152 200 16
DPC16000701 16.00 152 200 16
Unit:mm
P M K N S H
● ● ● ○
Product Specs
．7×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant ．UNIX Coating
．Tolerance h8 standard / m7 possible on request
．Double Margins Design
．SX Design
．For Steel, Alloy Steel, Cast Iron and 400 series Stainless Steel
.
C010
DPC Solid Carbide Drills - 7×D (for Universal) 內冷泛用鎢鋼鑽頭
Solid Carbide Drills
Drilling
DPN Solid Carbide Drills - 3×D (for Universal)
P M K N S H
●○●
Product Specs
．3×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．External Coolant
．UNIX Coating ．Tolerance h8 ．SX Design
．For Steel, Alloy Steel up to 1200 N/mm2, Cast Iron and 400 series Stainless Steel.
Order No. D L1 L Ds
DPN03000341 3.00 20 60 4
DPN03100341 3.10 20 60 4
DPN03170341 3.17(1/8") 20 60 4
DPN03200341 3.20 20 60 4
DPN03250341 3.25(5/39") 20 60 4
DPN03300341 3.30 20 60 4
DPN03400341 3.40 20 60 4
DPN03500341 3.50 20 60 4
DPN03600341 3.60 20 60 4
DPN03700341 3.70 20 60 4
DPN03800341 3.80 24 60 4
DPN03900341 3.90 24 60 4
DPN03970341 3.97(5/32") 24 60 4
DPN03000301 3.00 20 62 6
DPN03100301 3.10 20 62 6
DPN03200301 3.20 20 62 6
DPN03250301 3.25(5/39") 20 62 6
DPN03300301 3.30 20 62 6
DPN03400301 3.40 20 62 6
DPN03500301 3.50 20 62 6
DPN03600301 3.60 20 62 6
DPN03700301 3.70 20 62 6
DPN03800301 3.80 24 66 6
DPN03900301 3.90 24 66 6
DPN03970301 3.97(5/32") 24 66 6
DPN04000301 4.00 24 66 6
DPN04100301 4.10 24 66 6
DPN04200301 4.20 24 66 6
DPN04300301 4.30 24 66 6
DPN04400301 4.40 24 66 6
DPN04500301 4.50 24 66 6
DPN04600301 4.60 24 66 6
DPN04650301 4.65(13/71") 24 66 6
DPN04700301 4.70 24 66 6
DPN04760301 4.76(3/16") 2866 6
DPN04800301 4.80 28 66 6
DPN04900301 4.90 28 66 6
DPN05000301 5.00 28 66 6
DPN05100301 5.10 28 66 6
DPN05200301 5.20 28 66 6
DPN05300301 5.30 28 66 6
DPN05400301 5.40 28 66 6
DPN05500301 5.50 28 66 6
DPN05560301 5.56(7/32") 28 66 6
DPN05600301 5.60 28 66 6
DPN05700301 5.70 28 66 6
DPN05800301 5.80 28 66 6
DPN05900301 5.90 28 66 6
Order No. D L1 L Ds
DPN06000301 6.00 28 66 6
DPN06100301 6.10 34 79 8
DPN06200301 6.20 34 79 8
DPN06300301 6.30 34 79 8
DPN06350301 6.35(1/4") 34 79 8
DPN06400301 6.40 34 79 8
DPN06500301 6.50 34 79 8
DPN06600301 6.60 34 79 8
DPN06700301 6.70 34 79 8
DPN06800301 6.80 34 79 8
DPN06900301 6.90 34 79 8
DPN07000301 7.00 34 79 8
DPN07100301 7.10 41 79 8
DPN07200301 7.20 41 79 8
DPN07300301 7.30 41 79 8
DPN07400301 7.40 41 79 8
DPN07500301 7.50 41 79 8
DPN07600301 7.60 41 79 8
DPN07700301 7.70 41 79 8
DPN07800301 7.80 41 79 8
DPN07900301 7.90 41 79 8
DPN07940301 7.94(5/16") 41 79 8
DPN08000301 8.00 41 79 8
DPN08100301 8.10 47 89 10
DPN08200301 8.20 47 89 10
DPN08300301 8.30 47 89 10
DPN08400301 8.40 47 89 10
DPN08500301 8.50 47 89 10
DPN08600301 8.60 47 89 10
DPN08700301 8.70 47 89 10
DPN08800301 8.80 47 89 10
DPN08900301 8.90 47 89 10
DPN09000301 9.00 47 89 10
DPN09100301 9.10 47 89 10
DPN09200301 9.20 47 89 10
DPN09250301 9.25(23/64") 47 89 10
DPN09300301 9.30 47 89 10
DPN09400301 9.40 47 89 10
DPN09500301 9.50 47 89 10
DPN09520301 9.52(3/8") 47 89 10
DPN09600301 9.60 47 89 10
DPN09700301 9.70 47 89 10
DPN09800301 9.80 47 89 10
DPN09900301 9.90 47 89 10
Unit:mm
C011
外冷泛用鎢鋼鑽頭
Solid Carbide Drills
DPN Solid Carbide Drills - 3×D (for Universal)
P M K N S H
●○●
Unit:mm
Order No. D L1 L Ds
DPN10000301 10.00 47 89 10
DPN10100301 10.10 55 102 12
DPN10200301 10.20 55 102 12
DPN10300301 10.30 55 102 12
DPN10400301 10.40 55 102 12
DPN10500301 10.50 55 102 12
DPN10600301 10.60 55 102 12
DPN10700301 10.70 55 102 12
DPN10800301 10.80 55 102 12
DPN10900301 10.90 55 102 12
DPN11000301 11.00 55 102 12
DPN11100301 11.10 55 102 12
DPN11110301 11.11(7/16") 55 102 12
DPN11200301 11.20 55 102 12
DPN11300301 11.30 55 102 12
DPN11400301 11.40 55 102 12
DPN11500301 11.50 55 102 12
DPN11600301 11.60 55 102 12
DPN11700301 11.70 55 102 12
DPN11800301 11.80 55 102 12
DPN11900301 11.90 55 102 12
DPN12000301 12.00 55 102 12
DPN12100301 12.10 60 107 14
DPN12200301 12.20 60 107 14
DPN12300301 12.30 60 107 14
DPN12400301 12.40 60 107 14
DPN12500301 12.50 60 107 14
DPN12600301 12.60 60 107 14
DPN12700301 12.70(1/2") 60 107 14
DPN12800301 12.80 60 107 14
DPN12900301 12.90 60 107 14
DPN13000301 13.00 60 107 14
DPN13200301 13.20 60 107 14
DPN13300301 13.30 60 107 14
DPN13500301 13.50 60 107 14
DPN13700301 13.70 60 107 14
DPN13800301 13.80 60 107 14
DPN14000301 14.00 60 107 14
DPN14200301 14.20 65 115 16
DPN14290301 14.29(9/16") 65 115 16
DPN14300301 14.30 65 115 16
DPN14400301 14.40 65 115 16
DPN14500301 14.50 65 115 16
DPN14700301 14.70 65 115 16
Order No. D L1 L Ds
DPN15000301 15.00 65 115 16
DPN15200301 15.20 65 115 16
DPN15500301 15.50 65 115 16
DPN15600301 15.60 65 115 16
DPN15700301 15.70 65 115 16
DPN15800301 15.80 65 115 16
DPN15870301 15.87(5/8") 65 115 16
DPN16000301 16.00 65 115 16
DPN16500301 16.50 73 123 18
DPN17000301 17.00 73 123 18
DPN17500301 17.50 73 123 18
DPN18000301 18.00 73 123 18
DPN18500301 18.50 79 131 20
DPN19000301 19.00 79 131 20
DPN19050301 19.05(3/4") 79 131 20
DPN19500301 19.50 79 131 20
DPN20000301 20.00 79 131 20
Product Specs
．3×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．External Coolant
．UNIX Coating ．Tolerance h8 ．SX Design
．For Steel, Alloy Steel up to 1200 N/mm2, Cast Iron and 400 series Stainless Steel.
C012
外冷泛用鎢鋼鑽頭
Solid Carbide Drills
Drilling
DPN Solid Carbide Drills - 5×D (for Universal)
P M K N S H
●○●
Product Specs
．5×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．External Coolant
．UNIX Coating ．Tolerance h8 ．SX Design
．For Steel, Alloy Steel up to 1200 N/mm2, Cast Iron and 400 series Stainless Steel.
Order No. D L1 L Ds
DPN03000501 3.00 28 66 6
DPN03170501 3.17(1/8") 28 66 6
DPN03250501 3.30 28 66 6
DPN03300501 3.30 28 66 6
DPN03400501 3.40 28 66 6
DPN03500501 3.50 28 66 6
DPN03600501 3.60 28 66 6
DPN03700501 3.70 28 66 6
DPN03800501 3.80 36 74 6
DPN03970501 3.97(5/32") 36 74 6
DPN04000501 4.00 36 74 6
DPN04100501 4.10 36 74 6
DPN04200501 4.20 36 74 6
DPN04300501 4.30 36 74 6
DPN04400501 4.40 36 74 6
DPN04500501 4.50 36 74 6
DPN04600501 4.60 36 74 6
DPN04650501 4.65(13/71") 36 74 6
DPN04700501 4.70 36 74 6
DPN04760501 4.76(3/16") 44 82 6
DPN04800501 4.80 44 82 6
DPN04900501 4.90 44 82 6
DPN05000501 5.00 44 82 6
DPN05100501 5.10 44 82 6
DPN05200501 5.20 44 82 6
DPN05300501 5.30 44 82 6
DPN05400501 5.40 44 82 6
DPN05500501 5.50 44 82 6
DPN05560501 5.56(7/32") 44 82 6
DPN05600501 5.60 44 82 6
DPN05700501 5.70 44 82 6
DPN05800501 5.80 44 82 6
DPN05900501 5.90 44 82 6
DPN06000501 6.00 44 82 6
DPN06100501 6.10 53 91 8
DPN06200501 6.20 53 91 8
DPN06300501 6.30 53 91 8
DPN06350501 6.35(1/4") 53 91 8
DPN06400501 6.40 53 91 8
DPN06500501 6.50 53 91 8
DPN06600501 6.60 53 91 8
DPN06700501 6.70 53 91 8
DPN06800501 6.80 53 91 8
DPN06900501 6.90 53 91 8
Order No. D L1 L Ds
DPN07000501 7.00 53 91 8
DPN07100501 7.10 53 91 8
DPN07200501 7.20 53 91 8
DPN07300501 7.30 53 91 8
DPN07400501 7.40 53 91 8
DPN07500501 7.50 53 91 8
DPN07600501 7.60 53 91 8
DPN07700501 7.70 53 91 8
DPN07800501 7.80 53 91 8
DPN07900501 7.90 53 91 8
DPN07940501 7.94(5/16") 53 91 8
DPN08000501 8.00 53 91 8
DPN08100501 8.10 61 103 10
DPN08200501 8.20 61 103 10
DPN08300501 8.30 61 103 10
DPN08400501 8.40 61 103 10
DPN08500501 8.50 61 103 10
DPN08600501 8.60 61 103 10
DPN08700501 8.70 61 103 10
DPN08800501 8.80 61 103 10
DPN08900501 8.90 61 103 10
DPN09000501 9.00 61 103 10
DPN09100501 9.10 61 103 10
DPN09200501 9.20 61 103 10
DPN09250501 9.25(23/64") 61 103 10
DPN09300501 9.30 61 103 10
DPN09400501 9.40 61 103 10
DPN09500501 9.50 61 103 10
DPN09520501 9.52(3/8") 61 103 10
DPN09600501 9.60 61 103 10
DPN09700501 9.70 61 103 10
DPN09800501 9.80 61 103 10
DPN09900501 9.90 61 103 10
DPN10000501 10.00 61 103 10
DPN10100501 10.10 71 118 12
DPN10200501 10.20 71 118 12
DPN10300501 10.30 71 118 12
DPN10400501 10.40 71 118 12
DPN10500501 10.50 71 118 12
DPN10600501 10.60 71 118 12
DPN10700501 10.70 71 118 12
DPN10800501 10.80 71 118 12
DPN10900501 10.90 71 118 12
Unit:mm
C013
外冷泛用鎢鋼鑽頭
Solid Carbide Drills
DPN Solid Carbide Drills - 5×D (for Universal)
P M K N S H
●○●
Unit:mm
Order No. D L1 L Ds
DPN11000501 11.00 71 118 12
DPN11100501 11.10 71 118 12
DPN11110501 11.11(7/16") 71 118 12
DPN11200501 11.20 71 118 12
DPN11300501 11.30 71 118 12
DPN11400501 11.40 71 118 12
DPN11500501 11.50 71 118 12
DPN11600501 11.60 71 118 12
DPN11700501 11.70 71 118 12
DPN11800501 11.80 71 118 12
DPN11900501 11.90 71 118 12
DPN12000501 12.00 71 118 12
DPN12100501 12.10 77 124 14
DPN12200501 12.20 77 124 14
DPN12300501 12.30 77 124 14
DPN12400501 12.40 77 124 14
DPN12500501 12.50 77 124 14
DPN12600501 12.60 77 124 14
DPN12700501 12.70(1/2") 77 124 14
DPN12800501 12.80 77 124 14
DPN12900501 12.90 77 124 14
DPN13000501 13.00 77 124 14
DPN13100501 13.10 77 124 14
DPN13300501 13.30 77 124 14
DPN13400501 13.40 77 124 14
DPN13500501 13.50 77 124 14
DPN13600501 13.60 77 124 14
DPN13700501 13.70 77 124 14
DPN13800501 13.80 77 124 14
DPN13900501 13.90 77 124 14
DPN14000501 14.00 77 124 14
DPN14100501 14.10 83 133 16
DPN14200501 14.20 83 133 16
DPN14290501 14.29(9/16") 83 133 16
DPN14300501 14.30 83 133 16
DPN14400501 14.40 83 133 16
DPN14500501 14.50 83 133 16
DPN14600501 14.60 83 133 16
DPN14700501 14.70 83 133 16
DPN14800501 14.80 83 133 16
DPN14900501 14.90 83 133 16
Order No. D L1 L Ds
DPN15000501 15.00 83 133 16
DPN15100501 15.10 83 133 16
DPN15200501 15.20 83 133 16
DPN15300501 15.30 83 133 16
DPN15400501 15.40 83 133 16
DPN15500501 15.50 83 133 16
DPN15600501 15.60 83 133 16
DPN15700501 15.70 83 133 16
DPN15800501 15.80 83 133 16
DPN15870501 15.87(5/8") 83 133 16
DPN15900501 15.90 83 133 16
DPN16000501 16.00 83 133 16
DPN16500501 16.50 93 143 18
DPN17000501 17.00 93 143 18
DPN17500501 17.50 93 143 18
DPN18000501 18.00 93 143 18
DPN18500501 18.50 101 153 20
DPN19000501 19.00 101 153 20
DPN19050501 19.05(3/4") 101 153 20
DPN19500501 19.50 101 153 20
DPN20000501 20.00 101 153 20
Product Specs
．5×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．External Coolant
．UNIX Coating ．Tolerance h8 ．SX Design
．For Steel, Alloy Steel up to 1200 N/mm2, Cast Iron and 400 series Stainless Steel.
C014
外冷泛用鎢鋼鑽頭
Solid Carbide Drills
Drilling
DDC Solid Carbide Drills (for Deep Hole)
C015
‧ 優異的孔壁品質
‧更長的刀具壽命
‧ 最佳化的幾何設計
‧提供客製化服務
‧10xD 到40xD 鑽削深度
FEATURES
‧Excellent hole surface quality
‧Unique UNIX coating improves tool life
‧Optimized geometry improves working eciency
‧Customized available
‧10xD to 40xD Cutting Depth
High Performance
High Rigidity
內冷深孔鎢鋼鑽頭
Solid Carbide Drills
DDC Solid Carbide Drills - 10×D (for Deep Hole)
C016
P M K N S H
●●●○○○
Product Specs
．10×D Cutting depth ．Reinforced Shank ．135° Tip Angle ．Internal Coolant
．UNIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Steel, Alloy Steel, Stainless Steel and Cast Iron.
※DDC drills require an initial pilot hole to guide the drill.
Order No. D L1 L Ds
DDC03001001 3.00 48 100 4
DDC03501001 3.50 48 100 4
DDC04001001 4.00 48 100 4
DDC04501001 4.50 72 125 6
DDC05001001 5.00 72 125 6
DDC05501001 5.50 72 125 6
DDC06001001 6.00 72 125 6
DDC06501001 6.50 96 150 8
DDC07001001 7.00 96 150 8
DDC07501001 7.50 96 150 8
DDC08001001 8.00 96 150 8
DDC08501001 8.50 120 175 10
DDC09001001 9.00 120 175 10
DDC09501001 9.50 120 175 10
DDC10001001 10.00 120 175 10
DDC11001001 11.00 132 200 12
DDC12001001 12.00 144 200 12
Order No. D L1 L Ds
Unit:mm
內冷深孔鎢鋼鑽頭
Solid Carbide Drills
Drilling
DDC Solid Carbide Drills - 15×D (for Deep Hole)
C017
P M K N S H
●●●○○○
Product Specs
．15×D Cutting depth ．Reinforced Shank ．135° Tip Angle ．Internal Coolant
．UNIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Steel, Alloy Steel, Stainless Steel and Cast Iron.
※DDC drills require an initial pilot hole to guide the drill.
Unit:mm
Order No. D L1 L Ds
DDC03001501 3.00 55 95 3
DDC03501501 3.50 76 116 4
DDC04001501 4.00 76 116 4
DDC04501501 4.50 93 133 6
DDC05001501 5.00 93 133 6
DDC05501501 5.50 110 150 6
DDC06001501 6.00 110 150 6
DDC06501501 6.50 127 167 8
DDC07001501 7.00 127 167 8
DDC07501501 7.50 143 183 8
DDC08001501 8.00 143 183 8
DDC08501501 8.50 160 204 10
DDC09001501 9.00 160 204 10
DDC09501501 9.50 177 221 10
DDC10001501 10.00 177 221 10
DDC11001501 11.00 198 247 12
DDC12001501 12.00 214 263 12
Order No. D L1 L Ds
內冷深孔鎢鋼鑽頭
Solid Carbide Drills
C018
P M K N S H
●●●○○○
Product Specs
．20×D Cutting depth ．Reinforced Shank ．135° Tip Angle ．Internal Coolant
．UNIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Steel, Alloy Steel, Stainless Steel and Cast Iron.
※DDC drills require an initial pilot hole to guide the drill.
Unit:mm
Order No. D L1 L DsOrder No. D L1 L Ds
DDC03002001 3.00 70 110 3
DDC03502001 3.50 83 123 4
DDC04002001 4.00 96 136 4
DDC04502001 4.50 118 158 6
DDC05002001 5.00 118 158 6
DDC05502001 5.50 140 180 6
DDC06002001 6.00 140 180 6
DDC06502001 6.50 162 202 8
DDC07002001 7.00 162 202 8
DDC07502001 7.50 183 223 8
DDC08002001 8.00 183 223 8
DDC08502001 8.50 205 249 10
DDC09002001 9.00 205 249 10
DDC09502001 9.50 227 271 10
DDC10002001 10.00 227 271 10
DDC Solid Carbide Drills - 20×D (for Deep Hole) 內冷深孔鎢鋼鑽頭
Solid Carbide Drills
Drilling
DDC Solid Carbide Drills - 30×D (for Deep Hole)
C019
P M K N S H
●●●○○○
Product Specs
．30×D Cutting depth ．Reinforced Shank ．135° Tip Angle ．Internal Coolant
．UNIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Steel, Alloy Steel, Stainless Steel and Cast Iron.
※DDC drills require an initial pilot hole to guide the drill.
Unit:mm
Order No. D L1 L DsOrder No. D L1 L Ds
DDC03003001 3.00 100 140 3
DDC03503001 3.50 136 176 4
DDC04003001 4.00 136 176 6
DDC04503001 4.50 168 208 6
DDC05003001 5.00 168 208 6
DDC05503001 5.50 200 240 6
DDC06003001 6.00 200 240 6
內冷深孔鎢鋼鑽頭
Solid Carbide Drills
DDC Solid Carbide Drills - 40×D (for Deep Hole)
C020
P M K N S H
●●●○○○
Product Specs
．40×D Cutting depth ．Reinforced Shank ．135° Tip Angle ．Internal Coolant
．UNIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Steel, Alloy Steel, Stainless Steel and Cast Iron.
※DDC drills require an initial pilot hole to guide the drill.
Unit:mm
Order No. D L1 L DsOrder No. D L1 L Ds
DDC03004001 3.00 130 170 3
DDC03504001 3.50 153 193 4
DDC04004001 4.00 176 216 4
DDC04504001 4.50 198 238 6
DDC05004001 5.00 218 258 6
內冷深孔鎢鋼鑽頭
Solid Carbide Drills
Drilling
DLC, DLN Solid Carbide Drills (for Mini Hole)
C021
FEATURES
‧ 高效內冷孔
‧ UNIX 鍍膜提升刀具壽命
‧優化排屑槽，提升刀具效能與壽命
‧提供客製化服務
‧尺寸範圍 0.2-3.9mm
‧Internal coolant design
‧Unique UNIX coating improves tool life
‧Optimized ute improves drilling eciency
‧Customized available
‧Diameter 0.2-3.9mm
High Performance
Hight Productivity
Hight Stability
內冷 & 外冷小徑鎢鋼鑽頭
Solid Carbide Drills
DLC Solid Carbide Drills - 3~4×D (for Mini hole)
P M K N S H
●●●
Product Specs
．3~4×D Cutting depth ．Reinforced Shank ．130°, 140° Tip Angle ．Internal Coolant
．UNIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Alloy Steel, Stainless Steel and Cast Iron.
Order No. D L1 L Ds
DLC02000301 2.00 12 50 3
DLC02100301 2.10 12 50 3
DLC02200301 2.20 12 50 3
DLC02300301 2.30 12 50 3
DLC02400301 2.40 16 50 3
DLC02500301 2.50 16 50 3
DLC02600301 2.60 16 50 3
DLC02700301 2.70 16 50 3
DLC02800301 2.80 16 50 3
DLC02900301 2.90 16 50 3
DLC03000301 3.00 20 60 4
DLC03100301 3.10 20 60 4
DLC03200301 3.20 20 60 4
DLC03300301 3.30 20 60 4
DLC03400301 3.40 20 60 4
DLC03500301 3.50 20 60 4
DLC03600301 3.60 20 60 4
DLC03700301 3.70 20 60 4
DLC03800301 3.80 24 60 4
DLC03900301 3.90 24 60 4
Order No. D L1 L Ds
Unit:mm
C022
內冷小徑鎢鋼鑽頭
Solid Carbide Drills
Drilling
DLN Solid Carbide Drills - 3×D (for Mini hole)
P M K N S H
●○●
Product Specs
．3×D Cutting depth ．Reinforced Shank ．130° Tip Angle ．External Coolant
．UNIX Coating ．Tolerance h8 ．NX Design
．For Alloy Steel and Cast Iron.
Order No. D L1 L Ds
DLN00200301 0.20 3 38 3
DLN00300301 0.30 3 38 3
DLN00400301 0.40 3 38 3
DLN00500301 0.50 3 38 3
DLN00600301 0.60 3 38 3
DLN00700301 0.70 3 38 3
DLN00800301 0.80 4 38 3
DLN00900301 0.90 4 38 3
DLN01000301 1.00 4 38 3
DLN01100301 1.10 6 38 3
DLN01200301 1.20 6 38 3
DLN01300301 1.30 6 38 3
DLN01400301 1.40 6 38 3
DLN01500301 1.50 6 38 3
DLN01600301 1.60 8 38 3
DLN01700301 1.70 8 38 3
DLN01800301 1.80 8 38 3
DLN01900301 1.90 8 38 3
DLN02000301 2.00 8 38 3
DLN02100301 2.10 8 38 3
DLN02200301 2.20 8 38 3
DLN02300301 2.30 8 38 3
DLN02400301 2.40 8 38 3
DLN02500301 2.50 8 38 3
DLN02600301 2.60 8 38 3
DLN02700301 2.70 8 38 3
DLN02800301 2.80 8 38 3
DLN02900301 2.90 8 38 3
Order No. D L1 L Ds
Unit:mm
C023
外冷小徑鎢鋼鑽頭
C024
Endmills．Inserts．Drills
Solid Carbide Drills
Drilling
DMC Solid Carbide Drills (for Stainless Steel)
C025
FEATURES
High Performance
Excellent Tool Life
‧ 內冷孔設計
‧高效能不鏽鋼、鈦金屬專用幾何
‧高耐久 UNIX 鍍膜適用難切削材質加工
‧提供客製化服務
‧Internal coolant
‧
High performance geometry design for stainless steel drilling and titanium drilling
‧Durable UNIX coating suitable to dicult-to-process material
‧Customized available
內冷不銹鋼用鎢鋼鑽頭
Solid Carbide Drills
DMC Solid Carbide Drills - 3×D (for Stainless Steel)
P M K N S H
●●●●●
Order No. D L1 L Ds
DMC04000301 4.00 24 66 6
DMC04100301 4.10 24 66 6
DMC04200301 4.20 24 66 6
DMC04300301 4.30 24 66 6
DMC04400301 4.40 24 66 6
DMC04500301 4.50 24 66 6
DMC04600301 4.60 24 66 6
DMC04650301 4.65(13/71") 24 66 6
DMC04700301 4.70 24 66 6
DMC04800301 4.80 28 66 6
DMC04900301 4.90 28 66 6
DMC05000301 5.00 28 66 6
DMC05100301 5.10 28 66 6
DMC05200301 5.20 28 66 6
DMC05300301 5.30 28 66 6
DMC05400301 5.40 28 66 6
DMC05500301 5.50 28 66 6
DMC05560301 5.56 28 66 6
DMC05600301 5.60 28 66 6
DMC05700301 5.70 28 66 6
DMC05800301 5.80 28 66 6
DMC05900301 5.90 28 66 6
DMC06000301 6.00 28 66 6
DMC06100301 6.10 34 79 8
DMC06200301 6.20 34 79 8
DMC06300301 6.30 34 79 8
DMC06350301 6.35(1/4") 34 79 8
DMC06400301 6.40 34 79 8
DMC06500301 6.50 34 79 8
DMC06600301 6.60 34 79 8
DMC06700301 6.70 34 79 8
DMC06800301 6.80 34 79 8
DMC06900301 6.90 34 79 8
DMC07000301 7.00 34 79 8
DMC07100301 7.10 41 79 8
DMC07200301 7.20 41 79 8
DMC07300301 7.30 41 79 8
DMC07400301 7.40 41 79 8
DMC07500301 7.50 41 79 8
DMC07600301 7.60 41 79 8
DMC07700301 7.70 41 79 8
DMC07800301 7.80 41 79 8
DMC07900301 7.90 41 79 8
Order No. D L1 L Ds
DMC08000301 8.00 41 79 8
DMC08100301 8.10 47 89 10
DMC08200301 8.20 47 89 10
DMC08300301 8.30 47 89 10
DMC08400301 8.40 47 89 10
DMC08500301 8.50 47 89 10
DMC08600301 8.60 47 89 10
DMC08700301 8.70 47 89 10
DMC08800301 8.80 47 89 10
DMC08900301 8.90 47 89 10
DMC09000301 9.00 47 89 10
DMC09100301 9.10 47 89 10
DMC09200301 9.20 47 89 10
DMC09250301 9.25(23/64") 47 89 10
DMC09300301 9.30 47 89 10
DMC09400301 9.40 47 89 10
DMC09500301 9.50 47 89 10
DMC09600301 9.60 47 89 10
DMC09700301 9.70 47 89 10
DMC09800301 9.80 47 89 10
DMC09900301 9.90 47 89 10
DMC10000301 10.00 47 89 10
DMC10100301 10.10 55 102 12
DMC10200301 10.20 55 102 12
DMC10300301 10.30 55 102 12
DMC10400301 10.40 55 102 12
DMC10500301 10.50 55 102 12
DMC10600301 10.60 55 102 12
DMC10700301 10.70 55 102 12
DMC10800301 10.80 55 102 12
DMC10900301 10.90 55 102 12
DMC11000301 11.00 55 102 12
DMC11100301 11.10 55 102 12
DMC11200301 11.20 55 102 12
DMC11300301 11.30 55 102 12
DMC11400301 11.40 55 102 12
DMC11500301 11.50 55 102 12
DMC11600301 11.60 55 102 12
DMC11700301 11.70 55 102 12
DMC11800301 11.80 55 102 12
DMC11900301 11.90 55 102 12
Unit:mm
Product Specs
．3×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant
．UNIX Coating ．Tolerance h8 ．Double Margins Design ．SR Design
．For Steel, Alloy Steel, Stainless Steel, Cast Iron, Non-ferrous metal, Aluminum and Titanium.
C026
內冷不銹鋼用鎢鋼鑽頭
Solid Carbide Drills
Drilling
DMC Solid Carbide Drills - 3×D (for Stainless Steel)
P M K N S H
●●●●●
Unit:mm
Product Specs
．3×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant
．UNIX Coating ．Tolerance h8 ．Double Margins Design ．SR Design
．For Steel, Alloy Steel, Stainless Steel, Cast Iron, Non-ferrous metal, Aluminum and Titanium.
Order No. D L1 L Ds
DMC12000301 12.00 55 102 12
DMC12100301 12.10 60 107 14
DMC12200301 12.20 60 107 14
DMC12300301 12.30 60 107 14
DMC12400301 12.40 60 107 14
DMC12500301 12.50 60 107 14
DMC12600301 12.60 60 107 14
DMC12700301 12.70 60 107 14
DMC12800301 12.80 60 107 14
DMC12900301 12.90 60 107 14
DMC13000301 13.00 60 107 14
DMC13200301 13.20 60 107 14
DMC13300301 13.30 60 107 14
DMC13500301 13.50 60 107 14
DMC13700301 13.70 60 107 14
DMC13800301 13.80 60 107 14
DMC14000301 14.00 60 107 14
DMC14200301 14.20 65 115 16
DMC14300301 14.30 65 115 16
DMC14400301 14.40 65 115 16
DMC14500301 14.50 65 115 16
DMC14700301 14.70 65 115 16
DMC15000301 15.00 65 115 16
DMC15200301 15.20 65 115 16
DMC15500301 15.50 65 115 16
DMC15600301 15.60 65 115 16
DMC15700301 15.70 65 115 16
DMC15800301 15.80 65 115 16
DMC16000301 16.00 65 115 16
DMC16500301 16.50 73 123 18
DMC17000301 17.00 73 123 18
DMC17500301 17.50 73 123 18
DMC18000301 18.00 73 123 18
DMC18500301 18.50 79 131 20
DMC19000301 19.00 79 131 20
DMC19500301 19.50 79 131 20
DMC20000301 20.00 79 131 20
Order No. D L1 L Ds
C027
內冷不銹鋼用鎢鋼鑽頭
Solid Carbide Drills
DMC Solid Carbide Drills - 5×D (for Stainless Steel)
P M K N S H
●●●●●
Product Specs
．5×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant
．UNIX Coating ．Tolerance h8 ．Double Margins Design ．SR Design
．For Steel, Alloy Steel, Stainless Steel, Cast Iron, Non-ferrous metal, Aluminum and Titanium.
Order No. D L1 L Ds
DMC04000501 4.00 36 74 6
DMC04100501 4.10 36 74 6
DMC04200501 4.20 36 74 6
DMC04300501 4.30 36 74 6
DMC04400501 4.40 36 74 6
DMC04500501 4.50 36 74 6
DMC04600501 4.60 36 74 6
DMC04650501 4.65(13/71") 36 74 6
DMC04700501 4.70 36 74 6
DMC04800501 4.80 44 82 6
DMC04900501 4.90 44 82 6
DMC05000501 5.00 44 82 6
DMC05100501 5.10 44 82 6
DMC05200501 5.20 44 82 6
DMC05300501 5.30 44 82 6
DMC05400501 5.40 44 82 6
DMC05500501 5.50 44 82 6
DMC05550501 5.55(7/32") 44 82 6
DMC05600501 5.60 44 82 6
DMC05700501 5.70 44 82 6
DMC05800501 5.80 44 82 6
DMC05900501 5.90 44 82 6
DMC06000501 6.00 44 82 6
DMC06100501 6.10 53 91 8
DMC06200501 6.20 53 91 8
DMC06300501 6.30 53 91 8
DMC06400501 6.40 53 91 8
DMC06500501 6.50 53 91 8
DMC06600501 6.60 53 91 8
DMC06700501 6.70 53 91 8
DMC06800501 6.80 53 91 8
DMC06900501 6.90 53 91 8
DMC07000501 7.00 53 91 8
DMC07100501 7.10 53 91 8
DMC07200501 7.20 53 91 8
DMC07300501 7.30 53 91 8
DMC07400501 7.40 53 91 8
DMC07500501 7.50 53 91 8
DMC07600501 7.60 53 91 8
DMC07700501 7.70 53 91 8
DMC07800501 7.80 53 91 8
DMC07900501 7.90 53 91 8
Order No. D L1 L Ds
DMC08000501 8.00 53 91 8
DMC08100501 8.10 61 103 10
DMC08200501 8.20 61 103 10
DMC08300501 8.30 61 103 10
DMC08400501 8.40 61 103 10
DMC08500501 8.50 61 103 10
DMC08600501 8.60 61 103 10
DMC08700501 8.70 61 103 10
DMC08800501 8.80 61 103 10
DMC08900501 8.90 61 103 10
DMC09000501 9.00 61 103 10
DMC09100501 9.10 61 103 10
DMC09200501 9.20 61 103 10
DMC09250501 9.25(23/64") 61 103 10
DMC09300501 9.30 61 103 10
DMC09400501 9.40 61 103 10
DMC09500501 9.50 61 103 10
DMC09600501 9.60 61 103 10
DMC09700501 9.70 61 103 10
DMC09800501 9.80 61 103 10
DMC09900501 9.90 61 103 10
DMC10000501 10.00 61 103 10
DMC10100501 10.10 71 118 12
DMC10200501 10.20 71 118 12
DMC10300501 10.30 71 118 12
DMC10400501 10.40 71 118 12
DMC10500501 10.50 71 118 12
DMC10600501 10.60 71 118 12
DMC10700501 10.70 71 118 12
DMC10800501 10.80 71 118 12
DMC10900501 10.90 71 118 12
DMC11000501 11.00 71 118 12
DMC11100501 11.10 71 118 12
DMC11200501 11.20 71 118 12
DMC11300501 11.30 71 118 12
DMC11400501 11.40 71 118 12
DMC11500501 11.50 71 118 12
DMC11600501 11.60 71 118 12
DMC11700501 11.70 71 118 12
DMC11800501 11.80 71 118 12
DMC11900501 11.90 71 118 12
Unit:mm
C028
內冷不銹鋼用鎢鋼鑽頭
Solid Carbide Drills
Drilling
DMC Solid Carbide Drills - 5×D (for Stainless Steel)
P M K N S H
●●●●●
Product Specs
．5×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant
．UNIX Coating ．Tolerance h8 ．Double Margins Design ．SR Design
．For Steel, Alloy Steel, Stainless Steel, Cast Iron, Non-ferrous metal, Aluminum and Titanium.
Unit:mm
Order No. D L1 L Ds
DMC12000501 12.00 71 118 12
DMC12100501 12.10 77 124 14
DMC12200501 12.20 77 124 14
DMC12300501 12.30 77 124 14
DMC12400501 12.40 77 124 14
DMC12500501 12.50 77 124 14
DMC12600501 12.60 77 124 14
DMC12700501 12.70 77 124 14
DMC12800501 12.80 77 124 14
DMC12900501 12.90 77 124 14
DMC13000501 13.00 77 124 14
DMC13100501 13.10 77 124 14
DMC13300501 13.30 77 124 14
DMC13400501 13.40 77 124 14
DMC13500501 13.50 77 124 14
DMC13600501 13.60 77 124 14
DMC13700501 13.70 77 124 14
DMC13800501 13.80 77 124 14
DMC13900501 13.90 77 124 14
DMC14000501 14.00 77 124 14
DMC14100501 14.10 83 133 16
DMC14200501 14.20 83 133 16
DMC14300501 14.30 83 133 16
DMC14400501 14.40 83 133 16
DMC14500501 14.50 83 133 16
DMC14600501 14.60 83 133 16
DMC14700501 14.70 83 133 16
DMC14800501 14.80 83 133 16
DMC14900501 14.90 83 133 16
DMC15000501 15.00 83 133 16
DMC15100501 15.10 83 133 16
DMC15200501 15.20 83 133 16
DMC15300501 15.30 83 133 16
DMC15400501 15.40 83 133 16
DMC15500501 15.50 83 133 16
DMC15600501 15.60 83 133 16
DMC15700501 15.70 83 133 16
DMC15800501 15.80 83 133 16
DMC15900501 15.90 83 133 16
DMC16000501 16.00 83 133 16
DMC16500501 16.50 93 143 18
DMC17000501 17.00 93 143 18
DMC17500501 17.50 93 143 18
DMC18000501 18.00 93 143 18
DMC18500501 18.50 101 153 20
DMC19000501 19.00 101 153 20
DMC19500501 19.50 101 153 20
DMC20000501 20.00 101 153 20
Order No. D L1 L Ds
C029
內冷不銹鋼用鎢鋼鑽頭
C030
Endmills．Inserts．Drills
Solid Carbide Drills
Drilling
DHC, DHN Solid Carbide Drills (for Hardened Steel)
C031
FEATURES
‧高剛性刀口幾何，專為高硬度材質加工設計
‧特殊 SINIX 鍍膜，高效抗磨損
‧ 內冷孔設計，更有效提升刀具壽命
‧High rigidity cutting design for hardened material
‧Unique SINIX coating for wear resistance
‧Internal coolant design to increase tool life
內冷 & 外冷高硬用鎢鋼鑽頭
Solid Carbide Drills
DHC Solid Carbide Drills - 3×D (for Hardened Steel)
P M K N S H
○○● ○●
Product Specs
．3×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant
．SINIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Steel, Alloy Steel, Cast Iron and Hardened Steel(HRC 30~50).
Order No. D L1 L Ds
DHC04000302 4.00 24 66 6
DHC04100302 4.10 24 66 6
DHC04200302 4.20 24 66 6
DHC04300302 4.30 24 66 6
DHC04400302 4.40 24 66 6
DHC04500302 4.50 24 66 6
DHC04600302 4.60 24 66 6
DHC04650302 4.65(13/71") 24 66 6
DHC04700302 4.70 24 66 6
DHC04800302 4.80 28 66 6
DHC04900302 4.90 28 66 6
DHC05000302 5.00 28 66 6
DHC05100302 5.10 28 66 6
DHC05200302 5.20 28 66 6
DHC05300302 5.30 28 66 6
DHC05400302 5.40 28 66 6
DHC05500302 5.50 28 66 6
DHC05560302 5.56 28 66 6
DHC05600302 5.60 28 66 6
DHC05700302 5.70 28 66 6
DHC05800302 5.80 28 66 6
DHC05900302 5.90 28 66 6
DHC06000302 6.00 28 66 6
DHC06100302 6.10 34 79 8
DHC06200302 6.20 34 79 8
DHC06300302 6.30 34 79 8
DHC06350302 6.35(1/4") 34 79 8
DHC06400302 6.40 34 79 8
DHC06500302 6.50 34 79 8
DHC06600302 6.60 34 79 8
DHC06700302 6.70 34 79 8
DHC06800302 6.80 34 79 8
DHC06900302 6.90 34 79 8
DHC07000302 7.00 34 79 8
DHC07100302 7.10 41 79 8
DHC07200302 7.20 41 79 8
DHC07300302 7.30 41 79 8
DHC07400302 7.40 41 79 8
DHC07500302 7.50 41 79 8
DHC07600302 7.60 41 79 8
DHC07700302 7.70 41 79 8
DHC07800302 7.80 41 79 8
DHC07900302 7.90 41 79 8
Order No. D L1 L Ds
DHC08000302 8.00 41 79 8
DHC08100302 8.10 47 89 10
DHC08200302 8.20 47 89 10
DHC08300302 8.30 47 89 10
DHC08400302 8.40 47 89 10
DHC08500302 8.50 47 89 10
DHC08600302 8.60 47 89 10
DHC08700302 8.70 47 89 10
DHC08800302 8.80 47 89 10
DHC08900302 8.90 47 89 10
DHC09000302 9.00 47 89 10
DHC09100302 9.10 47 89 10
DHC09200302 9.20 47 89 10
DHC09250302 9.25(23/64") 47 89 10
DHC09300302 9.30 47 89 10
DHC09400302 9.40 47 89 10
DHC09500302 9.50 47 89 10
DHC09600302 9.60 47 89 10
DHC09700302 9.70 47 89 10
DHC09800302 9.80 47 89 10
DHC09900302 9.90 47 89 10
DHC10000302 10.00 47 89 10
DHC10100302 10.10 55 102 12
DHC10200302 10.20 55 102 12
DHC10300302 10.30 55 102 12
DHC10400302 10.40 55 102 12
DHC10500302 10.50 55 102 12
DHC10600302 10.60 55 102 12
DHC10700302 10.70 55 102 12
DHC10800302 10.80 55 102 12
DHC10900302 10.90 55 102 12
DHC11000302 11.00 55 102 12
DHC11100302 11.10 55 102 12
DHC11200302 11.20 55 102 12
DHC11300302 11.30 55 102 12
DHC11400302 11.40 55 102 12
DHC11500302 11.50 55 102 12
DHC11600302 11.60 55 102 12
DHC11700302 11.70 55 102 12
DHC11800302 11.80 55 102 12
DHC11900302 11.90 55 102 12
Unit:mm
C032
內冷高硬用鎢鋼鑽頭
Solid Carbide Drills
Drilling
DHC Solid Carbide Drills - 3×D (for Hardened Steel)
P M K N S H
○○● ○●
Product Specs
．3×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant
．SINIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Steel, Alloy Steel, Cast Iron and Hardened Steel(HRC 30~50).
Unit:mm
Order No. D L1 L Ds
DHC12000302 12.00 55 102 12
DHC12100302 12.10 60 107 14
DHC12200302 12.20 60 107 14
DHC12300302 12.30 60 107 14
DHC12400302 12.40 60 107 14
DHC12500302 12.50 60 107 14
DHC12600302 12.60 60 107 14
DHC12700302 12.70 60 107 14
DHC12800302 12.80 60 107 14
DHC12900302 12.90 60 107 14
DHC13000302 13.00 60 107 14
DHC13200302 13.20 60 107 14
DHC13300302 13.30 60 107 14
DHC13500302 13.50 60 107 14
DHC13700302 13.70 60 107 14
DHC13800302 13.80 60 107 14
DHC14000302 14.00 60 107 14
DHC14200302 14.20 65 115 16
DHC14300302 14.30 65 115 16
DHC14400302 14.40 65 115 16
DHC14500302 14.50 65 115 16
DHC14700302 14.70 65 115 16
DHC15000302 15.00 65 115 16
DHC15200302 15.20 65 115 16
DHC15500302 15.50 65 115 16
DHC15600302 15.60 65 115 16
DHC15700302 15.70 65 115 16
DHC15800302 15.80 65 115 16
DHC16000302 16.00 65 115 16
DHC16500302 16.50 73 123 18
DHC17000302 17.00 73 123 18
DHC17500302 17.50 73 123 18
DHC18000302 18.00 73 123 18
DHC18500302 18.50 79 131 20
DHC19000302 19.00 79 131 20
DHC19500302 19.50 79 131 20
DHC20000302 20.00 79 131 20
Order No. D L1 L Ds
C033
內冷高硬用鎢鋼鑽頭
Solid Carbide Drills
DHC Solid Carbide Drills - 5×D (for Hardened Steel)
P M K N S H
○○● ○●
Product Specs
．5×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant
．SINIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Steel, Alloy Steel, Cast Iron and Hardened Steel(HRC 30~50).
Order No. D L1 L Ds
DHC04000502 4.00 36 74 6
DHC04100502 4.10 36 74 6
DHC04200502 4.20 36 74 6
DHC04300502 4.30 36 74 6
DHC04400502 4.40 36 74 6
DHC04500502 4.50 36 74 6
DHC04600502 4.60 36 74 6
DHC04650502 4.65(13/71") 36 74 6
DHC04700502 4.70 36 74 6
DHC04800502 4.80 44 82 6
DHC04900502 4.90 44 82 6
DHC05000502 5.00 44 82 6
DHC05100502 5.10 44 82 6
DHC05200502 5.20 44 82 6
DHC05300502 5.30 44 82 6
DHC05400502 5.40 44 82 6
DHC05500502 5.50 44 82 6
DHC05550502 5.55(7/32") 44 82 6
DHC05600502 5.60 44 82 6
DHC05700502 5.70 44 82 6
DHC05800502 5.80 44 82 6
DHC05900502 5.90 44 82 6
DHC06000502 6.00 44 82 6
DHC06100502 6.10 53 91 8
DHC06200502 6.20 53 91 8
DHC06300502 6.30 53 91 8
DHC06400502 6.40 53 91 8
DHC06500502 6.50 53 91 8
DHC06600502 6.60 53 91 8
DHC06700502 6.70 53 91 8
DHC06800502 6.80 53 91 8
DHC06900502 6.90 53 91 8
DHC07000502 7.00 53 91 8
DHC07100502 7.10 53 91 8
DHC07200502 7.20 53 91 8
DHC07300502 7.30 53 91 8
DHC07400502 7.40 53 91 8
DHC07500502 7.50 53 91 8
DHC07600502 7.60 53 91 8
DHC07700502 7.70 53 91 8
DHC07800502 7.80 53 91 8
DHC07900502 7.90 53 91 8
Order No. D L1 L Ds
DHC08000502 8.00 53 91 8
DHC08100502 8.10 61 103 10
DHC08200502 8.20 61 103 10
DHC08300502 8.30 61 103 10
DHC08400502 8.40 61 103 10
DHC08500502 8.50 61 103 10
DHC08600502 8.60 61 103 10
DHC08700502 8.70 61 103 10
DHC08800502 8.80 61 103 10
DHC08900502 8.90 61 103 10
DHC09000502 9.00 61 103 10
DHC09100502 9.10 61 103 10
DHC09200502 9.20 61 103 10
DHC09250502 9.25(23/64") 61 103 10
DHC09300502 9.30 61 103 10
DHC09400502 9.40 61 103 10
DHC09500502 9.50 61 103 10
DHC09600502 9.60 61 103 10
DHC09700502 9.70 61 103 10
DHC09800502 9.80 61 103 10
DHC09900502 9.90 61 103 10
DHC10000502 10.00 61 103 10
DHC10100502 10.10 71 118 12
DHC10200502 10.20 71 118 12
DHC10300502 10.30 71 118 12
DHC10400502 10.40 71 118 12
DHC10500502 10.50 71 118 12
DHC10600502 10.60 71 118 12
DHC10700502 10.70 71 118 12
DHC10800502 10.80 71 118 12
DHC10900502 10.90 71 118 12
DHC11000502 11.00 71 118 12
DHC11100502 11.10 71 118 12
DHC11200502 11.20 71 118 12
DHC11300502 11.30 71 118 12
DHC11400502 11.40 71 118 12
DHC11500502 11.50 71 118 12
DHC11600502 11.60 71 118 12
DHC11700502 11.70 71 118 12
DHC11800502 11.80 71 118 12
DHC11900502 11.90 71 118 12
Unit:mm
C034
內冷高硬用鎢鋼鑽頭
Solid Carbide Drills
Drilling
DHC Solid Carbide Drills - 5×D (for Hardened Steel)
P M K N S H
○○● ○●
Product Specs
．5×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．Internal Coolant
．SINIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Steel, Alloy Steel, Cast Iron and Hardened Steel(HRC 30~50).
Unit:mm
Order No. D L1 L Ds
DHC12000502 12.00 71 118 12
DHC12100502 12.10 77 124 14
DHC12200502 12.20 77 124 14
DHC12300502 12.30 77 124 14
DHC12400502 12.40 77 124 14
DHC12500502 12.50 77 124 14
DHC12600502 12.60 77 124 14
DHC12700502 12.70 77 124 14
DHC12800502 12.80 77 124 14
DHC12900502 12.90 77 124 14
DHC13000502 13.00 77 124 14
DHC13100502 13.10 77 124 14
DHC13300502 13.30 77 124 14
DHC13400502 13.40 77 124 14
DHC13500502 13.50 77 124 14
DHC13600502 13.60 77 124 14
DHC13700502 13.70 77 124 14
DHC13800502 13.80 77 124 14
DHC13900502 13.90 77 124 14
DHC14000502 14.00 77 124 14
DHC14100502 14.10 83 133 16
DHC14200502 14.20 83 133 16
DHC14300502 14.30 83 133 16
DHC14400502 14.40 83 133 16
DHC14500502 14.50 83 133 16
DHC14600502 14.60 83 133 16
DHC14700502 14.70 83 133 16
DHC14800502 14.80 83 133 16
DHC14900502 14.90 83 133 16
DHC15000502 15.00 83 133 16
DHC15100502 15.10 83 133 16
DHC15200502 15.20 83 133 16
DHC15300502 15.30 83 133 16
DHC15400502 15.40 83 133 16
DHC15500502 15.50 83 133 16
DHC15600502 15.60 83 133 16
DHC15700502 15.70 83 133 16
DHC15800502 15.80 83 133 16
DHC15900502 15.90 83 133 16
DHC16000502 16.00 83 133 16
DHC16500502 16.50 93 143 18
DHC17000502 17.00 93 143 18
DHC17500502 17.50 93 143 18
DHC18000502 18.00 93 143 18
DHC18500502 18.50 101 153 20
DHC19000502 19.00 101 153 20
DHC19500502 19.50 101 153 20
DHC20000502 20.00 101 153 20
Order No. D L1 L Ds
C035
內冷高硬用鎢鋼鑽頭
Solid Carbide Drills
DHN Solid Carbide Drills - 3×D (for Hardened Steel)
P M K N S H
○○● ○●
Product Specs
．3×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．External Coolant
．SINIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Steel, Alloy Steel, Cast Iron and Hardened Steel(HRC 30~50). ．Customizable
Order No. D L1 L Ds
DHN04000302 4.00 24 66 6
DHN04100302 4.10 24 66 6
DHN04200302 4.20 24 66 6
DHN04300302 4.30 24 66 6
DHN04400302 4.40 24 66 6
DHN04500302 4.50 24 66 6
DHN04600302 4.60 24 66 6
DHN04650302 4.65(13/71") 24 66 6
DHN04700302 4.70 24 66 6
DHN04800302 4.80 28 66 6
DHN04900302 4.90 28 66 6
DHN05000302 5.00 28 66 6
DHN05100302 5.10 28 66 6
DHN05200302 5.20 28 66 6
DHN05300302 5.30 28 66 6
DHN05400302 5.40 28 66 6
DHN05500302 5.50 28 66 6
DHN05560302 5.56 28 66 6
DHN05600302 5.60 28 66 6
DHN05700302 5.70 28 66 6
DHN05800302 5.80 28 66 6
DHN05900302 5.90 28 66 6
DHN06000302 6.00 28 66 6
DHN06100302 6.10 34 79 8
DHN06200302 6.20 34 79 8
DHN06300302 6.30 34 79 8
DHN06350302 6.35(1/4") 34 79 8
DHN06400302 6.40 34 79 8
DHN06500302 6.50 34 79 8
DHN06600302 6.60 34 79 8
DHN06700302 6.70 34 79 8
DHN06800302 6.80 34 79 8
DHN06900302 6.90 34 79 8
DHN07000302 7.00 34 79 8
DHN07100302 7.10 41 79 8
DHN07200302 7.20 41 79 8
DHN07300302 7.30 41 79 8
DHN07400302 7.40 41 79 8
DHN07500302 7.50 41 79 8
DHN07600302 7.60 41 79 8
DHN07700302 7.70 41 79 8
DHN07800302 7.80 41 79 8
DHN07900302 7.90 41 79 8
Order No. D L1 L Ds
DHN08000302 8.00 41 79 8
DHN08100302 8.10 47 89 10
DHN08200302 8.20 47 89 10
DHN08300302 8.30 47 89 10
DHN08400302 8.40 47 89 10
DHN08500302 8.50 47 89 10
DHN08600302 8.60 47 89 10
DHN08700302 8.70 47 89 10
DHN08800302 8.80 47 89 10
DHN08900302 8.90 47 89 10
DHN09000302 9.00 47 89 10
DHN09100302 9.10 47 89 10
DHN09200302 9.20 47 89 10
DHN09250302 9.25(23/64") 47 89 10
DHN09300302 9.30 47 89 10
DHN09400302 9.40 47 89 10
DHN09500302 9.50 47 89 10
DHN09600302 9.60 47 89 10
DHN09700302 9.70 47 89 10
DHN09800302 9.80 47 89 10
DHN09900302 9.90 47 89 10
DHN10000302 10.00 47 89 10
DHN10100302 10.10 55 102 12
DHN10200302 10.20 55 102 12
DHN10300302 10.30 55 102 12
DHN10400302 10.40 55 102 12
DHN10500302 10.50 55 102 12
DHN10600302 10.60 55 102 12
DHN10700302 10.70 55 102 12
DHN10800302 10.80 55 102 12
DHN10900302 10.90 55 102 12
DHN11000302 11.00 55 102 12
DHN11100302 11.10 55 102 12
DHN11200302 11.20 55 102 12
DHN11300302 11.30 55 102 12
DHN11400302 11.40 55 102 12
DHN11500302 11.50 55 102 12
DHN11600302 11.60 55 102 12
DHN11700302 11.70 55 102 12
DHN11800302 11.80 55 102 12
DHN11900302 11.90 55 102 12
Unit:mm
C036
外冷高硬用鎢鋼鑽頭
Solid Carbide Drills
Drilling
DHN Solid Carbide Drills - 3×D (for Hardened Steel)
P M K N S H
○○● ○●
Product Specs
．3×D Cutting depth ．Reinforced Shank ．140° Tip Angle ．External Coolant
．SINIX Coating ．Tolerance h8 ．Double Margins Design ．SX Design
．For Steel, Alloy Steel, Cast Iron and Hardened Steel(HRC 30~50). ．Customizable
Unit:mm
Order No. D L1 L Ds
DHN12000302 12.00 55 102 12
DHN12100302 12.10 60 107 14
DHN12200302 12.20 60 107 14
DHN12300302 12.30 60 107 14
DHN12400302 12.40 60 107 14
DHN12500302 12.50 60 107 14
DHN12600302 12.60 60 107 14
DHN12700302 12.70 60 107 14
DHN12800302 12.80 60 107 14
DHN12900302 12.90 60 107 14
DHN13000302 13.00 60 107 14
DHN13200302 13.20 60 107 14
DHN13300302 13.30 60 107 14
DHN13500302 13.50 60 107 14
DHN13700302 13.70 60 107 14
DHN13800302 13.80 60 107 14
DHN14000302 14.00 60 107 14
DHN14200302 14.20 65 115 16
DHN14300302 14.30 65 115 16
DHN14400302 14.40 65 115 16
DHN14500302 14.50 65 115 16
DHN14700302 14.70 65 115 16
DHN15000302 15.00 65 115 16
DHN15200302 15.20 65 115 16
DHN15500302 15.50 65 115 16
DHN15600302 15.60 65 115 16
DHN15700302 15.70 65 115 16
DHN15800302 15.80 65 115 16
DHN16000302 16.00 65 115 16
DHN16500302 16.50 73 123 18
DHN17000302 17.00 73 123 18
DHN17500302 17.50 73 123 18
DHN18000302 18.00 73 123 18
DHN18500302 18.50 79 131 20
DHN19000302 19.00 79 131 20
DHN19500302 19.50 79 131 20
DHN20000302 20.00 79 131 20
Order No. D L1 L Ds
C037
外冷高硬用鎢鋼鑽頭
C038
Endmills．Inserts．Drills
Solid Carbide Drills
Drilling
DAN Solid Carbide Drills (with Straight Flute)
C039
FEATURES
‧Tolerance: h7
‧Tip angle: 130°
‧UNIX Coating
‧3×D ~ 5×D Cutting Depth
外冷直刃鑽鉸刀
‧鑽尖 130°
‧ 3×D ~ 5×D 加工深度
‧ UNIX 塗層
‧鑽孔及鉸孔一次完成
Solid Carbide Drills
DAN Solid Carbide Drills - 3×D (with Straight Flute)
Order No. D L1 L Ds
DAN04000301 4.00 24 75 4
DAN04500301 4.50 24 75 6
DAN05000301 5.00 28 75 6
DAN05500301 5.50 28 75 6
DAN06000301 6.00 28 75 6
DAN06500301 6.50 34 100 8
DAN07000301 7.00 34 100 8
DAN07500301 7.50 41 100 8
DAN08000301 8.00 41 100 8
DAN08500301 8.50 47 100 10
DAN09000301 9.00 47 100 10
DAN09500301 9.50 47 100 10
DAN10000301 10.00 47 100 10
DAN12000301 12.00 55 100 12
DAN14000301 14.00 60 100 14
DAN16000301 16.00 65 107 16
P M K N S H
○ ● ●
Order No. D L1 L Ds
Unit:mm
Product Specs
．3×D Cutting depth ．130° Tip Angle ．External Coolant ．UNIX Coating
．Tolerance h7
．For Cast Iron, Aluminum and Copper.
C040
外冷直刃鑽鉸刀
Solid Carbide Drills
Drilling
DAN Solid Carbide Drills - 5×D (with Straight Flute)
P M K N S H
○ ● ●
Unit:mm
Product Specs
．3×D Cutting depth ．130° Tip Angle ．External Coolant ．UNIX Coating
．Tolerance h7
．For Cast Iron, Aluminum and Copper.
Order No. D L1 L Ds
DAN04000501 4.00 36 100 4
DAN04500501 4.50 36 100 6
DAN05000501 5.00 44 100 6
DAN05500501 5.50 44 100 6
DAN06000501 6.00 44 100 6
DAN06500501 6.50 53 100 8
DAN07000501 7.00 53 100 8
DAN07500501 7.50 53 100 8
DAN08000501 8.00 53 100 8
DAN08500501 8.50 61 107 10
DAN09000501 9.00 61 107 10
DAN09500501 9.50 61 107 10
DAN10000501 10.00 61 107 10
DAN12000501 12.00 71 150 12
DAN14000501 14.00 77 150 14
DAN16000501 16.00 83 150 16
Order No. D L1 L Ds
C041
外冷直刃鑽鉸刀
C042
Endmills．Inserts．Drills
Solid Carbide Drills
Drilling
DZC, DZN Solid Carbide Drills (for Step Hole)
C043
FEATURES
‧專為沉孔加工、導角加工設計
‧適用鋼、合金鋼、鑄鐵的孔加工
‧提供客製化服務
‧For drill a hole with counterbore, countersink, or chamfer
‧For steel,alloy steel,cast iron
‧Customized Service
High Performance
High CP Value
內冷 & 外冷階梯鎢鋼鑽頭
Solid Carbide Drills
DZC Solid Carbide Drills (for Step hole)
Order No. D L1 L2 L Ds
DZC03300301 3.30 12 26 62 6
DZC04200301 4.20 15 28 66 6
DZC05000301 5.00 18 36 79 8
DZC06800301 6.80 24 48 90 10
DZC08500301 8.50 30 55 102 12
P M K N S H
● ● ● ○
Order No. D L1 L2 L Ds
Unit:mm
Product Specs
．Reinforced Shank ．Internal Coolant ．UNIX Coating ．Tolerance h8
．For drill with a counterbore, countersink, or chamfer. ．Customizable
．For Steel, Alloy Steel, Stainless Steel and Cast Iron.
C044
內冷階梯鎢鋼鑽頭
Solid Carbide Drills
Drilling
DZN Solid Carbide Drills (for Step hole)
Order No. D L1 L2 L Ds
DZN03300301 3.30 12 26 62 6
DZN04200301 4.20 15 28 66 6
DZN05000301 5.00 18 36 79 8
DZN06800301 6.80 24 48 90 10
DZN08500301 8.50 30 55 102 12
P M K N S H
●○●
Product Specs
．Reinforced Shank ．External Coolant ．UNIX Coating ．Tolerance h8
．For drill with a counterbore, countersink, or chamfer. ．Customizable
．For Steel, Alloy Steel, Stainless Steel and Cast Iron.
Order No. D L1 L2 L Ds
Unit:mm
C045
外冷階梯鎢鋼鑽頭
C046
Endmills．Inserts．Drills
Solid Carbide Drills
Drilling
DFN Solid Carbide Drills - 3×D (with Flat tip)
C047
FEATURES
‧適用多種加工場景
‧搪孔加工 、斜面鑽孔、曲面鑽孔、跨孔鑽孔、薄板鑽孔
‧導引孔加工
‧孔位校正
‧ 有效減少加工程序
‧Multiple application
‧Counter boring、Slope、Curve、Cross hole、Thin plate
‧Pre-hole
‧Hole correction
‧Reduce manufacturing procedure
外冷平底鎢鋼鑽頭
Solid Carbide Drills
DFN Solid Carbide Drills - 3×D (with Flat tip)
P M K N S H
●○●
Product Specs
．3×D Cutting depth ．Reinforced Shank ．Flat tip ．External Coolant
．SINIX Coating ．Tolerance h8 ．FX Design
．For Steel, Alloy Steel, Stainless Steel (Martensitic), Cast iron, Non-ferrous metal
.
Order No. D L1 L Ds
DFN03000342 3.00 20 60 4
DFN03100342 3.10 20 60 4
DFN03170342 3.17(1/8") 20 60 4
DFN03200342 3.20 20 60 4
DFN03250342 3.25(5/39") 20 60 4
DFN03300342 3.30 20 60 4
DFN03400342 3.40 20 60 4
DFN03500342 3.50 20 60 4
DFN03600342 3.60 20 60 4
DFN03700342 3.70 20 60 4
DFN03800342 3.80 24 60 4
DFN03900342 3.90 24 60 4
DFN03970342 3.97(5/32") 24 60 4
DFN03000302 3.00 20 62 6
DFN03100302 3.10 20 62 6
DFN03200302 3.20 20 62 6
DFN03250302 3.25(5/39") 20 62 6
DFN03300302 3.30 20 62 6
DFN03400302 3.40 20 62 6
DFN03500302 3.50 20 62 6
DFN03600302 3.60 20 62 6
DFN03700302 3.70 20 62 6
DFN03800302 3.80 24 66 6
DFN03900302 3.90 24 66 6
DFN03970302 3.97(5/32") 24 66 6
DFN04000302 4.00 24 66 6
DFN04100302 4.10 24 66 6
DFN04200302 4.20 24 66 6
DFN04300302 4.30 24 66 6
DFN04400302 4.40 24 66 6
DFN04500302 4.50 24 66 6
DFN04600302 4.60 24 66 6
DFN04650302 4.65(13/71") 24 66 6
DFN04700302 4.70 24 66 6
DFN04800302 4.80 28 66 6
DFN04900302 4.90 28 66 6
DFN05000302 5.00 28 66 6
DFN05100302 5.10 28 66 6
DFN05200302 5.20 28 66 6
DFN05300302 5.30 28 66 6
DFN05400302 5.40 28 66 6
DFN05500302 5.50 28 66 6
DFN05560302 5.56(7/32") 28 66 6
DFN05600302 5.60 28 66 6
DFN05700302 5.70 28 66 6
DFN05800302 5.80 28 66 6
DFN05900302 5.90 28 66 6
Order No. D L1 L Ds
DFN06000302 6.00 28 66 6
DFN06100302 6.10 34 79 8
DFN06200302 6.20 34 79 8
DFN06300302 6.30 34 79 8
DFN06350302 6.35 34 79 8
DFN06400302 6.40 34 79 8
DFN06500302 6.50 34 79 8
DFN06600302 6.60 34 79 8
DFN06700302 6.70 34 79 8
DFN06800302 6.80 34 79 8
DFN06900302 6.90 34 79 8
DFN07000302 7.00 34 79 8
DFN07100302 7.10 41 79 8
DFN07200302 7.20 41 79 8
DFN07300302 7.30 41 79 8
DFN07400302 7.40 41 79 8
DFN07500302 7.50 41 79 8
DFN07600302 7.60 41 79 8
DFN07700302 7.70 41 79 8
DFN07800302 7.80 41 79 8
DFN07900302 7.90 41 79 8
DFN08000302 8.00 41 79 8
DFN08100302 8.10 47 89 10
DFN08200302 8.20 47 89 10
DFN08300302 8.30 47 89 10
DFN08400302 8.40 47 89 10
DFN08500302 8.50 47 89 10
DFN08600302 8.60 47 89 10
DFN08700302 8.70 47 89 10
DFN08800302 8.80 47 89 10
DFN08900302 8.90 47 89 10
DFN09000302 9.00 47 89 10
DFN09100302 9.10 47 89 10
DFN09200302 9.20 47 89 10
DFN09250302 9.25(23/64") 47 89 10
DFN09300302 9.30 47 89 10
DFN09400302 9.40 47 89 10
DFN09500302 9.50 47 89 10
DFN09600302 9.60 47 89 10
DFN09700302 9.70 47 89 10
DFN09800302 9.80 47 89 10
DFN09900302 9.90 47 89 10
Unit:mm
C048
外冷平底鎢鋼鑽頭
Solid Carbide Drills
Drilling
DFN Solid Carbide Drills - 3×D (with Flat tip)
P M K N S H
●○●
Product Specs
．3×D Cutting depth ．Reinforced Shank ．Flat tip ．External Coolant
．SINIX Coating ．Tolerance h8 ．FX Design
．For Steel, Alloy Steel, Stainless Steel (Martensitic), Cast iron, Non-ferrous metal
.
Order No. D L1 L Ds
DFN10000302 10.00 47 89 10
DFN10100302 10.10 55 102 12
DFN10200302 10.20 55 102 12
DFN10300302 10.30 55 102 12
DFN10400302 10.40 55 102 12
DFN10500302 10.50 55 102 12
DFN10600302 10.60 55 102 12
DFN10700302 10.70 55 102 12
DFN10800302 10.80 55 102 12
DFN10900302 10.90 55 102 12
DFN11000302 11.00 55 102 12
DFN11100302 11.10 55 102 12
DFN11200302 11.20 55 102 12
DFN11300302 11.30 55 102 12
DFN11400302 11.40 55 102 12
DFN11500302 11.50 55 102 12
DFN11600302 11.60 55 102 12
DFN11700302 11.70 55 102 12
DFN11800302 11.80 55 102 12
DFN11900302 11.90 55 102 12
DFN12000302 12.00 55 102 12
DFN12100302 12.10 60 107 14
DFN12200302 12.20 60 107 14
DFN12300302 12.30 60 107 14
DFN12400302 12.40 60 107 14
DFN12500302 12.50 60 107 14
DFN12600302 12.60 60 107 14
DFN12700302 12.70(1/2") 60 107 14
DFN12800302 12.80 60 107 14
DFN12900302 12.90 60 107 14
DFN13000302 13.00 60 107 14
DFN13200302 13.20 60 107 14
DFN13300302 13.30 60 107 14
DFN13500302 13.50 60 107 14
DFN13700302 13.70 60 107 14
DFN13800302 13.80 60 107 14
DFN14000302 14.00 60 107 14
DFN14200302 14.20 65 115 16
DFN14300302 14.30 65 115 16
DFN14400302 14.40 65 115 16
DFN14500302 14.50 65 115 16
DFN14700302 14.70 65 115 16
Order No. D L1 L Ds
DFN15000302 15.00 65 115 16
DFN15200302 15.20 65 115 16
DFN15500302 15.50 65 115 16
DFN15600302 15.60 65 115 16
DFN15700302 15.70 65 115 16
DFN15800302 15.80 65 115 16
DFN16000302 16.00 65 115 16
DFN16500302 16.50 73 123 18
DFN17000302 17.00 73 123 18
DFN17500302 17.50 73 123 18
DFN18000302 18.00 73 123 18
DFN18500302 18.50 79 131 20
DFN19000302 19.00 79 131 20
DFN19500302 19.50 79 131 20
DFN20000302 20.00 79 131 20
Unit:mm
C049
外冷平底鎢鋼鑽頭
C050
Endmills．Inserts．Drills
Solid Carbide Drills
Drilling
C051
DGN Solid Carbide Drills (for General Purpose)
Product Features
‧泛用鑽孔
‧適用一般鋼料與鑄鐵
‧刀具壽命佳
‧價格實惠
‧General Purpose Drilling
‧For Steel and Cast Iron
‧Longer Tool Life
‧Competitive Price
外冷泛用鎢鋼鑽頭
Solid Carbide Drills
P M K N S H
●○●
Product Specs
．3×D Cutting depth ．Straight Shank ．130° Tip Angle ．External Coolant
．UNIX Coating ．Tolerance h8 ．NX Design
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
Unit:mm
Order No. D L1 L Ds
DGN06000301 6.00 28 66 6.00
DGN06100301 6.10 31 70 6.10
DGN06200301 6.20 31 70 6.20
DGN06300301 6.30 31 70 6.30
DGN06350301 6.35(1/4") 31 70 6.35
DGN06400301 6.40 31 70 6.40
DGN06500301 6.50 31 70 6.50
DGN06600301 6.60 31 70 6.60
DGN06700301 6.70 31 70 6.70
DGN06800301 6.80 34 74 6.80
DGN06900301 6.90 34 74 6.90
DGN07000301 7.00 34 74 7.00
DGN07100301 7.10 34 74 7.10
DGN07140301 7.14(9/32") 34 74 7.14
DGN07200301 7.20 34 74 7.20
DGN07300301 7.30 34 74 7.30
DGN07400301 7.40 34 74 7.40
DGN07500301 7.50 34 74 7.50
DGN07600301 7.60 37 79 7.60
DGN07700301 7.70 37 79 7.70
DGN07800301 7.80 37 79 7.80
DGN07900301 7.90 37 79 7.90
DGN07940301 7.94(5/16") 37 79 7.94
DGN08000301 8.00 37 79 8.00
DGN08100301 8.10 37 79 8.10
DGN08200301 8.20 37 79 8.20
DGN08300301 8.30 37 79 8.30
DGN08400301 8.40 37 79 8.40
DGN08500301 8.50 37 79 8.50
DGN08600301 8.60 37 79 8.60
DGN08700301 8.70 37 79 8.70
DGN08730301 8.73(11/32") 40 84 8.73
DGN08800301 8.80 40 84 8.80
DGN08900301 8.90 40 84 8.90
DGN09000301 9.00 40 84 9.00
DGN09100301 9.10 40 84 9.10
DGN09200301 9.20 40 84 9.20
DGN09300301 9.30 40 84 9.30
DGN09400301 9.40 40 84 9.40
DGN09500301 9.50 40 84 9.50
DGN09700301 9.70 43 89 9.70
DGN09800301 9.80 43 89 9.80
DGN09900301 9.90 43 89 9.90
Order No. D L1 L Ds
DGN02000301 2.00 12 38 2.00
DGN02100301 2.10 12 38 2.10
DGN02200301 2.20 13 40 2.20
DGN02300301 2.30 13 40 2.30
DGN02380301 2.38(3/32") 14 43 2.38
DGN02400301 2.40 14 43 2.40
DGN02500301 2.50 14 43 2.50
DGN02600301 2.60 14 43 2.60
DGN02700301 2.70 16 46 2.70
DGN02780301 2.78(7/64") 16 46 2.78
DGN02800301 2.80 16 46 2.80
DGN02900301 2.90 16 46 2.90
DGN03000301 3.00 16 46 3.00
DGN03100301 3.10 18 49 3.10
DGN03170301 3.17(1/8") 18 49 3.17
DGN03200301 3.20 18 49 3.20
DGN03300301 3.30 18 49 3.30
DGN03400301 3.40 20 52 3.40
DGN03500301 3.50 20 52 3.50
DGN03570301 3.57(9/64") 20 52 3.57
DGN03600301 3.60 20 52 3.60
DGN03700301 3.70 20 52 3.70
DGN03800301 3.80 22 55 3.80
DGN03900301 3.90 22 55 3.90
DGN03970301 3.97(5/32") 22 55 3.97
DGN04000301 4.00 22 55 4.00
DGN04100301 4.10 22 55 4.10
DGN04200301 4.20 24 58 4.20
DGN04300301 4.30 24 58 4.30
DGN04370301 4.37(11/64") 24 58 4.37
DGN04400301 4.40 24 58 4.40
DGN04500301 4.50 24 58 4.50
DGN04600301 4.60 24 58 4.60
DGN04700301 4.70 24 58 4.70
DGN04760301 4.76(3/16") 26 62 4.76
DGN04800301 4.80 26 62 4.80
DGN04900301 4.90 26 62 4.90
DGN05000301 5.00 26 62 5.00
DGN05100301 5.10 26 62 5.10
DGN05200301 5.20 26 62 5.20
DGN05300301 5.30 26 62 5.30
DGN05400301 5.40 28 66 5.40
DGN05500301 5.50 28 66 5.50
DGN05600301 5.60 28 66 5.60
DGN05700301 5.70 28 66 5.70
DGN05800301 5.80 28 66 5.80
DGN05900301 5.90 28 66 5.90
C052
DGN Solid Carbide Drills - 3×D (for General Purpose) 外冷泛用鎢鋼鑽頭
Solid Carbide Drills
Drilling
P M K N S H
●○●
Unit:mm
Order No. D L1 L DsOrder No. D L1 L Ds
DGN10000301 10.00 43 89 10.00
DGN10100301 10.10 43 89 10.10
DGN10200301 10.20 43 89 10.20
DGN10300301 10.30 43 89 10.30
DGN10400301 10.40 43 89 10.40
DGN10500301 10.50 43 89 10.50
DGN10600301 10.60 43 89 10.60
DGN10800301 10.80 47 95 10.80
DGN10900301 10.90 47 95 10.90
DGN11000301 11.00 47 95 11.00
DGN11100301 11.10 47 95 11.10
DGN11200301 11.20 47 95 11.20
DGN11500301 11.50 47 95 11.50
DGN11600301 11.60 47 95 11.60
DGN11800301 11.80 47 95 11.80
DGN11900301 11.90 51 102 11.90
DGN12000301 12.00 51 102 12.00
DGN12500301 12.50 51 102 12.50
DGN12700301 12.70 51 102 12.70
DGN13000301 13.00 51 102 13.00
DGN13500301 13.50 54 107 13.50
DGN14000301 14.00 54 107 14.00
DGN14500301 14.50 56 111 14.50
DGN15000301 15.00 56 111 15.00
DGN15500301 15.50 58 115 15.50
DGN16000301 16.00 58 115 16.00
Product Specs
．3×D Cutting depth ．Straight Shank ．130° Tip Angle ．External Coolant
．UNIX Coating ．Tolerance h8 ．NX Design
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
C053
DGN Solid Carbide Drills - 3×D (for General Purpose) 外冷泛用鎢鋼鑽頭
Solid Carbide Drills
Unit:mm
P M K N S H
●○●
Product Specs
．5×D Cutting depth ．Straight Shank ．130° Tip Angle ．External Coolant
．UNIX Coating ．Tolerance h8 ．NX Design
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
Order No. D L1 L Ds
DGN09000501 9.00 55 98 9.00
DGN09100501 9.10 58 102 9.10
DGN09200501 9.20 58 102 9.20
DGN09300501 9.30 58 102 9.30
DGN09500501 9.50 58 102 9.50
DGN09600501 9.60 60 105 9.60
DGN09700501 9.70 60 105 9.70
DGN09800501 9.80 60 105 9.80
DGN10000501 10.00 60 105 10.00
DGN10200501 10.20 66 112 10.20
DGN10300501 10.30 66 112 10.30
DGN10400501 10.40 66 112 10.40
DGN10500501 10.50 66 112 10.50
DGN10600501 10.60 68 114 10.60
DGN10700501 10.70 68 114 10.70
DGN10800501 10.80 68 114 10.80
DGN10900501 10.90 68 114 10.90
DGN11000501 11.00 68 114 11.00
DGN11100501 11.10 71 118 11.10
DGN11200501 11.20 71 118 11.20
DGN11400501 11.40 71 118 11.40
DGN11500501 11.50 71 118 11.50
DGN11600501 11.60 73 121 11.60
DGN11700501 11.70 73 121 11.70
DGN11800501 11.80 73 121 11.80
DGN11900501 11.90 73 121 11.90
DGN12000501 12.00 73 121 12.00
DGN12500501 12.50 76 135 12.50
DGN12700501 12.70 78 137 12.70
DGN13000501 13.00 78 137 13.00
DGN13500501 13.50 84 144 13.50
DGN14000501 14.00 86 147 14.00
DGN14500501 14.50 89 151 14.50
DGN15000501 15.00 91 153 15.00
DGN15500501 15.50 94 157 15.50
DGN16000501 16.00 96 160 16.00
Order No. D L1 L Ds
DGN05000501 5.00 34 73 5.00
DGN05100501 5.10 38 76 5.10
DGN05200501 5.20 38 76 5.20
DGN05300501 5.30 38 76 5.30
DGN05400501 5.40 38 76 5.40
DGN05500501 5.50 38 76 5.50
DGN05600501 5.60 41 81 5.60
DGN05700501 5.70 41 81 5.70
DGN05800501 5.80 41 81 5.80
DGN05900501 5.90 41 81 5.90
DGN06000501 6.00 41 81 6.00
DGN06100501 6.10 41 81 6.10
DGN06200501 6.20 41 81 6.20
DGN06300501 6.30 41 81 6.30
DGN06400501 6.40 41 81 6.40
DGN06500501 6.50 41 81 6.50
DGN06600501 6.60 43 83 6.60
DGN06700501 6.70 43 83 6.70
DGN06800501 6.80 43 83 6.80
DGN06900501 6.90 43 83 6.90
DGN07000501 7.00 43 83 7.00
DGN07100501 7.10 45 87 7.10
DGN07200501 7.20 45 87 7.20
DGN07300501 7.30 45 87 7.30
DGN07400501 7.40 45 87 7.40
DGN07500501 7.50 45 87 7.50
DGN07600501 7.60 48 90 7.60
DGN07700501 7.70 48 90 7.70
DGN07800501 7.80 48 90 7.80
DGN07900501 7.90 48 90 7.90
DGN08000501 8.00 48 90 8.00
DGN08100501 8.10 53 96 8.10
DGN08200501 8.20 53 96 8.20
DGN08300501 8.30 53 96 8.30
DGN08400501 8.40 53 96 8.40
DGN08500501 8.50 53 96 8.50
DGN08600501 8.60 55 98 8.60
DGN08700501 8.70 55 98 8.70
DGN08800501 8.80 55 98 8.80
C054
DGN Solid Carbide Drills - 5×D (for General Purpose) 外冷泛用鎢鋼鑽頭
Solid Carbide Drills
Drilling
C055
DTN Solid Carbide Drills (for Spotting)
Product Spec.
‧刀具壽命佳
‧價格實惠
‧客製化服務
‧Better Tool Life
‧Competitive Price
‧Customized Service
‧Spotting Drills
Tip angle 90°
Tip angle 120°
外冷定點鎢鋼鑽頭
Solid Carbide Drills
P M K N S H
●○●
Order No. D L1 L DsOrder No. D L1 L Ds
DTN01300901 1.30 4 50 3
DTN01700901 1.70 5 50 3
DTN03000901 3.00 8 50 3
DTN04000901 4.00 10 50 4
DTN05000901 5.00 13 50 5
DTN06000901 6.00 15 50 6
DTN08000901 8.00 20 60 8
DTN10000901 10.00 25 75 10
DTN12000901 12.00 30 75 12
DTN16000901 16.00 35 100 16
Unit:mm
Product Specs
．90° Tip Angle ．45° Chamfer Angle ．External Coolant ．UNIX Coating
．Tolerance h8
．For Alloy Steel, Stainless Steel and Cast Iron.
C056
DTN Solid Carbide Drills - Tip angle 90° (for Spotting) 外冷定點鎢鋼鑽頭
Solid Carbide Drills
Drilling
P M K N S H
●○●
Order No. D L1 L DsOrder No. D L1 L Ds
DTN03001201 3.00 8 50 3
DTN04001201 4.00 10 50 4
DTN05001201 5.00 13 50 5
DTN06001201 6.00 15 50 6
DTN08001201 8.00 20 60 8
DTN10001201 10.00 25 75 10
DTN12001201 12.00 30 75 12
DTN16001201 16.00 35 100 16
Unit:mm
Product Specs
．120° Tip Angle ．60° Chamfer Angle ．External Coolant ．UNIX Coating
．Tolerance h8
．For Alloy Steel, Stainless Steel and Cast Iron.
C057
DTN Solid Carbide Drills - Tip angle 120° (for Spotting) 外冷定點鎢鋼鑽頭
Solid Carbide Drills
P M K N S H
●○●
Order No. D L1 L DsOrder No. D L1 L Ds
DTN04000911 4.00 10 75 4
DTN05000911 5.00 13 75 5
DTN06000911 6.00 15 100 6
DTN08000911 8.00 20 100 8
DTN10000911 10.00 25 150 10
DTN12000911 12.00 30 150 12
DTN16000911 16.00 35 150 16
Unit:mm
Product Specs
．90° Tip Angle ．45° Chamfer Angle ．External Coolant ．UNIX Coating
．Tolerance h8
．For Alloy Steel, Stainless Steel and Cast Iron.
C058
DTN Solid Carbide Drills - Tip angle 90°, Long shank (for Spotting) 外冷定點鎢鋼鑽頭
Solid Carbide Drills
Drilling
P M K N S H
●○●
Product Specs
．120° Tip Angle ．60° Chamfer Angle ．External Coolant ．UNIX Coating
．Tolerance h8
．For Alloy Steel, Stainless Steel and Cast Iron.
Order No. D L1 L DsOrder No. D L1 L Ds
DTN04001211 4.00 10 75 4
DTN05001211 5.00 13 75 5
DTN06001211 6.00 15 100 6
DTN08001211 8.00 20 100 8
DTN10001211 10.00 25 150 10
DTN12001211 12.00 30 150 12
DTN16001211 16.00 35 150 16
Unit:mm
C059
DTN Solid Carbide Drills - Tip angle 120°, Long shank (for Spotting) 外冷定點鎢鋼鑽頭
Solid Carbide Drills
P M K N S H
●○●
Product Specs
．140° Tip Angle ．70° Chamfer Angle ．External Coolant ．UNIX Coating
．Tolerance h8
．For Alloy Steel, Stainless Steel and Cast Iron.
Order No. D L1 L Ds
DTN04001411 4.00 10 75 4
DTN05001411 5.00 13 75 5
DTN06001411 6.00 15 100 6
DTN08001411 8.00 20 125 8
DTN10001411 10.00 25 150 10
DTN12001411 12.00 30 150 12
DTN16001411 16.00 35 150 16
Order No. D L1 L Ds
DTN03001401 3.00 8 50 3
DTN04001401 4.00 10 50 4
DTN05001401 5.00 13 50 5
DTN06001401 6.00 15 50 6
DTN08001401 8.00 20 60 8
DTN10001401 10.00 25 75 10
DTN12001401 12.00 30 75 12
DTN16001401 16.00 35 100 16
Unit:mm
C060
DTN Solid Carbide Drills - Tip angle 140° (for Spotting) 外冷定點鎢鋼鑽頭
Solid Carbide Drills
Drilling
C061
DCN Solid Carbide Drills (for Centering)
Product Spec.
‧刀具壽命佳
‧價格實惠
‧客製化服務
‧Better Tool Life
‧Competitive Price
‧Customized Service
‧Spotting Drills
Countersink angle 60°
Countersink angle 90°
外冷中心鎢鋼鑽頭
Solid Carbide Drills
P M K N S H
●○●
Product Specs
．120° Tip Angle ．
60° Countersink Angle (γ)．External Coolant ．UNIX Coating
．Tolerance h8
．For Alloy Steel, Stainless Steel and Cast Iron.
Order No. D L1 L DsOrder No. D L1 L Ds
DCN01000601 1.00 1.6 38 3
DCN01250601 1.25 1.9 38 3
DCN01600601 1.60 2.4 42 4
DCN02000601 2.00 2.9 50 5
DCN02500601 2.50 3.6 50 6
DCN03000601 3.00 3.9 60 8
DCN03150601 3.15 3.9 60 8
DCN04000601 4.00 5.0 75 10
DCN05000601 5.00 6.3 75 12
Unit:mm
C062
DCN Solid Carbide Drills - Countersink angle 60° (for Centering) 外冷中心鎢鋼鑽頭
Solid Carbide Drills
Drilling
Order No. D L1 L DsOrder No. D L1 L Ds
DCN01000901 1.00 1.6 38 3
DCN01250901 1.25 1.9 38 3
DCN01600901 1.60 2.4 42 4
DCN02000901 2.00 2.9 50 5
DCN02500901 2.50 3.6 50 6
DCN03000901 3.00 3.9 60 8
DCN03150901 3.15 3.9 60 8
DCN04000901 4.00 5.0 75 10
DCN05000901 5.00 6.3 75 12
P M K N S H
●○●
Product Specs
．120° Tip Angle ．
90° Countersink Angle (γ)．External Coolant ．UNIX Coating
．Tolerance h8
．For Alloy Steel, Stainless Steel and Cast Iron.
Unit:mm
C063
DCN Solid Carbide Drills - Countersink angle 90° (for Centering) 外冷中心鎢鋼鑽頭
C064
Endmills．Inserts．Drills
Indexable Drilling
Drilling
C065
Indexable Drill Insert & Tools 捨棄式鑽頭刀片與刀桿
‧Economical and Ecient
‧Durable full SDK holder body
‧Excellent chips ow
‧Internal coolant design
‧Better tool life
Product Features
‧經濟與效能
‧高耐久工具鋼刀桿
‧優異的排屑效率
‧內冷孔設計
‧良好的刀具壽命
Indexable Drilling
C066
Grade ISO Substrate
(HRA)
Coating
Type Thickness
Coolant Cutting
Condition
WET DRY
CX31NS
P20~P30
M15~M30
K30
91.6 TiSixN ~ 3 ★
★★Medium
Continuous
CX41NS
P20~P40
M20~M40
K30
90.0 TiSixN ~ 3 ★
★★Rough
Interrupted
Chip breaker design
Grade Descriptions
Grade Code : CX31NS, CX41NS
Ingredient : Ti, Al, Si, N
Feature : ．Si contained
．
Improve the hardness and heat resistance
．
The Si NANO particles uniformly distributed
．Eective protection of the substrate
．Extend inserts life
Tisixn
Altin
Substrate
Coating layers
Insert Grade Descriptions 刀片塗層介紹
MG MM
Indexable Drilling
Drilling
C067
SPMG Inserts SPMG 刀片
P Steel ◎◎◎○ ○
1st choice 2st choice
M Stainless steel ○○○◎ ◎
K Cast iron ◎○○○○
Inserts Designation
Grade Dimensions (mm)
Drawing
CX21NS
CX31NA
CX31NS
CX41NS
CX41NA
A B S r d1 t1
SPMG 050204-MG ✓ ✓
5.00 -2.38 0.4 2.30 -
11°
SPMG 060204-MG ✓ ✓
6.00 -2.38 0.4 2.65 -
SPMG 07T308-MG ✓ ✓
7.94 -3.97 0.8 2.85 -
SPMG 090408-MG ✓ ✓
9.80 -4.3 0.8 4.05 -
SPMG 110408-MG ✓ ✓
11.50 -
4.8 0.8 4.45
-
Holder Page : C070~C076
Indexable Drilling
C068
WCMT Inserts WCMT 刀片
P Steel ◎◎◎○ ○
1st choice 2st choice
M Stainless steel ○○○◎ ◎
K Cast iron ◎○○○○
Inserts Designation
Grade Dimensions (mm)
Drawing
CX21NS
CX31NA
CX31NS
CX41NS
CX41NA
A B S r d1 t1
WCMT 030208-MM ✓ ✓ 3.8 5.56 2.38 0.8 2.8 -
WCMT 040208-MM ✓ ✓ 4.3 6.35 2.38 0.8 3.0 -
WCMT 050308-MM ✓ ✓ 5.4 7.94 3.18 0.8 3.4 -
WCMT 06T308-MM ✓ ✓ 6.5 9.53 3.97 0.8 4.0 -
WCMT 080412-MM ✓ ✓ 8.7 12.7 4.76 1.2 4.3 -
Holder Page : C078~C084
Indexable Drilling
Drilling
C069
DSP Indexable Drills
‧SPMG series inserts
‧Optimized ute design
‧Internal coolant
‧Better tool life
‧Self-Produced inserts
‧Diameter 12.5-50 mm
Product Features
‧ 使用 SPMG 系列刀片
‧排屑槽設計優化
‧內冷孔設計
‧良好刀具壽命
‧刀片全程自產，提供您最佳性價比
‧孔徑加工範圍 : 12.5-50mm
內冷捨棄式快速鑽頭
Indexable Drilling
C070
Product Specs
．2×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with SPMG series inserts ．Indexable Insert with 4 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDSP1252-20T2-05 12.5
20 27
94 26 44
50
2
SPMG0502... TS2003 TK06
IDSP1302-20T2-05 13 2
IDSP1352-20T2-05 13.5 96 28 46 2
IDSP1402-20T2-05 14 2
IDSP1452-20T2-05 14.5 99 30 49 2
IDSP1502-20T2-05 15 2
IDSP1552-25T2-06 15.5
25 33
108 32 52
56
2
SPMG0602... TS2202 TK06
IDSP1602-25T2-06 16 2
IDSP1652-25T2-06 16.5 110 34 54 2
IDSP1702-25T2-06 17 2
IDSP1752-25T2-06 17.5 113 36 57 2
IDSP1802-25T2-06 18 2
IDSP1852-25T2-06 18.5 115 38 59 2
IDSP1902-25T2-06 19 2
IDSP1952-25T2-06 19.5 119 40 63 2
IDSP2002-25T2-06 20 2
IDSP2052-25T2-06 20.5 121 42 65 2
IDSP2102-25T2-06 21 2
IDSP2152-25T2-06 21.5 123 44 67 2
IDSP2202-25T2-07 22 2
SPMG07T308 TS2511 TK08
IDSP2252-32T2-07 22.5
32 43
131 46 71
60
2
IDSP2302-32T2-07 23 2
IDSP2352-32T2-07 23.5 134 48 74 2
IDSP2402-32T2-07 24 2
IDSP2452-32T2-07 24.5 137 50 77 2
IDSP2502-32T2-07 25 2
IDSP2552-32T2-07 25.5 139 52 79 2
IDSP2602-32T2-07 26 2
IDSP2652-32T2-07 26.5 142 54 81 2
IDSP2702-32T2-07 27 2
IDSP2752-32T2-07 27.5 144 56 84 2
DSP Indexable Drills - 2×D 內冷捨棄式快速鑽頭
Indexable Drilling
Drilling
C071
Product Specs
．2×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with SPMG series inserts ．Indexable Insert with 4 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDSP2802-32T2-09 28
32 43
144 56 84
60
2
SPMG090408 TS3504 TK15
IDSP2852-32T2-09 28.5 146 58 86 2
IDSP2902-32T2-09 29 2
IDSP2952-32T2-09 29.5 148 60 88 2
IDSP3002-32T2-09 30 2
IDSP3052-32T2-09 30.5 150 62 90 2
IDSP3102-32T2-09 31 2
IDSP3152-32T2-09 31.5 152 64 92 2
IDSP3202-32T2-09 32 2
IDSP3252-32T2-09 32.5 154 66 94 2
IDSP3302-32T2-09 33 2
IDSP3402-32T2-11 34 156 68 96 2
SPMG110408 TS4006 TK15
IDSP3502-32T2-11 35 158 70 98 2
IDSP3602-32T2-11 36 160 72 100 2
IDSP3702-32T2-11 37 162 74 102 2
IDSP3802-32T2-11 38 164 76 104 2
IDSP3902-32T2-11 39 166 78 106 2
IDSP4002-40T2-11 40 40 53 185 80 115 2
IDSP4102-40T2-11 41 187 82 117 2
DSP Indexable Drills - 2×D 內冷捨棄式快速鑽頭
Indexable Drilling
C072
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDSP1253-20T2-05 12.5
20 25
107 39 57
50
2
SPMG0502... TS2003 TK06
IDSP1303-20T2-05 13 2
IDSP1353-20T2-05 13.5 110 42 60 2
IDSP1403-20T2-05 14 2
IDSP1453-20T2-05 14.5 114 45 64 2
IDSP1503-20T2-05 15 2
IDSP1553-25T2-06 15.5
25 33
124 48 68
56
2
SPMG0602... TS2202 TK06
IDSP1603-25T2-06 16 2
IDSP1653-25T2-06 16.5 127 51 71 2
IDSP1703-25T2-06 17 2
IDSP1753-25T2-06 17.5 131 54 75 2
IDSP1803-25T2-06 18 2
IDSP1853-25T2-06 18.5 134 57 78 2
IDSP1903-25T2-06 19 2
IDSP1953-25T2-06 19.5 139 60 83 2
IDSP2003-25T2-06 20 2
IDSP2053-25T2-06 20.5 142 63 86 2
IDSP2103-25T2-06 21 2
IDSP2153-25T2-06 21.5 145 66 89 2
IDSP2203-25T2-07 22 2
SPMG07T3... TS2511 TK08
IDSP2253-32T2-07 22.5
32 43
154 69 94
60
2
IDSP2303-32T2-07 23 2
IDSP2353-32T2-07 23.5 158 72 98 2
IDSP2403-32T2-07 24 2
IDSP2453-32T2-07 24.5 162 75 102 2
IDSP2503-32T2-07 25 2
IDSP2553-32T2-07 25.5 165 78 105 2
IDSP2603-32T2-07 26 2
IDSP2653-32T2-07 26.5 169 81 108 2
IDSP2703-32T2-07 27 2
IDSP2753-32T2-07 27.5 172 84 112 2
Product Specs
．3×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with SPMG series inserts ．Indexable Insert with 4 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
DSP Indexable Drills - 3×D 內冷捨棄式快速鑽頭
Indexable Drilling
Drilling
C073
Product Specs
．3×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with SPMG series inserts ．Indexable Insert with 4 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDSP2803-32T2-09 28
32 43
172 84 112
60
2
SPMG0904... TS3504 TK15
IDSP2853-32T2-09 28.5 175 87 115 2
IDSP2903-32T2-09 29 2
IDSP2953-32T2-09 29.5 178 90 118 2
IDSP3003-32T2-09 30 2
IDSP3053-32T2-09 30.5 181 93 121 2
IDSP3103-32T2-09 31 2
IDSP3153-32T2-09 31.5 184 96 124 2
IDSP3203-32T2-09 32 2
IDSP3253-32T2-09 32.5 187 99 127 2
IDSP3303-32T2-09 33 2
IDSP3403-32T2-11 34 190 102 130 2
SPMG1104... TS4006 TK15
IDSP3503-32T2-11 35 193 105 133 2
IDSP3603-32T2-11 36 196 108 136 2
IDSP3703-32T2-11 37 199 111 139 2
IDSP3803-32T2-11 38 202 114 142 2
IDSP3903-32T2-11 39 205 117 145 2
IDSP4003-40T2-11 40 40 53 225 120 155 2
IDSP4103-40T2-11 41 228 123 158 2
DSP Indexable Drills - 3×D 內冷捨棄式快速鑽頭
Indexable Drilling
C074
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDSP1254-20T2-05 12.5
20 27
120 52 70
50
2
SPMG0502... TS2003 TK06
IDSP1304-20T2-05 13 2
IDSP1354-20T2-05 13.5 124 56 74 2
IDSP1404-20T2-05 14 2
IDSP1454-20T2-05 14.5 129 60 79 2
IDSP1504-20T2-05 15 2
IDSP1554-25T2-06 15.5
25 33
140 64 84
56
2
SPMG0602... TS2205 TK06
IDSP1604-25T2-06 16 2
IDSP1654-25T2-06 16.5 144 68 88 2
IDSP1704-25T2-06 17 2
IDSP1754-25T2-06 17.5 148 72 92 2
IDSP1804-25T2-06 18 2
IDSP1854-25T2-06 18.5 152 76 96 2
IDSP1904-25T2-06 19 2
IDSP1954-25T2-06 19.5 156 80 100 2
IDSP2004-25T2-06 20 2
IDSP2054-25T2-06 20.5 160 84 104 2
IDSP2104-25T2-06 21 2
IDSP2154-25T2-06 21.5 164 88 108 2
IDSP2204-25T2-07 22 2
SPMG07T3... TS2511 TK08
IDSP2254-32T2-07 22.5
32 43
177 92 117
60
2
IDSP2304-32T2-07 23 2
IDSP2354-32T2-07 23.5 181 96 121 2
IDSP2404-32T2-07 24 2
IDSP2454-32T2-07 24.5 185 100 125 2
IDSP2504-32T2-07 25 2
IDSP2554-32T2-07 25.5 189 104 129 2
IDSP2604-32T2-07 26 2
IDSP2654-32T2-07 26.5 196 108 136 2
IDSP2704-32T2-07 27 2
IDSP2754-32T2-07 27.5 200 112 140 2
Product Specs
．4×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with SPMG series inserts ．Indexable Insert with 4 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
DSP Indexable Drills - 4×D 內冷捨棄式快速鑽頭
Indexable Drilling
Drilling
C075
Product Specs
．4×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with SPMG series inserts ．Indexable Insert with 4 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDSP2804-32T2-09 28
32 43
200 112 140
60
2
SPMG0904... TS3504 TK15
IDSP2854-32T2-09 28.5 204 116 144 2
IDSP2904-32T2-09 29 2
IDSP2954-32T2-09 29.5 208 120 148 2
IDSP3004-32T2-09 30 2
IDSP3054-32T2-09 30.5 212 124 152 2
IDSP3104-32T2-09 31 2
IDSP3154-32T2-09 31.5 216 128 156 2
IDSP3204-32T2-09 32 2
IDSP3254-32T2-09 32.5 220 132 160 2
IDSP3304-32T2-09 33 2
IDSP3404-32T2-11 34 224 136 164 2
SPMG1104... TS4006 TK15
IDSP3504-32T2-11 35 228 140 168 2
IDSP3604-32T2-11 36 232 144 172 2
IDSP3704-32T2-11 37 236 148 176 2
IDSP3804-32T2-11 38 240 152 180 2
IDSP3904-32T2-11 39 244 156 184 2
IDSP4004-40T2-11 40 40 53 265 160 195 2
IDSP4104-40T2-11 41 269 164 199 2
DSP Indexable Drills - 4×D 內冷捨棄式快速鑽頭
Indexable Drilling
DSP Indexable Drills - 5×D
C076
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDSP1305-20T2-05 13
20 27
133 65 83
50
2
SPMG0502... TS2003 TK06IDSP1405-20T2-05 14 138 70 88 2
IDSP1505-20T2-05 15 144 75 94 2
IDSP1605-25T2-06 16
25 33
156 80 100
56
2
SPMG0602 TS2205 TK06
IDSP1705-25T2-06 17 161 85 105 2
IDSP1805-25T2-06 18 166 90 110 2
IDSP1905-25T2-06 19 171 95 115 2
IDSP2005-25T2-06 20 176 100 120 2
IDSP2105-25T2-06 21 181 105 125 2
IDSP2205-25T2-07 22 186 110 130 2
SPMG07T3 TS2511 TK08
IDSP2305-32T2-07 23
32 43
200 115 140
60
2
IDSP2405-32T2-07 24 205 120 145 2
IDSP2505-32T2-07 25 210 125 150 2
IDSP2605-32T2-07 26 215 130 155 2
IDSP2705-32T2-07 27 223 135 163 2
IDSP2805-32T2-09 28 228 140 168 2
SPMG0904 TS3504 TK15
IDSP2905-32T2-09 29 233 145 173 2
IDSP3005-32T2-09 30 238 150 178 2
IDSP3105-32T2-09 31 243 155 183 2
IDSP3205-32T2-09 32 248 160 188 2
IDSP3305-32T2-09 33 253 165 193 2
IDSP3405-32T2-11 34 258 170 198 2
SPMG1104 TS4006 TK15IDSP3505-32T2-11 35 263 175 203 2
IDSP3605-32T2-11 36 268 180 208 2
Product Specs
．5×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with SPMG series inserts ．Indexable Insert with 4 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
內冷捨棄式快速鑽頭
Indexable Drilling
Drilling
C077
DWC Indexable Drills
‧WCMT series inserts
‧Optimized ute design
‧Internal coolant
‧Better tool life
‧Self-Produced inserts
‧Diameter 14-60 mm
Product Features
‧使用 WCMT 系列刀片
‧排屑設計優化
‧內冷孔設計
‧良好刀具壽命
‧刀片全程自產，提供您最佳性價比
‧孔徑加工範圍 :14-60mm
內冷捨棄式快速鑽頭
Indexable Drilling
C078
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDWC1402-25T2-03 14
25 38
114 28 58
56
2
WCMT0302...
TS2502
TK08
IDWC1452-25T2-03 14.5 2
IDWC1502-25T2-03 15 116 30 60 2
TS2507
IDWC1552-25T2-03 15.5 2
IDWC1602-25T2-03 16 119 32 63 2
IDWC1652-25T2-03 16.5 2
IDWC1702-25T2-03 17 120 34 64 2
IDWC1752-25T2-03 17.5 2
IDWC1802-25T2-03 18 122 36 66 2
IDWC1852-25T2-03 18.5 2
IDWC1902-25T2-03 19 124 38 68 2
IDWC1952-25T2-03 19.5 2
IDWC2002-25T2-03 20 126 40 70 2
IDWC2052-25T2-03 20.5 2
IDWC2102-25T2-04 21 128 42 72 2
WCMT0402...
IDWC2152-25T2-04 21.5 2
IDWC2202-32T2-04 22
32 43
136 44 76
60
2
IDWC2252-32T2-04 22.5 2
IDWC2302-32T2-04 23 138 46 78 2
IDWC2352-32T2-04 23.5 2
IDWC2402-32T2-04 24 141 48 81 2
IDWC2452-32T2-04 24.5 2
IDWC2502-32T2-04 25 142 50 82 2
IDWC2552-32T2-04 25.5 2
IDWC2602-32T2-05 26 144 52 84 2
WCMT0503... TS3007 TK10
IDWC2702-32T2-05 27 146 54 86 2
IDWC2802-32T2-05 28 148 56 88 2
IDWC2902-32T2-05 29 150 58 90 2
IDWC3002-32T2-05 30 152 60 92 2
Product Specs
．2×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with WCMT series inserts ．Indexable Insert with 3 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
L
DWC Indexable Drills - 2×D 內冷捨棄式快速鑽頭
Indexable Drilling
Drilling
C079
Product Specs
．2×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with WCMT series inserts ．Indexable Insert with 3 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
L
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDWC3102-32T2-06 31
32 43
154 62 94
60
2
WCMT06T3... TS3504
TK15
IDWC3202-32T2-06 32 156 64 96 2
IDWC3302-32T2-06 33 159 66 99 2
IDWC3402-32T2-06 34 160 68 100 2
IDWC3502-32T2-06 35 162 70 102 2
IDWC3602-32T2-06 36 164 72 104 2
IDWC3702-32T2-06 37 166 74 106 2
IDWC3802-32T2-06 38 168 76 106 2
IDWC3902-32T2-06 39 170 78 110 2
IDWC4002-40T2-06 40
40
54
185 80 115
70
2
IDWC4102-40T2-06 41 187 82 117 2
IDWC4202-40T2-08 42 189 84 119 2
WCMT0804... TS4004
IDWC4302-40T2-08 43 191 86 121 2
IDWC4402-40T2-08 44 194 88 124 2
IDWC4502-40T2-08 45 195 90 125 2
IDWC4602-40T2-08 46 197 92 127 2
IDWC4702-40T2-08 47 199 94 129 2
IDWC4802-40T2-08 48 201 96 131 2
IDWC4902-40T2-08 49 202 98 132 2
IDWC5002-40T2-08 50 204 100 134 2
IDWC5102-40T2-08 51 206 102 136 2
IDWC5202-40T2-08 52 208 104 138 2
IDWC5302-40T2-08 53 210 106 140 2
IDWC5402-40T2-08 54 212 108 142 2
IDWC5502-40T2-08 55
58
215 110 145 2
IDWC5602-40T2-08 56 217 112 147 2
IDWC5702-40T2-08 57 219 114 149 2
IDWC5802-40T2-08 58 59 221 116 151 2
IDWC5902-40T2-08 59 223 118 153 2
IDWC6002-40T2-08 60 63 225 120 155
DWC Indexable Drills - 2×D 內冷捨棄式快速鑽頭
Indexable Drilling
C080
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDWC1403-25T2-03 14
25 38
128 42 72
56
2
WCMT0302...
TS2502
TK08
IDWC1453-25T2-03 14.5 2
IDWC1503-25T2-03 15 131 45 75 2
TS2507
IDWC1553-25T2-03 15.5 2
IDWC1603-25T2-03 16 134 48 78 2
IDWC1653-25T2-03 16.5 2
IDWC1703-25T2-03 17 137 51 81 2
IDWC1753-25T2-03 17.5 2
IDWC1803-25T2-03 18 140 54 84 2
IDWC1853-25T2-03 18.5 2
IDWC1903-25T2-03 19 143 57 87 2
IDWC1953-25T2-03 19.5 2
IDWC2003-25T2-03 20 146 60 90 2
IDWC2053-25T2-03 20.5 2
IDWC2103-25T2-04 21 149 63 93 2
WCMT0402...
IDWC2153-25T2-04 21.5 151 64 95 2
IDWC2203-32T2-04 22
32 43
158 66 98
60
2
IDWC2253-32T2-04 22.5 2
IDWC2303-32T2-04 23 161 69 101 2
IDWC2353-32T2-04 23.5 2
IDWC2403-32T2-04 24 164 72 104 2
IDWC2453-32T2-04 24.5 2
IDWC2503-32T2-04 25 167 75 107 2
IDWC2553-32T2-04 25.5 2
IDWC2603-32T2-05 26 170 78 110 2
WCMT0503... TS3007 TK10
IDWC2703-32T2-05 27 173 81 113 2
IDWC2803-32T2-05 28 176 84 116 2
IDWC2903-32T2-05 29 179 87 119 2
IDWC3003-32T2-05 30 182 90 122 2
IDWC3053-32T2-06 30.5 182 93 125 2 WCMT06T3... TS3504 TK15
IDWC3103-32T2-06 31 185 93 125 2
Product Specs
．3×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with WCMT series inserts ．Indexable Insert with 3 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
L
DWC Indexable Drills - 3×D 內冷捨棄式快速鑽頭
Indexable Drilling
Drilling
C081
Product Specs
．3×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with WCMT series inserts ．Indexable Insert with 3 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
L
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDWC3153-32T2-06 31.5
32 43
185 93 125
60
2
WCMT06T3... TS3504
TK15
IDWC3203-32T2-06 32 188 96 128 2
IDWC3253-32T2-06 32.5 188 96 128 2
IDWC3303-32T2-06 33 191 99 131 2
IDWC3403-32T2-06 34 194 102 134 2
IDWC3503-32T2-06 35 197 105 137 2
IDWC3603-32T2-06 36 200 108 140 2
IDWC3703-32T2-06 37 203 111 143 2
IDWC3803-32T2-06 38 206 114 146 2
IDWC3903-32T2-06 39 209 117 149
70
2
IDWC4003-40T2-06 40
40
54
225 120 155 2
IDWC4103-40T2-06 41 228 123 158 2
IDWC4203-40T2-08 42 231 126 161 2
WCMT0804... TS4004
IDWC4303-40T2-08 43 234 129 164 2
IDWC4403-40T2-08 44 238 132 168 2
IDWC4503-40T2-08 45 240 135 170 2
IDWC4603-40T2-08 46 243 138 173 2
IDWC4703-40T2-08 47 246 141 176 2
IDWC4803-40T2-08 48 249 144 179 2
IDWC4903-40T2-08 49 253 147 182 2
IDWC5003-40T2-08 50 254 150 184 2
IDWC5103-40T2-08 51 257 153 187 2
IDWC5203-40T2-08 52 260 156 190 2
IDWC5303-40T2-08 53 263 159 193 2
IDWC5403-40T2-08 54 266 162 196 2
IDWC5503-40T2-08 55
58
270 165 200 2
IDWC5603-40T2-08 56 273 168 203 2
IDWC5703-40T2-08 57 276 171 205 2
IDWC5803-40T2-08 58 59 279 174 209 2
IDWC5903-40T2-08 59 282 177 212 2
IDWC6003-40T2-08 60 63 285 180 215 2
DWC Indexable Drills - 3×D 內冷捨棄式快速鑽頭
Indexable Drilling
C082
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDWC1404-25T2-03 14
25 38
142 56 86
56
2
WCMT0302...
TS2502
TK08
IDWC1504-25T2-03 15 146 60 90 2
TS2507
IDWC1604-25T2-03 16 150 64 94 2
IDWC1704-25T2-03 17 154 68 98 2
IDWC1804-25T2-03 18 158 72 102 2
IDWC1904-25T2-03 19 162 76 106 2
IDWC2004-25T2-03 20 166 80 110 2
IDWC2104-25T2-04 21 170 84 114 2
WCMT0402... TS2507
IDWC2204-32T2-04 22
32 43
180 88 120
60
2
IDWC2304-32T2-04 23 184 92 124 2
IDWC2404-32T2-04 24 188 96 128 2
IDWC2504-32T2-04 25 192 100 132 2
IDWC2604-32T2-05 26 196 104 136 2
WCMT0503... TS3007 TK10
IDWC2704-32T2-05 27 200 108 140 2
IDWC2804-32T2-05 28 204 112 144 2
IDWC2904-32T2-05 29 208 116 148 2
IDWC3004-32T2-05 30 212 120 152 2
IDWC3104-32T2-06 31 216 124 156 2
WCMT06T3... TS3504 TK15
IDWC3204-32T2-06 32 220 128 160 2
IDWC3304-32T2-06 33 224 132 164 2
IDWC3404-32T2-06 34 228 136 168 2
IDWC3504-32T2-06 35 232 140 172 2
IDWC3604-32T2-06 36 236 144 176 2
IDWC3704-32T2-06 37 240 148 180 2
IDWC3804-32T2-06 38 244 152 184 2
IDWC3904-32T2-06 39 248 156 188 2
IDWC4004-40T2-06 40 40 54 265 160 195 70 2
IDWC4104-40T2-06 41 269 164 199 2
Product Specs
．4×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with WCMT series inserts ．Indexable Insert with 3 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
L
DWC Indexable Drills - 4×D 內冷捨棄式快速鑽頭
Indexable Drilling
Drilling
C083
Product Specs
．4×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with WCMT series inserts ．Indexable Insert with 3 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
L
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDWC4204-40T2-08 42
40
54
273 168 203
70
2
WCMT0804... TS4004 TK15
IDWC4304-40T2-08 43 277 172 207 2
IDWC4404-40T2-08 44 282 176 212 2
IDWC4504-40T2-08 45 285 180 215 2
IDWC4604-40T2-08 46 289 184 219 2
IDWC4704-40T2-08 47 293 188 223 2
IDWC4804-40T2-08 48 297 192 227 2
IDWC4904-40T2-08 49 301 196 231 2
IDWC5004-40T2-08 50 305 200 235 2
IDWC5104-40T2-08 51 309 204 239 2
IDWC5204-40T2-08 52 313 208 243 2
IDWC5304-40T2-08 53 317 212 247 2
IDWC5404-40T2-08 54 320 216 250 2
IDWC5504-40T2-08 55 325 220 255 2
IDWC5604-40T2-08 56 58 329 224 259 2
IDWC5704-40T2-08 57 333 228 263 2
IDWC5804-40T2-08 58 59 337 232 267 2
IDWC5904-40T2-08 59 341 236 271 2
IDWC6004-40T2-08 60 63 345 240 275 2
DWC Indexable Drills - 4×D 內冷捨棄式快速鑽頭
Indexable Drilling
C084
Item Code Dimensions, mm Teeth Insert Screw Wrench
D d d1 L L3 L2 L1
IDWC1605-25T2-03 16 25 38 166 80 110 56 2
WCMT0302... TS2507 TK08
IDWC1705-25T2-03 17 25 38 171 85 115 56 2
IDWC1805-25T2-03 18 25 38 176 90 120 56 2
IDWC1905-25T2-03 19 25 38 181 95 125 56 2
IDWC2005-25T2-03 20 25 38 186 100 130 56 2
IDWC2105-25T2-03 21 25 38 191 105 135 56 2
IDWC2205-25T2-03 22 25 38 196 110 140 56 2
IDWC2305-32T2-04 23 32 43 207 115 147 60 2
WCMT0402... TS2507 TK08IDWC2405-32T2-04 24 32 43 212 120 152 60 2
IDWC2505-32T2-04 25 32 43 217 125 157 60 2
IDWC2605-32T2-05 26 32 43 222 130 162 60 2
WCMT0503...
TS3007 TK10
IDWC2705-32T2-05 27 32 43 227 135 167 60 2
IDWC2805-32T2-05 28 32 43 232 140 172 60 2
IDWC2905-32T2-05 29 32 43 237 145 177 60 2
IDWC3005-32T2-05 30 32 43 242 150 182 60 2
IDWC3105-32T2-06 31 32 43 247 155 187 60 2
WCMT06T3... TS3504 TK15
IDWC3205-32T2-06 32 32 43 252 160 192 60 2
IDWC3305-32T2-06 33 32 43 257 165 197 60 2
IDWC3405-32T2-06 34 32 43 262 170 202 60 2
IDWC3505-32T2-06 35 32 43 267 175 207 60 2
IDWC3605-32T2-06 36 32 43 272 180 212 60 2
IDWC4405-40T2-08 44 40 54 326 220 256 70 2 WCMT0804... TS4004 TK15
Product Specs
．5×D Cutting depth ．High durable SDK holder body ．Internal Coolant
．Use with WCMT series inserts ．Indexable Insert with 3 sides cutting edge
．For Alloy Steel, Steel, Stainless Steel and Cast Iron.
L
DWC Indexable Drills - 5×D 內冷捨棄式快速鑽頭
Reaming Tools
Reaming
C085
DRC, DRN Solid Carbide Machine Reamers 內冷 & 外冷鎢鋼機械鉸刀
‧Unique durable UNIX coating
‧Specially for high accurate hole machining
‧Superior hole surface nish
‧Internal & external coolant available
‧Customized available
Product Features
‧高耐久 UNIX 鍍膜技術
‧專為高精度的孔加工設計
‧加工表面品質優異
‧內冷孔與外冷產品可供選擇
‧提供客製化服務冷
Reaming Tools
C086
DRC Solid Carbide Machine Reamers
P M K N S H
●○●●○
Product Specs
．Internal ．Straight flute ．UNIX Coating ．Tolerance h7
．Unequal ute spacing
．Provides high degree of accuracy of leave smooth sides
．
For blind hole using
．For steel, 400 series stainless steel, cast iron, aluminum Alloy
Order No. D L1 L2 L Ds F
DRC03000901 3.00 15 35 60 4 4
DRC03100901 3.10 15 35 60 4 4
DRC03200901 3.20 15 35 60 4 4
DRC03300901 3.30 15 35 60 4 4
DRC03400901 3.40 15 35 60 4 4
DRC03500901 3.50 18 35 60 4 4
DRC03600901 3.60 18 35 60 4 4
DRC03700901 3.70 18 35 60 4 4
DRC03800901 3.80 18 35 60 4 4
DRC03900901 3.90 18 35 60 4 4
DRC04000901 4.00 19 50 75 4 4
DRC04100901 4.10 19 50 75 6 4
DRC04200901 4.20 19 50 75 6 4
DRC04300901 4.30 19 50 75 6 4
DRC04400901 4.40 19 50 75 6 4
DRC04500901 4.50 21 50 75 6 4
DRC04600901 4.60 21 50 75 6 4
DRC04700901 4.70 21 50 75 6 4
DRC04800901 4.80 21 50 75 6 4
DRC04900901 4.90 21 50 75 6 4
DRC05000901 5.00 23 50 75 6 6
DRC05100901 5.10 23 50 75 6 6
DRC05200901 5.20 23 50 75 6 6
DRC05300901 5.30 23 50 75 6 6
DRC05400901 5.40 23 50 75 6 6
DRC05500901 5.50 26 50 75 6 6
DRC05600901 5.60 26 50 75 6 6
DRC05700901 5.70 26 50 75 6 6
DRC05800901 5.80 26 50 75 6 6
DRC05900901 5.90 26 50 75 6 6
DRC06000901 6.00 26 65 100 6 6
DRC06500901 6.50 28 65 100 8 6
DRC07000901 7.00 31 70 109 8 6
DRC07500901 7.50 31 70 109 8 6
DRC08000901 8.00 33 80 109 8 6
DRC08500901 8.50 33 80 125 10 6
DRC09000901 9.00 36 85 125 10 6
DRC09500901 9.50 36 85 125 10 6
DRC10000901 10.00 38 85 125 10 6
DRC10500901 10.50 38 85 125 12 6
DRC11000901 11.00 41 100 150 12 6
DRC11500901 11.50 41 100 150 12 6
DRC12000901 12.00 44 100 150 12 6
內冷鎢鋼機械鉸刀
Order No. D L1 L2 L Ds F
Reaming Tools
Reaming
C087
DRN Solid Carbide Machine Reamers
P M K N S H
● ● ●
Product Specs
．External ．Left Helix Angle ．UNIX Coating ．Tolerance h7
．Provide high degree of accuracy to leave smooth sides. ．For through hole using
．For Steel, Alloy Steel, Cast Iron, Aluminum Alloy.
外冷鎢鋼機械鉸刀
Order No. D L1 L2 L Ds FOrder No. D L1 L2 L Ds F
DRN03000901 3.00 15 35 60 4 4
DRN03100901 3.10 15 35 60 4 4
DRN03200901 3.20 15 35 60 4 4
DRN03300901 3.30 15 35 60 4 4
DRN03400901 3.40 15 35 60 4 4
DRN03500901 3.50 18 35 60 4 4
DRN03600901 3.60 18 35 60 4 4
DRN03700901 3.70 18 35 60 4 4
DRN03800901 3.80 18 35 60 4 4
DRN03900901 3.90 18 35 60 4 4
DRN04000901 4.00 19 50 75 4 4
DRN04100901 4.10 19 50 75 6 4
DRN04200901 4.20 19 50 75 6 4
DRN04300901 4.30 19 50 75 6 4
DRN04400901 4.40 19 50 75 6 4
DRN04500901 4.50 21 50 75 6 4
DRN04600901 4.60 21 50 75 6 4
DRN04700901 4.70 21 50 75 6 4
DRN04800901 4.80 21 50 75 6 4
DRN04900901 4.90 21 50 75 6 4
DRN05000901 5.00 23 50 75 6 6
DRN05100901 5.10 23 50 75 6 6
DRN05200901 5.20 23 50 75 6 6
DRN05300901 5.30 23 50 75 6 6
DRN05400901 5.40 23 50 75 6 6
DRN05500901 5.50 26 50 75 6 6
DRN05600901 5.60 26 50 75 6 6
DRN05700901 5.70 26 50 75 6 6
DRN05800901 5.80 26 50 75 6 6
DRN05900901 5.90 26 50 75 6 6
DRN06000901 6.00 26 65 100 6 6
DRN06500901 6.50 28 65 100 8 6
DRN07000901 7.00 31 70 109 8 6
DRN07500901 7.50 31 70 109 8 6
DRN08000901 8.00 33 80 109 8 6
DRN08500901 8.50 33 80 125 10 6
DRN09000901 9.00 36 85 125 10 6
DRN09500901 9.50 36 85 125 10 6
DRN10000901 10.00 38 85 125 10 6
DRN10500901 10.50 38 85 125 12 6
DRN11000901 11.00 41 100 150 12 6
DRN11500901 11.50 41 100 150 12 6
DRN12000901 12.00 44 100 150 12 6
C088
Endmills．Inserts．Drills
Boring Tools
C089
DB & DBLA rough boring head
‧Easy to adjust
‧High rigidity tool body
‧Various inserts available
‧Diameter 25mm to 610mm
‧易於調整加工孔徑
‧高剛性合金鋼本體
‧可適用多種刀片
‧適用 25-610mm 孔徑加工
FEATURES
雙刃粗搪刀 & 大徑雙刃粗搪刀
Boring
Boring Tools
C090
PSteel
Cutting Type : General Interrupted
MStainless steel
KCast iron
Inserts Designation
Grade Dimensions (mm)
Drawing
CX2565
CX2555
CX3565
CX3555
d l S r h
CCMT 060204-MP ✓ ✓ 6.35 6.4 2.38 0.4 2.8
09T304-MP ✓ ✓ 9.53 9.7 3.97 0.4 4.4
09T308-MP ✓ ✓ 9.53 9.7 3.97 0.8 4.4
CCMT 060202-MG ✓ ✓ 6.35 6.4 2.38 0.4 2.8
060204-MG ✓ ✓ 6.35 6.4 2.38 0.4 2.8
09T304-MG ✓ ✓ 9.53 9.7 3.97 0.4 4.4
09T308-MG ✓ ✓ 9.53 9.7 3.97 0.8 4.4
120408-MG ✓ ✓ 12.7 12.9 4.76 0.8 5.5
0.1 0.2 0.3 0.4 0.5 0.6
1
2
3
4
5
6
f (mm/rev)
ap (mm)
MP
0.1 0.2 0.3 0.4 0.5 0.6
1
2
3
4
5
6
f (mm/rev)
ap (mm)
MG
CCMT - Positive Turning Insert 搪刀刀片
Holder Page : C093, C095
Boring Tools
Boring
C091
PSteel
Cutting Type : General Interrupted
MStainless steel
KCast iron
Inserts Designation
Grade Dimensions (mm)
Drawing
CX2565
CX2555
CX3565
CX3555
d l S r h
SCMT 09T304-MG ✓ ✓ 9.53 9.53 3.97 0.4 4.4
09T308-MG ✓ ✓ 9.53 9.53 3.97 0.8 4.4
0.1 0.2 0.3 0.4 0.5 0.6
1
2
3
4
5
6
f (mm/rev)
ap (mm)
MG
SCMT - Positive Turning Insert 搪刀刀片
Holder Page : C093, C095
Boring Tools
C092
PSteel
Cutting Type : General Interrupted
MStainless steel
KCast iron
Inserts Designation
Grade Dimensions (mm)
Drawing
CX2565
CX2555
CX3565
CX3555
d l S r h
TCMT 110204-MP ✓ ✓ 6.35 11.0 2.38 0.4 2.8
TCMT 110204-MG ✓ ✓ 6.35 11.0 2.38 0.4 2.8
16T304-MG ✓ ✓ 9.53 16.5 3.97 0.4 4.4
16T308-MG ✓ ✓ 9.53 16.5 3.97 0.8 4.4
0.1 0.2 0.3 0.4 0.5 0.6
1
2
3
4
5
6
f (mm/rev)
ap (mm)
MP
0.1 0.2 0.3 0.4 0.5 0.6
1
2
3
4
5
6
f (mm/rev)
ap (mm)
MG
TCMT - Positive Turning Insert 搪刀刀片
Holder Page : C093, C095
Boring Tools
Boring
C093
Adjustable twin boring arm system for variety situation of rough boring.
Reliable cartridge system provides high rigidity and eciency.
Step boring arm design, suitable for single bit boring, twin bit boring, and step boring.
Side division easy to adjust tool extended without pre-setter.
Boring diameter from 25mm to 204mm.
●
●
●
●
●
Order No. LBK No. Boring Range
ØD (mm)
L
(mm)
C
(mm) Insert Weight
(kg)
IDB25-33-C IDB2 25 ~ 33 45 24 CCMT060204 0.15
IDB32-42-C
IDB3 32 ~ 42 55 31
CCMT060204
0.3
IDB32-42-T TCMT110204
IDB40-55-C
IDB4 40 ~ 5565 39
CCMT09T304
0.5IDB40-55-T TCMT16T304
IDB40-55-S SCMT09T304
IDB52-70-C
IDB5 52 ~ 70 75 50
CCMT09T304
1.0IDB52-70-T TCMT16T304
IDB52-70-S SCMT09T304
IDB68-92-C
IDB6
68 ~ 92 85 64
CCMT120408
2.0IDB68-92-T TCMT16T304
IDB68-92-S SCMT09T304
IDB90-122-C 90 ~ 122 100 80 CCMT120408 2.9
IDB120-164-C
IDB20
120 ~ 164 100 100 CCMT120408 3.8
IDB160-204-C 160 ~ 204 130 130 CCMT120408 4.8
DB Rough boring head 雙刃粗搪刀
Boring Tools
C094
Order No. Type ØD
(mm)
Z
(mm)
Tool Connection LBK No. L
(mm)
L1
(mm)
D1
(mm)
Weight
(kg)
IDB Shank Type Boring Head Type
IDB-BT30-25-125
Fig. 2
25 ~ 33 95 IDB-BT30-2-80 IDB25-33 IDB2 125 80 24 0.8
IDB-BT30-32-135 32 ~ 42
105
IDB-BT30-3-80 IDB32-42 IDB3
135
31 1.0
IDB-BT30-40-135 40 ~ 55 IDB-BT30-4-70 IDB40-55 IDB4 70 39 1.3
IDB-BT30-52-135 52 ~ 70 IDB-BT30-5-60 IDB52-70 IDB5
60
50 1.8
IDB-BT30-68-145 68 ~ 92 115 IDB-BT30-6-60 IDB68-92 IDB6 145 64 3.0
IDB-BT30-90-160 90 ~ 122 130 IDB90-122 160 3.9
IDB-BT40-25-130 25 ~ 33 95 IDB-BT40-2-85 IDB25-33 IDB2 130 85 24 1.3
IDB-BT40-32-150 32 ~ 42
115
IDB-BT40-3-95 IDB32-42 IDB3
150
95 31 1.5
IDB-BT40-40-150 40 ~ 55 IDB-BT40-4-85 IDB40-55 IDB4 85 39 1.8
IDB-BT40-52-150 52 ~ 70 IDB-BT40-5-75 IDB52-70 IDB5 75 50 2.3
IDB-BT40-68-150 68 ~ 92 IDB-BT40-6-65 IDB68-92 IDB6 65 64 3.3
IDB-BT40-90-165 90 ~ 122
130
IDB90-122
165
4.2
IDB-BT40-120-165 120 ~ 164 IDB-BT40-120-70 IDB120-164 IDB120 70 95 7.0
IDB-BT40-160-165 160 ~ 204 IDB160-204 8.0
IDB-BT50-25-155 25 ~ 33 105 IDB-BT50-2-110 IDB25-33 IDB2 155 110 24 4.1
IDB-BT50-32-180 32 ~ 42 130 IDB-BT50-3-125 IDB32-42 IDB3 180 125 31 4.4
IDB-BT50-40-180 40 ~ 55 IDB-BT50-4-115 IDB40-55 IDB4 115 39 4.8
IDB-BT50-40-240 190 IDB-BT50-4-175 240 175 5.3
IDB-BT50-52-180
52 ~ 70
130 IDB-BT50-5-105
IDB52-70 IDB5
180 105
50
5.5
IDB-BT50-52-255 205 IDB-BT50-5-180 255 180 6.5
IDB-BT50-52-315 265 IDB-BT50-5-240 315 240 7.2
IDB-BT50-68-180
68 ~ 92
130 IDB-BT50-6-95
IDB68-92
IDB6
180 105
64
6.5
IDB-BT50-68-255 205 IDB-BT50-6-170 255 180 8.3
IDB-BT50-68-315 265 IDB-BT50-6-230 315 240 9.6
IDB-BT50-68-375 325 IDB-BT50-6-290 375 290 11.0
IDB-BT50-68-435 Fig. 1 385 IDB-BT50-6-350 435 350 15.5
IDB-BT50-90-195
Fig. 2
90 ~ 122
145 IDB-BT50-6-95
IDB90-122
195 95 7.4
IDB-BT50-90-270 220 IDB-BT50-6-170 270 170 9.2
IDB-BT50-90-330 280 IDB-BT50-6-230 330 230 10.5
IDB-BT50-90-390 Fig. 1 340 IDB-BT50-6-290 390 290 11.9
IDB-BT50-90-450
Fig. 2
400 IDB-BT50-6-350 450 350 16.4
IDB-BT50-120-195 150 IDB-BT50-120-100
IDB120-164 IDB120
195 100
95
8.8
IDB-BT50-120-295 250 IDB-BT50-200 295 200 11.3
IDB-BT50-120-395 350 IDB-BT50-300 395 300 13.8
IDB-BT50-120-495
160 ~ 204
450 IDB-BT50-400 495 400 16.3
IDB-BT50-160-195 150 IDB-BT50-100 195 100 9.8
IDB-BT50-160-295 250 IDB-BT50-200 295 200 12.3
IDB-BT50-160-395 350 IDB-BT50-300 395 300 14.8
IDB-BT50-160-495 450 IDB-BT50-400 495 400 17.3
Fig. 1
Fig. 2
DB Rough boring tool 雙刃粗搪刀含 BT 刀柄
Boring Tools
Boring
C095
Optional accessories for dierent boring work and working diameter.
Reliable cartridge system provides high rigidity and eciency.
Alloy steel body provides great rigidity to large size rough boring.
Variable inserts for dierent material of rough boring.
Boring diameter from 200mm to 610mm.
●
●
●
●
●
Boring Head
Order No. IDBLA200 IDBLA300 IDBLA400 IDBLA500
Length (mm) 130
Total Weight (kg) 9.5 11.5 13.5 15.5
Module
Boring Range (mm) 200 ~ 310 300 ~ 410 400 ~ 510 500 ~ 610
Shank IDB-BT50-120-165
Flange BR200
Weight (kg) 2.7
Extension SlideRST200 RST300 RST400 RST500
Weight (kg) 3.4 5.4 7.4 9.4
Clamp Base RS200
Weight (kg) 0.98
Height Setting Shim RS201
Weight (kg) 0.05
Insert Height RB200C12, RB200T16
Insert CCMT1204... , TCMT16T3...
Weight (kg) 0.68
DBLA Rough boring head for large hole 大徑雙刃粗搪刀
Boring Tools
C096
Order No. Boring Range
ØD(mm)
Z
(mm) Shank Type Boring Head
Type LNK No. L
(mm)
L1
(mm)
D1
(mm)
Weight
IDBLA-BT50-200-230
200 ~ 310
185 IDB-BT50-120-100
IDBLA200
IDB120
230 100
95
18
IDBLA-BT50-200-330 285 IDB-BT50-120-200 330 200 19
IDBLA-BT50-200-430 385 IDB-BT50-120-300 430 300 23
IDBLA-BT50-200-530 485 IDB-BT50-120-400 530 400 27
IDBLA-BT50-300-230
300 ~ 410
185 IDB-BT50-120-100
IDBLA300
230 100 20
IDBLA-BT50-300-330 285 IDB-BT50-120-200 330 200 21
IDBLA-BT50-300-430 385 IDB-BT50-120-300 430 300 25
IDBLA-BT50-300-530 485 IDB-BT50-120-400 530 400 29
IDBLA-BT50-400-230
400 ~ 510
185 IDB-BT50-120-100
IDBLA400
230 100 22
IDBLA-BT50-400-330 285 IDB-BT50-120-200 330 200 23
IDBLA-BT50-400-430 385 IDB-BT50-120-300 430 300 27
IDBLA-BT50-400-530 485 IDB-BT50-120-400 530 400 31
IDBLA-BT50-500-230
500 ~ 610
185 IDB-BT50-120-100
IDBLA500
230 100 24
IDBLA-BT50-500-330 285 IDB-BT50-120-200 330 200 25
IDBLA-BT50-500-430 385 IDB-BT50-120-300 430 300 29
IDBLA-BT50-500-530 485 IDB-BT50-120-400 530 400 33
DBLA Rough boring tool for large hole 大徑雙刃粗搪刀含 BT 刀柄
Boring Tools
Boring
C097
Order No. Type OAL with boring head (L)
(mm)
L1
(mm)
ØD
(mm) Weight
IDB1-BT30-105
Fig. 2
105 70 19 0.70
IDB2-BT30-120 120 80 24 0.80
IDB3-BT30-120 120 80 31 0.90
IDB4-BT30-120 120 70 39 1.00
IDB5-BT30-120 120 60 50 1.10
IDB6-BT30-130 130 60 64 1.20
IDB1-BT40-110 110 75 19 1.20
IDB2-BT40-125 125 85 24 1.30
IDB3-BT40-135 135 95 31 1.45
IDB4-BT40-135 135 85 39 1.50
IDB5-BT40-135 135 75 50 1.40
IDB6-BT40-135 135 65 64 2.15
IDB1-BT50-150 Fig. 1 150 115 19 3.50
IDB2-BT50-150
Fig. 2
155 110 24 4.20
IDB3-BT50-165 165 125 31 4.40
IDB4-BT50-165 165 115 39 4.80
IDB4-BT50-225 225 175 39 5.20
IDB5-BT50-165 165 105 50 5.90
IDB5-BT50-240 240 180 50 6.50
IDB5-BT50-300 300 240 50 6.90
IDB6-BT50-165 165 95 64 4.09
IDB6-BT50-240 240 170 64 6.15
IDB6-BT50-300 300 230 64 7.74
IDB6-BT50-360 Fig. 1 290 290 64 9.07
IDB6-BT50-420 Fig. 2 420 350 90 13.51
IDB120-BT40-200
Fig. 3
170 70 95 3.20
IDB120-BT50-230 205 105 95 5.71
IDB120-BT50-330 300 200 95 8.79
IDB120-BT50-430 400 300 95 11.25
IDB120-BT50-530 530 430 95 13.74
Fig. 1
Fig. 2
Fig. 3
DBBT Taper shank 搪刀刀柄
Technical Data
Work Material
Drill Diameter Ø3-6mm Ø6.1~10mm Ø10.1-16mm
Hardness
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
P
Mild Steel (<180HB) 70~120 0.1~0.2 90~130 0.15~0.3 110~150 0.25~0.4
Cabon Steel (180~280HB) 70~110 0.1~0.2 90~120 0.15~0.3 110~140 0.25~0.4
Alloy Steel (280~350HB) 60~100 0.08~0.18 65~110 0.15~0.27 80~120 0.22~0.35
MStainless Steel (<200HB) 35~60 0.06~0.15 45~80 0.1~0.25 55~100 0.2~0.3
K
Cast lron (<350Mpa) 70~100 0.1~0.2 80~120 0.15~0.3 90~140 0.25~0.4
Ductile Cast lron (<450Mpa) 50~80 0.1~0.2 60~90 0.15~0.3 70~110 0.25~0.4
N
Aluminum <12% Si -80~140 0.1~0.25 100~160 0.15~0.35 110~180 0.3~0.45
Aluminum >12% Si -70~120 0.1~0.25 90~130 0.15~0.35 100~150 0.3~0.45
SHeat Resistant Alloy - 15~30 0.02~0.08 20~40 0.04~0.1 25~45 0.06~0.12
HHardened Material 40~60HRC 10~25 0.02~0.08 15~35 0.04~0.1 20~40 0.06~0.12
DPC, DMC (Internal Coolant)
DPN, DFN, DGN (External Coolant)
Work Material
Drill Diameter Ø3-6mm Ø6.1~10mm Ø10.1-16mm
Hardness
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
P
Mild Steel (<180HB) 40~70 0.1~0.2 55~85 0.15~0.3 60~100 0.25~0.4
Cabon Steel (180~280HB) 35~65 0.1~0.2 50~80 0.15~0.3 55~90 0.25~0.4
Alloy Steel (280~350HB) 30~60 0.08~0.18 40~75 0.15~0.27 50~85 0.22~0.35
MStainless Steel (<200HB) 20~40 0.06~0.15 25~50 0.1~0.25 30~60 0.2~0.3
K
Cast lron (<350Mpa) 40~60 0.1~0.2 50~75 0.15~0.3 55~85 0.25~0.4
Ductile Cast lron (<450Mpa) 35~55 0.1~0.2 45~70 0.15~0.3 50~80 0.25~0.4
N
Aluminum <12% Si -60~100 0.1~0.25 65~115 0.15~0.35 70~130 0.3~0.45
Aluminum >12% Si -50~90 0.1~0.25 60~110 0.15~0.35 65~120 0.3~0.45
SHeat Resistant Alloy - 15~30 0.02~0.08 20~40 0.04~0.1 25~45 0.06~0.12
HHardened Material 40~60HRC 10~25 0.02~0.08 15~35 0.04~0.1 20~40 0.06~0.12
Recommended Cutting Conditions 切削條件數據表
Warning :For slope drilling, please adjust cutting data acording to inclined angle
1. For inclined angle under 20 degree, reduce the feed to 50%
2. For inclined angle between 20 to 50 degree, reduce the feed to 40%, and reduce rotation to 70%
3. For inclined angle between 50 to 65 degree, reduce the feed to 30%, and reduce rotation to 70%
4. Not recommend to side milling
C098
Technical Data
DZC, DDC, DHC, DLC (Internal Coolant)
Work Material
Drill Diameter Ø3-6mm Ø6.1~10mm Ø10.1-16mm
Hardness
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
P
Mild Steel (<180HB) 60~100 0.1~0.2 80~120 0.15~0.3 100~140 0.25~0.4
Cabon Steel (180~280HB) 60~90 0.1~0.2 80~110 0.15~0.3 100~130 0.25~0.4
Alloy Steel (280~350HB) 50~80 0.08~0.18 60~100 0.15~0.27 70~110 0.22~0.35
MStainless Steel (<200HB) 30~50 0.06~0.15 40~70 0.1~0.25 50~90 0.2~0.3
K
Cast lron (<350Mpa) 70~100 0.1~0.2 80~120 0.15~0.3 90~140 0.25~0.4
Ductile Cast lron (<450Mpa) 50~80 0.1~0.2 60~90 0.15~0.3 70~110 0.25~0.4
N
Aluminum <12% Si -70~120 0.1~0.25 80~140 0.15~0.35 90~160 0.3~0.45
Aluminum >12% Si -60~100 0.1~0.25 70~120 0.15~0.35 90~140 0.3~0.45
SHeat Resistant Alloy - 15~30 0.02~0.08 20~40 0.04~0.1 25~45 0.06~0.12
HHardened Material 40~60HRC 10~25 0.02~0.08 15~35 0.04~0.1 20~40 0.06~0.12
Note:DDC drills require an initial pilot hole to help guide the drill.
DZN (External Coolant)
Note: for DLN please use 3-6mm table, for smaller size please reduce 20%.
Work Material
Drill Diameter Ø3-6mm Ø6.1~10mm Ø10.1-16mm
Hardness
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
P
Mild Steel (<180HB) 35~60 0.1~0.2 45~75 0.15~0.3 50~85 0.25~0.4
Cabon Steel (180~280HB) 30~55 0.1~0.2 40~70 0.15~0.3 45~80 0.25~0.4
Alloy Steel (280~350HB) 25~50 0.08~0.18 35~65 0.15~0.27 40~75 0.22~0.35
MStainless Steel (<200HB) 20~40 0.06~0.15 25~50 0.1~0.25 30~60 0.2~0.3
K
Cast lron (<350Mpa) 40~60 0.1~0.2 50~75 0.15~0.3 55~85 0.25~0.4
Ductile Cast lron (<450Mpa) 35~55 0.1~0.2 45~70 0.15~0.3 50~80 0.25~0.4
N
Aluminum <12% Si -60~100 0.1~0.25 65~115 0.15~0.35 70~130 0.3~0.45
Aluminum >12% Si -50~90 0.1~0.25 60~110 0.15~0.35 65~120 0.3~0.45
SHeat Resistant Alloy -15~30 0.02~0.08 20~40 0.04~0.1 25~45 0.06~0.12
HHardened Material 40~60HRC 10~25 0.02~0.08 15~35 0.04~0.1 20~40 0.06~0.12
Recommended Cutting Conditions 切削條件數據表
C099
Technical Data
Technical Data
DSP (2×D, 3×D)
Apply for 4×D reduce 10%, 5×D reduce 15%.
DWC (2×D, 3×D)
Apply for 4×D reduce 10%, 5×D reduce 15%.
Work Material Hardness Cutting speed
Vc (m/min)
Feed Rate (mm/rev)
SPMG05
Ø13-Ø15
SPMG06
Ø16-Ø21
SPMG07
Ø22-Ø27
SPMG09
Ø28-Ø33
SPMG11
Ø34-Ø41
P
Mild Steel (<180HB) 220~350 0.04~0.08 0.05~0.10 0.06~0.13 0.07~0.15 0.08~0.18
Cabon Steel (180~280HB) 100~150 0.04~0.08 0.05~0.09 0.06~0.12 0.07~0.13 0.08~0.15
Alloy Steel (280~350HB) 80~140 0.04~0.07 0.05~0.08 0.05~0.09 0.06~0.12 0.07~0.14
MStainless Steel (<200HB) 80~180 0.04~0.08 0.05~0.09 0.05~0.10 0.06~0.12 0.07~0.14
K
Cast lron (<350Mpa) 150~250 0.05~0.09 0.07~0.12 0.08~0.15 0.09~0.17 0.12~0.20
Ductile Cast lron (<450Mpa) 100~160 0.05~0.08 0.06~0.11 0.07~0.13 0.08~0.15 0.10~0.18
N
Aluminum <12% Si -300~400 0.05~0.11 0.07~0.13 0.08~0.15 0.09~0.20 0.12~0.25
Aluminum >12% Si -200~330 0.04~0.08 0.05~0.10 0.06~0.13 0.07~0.15 0.08~0.18
SHeat Resistant Alloy -30~60 0.02~0.04 0.03~0.05 0.03~0.05 0.04~0.06 0.05~0.08
HHardened Material 40~60HRC 30~60 0.02~0.04 0.03~0.05 0.03~0.05 0.04~0.06 0.05~0.08
Work Material Hardness Cutting speed
Vc (m/min)
Feed Rate (mm/rev)
WCMT03
Ø14-Ø20.5
WCMT04
Ø22-Ø25.5
WCMT05
Ø26-Ø30
WCMT06
Ø31-Ø39
WCMT08
Ø40-Ø60
P
Mild Steel (<180HB) 110~220 0.06~0.09 0.06~0.11 0.07~0.13 0.08~0.18 0.10~0.25
Cabon Steel (180~280HB) 90~140 0.06~0.09 0.06~0.11 0.07~0.13 0.08~0.18 0.10~0.25
Alloy Steel (280~350HB) 70~120 0.05~0.07 0.05~0.09 0.06~0.11 0.07~0.14 0.08~0.17
MStainless Steel (<200HB) 60~140 0.05~0.09 0.05~0.10 0.06~0.13 0.07~0.15 0.08~0.18
K
Cast lron (<350Mpa) 110~260 0.07~0.11 0.07~0.13 0.08~0.15 0.09~0.18 0.11~0.22
Ductile Cast lron (<450Mpa) 90~120 0.06~0.10 0.06~0.12 0.07~0.14 0.08~0.16 0.10~0.20
N
Aluminum <12% Si -200~360 0.06~0.11 0.08~0.13 0.09~0.15 0.11~0.18 0.12~0.25
Aluminum >12% Si -150~250 0.06~0.11 0.08~0.13 0.09~0.15 0.11~0.18 0.12~0.25
SHeat Resistant Alloy -25~50 0.03~0.05 0.03~0.06 0.04~0.08 0.05~0.10 0.06~0.12
HHardened Material - - - - - - -
Recommended Cutting Conditions 切削條件數據表
C100
Technical Data
Technical Data
Recommended Cutting Conditions 切削條件數據表
DRC (Internal Coolant)
Work Material
Drill Diameter Ø3-6mm Ø6.1~10mm Ø10.1-12mm
Hardness
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
P
Mild Steel (<180HB) 40~70 0.1~0.2 40~70 0.1~0.24 40~70 0.1~0.3
Cabon Steel (180~280HB) 25~50 0.1~0.2 25~50 0.1~0.24 25~50 0.1~0.3
Alloy Steel (280~350HB) 15~25 0.08~0.16 15~25 0.08~0.2 15~25 0.08~0.24
MStainless Steel (<200HB) 8~15 0.08~0.16 8~15 0.08~0.18 8~15 0.08~0.2
K
Cast lron (<350Mpa) 35~60 0.1~0.32 35~60 0.1~0.36 35~60 0.1~0.4
Ductile Cast lron (<450Mpa) 20~45 0.1~0.24 20~45 0.1~0.28 20~45 0.1~0.32
N
Aluminum <12% Si -110~195 0.12~0.32 110~195 0.12~0.36 110~195 0.12~0.4
Aluminum >12% Si -105~180 0.12~0.32 105~180 0.12~0.36 105~180 0.12~0.4
SHeat Resistant Alloy - 8~15 0.08~0.16 8~15 0.08~0.18 8~15 0.08~0.2
HHardened Material - - - - - - -
DRN (External Coolant)
Work Material
Drill Diameter Ø3-6mm Ø6.1~10mm Ø10.1-12mm
Hardness
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
Cutting Speed
(m/min)
Feed
(mm/rev)
P
Mild Steel (<180HB) 10~20 0.03~0.12 10~20 0.06~0.2 10~20 0.1~0.22
Cabon Steel (180~280HB) 10~16 0.03~0.12 10~16 0.06~0.2 10~16 0.1~0.22
Alloy Steel (280~350HB) 8~12 0.03~0.12 8~12 0.06~0.2 8~12 0.1~0.22
MStainless Steel - - - - - - -
K
Cast lron (<350Mpa) 8~16 0.03~0.12 8~16 0.06~0.02 8~16 0.1~0.22
Ductile Cast lron (<450Mpa) 8~16 0.03~0.12 8~16 0.06~0.02 8~16 0.1~0.22
N
Aluminum <12% Si -20~30 0.03~0.13 20~30 0.07~0.23 20~30 0.1~0.28
Aluminum >12% Si -20~30 0.03~0.13 20~30 0.07~0.23 20~30 0.1~0.28
SHeat Resistant Alloy - ------
HHardened Material - - - - - - -
C101
Technical Data
Recommended Cutting Conditions 切削條件數據表
Boring
Work Material Hardness
Cutting Speed
(m/min)
Feed
(mm/rev)
P
Mild Steel (<180HB) 90~200 0.04~0.14
Cabon Steel (180~280HB) 60~180 0.04~0.15
Alloy Steel (280~350HB) 50~150 0.04~0.15
MStainless Steel (<200HB) 60~230 0.07~0.12
K
Cast lron (<350Mpa) 120~230 0.04~0.13
Ductile Cast lron (<450Mpa) 120~230 0.04~0.13
N
Aluminum <12% Si -120~700 0.04~0.25
Aluminum >12% Si -120~700 0.04~0.25
SHeat Resistant Alloy - 20~80 0.04~0.05
HHardened Material - 20~70 0.04~0.05
C102
Technical Data
Technical Data
Helix Angle
Tip Angle 130°
Cutting Length
Overall Length
Ds
D
Type NX
External
Coolant
Helix Angle
Tip Angle 140°
Cutting Length
Overall Length
Ds
D
Type SX
External
Coolant
Reinforced Shank with Double Margins
Straight Shank
Reinforced Shank with Single Margin
Helix Angle Double MarginsTip Angle 140°
Cutting Length
Overall Length
Ds
D
Type SX
Internal
Coolant
For High Performance Series with Internal Coolant
For High Performance Series with External Coolant
For General Purpose Series with External Coolant
Geometry Design of Drills 鑽頭幾何設計
C103
Technical Data
Trouble / 情況 Occurrences / 原因 Countermeasures / 對策
Deformation of hole
鑽孔成橢圓
Becoming thread scratch in the hole
形成螺紋刮痕
1.Check for suitable Guide-bush
使用適合之鑽套
2.Reduce relief angle
減少間隙角度
3.Check for proper point angle & length of lips
檢查鑽頭尖端角度及兩邊長度是否對稱
Generation of chattering & vibration
產生顫動、振動
1.Reduce relief angle
減少間隙角度
2.Grind web thinning
腹板削薄
3.Shortening length of drill
縮短鑽頭長度，增加剛性
4.Check for proper drill
檢查鑽頭角度研磨是否正確
5.Check for chuck & collet & socket
檢查夾具與鑽頭接觸情形
6.Pre-centering
預先鑽好中心孔
7.Inspect rigidity of the drill machine
提高工作機械的剛性
Poor chip evacuation
切屑排出不易
1.Increase feed
加大每週進給量
2.Check for proper helix angle
選擇正確螺旋角
3.Check for proper chip space
加大槽寬比
4.Using step feed
採用間歇式進給
Deection of hole
鑽孔傾斜
Drill won't enter work
剛切入時不良
1.Check for suitable Guide-bush
使用適合之鑽套
2.Reduce feed
減少切入時之每週進給量
3.Pre-centering
預先鑽好中心孔
Insufficient rigidity of drill
鑽頭剛性不良
Shortening length of drill
縮短鑽頭長度，增加剛性
Unsuitable angle
鑽頭角度不對
Regrinding
再研磨
Excessive wear
of cutting edge
外角磨損
Cutting speed too high
切削速度太快
1.Reduce cutting speed
降低切削速度
2.Check lip relief
加大間隙角
3.Increase coolant ow
充分供給切削液
4.Check for proper material
提高鑽頭之材質
Drill Troubleshooting Guide 鑽削加工異常原因及對策
C104
Technical Data
Technical Data
Trouble / 情況 Occurrences / 原因 Countermeasures / 對策
Poor surface
conditions
of work piece
孔壁粗糙
Excessive wear of cutting edge
刀刃磨損太大
Regrinding
再研磨
Too much feed
進刀速度太大
Decrease feed
降低進刀速度
Chips clog in hole
切削阻塞
Add number of exit
增加退刀次數
The others
其他
1.Thin web
腹板削薄
2.Check for proper Guide-bush
使用適合導套
3.Use the highly rigid spindle
採用高剛性主軸
Breakage
切削中鑽頭折斷
Feed too heavy
進給量太大
Decrease feed rate
減少每週進給量
Chips clog in hole
切削阻塞
1.Check for proper chip space
加大槽寬比
2.Check for proper helix angle
選擇適當之螺旋角度
Insucient rigidity of drill
鑽頭剛性不足
1.Reduce feed
減少每週進告量
2.Shortening length of drill
縮短鑽頭長度，增加剛性
3.Increasing web thickness
腹板厚度加大
Unstable in throughout hole drilling
貫穿時安定性不夠 ( 工件不完全被夾住 )
1.Reduce feed while throughout drilling
降低貫穿時的每週進給量
2.Check set up rigidity
工作保持固定
3.Use the highly rigid spindle
採用高剛性主軸
Chipping
切唇崩刃
Feed speed too high
進給速度太快
Decrease feed rate
減少每週進給量
Tool high lip relief angle
切刃強度不足 ( 過度的間隙角度 )
1.Reduce lip relief angle
減少間隙角度
2.Reduce feed in drilling
降低貫空時的每週進給量
3.Check set up rigidity
工作保持固定
During oversize operation
使用在擴孔作業時
1.Properly grind point angle
加大尖端角度
2.Reduce cutting speed
降低切削速度
Hole oversize
孔徑擴大
Point angle is not properly, large chip
of one ute; small chip of other ute
尖端角度未對稱或刃大小不一
1.Regrinding
再研磨
2.Thin web
腹板削薄
3.Properly grind point angle
減少尖端角度
4.Guide-bush
使用鑽套
Drill Troubleshooting Guide 鑽削加工異常原因及對策
C105
Technical Data
Deep Hole Drilling Application Guide 深孔加工應用指南
C106
P M K N S H
●●●○○○
1Short drill for piloting
2Long drill into pilot hole
3Spotting
4Deep Hole drilling
5Retracting
2×D
1.5×D
3×D
Coolant : On/o
Coolant : O
Coolant : On
Coolant : On
Coolant : O
n = 100~500rpm
Vf > 500mm/min
Vc = 50%
Vf = 50%
Vc = 100%
Vf = 100%
n = 100~500rpm
Vf > 500mm/min
DP Series
DD Series
DD Series
DD Series
DD Series
