VALUE AT THE SPINDLE
High Performance
ISO 9001 Certified Company
Solid Carbide Tools
Drilling Solutions
New Expanded Offering
The second margin gives the Hi-PerCarb drill a burnishing effect and the ute form effectively controls and trans-
ports chips allowing the drill to offer superior surface nishes and hole size in high production environments
saving cycle time by often avoiding the need for reaming in many applications.
SGS HI-PERCARB SOLID CARBIDE DRILL AND REAMER
0
10
20
30
40
50
60
70
4140 Steel
@ 28 HRc
6AI4V Titanium
@ 30 HRc
MATERIAL GROUPS
AVERAGE SURFACE FINISH RESULTS
AVERAGE SURFACE FINISH IN RA
MATERIAL GROUPS
ACCURACY OF HOLE PRODUCED
0.3122
0.3124
0.3126
0.3128
0.3130
0.3132
0.3134
4140 Steel
@ 28 HRc
6AI4V Titanium
@ 30 HRc
MEASURED HOLE SIZE IN INCHES
0
5
10
15
20
25
30
35
40
45
4140 Steel
@ 28 HRc
6AI4V Titanium
@ 30 HRc
MATERIAL GROUPS
TOTAL CYCLE TIME
TIME PER HOLE IN SECONDS
PERFORMANCE.
MACHINING ENVIRONMENT:
Haas VM-3 with 9% Water Soluble Oil Flood Coolant
5/16” (.3125) diameter hole:
4140 application – .650” deep
6Al-4V application – 1.125” deep
PERFORMANCE. PRECISION. PASSION.
WITH HI-PERCARB EXTERNAL COOLANT DRILLS
The key features designed into the SGS Hi-PerCarb
drill allow the product to offer application benets not
only beyond that of standard carbide drills, but also
other High Performance drills. Each feature of the SGS
Hi-PerCarb drill was uniquely engineered as a solution
towards addressing the issues commonly encountered
during high production drilling.
A
B1
B2
C
D
E
HIGH PERFORMANCE FLUTE DESIGN
• efciently transports chips
• increases strength for aggressive drilling
B1
B2
C
D
E
A
Ti-NAMITE A COATING
• improves resistance to heat and wear
• enhances tool life
DOUBLE MARGIN DESIGN
improves accuracy and surface nish
• increases stability and rigidity
SECONDARY FLUTE
improves coolant ow to point
• reduces friction along drill body
• assists in ne swarf evacuation
SPECIALIZED 145° NOTCHED POINT
self centering eliminates need for spot drill
improves chip control
decreases drill thrust and deection
ENGINEERED EDGE PROTECTION
improves edge strength
reduces edge fatigue
allows increased feed rates
Solid Carbide Tools
The second margin gives the Hi-PerCarb drill a burnishing effect and the ute form effectively controls and trans-
ports chips allowing the drill to offer superior surface nishes and hole size in high production environments
saving cycle time by often avoiding the need for reaming in many applications.
SGS HI-PERCARB SOLID CARBIDE DRILL AND REAMER
0
10
20
30
40
50
60
70
4140 Steel
@ 28 HRc
6AI4V Titanium
@ 30 HRc
MATERIAL GROUPS
AVERAGE SURFACE FINISH RESULTS
AVERAGE SURFACE FINISH IN RA
MATERIAL GROUPS
ACCURACY OF HOLE PRODUCED
0.3122
0.3124
0.3126
0.3128
0.3130
0.3132
0.3134
4140 Steel
@ 28 HRc
6AI4V Titanium
@ 30 HRc
MEASURED HOLE SIZE IN INCHES
0
5
10
15
20
25
30
35
40
45
4140 Steel
@ 28 HRc
6AI4V Titanium
@ 30 HRc
MATERIAL GROUPS
TOTAL CYCLE TIME
TIME PER HOLE IN SECONDS
PERFORMANCE.
MACHINING ENVIRONMENT:
Haas VM-3 with 9% Water Soluble Oil Flood Coolant
5/16” (.3125) diameter hole:
4140 application – .650” deep
6Al-4V application – 1.125” deep
PERFORMANCE. PRECISION. PASSION.
WITH HI-PERCARB EXTERNAL COOLANT DRILLS
The key features designed into the SGS Hi-PerCarb
drill allow the product to offer application benets not
only beyond that of standard carbide drills, but also
other High Performance drills. Each feature of the SGS
Hi-PerCarb drill was uniquely engineered as a solution
towards addressing the issues commonly encountered
during high production drilling.
A
B1
B2
C
D
E
HIGH PERFORMANCE FLUTE DESIGN
• efciently transports chips
• increases strength for aggressive drilling
B1
B2
C
D
E
A
Ti-NAMITE A COATING
• improves resistance to heat and wear
• enhances tool life
DOUBLE MARGIN DESIGN
improves accuracy and surface nish
• increases stability and rigidity
SECONDARY FLUTE
improves coolant ow to point
• reduces friction along drill body
• assists in ne swarf evacuation
SPECIALIZED 145° NOTCHED POINT
self centering eliminates need for spot drill
improves chip control
decreases drill thrust and deection
ENGINEERED EDGE PROTECTION
improves edge strength
reduces edge fatigue
allows increased feed rates
Solid Carbide Tools
PRECISION.
The stability of the double margin design and penetration capability of the point geometry allow the Hi-PerCarb drill
to address demanding applications that would normally require reduced operating parameters or a two step process.
PASSION.
The secondary ute provides a channel for cooling capabilities normally not found in external coolant drills, this
combined with the Ti-NAMITE A tool coating and the high strength edge design results in increased operating
parameters with additional tool life.
ORIGINAL
TOTAL COST
TO DRILL
PER PART
$0.78
$0.12
(16%)
$0.05
(7%)
$0.20
(25%)
$0.15
(19%)
$0.23
(30%)
$0.02
(3%)
NEW
TOTAL COST
TO DRILL
PER PART
$0.17
$0.03
(16%)
$0.01
(7%)
$0.04
(25%)
$0.03
(19%)
$0.05
(30%)
$0.005
(3%)
TOTAL
COST TO DRILL
PER PART
REDUCED BY
$0.61
(79%)
$0.10
(12.51%)
$0.04
(5.47%)
$0.15
(19.55%)
$0.12
(14.86%)
$0.18
(23.46%)
$0.02
(2.35%)
COMPETITOR SGS HI-PERCARB
NUMBER OF PARTS TO PRODUCE 50000 50000
SURFACE FEET PER MINUTE (SFM) 74 124
SPEED IN REVOLUTIONS PER MINUTE (RPM) 1200 2000
FEED IN INCHES PER MINUTE (IPM) 3.6 10
NUMBER OF PARTS PRODUCED PER TOOL 140 500
DEPTH OF HOLE 0.6800 0.6800
NUMBER OF NEW TOOLS REQUIRED TO COMPLETE JOB 358 100
TOTAL HOURS OF MACHINING TIME 157 57
TOTAL MACHINING COST $10,231.48 $3,683.33
TOOL CHANGE COST $1,939.17 $541.67
TOTAL COST $39,017.07 $8,460.00
COST PER PART $0.78 $0.17
MATERIAL REMOVAL RATE (IN
3
/ MIN) – DRILLING 0.16 0.44
CUTTING TIME PER PART – MINUTES 0.19 0.07
SAVINGS PER PART – DOLLARS 0 $0.61
TOTAL COST SAVINGS / JOB – PERCENTAGE 0 78.32%
TOTAL COST SAVINGS / JOB – DOLLARS 0 $30,557.07
ACTUAL CUSTOMER APPLICATION USING A 6MM DRILL IN 17-4 PH STAINLESS STEEL
Using 100 tools per job compared to 358 means less inventory and fewer purchase orders
to issue resulting in improved administrative cost and reduced tooling cost per job.
Increasing the feed by 278% has decreased the total hours of machine time by 100 hours
gaining manufacturing capacity; this factored with the hourly shop rate has resulted in the
largest portion of the savings.
With a tool life of 500 parts compared to 140 parts or a 357% improvement in tool life
equates to less time dedicated to changing tools to keep the job running.
Increasing the material removal rate by .28 cubic inches or 275% requires less time
in the cut and a reduced use of coolant.
TOOL COST REDUCED BY
MACHINING COST REDUCED BY
COOLANT COST REDUCED BY
TOOL COST
MACHINING COST
COOLANT COST
MACHINE DOWNTIME COST
TOOL CHANGE COST
ADMINISTRATIVE COST
MACHINE DOWNTIME COST REDUCED BY
TOOL CHANGE COST REDUCED BY
ADMINISTRATIVE COST REDUCED BY
BLIND HOLE THROUGH HOLE CROSS HOLE PRECAST HOLE INTERRUPTIONS
PRECISION.
The stability of the double margin design and penetration capability of the point geometry allow the Hi-PerCarb drill
to address demanding applications that would normally require reduced operating parameters or a two step process.
PASSION.
The secondary ute provides a channel for cooling capabilities normally not found in external coolant drills, this
combined with the Ti-NAMITE A tool coating and the high strength edge design results in increased operating
parameters with additional tool life.
ORIGINAL
TOTAL COST
TO DRILL
PER PART
$0.78
$0.12
(16%)
$0.05
(7%)
$0.20
(25%)
$0.15
(19%)
$0.23
(30%)
$0.02
(3%)
NEW
TOTAL COST
TO DRILL
PER PART
$0.17
$0.03
(16%)
$0.01
(7%)
$0.04
(25%)
$0.03
(19%)
$0.05
(30%)
$0.005
(3%)
TOTAL
COST TO DRILL
PER PART
REDUCED BY
$0.61
(79%)
$0.10
(12.51%)
$0.04
(5.47%)
$0.15
(19.55%)
$0.12
(14.86%)
$0.18
(23.46%)
$0.02
(2.35%)
COMPETITOR SGS HI-PERCARB
NUMBER OF PARTS TO PRODUCE 50000 50000
SURFACE FEET PER MINUTE (SFM) 74 124
SPEED IN REVOLUTIONS PER MINUTE (RPM) 1200 2000
FEED IN INCHES PER MINUTE (IPM) 3.6 10
NUMBER OF PARTS PRODUCED PER TOOL 140 500
DEPTH OF HOLE 0.6800 0.6800
NUMBER OF NEW TOOLS REQUIRED TO COMPLETE JOB 358 100
TOTAL HOURS OF MACHINING TIME 157 57
TOTAL MACHINING COST $10,231.48 $3,683.33
TOOL CHANGE COST $1,939.17 $541.67
TOTAL COST $39,017.07 $8,460.00
COST PER PART $0.78 $0.17
MATERIAL REMOVAL RATE (IN
3
/ MIN) – DRILLING 0.16 0.44
CUTTING TIME PER PART – MINUTES 0.19 0.07
SAVINGS PER PART – DOLLARS 0 $0.61
TOTAL COST SAVINGS / JOB – PERCENTAGE 0 78.32%
TOTAL COST SAVINGS / JOB – DOLLARS 0 $30,557.07
ACTUAL CUSTOMER APPLICATION USING A 6MM DRILL IN 17-4 PH STAINLESS STEEL
Using 100 tools per job compared to 358 means less inventory and fewer purchase orders
to issue resulting in improved administrative cost and reduced tooling cost per job.
Increasing the feed by 278% has decreased the total hours of machine time by 100 hours
gaining manufacturing capacity; this factored with the hourly shop rate has resulted in the
largest portion of the savings.
With a tool life of 500 parts compared to 140 parts or a 357% improvement in tool life
equates to less time dedicated to changing tools to keep the job running.
Increasing the material removal rate by .28 cubic inches or 275% requires less time
in the cut and a reduced use of coolant.
TOOL COST REDUCED BY
MACHINING COST REDUCED BY
COOLANT COST REDUCED BY
TOOL COST
MACHINING COST
COOLANT COST
MACHINE DOWNTIME COST
TOOL CHANGE COST
ADMINISTRATIVE COST
MACHINE DOWNTIME COST REDUCED BY
TOOL CHANGE COST REDUCED BY
ADMINISTRATIVE COST REDUCED BY
BLIND HOLE THROUGH HOLE CROSS HOLE PRECAST HOLE INTERRUPTIONS
www.sgstool.com
6
SERIES 135
3xD
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
(continued on next page)
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
Series 135 3xD
|
External Coolant Drills
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
1/64 0.0156 1/8 1-1/2 1/8 5/64 1 51752
1/32 0.0312 1/8 1-1/2 1/4 3/16 1 51269
3/64 0.0469 1/16-64 1/8 1-1/2 3/8 5/16 1 51270
1,25 mm 0.0492 3,0 38,0 10,0 8,0 25,0
64500
1,45 mm 0.0571 3,0 38,0 10,0 8,0 25,0
64501
#53 0.0595 1/8 1-1/2 3/8 5/16 1
64502
1/16 0.0625 5/64-60 1/8 2 7/16 3/8 1-1/4 51271
1,6 mm 0.0630 3,0 50,0 12,0 9,0 32,0
64503
1,75 mm 0.0689 3,0 50,0 12,0 9,0 32,0
64504
#50 0.0700 1/8 2 7/16 3/8 1-1/4
64505
5/64 0.0781 1/8 2 1/2 7/16 1-1/4 51272
#47 0.0785 1/8 2 1/2 7/16 1-1/4
64506
2,05 mm 0.0807 3,0 50,0 14,0 11,0 32,0
64507
#46 0.0810 1/8 2 1/2 7/16 1-1/4
64508
#43 0.0890 1/8 2 1/2 7/16 1-1/4
64509
#42 0.0935 1/8 2 1/2 7/16 1-1/4
64510
3/32 0.0938 1/8-32 1/8 2 1/2 7/16 1-1/4 51273
40 0.0980 1/8 2 9/16 1/2 1-1/4 51274
2,5 mm 0.0984 3,0 50,0 1 7, 0 12,0 32,0
64511
39 0.0995 1/8 2 9/16 1/2 1-1/4 51753
38 0.1015 5-40 1/8 2 9/16 1/2 1-1/4 51754
37 0.1040 5-44 1/8 2 9/16 1/2 1-1/4 51755
36 0.1065 6-32 1/8 2 9/16 1/2 1-1/4 51756
7/64 0.1094 1/8 2 5/8 9/16 1-1/4 51275
35 0.1100 1/8 2 5/8 9/16 1-1/4 51276
34 0 .1110 1/8 2 5/8 9/16 1-1/4 51277
33 0.1130 6-40 1/8 2 5/8 9/16 1-1/4 51757
2,9 mm 0.1142 3,0 50,0 19,0 14,0 32,0
64512
32 0.1160 1/8 2 5/8 9/16 1-1/4 51758
3,0 mm 0.1181 6,0 62,0 20,0 1 7, 0 36,0 63155
31 0.1200 1/8 2 5/8 9/16 1-1/4 51759
3,1 mm 0.1220 6,0 62,0 20,0 1 7, 0 36,0 63741
1/8 0.1250 1/4 2-1/2 3/4 21/32 1-7/16 51330
3,2 mm 0.1260 M3,5 X 0,35 6,0 62,0 20,0 1 7, 0 36,0 63156
30 0.1285 1/4 2-1/2 3/4 21/32 1-7/16 51278
3,3 mm 0.1299 M4 X 0,7 6,0 62,0 20,0 1 7, 0 36,0 63157
3,4 mm 0.1339 6,0 62,0 20,0 1 7, 0 36,0 63158
29 0.1360 8-32,8-36 1/4 2-1/2 3/4 21/32 1-7/16 51331
3,5 mm 0.1378 M4 X 0,5 6,0 62,0 20,0 1 7, 0 36,0 63159
28 0.1405 8-40 1/4 2-1/2 3/4 2w 1-7/16 51760
9/64 0.1406 1/4 2-1/2 3/4 21/32 1-7/16 51332
3,6 mm 0.1417 M4 X 0,35 6,0 62,0 20,0 1 7, 0 36,0 63160
New Expanded Tools
www.sgstool.com
7
Series 135 3xD
|
External Coolant Drills
SERIES 135
3xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
27 0.1440 1/4 2-1/2 3/4 21/32 1-7/16 51761
3,7 mm 0.1457 M4.5 X 0,75 6,0 62,0 20,0 1 7, 0 36,0 63161
26 0.1470 3/16-24 1/4 2-1/2 3/4 21/32 1-7/16 51762
25 0.1495 10-24 1/4 2-5/8 7/8 23/32 1-7/16 51333
3,8 mm 0.1496 6,0 66,0 24,0 21,0 36,0 63472
24 0.1520 10-28 1/4 2-5/8 7/8 23/32 1-7/16 51763
3,9 mm 0.1535 6,0 66,0 24,0 21,0 36,0 63743
23 0.1540 1/4 2-5/8 7/8 23/32 1-7/16 51764
5/32 0.1562 1/4 2-5/8 7/8 23/32 1-7/16 51334
22 0.1570 10-30 1/4 2-5/8 7/8 23/32 1-7/16 51765
4,0 mm 0.1575 M4,5 X 0,5 6,0 66,0 24,0 21,0 36,0 63162
21 0.1590 10-32 1/4 2-5/8 7/8 23/32 1-7/16 51335
20 0.1610 13/64-24 1/4 2-5/8 7/8 23/32 1-7/16 51279
4,1 mm 0.1614 6,0 66,0 24,0 21,0 36,0 63744
4,2 mm 0.1654 M5 / M5 X 0,75 6,0 66,0 24,0 21,0 36,0 63163
19 0.1660 1/4 2-5/8 7/8 23/32 1-7/16 51766
4,3 mm 0.1693 6,0 66,0 24,0 21,0 36,0 63164
18 0.1695 1/4 2-5/8 7/8 23/32 1-7/16 51767
11/64 0.1719 1/4 2-5/8 7/8 23/32 1-7/16 51336
17 0.1730 1/4 2-5/8 7/8 23/32 1-7/16 51768
4,4 mm 0.1732 6,0 66,0 24,0 21,0 36,0 63745
16 0.1770 12-24 1/4 2-5/8 7/8 23/32 1-7/16 51769
4,5 mm 0.1772 M5 X 0,5 6,0 66,0 24,0 21,0 36,0 63165
15 0.1800 1/4 2-5/8 7/8 23/32 1-7/16 51770
4,6 mm 0.1811 12-28 6,0 66,0 24,0 21,0 36,0 63166
14 0.1820 1/4 2-5/8 7/8 23/32 1-7/16 51771
13 0.1850 12-32 1/4 2-5/8 7/8 23/32 1-7/16 51772
4,7 mm 0.1850 6,0 66,0 24,0 21,0 36,0 63746
3/16 0.1875 1/4 2-5/8 1 53/64 1-7/16 51337
12 0.1890 7/32-32 1/4 2-5/8 1 53/64 1-7/16 51773
4,8 mm 0.1890 6,0 66,0 28,0 24,0 36,0 63167
11 0.1910 1/4 2-5/8 1 53/64 1-7/16 51774
4,9 mm 0.1929 6,0 66,0 28,0 24,0 36,0 63747
10 0.1935 14-20 1/4 2-5/8 1 53/64 1-7/16 51775
9 0.1960 1/4 2-5/8 1 53/64 1-7/16 51776
5,0 mm 0.1969 M6 X 1 6,0 66,0 28,0 24,0 36,0 63168
8 0.1990 1/4 2-5/8 1 53/64 1-7/16 51777
5,1 mm 0.2008 6,0 66,0 28,0 24,0 36,0 63748
7 0.2010 1/4-20 1/4 2-5/8 1 53/64 1-7/16 51338
13/64 0.2031 1/4 2-5/8 1 53/64 1-7/16 51339
6 0.2040 1/4 2-5/8 1 53/64 1-7/16 51778
5,2 mm 0.2047 M6 X 0,75 6,0 66,0 28,0 24,0 36,0 63749
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
(continued on next page)
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
New Expanded Tools
www.sgstool.com
8
Series 135 3xD
|
External Coolant Drills
SERIES 135
3xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
5 0.2055 1/4 2-5/8 1 53/64 1-7/16 51779
5,25 mm 0.2067 6,0 66,0 28,0 24,0 36,0 63169
5,3 mm 0.2087 6,0 66,0 28,0 24,0 36,0 63170
4 0.2090 1/4-24 1/4 2-5/8 1 53/64 1-7/16 51780
5,4 mm 0.2126 6,0 66,0 28,0 24,0 36,0 63750
3 0.2130 1/4-28 1/4 2-5/8 1 53/64 1-7/16 51340
5,5 mm 0.2165 M6 X 0,5 6,0 66,0 28,0 24,0 36,0 63171
7/32 0.2188 1/4-32 1/4 2-5/8 1 53/64 1-7/16 51341
5,6 mm 0.2205 6,0 66,0 28,0 24,0 36,0 63751
2 0.2210 1/4 2-5/8 1 53/64 1-7/16 51781
5,7 mm 0.2244 6,0 66,0 28,0 24,0 36,0 63752
1 0.2280 1/4 2-5/8 1 53/64 1-7/16 51782
5,8 mm 0.2283 6,0 66,0 28,0 24,0 36,0 63172
5,9 mm 0.2323 6,0 66,0 28,0 24,0 36,0 63753
A 0.2340 1/4 2-5/8 1 53/64 1-7/16 51601
15/64 0.2344 1/4 2-5/8 1 53/64 1-7/16 51342
6,0 0.2362 M7 X 1 6,0 66,0 28,0 24,0 36,0 63173
B 0.2380 1/4 3-1/8 1-5/16 1-3/64 1-7/16 51602
6,1 mm 0.2402 8,0 79,0 34,0 28,0 36,0 63754
C 0.2420 1/4 3-1/8 1-5/16 1-3/64 1-7/16 51603
6,2 mm 0.2441 8,0 79,0 34,0 28,0 36,0 63755
D 0.2460 1/4 3-1/8 1-5/16 1-3/64 1-7/16 51604
6,25 mm 0.2461 M7 X 0,75 8,0 79,0 34,0 28,0 36,0 63174
6,3 mm 0.2480 8,0 79,0 34,0 28,0 36,0 63756
1/4 0.2500 1/4 3-1/8 1-5/16 1-3/64 1-7/16 51343
E 0.2500 1/4 3-1/8 1-5/16 1-3/64 1-7/16 51605
6,4 mm 0.2520 8,0 79,0 34,0 28,0 36,0 63175
6,5 mm 0.2559 8,0 79,0 34,0 28,0 36,0 63213
F 0.2570 5/16-18 5/16 3-1/8 1-5/16 1-3/64 1-7/16 51344
6,6 mm 0.2598 8,0 79,0 34,0 28,0 36,0 63757
G 0.2610 5/16 3-1/8 1-5/16 1-3/64 1-7/16 51606
6,7 mm 0.2638 8,0 79,0 34,0 28,0 36,0 63758
17/64 0.2656 5/16-20 5/16 3-1/8 1-5/16 1-3/64 1-7/16 51345
H 0.2660 5/16 3-1/8 1-5/16 1-3/64 1-7/16 51607
6,8 mm 0.2677 M8 X 1,25 8,0 79,0 34,0 28,0 36,0 63176
6,9 mm 0.2717 8,0 79,0 34,0 28,0 36,0 63759
I 0.2720 5/16-24 5/16 3-1/8 1-5/16 1-3/64 1-7/16 51346
7,0 mm 0.2756 M8 X 1 8,0 79,0 34,0 28,0 36,0 63177
J 0.2770 5/16 3-1/8 1-5/16 1-3/64 1-7/16 51608
7,1 mm 0.2795 8,0 79,0 41,0 34,0 36,0 63760
K 0.2810 5/16 3-1/8 1-9/16 1-3/16 1-7/16 51609
9/32 0.2812 5/16-32 5/16 3-1/8 1-9/16 1-3/16 1-7/16 51347
(continued on next page)
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
New Expanded Tools
www.sgstool.com
9
Series 135 3xD
|
External Coolant Drills
SERIES 135
3xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
7,2 mm 0.2835 8,0 79,0 41,0 34,0 36,0 63761
7,25 mm 0.2854 M8 X 0,75 8,0 79,0 41,0 34,0 36,0 63178
7,3 mm 0.2874 8,0 79,0 41,0 34,0 36,0 63762
L 0.2900 5/16 3-1/8 1-9/16 1-3/16 1-7/16 51610
7,4 mm 0.2913 8,0 79,0 41,0 34,0 36,0 63763
M 0.2950 5/16 3-1/8 1-9/16 1-3/16 1-7/16 51611
7,5 mm 0.2953 M8 X 0,5 8,0 79,0 41,0 34,0 36,0 63179
19/64 0.2969 5/16 3-1/8 1-9/16 1-3/16 1-7/16 51348
7,6 mm 0.2992 8,0 79,0 41,0 34,0 36,0 63764
N 0.3020 5/16 3-1/8 1-9/16 1-3/16 1-7/16 51612
7,7 mm 0.3031 8,0 79,0 41,0 34,0 36,0 63765
7,8 mm 0.3071 M9 X 1,25 8,0 79,0 41,0 34,0 36,0 63180
7,9 mm 0.3110 8,0 79,0 41,0 34,0 36,0 63766
5/16 0.3125 3/8-16 5/16 3-1/8 1-9/16 1-3/16 1-7/16 51349
8,0 mm 0.3150 M9 x 1 8,0 79,0 41,0 34,0 36,0 63181
O 0.3160 3/8 3-1/2 1-27/32 1-37/64 1-9/16 51613
8,1 mm 0.3189 10,0 89,0 47,0 40,0 40,0 63767
8,2 mm 0.3228 10,0 89,0 47,0 40,0 40,0 63768
P 0.3230 3/8 3-1/2 1-27/32 1-37/64 1-9/16 51614
8,3 mm 0.3268 10,0 89,0 47,0 40,0 40,0 63769
21/64 0.3281 3/8-20 3/8 3-1/2 1-27/32 1-37/64 1-9/16 51350
8,4 mm 0.3307 10,0 89,0 47,0 40,0 40,0 63182
Q 0.3320 3/8-24 3/8 3-1/2 1-27/32 1-37/64 1-9/16 51351
8,5 mm 0.3346 M10 X 1,5 10,0 89,0 47,0 40,0 40,0 63183
8,6 mm 0.3386 10,0 89,0 47,0 40,0 40,0 63770
R 0.3390 3/8 3-1/2 1-27/32 1-37/64 1-9/16 51615
8,7 mm 0.3425 10,0 89,0 47,0 40,0 40,0 63771
11/32 0.3438 3/8-32 3/8 3-1/2 1-27/32 1-37/64 1-9/16 51352
8,8 mm 0.3465 M10 X 1,25 10,0 89,0 47,0 40,0 40,0 63184
S 0.3480 3/8 3-1/2 1-27/32 1-37/64 1-9/16 51616
8,9 mm 0.3504 10,0 89,0 47,0 40,0 40,0 63772
9,0 mm 0.3543 M10 X 1 10,0 89,0 47,0 40,0 40,0 63185
T 0.3580 3/8 3-1/2 1-27/32 1-37/64 1-9/16 51617
9,1 mm 0.3583 10,0 89,0 47,0 40,0 40,0 63773
23/64 0.3594 3/8 3-1/2 1-27/32 1-37/64 1-9/16 51353
9,2 mm 0.3622 M10 X 0,75 10,0 89,0 47,0 40,0 40,0 63774
9,25 mm 0.3642 10,0 89,0 47,0 40,0 40,0 63186
9,3 mm 0.3661 10,0 89,0 47,0 40,0 40,0 63775
U 0.3680 7/16-14 3/8 3-1/2 1-27/32 1-37/64 1-9/16 51354
9,4 mm 0.3701 10,0 89,0 47,0 40,0 40,0 63776
9,5 mm 0.3740 M10 X 0,5 10,0 89,0 47,0 40,0 40,0 63187
3/8 0.3750 3/8 3-1/2 1-27/32 1-37/64 1-9/16 51355
(continued on next page)
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
New Expanded Tools
www.sgstool.com
10
Series 135 3xD
|
External Coolant Drills
SERIES 135
3xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
V 0.3770 1/2 3-1/2 1-27/32 1-37/64 1-9/16 51618
9,6 mm 0.3780 10,0 89,0 47,0 40,0 40,0 63777
9,7 mm 0.3819 10,0 89,0 47,0 40,0 40,0 63778
9,8 mm 0.3858 10,0 89,0 47,0 40,0 40,0 63779
W 0.3860 1/2 3-1/2 1-27/32 1-37/64 1-9/16 51619
9,9 mm 0.3898 10,0 89,0 47,0 40,0 40,0 63780
25/64 0.3906 7/16-20 1/2 3-1/2 1-27/32 1-37/64 1-9/16 51356
10,0 mm 0.3937 10,0 89,0 47,0 40,0 40,0 63188
X 0.3970 7/16-24 1/2 4-1/16 2-3/16 1-51/64 1-49/64 51620
10,1 mm 0.3976 12,0 102,0 55,0 45,0 45,0 63781
10,2 mm 0.4016 M12 X 1,75 12,0 102,0 55,0 45,0 45,0 63189
Y 0.4040 7/16-28 1/2 4-1/16 2-3/16 1-51/64 1-49/64 51621
10,3 mm 0.4055 12,0 102,0 55,0 45,0 45,0 63782
13/32 0.4062 1/2 4-1/16 2-3/16 1-51/64 1-49/64 51357
10,4 mm 0.4094 12,0 102,0 55,0 45,0 45,0 63783
Z 0.4130 1/2 4-1/16 2-3/16 1-51/64 1-49/64 51622
10,5 mm 0.4134 M12 X 1,5 12,0 102,0 55,0 45,0 45,0 63190
10,6 mm 0.4173 12,0 102,0 55,0 45,0 45,0 63784
10,7 mm 0.4213 12,0 102,0 55,0 45,0 45,0 63785
27/64 0.4219 1/2-13 1/2 4-1/16 2-3/16 1-51/64 1-49/64 51358
10,8 mm 0.4252 M12 X 1,25 12,0 102,0 55,0 45,0 45,0 63191
10,9 mm 0.4291 12,0 102,0 55,0 45,0 45,0 63786
11,0 mm 0.4331 M12 X 1 12,0 102,0 55,0 45,0 45,0 63192
11,1 mm 0.4370 12,0 102,0 55,0 45,0 45,0 63787
7/16 0.4375 1/4-18 NPT 1/2 4-1/16 2-3/16 1-51/64 1-49/64 51359
11,2 mm 0.4409 12,0 102,0 55,0 45,0 45,0 63788
11,25 mm 0.4429 12,0 102,0 55,0 45,0 45,0 63193
11,3 mm 0.4449 12,0 102,0 55,0 45,0 45,0 63789
11,4 mm 0.4488 12,0 102,0 55,0 45,0 45,0 63790
11,5 mm 0.4528 M12 X 0,5 12,0 102,0 55,0 45,0 45,0 63194
29/64 0.4531 1/2-20 1/2 4-1/16 2-3/16 1-51/64 1-49/64 51360
11,6 mm 0.4567 12,0 102,0 55,0 45,0 45,0 63791
11,7 mm 0.4606 12,0 102,0 55,0 45,0 45,0 63792
11,8 mm 0.4646 12,0 102,0 55,0 45,0 45,0 63793
11,9 mm 0.4685 12,0 102,0 55,0 45,0 45,0 63794
15/32 0.4688 1/2-28 1/2 4-1/16 2-3/16 1-51/64 1-49/64 51361
12,0 mm 0.4724 M14 X 2 12,0 102,0 55,0 45,0 45,0 63195
31/64 0.4844 9/16-12 1/2 4-1/4 2-5/16 1-7/8 1-49/64 51362
12,5 mm 0.4921 M14 X 1,5 14,0 107,0 60,0 49,0 45,0 63196
1/2 0.5000 1/2 4-1/4 2-5/16 1-7/8 1-49/64 51363
12,8 mm 0.5039 M14 X 1,25 14,0 107,0 60,0 49,0 45,0 63197
13,0 mm 0.5118 M14 X 1 14,0 107,0 60,0 49,0 45,0 63198
(continued on next page)
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
New Expanded Tools
www.sgstool.com
11
Series 135 3xD
|
External Coolant Drills
SERIES 135
3xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
33/64 0.5156 9/16-18 5/8 4-1/4 2-5/16 1-7/8 1-49/64 51364
17/32 0.5312 5/8-11 5/8 4-1/4 2-5/16 1-7/8 1-49/64 51365
13,5 mm 0.5315 14,0 107,0 60,0 49,0 45,0 63199
35/64 0.5469 5/8-12 5/8 4-1/4 2-5/16 1-7/8 1-49/64 51783
14,0 mm 0.5512 M16 X 2 14,0 107,0 60,0 49,0 45,0 63200
9/16 0.5625 5/8 4-9/16 2-1/2 2 1-57/64 51366
14,5 mm 0.5709 M16 X 1,5 16,0 115,0 65,0 51,0 48,0 63201
37/64 0.5781 5/8-18 5/8 4-9/16 2-1/2 2 1-57/64 51367
15,0 mm 0.5906 M16 X 1 16,0 115,0 65,0 51,0 48,0 63202
19/32 0.5938 11/16-11 5/8 4-9/16 2-1/2 2 1-57/64 51784
39/64 0.6094 11/16-12 5/8 4-9/16 2-1/2 2 1-57/64 51785
15,5 mm 0.6102 M18 X 2,5 16,0 115,0 65,0 51,0 48,0 63203
5/8 0.6250 11/16-16 5/8 4-9/16 2-1/2 2 1-57/64 51368
16,0 mm 0.6299 16,0 115,0 65,0 51,0 48,0 63204
41/64 0.6406 11/16-24 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51786
16,5 mm 0.6496 M18 X 1,5 18,0 123,0 73,0 58,0 48,0 63205
21/32 0.6562 3/4-10 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51369
17,0 mm 0.6693 18,0 123,0 73,0 58,0 48,0 63206
43/64 0.6719 3/4-12 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51787
11/16 0.6875 3/4-16 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51370
17,5 mm 0.6890 M20 X 2,5 18,0 123,0 73,0 58,0 48,0 63207
45/64 0.7031 3/4-20, 1/2-14 NPT 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51788
18,0 mm 0.7087 18,0 123,0 73,0 58,0 48,0 63208
23/32 0.7188 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51789
18,5 mm 0.7283 M20 X 1,5 20,0 131,0 79,0 63,0 50,0 63209
47/64 0.7344 13/16-12 3/4 4-7/8 2-3/4 2-5/16 1-57/64 51790
19,0 mm 0.7480 20,0 131,0 79,0 63,0 50,0 63210
3/4 0.7500 13/16-16 3/4 5-1/4 3-1/16 2-7/16 1-31/32 51371
49/64 0.7656 7/8-9 7/8 5-1/4 3-1/16 2-7/16 1-31/32 51372
19,5 mm 0.7677 M22 X 2,5 20,0 131,0 79,0 63,0 50,0 63211
25/32 0.7812 7/8 6 3-11/16 2-11/16 2-1/8 51791
20,0 mm 0.7874 20,0 131,0 79,0 63,0 50,0 63212
51/64 0.7969 7/8-12 7/8 6 3-11/16 2-11/16 2-1/8 51792
20,5 mm 0.8071 22 150 93 73 53
64513
13/16 0.8125 7/8-14 7/8 6 3-11/16 2-11/16 2-1/8 51373
21,0 mm 0.8268 22 150 93 73 53
64514
22,0 mm 0.8661 22 150 93 73 53
64515
7/8 0.8750 15/16-16, 1-8 7/8 6 3-11/16 2-11/16 2-1/8 51374
59/64 0.9219 1-12 1 6 3-11/16 2-11/16 2-1/8 51375
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
New Expanded Tools
www.sgstool.com
12
Series 135 5xD
|
External Coolant Drills
SERIES 135
5xD
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
1/64 0.0156 1/8 1 1/2 5/32 1/8 1 52300
1/32 0.0312 1/8 1 1/2 5/16 15/64 1
52301
3/64 0.0469 1/16-64 1/8 1 1/2 25/64 19/64 1
52302
1,25 mm 0.0492 3,0 38,0 10,0 9,0 25,0
64520
1,45 mm 0.0571 3,0 38,0 10,0 9,0 25,0
64521
#53 0.0595 1/8 1-1/2 25/64 19/64 1
64522
1/16 0.0625 5/64-60 1/8 2 15/32 23/64 1-1/4
52303
1,6 mm 0.0630 3,0 50,0 12,0 11,0 32,0
64523
1,75 mm 0.0689 3,0 50,0 12,0 11,0 32,0
64524
#50 0.0700 1/8 2 15/32 23/64 1-1/4
64525
5/64 0.0781 1/8 2 35/64 27/64 1-1/4
52304
#47 0.0785 1/8 2 35/64 27/64 1-1/4
64526
2,05 mm 0.0807 3,0 50,0 14,0 12,0 32,0
64527
#46 0.0810 1/8 2 35/64 27/64 1-1/4
64528
#43 0.0890 1/8 2 19/32 15/32 1-1/4
64529
#42 0.0935 1/8 2 5/8 9/16 1-1/4
64530
3/32 0.0938 1/8-32 1/8 2 5/8 9/16 1-1/4
52305
#40 0.0980 1/8 2 43/64 9/16 1-1/4
52306
2,5 mm 0.0984 3,0 50,0 1 7, 0 15,0 32,0
64531
#39 0.0995 1/8 2 43/64 9/16 1-1/4
52307
#38 0.1015 5-40 1/8 2 43/64 9/16 1-1/4
52308
#37 0.1040 5-44 1/8 2 45/64 9/16 1-1/4
52309
#36 0.1065 6-32 1/8 2 45/64 9/16 1-1/4
52310
7/64 0.1094 1/8 2 3/4 39/64 1-1/4
52311
#35 0.1100 1/8 2 3/4 39/64 1-1/4
52312
#34 0 .1110 1/8 2 3/4 39/64 1-1/4
52313
#33 0.1130 6-40 1/8 2 3/4 39/64 1-1/4
52314
2,9 mm 0.1142 3,0 50,0 19,0 1 7, 0 32,0
64532
#32 0.1160 1/8 2 3/4 39/64 1-1/4
52315
3,0 mm 0.1181 6,0 66,0 28,0 23,0 36,0
64100
#31 0.1200 1/8 2 3/4 39/64 1-1/4
52316
3,1 mm 0.1220 6,0 66,0 28,0 23,0 36,0
64101
1/8 0.1250 1/4 3 1 53/64 1-15/16 51580
3,2 mm 0.1260 M3,5 X 0,35 6,0 66,0 28,0 23,0 36,0
64102
30 0.1285 1/4 3 1 53/64 1-15/16 51581
3,3 mm 0.1299 M4 X 0,7 6,0 66,0 28,0 23,0 36,0
64103
3,4 mm 0.1339 8-32,8-36 6,0 66,0 28,0 23,0 36,0
64104
29 0.1360 1/4 3 1 53/64 1-15/16 51582
3,5 mm 0.1378 6,0 66,0 28,0 23,0 36,0
64105
#28 0.1405 8-40 1/4 3 1 53/64 1- 7/16
52317
9/64 0.1406 1/4 3 1 53/64 1-15/16 51583
3,6 mm 0.1417 M4 X 0,35 6,0 66,0 28,0 23,0 36,0
64106
(continued on next page)
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
New Expanded Tools
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
www.sgstool.com
13
Series 135 5xD
|
External Coolant Drills
SERIES 135
5xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
#27 0.1440 1/4 3 1 53/64 1-7/16 52318
3,7 mm 0.1457 M4.5 X 0,75 6,0 66,0 28,0 23,0 36,0
64107
#26 0.1470 3/16-24 1/4 3 1 53/64 1-7/16
52319
25 0.1495 10-24 1/4 3-1/4 1-1/4 1-5/64 1-15/16 51584
3,8 mm 0.1496 6,0 75,0 36,0 29,0 36,0
64108
#24 0.1520 10-28 1/4 3 1/4 1 1/4 1 5/64 1 7/16
52321
3,9 mm 0.1535 6,0 75,0 36,0 29,0 36,0
64109
#23 0.1540 1/4 3 1/4 1 1/4 1 5/64 1 7/16
52322
5/32 0.1562 1/4 3-1/4 1-1/4 1-5/64 1-15/16 51585
#22 0.1570 10-30 1/4 3 1/4 1 1/4 1 5/64 1 7/16
52323
4,0 mm 0.1575 M4,5 X 0,5 6,0 75,0 36,0 29,0 36,0
64110
21 0.1590 10-32 1/4 3-1/4 1-1/4 1-5/64 1-15/16 51586
20 0.1610 13/64-24 1/4 3-1/4 1-1/4 1-5/64 1-15/16 51587
4,1 mm 0.1614 6,0 75,0 36,0 29,0 36,0
6 4111
4,2 mm 0.1654 M5 / M5 X 0,75 6,0 75,0 36,0 29,0 36,0
64112
#19 0.1660 1/4 3 1/4 1 1/4 1 5/64 1- 7/16
52324
4,3 mm 0.1693 6,0 75,0 36,0 29,0 36,0
64113
#18 0.1695 1/4 3 1/4 1 1/4 1 5/64 1- 7/16
52325
11/64 0.1719 1/4 3-1/4 1-1/4 1-5/64 1-15/16 51588
#17 0.1730 1/4 3-1/4 1-3/4 1-37/64 1-7/16
52326
4,4 mm 0.1732 6,0 75,0 36,0 29,0 36,0
64114
4,5 mm 0.1772 M5 X 0,5 6,0 75,0 36,0 29,0 36,0
64115
#15 0.1800 1/4 3-1/4 1-3/4 1-37/64 1-7/16
52327
4,6 mm 0.1811 12-28 6,0 75,0 36,0 29,0 36,0
64116
#14 0.1820 1/4 3-1/4 1-3/4 1-37/64 1-7/16
52328
#13 0.1850 12-32 1/4 3-1/4 1-3/4 1-37/64 1-7/16
52329
4,7 mm 0.1850 6,0 75,0 36,0 29,0 36,0
64117
3/16 0.1875 1/4 3-1/4 1-3/4 1-37/64 1-7/16
51589
#12 0.1890 7/32-32 1/4 3-1/4 1-3/4 1-37/64 1-7/16
52330
4,8 mm 0.1890 6,0 82,0 44,0 35,0 36,0
64118
4,9 mm 0.1929 6,0 82,0 44,0 35,0 36,0
64119
#10 0.1935 14-20 1/4 3-1/4 1-3/4 1-37/64 1-7/16
52331
#9 0.1960 1/4 3-1/4 1-3/4 1-37/64 1-7/16
52332
5,0 mm 0.1969 M6 X 1 6,0 82,0 44,0 35,0 36,0
64120
#8 0.1990 1/4 3-1/4 1-3/4 1-37/64 1-7/16
52333
5,1 mm 0.2008 6,0 82,0 44,0 35,0 36,0
64121
7 0.2010 1/4-20 1/4 3-1/4 1-3/4 1-37/64 1-7/16 51506
13/64 0.2031 1/4 3-1/4 1-3/4 1-37/64 1-7/16 51507
#6 0.2040 1/4 3 1/4 1 3/4 1 37/64 1 7/16
52334
5,2 mm 0.2047 M6 X 0,75 6,0 82,0 44,0 35,0 36,0
64122
5 0.2055 1/4 3-1/4 1-3/4 1-37/64 1-7/16 51590
5,25 mm 0.2067 6,0 82,0 44,0 35,0 36,0
64123
(continued on next page)
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
New Expanded Tools
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
www.sgstool.com
14
Series 135 5xD
|
External Coolant Drills
SERIES 135
5xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
5,3 mm 0.2087 6,0 82,0 44,0 35,0 36,0 64124
4 0.2090 1/4-24 1/4 3-1/4 1-3/4 1-37/64 1-7/16 51508
5,4 mm 0.2126 6,0 82,0 44,0 35,0 36,0
64125
3 0.2130 1/4-28 1/4 3-1/4 1-3/4 1-37/64 1-7/16 51509
5,5 mm 0.2165 M6 X 0,5 6,0 82,0 44,0 35,0 36,0
64126
7/32 0.2188 1/4-32 1/4 3-1/4 1-3/4 1-37/64 1-7/16 51510
5,6 mm 0.2205 6,0 82,0 44,0 35,0 36,0
64127
#2 0.2210 1/4 3-1/4 1-3/4 1-37/64 1-7/16
52335
5,7 mm 0.2244 6,0 82,0 44,0 35,0 36,0
64128
#1 0.2280 1/4 3-1/4 1-3/4 1-37/64 1-7/16
52336
5,8 mm 0.2283 6,0 82,0 44,0 35,0 36,0
64129
5,9 mm 0.2323 6,0 82,0 44,0 35,0 36,0
64130
A 0.2340 1/4 3-1/4 1-3/4 1-37/64 1-7/16
52337
15/64 0.2344 1/4 3-1/4 1-3/4 1-37/64 1-7/16 51591
6,0 mm 0.2362 M7 X 1 6,0 82,0 44,0 35,0 36,0
64131
B 0.2380 1/4 3 5/8 2-5/64 1-51/64 1-7/16
52338
6,1 mm 0.2402 8,0 91,0 53,0 43,0 36,0
64132
C 0.2420 1/4 3 5/8 2-5/64 1-51/64 1-7/16
52339
6,2 mm 0.2441 8,0 91,0 53,0 43,0 36,0
64133
D 0.2460 1/4 3 5/8 2-5/64 1-51/64 1-7/16
52340
6,25 mm 0.2461 M7 X 0,75 8,0 91,0 53,0 43,0 36,0
64134
6,3 mm 0.2480 8,0 91,0 53,0 43,0 36,0
64135
1/4 0.2500 1/4 3-5/8 2-5/64 1-51/64 1-7/16 51511
6,4 mm 0.2520 8,0 91,0 53,0 43,0 36,0
64136
6,5 mm 0.2559 8,0 91,0 53,0 43,0 36,0
64137
F 0.2570 5/16-18 5/16 3-5/8 2-5/64 1-51/64 1-7/16 51512
6,6 mm 0.2598 8,0 91,0 53,0 43,0 36,0
64138
G 0.2610 5/16 3 5/8 2 5/64 1 51/64 1 7/16
52341
6,7 mm 0.2638 8,0 91,0 53,0 43,0 36,0
64139
17/64 0.2656 5/16-20 5/16 3-5/8 2-5/64 1-51/64 1-7/16 51513
H 0.2660 5/16 3-5/8 2-5/64 1-51/64 1-7/16
52342
6,8 mm 0.2677 M8 X 1,25 8,0 91,0 53,0 43,0 36,0
64140
6,9 mm 0.2717 8,0 91,0 53,0 43,0 36,0
64141
I 0.2720 5/16-24 5/16 3-5/8 2-5/64 1-51/64 1-7/16 51514
7,0 mm 0.2756 M8 X 1 8,0 91,0 53,0 43,0 36,0
64142
J 0.2770 5/16 3 5/8 2-5/64 1-51/64 1-7/16
52343
7,1 mm 0.2795 8,0 91,0 53,0 43,0 36,0
64143
K 0.2810 5/16 3 5/8 2-5/64 1-51/64 1-7/16
52344
9/32 0.2812 5/16-32 5/16 3-5/8 2-5/64 1-51/64 1-7/16 51515
7,2 mm 0.2835 8,0 91,0 53,0 43,0 36,0
64144
7,25 mm 0.2854 M8 X 0,75 8,0 91,0 53,0 43,0 36,0
64145
7,3 mm 0.2874 8,0 91,0 53,0 43,0 36,0
64146
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
New Expanded Tools
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
(continued on next page)
www.sgstool.com
15
Series 135 5xD
|
External Coolant Drills
SERIES 135
5xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
L 0.2900 5/16 3-5/8 2-5/64 1-51/64 1-7/16 52345
7,4 mm 0.2913 8,0 91,0 53,0 43,0 36,0
64147
M 0.2950 5/16 3-5/8 2-5/64 1-51/64 1-7/16
52346
7,5 mm 0.2953 M8 X 0,5 8,0 91,0 53,0 43,0 36,0
64148
19/64 0.2969 5/16 3-5/8 2-5/64 1-51/64 1-7/16 51516
7,6 mm 0.2992 8,0 91,0 53,0 43,0 36,0
64149
N 0.3020 5/16 3-5/8 2-5/64 1-51/64 1-7/16
52347
7,7 mm 0.3031 8,0 91,0 53,0 43,0 36,0
64150
7,8 mm 0.3071 M9 X 1,25 8,0 91,0 53,0 43,0 36,0
64151
7,9 mm 0.3110 8,0 91,0 53,0 43,0 36,0
64152
5/16 0.3125 3/8-16 5/16 3-5/8 2-5/64 1-51/64 1-7/16 51517
8,0 mm 0.3150 M9 X 1 8,0 91,0 53,0 43,0 36,0
64153
O 0.3160 3/8 4 2-13/32 2-1/8 1-9/16
52348
8,1 mm 0.3189 10,0 103,0 61,0 49,0 40,0
64154
8,2 mm 0.3228 10,0 103,0 61,0 49,0 40,0
64155
P 0.3230 3/8 4 2-13/32 2-1/8 1-9/16 51518
8,3 mm 0.3268 10,0 103,0 61,0 49,0 40,0
64156
21/64 0.3281 3/8-20 3/8 4 2-13/32 2-1/8 1-9/16 51519
8,4 mm 0.3307 10,0 103,0 61,0 49,0 40,0
64157
Q 0.3320 3/8-24 3/8 4 2-13/32 2-1/8 1-9/16 51520
8,5 mm 0.3346 M10 X 1,5 10,0 103,0 61,0 49,0 40,0
64158
8,6 mm 0.3386 10,0 103,0 61,0 49,0 40,0
64159
R 0.3390 3/8-32 3/8 4 2-13/32 2-1/8 1-9/16
52349
8,7 mm 0.3425 M10 X 1,25 10,0 103,0 61,0 49,0 40,0
64160
11/32 0.3438 3/8 4 2-13/32 2-1/8 1-9/16 51521
8,8 mm 0.3465 10,0 103,0 61,0 49,0 40,0
64161
S 0.3480 3/8 4 2-13/32 2-1/8 1-9/16 51522
8,9 mm 0.3504 10,0 103,0 61,0 49,0 40,0
64162
9,0 mm 0.3543 M10 X 1 10,0 103,0 61,0 49,0 40,0
64163
T 0.3580 3/8 4 2 13/32 2 1/8 1 9/16
52350
9,1 mm 0.3583 10,0 103,0 61,0 49,0 40,0
64164
23/64 0.3594 3/8 4 2-13/32 2-1/8 1-9/16 51523
9,2 mm 0.3622 M10 X 0,75 10,0 103,0 61,0 49,0 40,0
64165
9,25 mm 0.3642 10,0 103,0 61,0 49,0 40,0
64166
9,3 mm 0.3661 10,0 103,0 61,0 49,0 40,0
64167
U 0.3680 7/16-14 3/8 4 2-13/32 2-1/8 1-9/16 51524
9,4 mm 0.3701 10,0 103,0 61,0 49,0 40,0
64168
9,5 mm 0.3740 M10 X 0,5 10,0 103,0 61,0 49,0 40,0
64169
3/8 0.3750 3/8 4 2-13/32 2-1/8 1-9/16 51525
V 0.3770 1/2 4 2-13/32 2-1/8 1-9/16
52351
9,6 mm 0.3780 10,0 103,0 61,0 49,0 40,0
64170
9,7 mm 0.3819 10,0 103,0 61,0 49,0 40,0
64171
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
New Expanded Tools
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
(continued on next page)
www.sgstool.com
16
Series 135 5xD
|
External Coolant Drills
SERIES 135
5xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
9,8 mm 0.3858 10,0 103,0 61,0 49,0 40,0 64172
W 0.3860 1/2 4 2-13/32 2-1/8 1-9/16 51526
9,9 mm 0.3898 10,0 103,0 61,0 49,0 40,0
64173
25/64 0.3906 7/16-20 1/2 4 2-13/32 2-1/8 1-9/16 51527
10,0 mm 0.3937 10,0 103,0 61,0 49,0 40,0
64174
X 0.3970 7/16-24 1/2 4-11/16 2-3/4 2-23/64 1-49/64
52352
10,1 mm 0.3976 12,0 118,0 71,0 56,0 45,0
64175
10,2 mm 0.4016 12,0 118,0 71,0 56,0 45,0
64176
Y 0.4040 7/16-28 1/2 4-11/16 2-3/4 2-23/64 1-49/64
52353
10,3 mm 0.4055 12,0 118,0 71,0 56,0 45,0
64177
13/32 0.4062 1/2 4-11/16 2-3/4 2-23/64 1-49/64 51528
10,4 mm 0.4095 12,0 118,0 71,0 56,0 45,0
64178
Z 0.4130 1/2 4-11/16 2-3/4 2-23/64 1-49/64
52354
10,5 mm 0.4134 M12 X 1,5 12,0 118,0 71,0 56,0 45,0
64179
10,6 mm 0.4173 12,0 118,0 71,0 56,0 45,0
64180
10,7 mm 0.4213 12,0 118,0 71,0 56,0 45,0
64181
27/64 0.4219 1/2-13 1/2 4-11/16 2-3/4 2-23/64 1-49/64 51529
10,8 mm 0.4252 M12 X 1,25 12,0 118,0 71,0 56,0 45,0
64182
10,9 mm 0.4291 12,0 118,0 71,0 56,0 45,0
64183
11,0 mm 0.4331 12,0 118,0 71,0 56,0 45,0
64184
11,1 mm 0.4370 M12 X 1 12,0 118,0 71,0 56,0 45,0
64185
7/16 0.4375 1/4-18 NPT 1/2 4-11/16 2-3/4 2-23/64 1-49/64 51530
11,2 mm 0.4409 12,0 118,0 71,0 56,0 45,0
64186
11,25 mm 0.4429 12,0 118,0 71,0 56,0 45,0
64187
11,3 mm 0.4449 12,0 118,0 71,0 56,0 45,0
64188
11,4 mm 0.4488 12,0 118,0 71,0 56,0 45,0
64189
11,5 mm 0.4528 M12 X 0,5 12,0 118,0 71,0 56,0 45,0
64190
29/64 0.4531 1/2-20 1/2 4-11/16 2-3/4 2-23/64 1-49/64 51531
11,6 mm 0.4567 12,0 118,0 71,0 56,0 45,0
64191
11,7 mm 0.4606 12,0 118,0 71,0 56,0 45,0
64192
11,8 mm 0.4646 12,0 118,0 71,0 56,0 45,0
64193
11,9 mm 0.4685 12,0 118,0 71,0 56,0 45,0
64194
15/32 0.4688 1/2-28 1/2 4-11/16 2-3/4 2-23/64 1-49/64 51532
12,0 mm 0.4724 M14 X 2 12,0 118,0 71,0 56,0 45,0
64195
31/64 0.4844 9/16-12 1/2 4-7/8 3-1/32 2-19/32 1-49/64 51533
12,5 mm 0.4921 M14 X 1,5 14,0 124,0 77,0 60,0 45,0
64196
1/2 0.5000 1/2 4-7/8 3-1/32 2-19/32 1-49/64 51534
12,8 mm 0.5039 M14 X 1,25 14,0 124,0 77,0 60,0 45,0
64197
13,0 mm 0.5118 M14 X 1 14,0 124,0 77,0 60,0 45,0
64198
33/64 0.5156 9/16-18 5/8 4-7/8 3-1/32 2-19/32 1-49/64 51535
17/32 0.5312 5/8-11 5/8 4-7/8 3-1/32 2-19/32 1-49/64 51536
13,5 mm 0.5315 14,0 124,0 77,0 60,0 45,0
64199
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
New Expanded Tools
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
(continued on next page)
www.sgstool.com
17
Series 135 5xD
|
External Coolant Drills
SERIES 135
5xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
35/64 0.5469 5/8-12 5/8 4-7/8 3-1/32 2-19/32 1-49/64 51537
14,0 mm 0.5512 M16 X 2 14,0 124,0 77,0 60,0 45,0
64200
9/16 0.5625 5/8 5-1/4 3-1/4 2-3/4 1-57/64 51538
14,5 mm 0.5709 M16 X 1,5 16,0 133,0 83,0 63,0 48,0
64201
37/64 0.5781 5/8-18 5/8 5-1/4 3-1/4 2-3/4 1-57/64 51539
15,0 mm 0.5906 M16 X 1 16,0 133,0 83,0 63,0 48,0
64202
19/32 0.5938 11/16-11 5/8 5-1/4 3-1/4 2-3/4 1-57/64 51592
39/64 0.6094 11/16-12 5/8 5-1/4 3-1/4 2-3/4 1-57/64 51593
15,5 mm 0.6102 M18 X 2,5 16,0 133,0 83,0 63,0 48,0
64203
5/8 0.6250 11/16-16 5/8 5-1/4 3-1/4 2-3/4 1-57/64 51540
16,0 mm 0.6299 16,0 133,0 83,0 63,0 48,0
64204
41/64 0.6406 11/16-24 3/4 5-5/8 3-5/8 3-3/16 1-57/64 51594
16,5 mm 0.6496 M18 X 1,5 20,0 143,0 93,0 71,0 48,0
64205
21/32 0.6562 3/4-10 3/4 5-5/8 3-5/8 3-3/16 1-57/64 51541
17,0 mm 0.6693 18,0 143,0 93,0 71,0 48,0
64206
43/64 0.6719 3/4-12 3/4 5-5/8 3-5/8 3-3/16 1-57/64 51595
11/16 0.6875 3/4-16 3/4 5-5/8 3-5/8 3-3/16 1-57/64 51542
17,5 mm 0.6890 M20 X 2,5 18,0 143,0 93,0 71,0 48,0
64207
45/64 0.7031 3/4-20, 1/2-14 NPT 3/4 5-5/8 3-5/8 3-3/16 1-57/64 51543
18,0 mm 0.7087 18,0 143,0 93,0 71,0 48,0
64208
23/32 0.7188 3/4 6 4 3-3/8 1-31/32 51596
18,5 mm 0.7283 M20 X 1,5 20,0 153,0 101,0 77,0 50,0
64209
47/64 0.7344 13/16-12 3/4 6 4 3-3/8 1-31/32 51544
19,0 mm 0.7480 20,0 153,0 101,0 77,0 50,0
64210
3/4 0.7500 13/16-16 3/4 6 4 3-3/8 1-31/32 51545
49/64 0.7656 7/8-9 7/8 6 4 3-3/8 1-31/32
52355
19,5 mm 0.7677 M22 X 2,5 20,0 153,0 101,0 77,0 50,0
64211
25/32 0.7812 7/8 6 4 3-7/8 1-31/32
52356
20,0 mm 0.7874 20,0 153,0 101,0 77,0 50,0
64212
51/64 0.7969 7/8-12 7/8 6 4 3-7/8 1-31/32
52357
20,5 mm 0.8071 22,0 153,0 101,0 77,0 50,0
64533
13/16 0.8125 7/8-14 7/8 6-1/2 4-1/2 3-7/8 2-1/8
52358
21,0 mm 0.8268 22,0 153,0 101,0 77,0 50,0
64534
22,0 mm 0.8661 22,0 178,0 127,0 108,0 54,0
64535
7/8 0.8750 15/16-16, 1-8 7/8 6-1/2 4-1/2 3-7/8 2-1/8
52359
59/64 0.9219 1-12 1 7 5 4-7/32 2-1/8
52360
145°
32°
L
1
L
2
L
3
L
4
D
2
D
1
New Expanded Tools
TOLERANCES (inch)
DIAMETER D
1
D
2
≤ 34 +0.0001 / –0.0005 h6
> 34 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
www.sgstool.com
18
Fractional
|
Speed & Feed Recommendations
Series
135 3D
Fractional
Hardness
(Brinell)
Vc
(SFM)
Diameter (D
1
)
(inch)
1/32 1/8 1/4 3/8 1/2 5/8 7/8
P
CARBON STEELS
1018, 1040, 1080, 1090, 10L50,
1140, 1212, 12L15, 1525, 1536
≤ 175
385 RPM 47062 11766 5883 3922 2941 2353 1681
(308-462)
Fr 0.0010 0.0038 0.0076 0.0115 0.0153 0.0191 0.0268
Feed (IPM) 45.0 45.0 45.0 45.0 45.0 45.0 45.0
> 175
≤ 275
350 RPM 42784 10696 5348 3565 2674 2139 1528
(280-420)
Fr 0.0009 0.0036 0.0071 0.0107 0.0142 0.0178 0.0249
Feed (IPM) 38.0 38.0 38.0 38.0 38.0 38.0 38.0
> 275
≤ 425
200 RPM 24448 6112 3056 2037 1528 1222 873
(160-240)
Fr 0.0007 0.0029 0.0059 0.0088 0.0118 0.0147 0.0206
Feed (IPM) 18.0 18.0 18.0 18.0 18.0 18.0 18.0
P
ALLOY STEELS
4140, 4150, 4320, 5120,
5150, 8630, 86L20, 50100
≤ 275
300 RPM 36672 9168 4584 3056 2292 1834 1310
(240-360)
Fr 0.0007 0.0029 0.0059 0.0088 0.0118 0.0147 0.0206
Feed (IPM) 27.0 27.0 27.0 27.0 27.0 27.0 27.0
> 275
≤ 375
185 RPM 22614 5654 2827 1885 1413 1131 808
(148-222)
Fr 0.0006 0.0026 0.0051 0.0077 0.0103 0.0128 0.0180
Feed (IPM) 14.5 14.5 14.5 14.5 14.5 14.5 14.5
> 375
≤ 450
130 RPM 15891 3973 1986 1324 993 795 568
(104-156)
Fr 0.0004 0.0018 0.0035 0.0053 0.0070 0.0088 0.0123
Feed (IPM) 7.0 7.0 7.0 7.0 7.0 7.0 7.0
P
TOOL STEELS
A2, D2, H13, L2, M2,
P20, S7, T15, W2
≤ 200
130 RPM 15891 3973 1986 1324 993 795 568
(104-156)
Fr 0.0007 0.0026 0.0053 0.0079 0.0106 0.0132 0.0185
Feed (IPM) 10.5 10.5 10.5 10.5 10.5 10.5 10.5
> 200
≤ 375
90 RPM 11002 2750 1375 917 688 550 393
(72-108)
Fr 0.0003 0.0012 0.0023 0.0035 0.0047 0.0058 0.0081
Feed (IPM) 3.2 3.2 3.2 3.2 3.2 3.2 3.2
> 375
≤ 475
75 RPM 9168 2292 1146 764 573 458 327
(60-90)
Fr 0.0002 0.0008 0.0016 0.0024 0.0031 0.0039 0.0055
Feed (IPM) 1.8 1.8 1.8 1.8 1.8 1.8 1.8
K
CAST IRONS
Gray, Malleable, Ductile
≤ 220
320 RPM 39117 9779 4890 3260 2445 1956 1397
(256-384)
Fr 0.0012 0.0046 0.0092 0.0138 0.0184 0.0230 0.0322
Feed (IPM) 45.0 45.0 45.0 45.0 45.0 45.0 45.0
> 220
≤ 260
285 RPM 34838 8710 4355 2903 2177 1742 1244
(228-342)
Fr 0.0011 0.0046 0.0092 0.0138 0.0184 0.0230 0.0321
Feed (IPM) 40.0 40.0 40.0 40.0 40.0 40.0 40.0
M
STAINLESS STEELS
(FREE MACHINING)
303, 416, 420F, 430F, 440F
≤ 185
275 RPM 33616 8404 4202 2801 2101 1681 1201
(220-330)
Fr 0.0006 0.0026 0.0051 0.0077 0.0102 0.0128 0.0179
Feed (IPM) 21.5 21.5 21.5 21.5 21.5 21.5 21.5
> 185
≤ 275
170 RPM 20781 5195 2598 1732 1299 1039 742
(136-204)
Fr 0.0005 0.0020 0.0040 0.0061 0.0081 0.0101 0.0141
Feed (IPM) 10.5 10.5 10.5 10.5 10.5 10.5 10.5
M
STAINLESS STEELS
(DIFFICULT)
304, 316, 321, 13-8 PH,
15-5PH, 17-4 PH, CUSTOM 450
≤ 275
90 RPM 11002 2750 1375 917 688 550 393
(72-108)
Fr 0.0005 0.0020 0.0040 0.0060 0.0080 0.0100 0.0140
Feed (IPM) 5.5 5.5 5.5 5.5 5.5 5.5 5.5
> 275
≤ 375
65 RPM 7946 1986 993 662 497 397 284
(52-78)
Fr 0.0004 0.0018 0.0035 0.0053 0.0070 0.0088 0.0123
Feed (IPM) 3.5 3.5 3.5 3.5 3.5 3.5 3.5
continued on next page
www.sgstool.com
19
Fractional
|
Speed & Feed Recommendations
Tool Wizard
CALCULATE APPLICATION PARAMETERS
www.sgstool.com
Series
135 3D
Fractional
Hardness
(Brinell)
Vc
(SFM)
Diameter (D
1
)
(inch)
1/32 1/8 1/4 3/8 1/2 5/8 7/8
S
SUPER ALLOYS
(NICKEL , COBALT,
IRON BASE)
Inconel 601, 617, 625, Incoloy,
Monel 400, Rene, Waspaloy
≤ 300
55 RPM 6723 1681 840 560 420 336 240
(44-66)
Fr 0.0002 0.0008 0.0015 0.0023 0.0031 0.0039 0.0054
Feed (IPM) 1.3 1.3 1.3 1.3 1.3 1.3 1.3
> 300
≤ 400
30 RPM 3667 917 458 306 229 183 131
(24-36)
Fr 0.0002 0.0007 0.0013 0.0020 0.0026 0.0033 0.0046
Feed (IPM) 0.6 0.6 0.6 0.6 0.6 0.6 0.6
S
TITANIUM ALLOYS
Pure Ttanium, Ti6Al4V,
Ti6Al2Sn4Zr2Mo,
Ti4Al4Mo2Sn0.5Si,
Ti-6Al4V
≤ 275
135 RPM 16502 4126 2063 1375 1031 825 589
(108-162)
Fr 0.0004 0.0018 0.0035 0.0053 0.0071 0.0088 0.0124
Feed (IPM) 7.3 7.3 7.3 7.3 7.3 7.3 7.3
> 275
≤ 350
100 RPM 12224 3056 1528 1019 764 611 437
(80-120)
Fr 0.0004 0.0016 0.0033 0.0049 0.0065 0.0082 0.0115
Feed (IPM) 5.0 5.0 5.0 5.0 5.0 5.0 5.0
> 350
≤ 440
55 RPM 6723 1681 840 560 420 336 240
(44-66)
Fr 0.0003 0.0012 0.0024 0.0036 0.0048 0.0059 0.0083
Feed (IPM) 2.0 2.0 2.0 2.0 2.0 2.0 2.0
N
ALUMINUM ALLOYS
2017, 2024, 356,
6061, 7075
≤ 80
700 RPM 85568 21392 10696 7131 5348 4278 3056
(560-840)
Fr 0.0012 0.0049 0.0098 0.0147 0.0196 0.0245 0.0344
Feed (IPM) 105.0 105.0 105.0 105.0 105.0 105.0 105.0
> 80
600 RPM 73344 18336 9168 6112 4584 3667 2619
(480-720)
Fr 0.0012 0.0050 0.0099 0.0149 0.0199 0.0248 0.0347
Feed (IPM) 91.0 91.0 91.0 91.0 91.0 91.0 91.0
N
COPPER ALLOYS
Alum Bronze, C110,
Muntz Brass
≤ 140
500 RPM 61120 15280 7640 5093 3820 3056 2183
(400-600)
Fr 0.0005 0.0020 0.0039 0.0059 0.0079 0.0098 0.0137
Feed (IPM) 30.0 30.0 30.0 30.0 30.0 30.0 30.0
> 140
400 RPM 48896 12224 6112 4075 3056 2445 1746
(320-480)
Fr 0.0005 0.0020 0.0040 0.0060 0.0080 0.0100 0.0140
Feed (IPM) 24.5 24.5 24.5 24.5 24.5 24.5 24.5
Note:
•  rpm = sfm x 3.82 / D
1
•  ipm = (inch / revolution) x rpm
•  reduce speed and feed for materials harder than listed
•  refer to the SGS Tool Wizard for complete technical information (www.sgstool.com)
www.sgstool.com
20
Metric
|
Speed & Feed Recommendations
Series
135M 3D
Metric
Hardness
(Brinell)
Vc
(m/min)
Diameter (D
1
)
(mm)
1.5 3 6 8 10 12 16 20
P
CARBON STEELS
1018, 1040, 1080, 1090, 10L50,
1140, 1212, 12L15, 1525, 1536
≤ 175
117 RPM 24882 12441 6220 4665 3732 3110 2333 1866
(94-141)
Fr 0.047 0.094 0.189 0.252 0.315 0.378 0.504 0.630
Feed (mm/min) 1175 1175 1175 1175 1175 1175 1175 1175
> 175
≤ 275
107 RPM 22620 11310 5655 4241 3393 2827 2121 1696
(85-128)
Fr 0.043 0.086 0.172 0.229 0.286 0.343 0.457 0.572
Feed (mm/min) 970 970 970 970 970 970 970 970
> 275
≤ 425
61 RPM 12926 6463 3231 2424 1939 1616 1212 969
(49-73)
Fr 0.036 0.071 0.142 0.190 0.237 0.285 0.380 0.475
Feed (mm/min) 460 460 460 460 460 460 460 460
P
ALLOY STEELS
4140, 4150, 4320, 5120,
5150, 8630, 86L20, 50100
≤ 275
91 RPM 19388 9694 4847 3635 2908 2424 1818 1454
(73-110)
Fr 0.036 0.071 0.142 0.190 0.237 0.285 0.380 0.475
Feed (mm/min) 690 690 690 690 690 690 690 690
> 275
≤ 375
56 RPM 11956 5978 2989 2242 1793 1495 1121 897
(45-68)
Fr 0.031 0.061 0.122 0.163 0.204 0.244 0.326 0.407
Feed (mm/min) 365 365 365 365 365 365 365 365
> 375
≤ 450
40 RPM 8402 4201 2100 1575 1260 1050 788 630
(32-48)
Fr 0.021 0.042 0.083 0.111 0.139 0.167 0.222 0.278
Feed (mm/min) 175 175 175 175 175 175 175 175
P
TOOL STEELS
A2, D2, H13, L2, M2,
P20, S7, T15, W2
≤ 200
40 RPM 8402 4201 2100 1575 1260 1050 788 630
(32-48)
Fr 0.032 0.063 0.126 0.168 0.210 0.252 0.336 0.421
Feed (mm/min) 265 265 265 265 265 265 265 265
> 200
≤ 375
27 RPM 5816 2908 1454 1091 872 727 545 436
(22-33)
Fr 0.014 0.028 0.055 0.073 0.092 0.110 0.147 0.183
Feed (mm/min) 80 80 80 80 80 80 80 80
> 375
≤ 475
23 RPM 4847 2424 1212 909 727 606 454 364
(18-27)
Fr 0.009 0.019 0.037 0.050 0.062 0.074 0.099 0.124
Feed (mm/min) 45 45 45 45 45 45 45 45
K
CAST IRONS
Gray, Malleable, Ductile
≤ 220
98 RPM 20681 10340 5170 3878 3102 2585 1939 1551
(78-117)
Fr 0.055 0.110 0.220 0.293 0.366 0.439 0.585 0.732
Feed (mm/min) 1135 1135 1135 1135 1135 1135 1135 1135
> 220
≤ 260
87 RPM 18419 9209 4605 3454 2763 2302 1727 1381
(69-104)
Fr 0.055 0.110 0.219 0.292 0.366 0.439 0.585 0.731
Feed (mm/min) 1010 1010 1010 1010 1010 1010 1010 1010
M
STAINLESS STEELS
(FREE MACHINING)
303, 416, 420F, 430F, 440F
≤ 185
84 RPM 17773 8886 4443 3332 2666 2222 1666 1333
(67-101)
Fr 0.031 0.061 0.123 0.164 0.204 0.245 0.327 0.409
Feed (mm/min) 545
545 545 545 545 545 545 545
> 185
≤ 275
52 RPM 10987 5493 2747 2060 1648 1373 1030 824
(41-62)
Fr 0.024 0.047 0.095 0.126 0.158 0.189 0.252 0.316
Feed (mm/min) 260 260 260 260 260 260 260 260
M
STAINLESS STEELS
(DIFFICULT)
304, 316, 321, 13-8 PH,
15-5PH, 17-4 PH, CUSTOM 450
≤ 275
27 RPM 5816 2908 1454 1091 872 727 545 436
(22-33)
Fr 0.023 0.046 0.093 0.124 0.155 0.186 0.248 0.309
Feed (mm/min) 135 135 135 135 135 135 135 135
> 275
≤ 375
20 RPM 4201 2100 1050 788 630 525 394 315
(16-24)
Fr 0.020 0.040 0.081 0.108 0.135 0.162 0.216 0.270
Feed (mm/min) 85 85 85 85 85 85 85 85
continued on next page
www.sgstool.com
21
Metric
|
Speed & Feed Recommendations
Tool Wizard
CALCULATE APPLICATION PARAMETERS
www.sgstool.com
Series
135M 3D
Metric
Hardness
(Brinell)
Vc
(m/min)
Diameter (D
1
)
(mm)
1.5 3 6 8 10 12 16 20
S
SUPER ALLOYS
(NICKEL , COBALT,
IRON BASE)
Inconel 601, 617, 625, Incoloy,
Monel 400, Rene, Waspaloy
≤ 300
17 RPM 3555 1777 889 666 533 444 333 267
(13-20)
Fr 0.010 0.020 0.039 0.053 0.066 0.079 0.105 0.131
Feed (mm/min) 35 35 35 35 35 35 35 35
> 300
≤ 400
9 RPM 1939 969 485 364 291 242 182 145
(7-11)
Fr 0.008 0.015 0.031 0.041 0.052 0.062 0.083 0.103
Feed (mm/min) 15 15 15 15 15 15 15 15
S
TITANIUM ALLOYS
Pure Ttanium, Ti6Al4V,
Ti6Al2Sn4Zr2Mo,
Ti4Al4Mo2Sn0.5Si,
Ti-6Al4V
≤ 275
41 RPM 8725 4362 2181 1636 1309 1091 818 654
(33-49)
Fr 0.021 0.042 0.085 0.113 0.141 0.170 0.226 0.283
Feed (mm/min) 185 185 185 185 185 185 185 185
> 275
≤ 350
30 RPM 6463 3231 1616 1212 969 808 606 485
(24-37)
Fr 0.019 0.039 0.077 0.103 0.129 0.155 0.206 0.258
Feed (mm/min) 125 125 125 125 125 125 125 125
> 350
≤ 440
17 RPM 3555 1777 889 666 533 444 333 267
(13-20)
Fr 0.014 0.028 0.056 0.075 0.094 0.113 0.150 0.188
Feed (mm/min) 50 50 50 50 50 50 50 50
N
ALUMINUM ALLOYS
2017, 2024, 356,
6061, 7075
≤ 80
213 RPM 45239 22620 11310 8482 6786 5655 4241 3393
(171-256)
Fr 0.059 0.119 0.238 0.317 0.396 0.476 0.634 0.793
Feed (mm/min) 2690 2690 2690 2690 2690 2690 2690 2690
> 80
183 RPM 38777 19388 9694 7271 5816 4847 3635 2908
(146-219)
Fr 0.060 0.120 0.240 0.320 0.400 0.480 0.640 0.799
Feed (mm/min) 2325 2325 2325 2325 2325 2325 2325 2325
N
COPPER ALLOYS
Alum Bronze, C110,
Muntz Brass
≤ 140
152 RPM 32314 16157 8078 6059 4847 4039 3029 2424
(122-183)
Fr 0.024 0.048 0.096 0.128 0.160 0.192 0.256 0.320
Feed (mm/min) 776 776 776 776 776 776 776 776
> 140
122 RPM 25851 12926 6463 4847 3878 3231 2424 1939
(98-146)
Fr 0.024 0.049 0.097 0.130 0.162 0.195 0.260 0.325
Feed (mm/min) 630 630 630 630 630 630 630 630
Note:
•  rpm = (1000 x m / min) / (3.14 x D
1
)
•  mm / min = (mm / revolution) x rpm
•  reduce speed and feed for materials harder than listed
•  refer to the SGS Tool Wizard for complete technical information (www.sgstool.com)
www.sgstool.com
22
Fractional
|
Speed & Feed Recommendations
Series
135 5D
Fractional
Hardness
(Brinell)
Vc
(SFM)
Diameter (D
1
)
(inch)
1/32 1/8 1/4 3/8 1/2 5/8 7/8
P
CARBON STEELS
1018, 1040, 1080, 1090, 10L50,
1140, 1212, 12L15, 1525, 1536
≤ 175
345 RPM 42173 10543 5272 3514 2636 2109 1506
(276-414)
Fr 0.0010 0.0040 0.0080 0.0120 0.0159 0.0199 0.0279
Feed (IPM) 42.0 42.0 42.0 42.0 42.0 42.0 42.0
> 175
≤ 275
310 RPM 37894 9474 4737 3158 2368 1895 1353
(248-372)
Fr 0.0009 0.0036 0.0072 0.0108 0.0144 0.0179 0.0251
Feed (IPM) 34.0 34.0 34.0 34.0 34.0 34.0 34.0
> 275
≤ 425
180 RPM 22003 5501 2750 1834 1375 1100 786
(144-216)
Fr 0.0007 0.0030 0.0060 0.0090 0.0120 0.0150 0.0210
Feed (IPM) 16.5 16.5 16.5 16.5 16.5 16.5 16.5
P
ALLOY STEELS
4140, 4150, 4320, 5120,
5150, 8630, 86L20, 50100
≤ 275
270 RPM 33005 8251 4126 2750 2063 1650 1179
(216-324)
Fr 0.0008 0.0030 0.0061 0.0091 0.0121 0.0151 0.0212
Feed (IPM) 25.0 25.0 25.0 25.0 25.0 25.0 25.0
> 275
≤ 375
165 RPM 20170 5042 2521 1681 1261 1008 720
(132-198)
Fr 0.0006 0.0026 0.0052 0.0077 0.0103 0.0129 0.0180
Feed (IPM) 13.0 13.0 13.0 13.0 13.0 13.0 13.0
> 375
≤ 450
115 RPM 14058 3514 1757 1171 879 703 502
(92-138)
Fr 0.0004 0.0018 0.0035 0.0053 0.0071 0.0088 0.0123
Feed (IPM) 6.2 6.2 6.2 6.2 6.2 6.2 6.2
P
TOOL STEELS
A2, D2, H13, L2, M2,
P20, S7, T15, W2
≤ 200
120 RPM 14669 3667 1834 1222 917 733 524
(96-144)
Fr 0.0006 0.0026 0.0051 0.0077 0.0103 0.0128 0.0179
Feed (IPM) 9.4 9.4 9.4 9.4 9.4 9.4 9.4
> 200
≤ 375
80 RPM 9779 2445 1222 815 611 489 349
(64-96)
Fr 0.0003 0.0012 0.0024 0.0036 0.0047 0.0059 0.0083
Feed (IPM) 2.9 2.9 2.9 2.9 2.9 2.9 2.9
> 375
≤ 475
70 RPM 8557 2139 1070 713 535 428 306
(56-84)
Fr 0.0002 0.0008 0.0016 0.0024 0.0032 0.0040 0.0056
Feed (IPM) 1.7 1.7 1.7 1.7 1.7 1.7 1.7
K
CAST IRONS
Gray, Malleable, Ductile
≤ 220
300 RPM 36672 9168 4584 3056 2292 1834 1310
(240-360)
Fr 0.0011 0.0045 0.0089 0.0134 0.0179 0.0224 0.0313
Feed (IPM) 41.0 41.0 41.0 41.0 41.0 41.0 41.0
> 220
≤ 260
265 RPM 32394 8098 4049 2699 2025 1620 1157
(212-318)
Fr 0.0011 0.0046 0.0091 0.0137 0.0183 0.0228 0.0320
Feed (IPM) 37.0 37.0 37.0 37.0 37.0 37.0 37.0
M
STAINLESS STEELS
(FREE MACHINING)
303, 416, 420F, 430F, 440F
≤ 185
250 RPM 30560 7640 3820 2547 1910 1528 1091
(200-300)
Fr 0.0006 0.0026 0.0051 0.0077 0.0102 0.0128 0.0179
Feed (IPM) 19.5 19.5 19.5 19.5 19.5 19.5 19.5
> 185
≤ 275
150 RPM 18336 4584 2292 1528 1146 917 655
(120-180)
Fr 0.0005 0.0020 0.0039 0.0059 0.0079 0.0098 0.0137
Feed (IPM) 9.0 9.0 9.0 9.0 9.0 9.0 9.0
M
STAINLESS STEELS
(DIFFICULT)
304, 316, 321, 13-8 PH,
15-5PH, 17-4 PH, CUSTOM 450
≤ 275
80 RPM 9779 2445 1222 815 611 489 349
(64-96)
Fr 0.0005 0.0020 0.0039 0.0059 0.0079 0.0098 0.0137
Feed (IPM) 4.8 4.8 4.8 4.8 4.8 4.8 4.8
> 275
≤ 375
55 RPM 6723 1681 840 560 420 336 240
(44-66)
Fr 0.0004 0.0018 0.0036 0.0054 0.0071 0.0089 0.0125
Feed (IPM) 3.0 3.0 3.0 3.0 3.0 3.0 3.0
continued on next page
www.sgstool.com
23
Fractional
|
Speed & Feed Recommendations
Tool Wizard
CALCULATE APPLICATION PARAMETERS
www.sgstool.com
Series
135 5D
Fractional
Hardness
(Brinell)
Vc
(SFM)
Diameter (D
1
)
(inch)
1/32 1/8 1/4 3/8 1/2 5/8 7/8
S
SUPER ALLOYS
(NICKEL , COBALT,
IRON BASE)
Inconel 601, 617, 625, Incoloy,
Monel 400, Rene, Waspaloy
≤ 300
40 RPM 4890 1222 611 407 306 244 175
(32-48)
Fr 0.0002 0.0008 0.0016 0.0025 0.0033 0.0041 0.0057
Feed (IPM) 1.0 1.0 1.0 1.0 1.0 1.0 1.0
> 300
≤ 400
20 RPM 2445 611 306 204 153 122 87
(16-24)
Fr 0.0002 0.0007 0.0013 0.0020 0.0026 0.0033 0.0046
Feed (IPM) 0.4 0.4 0.4 0.4 0.4 0.4 0.4
S
TITANIUM ALLOYS
Pure Ttanium, Ti6Al4V,
Ti6Al2Sn4Zr2Mo,
Ti4Al4Mo2Sn0.5Si,
Ti-6Al4V
≤ 275
105 RPM 12835 3209 1604 1070 802 642 458
(84-126)
Fr 0.0005 0.0018 0.0036 0.0054 0.0072 0.0090 0.0127
Feed (IPM) 5.8 5.8 5.8 5.8 5.8 5.8 5.8
> 275
≤ 350
80 RPM 9779 2445 1222 815 611 489 349
(64-96)
Fr #VALUE! 0.0016 0.0032 0.0048 0.0064 0.0080 0.0112
Feed (IPM) 3.9 3.9 3.9 3.9 3.9 3.9
> 350
≤ 440
42 RPM 5134 1284 642 428 321 257 183
(34-50)
Fr 0.0003 0.0012 0.0025 0.0037 0.0050 0.0062 0.0087
Feed (IPM) 1.6 1.6 1.6 1.6 1.6 1.6 1.6
N
ALUMINUM ALLOYS
2017, 2024, 356,
6061, 7075
≤ 80
635 RPM 77622 19406 9703 6469 4851 3881 2772
(508-762)
Fr 0.0012 0.0049 0.0099 0.0148 0.0198 0.0247 0.0346
Feed (IPM) 96.0 96.0 96.0 96.0 96.0 96.0 96.0
> 80
540 RPM 66010 16502 8251 5501 4126 3300 2357
(432-648)
Fr 0.0012 0.0050 0.0099 0.0149 0.0199 0.0248 0.0348
Feed (IPM) 82.0 82.0 82.0 82.0 82.0 82.0 82.0
N
COPPER ALLOYS
Alum Bronze, C110,
Muntz Brass
≤ 140
450 RPM 55008 13752 6876 4584 3438 2750 1965
(360-540)
Fr 0.0005 0.0020 0.0040 0.0060 0.0080 0.0100 0.0140
Feed (IPM) 27.5 27.5 27.5 27.5 27.5 27.5 27.5
> 140
360 RPM 44006 11002 5501 3667 2750 2200 1572
(288-432)
Fr 0.0005 0.0020 0.0040 0.0060 0.0080 0.0100 0.0140
Feed (IPM) 22.0 22.0 22.0 22.0 22.0 22.0 22.0
Note:
•  rpm = sfm x 3.82 / D
1
•  ipm = (inch / revolution) x rpm
•  reduce speed and feed for materials harder than listed
•  refer to the SGS Tool Wizard for complete technical information (www.sgstool.com)
www.sgstool.com
24
Metric
|
Speed & Feed Recommendations
Series
135M 5D
Metric
Hardness
(Brinell)
Vc
(m/min)
Diameter (D
1
)
(mm)
1.5 3 6 8 10 12 16 20
P
CARBON STEELS
1018, 1040, 1080, 1090, 10L50,
1140, 1212, 12L15, 1525, 1536
≤ 175
105 RPM 22297 11148 5574 4181 3344 2787 2090 1672
(84-126)
Fr 0.048 0.095 0.190 0.254 0.317 0.380 0.507 0.634
Feed (mm/min) 1060 1060 1060 1060 1060 1060 1060 1060
> 175
≤ 275
94 RPM 20035 10017 5009 3756 3005 2504 1878 1503
(76-113)
Fr 0.043 0.085 0.171 0.228 0.285 0.341 0.455 0.569
Feed (mm/min) 855 855 855 855 855 855 855 855
> 275
≤ 425
55 RPM 11633 5816 2908 2181 1745 1454 1091 872
(44-66)
Fr 0.036 0.071 0.143 0.190 0.238 0.285 0.381 0.476
Feed (mm/min) 415 415 415 415 415 415 415 415
P
ALLOY STEELS
4140, 4150, 4320, 5120,
5150, 8630, 86L20, 50100
≤ 275
82 RPM 17449 8725 4362 3272 2617 2181 1636 1309
(66-99)
Fr 0.036 0.072 0.143 0.191 0.239 0.287 0.382 0.478
Feed (mm/min) 625 625 625 625 625 625 625 625
> 275
≤ 375
50 RPM 10664 5332 2666 1999 1600 1333 1000 800
(40-60)
Fr 0.031 0.062 0.124 0.165 0.206 0.248 0.330 0.413
Feed (mm/min) 330 330 330 330 330 330 330 330
> 375
≤ 450
35 RPM 7432 3716 1858 1394 1115 929 697 557
(28-42)
Fr 0.022 0.043 0.086 0.115 0.144 0.172 0.230 0.287
Feed (mm/min) 160 160 160 160 160 160 160 160
P
TOOL STEELS
A2, D2, H13, L2, M2,
P20, S7, T15, W2
≤ 200
37 RPM 7755 3878 1939 1454 1163 969 727 582
(29-44)
Fr 0.031 0.062 0.124 0.165 0.206 0.248 0.330 0.413
Feed (mm/min) 240 240 240 240 240 240 240 240
> 200
≤ 375
24 RPM 5170 2585 1293 969 776 646 485 388
(20-29)
Fr 0.015 0.029 0.058 0.077 0.097 0.116 0.155 0.193
Feed (mm/min) 75 75 75 75 75 75 75 75
> 375
≤ 475
21 RPM 4524 2262 1131 848 679 565 424 339
(17-26)
Fr 0.010 0.020 0.040 0.053 0.066 0.080 0.106 0.133
Feed (mm/min) 45 45 45 45 45 45 45 45
K
CAST IRONS
Gray, Malleable, Ductile
≤ 220
91 RPM 19388 9694 4847 3635 2908 2424 1818 1454
(73-110)
Fr 0.054 0.108 0.217 0.289 0.361 0.433 0.578 0.722
Feed (mm/min) 1050 1050 1050 1050 1050 1050 1050 1050
> 220
≤ 260
81 RPM 17126 8563 4282 3211 2569 2141 1606 1284
(65-97)
Fr 0.055 0.109 0.218 0.291 0.364 0.437 0.582 0.728
Feed (mm/min) 935 935 935 935 935 935 935 935
M
STAINLESS STEELS
(FREE MACHINING)
303, 416, 420F, 430F, 440F
≤ 185
76 RPM 16157 8078 4039 3029 2424 2020 1515 1212
(61-91)
Fr 0.031 0.061 0.123 0.163 0.204 0.245 0.327 0.408
Feed (mm/min) 495
495 495 495 495 495 495 495
> 185
≤ 275
46 RPM 9694 4847 2424 1818 1454 1212 909 727
(37-55)
Fr 0.024 0.047 0.095 0.127 0.158 0.190 0.253 0.316
Feed (mm/min) 230 230 230 230 230 230 230 230
M
STAINLESS STEELS
(DIFFICULT)
304, 316, 321, 13-8 PH,
15-5PH, 17-4 PH, CUSTOM 450
≤ 275
24 RPM 5170 2585 1293 969 776 646 485 388
(20-29)
Fr 0.023 0.046 0.093 0.124 0.155 0.186 0.248 0.309
Feed (mm/min) 120 120 120 120 120 120 120 120
> 275
≤ 375
17 RPM 3555 1777 889 666 533 444 333 267
(13-20)
Fr 0.021 0.042 0.084 0.113 0.141 0.169 0.225 0.281
Feed (mm/min) 75 75 75 75 75 75 75 75
continued on next page
www.sgstool.com
25
Metric
|
Speed & Feed Recommendations
Tool Wizard
CALCULATE APPLICATION PARAMETERS
www.sgstool.com
Series
135M 5D
Metric
Hardness
(Brinell)
Vc
(m/min)
Diameter (D
1
)
(mm)
1.5 3 6 8 10 12 16 20
S
SUPER ALLOYS
(NICKEL , COBALT,
IRON BASE)
Inconel 601, 617, 625, Incoloy,
Monel 400, Rene, Waspaloy
≤ 300
12 RPM 2585 1293 646 485 388 323 242 194
(10-15)
Fr 0.010 0.019 0.039 0.052 0.064 0.077 0.103 0.129
Feed (mm/min) 25 25 25 25 25 25 25 25
> 300
≤ 400
6 RPM 1293 646 323 242 194 162 121 97
(5-7)
Fr 0.007 0.014 0.028 0.037 0.046 0.056 0.074 0.093
Feed (mm/min) 9 9 9 9 9 9 9 9
S
TITANIUM ALLOYS
Pure Ttanium, Ti6Al4V,
Ti6Al2Sn4Zr2Mo,
Ti4Al4Mo2Sn0.5Si,
Ti-6Al4V
≤ 275
32 RPM 6786 3393 1696 1272 1018 848 636 509
(26-38)
Fr 0.021 0.043 0.085 0.114 0.142 0.171 0.228 0.285
Feed (mm/min) 145 145 145 145 145 145 145 145
> 275
≤ 350
24 RPM 5170 2585 1293 969 776 646 485 388
(20-29)
Fr 0.019 0.039 0.077 0.103 0.129 0.155 0.206 0.258
Feed (mm/min) 100 100 100 100 100 100 100 100
> 350
≤ 440
13 RPM 2714 1357 679 509 407 339 254 204
(10-15)
Fr 0.015 0.029 0.059 0.079 0.098 0.118 0.157 0.196
Feed (mm/min) 40 40 40 40 40 40 40 40
N
ALUMINUM ALLOYS
2017, 2024, 356,
6061, 7075
≤ 80
194 RPM 41039 20519 10260 7695 6156 5130 3847 3078
(155-232)
Fr 0.059 0.118 0.237 0.316 0.395 0.474 0.632 0.790
Feed (mm/min) 2430 2430 2430 2430 2430 2430 2430 2430
> 80
165 RPM 34899 17449 8725 6544 5235 4362 3272 2617
(132-198)
Fr 0.059 0.118 0.237 0.316 0.394 0.473 0.631 0.789
Feed (mm/min) 2065 2065 2065 2065 2065 2065 2065 2065
N
COPPER ALLOYS
Alum Bronze, C110,
Muntz Brass
≤ 140
137 RPM 29082 14541 7271 5453 4362 3635 2726 2181
(110-165)
Fr 0.027 0.053 0.107 0.142 0.178 0.213 0.284 0.355
Feed (mm/min) 775 775 775 775 775 775 775 775
> 140
110 RPM 23266 11633 5816 4362 3490 2908 2181 1745
(88-132)
Fr 0.027 0.054 0.108 0.144 0.181 0.217 0.289 0.361
Feed (mm/min) 630 630 630 630 630 630 630 630
Note:
•  rpm = (1000 x m / min) / (3.14 x D
1
)
•  mm / min = (mm / revolution) x rpm
•  reduce speed and feed for materials harder than listed
•  refer to the SGS Tool Wizard for complete technical information (www.sgstool.com)
www.sgstool.com
26
A
A
B
C
D
E
The cutting edges of the SGS ICe-Carb are designed to allow the tool to achieve high penetration rates, while the
highly polished Ti-NAMITE A tool coating allows the chips to move smoothly along the ute and out of the cut.
This helps to avoid chip clogging often associated with elevated penetration rates. Through efcient chip
creation and movement, the drill operates at lower loads under identical conditions.
PERFORMANCE.
PERFORMANCE. PRECISION. PASSION.
WITH ICE-CARB INTERNAL COOLANT DRILLS
The design of the SGS ICe-Carb was created to bring
to the end user the ability to achieve high performance
results with high production demands. The internal
coolant design allows for better control of machining
temperatures during these types of applications, while
the geometry features provide effective and efcient
chip creation and removal. The results of the ICe-Carb
design are reduced cutting loads, increased operating
parameters and enhanced tool life.
COOLANT THROUGH DESIGN
promotes controlled and consistent
operating temperatures
• improves coolant ow to the cut while
maintaining strength
• increases tool life at increased
operating parameters
A
B
HIGH PERFORMANCE FLUTE DESIGN
optimized open uting
improved surface nish through effective
chip evacuation
C
POLISHED Ti-NAMITE A COATING
reduces friction between the chip and tool
preventing the impediment of chip ow
• decreased machine loads associated with
chip clogging
reduced friction reduces heat and
abrasion wear
D
HIGH PENETRATION 140° POINT GEOMETRY
• split point geometry for improved drill
penetration and accuracy
cam relief drill point
self centering design with high
penetration capabilities
E
ENGINEERED CUTTING EDGES
• precisely ground with a curvature that
allows efcient chip creation and control
controlled edge honing for longevity
negative corner position strengthens
and protects
TORQUE COMPARISON
8620 Carbon Steel @ 175 BHN
3/8” Diameter 1.125” Deep
350 sfm / 29 ipm
0
10
20
30
40
50
60
70
Unpolished Polished
TORQUE (in–lbs)
20% LESS
TORQUE
Solid Carbide Tools
www.sgstool.com
27
A
A
B
C
D
E
The cutting edges of the SGS ICe-Carb are designed to allow the tool to achieve high penetration rates, while the
highly polished Ti-NAMITE A tool coating allows the chips to move smoothly along the ute and out of the cut.
This helps to avoid chip clogging often associated with elevated penetration rates. Through efcient chip
creation and movement, the drill operates at lower loads under identical conditions.
PERFORMANCE.
PERFORMANCE. PRECISION. PASSION.
WITH ICE-CARB INTERNAL COOLANT DRILLS
The design of the SGS ICe-Carb was created to bring
to the end user the ability to achieve high performance
results with high production demands. The internal
coolant design allows for better control of machining
temperatures during these types of applications, while
the geometry features provide effective and efcient
chip creation and removal. The results of the ICe-Carb
design are reduced cutting loads, increased operating
parameters and enhanced tool life.
COOLANT THROUGH DESIGN
promotes controlled and consistent
operating temperatures
• improves coolant ow to the cut while
maintaining strength
• increases tool life at increased
operating parameters
A
B
HIGH PERFORMANCE FLUTE DESIGN
optimized open uting
improved surface nish through effective
chip evacuation
C
POLISHED Ti-NAMITE A COATING
reduces friction between the chip and tool
preventing the impediment of chip ow
• decreased machine loads associated with
chip clogging
reduced friction reduces heat and
abrasion wear
D
HIGH PENETRATION 140° POINT GEOMETRY
• split point geometry for improved drill
penetration and accuracy
cam relief drill point
self centering design with high
penetration capabilities
E
ENGINEERED CUTTING EDGES
• precisely ground with a curvature that
allows efcient chip creation and control
controlled edge honing for longevity
negative corner position strengthens
and protects
TORQUE COMPARISON
8620 Carbon Steel @ 175 BHN
3/8” Diameter 1.125” Deep
350 sfm / 29 ipm
0
10
20
30
40
50
60
70
Unpolished Polished
TORQUE (in–lbs)
20% LESS
TORQUE
Solid Carbide Tools
www.sgstool.com
28
SPEED (RPM) 1600
FEED (IPM) 9.6
HOLE DIAMETER 9.1mm (.3583)
HOLE DEPTH 3.3”
COOLANT PRESSURE 60 psi (BELOW RECOMMENDATIONS)
TYPE OF COOLANT WATER SOLUBLE
TYPE OF MACHINE CNC LATHE – LIVE PART
SGS ICE-CARB 8xD VS. COMPETITOR M
ACTUAL CUSTOMER TEST IN 17-4 PH STAINLESS STEEL @ 36 HRc
PRECISION.
The more efcient a drill can function, the more precise the results it can produce. The symmetrical grind of the
cam relieved point ensures balanced pressure during cutting, while the split point design ensures fast and accu-
rate engagement into the material. Precision must be maintained throughout the life of the drill, so the SGS
ICe-Carb’s specialized hone, strong margin design and negative corner position help to delay the wear that often
causes a drill to lose precision in the cut and prematurely end tool life.
PASSION.
Controlling temperatures during the cutting process certainly helps to improve the operating parameters and tool life
a tool is capable of achieving. All of the high performance features of the ICe-Carb are engineered to work together
to create the most efcient total
cutting performance beyond what
simply having coolant through the
tool can offer. The ute prole
compliments the coolant through
design of the ICe-Carb to create a
strong cutting tool that effectively
transports the chips being creat-
ed, while the cutting edges offer
a balance of strength and shear.
COST PER PART
$1.50$0.50$ $1.00
Competitor
SGS ICe-Carb
TOOL LIFE
NUMBER OF HOLES
5004003002001000
SGS ICe-Carb
Competitor
DRILL SIZE 3/8” (.3750)
DEPTH OF HOLE 1.875”
MATERIAL 316 STAINLESS STEEL @ 140 BHN
SPEED 1430 RPM (140 sfm)
FEED 8.5 IPM (.0059 ipr)
COOLANT 8% WATER SOLUBLE @ 700 psi
MACHINE HAAS VF-3 VMC
TYPE OF HOLE BLIND
SGS ICE-CARB VS. 2 COMPETITORS
CONDITION OF DRILLS AFTER 175 HOLES
SGS ICE-CARB COMPETITOR 1 COMPETITOR 2
FIRST HOLE LAST HOLE FIRST HOLE LAST HOLE FIRST HOLE LAST HOLE
No damage found, good
condition to continue using;
.375 Ø throughout depth
with good nish
Point severely chipped with
wear on margins; Coating
loss below cutting lips; .375
Ø held but surface nish
deteriorating
Better condition than
Competitor 1 but unacceptable
holes; Holes out of round,
oversized to .385 Ø and
tapered to .392 Ø with
heavy swirl marks
www.sgstool.com
29
SPEED (RPM) 1600
FEED (IPM) 9.6
HOLE DIAMETER 9.1mm (.3583)
HOLE DEPTH 3.3”
COOLANT PRESSURE 60 psi (BELOW RECOMMENDATIONS)
TYPE OF COOLANT WATER SOLUBLE
TYPE OF MACHINE CNC LATHE – LIVE PART
SGS ICE-CARB 8xD VS. COMPETITOR M
ACTUAL CUSTOMER TEST IN 17-4 PH STAINLESS STEEL @ 36 HRc
PRECISION.
The more efcient a drill can function, the more precise the results it can produce. The symmetrical grind of the
cam relieved point ensures balanced pressure during cutting, while the split point design ensures fast and accu-
rate engagement into the material. Precision must be maintained throughout the life of the drill, so the SGS
ICe-Carb’s specialized hone, strong margin design and negative corner position help to delay the wear that often
causes a drill to lose precision in the cut and prematurely end tool life.
PASSION.
Controlling temperatures during the cutting process certainly helps to improve the operating parameters and tool life
a tool is capable of achieving. All of the high performance features of the ICe-Carb are engineered to work together
to create the most efcient total
cutting performance beyond what
simply having coolant through the
tool can offer. The ute prole
compliments the coolant through
design of the ICe-Carb to create a
strong cutting tool that effectively
transports the chips being creat-
ed, while the cutting edges offer
a balance of strength and shear.
COST PER PART
$1.50$0.50$ $1.00
Competitor
SGS ICe-Carb
TOOL LIFE
NUMBER OF HOLES
5004003002001000
SGS ICe-Carb
Competitor
DRILL SIZE 3/8” (.3750)
DEPTH OF HOLE 1.875”
MATERIAL 316 STAINLESS STEEL @ 140 BHN
SPEED 1430 RPM (140 sfm)
FEED 8.5 IPM (.0059 ipr)
COOLANT 8% WATER SOLUBLE @ 700 psi
MACHINE HAAS VF-3 VMC
TYPE OF HOLE BLIND
SGS ICE-CARB VS. 2 COMPETITORS
CONDITION OF DRILLS AFTER 175 HOLES
SGS ICE-CARB COMPETITOR 1 COMPETITOR 2
FIRST HOLE LAST HOLE FIRST HOLE LAST HOLE FIRST HOLE LAST HOLE
No damage found, good
condition to continue using;
.375 Ø throughout depth
with good nish
Point severely chipped with
wear on margins; Coating
loss below cutting lips; .375
Ø held but surface nish
deteriorating
Better condition than
Competitor 1 but unacceptable
holes; Holes out of round,
oversized to .385 Ø and
tapered to .392 Ø with
heavy swirl marks
www.sgstool.com
30
Series 140 5xD
|
Internal Coolant Drills
SERIES 140
5xD
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
3,0 mm 0.1181 6,0 66,0 28,0 23,0 36,0 63901
3,1 mm 0.1220 6,0 66,0 28,0 23,0 36,0 63902
1/8 0.1250 6,0 66,0 28,0 23,0 36,0 51901
3,2 mm 0.1260 M3,5 X 0,35 6,0 66,0 28,0 23,0 36,0 63903
3,3 mm 0.1299 M4 X 0,7 6,0 66,0 28,0 23,0 36,0 63904
3,4 mm 0.1339 6,0 66,0 28,0 23,0 36,0 63905
29 0.1360 8-32,8-36 6,0 66,0 28,0 23,0 36,0 51902
3,5 mm 0.1378 M4 X 0,5 6,0 66,0 28,0 23,0 36,0 63906
9/64 0.1406 6,0 66,0 28,0 23,0 36,0 51903
3,6 mm 0.1417 M4 X 0,35 6,0 66,0 28,0 23,0 36,0 63907
3,7 mm 0.1457 M4,5 X 0,75 6,0 66,0 28,0 23,0 36,0 63908
3,8 mm 0.1496 10-24 6,0 74,0 36,0 29,0 36,0 51904
3,9 mm 0.1535 6,0 74,0 36,0 29,0 36,0 63909
5/32 0.1562 6,0 74,0 36,0 29,0 36,0 51905
4,0 mm 0.1575 M4,5 X 0,5 6,0 74,0 36,0 29,0 36,0 63910
21 0.1590 10-32 6,0 74,0 36,0 29,0 36,0 51906
4,1 mm 0.1614 6,0 74,0 36,0 29,0 36,0 63911
4,2 mm 0.1654 M5 / M5 x 0,75 6,0 74,0 36,0 29,0 36,0 63912
4,3 mm 0.1693 6,0 74,0 36,0 29,0 36,0 63913
11/64 0.1719 6,0 74,0 36,0 29,0 36,0 51907
4,4 mm 0.1732 12-24 6,0 74,0 36,0 29,0 36,0 63914
4,5 mm 0.1772 M5 X 0,5 6,0 74,0 36,0 29,0 36,0 63915
4,6 mm 0.1811 12-28 6,0 74,0 36,0 29,0 36,0 63916
4,7 mm 0.1850 12-32 6,0 74,0 36,0 29,0 36,0 63917
3/16 0.1875 6,0 82,0 44,0 35,0 36,0 51908
4,8 mm 0.1890 7/32-32 6,0 82,0 44,0 35,0 36,0 63918
4,9 mm 0.1929 6,0 82,0 44,0 35,0 36,0 63919
5,0 mm 0.1969 M6 X 1 6,0 82,0 44,0 35,0 36,0 63920
5,1 mm 0.2008 1/4-20 6,0 82,0 44,0 35,0 36,0 63900
13/64 0.2031 6,0 82,0 44,0 35,0 36,0 51910
5,2 mm 0.2047 M6 X 0,75 6,0 82,0 44,0 35,0 36,0 63921
5,3 mm 0.2087 6,0 82,0 44,0 35,0 36,0 63922
5,4 mm 0.2126 6,0 82,0 44,0 35,0 36,0 63998
5,5 mm 0.2165 M6 X 0,5 6,0 82,0 44,0 35,0 36,0 63923
7/32 0.2188 1/4-32 6,0 82,0 44,0 35,0 36,0 51912
5,6 mm 0.2205 6,0 82,0 44,0 35,0 36,0 63924
5,7 mm 0.2244 6,0 82,0 44,0 35,0 36,0 63925
5,8 mm 0.2283 6,0 82,0 44,0 35,0 36,0 63926
5,9 mm 0.2323 6,0 82,0 44,0 35,0 36,0 63927
15/64 0.2344 6,0 82,0 44,0 35,0 36,0 51913
TOLERANCES (inch)
DIAMETER D
1
D
2
≥ 1/8 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
(continued on next page)
140°
30°
L
1
L
2
L
3
L
4
D
2
D
1
www.sgstool.com
31
Series 140 5xD
|
Internal Coolant Drills
SERIES 140
5xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
6,0 mm 0.2362 M7 X 1 6,0 82,0 44,0 35,0 36,0 63928
6,1 mm 0.2402 8,0 91,0 53,0 43,0 36,0 63929
6,2 mm 0.2441 M7 X 0,75 8,0 91,0 53,0 43,0 36,0 63930
6,3 mm 0.2480 8,0 91,0 53,0 43,0 36,0 63931
1/4 0.2500 8,0 91,0 53,0 43,0 36,0 51914
6,4 mm 0.2520 8,0 91,0 53,0 43,0 36,0 63932
6,5 mm 0.2559 8,0 91,0 53,0 43,0 36,0 63933
F 0.2570 5/16-18 8,0 91,0 53,0 43,0 36,0 51915
6,6 mm 0.2598 8,0 91,0 53,0 43,0 36,0 63934
6,7 mm 0.2638 8,0 91,0 53,0 43,0 36,0 63935
17/64 0.2657 5/16-20 8,0 91,0 53,0 43,0 36,0 51916
6,8 mm 0.2677 M8 X 1,25 8,0 91,0 53,0 43,0 36,0 63936
6,9 mm 0.2717 5/16-24 8,0 91,0 53,0 43,0 36,0 63999
7,0 mm 0.2756 M8 X 1 8,0 91,0 53,0 43,0 36,0 63937
7,1 mm 0.2795 8,0 91,0 53,0 43,0 36,0 63938
9/32 0.2812 5/16-32 8,0 91,0 53,0 43,0 36,0 51918
7,2 mm 0.2835 M8 X 0,75 8,0 91,0 53,0 43,0 36,0 63939
7,3 mm 0.2874 8,0 91,0 53,0 43,0 36,0 63940
7,4 mm 0.2913 8,0 91,0 53,0 43,0 36,0 63941
7,5 mm 0.2953 M8 X 0,5 8,0 91,0 53,0 43,0 36,0 63942
19/64 0.2969 8,0 91,0 53,0 43,0 36,0 51919
7,6 mm 0.2992 8,0 91,0 53,0 43,0 36,0 63943
7,7 mm 0.3031 8,0 91,0 53,0 43,0 36,0 63944
7,8 mm 0.3071 M9 X 1,25 8,0 91,0 53,0 43,0 36,0 63945
7,9 mm 0.3110 8,0 91,0 53,0 43,0 36,0 63946
5/16 0.3125 3/8-16 8,0 91,0 53,0 43,0 36,0 51920
8,0 mm 0.3150 M9 X 1 8,0 91,0 53,0 43,0 36,0 63947
8,1 mm 0.3189 10,0 103,0 61,0 49,0 40,0 63948
8,2 mm 0.3228 10,0 103,0 61,0 49,0 40,0 63949
8,3 mm 0.3268 10,0 103,0 61,0 49,0 40,0 63950
21/64 0.3281 3/8-20 10,0 103,0 61,0 49,0 40,0 51921
8,4 mm 0.3307 10,0 103,0 61,0 49,0 40,0 63951
Q 0.3320 3/8-24 10,0 103,0 61,0 49,0 40,0 51922
8,5 mm 0.3346 M10 X 1,5 10,0 103,0 61,0 49,0 40,0 63952
8,6 mm 0.3386 10,0 103,0 61,0 49,0 40,0 63953
8,7 mm 0.3425 10,0 103,0 61,0 49,0 40,0 63954
11/32 0.3438 3/8-32 10,0 103,0 61,0 49,0 40,0 51923
8,8 mm 0.3465 M10 X 1,25 10,0 103,0 61,0 49,0 40,0 63955
8,9 mm 0.3504 10,0 103,0 61,0 49,0 40,0 63956
9,0 mm 0.3543 M10 X 1 10,0 103,0 61,0 49,0 40,0 63957
TOLERANCES (inch)
DIAMETER D
1
D
2
≥ 1/8 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
(continued on next page)
140°
30°
L
1
L
2
L
3
L
4
D
2
D
1
www.sgstool.com
32
Series 140 5xD
|
Internal Coolant Drills
SERIES 140
5xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
9,1 mm 0.3583 10,0 103,0 61,0 49,0 40,0 63958
23/64 0.3594 10,0 103,0 61,0 49,0 40,0 51924
9,2 mm 0.3622 M10 X 0,75 10,0 103,0 61,0 49,0 40,0 63959
9,3 mm 0.3661 10,0 103,0 61,0 49,0 40,0 63960
U 0.3680 7/16-14 10,0 103,0 61,0 49,0 40,0 51925
9,4 mm 0.3701 10,0 103,0 61,0 49,0 40,0 63961
9,5 mm 0.3740 M11 / M10 X 0,5 10,0 103,0 61,0 49,0 40,0 63962
3/8 0.3750 10,0 103,0 61,0 49,0 40,0 51926
9,6 mm 0.3780 10,0 103,0 61,0 49,0 40,0 63963
9,7 mm 0.3819 10,0 103,0 61,0 49,0 40,0 63964
9,8 mm 0.3858 10,0 103,0 61,0 49,0 40,0 63965
9,9 mm 0.3898 10,0 103,0 61,0 49,0 40,0 63966
25/64 0.3906 7/16-20 10,0 103,0 61,0 49,0 40,0 51927
10,0 mm 0.3937 10,0 103,0 61,0 49,0 40,0 63967
10,1 mm 0.3976 12,0 118,0 71,0 56,0 45,0 63968
10,2 mm 0.4016 M12 X 1,75 12,0 118,0 71,0 56,0 45,0 63969
10,3 mm 0.4055 12,0 118,0 71,0 56,0 45,0 63970
13/32 0.4062 12,0 118,0 71,0 56,0 45,0 51928
10,4 mm 0.4094 12,0 118,0 71,0 56,0 45,0 63971
10,5 mm 0.4134 M12 X 1,5 12,0 118,0 71,0 56,0 45,0 63972
10,6 mm 0.4173 12,0 118,0 71,0 56,0 45,0 63973
10,7 mm 0.4213 12,0 118,0 71,0 56,0 45,0 63974
27/64 0.4219 1/2-13 12,0 118,0 71,0 56,0 45,0 51929
10,8 mm 0.4252 M12 X 1,25 12,0 118,0 71,0 56,0 45,0 63975
10,9 mm 0.4291 12,0 118,0 71,0 56,0 45,0 63976
11,0 mm 0.4331 M12 X 1 12,0 118,0 71,0 56,0 45,0 63977
11,1 mm 0.4370 12,0 118,0 71,0 56,0 45,0 63978
7/16 0.4375 1/4-18NPT 12,0 118,0 71,0 56,0 45,0 51930
11,2 mm 0.4409 12,0 118,0 71,0 56,0 45,0 63979
11,3 mm 0.4449 12,0 118,0 71,0 56,0 45,0 63980
11,4 mm 0.4488 12,0 118,0 71,0 56,0 45,0 63981
11,5 mm 0.4528 M12 X 0,5 12,0 118,0 71,0 56,0 45,0 64000
11,6 mm 0.4567 12,0 118,0 71,0 56,0 45,0 63982
11,7 mm 0.4606 12,0 118,0 71,0 56,0 45,0 63983
11,8 mm 0.4646 12,0 118,0 71,0 56,0 45,0 63984
11,9 mm 0.4685 12,0 118,0 71,0 56,0 45,0 63985
15/32 0.4688 1/2-28 12,0 118,0 71,0 56,0 45,0 51932
12,0 mm 0.4724 M14 X 2 12,0 118,0 71,0 56,0 45,0 63986
31/64 0.4844 9/16-12 14,0 124,0 77,0 60,0 45,0 51933
12,5 mm 0.4921 M14 X 1,5 14,0 124,0 77,0 60,0 45,0 63987
TOLERANCES (inch)
DIAMETER D
1
D
2
≥ 1/8 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
140°
30°
L
1
L
2
L
3
L
4
D
2
D
1
(continued on next page)
www.sgstool.com
33
Series 140 5xD
|
Internal Coolant Drills
SERIES 140
5xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
1/2 0.5000 14,0 124,0 77,0 60,0 45,0 51934
12,8 mm 0.5039 M14 X 1,25 14,0 124,0 77,0 60,0 45,0 63988
13,0 mm 0.5118 M14 X 1 14,0 124,0 77,0 60,0 45,0 63989
33/64 0.5156 9/16-18 14,0 124,0 77,0 60,0 45,0 51935
13,5 mm 0.5315 5/8-11 14,0 124,0 77,0 60,0 45,0 64001
13,8 mm 0.5433 14,0 124,0 77,0 60,0 45,0 63990
14,0 mm 0.5512 M16 X 2 14,0 124,0 77,0 60,0 45,0 63991
9/16 0.5625 16,0 133,0 83,0 63,0 48,0 51937
14,5 mm 0.5709 M16 X 1,5 16,0 133,0 83,0 63,0 48,0 63992
37/64 0.5781 5/8-18 16,0 133,0 83,0 63,0 48,0 51938
14,8 mm 0.5827 16,0 133,0 83,0 63,0 48,0 63993
15,0 mm 0.5906 M16 X 1 16,0 133,0 83,0 63,0 48,0 63994
15,5 mm 0.6102 M18 X 2,5 16,0 133,0 83,0 63,0 48,0 63995
15,8 mm 0.6220 16,0 133,0 83,0 63,0 48,0 63996
5/8 0.6250 11/16-16 16,0 133,0 83,0 63,0 48,0 51939
16,0 mm 0.6299 16,0 133,0 83,0 63,0 48,0 63997
21/32 0.6562 3/4-10 18,0 143,0 93,0 71,0 48,0 51940
11/16 0.6875 3/4-16 18,0 143,0 93,0 71,0 48,0 51941
3/4 0.7500 13/16-16 20,0 153,0 101,0 77,0 50,0 51942
TOLERANCES (inch)
DIAMETER D
1
D
2
≥ 1/8 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
> 3/4 - 1 +0.0003 / –0.0011 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
140°
30°
L
1
L
2
L
3
L
4
D
2
D
1
www.sgstool.com
34
Series 140 8xD
|
Internal Coolant Drills
SERIES 140
8xD
TOLERANCES (inch)
DIAMETER D
1
D
2
≥ 1/8 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
(continued on next page)
30°140°
L
1
L
2
L
3
L
4
D
2
D
1
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
3,0 mm 0.1181 6,0 72,0 34,0 29,0 36,0 63575
3,1 mm 0.1220 6,0 72,0 34,0 29,0 36,0 63576
1/8 0.1250 6,0 72,0 34,0 29,0 36,0 51801
3,2 mm 0.1260 M3,5 X 0,35 6,0 72,0 34,0 29,0 36,0 63577
3,3 mm 0.1299 M4 X 0,7 6,0 72,0 34,0 29,0 36,0 63578
3,4 mm 0.1339 6,0 72,0 34,0 29,0 36,0 63579
29 0.1360 8-32,8-36 6,0 72,0 34,0 29,0 36,0 51802
3,5 mm 0.1378 M4 X 0,5 6,0 72,0 34,0 29,0 36,0 63580
9/64 0.1406 6,0 72,0 34,0 29,0 36,0 51803
3,6 mm 0.1417 M4 X 0,35 6,0 72,0 34,0 29,0 36,0 63581
3,7 mm 0.1457 M4,5 X 0,75 6,0 72,0 34,0 29,0 36,0 63582
3,8 mm 0.1496 10-24 6,0 81,0 43,0 36,0 36,0 63583
3,9 mm 0.1535 6,0 81,0 43,0 36,0 36,0 63584
5/32 0.1562 6,0 81,0 43,0 36,0 36,0 51804
4,0 mm 0.1575 M4,5 X 0,5 6,0 81,0 43,0 36,0 36,0 63585
21 0.1590 10-32 6,0 81,0 43,0 36,0 36,0 51805
4,1 mm 0.1614 6,0 81,0 43,0 36,0 36,0 63586
4,2 mm 0.1654 M5 / M5 X 0,75 6,0 81,0 43,0 36,0 36,0 63587
4,3 mm 0.1693 6,0 81,0 43,0 36,0 36,0 63588
11/64 0.1719 6,0 81,0 43,0 36,0 36,0 51806
4,4 mm 0.1732 12-24 6,0 81,0 43,0 36,0 36,0 63589
4,5 mm 0.1772 M5 X 0,5 6,0 81,0 43,0 36,0 36,0 63590
4,6 mm 0.1811 12-28 6,0 81,0 43,0 36,0 36,0 63591
4,7 mm 0.1850 12-32 6,0 81,0 43,0 36,0 36,0 63592
3/16 0.1875 6,0 95,0 57,0 48,0 36,0 51807
4,8 mm 0.1890 7/32-32 6,0 95,0 57,0 48,0 36,0 63593
4,9 mm 0.1929 6,0 95,0 57,0 48,0 36,0 63594
5,0 mm 0.1969 M6 X 1 6,0 95,0 57,0 48,0 36,0 63595
5,1 mm 0.2008 1/4-20 6,0 95,0 57,0 48,0 36,0 63596
13/64 0.2031 6,0 95,0 57,0 48,0 36,0 51808
5,2 mm 0.2047 M6 X 0,75 6,0 95,0 57,0 48,0 36,0 63597
5,3 mm 0.2087 6,0 95,0 57,0 48,0 36,0 63598
5,4 mm 0.2126 6,0 95,0 57,0 48,0 36,0 63599
5,5 mm 0.2165 M6 X 0,5 6,0 95,0 57,0 48,0 36,0 63600
7/32 0.2188 1/4-32 6,0 95,0 57,0 48,0 36,0 51809
5,6 mm 0.2205 6,0 95,0 57,0 48,0 36,0 63601
5,7 mm 0.2244 6,0 95,0 57,0 48,0 36,0 63602
5,8 mm 0.2283 6,0 95,0 57,0 48,0 36,0 63603
5,9 mm 0.2323 6,0 95,0 57,0 48,0 36,0 63604
15/64 0.2344 6,0 95,0 57,0 48,0 36,0 51810
www.sgstool.com
35
TOLERANCES (inch)
DIAMETER D
1
D
2
≥ 1/8 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
Series 140 8xD
|
Internal Coolant Drills
SERIES 140
8xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
6,0 mm 0.2362 M7 X 1 6,0 95,0 57,0 48,0 36,0 63605
6,1 mm 0.2402 8,0 114,0 76,0 64,0 36,0 63606
6,2 mm 0.2441 M7 X 0,75 8,0 114,0 76,0 64,0 36,0 63607
6,3 mm 0.2480 8,0 114,0 76,0 64,0 36,0 63608
1/4 0.2500 8,0 114,0 76,0 64,0 36,0 51811
6,4 mm 0.2520 8,0 114,0 76,0 64,0 36,0 63609
6,5 mm 0.2559 8,0 114,0 76,0 64,0 36,0 63610
F 0.2570 5/16-18 8,0 114,0 76,0 64,0 36,0 51812
6,6 mm 0.2598 8,0 114,0 76,0 64,0 36,0 63611
6,7 mm 0.2638 8,0 114,0 76,0 64,0 36,0 63612
17/64 0.2657 5/16-20 8,0 114,0 76,0 64,0 36,0 51813
6,8 mm 0.2677 M8 X 1,25 8,0 114,0 76,0 64,0 36,0 63613
6,9 mm 0.2717 8,0 114,0 76,0 64,0 36,0 63614
7,0 mm 0.2756 M8 X 1 8,0 114,0 76,0 64,0 36,0 63615
7,1 mm 0.2795 8,0 114,0 76,0 64,0 36,0 63616
9/32 0.2812 5/16-32 8,0 114,0 76,0 64,0 36,0 51814
7,2 mm 0.2835 M8 X 0,75 8,0 114,0 76,0 64,0 36,0 63617
7,3 mm 0.2874 8,0 114,0 76,0 64,0 36,0 63618
7,4 mm 0.2913 8,0 114,0 76,0 64,0 36,0 63619
7,5 mm 0.2953 M8 X 0,5 8,0 114,0 76,0 64,0 36,0 63620
19/64 0.2969 8,0 114,0 76,0 64,0 36,0 51815
7,6 mm 0.2992 8,0 114,0 76,0 64,0 36,0 63621
7,7 mm 0.3031 8,0 114,0 76,0 64,0 36,0 63622
7,8 mm 0.3071 M9 X 1,25 8,0 114,0 76,0 64,0 36,0 63623
7,9 mm 0.3110 8,0 114,0 76,0 64,0 36,0 63624
5/16 0.3125 3/8-16 8,0 114,0 76,0 64,0 36,0 51816
8,0 mm 0.3150 M9 X 1 8,0 114,0 76,0 64,0 36,0 63625
8,1 mm 0.3189 10,0 142,0 95,0 80,0 40,0 63626
8,2 mm 0.3228 10,0 142,0 95,0 80,0 40,0 63627
8,3 mm 0.3268 10,0 142,0 95,0 80,0 40,0 63628
21/64 0.3281 3/8-20 10,0 142,0 95,0 80,0 40,0 51817
8,4 mm 0.3307 10,0 142,0 95,0 80,0 40,0 63629
Q 0.3320 3/8-24 10,0 142,0 95,0 80,0 40,0 51818
8,5 mm 0.3346 M10 X 1,5 10,0 142,0 95,0 80,0 40,0 63630
8,6 mm 0.3386 10,0 142,0 95,0 80,0 40,0 63631
8,7 mm 0.3425 10,0 142,0 95,0 80,0 40,0 63632
11/32 0.3438 3/8-32 10,0 142,0 95,0 80,0 40,0 51819
8,8 mm 0.3465 M10 X 1,25 10,0 142,0 95,0 80,0 40,0 63633
8,9 mm 0.3504 10,0 142,0 95,0 80,0 40,0 63634
9,0 mm 0.3543 M10 X 1 10,0 142,0 95,0 80,0 40,0 63635
(continued on next page)
30°140°
L
1
L
2
L
3
L
4
D
2
D
1
www.sgstool.com
36
Series 140 8xD
|
Internal Coolant Drills
SERIES 140
8xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
9,1 mm 0.3583 10,0 142,0 95,0 80,0 40,0 63636
23/64 0.3594 10,0 142,0 95,0 80,0 40,0 51820
9,2 mm 0.3622 M10 X 0,75 10,0 142,0 95,0 80,0 40,0 63637
9,3 mm 0.3661 10,0 142,0 95,0 80,0 40,0 63638
U 0.3680 7/16-14 10,0 142,0 95,0 80,0 40,0 51821
9,4 mm 0.3701 10,0 142,0 95,0 80,0 40,0 63639
9,5 mm 0.3740 M11 / M10 X 0,5 10,0 142,0 95,0 80,0 40,0 63640
3/8 0.3750 10,0 142,0 95,0 80,0 40,0 51822
9,6 mm 0.3780 10,0 142,0 95,0 80,0 40,0 63641
9,7 mm 0.3819 10,0 142,0 95,0 80,0 40,0 63642
9,8 mm 0.3858 10,0 142,0 95,0 80,0 40,0 63643
9,9 mm 0.3898 10,0 142,0 95,0 80,0 40,0 63644
25/64 0.3906 7/16-20 10,0 142,0 95,0 80,0 40,0 51823
10,0 mm 0.3937 10,0 142,0 95,0 80,0 40,0 63645
10,1 mm 0.3976 12,0 162,0 114,0 96,0 45,0 63646
10,2 mm 0.4016 M12 X 1,75 12,0 162,0 114,0 96,0 45,0 63647
10,3 mm 0.4055 12,0 162,0 114,0 96,0 45,0 63648
13/32 0.4062 12,0 162,0 114,0 96,0 45,0 51824
10,4 mm 0.4094 12,0 162,0 114,0 96,0 45,0 63649
10,5 mm 0.4134 M12 X 1,5 12,0 162,0 114,0 96,0 45,0 63650
10,6 mm 0.4173 12,0 162,0 114,0 96,0 45,0 63651
10,7 mm 0.4213 12,0 162,0 114,0 96,0 45,0 63652
27/64 0.4219 1/2-13 12,0 162,0 114,0 96,0 45,0 51825
10,8 mm 0.4252 M12 X 1,25 12,0 162,0 114,0 96,0 45,0 63653
10,9 mm 0.4291 12,0 162,0 114,0 96,0 45,0 63654
11,0 mm 0.4331 M12 X 1 12,0 162,0 114,0 96,0 45,0 63655
11,1 mm 0.4370 12,0 162,0 114,0 96,0 45,0 63656
7/16 0.4375 1/4-18NPT 12,0 162,0 114,0 96,0 45,0 51826
11,2 mm 0.4409 12,0 162,0 114,0 96,0 45,0 63657
11,3 mm 0.4449 12,0 162,0 114,0 96,0 45,0 63658
11,4 mm 0.4488 12,0 162,0 114,0 96,0 45,0 63659
11,5 mm 0.4528 M12 X 0,5 12,0 162,0 114,0 96,0 45,0 63660
11,6 mm 0.4567 12,0 162,0 114,0 96,0 45,0 63661
11,7 mm 0.4606 12,0 162,0 114,0 96,0 45,0 63662
11,8 mm 0.4646 12,0 162,0 114,0 96,0 45,0 63663
11,9 mm 0.4685 12,0 162,0 114,0 96,0 45,0 63664
15/32 0.4688 1/2-28 12,0 162,0 114,0 96,0 45,0 51827
12,0 mm 0.4724 M14 X 2 12,0 162,0 114,0 96,0 45,0 63665
31/64 0.4844 9/16-12 14,0 178,0 133,0 112,0 45,0 51828
12,5 mm 0.4921 M14 X 1,5 14,0 178,0 133,0 112,0 45,0 63666
TOLERANCES (inch)
DIAMETER D
1
D
2
≥ 1/8 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
(continued on next page)
30°140°
L
1
L
2
L
3
L
4
D
2
D
1
www.sgstool.com
37
TOLERANCES (inch)
DIAMETER D
1
D
2
≥ 1/8 - 1/4 +0.0002 / –0.0006 h6
> 1/4 - 3/8 +0.0002 / –0.0008 h6
> 3/8 - 3/4 +0.0003 / –0.0010 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
≤ 3 +0,0025 / –0,0127 h6
> 3 - 6 +0,0050 / –0,0152 h6
> 6 - 10 +0,0050 / –0,0200 h6
> 10 - 18 +0,0076 / –0,0254 h6
> 18 - 30 +0,0076 / –0,0279 h6
Series 140 8xD
|
Internal Coolant Drills
SERIES 140
8xD
(continued)
Cutting
Diameter
D
1
Decimal
Equivalent
Tap Size
Reference
Only
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
Min. Cleared
Length
L
3
Shank
Length
L
4
Ti-NAMITE-A
(AlTiN)
EDP No.
1/2 0.5000 14,0 178,0 133,0 112,0 45,0 51829
12,8 mm 0.5039 M14 X 1,25 14,0 178,0 133,0 112,0 45,0 63667
13,0 mm 0.5118 M14 X 1 14,0 178,0 133,0 112,0 45,0 63668
33/64 0.5156 9/16-18 14,0 178,0 133,0 112,0 45,0 51830
13,5 mm 0.5315 5/8-11 14,0 178,0 133,0 112,0 45,0 63669
13,8 mm 0.5433 14,0 178,0 133,0 112,0 45,0 63670
14,0 mm 0.5512 M16 X 2 14,0 178,0 133,0 112,0 45,0 63671
9/16 0.5625 16,0 203,0 152,0 128,0 48,0 51831
14,5 mm 0.5709 M16 X 1,5 16,0 203,0 152,0 128,0 48,0 63672
37/64 0.5781 5/8-18 16,0 203,0 152,0 128,0 48,0 51832
14,8 mm 0.5827 16,0 203,0 152,0 128,0 48,0 63673
15,0 mm 0.5906 M16 X 1 16,0 203,0 152,0 128,0 48,0 63674
15,5 mm 0.6102 M18 X 2,5 16,0 203,0 152,0 128,0 48,0 63675
15,8 mm 0.6220 16,0 203,0 152,0 128,0 48,0 63676
5/8 0.6250 11/16-16 16,0 203,0 152,0 128,0 48,0 51833
16,0 mm 0.6299 16,0 203,0 152,0 128,0 48,0 63677
21/32 0.6562 3/4-10 18,0 222,0 171,0 144,0 48,0 51834
11/16 0.6875 3/4-16 18,0 222,0 171,0 144,0 48,0 51835
3/4 0.7500 13/16-16 20,0 243,0 190,0 160,0 50,0 51836
30°140°
L
1
L
2
L
3
L
4
D
2
D
1
www.sgstool.com
38
Fractional
|
Speed & Feed Recommendations
Series
140 5D
Fractional
Hardness
(Brinell)
Vc
(SFM)
Diameter (D
1
)
(inch)
1/8 3/16 1/4 3/8 1/2 5/8 3/4
P
CARBON STEELS
1018, 1040, 1080, 1090, 10L50,
1140, 1212, 12L15, 1525, 1536
≤ 175
425 RPM 12988 8659 6494 4329 3247 2598 2165
(340-510)
Fr 0.0039 0.0059 0.0079 0.0118 0.0157 0.0196 0.0236
Feed (IPM) 51.0 51.0 51.0 51.0 51.0 51.0 51.0
> 175
≤ 275
380 RPM 11613 7742 5806 3871 2903 2323 1935
(304-456)
Fr 0.0035 0.0053 0.0071 0.0106 0.0141 0.0177 0.0212
Feed (IPM) 41.0 41.0 41.0 41.0 41.0 41.0 41.0
> 275
≤ 425
220 RPM 6723 4482 3362 2241 1681 1345 1121
(176-264)
Fr 0.0030 0.0045 0.0059 0.0089 0.0119 0.0149 0.0178
Feed (IPM) 20.0 20.0 20.0 20.0 20.0 20.0 20.0
P
ALLOY STEELS
4140, 4150, 4320, 5120,
5150, 8630, 86L20, 50100
≤ 275
330 RPM 10085 6723 5042 3362 2521 2017 1681
(264-396)
Fr 0.0030 0.0045 0.0059 0.0089 0.0119 0.0149 0.0178
Feed (IPM) 30.0 30.0 30.0 30.0 30.0 30.0 30.0
> 275
≤ 375
200 RPM 6112 4075 3056 2037 1528 1222 1019
(160-240)
Fr 0.0025 0.0038 0.0051 0.0076 0.0101 0.0127 0.0152
Feed (IPM) 15.5 15.5 15.5 15.5 15.5 15.5 15.5
> 375
≤ 450
140 RPM 4278 2852 2139 1426 1070 856 713
(112-168)
Fr 0.0018 0.0027 0.0036 0.0054 0.0072 0.0090 0.0108
Feed (IPM) 7.7 7.7 7.7 7.7 7.7 7.7 7.7
P
TOOL STEELS
A2, D2, H13, L2, M2,
P20, S7, T15, W2
≤ 200
145 RPM 4431 2954 2216 1477 1108 886 739
(116-174)
Fr 0.0026 0.0039 0.0052 0.0078 0.0104 0.0130 0.0156
Feed (IPM) 11.5 11.5 11.5 11.5 11.5 11.5 11.5
> 200
≤ 375
95 RPM 2903 1935 1452 968 726 581 484
(76-114)
Fr 0.0012 0.0018 0.0024 0.0036 0.0048 0.0060 0.0072
Feed (IPM) 3.5 3.5 3.5 3.5 3.5 3.5 3.5
> 375
≤ 475
85 RPM 2598 1732 1299 866 649 520 433
(68-102)
Fr 0.0008 0.0012 0.0015 0.0023 0.0031 0.0038 0.0046
Feed (IPM) 2.0 2.0 2.0 2.0 2.0 2.0 2.0
K
CAST IRONS
Gray, Malleable, Ductile
≤ 220
360 RPM 11002 7334 5501 3667 2750 2200 1834
(288-432)
Fr 0.0045 0.0068 0.0091 0.0136 0.0182 0.0227 0.0273
Feed (IPM) 50.0 50.0 50.0 50.0 50.0 50.0 50.0
> 220
≤ 260
335 RPM 10238 6825 5119 3413 2559 2048 1706
(268-402)
Fr 0.0045 0.0068 0.0091 0.0136 0.0182 0.0227 0.0273
Feed (IPM) 46.5 46.5 46.5 46.5 46.5 46.5 46.5
M
STAINLESS STEELS
(FREE MACHINING)
303, 416, 420F, 430F, 440F
≤ 185
305 RPM 9321 6214 4660 3107 2330 1864 1553
(244-366)
Fr 0.0026 0.0039 0.0051 0.0077 0.0103 0.0129 0.0154
Feed (IPM) 24.0 24.0 24.0 24.0 24.0 24.0 24.0
> 185
≤ 275
195 RPM 5959 3973 2980 1986 1490 1192 993
(156-234)
Fr 0.0020 0.0030 0.0040 0.0060 0.0081 0.0101 0.0121
Feed (IPM) 12.0 12.0 12.0 12.0 12.0 12.0 12.0
M
STAINLESS STEELS
(DIFFICULT)
304, 316, 321, 13-8 PH,
15-5PH, 17-4 PH, CUSTOM 450
≤ 275
150 RPM 4584 3056 2292 1528 1146 917 764
(120-180)
Fr 0.0020 0.0030 0.0040 0.0060 0.0079 0.0099 0.0119
Feed (IPM) 9.1 9.1 9.1 9.1 9.1 9.1 9.1
> 275
≤ 375
110 RPM 3362 2241 1681 1121 840 672 560
(88-132)
Fr 0.0018 0.0027 0.0036 0.0054 0.0071 0.0089 0.0107
Feed (IPM) 6.0 6.0 6.0 6.0 6.0 6.0 6.0
continued on next page
www.sgstool.com
39
Fractional
|
Speed & Feed Recommendations
Tool Wizard
CALCULATE APPLICATION PARAMETERS
www.sgstool.com
Series
140 5D
Fractional
Hardness
(Brinell)
Vc
(SFM)
Diameter (D
1
)
(inch)
1/8 3/16 1/4 3/8 1/2 5/8 3/4
S
SUPER ALLOYS
(NICKEL , COBALT,
IRON BASE)
Inconel 601, 617, 625, Incoloy,
Monel 400, Rene, Waspaloy
≤ 300
95 RPM 2903 1935 1452 968 726 581 484
(76-114)
Fr 0.0008 0.0012 0.0016 0.0024 0.0032 0.0040 0.0048
Feed (IPM) 2.3 2.3 2.3 2.3 2.3 2.3 2.3
> 300
≤ 400
50 RPM 1528 1019 764 509 382 306 255
(40-60)
Fr 0.0007 0.0010 0.0013 0.0020 0.0026 0.0033 0.0039
Feed (IPM) 1.0 1.0 1.0 1.0 1.0 1.0 1.0
S
TITANIUM ALLOYS
Pure Ttanium, Ti6Al4V,
Ti6Al2Sn4Zr2Mo,
Ti4Al4Mo2Sn0.5Si,
Ti-6Al4V
≤ 275
215 RPM 6570 4380 3285 2190 1643 1314 1095
(172-258)
Fr 0.0018 0.0026 0.0035 0.0053 0.0070 0.0088 0.0105
Feed (IPM) 11.5 11.5 11.5 11.5 11.5 11.5 11.5
> 275
≤ 350
160 RPM 4890 3260 2445 1630 1222 978 815
(128-192)
Fr 0.0016 0.0024 0.0032 0.0048 0.0064 0.0080 0.0096
Feed (IPM) 7.8 7.8 7.8 7.8 7.8 7.8 7.8
> 350
≤ 440
85 RPM 2598 1732 1299 866 649 520 433
(68-102)
Fr 0.0012 0.0018 0.0024 0.0036 0.0048 0.0060 0.0072
Feed (IPM) 3.1 3.1 3.1 3.1 3.1 3.1 3.1
N
ALUMINUM ALLOYS
2017, 2024, 356,
6061, 7075
≤ 80
770 RPM 23531 15687 11766 7844 5883 4706 3922
(616-924)
Fr 0.0049 0.0073 0.0098 0.0147 0.0195 0.0244 0.0293
Feed (IPM) 115.0 115.0 115.0 115.0 115.0 115.0 115.0
> 80
660 RPM 20170 13446 10085 6723 5042 4034 3362
(528-792)
Fr 0.0050 0.0074 0.0099 0.0149 0.0198 0.0248 0.0297
Feed (IPM) 100.0 100.0 100.0 100.0 100.0 100.0 100.0
N
COPPER ALLOYS
Alum Bronze, C110,
Muntz Brass
≤ 140
550 RPM 16808 11205 8404 5603 4202 3362 2801
(440-660)
Fr 0.0020 0.0030 0.0040 0.0060 0.0080 0.0100 0.0120
Feed (IPM) 33.5 33.5 33.5 33.5 33.5 33.5 33.5
> 140
440 RPM 13446 8964 6723 4482 3362 2689 2241
(352-528)
Fr 0.0020 0.0030 0.0040 0.0060 0.0080 0.0100 0.0120
Feed (IPM) 27.0 27.0 27.0 27.0 27.0 27.0 27.0
Note:
•  rpm = sfm x 3.82 / D
1
•  ipm = (inch / revolution) x rpm
•  reduce speed and feed for materials harder than listed
•  refer to the SGS Tool Wizard for complete technical information (www.sgstool.com)
www.sgstool.com
40
Metric
|
Speed & Feed Recommendations
Series
140M 5D
Metric
Hardness
(Brinell)
Vc
(m/min)
Diameter (D
1
)
(mm)
3 6 8 10 12 14 16
P
CARBON STEELS
1018, 1040, 1080, 1090, 10L50,
1140, 1212, 12L15, 1525, 1536
≤ 175
130 RPM 13733 6867 5150 4120 3433 2943 2575
(104-155)
Fr 0.095 0.189 0.252 0.316 0.379 0.442 0.505
Feed (mm/min) 1300 1300 1300 1300 1300 1300 1300
> 175
≤ 275
116 RPM 12279 6140 4605 3684 3070 2631 2302
(93-139)
Fr 0.086 0.171 0.228 0.285 0.342 0.399 0.456
Feed (mm/min) 1050 1050 1050 1050 1050 1050 1050
> 275
≤ 425
67 RPM 7109 3555 2666 2133 1777 1523 1333
(54-80)
Fr 0.071 0.142 0.189 0.237 0.284 0.332 0.379
Feed (mm/min) 505 505 505 505 505 505 505
P
ALLOY STEELS
4140, 4150, 4320, 5120,
5150, 8630, 86L20, 50100
≤ 275
101 RPM 10664 5332 3999 3199 2666 2285 1999
(80-121)
Fr 0.071 0.143 0.190 0.238 0.285 0.333 0.380
Feed (mm/min) 760 760 760 760 760 760 760
> 275
≤ 375
61 RPM 6463 3231 2424 1939 1616 1385 1212
(49-73)
Fr 0.062 0.124 0.165 0.206 0.248 0.289 0.330
Feed (mm/min) 400 400 400 400 400 400 400
> 375
≤ 450
43 RPM 4524 2262 1696 1357 1131 969 848
(34-51)
Fr 0.043 0.086 0.115 0.144 0.172 0.201 0.230
Feed (mm/min) 195 195 195 195 195 195 195
P
TOOL STEELS
A2, D2, H13, L2, M2,
P20, S7, T15, W2
≤ 200
44 RPM 4686 2343 1757 1406 1171 1004 879
(35-53)
Fr 0.061 0.122 0.162 0.203 0.243 0.284 0.324
Feed (mm/min) 285 285 285 285 285 285 285
> 200
≤ 375
29 RPM 3070 1535 1151 921 767 658 576
(23-35)
Fr 0.029 0.059 0.078 0.098 0.117 0.137 0.156
Feed (mm/min) 90 90 90 90 90 90 90
> 375
≤ 475
26 RPM 2747 1373 1030 824 687 589 515
(21-31)
Fr 0.018 0.036 0.049 0.061 0.073 0.085 0.097
Feed (mm/min) 50 50 50 50 50 50 50
K
CAST IRONS
Gray, Malleable, Ductile
≤ 220
110 RPM 11633 5816 4362 3490 2908 2493 2181
(88-132)
Fr 0.109 0.218 0.291 0.364 0.437 0.509 0.582
Feed (mm/min) 1270 1270 1270 1270 1270 1270 1270
> 220
≤ 260
102 RPM 10825 5413 4059 3248 2706 2320 2030
(82-123)
Fr 0.109 0.218 0.291 0.363 0.436 0.509 0.581
Feed (mm/min) 1180 1180 1180 1180 1180 1180 1180
M
STAINLESS STEELS
(FREE MACHINING)
303, 416, 420F, 430F, 440F
≤ 185
93 RPM 9856 4928 3696 2957 2464 2112 1848
(74-112)
Fr 0.061 0.123 0.164 0.205 0.246 0.286 0.327
Feed (mm/min) 605 605 605 605 605 605 605
> 185
≤ 275
59 RPM 6301 3151 2363 1890 1575 1350 1181
(48-71)
Fr 0.048 0.095 0.127 0.159 0.190 0.222 0.254
Feed (mm/min) 300 300 300 300 300 300 300
M
STAINLESS STEELS
(DIFFICULT)
304, 316, 321, 13-8 PH,
15-5PH, 17-4 PH, CUSTOM 450
≤ 275
46 RPM 4847 2424 1818 1454 1212 1039 909
(37-55)
Fr 0.047 0.095 0.127 0.158 0.190 0.221 0.253
Feed (mm/min) 230 230 230 230 230 230 230
> 275
≤ 375
34 RPM 3555 1777 1333 1066 889 762 666
(27-40)
Fr 0.042 0.084 0.113 0.141 0.169 0.197 0.225
Feed (mm/min) 150 150 150 150 150 150 150
continued on next page
www.sgstool.com
41
Metric
|
Speed & Feed Recommendations
Tool Wizard
CALCULATE APPLICATION PARAMETERS
www.sgstool.com
Series
140M 5D
Metric
Hardness
(Brinell)
Vc
(m/min)
Diameter (D
1
)
(mm)
3 6 8 10 12 14 16
S
SUPER ALLOYS
(NICKEL , COBALT,
IRON BASE)
Inconel 601, 617, 625, Incoloy,
Monel 400, Rene, Waspaloy
≤ 300
29 RPM 3070 1535 1151 921 767 658 576
(23-35)
Fr 0.020 0.039 0.052 0.065 0.078 0.091 0.104
Feed (mm/min) 60 60 60 60 60 60 60
> 300
≤ 400
15 RPM 1616 808 606 485 404 346 303
(12-18)
Fr 0.015 0.031 0.041 0.052 0.062 0.072 0.083
Feed (mm/min) 25 25 25 25 25 25 25
S
TITANIUM ALLOYS
Pure Ttanium, Ti6Al4V,
Ti6Al2Sn4Zr2Mo,
Ti4Al4Mo2Sn0.5Si,
Ti-6Al4V
≤ 275
66 RPM 6947 3474 2605 2084 1737 1489 1303
(52-79)
Fr 0.040 0.079 0.106 0.132 0.158 0.185 0.211
Feed (mm/min) 275 275 275 275 275 275 275
> 275
≤ 350
49 RPM 5170 2585 1939 1551 1293 1108 969
(39-59)
Fr 0.039 0.077 0.103 0.129 0.155 0.181 0.206
Feed (mm/min) 200 200 200 200 200 200 200
> 350
≤ 440
26 RPM 2747 1373 1030 824 687 589 515
(21-31)
Fr 0.029 0.058 0.078 0.097 0.117 0.136 0.155
Feed (mm/min) 80 80 80 80 80 80 80
N
ALUMINUM ALLOYS
2017, 2024, 356,
6061, 7075
≤ 80
235 RPM 24882 12441 9331 7465 6220 5332 4665
(188-282)
Fr 0.118 0.237 0.316 0.395 0.473 0.552 0.631
Feed (mm/min) 2945 2945 2945 2945 2945 2945 2945
> 80
201 RPM 21327 10664 7998 6398 5332 4570 3999
(161-241)
Fr 0.119 0.238 0.318 0.397 0.476 0.556 0.635
Feed (mm/min) 2540 2540 2540 2540 2540 2540 2540
N
COPPER ALLOYS
Alum Bronze, C110,
Muntz Brass
≤ 140
168 RPM 17773 8886 6665 5332 4443 3808 3332
(134-201)
Fr 0.048 0.096 0.128 0.159 0.191 0.223 0.255
Feed (mm/min) 850 850 850 850 850 850 850
> 140
134 RPM 14218 7109 5332 4265 3555 3047 2666
(107-161)
Fr 0.048 0.096 0.128 0.161 0.193 0.225 0.257
Feed (mm/min) 685 685 685 685 685 685 685
Note:
•  rpm = (1000 x m / min) / (3.14 x D
1
)
•  mm / min = (mm / revolution) x rpm
•  reduce speed and feed for materials harder than listed
•  refer to the SGS Tool Wizard for complete technical information (www.sgstool.com)
www.sgstool.com
42
Fractional
|
Speed & Feed Recommendations
Series
140 8D
Fractional
Hardness
(Brinell)
Vc
(SFM)
Diameter (D
1
)
(inch)
1/8 3/16 1/4 3/8 1/2 5/8 3/4
P
CARBON STEELS
1018, 1040, 1080, 1090, 10L50,
1140, 1212, 12L15, 1525, 1536
≤ 175
405 RPM 12377 8251 6188 4126 3094 2475 2063
(324-486)
Fr 0.0036 0.0053 0.0071 0.0107 0.0142 0.0178 0.0213
Feed (IPM) 44.0 44.0 44.0 44.0 44.0 44.0 44.0
> 175
≤ 275
370 RPM 11307 7538 5654 3769 2827 2261 1885
(296-444)
Fr 0.0030 0.0045 0.0060 0.0090 0.0120 0.0150 0.0180
Feed (IPM) 34.0 34.0 34.0 34.0 34.0 34.0 34.0
> 275
≤ 425
210 RPM 6418 4278 3209 2139 1604 1284 1070
(168-252)
Fr 0.0026 0.0039 0.0051 0.0077 0.0103 0.0129 0.0154
Feed (IPM) 16.5 16.5 16.5 16.5 16.5 16.5 16.5
P
ALLOY STEELS
4140, 4150, 4320, 5120,
5150, 8630, 86L20, 50100
≤ 275
320 RPM 9779 6519 4890 3260 2445 1956 1630
(256-384)
Fr 0.0026 0.0038 0.0051 0.0077 0.0102 0.0128 0.0153
Feed (IPM) 25.0 25.0 25.0 25.0 25.0 25.0 25.0
> 275
≤ 375
190 RPM 5806 3871 2903 1935 1452 1161 968
(152-228)
Fr 0.0020 0.0030 0.0040 0.0059 0.0079 0.0099 0.0119
Feed (IPM) 11.5 11.5 11.5 11.5 11.5 11.5 11.5
> 375
≤ 450
135 RPM 4126 2750 2063 1375 1031 825 688
(108-162)
Fr 0.0016 0.0024 0.0032 0.0047 0.0063 0.0079 0.0095
Feed (IPM) 6.5 6.5 6.5 6.5 6.5 6.5 6.5
P
TOOL STEELS
A2, D2, H13, L2, M2,
P20, S7, T15, W2
≤ 200
140 RPM 4278 2852 2139 1426 1070 856 713
(112-168)
Fr 0.0020 0.0030 0.0040 0.0060 0.0079 0.0099 0.0119
Feed (IPM) 8.5 8.5 8.5 8.5 8.5 8.5 8.5
> 200
≤ 375
90 RPM 2750 1834 1375 917 688 550 458
(72-108)
Fr 0.0011 0.0016 0.0022 0.0033 0.0044 0.0055 0.0065
Feed (IPM) 3.0 3.0 3.0 3.0 3.0 3.0 3.0
> 375
≤ 475
80 RPM 2445 1630 1222 815 611 489 407
(64-96)
Fr 0.0006 0.0009 0.0012 0.0018 0.0025 0.0031 0.0037
Feed (IPM) 1.5 1.5 1.5 1.5 1.5 1.5 1.5
K
CAST IRONS
Gray, Malleable, Ductile
≤ 220
350 RPM 10696 7131 5348 3565 2674 2139 1783
(280-420)
Fr 0.0037 0.0056 0.0075 0.0112 0.0150 0.0187 0.0224
Feed (IPM) 40.0 40.0 40.0 40.0 40.0 40.0 40.0
> 220
≤ 260
310 RPM 9474 6316 4737 3158 2368 1895 1579
(248-372)
Fr 0.0039 0.0059 0.0078 0.0117 0.0156 0.0195 0.0234
Feed (IPM) 37.0 37.0 37.0 37.0 37.0 37.0 37.0
M
STAINLESS STEELS
(FREE MACHINING)
303, 416, 420F, 430F, 440F
≤ 185
290 RPM 8862 5908 4431 2954 2216 1772 1477
(232-348)
Fr 0.0020 0.0030 0.0039 0.0059 0.0079 0.0099 0.0118
Feed (IPM) 17.5 17.5 17.5 17.5 17.5 17.5 17.5
> 185
≤ 275
180 RPM 5501 3667 2750 1834 1375 1100 917
(144-216)
Fr 0.0018 0.0027 0.0036 0.0055 0.0073 0.0091 0.0109
Feed (IPM) 10.0 10.0 10.0 10.0 10.0 10.0 10.0
M
STAINLESS STEELS
(DIFFICULT)
304, 316, 321, 13-8 PH,
15-5PH, 17-4 PH, CUSTOM 450
≤ 275
130 RPM 3973 2649 1986 1324 993 795 662
(104-156)
Fr 0.0018 0.0026 0.0035 0.0053 0.0070 0.0088 0.0106
Feed (IPM) 7.0 7.0 7.0 7.0 7.0 7.0 7.0
> 275
≤ 375
95 RPM 2903 1935 1452 968 726 581 484
(76-114)
Fr 0.0016 0.0023 0.0031 0.0047 0.0062 0.0078 0.0093
Feed (IPM) 4.5 4.5 4.5 4.5 4.5 4.5 4.5
continued on next page
www.sgstool.com
43
Fractional
|
Speed & Feed Recommendations
Tool Wizard
CALCULATE APPLICATION PARAMETERS
www.sgstool.com
Series
140 8D
Fractional
Hardness
(Brinell)
Vc
(SFM)
Diameter (D
1
)
(inch)
1/8 3/16 1/4 3/8 1/2 5/8 3/4
S
SUPER ALLOYS
(NICKEL , COBALT,
IRON BASE)
Inconel 601, 617, 625, Incoloy,
Monel 400, Rene, Waspaloy
≤ 300
65 RPM 1986 1324 993 662 497 397 331
(52-78)
Fr 0.0009 0.0013 0.0017 0.0026 0.0034 0.0043 0.0051
Feed (IPM) 1.7 1.7 1.7 1.7 1.7 1.7 1.7
> 300
≤ 400
35 RPM 1070 713 535 357 267 214 178
(28-42)
Fr 0.0006 0.0008 0.0011 0.0017 0.0022 0.0028 0.0034
Feed (IPM) 0.6 0.6 0.6 0.6 0.6 0.6 0.6
S
TITANIUM ALLOYS
Pure Ttanium, Ti6Al4V,
Ti6Al2Sn4Zr2Mo,
Ti4Al4Mo2Sn0.5Si,
Ti-6Al4V
≤ 275
185 RPM 5654 3769 2827 1885 1413 1131 942
(148-222)
Fr 0.0016 0.0024 0.0032 0.0048 0.0064 0.0080 0.0096
Feed (IPM) 9.0 9.0 9.0 9.0 9.0 9.0 9.0
> 275
≤ 350
140 RPM 4278 2852 2139 1426 1070 856 713
(112-168)
Fr 0.0012 0.0018 0.0023 0.0035 0.0047 0.0058 0.0070
Feed (IPM) 5.0 5.0 5.0 5.0 5.0 5.0 5.0
> 350
≤ 440
75 RPM 2292 1528 1146 764 573 458 382
(60-90)
Fr 0.0010 0.0015 0.0020 0.0030 0.0040 0.0050 0.0060
Feed (IPM) 2.3 2.3 2.3 2.3 2.3 2.3 2.3
N
ALUMINUM ALLOYS
2017, 2024, 356,
6061, 7075
≤ 80
730 RPM 22309 14873 11154 7436 5577 4462 3718
(584-876)
Fr 0.0045 0.0067 0.0090 0.0134 0.0179 0.0224 0.0269
Feed (IPM) 100.0 100.0 100.0 100.0 100.0 100.0 100.0
> 80
635 RPM 19406 12937 9703 6469 4851 3881 3234
(508-762)
Fr 0.0046 0.0070 0.0093 0.0139 0.0186 0.0232 0.0278
Feed (IPM) 90.0 90.0 90.0 90.0 90.0 90.0 90.0
N
COPPER ALLOYS
Alum Bronze, C110,
Muntz Brass
≤ 100
255 RPM 7793 5195 3896 2598 1948 1559 1299
(204-306)
Fr 0.0018 0.0027 0.0036 0.0054 0.0072 0.0090 0.0108
Feed (IPM) 14.0 14.0 14.0 14.0 14.0 14.0 14.0
≤ 200
235 RPM 7182 4788 3591 2394 1795 1436 1197
(188-282)
Fr 0.0018 0.0027 0.0036 0.0054 0.0072 0.0091 0.0109
Feed (IPM) 13.0 13.0 13.0 13.0 13.0 13.0 13.0
Note:
•  rpm = sfm x 3.82 / D
1
•  ipm = (inch / revolution) x rpm
•  reduce speed and feed for materials harder than listed
•  refer to the SGS Tool Wizard for complete technical information (www.sgstool.com)
www.sgstool.com
44
Metric
|
Speed & Feed Recommendations
Series
140M 8D
Metric
Hardness
(Brinell)
Vc
(m/min)
Diameter (D
1
)
(mm)
3 6 8 10 12 14 16
P
CARBON STEELS
1018, 1040, 1080, 1090, 10L50,
1140, 1212, 12L15, 1525, 1536
≤ 175
123 RPM 13087 6544 4908 3926 3272 2804 2454
(100-170)
Fr 0.085 0.171 0.228 0.285 0.342 0.399 0.455
Feed (mm/min) 1118 1118 1118 1118 1118 1118 1118
> 175
≤ 275
113 RPM 11956 5978 4484 3587 2989 2562 32
(90-135)
Fr 0.072 0.144 0.193 0.241 0.289 0.337 26.908
Feed (mm/min) 864 864 864 864 864 864 864
> 275
≤ 425
64 RPM 6786 3393 2545 2036 1696 1454 1272
(51-77)
Fr 0.062 0.124 0.165 0.206 0.247 0.288 0.329
Feed (mm/min) 419 419 419 419 419 419 419
P
ALLOY STEELS
4140, 4150, 4320, 5120,
5150, 8630, 86L20, 50100
≤ 275
98 RPM 10340 5170 3878 3102 2585 2216 1939
(78-117)
Fr 0.061 0.123 0.164 0.205 0.246 0.287 0.328
Feed (mm/min) 635 635 635 635 635 635 635
> 275
≤ 375
58 RPM 6140 3070 2302 1842 1535 1316 1151
(46-69)
Fr 0.048 0.095 0.127 0.159 0.190 0.222 0.254
Feed (mm/min) 292 292 292 292 292 292 292
> 375
≤ 450
41 RPM 4362 2181 1636 1309 1091 935 818
(33-49)
Fr 0.038 0.076 0.101 0.126 0.151 0.177 0.202
Feed (mm/min) 165 165 165 165 165 165 165
P
TOOL STEELS
A2, D2, H13, L2, M2,
P20, S7, T15, W2
≤ 200
43 RPM 4524 2262 1696 1357 1131 969 848
(34-51)
Fr 0.048 0.095 0.127 0.159 0.191 0.223 0.255
Feed (mm/min) 216 216 216 216 216 216 216
> 200
≤ 375
27 RPM 2908 1454 1091 872 727 623 545
(22-33)
Fr 0.026 0.052 0.070 0.087 0.105 0.122 0.140
Feed (mm/min) 76 76 76 76 76 76 76
> 375
≤ 475
24 RPM 2585 1293 969 776 646 554 485
(20-29)
Fr 0.015 0.029 0.039 0.049 0.059 0.069 0.079
Feed (mm/min) 38 38 38 38 38 38 38
K
CAST IRONS
Gray, Malleable, Ductile
≤ 220
107 RPM 11310 5655 4241 3393 2827 2424 2121
(85-128)
Fr 0.090 0.180 0.240 0.299 0.359 0.419 0.479
Feed (mm/min) 1016 1016 1016 1016 1016 1016 1016
> 220
≤ 260
94 RPM 10017 5009 3756 3005 2504 2147 1878
(76-113)
Fr 0.094 0.188 0.250 0.313 0.375 0.438 0.500
Feed (mm/min) 940 940 940 940 940 940 940
M
STAINLESS STEELS
(FREE MACHINING)
303, 416, 420F, 430F, 440F
≤ 185
88 RPM 9371 4686 3514 2811 2343 2008 1757
(71-106)
Fr 0.047 0.095 0.126 0.158 0.190 0.221 0.253
Feed (mm/min) 445 445 445 445 445 445 445
> 185
≤ 275
55 RPM 5816 2908 2181 1745 1454 1246 1091
(44-66)
Fr 0.044 0.087 0.116 0.146 0.175 0.204 0.233
Feed (mm/min) 254 254 254 254 254 254 254
M
STAINLESS STEELS
(DIFFICULT)
304, 316, 321, 13-8 PH,
15-5PH, 17-4 PH, CUSTOM 450
≤ 275
40 RPM 4201 2100 1575 1260 1050 900 788
(32-48)
Fr 0.042 0.085 0.113 0.141 0.169 0.198 0.226
Feed (mm/min) 178 178 178 178 178 178 178
> 275
≤ 375
29 RPM 3070 1535 1151 921 767 658 576
(23-35)
Fr 0.037 0.074 0.099 0.124 0.149 0.174 0.199
Feed (mm/min) 114 114 114 114 114 114 114
continued on next page
www.sgstool.com
45
Tool Wizard
CALCULATE APPLICATION PARAMETERS
www.sgstool.com
Metric
|
Speed & Feed Recommendations
Series
140M 8D
Metric
Hardness
(Brinell)
Vc
(m/min)
Diameter (D
1
)
(mm)
3 6 8 10 12 14 16
S
SUPER ALLOYS
(NICKEL , COBALT,
IRON BASE)
Inconel 601, 617, 625, Incoloy,
Monel 400, Rene, Waspaloy
≤ 300
20 RPM 2100 1050 788 630 525 450 394
(16-24)
Fr 0.021 0.041 0.055 0.069 0.082 0.096 0.110
Feed (mm/min) 43 43 43 43 43 43 43
> 300
≤ 400
11 RPM 1131 565 424 339 283 242 212
(9-13)
Fr 0.013 0.027 0.036 0.045 0.054 0.063 0.072
Feed (mm/min) 15 15 15 15 15 15 15
S
TITANIUM ALLOYS
Pure Ttanium, Ti6Al4V,
Ti6Al2Sn4Zr2Mo,
Ti4Al4Mo2Sn0.5Si,
Ti-6Al4V
≤ 275
56 RPM 5978 2989 2242 1793 1495 1281 1121
(45-68)
Fr 0.038 0.076 0.102 0.127 0.153 0.178 0.204
Feed (mm/min) 229 229 229 229 229 229 229
> 275
≤ 350
43 RPM 4524 2262 1696 1357 1131 969 848
(34-51)
Fr 0.028 0.056 0.075 0.094 0.112 0.131 0.150
Feed (mm/min) 127 127 127 127 127 127 127
> 350
≤ 440
23 RPM 2424 1212 909 727 606 519 454
(18-27)
Fr 0.024 0.048 0.064 0.080 0.096 0.112 0.129
Feed (mm/min) 58 58 58 58 58 58 58
N
ALUMINUM ALLOYS
2017, 2024, 356,
6061, 7075
≤ 80
223 RPM 23589 11795 8846 7077 5897 5055 4423
(178-267)
Fr 0.108 0.215 0.287 0.359 0.431 0.502 0.574
Feed (mm/min) 2540 2540 2540 2540 2540 2540 2540
> 80
194 RPM 20519 10260 7695 6156 5130 4397 3847
(155-232)
Fr 0.111 0.223 0.297 0.371 0.446 0.520 0.594
Feed (mm/min) 2286 2286 2286 2286 2286 2286 2286
N
COPPER ALLOYS
Alum Bronze, C110,
Muntz Brass
≤ 140
78 RPM 8240 4120 3090 2472 2060 1766 1545
(62-93)
Fr 0.043 0.086 0.115 0.144 0.173 0.201 0.230
Feed (mm/min) 356 356 356 356 356 356 356
> 140
72 RPM 7594 3797 2848 2278 1898 1627 1424
(57-86)
Fr 0.043 0.087 0.116 0.145 0.174 0.203 0.232
Feed (mm/min) 330 330 330 330 330 330 330
Note:
•  rpm = (1000 x m / min) / (3.14 x D
1
)
•  mm / min = (mm / revolution) x rpm
•  reduce speed and feed for materials harder than listed
•  refer to the SGS Tool Wizard for complete technical information (www.sgstool.com)
www.sgstool.com
46
Double margin construction design stabilized the drill for greater hole accuracy and improved
surface nish in nal hole.
Minimized delamination at hole entry/exit.
Manufactured exclusively with Di-NAMITE coating for even wear, extended tool life and
improved nishes.
PERFORMANCE.
PERFORMANCE. PRECISION. PASSION.
WITH SERIES 120 COMPOSITE DRILL
SERIES 120 COMPOSITE DRILL
The key features of the 8 Facet Double Angle Series
120 drill design offers application benets beyond that
of other high performance drills in its category. Each
feature of this 8 facet design was engineered as a
solution towards addressing the issues commonly
encountered during Composite drilling. This unique
High Performance design successfully creates an accu-
rate hole without splintering or delamination.
Solid Carbide Tools
A
B
DOUBLE MARGIN CONSTRUCTION
improves drill stability for better hole nish
and size control
allows coolant to reach the point for improved
hole quality and extended tool life
A
DOUBLE ANGLE POINT
minimizes workpiece delamination on drill
entry and exit
redistributes loads along multiple cutting
edges for improved performance
NOTCHED POINT
reduces cutting forces at the drill center
for enhanced performance and tool life
manufactured exclusively with Di-NAMITE
coating for even wear, extended tool life,
and improved nishes.
C
C
B
CRYSTALLINE DIAMOND COATING
®
www.sgstool.com
47
Double margin construction design stabilized the drill for greater hole accuracy and improved
surface nish in nal hole.
Minimized delamination at hole entry/exit.
Manufactured exclusively with Di-NAMITE coating for even wear, extended tool life and
improved nishes.
PERFORMANCE.
PERFORMANCE. PRECISION. PASSION.
WITH SERIES 120 COMPOSITE DRILL
SERIES 120 COMPOSITE DRILL
The key features of the 8 Facet Double Angle Series
120 drill design offers application benets beyond that
of other high performance drills in its category. Each
feature of this 8 facet design was engineered as a
solution towards addressing the issues commonly
encountered during Composite drilling. This unique
High Performance design successfully creates an accu-
rate hole without splintering or delamination.
Solid Carbide Tools
A
B
DOUBLE MARGIN CONSTRUCTION
improves drill stability for better hole nish
and size control
allows coolant to reach the point for improved
hole quality and extended tool life
A
DOUBLE ANGLE POINT
minimizes workpiece delamination on drill
entry and exit
redistributes loads along multiple cutting
edges for improved performance
NOTCHED POINT
reduces cutting forces at the drill center
for enhanced performance and tool life
manufactured exclusively with Di-NAMITE
coating for even wear, extended tool life,
and improved nishes.
C
C
B
CRYSTALLINE DIAMOND COATING
®
www.sgstool.com
48
PRECISION.
A test was conducted of our CFRP drill to determine the necessity of coating when drilling Carbon
Fiber material. Fifty holes were drilled using a special size .190” CFRP drill. The tool’s design produces
acceptable quality holes; but as shown in the photos, early edge wear on the uncoated drill resulted
in holes with frayed edges. The diamond coated drill produced all 50 holes with little to no fraying
and edge wear was 38% less than the uncoated drills.
The geometry of the 8 Facet drill with the Di-NAMITE coating is a necessity for additional tool life
and productivity when manufacturing Carbon Fiber material.
1ST HOLE 3RD HOLE 50TH HOLE AFTER 50 HOLES
50 holes.0001”
.190” CFRP drill
uncoated
1
TOOL NO.
TYPE
DESCRIPTION
TIR IN
MACHINE
USAGE
SPEED
5,000 rpm
FEED
5.0 ipm
DIAMETER
.190”
HOLE DEPTH
.240”
WORKPIECE
CFRP
MACHINE TYPE
Vertical Machining Center
COOLANT
none
Good hole quality for 1st 3 holes.
fraying starting by 3rd hole, .0021” wear
INSPECTION
NOTES
1ST HOLE 25TH HOLE 50TH HOLE AFTER 50 HOLES
50 holes.0002”
.190” CFRP drill
diamond
2
TOOL NO.
TYPE
DESCRIPTION
TIR IN
MACHINE
USAGE
Good hole quality all 50 holes
slight fraying, .0013” wear
INSPECTION
NOTES
PASSION.
The compound angle creates 4 cutting edges along the drill point.
Distinct double angle prevents abrasiveness of the Composite from localizing along the point
and diminishing tool life.
www.sgstool.com
49
PRECISION.
A test was conducted of our CFRP drill to determine the necessity of coating when drilling Carbon
Fiber material. Fifty holes were drilled using a special size .190” CFRP drill. The tool’s design produces
acceptable quality holes; but as shown in the photos, early edge wear on the uncoated drill resulted
in holes with frayed edges. The diamond coated drill produced all 50 holes with little to no fraying
and edge wear was 38% less than the uncoated drills.
The geometry of the 8 Facet drill with the Di-NAMITE coating is a necessity for additional tool life
and productivity when manufacturing Carbon Fiber material.
1ST HOLE 3RD HOLE 50TH HOLE AFTER 50 HOLES
50 holes.0001”
.190” CFRP drill
uncoated
1
TOOL NO.
TYPE
DESCRIPTION
TIR IN
MACHINE
USAGE
SPEED
5,000 rpm
FEED
5.0 ipm
DIAMETER
.190”
HOLE DEPTH
.240”
WORKPIECE
CFRP
MACHINE TYPE
Vertical Machining Center
COOLANT
none
Good hole quality for 1st 3 holes.
fraying starting by 3rd hole, .0021” wear
INSPECTION
NOTES
1ST HOLE 25TH HOLE 50TH HOLE AFTER 50 HOLES
50 holes.0002”
.190” CFRP drill
diamond
2
TOOL NO.
TYPE
DESCRIPTION
TIR IN
MACHINE
USAGE
Good hole quality all 50 holes
slight fraying, .0013” wear
INSPECTION
NOTES
PASSION.
The compound angle creates 4 cutting edges along the drill point.
Distinct double angle prevents abrasiveness of the Composite from localizing along the point
and diminishing tool life.
www.sgstool.com
50
SERIES 120
TOLERANCES (inch)
DIAMETER D
1
D
2
#40-1/2 +0.0000 / –0.0005 h6
TOLERANCES (mm)
DIAMETER D
1
D
2
2,7-12 +0,000 / –0,013 h6
Cutting
Diameter
D
1
Decimal
Equivalent
Shank
Diameter
D
2
Overall
Length
L
1
Flute
Length
L
2
/ L
3
Shank
Length
L
4
Di-NAMITE
(TD)
EDP No.
#40 0.0980 1/8 2 9/16 1-1/4 50000
2,7 mm 0.1063 6,0 63,0 20,0 32,0 50001
3,0 mm 0.1181 6,0 63,0 20,0 36,0 50002
1/8 0.1250 1/4 2-1/2 3/4 1-7/16 50003
3,2 mm 0.1260 6,0 63,0 20,0 36,0 50004
#30 0.1285 1/4 2-1/2 3/4 1-7/16 50005
#28 0.1405 1/4 2-1/2 3/4 1-7/16 50006
#22 0.1570 1/4 2-5/8 7/8 1-7/16 50007
#21 0.1590 1/4 2-5/8 7/8 1-7/16 50008
4,1 mm 0.1614 6,0 66,0 24,0 36,0 50009
#19 0.1660 1/4 2-5/8 7/8 1-7/16 50010
11/64 0.1719 1/4 2-5/8 7/8 1-7/16 5 0 011
3/16 0.1875 1/4 2-5/8 1 1-7/16 50012
# 11 0.1910 1/4 2-5/8 1 1-7/16 50013
#8 0.1990 1/4 2-5/8 1 1-7/16 50014
#7 0.2010 1/4 2-5/8 1 1-7/16 50015
#2 0.2210 1/4 2-5/8 1 1-7/16 50 016
6,0 mm 0.2362 6,0 66,0 28,0 36,0 50017
1/4 0.2500 1/4 3-1/8 1-5/16 1-7/16 50 018
.2510 0.2510 5/16 3-1/8 1-5/16 1-7/16 50 019
F 0.2570 5/16 3-1/8 1-5/16 1-7/16 50020
I 0.2720 5/16 3-1/8 1-5/16 1-7/16 50021
J 0.2770 5/16 3-1/8 1-5/16 1-7/16 50022
K 0.2810 5/16 3-1/8 1-9/16 1-7/16 50023
5/16 0.3125 5/16 3-1/8 1-9/16 1-7/16 50024
8,0 mm 0.3150 8,0 79,0 41,0 36,0 50025
3/8 0.3750 3/8 3-1/2 1-27/32 1-9/16 50026
V 0.3770 1/2 3-1/2 1-27/32 1-9/16 50027
10,0 mm 0.3937 10,0 89,0 47,0 40,0 50028
7/16 0.4375 1/2 4-1/4 2-3/16 1-9/16 50029
12,0 mm 0.4724 12,0 102,0 55,0 45,0 50030
1/2 0.5000 1/2 4-1/4 2-5/16 1-3/4 50031
Series 120
|
CFRP 8 Facet Drills
www.sgstool.com
51
Fractional & Metric
|
Speed & Feed Recommendations
Tool Wizard
CALCULATE APPLICATION PARAMETERS
www.sgstool.com
Series
120
Fractional
Vc
(SFM)
Diameter (D
1
)
(inch)
1/8 3/16 1/4 5/16 3/8 7/16 1/2
CFRP, AFRP
(CARBON FIBER,
ARAMID FIBER)
320 RPM 9779 6519 4890 3912 3260 2794 2445
(256-384)
Fr 0.0006 0.0008 0.0012 0.0015 0.0018 0.0021 0.0024
Feed (IPM) 5.9 5.2 5.9 5.9 5.9 5.9 5.9
GFRP
(FIBERGLASS)
240 RPM 7334 4890 3667 2934 2445 2096 1834
(192-288)
Fr 0.0006 0.0008 0.0012 0.0015 0.0018 0.0021 0.0024
Feed (IPM) 4.4 3.9 4.4 4.4 4.4 4.4 4.4
CARBON,
GRAPHITE
400 RPM 12224 8149 6112 4890 4075 3493 3056
(320-480)
Fr 0.0008 0.0012 0.0016 0.0020 0.0024 0.0028 0.0032
Feed (IPM) 9.8 9.8 9.8 9.8 9.8 9.8 9.8
Note:
•  rpm = sfm x 3.82 / D
1
•  ipm = (inch / revolution) x rpm
•  reduce speed and feed for materials harder than listed
•  refer to the SGS Tool Wizard for complete technical information (www.sgstool.com)
Series
120
Metric
Vc
(m/min)
Diameter (D
1
)
(mm)
2.5 3 4 6 8 10 12
CFRP, AFRP
(CARBON FIBER,
ARAMID FIBER)
100 RPM 12722 10602 7951 5301 3976 3181 2650
(80-120)
Fr 0.015 0.018 0.020 0.030 0.038 0.046 0.053
Feed (mm/min) 191 191 159 159 151 146 140
GFRP
(FIBERGLASS)
75 RPM 9542 7951 5963 3976 2982 2385 1988
(65-90)
Fr 0.015 0.018 0.020 0.030 0.038 0.046 0.053
Feed (mm/min) 143 143 119 119 113 110 105
CARBON,
GRAPHITE
120 RPM 15266 12722 9542 6361 4771 3817 3181
(96-144)
Fr 0.020 0.024 0.030 0.041 0.051 0.061 0.071
Feed (mm/min) 305 305 286 261 243 233 226
Note:
•  rpm = (1000 x m / min) / (3.14 x D
1
)
•  mm / min = (mm / revolution) x rpm
•  reduce speed and feed for materials harder than listed
•  refer to the SGS Tool Wizard for complete technical information (www.sgstool.com)
